SteelSeries MMO User Manual
Thank you for choosing the World of Warcraft® MMO Gaming Mouse.
This mouse has been jointly developed by Blizzard Entertainment, makers of
World of Warcraft® and by SteelSeries, the leading manufacturer of innovative
professional gaming gear, including headsets, keyboards, mice, mouse pads, and
other accessories. This user guide is designed to familiarize you with all aspects of
the mouse including setup and usage.
OVERVIEW (DEFAULT LAYOUT)
11..
Left Click
22..
Right Click
33.. AAssssiisstt TTaarrggeett
44.. SSccrroollll UUpp
5. Open All Bags
6. World Map
7. Character
SSccrroollll DDoowwnn PPrreessss -
- Zoom in
Move & Steer
Zoom out
88..
Windows Button 5
99..
Windows Button 4
1100..
Autorun
1111.. Last Hostile
1122.. Attack Target
133..
Nearest Enemy
1144..
Battle Map
1155.. Target Self
2
CONNECTING YOUR MOUSE
Connect the USB cord to a USB port.
NOTE:
The World of Warcraft® MMO Gaming Mouse can work in 250/500/1000Hz polling
rate frequencies. This is configurable through the software and will be explained in the
software section below. Some USB hubs might decrease the mouse polling frequency; if you
experience decreased performance when using your mouse with a USB hub, plug your
mouse directly into the USB port on your computer.
TECHNICAL SPECIFICATIONS
• Interface: USB 1.1 operating at full speed*
• Sensor Type: Laser
• Real-time Adjustable (via software) Resolution: 800/1200/1600/2000/2400/
3200 DPI (Default: 800 DPI)
• Max. Speed: 65ips
• Frame Rate: 7200fps
• Max. Acceleration: 20g
• Min. Lift Distance: 2.5mm
• Adjustable Polling Rate (via software): 1000/500/250 Hz at 1/2/4 ms respectively
(Default: 500 Hz / 2 ms response time)
• Data Path Format: 16-bit
• Sleep Mode: Disabled (the mouse is always on)
• Buttons: 15
• Cord: Braided, 2m (6.5 feet)
*Denotes operating rate of 12 Mbit/s (1.5 MB/s).
INSTALLING THE SOFTWARE
1.Download the software from our website:
http://www.steelseries.com/downloads/
2.Launch the installer and follow the instructions on the screen
3
SOFTWARE OVERVIEW
1.
Menu Area
2.
Profile Area
3.
Character Information Area
4.
Button Groups with current assignments
5.
Button Assignments Panel*
6.
Mouse Properties Panel*
7.
Illumination Panel*
8.
Restore Defaults button
*These panels are closed by default; press the panel tab to open.
4
1
2
3
4
6
7
8
5
