STA-RITE SR200NA, SR400LP, SR400HD, SR200LP, SR333LP User Manual

...
SR POOL AND SPA HEATER 120/240 VAC NATURAL GAS/LP GAS
O W N E R’ S M A N U A L
INSTALLATION, OPERATION & PARTS
MODELS
200K BTU/HR SR200NA, SR200LP 333K BTU/HR SR333NA, SR333LP 400K BTU/HR SR400NA, SR400LP, SR400HD
Sta-Rite Pool/Spa Group
International: 262-728-5551, FAX: 262-728-7550 www.starite.com
Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA
© 2004, Sta-Rite Industries Printed in U.S.A. S628 (Rev. 6/10/04)
If the information in these instructions is not followed exactly, a fire
or explosion may result causing property damage, personal injury or death.
– Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
– Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
SPECIAL INSTRUCTIONS TO OWNER
Retain this manual for future reference. This manual supplies information for the installation, operation,
and servicing of the appliance. It is strongly recommended that this manual be reviewed completely before proceeding with an installation. Its use will reduce service calls and chance of injury and will lengthen product life.
2668 039
FILTER PUMP
AUX 1
AUX 2
HIGH SPEED
LOW SPEE
D
BOOSTER PUMP
®
CERTIFIED
®
INSTALLATION, OPERATION AND SERVICE MANUAL
Model SRC Pool and Spa Natural Gas Heater
TO INSTALLER:
Affix these instructions adjacent to the heater.
TO CONSUMER:
Retain these instructions for future reference. FOR YOUR SAFETY - This product must be installed and
serviced by a professional service technician, qualified in pool heater installation. Improper installation and/or oper­ation could create carbon monoxide gas and flue gases which could cause serious injury or death. Improper installation and/or operation will void the warranty.
FIGURE 1
Table of Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General Specifications, Requirements . . . . . . . . . . . . . . 3
Description of the Heater . . . . . . . . . . . . . . . . . . . . . . . 4
Sequence of Operation. . . . . . . . . . . . . . . . . . . . . . . . . 4
Owner’s Operating Instructions . . . . . . . . . . . . . . . . . . 4
Before Startup. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
What To Do If You Smell Gas . . . . . . . . . . . . . . . . 5
Spa Temperature Caution . . . . . . . . . . . . . . . . . . . 5
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . 5
To Turn Off Gas To the Appliance . . . . . . . . . . . . . 6
Operating Control. . . . . . . . . . . . . . . . . . . . . . . . . 6
After Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Care/Maintenance/Winterizing. . . . . . . . . . . . . . . . . . . 8
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . 9
Outdoor Installation . . . . . . . . . . . . . . . . . . . . . . . 9
Outdoor Shelter/Indoor Installation . . . . . . . . . 10-15
Water Connections . . . . . . . . . . . . . . . . . . . . 15-18
Pressure Relief Valve . . . . . . . . . . . . . . . . . . . . . . 18
Checking Combination Gas Control Valve . . . . . . 19
Gas Connections . . . . . . . . . . . . . . . . . . . . . . . . 20
Pressure Testing . . . . . . . . . . . . . . . . . . . . . . . . . 20
Electrical Wiring . . . . . . . . . . . . . . . . . . . . . . 20-22
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . 23-30
Repair Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31-35
Wiring Diagrams/External Control Interface . . . . . . 36-37
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SAFETY INSTRUCTIONS
FOR YOUR SAFETY - This product must be installed and
serviced by a professional service technician, qualified in pool heater installation. Some jurisdictions require that installers be licensed. Check with your local building authority about contractor licensing requirements. Improper installation and/or operation could create carbon monoxide gas and flue gases which could cause serious injury or death. Improper installation and/or operation will void the warranty.
Installation must be in accordance with all local codes and/or the lastest edition of the National Fuel Gas Code, Z233.1 and the National Electrical Code, ANSI/NFPA70 (U.S.), or standards CSA B149 – INSTALLATION CODES FOR GAS-BURNING APPLIANCES AND EQUIPMENT and/or local codes and Standard CSA C22.1 – Canadian Electrical Code, Part 1 (Canada). The heater, when installed, must be electrically grounded and bonded in accordance with local codes, or, in absence of local codes, with the Canadian Electrical Code or the National Electrical Code, ANSI/NFPA70, as applicable.
2
For instructions on checking the gas pressure
through the Combination Gas Control Valve,
See the sidebar on Page 19.
AUX
LOW SPEED
BOOSTER PUMP
2
AUX
1
HIGH SPEED
R
FILTE
P
M U P
2668 10
SAFETY INSTRUCTIONS (Continued)
This appliance is equipped with an uncon­ventional gas control valve that is factory set with a mani­fold pressure of -.2 inches wc. Improper installation, adjustment, alteration, service or maintenance can cause property damage, personal injury or loss of life.
Installation or service must be performed by a qualified installer, service agency or the gas supplier. If this control is replaced, it must be replaced with an identical control.
Do not attempt to adjust the gas flow by adjusting the reg­ulator setting.
Risk of fire or explosion from incorrect fuel use or faulty fuel conversion. Do not try to run a heater set
up for natural gas on propane gas or vice versa. Only qual­ified service technicians should attempt to convert heater from one fuel to the other.
Do not attempt to alter the rated input or type of gas by changing the orifice. If it is necessary to convert to a different type of gas, consult your Sta-Rite dealer. Serious malfunction of the burner can occur which may result in loss of life. Any additions, changes, or conversions required in order for the appliance to satisfactorily meet the application needs must be made by a Sta-Rite dealer or other qualified agency using factory specified and approved parts.
The heater is available for use with natural gas. It can be converted to propane gas. Refer to the nameplate for the type of gas the heater is equipped to use.
• Use this heater only with natural gas. Do not attempt to
convert it to another type of gas.
• If propane gas is the only available fuel, have a qualified
service technician convert the heater to propane before putting heater into operation.
Risk of fire or explosion from flammable vapors. Do not store gasoline, cleaning fluids, varnishes,
paints, or other volatile flammable liquids near heater or in the same room with heater.
Risk of fire, carbon monoxide poisoning, or asphyxiation if exhaust venting system leaks. Only quali-
fied service technicians should attempt to service the heater, as leakage of exhaust products or flammable gas may result from incorrect servicing.
Risk of explosion if unit is installed near propane gas storage. Propane (LP) gas is heavier than air.
Consult local codes and fire protection authorities about specific installation requirements and restrictions. Locate the heater away from propane gas storage and filling equip­ment as specified by the Standard for the Storage and Handling of Liquified Petroleum Gases, CAN/CSA B149.2 (latest edition) or ANSI/NFPA 58 (latest edition).
Risk of asphyxiation if exhaust is not correct­ly vented. Follow venting instructions exactly when installing heater. Do not use a draft hood with this heater,
as the exhaust is under pressure from the burner blower and a draft hood will allow exhaust fumes to blow into the room housing the heater.
The heater is supplied with an integral venting system for outdoor installation. A vent conversion kit (See Page 14 for Part Numbers for Conversion Kits) is available for installa­tions in enclosures (Canada) or indoors (U.S.). Use the specified venting, and only the specified venting, when heater is installed in an enclosure or indoors. In Canada, this pool heater can only be installed outdoors or in an enclosure that is not normally occupied and does not directly communicate with occupied areas. See Page 11 for enclosure venting requirements.
Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Wiring errors can also destroy the control board.
Connect heater to 120 or 240 Volt, 60 Hz., 1 Phase power only.
Verify proper operation after servicing. Do not allow children to play on or around heater or asso-
ciated equipment. Never allow children to use the pool or spa without adult
supervision. Read and follow other safety information contained in this
manual prior to operating this pool heater.
GENERAL SPECIFICATIONS/ REQUIREMENTS
NOTICE: Combustion air contaminated by corrosive chemi-
cal fumes can damage the heater and will void the warranty. NOTICE: The Combination Gas Control Valve on this
appliance differs from most appliance gas controls. If it must be replaced, for safety reasons replace it only with an identical gas control.
NOTICE: The jacket covers must be in place to provide proper ventilation. Do not operate the heater for more than five (5) minutes with the jacket covers removed.
This heater is design certified by CSA International as com­plying with the Standard for Gas Fired Pool Heaters, ANSI Z21.56* CSA 4.7, and is intended for use in heating fresh water swimming pools or spas.
NOTICE: Do not use this heater as a heating boiler, water heater, or for heating salt-water pools. This heater is intended for use in heating fresh water swimming pools or spas only.
The heater requires an external 120 or 240 VAC single­phase electric power source.
The heater is design certified by CSA International for installation on combustible flooring. Specified minimum clearances must be maintained to combustible surfaces (see “Installation Instructions”, Pages 9 and 10).
The heater should be located in an area where leakage of the heater or connections will not result in damage to the area adjacent to the heater or to the structure. When such locations cannot be avoided, it is recommended that a suit­able drain pan, adequately drained, be installed under the heater. The pan must not restrict air flow.
3
The heater may not be installed within five feet of the inside surface of a pool or spa unless it is separated by a solid fence, wall or other permanent barrier.
Propane (LPG) fired heaters must not be installed in Massachusetts, by order of the Massachusetts State Fire Marshall. For more information, call the Fire Marshall’s office.
DESCRIPTION OF THE HEATER
Figure 2 is a diagram of the heater showing how it operates. Precisely matched orifice plates meter the air and gas into
the mixer. The blower draws the air and gas through the mixer and forces it into the burner’s flameholder. A sealed heat exchanger surrounds the flameholder, discharging exhaust gases out the flue.
Two inch PVC water piping connects directly to the mani­fold/header on the heat exchanger using 2” PVC slip unions provided with the heater. The outer manifold remains cool; no heat sinks are required. A thermal regulator and an inter­nal bypass regulate the water flow through the heat exchanger to maintain the correct outlet temperature.
A plastic jacket with the top half split for access surrounds the assembly. The heater control board assembly, set into the top of the jacket, contains the operating controls.
SEQUENCE OF OPERATION
An electronic temperature sensing thermistor in the mani­fold adapter inlet controls the heater operation. When the inlet water temperature drops below the temperature set on the operating control, the burner controller supplies power to the combustion air blower through a series of safety interlocks. The interlocks consist of
• the pressure switch (PS), which senses that the pump is
running,
• the high limit switch (HLS), which opens if the heat
exchanger outlet temperature goes above 135°F (57°C), and
• the automatic gas shutoff (AGS) switch, which opens
if the heat exchanger outlet temperature goes above 140°F (60°C).
• the stack flue sensor (SFS), which shuts down the heater
if the flue gas temperature reaches 500°F (260°C).
The air flow switch (AFS) senses the pressure drop across the air metering orifice. As soon as there is sufficient air flow, the AFS closes, closing the circuit to the hot surface igniter (HSI), which ignites the fuel mixture.
On a call for heat, the blower and HSI are energized. In about 20 seconds, the gas valve opens and ignition occurs. The HSI then switches to a sensing mode and monitors the flame.
The heater is equipped with a digital operating control that enables the user to pre-set the desired pool and spa water temperatures. The control enables the user to select between pool and spa heating, and features a digital dis­play that indicates the water temperature.
OWNER’S OPERATING INSTRUCTIONS
FOR YOUR SAFETY READ BEFORE OPERATING
IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
START-UP AND OPERATION
START-UP AND SHUTDOWN INSTRUCTIONS ARE ON THE LABEL ATTACHED TO THE COVER OF THE APPLI­ANCE CONTROL BOX.
BEFORE START-UP
A. This appliance does not have a pilot. It is equipped
with an ignition device which automatically lights the burner. Do not try to light the burner by hand.
B. BEFORE OPERATING check for odor. Sniff all around
the appliance area for gas. Be sure to sniff next to the floor, because some gas (such as propane) is heavier than air and will settle on the floor.
4
FIGURE 2
Gas
Inlet (Cold Water)
Outlet (Mixed Water)
Air
Mixer
Burner
Blower
Heating Coils
Exhaust
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
C. Use only your hand to push in or turn the gas control
knob. Never use tools. If the knob will not push in or turn by hand, don’t try to repair it, call a qualified ser­vice technician. Force or attempted repair may result in fire or explosion.
D. Do not use this heater if any part has been under
water. Immediately call a qualified service technician to inspect the heater and to replace any part of the control system and any gas control which has been under water.
E. Do not operate the pool heater unless the pool or spa
is properly filled with water.
F. Before operating the appliance for the first time or after
it has been off for an extended time, perform the fol­lowing checklist:
1. Remove debris or other articles from inside the heater and the area around the heater and its exhaust vent. Make sure the ventilation openings are clear of debris or obstruction. For installations in an enclosed space, make sure openings for combustion and ventilation air are unobstructed.
2. Keep heater area clear and free from combustibles, flammable liquids and chemicals.
3. Check that all water connections are tight.
4. Water must be flowing through the heater during operation. Make sure that pool/spa is filled with water and have pump operating. Check that water flow is unobstructed from the appliance. When operating for the first time or after an extended shut­down, run filter pump for several minutes to clear all air from the system.
SPA TEMPERATURE CAUTION
All safety rules recommended by the U.S. Consumer Product Safety Commission should be observed when using a spa or hot tub, including:
1. Spa or hot tub water temperatures should never exceed 104°F (40°C). A temperature of 100°F (38°C) is consid­ered safe for a healthy adult. Special caution is sug­gested for young children.
