SOYO SY-7VCA2 User Manual

SY-7VCA2
Motherboard
****************************************************
VIA Cyrix III, Intel Pentium® III & Celeron
Processor supported
Via 694X AGP/PCI/AMR Motherboard
ATX Form Factor
****************************************************
User's Manual
SOYOSY-7VCA2
Copyright © 2001 by Soyo Computer Inc.
Trademarks:
Soyo is the registered trademark of Soyo Computer Inc. All trademarks are the properties of their owners.
Product Rights:
All names of the product and corporate mentioned in this publication are used for identification purposes only. The registered trademarks and copyrights belong to their respective companies.
Copyright Notice:
All rights reserved. This manual has been copyrighted by Soyo Computer Inc. No part of this manual may be reproduced, transmitted, transcribed, translated into any other language, or stored in a retrieval system, in any form or by any means, such as by electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without permission in writing from Soyo Computer Inc.
Disclaimer:
Soyo Computer Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to amend the manual or revise the specifications of the product described in it from time to time without obligation to notify any person of such revision or amend. The information contained in this manual is provided to our customers for general use. Customers should be aware that the personal computer field is subject to many patents. All of our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or to cause others to infringe upon such rights.
Restricted Rights Legend:
Use, duplication, or disclosure by the Government is subject to restrictions set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at 252.277-7013.
About This Guide:
This Quick Start Guide can help system manufacturers and end users in setting up and installing the Motherboard. Information in this guide has been carefully checked for reliability; however, to the correctness of the contents there is no guarantee given. The information in this document is subject to amend without notice.
For further information, please visit our Web Site on the Internet. The address is
"http://www.soyo.com.tw".
Edition: January 2001 Version 1.1 7VCA2 SERIAL
Tested To Comply
C
With FCC Standards
FC
FOR HOME OR OFFICE USE
POST CONSUMER
100%
RECYCLED PAPER
ii
Table of Contents SY-7VCA2
Table of Contents
CHAPTER 1 MOTHERBOARD DESCRIPTION .............................1
1-1 INTRODUCTION...........................................................1
1-2 KEY FEATURES............................................................1
1-3 HANDLING THE MOTHERBOARD .............................5
1-4 ELECTROSTATIC DISCHARGE PRECAUTIONS ........5
1-5 SY-7VCA2 MOTHERBOARD LAYOUT .......................6
1-6 SY-7VCA2 MOTHERBOARD COMPONENTS.............7
1-7 MICROPROCESSOR......................................................9
1-8 SY-7VCA2 MOTHERBOARD COMPONENTS...........10
1-9 MICROPROCESSOR....................................................12
1-10 I/O INTERFACE CONTROLLER.................................16
1-11 HARDWARE MONITOR ..............................................18
1-12 WAKE ON LAN TECHNOLOGY .................................19
CHAPTER 2 HARDWARE INSTALLATION..................................20
2-1 PREPARATIONS .......................................................... 20
2-2 UNPACKING THE MOTHERBOARD ......................... 21
2-3 INSTALLATION GUIDE..............................................22
2-3.1 CPU Fan Installation..................................................23
2-3.2 SDRAM Memory Module Installation......................... 26
2-3.3 Motherboard Connector..............................................28
3-3.4 CMOS Clearing (JP5)................................................. 43
2-3.5 Power On................................................................... 43
2-3.6 Quick BIOS Setup.......................................................44
2-3.7 Troubleshooting at First Start .....................................46
2-3.8 Power Off...................................................................49
CHAPTER 3 BIOS SETUP UTILITY ..............................................52
3-1 SOYO COMBO SETUP.................................................55
3-2 STANDARD CMOS SETUP..........................................60
iii
Table of Contents SY-7VCA2
3-3 ADVANCED BIOS FEATURES.....................................63
3-4 ADVANCED CHIPSET FEATURES..............................67
3-5 INTEGRATED PERIPHERALS.....................................72
3-6 POWER MANAGEMENT SETUP ................................77
3-7 PNP/PCI CONFIGURATION SETUP.............................81
3-8 PC HEALTH STATUS.................................................... 84
3-9 LOAD FAIL-SAFE DEFAULTS.....................................86
3-10 LOAD OPTIMIZED DEFAULTS................................... 87
3-11 SUPERVISOR PASSWORD........................................... 88
3-12 USER PASSWORD........................................................ 89
3-13 IDE HDD AUTO DETECTION .....................................90
CHAPTER 4 DRIVERS INSTALLATION ........................................91
iv
Motherboard Description SY-7VCA2
Chapter 1
MOTHERBOARD DESCRIPTION
1-1 INTRODUCTION
The SY-7VCA2 AGP/PCI/AMR Motherboard is a high-performance Socket 370 supported ATX form-factor system board. The SY-7VCA2 uses VIA Chipset technology and supports Socket 370 class processors. This Motherboard is fully compatible with industry standards and adds many technical enhancements.
1-2 KEY FEATURES
Ø CPU SUPPORT
The SY-7VCA2 supports a wide range of INTEL CPUs:
n FSB 66MHz: Celeron(400-700MHz) n FSB 100MHz: Pentium® III (500-850MHz) n FSB 133MHz: Pentium® III (533MHz-1.13GHz)
Supports Via Cyrix processors
n FSB 100MHz: Cyrix III (500MHz-600MHz) n FSB 133MHz: Cyrix III (533MHz-600MHz)
New released Intel Socket 370 CPUs will very likely be supported by the SY-7VCA2 as well.
Ø CPU SETTINGS
The SY-7VCA2 provides the user with a very complete and convenient CPU setting environment. The CPU settings are all adjusted through the special SOYO COMBO page in the BIOS, therefore rendering the use of jumpers obsolete.
n CPU FSB Frequency
The SY-7VCA2 supports an incredible wide range of CPU FSB frequency settings: 66, 75, 81, 83, 90, 95, 100, 105, 110, 112, 113, 115, 117, 118, 120, 122, 124, 126, 133, 135, 137, 138, 140, 142, 144, 150 and 155 MHz. This ensures that the SY-7VCA2 has an overwhelming overclocking potential.
1
Motherboard Description SY-7VCA2
n CPU Multiplier
The SY-7VCA2 supports a wide range of multipliers:
2.0x, 2.5x, 3.0x, 3.5x, 4.0x, 4.5x, 5.0x, 5.5x, 6.0x, 6.5x, 7.0x, 7.5x and
8.0x
Ø EXPANDABILITY
The SY-7VCA2 provides all the standard expansion slots, and many more additional expansion features:
u Expansion slots
n 1 x 32-bit bus master AGP slot n 5 x 32-bit bus master PCI slots n 1 x 16-bit ISA slots
u Enhanced IO
n Floppy disk controller n 2x EIDE controllers with support for up to 4 Ultra DMA 33/66
/100 devices
n Standard/EPP/ECP parallel port n 2x 16550 compatible serial ports n IrDA compatible infrared port n 4x USB (Universal Serial Bus) connectors n PS/2 mouse connector n PS/2 keyboard connector
2
Motherboard Description SY-7VCA2
Ø ADVANCED FUNCTIONS
The SY-7VCA2 supports advanced functions such as:
n Wake-On-LAN Supports Wake-On-LAN (Some advanced network cards can
wake the system up over the network, the WOL connector is provided by the SY-7VCA2 to support this function).
n Multiple boot The SY-7VCA2 supports booting from devices such as CD-ROM. n Power on by modem or alarm If the SY-7VCA2 system is in suspend mode, it can be switched back on through the modem or RTC alarm through this function. This opens a lot of possibilities, such as remote access that switches the system on only after the modem receives a call.
Ø FAIL SAFE
The SY-7VCA2 comes with added functionality to make managing the system easy and safe
u Hardware Monitor
The integrated Hardware Monitor IC and Hardware doctor software enables the user to monitor system voltages, temperatures and FAN speeds. This makes sure that the user is full control of the system
u Power Failure Resume Function
This function can be set in the BIOS, and determines whether the system will automatically turn on again after a power failure. This function is indispensable for server systems that need to always be on line.
u 5VSB Indicator
This green LED gives an indication of the presence of the 5V Standby voltage. This voltage is always fed into the motherboard and is used for functions such as WOL.
Ø SOYO Bonus Pack CD-ROM Ø COMPLIANCE
The SY-7VCA2 complies with all important industry standards. The
3
Motherboard Description SY-7VCA2
following underlines the reliability of the SY-7VCA2, a motherboard to trust.
n PC99, ACPI compliant
Ø USER FRIENDLY
n SOYO Combo Setup n Jumperless design n You can set up the following options trough the BIOS setting
CPU FSB frequencyCPU multiplierCPU Vcore voltagePCI clockAGP ClockSDRAM Clock
4
Motherboard Description SY-7VCA2
1-3 HANDLING THE MOTHERBOARD
To avoid damage to your Motherboard, follow these simple rules while unpacking:
Ø Before handling the Motherboard, ground yourself by grasping an
unpainted portion of the system's metal chassis.
Ø Remove the Motherboard from its anti-static packaging. Hold the
Motherboard by the edges and avoid touching its components.
Ø Check the Motherboard for damage. If any chip appears loose, press
carefully to seat it firmly in its socket.
Warning: Do not apply power if the Motherboard appears damaged. If there is damage to the board, contact your dealer immediately.
1-4 ELECTROSTATIC DISCHARGE PRECAUTIONS
Make sure to ground yourself before handling the Motherboard or other system components. Electrostatic discharge can easily damage the components. Note that you must take special precautions when handling the Motherboard in dry or air-conditioned environment.
To protect your equipment from electrostatic discharge, take the following precautions:
Ø Do not remove the anti-static packaging until you are ready to install. Ø Ground yourself before removing any system component from its
protective anti-static packaging. (To ground yourself, grasp the expansion slot covers or other unpainted portions of the computer chassis.)
Ø Frequently ground yourself while working or use a grounding strap. Ø Handle the Motherboard by its edges and avoid touching its
components.
5
Motherboard Description SY-7VCA2
Speaker
_
+
_
+
_
+
_
+
Reset
PWRBT
PCI Slot #1
PCI Slot #3
PCI Slot #4
PCI Slot #5
1
1
1
2
FDC1
ATX Power
DIMM 2
DIMM 3
DIMM 1
PCI Slot #2
CHAFAN
SDRAM
SDRAM
VT82C694X
AGP Slot
3V
Lithium
USB2
SIRCON
1
5
JP5
3
1
1
1
3
6
5
10
CDIN1
ISA Slot
Via
VT82C686B
Flash BIOS
1-5 SY-7VCA2 MOTHERBOARD LAYOUT
PS/2 KB
PS/2 Mouse
Connector
Connector
USB 1
PRT
Socket 370
COM1
COM2
GAME
AUDIO-OUT
LINE-IN
MIC-IN
CODEC AC97
1
1 4
CDIN2
JP10
3
1
D1D8D3
D2
4
AMR
Battery
1 3
CPUFAN
®
IDE 1 IDE 2
®
Power
LED
STR
HDD LED
LED
Back Panel SY-7VCA2 Platform
6
Motherboard Description SY-7VCA2
SDRAM
SDRAM
A
B
D
E
F
G
H
I
J
K
L
M
N
O
C
1-6 SY-7VCA2 MOTHERBOARD COMPONENTS
W
V U
T S
R Q
P
®
®
7
Motherboard Description SY-7VCA2
A Socket 370 Connector B CPU Cooling Fan Connector C Via 694X North Bridge chip D ATX Power Supply Connector E DIMM Banks
F Bus Mastering e-IDE/ATAPI Ports G CMOS Clear Jumper H Via 686B South Bridge Chip
I Flash BIOS
J USB Ports K Chassis Cooling Fan
L Front panel connectors
M Serial Infrared (IrDA) Device Header
N Floppy Disk Drive (FDD) Port
O 16-bit ISA Slot
P 3V Lithium Battery Q Audio Modem Riser Slot
R Wake-On-LAN (WOL) Header
S 32-bit PCI Mastering Slots
T CD-IN Connectors U AC97 Codec Chip V 32-bit AGP Slot
W Back panel Connectors
X Debug LEDs
8
Motherboard Description SY-7VCA2
1-7 MICROPROCESSOR
The motherboard supports a single Socket 370 processor. The processor’s VID pins automatically program the voltage regulator on the motherboard to the required processor voltage. In addition, the front side bus speed (100 MHz and 133 MHz) is automatically selected. The motherboard supports all current Socket 370 processor speeds, voltages, and bus frequencies.
1-7.1 Microprocessor Packaging
The CPU is packaged in a 370 pin PGA package. A fan must be used to ensure adequate cooling.
1-7.2 Second Level Cache
The second-level cache is located on the substrate of the CPU package. The cache includes 0KB/128KB or 512 KB of synchronous pipelined burst static RAM. All supported onboard memory can be cached.
