STIHL BF-KM
Instruction Manual
Contents
English
KombiSystem 2
Guide to Using this Manual 2
Safety Precautions and Working
Techniques 2
Using the Unit 6
Approved KombiEngines 7
Assembling the Unit 8
Mounting the KombiTool 9
Original Instruction ManualPrinted on chlorine-free paper
Fitting the Harness 10
Starting / Stopping the Engine 11
Storing the Machine 11
Maintenance and Care 12
Minimize Wear and Avoid Damage 12
Main Parts 13
Specifications 13
Maintenance and Repairs 14
Disposal 15
EC Declaration of Conformity 15
UKCA Declaration of Conformity 16
Printing inks contain vegetable oils, paper can be recycled.
Dear Customer,
Thank you for choosing a quality
engineered STIHL product.
It has been built using modern
production techniques and
comprehensive quality assurance.
Every effort has been made to ensure
your satisfaction and trouble-free use of
the product.
Please contact your dealer or our sales
company if you have any queries
concerning this product.
Your
Dr. Nikolas Stihl
© ANDREAS STIHL AG & Co. KG, 2021
0458-478-0121-B. VA0.H21.
0000000666_020_GB
BF-KM
This instruction manual is protected by copyright. All rights reserved, especially the rights to reproduce, translate and process
with electronic systems.
1
English
KombiSystem Guide to Using this Manual Safety Precautions and
Working Techniques
In the STIHL KombiSystem a number of
different KombiEngines and KombiTools
can be combined to produce a power
tool. In this instruction manual the
functional unit formed by the
KombiEngine and KombiTool is referred
to as the power tool.
Therefore, the separate instruction
manuals for the KombiEngine and
KombiTool should be used together for
the power tool.
Always read and and make sure you
understand both instruction manuals
before using your power tool for the first
time and keep them in a safe place for
future reference.
Pictograms
All the pictograms attached to the
machine are shown and explained in this
manual.
Symbols in text
WARNING
Warning where there is a risk of an
accident or personal injury or serious
damage to property.
NOTICE
Caution where there is a risk of
damaging the machine or its individual
components.
Engineering improvements
STIHL's philosophy is to continually
improve all of its products. For this
reason we may modify the design,
engineering and appearance of our
products periodically.
Therefore, some changes, modifications
and improvements may not be covered
in this manual.
Lend or rent your machine only to
persons who are familiar with this model
and its operation – do not lend or rent
your machine without the KombiEngine
and KombiTool user manuals.
Use the cultivator only for tilling
previously cultivated, packed or loose
soil, furrowing and working in mulches.
The machine must not be used for any
other purposes – risk of accidents!
Only mount rotor blades and
accessories that are explicitly approved
for this power tool by STIHL or are
technically identical. If you have any
questions in this respect, consult your
dealer.
Use only high quality parts and
accessories. In order to avoid the risk of
accidents and damage to the machine.
Special safety precautions must be observed
when working with the
cultivator because its
pointed and sharp-edged
rotor blades rotate at high
speed.
Always read and and
make sure you understand both user manuals
(KombiEngine and
KombiTool) before using
your power tool for the
first time and keep them
in a safe place for future
reference. Non-compliance with the user
manuals may cause serious or even fatal injury.
2
BF-KM
English
STIHL recommends the use of original
STIHL replacement parts, rotor blades
and accessories. They are specifically
designed to match the product and meet
your performance requirements.
The deflector on this power tool cannot
protect the operator from all objects
thrown by the blade (stones, glass, wire,
etc.). Ejected objects may also ricochet
and strike the operator.
Never attempt to modify your power tool
in any way since this may increase the
risk of personal injury. STIHL excludes
all liability for personal injury and
damage to property caused while using
unauthorized attachments.
Do not use a high-pressure washer to
clean the power tool. The solid jet of
water may damage parts of the unit.
Clothing and equipment
Wear proper protective clothing and
equipment.
Clothing must be sturdy
but allow complete freedom of movement. Wear
close-fitting clothes such
as a boiler suit, not a
loose jacket.
