Spectec t211 User Manual

WARNING

Please read and follow all of the instructions & safety precautions detailed below prior to using this product. Failure to

do so may result in serious personal injury and / or property damage.

Safety Precautions

 Do not expose this product to heat sources (including open flame or direct sunlight)
 Do not expose this product to water or liquids. If liquid enters the product, immediately unplug the product

from any connected power sources or devices.

 Do not disassemble or modify the product
 Avoid dropping this product (or any other heavy impact which might damage the internal circuit)
 In the unlikely event of any abnormalities (such as strange odor, overheating, leaking, color change, etc.),

discontinue use immediately.

 Avoid cleaning this product using liquids or chemical substances (use dry cloth only)
 Only use attachments/accessories specified by the manufacturer
 Dispose of this item properly (do not dispose of it in trash receptacles and do not attempt to incinerate it)
 Do not leave this product unattended while it is in use or while it is being charged
 This product is not a toy: KEEP AWAY FROM CHILDREN
 Do not use this product while it is being charged

T211 USER MANUAL

The T211 Wireless 4.0 desktop speaker that features is a stereo sound & a convenient tablet or smart phone
stand. Please see below product specifications & user guide.

T211 Specifications

Battery Type: Lithium Polymer
Battery Duration/Lifespan: 400 times
Capacity: 800 mAh
Power Input & Current: 5V/0.5A
Sound Output: 3W x 2 speakers
Sensitivity: 80 dB (per speaker)
Frequency Response: 90Hz - 20KHz
Distortion Rate: 1%
Wireless Version: V4.0
Range of Wireless Communication: 10 meters
Charge Time (0-100%): 2 hours
Playback Time: 8 hours
Accessories included: Micro USB/USB charging cable & 3.5 mm AUX cable
Product Size: 240*425*60mm
Net Weight: 325.5g

T211 Product Map

To charge the T211

1. Insert the micro USB tip of the charging cable into the T211 & connect USB output to a power source.

2. Battery charge indicator (white LED) will remain lit & will turn OFF once T211 is fully charged.

Operation

1. Wireless Mode

Pairing the T211 with your audio device

a. Turn the T211 power switch ON (white LED light (Bluetooth symbol) will flash quickly to indicate the speaker

is ready for pairing)

b. Turn on the Bluetooth on your audio device
c. Device name is Spector T211 (no pairing password required)

d. White LED light will flash slowly once paired

NOTES:

 If your Bluetooth device has paired with the unit successfully once, when the T211 is activated they will

connect automatically.

 To disconnect from Wireless mode, hold down the T211 function button for 3 seconds

Operation in Wireless mode

a. Function button: Press once to Play/Pause when in music mode
b. Function button: Press once to Answer/End Calls
c. Function button: press & hold to REJECT incoming calls & double press when in music mode to redial last

call

d. Skip Songs & Volume Control – must be controlled directly on your connected audio device

NOTE:
After a call is terminated, the T250 will resume to previous working status.

Power switch

Micro USB charge interface

3.5 Aux input interface

Indicator light & Function button

Tablet or Smart Phone

Support

Red LED light will flash to indicate low battery

AUX in Mode

1. Turn the T211 power switch ON & connect the AUX cable to the speaker & to your audio device (white LED
(AUX logo) will flash slowly when connected by audio cable)

2. When in AUX mode you must use your audio device to operate the speaker (play/pause skip songs/volume
control & answer/end phone calls)
