Sony Ericsson
Yendo
™
with Walkman™
Extended User guide
Contents
Experience more. Discover how.................................................5
Getting started..............................................................................6
Starting your phone for the first time....................................................7
Getting to know your phone........................................................9
Phone overview...................................................................................9
Charging the battery...........................................................................9
Using the home key..........................................................................10
Home screen....................................................................................10
Applications panes............................................................................11
Using the touch screen.....................................................................12
Internet and messaging settings........................................................12
Phone settings overview....................................................................12
Entering text......................................................................................12
Contacts .....................................................................................14
Calling..........................................................................................15
Music...........................................................................................16
Walkman™ player overview..............................................................16
Walkman™ player widget..................................................................17
Walkman™ mini-player.....................................................................17
Connecting your phone to a computer....................................18
Transferring and handling content using a USB cable........................18
Camera........................................................................................19
Viewfinder and camera controls........................................................19
TrackID™ technology................................................................20
PlayNow™...................................................................................21
Multimedia and text messaging................................................22
Email............................................................................................23
Bluetooth™ wireless technology..............................................24
Phone name.....................................................................................24
Web browser...............................................................................25
Browsing the web.............................................................................25
More features.............................................................................26
Alarms..............................................................................................26
Calendar...........................................................................................26
Voicemail..........................................................................................26
Locking and protecting your phone.........................................28
IMEI number.....................................................................................28
2
This is an Internet version of this publication. © Print only for private use.
Troubleshooting.........................................................................29
Common questions...........................................................................29
Error messages.................................................................................29
Legal information.......................................................................31
Index............................................................................................32
3
This is an Internet version of this publication. © Print only for private use.
Important information
Please read the Important information leaflet before you use your mobile phone.
Some of the services and features described in this User guide are not supported in all countries/
regions or by all networks and/or service providers in all areas. Without limitation, this applies to
the GSM International Emergency Number 112. Please contact your network operator or service
provider to determine availability of any specific service or feature and whether additional access
or usage fees apply.
4
This is an Internet version of this publication. © Print only for private use.
Experience more. Discover how.
Visit
www.sonyericsson.com/support
to get the most from your phone.
5
This is an Internet version of this publication. © Print only for private use.
Getting started
1
2
To insert the SIM card
1
Remove the battery cover.
2
Slide the SIM card into its holder with the gold-coloured contacts facing down.
To insert or remove a memory card
You may have to purchase a memory card separately.
1
Insert the memory card with the gold-coloured contacts facing down.
2
To remove the memory card, press the edge of the memory card inwards and release
it immediately.
This is an Internet version of this publication. © Print only for private use.
6
To insert the battery
1
2
1
Insert the battery with connectors facing each other.
2
Attach the battery cover.
To turn on the phone
1
Press and hold down the
2
Enter your SIM card PIN, if requested, and select Done.
3
At first startup, follow the setup instructions that appear.
key on the top of your phone.
Your PIN is supplied by your network operator. If you want to correct a mistake made while
entering your SIM card PIN, press
.
To turn off the phone
•
Press and hold the key on the top of the phone until the phone turns off.
To lock the screen
•
When the screen is active, briefly press the
key.
To unlock the screen
•
When the screen is locked, briefly press the key.
Starting your phone for the first time
The first time you start your phone, a setup wizard helps you enter essential phone settings.
Follow the steps to select your language, import your SIM contacts, and set the time and
date, respectively. If you prefer, you can skip some steps and access the setup wizard later
from the phone settings menu.
To set the phone language
1
When you start your phone for the first time, a list of languages appears. Scroll
through the list and select your language.
2
Tap Done.
To import contacts from a SIM card
•
When you start your phone for the first time with a SIM card inserted, the setup
wizard prompts you to import your SIM contacts. Tap Import contacts.
