Sprint Kyocera Echo User Manual
©2011 Sprint. SPRINT and the logo are trademarks of Sprint.
S/W version
1.003SP
KYOCERA is a registered trademark of Kyocera Corporation.
Other marks are the property of their respective owners.
User Guide
www.sprint.com
Consejo: Para encontrar una guía para usuarios en español,
por favor visita a
Support > Devices.
To find a User Guide in Spanish, please visit
www.sprint.com and click Support > Devices.
Important Privacy Message – Sprint’s policies often do not
apply to third-party applications. Third-party applications may
access your personal information or require Sprint to disclose
your customer information to the third-party application
provider. To find out how a third-party application will collect,
access, use, or disclose your personal information, check the
application provider’s policies, which can usually be found on
their website. If you aren’t comfortable with the third-party
www.sprint.com y haz clic en
application’s policies, don’t use the application.
Table of Contents
Tip: Looking for something? If you don’t see it in the headings
listed here, try the Index on page 176.
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Your Device’s Menu. . . . . . . . . . . . . . . . . . . . . . . . i
Section 1: Getting Started . . . . . . . . . . . . . . . . . 1
1A. Setting Up Service . . . . . . . . . . . . . . . . . . . 2
Setting Up Your Device . . . . . . . . . . . . . . . . . . . . . . 2
Activating Your Device . . . . . . . . . . . . . . . . . . . . . . 3
Setting Up Your Voicemail . . . . . . . . . . . . . . . . . . . 4
Sprint Account Passwords . . . . . . . . . . . . . . . . . . . 5
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Section 2: Your Device . . . . . . . . . . . . . . . . . . . . 7
2A. Device Basics . . . . . . . . . . . . . . . . . . . . . . . 8
Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Viewing the Display Screen . . . . . . . . . . . . . . . . . 10
Turning Your Device On and Off . . . . . . . . . . . . . 12
Battery and Charger . . . . . . . . . . . . . . . . . . . . . . . 13
Opening and Closing the Device . . . . . . . . . . . . 17
Navigating Through the Onscreen Menus . . . . 18
Home Screen Overview . . . . . . . . . . . . . . . . . . . . 20
Your Device’s Screen Modes . . . . . . . . . . . . . . . 26
Making and Answering Calls . . . . . . . . . . . . . . . 32
Displaying Your Phone Number . . . . . . . . . . . . . 38
Entering Text Using the Onscreen Keyboards . . 38
Creating a Google Account . . . . . . . . . . . . . . . . 46
2B. Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Location Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Synchronizing Accounts . . . . . . . . . . . . . . . . . . . 53
Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Airplane Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
TTY Use With Sprint Service . . . . . . . . . . . . . . . . 57
Using the Hearing Device Compatibility
Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Security Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Application Settings . . . . . . . . . . . . . . . . . . . . . . . 61
Privacy Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
2C. Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Viewing the Call Log . . . . . . . . . . . . . . . . . . . . . . 64
Call Log Options . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Making a Call From the Call Log . . . . . . . . . . . . 65
Saving a Number From the Call Log . . . . . . . . 65
Editing a Call Log Number . . . . . . . . . . . . . . . . . 66
Erasing the Call Log . . . . . . . . . . . . . . . . . . . . . . . 66
2D. Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Displaying the Contacts List . . . . . . . . . . . . . . . . . 67
Adding a New Contacts Entry . . . . . . . . . . . . . . . 67
Contacts Entry Options . . . . . . . . . . . . . . . . . . . . 68
Editing a Contacts Entry . . . . . . . . . . . . . . . . . . . 69
Adding a Number to a Contacts Entry . . . . . . . 69
Editing a Contacts Entry’s Number . . . . . . . . . . 69
Assigning a Ringer Type for an Entry . . . . . . . . 69
Assigning a Picture to an Entry . . . . . . . . . . . . . . 70
Finding Contacts Entries . . . . . . . . . . . . . . . . . . . . 70
Deleting Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Adding Entries to Your Favorites . . . . . . . . . . . . . 70
Import and Export Contacts . . . . . . . . . . . . . . . . . 71
Sending Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Synchronizing and Displaying Contacts . . . . . . 71
