SR201 Instruction Manual
The Spektrum™SR201 2-channel DSM® Sport Surface receiver is compatible with all Spektrum surface transmitters and operates in DSM mode.
Specifications
Type: DSM Dimensions (LxWxH): 1.62 x 1.06 x .58 in (41 x 27 x 15mm)
Channels: 2 Weight: 0.36 oz (10 g)
Band: 2.4GHz Voltage Range: 3.5–9.6V
Antenna
LED
SR201
THR
STR
BIND
Receiver Connection and Installation
Install the Receiver in your vehicle using double-sided foam servo tape.
Foam servo tape will hold the receiver in place and help isolate it from
vibrations. Mount the antenna up and away from the vehicle in an antenna
tube. The higher up the antenna is, the better signal it will receive.
NOTICE: Do not cut the antenna.
Binding Receiver to Transmitter
In order to operate, the receiver must be bound to the transmitter. Binding
is the process of programming the receiver to recognize the GUID (Globally
Unique Identifier) code of a single specific transmitter. When areceiver is
bound to atransmitter/model memory, the receiver will only respond to
that specific transmitter/model memory.
Binding
1. With the receiver off, insert the bind plug into the BIND port in the
receiver.
2. Power the receiver through any port. If an ESC is being used, power
on the ESC with the ESC lead plugged in the throttle channel port. The
green LED will flash continuously, indicating that the receiver is in bind
mode.
Powering the receiver with a separate receiver pack
Receiver
2.4Ghz DSM
SR201
THR
SPORT SURFACE
RECEIVER
STR
BIND
Throttle Port
Steering Port
Bind/Battery Port
Bind Plug
Throttle Servo
Steering Servo
EN
Battery
EN
Powering the receiver with an ESC
Battery
Electronic
Receiver
2.4Ghz DSM
SR201
THR
SPORT SURFACE
RECEIVER
STR
BIND
3. With the steering wheel, and throttle trigger in the desired preset
failsafe positions (generally full brake and neutral steering), initiate the
Speed Control
Steering Servo
To Motor
bind process with your Spektrum transmitter. This stores the failsafe
positions. Continue to hold the failsafe positions until the binding
process is complete. Please see the next section for more information
about failsafe.
4. The LED on the receiver should now be solid, indicating asuccessful
bind has taken place.
5. Once the bind process is complete and before power is cycled on the
receiver, remove the bind plug and store it in aconvenient place. Failure to
remove the bind plug will result in the receiver going back into bind mode.
The only time it is necessary to do arebind is if different failsafe positions
are desired e.g., servo travel has been reversed after the initial bind, or if
the receiver is to be bound to adifferent model memory.
Failsafe
Failsafe positions are set during binding. In the unlikely event that the
radio link is lost during use, the receiver will drive the servos to their
preprogrammed failsafe positions (normally full brakes and straight
steering). If the receiver is turned on prior to turning on the transmitter, the
receiver will enter failsafe mode, driving the servos to their preset failsafe
positions. When the transmitter is turned on, normal control is resumed.
2.4GHz Troubleshooting Guide
Problem Possible Cause Solution
The system
will not
connect
Your transmitter and receiver are too close together
You are around metal
objects
The model selected is not
the model bound to
Move transmitter 8 to 12
feet from receiver
Move to an area with less
metal
Check model selected
and ensure you are bound
to that model
Your transmitter was
accidentally put into bind
Rebind your transmitter
and receiver
mode and is no longer
bound to your receiver
Problem Possible Cause Solution
The receiver
goes into
failsafe
mode a
short distance away
from the
transmitter
The receiver
quits responding
during
operation
Check the receiver antenna
to be sure it is not cut or
damaged
Inadequate battery voltage Charge batteries. Spe-
Loose or damaged wires
or connectors between
battery and receiver
Replace the receiver or
contact Horizon Product
Support
Make sure your receiver
antenna is in an antenna
tube and is above the
vehicle
ktrum receivers require
at least 3.5V to operate.
An inadequate power
supply can allow voltage
to momentarily drop
below 3.5V and cause the
receiver to brown out and
reconnect
Check the wires and
connection between the
battery and receiver.
Repair or replace wires
and/or connectors