When you copy contacts between two phones using your SIM card, the amount and the type of
information you can transfer for each contact is limited. To get more help on how to copy
contacts between two phones, go to
This is an Internet version of this publication. © Print only for private use.
www.sonyericsson.com/support
7
.
To set the time and date
1
When you start your phone for the first time, the setup wizard prompts you to set
the time and date. Tap Time & date.
2
Find and tap Time.
3
Tap the hour and minute fields to adjust the time.
4
Tap Save.
5
Find and tap Date.
6
Tap the day, month and year fields to adjust the date.
7
Tap Save.
While setting the time and date, you can also select your preferred time and date display formats.
Tap Time format or Date format to select a desired format.
8
This is an Internet version of this publication. © Print only for private use.
Getting to know your phone
5
8
6
1
2
3
4
7
9
10
11
Phone overview
1 3.5 mm Audio Video Plus connector
2 Power key/screen lock
3 Ear speaker
4 Strap hole
5 Connector for charger/USB cable
6 Touch screen
7 Home key
8 Microphone
9 Volume key
10 Camera lens
11 Speaker
Charging the battery
Your phone battery is partly charged when you buy the phone. It may take a few minutes
before the battery icon appears on the screen when you connect the phone charger
cable to a power source, such as a USB port or a phone changer. You can still use your
phone while it is charging.
The battery will start to discharge a little after it is fully charged and then charges again after a
certain time. This is to extend battery life and may result in the charge status showing a level
below 100 percent.
This is an Internet version of this publication. © Print only for private use.
9
1
2
To charge the phone using the power adapter
•
Connect the phone to a power outlet using the USB cable and the power adapter.
Using the home key
To go to the home screen
•
Press the home key.
Home screen
The Home screen is your gateway to the main features in your phone. You can customise
it with different application icons, shortcuts, wallpaper and more. The Home screen
extends beyond the regular screen display width, giving you more room to play with.
Close your opened applications before going to the
may stay running in the background and slow down your phone.
Home screen. Otherwise, these applications
10
This is an Internet version of this publication. © Print only for private use.
Januar
, 2
0
0
Applications panes
Use the applications panes to get quick access to applications in your phone. You can also
customise your panes. Remember that applications panes extend beyond the regular
screen dimensions, so you might have to flick left or right to see everything.
An indicator at the top of the screen shows which of the applications panes you are in. For
example, indicates you are in the middle applications pane.
To open the applications panes
There are two ways to open the applications panes:
•
From the Home screen, drag upwards.
•
Flick upwards from any location on the Home screen.
To browse the applications panes
•
From the applications panes, flick right or left.
To move an application
1
From the Home screen, drag
2
Touch and hold an item until application icons appear in four corners of the screen.
3
Drag the item into one of the corners, or into another applications pane.
The items in the applications panes are the actual applications, and are not shortcuts. So if you
move an item from one applications pane to another location, you are moving the actual
application, and not creating a shortcut.
upwards.
11
This is an Internet version of this publication. © Print only for private use.
Using the touch screen
To open or highlight an item
•
Tap the item.
To mark or unmark options
•
Tap the relevant checkbox, or in some cases tap the switch beside the option name.
Marked checkbox
Unmarked checkbox
Switched on
Switched off
To go back to the previous screen
•
Tap , when this option is available.
Scrolling
Scroll by moving your finger up or down on the screen. On some web pages you can also
scroll to the sides.
Dragging or flicking will not activate anything on the screen.
Internet and messaging settings
For most mobile phone networks and operators, messaging and Internet settings come
preinstalled on your phone. In some cases the settings are downloaded the first time you
turn on the phone with your SIM card inserted.
You can manually add and change Internet and network settings in your phone at any time,
or you can get the settings sent to your phone automatically. Contact your network operator
if you need more information about your subscription settings.
Phone settings overview
You can customise some phone settings to suit your preferences. For example, you can
adjust the Time & date and Phone language settings.
To change the phone language
1
From the Home screen, drag upwards.
