Sounding Audio MS2ABK, MS2A Users Manual

MS2A
MARINE AUDIO SYSTEM
Installation and Operation Manual
CONTENTS
Important Safety Instructions ................................................................................. 1
Introduction ............................................................................................................ 2
Installation .............................................................................................................. 4
Wiring ..................................................................................................................... 5
Basic Operation ..................................................................................................... 6
Tuner Operation ..................................................................................................... 8
MP3/USB Operation .............................................................................................. 9
iPod® Operation ................................................................................................... 10
Bluetooth Operation ............................................................................................. 12
App Operation ...................................................................................................... 13
Care and Maintenance ......................................................................................... 14
Troubleshooting ................................................................................................... 14
Specifications ....................................................................................................... 15
Copyrights and Trademarks
iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance.
ii
WARNINGS AND COMPLIANCE
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
Portable Cart Warning
WARNING! To reduce the risk of fire of electric shock, do not expose this apparatus to rain or moisture.
WARNING! The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on apparatus.
NOTE: Keep the volume low enough to be aware of your surroundings.
NOTE: USE THE PROPER POWER SUPPLY! This product is designed to operate with a12 volt DC negative ground battery system.
FCC Notes
WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the users authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power -supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
1
HARDWARE KIT CONTENTS
M5 NUT X1PCS
PANEL COVER
X2PCS
WIRE HARNESS X1PCS
MOUNTING BRACKET X1PCS
INTRODUCTION
System Features
Features of the Jensen MS2A marine audio system include:
White LED Backlit LCD
iPX5 Waterproof (after installation)
Low Battery Alarm
AM/FM US/EURO Tuner with 30 Presets (12 AM, 18 FM)
Bluetooth (Supports A2DP and AVRCP)
USB Playback of MP3/WMA files with iPod/iPhone Interface
Mute
Pre-set Equalizer - 5 settings (USER > FLAT > POP > CLASSIC > ROCK)
Electronic Bass, Treble, Balance and Fader Controls
Output Power 40W x 4
Wired Remote Control Ready (MWR150 and MWR75 sold separately)
2-Channel Pre-amp Line Level Outputs
Auxiliary Audio Input (Rear RCA)
Content List
Jensen MS2A Radio
Wire Harness
Hardware Kit
Owner’s Manual
2
SAFETY INFORMATION
When Boating
Keep the volume level low enough to be aware of your surroundings.
Protect from Water
Do not submerge the product in water, as this can cause electric shorts, fire or other damage.
Protect from the Elements
Use the included cover to protect the wired commander from sunlight, dust, and water while not in use.
Protect from High Temperatures Do not mount radio within close proximity of engine compartment.
Use the Proper Power Supply
This product is designed to operate with a 12 volt DC negative ground battery system.
CAUTION:
DO NOT OPEN COVERS AND DO NOT REPAIR BY YOURSELF. PLEASE REFER SERVICING TO A QUALIFIED TECHNICIAN.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND INTERFERENCE, USE ONLY THE RECOMMENDED ACCESSORIES.
3
INSTALLATION
Before You Begin
Before you begin, always disconnect the negative battery terminal.
Important Notes
Before final installation, test the wiring connections to make sure the unit is connected properly and the system works.
Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions.
Consult with your nearest dealer if installation requires the drilling of holes or other modifications to your vessel.
Install the unit where it does not interfere with operating the vessel and cannot injure passengers if there is a sudden or emergency stop.
Avoid installing the unit where it will be subject to high temperatures from direct sunlight, hot air, or from a heater, or where it would be subject to excessive dust, dirt or vibration.
Front Mount
1. Check the dashboard opening size by sliding the radio into it. If the opening is not large enough, carefully cut or file as necessary until the radio slides into the opening. Check that there will be sufficient space behind the dashboard for the radio chassis.
CAUTION: The rear of the radio must be supported with the strap to prevent damage to the radio and supporting structures.
2. Place the radio in front of the dashboard opening so the wiring can be brought through the opening.
3. Follow the wiring diagram carefully and make certain all connections are secure to ensure proper operation.
4. After completing the wiring connections, turn the unit on to confirm operation (vessel accessory switch must be on). If the unit does not operate, recheck all wiring until the problem is corrected. Once proper operation is achieved, turn the accessory switch off and proceed with final mounting of the chassis.