1-7.3 Microprocessor Upgrades
The motherboard can be upgraded with Socket 370 processors that run at higher speeds. When upgrading the processor, use the BIOS configuration mode to change the processor speed.
9
Motherboard Description SY-7VCA2
1-8 MEMORY
1-8.1 Main Memory
The motherboard has three DIMM sockets. SDRAM can be installed in one, two, or three sockets. Using the serial presence detect (SPD) data structure, programmed into an E²PROM on the DIMM, the BIOS can determine the SDRAM’s size and speed. Minimum DIMM memory size is 8 MB; maximum DIMM memory size is 256/512 MB. Memory size and speed can vary between sockets. The motherboard supports the following memory features:
DRAM interface synchronous with host CPU (66/100/133MHz) or
AGP (66MHz) for most flexible configuration
DRAM interface may be faster than CPU by 33 MHz to allow use
of PC100 memory modules with 66MHz Celeron or use of PC133 with 100MHz Pentium II or Pentium III
DRAM interface may be slower than CPU by 33 MHz to allow use
of older memory modules with newer CPUs (e.g., PC66 memory modules with 100MHz Pentium II or Pentium III)
Concurrent CPU, AGP, and PCI accessSupports FP,EDO, SDRAM, ESDRAM and VCM SDRAM
memory types
Different DRAM types may be used in mixed combinationsDifferent DRAM timing for each bankDynamic Clock Enable (CKE) control for SDRAM power
reduction in high speed system.
Mixed 1M/2M/4M/8M/16M/32MxN DRAMsThe 7VCA2 supports 3 DIMMs or 6 banks at 133MHz for 1.5GB
max memory.
Flexible row and column addresses64-bit data width only3.3V DRAM interface with 5V-tolerant inputsProgrammable I/O drive capability for MA, command, and MD
signals
10
Motherboard Description SY-7VCA2
Dual copies of MA signals for improved driveOptional bank-by-bank ECC (single-bit error correction and multi-
bit error detection) or EC(error checking only) for DRAM integrity
Two-bank interleaving for 16Mbit SDRAM supportTwo-bank and four bank interleaving for 64Mbit SDRAM supportIndependent SDRAM control for each bankSeamless DRAM command scheduling for maximum DRAM bus
utilization (e.g., precharge other banks while accessing the current bank)
Four cache lines (16quadwords) of CPU to DRAM write buffersFour cache lines of CPU to DRAM read prefetch buffersRead around write capability for non-stalled CPU readSpeculative DRAM read before snoop resultBurst read and write operationx-2-2-2-2-2-2-2 bank-to-back accesses for EDO DRAM from CPU
or from DRAM controller
x-1-1-1-1-1-1-1 back-to back accesses for SDRAMBIOS shadow at 16KB incrementDecoupled and burst DRAM refresh with staggered RAS timingCAS before RAS or self refresh
11
Motherboard Description SY-7VCA2
1-9 CHIPSET
Ø VT82C694X
The VIA 694X is a high performance, cost-effective and energy efficient chip set for the implementation of AGP/PCI/ISA desktop personal computer systems from 66MHz, 100MHz and 133MHz based on 64-bit Socket 370 super-scalar processors. The Via 694X chip set consists of the VT82C694A system controller (510 pin BGA) and the VT82C686B PCI to ISA bridge (352 pin BGA). The system controller provides superior performance between the CPU, DRAM, AGP bus, and PCI bus with pipelined, burst, and concurrent operation. The VT82C694X supports eight banks of DRAMs up to 1.5GB. The DRAM controller supports standard Fast Page Mode (FPM) DRAM, EDO-DRAM, Synchronous DRAM (SDRAM) and Virtual Channel SDRAM (VC SDRAM), in a flexible mix / match manner. The Synchronous DRAM interface allows zero wait state bursting between the DRAM and the data buffers at 66/100/133 MHz. The eight banks of DRAM can be composed of an arbitrary mixture of 1M/2M/4M/8M/16M/32MxN DRAMs. The DRAM controller also supports optional ECC (single-bit error correction and multi-bit detection) or EC (error checking) capability separately selectable on a bank-by-bank basis. The DRAM controller can run at either the host CPU bus frequency (66/100/133 MHz) or at the AGP bus frequency (66 MHz) with built-in PLL timing control. The VT82C694X system controller also supports full AGP v2.0 capability for maximum bus utilization including 4x mode transfers, SBA (Side Band Addressing), Flush/Fence commands, and pipelined grants. An eight level request queue plus a four level post-write request queue with thirty-two and sixteen quad words of read and write data FIFO’s respectively are included for deep pipelined and split AGP transactions. A single-level GART TLB with 16 full associative entries and flexible CPU/AGP/PCI remapping control is also provided for operation under protected mode
12
Motherboard Description SY-7VCA2
operating environments. Both Window 95 VxD and Windows 98 /NT5.0 mini port drivers are supported for interoperability with major AGP-based 3D and DVD- capable multimedia accelerators. The VT82C694X supports two 32-bit 3.3/5V system buses (one AGP and one PCI) that are synchronous/ pseudo-synchronous to the CPU bus. The chip also contains a built-in bus-to-bus bridge to allow simultaneous concurrent operations on each bus. Five levels (double words) of post write buffers are included to allow for concurrent CPU and PCI operation. For PCI master operation, forty-eight levels (double words) of post write buffers and sixteen levels (double words) of prefetch buffers are included for concurrent PCI bus and DRAM/cache accesses. The chip also supports enhanced PCI bus commands such as Memory-Read-Line, Memory-Read­Multiple and Memory-Write-Invalid commands to minimize snoop overhead. In addition, advanced features are supported such as snoop ahead, snoop filtering, L1 write-back forward to PCI master, and L1 write­back merged with PCI post write buffers to minimize PCI master read latency and DRAM utilization. Delay transaction and read caching mechanisms are also implemented for further improvement of over all system performance. The 352-pin Ball Grid Array VT82C686B PCI to ISA bridge supports four levels (double words) of line buffers, type F DMA transfers and delay transaction to allow efficient PCI bus utilization The VT82C686B also includes an integrated keyboard controller with PS/2 mouse support, integrated DS12885 style real time clock with extended 256 byte CMOS RAM, integrated master mode enhanced IDE controller with full scatter/ gather capability and extension to UltraDMA-33/66 for 33/66 MB/sec transfer rate, integrated USB interface with root Hub and two function ports with built-in physical layer transceivers, Distributed DMA supports, and On Now/ ACPI compliant advanced configuration and power management interface. For sophisticated power management, the Via 694X provides independent clock stop control for the CPU/SDRAM, PCI, and AGP buses and
13
Motherboard Description SY-7VCA2
Dynamic CKE control for powering down of the SDRAM. A separate suspend-well plane is implemented for the SDRAM control signals for Suspend-to-DRAM operation. Coupled with the VT82C686B south bridge chip, a complete power conscious PC motherboard can be implemented with no external TTLs. The Via 694X chipset is ideal for high performance, high quality, high energy efficient and high integration desktop and notebook AGP / PCI / ISA computer systems.
Ø VT82C686B
The VT82C686B PSIPC (PCI Super-I/O integrated Peripheral Controller) is a high integration, high performance, power-efficient, and high compatibility device that supports Intel and non-Intel based processor to PCI bus bridge functionality to make a complete Microsoft PC99­compliant PCI/ISA system In addition to complete ISA extension bus functionality, the VT82C686B includes standard intelligent peripheral controllers:
1) Master mode enhanced IDE controller with dual channel DMA engine
and interlaced dual channel commands. Dedicated FIFO coupled with scatter and gather master mode operation allows high performance transfers between PCI and IDE \devices. In addition to standard PIO and DMA mode operation, the VT82C686B also supports the UltraDMA-33 standard to allow reliable data transfer rates up to 33MB/sec throughput. The VT82C686B also supports the UltraDMA-66/100 standard. The IDE controller is SFF-8038I v1.0 and Microsoft Windows-family compliant.
2) Universal Serial Bus controller that is USB v1.1 and Universal HCI
v1.1 compliant. The VT82C686B includes the root hub with four function ports with integrated physical layer transceivers. The USB controller allows hot plug and play and isochronous peripherals to be inserted into the system with universal driver support. The controller also implements legacy keyboard and mouse support so that legacy
14
Motherboard Description SY-7VCA2
software can run transparently in non-USB-aware operating system environment.
3) Keyboard controller with PS2 mouse support.
4) Real Time Clock with 256 byte extended CMOS. In addition to the
standard ISA RTC functionality, the integrated RTC also includes the date alarm, century field, and other enhancements for compatibility with the ACPI standard.
5) Hardware monitoring subsystem for managing system/ motherboard
voltage levels, temperatures, and fan speeds
6) Full System Management Bus (SMBus) interface.
7) Two 16550-compatible serial I/O ports with infrared communications
port option. A third serial port is available to be dedicated to the IR interface.
8) Integrated PCI-mastering dual full-duplex direct-sound AC97-link-
compatible sound system. Hardware soundblaster-pro and hardware­assisted FM blocks are included for Windows DOS box and real-mode DOS compatibility. Loopback capability is also implemented for directing mixed audio streams into USB and 1394 speakers for high quality digital audio
9) Two game ports and One MIDI port
10) ECP/EPP-capable parallel port
11) Standard floppy disk drive interface
12) Distributed DMA capability for support O ISA legacy DMA over
the PCI bus. Serial IRQ is also supported for docking and non-docking application.
13) Plug and Play controller that allows complete steerability of all PCI
interrupts and internal interrupts/ DMA channels to any interrupt channel. One additional steerable interrupt channel is provided to allow plug and play and reconfigurability of onboard peripherals for Windows family compliance.
The VT82C686B also enhances the functionality of the standard ISA peripherals. The integrated interrupt controller supports both edge and
15
Motherboard Description SY-7VCA2
level triggered interrupts channel by channel. The integrated DMA controller supports type F DMA in addition to standard ISA DMA modes. Compliant with the PCI2.2 specification, the VT83C686B supports delayed transactions and remote power management so that slower ISA peripherals do not block the traffic of the PCI bus. Special circuitry is built in to allow concurrent operation without causing dead lock even in a PCI­to PCI bridge environment. The chip also includes eight levels (doublewords) of line buffers from the PCI bus to the ISA bus to further enhance overall system performance.
1-10 I/O INTERFACE CONTROLLER
The motherboard uses the VT82C686B Super-I/O controller which features:
Ø Supports 2 serial ports, IR port, parallel port, and floppy disk
controller functions
Ø Two UARTs for Complete Serial Ports
Even, odd, stick or no parity bit generation and detectionProgrammable baud rate generatorHigh speed baud rate (230Kbps, 460Kbps) supportIndependent transmit/receiver FIFOsModem ControlPlug and play with 96 base IO address and 12 IRQ options
Ø One dedicated IR port
Third serial port dedicated to IR functionIR function either through the two complete serial ports or the
third dedicated port
Infrared-IrDA (HPSIR) and ASK (Amplitude Shift Keyed) IR
Ø Multi-mode parallel port
Standard mode, ECP and EPP supportPlug and play with 192 base IO address, 12 IRQ and 4 DMA
options
Ø Floppy Disk Controller
16bytes of FIFO
16
Motherboard Description SY-7VCA2
Data rates up to 1MbpsPerpendicular recording driver supportTwo FDDs with drive swap supportPlug and play with 48 base IO address, 12 IRQ and 4 DMA
options
The Setup program provides configuration option for the I/O controller.
1-10.1 Serial Ports
The motherboard has two 9-pin D-Sub serial port connectors located on the back panel. The NS16C5450-compatible UARTs support data transfers at speeds up to 115.2 Kbits/sec with BIOS support.
1-10.2 Parallel Port
The connector for the multimode bi-directional parallel port is a 25-pin D­Sub connector located on the back panel of the motherboard. In the Setup program, there are four options for parallel port operation:
l Compatible (standard mode) l Bi-directional (PS/2 compatible) l Bi-directional EPP. A driver from the peripheral manufacturer is
required for operation.
l Bi-directional high-speed ECP
1-10.3 Diskette Drive Controller
The I/O controller is software compatible with the 82077 diskette drive controller and supports both PC-AT and PS/2 modes. In the Setup program, the diskette drive interface can be configured for the following diskette drive capacities and sizes.
l 360 KB, 5.25-inch l 1.2 MB, 5.25-inch l 720 KB, 3.5-inch l 1.2 MB. 3.5-inch (driver required) l 1.25-1.44 MB, 3.5-inch l 2.88 MB, 3.5-inch
17
Motherboard Description SY-7VCA2
1-10.4 PS/2 Keyboard and Mouse Interface
PS/2 keyboard and mouse connectors are located on the back panel of the motherboard. The +5 V lines to keyboard and mouse connectors are protected with a fuse that prevents motherboard components from being damaged when an over-current condition occurs.
Note
The mouse and keyboard can be plugged into either PS/2 connector. Power to the computer should be turned off before a keyboard or mouse is connected or disconnected.