2
Find and tap Settings > Language and writing > Phone language.
3
Select an option.
If you choose the wrong language and cannot read the menu texts, go to
www.sonyericsson.com/support
To turn on Flight mode
1
From the Home screen, drag
2
Find and tap Settings > General.
3
Select Flight mode.
for help.
upwards.
Entering text
There are two text input methods: multitap and quick text . Quick text input uses the inphone dictionary to help you spell words.
12
This is an Internet version of this publication. © Print only for private use.
To display the keypad and enter text
•
Tap a text field to display the keypad, then enter your text.
To shift between upper-case and lower-case letters
•
Before you enter a letter, tap .
To turn on the caps lock
•
Before you type a word, tap until appears.
To enter numbers using the keypad
•
When you enter text, tap . A keypad with numbers appears.
To insert symbols
•
When you enter text, tap . A keypad with symbols appears.
To change the writing language
1
When you enter text, tap the language icon, for example, .
2
Select an option.
To enter text using multitap text input
1
When you enter text, tap the language icon, for example,
2
Tap Multitap to change to multitap input.
3
To write a word, tap the character key as many times as needed to show the letter
.
you want.
To enter text using quick text input
1
When you enter text, tap the language icon, for example, .
2
Tap Quick text to change to quick text input.
3
To write a word, tap each character key only once, even if the letter you want is not
the first letter on the key.
4
Tap the word that appears or tap
5
If the word you want is not in the list, tap Spell, make any necessary changes, and
to select a word from the list.
tap Save.
13
This is an Internet version of this publication. © Print only for private use.
Contacts
Use the Contacts application to save information about the people you know. Enter their
phone numbers, email addresses, birthdays and other details. You can keep track of all
communication with a particular contact.
To call a contact
1
From the Home screen, tap .
2
Tap the contact.
3
Tap the desired phone number for the contact.
To add a contact
1
From the Home screen, tap .
2
Tap Add contact.
3
Tap Name, enter the name and tap Done.
4
Tap Phone number, enter the phone number and tap Done.
5
Enter or select the desired additional information for the contact, then scroll up and
tap Save. To add additional information fields, tap Add more.
You can also add contacts from numbers in your call log.
To back up contacts on a memory card
1
From the Home screen, drag
2
Tap Settings > Contacts > Back up to memory card.
upwards.
To restore contacts from a memory card
1
From the Home screen, drag upwards.
2
Tap Settings > Contacts > Restore from memory card.
14
This is an Internet version of this publication. © Print only for private use.
Calling
To make an emergency call
1
From the Home screen, tap .
2
Enter the emergency number and tap . To delete a number, tap .
You can make emergency calls when no SIM card is inserted.
To make a call
1
From the Home screen, tap .
2
If the call log appears, tap to enter the dial pad view.
3
Enter the number you want to call and tap
To answer a call
•
Drag to the left until it touches .
To decline a call
•
Drag to the right until it touches .
. To delete a number, tap .
To end a call
•
Tap .
15
This is an Internet version of this publication. © Print only for private use.
Music
02:53
Jason Dgrewer
Talent
1
2
3
4
7
6
8
5
Get the most out of your Walkman™ player. Listen to music, audio books and podcasts.
Manage your own playlists, and send your favourite tunes to friends.
Install the Media Go™ application on your computer and transfer content to and from the
memory card in your phone. Media Go™ can be downloaded from
www.sonyericsson.com/support
Walkman™ player overview
.
1 Browse the music on your memory card
2 Cover art (if available)
3 Go to the previous track in the current play queue, or rewind
4 Play/pause button
5 Progress indicator: fast forward or rewind by dragging or tapping
6 Current track time remaining
7 Go to the next track in the current play queue, or fast forward
8 View the current play queue
To play audio content
1
From the Home screen, tap .
2
Tap .
3
Tap to browse audio by artist. Tap to browse audio by playlist. Tap to browse
audio by track.