5. Carefully slide the radio into the opening, making sure it is right-side-up.
6. Secure the radio to the dashboard using the M5 x 25mm screws provided.
7. Replace the covers on either side of the radio.
8. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using the hex nut and spring washer provided. Fasten the other end of the perforated strap to a secure part of the dashboard either above or below the radio using the screw and plain washer provided. Bend the strap, as necessary, to position it.
9. Test radio operation by referring to the operating instructions for the unit.
Removing the Unit
To remove the radio after installation, remove the covers, unscrew the installation screws and pull the radio out.
Removing Battery
When wiring is complete, reconnect the battery negative terminal.
4
POWER SOCKET
SHOWN FROM PIN VIEW
PIN DESCRIPTION
WIRE COLOR
A1
RIGHT REAR SPEAKERS (+)
PURPLE
A2
RIGHT FRONT SPEAKERS (+)
GRAY
A3
LEFT FRONT SPEAKERS (+)
WHITE
A4
LEFT REAR SPEAKERS (+)
GREEN
A5
LEFT REAR SPEAKERS (-)
GREEN/BLACK
A6
LEFT FRONT SPEAKERS (-)
WHITE/BLACK
A7
RIGHT FRONT SPEAKERS (-)
GRAY/BLACK
A8
RIGHT REAR SPEAKERS (-)
PURPLE/BLACK
B1
NO CONNECTION
EMPTY
B2
NO CONNECTION
EMPTY
B3
AMP REMOTE (+12VDC 100mA)
BLUE
B4
NO CONNECTION
EMPTY
B5
GROUND
BLACK
B6
NO CONNECTION
EMPTY
B7
+12VDC SWITCHED
RED
B8
NO CONNECTION
EMPTY
WIRING
5
BASIC OPERATION
Power On/Off
Press any button on the front panel to turn the unit on. Press the power button (1) to turn the unit on/off.
Volume Control
To increase the volume, press the VOL+ UP button (2a). To decrease the volume, press the DOWN VOL- button (2b).
Mute
Press the MUTE button (17) on the control panel to mute the audio output. Press MUTE again to restore the audio output to the previous level.
Mode
Press the MODE button (4) on the control panel to select a different mode of operation, as indicated on the display panel. Available modes include Tuner, iPod, USB, AUX In (optional Auxiliary Input) and BT Audio.
Reset
The reset button should be activated for the following reasons:
initial installation of the unit when all wiring is completed
function buttons do not operate
error symbol on the display
Use a ball point pen or similar object to press the RESET button (19). This may be necessary should the unit display an error code.
You can recover factory default settings using the RESET function located on the system menu. With “RESET” flashing, press the ENTER button (18) to activate.
Audio Menu
Press the AUDIO/MENU button (3) on the control panel to access the audio menu. You can navigate through the audio menu items by pressing the AUDIO/MENU button repeatedly. Once the desired menu item appears on the display, adjust that option by pressing the VOL+ UP or DOWN VOL- buttons (2) within 5 seconds. The unit will automatically exit the audio menu after five seconds of inactivity. The following menu items can be adjusted.
Bass Level
Use the VOL buttons to adjust the Bass level range from “-6” to “+6”.
Treble Level
Use the VOL buttons to adjust the Treble level range from “-6” to “+6”.
Balance
Use the VOL buttons to adjust the Balance between the left and right speakers from “L12” (full left) to “R12” (full right).
Fader
Use the VOL buttons to adjust the Fader between the rear and front speakers from “R12” (full rear) to “F12” (full front).
System Menu
1. Press and hold the AUDIO/MENU button (3) for more than 3 seconds to enter the system menu. “MENU” will appear on the display, followed by the first menu item, “CONTRAST.”
2. Press the ►►| SEEK/TUNE/TRK or |◄◄ SEEK/TUNE/TRK button (14, 13) or press the AUDIO/MENU button repeatedly to navigate the system menu and select the desired item.
3. Press the VOL+ UP or DOWN VOL- buttons (2) to adjust the selected menu item.
4. Press the AS/PS button (15) to return to the previous operation.
The following items can be adjusted:
CONTRAST (00 – 10): Set LCD contrast.
LOW BATT (ON/OFF): Monitor voltage on ACC line.
DISTANT/LOC: “Local” mode favors access to local stations whose signals
are much stronger, thereby improving reception. Select “Distant” to terminate local receive mode and resume normal mode.
AREA (USA/Latin/Europe): Set frequency spacing for various regions.
VOL PGM (00 – 46): Select an automatic turn-on volume.
BEEP TONE (ON/OFF): Turn the audible beep ON/OFF (heard when
functions/buttons are selected). NOTE: Beep tone off will not affect LOW
6
BATT audible tone.
