ST STA515W User Manual

40-volt, 3-amp, quad power half bridge
Features
Multipower BCD technology
Low input/output pulse width distortion
200 m R
stage
CMOS-compatible logic inputs
Thermal protection
Thermal warning output
Undervoltage protection
Short-circuit protection
Description
The STA515W is a monolithic quad half-bridge stage in Multipower BCD Technology. The device can be used as a dual bridge or reconfigured, by connecting pin CONFIG to pins VDD, as a single bridge with double-current capability.
The device is designed, particularly, to be the output stage of a stereo all-digital high-efficiency amplifier. It is capable of delivering 10 W x

Table 1. Device summary

complementary DMOS output
STA515W
PowerSSO36 package with exposed pad down
4 channels into 4- loads with 10% THD at V
= 18 V in single-ended configuration.
CC
It can also deliver 20 W + 20 W into 8- loads with 10% THD at V or, in single parallel BTL configuration, 40 W into a 8-Ω load with 10% THD at V
The input pins have a threshold proportional to the voltage on pin VL.
The STA515W comes in a 36-pin PowerSSO package with exposed pad down (EPD).
= 18 V in BTL configuration
CC
= 26 V.
CC
Order code Ambient temp. range Package Packaging
STA515W 0 to 70 °C PowerSSO36 EPD Tube
STA515W13TR 0 to 70 °C PowerSSO36 EPD Tape and reel
April 2010 Doc ID 11079 Rev 2 1/14
www.st.com
14
Introduction STA515W

1 Introduction

Figure 1. STA515W circuit for quad single-ended amplifiers

+3.3V
TH_WARN
C58
100nF
VCC1A
29
IN1A
IN1A
23
VL
24
CONFIG
25
PWRDNPWR_DN
R57
R59
100nF
C60
C58
100nF
10K
C53
IN1B
IN2A
IN2B
FAULT
TRISTATE
THWARN
IN1B
VDD
VDD
VSS
VSS
VCCSIG
VCCSIG
IN2A
GNDREG
GNDCLEAN
IN2B
GNDSUB
10K
100nF
27
26
28
30
21
22
33
34
35
36
31
20
19
32
1
PROTECTION
&
LOGIC
REGULATORS
M3
M2
M5
M4
M17
M15
M16
M14
15
17
16
14
12
11
10
13
7
8
9
6
4
3
2
5
D03AU1474bc
OUT1A
OUT1A
GND1A
VCC1B
OUT1B
OUT1B
GND1B
VCC2A
OUT2A
OUT2A
GND2A
VCC2B
OUT2B
OUT2B
GND2B
C81
100nF
C82
100nF
C83
100nF
C84
100nF
R61
5K
C31 820µF
C91 1µF
R62
5K
R63
C32 820µF
5K
C92 1µF
R64
5K
R65
C33 820µF
5K
C93 1µF
R66
5K
R67
C34 820µF
5K
C94 1µF
R68
5K
1µF
L11 22µH
C71
R41
100nF
20
C41
330pF
C51
C61
1µF
100nF
C42
330pF
C43
330pF
C52
C62
1µF
100nF
C44
330pF
R51
6
L12 22µH
C72
R42
100nF
20
R52
6
1µF
L13 22µH
C73
R43
100nF
20
R53
6
L14 22µH
C74
R44
100nF
20
R54
6
+V
CC
C21
2200µF
4
4
4
4
2/14 Doc ID 11079 Rev 2
STA515W Pin description