The keyboard controller contains code, which provides the traditional keyboard and mouse control functions, and also supports Power On/Reset password protection. Power On/Reset password can be specified in the BIOS Setup program.
The keyboard controller also supports the hot-key sequence <Ctrl><Alt><Del>, software reset. This key sequence resets the computer’s software by jumping to the beginning of the BIOS code and running the Power On Self Test (POST).
1-10.5 Infrared Support
On the front panel I/O connector, there are six pins that support Hewlett Packard HSDL-1000 compatible infrared (IR) transmitters and receivers. In the Setup program, Serial Port B can be direct4d to a connected IR device. (In this case, the Serial Port B connector on the back panel cannot be used.) The IR connection can be used to transfer files to or from portable devices like laptops, PDAs, and printers. The Infrared Data Association (IrDA) specification supports data transfers of 115Kbits/sec at a distance of 1 meter.
1-11 HARDWARE MONITOR
The optional hardware monitor subsystem provides low-cost instrumentation capabilities. The features of the hardware monitor
18
Motherboard Description SY-7VCA2
subsystem include:
Ø An integrated ambient temperature sensor Ø Fan speed sensors, which monitor the fan 1 and fan 2 connector. Ø Power supply voltage monitoring to detect levels above or below
acceptable values When suggested ratings for temperature, fan speed, or voltage are exceeded, an interrupt is activated. The hardware monitor component connects to the SMBus.
1-12 WAKE ON LAN TECHNOLOGY
Wake on LAN technology enables remote wakeup of the computer through a network. Wake on LAN technology requires a PCI add-in network interface card (NIC) with remote wakeup capabilities. The remote wakeup connector on the NIC must be connected to the onboard Wake on LAN connector. The NIC monitors network traffic at the Ethernet interface; upon detecting a Magic Packet, the NIC asserts a wakeup signal that powers up the computer. This feature uses the Wake on LAN connector.
*
CAUTION
For Wake on LAN, the 5-V standby line for the power supply must be capable of delivering +5V ±5 % at 720 mA. Failure to provide adequate standby current when implementing Wake on LAN can damage the power supply.
19
Hardware Installation SY-7VCA2
Chapter 2
HARDWARE INSTALLATION
Congratulations on your purchase of SY-7VCA2 Motherboard. You are about to install and connect your new Motherboard.
Note: Do not unpack the Motherboard from its protective anti­static packaging until you have made the following preparations.
2-1 PREPARATIONS
Gather and prepare all the following hardware equipment to complete the installation successfully:
1. Socket 370 processor with built-in CPU cooling fan (boxed type).
Note: This Motherboard supports non-boxed type CPUs. The heavier
CPU cooling fan requires the installation of a CPU support stand.
2. DIMM memory module (s)
3. Computer case and chassis with adequate power supply unit
4. Monitor
5. PS/2 Keyboard
6. Pointing Device (PS/2 mouse)
7. Speaker(s) (optional)
8. Disk Drives: HDD, CD-ROM, Floppy drive…
9. External Peripherals: Printer, Plotter, and Modem (optional)
10. Internal Peripherals: Modem and LAN cards (optional)
20
Hardware Installation SY-7VCA2
2-2 UNPACKING THE MOTHERBOARD
When unpacking the Motherboard, check for the following items:
u The SY-7VCA2 VT82C694X AGP/PCI Motherboard
u The Quick Start Guide
u The Installation CD-ROM
u SOYO Bonus Pack CD-ROM
u One IDE Device ATA 66 Flat Cable
u One Floppy Disk Drive Flat Cable
Warning: Do not unpack the Motherboard from its anti-static packaging until you are ready to install it.
Like most electronic equipment, your Motherboard may be damaged by electrostatic discharge. To avoid permanent damage to components ground yourself while working by using a grounding strap. Otherwise, ground yourself frequently by touching the unpainted portion of the computer chassis to drain the static charges. Handle the Motherboard carefully, holding it by the edges. You are now ready to start the installation.
21
Hardware Installation SY-7VCA2
2-3 INSTALLATION GUIDE
We will now begin the installation of the Motherboard. Please follow the step-by-step procedure designed to lead you to a complete and correct installation.
Warning: Turn off the power to the Motherboard, system chassis, and peripheral devices before performing any work on the Motherboard or system.
BEGIN THE INSTALLATION
22
Hardware Installation SY-7VCA2
2-3.1 CPU Installation
Your SY-7VCA2 motherboard comes with a CPU retention set kit. The retention set is used to hold the processor attached to the Socket 370 CPU connector on the motherboard.
Mark your CPU Frequency:
your CPU that should be clearly marked on the CPU cover.
Record the working frequency of
FSB 66MHz
400MHz (66 x 6.0) 466MHz (66 x7.0) 533MHz (66 x 8.0) 600MHz (66 x 9.0) 667MHz (66 x 10.0) 433MHz (66 x 6.5) 500MHz (66 x7.5) 566MHz (66 x 8.5) 633MHz (66 x 9.5) 700MHz (66 x 10.5)
FSB 100MHz
500MHz (100 x 5.0) 600MHz (100 x 6.0) 700MHz (100 x 7.0) 800MHz (100 x 8.0) 550MHz (100 x 5.5) 650MHz (100 x 6.5) 750MHz (100 x7.5) 850MHz (100 x 8.5)
FSB 133MHz
533MHz(133x4.0) 667MHz(133x5.0) 800MHz(133x 6.0) 933MHz(133x 7.0) 1.13GHz(133x 8.5) 600MHz(133x4.5) 733MHz(133x5.5) 866MHz(133x 6.5) 1000MHz(133x 7.5)
CPU Mount Procedure:
processor & VIA Cyrix processor that you have purchased separately, follow these instructions.
To mount the Pentium® & Celeron
TM
1. Lift the socket handle up to a vertical position.
23
Hardware Installation SY-7VCA2
2. Align the blunt edge of the CPU with the matching pinhole
distinctive edge on the socket.
3. Seat the processor in the socket completely and without forcing.
4. Then close the socket handle to secure the CPU in place.
24
Hardware Installation SY-7VCA2
Remember to connect the CPU Cooling Fan to the appropriate power connector on the Motherboard. The fan is
a key component that will ensure system stability. The fan prevents overheating, therefore prolonging the life of your CPU.
2-3.1.1 CPU Fan Installation
Your Socket 370 processor kit comes with a cooling fan. Mount the fan on the processor according to the instructions provided by the manufacturer. The fan is a key component that will ensure system stability. The fan prevents overheating, therefore prolonging the life of your CPU.
Note: Remember to connect the fan to the appropriate power source.
25
Hardware Installation SY-7VCA2
SDRAM
SDRAM
1
84
DI
DIMM 2
DIMM 3
2-3.2 SDRAM Memory Module Installation
®
®
MM 1
Your board comes with three DIMM sockets, providing support for up to
1.5GB of main memory using unbuffered and registered DIMM modules from 8MB to 512MB. On this motherboard, DRAM speed can be set independent from the CPU front side bus speed. Depending on the DRAM clock speed setting in the BIOS setup (Chapter 3), appropriate memory modules must be used. For 66MHz DRAM speed, use PC66 memory; for 100MHz DRAM speed, use PC100 memory; for 133MHz DRAM speed, use PC133 memory.
1
84
26
Hardware Installation SY-7VCA2
Memory Configuration Table
Number of Memory
Modules
RAM Type
Memory Module Size
(MB)
DIMM 1 DIMM 2 DIMM 3
SDRAM
8/16/32/64/128/256/512 MB
27
Hardware Installation SY-7VCA2
SDRAM
SDRAM
IDE 2
IDE 1
Pin -1
IDE
39
39
40-pin
80-Conductor
2-3.3 Motherboard Connector
2-3.3.1 IDE Device Installation (HDD, CD-ROM)
®
®
Primary
Secondary
IDE
This Motherboard offers two primary and secondary IDE device connectors (IDE1, IDE2). It can support up to four high-speed Ultra DMA 33/66/100HDD or CD-ROM.
Connect one side of the ATA66/100 flat cable to the IDE device (HDD or CD-ROM) and plug the other end to the primary (IDE1) or secondary (IDE2) directionally keyed IDE connector on the Motherboard. The ATA66/100 cable is backward compatible with ATA33 HDDs. This Motherboard can support up to four HDDs.
ATA 66/100
Flat Cable
1
1
28
Hardware Installation SY-7VCA2
SDRAM
SDRAM
33
33
2-3.3.2 Floppy Drive Installation
®
®
Pin -1
FDC
Floppy Drive
Connector
The system supports 5 possible floppy drive types: 720 KB, 1.2 MB,
1.44 MB, 2.88 MB, and LS-120. Connect one side of the 34-pin flat cable to the floppy drive and plug the other end to the floppy drive connector on the Motherboard. This Motherboard can support up to 2 floppy drives.
1
1
29
Hardware Installation SY-7VCA2
SDRAM
SDRAM
Power LED
Pin Assignment
GND
Speaker
LED
LED
+
+
+
_
_
2-3.3.3 Front Panel Connections
®
Power
LED
_
+
_
ResetPWRBT
®
Plug the computer case's front panel devices to the corresponding headers on the Motherboard.
1. Power LED
Please install according to the following pin assignment: pin 1,3 are for Power LED.
STR
HDD
+5V+5V
+
_
NCNC
30
Hardware Installation SY-7VCA2
Reset Pin Assignment
Power Good
GND
Speaker Pin Assignment
Speaker out
HDD LED Pin Assignment
LED Anode
LED Cathode
2. Reset
Plug the Reset push-button cable into the 2-pin Reset header on the Motherboard. Pushing the Reset button on the front panel will cause the system to restart the boot-up sequence.
1
3. Speaker
Attach the 4-pin PC speaker cable from the case to the Speaker header on the Motherboard.
_
+
+5V
4. IDE LED
Attach the 2-pin IDE device LED cable to the corresponding IDE LED header on the Motherboard. This will cause the LED to light up when an IDE (HDD, CD-ROM) device is active.
NC NC
+
_
31
Hardware Installation SY-7VCA2
PWRBT Pin Assignment
Power On/Off
GND
STR LED Pin Assignment
LED Anode
LED Cathode
5. ATX Power On/Off Switch
Attach the 2-pin momentary type switch to the PWRBT header for turning On or Off your ATX power supply.
1
6. STR LED
The STR LED is connected to the Voltage that feeds the DIMM sockets. Therefore the following table applies:
Suspend to RAM Normal Operation Power Off
STR LED ON ON OFF
_
+
32
Hardware Installation SY-7VCA2
SDRAM
SDRAM
PRT
PS/2 KB
Connector
PS/2 Mouse
MIC JACK
JOYSTICK
COM2
2-3.3.4 Back Panel Connections
All external devices such as the PS/2 keyboard, PS/2 mouse, printer, modem, USB can be plugged directly onto the Motherboard back panel.
Only after you have fixed and locked the Motherboard to the computer case can you start connecting the external peripheral devices.
When connecting an external device, use the following figure to locate and identify which back panel connector to plug the device to.
Connector
USB 1
COM 1
LINE-OUT LINE-IN
USB2
®
®
33
Hardware Installation SY-7VCA2
Pin5
KBD Clock
Pin5
Mouse Clock
1. Onboard Serial Ports COM1/COM2
External peripherals that use serial transmission scheme include:
- serial mouse,
- and modem. Plug the serial device cables directly into the COM1/COM2 9-pin male connectors located at the rear panel of the Motherboard.
2. Parallel Port PRT
This parallel port is used to connect the printer or other parallel devices. Plug the parallel device cable into the 25-pin female connector located at the rear panel of the Motherboard.
3. PS/2 Keyboard
Plug the keyboard jack directly into the 6-pin female PS/2 keyboard connector located at the rear panel of the Motherboard.
Pin6
NC
Pin4 VCC
Pin2
NC
Pin3
GND Pin1
KBD DATA
4. PS/2 Mouse
Similarly, plug the mouse jack directly into the 6-pin female PS/2 mouse connector.
Pin6
NC
Pin4 VCC
Pin2
NC
Pin3 GND
Pin1
Mouse DATA
34
Hardware Installation SY-7VCA2
1
5
None
(+)Data
(-)Data
USB2
USB2
5. Universal Serial Bus USB1 (2 Ports)/USB2 (2 Ports)
This Motherboard provides four USB ports for your additional devices. Plug the USB device jack into the available USB connector USB1 or USB2.
- Standard device drivers come with the Win98 for commonly used
USB devices.
- With Win95, use the flow UHCI specifications. To use USB devices
under Win95, usually you have to install the device that driver comes
with the USB device you have purchased. USB2 is available. To make use of these USB ports, purchase a USB cable from your dealer. The lay-out of USB2 is as follows:
GND GND
(+)Data
(-)Data
Power
6. Onboard Joystick port/audio
This Motherboard provides Joystick port and audio.