Do not wear clothing which could
become trapped in wood, brush or
moving parts of the machine. Do not
wear a scarf, necktie or jewelry. Tie up
and confine long hair above your
shoulders.
Wear safety boots with
steel toe caps and nonslip soles.
WARNING
To reduce the risk of eye
injuries, wear close-fitting safety glasses in
accordance with European Standard EN 166.
Make sure the safety
glasses are a snug fit.
Wear "personal" sound protection, e.g.
ear defenders.
Wear sturdy protective
gloves made of a resistant material (e. g.
leather).
STIHL can supply a comprehensive
range of personal protective equipment.
Transporting the machine
Always stop the engine.
Carry the power tool hanging from the
shoulder strap or properly balanced by
the drive tube.
Do not touch hot parts of the machine risk of burn injury!
By vehicle: When transporting in a
vehicle, properly secure your machine to
prevent turnover, damage and fuel
spillage.
Before starting
Check that your power tool is properly
assembled and in good condition – refer
to appropriate chapters in the
KombiEngine and KombiTool user
manuals:
– Rotor blades, correctly fitted, secure
and in perfect condition (clean,
moves freely, not warped)
– Inspect the deflectors for damage
and wear. Do not operate the
machine with a damaged deflector –
replace damaged parts.
– Do not attempt to modify the
controls or safety devices in any
way – only work with the deflector
fitted
– Keep the handles dry and clean –
free from oil and dirt – this is
important for safe control of the
machine
– Adjust carrying harness and
handles in accordance with body
height. Observe the chapter "Fitting
the Harness"
To reduce the risk of personal injury, do
not operate your power tool if it is
damaged or not properly assembled!
To prepare for emergencies when using
a harness: Practice setting down the
machine quickly. To avoid damage, do
not throw the machine to the ground
when practicing.
Holding and guiding the machine
BF-KM
Make sure you always have good
balance and secure footing.
3
English
002BA055 KN
002BA080 KN
Always hold the unit firmly with both
hands on the handles.
For versions with bike handle
7
Right hand on control handle, left hand
on grip on handlebar.
For versions with loop handle
For versions with loop handle and loop
handle with barrier bar, left hand on the
loop handle, right hand on the control
handle – even if you are left-handed.
While working
In the event of impending danger or in
an emergency, switch off the engine
immediately by moving the slide control
/ stop switch/button to 0 or STOP.
To reduce the risk of injury from ejected
objects, do not allow any other persons
within 5 meters of your own position.
This distance must also be maintained in
relation to objects (vehicles, window
panes) – risk of property damage!
Ensure that the gear unit
and the rotor blades are
correctly attached and
aligned and avoid contact
with the chopping stars risk of injury!
As soon as the engine is
running, the power
machine generates toxic
exhaust gas. These
gases may be odorless
and invisible and may
contain unburned hydrocarbons and benzene.
Never run the engine
indoors or in poorly ventilated locations, even if
your model is equipped
with a catalytic converter.
Arrows on the blades show the direction
of rotation. The arrows on the rotor
blades must point in the same direction
as the arrows on the gear.
Make sure the idle speed setting is
correct. The rotor blades must not rotate
when the engine is idling with the throttle
trigger released. Check and correct the
idle speed setting at regular intervals. If
the rotor blades still rotate, have your
dealer check your machine and make
proper adjustments or repairs – see
KombiEngine instruction manual.
Never work without suitable protection
for the unit and KombiTool - risk of injury
from thrown objects!
Take special care in slippery conditions
– damp, snow, ice, on slopes or uneven
ground!
Watch out for obstacles: tree stumps,
roots – risk of tripping or stumbling!
Check the work site – rocks, metal
objects etc. may be caught up and
ejected – risk of injury! - and may
damage the rotor blades.
4
BF-KM
English
To avoid the risk of electrocution, never use your
power tool in areas where
electrical lines are laid on
the surface or buried just
below the surface.Striking and damaging such
lines with the KombiTool
could cause serious or
even fatal injury.
Make sure you always have good
balance and secure footing.
Operate your power tool at normal
walking pace only.
Take particular care when working close
to fences, walls, stones, roots, trees and
areas of dense growth. The rotor blades
may snag –risk of injury!