2E. Calendar & Tools . . . . . . . . . . . . . . . . . . . . 73
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Document Viewer . . . . . . . . . . . . . . . . . . . . . . . . . 80
Updating Your Device . . . . . . . . . . . . . . . . . . . . . . 80
2F. Voice Services . . . . . . . . . . . . . . . . . . . . . 82
Automatic Speech Recognition (ASR) . . . . . . . . 82
Voice Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Text-to-Speech . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
2G. microSD Card . . . . . . . . . . . . . . . . . . . . . . 85
Your Device’s microSD Card and Adapter . . . . 85
microSD Card Settings . . . . . . . . . . . . . . . . . . . . . 87
Connecting Your Device to Your Computer . . . 88
Important Connection Information . . . . . . . . . . . 89
2H. Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Taking Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Recording Videos . . . . . . . . . . . . . . . . . . . . . . . . . 95
Opening Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . 97
2I. Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Turning Bluetooth On and Off . . . . . . . . . . . . . . . 99
Using the Bluetooth Settings Menu . . . . . . . . . 100
Pairing Bluetooth Devices . . . . . . . . . . . . . . . . . 100
Sending Items via Bluetooth . . . . . . . . . . . . . . . 102
Section 3: Sprint Service. . . . . . . . . . . . . . . . 103
3A. Sprint Service: The Basics . . . . . . . . . . 104
Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Making a 3-Way Call . . . . . . . . . . . . . . . . . . . . . . 110
Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
3B. Web and Data Services . . . . . . . . . . . . . 114
Getting Started With Data Services . . . . . . . . . 114
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Portable Wi-Fi Hotspot . . . . . . . . . . . . . . . . . . . . 123
Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Corporate Email . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Removing an Email Account . . . . . . . . . . . . . . . 134
Removing a Gmail Account . . . . . . . . . . . . . . . 134
Email Icons On Your Device . . . . . . . . . . . . . . . 134
Using Google Talk . . . . . . . . . . . . . . . . . . . . . . . . 135
Using Android Market . . . . . . . . . . . . . . . . . . . . . 138
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Data Services FAQs . . . . . . . . . . . . . . . . . . . . . . 143
3C. Entertainment: TV and Music . . . . . . . . 145
TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Streaming Music . . . . . . . . . . . . . . . . . . . . . . . . . 151
VueQue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
3D. GPS Navigation . . . . . . . . . . . . . . . . . . . . 153
GPS Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
TeleNav GPS Navigator . . . . . . . . . . . . . . . . . . . 153
Google Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Section 4: Safety and Warranty
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
4A. Important Safety Information . . . . . . . . 161
General Precautions . . . . . . . . . . . . . . . . . . . . . . 161
Maintaining Safe Use of and Access to Your
Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Using Your Device With a
Hearing Device . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Caring for the Battery . . . . . . . . . . . . . . . . . . . . . 165
Radio Frequency (RF) Energy . . . . . . . . . . . . . 165
Owner’s Record . . . . . . . . . . . . . . . . . . . . . . . . . 168
User Guide Proprietary Notice . . . . . . . . . . . . . 168
4B. Manufacturer’s Warranty . . . . . . . . . . . . 169
Manufacturer’s Warranty . . . . . . . . . . . . . . . . . . 169
4C. End User License Agreement . . . . . . . 172
End User License Agreement . . . . . . . . . . . . . . 172
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
Introduction
Your Device’s Menu
This User Guide introduces you to Sprint® service and
all the features of your new device. It’s divided into four
sections:
⽧ Section 1: Getting Started
⽧ Section 2: Your Device
⽧ Section 3: Sprint Service
⽧ Section 4: Safety and Warranty Information
WARNING: Please refer to the Important Safety Information
section on page 161 to learn about information
that will help you safely use your device. Failure
to read and follow the Important Safety
Information in this guide may result in serious
bodily injury, death, or property damage.
The following table outlines your device’s main menu
structure. For more information about using your
device’s menus, see “Navigating Through the
Onscreen Menus” on page 18.