- Attach the joystick cable to the 15-pin JOYSTICK port at the rear
panel of you motherboard.
- This Motherboard features three built-in audio-stereo ports (labeled
line-in, line-out, and mic jack) convenient to directly plug-in all your
external audio devices.
10
9 8 7 6
35
4 3 2
GND
Power
Hardware Installation SY-7VCA2
MP-Wake-up
2-3.3.5 Other Connections
1. Wake-On-LAN (WOL)
Attach the 3-pin connector from the LAN card which supports the Wake­On-LAN (WOL) function to the JP10 header on the Motherboard. This WOL function lets users wake up the connected computer through the LAN card.
Please install according to the following pin assignment:
Wake-On-LAN
JP44 Pin Assignment
GND5VSB
1 2 3
36
Hardware Installation SY-7VCA2
Serial Infrared (IR1) Connector
2
3
4
5
IRTX
2. Infrared (IR1)
Plug the 5-pin infrared device cable to the IR1 header. This will enable the
infrared transfer function. This Motherboard meets both the ASKIR and HPSIR specifications. Please install according to the following pin assignment:
IR1 Pin Assignment
1
VCC
IRRX
GND
3. Other Display Cards
Insert other types of VGA cards into the PCI or ISA expansion slots according to card specifications.
37
Hardware Installation SY-7VCA2
CPU Cooling Fan
CPUFAN Pin Assignment
SENSOR
4. Cooling Fan Installation
(1) CPU Cooling Fan
After you have seated the CPU properly on the processor, attach the 3-pin fan cable to the CPUFAN connector on the Motherboard. The fan will stop when the system enters into Suspend Mode. (Suspend mode can be enabled from the BIOS Setup Utility, [POWER MANAGEMENT] menu.) To avoid damage to the system, install according to the following pin assignment:
132
12VGND
38
Hardware Installation SY-7VCA2
SENSOR
(2) Chassis Cooling Fan
Some chassis also feature a cooling fan. This Motherboard features a CHAFAN connector to provide 12V power to the chassis fan. Connect the cable from the chassis fan to the CHAFAN 3-pin connector. Install according to the following pin assignment:
Chassis Cooling Fan
CHAFAN Pin Assignment
132
12VGND
Note: CPUFAN must be installed for this Motherboard, CHAFAN is optional.
39
Hardware Installation SY-7VCA2
Right
CD Line-in)
Pin Assigment
Right
5. CD Line-in (CDIN1,CDIN2)
This Motherboard provides two CD-Line in connectors. Please connect the 4-pin audio cable from your CD-ROM drive to either CDIN1 or CDIN2. (It fits in only one, depending on the cable that came with your CD-ROM drive) Please install according to the following pin assignment:
CDIN1,CDIN2(
CDIN2
1234
GND
Left
GND
Left
CDIN1
2-3.3.6 AGP VGA Card
Insert the AGP VGA card into the AGP slot. Then connect the monitor information cable to the AGP card back plane external connector. Follow the manufacturer's instructions to perform the AGP VGA drivers installation.
GND
GND
1234
40
Hardware Installation SY-7VCA2
SDRAM
SDRAM
ATX Power
2-3.3.7 ATX Power Supply
Plug the connector from the power directly into the 20-pin male ATX PW connector on the Motherboard, as shown in the following figure.
®
®
Warning: Follow these precautions to preserve your Motherboard from any remnant currents when connecting to ATX power supply:
Turn off the power supply and unplug the power cord of the ATX power supply before connecting to ATX PW connector.
The Motherboard requires a power supply with at least 200 Watts and a "power good" signal. Make sure the ATX power supply can take at least 720 mA * load on the 5V Standby lead (5VSB) to meet the standard ATX specification.
* Note: If you use the Wake-On-LAN (WOL) function, make sure the ATX power supply can support at least 720 mA on the 5V Standby lead (5VSB).
41
Hardware Installation SY-7VCA2
3.3V
-12V
PS-ON
ATX Power
SDRAM
SDRAM
Please install the ATX power according to the following pin assignment:
12V
5VSB
PW-OK
GND
5V
GND
5V 5V
-5V GND GND
Ø Pay special care to the directionality.
GND
5V
GND
GND
3.3V
3.3V
2-3.3.8 AMR (Audio Modem Riser)Connector
This motherboard supports AMR (Audio-Modem Riser) slot that facilitates audio or modem riser card expansion. Since AC97 audio codec is built-in down on the motherboard, only “Secondary” mode modem riser (MR) card can be used on the AMR slot.
®
®
42
Hardware Installation SY-7VCA2
123
1
2
3
2-3.4 CMOS Clearing (JP5)
After you have turned off your computer, clear the CMOS memory by momentarily shorting pins 2-3 on jumper JP5, for a few seconds. Then restore JP5 to the initial 1-2 jumper setting in order to recover and retain the default settings. Jumper JP5 can be easily identified by its white colored cap.
CMOS
Clearing
JP5 Setting
Clear CMOS Data Retain CMOS Data
Short pin 2-3 for at least 5 seconds to clear the CMOS
Short pin 1-2 to retain new settings
Note: You must unplug the ATX power cable from the ATX power connector when performing the CMOS Clear operation.
2-3.5 Power On
You have now completed the hardware installation of your Motherboard successfully.
1. Turn the power on
2. To enter the BIOS Setup Utility, press the <DEL> key while the system
is performing the diagnostic checks,
Note: If you have failed to enter the BIOS, wait until the boot up sequence is completed. Then push the RESET button and press <DEL> key again at the beginning of boot-up, during diagnostic checks.
43
Hardware Installation SY-7VCA2
Repeat this operation until you get the following screen.
3. The BIOS Setup screen appears:
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
4Soyo Combo Feature 4PC Health Status 4Standard CMOS Features Load Optimized Defaults 4Advanced BIOS Features Load Fail - Safe Defaults 4Advanced Chipset Features Set Supervisor Password 4Integrated Peripherals Set User Password 4Power Management Setup Save & Exit Setup 4PnP/PCI Configurations Exit Without Saving
Esc : Quit áâàß : Select Item F10 : Save & Exit Setup
Change CPU’s Clock & Voltage
2-3.6 Quick BIOS Setup
This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead, CPU settings are software configurable with the BIOS [SOYO COMBO SETUP]. The [SOYO COMBO SETUP] menu combines the main parameters that you need to configure, all in one menu, for a quick setup in BIOS. After the hardware installation is complete, turn the power switch on, then press the <DEL> key during the system diagnostic checks to enter the Award BIOS Setup program. The CMOS SETUP UTILITY will display on screen. Follow these steps to configure the CPU settings.
44
Hardware Installation SY-7VCA2
Step 1. Select [STANDARD CMOS SETUP]
Set [Date/Time] and [Floppy drive type], then set [Hard Disk Type] to “Auto”.
Step 2. Select [LOAD SETUP DEFAULT]
Select the “LOAD SETUP DEFAULT” menu and type “Y” at the prompt to load the BIOS optimal setup.
Step 3. Select [SOYO COMBO SETUP]
Move the cursor to the [CPU Frequency] field to set the CPU frequency. Available [CPU Frequency] settings on your SY-7VCA2 Motherboard are
detailed in the following table. If you set this field to [Manual], you are then required to fill in the next
two consecutive fields: (1) the CPU Host/PCI Clock, and (2) the CPU Ratio.
CPU Frequency (MHz) 667MHz (66 x 10.0) 600MHz (133 x 4.5)
Manual 700MHz (66 x 10.5) 666MHz (133 x 5.0) 400MHz (66 x 6.0) 500MHz (100 x 5.0) 733MHz (133 x 5.5) 433MHz (66 x 6.5) 550MHz (100 x 5.5) 800MHz (133 x 6.0)
466MHz (66 x 7.0) 600MHz (100 x 6.0) 866MHz (133 x 6.5)
500MHz (66 x 7.5) 650MHz (100 x 6.5) 933MHz (133 x 7.0) 533MHz (66 x 8.0) 700MHz (100 x 7.0) 1000MHz (133 x 7.5) 566MHz (66 x 8.5) 750MHz (100 x 7.5) 1.13GHz (133 x 8.5) 600MHz (66 x 9.0) 800MHz (100 x 8.0) 633MHz (66 x 9.5) 850MHz (100 x 8.5)
Select the working frequency of your Pentium® & CeleronTM processor & VIA Cyrix processor among these preset values.
Note: Mark the checkbox that corresponds to the working frequency of your Pentium® III, Celeron processor in case the CMOS configuration should be lost.
Step 4. Select [SAVE & EXIT SETUP]
Press <Enter> to save the new configuration to the CMOS memory, and continue the boot sequence.
45
Hardware Installation SY-7VCA2
2-3.7 Troubleshooting at First Start
Video (no display) related issues
I built a new computer system using a Soyo board and nothing happens when turning it on, no video and no beeps from the PC speaker. What is happening and how can it be fixed?
No screen and no beeps mean that your CPU and motherboard do not work at all. It could be that the CPU is not seated correctly or that a component on the M/B is grounded (shorted) with the case. Also make sure to check the voltage setting switch (110V/220V) on the back of the power supply. To isolate the problem do the following:
1. Press and hold down on the “Ins” (insert) key while turning on the computer until you get video. If you do not get video then,
2. Double-check jumpers setting on you motherboard and remove all add-on cards, unplug all hard-disk and floppy-disk drive cables and see if you can hear some beeps. If you still do not get any beeps, then try putting the motherboard on the table (to isolate it from the case) with the CPU and speaker only, and give it one more try.
I hear a series of beeps and I do not get anything from my monitor. What could be wrong?
The following lists some basic beep codes and their possible meanings:
One long beep and 3 very short beeps - The video card is not
detected by the motherboard. Please re-seat your video card. If you are using an AGP card, please push your AGP card down real hard. You may have to push VERY hard without the AGP card mounting screw. Make sure not to insert the card the other way around.
Continuous beeps – One or more of the memory modules is not
seated correctly in its socket.
46
Hardware Installation SY-7VCA2 My PCI VGA card works fine with my system, but when I put in a
new AGP card, it does not give me any video. Is my AGP slot bad?
This is a common problem with AGP video cards. The reason is that your AGP card did not get seated into the AGP slot fully and firmly. Please push your AGP card down into the socket real hard, it should snap twice. You may have to unscrew the AGP card to allow the card to go further down. Do take care not to damage the card by using too much force.
I get distorted video my AGP card right after I save my bios. Why is that?
The cause is likely that your AGP card is not running at the correct bus speed. To fix this, please clear the CMOS via JP5 and if it still does not work, please upgrade your motherboard bios to the latest version.
BIOS Issues
Where can I find the BIOS revision of my mainboard?
It will be displayed on the up-left corner on the screen during boot-up. It will show as your board type followed by the revision number, such as 5EH_2CA1 (meaning revision 2CA1 for the SY-5EH board) or 6BA+ IV_2AA2 which means SY-6BA+ IV motherboard with 2AA2 bios.
Where can I find the latest BIOS of my motherboard?
Please go to the technical support page of one of the SOYO websites (Taiwan: www.soyo.com.tw), and look up your motherboard to find the latest BIOS revision.
Hard disk, floppy drive, CD-ROM etc
When I boot up my new computer I got "floppy boot failure" and the LED on the floppy stays on
Make sure the red wire of floppy ribbon cable goes to Pin1 on the floppy drive side (don't trust the "key lock" or "notch") and use the end-connector of the cable (don't use middle one).
Modem issues
I get an "I/O Conflict" message when I turn on my system and I can not get my modem to work
47
Hardware Installation SY-7VCA2
What you need to do is to disable 'COM2' (or UART2 or serial port 2) in the bios under integrated peripheral setup.
I have installed my modem drivers several times and I still cannot get my modem to work. Why?
If you are sure that the modem driver has been installed correctly, then you need to install the south bridge driver from the SOYO CD, this is because Windows does not properly recognize relatively new chipsets.
Audio Issues
I do not get any sound from my sound card. What could be wrong?
Please make sure the speaker is connected to the speaker out port on your sound card.
In Device Manager, I keep getting yellow exclamation signs on my sound port even though I have installed my sound driver several times and I could not get my sound card to work. What is wrong?
It is likely that you did not have the correct driver installed. If you are sure that the correct sound driver has been installed, then please install the 'south bridge' driver for the motherboard.
The sound is working in my system, but when I play CD music from the CD-ROM, I do not get any sound. What is wrong?
This is because the 3-wire audio cable from the CD-ROM to the sound card is not connected or it is loose.
The sound from my sound card is distorted when Windows starts. What is wrong?
First, if you are using an ISA sound card, please make sure the IRQ needed for the sound card is set to 'Legacy ISA' in the bios. In other words, if your ISA sound card takes IRQ5, then set IRQ5 to 'Legacy ISA'. Next, install the 'south bridge' driver for the motherboard.
