Spectra preciSion
®
EPOCH® 35 GNSS SYSTEM
USER GUIDE
EPOCH® 35 GNSS System
Version 1.00
Revision A
December 2008
Contact details
Declaration of Conformity
We, Spectra Precision Navigation Limited,
10355 Westmoor Drive
Suite #100
Westminster, CO 80021
United States of America
+1-303-323-4100
declare under sole responsibility that the products:
EPOCH 35 GNSS receiver
comply with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Spectra Precision
10355 Westmoor Drive
Suite #100
Westminster, CO 80021
+1-720-587-4700
888-477-7516 (Toll free in USA)
www.spectraprecision.com
Legal notices
© 2008, Spectra Precision. All rights reserved.
Recon and Nomad are either registered trademarks or trademarks
of Tripod Data Systems Inc.
The Bluetooth word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks is under license.
Microsoft, ActiveSync, Windows, and Windows NT are either
registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries. All other trademarks are
the property of their respective owners.
Release notice
This is the December 2008 release (Revision A) of the EPOCH 35
GNSS System User Guide. It applies to version 1.00 of the EPOCH 35
GNSS receiver.
Product Limited Warranty Information
For applicable product Limited Warranty information, please refer to the
Limited Warranty Card included with this Spectra Precision product, or
consult your local Spectra Precision authorized dealer.
Product Extended Limited Warranty Information
For applicable product Extended Limited Warranty information, please
refer to the Limited Warranty Card included with this Spectra Precision
product, or consult your Spectra Precision dealer.
Notices
Class B Statement – Notice to Users. This equipment has been tested
and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communication.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and the receiver.
– Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Changes and modifications not expressly approved by the manufacturer
or registrant of this equipment can void your authority to operate this
equipment under Federal Communications Commission rules.
Canada
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the radio interference
regulations of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de Classe B
prescrites dans le règlement sur le brouillage radioélectrique édicté par
le Ministère des Communications du Canada.
Europe
This product has been tested and found to comply with the
requirements for a Class B device pursuant to European
Council Directive 89/336/EEC on EMC, thereby satisfying the
requirements for CE Marking and sale within the European Economic
Area (EEA). These requirements are designed to provide reasonable
protection against harmful interference when the equipment is operated
in a residential or commercial environment.
Australia and New Zealand
This product conforms with the regulatory requirements of the
Australian Communications Authority (ACA) EMC framework,
thus satisfying the requirements for C-Tick Marking and sale
within Australia and New Zealand.
Taiwan – Battery Recycling Requirements
The product contains a removable Lithium-ion battery.
Taiwanese regulations require that waste batteries are recycled.
廢電池請回收
Notice to Our European Union Customers
For product recycling instructions and more information, please go to
www.Spectra Precision.com/ev.shtml.
Recycling in Europe: To recycle Spectra Precision WEEE (Waste
Electrical and Electronic Equipment, products that run on
electrical power.), Call +31 497 53 24 30, and ask for the "WEEE
Associate". Or, mail a request for recycling instructions to:
Spectra Precision Europe BV
c/o Menlo Worldwide Logistics
Meerheide 45
5521 DZ Eersel, NL
Safety Information
Before you use a Spectra Precision® EPOCH® 35 GNSS system, make sure that you
have read and understood this guide, as well as the safety requirements listed in this
chapter.
2.1 Warnings and Cautions
An absence of specific alerts does not mean that there are no safety risks involved.
Always follow the instructions that accompany a Warning or Caution. The information
they provide is intended to minimize the risk of personal injury and/or damage to the
equipment. In particular, observe safety instructions that are presented in the
following formats:
C
C
2.2 Regulations and safety
WARNING – A Warning alerts you to a likely risk of serious injury to your person and/or
damage to the equipment. A warning identifies the nature of the risk and the extent of
possible injury and/or damage. It also describes how to protect yourself and/or the
equipment from this risk. Warnings that appear in the text are repeated at the front of
the manual.
CAUTION – A Caution alerts you to a possible risk of damage to the equipment and/or
loss of data. A Caution describes how to protect the equipment and/or data from this risk.
The receivers contain an internal radio-modem and can send signals through
®
Bluetooth
Regulations regarding the use of the Ultra High Frequency (UHF) radio-modems vary
greatly from country to country. In some countries, the unit can be used without
obtaining an end-user license. Other countries require end-user licensing. For licensing
information, consult your local Spectra Precision dealer. Bluetooth operates in licensefree bands.
Before operating this receiver, determine if authorization or a license to operate the
receiver is required in your country. It is the responsibility of the end user to obtain an
operator’s permit or license for the receiver for the location or country of use. For FCC
regulations, see Notices, page -2.
wireless technology or through an external data communications radio.
2.3 Type approval
Type approval, or acceptance, covers technical parameters of the equipment related to
emissions that can cause interference. Type approval is granted to the manufacturer of
the transmission equipment, independent from the operation or licensing of the units.
Some countries have unique technical requirements for operation in particular
EPOCH 35 GNSS System User Guide 3
Safety Information
radio-modem frequency bands. To comply with those requirements, Spectra Precision
may have modified your equipment to be granted Type approval. Unauthorized
modification of the units voids the Type approval, the warranty, and the operational
license of the equipment.
2.4 Exposure to radio frequency radiation
24.1 For UHF radio
For example, a 450 MHz radio.
Safety. Exposure to RF energy is an important safety consideration. The FCC has
adopted a safety standard for human exposure to radio frequency electromagnetic
energy.
Proper use of this radio modem results in exposure below government limits. The
following precautions are recommended:
• DO NOT operate the transmitter when someone is 20 cm (7.8 inches) of the
antenna.