Pressing
Home provides access to your device’s
Main Home screen. From the Home screen, press
Menu to open the following menus:
䢇 Add ()
䢇 Wallpaper ()
䢇 Search ()
䢇 Notifications ()
䢇 Settings ()
Tap these onscreen buttons to view additional options
and features.
i
Add
1: S hortc uts
2: Widgets
3: Folders
4: Wallpapers
Wallpaper
1: Gallery
2: Live wallpapers
3: Wallpapers
Search
Notifications
ii
1: Applications 2: Bookmark
3: Contact 4: Direct dial
5: Direct message 6: Directions & Navigation
7: Latitude 8: Music playlist
9: Settings 10: Tablet Mode Extension
1: New folder 2: All contacts
3:
Bluetooth received
5: Facebook Phonebook 6: Starred contacts
1: Gallery 2: Live wallpapers
3: Wallpapers
4:
Contacts with phone number s
Settings
1: Wireless & networks
1: Airplane mode (On/Off)
2: Wi-Fi (On/Off)
3: Wi-Fi settings
1: Wi-Fi (On/Off) 2:
3: Add Wi-Fi network
4: Bluetooth (On/Off)
5: Bluetooth settings
1: Bluetooth (On/Off) 2: Device name
3: Discoverable (On/Off) 4: Scan for devices
6: Tethering & portable hotspot
1: USB tethering (On/Off)
2: Portable Wi-Fi hotspot (On/Off)
3: Portable Wi-Fi hotspot settings
4: Help
7: Mobile networks
1: Data enabled (On/Off) 2: Roaming mode
3:
Domestic voice (On/Off)
5:
International voice (On/Off)
7: Roaming guards
Network notification (On/Off)
4: Domestic data (On/Off)
6:
International data (On/Off)
2: Call settings
1: Voicemail service
2: Voicemail settings
3: Plus code dialing
1:
North American dialing (On/Off) 2: International dialing
4: DDTM mode (On/Off)
5: TTY mode
1: TTY Off 2: TTY Full
3: TTY HCO 4: TTY VCO
6: CDMA call settings
1: Voice Privacy(On/Off)
3: Sound
1: Silent mode (On/Off)
2: Vibrate
1: Always 2: Never
3: Only in Silent mode 4:
3: Volume
4: Phone ringtone
5: Notification ringtone
Only when not in Silent mode
6: Audible touch tones (On/Off)
7: Audible selection (On/Off)
8: Screen lock sounds (On/Off)
9: Haptic feedback (On/Off)
10: Hearing Aid (On/Off)
4: Display
1: Brightness
2: Auto-rotate screen (On/Off)
3: Animation
4: Screen timeout
5: Auto backlight (On/Off)
5: Location & security
1: Use wireless networks (On/Off)
2: Use GPS satellites (On/Off)
3: Set up screen lock
4: Visible passwords (On/Off)
5: Select device administrators
6: Use secure credentials (On/Off)
iii
6: Applications
7: Accounts & sync
8: Privacy
iv
7: Install from SD card
8: Set password
9: Clear storage
1: Unknown sources (On/Off)
2: Manage applications
3: Running services
4: Development
1: USB debugging (On/Off) 2: Stay awake (On/Off)
3: Allow mock locations (On/Off)
1: Background data (On/Off)
2: Auto-sync (On/Off)
1: Back up my data (On/Off)
2: Automatic restore (On/Off)
3: Factory data reset
9: SD card & phone storage
1: Total space
2: Available space
3: Mount SD card / Unmount SD card
4: Format SD card
5: Available space
10: Language & keyboard
1: Select language
1: English 2: Espa ñol
2: Swype (settings)
1: Language 2: Word prediction (On/Off)
3:
Audio feedback (On/Off )
5:
Enable tip indicator (On/Off)
7: Auto-capitalization (On/Off)
8: Show complete trace (On/Off)
9: Word choice window 10: Speed vs. accuracy
11: Swype help 12: Tutorial
13: Version
4:
Vibrate on keypress (On/Off)
6: Auto-spacing (On/Off)
3: Android keyboard (settings)
1: Vibrate on keypress (On/Off)
2: Sound on keypress (On/Off)
3: Auto-capitalization (On/Off)
4: Voice input
5: Input languages
6: Quick fixes (On/Off)
7: Show suggestions (On/Off)
8: Auto-complete (On/Off)
4: User dictionary
11: Voice input & output
1: Voice recognizer settings
1: Language 2: SafeSearch
3: Block offensive words (On/Off)
4: Show hints (On/Off)
2: Text-to-speech settings
1: Listen to an example 2:
3: Default Engine 4: Install voice data
5: Speech rate 6: Language
7: Pico TTS
Always use my settings (On/Off)
12: Accessibility
1: Accessibility (On/Off)
2: Power button ends call (On/Off)
13: Date & time
1: Automatic (On/Off)
2: Set date
3: Select time zone
4: Set time
5: Use 24-hour format (On/Off)
6: Select date format
14: About phone
1: S tat us
1: Battery status 2: Battery level
