Sony Ericsson W900

Getting started ................... 4

Assembly, SIM card, battery, turning on, start-up menu, calls.

Connectivity ..................... 60

Internet and email settings, synchronizing, Bluetooth, infrared, USB cable, update service.

Getting to know your

phone ................................ 10

Phone overview, icons, use the menus, entering letters, activity menu, file manager.

Calling ............................... 21

Calls, video calls, contacts, voice control, call options.

Messaging ........................ 35

Text messaging, picture messaging, voice messaging, email, My friends.

Imaging ............................. 46

Camera, video recorder, pictures.

More features ................... 70

Alarm clock, calendar, tasks, profiles, time and date, SIM card lock, etc.

Troubleshooting ............... 77

Why doesn’t the phone work the way I want?

Important information ...... 82

Sony Ericsson Consumer Web site, safe and efficient use, warranty, declaration of conformity.

Index ................................. 90

Entertainment ................... 50

WALKMAN™, radio, PlayNow™, ringtones, MusicDJ™, VideoDJ™, games and more.

This is the Internet version of the user's guide. © Print only for private use.

1Contents

Sony Ericsson

UMTS-GSM 900/1800/1900 This user guide is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this user guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this user guide. All rights reserved.

©Sony Ericsson Mobile Communications AB, 2005

Publication number: EN/LZT 108 7455 R1A Please note: Some of the services in this user guide are not

supported by all networks.

the GSM International Emergency Number 112

Please contact your network operator or service provider if you are in doubt whether you can use a particular service or not. Please read the

use

and the

use your mobile phone. Your mobile phone has the capability to download,

store and forward additional content, e.g. ringtones. The use of such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under applicable copyright laws. You, and not Sony Ericsson, are entirely responsible for additional content that you download to or forward from your mobile phone. Prior to your use of any additional content, please verify that your intended use is properly licensed or is otherwise authorized. Sony Ericsson does not guarantee the accuracy, integrity or quality of any additional content or any other third party content. Under no circumstances will Sony Ericsson be liable in any

Limited warranty

This also applies to

Guidelines for safe and efficient

chapters before you

way for your improper use of additional content or other third party content.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Ericsson is under license.

QuickShare, PlayNow, MusicDJ, PhotoDJ and VideoDJ are trademarks or registered trademarks of Sony Ericsson Mobile Communications AB. Memory Stick™, Memory Stick Duo™ and Memory Stick PRO Duo™ are trademarks or registered trademarks of Sony Corporation.

WALKMAN™ and the WALKMAN™ logo and symbol are registered trademarks of Sony Corporation.

Real is a trademark or a registered trademark of RealNetworks, Inc. RealPlayer® for Mobile is included under license from RealNetworks, Inc. Copyright 1995-2004, RealNetworks, Inc. All rights reserved. Microsoft, Windows and PowerPoint are either registered trademarks or trademarks of Microsoft Corporation in the U.S and other countries. Mac OS is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. T9™ Text Input is a trademark or a registered trademark of Tegic Communications. T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide. Java and all Java based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. End-user license agreement for Sun™ Java™ J2ME™.

2 Contents

This is the Internet version of the user's guide. © Print only for private use.

1 Restrictions: Software is confidential copyrighted

information of Sun and title to all copies is retained by Sun and/or its licensors. Customer shall not modify decompile, disassemble, decrypt, extract, or otherwise reverse engineer Software. Software may not be leased, assigned, or sublicensed, in whole or in part.

2 Export Regulations: Software, including technical

data, is subject to U.S. export control laws, including the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries. Customer agrees to comply strictly with all such regulations and acknowledges that it has the responsibility to obtain licenses to export, re-export, or import Software. Software may not be downloaded, or otherwise exported or re-exported (i) into, or to a national or resident of, Cuba, Iraq, Iran, North Korea, Libya, Sudan, Syria (as such listing may be revised from time to time) or any country to which the U.S. has embargoed goods; or (ii) to anyone on the U.S. Treasury Department's list of Specially Designated Nations or the U.S. Commerce Department's Table of Denial Orders.

