Summit FFAR25L7CSS Instruction Manual

FFAR25L7CSS

20.25" x 17" x 19.13" (H x W x D)

Commercially approved compact all-refrigerator in white
with digital thermostat

Highlights:

Commercially listed to NSF-7 standards and meets UL-471
Stainless steel exterior offers long-lasting durability
Digital thermostat for easier and more precise temperature

management

Product Features:

Commercially approved ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
Stainless steel finish Solid construction for lasting durability and a professional look
Automatic defrost No-frost convenience for reduced user maintenance
Digital thermostat Electronic controls offer more precision in temperature management, with a readout viewable

in Celsius or Fahrenheit
Factory-installed lock Keyed lock for a secure interior
Adjustable chrome shelves Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup
LED lighting Interior LED lighting offers an energy efficient view in an attractive blue hue
Flat door liner No door shelving allows the unit to accommodate deeper items
Sealed back Space-saving design with no exposed coils in the rear offers easy cleanability

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2008 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

FFAR25L7CSS Specifications:

Overview

Height of Cabinet 20.25" (51 cm)
Height to Hinge Cap 20.75" (53 cm)
Width 17.0" (43 cm)
Width with Door Open 17.75" (45 cm)
Depth 19.13" (49 cm)
Depth with door at 90° 34.25" (87 cm)
Capacity 1.7 cu.ft. (48 L)
Defrost Type Automatic
Door Stainless Steel
Cabinet Stainless Steel
US Electrical Safety ETL
Canadian Electrical

Safety
Sanitation ETL-S
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 55.0 lbs. (25 kg)
Shipping Weight 60.0 lbs. (27 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Refrigerator Features

Door Swing RHD
Reversible Factory

Shelf Type Chrome
Shelf Qty 2
Adjustable Shelves Yes
Thermostat Type Digital
Refrigerant Type R600a
Refrigerant Amount 0.6oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Light Yes
Temperature Range 34°F to 43°F

Dimensions

Interior Height 16.5" (42 cm)
Interior Width 13.75" (35 cm)
Interior Depth 15.0" (38 cm)

ETL-C

Reversible

Compressor Step
Height

Compressor Step Width 13.75" (35 cm)
Compressor Step Depth 6.0" (15 cm)

8.0" (20 cm)