4
Scroll up or down and browse to a track.
5
Tap a track to play it.
To pause a track
•
In the Walkman™ player, tap .
To fast forward and rewind music
•
In the Walkman™ player, touch and hold or .
You can also drag the progress indicator marker right or left.
16
This is an Internet version of this publication. © Print only for private use.
To send or delete a track
1
In the Walkman™ player, tap the cover art for a particular track.
2
Selete an option.
To play smart playlists
1
In the Walkman™ player, tap
2
Tap .
3
Under Smart playlists, tap a playlist.
4
Tap a track to play it.
To adjust the audio volume
•
Press the volume key.
.
Walkman™ player widget
The Walkman™ player widget appears on your Home screen when you minimise the
Walkman™ player, but you might have to flick left or right to find it.
Walkman™ mini-player
Use the Walkman™ mini-player to control music playback features when the screen is
locked.
To use the mini-player when the screen is locked
1
Press the volume key to activate the mini-player.
2
Tap
, or to control the playback.
17
This is an Internet version of this publication. © Print only for private use.
Connecting your phone to a computer
Connect your phone to a computer and start transferring pictures, music and other file
types.
You might not be able to transfer some copyright-protected material between your phone and
computer.
Transferring and handling content using a USB cable
The most common way to transfer files between your phone and a computer is using a
USB cable. Once the phone and computer are connected, you can drag and drop content
from one to the other using your computer’s file explorer.
Make sure you place files in the corresponding folder types. For example, put your music files in
the Music folder. Java application files are an exception. You should place them in the Other
folder.
To drag and drop content between your phone and a computer
1
Connect the USB cable to the phone and the computer.
2
Phone: Select Mass storage.
3
Computer: Wait until the phone memory and memory card appear as external disks
in the file explorer.
4
Computer: On the computer desktop, double-click the My Computer icon.
5
Computer: To view the phone memory and memory card folders, double-click the
icon representing your phone.
6
Computer: Copy and paste your file, or drag and drop it, into a corresponding folder
on your computer, in your phone memory, or on your memory card.
You cannot use your phone while transferring files.
To disconnect the USB cable safely
Do not disconnect the USB cable while you are transferring content as this may corrupt the
content.
1
Computer: Use the Safely Remove Hardware function to select the device you want
to unplug, then click Stop.
2
Disconnect the USB cable.
Computer instructions may vary depending on your operating system. See the documentation
of your computer's operating system for more information.
18
This is an Internet version of this publication. © Print only for private use.
Camera
1
2
10
7
8
9
3
4
5
6
Take photos, record videos, view albums and share your favourite clips and pictures with
friends – all with your camera application.
To activate the camera
1
From the Home screen, drag upwards.
2
Find and tap Camera.
To take a photo
1
Activate the camera.
2
If the still camera is not selected, tap .
3
Point the camera towards the subject and tap . A photo is taken and appears in
review mode.
4
To return to the camera viewfinder, tap
Viewfinder and camera controls
.
1
Zoom in and out (only available in video mode)
2 Take photos
3 Exit the camera
4 Switch between still and video camera
5 Record video clips
6 Switch between still and video camera
7 View photos and video clips
8 Select video length
9 View photos and video clips
10 Number of remaining photos you can take
This is an Internet version of this publication. © Print only for private use.
19
TrackID™ technology
Use the TrackID™ music recognition service to identify a music track you hear playing in
your surroundings. Just record a short sample of the song and you’ll get artist, title and
album info within seconds. You can also purchase tracks identified by TrackID™. For best
results, use TrackID™ technology in a quiet area. If you have problems using this
application, see I cannot use Internet-based services on page 29.
The TrackID™ application and the TrackID™ service are not supported in all countries/ regions,
or by all networks and/or service providers in all areas.
To open the TrackID™ application
1
From the Home screen, drag upwards.
2
Find and tap TrackID™ .