3 Restricted Rights: Use, duplication or disclosure

by the United States government is subject to the restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS

252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2) as applicable.

Other product and company names mentioned herein may be the trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

This is the Internet version of the user's guide. © Print only for private use.

3Contents

Getting started

Assembly, SIM card, battery, turning on, start-up menu, calls.

More information and downloads are available at

support.

Instruction symbols

The following instruction symbols appear in this user guide:

% See also page...

} Use a selection or navigation

www.SonyEricsson.com/

Note

Indicates that a service or function is networkor subscription-dependent. Contact your network operator for details.

key to scroll and select,

14 Navigation

Press the navigation key centre.

Press the navigation key up.

Press the navigation key down.

Press the navigation key to the left.

Press the navigation key to the right.

Assembly

Before you can use your phone you need to:

• Insert the SIM card.

• Attach and charge the battery.

SIM card and battery information

When you register as a subscriber with a network operator, you get a SIM (Subscriber Identity Module) card. The SIM card contains a computer chip that keeps track of your phone number, the services included in your subscription, and names and numbers in your contacts, among other things.

If you have used your SIM card in another phone, make sure that your information is saved to the SIM card before you remove it. For example, contacts may have been saved in the phone memory.

4 Getting started

This is the Internet version of the user's guide. © Print only for private use.

To insert SIM card and battery

To charge the battery

1 Remove the battery cover. 2 Slide the SIM card into its holder with

the gold contacts facing down.

3 Insert the battery with the label side up

and the connectors facing each other.

4 Slide the battery cover into place.

1 Connect the charger to the phone. The

symbol on the charger plug must face upwards.

2 It may take up to 30 minutes before the

battery icon appears on the screen.

3 Wait approximately 2.5 hours or until

the battery icon indicates that the battery is fully charged. Press a key to activate the screen.

4 Remove the charger by pulling it out.

This is the Internet version of the user's guide. © Print only for private use.

5Getting started

Memory Stick PRO Duo™

Your phone supports Memory Stick PRO Duo™. A Memory Stick adds more storage space to your phone to store, for example, music, ringtones, video clips and pictures.

With a Memory Stick you can share your saved information by moving or copying it to other Memory Stick compatible devices.

You can also use it as a portable memory for office documents, and move documents between the phone and a computer.

To insert and remove a Memory Stick PRO Duo™

1 Insert the Memory Stick in the slot. 2 Press the edge of the Memory Stick

to release it from the slot.

You may need a PIN (Personal Identity Number) to activate the services in your phone. The PIN is associated with your SIM card, and not with the phone. Your PIN is provided by your network operator. When you enter your PIN, each digit appears as *, unless your PIN starts with the same digits as an emergency number, for example 112. This allows for emergency calls without entering a PIN.

If you make a mistake while entering your PIN, delete the number by pressing .

If you enter the wrong PIN three times in a row, the SIM card is blocked and the message “PIN blocked” appears. To unblock it, you need to enter your PUK (Personal Unblocking Key)

74 SIM card lock

Battery

Some functions use more battery power than others and may cause a need for more frequent re-charging. If talk time or standby time becomes noticeably shorter, you may have to replace the battery. Only use approved batteries from Sony Ericsson

and care

86 Battery use

6 Getting started

This is the Internet version of the user's guide. © Print only for private use.

Turning on the phone and making calls

Make sure that the phone is charged and your SIM card is inserted before you turn it on. When you have turned the phone on, you can use the setup wizard to quickly and easily prepare your phone for use.

To open and close the phone

1 Rotate the top section up until it clicks

into place to open the phone.

2 Rotate the top section down in the

opposite direction to close the phone.

Do not rotate the top section more than 180 degrees, in either direction, as the phone will be damaged.

This is the Internet version of the user's guide. © Print only for private use.