Be extremely cautious when pulling the
power tool towards you because of the
risk of injury from contact with the
rotating blades.
Be particularly alert and cautious when
wearing hearing protection because
your ability to hear warnings (shouts,
alarms, etc.) is restricted.
Take breaks when you start getting tired
or feeling fatigue – risk of accidents!
Work calmly and carefully – in daylight
conditions and only when visibility is
good. Proceed with caution, do not put
others in danger.
If your power tool is subjected to
unusually high loads for which it was not
designed (e.g. heavy impact or a fall),
always check that it is in good condition
before continuing work – see also
"Before Starting". Make sure the safety
devices are working properly. Never use
a power tool that is no longer safe to
operate. In case of doubt, contact a
dealer.
Do not touch the rotor blades while the
engine is running. If the rotor blades
become jammed by an object, switch off
the engine immediately before
attempting to remove the object – there
is otherwise a risk of injury!
Opening the throttle while the rotor
blades are blocked increases the load
and reduces engine speed. The clutch
then slips continuously and this causes
overheating and damage to important
components (e.g. clutch, polymer
housing components) – and this can
increase the risk of injury from the rotor
blades running while the engine is idling.
Check the rotor blades at regular short
intervals during operation or
immediately if there is a noticeable
change in operating behavior:
– Shut off the engine, hold the
machine securely.
– Check condition and secure fitting;
watch out for cracks
– Replace damaged rotor blades
immediately, even if they have only
superficial cracks.
Clean the rotor blades and deflector at
regular intervals during operation.
– Shut off the engine
– Use gloves
– Remove grass, weeds, clumps of
soil, etc.
Switch off the engine before changing
the rotor blades – Risk of injury!
Do not continue using or attempt to
repair damaged or cracked rotor blades
by welding or straightening – risk of
deformation (out of balance).
Particles or pieces may come off and hit
the operator or a bystander at a high
speed –
After finishing work
After finishing work or before leaving the
power tool unattended: Shut off the
engine.
After finishing work, clean dirt, soil and
plant residue off the KombiTool – wear
gloves to reduce the risk of injury!
Do not use any grease solvents when
cleaning.
After thorough cleaning, wet the surface
of metal KombiTools with an
anticorrosive agent.
Maintenance and Repairs
Service the machine regularly. Do not
attempt any maintenance or repair work
not described in the KombiTool and
KombiEngine instruction manuals. Have
all other work performed by a servicing
dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer. STIHL dealers are
regularly given the opportunity to attend
training courses and are supplied with
the necessary technical information.
risk of most severe injuries!
BF-KM
5
English
Only use high-quality replacement parts
in order to avoid the risk of accidents
and damage to the machine. If you have
any questions in this respect, consult a
servicing dealer.
STIHL recommends the use of genuine
STIHL replacement parts. They are
specifically designed to match your
model and meet your performance
requirements.
To reduce the risk of injury, always shut
off the engine before carrying out any
maintenance or repairs or cleaning the
machine.
Using the Unit
General Information
Preparation
N Starting the engine
N Fitting the harness
Working techniques
You can work with your cultivator in the
forward (1) and backward (2) directions,
from left to right or vice versa (3) or in a
circular motion.
Choose the best method to suit your
purpose, i.e. this depends on the shape
and size of the area and soil conditions.
Working in an alternating backwards
and forwards motion is particularly
suitable for loosening packed soil.
0000097751_001
WARNING
The cultivator moves away from the user
during work. Always ensure a secure
footing to be able to control the
cultivator.
Example applications
N Breaking up soil
6
BF-KM
English
A few preparations are necessary before
you begin to break up soil which has
been previously tilled (e.g. last year's
vegetable or flower garden). First clear
away surface weeds and remains of
other plants as well as hard objects like
rocks, stones, bottles, pieces of wood
etc. which can be thrown up by the rotor
blades.
Hold the cultivator firmly with both hands
and till only a small area at a time to the
required depth.
Finish tilling the area by guiding the
cultivator in such a way that you leave
no footprints. Use a rake to level off the
entire area.
