Models
GLDS4R
GLDS5R
GLDS6R
GLDS8R
GLDS10R
GLDS12R
GLDSX4R
GLDSX2R
GLDSX9R
GLDSN2R
GLDSN4R
GLDSN9R
G Series - GLDS Refrigerated Low-Capacity Service Case
Applications
• Low capacity
refrigerated service
merchandiser for deli
& bakery items
EXTERIOR COLOR
INTERIOR COLOR
TRIM COLOR
BASE
END PANELS
FRONT GLASS
REAR DOORS UPPER
REAR LEDGE
LIGHTING UPPER
ELECTRICAL CONNECT
REFRIGERATION
MISCELLANEOUS
□ Painted
□ Black
□ Black
□ 35''H refrigerated base
□ None (Specify per line-up)
□ Curved single pane, lift-up
□ Removable angled clear acrylic upper
rear sliding doors
□ Black poly
□ Double row T-8 top light(s)
□ Leads
□ Remote DX refrigeration
Options Features Standard
□ Stainless steel
□ Stainless steel
□ White
□ Silver
□ Case to case cutaway end
□ Case to case full end
□ Cutaway with glass
□ Full with mirror
□ Flat angled single pane, lift-up
□ Front glass lock
□ Night curtain, retractable, non-locking
□ Open
□ Rear door lock
□ Corian solid surface
□ Quartz
□ Stainless steel
□ White poly
□ LED top light(s)
□ 6' power cord (self-cont.)
□ Breeze™ w/EnergyWise s/c refrigeration
□ Clean Sweep® condenser coil cleaner
□ Coated evaporator coil
□ Remote Glycol refrigeration
□ 1'' bumper on front (specify color)
□ 2'' bumper on upper front panel
□ 2''H Full depth display riser(s)
□ Price tag moulding
□ Stainless steel condiment rail system
□ Top mount scale stand w/receptacle
Revised
20014090
4/14/2015
ONE PART PASSION, TWO PARTS SCIENCE
(Lengths do not include 1-1/8 " end panels)
(Lengths do not include 1 " end panels)
(Lengths do not include 1 " end panels)
G Series GLDS Refrigerated Low-Capacity Service Case
GLDS4R 48-3/4"L x 46-5/8"D x 51-1/4"H
Model
GLDS5R 60-5/8"L x 46-5/8"D x 51-1/4"H
GLDS6R 73-1/8"L x 46-5/8"D x 51-1/4"H
GLDS8R 97-1/2"L x 46-5/8"D x 51-1/4"H
GLDS10R 121-1/8"L x 46-5/8"D x 51-1/4"H
GLDS12R 146-1/4"L x 46-5/8"D x 51-1/4"H
L x D x H
CONVEX / OUTSIDE CURVE
GLDSX4R 39-1/4"L x 46-5/8"D x 51-1/4"H
Model
GLDSX2R 47-3/4"L x 46-5/8"D x 51-1/4"H
GLDSX9R 71-5/8"L x 46-5/8"D x 51-1/4"H
L x D x H
STRAIGHT
IMPORTANT
NOTES:
1) Units must be shimmed
during installation to
ensure the unit is level
and plumb.
CONCAVE / INSIDE CURVE
GLDSN2R 41-1/4"L x 46-5/8"D x 51-1/4"H
Model
GLDSN4R 56-7/8"L x 46-5/8"D x 51-1/4"H
GLDSN9R 105"L x 46-5/8"D x 51-1/4"H
L x D x H
INTENDED
ENVIRONMENT
Designed to operate in
ambient conditions of 75°F
with 55% relative humidity.
INTEGRATED AVG
PRODUCT TEMP
Zone Temp (°F)
40 All
INTENDED USE OF
DISPLAY AREAS
Zone Intended Use
Unpackaged
All
refrigerated products
INFORMATION IS SUBJECT TO CHANGE WITHOUT NOTICE. Visit www.structuralconcepts.com for the most current specs.
888 E. Porter Rd. Muskegon, MI 49441 231-798-8888
For more information on any
of our products or services
please visit us on the web at:
www.structuralconcepts.com