7Getting started

To turn on the phone

1 Open the phone, press and hold .

The first start-up may take a few minutes.

2 Select Start phone to use the phone

with full functionality or Music only to use the WALKMAN™ player only.

8 Start-up menu

3 Enter your SIM card PIN, if requested. 4 At first start-up, select the language

for your phone menus.

5 } Yes if you want the setup wizard

to help you get started. Follow the instructions to complete the setup.

More information

You can start the setup wizard from the menu system at any time.

To activate the setup wizard

} Settings } the General tab } Setup wizard.

Start-up menu

When the start-up menu is activated, each time you turn on the phone, you can select to listen to music only, with phone network transmitters turned off. This prevents disturbance of sensitive equipment, for example, in an aeroplane where calls and messages are prohibited. You cannot make calls, receive calls, or send messages, etc. You can only use the WALKMAN™ player. If you have selected Music only, some limited functions are still available such as the alarm, calendar and task reminders.

Always follow regulations and flight crew instructions with respect to onboard use of electronic devices.

To deactivate the start-up menu

} Settings and scroll to the General tab } Start-up menu. Select Don´t show.

To make and receive calls

You can make and receive calls when the phone is open or closed.

1 When open, enter the phone number

(with international prefix and area code if applicable) } Call to make the call

8 Getting started

This is the Internet version of the user's guide. © Print only for private use.

or press to make a video call.

} End call to end the call.

2 When open or closed, } Contacts and

select the contact to call. Use or to select a number } Call to make a voice call or press to make a video call.

3 When the phone rings } Answer or

} Busy to reject the call. This can be

done in either open or closed mode.

HPM-80

With the radio portable handsfree, HPM-80, you can listen to the radio and control the WALKMAN™ player in the phone. If you receive a call when using the HPM-80, the music stops and you can answer the call. When the call is ended or if the call is rejected the

HPM-80 continues to play. The HPM-80 can be used as a standard handsfree device for receiving and making calls even if it is turned off.

You can use the HPM-80 to:

• manually or automatically search

for radio broadcasting frequencies

• play and pause music

• move between music files

• fast forward or rewind

• increase or decrease the volume

• mute the ear speakers or the

microphone

10 Phone and menu overview

To use the HPM-80

1 Turn on your phone and connect the

HPM-80.

2 Press and hold the MP/FM - ON/OFF

button to turn on the HPM-80.

3 Press the MP/FM - ON/OFF button

to switch between the radio and WALKMAN™ player.

To use to the radio with the HPM-80

52 Radio

To control the WALKMAN™ with the HPM-80

52 WALKMAN™ player controls

To save battery power, turn off the HPM80 when it is not in use.

This is the Internet version of the user's guide. © Print only for private use.

9Getting started

Getting to know your phone

Phone overview, icons, use the menus, entering letters, activity menu, file manager.

Phone and menu overview

HPM-80

21 22

8 9

11 12

14 15 16

17 18 19

3 4

10 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

1 Video call camera

2, 7 Selection key

3 Back key

4 Internet button

5 Video call key

6 Ear speaker

8 Navigation key/WALKMAN™ player control

9 C key

10 Activity menu

11 Silent key

12 Power on/off button

13 Connector for charger and HPM-80

14 WALKMAN™ player button

15 Lock switch

16 Memory Stick PRO Duo™ slot

17 Infrared port

18 Camera button

19 Volume, camera and picture zoom buttons

20 HPM-80 buttons for radio, play/pause and mute/unmute control

21 HPM-80 volume buttons

22 HPM-80 for On/Off, MP/FM button

For more information

76 Keypad lock

14 Navigation

This is the Internet version of the user's guide. © Print only for private use.