LCD BRIT (01 – 10): Adjust LCD brightness.
BT ON/OFF: Choose “BT ON” or “BT OFF”.
BT PAIR (ON/OFF): Choose “YES” to automatically pair a previously paired
device.
BT DEVICE (Lock/Unlock, Disconnect/Connect, Delete): View, lock and delete from a list of previously paired mobile phone device models.
RESET: Return the EEPROM to factory default set up values. "RESET" will blink on the
LCD to confirm. Press the ENTER button (18) to select.
NOTE: BT Pair and BT Device menu options are only available while in the BT mode.
LOW BATTERY Operation
If LOW BATT is set to “ON”, an alarm will sound (8 beeps every 30 sec) when the
voltage drops to 10.8V (+/- 0.3V). A visual warning (LOBA) will appear flashing (8 flashes every 30 sec) in the lower left corner of the LCD display.
NOTE: “OFF” is the default setting for LOW BATT. If the audio is muted or
the volume is set to 0, the audible beep will not be heard.
2. Press the MODE button (4) twice to view the AUX option.
3. Press MODE again to cancel Aux In mode and switch to the next mode.
Liquid Crystal Display (LCD)
The current frequency and activated functions are shown on the LCD panel (20).
NOTE: LCD panels may take longer to respond when subjected to cold temperatures for an extended period of time. In addition, the visibility of the numbers on the LCD may decrease slightly. The LCD display will return to normal when the temperature increases to a normal range.
Quick Exit Hot Key
In the following modes and conditions, press the AS/PS button (15) < 3 seconds to quickly exit the current operation without waiting for the system default time out:
System menu operation
Searching mode
Audio menu operation
Equalizer
Press the EQ/LOUD button (11) to turn on the equalization function and select between five pre-defined bass and treble curves: USER > FLAT > POP > CLAS > ROCK.
Loudness
Press and hold the EQ/LOUD button (11) to toggle true loudness on/off. When listening to music at low volumes, this feature will boost the bass and treble ranges to compensate for the characteristics of human hearing.
Auxiliary Input
To access an auxiliary device:
1. Connect the portable audio player to the AUX IN cables routed from the rear of the radio.
7
TUNER OPERATION
Select a Band
Press the BAND/SEARCH button (16) to change between three FM bands and two AM (MW) bands.
Manual Tuning
Press the ►►or◄◄ buttons (14, 13) to seek stations up/down step by step.
Auto Seek Tuning
Press and hold the ►►| SEEK/TUNE/TRK or |◄◄ SEEK/TUNE/TRK buttons (14, 13) to automatically seek the next or previous strong station.
Automatically Store / Preset Scan (AS/PS )
Automatically Store
Select a band (if needed). Press and hold the AS/PS button (15) for more than three seconds to automatically select six strong stations and store them in the current band. The new stations replace any stations already stored in that band.
NOTE: During Auto Store (AS), the tuner will default to “Local” mode while
scanning the band initially. After scanning the entire band once, the unit will switch to “Distant” mode for all subsequent Auto Store tuning.
Preset Scan
Select a band (if needed). Press the AS/PS button (15) to scan stations stored in the current band. The unit will pause for ten seconds at each preset station. Press AS/PS again to stop scanning when the desired station is reached.
Preset Stations
Six numbered preset buttons store and recall stations for each band.
Store a Station
Select a band (if needed), then select a station. Press and hold a preset button (5-10) for two seconds. The preset number will appear in the display.
Recall a Station
Select a band (if needed). Press a preset button (5-10) to select the corresponding stored station.
8
MP3/USB OPERATION
MP3 Specifications
A directory that does not include an MP3 file is skipped.
Maximum number of folders: 512 (including skipped directories)
Maximum number of folder levels: 12
Maximum number of MP3 files: 999
Maximum number of characters for MP3 file name and folder name: 32
Sampling frequency: 16KHz, 22.05KHz, 24KHz, 32KHz, 44.1KHz, 48KHz.
Bit rates: maximum 384 Kbps.
Maximum number of Characters of ID3 Tag:
ID3 Tag version 1.0: 32
ID3 Tag version 2.x: 32
NOTE: USB flash drives with a capacity of up to 64 GB are supported.
Inserting and Removing a USB Device
Inserting a USB Device
Insert the USB device into the USB connector routed from the rear of the radio
and display will show the “Loading…” message. The unit will read the files on the
USB device automatically.