2 Pin description

Figure 2. Pin out

VCCSIG VCCSIG VSS VSS IN2B IN2A IN1B IN1A THWARN FAU LT TRISTATE PWRDN CONFIG VL VDD VDD GNDREG GNDCLEAN

Table 2. Pin list

GNDSUB
OUT2B OUT2B
VCC2B GND2B GND2A
VCC2A
OUT2A
OUT2A
OUT1B
OUT1B
VCC1B GND1B GND1A
VCC1A
OUT1A
OUT1A
N.C.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
STA515W
36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19
Pin Name Type Description
1 GNDSUB PWR Substrate ground
2, 3 OUT2B O Output half bridge 2B
4 VCC2B PWR Positive supply
5 GND2B PWR Negative supply
6 GND2A PWR Negative supply
7 VCC2A PWR Positive supply
8, 9 OUT2A O Output half bridge 2A
10, 11 OUT1B O Output half bridge 1B
12 VCC1B PWR Positive supply
13 GND1B PWR Negative supply
14 GND1A PWR Negative supply
15 VCC1A PWR Positive supply
16, 17 OUT1A O Output half bridge 1A
18 N.C. - No internal connection
19 GNDCLEAN PWR Logical ground
20 GNDREG PWR Ground for regulator V
DD
21, 22 VDD PWR 5-V regulator referred to ground
23 VL PWR High logical state setting voltage, V
Doc ID 11079 Rev 2 3/14
L
Pin description STA515W
Table 2. Pin list
Pin Name Type Description
Configuration pin:
24 CONFIG I
25 PWRDN I
26 TRISTATE I
27 FAULT O
28 THWARN O
29 IN1A I Input of half bridge 1A
30 IN1B I Input of half bridge 1B
0: normal operation 1: bridges in parallel, see Parallel-output and high-current
operation on page 9
Stand-by pin: 0: low-power mode
1: normal operation
Hi-Z pin: 0: all power amplifier outputs in high-impedance state
1: normal operation
Fault pin advisor (open-drain device, needs pull-up resistor): 0: fault detected (short circuit or thermal, for example)
1: normal operation
Thermal-warning advisor (open-drain device, needs pull-up resistor):
o
0: temperature of the IC >130
C
1: normal operation
31 IN2A I Input of half bridge 2A
32 IN2B I Input of half bridge 2B
33, 34 VSS PWR 5-V regulator referred to +V
35, 36 VCCSIG PWR Signal positive supply
CC
4/14 Doc ID 11079 Rev 2
STA515W Electrical characteristics

3 Electrical characteristics

Table 3. Absolute maximum ratings

Symbol Parameter Value Unit
V
CC
V
max
T
op
P
tot
T
stg

Table 4. Recommended operating conditions

DC supply voltage (Pins 4, 7, 12, 15) 40 V
Maximum voltage on pins 23 to 32 5.5 V
Operating temperature range 0 to 70 °C
Power dissipation (Tcase = 70 °C) 21 W
, TjStorage and junction temperature -40 to 150 °C
Symbol Parameter Min Typ Max Unit
V
CC
V
L
T
amb

Table 5. Thermal data

DC supply voltage (Pins 4, 7, 12, 15) 10 - 36 V
Input logic reference 2.7 3.3 5.0 V
Ambient temperature 0 - 70 °C
Symbol Parameter Min Typ Max Unit
T
T
T
t
hSD
warn
j-case
jSD
Thermal resistance junction to case (thermal pad) - - 1.5 °C/W
Thermal shut-down junction temperature - 150 - °C
Thermal warning temperature - 130 - °C
Thermal shut-down hysteresis - 25 - °C
Unless otherwise stated, the test conditions for Ta bl e 6 below are VL = 3.3 V, VCC = 30 V, R
=8Ω, fSW = 384 kHz and T
L

Table 6. Electrical characteristics

Symbol Parameter Test conditions Min Typ Max Unit
R
I
g
g
dsON
dss
N
P
Power P-channel/N-channel MOSFET R
dsON
Power P-channel/N-channel leakage Idss
Power P-channel R matching
Power N-channel R matching
Dt_s Low current dead time (static) see Figure 3 - 1020ns
= 25 °C
amb
= 1 A - 200 270 m
I
dd
V
= 35 V --50µA
CC
dsON
dsON
= 1 A 95--%
I
dd
= 1 A 95--%
I
dd
Doc ID 11079 Rev 2 5/14
Electrical characteristics STA515W
Table 6. Electrical characteristics (continued)
Symbol Parameter Test conditions Min Typ Max Unit
Dt_d
t
d ON
t
d OFF
t
r
t
f
V
CC
V
IN-Low
V
IN-High
I
IN-H
I
IN-L
I
PWRDN-H
V
Low
High current dead time (dynamic)
L = 22 µH, C = 470 nF
= 8 Ω, Idd = 3.0 A
R
L
see Figure 4
--50ns
Turn-on delay time Resistive load - - 100 ns
Turn-off delay time Resistive load - - 100 ns
Rise time
Fall time
Resistive load see Figure 3
Resistive load see Figure 3
--25ns
--25ns
Supply operating voltage - 10 - 36 V
Half-bridge input, low level voltage
Half-bridge input, high level voltage
-
-
High level input current VIN = V
-
VL / 2 + 300 mV
L
-1-µA
-
-
V
/ 2
L
300 mV
-
­V
V
Low level input current VIN = 0.3 V - 1 - µA
High level PWRDN pin input current
V
= 3.3 V - 35 - µA
L
Low logical state voltage (pins PWRDN, TRISTATE)
VL = 3.3V --0.8V
(seeTa bl e 7 )
V
High
I
VCC-
PWRDN
I
FAULT
I
VCC-HiZ
I
VCC
I
OCP
V
UVP
t
pw_min
High logical state voltage (pins PWRDN, TRISTATE)
VL = 3.3 V 1.7 - - V
(seeTa bl e 7 )
Supply current from VCC in power down
V
= 0 V --3mA
PWRDN
Output current on pins FAULT, THWARN with fault
= 3.3V -1-mA
V
pin
condition
Supply current from VCC in 3-state
V
TRISTATE
= 0 V - 22 - mA
Input pulse width
Supply current from VCC in operation (both channels switching)
= 50% duty, switching frequency
= 384 kHz,
-50-mA
no LC filters
Overcurrent protection threshold Isc (short circuit
- 36- A
current limit)
Undervoltage protection threshold
--7-V
Output minimum pulse width No load 70 - 150 ns
6/14 Doc ID 11079 Rev 2
STA515W Electrical characteristics