The sound and everything else works fine except that the recorder and microphone do not work. What is wrong?
48
Hardware Installation SY-7VCA2
This is because the recorder and microphone in the Windows are not enabled. Please go to sound properties and enable them.
Lock up (freeze)
When I boot up my system, everything works fine. It sees my CPU and memory, detects my hard drive, floppy drive and CD-ROM but locks up at "Verify DMI pool data... ", and it won’t go any further. What should I do?
Please clear the CMOS via JP5 then choose 'load setup default' in the bios and save the bios and exit. Next, unplug all other add-on cards except the video card and floppy drive controller, and see if it can boot from floppy. Then put back the peripherals one by one to identify which one causes the lockup. If you are running a Cyrix CPU, make sure the 'linear burst function' is enabled in the bios.
I can not get my board to run properly.
Please make sure you have the latest bios and driver from the SOYO web site at: http://www.soyo.com
2-3.8 Power Off
There are two possible ways to turn off the system:
1. Use the Shutdown command in the Start Menu of Windows 95/98
to turn off your computer.
2. Press the mechanical power-button and hold down for over 4
seconds, to shutdown the computer. If you press the power-button for less than 4 seconds, then your system will enter into Suspend Mode.
49
Hardware Installation SY-7VCA2
L
save space. At boot-up this code is decompressed and stored to RAM for faster
If the VGA card does not work or is not inserted at all, the system will display
At this point the BIOS is initializing the CPU. The L2 cache latency values are
show the BIOS testing the RAM by a running counter. After finishing the test,
This includes HD drives and ATAPI CD-ROM drives that are connected to the
The serial and parallel port registers are set to the values selected by the user.
At this point the BIOS passes control to the Operating System (OS). All LEDs
2-3.9 Debug LEDs
The Debug LEDs give an indication of the status of the system during boot-up. If the system does not boot-up properly, use the table below to find out at what point in boot-up sequence the problem arises. A x means the LED is off, a L means the LED is lit.
Code Explanation
X X X
D8 D3 D2 D1
X X L X
D8 D3 D2 D1
X X L L
D8 D3 D2 D1
X L X X
D8 D3 D2 D1
X L X L
D8 D3 D2 D1
X L L X
D8 D3 D2 D1
X L L L
D8 D3 D2 D1
L X X X
D8 D3 D2 D1
L X X L
D8 D3 D2 D1
L X L X
D8 D3 D2 D1
L X L L
D8 D3 D2 D1
L L X X
D8 D3 D2 D1
L L X L
D8 D3 D2 D1
L L L X
D8 D3 D2 D1
L L L L
D8 D3 D2 D1
Initialization of the chipset. The North-Bridge and South-Bridge registers will be set to the most conservative values by the BIOS to make sure the system boots up properly.
The BIOS is now decompressing the BIOS code into shadow RAM. Most of the BIOS code is stored in the BIOS Flash ROM IC in compressed form to
execution. The checksum for the decompressed code is calculated and checked. The
checksum is calculated by adding all data bytes together and storing the result in the BIOS ROM. If the calculated checksum is different from the checksum stored in the ROM, the code stored in the FLASH ROM is corrupted.
The chipset (North-Bridge and South-Bridge) registers are set to the values selected by the user.
Now the BIOS will set the CPU Vcore voltage and the FSB bus frequency to the user selected value. If the system stops at this point, the settings selected by the user are inappropriate. Please select more conservative settings.
The Hardware Monitor Functionality is initialized. The settings the user selected in the BIOS for the Hardware Monitor are written into the Hardware Monitor registers.
this code for a short period of time.
set, and more important, the CPU micro-code is written into the CPU. Now the system is testing the RAM inserted on the board. The screen will
the screen will show the amount of RAM in your system. The super I/O registers are set to the default values. This includes the serial,
parallel and IR etc settings. At this point the IDE busses (primary and secondary) are scanned for devices.
IDE bus. After scanning the detected devices are displayed on screen.
Now the BIOS will scan the peripheral busses for add-on cards. This includes the PCI and AGP busses. If any add-on cards are detected, the resources it requires are assigned by the BIOS in accordance with user settings.
The ESCD and DMI (Desktop Management Interface) values are checked. If there are changes, the BIOS will flash the new values into the BIOS Flash ROM IC.
will be on and will stay on to indicate a successful boot.
50
Hardware Installation SY-7VCA2
You are now ready to configure your system with the BIOS setup program. Go to Chapter 3: BIOS SETUP
51
BIOS Setup Utility SY-7VCA2
Chapter 3
BIOS SETUP UTILITY
This Motherboard's BIOS setup program uses the ROM PCI/ISA BIOS program from Award Software Inc. To enter the Award BIOS program's Main Menu:
1. Turn on or reboot the system.
2. After the diagnostic checks, press the [Del] key to enter the Award
BIOS Setup Utility.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
4Soyo Combo Feature 4PC Health Status 4Standard CMOS Features Load Fail - Safe Defaults 4Advanced BIOS Features Load Optimized Defaults 4Advanced Chipset Features Set Supervisor Password 4Integrated Peripherals Set User Password 4Power Management Setup Save & Exit Setup 4PnP/PCI Configurations Exit Without Saving
Esc : Quit áâàß : Select Item F10 : Save & Exit Setup
Change CPU’s Clock & Voltage
Selecting items
l Use the arrow keys to move between items and select fields. l From the Main Menu press arrow keys to enter the selected submenu.
Modifying selected items
l Use the [Up]/[Down] keys to modify values within the selected fields.
Some fields let you enter values directly.
52
BIOS Setup Utility SY-7VCA2 Hot Keys: Function keys give you access to a group of commands
throughout the BIOS utility.
Function Command Description
F1
F5
F6
General Help Previous
Values Load Fail­Safe Defaults
Gives the list of options available for each item. Restore the old values. These are the values that the user started the current session with. Loads all items with the most conservative values.
Load
F7
Optimized
Loads all options with the optimize values.
Defaults
F10
[Esc] Exit
[Enter]
Save Saves your changes and reboots the system.
Returns at anytime and from any location to the Main Menu.
Select
Will display a overlapping window with all options for the current item. Using the +, –, Page Up and Page Down
[+/–/PU/PD] Value
keys the user can toggle the value of the current item.
53
BIOS Setup Utility SY-7VCA2
Esc
F10
(Shift) F2
Esc
F10
(Shift) F2
SAVE AND EXIT SETUP
Select the [SAVE & EXIT SETUP] option from the Main Menu to save data to CMOS and exit the setup utility. This option saves all your changes and causes the system to reboot.
ROM PCI/ISA BIOS
CMOS SETUP UTILITY
STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION LOAD SETUP DEFAULTS LOAD BIOS DEFAULTS
: Quit : Save & Exit Setup
AWARD SOFTWARE, INC.
SAVE to CMOS and EXIT
Time, Date, Hard Disk Type…
INTEGRATED PERIPHERALS SUPERVISOR PASSWORD USER PASSWORD IDE HDD AUTO DETECTION SAVE & EXIT SETUP EXIT WITHOUT SAVING
↑ ↓ → ←
: Select Item : Change Color
Type [Y] to save the changes and exit or [N] to return to the Main Menu and keep current values.
EXIT WITHOUT SAVING
Selecting the [EXIT WITHOUT SAVING] option allows you to abandon all data and exit setup, therefore ignoring all your changes.
ROM PCI/ISA BIOS
CMOS SETUP UTILITY
STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION LOAD SETUP DEFAULTS LOAD BIOS DEFAULTS
: Quit : Save & Exit Setup
AWARD SOFTWARE, INC.
Quit Without Saving (Y/N)? _
Time, Date, Hard Disk Type…
INTEGRATED PERIPHERALS SUPERVISOR PASSWORD USER PASSWORD IDE HDD AUTO DETECTION SAVE & EXIT SETUP EXIT WITHOUT SAVING
↑ ↓ → ←
: Select Item : Change Color
Type [Y] to abandon changes and exit or [N] to return to the Main Menu and keep current values.
54
BIOS Setup Utility SY-7VCA2
3-1 SOYO COMBO SETUP
This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead, CPU settings are software configurable with the BIOS
[SOYO COMBO SETUP].
After the hardware installation is complete, turn the power switch on, then press the <DEL> key during the system diagnostic checks to enter the Award BIOS Setup program. The CMOS SETUP UTILITY will display on screen. Then, select the [SOYO COMBO SETUP] option from the main menu and press the <Enter> key.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
Soyo Combo Feature
CPU/PCI Frequency HW Default CPU Ratio X 3 Auto detect DIMM/PCI Clk Enabled Spread Spectrum Disabled
C.I.H. 4-WAY Protection Enabled CPU L2 Latency Control Default
x CPU L2 Latency Value 0
CPU L2 Cache ECC Checking Enabled Processor Number Feature Disabled Vcore Voltage Adjust Normal Quick Power On Self Test Enabled
First Boot Device Floppy Second Boot Device HDD-0 Third Boot Device LS/ZIP Boot Other Device Enabled
OnChip Sound Auto OnChip Modem Auto
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
Menu Level 4
Item Help
The [SOYO COMBO SETUP] menu combines the main parameters that you need to configure, all in one menu, for a quick setup in BIOS.
55
BIOS Setup Utility SY-7VCA2
3-1.1 Quick CPU Frequency Setup
Quick CPU Frequency Setup
Setting Description Note
CPU Host/PCI Clock
CPU Ratio
Auto Detect DIMM/PCI Clk
HW Default 120/40 MHz 66/33 MHz 124/31 MHz 68/34 MHz 126/31 MHz 75/37 MHz 129/32 MHz 80/40 MHz 133/33 MHz 83/41 MHz 135/33 MHz 85/28 MHz 138/34 MHz 90/30 MHz 140/35 MHz 95/31 MHz 141/35 MHz 100/33 MHz 143/35 MHz 103/34 MHz 145/36 MHz 105/35 MHz 147/36 MHz 109/36 MHz 150/37 MHz 112/37 MHz 154/38 MHz 114/38 MHz 160/40 MHz 115/38 MHz 166/41 MHz 118/39 MHz
After you have selected the host clock, choose the right multiplier for the CPU. Options are: [2, 2.5, 3., 3.5, 4, 4.5, 5,
5.5,6,6.5,7.0,7.5,8.0]. The CPU frequency is then defined as [host clock freq.]x[multiplier], and should the working frequency of your Pentium® III & Pentium® II processor.
Disabled Enabled
When enabled, this item will auto detect if the DIMM and PCI socket have devices and will send clock signal to DIMM and PCI devices. When disabled, it will send the clock signal to all DIMM and PCI socket.
Select the host clock of your Socket 370 processor among these values. Note: For the Via 694X chipset, 66 and 100 and 133 MHz host clock frequencies are acceptable. However, the system stability is not guaranteed for other frequencies due to the limitations of this chipset.
Default
Spread Spectrum
Disabled Default Enabled
This item allows you to enable/disable the spread spectrum modulate.
56
BIOS Setup Utility SY-7VCA2
3-1.2 C.I.H. 4-WAY Protection Settings
Setting Description Note
C.I.H. 4­WAY Protection
Disabled Enabled
When set to enabled, the BIOS can only be programmed through AWDFLASH, making sure that any virus is unable to program the system BIOS. Set to disable the BIOS can be programmed the traditional way.
3-1.3 L2 Cache Memory
Setting Description Note
CPU L2 Latency Control
CPU L2 Latency Value
Default Default Manual
1~15 If the item above is set to
Default
If set to Default, the CPU default value for L2 cache latency is used. If set to manual, the ‘Latency Value’ item will allow you to specify a latency value.
‘manual’ , a latency value ranging from 1 to 15 can be set. The smaller the number, the faster the performance. However, the system may become unstable at higher speeds.
CPU L2 Cache ECC Checking
Disabled
Enabled This option activates the CPU
L2 cache ECC checking function.
57
Default
BIOS Setup Utility SY-7VCA2
core voltage. If the Vcore Voltage Adjust is set to
than the VID code specifies. For instance the CPU
3-1.4 Processor Number Feature
Setting Description Note
Processor Number Feature
Disabled Default Enabled
Setting this item to enabled will allow application programs to read the ID­code in your Pentium III CPU, disabling this item will not allow any program to read the CPU ID code.
3-1.5 Vcore voltage Setup
Vcore voltage Setup
Vcore voltage Adjust
Setting Description Note
Normal Default +1.5 % +3.0 % +4.5 % +6.0 % +7.5 % +9.0 % +10.0%
The CPU notifies the board of what core voltage it requires by its VID outputs. The on-board voltage regulator uses the VID code to set the
normal, the Vcore will be exactly what the VID code specifies. If an adjustment percentage is selected the Vcore will be that percentage higher
VID code specifies 2.0V and the Vcore Voltage adjust is set to +10.0% the actual CPU Voltage will be 2.2V. This function should only be used if the CPU is running on FSB Frequencies beyond the CPU specifications, note that SOYO does not guarantee system stability if this item is not set to normal.
