Sper Scientific 840045 User Manual

EMF Meter

840045

Instruction Manual

SPER

SPER

SPERSPER
SCIENTIFIC

SCIENTIFIC

SCIENTIFICSCIENTIFIC

TABLE OF CONTENTS

Introduction ………………………………………..... 3

Application ……………………………………...…... 4

Features ……………………………………………. 4

Panel Description ………………………..…………. 5

Measurement Procedures …………….…...……… 5-7

Specifications ……………………..………………… 8

Battery Replacement ……….……………………… 9

Notes & Precautions …….…………………………. 9

THIS PAGE INTENTIONALLY LEFT BLANK.

Sper Scientific warrants this product against

defects in materials and workmanship for a period

of five (5) years from the date of purchase, and

agrees to repair or replace any defective unit
without charge. If your model has since been

discontinued, an equivalent Sper Scientific product

will be substituted if available. This warranty does

not cover probes, batteries, or damage resulting

from accident, misuse, or abuse of the product. In

order to obtain warranty service, simply ship the

unit postage prepaid to:

SPER SCIENTIFIC LTD.

7720 East Redfield, Suite 7

Scottsdale, AZ 85260

Email: [e-mail],

Phone: [phone]

Be sure to include your name, address, phone

number, and a detailed explanation of why you are

returning the item. Mail your warranty card within

10 days or register on line at:

www.sperscientific.com.

INTRODUCTION

Your new meter measures electromagnetic emissions from

power lines, computer monitors, television sets, video ma-

chinery and other electrical appliances. While the evidence

of the carcinogenic effect of such electromagnetic emis-

sions is still inconclusive, the USD EPA recommends

“prudent avoidance” of excessive exposure over long peri-

ods of time.

Revised: 10/31/2007

3

APPLICATION

BATTERY REPLACEMENT

This meter is designed to measure electromagnetic fields of
extremely low frequency (ELF) between 30 to 300Hz. It is
capable of measuring the electromagnetic field radiation
intensity that is produced by electric transmission equip­ment, power lines, microwave ovens, air conditioners, re­frigerators, computer monitors and video/audio devices to
name a few.

The magnetic field measurement unit is Tesla (T), Gauss
(G), milli-Gauss (mG) or micro-Tesla (µT).

FEATURES

• micro-Tesla and milli-Gauss Measurement unit display .

• Data hold and maximum hold function.

• Low battery indicator

1. Turn off the instrument.

2. Remove the battery cover.

3. Replace the battery.

4. Install the battery cover.

NOTES & PRECAUTIONS

• Never touch the meter to electrical cables or other dan-

gerous materials.

• To clean the EMF Meter use a soft dry cloth. Never use

a wet cloth, solvents or water, etc.

• Operation Altitude: Up to 2000M.

• Operating Environment: Indoor use. This instrument has

been designed for use in a pollution environment of
degree 2.

4

Caution: this symbol indicates that equip­ment and its accessories are subject to a
separate collection and correct disposal.

9

SPECIFICATIONS

PANEL DESCRIPTION

Display:

Range:

Resolution:

Frequency
response:

Sensor:

Accuracy:

Over load:

Sample rate:

Battery:

Battery life:

Operating
temperature &
humidity:

Storage
temperature &
humidity:

Weight:

Dimensions:

Accessories:

3.5 digits LCD, maximum reading
1999

200/2000 mG,20/200µT.

0.1/1 mG or 0.01/0.1 µT.

30Hz to 300Hz.

Single Axis

±(2.5% + 6 dgt) at 50Hz/60Hz.

LCD display “OL”.

2.5 times per second.

9V Battery

Approximate 100 hours.

5ºC to 40ºC, below 80% RH.

-10º C to 60ºC, below 70%. RH

170g.

130x56x38 mm.

User’s manual, 9V battery, Carrying
case

1. Sensor .

2. LCD

3. Power on/off.

4. Maximum hold button

5. Data hold button

6. mG unit select button

7. µT unit select button

8. Range select button

9. Battery compartment

MEASUREMENT PROCEDURES

1. Press to turn on the unit.

2. Select for mG or for µT.

3. Position the front (see Figure 1) of the meter to measure
the electromagnetic waves. Change the measurement
angle or position to obtain the highest reading value
(see Figure 2 through Figure 6).

4. Read the measured value. The display of “OL” indicates
an overload. Press to select a higher range and
repeat the measurement.

8

5

MEASUREMENT PROCEDURES

Note: Due to normal environmental magnetic fields,
the meter may display a reading below 0.5mG prior
to measuring. This is not a malfunction of the device.

5. To freeze the current reading displayed on the LCD,
press . Press again to resume active meas­urement.

6. To retain the maximum value, press and the read­ing value displayed on the LCD will continually update
the maximum value.

MEASUREMENT PROCEDURES

6

Figure 1 and 2 indicates the correct measurement direction
for electromagnetic waves.

Figure 3, 4, 5 and 6 indicates the incorrect measurement
direction for electromagnetic waves.