Removing a USB Device
Press the MODE button (4) to select another mode and then remove the USB device from the USB connector.
NOTE: After loading a USB device, files and folders are accessed in the order in which they were written to the device. Therefore, the playing order may not be the same as the order in which they are expected to be played.
Controlling Playback
Pause/Play
Press the 1/|| button (5) to suspend playback. Press the 1/|| button again to resume playback.
Track Select
Press the ►►| SEEK/TUNE/TRK or |◄◄ SEEK/TUNE/TRK buttons (14, 13) button for less than one second to advance to the next file, or press and hold to fast forward or fast reverse. Playback begins when the button is released.
Repeat (RPT)
Press the 2/RPT button (6) to repeatedly play the current file. Press 2/RPT again to repeat all songs in the current folder. Press 2/RPT a third time to resume normal playback.
Intro Scan (INT)
Press the 3/INT button (7) once to play the first 10 seconds of each file in the current folder. Press 3/INT again to play the first 10 seconds of each file on the current device. When the desired file is reached, press 3/INT a third time to end the scan and play the selected file.
Random (RDM)
Press the 4/RDM button (8) to randomly play all files in the current folder. Press 4/RDM again to randomly play all files on the device. Press 4/RDM a third time to
resume normal playback.
Navigating Folders
Press the 5 button (9) to move to the previous folder and begin playback of the first song in the folder. Press the 6 button (10) to advance to the next folder and begin playback of the first song in the folder.
Alternate Display Information
Press the DISP button (12) to change the display information in the following order: ALBUM >SONG TITLE > ARTIST > FILE X of Y > ALBUM.
MP3/WMA Directory Search
1. Press the BAND/SEARCH button (16) to enter directory search mode.
2. Press the ENTER button (18) to confirm search mode. The LCD will display the folder list.
3. Navigate the folder list by pressing the VOL+ UP or DOWN VOL- buttons (2).
4. Press the ENTER button to select a folder. The LCD will display the list of files within that folder.
5. Navigate the file list by pressing the VOL+ UP or DOWN VOL- buttons.
6. Press the ENTER button to select a file.
9
iPOD® OPERATION
This unit is equipped with an iPod ready function that will allow you to control your iPod (if compatible) using the control panel buttons. The following iPod versions are supported:
iPod Nano – 6G, 7G
iPod Classic
iPod Touch – 4G, 5G
iPhone – 4, 4S, 5, 5C, 5S
NOTE: Earlier model iPods may not be supported because they do not implement the USB control protocol. The iPod Shuffle is not supported because it does not utilize the 30-pin Apple iPod Connector. These unsupported iPod models may be connected to the radio using one of the Auxiliary Inputs.
Accessing iPod Mode
Connect a supported iPod or iPhone to the USB connector. The iPod icon illuminates in the bottom right left corner of the LCD whenever an iPod or iPhone is attached to the USB connector. Music playback begins automatically.
To enter iPod mode from any other source, press the MODE button (4) until “USB” appears on the display. If the user connects an iPod containing no songs, the
radio will display a message stating “No Songs” when it enters iPod mode.
Turning the iPod On/Off
The iPod power turns on automatically when an iPod is connected to the USB connector, as long as the vehicle ignition is turned on. You can turn the iPod off by disconnecting it or by turning the ignition off. When the ignition is turned off, the iPod will pause and then enter sleep mode after 2 minutes. While the iPod is connected, the power cannot be turned on or off from the iPod itself.
NOTE: The iPod will continuously recharge when connected to the unit, as long as
the vehicle ignition is turned on.
Controlling Playback
Selecting Tracks
During playback, press the ►►| SEEK/TUNE/TRK button (14) to play the next track in the current category. Press the |◄◄ SEEK/TUNE/TRK button (13) twice to play the previous track. After the first 2 seconds of the playback. Press and hold the ►►| SEEK/TUNE/TRK or |◄◄ SEEK/TUNE/TRK buttons to fast reverse/forward the song.
Pausing Playback
During playback, press the 1/|| button (5) to pause playback. “Pause” will appear on the LCD. Press 1/|| button again to resume playback.
Repeat Play
During playback, press the 2/RPT button (6) to repeat the current song. “REPEA will appear on the LCD. Press 2/RPT again to stop repeat playback.
Random Play
During playback, press the 4/RDM button (8) to play all songs in the current category in random order. Random play will begin once the current song has finished playing. “SHUFF” will appear on the LCD. Press 4/RDM again to stop random playback.