To search for track information
1
Open the TrackID™ application and tap Record.
2
Hold your phone towards the music source. The results are shown in the result
screen.
3
Flick left or right to view previous search results.
20
This is an Internet version of this publication. © Print only for private use.
PlayNow™
Use the PlayNow™ application in your phone to browse, purchase and download the latest
music, games, ringtones, applications, themes and wallpapers.
PlayNow™ is not available in all countries.
To start PlayNow™
1
From the Home screen, drag upwards.
2
Find and tap .
21
This is an Internet version of this publication. © Print only for private use.
Multimedia and text messaging
To create and send a message
1
From the Home screen, tap .
2
Tap New message > Write message. Enter your message text and tap .
3
To add a recipient, select a contact from the list that appears. You can also tap the
text field, enter a number manually, and then tap Done.
4
If you want to add a photo or a video, tap and select an option.
5
When you are finished, tap Send.
To read a received message
1
From the Home screen, tap
2
Tap a message thread.
3
To download a message that is not downloaded yet, tap the message.
4
If the received message contains music or a video, tap the item and then tap View
video or Play audio.
.
22
This is an Internet version of this publication. © Print only for private use.
Use your phone to send and receive emails through your regular email account. Before you
get started, you need the correct Internet settings in your phone. See Internet and
messaging settings on page 12.
To set up an email account in your phone
1
From the Home screen, drag
2
Find and tap Email.
3
Select an email account. If the account you want to use is not in the list, tap Other.
4
Enter your Email address and password, then tap Continue.
5
If the phone cannot download your email account settings automatically, enter them
manually.
If you need to enter the settings manually, contact your email service provider for the correct
email account settings. For example, you need to know if the account type is POP3 or IMAP.
To create and send an email message
1
From the Home screen, drag upwards.
2
Find and tap Email.
3
Tap Write new.
4
Tap To: and enter the recipient's address, then tap Done. You can add more
recipients the same way, or delete a recipient by tapping
5
Tap Subject and enter the email subject.
6
Tap Write email, then enter your message text.
7
To attach a file, tap Attach, select the type of file, and then select the file you want
to send.
8
Tap Send.
upwards.
.
To receive and open email messages
1
From the Home screen, drag
2
Find and tap Email.
3
Tap Inbox.
4
To update the inbox with new messages, tap
5
To open and read a message, tap the message.
upwards.
.
23
This is an Internet version of this publication. © Print only for private use.
Bluetooth™ wireless technology
Turn on the Bluetooth™ function in your phone and create wireless connections to other
Bluetooth™ compatible devices such as computers, handsfree accessories, and phones.
Bluetooth™ connections work better within a 10 metre (33 feet) range, with no solid objects
in between. In some cases you have to manually pair your phone with other Bluetooth™
devices. Remember to set your phone to visible if you want other Bluetooth™ devices to
detect it.
To turn on the Bluetooth™ function and make your phone visible
1
From the Home screen, drag upwards.
2
Find and tap Settings > Connectivity > Bluetooth.
3
Tap Bluetooth and tap the on/off button to turn on Bluetooth. appears in the
status bar.
4
Tap Visibility and tap the on/off button to make your phone visible.
Phone name
You can give your phone a name. This name is shown to other devices after you have
turned on the Bluetooth™ function and your phone is set to visible.
To give your phone a name
1
From the Home screen, drag upwards.
2
Find and tap Settings > Connectivity > Bluetooth > Device name.
3
Enter your desired phone name.
4
Tap OK.
To pair your phone with another Bluetooth™ device
1
From the Home screen, drag
2
Find and tap Settings > Connectivity > Bluetooth.
3
Tap Add new device. The Bluetooth™ devices found will be shown in a list.
4
Tap the Bluetooth™ device that you want to pair with your phone.
5
Enter a passcode, if required.