3: My phone number 4: MSID
5: ESN 6: Network
7: Signal strength 8: Mobile network type
9: MEID 10: Service state
11: Roaming 12: Mobile network state
13: SID 14: Wi-Fi MAC address
15: Bluetooth address 16: Up time
2: Battery use
3: Legal information
1: Open source licenses 2: Google legal
4: System tutorial
v
15: System Update
vi
5: Model number
6: Software Version
7: Ha rdwa re
8: PRL Version
9: Android version
10: Baseband version
11: Kernel version
12: Build number
1: Update Android
1: Check Now 2:
Scheduled Check (On/Off)
2: Update Kyocera software
3: Update Profile
4: Update PRL
Section 1
Getting Started
⽧ Setting Up Your Device (page 2)
1A. Setting Up Service
⽧ Activating Your Device (page 3)
⽧ Setting Up Your Voicemail (page 4)
⽧ Sprint Account Passwords (page 5)
⽧ Getting Help (page 5)
Setting Up Your Device
1. Install the battery.
䡲 Firmly press your thumbs
against the battery cover
and push upward to
remove it.
2 1A. Setting Up Service
䡲 Insert the top end of the
battery into the opening on
the back of the device,
making sure the
connectors align. Gently
press down to secure the
battery.
䡲 Position the back cover over
the battery compartment,
making sure the notches on
the top align and slide the
cover downward with your
thumbs until the cover is
seated.
2. Press and hold the power button to turn on
your device.
Power button
䡲 If your device is activated, it will search for Sprint
service and show the Lock screen. To unlock the
screen, flick the Unlock icon .
䡲 If your device is not yet activated, see the
following section “Activating Your Device” for
more information.
3. Make your first call.
䡲 Press Home to access the Home screen and
tap the Phone icon to access the onscreen
phone keypad.
䡲 Use your phone keypad to enter a phone number.
䡲 Ta p .
Note: You should fully charge your battery before setting up
your device. See “Charging the Internal Battery” on
page 14 for details.
Activating Your Device
䢇 If you purchased your device at a Sprint Store, it is
probably activated and ready to use.
䢇 If you received your device in the mail, and it is for a new
Sprint account or a new line of service, your device is
designed to activate automatically when you first turn
it on. To confirm your activation, make a phone call.
䢇 If you received your device in the mail and it is going to
be activated on an existing number on your account
(you’re swapping phones), you can activate on your
computer online or directly on your device.
Activating on your computer:
䡲 Go to w ww.sprint.com/activate and follow the
instructions.
Activating on your device:
Note: For security reasons, you will need your Sprint phone
number and PIN to use this activation method.
1. Turn on your new device. (Make sure the old one is
turned off.) Your device will automatically attempt
Hands-Free Activation.
1A. Setting Up Service 3
Setting Up Service
Note: Your device will need to complete one hands-free
activation attempt before you can continue.
Tap Activate to override auto-activation and start
2.
the manual activation wizard.
Note: If you don’t override Hands-Free Activation, your device
will attempt to auto-activate five times. Wait for
appear on your screen. Tap
Activate.
Retry and then tap
Retry to
3. Follow the onscreen prompts to complete the
activation process.
4. After you have completed the wizard, make a
phone call to confirm your activation.
If your device is still not activated, contact Sprint
Customer Service at
1-888 -211-4727 for assistance.
4 1A. Setting Up Service
Setting Up Your Voicemail
Your device automatically transfers all unanswered calls
to your voicemail, even if your device is in use or turned
off. You should set up your Sprint Voicemail and personal
greeting as soon as your device is activated. Always use
a password to protect against unauthorized access.
1. Press Home and tap to access the
onscreen phone keypad.
2. Tap and hold .
3. Follow the system prompts to:
䡲 Create your password.
䡲 Record your name announcement.
䡲 Record your greeting.
