SoundOff Signal Pinnacle LED User Manual

OWNER’S MANUAL &
INSTALLATION INSTRUCTIONS

EPL9000-B 11.14

TABLE OF CONTENTS

PAGE CONTENT

3 TECHNICAL SPECIFICATIONS

4 PRE-INSTALLATION

5 PINNACLE BASICS

6 FIXED HEIGHT BRACKETS AND HOOK MOUNTING

7 FIXED HEIGHT BRACKETS PERMANENT MOUNTING

8-10 ADJUSTABLE HEIGHT BRACKETS AND HOOK MOUNTING

10-11 ELECTRICAL INSTALLATION

12-13 BREAKOUT BOX

13 FLASH PATTERNS AND CONNECTOR INSTRUCTIONS

14 CONTROLLER AND WIRE HARNESS INSTRUCTIONS

15 PINNACLE TROUBLESHOOTING

16 REPLACEMENT PARTS

17 PRODUCT MAINTENANCE

BACK WARRANTIES AND POLICIES

Page 2

PRE-INSTALLATION

IMPORTANT NOTICE TO INSTALLER: Make sure to read and understand all instructions and warnings before
proceeding with the installation of this product. Ensure that the manual and any warning cards are delivered to
the end user of this equipment. Proper installation of the lightbar requires the installer to have a thorough
knowledge of automotive electronics, systems, and procedures. Lightbars provide an essential function of an
effective visual warning system. The use of the lightbar does not insure that all drivers can or will abide by or
react to an emergency warning signal, especially at high rates of speeds or long distances. The operator of the
vehicle must never take the right of way for granted and it is the operator’s responsibility to proceed safely.
The effectiveness of the this lightbar is highly dependant on the correct mounting and wiring. The installer
must read and follow the manufacturer’s installation instructions and warnings in the manual. The vehicle
operator should verify daily that the lightbar is securely fastened to the vehicle and properly functioning before
operating vehicle. The lightbar is intended for use by authorized personnel only. It is the user’s responsibility
to ensure they understand and operate the emergency warning devices in compliance with the applicable city,
state and federal laws and regulations. (SoundOff Signal assumes no liability for any loss resulting from the
use of this warning device.)

Unpack box:

1. Remove the light bar and packaging.

2. Save packaging for later shipping.

3. Check components/contents.

4. Please reference this instruction manual for
proper wiring and installation.

Tools Required for Installation:

5/32” Allen Driver
7/16” Socket with ratchet
T-25 Torx Driver
Phillips Head Screwdriver
Electric Drill with #30 (.128 dia.) drill bit
1 1/4” Hole Saw

Components/Contents

Standard Equipment
1- PINNACLE Lightbar
1- Roof Side Cable Grommet (cable specific)

Controller

1- Breakout Box (DSC Option)
1- Wire Harness

Optional Mounting Kits

2- Adjustable Height Mounting Brackets (OR)
2- Fixed Height Mounting Brackets
1- Specific Vehicle Hook w/ Hardware Kit (OR)
1- Specific Mounting Hardware Kit

**Kits will vary with each bar

WARNING - DRILLING ANY HOLES INTO THE LIGHTBAR IS NOT RECOMMENDED! THE
RISK OF DAMAGING INTERNAL COMPONENTS AND THE RESULTING FAILURE OF THE
LIGHTBAR WILL VOID ANY WARRANTY OF THIS PRODUCT.

At anytime during your installation process, feel free to call our technical support line at
1-800-338-7337. Press #4 to skip automated message. You can also visit our website at
www.soundoffsignal.com or e-mail technical assistance at [e-mail].

Page 4

TECHNICAL SPECIFICATIONS

Input Voltage 10-16Vdc

Current Draw (Amps)
Average Peak Power Consumption
(Watts)
Inboard Module (ea): 0.5Amps @ 12.8Vdc 1.0Amps @ 12.8Vdc 6.4
Corner Module (ea): 1.0Amps @ 12.8Vdc 2.0Amps @ 12.8Vdc 12.8
Takedown Module (ea): 0.5Amps @ 12.8Vdc 1.0Amps @ 12.8Vdc 6.4
Alley Light Module (ea): 0.33Amps @ 12.8Vdc 0.65Amps @ 12.8Vdc 4.2

Average = Flashing Peak = 100% Steady ON

Standby Current: .022Amps@12.8Vdc Power Consumption = 0.28 Watts*
Reverse Polarity: Fuse Protected
Load Dump: Protected
Wiring: Power Cable 15ft 10AWG Wires, (+) RED, (-) BLK
Data Cable 15ft RJ-45 Type

Number of LEDs:
Inboard Module (ea) 6 Gen3 LEDs
Corner Module (ea) 12 Gen3 LEDs
Takedown Module (ea) 6 Gen3 LEDs
Alley Light Module (ea) 1 Multi Chip Gen3 LED

Operating Temperature: -40°C to +65°C

Light output:
Blue LED 30 Lumens minimum per LED
Red LED 50 Lumens minimum per LED
White LED 100 Lumens minimum per LED
White Multichip LED 400 Lumens minimum per LED
Amber LED 45 Lumens minimum per LED
Green LED 40 Lumens minimum per LED

Life: 50K+ hours

Optical Distribution:
Inboard Module (ea) 20° Vert. x 90° Horiz. Angle
Corner Module (ea) 20° Vert. x 120° Horiz. Anle
Takedown Module (ea) 20° Beam Angle
Alley Light Module (ea) 20° Beam Angle

Moisture Protection: IP66 sealed construction
Outer Lens: Polycarbonate with UV Protection

Mounting Bolt: n3/16” Stainless / A2

Dimensions:
36” Lightbar 35.4“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
42” Lightbar 41.7“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
48” Lightbar 48.0“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
54” Lightbar 54.3“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
60” Lightbar 60.7“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
72” Lightbar 73.5“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
*Based on configuration see page 12.

Page 3

PINNACLE BASICS

This is a basic configuration showing many of the features offered. Your PINNACLE may

have a different configuration. This diagram should only be used as a reference.