N Loosening soil around plants
Only loosen the surface soil around
plants. Avoid going too deep as this
could damage the shallow roots of some
plants.
To avoid any damage to the cultivator or
trees, be wary not to catch the blades on
the large roots of trees.
N Working in soil improvers
The cultivator can be used for mulching
with loam, compost, leaves, other
organic material or fertilizers.
Prepare the area by removing all old
roots, the remains of large plants and
hard objects (stones etc.). Spread the
mulch evenly on the ground.
Work in the mulch with a circular or back
and forth motion.
Finish off by leveling the area with a
rake.
N Trenching or furrowing
Walk slowly backward and pull the
cultivator to create the furrow required.
Repeat as necessary to obtain deeper
furrows.
Cleaning the Rotor Blades
Parts of plants, e.g. roots, can become
tightly wrapped around or between the
rotor blades during operation. To clean
the rotor blades:
– Switch off the cultivator and wait
until the blades come to a complete
standstill.
– Pull the hitch pins out of the axle
– Pull the rotor blades off the shaft
– Remove pieces of roots, plants and
soil
WARNING
Rotor blades are sharp edged. Wear
gloves while cleaning.
Approved KombiEngines
KombiEngines
Only use KombiEngines supplied or
explicitly approved by STIHL for use with
the attachment.
This KombiTool may be operated only in
combination with the following
KombiEngines:
STIHL KM 55 R, KM 56 R, KM 85 R,
KM 90, KM 90 R, KM 94 R, KM 100,
KM 100 R, KM 110, KM 110 R, KM 130,
KM 130 R, KMA 130 R, KMA 135 R
WARNING
Loop-handled machines must be
equipped with a barrier bar.
Brushcutters with split boom
The KombiTool can also be fitted to
STIHL brushcutters with a split boom (Tmodels) (basic power tools).
This KombiTool can therefore also be
used on the following machine:
STIHL FR 130 T
WARNING
Refer to the user manual of the power
tool for use of the barrier bar.
BF-KM
7
English
413BA014 KN
002BA248 KN
Assembling the Unit
N Pull the protective caps off the ends
of the shaft and keep them in a safe
place for later use – see "Storing the
Machine"
NOTICE
The plug may come out of the drive tube
when you pull off the cap. Push it back
into the shaft as far as it will go.
Mounting the guard
N Slide the deflector (1) onto the drive
tube (2) until distance (a) is 100 mm
N Line up the deflector (1) so that it is
vertical and the fixing lug (arrow) on
the drive tube points up
N Tighten the clamp screw (3)
moderately
NOTICE
Check that the deflector is secure – it
must not be possible to rotate it on the
drive tube.
Mounting the gearbox
5
1
2
4
7
6
3
N align the gear unit (1) on the shaft
(2) so that the shaft (3) is below the
shaft and the locating pin (4) is
pointing upwards
N the upper clamping screw (5) must
be aligned like the clamping screw
(7) on the guard
N tighten down the clamp screws
firmly
NOTICE
It must not be possible to rotate the
gearbox on the drive tube.
2
1
0000097752_001
0000098185_001
the axle (1) must be located below the
shaft (2). The arrows on the gear unit
indicate the direction of rotation
N Loosen the clamp screws (4)
N Push the gearbox (5) onto the drive
tube (2), turn the gearbox back and
forth as necessary
8
BF-KM
English
1
002BA326 KN
2
3
002BA327 KN
4
WARNING
An incorrectly mounted
and aligned gearbox can
cause the rotor blades to
rotate in the wrong
direction.
Ensure that the gearbox is properly
aligned and that the cultivator moves
away from the user during operation.
Mounting the Rotor Blades
Take care not to lose the two washers
on the gearbox output shaft.
N Arrange the blades in the order they
will be fitted on the shaft, noting the
following points:
Left-hand and right-hand rotor blades
are different. The direction of rotation is
marked with arrows on the gearbox and
rotor blades.