Note: Voicemail Password
Sprint strongly recommends that you create a
password when setting up your voicemail to protect
against unauthorized access. Without a password,
anyone who has access to your device is able to
access your voicemail messages.
For more information about using your voicemail, see
“Voicemail” on page 104.
Sprint Account Passwords
As a Sprint customer, you enjoy unlimited access to
your personal account information, your voicemail
account, and your data services account. To ensure
that no one else has access to your information, you
will need to create passwords to protect your privacy.
Account User Name and Password
If you are the account owner, you will create an account
user name and password when you sign on to
www.sprint.com. (Click Sign in and then click Sign up now!
to get started.) If you are not the account owner (if
someone else receives the bill for your Sprint service), you
can get a sub-account password at
Voicemail Password
You’ll create your voicemail password when you set up
your voicemail. See “Setting Up Your Voicemail” on
page 4 for more information on your voicemail
password.
www.sprint.com.
Data Services Password
With your Sprint device, you may elect to set up an
optional data services password to control access and
authorize Premium Service purchases.
For more information, or to change your passwords,
sign on to
Service at
www.sprint.com or call Sprint Customer
1-888 -211-4727.
Getting Help
Managing Your Account
Online: www.sprint.com
䢇 Access your account information.
䢇 Check your minutes used (depending on your Sprint
service plan).
䢇 View and pay your bill.
䢇 Enroll in Sprint online billing and automatic payment.
䢇 Purchase accessories.
䢇 Shop for the latest Sprint phones.
䢇 View available Sprint service plans and options.
䢇 Learn more about data services and other products
like games, ringers, screen savers, and more.
1A. Setting Up Service 5
Setting Up Service
From Your Sprint Phone
䢇 Tap to check minute usage and
account balance.
䢇 Tap to make a payment.
䢇 Tap to access a summary of your
Sprint service plan or get answers to other questions.
From Any Other Phone
䢇 Sprint Customer Service: 1-8 88-211-4727.
䢇 Business Customer Service: 1-800-927-2199.
Sprint 411
Sprint 411 gives you access to a variety of services and
information, including residential, business, and
government listings; movie listings or showtimes;
driving directions, restaurant reservations, and major
local event information. You can get up to three pieces
of information per call, and the operator can
automatically connect your call at no additional charge.
There is a per-call charge to use Sprint 411, and you
will be billed for airtime.
䊳 Ta p .
6 1A. Setting Up Service
Sprint Operator Services
Sprint Operator Services provides assistance when you
place collect calls or when you place calls billed to a
local telephone calling card or third party.
䊳 Ta p .
For more information or to see the latest in products
and services, visit us online at
www.sprint.com.
Section 2
Your Device
⽧ Your Device (page 8)
2A. Device Basics
⽧ Viewing the Display Screen (page 10)
⽧ Turning Your Device On and Off (page 12)
⽧ Battery and Charger (page 13)
⽧ Navigating Through the Onscreen Menus (page 18)
⽧ Home Screen Overview (page 20)
⽧ Your Device’s Screen Modes (page 26)
⽧ Making and Answering Calls (page 32)
⽧ Displaying Your Phone Number (page 38)
⽧ Entering Text Using the Onscreen Keyboards (page 38)
⽧ Creating a Google Account (page 46)
8 2A. Device Basics
Tip: Device Software Upgrades – Updates to your device’s
software may become available from time to time. Sprint
will automatically upload critical updates to your device.
You can also use the menu to check for and download
updates. Press
S
ettings >
Update Kyocera software
PRL
Ho
me > Menu , and then tap
System Update > Update Android,
, Update Profile, or Update
to search for and download available updates.
Your Device
1. Proximity
Sensor
2. Light Sensor
3. Earpiece
4. Display
Screens
9. LED Indicator
8. Microphone
7. Back Keys
( )
5. Home Keys
( )
6. Menu Keys
( )
Key Functions
15. Camera Lens
16. Camera Flash
14. Charger/Accessory
Jack
13. Volume Button
10. Headset Jack
12. Power Button
11. microSD Card Slot
17. Speaker
18. Internal Antennas
1. Proximity Sensor automatically decreases the
display brightness when you hold the device near
your face. This prevents you from unintentionally
activating device functions during a call.