• DO NOT collocate (place within 20 cm) the radio antenna with any other
transmitting device.
• DO NOT operate the transmitter unless all RF connectors are secure and any
open connectors are properly terminated.
• DO NOT operate the equipment near electrical blasting caps or in an explosive
atmosphere.
• All equipment must be properly grounded according to Spectra Precision
installation instructions for safe operation.
• All equipment should be serviced only by a qualified technician.
24.2 For Bluetooth radio
The radiated output power of the internal Bluetooth wireless radio is far below the
FCC radio frequency exposure limits. Nevertheless, the wireless radio shall be used in
such a manner that the Spectra Precision receiver is 20 cm or further from the human
body. The internal wireless radio operates within guidelines found in radio frequency
safety standards and recommendations, which reflect the consensus of the scientific
community. Spectra Precision therefore believes the internal wireless radio is safe for
use by consumers. The level of energy emitted is far less than the electromagnetic
energy emitted by wireless devices such as mobile phones. However, the use of wireless
radios may be restricted in some situations or environments, such as on aircraft. If you
are unsure of restrictions, you are encouraged to ask for authorization before turning
on the wireless radio.
4 EPOCH 35 GNSS System User Guide
2.5 Installing antennas
Safety Information
C
CAUTION – For your own safety, and in terms of the RF Exposure requirements of the FCC,
always observe these precautions:
– Always maintain a minimum separation distance of 20 cm (7.8 inches) between yourself
and the radiating antenna.
– Do not collocate (place within 20cm) the radio antenna with any other transmitting
device.
This device has been designed to operate with the antennas listed below.
UHF Antennas not included in this list, or having a gain greater than 5 dBi, are strictly
prohibited for use with this device. The required antenna impedance is 50 ohms.
The antennas that can be used (country dependent) with the UHF radio are 0 dBi and
5 dBi whip antennas.
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that permitted for successful communication.
2.6 Rechargeable Lithium-ion batteries
These receivers use a rechargeable Lithium-ion battery.
C
WARNING – Do not damage the rechargeable Lithium-ion battery. A damaged battery
can cause an explosion or fire, and can result in personal injury and/or property damage.
To prevent injury or damage:
– Do not use or charge the battery if it appears to be damaged. Signs of damage include,
but are not limited to, discoloration, warping, and leaking battery fluid.
– Do not expose the battery to fire, high temperature, or direct sunlight.
– Do not immerse the battery in water.
– Do not use or store the battery inside a vehicle during hot weather.
– Do not drop or puncture the battery.
– Do not open the battery or short-circuit its contacts.
C
C
WARNING – Avoid contact with the rechargeable Lithium-ion battery if it appears to be
leaking. Battery fluid is corrosive, and contact with it can result in personal injury and/or
property damage.
To prevent injury or damage:
– If the battery leaks, avoid contact with the battery fluid.
– If battery fluid gets into your eyes, immediately rinse your eyes with clean water and
seek medical attention. Do not rub your eyes!
– If battery fluid gets onto your skin or clothing, immediately use clean water to wash off
the battery fluid.
WARNING – Charge and use the rechargeable Lithium-ion battery only in strict
accordance with the instructions. Charging or using the battery in unauthorized
equipment can cause an explosion or fire, and can result in personal injury and/or
equipment damage.
EPOCH 35 GNSS System User Guide 5
Safety Information
2.7 Cautions
To prevent injury or damage:
– Do not charge or use the battery if it appears to be damaged or leaking.
– Charge the Lithium-ion battery only in a Spectra Precision product that is specified to
charge it. Be sure to follow all instructions that are provided with the battery charger.
– Discontinue charging a battery that gives off extreme heat or a burning odor.
– Use the battery only in Spectra Precision equipment that is specified to use it.
– Use the battery only for its intended use and according to the instructions in the product
documentation.
C
C
CAUTION – Operating or storing the receiver outside the specified temperature range can
damage it. For more information, see Physical specifications, page 32.
CAUTION – Data are written to the SD card only with logging settings configured
manually through the receiver key panel. GNSS data files are named in chronological
order only.
6 EPOCH 35 GNSS System User Guide
Contents
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Regulations and safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Type approval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Exposure to radio frequency radiation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
For UHF radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
For Bluetooth radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rechargeable Lithium-ion batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
About the EPOCH 35 L1/L2 GNSS system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Use and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
COCOM limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Related information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Your comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 Setup, Connection, and Cabling . . . . . . . . . . . . . . . . . . . . . . . . 13
Parts of the base receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Ports and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Parts of the rover receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Ports and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setup guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Environmental conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sources of electrical interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
General guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Base setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Other system components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Rover setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Configuring the internal rover radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3 General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Batteries and power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Rover receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Base receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Charging and storing batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Charging the Lithium-ion battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Disposing of the rechargeable Lithium-ion battery. . . . . . . . . . . . . . . . . . . . . . . . 24
General operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Power button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
EPOCH 35 GNSS System User Guide 7
Scroll buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Enter (Select) button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
LED display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Selecting the radio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Setting the radio channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Post-processing routine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Resetting to defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Positioning specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5 Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Default behavior. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6 Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Port 1 and 2 connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
A RTCM Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Generated messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Message scheduling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
B Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Receiver issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8 EPOCH 35 GNSS System User Guide
CHAPTER
1
Introduction 1
In this chapter:
About the EPOCH 35 L1/L2 GNSS
system
Features
Use and care
COCOM limits
Related information
Technical assistance
Your comments
Welcome to the EPOCH 35 GNSS System User
Guide. This manual describes how to install, set
up, and use a Spectra Precision
GNSS receiver.