2. Drinking of alcoholic beverages before or during spa or hot tub use can cause drowsiness which could lead to unconsciousness and subsequently result in drowning.
3. Pregnant women beware! Soaking in water above 102°F (39°C) can cause fetal damage during the first three months of pregnancy (resulting in the birth of a brain-damaged or deformed child). Pregnant women should follow the 100°F (38°C) maximum rule.
4. Before entering the spa or hot tub, users should check the water temperature with an accurate thermometer; spa or hot tub thermostats may err in regulating water temperature.
5. Persons with medical history of heart disease, circula­tory problems, diabetes or blood pressure problems should obtain their physician’s advice before using spas or hot tubs.
6. Persons taking medications which induce drowsiness, such as tranquilizers, antihistamines or anticoagulants, should not use spas or hot tubs.
OPERATING INSTRUCTIONS
1. STOP! Read the safety information above.
2. Set both pool and spa thermostats to the lowest settings.
3. Turn off all electric power to the appliance.
4. This appliance does not have a pilot. It is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand.
5. Remove the jacket cover(s) by unfastening the screws connecting both halves of the top jacket. See Figure 3.
5
FIGURE 3: Removal of Jacket Covers
6. Turn the knob on the gas control clockwise ( ) to the black line, depress slightly, and turn to “OFF” posi­tion. See Figure 4.
7. Wait five (5) minutes to clear out any gas. If you then smell gas, STOP! Follow “B” in the “Before Startup” instructions (Page 4). If you don’t smell gas, go to the next step.
8. Turn the knob on the gas control counter-clockwise () to the “ON” position. See Figure 5.
9. Replace jacket cover(s). All jacket covers must be in place when operating the appliance.
10. Set 3-way valves on inlet and outlet to pool or spa, as appropriate.
11.Turn on all electric power to the appliance.
12. Press either the POOL ON or SPA ON button switches on the operating control.
13. Set the thermostat to desired setting (NOTICE: Set point must be above actual water temperature or burn­er will not fire). See OPERATING CONTROL below.
14. The blower should come on immediately, and after about 20 seconds, the burner should fire. When oper­ating for the first time, the burner may not fire on the first try because of air in the gas line. If it does not fire at first, push the OFF switch, wait five minutes, and again push the POOL or SPA ON switch. The burner should fire after about 20 seconds. You may have to repeat this until all of the air has cleared the gas line.
15. The burner should fire until the pool/spa temperature reaches the desired temperature set on the thermostat. The blower will continue to run for about 45 seconds after the burner shuts off. If any of the safety interlocks should open during burner operation, the burner shuts off immediately, but the blower continues to run for about 45 seconds.
Should overheating occur or the gas supply fail to shut off, turn off the manual gas control valve to the appliance.
16. If the appliance will not operate, follow the instruc­tions “TO TURN OFF GAS TO THE APPLIANCE”, and call your service technician or gas supplier.
TO TURN OFF GAS TO THE APPLIANCE
1. Depress OFF button on operating control.
2. Turn off all electric power to the unit.
3. Remove jacket cover(s). See Figure 3.
HEATER PARTS MAY BE HOT.
4. Turn the knob on the gas control clockwise ( ) to the black line, depress slightly, and turn to “OFF” posi­tion. See Figure 4.
5. Replace jacket cover(s).
OPERATING CONTROL
6
FIGURE 4: Turning Gas Control OFF
FIGURE 5: Turning Gas Control ON
FIGURE 6: Operating Control. See Page 36 for External Control Interface.
Indexing Point
Gas control is shown ON. Turn Clockwise and press down to turn gas off.
You are
here
OFF
OFF
ON
Gas is now OFF
You are here
2671 1096
Indexing Point
Gas control is shown OFF. Turn Counter-clockwise and release to turn gas on.
ON
ON
OFF
Gas is now ON.
You are
here
2672 1096
You are here
Digital Temperature
Display
TemperatureUp/Down
Controls
System Operation
Indicator Lights
LOW SPEED
BOOSTER PUMP
HIGH SPEED
FILTER
PUMP
AUX
1
Dual Temperature
AUX
2
The five operating switches are:
POOL ON Press this button to govern heater operation by the pool temperature setting.
SPA ON Press this button to govern heater operation by the spa temperature setting.
OFF Press this button to switch off the heater.
TEMP Press this button to raise the temperature setting.
TEMP Press this button to lower the temperature setting. To toggle the display between degrees Centigrade (°C) and
degrees Farenheit (°F):
1. Turn the Operating Control OFF.
2. Press ▲TEMP or ▼ TEMP for 5 seconds. The display will flash once and change modes (°C to °F or vice versa).
When either the ▲TEMP or ▼ TEMP buttons are depressed, the digital display will indicate the temperature setting. After five seconds, the display will return to the actual pool/spa temperature.
In addition to the digital temperature display, there are five indicator lights:
The POOL ON light indicates that the pool water tempera- ture is governing operation of the heater.
The SPA ON light indicates that the spa water temperature is governing operation of the heater.
The HEATING light comes on and stays on when the burn­er is firing. This light should be on whenever the burner is on. It blinks when the heater is calling for heat but not fir­ing. If this light is on but the burner fails to come on, one of the “service” lights should come on, indicating a fault in the system.
The SERVICE SYSTEM light indicates that there is insuffi- cient water flow to the heater. If the pump is operating, this usually indicates that the filter and/or skimmers should be cleaned (some filters may require backwashing). If the light remains on after the filter/skimmers have been serviced, the system should be checked by a qualified service tech­nician.
The SERVICE HEATER light indicates a fault in the heater or its controls. If this light comes on, shut down the heater (See TO TURN OFF GAS TO THE APPLIANCE, at left), and have a qualified service technician check the system.
Risk of explosion or fire causing burns or
death if safety interlocks are disabled. DO NOT attempt to
operate heater when SERVICE HEATER light is on or if blower or burner will not start. Instead, follow instructions under “To Turn Off Gas to the Appliance”, at left, and call a qualified service technician to repair unit.
AFTER START-UP
CHECKING WATER FLOW
Fire or flooding hazard. If the unit overheats
and the burner fails to shut off, follow instructions under “To Turn Off Gas to the Appliance”, Page 6, and call a qualified service technician to repair unit.
After start-up, the outlet water pipe should feel slightly warmer than the inlet pipe. If it feels hot, or if you hear the water in the heater boiling, there may not be enough water flow to the appliance. Make sure that the filter is not plugged. If water temperature remains high but the unit continues to operate, turn off the appliance and call your service technician.
SPRING AND FALL OPERATION
If the pool is only used occasionally, lower the pool ther­mostat to 65°F (18°C). and leave the heater on. This will keep the pool and the surrounding ground warm enough so that the heater should restore the pool to a comfortable temperature within about one day.
COLD WEATHER OPERATION
The heater may be operated in the wintertime, provided air temperatures remain above freezing and the water temper­ature is not permitted to drop below 65°F (18°C). Extended heater operation with water temperatures below 65°F (10°C) can result in serious damage to the heater and is not covered by warranty.
NOTICE: When starting the heater for the swimming season with a water temperature below 50°F (10°C), the heater may be used to heat the water; however, make sure that the heater operates continuously until the water temperature reaches the heater’s minimum setting of 65°F (18°C).
DO NOT operate this unit outdoors at temperatures below 40°F (4°C).
During cold weather, if there is no danger of freezing, operate the filter pump continuously even if the heater is not operating. If air temperatures are expected to drop below freezing (32°F/0°C), shut down the heater and win­terize it (See ”WINTERIZING”, Page 8). Allowing the heater to freeze will void the warranty.
MAINTAINING POOL TEMPERATURE
To maintain pool temperature, make sure that the heater switch and valving are reset to pool settings after using the spa.
ENERGY SAVING TIPS
1. Keep the pool or spa covered when not in use. This will reduce heating costs, reduce water evaporation, con­serve chemicals and reduce load on the filtering system.
2. Reduce pool thermostat to 78°F (25°C) or lower; reduce spa temperature to 100°F (38°C).
3. Use a time clock to start the filter pump at 6 a.m. or later. The swimming pool loses less heat after daybreak.
4. For pools used only on weekends, lower the thermostat setting by 10°F to 15°F (5°C to 8°C) during the week to reduce heat loss. A properly sized heater will restore normal temperature within one day.
5. Turn the heater off when the pool will not be used for an extended period.
6. Follow a regular program of preventive maintenance for the heater each new swimming season. Check operation of the heater and its controls.
7
CARE AND MAINTENANCE
MAINTENANCE INSTRUCTIONS
Risk of fire or explosion from flammable
vapors. Do not store gasoline, cleaning fluids, varnishes,
paints, or other volatile flammable liquids near heater or in the same room with heater.
The following maintenance is recommended every six months and at the start of every swimming season:
1. Inspect the jacket and venting system to make sure that there are no obstructions to the flow of ventilating air or burner exhaust. Check that room air intakes are open and clear of obstructions.
2. Keep the area in and around the heater clear and free from combustible materials, gasoline and other flam­mable vapors and corrosive liquids.
3. Test the operation of the pressure relief valve by lifting the valve lever.
4. Test for proper operation of the pressure switch. (See “SWITCH SETTINGS” for testing instructions).
5. On enclosed installations with high-temperature Special Gas Vent systems, repeat the Final Installation Check, Page 15. Check for evidence of joint leakage. Make sure that joints have not slipped partially or completely apart. Check pipe and fittings for cracks or breaks.
The combustion air blower is permanently lubricated, and does not require periodic lubrication. The burner does not require maintenance or adjustment by the user. Call a qualified service technician if you suspect that the burner may require maintenance.
WINTERIZING (See Figure 7)
For outdoor heaters in freezing climates, shut the heater down and drain it for winter as follows:
1. Turn off electrical supply to the heater and pump.
2. Close main gas control valve and manual gas valve
(located outside the heater).
3. Open drain cock located on the bottom of the mani-
fold adapter, and drain the heat exchanger and mani­fold adapter completely. If heater is below pool water level, be sure to close isolation valves to prevent drain­ing the pool (isolation valves are not required and should not be used on heaters installed above pool water level). Assist the draining by blowing out the heat exchanger through the pressure switch fitting with low pressure compressed air (less than 5 PSI or 35 kPa).
Explosion hazard. Purging the system with compressed air can cause components to explode, with risk of severe injury or death to anyone nearby. Use only
a low pressure (below 5 PSI or 35 kPa), high volume blow­er when air purging the heater, pump, filter, or piping.
4. Remove the Water Pressure Switch. Plug the port in the
manifold to prevent bugs and dirt from getting into the manifold.
5. Drain the plastic inlet/outlet manifold through the out-
let pipe. If the pipe does not drain naturally to the pool, install a drain cock in the outlet pipe to drain the manifold.
6. Cover air inlet grate with a plastic bag to prevent bugs,
leaves, etc., from getting into the heater.
NOTICE: Water trapped in the heater can cause freeze damage. Allowing the heater to freeze voids the warranty.
To return the heater to service after winterizing:
1. Close drain cock and fittings.
2. Before starting the heater, circulate water through the
heater for several minutes until all air noises stop. See also “BEFORE STARTUP” (Page 4) and “CARE AND MAINTENANCE” (above).
8
OFF
ON
OFF
ON
FIGURE 7: Winterizing
Power
Combination Gas Control Valve OFF
Turn Clockwise and press down to turn off gas.
Manual/Gas Valve OFF
ON
OFF
VENT
PRESS
TAB
PILOT
O N
FF O
T EN V
SS E
PR
B A
T
OT
PIL
Remove Water Pressure Switch to help Manifold Drain
Drain Inlet/Outlet Manifold
Inlet
Open
2704 1196
Drain Cock(s) and Plugs OPEN
Close Isolation Valves
Outlet
INSTALLATION INSTRUCTIONS
Risk of fire, explosion, or asphyxiation if heater is improperly installed, adjusted, serviced or main­tained.
These instructions are for licensed, certified, trained and experienced installers only. Be sure your installer or service technician holds all required licenses or certification for your area. Attempts by unqualified persons to service or repair this heater are dangerous and could be fatal.
PUTTING THE HEATER INTO SERVICE
If the heater is installed below the level of the pool, or more than two feet above pool level, the pressure switch setting should be adjusted. See PRESSURE SWITCH, in the MAINTENANCE section.
Before putting the heater into service for the first time, fol­low the instructions under BEFORE STARTUP in the front of this manual. Check for proper operation of the heater by following the steps under OPERATING INSTRUCTIONS.
Damage to equipment caused by improper installation or repair will void the warranty.
OUTDOOR INSTALLATION INSTRUCTIONS
For heaters located outdoors, using the built-in stackless venting system.
Risk of explosion if a unit converted to propane gas is installed in a pit or other low spot. Propane is
heavier than air. Do not install the heater using propane in pits or other locations where gas might collect. Consult your local building code officials to determine installation require­ments of heater relative to propane storage tanks and filling equipment. Installation must meet the requirements of the Standard for the Storage and Handling of Liquid Petroleum Gases, ANSI/NFPA 58 (latest edition) in the U.S., or CAN/CSA B149.2 (latest edition) in Canada. Consult local codes and fire protection authorities about specific installation restrictions.