TOP VIEW WITH COVER ON

6 TOP COVER SCREWS

TOP VIEW WITH COVER OFF

INBOARD LED MODULES CORNER LED MODULES

WIRE EXIT

BOTTOM VIEW

MODEL NUMBER
SERIAL NUMBER

TAKE DOWN MODULES

FRONT

REAR

ELECTRICAL ENCLOSURE

CARRIAGE BOLTS
FOR MOUNTING
BRACKETS IN CHANNELS

Page 5

FIXED HEIGHT BRACKETS
& HOOK MOUNTING

1. Mount fixed height brackets (See Figure 1) using supplied (3) T25 torx screws on each side. Temporarily place the lightbar in
it’s correct position on the roof of the vehicle. The bar should be positioned about the center line of the “B” pillar.

2. Based on the bar’s position, determine wire entry into vehicle. Mark location for later use. Note: Take into consideration the
location of any structural, airbag, or heating and cooling system components that can be in the way of the the wire entry point
or wire routing.

3. Install supplied vehicle specific hook brackets using supplied 1/4”-20 x 2.5 Hex Head bolts and Nylon Locking Nuts onto the bar
mounting foot as shown in Figure 2. Nut will nest into molded socket to prevent turning and improve ease of installation. It’s
recommended that you position the nut into the foot and tap it slightly with a hammer to seat it into the cast foot prior to placing
the bar on the roof. This will make installation easier.

4. Adjust fixed height bracket position on the Lightbar by loosening the (3) T25 Torx Screws on each side (See Figure 1). Be sure
that there is enough clearance between fixed height brackets and vehicle specific brackets to allow for tensioning to roof. When
the correct position is found, tighten T25 torx screws that attach fixed height bracket to lightbar base end plates.

5. Using the vehicle specific hook brackets as a template, drill 4 pilot holes using a #30 (.128 dia.) drill bit on each side of the
vehicle.

Slots for
adjustablitlity
for correct roof fit

1/4”-20 Nylon
Locking Hex Nut

Loosen T25 Torx Screws
to adjust brackets

FIGURE 1 FIGURE 2

6. Secure each vehicle specific hook bracket by using the 8 supplied #8 x 1/2” Truss Head Sheet metal screws on each side.

7. Tighten each vehicle specfic hook bracket by turning the 1/4”-20 x 2.5 Hex head bolt clockwise until bar is snug and no side to
side or fore to aft movement occurs.

8. Route cables into vehicle. Use supplied rubber grommet in roof for sealing/protection of wires. It is recommended that silicone
be placed around grommet to ensure roof sealing.

WARNING - ROUTE WIRES ONLY IN LOCATIONS THAT ARE NOT SUBJECTED TO POTENTIAL WEAR. MAKE SURE TO
AVOID ROUTING WIRES IN THE DEPLOYMENT AREA OF YOUR AIR BAG. REFER TO YOUR VEHICLE’S OWNER’S
MANUAL FOR AIR BAG DEPLOYMENT ZONES.

1/4”-20 x 2.5”
Hex Head Bolt

Vehicle Specific Hook Bracket

Page 6

FIXED HEIGHT BRACKETS
PERMANENT MOUNTING

1. Locate the permanent hardware kit that is included. Kit will include (4) 1/4”-20 x 1“ hex head screws, (4) flat washers, (4) lock
washers, (4) square nuts, and (6) T25 Torx Screws.

2. Attach fixed height brackets to lightbar using T25 Torx Screws. Brackets should be adjusted to identical positions at both ends
of lightbar. See Figure 1.

3. Position the lightbar on the vehicle roof in the desired mounting location. The recommended location is directly above the B­Pillars. This is the strongest part of the roof. Make sure that the bar is centered on the vehicle left to right. Adjust bracket
location on lightbar base end castings if needed.

4. Mark the location for the (4) holes that need to be drilled through the roof that will attach the fixed height brackets to the roof.

5. Determine the best location for cable entry depending on the configuration of your bar. Using a 1-1/4” hole saw, drill hole in the
marked location. Be mindful that you do not drill through any roof support members or the interior headliner.

6. Using a 5/16” drill bit, drill the 4 holes in the locations that you marked in step 4. Clean and debur each hole.

7. Attach the lightbar to the vehicle using the supplied hardware. Use (1) flat washer and locking nut for each bolt. You should
have a total of 4 bolts attaching the lightbar to the roof of the vehicle. See Figure 2 for details. It is recommended that you add
silicone around the hole to ensure roof sealing.

8. Route cables into vehicle. Use supplied rubber grommet in roof for the sealing/protection of wires. It is recommended that
silicone be placed around the grommet to ensure roof sealing.

Slots for
adjustablitlity
for correct roof fit

4x 1/4” -20

Roof Cut-away

Loosen T25 Torx Screws
to adjust brackets

FIGURE 1

WARNING - ROUTE WIRES ONLY IN LOCATIONS THAT ARE NOT SUBJECTED TO POTENTIAL WEAR. MAKE SURE TO
AVOID ROUTING WIRES IN THE DEPLOYMENT AREA OF YOUR AIR BAG. REFER TO YOUR VEHICLE’S OWNER’S
MANUAL FOR AIR BAG DEPLOYMENT ZONES.

4x 1/4”-20 x 1”
Hex Head Screw

Square Nuts

4x 1/4” Flat
Washers

4x 1/4” Lock
Washers

FIGURE 2

Page 7

ADJUSTABLE HEIGHT BRACKETS
& HOOK MOUNTING

PIVOT
ARM

HEIGHT & ROOF ANGLE ADJUSTMENT SCREWS

FRONT TO BACK TILT ADJUSTMENT SCREWS

VEHICLE
SPECIFIC
BRACKET

VEHICLE SPECIFIC BRACKET
ADJUSTMENT SCREW

ADJUSTABLE RUBBER FEET

HEIGHT ADJUSTMENT
SCREWS

Page 8

ADJUSTABLE HEIGHT BRACKETS
& HOOK MOUNTING

1. Attach vehicle specific bracket to adjustable mounting bracket. 1 1/2” Allen drive screw must be placed “underneath” djustable
mounting bracket (See Figure 1). Allen drive screw will be accessible through hole in front of adjustable bracket. Square nut
must be placed in front of vehicle specific bracket. Place 1/4“ lockwasher between square nut and vehicle specific hook
bracket. See Figure 1 for details. To hold bracket in place, use provided hardware: 1 flat washer, 1 lock washer and 3/8” Allen
drive screw per slot (as shown in Figure 1).