3-1.6 Quick Power On Self Test
Setting Description Note
Quick Power On Self Test
Disabled Enabled Provides a fast POTS at boot-up. Default
58
BIOS Setup Utility SY-7VCA2
3-1.7 System Boot Control Settings
System Boot Control Settings
Setting Description Note
First /Second/Third Boot Device
Boot Other Device
OnChip Sound/Modem
Floppy LS/ZIP HDD-0 SCSI CDROM HDD-1 HDD-2 HDD-3 LAN Disabled
Disabled Enabled
Disabled Auto
Select Your Boot Device Priority
Select Your Boot Device Priority
This item allows you to control the onboard AC 97 audio/ MC 97 Modem.
Default
Default
59
BIOS Setup Utility SY-7VCA2
3-2 STANDARD CMOS SETUP
Select the [STANDARD CMOS SETUP] option from the Main Menu and press [Enter] key.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
Standard CMOS Features
Date (mm:dd:yy) Fri, Jan 1 1999 Time (hh:mm:ss) 1 : 22 : 12
4 IDE Primary Master Press Enter None 4 IDE Primary Slave Press Enter None 4 IDE Secondary Master Press Enter None 4 IDE Secondary Slave Press Enter None
Drive A 1.44M, 3.5 in. Drive B None Floppy 3 Mode Support Disabled
Video EGA/VGA Halt On All Errors
Base Memory 640K Extended Memory 30720K Total Memory 31744K
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
Menu Level 4
Item Help
This screen allows you to modify the basic CMOS settings. After you have completed the changes, press [Esc] key to return to the Main Menu.
3-2.1 Date & Time
Display Setting Please Note
Date
mm/dd/yyyy Type the current date You can also the
PUp/PDn keys to toggle
Time
hh:mm:ss Type the current time 24-hour clock format
3:15 PM is displayed as 15:15:00
60
BIOS Setup Utility SY-7VCA2
3-2.2 Hard Disks Type & Mode
Choose the type and mode for the hard disks that you have already installed.
Primary (Secondary) Master & Slave
Setting Description Note
IDE HDD Auto­Detection
IDE Primary Slave (User Type)
Press Enter
Auto BIOS detects hard disk type
User User defines the type of hard disk.
To auto-detect the HDD’s size, head… on this channel
automatically.
None
Access Mode
Auto BIOS detects hard disk mode
automatically. Normal Normal IDE hard disk <528MB LBA Enhanced IDE hard disk >528MB Large Large IDE hard disk (for certain
hard disk)
Note: If you have any questions on your hard disk type or mode, ask your hard disk provider or previous user for details.
3-2.3 Floppy Drives
Floppy Drives Setting Description Note Drives A & B
360KB, 5.25 in.
1.2MB, 5.25 in. 720KB, 3.5 in.
1.44MB, 3.5 in. Default
2.88MB, 3.5 in. None Not installed
Default
Default
Floppy 3-Mode Support
Disabled Default Drive A Drive B Both
Supports 3-mode floppy diskette: 740KB/1.2MB/
1.44MB on selected disk drive.
Special disk drive commonly used in Japan
61
BIOS Setup Utility SY-7VCA2
3-2.4 Others Optional
Setting Description Note
Video
Halt On
EGA/VGA Default CGA 40 CGA 80 MONO (Monochrome)
ALL Errors Default No Errors All, But Keyboard All, But Diskette All, But Disk/Key
Select the video mode.
When the BIOS detects system errors, this function will stop the system. Select which type of error will cause the system halt.
62
BIOS Setup Utility SY-7VCA2
3-3 ADVANCED BIOS FEATURES
Select the [Advanced BIOS Features] option from the Main Menu and press [Enter] key.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
Advanced BIOS Features
Anti-Virus Protection Disabled CPU Internal Cache Enabled External Cache Enabled Swap Floppy Drive Disabled Boot Up Floppy Seek Enabled Boot Up NumLock Status On Gate A20 Option Fast
Typematic Rate Setting Disabled
x Typematic Rate (Chars/Sec) 6 x Typematic Delay (Msec) 250
Security Option Setup
OS Select For DRAM > 64MB Non-OS2
Report No FDD For WIN 95 Yes
Video BIOS Shadow Enabled
C8000-CBFFF Shadow Disabled
CC000-CFFFF Shadow Disabled
D0000-D3FFF Shadow Disabled
D4000-D7FFF Shadow Disabled
D8000-DBFFF Shadow Disabled
DC000-DFFFF Shadow Disabled
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level 4
After you have completed the changes, press [Esc] key and follow the instructions on your screen to save your settings or exit without saving.
63
BIOS Setup Utility SY-7VCA2
3-3.1 Virus Warning
Setting Description Note
Anti - Virus Protection
Disabled Default Enabled
If set to enabled, the Paragon Anti­Virus. Function will scan your boot drive for boot virusses. If a boot virus is detected, the BIOS will display a warning message.
3-3.2 Cache Memory Options
Setting Description Note
CPU Internal Cache
External Cache
Disabled Enabled Enables the CPU's internal
Disabled Enabled Enables the external
3-3.3 Floppy Driver Settings
Setting Description Note
Swap Floppy Drive
Disabled Default Enabled Changes the sequence of A and B
drives.
Default
cache.
Default
memory.
3-3.4 Boot Up Floppy Seek
Setting Description Note
Boot Up Floppy Seek
Disabled Seeks disk drives during boot up.
Disabling speeds boot up.
Enabled Default
3-3.5 Boot Up NumLock Status
Setting Description Note
Boot Up NumLock Status
On Puts numeric keypad in
NumLock mode at boot-up.
Off Puts numeric keypad in arrow key
mode at boot-up.
64
Default
BIOS Setup Utility SY-7VCA2
3-3.6 Gate A20 Options
Setting Description Note
Gate A20 Options
Normal Lets chipset control GateA20. Fast A pin in the keyboard controller
Default
controls GateA20.
3-3.7 Typematic Settings
Typematic Settings Setting Description Note Typematic
Rate Setting
Disabled Keystrokes repeat at a rate
determined by the keyboard.
Enabled When enables , the
typematic rate and typematic delay can be selected.
The following [Typematic Rate] and [Typematic Delay] fields are active only if [Typematic Rate Setting] is set to [Enabled]
Typematic Rate
6 (Char/sec) 8 (Char/sec) 10 (Char/sec) 12 (Char/sec) 15 (Char/sec) 20 (Char/sec) 24 (Char/sec) 30 (Char/sec)
Choose the rate at which a character is repeated when holding down a key.
Default
Default
Typematic Delay
250 (msec) 500 (msec) 750 (msec) 1000 (msec)
Choose how long after you press a key down the character begins repeating.
65
Default
BIOS Setup Utility SY-7VCA2
3-3.8 Security Option
Use this feature to prevent unauthorized system boot-up or use of BIOS Setup. The following table describes the security settings.
Setting Description
Security Option
System Each time the system is booted, the
password prompt appears.
Setup If a password is set, the password prompt
only appears when you attempt to enter the BIOS Setup program.
3-3.9 Other Control Options
Other Control Options
Setting Description Note
OS Select for DRAM>64MB
Report No FDD For WIN 95
Video BIOS Shadow
OS2 When using an OS2 operating
system.
Non-OS2 When using another,
non-OS2 operating system.
Yes Windows will release IRQ line 6
(normally used by the Floppy Disk Drive) after you disable your on-board FDD and set this field to [Yes].
No Windows will reserve INT 6 for
your FDD, whether it is disabled or not.
Disabled Enabled The BIOS is shadowed in a 16K segment if it is enabled and if it has BIOS present. These 16 segments can be shadowed from ROM to RAM. BIOS shadow copies BIOS code from slower ROM to faster RAM. BIOS can then execute from RAM.
Default
Default
Default
66
BIOS Setup Utility SY-7VCA2
3-4 ADVANCED CHIPSET FEATURES
Caution: Change these settings only if you are already familiar with the Chipset.
The [Advanced Chipset Features] option changes the values of the chipset registers. These registers control the system options in the computer.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
Advanced Chipset Features
Bank 0/1 DRAM Timing SDRAM 8/10ns Bank 2/3 DRAM Timing SDRAM 8/10ns Bank 4/5 DRAM Timing SDRAM 8/10ns DRAM Clock Host CLK SDRAM Cycle Length 3 Bank Interleave 4 Bank Memory Hole Disabled P2C/C2P Concurrency Enabled Fast R-W Turn Around Enabled CPU In Order Queue Size 4 Level System BIOS Cacheable Disabled Video RAM Cacheable Disabled AGP Aperture Size 64M AGP-4X Mode Enabled AGP Driving Control Auto
x AGP Driving Value DA
AGP Fast Write Disabled OnChip USB Enabled USB Keyboard Support Disabled CPU to PCI Write Buffer Enabled PCI Dynmic Bursting Enabled PCI Master 0 WS Write Enabled PCI Delay Transaction Enabled PCI#2 Access #1 Retry Enabled AGP Master 1 WS Write Disabled AGP Master 1 WS Read Disabled Memory Parity/ECC Check Disabled 6
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
5
Menu Level 4
Item Help
67
BIOS Setup Utility SY-7VCA2
After you have completed the changes, press [Esc] and follow the instructions on your screen to save your settings or exit without saving. The following table describes each field in the Advanced Chipset Features Menu and how to configure each parameter.
3-4.1 CHIPSET FEATURES SETUP
CHIPSET FEATURES
Setting Description Note
Bank 0/1, 2/3, 4/5 DRAM Timing
DRAM Clock
SDRAM Cycle Length
Bank Interleave
Memory Hole
SDRAM 8/10ns SDRAM 8ns Normal
This item allows you to select the value in this field, depending on whether the board has paged DRAMs or EDO (extended data output) DRAMs.
Default
Medium Fast Turbo
Host Clock Default
HCLK-33M
HCLK+33M
This item allows you to control the DRAM speed.
2
When synchronous DRAM is
3
installed, the number of clock cycles
Default
of CAS latency depends on the DRAM timing. Do not reset this field from the default value specified by the system designer.
4 Bank Increase DRAM performance. Default Disabled 2 Bank
Disabled Default Enabled Some interface cards will map their
ROM address to this area. If this occurs, select [Enabled] in this field.
P2C/C2P Concurrency
Disabled Enabled
This item allows you to enable/disable the PCI to CPU, CPU to PCI concurrency
68
Default
BIOS Setup Utility SY-7VCA2
CHIPSET FEATURES SETUP (Continued)
CHIPSET FEATURES
Setting Description Note
Fast R-W Turn Around
CPU In Order Queue Size
System BIOS Cacheable
Video RAM Cacheable
AGP Aperture Size
Disabled Enabled
4 Level Default 1 Level
Disabled Enabled The ROM area F0000H-FFFFFH is
Disabled Default Enabled
64M Default 4M, 8M, 16M, 32M, 128M, 256M.
This item controls the DRAM timing. It allows you to enable/ disable the fast read/write turn around.
This item is related to cache performance. A queue size of 4 gives highest performance.
cacheable. When synchronous DRAM is
installed, the number of clock cycles of CAS latency depends on the DRAM timing. Do not reset this field from the default value specified by the system designer
Select the size of Accelerated Graphics Port (AGP) aperture. The aperture is a portion of the PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are forwarded to the AGP without any translation.
Default
Default
AGP-4X Mode
AGP Driving Control
Disabled Enabled
Auto Default Manual
This item allows you to enable / disable the AGP-4X Mode.
This item allows you to adjust the AGP driving force. Choose Manual to key in a AGP Driving Value in the next selection. This field is recommended to set in Auto for avoiding any error in your system.
69
Default
BIOS Setup Utility SY-7VCA2
CHIPSET FEATURES SETUP (Continued)
CHIPSET FEATURES
Setting Description Note
AGP Driving Value
AGP Fast Write
OnChip USB
USB Keyboard Support
CPU to PCI Write Buffer
Min=0000 ~ Max=00FF
Disabled Default Enabled
Disabled Enabled
Disabled Default Enabled Select Enabled if your system
Disabled Enabled
This item allows you to adjust the AGP driving force.
The VIA chipset will use fast write to AGP if this item is enabled. Not all AGP cards support fast write.
This should be enabled if your system has a USB installed on the system board and you want to use it. Even when so equipped, if you add a higher performance controller, you will need to disable this feature.
contains a Universal Serial Bus (USB) controller and you have a USB keyboard.
When this field is Enabled, writes from the CPU to the PCI bus are buffered, to compensate for the speed differences between the CPU and the PCI bus. When Disabled, the writes are not buffered and the CPU must wait until the write is complete before starting another write cycle.
Default
Default
PCI Dynmic Bursting
Disabled Enabled
When Enabled, every write transaction goes to the write buffer. Burstable transactions then burst on the PCI bus and nonburstable transactions don’t.
