I. Introduction:

This instrument is a digital thermometer for use with
any K-type and J-type thermocouple as temperature
sensor.
Temperature indication follows National Bureau of
Standards and IEC584 temperature/voltage table for
K-type and J-type thermocouples.

II. Specifications:

Numerical Display:

4 digital liquid crystal display

Measurement Range:

K-Type -200• ~ 1370•

J-Type

Resolution:

K-Type:

-328• ~ 2498•

-200• ~ 760•

-328• ~ 1400•

-200°C~ 800°C 0.1°C; 800°C ~1370°C 1°C

-328°F~ 1000°F 0.1°F; else 1°F

J-Type:

-200°C~ 600°C 0.1°C; 600°C ~760°C 1°C

-328°F~ 1000°F 0.1°F; else 1°F

Maximum Voltage at Thermocouple Input:

60V DC, or 24Vrms AC

Environmental:

ο

Operating Temperature and Humidity:

0°C ~50°C (32°F ~ 122°F) ; 0 ~ 80% RH

ο

Storage Temperature and Humidity:

-10°C to 60°C (14°F ~ 140°F); 0 ~ 80% RH

ο

Altitude up to 2000 meters.

2

Accuracy: at ( 23 ± 5°C )

Range Accuracy

K-Type -200°C ~ 1370°C ±(0.1% reading + 0.7°C)

J-Type -200°C ~ 760°C ±(0.1% reading + 0.7°C)

K-Type -328°F ~ 2498°F ±(0.1% reading + 1.4°F)

J-Type -328°F ~ 1400°F ±(0.1% reading + 1.4°F)

Temperature Coefficient:

For ambient temperatures from 0°C ~ 18°C and
28°C ~ 50°C, for each °C ambient below 18°C or
above 28°C add the following tolerance into the
accuracy spec.

0.01% of reading + 0.03°C
( 0.01% of reading + 0.06°F )

Note:

The basic accuracy Specification does not include the
error of the probe please refer to the probe accuracy
specification for additional details.

Sample Rate: 3.3 times per second
Dimension: 184×64×30mm
Weight: 210g Approx.
Accessory:

K Type Bead Probe, Battery, Carrying Case,
Instruction Menu.

Option:

Soft Ware Package(Program, RS
Cable), AC Adapter

Power requirement:

9 Volt Battery, NEDA 1604 or JIS 006P or IEC6F22

232

Connection

3

Battery Life:

Approx. 100hrs with alkaline battery

DC

AC Adapter: 9V

±15% 100mA

Plug Diameter: 3.5×1.35mm

III. Symbol Definition and Button
Location:

Main Display Timer Display

-

H : It indicates that the timer is expressing in hours

°C °F : Centigrade and Fahrenheit indication.

K J

HOLD

MAX : The Maximum value is now being displayed

: This indicates that the minus temperature is

sensed.

and minutes.

: Thermocouple Type Indication

: This indicates that the display data is being

hold.

MIN : The Minimum value is now being displayed

AVG : The Average value is now being displayed.

4

•REL : The reading is now under Relative Mode.

: The Battery is not sufficient for proper

operation.

1

K,J type temperature sensor connector

•

2

LCD display

•

3

ON/OFF button

•

4

HOLD button

•

5

Timer function control button

•

6

Relative readout button

•

7

MAX MIN Average control button

•

8

°C, °F control button

•

9

Digital output connector

•

10

AC power adapter connector

•

5

11

Tripod connector

•

12

Battery cabinet cover

•

IV. Operation Instructions:

4.1 Power-Up

I

Press the •

4.2 Connection the Thermocouples

For measurement, plug the thermocouple into the

key to turn the thermometer On or OFF

input connectors.

4.3 Selecting the Temperature Scale

When the meter was first power on, the default scale
setting is set at Celsius (°C) scale. The user may
change it to Fahrenheit (°F) by pressing “ °C/°F ”
button and vice versa to Celsius.

4.4 Selecting the Thermocouple Type

By default, when the meter is powered on, it is
K-Type, One may press and hold “°C/°F” button and
then power on the meter, then it will change to
J-Type.

4.5 Data-Hold Operation

The user may hold the present reading and keep it on
the display by pressing the “
hold data is no longer needed, one may release the
data-hold operation by pressing “
When the meter is under Data Hold operation, the

“•REL”, and “ °C/°F ” button are disabled.

HOLD

HOLD

” button. When the

” button again.

4.6 Timer Operation:

One may start the timer by press the “ TIMER
button. The counting can be stopped or continued by
pressing it again.

6

”

When the counting exceed 59min 59sec, the time
scale will be changed to hours and minutes and the

“ H ” symbol will appear on the display.

The counting can be reset by press and hold
“ TIMER

4.7 Relative Operation:

When one press the “•REL” button, the meter will
memorize the present reading and the difference
between the new reading and the memorized data

will be shown on the display. Press the “•REL” button

again to exit the Relative operation.