2. Attach mounting brackets to bar using the carriage bolts pre-installed on the bar. Use two lockwashers and a acorn nut per bolt.
Leave acorn nuts loose so that the bracket has the ability to slide to fit your specific vehicle application. When choosing the
placement for the mounting bracket, consider the cable routing and the risk of pinching wires or anything that can lead to cable
failure. See Figure 2 for details.

VEHICLE SPECIFIC BRACKET

SQUARE NUT

1/4-20 X 3/8 SCREW

1/4” TOOTH LOCKWASHER

1/4” FLAT WASHER

3. Position bar on roof about center line of “B” pillar. Determine final location of adjustable mounting brackets for vehicle
application and ensure bar is centered about brackets and vehicle. Determine and mark off locations for mounting screws
through vehicle specific bracket into roof. Determine location for wire entry into vehicle.

4. Determine the height of bar in relationship to the roof that best suits your application. Height of bar can be adjusted by
loosening 4 allen drive screws that fasten pivot arm to either end. To simplify this procedure we recommend cutting 2 wood
blocks to your preferred height to set gap height between roof and bar. Also be sure that adjustable height bracket feet are
sitting flat on vehicle roof. See Figure 3.

TOOTH LOCKWASHER

ACORN NUT

LOCKWASHER

1/4-20 X 1.5” SCREW

GASKET

FIGURE 1

FIGURE 2

5. After position of bar is determined. Tighten tilt and height adjustment screws (shown on page 5). Also tighten acorn nuts
attaching adjustable mounting bracket to bar.

6. Drill 4 holes using a #30 (.128 dia.) drill bit on each side of vehicle that were marked in Step 5. Be careful not to damage
weather stripping on vehicle.

7. Using 1 1/4” hole saw, drill hole in marked location on roof for cable routing. Be mindful that you do not drill through any roof
support members or interior head liner. Clean and debur hole.

8. Secure each vehicle specific bracket by using 4 supplied #8 x 1/2” truss head screws.

9. When required, adjust front to back tilt to make bar parallel with road for best optical range. 5/32“ allen drive adjustment
screws are located above each mounting foot in the mounting bracket base. Adjustment screws must be turned
counter-clockwise to raise either front or back of bar.

Page 9

ELECTRICAL INSTALLATION

REPRESENTS
VEHICLE ROOF

FRONT-BACK
TILT ADJUSTMENT
SCREWS

FEET MUST SIT
FLAT ON ROOF

TIGHTEN BRACKETS
TO ROOF BY COUNTER
CLOCKWISE ROTATION

LOCATION FOR MOUNTING
SCREWS TO ROOF

CENTER ABOUT “B” PILLAR

FIGURE 3

WARNING - CARE MUST BE TAKEN WHEN DRILLING THROUGH THE ROOF OF THE VEHICLE NOT TO
DRILL INTO ANY EXISTING WIRING AND NOT TO DRILL THROUGH THE HEADLINER OR SUPPORT
MEMBERS OF THE VEHICLE. CHECK BOTH SIDES OF THE MOUNTING SERVICE PRIOR TO DRILLING.
DE-BURR ANY HOLES AND REMOVE ANY METAL SHARDS OR REMNANTS. INSTALL GROMMETS
INTO ALL WIRE PASSAGE HOLES.

10. Tighten vehicle attachment brackets to roof by turning 5/32” Allen driver in COUNTER-CLOCKWISE ROTATION. Depending on
your desired height, you may need to cut down your allen wrench to fit between the bar and the mounting bracket. Or use a micro
drive gear wrench and 1/4” shank with 5/32” allen bit.

WARNING - ROUTE WIRES ONLY IN LOCATIONS THAT ARE NOT SUBJECTED TO POTENTIAL WEAR.
MAKE SURE TO AVOID ROUTING WIRES IN THE DEPLOYMENT AREA OF YOUR AIR BAG. REFER TO
YOUR VEHICLE OWNER’S MANUAL FOR AIR BAG DEPLOYMENT ZONES

11. Route cables into vehicle. Use supplied rubber grommet in roof for sealing/protection of wires. It is recommended that silicone
be placed around grommet to ensure roof sealing.

12. Route cable down through the “B” pillar and towards switch panel. Refer to the instructions included with your switch for
switch wiring information.

ELECTRICAL INSTALLATION

Featured Highlights:
Mode Select: The PINNACLE Lightbar is equipped with 2 selectable pattern configuration modes via the Mode Select Input. Default

is Mode 1 where the input is floating, Mode 2 is in use when the input activated. This feature allows 2 complete sets of patterns to
be programmed into the Lightbar's non-volatile memory. Once programming configuration is complete, the Mode can be changed
“on-the-fly” by an activation switch.

Cruise Mode: Allows the user to program any Light Head Group(s) to “Glow” when this feature is activated.

Directional Arrow Built-in: If the lightbar was purchased with a directional arrow, the directional controller is built-in w/ 4 arrow

patterns for each direction and 9 warning patterns for warming functions.

WARNING - ALL CUSTOMER SUPPLIED POWER WIRES CONNECTING TO THE POSITIVE (+) OR
NEGATIVE (-) BATTERY TERMINAL OR LOCAL CHASSIS GROUND (-) MUST BE SIZED TO SUPPLY AT
LEAST 125% OF THE MAXIMUM CURRENT AND PROPERLY FUSED AT THE POWER SOURCE WITH
APPROPRIATELY RATED FUSE.

