ST SPC563M64L5, SPC563M64L7 User Manual

SPC563M64L5, SPC563M64L7
32-bit Power Architecture® based MCU for automotive
powertrain applications
Features
Single issue, 32-bit Power Architecture
E compliant e200z335 CPU core complex – Includes variable length encoding (VLE)
enhancements for code size reduction
32-channel direct memory access controller
(DMA)
Interrupt controller (INTC) capable of handling
364 selectable-priority interrupt sources: 191 peripheral interrupt sources, 8 software interrupts and 165 reserved interrupts.
Frequency-modulated phase-locked loop
(FMPLL)
Calibration external bus interface (EBI)
System integration unit (SIU)
Up to 1.5 Mbyte on-chip Flash with Flash
controller – Fetch Accelerator for single cycle Flash
access @80 MHz
Up to 94 Kbyte on-chip static RAM (including
up to 32 Kbyte standby RAM)
Boot assist module (BAM)
32-channel second-generation enhanced time
processor unit (eTPU)
a. The external bus interface is only accessible when
using the calibration tool. It is not available on production packages.
Table 1. Device summary
Memory Flash size
Package: LQFP100 Package: LQFP144 Package: LQFP176 Package: LBGA208
®
Book
(a)
144 LQFP 20 mm x 20 mm
176 LQFP
24 mm x 24 m
m
100 LQFP 14 mm x 14 mm
LFBGA208 17 mm x 17 mm x1.5mm
– 32 standard eTPU channels – Architectural enhancements to improve
code efficiency and added flexibility
16-channels enhanced modular input-output
system (eMIOS)
Enhanced queued analog-to-digital converter
(eQADC)
Decimation filter (part of eQADC)
Silicon die temperature sensor
2 deserial serial peripheral interface (DSPI)
modules (compatible with Microsecond Bus)
2 enhanced serial communication interface
(eSCI) modules compatible with LIN
2 controller area network (FlexCAN) modules
that support CAN 2.0B
Nexus port controller (NPC) per IEEE-ISTO
5001-2003 standard
IEEE 1149.1 (JTAG) support
Nexus interface
On-chip voltage regulator controller that
provides 1.2 V and 3.3 V internal supplies from a 5 V external source.
Designed for LQFP100, LQFP144, LQFP176
and LBGA208.
Part number
1536 Kbyte SPC563M64L5 SPC563M64L7
June 2012 Doc ID 14642 Rev 9 1/142
This is information on a product in full production.
www.st.com