N rotate the outer right-hand rotor
blade (8) on the shaft until it can be
pushed into position – check the
direction of rotation again - arrows
N Insert and engage the hitch pin (9)
in the hole in the shaft – fold the
hitch pin flat against the rotor blade
N Use the same procedure to mount
the rotor blades on the left-hand
side
WARNING
The rotor blades are sharp-edged. Wear
gloves when mounting the rotor blades
Mounting the KombiTool
N Push the lug (1) on the drive tube
into the slot (2) in the coupling
sleeve as far as stop.
When correctly installed, the red line (3)
(arrow point) must be flush with the end
of the coupling sleeve.
N Tighten down the star knob (4)
firmly.
N rotate the inner right-hand rotor
blade (7) on the shaft until it can be
pushed into position – check the
direction of rotation again - arrows -
The hub of the inner rotor blade is larger
than that of the outer blade.
BF-KM
Removing the KombiTool
N Reverse the above sequence to
remove the drive tube.
9
English
1
002BA374 KN
2
1
002BA375 KN
2
1
002BA308 KN
2
1
2
1
002BA310 KN
2
1
2
Fitting the Harness
The type and style of the harness,
carrying ring and carabiner (spring hook)
depend on the market.
Shoulder Strap
N Put on the shoulder strap (1).
N Adjust the length of the strap so that
the carabiner (2) is about a hand’s
width below your right hip.
10
Full harness
N Put on the full harness (1).
N Adjus t the l ength o f the s trap so that
the carabiner (2) is about a hand’s
width below your right hip.
Attaching Machine to Harness
N Attach the carabiner (1) to the
carrying ring (2) on the drive tube –
hold the carrying ring steady.
Disconnecting Machine from Harness
N Press down the bar on the
carabiner (1) and pull the carrying
ring (2) out of the carabiner.
Throwing Off the Machine
WARNING
The machine must be quickly thrown off
in the event of imminent danger.
Practice removing and putting down the
machine as you would in an emergency.
To avoid damage, do not throw the
machine to the ground when practicing.
Practice quickly detaching the power
tool from the carabiner as described
under "Disconnecting Machine from
Harness".
If you are using a shoulder strap:
Practice slipping the strap off your
shoulder.
If you are using a full harness: Practice
quickly opening the locking plate and
slipping the harness straps off your
shoulders.
BF-KM
English
504BA018 KN
Starting / Stopping the
Engine
Starting the Engine
Always follow the operating instructions
for the KombiEngine and basic power
tool.
N Place the machine on the ground: It
must rest securely on the machine
support. Rest the deflector end of
the drive tube on a raised support
(e.g. mound, log, brick).
To reduce the risk of accidents, check
that the rotor blades are not touching the
ground of any other obstacles.
N Make sure you have a firm footing,
either standing, stooping or
kneeling.
N Hold the machine with you left hand
and press it down firmly – do not
touch the controls on the control
handle – see KombiEngine or basic
power tool instruction manual.
WARNING
The blades may begin to rotate as soon
as the engine starts. For this reason, blip
the throttle after starting – the engine
returns to idling speed.
The starting procedure is now as
described in the instruction manual of
the KombiEngine or basic power tool
you are using.
Stopping the Engine
N See KombiEngine or basic power
tool instruction manual.
Storing the Machine
For periods of 3 months or longer
N Remove, clean and inspect the rotor
blades.
N If the KombiTool is removed from
the KombiEngine and stored
separately: Fit the protective cap on
the drive tube to avoid dirt getting
into the coupling.
N Store the machine in a dry, high or
locked location – out of the reach of
children and other unauthorized
persons.
NOTICE
Do not stand or kneel on the drive tube.
BF-KM
11
English
Maintenance and Care Minimize Wear and Avoid
Damage
The following intervals apply to normal
operating conditions only. If your daily
working time is longer or operating
conditions are difficult (very dusty work
area, etc.), shorten the specified
intervals accordingly.
All accessible screws and nuts
N Retighten if necessary
Sweeping attachments and deflectors
N Visual inspection, check tightness
before starting work and after every
refueling stop
N Replace if damaged
Safety labels
N Replace illegible safety labels
Observing the instructions in this manual
and the KombiEngine manual helps
reduce the risk of unnecessary wear and
damage to the power tool.
The power tool must be operated,
maintained and stored with the due care
and attention described in these
instruction manuals.