Power Cable:

1. Route lightbar power cables as close to vehicles power source (battery) as possible.

Page 10

BREAKOUT BOX

40Amp FUSE

(Customer Supplied)

GROUND

DRAIN WIRE

BLACK 12 GA.

GROUND

RED 12 GA.

POWER
CABLE

RJ-45 CABLE

Active Low
Switch #1

Active Low
Switch #2

Green LED

Red LED

RED LIGHT

No Inputs Flashes Every 5 Secs.
Input Activated Steady On
Added Input Brief Flash

GREEN LIGHT

Command Rec’d Steady On Has good
(See below) connection

LOW POWER (STANDBY) MODE

If there is no input to the breakout box for
15 seconds, the lightbar will go into a
“standby” mode. The standby mode is a
low power mode that is used to extend
the life of your battery. The green light
will turn off when the lightbar enters
standby mode. The red light will flash
every five seconds showing that it has
power. The lightbar will awaken from the
standby mode if any input is activated on
the breakout box.

*note in standby mode each switch in the
down position will contribute to another

0.03A of standby current.

· When the switch is in the up position inputs connected to that switch are
active high. To activate an active high input, apply 12Vdc.

· When the switch is in the down position inputs connected to that switch
are active low. To activate the active low, apply ground (negative).

Wire Color

(Major Color/Stripe)

Light Green/White 24 Left Turn Signal* Discrete Output #4*
Red/Black 23 Right Turn Signal* Discrete Output #3*
Orange/White 22 Rear Inboard 3 Discrete Output #2*
Yellow White 21 Rear Inboard 2 Discrete Output #1 (L)*
Brown 20 Front Takedown Front Takedown
Red/White 19 Alley Flash Alley Flash
Pink 18 Alley Driver Alley Driver
Red 17 Alley Passenger Alley Passenger
Orange 16 Front Inboard 3 Front Inboard 3
Yellow 15 Front Inboard 2 Front Inboard 2
Green 14 Front Inboard 1 Front Inboard 1
Blue 13 Front Corners Front Corners
Pink/White 12 Arrow, Left* Discrete Output #8 (R)*
Purple/White 11 Arrow, Center* Discrete Output #7*
Gray/White 10 Arrow, Right* Discrete Output #6*
Black/White 9 Arrow, Warning Discrete Output #5*
White 8 Pattern Select* Pattern Select*
Purple 7 Low Power Low Power
Brown/White 6 Front Takedown Flash Front Takedown Flash
Light Green 5 Auxiliary* Auxiliary*
Black 4 Cruise Lights* Cruise Lights*
Gray 3 Mode Select* Mode Select*
Green/White 2 Rear Inboard 1 Rear Inboard 1
Blue/White 1 Rear Corners Rear Corners

* - Reference page 11 for detailed explanation of functions

Note - Reference Switch table for explanation of what inputs are affected by
Active Low Switches

Standard Functions

Pin#

(4 Wire Arrow Control)

Discrete Functions

(8 Wire Arrow Control)

Fuctional inputs connect to your control head or

switching unit. Applying +12Vdc to any functional

input will activate it’s function (default-active high).

For more information, see switches explanantion on

Functional Inputs

second page.

Connector Pinning Chart

Controlled by Active Low Switch #2

Controlled by Active Low Switch #1

PIN#24 - Light Green/White

PIN#23 - Red Black

PIN#22 - Orange/White

PIN#21 - Yellow/White

PIN#20 - Brown

PIN#19 - Red/White

PIN#18 - Pink

PIN#17 - Red

PIN#16 - Orange

PIN#15 - Yellow

PIN#14 - Green

PIN#13 - Blue

White - PIN#08

Purple - PIN#07

Pink/White - PIN#12

Gray/White - PIN#10

Black/White - PIN#09

Purple/White - PIN#11

Gray - PIN#03

Black - PIN#04

Light Green - PIN#05

Brown/White - PIN#06

Blue/White - PIN#01

GreenWhite - PIN#02

Page 12

ELECTRICAL INSTALLATION

IMPORTANT: When passing cables through firewall or other sheet

metal, insert grommet to protect the cable!

2. Install a 40Amp Fuse (customer supplied) to the end of the RED wire of the Lightbar Power Cable.
a. Remove the fuse before connecting any wires to the battery.
b. DO NOT USE CIRCUIT BREAKER OR FUSIBLE LINK.

3. Connect the other end of the Fuse to the POSITIVE (+) terminal of the battery.
a. Do NOT use any more than 2ft of wire between the battery terminal and the fuse and ensure the wire is protected

4. Connect the BLACK wire to the factory chassis ground right next to the battery.

Control (Data) Cable:

1. Route Lightbar Control Cable to the location where all controlling equipment will be, i.e. switch box, center console area.

2. Locate the Breakout Box in the same area to connect jumpers from the switching equipment to the breakout box.

NOTE: Power is supplied to Breakout Box through data cable, no additional power connections necessary.

Initial Power up Test:

1. Insert 40Amp Fuse into Fuse Holder.

2. Plug data jack into Data 1 connector of the breakout box (Data 2 may also be used, but is for future use.)

3. Observe the GREEN Data Link indicator LED on the Breakout Box; the LED will turn steady ON about 15 seconds after main
power is connected

4. When GREEN LED is steady ON (see below), the lightbar is ready to be configured.

Low Power (Standby) Mode

If there is no input to the breakout box for 15 seconds, the lightbar will go into a “standby” mode. The standby mode is a low power mode that is
used to extend the life of your battery. The green light will turn off when the lightbar enters standby mode. The red light will flash every five
seconds showing that it has power. The lightbar will awaken from the standby mode if any input is activated on the breakout box.

*note in standby mode each switch in the down position will contribute to another 0.03A of standby current.

and secured from being cut into; this is non-fused wire.