11Getting to know your phone

PlayNow™* Internet services* Entertainment

Online services* Games VideoDJ™ PhotoDJ™ MusicDJ™ Remote control Record sound Demo tour

File manager*** Contacts**

Pictures Videos Sounds Themes Web pages Games Applications Other

Options:

Speed dial My business card Groups

SIM contacts** Special numbers Advanced

New contact

Settings***

Video call

General

Profiles Time & date Language Voice control Update service New events Shortcuts Start-up menu Locks Setup wizard Tips and tricks Phone status Master reset

Sounds & alerts

Ring volume Ringtone Silent mode Increasing ring Vibrating alert Open phone sounds Message alert Key sound

Display

Wallpaper Themes Start-up screen Screen saver Brightness Edit line names*

Calls

Divert calls Manage calls Time & cost* Show/hide my no. Handsfree Switch to line 2*

Connectivity*

Bluetooth Infrared port USB connection Synchronization Device mgmt. Mobile networks Data comm. Internet settings Streaming settings Settings for Java™ Accessories

12 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

Camera Messaging WALKMAN

Write new Inbox My friends* Email Call voicemail Drafts Outbox Sent messages Saved messages Templates Settings

Now playing Artists Tracks Playlists Videos

Calls*** Organizer

Alarms

All Answered Dialled Missed

* Some menus are operator-, network- and subscription-dependent. ** Options when phone contacts are set to default, options change when SIM contacts are set to default. *** Use the navigation key to move across tabs in submenus. For more information

Applications Calendar Tasks Notes Synchronization Timer Stopwatch Light Calculator Code memo

14 Navigation.

This is the Internet version of the user's guide. © Print only for private use.

13Getting to know your phone

Navigation

The main menus are shown as icons on the desktop. Some submenus include tabs that appear on the screen. Scroll to a tab by pressing the navigation key left or right and select an option.

Navigating the menus

• Press

desktop or to select highlighted items.

(navigation key) to go to the

Key Press to

delete items, such as pictures, sounds and contacts. During a call, press and hold to mute the microphone.

open the browser.

make a video call or to enter video call mode.

open the activity menu

open or minimize the WALKMAN™ player.

take a picture or to record a video clip.

• Press

the menus.

• Press

• Press to select options shown

immediately above these keys on the screen.

• Press to go back one level in

the menus. Press and hold to return to standby or to end a function.

• Scroll to a menu item } Info to get more

information, explanations or tips about selected features, menus or functions available in your phone.

• } More and enter a list of options.

There are different alternatives in the list of options depending on where you are in the menus.

18 Activity menu

to move through

to move between the tabs.

14 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

Press and hold to call your voicemail service (if set).

- Press and hold any of these keys to reach a contact beginning

- Press a number key and } Call to speed dial.

with a specific letter.

turn off the ringtone when receiving a call. Press and hold to set the phone to silent. The alarm signals even if the phone is set to silent.

view status information in standby. increase the volume during a call, or when using the WALKMAN player. zoom out when using the camera. Press and hold to go back one track. Quickly press twice to reject a call. Press and hold to voice dial, alternatively say your magic word (if set)

29 Voice dialling

decrease the volume during a call, or when using the WALKMAN player. zoom in when using the camera. Press and hold to go forward one track. Press and hold to voice dial, alternatively say your magic word (if set)

29 Voice dialling

This is the Internet version of the user's guide. © Print only for private use.

15Getting to know your phone

Standby icons

The 3G (UMTS) network is available.

Tells you the strength of the GSM network signal.

Tells you the status of the battery.

Tells you the status of the battery charging.

You have missed an incoming call.

Call and messaging function alerts are off, alarm is still on.

You have received a text message.

You have received an email message.

Your phone is receiving a picture message.

You have received a picture message.

You have received a voice message.

You have an ongoing call.

You have an appointment reminder.

You have a task reminder.

The magic word is activated.

Shortcuts

Use keypad shortcuts to quickly go to a menu, and you can use predefined navigation key shortcuts to quickly reach certain functions. Edit the navigation key shortcuts to suit your own needs.

Using keypad shortcuts

Enter the menus by pressing and then enter the number of the menu to which you want to go. For example, to reach the fifth menu item, press . To reach the tenth, eleventh and twelfth menu items, press , and respectively. To go back to standby, press and hold .