6
The phone and the Bluetooth™ device are now paired. In some cases, you may
need create connection manually after pairing. The status of the pairing and
connection is shown below the name of the Bluetooth™ device in the My devices
list.
Make sure the device you want to pair your phone with has the Bluetooth™ function activated
and has Bluetooth™ visibility turned on.
upwards.
24
This is an Internet version of this publication. © Print only for private use.
Web browser
Browsing the web
View and navigate web pages, bookmark your favourites, create shortcuts, and browse
with several windows open at the same time – all with your web browser.
To open the web browser
1
From the Home screen, drag upwards.
2
Find and tap Browser .
To go to a web page
1
Tap .
2
Tap the text field to activate the keypad.
3
Enter a web address.
4
Tap Go to.
25
This is an Internet version of this publication. © Print only for private use.
More features
Alarms
Customise your alarm and wake up to your preferred alarm tone or radio station. Activated
alarms sound even if your phone is turned off.
To set a new alarm
1
From the Home screen, drag upwards.
2
Find and tap Alarm.
3
Tap Add new.
4
Set an alarm time and enter the relevant details in the Alarm text, Recurrence and
Alarm signal fields, then tap Done.
To delete an alarm
1
From the Home screen, drag upwards.
2
Find and tap Alarm.
3
Scroll to the alarm you have set and want to delete, and tap it.
4
Scroll down and Tap Delete.
To silence the alarm
1
When the alarm sounds, drag Slide to turn off to the right to turn off the alarm.
2
To repeat the alarm, select Snooze.
Calendar
Use your phone calendar to manage your schedule and appointments.
To open the Calendar application
1
From the Home screen, drag upwards.
2
Find and tap Calendar.
When you open the
previously used the application, it opens in the view you last used.
To log in to Facebook
1
From the Home screen, drag
2
Find and tap Facebook.
3
Enter your login details.
To log in to Twitter
1
From the Home screen, drag upwards.
2
Find and tap Twitter.
3
Enter your login details.
Calendar application for the first time, it opens in month view. If you have
upwards.
Voicemail
If your subscription includes a voicemail service, callers can leave voice messages for you
when you can't answer calls. Your voicemail service number is normally saved on your SIM
card. If not, you can get the number from your service provider and enter it manually.
To enter your voicemail service number
1
From the Home screen, drag
2
Select Settings > Calls > Voicemail.
3
Enter your voicemail number and tap Done.
This is an Internet version of this publication. © Print only for private use.
upwards.
26
To call your voicemail service
1
From the Home screen, drag upwards.
2
Tap Voicemail.
27
This is an Internet version of this publication. © Print only for private use.
Locking and protecting your phone
IMEI number
Every phone has a unique IMEI (International Mobile Equipment Identity) number. You
should keep a copy of this number. If your phone is stolen, your network provider can use
your IMEI number to stop the phone from accessing the network in your country.
To view the IMEI number in your phone
1
From the Home screen, drag upwards.
2
Find and tap Settings > General > About phone.
To change your SIM card PIN
1
From the Home screen, drag upwards.
2
Find and tap Settings > General > Security > Change PIN, then follow the
instructions.
28
This is an Internet version of this publication. © Print only for private use.
Troubleshooting
Common questions
My phone is not working as expected
If you experience problems with your phone, check these tips before you try anything else:
•
Restart your phone.
•
Remove and re-insert the battery and SIM card. Then restart your phone.
•
Update your phone. Even if you have the latest software, updating your phone can improve
software stability and solve other problems. By running the latest update on your phone,
you also ensure optimal performance and get the latest enhancements.
•
Reset your phone.
Be patient while resetting your phone. Restarting the phone during a reset procedure may
damage the phone permanently.
Resetting the phone
When you reset your phone, you delete all data, including downloaded applications. You
are basically resetting the phone to the state it was in before you first turned it on. So before
you perform a reset, make sure to back up any important data saved on your phone.