Even if you have used other Global Navigation
Satellite System (GNSS) products before, Spectra
Precision recommends that you spend some
time reading this manual to learn about the
special features of your receiver.
This guide assumes that you are familiar with a
Microsoft
you know how to use a mouse, select options
from menus and dialogs, make selections from
lists, and refer to online help.
®
Windows® operating system and that
®
EPOCH® 35
EPOCH 35 GNSS System User Guide 9
1 Introduction
1.1 About the EPOCH 35 L1/L2 GNSS system
The EPOCH 35 GNSS receiver uses an internal GNSS antenna and is designed for
GNSS surveying applications.
The base consists of a receiver, designed to operate with an external PacificCrest PDL
radio (“PacCrest”), and an external battery. For information on the PacCrest radio and
the external battery please refer to the documentation included with the radio kit.
The rover consists of a receiver, internal radio with receive option, and a removable
battery in a rugged lightweight unit.
1.2 Features
An LED screen on the receiver allow you to monitor the satellite tracking, radio
reception, file status, and power. Bluetooth
®
technology inside the receiver provides
cable-free communications between receiver and controller.
The receiver provides 54 channels (14 L1,14 L2 GPS, 12 L1, 12 L2 GLONASS, 2 SBAS)
full-cycle carrier satellite tracking and supports logging of raw GNSS observables to the
SD memory card.
The receiver provides the following features:
• Centimeter-accuracy, real-time positioning with RTK
• 54 channels L1 C/A code, L1/L2 full-cycle carrier
• WAAS/EGNOS capability (Wide Area Augmentation System/European
Geo-Stationary Navigation System)
• Highly accurate GNSS L1/L2 technology
• RTCM SC-104 input and output
• CMR+
• User removable SD memory for data storage
™
input
• Radio antenna connector
• Internal rover radio with a receive option
• Removable and rechargeable Lithium-ion battery
• Cable-free Bluetooth communications
10 EPOCH 35 GNSS System User Guide
1.3 Use and care
The receiver can withstand the rough treatment that typically occurs in the field.
However, the receiver is a high-precision electronic instrument and should be treated
with reasonable care.
Introduction 1
C
CAUTION – Operating or storing the receiver outside the specified temperature range can
damage it. For more information, see Chapter 4, Specifications.
High-power signals from a nearby radio or radar transmitter can overwhelm the
receiver circuits. This does not harm the instrument, but it can prevent the receiver
from functioning correctly. Do not use the receiver within 400 meters (1312 feet) of
powerful radar, television, or other transmitters. Low-power transmitters such as those
used in cell phones and two-way radios do not normally interfere with receiver
operations.
For more information, contact your Spectra Precision distributor.
1.4 COCOM limits
The U.S. Department of Commerce requires that all exportable GNSS products contain
performance limitations so that they cannot be used in a manner that could threaten
the security of the United States.
The following limitation is implemented on the receiver: Immediate access to satellite
measurements and navigation results is disabled when the receiver’s velocity is
computed to be greater than 1000 knots, or its altitude is computed to be above
18,000 meters (59,055 feet). The receiver continuously resets until the COCOM
situation is cleared.
1.5 Related information
An electronic copy of this manual is available in portable document format (PDF) on
the receiver CD. Use Adobe Reader to view the file.
Other sources of related information are:
• Registration – register your receiver to automatically receive e-mail notifications
of receiver firmware upgrades and new functionality. Register electronically at
www.spectraprecision.com/register/register.shtml.
• Contact your local Spectra Precision distributor for more information about the
support agreement contracts for software and firmware, and an extended
warranty program for hardware.
EPOCH 35 GNSS System User Guide 11
1 Introduction
1.6 Technical assistance
If you have a problem and cannot find the information you need in the product
documentation, contact your local distributor. Alternatively, request technical support
using the Spectra Precision website at www.spectraprecision.com.
1.7 Your comments
Your feedback about the supporting documentation helps us to improve it with each
revision. Email your comments to sales@spectrapecision.com.
12 EPOCH 35 GNSS System User Guide
CHAPTER
2
Setup, Connection, and Cabling 2
In this chapter:
Parts of the base receiver
Parts of the rover receiver
Setup guidelines
Base setup
Rover setup
This chapter provides general information on
setup, connection, and cabling for the most
common uses of the receiver.
EPOCH 35 GNSS System User Guide 13
2 Setup, Connection, and Cabling
inf
ormation.
N324
For home
and office use.
[
[
FCC ID: QOQ-WT12
IC: 5123A-BGTWT12A
Bluetooth B03005
M
ade in S
PAIN
CONTAINS:
10
Spec tra Preci sion
®
Serial ports
5
/8-11 threaded
insert
2.1 Parts of the base receiver
All operating controls on the receiver are located on the front panel. Serial ports and
connectors are located on the bottom of the unit.
• The power button controls the receiver’s power on or off functions.
• LEDs show the status of power, satellite tracking, and radio reception. See also
LED display, page 25.
21.1 Ports and connectors
Figure 2.1 shows the two serial ports and the 5/8-11 threaded insert.
Figure 2.1 Ports and connectors on the base receiver
COM 1 is a 7-pin 0-shell LEMO connectors that supports RS-232 communications and
external power input of 8–15 V. Port 1 has no power outputs.
COM 2 is a 7-pin 0-shell LEMO connector that supports RS-232 and external power
input of 8–15 V. Port 2 has no power outputs.
For more information, see Chapter 5, Default Settings and Chapter 6, Cables and
14 EPOCH 35 GNSS System User Guide
Connectors.