Using navigation key shortcuts

In standby, press , , to go to a shortcuts menu, or directly to a function.

To edit a navigation key shortcut

} Settings } the General tab } Shortcuts and select which

shortcut you want to edit } Edit.

16 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

Phone language

Select the language for phone menus or the languages that you may use when writing.

To change the phone language

} Settings } the General tab } Language } Phone language.

Select a language. From standby, you can also press

8888 for automatic language. 0000 for English.

Most SIM cards automatically set the menu language to the country where you bought your SIM card. If not, the predefined language is English.

To select writing language

1 } Settings } the General tab

} Language } Writing language.

2 Scroll to the language that you want

to use and mark it. } Save to exit the menu.

Entering letters

There are two ways of entering letters when writing messages, notes or a name in contacts:

• Multitap text input

• T9™ Text Input

To enter letters using multitap input

• Press - repeatedly until

the desired character appears on the screen.

• Press to shift between capital

and lower-case letters.

• Press and hold - to enter

numbers.

• Press to delete letters and

numbers.

• Press for the most common

punctuation marks.

• Press to add a space.

• T9™ Text Input

The T9 Text Input method uses a built-in dictionary to recognize the most commonly used word for each sequence of key presses. This way, you press each key only once, even if the letter you want is not the first letter on the key.

To enter letters using T9 Text Input

1 To enter text, you have to be in a

function where text input is possible, for example, } Messaging } Write new

} Text message.

2 For example, to write the word “Jane”,

press , , , .

This is the Internet version of the user's guide. © Print only for private use.

17Getting to know your phone

3 If the word shown is the one you want,

press to accept and add a space. To accept a word without adding a space, press . If the word shown is not the one you want, press or repeatedly to view alternative words. Accept a word and add a space by pressing .

4 Continue writing your message.

To enter a mark, press and then or repeatedly. Accept by pressing .

To add words to the T9 Text Input dictionary

1 While entering letters } More

} Spell word.

2 Edit the word by using multitap input.

Use and to navigate between the letters. To delete a character, press

. To delete the entire word, press and hold . When you have edited the word

} Insert. The word is added to the

T9 Text Input dictionary. Next time you enter this word using T9 Text Input, it will appear as one of the alternative words.

To select another writing method

Before, or while entering letters, press and hold to select another writing method.

Options when entering letters

} More to enter a list of options that

offers different alternatives when writing a message.

Activity menu

You can open the activity menu almost anywhere in the phone to view and handle new events, and access bookmarks and shortcuts.

To open and close the activity menu

Press .

Activity menu tabs

• New events – such as missed calls

and messages. When a new event occurs, the tab appears on the screen. Press to dismiss or delete an event from the event tab.

• My shortcuts – applications that are

running in the background. You can add, delete and change the order of shortcuts. When you select a shortcut and the application opens, other programs are closed or minimized.

• Bookmarks – your Internet

bookmarks. When you select a bookmark and the browser opens, other programs are closed or minimized.

18 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

• If you want new events to appear as

pop-up text instead of in the activity menu, } Settings } the General tab

} New events } Popup.

File manager

Use the File manager to handle items such as Pictures, Videos, Sounds,

Themes, Web pages, Games and Applications

memory Duo™.

Move and copy files between the phone, a computer and the Memory Stick. Create subfolders to move or copy files to. Games and applications can only be moved within the Games and

Applications folders and from the

phone memory to the Memory Stick. Unrecognized files are saved in the

Other folder. When handling files, you

can select several or all files in a folder at the same time for all items except

Games and Applications.

All files are automatically saved in the phone memory. If the phone memory is full and you have a Memory Stick inserted the files will automatically be saved on the Memory Stick. If both the phone memory and the Memory Stick are full, you cannot save any files until you have removed content.

saved in the phone

or on the Memory Stick PRO

File manager menu tabs

The file manager is divided into three tabs and icons are included to indicate where the files are saved.