Pattern Selection:

a. First review the Pattern Table (included on pg. 13) before attempting pattern selection to familiarize yourself with patterns

i. Depending on the Lightbar configuration purchased, the Arrow Pattern Table may or may not be applicable.
b. Select the Input Function(s) on breakout box (pg. 12) and apply +12V to activate.
i. To change patterns on more than one input function, simply connect desired input functions together. Before doing

c. Momentarily apply +12V to the pattern select input on breakout box to advance to the next pattern. See Flash Pattern

i. Once the last pattern is reached, the next pattern advance will cycle back to Pattern #1.
d. Once the desired pattern is reached, simply disconnect the Input Function(s) and proceed to the next Input Function(s)

i. The pattern is saved in non-volatile memory every time it is advanced.

Mode Configuration: See Mode Input on Function Description Table (attached sheet) for more details about this feature.
a. Mode 1 (Default): the Mode Select Input will be floating (no-connection)
i. Continue on to Pattern Selection instructions below to set the patterns for this Mode
b. Mode 2: apply +12V to activate Mode 2. This will need to be activated to configure the Lightbar in Mode 2
i. Continue on to Pattern Selection instructions below to set the patterns for this Mode
ii. Once patterns have been setup, connect Mode Select Input to switching system.
iii. When the Mode Select Input is activated, the Mode 2 Patterns will flash.

Cruise Mode Configuration: See Cruise Mode Input on Function Description Table (attached sheet) for more details about this

a. Apply +12V to activate Cruise Mode for configuration setup.
b. Determine what Input Function(s) are desired to use Cruise Mode.
c. Apply +12V to the Input Function(s) desired.
i. NOTE: Lights will flash preset flash pattern
d. With both the Cruise Mode Input and the Input Function(s) activated, momentarily apply +12V to
the pattern select wire to toggle the Cruise Mode to ON (default is OFF).
e. Observe the OFF sequence of the flash pattern is ON dim.
f. Disconnect the Input Function wire(s) (while leaving cruise mode input active) and observe the lightbar is NOT flashing, but

available for the different Functions

this, make sure all the inputs are using the same pattern table and are on the same pattern to make pattern
identification easier.

Table (pg .13).

to be configured.

Feature.

the output function(s) recently set are glowing steady.

Page 11

FLASH PATTERNS
& CONNECTOR INSTRUCTIONS

FLASH PATTERN TABLE

BREAKOUT BOX HOOKUP:

Make sure the 24-pin connector and the RJ-45
connector are snapped in securely.

Follow the label for the wire color to connect to a
12Vdc source, which turns on that given light or
lights.

Make sure your wire connections are secured and
isolated from any other wire.

LED Module Flash Patterns

#

10
11
12
13
14
15
16
17
18
19
20
21

Pattern Name
1
2
3
4
5
6
7
8
9

Quint
Warp

Inter-Cycle Flash

Quad Flash
RoadRunner™
RoadRunner™

Slow Runner
Slow Runner

Q-Switch

Single, Steady Burn

Quad, Steady Burn
Warp, Steady Burn

Nothing, Steady Burn

E-Pattern Single Flash

E-Pattern Double Flash

E-Pattern Single Flash

E-Pattern Double Flash

Warp 1,2,3
Warp 2,3,1
Warp 3,2,1

Steady Burn

Sequence
Alternating
Alternating
Alternating
Alternating
Alternating

Simultaneous

Alternating

Simultaneous

™

Variable
Steady Burn
Steady Burn
Steady Burn
Steady Burn

Alternating

Alternating
Simultaneous
Simultaneous

Variable
Variable
Variable

Steady Burn

fpm*

70

350

-

80
115
115

70

70

-

115

80
350

­230
128
230
155

-

-

-

-

fps**

*fpm=Flashes per Minute
**fps=Flashes per Second

1.18

5.88

-

1.35

1.92

1.92

1.16

1.16

-

1.92

1.35

5.88

-

3.85

2.13

3.85

2.6

-

-

-

-

LED Takedown & Alley Flash Patterns

1
2
3
4
5

RoadRunner™
PowerPulse™

Q-Switch™

ETM™

Steady Burn

Alternating
Alternating

Variable

Simultaneous

Steady Burn

115
180

-

214

-

Directional Bar Warning Function Patterns

PowerPulse™ Alternating

1

PowerPulse™ Alternating

2
3
4

Quad Alternating

Warp Alternating

5
6
7
8
9

Hyper Scan
Super Scan

Power Flash

Thunder and Lightning

Center Out

Left/Right

Center Out

Adjacent

2X Individual Sweep

Pulsing + Sweep
Dual Rate Pulse/Alt
Dual Rate Alt/Pulse

Random

180
180

80

350

-

-

-

-

-

Split Arrow Bars Also Have The Following Multi-color Patterns

10
11
12
13
14
15
16
17

RoadRunner™

Warp

Warp
Inter-Cycle Flash
Inter-Cycle Flash
Inter-Cycle Flash
Inter-Cycle Flash
Inter-Cycle Flash

Alternating

Adjacent
Adjacent

Adjacent
Alternating
Alternating
Alternating
Alternating

115

350
350

-

-

-

-

-

Directional Bar Directional Function Patterns For
Left, Center Out, & Right Sequences

1

Solid Arrow Plus, Slow

2

Solid Arrow, Slow

3

Individual Arrow, Fast

4

Chaser Arrow, Fast

Grow / Decay

Solid

Individual

2X Individual

1.92

3.00

-

3.57

-

3.00

3.00

1.35

5.88

-

-

-

-

-

1.92

5.88

5.88

-

-

-

-

-

Input Group Control

Front Corners

Rear Corners
Front Inboard 1
Front Inboard 2
Front Inboard 3

Rear Inboard 1
Rear Inboard 2
Rear Inboard 3

Front Takedown Flash

Alley Flash

LIGHTBAR CONTROLLER CONNECTOR INSTRUCTIONS

Light Output Groups

Orange

Brown

Red and Yellow

Green

Blue

Red and Yellow (2-wire)

Green (2-wire)

Blue (2-wire)