2.2 Parts of the rover receiver
inf
ormation.
N324
For home
and office use.
[
[
FCC ID: QOQ-WT12
IC: 5123A-BGTWT12A
Bluetooth B03005
M
ade in S
PAIN
CONTAINS:
10
Spec tra Preci sion
®
Serial ports
5
/8-11 threaded
insert
All operating controls on the receiver are located on the front panel. Serial ports and
connectors are located on the bottom of the unit.
• The power button controls the receiver’s power on or off functions.
• LEDs show the status of power, satellite tracking, and radio reception. See also
LED display, page 25.
22.1 Ports and connectors
Figure 2.2 shows the two serial ports and the 5/8-11 threaded insert.
Setup, Connection, and Cabling 2
Figure 2.2 Ports and connectors on the rover
• COM 1 is a 7-pin 0-shell LEMO connector that supports RS-232
communications and external power input. Port 1 has no power outputs and
external power input of 8–15 V.
• COM 2 is a 7-pin 0-shell LEMO connector that supports RS-232 . Port 2 has no
power outputs and external power input of 8–15 V.
For more information, see Chapter 5, Default Settings and Chapter 6, Cables and
Connectors.
• Use the TNC connector (not shown) to connect the radio antenna.
EPOCH 35 GNSS System User Guide 15
2 Setup, Connection, and Cabling
2.3 Setup guidelines
23.1 Environmental conditions
Although the receiver has a dust and moisture sealed housing, you must take
reasonable care to protect the unit from extreme environmental conditions. Do not:
• use or store the unit where temperatures are likely to rise above 65 °C (149 °F) or
fall below –20°C (–4°F).
• immerse the unit in water
• expose the unit to corrosive fluids and gases
23.2 Sources of electrical interference
Avoid the following sources of electrical and magnetic noise:
• Gasoline engines (spark plugs)
• Televisions and PC monitors
• Alternators and generators
• Electric motors
• Equipment with DC-to-AC converters
• Fluorescent lights
• Switching power supplies
23.3 General guidelines
C
WARNING – These receivers use a rechargeable Lithium-ion battery. To avoid personal
injury or equipment damage, make sure that you read and understand the Safety
Information at the front of the manual.
The following guidelines apply whenever you set up the receiver for operation:
• When disconnecting a LEMO cable, grasp the cable by the sliding collar or
lanyard and then pull the cable connector straight out of the port. Do not twist
the connector or pull on the cable itself.
• To securely connect a TNC cable or antenna, align the cable connector with the
receiver receptacle and then thread the cable connector clockwise onto the
receptacle until it is snug.
• To insert the internal battery, place the battery in the battery compartment,
ensuring that the contact points are in the correct position to align with the
contacts in the receiver. Slide the battery and compartment as a unit upward
into the receiver until the battery compartment latches are locked into position.
16 EPOCH 35 GNSS System User Guide
2.4 Base setup
EPOCH 35 GNSS receiver
External radio
Tribra ch
Extension pole
External battery
Radio cable
and antenna
To set up a base receiver, you must:
1. Connect the radio cable securely to the GNSS receiver.
2. Set up the receiver on a tripod:
Setup, Connection, and Cabling 2
a. Place the receiver on the tripod.
b. Attach the external radio to the tripod.
c. Connect the antenna to the external radio.
d. Connect the radio cable between the radio and the receiver.
e. Connect the radio and the receiver to the external battery.
Figure 2.3 EPOCH 35 GNSS receiver, base setup
20.1 Other system components
The base receiver requires the PacificCrest PDL HPB external radio.
EPOCH 35 GNSS System User Guide 17
2 Setup, Connection, and Cabling
EPOCH 35 GNSS receiver and antenna
Spectra Precision controller
2.1 Rover setup
C
WARNING – The rover uses a rechargeable Lithium-ion battery. To avoid personal injury
or equipment damage, make sure that you read and understand the Safety Information
on page 5 at the front of this manual.
When you set up the rover receiver, securely connect a TNC cable by aligning the cable
connector with the receiver receptacle and then threading the cable connector onto
the receptacle until the cable fits snugly.
Figure 2.4 on page 18 shows the pole-mounted setup for the receiver. To mount the
receiver on a range pole:
1. Thread the receiver onto the range pole.
2. Attach the controller bracket to the pole.
3. Insert the controller into the bracket.
Figure 2.4 EPOCH 35 GNSS receiver set up as a rover receiver
18 EPOCH 35 GNSS System User Guide
20.1 Configuring the internal rover radio
To configure the internal radio in the EPOCH 35 GNSS receiver, use the receiver
control panel.
By default, the internal radio has only a few “test” frequencies installed at the factory.
To configure the frequencies of the base or rover, contact your Spectra Precision
distributor. For more information, see the documentation supplied with your base
radio.
Setup, Connection, and Cabling 2
EPOCH 35 GNSS System User Guide 19
2 Setup, Connection, and Cabling
20 EPOCH 35 GNSS System User Guide
CHAPTER
3
General Operation 3
In this chapter:
Batteries and power
General operation
Selecting the radio mode
Setting the radio channel
Post-processing routine
Resetting to defaults
This section describes how to use the EPOCH 35
GNSS receiver as well as the controls on the front
panel that you need for general operation.
For information about other receiver panels, see
Parts of the base receiver, page 14 and Parts of the
rover receiver, page 15.
EPOCH 35 GNSS System User Guide 21
3 General Operation
3.1 Batteries and power
C
31.1 Rover receiver
WARNING – Do not damage the rechargeable Lithium-ion battery. A damaged battery
can cause an explosion or fire, and can result in personal injury and/or property damage.