To reset the phone
1
From the Home screen, drag
2
Find and tap Settings > General > Master reset > Reset all .
3
Tap Reset.
upwards.
No battery charging icon appears when I start charging the phone
It may take a few minutes before the battery icon appears on the screen.
I cannot use Internet-based services
Make sure your subscription covers data downloads and that the Internet settings in your
phone are correct. Contact your network operator for more information about your
subscription settings.
Error messages
No network coverage
•
Your phone is in flight mode. Make sure flight mode is off.
•
Your phone is not receiving any network signal, or the received signal is too weak. Contact
your network operator and make sure that the network has coverage where you are.
•
The SIM card is not working properly. Insert your SIM card in another phone. If this works,
it is probably your phone that is causing the problem. In this case, contact the nearest
Sony Ericsson service center.
Emergency calls only
You are within range of a network, but you are not allowed to use it. However, in an
emergency, some network operators allow you to call the international emergency number
112.
SIM locked
You have entered your PIN incorrectly three times in a row. To unlock the phone, you need
the PUK ((Personal Unblocking Key) provided by your operator.
29
This is an Internet version of this publication. © Print only for private use.
PUK blocked. Contact operator.
You have entered your PUK code incorrectly 10 times in a row. Please contact your service
provider.
30
This is an Internet version of this publication. © Print only for private use.
Legal information
Sony Ericsson Yendo™ with Walkman™ W150i
This User guide is published by Sony Ericsson Mobile Communications AB or its local affiliated company, without any
warranty. Improvements and changes to this User guide necessitated by typographical errors, inaccuracies of current
information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications
AB at any time and without notice. Such changes will, however, be incorporated into new editions of this User guide.
All rights reserved.
©Sony Ericsson Mobile Communications AB, 2010
Publication number: 1239-1711.1
Attention: Some of the services and features described in this User guide are not supported by all networks
and/or service providers in all areas. Without limitation, this applies to the GSM International Emergency
Number 112. Please contact your network operator or service provider to determine availability of any specific
service or feature and whether additional access or usage fees apply.
Your mobile phone has the capability to download, store and forward additional content, e.g. ringtones. The use of
such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under
applicable copyright laws. You, and not Sony Ericsson, are entirely responsible for additional content that you
download to or forward from your mobile phone. Prior to your use of any additional content, please verify that your
intended use is properly licensed or is otherwise authorized. Sony Ericsson does not guarantee the accuracy, integrity
or quality of any additional content or any other third party content. Under no circumstances will Sony Ericsson be
liable in any way for your improper use of additional content or other third party content.
The Liquid Identity logo and TrackID are trademarks or registered trademarks of Sony Ericsson Mobile
Communications AB.
This User guide may reference services or applications provided by third parties. Use of such programming or services
may require separate registration with the third party provider and may be subject to additional terms of use. For
applications accessed on or through a third-party website, please review such websites’ terms of use and applicable
privacy policy in advance. Sony Ericsson does not warrant or guarantee the availability or performance of any thirdparty websites or offered services.
WALKMAN, WALKMAN logo, Sony, Memory Stick Micro™ and M2™ are trademarks or registered trademarks of
Sony Corporation.
The Liquid Identity logo and Yendo are trademarks or registered trademarks of Sony Ericsson Mobile
Communications AB.
Sony and "make.believe" are trademarks or registered trademarks of Sony Corporation.
Bluetooth is a trademark or a registered trademark of Bluetooth SIG Inc. and any use of such mark by
Sony Ericsson is under license.
Media Go is a trademark or registered trademark of Sony Electronics Inc.
Ericsson is a trademark or registered trademark of Telefonaktiebolaget LM Ericsson.
Facebook and the F logo are trademarks or registered trademarks of Facebook, Inc.
Twitter and the Twitter T are trademarks or registered trademarks of Twitter, Inc.