Locate the heater on a level surface in an open area that is protected from drainage or run-off. Install the heater in an area where leaves or other debris will not collect on or around the heater. Do not install the heater where water (including sprinklers or runoff) will fall directly onto the jacket.
HEATER CLEARANCES – OUTDOOR
The heater must be installed with the top of the vent at least 10 feet (3M) below, or to either side of, any opening into a building.
If the heater is located under a roof or deck overhang, there must be at least three feet (1M) clear space between the bottom of the overhang and the top of the heater exhaust vent. The heater must be at least six inches (15cm) from the nearest wall (clearance for service access will depend on the installation). If the heater is under a roof or deck overhang, the space around the heater must be open on three sides.
The heater is certified for installation on combustible flooring. The following clearances must be maintained from
combustible surfaces:
TOP...................................3 FEET (U.S.)
...................4 FEET (1.2M) (Canada)
ALL SIDES..................6 INCHES (15cm)
Orient the heater for convenient access to the water connections and the gas and electrical connections.
Install the heater at least 18 inches (45cm) from any property line.
9
FIGURE 8: Combustible clearances
3' (1M) or more
Outdoor installations must have at least 3' (1 M) of clearance above vent.
Space around unit must be open on three sides when under roof or overhang.
leave 6 in. (15 cm) of clear space between unit and combustible surfaces
TOP VIEW
6"
(15 cm)
CONTROL PANEL INDEXING
The exhaust discharges vertically from outside the vent cover. The heater control panel assembly on top of the jacket can be turned to any of six positions for convenient access to the panel as follows:
1. Unbolt and separate the jacket halves.
2. Pull hair pin clips.
3. Depress plastic clips on the control panel assembly.
4. Lift panel off of support plate.
5. Turn the assembly to the desired position and snap in
place.
6. Make sure that the operating controls can be
adjusted without having to lean over the exhaust vent.
7. Replace hair pin clips.
8. Replace jacket halves and bolts and tighten.
OUTDOOR SHELTER INSTALLATION INSTRUCTIONS
This pool heater can only be installed outdoors or in an enclosure that is not normally occupied and does not directly communicate with occupied areas.
Risk of asphyxiation if exhaust is not correct­ly vented. Follow venting instructions exactly when installing heater. Do not use a draft hood with this heater,
as the exhaust is under pressure from the burner blower and a draft hood will allow exhaust fumes to blow into the room housing the heater. Exhaust venting to the outdoors is required for all outdoor shelter installations.
Risk of explosion if a unit converted to propane gas is installed in a pit or other low spot. Propane is
heavier than air. Do not install the heater using propane in pits or other locations where gas might collect. Consult your local building code officials to determine installation require­ments of heater relative to propane storage tanks and filling equipment. Installation must meet the requirements for the Standard for the Storage and Handling of Liquified Petroleum Gases, CAN/CSA B149.2 (latest edition) or ANSI/NFPA 58 (latest edition). Consult local codes and fire protection authorities about specific installation restrictions.
The heater is design certified by CSA International for installation on combustible flooring; in alcoves; basements; in closet or utility rooms (in the U.S.)
INSTALLATION IN A GARAGE OR UTILITY ROOM
In Canada, this must be not normally occupied and must not directly communicate with occupied areas.
Risk of fire and explosion if installed at floor level in an automotive garage or near gasoline or flamma­ble liquid storage. Gasoline fumes are heavier than air and
will settle to floor level in closed spaces. Gasoline fumes and spilled gasoline or other volatile liquids (such as some paints and varnishes) will travel across the floor and can be ignited by a gas appliance. In a utility room or residential garage installation, install the heater with the base at least 18 inches (.5M) above the floor. In a garage, install a rail or wall to protect the heater from physical damage by a moving vehicle.
Provide an adequate ventilation air supply (See Table 2, Page 11). Choose a location that will avoid contamination by chemical fumes.
NOTICE: PROPANE (LPG) fired heaters must not be installed in garages in Massachusetts, by order of the Massachusetts State Fire Marshall. For more information, call the State Fire Marshall’s office.
NOTICE: Combustion air contaminated by corrosive chemical fumes can damage the heater and will void the warranty (See Table 1, Page 11).
10
FIGURE 9: Indexing Control Panel
FIGURE 10: Minimum outdoor shelter clearances (Canada) or minimum garage or utility room clearances (U.S.)
5
L OW
SP EE
D
BO
O
ST
ER
PU
M P
H IG
H
SP
E E
D
F I
L T E
R
P
U M
P
A
U
X
1
A
UX
2
3
1
4
2
2732 1296
6 in. (15 cm) clear space above
Raise at least 18" (.5 M) above floor to avoid flammable
18" (.5 M)
vapors
leave 6 in. (15 cm) of clear space between unit and
6"
(15 cm)
combustible surfaces
TOP VIEW
HEATER CLEARANCES – OUTDOOR SHELTER (Canada) or INDOOR (U.S.)
The following clearances must be maintained from com­bustible surfaces:
TOP ...........................6 INCHES (15cm)
ALL SIDES..................6 INCHES (15cm)
VENT .........................6 INCHES (15cm)
The heater is design certified by CSA International for installation on combustible flooring. For installation on car­peting, the heater must be mounted on a metal or wood panel that extends at least three inches (10cm) beyond the base of the heater. If the heater is installed in a closet or alcove, the entire floor shall be covered by the panel.
On an outdoor shelter installation, the exhaust discharges into a vent pipe. Orient the heater so that the vent pipe does not interfere with adjustment of the operating controls. The operating control panel located on top of the jacket can be rotated for convenient access to the control panel.
COMBUSTION AND VENTILATION AIR SUPPLY
For shelter installation, the heater requires air supply open­ings for ventilation and combustion. The minimum require­ments are for two (2) openings: one 12 inches (30cm) from the ceiling for ventilation air and one 12 inches (30cm) from the floor for combustion air, in accordance with the latest edition of ANSI Z223.1, or the National Fuel Gas code, the
CSA B149.1, Natural Gas and Propane Installation Codes, as applicable, and any local codes that may apply.
The minimum net free area in square inches shall be as follows:
OUTDOOR SHELTER VENT INSTALLATION (Canada) or INDOOR INSTALLATION (U.S.)
Always vent the heater to the outdoors.
•Vent it horizontally or vertically using a Special Gas
Vent, (see Table 4, Page 14), or
•Vent it vertically using Type “B” double wall vent con-
nector pipe.
Locate the heater so as to minimize the length of horizon­tal venting and the number of vent elbows required. Horizontal vent runs must slope up 1/4” per foot (2cm/M) from the heater to allow exhaust condensate to drain and must have a condensate drain as described in the venting installation instructions.
11
Area Likely Contaminants
Chlorinated swimming Pool or spa cleaning pools and spas chemicals. Acids, such as
hydrochloric or muriatic acid
New construction and Glues and cements, remodeling areas construction adhesives,
paints, varnishes, and paint and varnish strippers. Waxes and cleaners containing calcium or sodium chloride
Beauty parlors Permanent wave solutions,
bleaches, aerosol cans containing chlorocarbons or fluorocarbons
Refrigeration plants or Refrigerants, acids, glues various industrial and cements, construction finishing and processing adhesives plants
Dry cleaning and Bleaches, detergents, or laundry areas laundry soaps containing
chlorine. Waxes and cleaners containing chlorine, calcium or sodium chloride
All Air From All Air From
Inside Building Outside Building
Model Combustion Vent Combustion Vent
200
200 sq. in. 200 sq. in. 50 sq. in. 50 sq. in.
1,291 sq. cm. 1,291 sq. cm. 323 sq. cm. 323 sq. cm.
333
333 sq. in. 333 sq. in. 84 sq. in. 84 sq. in.
2,149 sq. cm. 2,149 sq. cm. 542 sq. cm. 542 sq. cm.
400
400 sq. in. 400 sq. in. 100 sq. in. 100 sq. in.
2,581 sq. cm. 2,581 sq. cm. 645 sq. cm. 645 sq. cm.
Table 1: Corrosive Vapors and
Possible Causes
FIGURE 11: Flue Collar
Table 2: Combustion and Ventilation
Air Requirements
Vent Body
Clean the Interior Surface
4" x 8" Metal Flue Collar
Vent Pipe
Combustion Chamber Flue Collar
Clean and RTV This Surface
2855 0597 RTV
OUTSIDE VENT COVER REMOVAL
The heater is supplied from the factory with a built-in stackless outside vent for outdoor installation. Remove the outside vent cover for outdoor shelter installation.
VERTICAL VENTING - NEGATIVE PRESSURE
(See Figures 11 and 12)
Vent the heater vertically in a negative pressure (positive draft) system in accordance with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 and/or CSA B149.1, National Gas and Propane Installation Codes, and local codes. Type “B” Double-wall vent connector is recommended; however sin­gle-wall pipe is allowed by the National Fuel Gas Code in some circumstances. Consult your local code official for detailed information. Do not use a draft hood with this heater.
To connect a negative pressure metal gas vent to the heater, order the appropriate Metal Flue Collar from the chart below:
1. See Table 3, below, to determine allowable vent sizes for your heater.
NOTICE: Table 3 is for installations in which the total later­al vent length (that is, the horizontal distance from the flue collar to the main vertical portion of the vent) is less than 1/2 the total vent height (the vertical distance from the flue collar to the vent termination) and which have three or less elbows in the system. For venting systems which do not meet these conditions, consult the National Fuel Gas Code, ANSI Z223.1 (U.S.), or the standards CSA B149.1 and B149.2 (Canada).
2. Install the metal Flue Collar in the Vent Body of the heater (located under the outside vent cover). Fasten the metal Flue Collar to the Vent Body with two #10 sheet metal screws. Use UltraCopper
®
silicone RTV to seal the
Flue Collar to the Vent Body. Before connecting the metal Flue Collar to the Vent Body, wet a clean cloth or paper towel with isopropyl alcohol (rubbing alcohol) and vigorously wipe the socket of the Vent Body. Immediately wipe the cleaned surfaces dry with a clean cloth or paper towel. Repeat for the exterior of the 4” end of the metal Flue Collar. Attach the metal Flue Collar to the Vent Body using the RTV supplied with the kit, fol­lowing the vent manufacturer’s instructions (included with kit). Do not use a draft hood with this heater.
3. Attach the vent pipe to the metal Flue Collar with sheet-metal screws.
Risk of fire or asphyxiation if vent is not assembled according to manufacturer’s instructions or if vent parts from different manufacturers are mixed. Vent
parts from different manufacturers ARE NOT interchange­able. Mixing parts from more than one manufacturer may cause leaks or damage to vent. When assembling a vent, pick one manufacturer and be sure that all vent parts come from that manufacturer and are specified by the manufac­turer for your system. Follow manufacturer’s instructions, local code requirements, National Fuel Gas Code require­ments (U.S.) or standards CSA B149.1 and B149.2 (Canada) carefully during assembly and installation.
4. Install vent pipe so that it can expand and contract
freely as the temperature changes. Support the vent pipe according to applicable codes and the vent manufactur­er’s instructions. Pipe support must allow the vent pipe free movement out and back, from side to side, or up and down as necessary, without putting a strain on the heater or vent body. Slope horizontal pipe runs up from the heater at least 1/4” per foot (2cm per meter). Install Listed condensate drains at low points where conden­sate might collect. Plumb condensate drains to a drain through hard piping or high-temperature tubing such as silicone rubber or EPDM rubber – do not use vinyl or other low temperature tubing. Follow drain manufactur­er’s installation instructions.
12
Table 3: Permitted Minimum and Maximum Vent Heights By Size and Heater Model
Read “VERTICAL VENTING – NEGATIVE PRESSURE” (above) before using this table.
Type B Double Wall Vent With Type B Double Wall Connector In Feet (Meters)
Model 200 Model 333 Model 400
Vent Size Min. Height Max. Height Min. Height Max. Height Min. Height Max. Height
6 in. 6 Ft. (1.8) 100 Ft. (30.5) 30 Ft. (9) 100 Ft. (30.5) Not Rec. Not Rec. 7 in. 6 Ft. (1.8) 100 Ft. (30.5) 10 Ft. (3) 100 Ft. (30.5) 15 Ft. (4.6) 100 Ft. (30.5) 8 in. 6 Ft. (1.8) 100 Ft. (30.5) 6 Ft. (1.8) 100 Ft. (30.5) 8 Ft. (2.4) 100 Ft. (30.5)
9 and 10 in. 6 Ft. (1.8) 50 Ft. (15.3) 6 Ft. (1.8) 100 Ft. (30.5) 6 Ft. (1.8) 100 Ft. (30.5)
Type B Double Wall Vent With Single Wall Connector In Feet (Meters)
Model 200 Model 333 Model 400
Vent Size Min. Height Max. Height Min. Height Max. Height Min. Height Max. Height
6 in. 6 Ft. (1.8) 15 Ft. (4.6) Not Rec. Not Rec. Not Rec. Not Rec. 7 in. 6 Ft. (1.8) 8 Ft. (2.4) 10 Ft. (3) 20 Ft. (6) 15 Ft. (4.6) 50 Ft. (15.3) 8 in. Not Rec. Not Rec. 6 Ft. (1.8) 20 Ft. (6) 8 Ft. (2.4) 20 Ft. (6) 9 in. Not Rec. Not Rec. Not Rec. Not Rec. 6 Ft. (1.8) 6 Ft. (1.8)
10 in. Not Rec. Not Rec. Not Rec. Not Rec. Not Rec. Not Rec.