2. Light Sensor automatically brightens the display
when you are in sunlight or a bright room and
dims it in darker places.
3. Earpiece lets you hear the caller and automated
prompts.
4. Display Screens (upper and lower) display all the
information needed to operate your device. Use
finger gestures to navigate and interact with items
on the screen.
5. Home Keys ( ) return you to the Home screen.
Tap and hold to show the recently used applications.
6. Menu Keys ( ) let you open the menus of the
current screen or application.
7. Back Keys ( ) return you to the previous screen or
closes the dialog box.
8. Microphone allows other callers to hear you clearly
when you are speaking to them.
9. LED Indicator shows your device’s battery status. It
also flashes for incoming calls or pending
notifications.
10. Headset Jack allows you to plug in an optional
headset for convenient, hands-free conversations.
CAUTION! Inserting an accessory into the incorrect
jack may damage the device.
11. microSD Card Slot allows you to insert a microSD
card to support external memory.
Note: Your device comes with the microSD card preinstalled.
2A. Device Basics 9
Device Basics
12.
Power Button ( ) lets you turn the device on or
off, or turn the screen backlight on or off. This button
can be configured to end a call. ( See “Ending Calls
Using the Power Button” on page 33. )
13. Volume Button allows you to adjust the ringer and
media volumes when you are not on a call, or the
voice volume during a call.
14 . Charger/Accessory Jack allows you to connect the
device charger to charge the battery or a
micro-USB cable (included) to transfer files to and
from a computer. CAUTION! Inserting an accessory
into the incorrect jack may damage the device.
15. Camera Lens, as part of the built-in camera, lets
you take pictures and videos.
16. Camera Flash allows you to take pictures in low
light conditions.
17. Speaker lets you hear the different ringers and
sounds. It also lets you hear the caller’s voice in
speakerphone mode.
18. Internal Antennas facilitate reception and
transmission. To maximize performance, do not
obstruct while using the device.
10 2A. Device Basics
Viewing the Display Screen
Your device’s display screen provides information
about your device’s status and options.
Status Bar Icons
The following list identifies the symbols you may see on
the status bar at the top of your device’s display screen:
Status Bar Icons
Your device’s current signal strength. (More bars =
stronger signal.)
Your device cannot find a usable signal.
Your device is “roaming” off the Nationwide Sprint
Network.
Sprint data service is available. When active, the
icon is animated.
A Wi-Fi connection is available.
An open Wi-Fi network is available.
Bluetooth is enabled.
The Bluetooth data connection is active.
Status Bar Icons
A voice call is in progress.
Call forwarding is on.
A chat is in progress.
The battery is completely discharged.
The battery is fully charged. (The less blue
showing, the less charge there is remaining.)
The battery is charging.
An error has occurred.
You have missed voice calls.
A download is in progress.
An upload is in progress.
The USB port is connected.
A microSD card has been disconnected
(unmounted) from the device and is now ready for
either removal or formatting.
GPS is active.
Silent mode and Vibrate mode are active.
Airplane mode is active.
Status Bar Icons
Speakerphone is on.
TTY mode is enabled.
You have new voicemail messages.
You have new Text/Multimedia messages.
You have new Email messages.
You have new Gmail™ messages.
You have calendar notifications.
An alarm is set.
Alarm is in snooze mode.
2A. Device Basics 11
Device Basics
Turning Your Device On and Off
Turning Your Device On
䊳 Press and hold for approximately two
seconds.
Once your device is on and finds a signal, it
automatically enters standby mode – the device’s idle
state. At this point, you are ready to begin making and
receiving calls.
If your device is unable to find a signal after five
minutes of searching, a Power Save feature is activated
and your device searches for a signal periodically
without your intervention. When a signal is found, your
device automatically returns to standby mode.
Tip: The Power Save feature conserves your battery power
when you are in an area where there is no signal.
Turning Your Device Off
1. Press and hold until you see the
Phone options window.
2. Ta p Power off > OK to turn the device off.
12 2A. Device Basics
Turning Screen Lock On or Off
To save your battery or prevent accidental touches,
your device automatically turns off the display screen
and lock the screen after the time specified for the
screen timeout. (See “Changing the Backlight Time
Length” on page 51 for details.)
