STM8L15LPBOARD low-power demonstration board
Features
■ SWIM debug support
■ MCU consumption auto-measurement circuit
■ Function and wakeup buttons
■ 32.768 kHz quartz
■ MCU pins connector
■ LCD glass
Description
The STM8L15LPBOARD low-power
demonstration board is designed to demonstrate
all the STM8L15x low-power modes, and permits
the user to take consumption measurements in all
modes.
STM8L15LPBOARD
Data brief
The main demonstration modes proposed
through the LCD screen use either the automeasurement circuit or manual consumption
measurement.
Table 1. Device summary
Order code Reference
STM8L15LPBOARD
STM8L15LPBOARD lowpower demonstration board
August 2010 Doc ID 17807 Rev 1 1/3
For further information contact your local STMicroelectronics sales office .
www.st.com
3
Revision history
Table 2. Document revision history
Date Revision Changes
09-Aug-2010 1 Initial release.