Metal Flue Collar Sta-Rite Part No.
4x6” 77707-0076
4x8” 77707-0077
5. Use Listed firestops for floor and ceiling penetrations. Use Listed thimble for wall penetrations. Use a Listed roof flashing, roof jack, or roof thimble for all roof pen­etrations. Do not fill the space around the vent (that is, the clear air space in the thimble or firestop) with insulation. The roof opening must be located so that the vent is vertical.
6. Do not run the heater vent into a common vent with any other appliance.
7. Fire Hazard. Do not vent the heater directly into a masonry chimney. Installation into a masonry chimney must use a chimney liner and must meet the National Fuel Gas Code, ANSI Z223.1/NFPA 54 and/or CSA B149.1, Natural Gas and Propane Installation Codes requirements and all local code requirements.
HORIZONTAL OR VERTICAL VENTING ­POSITIVE PRESSURE (See Figure 13)
Vent the heater either horizontally or vertically using one of the 4-inch Special Gas Vent Pipes listed on Page 14 (Table 5). Install the vent pipe in accordance with local codes and the provisions of the National Fuel Gas Code, ANSI Z223.1 (U.S.), or the standards CSA B149.1, Natural Gas and Propane Installation Codes (Canada), and the vent manufacturer’s instructions. Do not use a draft hood with this heater. Use one of the special gas vents specified in Table 5 (Page 14) for positive-pressure venting of this heater – do not use any other vent with it. Install the vent according to the vent manufacturer’s detailed instructions.
Maintain clearance between the vent pipe and combustible surfaces according to the vent manufacturer’s instructions and code requirements. Do not place any insulating mate­rials around the vent or inside the required clear air space surrounding the vent. See Table 6 (Page 15) for maximum permissable vent lengths. See Table 7 (Page 15) for Listed vent components.
CONNECTING SPECIAL GAS VENT TO THE HEATER
Metallic:
1. Order an Appliance Adapter kit: Sta-Rite Part No. 77707-0086 for Saf-T Vent
®
or Saf-T Vent® CI. Sta-Rite Part No. 77707-0087 for Z-Vent.
2. Remove the outside vent cover.
3. Install the Appliance Adapter in the Vent Body of the heater (located under the outside Vent Cover). Before connecting the Appliance Adapter to the Vent Body, wet a clean cloth or paper towel with isopropyl alco­hol (rubbing alcohol) and vigorously wipe the socket of the Vent Body. Immediately wipe the cleaned sur­faces dry with a clean cloth or paper towel. Repeat for the exterior of the heater end of the Appliance Adapter. Attach the appliance adapter to the vent body using the adhesive specified by the vent manufacturer, fol­lowing the vent manufacturer’s instructions.
Risk of carbon monoxide poisoning if adapter is improperly attached. Mechanical connections (such as screws) can cause cracking and leaks in the adapter. Do
not drill holes or use screws to connect the appliance adapter to the heater vent body. Attach with manufacturer’s specified adhesive.
13
FIGURE 12A: Typical Metal Vent Pipe Installation-Canada (Vertical – Negative Pressure)
FIGURE 12B: Typical Metal Vent Pipe installation-U.S. (Vertical – Negative Pressure)
Listed Termination
Min. 2 Ft.
(.7 M)
6" (15 cm) Minimum Clearance to Combustible Materials
Min. 10 Ft. (3.3 M)
Type B Double Wall
Metal Vent Pipe
Vent Body
2731 1296 CAN
Metal Flue
Collar
Condensate Drain w/trap
Cap
Storm Collar
Flashing
Firestop
Type B Double Wall
Metal Vent Tee
Support Vertical Vent Pipe so adapter does not take weight of pipe. Dispose of condensate according to local codes.
Listed Termination
Min. 8 Ft.
See Table 4 For Min. Hght.
6" Minimum Clearance to Combustible
Materials
Class B Double Wall
Metal Vent Pipe
Metal Flue
Vent
Body
Collar
Cap
Storm Collar
Flashing
Firestop
Support Vertical Vent Pipe so adapter does not take weight of pipe.
Risk of fire or asphyxiation if vent is not assembled according to manufacturer’s instructions or if vent parts from different manufacturers are mixed. Vent
parts from different manufacturers ARE NOT interchange­able. Mixing parts from more than one manufacturer may cause leaks or damage to vent. When installing a vent, pick one manufacturer and be sure that all vent parts come from that manufacturer and are specified by the manufac­turer for your system. Follow manufacturer’s instructions and local and National Fuel Gas Code (U.S.) or CSA B149.1, Natural Gas and Propane Installation Codes (Canada) requirements carefully during assembly and installation.
4. Install vent pipe so that it can expand and contract
freely as the temperature changes. Support the vent pipe according to applicable codes and vent manufac­turer’s instructions. Pipe support must allow the vent pipe free movement out and back, from side to side, or up and down as necessary, without putting a strain on the heater or vent body. Slope horizontal pipe runs up
from the heater at least 1/4” per foot (2cm/M). Install Listed condensate drains at low points where conden­sate might collect. Plumb condensate drains to a drain through hard piping or high-temperature tubing such as silicone rubber or EPDM rubber – do not use vinyl or other low temperature tubing. Follow drain manu­facturer’s installation instructions.
5. Use Listed firestops for floor and ceiling penetrations. Use Listed thimble for wall penetrations. Use a Listed roof flashing, roof jack, or roof thimble for all roof pen­etrations. Do not fill the space around the vent (that is, the clear air space in the thimble or firestop) with insulation. The roof opening must be located so that the vent is vertical.
6. Vent Termination – Vertical (See Figures 12A and 12B, Page 13, for height of vent termination above the roof. See Table 7, Page 15, for Listed terminations.) Use a Listed vent terminal specified by local and national codes and your manufacturer’s instructions. A roof ter­mination must be vertical. In Canada, the Vent Cap location shall have a minimum clearance of 4 feet (1.2M) horizontally from electric meters, gas meters, regulators, and relief openings.
7. Vent Termination – Horizontal (See Table 7). Use a list­ed wall thimble and vent terminal from Table 7.
The terminal must be located (U.S.-See Figure 13):
• at least 3” and at most 12” out from the wall (see Figure
14), following the vent manufacturer’s instructions.
• at least 12” above finished grade or the normally
expected snow accumulation level, whichever is higher
• at least 4 feet below or horizontally from, or 1 foot
above, any doors or windows or gravity air inlet to a building
• At least 3 feet above any forced air inlet located within
10 feet
• At least 4 feet horizontally from electric meters, gas
meters, regulators and relief equipment
• At least 7 feet above grade adjacent to walkways or sim-
ilar traffic areas.
14
Brand Manufacturer Material Type Sealant
Saf-T Vent
®
4” Heat-Fab, Inc. Metal Consult Manufacturer Special Gas Vent 38 Hayward Street (Single Wall) Greenfield, MA 01301
(800) 772-0739
Saf-T CI Vent
®
Heat-Fab, Inc. Metal Consult Manufacturer Special Gas Vent 38 Hayward Street (Double Wall) Greenfield, MA 01301
(800) 772-0739
Z-Vent 4” Special Z-Flex U.S., Inc. Metal G.E. RTV 106 Gas Vent (Type BH), 20 Commerce Park North Model SVE Bedrford, NH 03110-6911
(800) 654-5600
Table 5: Recommended Special Gas Vents (Positive Pressure)
Minimum Height
Roof Pitch Above Roof*
Flat to 6/12 1 Ft.
6/12 to 7/12 1 Ft. 3 in. >7/12 to 8/12 1 Ft. 6 in. >8/12 to 9/12 2 Ft.
>9/12 to 10/12 2 Ft. 6 in. >10/12 to 11/12 3 Ft. 4 in. >11/12 to 12/12 4 Ft.
>12/12 to 14/12 5 Ft. >14/12 to 16/12 6 Ft. >16/12 to 18/12 7 Ft. >18/12 to 20/12 7 Ft. 6 in. >20/12 to 21/12 8 Ft.
*Vent must be at least eight (8) feet away from nearest vertical surface. Vents extending five (5) feet or more above the roof must be braced or guyed. Consult your local code officials for detailed information.
Table 4: Vent Termination Height vs.
Roof Pitch – U.S.
The terminal must be located (Canada):
• at least 10 feet (3.3M) from any opening into a building.
•at least 12” (.3M) above finished grade or the normally expected snow accumulation level, whichever is higher
• At least 4 feet (1.2M) horizontally from electric meters, gas meters, regulators and relief equipment
• At least 7 feet (2.1M) above grade adjacent to walkways or similar traffic areas.
Allow at least three feet (1M) vertical clearance over vent termination when terminating under an overhang or deck.
Avoid corners or alcoves where snow or wind could have an effect. Exhaust may affect shrubbery and some building materials. Keep shrubbery away from termination. To pre­vent staining or deterioration, sealing or shielding exposed surfaces may be required.
8. Fire Hazard. Do not run the heater vent into a common vent with any other appliance. Do not run the Special Gas Vent into, through, or within any active vent such as a factory built or masonry chimney.
Final Installation Check:
Check that horizontal vent pipe runs slope uniformly at least 1/4” per foot (2cm per meter) to condensate drain(s). No sags, no dips, no high or low spots.
Check that vent is supported at elbows, tees, and horizon­tal and vertical runs according to manufacturer’s instruc­tions and code requirements.
Check that vent supports and wall and ceiling penetrations allow free movements up, down, and sideways without putting any strains on the heater or vent body.
Check for at least six inch (15cm) free air clearance between the heater vent pipe and combustible materials.
Check that all joints are completely together and sealed.
WATER CONNECTIONS
The heater requires proper water flow and pressure for its operation. See Figures 15 and 16 for the recommended installation. The filter pump discharges to the filter, the fil­ter discharges to the heater, and the heater discharges directly to the pool or spa.
15
Vent Brand Wall Thimble Horizontal Terminal Vertical Terminal
Saf-T Vent
®
(Part of Vent term.) 5490CI Horizontal Term. 5400 Cap
Saf-T CI Vent
®
(Part of Vent term.) 5490CI Horizontal Term. 5400 Cap
Z-Vent 2SVSWTF04 2SVSTTF04 Tee 2SVSRCF04 Cap
Table 7: Listed Thimbles and Vent Terminals (for Special Gas Vents)
4” Special Gas Vent (Vertical or Horizontal)*
No. of 90° Elbows Maximum Length in Feet (M)
0 25 Ft. (7.6M) 1 20 Ft. (6.1M) 2 15 Ft. (4.6M) 3 10 Ft. (3.1M)
* Minimum vent length is one foot (.34M), or in accordance with vent manufacturer’s instructions, and local and national codes.
Horizontal vents 3’ (1M) or less in length do not require a conden­sate tee, but must slope down toward the outlet at 1/4” to the foot (2cm/M) to allow condensate to drain.
FIGURE 14: Typical Special Gas Vent Pipe Installation (Horizontal-Positive Pressure)
Max 12"
FIGURE 13: U.S. minimum Exhaust Vent clearances. Local codes may differ - consult local code officials.
Table 6: Maximum Vent Length
Min 3"
Vent Termination
At least 7' above grade adjacent to public walkways
Vent Termination
1' Minimum above snow or finished grade (whichever is higher)
Forced Air Inlet
4' Min.
4' Min.
Gas Meter
3' Minimum clearance if horizontal distance to exhaust opening is less than 10 feet.
4' Min.4' Min.
Vent Termination
1' Min.
Metal Vent Body
Metal Special Gas Vent requires Appliance Adapter
Condensate drain w/Trap
Support weight of pipe
Condensate Te e
Slope at least 1/4" per foot (2 cm per Meter) down towards condensate drain
Listed Terminal
3" (7.6 cm) Min., 12" (30.5 cm)Max. Clearance
A manual bypass valve should be installed across the heater when the pump flow exceeds 120 GPM (454 LPM). See instructions below for setting of the manual bypass.
Make sure that the outlet plumbing from the heater con­tains no shut-off valves or other flow restrictions that could prevent flow through the heater (except as noted below). To switch flow between the pool and spa, use a diverter valve. Do not use any valve that can shut off the flow.
Do not use a shut-off valve to isolate the heater unless it is below the level of the pool or spa.
Install a check valve to prevent back-siphoning through the heater when the pump is off.
NOTICE: Improper operation of chemical feeders can cause severe damage to the heater which is not covered by the warranty. Install the chemical feeder downstream of the heater (see “Water Chemistry,” Page 17).
Install a chemical resistant one-way check valve between the heater and the chemical feeder.
NOTICE: If you install a chemical feeder and check valve, you must install a relief valve on the heater. See “Pressure Relief Valve”, Page 18 and 19.
NOTICE: If the heater is plumbed in backwards, it will cycle continuously. Make sure piping from filter is not reversed when installing heater.