TrackID™ is powered by Gracenote Mobile MusicID™. Gracenote and Gracenote Mobile MusicID are trademarks or
registered trademarks of Gracenote, Inc.
The Liquid Identity logo, PlayNow, TrackID, are trademarks or registered trademarks of Sony Ericsson Mobile
Communications AB.
WALKMAN, WALKMAN logo are trademarks or registered trademarks of Sony Corporation.
This product is protected by certain intellectual property rights of Microsoft. Use or distribution of such technology
outside of this product is prohibited without a license from Microsoft.
Other product and company names mentioned herein may be the trademarks of their respective owners. Any rights
not expressly granted herein are reserved. All other trademarks are property of their respective owners.
All illustrations are for illustration only and may not accurately depict the actual phone.
Microsoft, Windows and Vista are registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries.
"Export Regulations: This product, including any software or technical data contained in or accompanying the product,
may be subject to import and export regulations of the European Union, the United States and other countries. The
user and any possessor of the product agrees to comply strictly with all such regulations and acknowledges that it is
their responsibility to obtain any required licenses to export, re-export, or import this product. Without limiting the
foregoing, and as an example, the user and any possessor of the product: (1) must not knowingly export or re-export
Products to destinations identified pursuant to Articles in Chapter II of European Council Regulation (EC) 428/2009;
(2), must comply with U.S. government Export Administration Regulations (“EAR”, 15 C.F.R. §§ 730-774, http://
www.bis.doc.gov/ ) administered by Department of Commerce, Bureau of Industry and Security; and (3) must comply
with economic sanctions regulations (30 C.F.R. §§ 500 et. seq.,., http://www.treas.gov/offices/enforcement/ofac/)
administered by the U.S. Department of Treasury, Office of Foreign Assets Control. The user and any possessor of
the product may not transport or deliver the product, its accessories or separate software to any country, region,
entity or person prohibited by these regulations."
31
This is an Internet version of this publication. © Print only for private use.
Index
A
adjusting volume .....................................................17
answering service ....................................................26
applications .............................................................21
audio
adjusting volume .............................................17
playing .............................................................16
B
battery .......................................................................9
Bluetooth™ wireless technology .............................24
browsing - see web browser
C
calls .........................................................................15
caps lock .................................................................12
charging .....................................................................9
contacts ...................................................................14
G
games ......................................................................21
H
Home screen ...........................................................10
I
input method ...........................................................12
Internet
web browser ....................................................25
K
keypad .....................................................................12
M
messages
multimedia .......................................................22
picture .............................................................22
text ..................................................................22
MMS ........................................................................22
multimedia messages ..............................................22
music .......................................................................16
adjusting volume .............................................17
audiobooks ......................................................16
downloading ....................................................21
pausing a track ................................................16
player overview ...............................................16
playing .............................................................16
podcast ...........................................................16
music player
smart playlists .................................................17
R
reset .........................................................................29
S
screen lock ..............................................................28
screen lock pattern ..................................................28
searching
music using TrackID™ technology .................20
track information .............................................20
setup guide ................................................................7
SIM ..........................................................................28
SIM card
inserting .............................................................6
smart playlists
playing .............................................................17
SMS .........................................................................22
symbols ...................................................................12
T
telephony See calls
text messages .........................................................22
TrackID™ technology ..............................................20
opening ...........................................................20
searching for track information .......................20
troubleshooting .......................................................29
U
USB connection ......................................................18
V
voicemail .................................................................26
W
Walkman™ player ...................................................16
web browser ............................................................25
N
navigation ................................................................12
O
overview
Walkman™ player ...........................................16
P
pausing a track ........................................................16
personal information ................................................14
phonebook ..............................................................14
picture messages ....................................................22
PIN ...........................................................................28
playing
music ...............................................................16
playlists
smart (auto-generated) ....................................17
PlayNow™ ...............................................................21
PUK .........................................................................28
This is an Internet version of this publication. © Print only for private use.
32
Loading...