The user is responsible for all damage
caused by non-observance of the safety
precautions, operating and maintenance
instructions. This includes in particular:
– Alterations or modifications to the
product not approved by STIHL.
– Using tools or accessories which
are neither approved or suitable for
the product or are of a poor quality.
– Using the product for purposes for
which it was not designed.
– Using the product for sports or
competitive events.
– Consequential damage caused by
continuing to use the product with
defective components.
servicing dealer. STIHL dealers are
regularly given the opportunity to attend
training courses and are supplied with
the necessary technical information.
If these maintenance operations are not
carried out as specified, the user
assumes responsibility for any damage
that may occur. Among other parts, this
includes:
– Corrosion and other consequential
damage resulting from improper
storage.
– Damage to the product resulting
from the use of poor quality
replacement parts.
12
Maintenance Work
All the operations described in the
chapter on "Maintenance and Care"
must be performed on a regular basis. If
these maintenance operations cannot
be performed by the owner, they should
be performed by a servicing dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
BF-KM
English
Main Parts
1
2
3
4
5
6
1 Shaft
2 Deflector
3 Gearhead
4 Outer right-hand rotor blade
5 Inner right-hand rotor blade
6 Inner left-hand rotor blade
7 Outer left-hand rotor blade
8 Hitch pin
8
7
Specifications
Gearbox
Single-stage worm gear
Reduction ratio: 44:1
Rotor Blades
Four rotor blades, double-edged, rotate
in same direction
Diameter: 230 mm
Working width: 220 mm
Weight
Complete with deflector and drive tube:
4.1 kg
Sound and Vibration Levels
Noise and vibration data measurements
on power tools with the BF-KM
KombiTool include idling and rated
maximum speed in a ratio of 1:6.
0000097754_001
For further details on compliance with
Vibration Directive 2002/44/EC see
www.stihl.com/vib
Sound pressure level L
KM 55 R with loop handle: 95 dB(A)
KM 56 R with loop handle: 95 dB(A)
KM 85 R with loop handle: 95 dB(A)
KM 90 R with loop handle: 97 dB(A)
KM 94 R with loop handle: 94 dB(A)
to ISO 11201
peq
KM 100 R with loop
handle: 91 dB(A)
KM 130 with bike handle: 97 dB(A)
KM 130 R with loop
handle: 99 dB(A)
KM 135 R with loop
handle: 74.2 dB(A)
FR130T: 97dB(A)
Sound pressure level L
accordance with EN 50636-2-92
KM 130 R with loop
handle: 76 dB(A)
Sound power level L
with ISO 11201
KM 94 R with loop handle: 106 dB(A)
Sound power level L
with ISO 3744
KM 55 R with loop handle: 105 dB(A)
KM 56 R with loop handle: 105 dB(A)
KM 85 R with loop handle: 106 dB(A)
KM 90 R with loop handle: 101 dB(A)
KM 100 R with loop
handle: 101 dB(A)
KM 130 with bike handle: 105 dB(A)
KM 130 R with loop
handle: 105 dB(A)
KM 135 R with loop
handle: 86 dB(A)
FR 130 T: 105 dB(A)
Sound power level L
with EN 50636-2-92
KM 130 R with loop
handle: 86 dB(A)
in
peq
in accordance
weq
in accordance
weq
in accordance
w
BF-KM
13
English
Vibration level a
KM 55 R with
loop handle: 6.9 m/s
to ISO 20643
hv,eq
Handle,
left
2
Handle,
right
8.0 m/s
KM 56 R with
loop handle: 5.5 m/s27.4 m/s
KM 85 R with
loop handle: 2.2 m/s26.3 m/s
KM 90 R with
loop handle: 3.6 m/s
KM 100 R with
loop handle: 3.6 m/s
KM 130 with
bike handle: 2.1 m/s
KM 130 R with
loop handle: 5.6 m/s
2
2
2
2
5.1 m/s
6.5 m/s
3.3 m/s
7.9 m/s
FR 130 T: 1.4 m/s21.8 m/s
Vibration level a
in accordance with
hv,eq
EN 50636-2-92
Handle,
left
KM 130 R with
loop handle: 1.8 m/s
KMA 135 R with
loop handle 1.6 m/s
Vibration level a
in accordance with
hv,eq
2
2
Handle,
right
2.3 m/s
2.1 m/s
ISO 22867
power level; the K-factor in accordance
with Directive 2006/42/EC is 2.0 m/s
2
Maintenance and Repairs
for the vibration level.