To prevent injury or damage:
– Do not use or charge the battery if it appears to be damaged. Signs of damage include,
but are not limited to, discoloration, warping, and leaking battery fluid.
– Do not expose the battery to fire, high temperature, or direct sunlight.
– Do not immerse the battery in water.
– Do not use or store the battery inside a vehicle during hot weather.
– Do not drop or puncture the battery.
– Do not open the battery or short-circuit its contacts.
The rover receiver can be powered by its internal, removable battery or by an external
power source connected to Port 1 or Port 2. Typically, one internal 2.4 Ah battery
provides approximately 5.5 hours of operation during an RTK survey when the internal
radio is used in Rover mode. The basic kit contains two batteries for up to 11 hours of
total operation. The base receiver can also run on an internal 2.4 Ah battery as a
network RTK rover.
If an external power source is connected to Port 1 or Port 2, it is used in preference to
the internal battery. When there is no external power source connected, or if the
external power supply fails, the internal battery is used.
31.2 Base receiver
The base receiver is powered by an external 12 V battery, which lasts 12 hours in
continuous use.
22 EPOCH 35 GNSS System User Guide
31.3 Charging and storing batteries
All battery types discharge over time when they are not being used. Batteries also
discharge faster in colder temperatures. If a Lithium-ion battery is to be stored for long
periods of time, make sure it is fully charged before storing and re-charged at least once
every three months.
General Operation 3
C
C
WARNING – Charge and use the rechargeable Lithium-ion battery only in strict
accordance with the instructions. Charging or using the battery in unauthorized
equipment can cause an explosion or fire, and can result in personal injury and/or
equipment damage.
To prevent injury or damage:
– Do not charge or use the battery if it appears to be damaged or leaking.
– Charge the Lithium-ion battery only with a product that is specified to charge it. Be sure
to follow all instructions that are provided with the battery charger.
– Discontinue charging a battery that gives off extreme heat or a burning odor.
– Use the battery only in equipment that is specified to use it.
– Use the battery only for its intended use and according to the instructions in the product
documentation.
The receiver can be powered by its internal battery or by an external power source. If
an external power source is connected, it is used in preference to the internal battery.
When there is no external power source connected, or if the external power supply
fails, the internal battery is used.
The receiver is supplied with two rechargeable Lithium-ion batteries, and a dual
battery charger. The two batteries charge sequentially and take approximately four
hours each to fully charge.
WARNING – Avoid contact with the rechargeable Lithium-ion battery if it appears to be
leaking. Battery fluid is corrosive, and contact with it can result in personal injury and/or
property damage.
To prevent injury or damage:
– If the battery leaks, avoid contact with the battery fluid.
– If battery fluid gets into your eyes, immediately rinse your eyes with clean water and
seek medical attention. Do not rub your eyes!
– If battery fluid gets onto your skin or clothing, immediately use clean water to wash off
the battery fluid.
EPOCH 35 GNSS System User Guide 23
3 General Operation
Power button
Scroll buttons
Enter button
LED display
31.4 Charging the Lithium-ion battery
The rechargeable Lithium-ion battery is supplied partially charged. Charge the battery
completely before using it for the first time. If the battery has been stored for longer
than six months, charge it before use.
• Fully charge all new batteries prior to use.
• Do not allow the batteries to discharge below 5 V.
• Keep all batteries on continuous charge when not in use. Batteries may be kept
on charge indefinitely without damage to the receiver or batteries.
• Do not store batteries in the receiver or external charger unless power is applied.
• If you must store the batteries, fully charge them before storing and then
recharge them at least every three months.
31.5 Disposing of the rechargeable Lithium-ion battery
Discharge the Lithium-ion battery before disposing of it. When disposing of the
battery, be sure to do so in an environmentally sensitive manner. Adhere to any local
and national regulations concerning battery disposal or recycling.
3.2 General operation
The following figure shows the control panel of the receiver. The LED display provides
power, radio, post-processing controls, and SV status information.
24 EPOCH 35 GNSS System User Guide
32.1 Power button
Press the Power button to turn on or turn off the receiver:
To … Do this...
Turn on the receiver Press and then release
Turn off the receiver Press and then hold
32.2 Scroll buttons
Use the scroll buttons ! or @ to scroll through the various menu items or options.
32.3 Enter (Select) button
Use the enter button # to access choices for the current menu item, or return to the
main menu.
General Operation 3
$.
The receiver beeps, followed by a self-test. See page 26. When
the test is complete, the GPS status appears.
$ for at least 5 seconds. GPS OFF appears
and the receiver beeps three times.
Release
Note – You cannot turn the power off during the self-test.
$ when the display turns off.
32.4 LED display
The LED display uses text and symbols to provide information and guide you through
various tasks. The symbols include the following:
This symbol ... Indicates that ...
. (in first position) Bluetooth technology is used for communicating with the
: (in first position) A serial cable on COM 1 is used for communicating with the
(in last position) Additional information or choices can be accessed if you press #.
(in first position) You are in a sub-menu. Press # to return to the main menu.
or(in last position) Additional items or options are available. Use the ! or @
controller.
controller.
buttons to access them.
EPOCH 35 GNSS System User Guide 25
3 General Operation
Self-test procedure
Note – You cannot turn the power off during the self-test.
The following messages are displayed during the self-test procedure that occurs each
time the receiver is turned on:
Message Description
EPOCH Welcome message
Checking Self-test procedure starts
V#.# Firmware version
Radio Testing internal radio. The test results can include one or more of the
following messages:
• Fail PDL: No internal radio detected or external base radio is not
connected.