White

Small Connector

EPL 9000 SWITCH SETTINGS

SW2

SW1

Off

Off

Off

Off

On

Off

On

Off

Off

On

Off

On

On

On

On

On

SW3

Off
On
Off
On
Off
On
Off
On

SW4

On
Off

SW5

On
Off

SW6

On

Off

PASSENGER-SIDE EXIT

SPLIT-COLOR ARROW MODULES

FULL ARROW MODULE

FOR TURN SIGNALS ON YELLOW OUTPUT

FOR TURN SIGNALS ON BLUE OUTPUT

PURPOSE

8-WIRE CONTROL

NO ARROW

N/A
4 MOD ARROW
5 MOD ARROW
6 MOD ARROW
7 MOD ARROW
8 MOD ARROW

DRIVER-SIDE EXIT

Page 13

CONTROLLER
& WIRE HARNESS INSTRUCTIONS

LIGHT MODULE WIRE HARNESS LOCATIONS

REPLACEMENT OF INBOARD, CORNER, TAKEDOWN AND ALLEY LED MODULES:

1. Disconnect main power.

2. Remove top cover by removing 6 sealed torx head screws.

3. Locate module and remove mounting screw. Pull module from lightbar.

4. Remove connector from rear of module by disengaging locking latch and pull
connector from back of module. (see illustration at right)

5. Push module connector into module ensuring locking latch is seated properly.

6. Replace module and 2 screws that fasten module to base extrusion.

7. Restore power to bar and test new module to ensure functionality.

8. Replace top cover of bar with screws removed in step 2.

ORANGE

SM

BROWN

ORANGE

SM

BROWN

ORANGE

SM

BROWN

ORANGE

SM

BROWN

ORANGE

SM

BROWN

ORANGE

SM

BROWN

DRIVER
SIDE

GREEN RED RED GREEN

A

11 12 13 14

E

31 32 33 34

B

GREEN RED RED GREEN

FRONT

PASSENGER

ORANGE

C

E

D

BROWN

SIDE

SM

36” BAR

BLUE GREEN RED GREEN

A

11 12 13 14 15

E

31 32 33 34 35

B

BLUE GREEN RED GREEN BLUE

ORANGE

C

E

D

BROWN

SM

42” BAR

BLUE GREEN RED RED GREEN

A

11 12 13 14 15 16

E

31 32 33 34 35 36

B

BLUE GREEN RED RED GREEN

BLUE

BLUE

ORANGE

C

E

D

BROWN

SM

48” BAR

YELLOW

A

11 12 13 14 15 16 17

E

31 32 33 34 35 36 37

B

YELLOW

BLUE GREEN RED GREEN BLUE

BLUE GREEN RED GREEN BLUE

YELLOW

YELLOW

ORANGE

C

E

D

BROWN

SM

54” BAR

YELLOW

A

11 12 13 14 15 16 17 18

E

31 32 33 34 35 36 37 38

B

YELLOW

BLUE GREEN RED RED GREEN

BLUE GREEN RED RED GREEN

BLUE

BLUE

YELLOW

YELLOW

60” BAR

YELLOW

A

11 12 13 14 15 16 17 18 19 20

E

31 32 33 34 35 36 37 38 39 40

B

YELLOW

BLUE GREEN

BLUE BLANK RED* RED* BLANK

RED* RED GREEN

RED* RED*

RED* RED*

72” BAR

C

D

BLUE

BLUE

Colors shown indicate color coded labels on
wiring harness.

White is used for all Take Down lights. Replace
color indicated on diagram with white labeled
wire.

SM=Small connector used on Alley lights only.

If modules are being replaced in the field make
sure they are reinstalled with single wire
connectors to FRONT of vehicle. See below.

Red, Blue Double

ORANGE

SM

E

BROWN

YELLOW

YELLOW

Wire (Rear)

BLUE

ORANGE

C

E

D

BROWN

* DENOTES

DOUBLE WIRE

UNITS IN FRONT

SM

ON 72” BAR

ONLY!

Green

Single Wire

Page 14

TROUBLESHOOTING

NORMAL OPERATION

Under Normal operation with lightbar turned on the breakout box will have the Green and Red LED light on steady. When ever you change
an input to the lightbar the Red LED on the breakout box will flash then go back to steady.

When the lightbar is off (no inputs active) the Green LED on the breakout box will stay on for 15 seconds then go off putting the lightbar into
sleep (standby) mode. The Red LED will flash every 5 seconds to tell you there is power to the breakout box and it is waiting for an input to
turn on the lightbar.

NO OPERATION

No LED on or flashing on Breakout box; Check input power and ground to lightbar, check data cable for damage and/or

opens, check 5 amp fuse in electronic control box in lightbar.

Breakout box LED’s operating correctly; Check FH1 & FH2 fuse in electronic control box in lightbar

NO OR INCORRECT INBOARDS OR CORNERS LIGHTS (WARNING)

Breakout box LED’s operating correctly; Check FH1 fuse in electronic control box in lightbar

No steady Red LED on breakout box; Check 24-pin connector at breakout box (insure it is snapped in correctly), check

appropriate input to breakout box for output lights which should be on

No rear warning lights; Check dip switch SW5 setting for full (off) or split (on) arrow (on full you may not

get any warning) (after arrow dip switch changes main power must be cycled)

NO TAKEDOWNS OR ALLEYS LIGHTS

Breakout box LED’s operating correctly; Check FH2 fuse in electronic control box in lightbar

No steady Red LED on breakout box; Check 24-pin connector at breakout box (insure it is snapped in correctly), check

appropriate input to breakout box for output lights which should be on

INCORRECT OR NO ARROW OPERATION

Breakout box LED’s operating correctly; Check dip switches setting in electronic control box in lightbar (after arrow dip

switch changes main power must be cycled)

No steady Red LED on breakout box; Check 24-pin connector at breakout box (insure it is snapped in correctly), check

appropriate input to breakout box for output lights which should be on

Arrow direction incorrect; Change passenger/drivers side dip switch SW4 in electronic control box in lightbar

(after arrow dip switch changes main power must be cycled)

8-wire control not operating; Check dip switch setting SW1-3 (should be off, off, off) in electronic control box in

lightbar (after arrow dip switch changes main power must be cycled)