WATER PIPING
Connect the heater directly to 2” PVC pipe, using the inte­gral unions provided. Heat sinks are not required. The low thermal mass of the heater will prevent overheating of the piping connected to the pump even if the heater shuts down unexpectedly.
16
FIGURE 15: Typical installation
FIGURE 16: Typical pool piping layout
3-Way
Valve
Main
Drain
Pool
Spa
3-Way
Valve
From Pool
Chlorinator
Heater
Filter
Pump
3-Way
Valve
SYSTEM 3
Modular Media
Filter
To Filter
Inlet
From Filter Outlet
to Heater
Inlet
Corrosion Resistant,
Positive Seal
Check Valve
Cool Water In From Spa
Warm Water Out to Pool or Spa
To Pool
To Spa
Sanitizer
2735 1296
Cool Water In From Pool
17
WATER FLOW RATE
Maximum and minimum water flow rates required by the heater are listed below:
If the water flow rate to the heater is above 120 GPM (454 LPM), it must be reduced by installing a manual bypass valve (Figure 17). After installing the valve, adjust the valve to bring the flow rate within the acceptable range. Then remove the valve handle or lock it in place to prevent tampering.
Occasionally a two-speed pump will not develop enough pressure on the low speed to operate the heater. In this case, run the pump at high speed only to operate the heater. If this does not solve the problem, do not try to run the heater. Instead, correct the installation.
Do not operate the heater while an automatic pool cleaner is also operating. If the circulation pump suction is plugged (for example by leaves), there may not be adequate flow to the heater. Do not rely on the pressure switch in this case.
WATER CHEMISTRY
Water chemistry should follow good swimming pool water chemistry practices. See Table 9 (below) for water chem­istry parameters.
When using a chlorinator, install it downstream from the heater and at a lower level than the heater outlet. Install a corrosion resistant positive seal check valve (see Figure 15) between the heater and the chlorinator to prevent concen­trated chemicals from back-siphoning into the heater. Back-siphoning is most likely to occur when the pump stops, creating a pressure-suction differential.
Do NOT sanitize the pool by putting chlorine tablets or sticks into the skimmer(s). When the pump is off, this will cause a high concentration of chlorine to enter the heater, which could cause corrosion damage to the heat exchanger.
Model Minimum Flow Maximum Flow
200 20 (76) 120 (454) 333 33 (125) 120 (454) 400 40 (152) 120 (454)
Table 9: Water Chemistry Parameters
Disinfectant levels Minimum Ideal Maximum
Free Chlorine, ppm 1.0 2.0-4.0 10.0 Combined Chlorine, ppm None None 0.2 Bromine, ppm 2.0 4-6 10.0 Other Sanitizers Levels not established. Consult local health department before use.
Chemical Values
pH 7.2 7.4-7.6 7.8 To tal Alklinity (Buffering), ppm 60 80-100 180 as CaCO
3
Total Dissolved Solids, ppm N/A N/A 1,500 ppm > TDS at startup* Calcium Hardness, ppm, as CaCO
3
150 200-400 500-1,000
Heavy Metals None None None
Biological Values
Algae None None None Bacteria None None Refer to Local Code
NOTICE: Failure to adhere to the listed water chemistry parameters may result in premature failure of the heat exchanger and will void the warranty. *Start-up TDS includes source water TDS and any other inorganic salt added at start-up.
Table 8: Maximum and Minimum
Flow Rate in GPM (LPM)
FIGURE 17: Manual bypass valve
Cool Water In
Warm Water Out
2680 1096
1. Set Manual Bypass Valve
2. Remove handle
Outlet to
Pool
Inlet from
Filter
18
WATER PRESSURE SWITCH
Hazardous pressure. Do not bypass the Water
Pressure Switch or render it inoperable.
Switch Settings
The water pressure switch turns off the burner if the water flow is interrupted. If the water flow is restricted, the water pressure switch may prevent the burner from firing and cause the “Service System” light to go on. If the light remains on after the filter has been serviced, have a quali­fied service technician check the system.
For deck-level heater installations, the Pressure Switch is factory set at 3 psi (20.6 kPa). If the pressure switch is one to two feet (.3-.6M) below or one to five feet (.3-1.5M) above the pool water level, reset the switch so that it is open when the pump is off and closed when the pump is running. Turn the star-wheel on the switch clockwise ( ) to raise setting (heater below the pool) and counterclock­wise ( ) to lower the setting (heater above the pool – see Figures 18 and 19). Test the switch after resetting.
NOTICE: When the heater is mounted more than five feet (1.5M) above or two feet (.6M) below the deck level, a
Pressure Switch is no longer adequate. A Flow Switch must be installed instead.
NOTICE: Heater operation with incorrect Pressure Switch setting may cause operation with no water flow. Operation of the heater without sufficient water flow may severely damage it.
Verify proper operation of the water pressure switch at the start of every season and every six months thereafter by the following steps:
1. Lower the thermostat setting to turn off the heater.
2. Wait at least 15 minutes after the burner is off, and then turn off the filter pump.
3. Turn up the thermostat as though to fire the burner.
4. Wait one minute. The “Service System” light should go on but the burner should not fire and the blower should not start. If the blower or burner do start, or if the “Service System” light does not go on, there is a pres­sure switch malfunction. Immediately press the OFF but­ton on the operating control to turn the burner off and call a qualified service technician to check the system.
Live steam hazard. If the Burner and the Pump stop at the same time, wait at least 15 minutes before starting the filter pump to avoid severe damage to the heater.
PRESSURE RELIEF VALVE
Canadian code requires and some U.S. local codes may require installation of a pressure relief valve. Purchase sep­arately and install a 3/4” pressure relief valve complying with the ANSI/ASME Boiler and Pressure Vessel Code, hav­ing a capacity equal to the Btu/hr rating of the heater. The relief pressure of the valve MUST NOT EXCEED 50 PSI.
A 3/4” NPT connection is provided in the manifold for installing a pressure relief valve. The relief valve must be installed vertically. To install the valve, use a 3/4” brass nipple and elbow (user supplied), as illustrated in Figure
20. No valve is allowed to be placed between the manifold adapter and the relief valve.
FIGURE 20: Relief Valve
FIGURE 19: Water Pressure Switch Adjustment
FIGURE 18: Remove cover for access to Switch
Raise Pressure
Raise
pressure set point if pressure switch is More than 2 feet (.6M)
below
water level
Lower Pressure
2734 1296 CAN
Relief Valve Installed
User supplied pipe fittings
Lower
pressure set point if pressure switch is more than 5 feet (1.5M)
above
water level
Back of pressure switch has a reference scale.
Pipe relief valve discharge to a drain or other safe disposal site.
2681 1096
19
To avoid water damage or scalding from operation of the relief valve, install a drain pipe in the outlet of the pressure relief valve that will direct water discharging from the valve to a safe place for disposal. Do not install any reduc­ing couplings or valves in the drain pipe. The drain pipe must be installed so as to allow complete drainage from the valve and drain line. The relief valve should be tested at least once a year by lifting the valve lever.
Explosion hazard. Any heater installed with
restrictive devices in the piping system downstream from the heater (including check valves, isolation valves, flow nozzles, or therapeutic pool valving) must have a relief valve installed as described above.
Risk of fire and explosion. Improper installation, adjustment, alteration, service, or main­tenance of the Combination Gas Control Valve can lead to fire or explosion, causing loss of life, per­sonal injury, or property damage.
These instructions are for the use of qualified service technicians only!
Do not attempt this procedure unless you have been trained and certified in the care and repair of gas-fired appliances!
Do not attempt this procedure if the following instructions are confusing!
This appliance is equipped with an unconventional gas control valve that is factory set with a manifold pressure of –.2” (–0.5cm) wc. Installation or service must be per­formed by a qualified installer, service agency, or the gas supplier. If this control valve is replaced, it must be replaced with an identical control.
The combination gas valve incorporates dual shut-off valves and a negative-pressure regulator. For proper operation, the regulated pressure at the outlet manifold of the valve must be 0.2” (0.5cm) wc below the refer­ence pressure at the blower mixer inlet, and the gas valve ‘VENT’ tap must be connected to the endcap air orifice as shown in Figure 21 (above).
Do not attempt to adjust the gas input by adjusting the regulator setting. The correct gas regulator setting is required to maintain proper combustion and must not be altered.
To check that the gas pressure setting is correct, use the following procedure:
1. Turn off the heater and remove the top covers for
access to the Combination Gas Control Valve.
2. Use a 3/16” hex key to remove the plug from the
‘PRESSURE TAP’ port on the outlet side of the
Combination Gas Control Valve.
3. Install a 1/8” NPT barbed fitting into the ‘PRESSURE
TAP’ port. Use a flexible tube to connect it to the low side of a differential pressure gauge or a slope gauge.
NOTICE: If you are using a slope gauge or a differ­ential pressure gauge of less than 3” capacity, close the shutoff valve of the gauge to avoid pulling the liq­uid out of the gauge when the blower starts.
4. Disconnect the tube from the Gas Valve ‘VENT’ port. Connect it to a tube with a tee running to the high side of a differential pressure gauge and to the blow­er’s air orifice grille (See Figure 21, above).
5. Turn on the heater and verify the gas supply pres­sure (Page 20).
6. After the burner ignites, open the shutoff valve of the gauge. The pressure gauge should then read 0.2” wc ±0.1” wc (0.5cm wc ± 0.25cm wc) (0.0” to 0.1” wc (0.0 to 0.2 cm) = rich mixture; 0.3” (.75 cm) and above = lean mixture). (Since the pressure tap is connected to the low side of the gauge, the pressure is actually negative.)
Risk of fire or explosion if Combination Gas Control Valve is incorrectly adjusted. If it is necessary to adjust the gas valve, this must be done only by a qualified service agency.
7. Turn off the heater.
8. Replace the plastic hose between the ‘VENT’ port and the inlet of blower mixer. Remove the barbed fit­ting and replace the plug in the ‘PRESSURE TAP’ port of the gas valve, using a thread sealant approved for use with natural gas and propane.
9. Replace the heater covers and cycle the heater to check for proper operation.
Instructions For Checking the Gas Pressure
Through the Combination Gas Control Valve
OFF
ON
OFF
ON
FIGURE 21: Connect Gas Valve to End Cap Air Orifice
To High Side of Differential Pressure Gauge
ON
CAUTION
OFF
VENT
PRESS
TAP
PILOT
Connection for Service
Connection for Test
To Low Side of Diff. Pressure Gauge
O
N
F F O
T EN V
SS RE P
B TA
T ILO P
2788 0397
To Air Flow Switch
NOTICE: The gas
piping and unions are not shown for clarity; make this test with all gas piping connected (as for normal service).
20
GAS CONNECTIONS
The heater requires a gas supply of not less than 4” (10.2cm) wc and not more than 14” (35.6cm) wc. Gas supply pressures outside of this range may result in improper burner operation. A minimum inlet pressure of 4” (10.2cm) wc is required to maintain input rating.
The gas supply must be installed in accordance with the National Fuel Gas Code, ANSI Z223.1, or standard CSA B149.1, Natural Gas and Propane Installation Codes, as applicable and all applicable local codes. Install a manual shut-off valve and a sediment trap and union located out­side the heater jacket (Figure 22). Do not use a restrictive gas cock.
The following gas pipe sizes are recommended for natural gas supply piping. For low pressure LP gas, pipe size may be reduced by 1/4”, with a minimum pipe size of 3/4”. Check for compliance with local codes.
NOTICE: DO NOT use a corrugated flexible gas line to supply the heater. it will not deliver enough gas (at nominal diameter) to supply heater.
PRESSURE TESTING
Before operating the heater, the heater and its gas connec­tions must be leak tested. Test all gas connections for leaks with soapy water.
Risk of fire or explosion. Do not use an open
flame to test for leaks. The heater and its individual shutoff valve must be discon-
nected from the gas supply piping system during any pres­sure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa).
The heater must be isolated from the gas supply system by closing its individual manual shutoff valve during any pres­sure testing of the gas supply at test pressures equal to or less than 1/2 psig (3.5 kPa).
SUPPLYING POWER TO THE HEATER
The heater requires a 120 or 240V/60Hz/1Ph power sup­ply. Enclose the line to the heater in an approved flexible conduit connected directly to the junction box on the inside of the heater jacket.
Line voltage field wiring should be 14 gauge, with a circuit capacity of 15 amps.
ELECTRICAL WIRING
1. All wiring must be in accordance with all applicable codes.
2. The heater, when installed, must be electrically grounded and bonded in accordance with local codes or, in the absence of local codes, with the National Electrical Code or the Canadian Electrical Code (as applicable). A bonding lug is provided on the outside of the jacket under the vent for this purpose.
3. Electrical power circuits to the pool heater must follow local codes and National Electrical Code or Canadian Electrical Code (as applicable).
4. All wiring between the heater and devices not attached to it, or between separate devices which are field installed and located, shall conform to the specifica­tions of Type T wire (35°C rise).
5. All line voltage wiring shall be enclosed in approved flexible conduit, and shall be securely attached to the field wiring box located inside the jacket. The conduit or cable connector at the field wiring box should con­tain an insulating bushing or its equivalent to prevent abrasion of the wires as they enter the box.
