IAR™ starter kit for ST ARM core-based microcontrollers
Features
■ The IAR Embedded WorkBench
(EWARM) software package with:
– KickStart™ C/C++ compiler for output of
code up to 32 Kbytes
– VisualSTATE
®
code generator, 20-state
version
– C-SPY
®
high-level language debugger
– Editor, linker and librarian tools
■ Embedded J-Link in-circuit debugger/
programmer with USB interface to host PC and
20-pin JTAG application interface
■ Full-featured KickStart development board with
target microcontroller
Description
®
for ARM
STM3210E-SK/IAR
Data brief
The IAR KickStart Kit™ is a complete,
cost-effective solution for starting application
development and evaluating the
STMicroelectronics STM32F101/102/103 ARM
core-based microcontrollers.
The STM3210E-SK/IAR is a KickStart kit
providing all the hardware and software you need
to start developing applications including the
KickStart development board with target
microcontroller, the IAR J-Link in-circuit
debugger/programmer (USB/JTAG) and IAR
Embedded WorkBench for ARM (EWARM)
integrated development environment with the
KickStart edition of the IAR C/C++ compiler
(output code up to 32 Kbytes), built-in Flash
loader and sample projects for all device
peripherals.
IAR KickStart kits are available for a full range of
ST ARM core-based microcontrollers.
March 2011 Doc ID 018597 Rev 1 1/4
For further information contact your local STMicroelectronics sales office.
www.st.com
4
Starter kit architecture STM3210E-SK/IAR
Starter kit architecture
The IAR development software is a suite of software tools for all phases of application
development that includes:
● IAR Embedded WorkBench
KickStart 32KB C/C++ compiler to build the application and the C-SPY™ debugger for
debugging the application while it runs on your microcontroller.
● VisualSTATE
®
20-state version of IAR’s graphical design environment with C/C++
code generator for developing application code based on machine states.
● J-Link in-circuit debugger/programmer (USB/JTAG) which integrates fully with
EWARM, allowing you to download the application to your target and debug it while it
runs on your ST ARM core-based microcontroller. J-Link is embedded on the KickStart
development board in the STM3210E starter kit.
● KickStart development board that provides a full range of features to help developers
evaluate and start developing applications for the included
microcontroller. The board is powered from the J-Link’s USB connection with the host
PC. The STM3210E KickStart development board key features include:
– Embedded J-Link
– 20-pin JTAG connector
– 20-pin trace tool connector
– SD/MMC connector
– Power supply from USB connection
– MEMS accelerometer
– 2 USART connectors
– SPI
2
C
–I
– USB connector
– 4 user LEDs
– Graphic LCD display
– Potentiometer connected to ADC
– 3 user, tamper, wake-up push buttons
– Reset button
– Wrap area
– Stepper motor
®
for ARM integrated development environment with the
STM32F103ZETx
Ordering information
IAR KickStart kits can be ordered from IAR or from your nearest ST distributor or sales
office for STM32 performance and access line microcontrollers with up to 512K Flash
(ST order code: STM3210E-SK/IAR).
2/4 Doc ID 018597 Rev 1
For more information and complete documentation, please refer to the IAR web site or the
STMicroelectronics microcontroller support site on www.st.com.
STM3210E-SK/IAR Revision history
Revision history
Table 1. Document revision history
Date Revision Changes
15-Mar-2011 1 Initial release.
