Part List, Electrical
1 Part list Main Board
The part list contains only components that are possible to replace on the main board.
Pos. number refers to the components position number on the board.
Some components are noted as MSL X. These components are moisture-sensitive
and are rated at various levels (MSL):
Level 1: Unlimited floor life; does not require dry pack or re-baking.
Level 2: 1 year floor life; </=30 C; 60%rh; shipped in dry pack; must be
re-baked after being opened if floor life is exceeded.
Level 2A: 4 week floor life; </=30 C; 60%rh; shipped in dry pack; must be
re-baked after being opened if floor life is exceeded.
Level 3: 168 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be
re-baked after being opened if floor life is exceeded.
Level 4: 72 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be
re-baked after being opened if floor life is exceeded.
Level 5: 48 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be
re-baked after being opened if floor life is exceeded.
Level 5A: 24 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be
re-baked after being opened if floor life is exceeded.
Level 6: 6 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be
re-baked after being opened if floor life is exceeded.
Parts shipped from the Sony Ericsson Parts Warehouse are most likely NOT shipped
in dry pack. This means the time elapsed between placing the order and receiving the
parts must be considered as time exposed to the environment.
Different moisture sensitivity levels and exposure times create the need for different
baking temperatures and times. More detailed information may be found in the most
recent version of the IPC/JEDEC J-STD-033A standard. The standard is available
online at
NOTE! RF Calibration by using SERP can only be done by authorized
repair centers.
http://www.jedec.org/
1215-7378 Rev 1
Company Internal
2(5)
© Sony Ericsson Mobile Communi cat i ons AB
Part List, Electrical
Component placing will be found in document 1215-7381.
P=Primary side, S=Secondary side.
Side Pos. Description Part Number Comments
B2100
P
B3105
P
B4200
S
C2217
P
L2200
P
L2401, L2402,
P
L2403, L2404,
L2411
L2421, L2422
P
N1002
P
N1200
P
N1210
P
N1400
P
Crystal 32,768 kHz
Microphone
Vibrator
Capacitor 220 μF 4.0 V
Inductor Wirewound 4.7μH
Filter 0.0 Hz 0402
Inductor 120nH 5% 0402 0.11A
IC Amplifier
Thor 2 Radio Module EDGE
RF-Module Squid
prebumped
Module Bluetooth +
FM STLC2592
RTM501911/1
1206-4070
1202-4687
1205-9750
1200-2190
REG70618/20
REG7245543/12J
1200-9356
1212-2584
1204-1674
1200-6182
Calibration required (SERP)
MSL3
MSL1
MSL1
Calibration required (SERP)
Inside the N1200 module.
Calibration required (SERP)
MSL5A
Calibration required (SERP)
MSL5A
MSL3
N2202
P
N2203
P
N2205
P
N2400
P
N2402
S
N2404
S
N2410
S
N2490
P
N3100, N3102
P
N3101
P
1215-7378 Rev 1
Company Internal
IC Vreg 600mA
IC Vreg PLP1010-4
DC/DC Converter
1-Bit Level Translator
IC ESD Prot UDFN 6 2x2mm
IC IF ISP1508 ES3
(3.5*3.5*0.8)
IC ESD Prot CS-5
ASIC Accelerometer
IC CS-9
ASIC Tjatte3 CSP20
1205-8787
1201-6465
RYT1137838/1
RYT109914/1
1200-6309
1200-1694
RKZ923926/1
1202-1676
1200-9978
ROP1013074/1
© Sony Ericsson Mobile Communi cat i ons AB
MSL1
MSL1
MSL1
MSL1
MSL1
3(5)
Part List, Electrical
Side Pos. Description Part Number Comments
N4200
P
N4310
P
N4311
P
R2432, R2434
P
V2200
P
V2202
P
V2405
P
V2408
P
V2420
S
V2421
P
X1200
S
X1201,
S
X1400, X1401
Trans N-ch FET
IC Vreg
IC Vreg
Resistor 0, Ohm +/-50m
63mW K0603
Zener diode
Trans P-ch FET
MOSFET Complementary
N P 20 V (DS)
Schottky Barrier Diodes
2PIN
Zenner Diode 15V
Zenner Diode 15V
Conn Receptacle 0p Hirose
RF connector
Antenna connector
RYN901936/1
RYT113997/4
1202-7650
REP623001/0
RKZ223911/1
RYN122910/1
RYN901918/2
RKZ123905/1
RKZ223921/1
RKZ223921/1
1204-6720
SND90161R2
MSL1
MSL1
X2200
S
X2400
P
X2410
S
X2420
S
X2430
P
X4200
P
X4300
P
Z4200, Z4201,
P
Z4202, Z4203
E1
P
P E1000
S E1001
Battery Connector
System Connector
MS Connector
SIM Connector
Connector FPC 25p
Connector FPC 51p
Connector FPC 26p
LC Filter
Shield Can Closed
assembly
Shield Can Lid Main
Shield Can Lid USB
RNV79943R1
1202-1195
1203-4820
1204-9440
1200-7390
1206-3316
1205-5606
REV50148/1
1200-0188
1206-5800
1206-5801
For N1002
1215-7378 Rev 1
Company Internal
4(5)
© Sony Ericsson Mobile Communi cat i ons AB
Part List, Electrical