6. The filter pump should run continuously when the
heater is on, and for at least 15 minutes after the heater is off. Any switches in the pump circuit (includ-
ing circuit breakers) that can disconnect the pump must also disconnect the heater.
7. Do not wire single pole switches, including protective devices, into a grounded line. Observe hot/neutral polarity when connecting power to the heater.
Recommended Pipe Size For Natural Gas
1,000 BTU/ft3, 0.6 Sp Gr, 0.5” wc Pressure Drop
0-25’ 26-50’ 51-100’ 101-200’ 201-300’
Model (0-7.6M) (7.6-15M) (15-31M) (31-62M) (62-92M)
200 3/4” 1” 1” 1-1/4” 1-1/4” 333 1” 1-1/4” 1-1/4” 1-1/2” 1-1/2” 400 1” 1-1/4” 1-1/4” 1-1/2” 2”
FIGURE 22: Gas line and Trap
Table 10
Manual Shut-off Valve
At least 4"
Union
Sediment Trap
Connect the L1 of the power supply to the black wire, the L2 or neutral lead to the red wire, and the ground wire to the green wire (See Figure 23).
A time clock controlling the filter pump should have a low­voltage Fireman’s Switch that switches off the heater at least 15 minutes before shutting off the pump.
FIREMAN’S SWITCH CONNECTION
NOTICE: If, while there is line voltage connected to the
heater, you touch either line voltage terminal with any 24VAC wire that is connected to the control board (includ­ing the Fireman’s Switch jumper), you will immediately destroy the control board and void the warranty.
NOTICE: When using a timer and Fireman’s Switch, the heater’s power supply should come from the load side of the timer. The Fireman’s Switch completes the circuit for the low voltage safety switches. It DOES NOT get any line voltage power from the power supply.
Connect the Fireman’s switch to the heater as follows:
1. Turn off power to heater at main circuit breaker panel.
2. Unbolt and remove the upper jacket halves (see Figure 3, Page 5).
3. Open control box cover (see Figure 24).
4. Remove the factory-installed jumper between the Fireman’s Switch terminals (see Figure 25).
5. Connect the wires between the Fireman’s Switch termi­nals on the heater and those on the time clock using 18 gauge wire with a minimum 3/64” (1.2mm) thick insulation rated for a temperature rise of at least 105°C. Route the wires out through the knockout on the bottom of the Control Box. Use a 90° conduit el and conduit run out through the cutout on the Lower Enclosure, next to the Junction Box (see Figure 23).
21
OFF
ON
FIGURE 24: Open Control Box Cover
FIGURE 25: Fireman’s Switch Connections
FIGURE 23: Field Wiring
120V: White to Red (L2) or 240V: Red to Red (L2)
Green (Ground)
to
Green (Ground)
Bonding Lug
Bonding Wire
View From Below (Exterior)
120/240V: Black to Black (L1)
Cutout for Conduit from Fireman's Switch
Wire into bottom of Junction-box in Flexible Conduit
Bonding Wire
Wiring Harness to Control Box
View From Above (Interior)
BK
O
J6
Y
Y
YY
24VAC
1
9
FUSE
W
FUSE
TRANS
TH
IND
VAL
GND
BK
OPERATING CONTROL
O
ENABLE TOGGLE
DISABLE TOGGLE
CONTROL CENTER
FS
24VAC
24VAC
THERMISTOR
MEMBRANE PAD
CONNECTION
VERSION 1 PAD
SPA CONTROL
O
N
F F O
T
N E V
S S E
R P
B
A T
T O IL
P
TERMINAL BOARD
F
S
I
W
R
I
GND
E
FL
T
M
C
A
H
N S
L1
F1
L1
R
G
BK
BOX
JUNCTION
L1
L2
24VAC
GROUND (GND)
12 Pin
Receptacle
TRANS
L2
BM
L2
W
W
R
R
Time Clock or Remote
(Purchase Separately —
Supplies Power to
Circulator Pump)
Fireman’s Switch Completes the heater 24 Volt AC Control Board Circuit. DO NOT connect this circuit to Line Voltage!
TRANS
22
6. Reinstall and bolt up the jacket halves. The fuse for the Fireman’s Switch is a 1.25 amp 1-1/4x1/4”
fast blow fuse, available locally.
MAXIMUM TEMPERATURE SET POINT
1. Unbolt and remove upper jacket halves (see Figure 3, Page 5).
2. Depress clips and remove control panel board dome (see Figure 9, Page 10).
3. Push the Max. Temp. Set Point button on the back of the control board (see Figure 26). The following sequence should happen:
A. The unit will come on and the POOL ON light will
come on.
B. Press the ▼Temp or ▲Temp pad (on TOP of the
panel) to set maximum pool temperature.
C. Wait 30 seconds; the POOL ON light will go off and
the SPA ON light will come on.
D. Press the ▼Temp or ▲Temp pad (on TOP of the
panel) to set maximum spa temperature (set temper­ature to 104°F (40°C) or less).
E. Wait 30 seconds; the SPA ON light will go off and
the unit will shut down.
4. Reinstall and bolt up the jacket halves.
FIGURE 26: Max Temperature Set Point Controls
SET
MAX
S1
SET
MAX
S1
23
Hazardous voltage. Can shock, burn or
kill. Disconnect power before servicing any components.
Fire and Explosion hazard. Do not
jumper switch terminals to remedy a failed safety switch.
Initial Troubleshooting
Only qualified, trained service technicians with appropriate test equipment should service the heater. Remember that all parts of the system affect heater operation. Before starting this troubleshooting procedure, make sure that the pump is running correctly, that there are no blockages in the system, that the valves are correctly set and that the time clock is correctly set and is running.
Go to chart “HEATER WILL NOT FIRE - A” (Page 24)
Go to chart “HEATER WILL NOT FIRE - B” (Page 25)
Go to specific safety switch troubleshooting chart (Pages 28 and 29)
Go to chart ‘HEATER WILL NOT FIRE -C” (Page 26)
Are any red diagnos­tic LED’s on back of board (AGS, AFS, SFS, HLS, PS or THERMISTOR) “on”
NO
NO
NO
NO
NO
YES
YES
YES
NO
YES
YES
Does red “SERVICE HEATER” LED come “on”
Verify that water temperature setting is above water temperature reading. If it is, and heater either will not fire or no red LED’s come “on”, replace Control Board.
YES
Is green “POOL” or “SPA” LED “on”?
Is red “SERVICE SYSTEM” LED “on”?
Is red “SERVICE HEATER” LED “on”?
Turn off power to heater for about 5 seconds, and turn back on. Make sure tempera­ture setting is above water temperature. Wait one minute.
Do any diagnostic LED’s on back of board (AGS, AFS, SFS, HLS, PS, or THERMISTOR) come “on” and stay on?
NOTICE: Any or all of the diag­nostic LED’s may come “on” momentarily when you turn on the power to the heater.
NOTICE: Installing the black 120 volt plug in the control box and then connecting the heater to a 240 volt line will destroy the
transformer, control board, and ignition control module, and will void the warranty. If you install the red 240 volt plug and then
connect the heater to a 120 volt line, the heater will not operate.
READ THE FOLLOWING CAREFULLY:
1. Check the line voltage to your heater. This heater will operate
on either 120 Volts AC or 240 Volts AC.
2. Remove the covers and check the 12-pin plug in the back of the control box. The plug must match the voltage in the heater circuit.
3. If the 12-pin plug is not plugged into the back of the control box, select the correct plug from the bag in the control box and plug it in. The BLACK plug is for 120 volts, the RED plug is for 240 volts.
IMPORTANT! READ ME FIRST!!
Start here for directions to specific Troubleshooting Chart
24
Heater Will Not Fire - A
Start
GO TO
“HEATER WILL NOT FIRE - B”
Page 25
Heater should fire on demand for heat.
Check Fireman’s Switch circuit connections (time clock, wiring, external controller relay).
Remove jumper. Check wiring between Transformer and J7 terminals on Control Board and between J7 and Fireman’s Switch on Terminal Board, check fuse, and restore continuity.
Restore power to heater.
Replace Transformer.
Heater should fire on demand for heat.
Replace Control Board.
Replace Membrane Pad.
Check wiring connections between power supply and Junction Box and between Junction Box and Terminal Board; restore continuity.
Check wiring connections between Terminal Board and Transformer primary and restore continuity.
Is green “SPA” or “POOL” LED “on”
YES
NO
NO
YES
YES
YES
NO
NO
Depress “POOL” or “SPA” ON button on Membrane Pad. Does “POOL” or “SPA” LED come on?
Check for line voltage to heater.
Check for 24 VAC at sec­ondary of Transformer.
Check for Line Voltage at Transformer primary pins. White connects to Pin 3 on Transformer, Black to Pin 2, Orange to Pin 1.
240V: check Pin1 to Pin 3. 120V: check Pin 2 to Pin 3.
Jumper Fireman’s Switch at Terminal Board and depress “POOL” or “SPA” ON button on membrane pad. Does “SPA” or “POOL” LED come “on”?
Leaving jumper in place, check for 24 VAC between Fireman’s Switch terminals and ground.
Jumper pins 9 and 8 on J6 of Control Board. Does “SPA” LED come on? Jumper pins 9 and 7 on J6 of Control Board. Does “POOL” LED come on?
Check for Line Voltage between L1 and L2 terminals on Terminal Board.
NO
YES
NO
NO
YES
YES
YES
YES
YES
NO
NO
YES
NO
Check that correct 12-pin plug is installed (red is 240V, black is 120V)
If plug is not installed:
Install correct plug.
240V plug in 120V circuit: Replace with
correct plug.
120V plug in 240V circuit: Replace trans-
former, control board, and ignition control module (see “HEATER WILL NOT FIRE-C and
-D”, Pages 26 and 27). Check fuse and all other 24V components for damage.
Remove jumper. Check ribbon cable connection between Membrane Pad and J6 on Control Board. Depress “POOL” or “SPA” On pad again. Does “POOL” or “SPA” LED come on?
NO
25
Heater Will Not Fire - B
Start
Increase POOL/SPA tempera­ture setting on Membrane Pad above actual water tem­perature. Heater should fire on demand for heat. If not, and no other red LED’s light, replace Control Board.
Service pump/filter and elimi­nate other flow obstructions.
Heater should fire on call for heat. Re-verify that water flow is above minimum require­ment.
Minimum Flow Requirements
Model Flow
200 20 GPM (76 LPM) 333 30 GPM (114 LPM) 400 40 GPM (151 LPM)
If water pressure is outside of adjustment range that will open switch with pump off and close switch with pump on, replace with flow switch set above minimum flow requirement.
Minimum Flow Requirements
Model Flow
200 20 GPM (76 LPM) 333 30 GPM (114 LPM) 400 40 GPM (151 LPM)
Is red “SERVICE HEATER” LED “on”
YES
YES
NO
YES
NO
NO
Is red “SERVICE SYSTEM” LED on?
Verify that pump is on, filter is not blocked, and the water flow is above the minimum requirement.
Check that water pressure is within the adjustment range of the Pressure Switch (0-5 psig)
Verify that switch wiring is OK and sensing tube is not blocked, and replace water Pressure Switch.
Check whether any of the red diagnostic LED’s on back of board (AGS, AFS, SFS, HLS or PS) are “on”
GO TO
“HEATER WILL NOT FIRE - C”
Page 26
Go to “Diagnostic LED’s”, (Pages 28 and 29)
With pump running, adjust Water Pressure Switch to lower pressure until ‘SER­VICE SYSTEM” LED goes out. Then verify that “SER­VICE SYSTEM” LED goes on with pump off.
YES
YES
YES
NO
NO
NO
CONTINUE
26
Heater Will Not Fire - C
Start
Go to “INITIAL TROUBLESHOOTING”
Continue to observe heater for several minutes. Cycle heater on and off several times. Observe for delayed or rough ignition, poor combus­tion, premature extinction of flame, evidence of boiling, or operation of any diagnostic LED. Go to pertinent trou­bleshooting section if any malfunction is observed.
Replace Control Board.
Replace Gas Valve with identical part.
Fix wiring between TH and GND terminals of Ignition Control Module and Control Board.
Replace Control Board.
Fix wiring between GAS ter­minals on Control Board and Gas Valve.
NOTE 1: Voltage appears immedi­ately after call for heat, and may be on for only about 30 seconds.
NOTE 2: Voltage appears about 24 seconds after call for heat, and may be on for only about 7 seconds.
Verify that gas supply is open all the way to Gas Valve, and Gas Valve knob is at “on” position. Check for 24 VAC to Gas Valve terminals during ignition try. (Voltage appears about 24 seconds after call for heat). SEE NOTE 2.
Turn off power to heater for 5 seconds, and turn back on. Make sure tempera­ture setting is above water temperature. Wait one minute.
Does heater fire and stay on?
Did Blower come on?
Verify that gas is flow­ing to burner during ignition try. Observe gas meter for move­ment during ignition try (wait for about 30 seconds after calling for heat).
Check for 24 VAC between TH and GND terminals on Ignition Control Module. SEE NOTE 1.
Check for 24 VAC between TH and GND terminals on Control Board. SEE NOTE 1.
Check for 24 VAC between GAS termi­nals on Control Board. SEE NOTE 2.