Table 7. Threshold switching voltage variation with voltage on pin VL

Voltage on pin VL, V
L
V
max V
LOW
min Unit
HIGH
2.7 0.7 1.5 V
3.3 0.8 1.7 V
5.0 0.85 1.85 V

Table 8. Logic truth table

Pin
TRISTATE
Inputs as per Figure 4 Transistors as per Figure 4
Output mode
INxA INxB Q1 Q2 Q3 Q4
0 x x Off Off Off Off Hi Z
100OffOffOnOnDump
101OffOnOnOffNegative
110OnOffOffOnPositive
111OnOnOffOffNot used
Test circuits

Figure 3. Test circuit

OUTxY
Vcc
Low current dead time = MAX(DTr,DTf)
Duty cycle = 50%
INxY
gnd
+Vcc
OUTxY
R 8
DTfDTr
+
-
(3/4)Vcc
(1/2)Vcc
(1/4)Vcc
t
vdc = Vcc/2
D03AU1458

Figure 4. Current dead time test circuit

High Current Dead time for Bridge application = ABS(DTout(A)-DTin(A))+ABS(DTOUT(B)-DTin(B))
+V
CC
Duty cycle=A Duty cycle=B
DTin(A)
INA
Duty cycle A and B: Fixed to have DC output current of 4.5A in the direction shown in figure
Q1
Q3
OUTA
Iout=4.5A
DTout(A)
C69
470nF
Rload=8
C71 470nF
DTout(B) DTin(B)
L68 22µL67 22µ
Iout=4.5A
C70
470nF
Q2
OUTB
Q4
INB
D03AU1517
Doc ID 11079 Rev 2 7/14
Applications information STA515W

4 Applications information

The STA515W is a dual channel H-bridge that can deliver 20 W per channel into 8 with 10% THD at V
The STA515W converts both DDX and binary-logic-controlled PWM signals into audio power at the load. It includes a logic interface, integrated bridge drivers, high efficiency MOSFET outputs and thermal and short-circuit protection circuitry.
In DDX mode, two logic-level signals per channel are used to control the high-speed MOSFET switches which drive the speaker load in a bridge configuration, according to the damped ternary modulation operation.
In binary mode, both full-bridge and half-bridge modes are supported.
The STA515W includes overcurrent and thermal protection as well as an undervoltage lockout with automatic recovery. A thermal warning status is also provided.

Figure 5. Block diagram for DDX or binary modes

= 18 V with high efficiency.
CC
INL[1,2]
INR[1,2]
VL
PWRDN
TRISTATE
FAU LT
THWARN
Logic interface and decode
Protection circuit
Regulators
Left H-bridge
Right H-bridge