• CH: #: Current radio channel number.
• T_Talk: Radio protocol set to TRIMTALK mode.
• Trans p: Radio protocol set to transparent mode.
BLUE/CABLE • If no cable is connected between COM1 and a controller,
Bluetooth is enabled and BLUE is displayed.
• When a serial cable is connected, Bluetooth is turned off and
CABLE is displayed.
BR:57600 The baud rate for COM1.
SD ON
SD OFF
Test Ok Self-test passed
SD card inserted.
No SD card inserted
The GPS status is displayed when the self-test is finished. Initially the display shows
0/00 while the receiver is acquiring satellites. It can take several minutes to update,
especially if the receiver has been turned off for a long time. Once the GPS status is
updated, the first character indicates the quality of position as described below,
followed by the number of satellites being tracked:
• A Autonomous
• B Base mode
• D Float solution
• F Fix solution
26 EPOCH 35 GNSS System User Guide
General Operation 3
Main menu
Once the self-test procedure is complete, the main menu appears. Use the scroll
buttons to access the following items in the main menu:
Select this item ... To ...
R_Mode:
CH: #
Signal
Postp
B:57600 Display the baud rate for COM 1.
Blue/Cable Show how the controller is connected to the controller.
s:##q:A Show the number of satellites being tracked and the quality of the
SD OFF / SD ON Indicate if an SD card is inserted.
B2 ##% Show the internal battery charge level.
B1 ##% Show the external battery charge level.
Set the internal radio mode. See Selecting the radio mode,
page 28.
Display the current channel number. See Setting the radio channel,
page 28.
Show the type of radio plugged into COM 2, press #.
Note – PDLRX0 is displayed when using the internal Pac Crest
radio.
Start a post-processing session. See Post-processing routine,
page 28.
Note – You cannot change the baud rate.
• When a serial cable is connected between COM1 and a
controller, Bluetooth is turned off and Cable is displayed.
• If no cable is connected, Bluetooth is enabled and Blue is
displayed.
position (ABDF).
• No SD card inserted (OFF)
• SD card inserted (
ON)
The following messages may also appear:
If this message
appears ...
Low Bat! the battery has dropped to an unusable level and power will shut
Wait the receiver is detecting a device plugged into a COM port.
Then ...
off automatically.
EPOCH 35 GNSS System User Guide 27
3 General Operation
3.3 Selecting the radio mode
You can toggle the internal radio protocol between T_Talk (TRIMTALK) and Transp.
(Transparent) mode. For successful communication, make sure that the radio modes
match in each radio.
1. Press ! or @ to scroll up or down in the main menu until
the LED display.
Note – If the LED display shows a symbol in the first position, you are in a sub-menu.
Press # to return to the main menu.
2. Press # to access the radio mode options.
3. Press ! or @ to select the required mode and then press # to return to the main
menu.
3.1 Setting the radio channel
You can set the radio channel to any channel between 0 and 15. For successful
communication, make sure that the channel set in each radio matches.
1. Press ! or @ to scroll up or down in the main menu until
LED display.
Note – If the LED display shows a symbol in the first position, you are in a sub-menu.
Press # to return to the main menu.
2. Press #.
CH: # appears.
3. Press ! or @ to select the required channel between 0 and 15 and then press #
to return to the main menu.
R_Mode: appears in
CH: #appears in the
3.1 Post-processing routine
The post-processing routine consists of four different menu items that walk you
through the process of starting and stopping a post processing session. Use the scroll
buttons to make selections for each menu item and the # button to continue with the
next menu item
1. Press ! or @ to scroll up or down in the main menu until
the LED display.
Note – If the LED display shows a symbol in the first position, you are in a sub-menu.
Press # to return to the main menu.
2. Press #.
Time # appears.
# specifies how often an epoch record is written to the post-processing file.
3. If
NO SD appears, insert an SD card to store the post processing files.
Note – You must insert the SD card before the receiver is powered up to be initialized for
data storage.
28 EPOCH 35 GNSS System User Guide
Postp appears in
General Operation 3
4. Press ! or @ to select a number of seconds between 1 to 19 and then press # to
advance to the next menu item,
Mask should appear.
You must now set the minimum angle above the horizon where satellites must
be located (at or above) before they are used.
Note – Satellites located between the horizon and the specified angle above the horizon
will be ignored.
5. Press ! or @ to select any angle between 0-19 degrees and then press # to
advance to the next menu item.
SD should appear.
Within a few seconds the display will show an animated
indicates that recording has started. At this point you should leave the receiver
alone for the duration of the post-processing session.
6. When you have finished recording post-processing data, press #.
briefly—this indicates that the current session has ended and that the post
processing file on the SD card is closed. You are automatically returned to the
main menu.
To record additional post-processing sessions, repeat the above steps. For each post
processing session, a new sequentially-numbered file (
SD card.
3.1 Resetting to defaults
To reset the receiver to its default settings, turn the device on and off.
Cycling power to reset the receiver will not change the data logging settings—the most
recent changes that were made are preserved.
See also Default settings, page 36.
[SD]* ← ← ←, which
close appears
FILE####.TXT) is written to the
EPOCH 35 GNSS System User Guide 29
3 General Operation
30 EPOCH 35 GNSS System User Guide
CHAPTER
4
Specifications 4
In this chapter:
Physical specifications
Positioning specifications
Technical specifications
This chapter lists the receiver specifications.