Replace Control Board.
NO
CONTINUE
YES
YES
YES
NO
NO
YES
NO
YES
NO
NO
YES
YES
NO
YES
YES
Is “SERVICE HEATER” LED “on”?
Go to “BURNER TROUBLESHOOTING” (Page 30)
Go to “HEATER WILL NOT FIRE-D” (Page 27)
Check for 24 VAC between VAL and GND terminals on Ignition Control Module. SEE NOTE 2.
Check for 24 VAC between VAL and GND terminals on Control Board. SEE NOTE 2.
If any red diagnostic LED’s (AGS, AFS, SFS, HLS, PS, or THERMISTOR) come “on”, go to to Pages 28 and 29.
Did burner fire at all?
Replace Ignition Control Module.
NO
YES
Fix wiring between VAL and GND terminals of Ignition Control Module and Control Board.
NO
YES
NO
NO
27
Heater Will Not Fire - D
Start
IMPORTANT! READ ME FIRST!!
If your heater is correctly connected to 240 Volts AC, The Ignition Control Module (ICM) will convert the 240VAC to an intermittent pulse to the ignitor. Digital meters don’t read this type of signal well. (An analog meter will give a better reading than a digital meter). If the ICM is bad, your volt-
meter will read either 0 VAC or 240 VAC. If your ICM is good, your meter will read some voltage between 0 and 240 VAC. Exactly what reading you get will depend on the meter, but with a good ICM, the reading won’t be 0 VAC or 240 VAC, but somewhere in between.
IMPORTANT! READ ME FIRST!!
Gas flows during igni­tion try, but burner does not fire.
NO (check fuse at terminal board)
NO
YES
Go back to chart “HEATER WILL NOT FIRE-C” (Page 26).
Check voltage across igniter leads; OK?
Replace Ignition Control Module. On a 120 V installation, check the ignitor for damage if it has seen 240 VAC.
NO
YES
Replace HSI Igniter.
Check gas pressure. OK?.
Increase gas flow into heater:
• Replace gas line with larger line;
• Replace regulator;
• Replace meter; or
• All of the above.
YES
28
Diagnostic LED’s: AGS, AFS, HLS, PS, THERMISTOR
Do not jumper a safety switch to
remedy a failed switch.
NOTE: ES1 is a spare and should be jumpered.
Service pump and filter to restore proper flow. After ser­vicing, verify proper operation of Pressure Switch (PS).
Replace thermistor or Control Board to correct overheating.
Replace High Limit Switch (HLS) or Automatic Gas Shutoff (AGS)
If problem persists, verify proper operation of Internal Bypass Valve and Thermal Governor, and check for Heat Exchanger blockage.
YES
NO
NO
AGS or HLS “on”
Verify that water flow rate is above minimum required for heater.
Verify that inlet water temper­ature is below 104° F.
YES
CONTINUE
YES
CONTINUE
Verify that there is no block­age in Blower intake, Heat Exchanger, and exhaust and that exhaust is not too long (see “Indoor Vent Installation”, Page 15.
Verify correct connection of wiring and that pressure taps to AFS are OK.
Verify that vinyl tubing to AFS and Blower is not misrouted, kinked, disconnected, or punctured.
Replace Air Flow Switch (AFS).
If problem persists, replace Blower.
Replace Blower.
Verify correct connection of wiring between 24 VAC and IND terminals on Ignition Control Module and Control Board, and replace Control Board.
YES
YES
NO
NO
NO
YES
YES
NO
AFS “on”
Does Blower operate?
THERMISTOR “on”
Verify Thermistor wiring. If OK, replace Thermistor.
Disconnect Blower and check for line voltage between pins 1 and 3 of Blower Connector on ignition try.
Connect correctly and retry. Does Blower start?
Replace Blower. Does Blower start on ignition try?
Replace Ignition Control Module.
NO
Verify that wires BM and F1 are correctly connected at the terminal strip (see Heater Connection Diagram, Page 36).
Disconnect wires F1 and F2 from Ignition Control Module and short them together. Does Blower come on?
Check for 24 VAC between 24 VAC and GND terminals on Ignition Control Module on ignition try. Check that IND wire is correctly connected.
NO
NO
Service pump and filter to restore proper flow.
Verify that wiring is OK and pressure tap is not blocked. Re­place Pressure Switch
CONTINUE
NO
PS “on”
Verify that water flow rate is above minimum required for heater.
Adjust Water Pressure Switch to close with pump running and open with pump off.
YES
29
Diagnostic LED’s: SFS
Replace Heater Membrane Pad Assembly, reset power to Heater and retry. Heater should fire.
Replace Heater Membrane Pad Assembly, reset power to Heater and retry. Heater should fire.
Replace Heater Control Board with new style board, reset power to Heater and retry. Heater should fire.
Change Low Level Board Programming to “SF1” (See Page 4-11 in S5066, “Sta-Rite Pool/Spa Heater Training and Service Manual”). Were you able to change the device code (SF0 to SF1)?
Reset power to Heater and retry. Heater should fire.
Check Heat Exchange Coil for liming or low flow.
Reset power to Heater and retry. Heater should fire.
Did Error Code (E05 or E06) disappear after change?
Replace Heater Control Board, reset power to Heater and retry. Heater should fire.
NO
YES
NO
NO
SENSOR
SWITCH
Reset power to Heater and retry. Heater should fire.
Does the Digital Temerature Display show Error Code “E05” or “E06”?
Change Low Level Board Programming to “SF0” (See Page 4-11 in S5066, “Sta-Rite Pool/Spa Heater Training and Service Manual”). Were you able to change the device code (SF1 to SF0)?
Check Heat Exchanger Coil for liming or low flow.
A) Is the Stack Flue
Switch or Sensor correctly connected to the wiring harness?
B) Is the Membrane Pad
connected to the correct pins on the Control Board? (See Page 36)
Check the J3 and J6 connectors for corrosion on the male pins. Corrosion found?
Clean pins
Reset power to Heater and retry. Heater should fire.
Reset power to Heater and retry. Heater should fire.
Replace switch, reset power to Heater and retry.
Verify whether you have a Stack Flue Sensor or a Stack Flue Switch (See Page 4-11 in S5066, “Sta-Rite Pool/Spa Heater Training and Service Manual”).
Does the Digital Temerature Display show Error Code “E05” or “E06”?
NO
YES
YES
NO
SFS “on”
Reconnect correctly.
Replace Stack Flue Sensor.
DONE
YES
NO
NO
YES
YES
NO
NO
NO
YES
YES
DONE
NO
NO
NO
30
Burner Troubleshooting
SYMPTOM CAUSE REMEDY
Loud, high-pitched whine Flame is too rich. Verify pressure tap between gas valve
and blower inlet. Turn to Page 19 and verify that the gas
regulator setting is 0.2” (0.5cm) wc below the blower inlet pressure.
Replace gas orifice with smaller size.
Flame is “fluttery.” Flame is too lean. Turn to Page 19 and verify that the gas Exhaust may have acrid regulator setting is 0.2” (0.5cm) wc smell or burner may fail below the blower inlet pressure. to stay lit.
Replace gas orifice with larger size.
Burner pulsates or Exhaust vent is too long. Reduce length of exhaust vent and/or surges, especially on number of elbows.
ignition.
Combustion appears Flame current is not Check for wet or damaged igniter with normal, but flame does being sensed. low resistance to ground. Replace with not stay lit. new igniter.
Verify burner flameholder is properly grounded. Replace Ignition Control Module.
Heat Exchanger Troubleshooting
SYMPTOM CAUSE REMEDY
Boiling in heat exchanger. Low water flow to heater. Service pump and or filter. May be accompanied by
Heat exchanger plugged. Service heat exchanger. Correct water
“bumping” sounds.
chemistry.
Bypass valve stuck open. Service bypass valve.
Thermal governor stuck Replace thermal governor. closed.
Sweating. Thermal governor failed. Replace thermal governor.
31
4
PRESS
TAB
VENT
PILOT
O
F
F
OFF
ONON
2737 0197
1
3
4
5
6
7
8
10
9
2
12
11
For complete
Electrical System
parts breakdown (Key Nos. 1 through 4), See Page 34
For complete
Burner System
parts breakdown (Key Nos. 5 through 9), See Pages 31 and 32
For complete
Water System
parts breakdown (Key Nos. 10 through 12), See Page 33
Repair Parts are available from your Sta-Rite dealer.
If your dealer cannot supply you, call Sta-Rite Customer Service at 1-800-752-0183.
For complete
Electrical System
parts breakdown (Key Nos. 1 through 4), See Page 35
For compete
Burner System
parts breakdown (Key Nos. 5 through 9), See Pages 32 and 33
For complete
Water System
parts breakdown (Key Nos. 10 through 13), see Page 34
32
14
15
18
19
20
21
22
23
1
2
3 4
2
5
6
7
9
8
11
12
13
10
17
16
24
25
2692 1196 115/230
P
R
E
S
S
T
A
B
VE
N
T
P
IL
O
T
O
F
F
O N
For Heater mounting bolts and clamps, purchase separately Bolt Down Bracket Kit, Part No. 42001-0085S.
33
REPAIR PARTS – BURNER SYSTEM
Model
SR400NA
Key Part SR200NA SR333NA SR400LP
No. Description Qty. SR200LP SR333LP SR400HD
1 Combination Gas Control Valve Kit 1 42001-0051S 42001-0051S 42001-0051S 2 3/4” Union 2 38404-4097S 38404-4097S 38404-4097S
Gas Orifice Kit – NG (Incl. Key Nos. 3 and 4)† 77707-0331 77707-0321 77707-0311 3 Gas Orifice – NG* 1 42001-0331 42001-0321 42001-0311 4 Gas Orifice O-Ring 1 U9-370 U9-370 U9-370
Gas Orifice Kit – Propane (Incl. Key Nos. 3 and 4)† 77707-0361 7707-0351 77707-0341 3 Gas Orifice – Propane* 1 42001-0361 42001-0351 42001-0341 4 Gas Orifice O-Ring 1 U9-370 U9-370 U9-370
NG to Propane Conversion Kit
(Incl. Key Nos. 3 and 4)† 77707-1361 77707-1351 77707-1341 3 Gas Orifice – Propane* 1 42001-0361 42001-0351 42001-0341 4 Gas Orifice O-Ring 1 U9-370 U9-370 U9-370
Conversion Instructions, NG to Propane* 1 S402 S402 S402
NG to Propane Conversion Decal* 1 32165-4158 32165-4158 32165-4158
Propane to NG Conversion Kit (Incl. Key Nos. 3 and 4)† 77707-1331 77707-1321 77707-1311
3 Gas Orifice – Propane* 1 42001-0331 42001-0321 42001-0311 4 Gas Orifice O-Ring 1 U9-370 U9-370 U9-370
Conversion Instructions, Propane to NG* 1 S403 S403 S403
Propane to NG Conversion Decal* 1 32165-4159 32165-4159 32165-4159
5 Air Blower Kit 1 42001-0246S 42001-0246S 42001-0246S 6 Endcap/Air Orifice – Inlet Mixing Tube 1 77707-0091 77707-0092 77707-0093 7 Endcap Mixing Tube Grill 1 42001-0094S 42001-0094S 42001-0094S
Blower/Adapter Plate Gasket Kit (Includes Key Nos. 9, 11, 13) 1 77707-0011 77707-0011 77707-0011
8 Blower/Adapter Plate Gasket* 1 42001-0067 42001-0067 42001-0067 9 Blower Adapter Plate 1 42001-0090 42001-0090 42001-0090
Flameholder Kit (Includes Key Nos. 11, 12, 13, 14 and Flameholder Insert) 77707-0202 77707-0203 77707-0204
10 Flameholder/Adapter Plate Gasket* 1 42001-0084 42001-0084 42001-0084 11 Flameholder Assembly* 1 42001-0202 42001-0203 42001-0204 12 Flameholder/Combustion Chamber Gasket 1 42001-0065 42001-0065 42001-0065 13 Flameholder Insulation Cap 1 42001-0075 42001-0075 42001-0075
Flameholder Insert* 1 42001-0027 42001-0027
Condensate Evaporator 1 42001-0031 42001-0031 42001-0031
14 Upper RH Heater Enclosure Kit** 77707-0002 77707-0002 77707-0002 15 Lower Enclosure 1 42001-0001S 42001-0001S 42001-0001S
Upper Enclosure Gasket 1 33457-1051S 33457-1051S 33457-1051S
16 Upper LH Heater Enclosure Kit-NG 1 77707-3200N 77707-3333N 77707-3400N 17 Upper Enclosure Fastener Kit 1 77707-0007 77707-0007 77707-0007 18 3/8” Flat Washer 4 U43-62SS U43-62SS U43-62SS 19 3/8” Lock Washer 4 U43-12SS U43-12SS U43-12SS 20 3/8” Hex Nut 4 U36-38SSW U36-38SSW U36-38SSW
Insulation Kit (Includes Key Nos. 22, 23, 24, 25 and Condensate Evaporator, Page 34) 1 77707-0008 77707-0008 77707-0008
21 Bottom Outer Insulation Blanket* 1 42001-0073 42001-0073 42001-0073 22 1” Bottom Inner Insulation* 1 42001-0072 42001-0072 42001-0072 23 1” Top Inner Insulation* 1 42001-0070 42001-0070 42001-0070 24 Top Outer Insulation Blanket* 1 42001-0071 42001-0071 42001-0071
Lower Enclosure Insulation 1 42001-0074S 42001-0074S 42001-0074S
25 Metal Vent Cover 1 42002-0005S 42002-0005S 42002-0005S
Metal Exhaust Elbow Kit 1 42001-0209S 42001-0209S 42001-0209S
One-Piece Metal Elbow/Cover Assembly 1 42001-0214S 42001-0214S 42001-0214S
* Not available separately.