Split arrow not operating; Check dip switch SW5 (should be on) in electronic control box in lightbar (after

arrow dip switch changes main power must be cycled)

Page 15

REPLACEMENT PARTS

STANDARD REPLACEMENT PARTS

EPL PART # DESCRIPTION
PEPL9A0C Pinnacle™ Blank Alley Light - Clear Lens/No LEDs
PEPL9A1C-D Pinnacle™ Alley Light, 15° Forward Facing, Driver Side - Clear Lens/White LEDs
PEPL9A1C-P Pinnacle™ Alley Light, 15° Forward Facing, Passenger Side - Clear Lens/White LEDs
PEPL9A2C Pinnacle™ Alley Light, Standard - Clear Lens/White LEDs
PEPL9BBHNS Pinnacle™ Breakout Box Harness, 12" Length
PEPL9BBHNL Pinnacle™ Breakout Box Harness, 36" Length
PEPL9CNTRL1 Pinnacle™ Motherboard, 12 volt
PEPL9CS12AA Pinnacle™ Corner Module - Amber Lens/Amber LEDs
PEPL9CS12AC Pinnacle™ Corner Module - Clear Lens/Amber LEDs
PEPL9CS12BB Pinnacle™ Corner Module - Blue Lens/Blue LEDs
PEPL9CS12BC Pinnacle™ Corner Module - Clear Lens/Blue LEDs
PEPL9CS12GC Pinnacle™ Corner Module - Clear Lens/Green LEDs
PEPL9CS12RC Pinnacle™ Corner Module - Clear Lens/Red LEDs
PEPL9CS12RR Pinnacle™ Corner Module - Red Lens/Red LEDs
PEPL9CS12WC Pinnacle™ Corner Module - Clear Lens/White LEDs
PEPL9HL6C Pinnacle™ Take Down/Work Light Module - Clear Lens/White LEDs
PEPL9L00A Pinnacle™ Blank Inboard Module - Amber Lens/ No LEDs
PEPL9L00B Pinnacle™ Blank Inboard Module - Blue Lens/ No LEDs
PEPL9L00C Pinnacle™ Blank Inboard Module - Clear Lens/ No LEDs
PEPL9L00R Pinnacle Blank Inboard Module - Red Lens/ No LEDs
PEPL9LLD(xx) Pinnacle™ Directional Inboard Module - (Lens Color / LED Color)
PEPL9LLSAA Pinnacle™ Inboard Module - Amber Lens/Amber LEDs
PEPL9LLSAC Pinnacle™ Inboard Module - Clear Lens/Amber LEDs
PEPL9LLSBB Pinnacle™ Inboard Module - Blue Lens/Blue LEDs
PEPL9LLSBC Pinnacle™ Inboard Module - Clear Lens/Blue LEDs
PEPL9LLSGC Pinnacle™ Inboard Module - Clear Lens/Green LEDs
PEPL9LLSRC Pinnacle™ Inboard Module - Clear Lens/Red LEDs
PEPL9LLSRR Pinnacle™ Inboard Module - Red Lens/Red LEDs
PEPL9LLSWC Pinnacle™ Inboard Module - Clear Lens/White LEDs

PEPL9LLSFC Pinnacle™ Dual Color Arrow Module, Clear Lens – White/Amber
PEPL9LLSKC Pinnacle™ Dual Color Arrow Module, Clear Lens – Red/Amber
PEPL9LLSMC Pinnacle™ Dual Color Arrow Module, Clear Lens – Blue/Amber
PEPL9LLSPC Pinnacle™ Dual Color Arrow Module, Clear Lens – Green/Amber
PEPL9LLSZC Pinnacle™ Dual Color Arrow Module, Clear Lens – No LEDs/Amber

PEPL9LLSJC Pinnacle™ Dual Color Warning Module Clear Lens - Red/Blue
PEPL9LLSNC Pinnacle™ Dual Color Warning Module Clear Lens - Blue/Green
PEPL9RFGR Roof Wire Grommet for External Break Out Box on Pinnacle Lightbars
PETLJ00 External Breakout Box for ETL 5000 & Pinnacle Lightbars
PETLK00 Adjustable Height Mounting Bracket (1 bracket) for use w/ ETL 5000 & Pinnacle Lightbars
PETLK04
PETLMX1
PETLM00
PETLM(nn)
PETLR00
PEPL9GTT1C Opticom™ Preemption Module
PEPL9RFGR2 Roof Grommet
PEPL9GTTHN Harness
PEPL9LLH12(x)C Pinnacle™ High Diode Dual Color Rear Arrow Module

PEPL9LLD9(xx) Pinnacle™ High Diode Dual Color Rear Arrow Module
PEPL9LLB(xx) Pinnacle (EPL9000) Inboard Module w/ Fusion Boost technology - (Lens Color/ LED Color)
PEPL9CR12(xx) Pinnacle (EPL9000) Corner Module - (Lens Color/ LED Color)

*Hook Kit Compatibility Chart available at www.soundoffsignal.com.

Low Profile Fixed Height Mounting Bracket (1 bracket) for use w/ ETL 5000 & Pinnacle Lightbars
Hook Kit Extension for use w/ Adjustable Height Bracket on ETL 5000 & Pinnacle Lightbars
Permanent Mount Hardware for the Adjustable Height Bracket for use w/ ETL 5000 & Pinnacle Lightbars
Adjustable Height Bracket Hook Kit for ETL 5000 or Pinnacle Lightbars:*
Permanent Mount Hardware for the Low Profile Fixed Height Bracket for use w/ ETL 5000 & Pinnacle Lightbars

Corner LED Assembly

Inboard Module

Takedown/Work Light Module

Fusion Boost Techology

Takedown/Worklight Optic

Alley Light Assembly

Opticom Preemption Module

Page 16

WARRANTY & RETURN GOODS PROCEDURE

To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product please visit our website at
www.soundoffsignal.com and select the “Warranty & Returns” link along the left column of our home page. If you have questions regarding this
product please contact Technical Services, Monday - Friday, 8 am to 5 pm at 1.800.338.7337, press #4 to skip the automated message. Questions
or comments that do not require immediate attention may be emailed to [e-mail]. 1.800.338.7337. /
www.soundoffsignal.com / Thank you for trusting us with your safety!