Figure 6. Block diagram for binary half-bridge mode

INL[1,2]
INR[1,2]
VL
PWRDN
TRISTATE
FAU LT
THWARN
Logic interface and decode
Protection circuit
Regulators
Left A bridge
Left B bridge
Right A bridge
Right B bridge
OUTPL
OUTNL
OUTPR
OUTNR
OUTPL
OUTNL
OUTPR
OUTNR
Logic interface and decode
The STA515W power outputs are controlled using one or two logic-level timing signals. In order to provide a proper logic interface, pin VL must operate at the same voltage as the DDX control logic supply.
8/14 Doc ID 11079 Rev 2
STA515W Applications information
Protection circuits
The STA515W includes protection circuitry for overcurrent and thermal overload conditions. A thermal warning pin (THWARN) is activated low (open-drain MOSFET) when the IC temperature exceeds 130 °C, which is in advance of the thermal shutdown protection. When a fault condition is detected an internal fault signal acts to immediately disable the output power MOSFETs, placing both H-bridges in the high-impedance state. At the same time an open-drain MOSFET connected to pin FAULT is switched on.
There are two possible modes subsequent to activating a fault:
z Shutdown mode:
with pins FAULT (with pull-up resistor) and TRISTATE independent, an activated fault disables the device, signalling low at pin FAULT. The device may subsequently be reset to normal operation by toggling pin TRISTATE from high to low and back to high using an external logic signal.
z Automatic recovery mode:
This is shown in the applications circuit in Figure 7 and Figure 7 on page 10. Pins FAULT and TRISTATE are shorted together and connected to a time constant circuit comprising R59 and C58. An activated fault forces a reset on pin TRISTATE causing normal operation to resume following a delay determined by the time constant of the circuit. If the fault condition is still present, the circuit operation continues, repeating until the fault condition is removed. An increase in the time constant of the circuit produces a longer recovery interval.
Care must be taken in the overall system design so as not to exceed the protection thresholds under normal operation.
Power outputs
The STA515W power and output pins are duplicated to provide a low-impedance path for the device bridged outputs. All duplicated power, ground and output pins must be connected for proper operation.
Pins PWRDN or TRISTATE should be used to set all MOSFETS to the high-impedance state during power-up and until the logic power supply, VL, has settled.
Parallel-output and high-current operation
When using DDX mode, the STA515W outputs can be connected in parallel to increase the output current capability. In this configuration the device can provide 40 W into 8 Ω.
This mode of operation is enabled with pin CONFIG connected to VDD. The inputs must be combined to give INLA = INLB and INRA = INRB, then the corresponding outputs can be shorted together to give OUTLA = OUTLB and OUTRA = OUTRB.
Output filter
A passive 2nd-order filter is used on the STA515W power outputs to reconstruct an analog audio signal. The system performance can be significantly affected by the output filter design and choice of passive components.
Filter designs for 4- and 8- loads are shown in the applications circuits of Figure 1 on
page 2 for the half-bridge mode, and Figure 7 and Figure 8 on page 10 for the full bridge.
Doc ID 11079 Rev 2 9/14
Applications information STA515W
Applications circuits
Figure 7 below shows a typical full-bridge circuit for supplying 20 W + 20 W into 8-
speakers with 10% THD at V

Figure 7. Typical stereo full-bridge configuration for 20 + 20 W

IN1A
+3.3V
TH_WARN
C58
100nF
IN1A
R57
R59
10K
10K
C58
100nF
IN1B
C53
100nF
C60
100nF
IN2A
GNDCLEAN
IN2B
CONFIG
PWRDNPWR_DN
FAULT
TRISTATE
THWARN
IN1B
VDD
VDD
VCCSIG
VCCSIG
IN2A
GNDREG
IN2B
GNDSUB
VSS
VSS
29
VL
23
24
25
27
26
28
30
21
22
33
34
35
36
31
20
19
32
1
CC
PROTECTION
&
LOGIC
REGULATORS
= 18 V.
M3
M2
M5
M4
M17
M15
M16
M14
VCC1A
15
C30 1µF
17
OUT1A
16
OUT1A
14
GND1A
12
VCC1B
OUT1B
OUT1B
GND1B
VCC2A
OUT2A
OUT2A
GND2A
VCC2B
OUT2B
OUT2B
GND2B
C32
220nF
C31
220nF
C31
220nF
11
10
13
7
8
9
6
4
3
2
5
L18 22µH
C52
330pF
R63
20
L19 22µH
L113 22µH
C109
330pF
R104
20
L112 22µH
D00AU1148Bbc
C20
100nF
R98
R100
C21
100nF
C110
100nF
R103
R102
C111
100nF
6
6
6
6
470nF
C101 100nF
C107 100nF
470nF
C106 100nF
C23
C108
C99
100nF
+V
CC
C55
1000µF
8
8
Figure 8 below shows a single-BTL configuration capable of supplying 40 W into a 4- load
at 10% THD with V
= 19 V. This result was obtained with peak power for <1 s using the
CC
STA308+STA515W+STA50X demo board. A PWM modulator as driver is required.