2
2
REACH
REACH is an EC regulation and stands
for the Registration, Evaluation,
2
2
Authorisation and Restriction of
Chemical substances.
For information on compliance with the
REACH regulation (EC) No. 1907/2006
2
see www.stihl.com/reach.
Users of this machine may only carry out
the maintenance and service work
described in this user manual. All other
repairs must be carried out by a
servicing dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer. STIHL dealers are
regularly given the opportunity to attend
training courses and are supplied with
the necessary technical information.
2
2
2
When repairing the machine, only use
replacement parts which have been
approved by STIHL for this power tool or
are technically identical. Only use highquality replacement parts in order to
avoid the risk of accidents and damage
to the machine.
STIHL recommends the use of original
STIHL replacement parts.
Original STIHL parts can be identified by
2
the STIHL part number, the {
logo and the STIHL parts symbol K
2
(the symbol may appear alone on small
parts).
Handle,
left
Handle,
right
KM 94 R with
loop handle: 3.9 m/s24.2 m/s
The K-factor in accordance with
Directive 2006/42/EC is 2.0 dB(A) for
the sound pressure level and sound
14
2
BF-KM
English
000BA073 KN
Disposal
Observe all country-specific waste
disposal rules and regulations.
STIHL products must not be thrown in
the garbage can. Take the product,
accessories and packaging to an
approved disposal site for environmentfriendly recycling.
Contact your STIHL servicing dealer for
the latest information on waste disposal.
EC Declaration of Conformity
ANDREAS STIHL AG & Co. KG
Badstr. 115
D-71336 Waiblingen
Germany
declare under our sole responsibility that
Designation: Cultivator
KombiTool
Make: STIHL
Series: BF-KM
Serial identification
number: 4601
conforms to the specifications of
Directives 2006/42/EC, 2014/30/EU and
2000/14/EC and has been developed
and built in compliance with the versions
of the following standards valid at the
production date:
EN ISO 12100 (in conjunction with the
listed KM- and FR- tools)
EN ISO 12100, EN 60335-1, EN 506362-92 (in conjunction with the specified
KMA tools).
Technical documents deposited at:
ANDREAS STIHL AG & Co. KG
Produktzulassung
The year of manufacture is specified on
the power tool.
Waiblingen, 15.07.2021
ANDREAS STIHL AG & Co. KG
pp
Dr. Jürgen Hoffmann
Director Product Certification &
Regulatory Affairs
BF-KM
15
English
UKCA Declaration of
Conformity
ANDREAS STIHL AG & Co. KG
Badstr. 115
D-71336 Waiblingen
Germany
declare under our sole responsibility that
Designation: Cultivator
KombiTool
Make: STIHL
Series: BF-KM
Serial identification
number: 4601
conforms to the relevant provisions of
the UK regulations Supply of Machinery
(Safety) Regulations 2008,
Electromagnetic Compatibility
Regulations 2016 and Noise Emission in
the Environment by Equipment for use
Outdoors Regulations 2001 and has
been manufactured in compliance with
the following standards in the versions
valid on the date of production:
EN ISO 12100 (in conjunction with the
listed KM- and FR- tools)
EN ISO 12100, EN 60335-1, EN 506362-92 (in conjunction with the specified
KMA tools).
Technical documents deposited at:
ANDREAS STIHL AG & Co. KG
The year of manufacture is stated on the
power tool.
Waiblingen, 15.07.2021
ANDREAS STIHL AG & Co. KG
pp
Dr. Jürgen Hoffmann
Director Product Certification &
Regulatory Affairs
16
BF-KM
0458-478-0121-B
englisch
G
www.stihl.com
*04584780121B*
0458-478-0121-B
Loading...