Warranty Return Process

Please contact your SoundOff Signal Sales Representative, Customer Services staff or our Technical Department (800.338.7337) for a RMA#
(Return Merchandise Authorization) number.

The following information is required for issuance of the RMA#:

• Reason for returning the product*

• Address where replacement product is to be shipped*

• Telephone number where you may be reached*

• SoundOff Signal invoice number on which product was purchased**

• SoundOff Signal part number and serial number**

• E-mail address where RMA# should be e-mailed**

• Fax number where RMA# should be faxed**

SoundOff Signal will NOT accept returns without an RMA#. Each RMA# is good for only one (1) item and will expire (7) days after the date it
was issued. Products must be shipped back to SoundOff Signal and the RMA# clearly marked on the outside of the package near the shipping
label. Please use the following address on your shipping label:
ATTN.: RMA#
SoundOff Signal
3900 Central Parkway
Hudsonville, MI 49426

Please see reverse side for manufacturer warranty.

Warranty Exclusions

Shipping & Handling, labor and service fees are non-refundable. SoundOff Signal is not liable for any damage due to installation or personal injury as
a result of using SoundOff Signal product.

Warranty Forfeiture

Warranty will not be granted if the Warranty Return Policy & Procedure rules are not strictly followed. Physical damage resulting from customer
abuse will void warranty. Warranty will also be voided if any SoundOff Signal and/or manufacturer serial tags, product stickers, seals, or the like,
are removed, altered or tampered with. Returned product that is damaged by shipping via the RMA# procedure is not the responsibility of
SoundOff Signal.

* RMA# will not be given without this information.
** If available, please provide this information.

Document effective date on cover and below supersedes previously dated policies and statements.

There are no other warranties, expressed or implied, including, but not limited to, any implied merchantability or fitness for a particular use.
SoundOff Signal reserves the right to modify this warranty statement at any time; or to discontinue, modify, or upgrade any products of its
manufacture with design improvements without prior notice.

ISO-9001 Registered ©2012 SoundOff Signal Emergency Technology Inc. dba SoundOff Signal

Printed in the USA / All Rights Reserved / Specifications subject to change without notice.

PO Box 206 / 3900 Central Parkway / Hudsonville, MI 49426

toll free 800.338.7337 / office 616.896.7100 / order fax [phone] / www.soundoffsignal.com

EPL9000-B 11.14

PRODUCT MAINTENANCE

CLEANING:

Keeping the lenses clean and scratch free will optimize the performance of the lightbar. To clean use a soft

cotton cloth and mild soapy water to clean dirt and insects off from the lenses. Never use window
cleaners or harsh chemicals on the lenses; this may cause failure of the lenses or reduce clarity resulting

The exterior of the lightbar also should be cleaned with mild soapy water and a soft cotton cloth.

MOUNTING INTEGRITY:

A review of bolt/hardware/mounting bracket integrity should be performed at the

in the reduction of light output.

beginning and end of each shift.

NOTES

Page 17

WARRANTY & RETURN GOODS PROCEDURE

To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product please visit our website at
www.soundoffsignal.com and select the “Warranty & Returns” link along the left column of our home page. If you have questions regarding this
product please contact Technical Services, Monday - Friday, 8 am to 5 pm at 1.800.338.7337, press #4 to skip the automated message. Questions
or comments that do not require immediate attention may be emailed to [e-mail]. 1.800.338.7337. /
www.soundoffsignal.com / Thank you for trusting us with your safety!

Warranty Return Process

Please contact your SoundOff Signal Sales Representative, Customer Services staff or our Technical Department (800.338.7337) for a RMA#
(Return Merchandise Authorization) number.

The following information is required for issuance of the RMA#:

• Reason for returning the product*

• Address where replacement product is to be shipped*

• Telephone number where you may be reached*

• SoundOff Signal invoice number on which product was purchased**

• SoundOff Signal part number and serial number**

• E-mail address where RMA# should be e-mailed**

• Fax number where RMA# should be faxed**

SoundOff Signal will NOT accept returns without an RMA#. Each RMA# is good for only one (1) item and will expire (7) days after the date it
was issued. Products must be shipped back to SoundOff Signal and the RMA# clearly marked on the outside of the package near the shipping
label. Please use the following address on your shipping label:
ATTN.: RMA#
SoundOff Signal
3900 Central Parkway
Hudsonville, MI 49426

Please see reverse side for manufacturer warranty.

Warranty Exclusions

Shipping & Handling, labor and service fees are non-refundable. SoundOff Signal is not liable for any damage due to installation or personal injury as
a result of using SoundOff Signal product.

Warranty Forfeiture

Warranty will not be granted if the Warranty Return Policy & Procedure rules are not strictly followed. Physical damage resulting from customer
abuse will void warranty. Warranty will also be voided if any SoundOff Signal and/or manufacturer serial tags, product stickers, seals, or the like,
are removed, altered or tampered with. Returned product that is damaged by shipping via the RMA# procedure is not the responsibility of
SoundOff Signal.

* RMA# will not be given without this information.
** If available, please provide this information.

Document effective date on cover and below supersedes previously dated policies and statements.

There are no other warranties, expressed or implied, including, but not limited to, any implied merchantability or fitness for a particular use.
SoundOff Signal reserves the right to modify this warranty statement at any time; or to discontinue, modify, or upgrade any products of its
manufacture with design improvements without prior notice.

ISO-9001 Registered ©2012 SoundOff Signal Emergency Technology Inc. dba SoundOff Signal

Printed in the USA / All Rights Reserved / Specifications subject to change without notice.

PO Box 206 / 3900 Central Parkway / Hudsonville, MI 49426

toll free 800.338.7337 / office 616.896.7100 / order fax [phone] / www.soundoffsignal.com