70
Default
BIOS Setup Utility SY-7VCA2
CHIPSET FEATURES SETUP (Continued)
CHIPSET FEATURES
Setting Description Note
PCI Master 0 WS Write
PCI Delay Transaction
PCI#2 Access #1 Retry
AGP Master 1 WS Write
AGP Master 1 WS Read
Disabled Enabled When Enabled, writes to the PCI
bus are executed with zero wait states.
Disabled Enabled
Disabled Enabled
Disabled Default Enabled When Enabled, writes to the
Disabled Default Enabled When Enabled, read to the AGP
The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI specification version 2.1.
When disabled, PCI#2 will not be disconnected until access finishes (difault). When enabled, PCI#2 will be disconnected if max retries are attempted without success.
AGP(Accelerated Graphics Port) are executed with one wait states.
(Accelerated Graphics Port) are executed with one wait states.
Default
Default
Default
Memory Parity/ECC Check
Disabled Default Enabled This item enabled to detect the
memory parity and Error Checking & Correcting.
71
BIOS Setup Utility SY-7VCA2
3-5 INTEGRATED PERIPHERALS
Caution: Change these settings only if you are already familiar with the Chipset.
The [INTEGRATED PERIPHERALS] option changes the values of the chipset registers. These registers control the system options in the computer. The following screen shows setup default settings.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
Integrated Peripherals
OnChip IDE Channel0 Enabled
OnChip IDE Channel1 Enabled
IDE Prefetch Mode Enabled
Primary Master PIO Auto
Primary Slave PIO Auto
Secondary Master PIO Auto
Secondary Slave PIO Auto
Primary Master UDMA Auto
Primary Slave UDMA Auto
Secondary Master UDMA Auto
Secondary Slave UDMA Auto
Init Display First PCI Slot
IDE HDD Block Mode Enabled
Onboard FDD Controller Enabled
Onboard Serial Port 1 3F8/IRQ4
Onboard Serial Port 2 2F8/IRQ3
UART 2 Mode Standard
x IR Function Duplex Half x TX,RX inverting enable No, Yes
Onboard Parallel Port 378/IRQ7
Onboard Parallel Mode Normal
x ECP Mode Use DMA 3 x Parallel Port EPP Type Epp1.9
Onboard Legacy Audio Enabled
Sound Blaster Disabled
SB I/O Base Address 220H
SB IRQ Select IRQ 5
SB DMA Select DMA 1
MPU-401 Disabled
MPU-401 I/O Address 330-333H
Game Port (200-207H) Enabled 6
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
5
Menu Level 4
Item Help
72
BIOS Setup Utility SY-7VCA2
The following tables describe each field in the INTEGRATED PERIPHERALS Menu and provide instructions on how to configure the IDE controls, FDC controls, and the onboard serial and parallel ports.
3-5.1 IDE Device Controls
IDE Controls Setting Description Note On-Chip PCI IDE
Ø Primary Ø Secondary
IDE
Ø Primary Master PIO Ø Primary Slave PIO Ø Secondary Master PIO
Ø Secondary Slave PIO
Disabled Turn off the on-board
IDE
Enabled Use the on-board IDE Default mode 0-4 0 is the slowest speed
4 is the fastest speed
Auto For better performance
Default and stability, we suggest you use the Auto setting to set the HDD control timing.
IDE
Ø Primary Master UDMA Ø Primary Slave UDMA Ø Secondary Master UDMA Ø Secondary Slave UDMA
Disabled Auto Select Auto to enable
Ultra DMA Mode support.
Default
3-5.2 Keyboard Controls
Keyboard Controls Setting Description Note Init Display First
PCI Slot Default AGP
Choose which card – AGP Display card or PCI VGA card – to initialize first.
3-5.3 IDE HDD Block Mode
Setting Description Note
IDE HDD Block Mode
Disabled Enabled Invokes multi-sector
Default transfer instead of one sector per transfer. Not all HDDs support this function.
73
BIOS Setup Utility SY-7VCA2
3-5.4 FDC Controls
FDC Controls Setting Description Note Onboard FDD
controller
Disabled Turn off the on-board
floppy controller
Enabled Use the on-board floppy
controller
3-5.5 Onboard Serial Ports
Onboard Serial Ports
Onboard Serial Port 1 / Serial Port 2
UART 2 Mode
If [UART Mode Select] is set to [IrDA]/[ASKIR]
IR Function Duplex
Setting Description Note
Disabled 3F8/IRQ4 Default
2F8/IRQ3 Default
3E8/IRQ4 2E8/IRQ3 Auto
Standard Default HPSIR ASKIR
Half Default Full
Choose serial port 1 & 2's I/O address. Do not set port 1 & 2 to the same address except for Disabled or Auto.
The second serial port offers these InfraRed interface modes.
Choose [Half] or [Duplex] to set UR2 in half duplex mode or full duplex mode respectively. Refer to your IR device specifications to select the suitable mode.
Default
(port 1)
(port 2)
TX,RX inverting enable
No,Yes Default No, No/ Yes, No/ Yes, Yes.
This item allow you to enable the TX, RX inverting which depends on different H/W requirement. This field is not recommended to change its default setting for avoiding any error in your system
74
BIOS Setup Utility SY-7VCA2
If [Parallel Port Mode] is set to [ECP] mode
If [Parallel Port Mode] is set to [EPP] mode
3-5.6 Onboard Parallel Ports
Onboard Parallel Ports
Setting Description Note
Onboard Parallel Port
Parallel Port Mode
ECP Mode use DMA
Parallel Port EPP TYPE
Disabled 378/IRQ7 Default 3BC/IRQ7 278/IRQ5
Normal Default EPP ECP ECP+EPP
3 Choose DMA3 Default 1 Choose DMA1
EPP 1.9 Select EPP port type 1.9 EPP 1.7 Select EPP port type 1.7 Default
Choose the printer I/O address.
The mode depends on your external device that connects to this port.
3-5.7 Onboard Legacy Audio
This field controls the onboard legacy audio.
Setting Description Note
Onboard Legacy Audio
Disabled Enabled
Set this item to Enabled if using software (like DOS games) that needs a ‘legacy’ audio device.
Default
Sound Blaster
SB I/O Base Address
SB IRQ Select
SB DMA Select
Disabled Default Enabled
220H Default
IRQ 5 Default
DMA1 Default
Set this item to enabled if your on­board audio-chip is sound Blaster compatible.
Select the base address for your sound Blaster (SB) compatible Audio IC.
Select the IRQ your SB Audio IC uses.
Select the DMA channel your SB Audio IC uses.
75
BIOS Setup Utility SY-7VCA2
Onboard Legacy Audio (Continued)
This field controls the onboard legacy audio.
Setting Description Note
MPU-401
MPU-401 I/O Address
Game Port (200-207H)
Disabled Default Enabled
330-333H Default 330-303H 310-313H 320-323H
Disabled Enabled
Set this item to enabled to make use of MIPI.
Select the I/O address for your MIDI functionality.
Set this item to enabled to make use of the game port.
Default
76
BIOS Setup Utility SY-7VCA2
3-6 POWER MANAGEMENT SETUP
The [POWER MANAGEMENT SETUP] sets the system's power saving functions.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
Power Management Setup
Power Management Press Enter Item Help ACPI Suspend Type S1 (POS) PM Control by APM Yes Video Off Option Suspend -> Off Video Off Method V/H SYNC+Blank MODE Use IRQ 3 Soft-Off by PWRBTN Instant-Off State After Power Failure Off Wake Up Events Press Enter
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
Menu Level 4
CMOS Setup Utility – Copyright ( C ) 1984-1999 Award Software
Wake Up Events
VGA OFF Item Help LPT & COM LPT/COM HDD & FDD ON PCI Master OFF PowerOn by PCI Card Disabled Modem Ring Resume Disabled RTC Alarm Resume Disabled
Primary INTR ON IRQs Activity Monitoring Press Enter
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
Menu Level 4
77
BIOS Setup Utility SY-7VCA2
After you have completed the Power Management Setup, press [Esc] to return to the Main Menu.
3-6.1 Power Management Controls
Power Management Controls
Setting Description Note
Power Management
PM Control by APM
Video Off Option
Video Off Method
Lets you define the HDD and system power down times. Doze timer
Min Saving 1 Hour 1 Hour 1 Hour 15 Min Max Saving 1 Min 1 Min 1 Min 1 Min
Yes Default NO
Suspend --> Off Always On
All Modes -­> Off
V/H Sync+Blank Blank screen DPMS
When enabled, an Advanced Power Management device will be activated to enhance the Max. Power Saving mode and stop the CPU internal clock. If Advance Power Management (APM) is installed on your system, selecting Yes gives better power savings.
When enabled, this feature allows the VGA adapter to operate in a power saving mode.
Selects the method by which the monitor is blanked.
Standby timer
Suspend timer
Default
HDD power down
Default
Default
78
BIOS Setup Utility SY-7VCA2
Power Management Controls (Continued)
Power Management Controls
MODEM Use IRQ
Setting Description Note
3 Default
Assigns an IRQ# to the modem
3-11, NA
device.
Soft-Off by PWR-BTTN
State After Power Failure
Wake Up Events
Wake Up Events
Instant-off Default Delay 4
Sec.
On The system will switch on when
Off The system will remain off when
Auto The system will return to the state
Press Enter Select items that will wake up your
Setting Description Note
Turns off the system power 4 seconds after pushing the power button.
power comes back after a power failure.
Default power comes back after a power failure.
it was in before the power failure when power returns. (i.e: If the system was on, it will switch on again, if it was off, it will remain off)
system when in one of sleep modes. Press enter to go the select item page.
VGA
LPT & COM
OFF Default ON You can set the VGA awakens the
system.
LPT/COM NONE, LPT, COM
When On of LPT & COM, any activity from one of the listed system peripheral devices or IRQs wakes up the system.
79
Default
BIOS Setup Utility SY-7VCA2 Wake Up
Events HDD & FDD
PCI Master
PowerOn by PCI Card
Modem Ring Resume
Resume by Alarm
Setting Description Note
OFF Default ON
OFF ON
Disabled Enabled
Disabled Enabled
Disabled The system ignores the alarm. Default Enabled Set alarm to power on the system by
When On of HDD & FDD, any activity from one of the listed system peripheral devices wakes up the system.
When On of PCI Master, any activity from one of the listed system peripheral devices wakes up the system
If enabled any PCI interrupt will wake up the system.
An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call on the modem) awakens the system from a soft off state.
the date (1-31) or time (hh:mm:ss). If the date is set to [0], the system will self-power on by alarm everyday at the set time.
Default
Default
Default
Primary INTR
IRQs Activity Monitoring (Press Enter)
ON Default OFF
Primary IRQ3(COM2), IRQ4(COM1),
Secondary IRQ9(IRQ2 Redir),
Disabled IRQ8 (RTC Alarm), IRQ15
When set to On, any event occurring at will awaken a system which has been powered down.
IRQ5(LPT2), IRQ6(Floppy Disk), IRQ7(LPT1), IRQ12(PS/2 mouse), IRQ13(Coprocessor), IRQ14(HardDsik)
IRQ10( Reserved), IRQ11(Reserved)
(Reserved)
80
BIOS Setup Utility SY-7VCA2
3-7 PNP/PCI CONFIGURATION SETUP
This option sets the Motherboard's PCI Slots.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
PnP/PCI Configurations
PNP OS Installed NO Reset Configuration Data Disabled
Resources Controlled By Auto (ESCD)
x IRQ Resources Press Enter x DMA Resources Press Enter
PCI/VGA Palette Snoop Disabled
Assign IRQ For VGA Enabled
Assign IRQ For USB Enabled
INT Pin 1 Assignment Auto
INT Pin 2 Assignment Auto
INT Pin 3 Assignment Auto
INT Pin 4 Assignment Auto
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level 4
Note: Starred (*) items will disappear when the [Resources Controlled By] option is set to [Auto].
After you have completed the PCI Slot Configuration, press [Esc] and follow the instructions on your screen to save your settings or exit without saving.
81
BIOS Setup Utility SY-7VCA2
3-7.1 PNP/PCI Configuration Controls
PNP/PCI Controls
Setting Description Note
PnP OS Installed
Yes Set this field to [Yes] if you
are running Windows 95, which is PnP compatible.
Reset Configuration Data
No If the OS you are running
does not support PnP configuration.
Disabled Retain PnP configuration
data in BIOS.
Enabled Reset PnP configuration data
Default
(If there is any doubt, set this field to [No])
Default
in BIOS.
Resources Controlled By
Manual BIOS does not manage PCI/ISA PnP
card IRQ assignment. Requires to assign IRQ-# and DMA-# to PCI or ISA PnP manually. IRQ-3,4,5,7,9,10,11,12,14,15 assigned to: _ DMA-0,1,3,5,6,7 assigned to: _ Auto (ESCD)
The Plug-and-Play BIOS
auto manages PCI/ISA PnP
Recommended
card IRQ assignment
automatically.