• All - all content in the phone

memory and on the Memory.

• Phone - all content in the phone

memory.

• Memory Stick - all content on

the Memory Stick.

File information

Items that are downloaded, or received using one of the available transfer methods, may be copyrightprotected. If a file is protected, you may not be able to copy or send that file. A DRMprotected file has a key symbol. View file information by highlighting it } More

} Information.

To use a file from the file manager

1 } File manager and select a folder. 2 Scroll to a file } More.

This is the Internet version of the user's guide. © Print only for private use.

19Getting to know your phone

To move or copy a file to a Memory Stick or to the phone memory

1 } File manager and select a folder. 2 Scroll to a file } More } Manage files

} Move to move the file or } More } Manage files } Copy to copy the file.

3 Select to move or copy the file to

the Memory or to the phone memory

} Select.

To move or copy files to a computer

67 Transferring files using the USB

cable

To create a subfolder

1 } File manager and select a folder. 2 } More } New folder and enter a name

for the folder.

3 } OK to save the folder.

To select several files

1 } File manager and select a folder. 2 } More } Mark } Mark several. 3 Scroll to select files and press Mark

or Unmark all.

To select all files in a folder

} File manager and select a folder } More } Mark } Mark all to select

all files.

To delete a file or a subfolder from the File manager

1 } File manager and select a folder. 2 Scroll to a file or a subfolder } More

} Delete.

Formatting a Memory Stick

You can format a Memory Stick to delete all information from it, or if it has been corrupted.

To format the Memory Stick

} File manager and select

the Memory Stick tab } More

} Format M.S.

20 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

Calling

Calls, video calls, contacts, voice control, call options.

Making and receiving calls

Before you can make or receive any calls, you must turn on the phone and be within range of a network.

7 Turning on the phone and making

calls

. To make a video call

22 Video call

Networks

When you turn on the phone, it automatically selects your home network if this is within range. If it is not within range, you may use another network, provided your network operator has an agreement that allows you to do so. This is called roaming.

You can select the network you want to use, or you can add a network to your list of preferred networks. You can also change the order in which networks are selected during an automatic search.

To view available network options

} Settings and use or to scroll

the Connectivity

networks

tab }

Mobile

To make a call

1 Enter the phone number (with

international country code and area code, if applicable).

2 } Call to make a voice call, or press

to make a video call. } More

to view options.

3 } End call to end the call.

You can call numbers from your contacts and call list,

27 Call list. You can also use your voice

to make calls, % 28 Voice control.

To make international calls

1 Press until a + sign appears. 2 Enter the country code, area code

(without the leading zero) and phone number } Call to make a voice call, or press to make a video call.

To re-dial a number

If a call connection fails and Retry? appears } Yes.

Do not hold the phone to your ear while

waiting. When the call connects, the phone

gives a loud signal.

To answer or reject a call

} Answer or } Busy.

24 Contacts, and

This is the Internet version of the user's guide. © Print only for private use.

21Calling

Missed calls

When activity menu is set to default missed calls appears in the New events tab in standby. If pop-up is set to default Missed appears in standby.

To check missed calls from standby

• If activity menu is set to default:

Press and use or to scroll to the New events tab and } Call to make a voice call.

• If pop-up is set to default:

} Calls and use or to scroll to

the Missed tab. Scroll and and

} Call to call a number.

To turn off the microphone

1 Press and hold . 2 To resume the conversation press and

hold again.

To use the loudspeaker during a voice call

} More } Turn on speaker or Turn off speaker.

Do not hold the phone to your ear while using the loudspeaker. This could damage your hearing.

To change the ear speaker volume

Press to increase or to decrease the ear speaker volume during a call.

Emergency calls

Your phone supports the international emergency numbers, for example, 112,

911. These numbers can normally be used to make emergency calls in any country, with or without a SIM card inserted, if a 3G (UMTS) or GSM network is within range.