Figure 8. Typical single-BTL configuration for 40 W

V
+3.3V
TH_WARN
10K
nPWR_DN
IN1A
IN1B
100nF
100nF
X7R
100nF
L
23 N.C.
GNDCLEAN
10K
100nF
X7R
100nF
X7R
Add.
GNDREG
CONFIG
THWARN
PWRDN
FAULT
TRISTATE
VCCSIG
VCCSIG
GNDSUB
VDD
VDD
IN1A
IN1B
IN2A
IN2B
VSS
VSS
19
20
21
22
24
28
25
27
26
29
30
31
32
33
34
35
36
1
18
17
OUT1A
16
OUT1A
11
OUT1B
10
OUT1B
OUT2A
9
OUT2A
8
OUT2B
3
OUT2B
2
VCC1A
15
VCC1B
12
VCC2A
7
VCC2B
4
GND1A
14
GND1B
13
GND2A
6
GND2B
5
10µH
22
1/2W
330pF
10µH
1µF X7R
220nF
1µF X7R
220nF
D04AU1545bc
3.3
1/2W
3.3
1/2W
100nF
FILM
100nF
FILM
2200µF
63V
220nF
X7R
220nF
X7R
Vcc
Vcc
680nF
FILM
4
10/14 Doc ID 11079 Rev 2
STA515W Package mechanical data

5 Package mechanical data

The STA515W comes in a 36-pin PowerSSO package with exposed pad down (EPD).
Figure 9 below shows the package outline and Ta bl e 9 gives the dimensions.
In order to meet environmental requirements, ST offers these devices in different grades of ECOPACK specifications, grade definitions and product status are available at: www.st.com. ECOPACK

Table 9. PowerSSO36 EPD dimensions

Symbol
A 2.15 - 2.47 0.085 - 0.097
A2 2.15 - 2.40 0.085 - 0.094
a1 0.00 - 0.10 0.000 - 0.004
b 0.18 - 0.36 0.007 - 0.014
c 0.23 - 0.32 0.009 - 0.013
D 10.10 - 10.50 0.398 - 0.413
E 7.40 - 7.60 0.291 - 0.299
e - 0.5 - - 0.020 -
e3 - 8.5 - - 0.335 -
F - 2.3 - - 0.091 -
G- - 0.10 - - 0.004
H 10.10 - 10.50 0.398 - 0.413
h- - 0.40 - - 0.016
®
packages, depending on their level of environmental compliance. ECOPACK®
®
is an ST trademark.
Dimensions in mm Dimensions in inches
Min Typ Max Min Typ Max
k 0 - 8 degrees 0 - 8 degrees
L 0.60 - 1.00 0.024 - 0.039
M - 4.30 - - 0.169 -
N - - 10 degrees - - 10 degrees
O - 1.20 - - 0.047 -
Q - 0.80 - - 0.031 -
S - 2.90 - - 0.114 -
T - 3.65 - - 0.144 -
U - 1.00 - - 0.039 -
X 4.10 - 4.70 0.161 - 0.185
Y 6.50 - 7.10 0.256 - 0.280
Doc ID 11079 Rev 2 11/14
12/14 Doc ID 11079 Rev 2

Figure 9. PowerSSO36 EPD outline drawing

h x 45°
Package mechanical data STA515W
STA515W Revision history

6 Revision history

Table 10. Document revision history

Date Revision Changes
Nov-2004 1 Initial release.
Added order code STA515W13TR Modified Figure 1 on page 2 Reconstructed pin list in Table 2 on page 3 with information from
27-Apr-2010 2
former table 3 Functional pin status Updated Vlow and Vhigh spec in Table 6 on page 5 Modified Figure 3 and Figure 4 on page 7 Updated applications circuits in Figure 7 and Figure 8 on page 10
Doc ID 11079 Rev 2 13/14
STA515W
Please Read Carefully:
Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, modifications or improvements, to this document, and the products and services described herein at any time, without notice.
All ST products are sold pursuant to ST’s terms and conditions of sale.
Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein, and ST assumes no liability whatsoever relating to the choice, selection or use of the ST products and services described herein.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
UNLESS EXPRESSLY APPROVED IN WRITING BY AN AUTHORIZED ST REPRESENTATIVE, ST PRODUCTS ARE NOT RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY, AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING APPLICATIONS, NOR IN PRODUCTS OR SYSTEMS WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY, DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE NOT SPECIFIED AS "AUTOMOTIVE GRADE" MAY ONLY BE USED IN AUTOMOTIVE APPLICATIONS AT USER’S OWN RISK.
Resale of ST products with provisions different from the statements and/or technical features set forth in this document shall immediately void any warranty granted by ST for the ST product or service described herein and shall not create or extend in any manner whatsoever, any liability of ST.
ST and the ST logo are trademarks or registered trademarks of ST in various countries.
Information in this document supersedes and replaces all information previously supplied.
The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective owners.
© 2010 STMicroelectronics - All rights reserved
STMicroelectronics group of companies
Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -
Malaysia - Malta - Morocco - Philippines - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America
www.st.com
14/14 Doc ID 11079 Rev 2
Loading...