4.8 MAX/MIN/AVG Operation:

When one press the button the meter will

button for 2 sec.

”

enter
the MAX/MIN mode. Under this mode the maximum
value, minimum value and average value of latest 4
data is kept in the memory simultaneously and
updated with every new data.
When the MAX symbol is display, the Maximum is
shown on the display.
Press again, then the NIN symbol is on the
display and also the minimum reading.
Press again, the AVG symbol is on the display
and also the average reading.
Press again, MAX, MIN and AVG will blink
together. This means that all these data is updated int
the memory and the reading is the present
temperature.
One may press to circulate the display mode
among these options.
When the meter is under operation, “•REL”

7

and “ °C/°F ” are disabled.
To exit the MAX/MIN mode, one may press and hold
for two seconds.

4.9 Auto Power Off:

By default, when the meter is powered on, it is under
auto power off mode. The meter will power itself off
after30 minutes if no key operation and RS232
communication. Key combination at power on or
RS232 communication can disable auto power off.
One may press and hold “
power on the meter and there will be two successive
beeps to indicate that auto power off is disabled.

4.10 Low Battery Condition

When the battery voltage is under proper operation
requirement, the symbol will show on the LCD
and the battery need to be replaced with new one.

HOLD

” button and then

4.11 Digital output:

The Digital Output is a 9600bps N 81 serial interface.
The RX is a 5V normal high input port.
The TX is a 5V normal high output port.
The command of Digital Output is list below.

TX

RX

GND

8

RS232 command Function Remarks

K(ASC 4BH) Ask for model No. Send 4 bytes

Ask for main display

D(ASC 44H)

Range, Data, Unit

Send 22 bytes

Ask for secondary display

B(ASC 42H)

Range, Data, Unit

S(ASH 53H) Ask Status Send 13 bytes

H(ASC 48H) Hold button

T(ASC 54H) TIMER button

M(ASC 4DH) AVG/MAX/MIN button

N(ASC 4EH) Exit AVG/MAX/MIN mode
R(ASC 52H) REL button
C(ASC 43H)

A(ASC 41H) Inquire all encoded data

•/•

button

Send 22 bytes

Send encoded 8
byte

•

Command K:

Return 4 bytes. For example, when sends command
"K" to meter, it will return "3","0","2", ASCII(13) .

•

Command D:

Return data of main window.
Range:
Data:

•••••••

9999.9,-OL,OL ( 7bytes include polarity and

±

decimal point), Unit: C,F(5bytes)
When the meter receive the D command, it will send :

( unused )

Range•Data•Unit.
( where

represent space (ASC(20H) )

•

For example:
T1

••••••

-199.9

••C••••

9

(0x13) represent T1,- 199.9°C, The total byte number
should be 7+1+7+1+5+chr(13)=22Bytes

Command B:

Return the counting of timer.

•

Command S:

Return the operation mode HOLD•MAX•REL, if the

mode is not
left as space.

entered, the related characters will be

For example:
when the meter is under MAX display, the meter will
return:

•

Command T:

Equivalent to one pushing on the HOLD button.

•

Command M:

Equivalent to one pushing on the HOLD AVG/MAX/
MIN button and no message is returned.

•

Command R:

•••••

MAX

••••

Equivalent to one pushing on the REL button and no
message is returned.

•

Command C:

Equivalent to one pushing on the •/• button and no

message is returned.

• Command A:

nd

BYTE:

1

The first byte is the start byte , it value is 2.

nd

2

BYTE:

bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0

C/F Low Bat Hold REL K/J MAX/AVG/MIN

bit 2 bit 1 bit 0

0 0 0 •normal mode

10

0 0 1 •MAXIMUN mode

0 1 0 •MINIMUN mode

1 0 0 •AVG mode
1 1 1 •calculate MAX/MIN/AVG in back-

ground and lcd
"MAX""AVG""MIN"
will flash.

bit3: 1•0->K TYPE ,1•J TYPE(300 only has K type)
bit4: 1•REL

bit5: 1•HOLD, 0•not HOLD
bit6: 1•LOW BATTERY , 0•BATTERY NORMAL

bit7: 1•• 0••

3th BYTE:

bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0

no use no use no use Time

unit

no use X1_

X10

minus OL

bit0: 1•main window value is OL, 0•not OL

bit1: 1•main window value is minus, 0•main window

value is plus.

bit2: 1•4

and 5

th

byte and 5

th

byte represent ###.#

th

byte represent #### , 0•4

th

byte

bit4: 1•sub window value is MM:SS, 0•sub window

value is HH:MM

th

BYTE:

4

first two BCD code of main window value.

th

BYTE:

5

last two BCD code of main window value

11

6th BYTE:

first two BCD code of sub window value.

th

BYTE:

7

last two BCD code of sub window value.

12