EPOCH 35 GNSS System User Guide 31
4 Specifications
4.1 Physical specifications
Feature Specification
Size (W x H x D) 19.0 cm x 7.0 cm x 20.0 cm (7.48 inch x 2.76 inch x 7.87 inch),
Weight
Base 1.0 kg (2.2 lb)
Rover 1.1 kg (2.2 lb), including internal battery and UHF antenna
Average operating times
on internal battery
External power input 10 V DC to 15 V DC power with over-voltage protection on
Operating temperature –20 °C through +65 °C (–4 °F to +149 °F)
Storage temperature –40 °C through +75 °C (–40 °F to +167 °F)
Humidity 95% condensing
Water/Dust IP64
Shock and vibration Tested and meets the following environmental standards:
Shock UNE EN 60068-2-27:1993
Vibration MIL-STD-810F Fig 514.5C-1
including connectors
RTK / Static: 5.5 hours
Port 1 and Port 2 (7-pin)
4.2 Positioning specifications
Positioning Specification
Static GNSS surveying
a
Real-Time surveying
Initialization time Typically <30 seconds
Code differential GPS positioning
differential positioning accuracy
a
Accuracy and reliability may be subject to anomalies such as multipath, obstructions, satellite
geometry, and atmospheric conditions. Always follow recommended survey practices.
b
WAAS/EGNOS-capable GPS receiver dependant on field software application.
Horizontal ±5 mm +0.5 ppm RMS
Vertical ±5 mm +1 ppm RMS
Horizontal ±10 mm + 1 ppm RMS
Vertical ±20 mm + 1 ppm RMS
Initialization Automatic OTF (on-the-fly) while moving
Start-up <60 seconds from power on to positioning
<30 seconds with recent ephemeris
a
WAAS/EGNOS
Typically <5 m 3DRMS
b
32 EPOCH 35 GNSS System User Guide
4.3 Technical specifications
Feature Specification
Measurements Low elevation satellite tracking technology
14 L1, 14 L2 GPS, 12 L1, 12 L2 GLONASS, 2 SBAS, WAAS/EGNOS
NMEA-0183: AVR, GSV, HDT, VGK, VHD, ROT, GGK, GGA, GSA, ZDA,
VTG,G S T, P J T, an d PJ K
5 Hz position rate
Start-up Cold start: < 60 seconds from power on
Warm start: < 30 seconds with recent ephemeris
Initialization 30 seconds, automatic while moving or static
Communications
Base • Pacific Crest LPB or HPB positioning data link
• OTA 9600 bps Transparent GMSK
• RTCM 2.1, 2.2, 2.3, 3.0, CMR
Rover • Integrated receive-only UHF data link
• RTCM 2.3 & 3.0, CMR, CMR+, NTRIP
Bluetooth Type approvals are country specific. For more information, contact
your Spectra Precision dealer.
Specifications 4
EPOCH 35 GNSS System User Guide 33
4 Specifications
34 EPOCH 35 GNSS System User Guide
CHAPTER
5
Default Settings 5
In this chapter:
Default settings
Default behavior
The following describes the default settings
shipped with the EPOCH 35 GNSS system.
EPOCH 35 GNSS System User Guide 35
5 Default Settings
5.1 Default settings
These settings are defined by default.
Function Factory default
General Controls: Elevation mask 10°
Serial Port 1: Baud rate 9,600
Serial Port 2: Baud rate 9,600
Antenna: Type Internal
Format 8-None-1
Flow control None
Format 8-None-1
Flow control None
Antenna height Dependent on measurement method
Group All
Measurement method Set by software
5.2 Default behavior
When you start the GNSS receiver, the logging settings are the factory defaults and
logging does not begin automatically. This is true in all of the following situations:
• it is the first time that the receiver has been used
• the receiver has been reset to its factory defaults
36 EPOCH 35 GNSS System User Guide
CHAPTER
6
Cables and Connectors 6
In this chapter:
Port 1 and 2 connectors
This chapter provides pinout information for the
EPOCH 35 GNSS receiver standard and optional
cables. This information can be used to prepare
special cables for connecting the receiver to
devices and instruments not supported by the
standard and optional cables.
EPOCH 35 GNSS System User Guide 37
6 Cables and Connectors
71
3
6
4
2
5
6.1 Port 1 and 2 connectors
Figure 6.1 Port 1 connector pinouts
Pin Pinout function, Port 1 – 7-pin LEMO
1 Signal ground
2 Power ground
3TXD
4N/C
5N/C
6 + Power in
7TRXD
8N/A
9N/A
38 EPOCH 35 GNSS System User Guide
APPENDIX
A
RTCM Output A
In this appendix:
Generated messages
Message scheduling
EPOCH 35 GNSS System User Guide 39
A RTCM Output
A.1 Generated messages
The following table shows the messages that are generated when you select a specific
RTCM version. The messages in the table are in the same order as they appear in the
GPS Configurator software. For the details of the contents of individual messages, refer
to the RTCM documentation.
Selection Message
Version 2 1 3 22 59
USCG 9-3 3 9-3
RTCM/RTK 2.2+2.3 1 3 18 19 22 23 24 59
RTK Only 2.2+2.3 3 18 19 22 23 24 59
RTCM/RTK 2.3 1 18 19 23 24
RTK Only 2.3 18 19 22
RTCM/RTK 2.2 1 3 18 19 22 59
RTK Only 2.2 3 18 19 22 59
RTCM/RTK 2.1 1 3 18 19 22 59
RTK Only 2.1 3 18 19 22 59
RTCM/RTK 3.00 1004 1006 1008 1013
A.2 Message scheduling
The following table describes the frequency at which messages are generated when
they are enabled in a base receiver
Type Frequency
1 Every second
3 The 10th second after the first measurement, then every 10 seconds after that
18 Every second
19 Every second
22 The 5th second after the first measurement, then every 10 seconds after that
23 The 4th second after the first measurement, then every 10 seconds after that
24 The 4th second after the first measurement, then every 10 seconds after that
59-sub, 13 The 5th second after the first measurement, then every 10 seconds after that
1004 Every second
1006 Every 10 seconds
1008 Every 10 seconds
1013 Every 300 seconds
.