To unlock the display screen:
1. Press to wake up the screen.
2. From the lock screen, flick .
To lock the display screen manually:
䊳 Press . (Once your backlight turns off, your
device locks.)
䡲 To wake up the screen, just press again.
Note: During a call, the screen will automatically turn off when
no operation is performed for about 15 seconds
(regardless of the screen timeout setting).
If you’ve locked your screen, you must draw an unlock
pattern or enter a PIN or password to unlock it. See
“Setting the Screen Lock” on page 59.
Battery and Charger
WARNING: Use only Sprint-approved or Kyocera-approved
Sprint-approved or Kyocera-approved batteries and
accessories can be found at Sprint Stores or through
Kyocera; or call 1-866-866-7509 to order. They are also
available at
Battery Capacity
Your device is equipped with two Lithium Ion (Li-Ion)
batteries. It allows you to recharge your battery before it
is fully drained.
When the battery level drops to 15%, a pop-up window
warns you that the battery is low. When the battery level
drops to 0%, the device shuts down.
batteries and chargers with your device. The
failure to use a Sprint-approved or Kyoceraapproved battery and charger may increase the
risk that your device will overheat, catch fire, or
explode, resulting in serious bodily injury, death,
or property damage.
www.sprint.com.
Note: Long backlight settings, searching for service, vibrate
mode, browser use, and other variables may reduce
the battery’s talk and standby times.
Tip: Watch your device’s battery level indicator and charge the
battery before it runs out of power.
Installing the Battery
䊳 See “Setting Up Your Device” on page 2.
Removing the Battery
1. Make sure the device is off so that you do not lose
any stored numbers or messages.
2. Firmly press your thumbs against the battery cover
and push upward to remove it.
3. Grasp the white pull-tab extending from the battery
pack and pull the battery out of its compartment.
WARNING: Do not handle a damaged or leaking Li-Ion
battery as you can be burned.
2A. Device Basics 13
Device Basics
Charging the Internal Battery
Keeping track of your battery’s charge is important. If
your battery level becomes too low, your device
automatically turns off, and you will lose any
information you were just working on.
Always use a Sprint-approved or Kyocera-approved
battery charger, desktop charger, travel charger, or
vehicle power adapter to charge your battery.
1. Plug the smaller end of the
micro-USB cable into the device’s
charger/accessory jack.
2. Plug the other end of the USB
cable into the wall/USB
charger, and then plug the
wall/USB charger into an electrical outlet.
䡲 A solid red indicator light means the battery is
charging.
䡲 A flashing red indicator light means the battery is low.
䡲 A solid green indicator light means the battery is
fully charged.
䡲 A flashing green indicator light means you have
new pending notifications.
WARNING: Do not remove the battery while it is charging.
14 2A. Device Basics
Always remove the charger from the electrical
outlet first before removing the micro-USB cable
from the device.
With the Sprint-approved Li-Ion battery, you can
recharge the battery before it becomes completely run
down. With the use of the included battery charger, you
can charge a spare battery without its having to be
inserted in the device. See “Using the External Battery
Charger” below.
Using the External Battery Charger
Your device comes with a spare battery and external
battery charger. You can use your device with one
battery while the other one charges, assuring you will
have access to your device where you need it and
when you need it.
To install a battery in the external charger:
1. Holding the charger with the printed logo right side
up, slide the cover to the right until it locks into
open position.
2. Insert the battery contacts end first, making sure
they align with the charger’s contact points.
3. Slide the cover to the left until you hear a click.
To charge the battery in the external charger:
Wall/USB charger
Charge lamp
(red)
Slide switch
DC IN 5V DC OUT 5V
Micro-USB jack
Charger
1. Slide the switch on the charger to the DC IN 5V
position.
2. Plug the smaller end of the micro-USB cable into
the micro-USB jack on the charger.
3. Plug the other end of the micro-USB cable into the
wall/USB charger, and then plug the wall/USB
charger into an electrical outlet.
䡲 The red lamp light is on while the battery is charging.
䡲 The red lamp light goes off when the battery is fully
charged.
Note: If the charge lamp starts flashing red, you may have a
high battery temperature, battery problem, wall/USB
charger problem, or battery charger problem.
To use the battery charger as an external battery:
1. Slide the switch on the charger to the DC OUT 5V
position. (The charge lamp turns green.)