In some countries, other emergency numbers may also be promoted. Your network operator may therefore have saved additional local emergency numbers on the SIM card.

To make an emergency call

Enter 112 (the international emergency number) } Call.

To view your local emergency numbers

} Contacts } Options } Special numbers } Emergency nos.

Video call

See a contact live on screen during calls.

22 Calling

This is the Internet version of the user's guide. © Print only for private use.

Before you start

To make a video call, both you and the person you are calling need a subscription that supports the 3G (UMTS) service, and you need to be within range of a 3G (UMTS) network. 3G (UMTS) service is available when the 3G icon appears in the status bar.

Video call demo mode

You can use the video call functions without making a call, if you, for example, want to prepare a view and check how it looks before calling. Press and hold

. Most video call functions are

available in the demo mode.

To make a video call

1 Press when 3G (UMTS) service

is available.

2 Enter a phone number } Call or } Call....

} Contacts to retrieve a phone number

and } Call or press .

3 } Camera to switch between the front

camera to the back camera or vice versa. Use the back camera to show a full image of your surrounds to the person you are talking.

To zoom the outgoing video in or out

Press to zoom in the outgoing video and press to zoom out.

To accept an incoming video call

} Answer.

To end a video call

During an ongoing video call, } End call.

Video call options

Press and to select from the following options:

• Stop camera/Start camera – turn

the outgoing video camera off and on. An alternative picture is showed when the camera is off.

• Turn off speaker/Turn on speaker –

turn the incoming sound off and on during a video call.

• Mute microphone/Unmute mic. – turn

the microphone off and on during a video call (this option is available during calls).

• Save picture – save the image in the

large window.

• Switch pictures – choose between

showing the incoming or the outgoing video in full size display.

• Hide small pic./Show small pic. – hide

or show the small picture.

This is the Internet version of the user's guide. © Print only for private use.

23Calling

• Advanced:

} Alternative pic. – this picture will

be shown to the other party when you have turned off the camera.

} Answer mode – select if the front

camera should be on or off when you answer a video call.

} Audio options – select if

microphone, speaker phone, or both should be on or off when you answer a video call.

} Brightness – adjust the brightness

level of the outgoing image.

} Video quality – select the picture

quality for incoming video calls. Changes do not take effect during an ongoing call.

} Mirror image – show a mirror image

of the camera picture.

} Night mode – use when the lighting

conditions are poor. This setting affects the outgoing video.

} Contacts – select to view contact

information such as to check a number during a call.

} Transfer sound – transfer the sound

to and from handsfree equipment using Bluetooth™ wireless technology.

} Demo clip – turn on or off.

Contacts

You can save your contact information in the phone memory as contacts, or on the SIM card as names and numbers. You can choose which contact information – Phone contacts or SIM contacts – is shown as default. For useful information and settings

} Contacts } Options.

Default contact

If you select to use Phone contacts as default, your contacts will show all information saved in Contacts. If you select SIM contacts as default, the contacts will only show names and numbers saved on the SIM card.

To select default contacts

1 } Contacts } Options } Advanced

} Default contacts.

Select

Phone contacts

SIM contacts

Save contacts on your SIM card with name and number.

To add a SIM contact

1 } Contacts } New contact } Add. 2 Enter the name } OK. 3 Enter the number } OK } Save.

24 Calling

This is the Internet version of the user's guide. © Print only for private use.

Phone contacts

Save contacts in the phone with names, phone numbers and personal information. You can also add pictures and ringtones to contacts. Use , ,

and to scroll between the tabs

and their information fields.

To add a phone contact

1 } Contacts } New contact } Add. 2 Enter the name } OK. 3 Enter the number } OK. 4 Select a number type. 5 Scroll between the tabs and select

the fields to add information. To enter symbols such as @, } More } Add

symbol and select the symbol } Insert.

6 When all information is entered } Save.

To delete a contact

} Contacts and scroll to a contact

and press .