If [Resources Controlled By] is set to [Manual]
IRQ-# and DMA-# assigned to:
PCI/ISA PnP Choose IRQ-# and
DMA-# assigned to PCI/ISA PnP card.
Legacy ISA Choose IRQ-# and
DMA-# assigned to Legacy ISA card.
Under this item the user can assign an IRQ to a PCI slot. However, there under some conditions the IRQ will not be assigned as selected under this item:
1. IRQs 0, 1, 2, 6, 8, 13 can NOT be assigned, because they are fixed.
2. IRQs 5, 9, 10, 11 are available
3. IRQs 3,4,7,12,14 and 15 will only be assigned if they are free. See the table
below on how to free them:
IRQ-3,4,5,7,9,10, 11,12,14,15
DMA-0,1,3,5,6,7 IRQ-3,4,5,7,9,10, 11,12,14,15
DMA-0,1,3,5,6,7
82
BIOS Setup Utility SY-7VCA2
PNP/PCI Configuration Setup (Continued)
PNP/PCI Setup
Interrupt Line IRQ 15 IRQ 15: PCI / ISA PnP On-Chip Secondary PCI IDE: disabled IRQ 14 IRQ 14: PCI / ISA PnP On-Chip Primary PCI IDE: disabled
IRQ 12 IRQ 12: PCI / ISA PnP
IRQ 7 IRQ 7: PCI / ISA PnP Onboard parallel port: disabled IRQ 4 IRQ 4: PCI / ISA PnP Onboard Serial port 1: disabled IRQ 3 IRQ 3: PCI / ISA PnP Onboard Serial port 2: disabled
4. Your OS may reassign another interrupt to a PCI slot after BIOS passes control
to the OS, especially if you use Windows 95, 98 or NT.
Setting Description Note
How to set the BIOS to release the IRQ to the PnP Interrupt pool: PnP / PCI configuration Integrated Peripherals
Interrupt 12 will be released by the PnP BIOS automatically if the PS/2 Mouse Port is not used.
Assign IRQ For VGA/USB
Disabled BIOS will assign IRQ for
VGA/USB port.
Enabled BIOS won’t assign IRQ for
Default
VGA/USB port.
5. Your OS may reassign another interrupt to a PCI slot after BIOS passes control
to the OS, especially if you use Windows 95, 98 or NT.
Auto DefaultINT Pin
1/2/3/4
Set to Auto the BIOS will using IRQs Automatically.
Assignment
83
BIOS Setup Utility SY-7VCA2
3-7.2 MULTI I/O ADDRESSES
Default settings for multi-I/O addresses are as follows:
Port I/O Address IRQ Status
LPT1 COM1 COM2
378H 7 ECP/EPP 3F8H 4 2F8H 3
Warning: If a default I/O address conflicts with other I/O cards such as sound card, you must change one of the I/O addresses to remedy to this address conflict. (I/O addresses can be adjusted from the BIOS Setup Utility)
3-8 PC HEALTH STATUS
This option sets the Motherboard's PC Health Status.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
PC Health Status
Current CPU Temp. 25 º C / 77 º F Current System Temp. 40 º C / 104 º F Current CPUFAN Speed 5192 RPM Current CHAFAN Speed 0 RPM Vcore 2.02 V
2.5V 2.50 V
3.3V 3.31 V 5V 4.97 V 12V 11.70 V
Menu Level 4
Item Help
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
Note: Starred (*) items will disappear when the [Resources Controlled By] option is set to [Auto].
84
BIOS Setup Utility SY-7VCA2
3-8.1 CPU Device Monitoring
CPU Device Monitoring
Setting Description Note
Current CPU Temp.
Current System Temp.
Current CPUFAN Speed
Current CHSFAN Speed
Vcore, 2.5V,
3.3V, +5V, +12V
°C/°F
°C/°F
°C/°F
°C/°F
V
Show the current status of CPU temperature.
Show the current status of the system temperature.
Show the current status of CPU Fan
Show the current status of the chassis Fan
Show the current voltage status.
85
BIOS Setup Utility SY-7VCA2
3-9 LOAD FAIL-SAFE DEFAULTS
Select the [Load Fail-Safe Defaults] option from the Main Menu to load the system values you have previously saved. This option is recommended if you need to reset the system setup and to retrieve the old values.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
4Soyo Combo Feature 4PC Health Status 4Standard CMOS Features Load Fail - Safe Defaults 4Advanced BIOS Features Load Optimized Defaults 4Advanced Chipset Features Set Supervisor Password 4Integrated Peripherals Set User Password 4Power Management Setup Save & Exit Setup 4PnP/PCI Configurations Exit Without Saving
Esc : Quit áâàß : Select Item F10 : Save & Exit Setup
Load Fail - Safe Defaults (Y/N)? Y
Change CPU’s Clock & Voltage
Type [Y] to use the Setup Defaults followed by [Enter] or otherwise [N] to return to the Main Menu and keep current values.
Warning: If you run into any problem after changing the BIOS configuration, please load the SETUP DEFAULTS for stable performance.
86
BIOS Setup Utility SY-7VCA2
3-10 LOAD OPTIMIZED DEFAULTS
Select the [Load Optimized Defaults] option from the Main Menu to load the system values you have previously saved. This option is recommended if you need to reset the system setup and to retrieve the old values.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
4Soyo Combo Feature 4PC Health Status 4Standard CMOS Features Load Fail - Safe Defaults 4Advanced BIOS Features Load Optimized Defaults 4Advanced Chipset Features Set Supervisor Password 4Integrated Peripherals Set User Password 4Power Management Setup Save & Exit Setup 4PnP/PCI Configurations Exit Without Saving
Esc : Quit áâàß : Select Item F10 : Save & Exit Setup
Load Optimized Defaults (Y/N)? Y
Change CPU’s Clock & Voltage
Type [Y] to use the Setup Defaults followed by [Enter] or otherwise [N] to return to the Main Menu and keep current values.
Warning: If you run into any problem after changing the BIOS configuration, please load the SETUP DEFAULTS for stable performance.
87
BIOS Setup Utility SY-7VCA2
3-11 SUPERVISOR PASSWORD
Based on the setting you have made in the [Security Option] of the [BIOS FEATURES SETUP] section, the password prevents access to the system or the setup program by unauthorized users. Follow this procedure to set a new password or disable the password:
1. Choose [BIOS FEATURES SETUP] in the Main Menu and press
[Enter]. Select the [Security Options] item and set the field to:
a. [System]: The password is required every time the system is
booted. This means only a person who knows the password can use this computer.
b. [Setup]: The password is required only when you attempt to
enter the BIOS Setup program.
2. Choose [SUPERVISOR PASSWORD] from the Main Menu and
press [Enter]. The following prompt appear:
Enter Password:
Warning: If you forget or lose the password, the only way to access the system is to set jumper JP5 to clear the CMOS RAM. All setup information is lost and you must run the BIOS setup program again.
Note: If you do not wish to use the password function, press [Enter] directly and the following message appears:
Password Disabled!!
88
BIOS Setup Utility SY-7VCA2
F10
(Shift) F2
Type the Password Press:
password, press
to exit
Type the Password
Press <Enter> without
After you confirm the password,
3. Enter your new password and press [Enter]. The following message
appears, prompting to confirm the new password:
Confirm Password:
4. Re-enter your password and then press [Enter] to exit to the Main
Menu.
This diagram outlines the password selection procedure:
and Press: <Enter>
STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP
Enter Password:
POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION
Confirm Password:
LOAD SETUP DEFAULTS LOAD BIOS DEFAULTS
Esc
: Quit : Save & Exit Setup
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
Enter Password:
∗∗∗∗∗
∗∗∗∗∗
After you confirm the
press <Esc> to exit
Time, Date, Hard Disk Type…
ROM PCI/ISA BIOS
Press:
entering the password
Without entering password
INTEGRATED PERIPHERALS SUPERVISOR PASSWORD USER PASSWORD
Password Disabled!!
IDE HDD AUTO DETECTION SAVE & EXIT SETUP EXIT WITHOUT SAVING
°
: Select Item : Change Color
3-12 USER PASSWORD
When the user password option is on, you are not allowed to change any setting in the [CMOS SETUP UTILITY] except for changing the user's password.
The password setting procedure is similar to that for the [SUPERVISOR PASSWORD] (Refer to section 3-9).
89
BIOS Setup Utility SY-7VCA2
3-13 IDE HDD AUTO DETECTION
This Main Menu function automatically detects the hard disk type and configures the [Standard CMOS Features] accordingly.
CMOS Setup Utility – Copyright ( C ) 1984-2000 Award Software
IDE Primary Master
IDE HDD Auto-Detection Press Enter
IDE Primary Master Auto
Capacity 0 MB
Access Mode Auto
0 Cylinder 0 Head 0 Precomp 0 Landing Zone 0 Sector 0
áâàß:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level 4
Note: This function is only valid for IDE type of hard disk drives.
90
Drivers installation SY-7VCA2
Chapter 4
DRIVERS INSTALLATION
Your SY-7VCA2 Motherboard comes with a CD-ROM labeled "SOYO CD." The SOYO CD contains the user's manual file for your new Motherboard, the drivers software available for installation, and a database in HTML format with information on SOYO Motherboards and other products.
Step 1. Insert the SOYO CD into the CD-ROM drive
The SOYO CD will auto-run, and the SOYO CD Start Up Menu will be as shown.
If you use Windows NT, the SOYO-CD will not detect your motherboard type. In that case the following dialog will pop up, please choose your motherboard and press OK. Now the SOYO-CD Start Up Menu will be shown.
Please Select Your Board
7IWA-F 7IWA-F V1.0 6IWM/L 6IWM 6IWA
OK
(SOYO CD Start Up Program Menu)
91
X
LI-7000 7IWB 7IWB V1.0 7IWM 7IWM/L V1
Cancel
Drivers installation SY-7VCA2
If you use Windows 95 or 98, the SOYO CD Start Up Program automatically detects which SOYO Motherboard you own and displays the corresponding model name.
The user's manual files included on the SOYO CD are in PDF (Postscript Document) format. In order to read a PDF file, the appropriate Acrobat Reader software must be installed in your system. Note: The Start Up program automatically detects if the Acrobat Reader utility is already present in your system, and otherwise prompts you on whether or not you want to install it. You must install the Acrobat Reader utility to be able to read the user's manual file. Follow the instructions on your screen during installation, then once the installation is completed, restart your system and re-run the SOYO CD.
92
Drivers installation SY-7VCA2
Step 2. Install Drivers and Utilities
Click the Install Drivers button to display the list of drivers software that can be installed with your Motherboard. The Start Up program displays the drivers available for the particular model of Motherboard you own. We recommend that you only install those drivers.
driver revision:
VIA 4 in 1 driver package for Win 9x/NT VIA Ac97 Codec Driver for Win 9x/NT/2000 VIA hardware monitor for (Win 95/98)
Cancel
OK
(Driver Installation Menu)
A short description of all available drivers follows:
Ø VIA 4in1 driver package
The 4 in 1 driver package includes all drivers your motherboard needs. After selecting this driver package, one driver will be installed automatically (the IRQ remapping utility), the other three are installed if selected. By default all three drivers are selected. A description of the 4 drivers follows:
Bus Master PCI IDE Driver
This driver will speed up the data-transfer rate to and from the harddisk.
AGP VxD Driver
This driver must be installed in order to be able to make use of the on-board AGP Video functionality.
93
Drivers installation SY-7VCA2
VIA Chipset Functions Registry
This driver will make the necessary changes to the Windows registry, in order to make sure that Windows has no problems recognizing your VIA chipset.
IRQ remapping utility (This driver is installed automatically)
This utility will remap the IRQ lines to make sure that everything functions properly under Windows.
Ø VIA Ac97 Codec Driver for Win 9x/NT/2000
You have to install the drivers before installing any application for the Ac97 codec.
Ø VIA hardware monitor for (Win 95/98)
Your motherboard comes with a hardware monitoring IC. By installing this utility Temperature, Fan speed and Voltages can be monitored. It is also possible to set alarms when current system values exceed or fall below pre-set values.
Step 3. Select which driver you want to install and click OK
Notice 1: Once you have selected a driver, the system will automatically exit
the SOYO CD to begin the driver installation program. When the installation is complete, most drivers require to restart your system before they can become active.
Notice 2: You may click Cancel to abort the driver installation and return to
the main menu.
Step 4. Check the Latest Releases
Click the 'Check the latest Releases' button to go the SOYO Website to automatically find the latest BIOS, manual and driver releases for your motherboard. This button will only work if your computer is connected to the internet through a network or modem connection. Make sure to get your modem connection up before clicking this button.
94
95
Loading...