NOTE: If you press and hold the ►►|SEEK/TUNE/TRK or |◄◄SEEK/TUNE/TRK button to change the current song to the
previous/next song, you will exit fast reverse/forward mode.
10
Alternate Display Information
Press the DISP button (12) to change the display information in the following order: ARTIST >TITLE > FOLDER > FILE NAME > ARTIST.
Search Mode
Press and hold the BAND/SEARCH button (16) to enter iPod search mode and choose from the following search criteria: Playlist, Artist, Album, Song, Genre or Composer (consecutively). When search mode is selected, press the ENTER button (18) to confirm selection. Use the VOL+ UP or DOWN VOL- button (2) to navigate through various list selections. Press ENTER (18) to make your final selection.
11
Device 1
Device 5
BT Device
Press Enter
Device 1
Device 5
Lock/Unlock
Connect/Disconnect
Delete
Lock/Unlock
Connect/Disconnect
Delete
Press Enter
Use VOL+ UP or
Navigate the List
BLUETOOTH OPERATION
The MS2A includes built-in Bluetooth technology that allows you to wirelessly connect Bluetooth devices to this head unit for streaming audio playback.
About Bluetooth Technology
Bluetooth is a short-range wireless radio protocol. Operating in the 2.4 GHz range, it transmits voice and data at speeds up to 2.1 Mbit/s over a range of up to 10 meters.
Bluetooth Menu Options
NOTE: Please note that some BT menu options are only available while the unit is in BT Audio mode
Press and hold the AUDIO/MENU button (3) to enter menu adjustment mode. Repeatedly press the AUDIO/MENU button to access the following Bluetooth Menu options:
BT ON/OFF: Press the VOL+ UP or DOWN VOL- button (2) to choose “BT ON” or “BT OFF”.
BT PAIR: Press the VOL+ UP or DOWN VOL- button to choose “ON or OFF, and then press the ENTER button to enter the selection.
BT DEVICE: Press the ENTER button to view devices from the list. Press the
VOL+ UP or DOWN VOL- buttons (2a, 2b) to view a list of previously paired mobile devices. Press the ENTER button to select the device. Press the VOL+ UP or DOWN VOL- button to choose Lock/Unlock, Disconnect or Delete for this device. You cannot delete a device that is actively connected.
LOCK/UNLOCK: The MS2A can store up to 5 devices for BT
connection. The devices are stored in FIFO (First in First Out) order. To prevent a device from being bumped from the list when more than 5 devices are used, you must lock the device. To Lock/Unlock a device, press the ENTER button to display/change the Locked ( ) or Unlocked ( ) icon.
DISCONNECT: To disconnect a paired device, press the ENTER
button to temporarily remove the BT link. The link can be re-established through your phone menu by selecting the MS2A for connection.
DELETE: To delete a device from the list, press the ENTER button.
DOWN VOL- to
Device 2 Device 3 Device 4
… … …
Pairing a Bluetooth Device
Before you begin, consult the owner’s manual for the Bluetooth device you want to
pair with the MS2A.
1. Make sure the device is on and ready to receive a signal from the MS2A. With the MS2A in BT Audio mode, choose BT PAIR from the MS2A menu and press the DOWN VOL- button to select ON. The unit is waiting to connect to a mobile device. With the BT function of the mobile device turned on, search for a Bluetooth device.
2. When the Bluetooth device has completed its search, the mobile device will display the Bluetooth device name (MS2A).
3. Select MS2A. The Bluetooth Audio icon ( ) will show on the radio LCD display.
4. Enter the pairing password (0000), if requested.
After connecting successfully, you are able to listen to music stored on your Bluetooth enabled device through the radio.
12
Receiving a Call While Listening to Music
When answering a call using a connected phone, BT AUDIO will pause. After hanging up from the call, BT AUDIO will continue on some phones. It may be necessary to press the play button to resume BT AUDIO.
BT Audio (A2DP)
When connected, a Bluetooth enabled device is able to stream audio to the MS2A. To access Bluetooth mode and play songs stored on your phone, press the MODE button (4). While in BT mode , the BT AUDIO icon ( ) illuminates on the LCD.
Selecting Tracks
During playback, press the ►►| SEEK/TUNE/TRK or |◄◄ SEEK/TUNE/TRK buttons (13, 14) to play the previous or next track.
Pausing Playback
During playback, press the 1/|| button (5) to pause the BT AUDIO player. BT AUDIO || will appear on the LCD. Press 1/|| again to resume playback. If you change to another mode, the mobile phone audio will pause. Press the MODE button (4) to return to BT mode and resume mobile phone audio playback.