Note: If the green charge lamp does not light up, the installed
battery is not sufficiently charged. Make sure your
battery is fully charged prior to use.
2. Plug the smaller end of the micro-USB cable into
the device’s charger/accessory jack and the other
end into the USB jack on the charger.
䡲 The green lamp on the charger remains on while
charging the battery. (The green lamp will not go off
until the external battery completely discharges.)
䡲 The LED indicator on the device will light red
while charging and it will change to green when
fully charged.
Charge lamp
(green)
Charger
Device
USB jack
DC IN 5V DC OUT 5V
Slide switch
LED indicator
Charger/
Accessory jack
2A. Device Basics 15
Device Basics
3.
When you have finished charging, slide the switch
on the charger to the
DC IN 5V position to conserve
energy.
Note: After use, make sure you slide the switch to the
DC IN 5V position to prevent battery drain.
It will take much longer to charge the device using the
battery charger than with the AC charger. If you need
the use of your device right away, replace the original
battery with a fully charged battery when your primary
battery becomes discharged.
Tip: You can also charge your battery by plugging the USB
cable into your computer. Simply plug the smaller end of
the micro-USB cable into the micro-USB jack on the
charger and plug the other end into a free USB port on
your desktop or laptop computer. Charging through USB
will take twice the time as the wall charger. Charging from
a computer will take about twice as long as the electrical
outlet.
Extending Your Battery Life
Active applications, backlight levels, Bluetooth, and
GPS use all contribute to draining your battery. The
following is a list of helpful tips that can help conserve
your battery’s charge:
16 2A. Device Basics
䢇 Reduce your backlight on time. See “Changing the
Backlight Time Length” on page 51.
䢇 Turn Bluetooth off when not in use. See “Turning
Bluetooth On and Off” on page 99.
䢇 Turn Wi-Fi off when not in use. See “Turning Wi-Fi On
and Off” on page 121.
䢇 Turn GPS off when not needed. Most applications
using this function will periodically query the GPS
satellites for your current location; each query drains
your battery. See “Location Settings” on page 53.
䢇 Do not wait until your battery is completely depleted
before charging your device. Repeated complete
discharging and recharging can reduce the storage
capacity of any battery over time.
䢇 Turn off Automatic application sync. See
“Synchronizing Accounts” on page 53.
䢇 Add a Power Control Widget to your Home screen to
deactivate features such as Wi-Fi, Bluetooth, GPS,
and synchronization and to reduce the screen’s
brightness setting.
䢇 Check running services and close any unnecessary
applications. See “To view and control currently
running services:” on page 62.
Opening and Closing the Device
Your device features dual touchscreens and allows you
to work on two displays at the same time. The lower
display is located beneath the upper display and is
accessed by sliding it open. With both screens open,
you can extend one application across two screens
(Tablet mode) or use them as separate displays in
Simul-Task or Optimized mode. See “Your Device’s
Screen Modes” on page 26 for details.
To open the device:
䊳 Using both hands, slowly slide the upper display in
the direction of the arrow until it locks in tilt position.
Note: When opening the device, make sure you are sliding in
the correct direction.
To make a flat display screen:
1. As you slide the device open, slide the upper
(right) display right until it lies flat.
2. Close the gap between the two displays by
pushing inward until you hear a click.
Device Basics
To close the device:
1. Grasp the right edge of the upper (right) display
and pull it slightly to the right to release the lock.
2. Slide the upper (right) display back to its original
position as shown in the second figure below.
2A. Device Basics 17
Navigating Through the Onscreen Menus
There are different ways to navigate around the
device’s Home screen, menus, and application screens
by using your finger. Here are some tips to move
around your device’s menus and screens:
Using the Touchscreen
Tap
Tap once with your finger to select or
launch a menu, option, or application.
A light tap works best.
Tap and Hold
To open the available options for an
item (for example, a link in a Web
page), simply tap and hold the item.
18 2A. Device Basics
Drag
Tap and hold your finger before you
start to move it. Do not release your
finger until you have reached the
target position.
Slide or Flick
To slide, quickly move your finger
vertically or horizontally across the
screen. To flick, move your finger in
lighter, quicker strokes than sliding.
This finger gesture is always used in a
vertical motion, such as when scrolling
through contacts or a message list.
Loading...