40 EPOCH 35 GNSS System User Guide
APPENDIX
B
Troubleshooting B
In this appendix:
Receiver issues
EPOCH 35 GNSS System User Guide 41
B Troubleshooting
B.1 Receiver issues
The following table describes some possible receiver issues, possible causes, and how
to solve them.
Issue Possible cause Solution
The receiver does
not power up.
Receiver does not
log data.
The receiver is not
responding.
Reference receiver is
not broadcasting.
Roving receiver is
not receiving radio.
External power too low. Check the charge on the external battery, and check
the fuse if applicable. Replace the battery if necessary.
Internal power too low. Check the charge on the internal batteries.
External power not properly
connected.
Faulty power cable. Try a different cable.
The receiver is tracking
fewer than four satellites.
Receiver needs soft reset. Power down the receiver and power back up.
Faulty cable between
receiver and radio.
No power to radio. If the radio has its own power supply, check the
Reference receiver is not
broadcasting.
Incorrect radio protocol set. Ensure that the radio protocol set on the rover
If the radio light flashes, but
there are no float or fixed
positions.
Check that the 7-pin LEMO connection is seated
properly.
Check for broken or bent pins in the connector.
Check pinouts with multimeter to ensure internal
wiring is intact.
Wait until at least 4 satellites are tracked.
Try a different cable.
Examine the ports for missing pins.
Use a multimeter to check pinouts.
charge and connections.
Check radio channel settings.
matches the base.
Check to ensure that the same correction format that
is set on the base is used on the rover.
42 EPOCH 35 GNSS System User Guide
Index
A
antenna
default information 36
electrical interference 16
height 36
mounting 16
Australia, notices to users 2
autonomous position 26
B
base mode 26
base receiver
guidelines for setting up 17
ports and connectors 14
specifications 10
battery, inserting in the receiver 16
baud rate, default 36
Bluetooth wireless technology 10
button
enter 25
power 25
scroll 25
select 25
C
D
data/power cable pinouts 38
default settings
antenna 36
baud rate 36
elevation mask 36
resetting 29
serial format 36
E
electrical interference 16
electronic interference 11
elevation mask, default 36
enter button 25
environmental factors affecting receiver 16
Europe, notices to users 2
European Council Directive 89/336/EEC 2
F
factory defaults, Epoch 35 GNSS receiver 35
features, receiver 10
fix solution 26
float solution 26
flow control, default setting 36
caring for the receiver 11
CMR 10
input 10
output 10
COCOM limits 11
cold start, time required 33
control panel 24
G
GPS status 26
guidelines for setting up receiver 16
base 17
rover 18
EPOCH 35 GNSS System User Guide 43
Index
I
initialization
specifications 33
input, RTCM 10
interference
electrical 16
electronic 11
internal radio protocol 28
L
LED display 24, 25
LED panel 14
limits, imposed by COCOM 11
logging to SD 10
logging, to a Recon controller 29
M
main menu 27
items 27
messages 27
maximum baud rate 36
menu, main 27
messages, self-test procedure 26
mounting antenna, avoiding electrical
interference 16
parts
base receiver 14
rover receiver 15
physical specifications 32
pinouts, serial ports 38
Port 1
default baud rate 36
default serial format 36
flow control 36
pinout diagram 38
Port 2
default baud rate 36
default serial format 36
pinout diagram 38
ports and connectors
base receiver 14
rover receiver 15
positioning specifications 32
post processing file, SD card 29
post-processing routine 28
power button 25
power supply 22
powering down the receiver 25
powering up the receiver 25
problems, troubleshooting 41–??
procedure, self-test 26
Q
N
New Zealand, notices to users 2
notices to users
Australia and New Zealand 2
Europe 2
number of satellites 26
O
operating controls 14
operating temperature 32
output formats, RTCM 10
P
PacificCrest PDL HPB radio 10
panel controls 24
44 EPOCH 35 GNSS System User Guide
quality of position 26
R
radio channel, setting 28
radio mode 28
radio mode, selecting 28
radio noise emissions, Canada 2
receiver
caring for 11
connecting to devices 37
control panel 24
features 10
inserting the internal battery 16
setup 13
turn off 25
turn on 25
registration 11
reset, soft 42
Index
rover receiver
parts 15
ports and connectors 15
specifications 10
RTCM input 10
S
scroll buttons 25
SD card 26, 27
logging caution 6
memory 10
post-processing 29
storing post-processing files 28
SD, logging to 10
security limits 11
Select button 25
selecting radio mode 28
self-test procedure 26
serial format, default setting 36
serial ports pinouts 38
Setup 16
setup guidelines 16
size 32
soft reset 42
specifications
physical 32
positioning 32
start-up 33
technical 33
static surveying 10
storage temperature 32
support agreement contracts 11
switching the receiver on and off 25
T
technical specifications 33
temperature
operating range 32
storage range 32
tracking specifications 33
troubleshooting 41
turning off the receiver 25
turning on the receiver 25
U
U.S. Department of Commerce 11
use and care 11
W
warm start, time required 33
weight
base receiver 32
rover receiver 32
EPOCH 35 GNSS System User Guide 45
Index
46 EPOCH 35 GNSS System User Guide