NOTE: If a Bluetooth device is disconnected due to the power being turned off or if the device is disconnected inadvertently, the unit will automatically search for the matching Bluetooth device when the power is restored.
APP OPERATION
JENSEN® Specialty Controller is the ultimate wireless remote control for your JENSEN stereo system. Store away your old remotes and enjoy the convenience of all the primary functions of your JENSEN stereo right from your phone or tablet by transforming your mobile device into a functional stereo remote control!
Features
This app controls all of the primary functions of your stereo features including:
Power on/off
Volume and mute
AM/FM radio tuner: access station, recall, store presets, switch songs
Bluetooth® streaming audio
File structure visibility, track selection, track audible scan up and down via
USB
iPod/iPhone/iPad® control capabilities via USB
Auxiliary audio input control –auxiliary analog 1
Audio menu controls- bass, treble, balance, fader, equalizer and volume
Visual display feedback so you can see artist title and album on your mobile
screen
Connecting and using jControl app
After downloading and installing jControl app on your apple device, pair your device to the MS2A as stated above for Bluetooth paring. Once your device is paired you can open the app and use as instructed with the jControl app manual found at http://asaelectronics.com/manuals-guides.
When jControl is installed on Android operating system, close the app before Bluetooth pairing, otherwise there may be errors on Bluetooth connection.
13
Symptom
Cause
Solution
No Power
The vessel’s accessory
switch is not on
If the power supply is properly connected to the
vessel’s accessory
terminal, switch the ignition key to “ACC”
Fuse is blown
Replace the fuse
No Sound
Volume is too low
Adjust volume to audible level
Wiring is not properly connected
Check wiring connections
The Operation keys do not work
Wired commander is not properly installed
Check wired commander installation and connection
Built-in microcontroller is not operating properly
Press the RESET button located on the back of the Tuner/Amp Module
CARE AND MAINTENANCE
Keep the product dry. If it does get wet, wipe it dry immediately. Liquids might
Keep the product away from dust and dirt, which can cause premature wear
Handle the product gently and carefully. Dropping it can damage circuit
Wipe the product with a dampened cloth occasionally to keep it looking new.
Use and store the product only in normal temperature environments. High
Ignition
The most common source of noise in reception is the ignition system. This is a result of the radio being placed close to the ignition system (engine). This type of noise can be easily detected because it will vary in intensity of pitch with the speed of the engine.
Usually, the ignition noise can be suppressed considerably by using a radio suppression type high voltage ignition wire and suppressor resistor in the ignition system. (Most vessels employ this wire and resistor but it may be necessary to check them for correct operation.) Another method of suppression is the use of additional noise suppressors. These can be obtained from most CB/A radio or electronic supply shops.
Interference
Radio reception in a moving environment is very different from reception in a stationary environment (home). It is very important to understand the difference.
AM reception will deteriorate when passing under a bridge or when passing under high voltage lines. Although AM is subject to environmental noise, it has the ability to receive at great distance. This is because broadcasting signals follow the curvature of the earth and are reflected back by the upper atmosphere.
contain minerals that can corrode the electronic circuits.
of parts.
boards and cases, and can cause the product to work improperly.
Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the product.
temperature can shorten the life of electronic devices, damage batteries, and distort or melt plastic parts.
TROUBLESHOOTING
14
SPECIFICATIONS
FM Radio
Frequency Coverage (USA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87.5 to 107.9 MHz
Frequency Coverage (Europe) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87.5 to 108 MHz
Sensitivity (S/N = 30dB) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4uV
Image Rejection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>45 dB
Stereo Separation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >25 dB
AM/MW
Frequency Coverage (USA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .530-1710 kHz
Frequency Coverage (Latin) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .520-1620 kHz
Frequency Coverage (Europe) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .522-1620 kHz
Sensitivity (S/N = 20dB) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30dB
General
Operating Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .DC 12 Volts
Grounding System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Negative Ground
Speaker Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8 ohms per channel
Tone Controls:
Bass (at 100 Hz) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..±14dB
Treble (at 10 kHz) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±13dB
Power Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40W x 4
Current Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Ampere (max.)
Chassis Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182(L) x 52.2(W) x 173(H)
Front Panel Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .188(L) x 58(W) x 21(H)
15
ASA Electronics Corporation
www.asaelectronics.com
www.jensenmarinedirect.com
© 2015 ASA Electronics Corporation
v.100615
Loading...