** Kit parts not available separately.
• Not illustrated.
† Not included with heater. Order separately.
34
REPAIR PARTS – WATER SYSTEM
1
2
19
20
3
4
7
8
11
10
9
6
5
2691 1196
18
13
14
12
17
16
15
* Not available separately.
Not illustrated.
** See Page 35 Key Nos. 7, 8, 9 and 10 for Safeties and Relief Valve Port Plug.
Model
SR400NA
Key Part SR200NA SR333NA SR400LP
No. Description Qty. SR200LP SR333LP SR400HD
1Tube Sheet Coil Assembly Kit (Includes Key No. 2) 1 77707-0232 77707-0233 77707-0234 1 SR400HD Tube Sheet Coil Assembly Kit
(Includes Key No. 2) 1 77707-0244 2 Coil/Tubesheet Sealing O-Ring Kit ( ) 77707-0117(6) 77707-0118(10) 77707-0119(12) 3 Manifold Bottom Plate 1 42002-0015 42002-0016 42002-0017 4 Manifold O-Ring* 1 35505-7437 35505-7437 35505-7437
O-Ring Kit (Incl. Key Nos. 2, 4) 1 77707-0120 77707-0120 77707-0120 5 Manifold Insert* 1 42002-0018 42002-0019 42002-0020 6 Manifold Baffle Plate* 1 42002-0013 42002-0014 42002-0022 7 Manifold Bypass Valve Kit 1 77707-0001 77707-0001 77707-0001 8Water Pressure Switch 1 42001-0060S 42001-0060S 42001-0060S 9 Manifold Body with Safeties** (Incl. Key Nos. 10, 11) 1 77707-0205 77707-0205 77707-0205 9 Manifold Body Only (Incl. O-Ring Kit) 1 77707-0206 77707-0206 77707-0206
10 5/16 Flat Washer 10 U43-41SS U43-41SS U43-41SS 11 5/16-18x2-3/4” Hex Capscrew 10 37007-0214 37007-0214 37007-0214 12 Connector Tube O-Ring 2 U9-226 U9-226 U9-226 13 Connector Tube Kit (Includes O-Ring) 2 77707-0017 77707-0017 77707-0017 14 Thermal Regulator Kit
(Incl. Key Nos. 15, 16, 17, 18 and Spring Clip) 1 77707-0010 77707-0010 77707-0010 15 Thermal Regulator (Includes Spring Clip) 1 38000-0007S 38000-0007S 38000-0007S 16 Thermal Regulator Spring* 1 37607-0011 37607-0011 37607-0011 17 Thermal Regulator Cap O-Ring 1 35505-1313 35505-1313 35505-1313
Thermal Regulator Spring Clip* 1 42001-0097 42001-0097 42001-0097 18 Thermal Regulator Cap* 1 42001-0016 42001-0016 42001-0016 19 Drain Plug 1 U178-920P U178-920P U178-920P 20 Condensate Evaporator* 1 42001-0031 42001-0031 42001-0031
35
REPAIR PARTS – ELECTRICAL SYSTEM
1
2
3
9
6
8
6
10
11
12
13
4
5
20
14
17
19
18
15
16
7
Model
SR400NA
Key Part SR200NA SR333NA SR400LP
No. Description Qty. SR200LP SR333LP SR400HD
Display Cover Retainer Cap Kit (Incl. Key No. 1)* 77707-0009 77707-0009 77707-0009
1 Display Cover Retainer Cap 1 42001-0009 42001-0009 42001-0009
CPSC Warning Label 1 32165-4084 32165-4084 32165-4084 2 Heater Display Cover 1 42001-0008S 42001-0008S 42001-0008S 3 Igniter Bracket 1 42001-0030S 42001-0030S 42001-0030S
Igniter/Igniter Gasket Kit (Incl. Key Nos. 4 and 5) 77707-0054 77707-0054 77707-0054 4 Igniter** 1 42001-0054 42001-0054 42001-0054 5 Igniter Gasket 1 42001-0066S 42001-0066S 42001-0066S 6 Manifold Switch Cover 2 42001-0007S 42001-0007S 42001-0007S 7 Automatic Gas Shutoff Switch (AGS) 1 42002-0025S 42002-0025S 42002-0025S 8 3/4” Hex Head Pipe Plug 1 WC78-38AT WC78-38AT WC78-38AT 9 High Limit Switch 1 42001-0063S 42001-0063S 42001-0063S
10 Thermistor 1 42001-0053S 42001-0053S 42001-0053S 11 Terminal Board 1 42001-0056S 42001-0056S 42001-0056S 12 Fireman’s Switch Fuse (1.25A, 1-1/4”) 1 32850-0099 32850-0099 32850-0099 13 Ignition Control Module 1 42001-0052S 42001-0052S 42001-0052S 14 Transformer 1 42001-0107S 42001-0107S 42001-0107S 15 Air Flow Switch 1 42001-0061S 42001-0061S 42001-0061S 16 Control Board Kit 1 42001-0096S 42001-0096S 42001-0096S
#6-19x5/16” Phil Pan 4 37337-0092 37337-0092 37337-0092
Heater Wiring Harness 1 42001-0104S 42001-0104S 42001-0104S
120/240 Volt Plug Kit 1 42001-0105S 42001-0105S 42001-0105S
Junction Box Cover Kit (Incl. Key No. 17)* 77707-0022 77707-0022 77707-0022
17 Junction Box Cover 1 42001-0022 42001-0022 42001-0022
Junction Box Wiring Decal 1 32165-4167 32165-4167 32165-4167
Control Bd Encl/Membrane Panel Kit 77707-0004 77707-0004 77707-0004
(Incl. Key Nos. 18 and 19)* 18 Control Board Enclosure 1 42001-0004 42001-0004 42001-0004 19 Membrane Pad** 1 42001-0055 42001-0055 42001-0055 20 Stack Flue Sensor 1 42002-0024S 42002-0024S 42002-0024S
* Kit parts not available separately.
** Not available separately.
*** Available separately.
Not illustrated.
36
Pool Heater Wiring Connection Diagram
12 pin Plug
Black — 120V Red — 240V
JMP3
9
1
J6
JMP3
1
JMP3
1
External Control Interface Circuit Disabled, Heater Membrane Pad Enabled
External Control Interface Circuit Enabled, "Pool On" and "Spa On" Keys Disabled. "OFF" Key on Membrane Pad Remains Functional.
CONNECTION DIAGRAM
AGS Switch
Stack Flue Sensor
Gas Valve
Air Flow Switch
Extra Switch 1
Hi-Limit Switch
Pressure Switch
VAL
TH
IND
GND
24VAC
24VAC
FS
THERMISTOR
OPERATING CONTROL
1
PS
HLS
ES1
AFS
AGS
SFS
GAS
CONTROL CENTER
SPA CONTROL
VERSION 1 PAD
MEMBRANE PAD
CONNECTION
Spa Line
Common Line
Pool Line
IGNITION CONTROL
MODULE
DIAGNOSTIC INDICATOR
F1 F2
24
VAC
S1
240
S1/ 120
L1
L1
L1
L2
L2
BM
FL
F1
L2S2TH IND
VALGND
GND
GND
BLOWER
120/240 Volt
Line 2
120VAC
IGNITER
TRANS
Line 1
Ground
JUNCTION BOX
F
I R E M A N S
S W I T C H
Replace jumper with
leads to 24V Fireman's
Switch (field installed)
24VAC
SEC
Y/W
Y/W
Y/R
Y/O
Y/BL
O
W
BK
BK
O
GYGYBK
BK
R
Y
W
BK
BL
Y
W
BK
BL
GY
GY
GY
GY
BK
BK
W
RRW
G
Y
R
R
Y
YY
BK
BK
Y/W
W
W
R
R
BL
BL
O
O
O
O
PR
PR
Y/R
Y/BL
Y/O
Y/W
Y
Y
Y
Y
Y
YY Y Y
BR
BR
External Control Interface
Y
If cable from Membrane Pad is a 6-Conductor Cable, connect it to pins 4 - 9 on Operating Control Board as shown.
9
1
J6
NOTICE: Touching any 24VAC wire, including the Fireman’s Switch wire, to any 120/240V terminal while the heater is connected to line power will immediately destroy the control board and void the warranty.
BK
R
GND
G
12 Position Receptacle
193
12
3
2
1
37
Pool Heater Electrical Schematic Ladder Diagram
L1 L2
120/240
VAC
120/240
VAC
IGNITER
L1
S1 S2 L2
F1
F2 BLOWER
GND
GND
CLASS II
TRANSFORMER
24 VAC
24 VAC
24V
OPERATING
CONTROL
24 VAC
LOGIC
TH
IND
AIR
FLOW
SWITCH
HI LIMIT SWITCH
WATER
PRESSURE
SWITCH
COM NO
AGS
SWITCH
VAL
GAS VALVE
THERMISTOR
SENSOR
STACK FLUE
SENSOR
NOTES:
1.)
AND TH
L1 L2 F1 F2 S1 24 VAC
S2 GND IND VAL
ARE CONNECTED ON THE IGNITION MODULE.
2. )
3. )
PIN AND SOCKET CONNECTOR.
IF ANY OF THE ORIGINAL WIRES AS SUPPLIED WITH THE APPLIANCE MUST BE REPLACED, THEY MUST BE REPLACED WITH TYPE 105°C OR ITS EQUIVALENT.
LADDER DIAGRAM
NOTES:
1.)
AND TH
L1 L2 F1 F2 S1 24 VAC
S2 GND IND VAL
ARE CONNECTED ON THE IGNITION MODULE.
2. )
3. )
PIN AND SOCKET CONNECTOR.
IF ANY OF THE ORIGINAL WIRES AS SUPPLIED WITH THE APPLIANCE MUST BE REPLACED, THEY MUST BE REPLACED WITH TYPE 105°C OR ITS EQUIVALENT.
CREATE A RECORD OF YOUR WARRANTY AT STA-RITE:
• Complete a warranty registration at www.staritepool.com by clicking on “Register Products” and selecting Sta-Rite Pool OR
• Complete bottom portion completely and mail within 10 days of installation to Sta-Rite, Attn.: Warranty Dept., 293 Wright St., Delavan , WI 53115
Warranty Registration Card
Name
Address
City State Zip
Installation (or Purchase) Date
Product Purchased
Model Number
New installation Replacement
Years pool has been in service ■ less than 1 ■ 1-3 ■ 3-5 ■ 5-10
This product was purchased from:
Company name
Address
City State Zip
STA-RITE LIMITED WARRANTY
For technical information about this product, contact the installer or call Sta-Rite at 262-728-9181. Visit www.staritepool.com
• for more information about Sta-Rite products listed above
• to locate a Sta-Rite dealer near you
Product Specific Warranties (from date of installation)
Product Limited Family Warranty Exceptions
Filters 1 Year System 3 Tank Bodies - 10 Yrs
Filter Valves 1 Year
Pumps 1 Year
Heaters 2 Years Commercial Application - 1 Yr
Controls 1 Year
Above Ground Systems 1 Year
Lights and Niches 1 Year Lamps and Bulbs - 90 Days
White Goods 1 Year
Maintenance Equipment 90 Days
Drainer/Utility Pumps 90 Days
Replacement Parts 90 Days
Cleaners: Lil Shark 1 Year
Cleaners: Calypso 1 Year
Cleaners: Pool Shark 2 Years Footpad and Seal Flaps - 1 Yr
Cleaners: Great White 2 Years
Retain this warranty certificate in a
safe and convenient location for your records.
Pumps, filters, skimmers, underwater lights (excluding bulbs), accessories and fittings manufactured by Sta-Rite are warranted to be free of defects in material and/or workmanship for one (1) year from the original date of installation.
The foregoing warranties relate to the original consumer purchas­er (“Purchaser”) only. Sta-Rite Industries shall have the option to repair or replace the defective product, at its sole discretion. Purchasers must pay all labor and shipping charges necessary to replace the product covered by this warranty. Requests for war­ranty service must be made through the installing dealer. This warranty shall not apply to any product that has been subject to negligence, misapplication, improper installation or maintenance, or other circumstances which are not in Sta-Rite’s direct control. Failure to have product installed by a professional in compliance with local codes will void any and all manufacturers warranty.
This warranty sets forth Sta-Rite’s obligation and Purchaser’s exclusive remedy for defective products.
STA-RITE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES. IMPLIED WAR­RANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PAR TICULAR PURPOSE, SHALL NOT EXTEND BEYOND THE DURATION OF THE APPLICABLE EXPRESS WARRANTIES PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
Supersedes all previous publications.
S4877PS (Rev. 5/28/04)
Loading...