To delete all phone contacts

} Contacts } Options } Advanced } Delete all contacts } Yes and } Yes.

Names and numbers on the SIM card are not deleted.

To automatically save names and phone numbers to the SIM card

} Contacts } Options }

Advanced

} Auto save on SIM and select On.

Memory status

The number of contacts you can save in the phone or on the SIM card depends on available memory.

} Contacts } Options } Advanced } Memory Status.

This is the Internet version of the user's guide. © Print only for private use.

25Calling

Using contacts

Contacts can be used in many ways. Below you can see how to:

• call phone and SIM contacts.

• send contacts to another device.

• copy contacts to the phone and

SIM card.

• add a picture or a ringtone

to a phone contact.

• edit contacts.

• synchronize your contacts.

To call a phone contact

1 } Contacts. Scroll to, or enter the first

letter or letters of the contact.

2 When the contact is highlighted. press

or to select a number } Call

or press to make a video call.

To call a SIM contact

• If SIM contacts is default } Contacts

and select the name and number from the list } Call.

• If Phone contacts is set as default

} Contacts } Options } SIM contacts

and select the name and number from the list } Call.

To send a contact

} Contacts and select a contact } More } Send contact and select

a transfer method.

To send all contacts

} Contacts } Options } Advanced } Send all contacts and select

a transfer method.

To copy names and numbers to the SIM card

1 } Contacts } Options } Advanced

} Copy to SIM.

2 Select one of the alternatives.

When copying all contacts from the phone to the SIM card, all existing SIM card information is replaced.

To copy names and numbers to phone contacts

1 } Contacts } Options } Advanced

} Copy from SIM.

2 Select one of the alternatives.

To add a picture or a ringtone to a phone contact

1 } Contacts and select the contact

you want to add a picture or personal ringtone to } More } Edit contact.

2 Select the relevant tab and then select

Picture or Ringtone and } Add.

3 Select a picture or sound and } Save.

26 Calling

This is the Internet version of the user's guide. © Print only for private use.

To edit a phone contact

1 } Contacts and select a contact

} More } Edit contact.

2 Scroll to the relevant tab and select

the field to edit } Edit.

3 Edit the information } Save.

To edit a SIM contact

1 If SIM contacts is default } Contacts

and select the name and number to edit. If phone contacts is default

} Contacts } Options } SIM contacts

and select the name and number to edit.

2 } More } Edit contact and edit the

name and number.

Synchronizing contacts

You can back up and synchronize your contacts with a contacts application on the Web. For more information, please contact your service provider.

To synchronize contacts

} Contacts } Options } Sync. contacts

2 If you have more than one account,

select which account to use } Select

63 Synchronizing

information.

for more

Call list

Information about the most recently dialled, answered and missed calls are listed in separate tabs.

To call a number from the call list

1 } Calls from standby and select

a relevant tab.

2 Scroll to the name or number to call

} Call, or press and hold to make

a video call.

To add a call list number to contacts

1 } Calls from standby and select a tab. 2 Scroll to the number to add } More

} Save number.

3 } New contact to create a new contact,

or select an existing contact to add the number to.

To clear the call list

} Calls and select the All tab } More } Delete all.

Speed dialling

Save the phone numbers that you want to reach easily in positions 1-9 in your phone.

To speed dial

From standby, enter the position number } Call.

This is the Internet version of the user's guide. © Print only for private use.

27Calling

To edit speed dialling numbers

1 } Contacts } Options } Speed dial. 2 Scroll to the position } Add or

} Replace.

Voicemail

If your subscription includes an answering service, callers can leave a voicemail message when you cannot answer a call.

Contact your network operator for your voicemail number or for more information.

To call your voicemail service

Press and hold . If you have not entered a voicemail number, } Yes and enter the number.

To edit your voicemail number

} Messaging } Settings } Voicemail number.

Voice control

Manage calls with your voice by creating voice commands to:

• Voice dial – call someone by saying

the name.

• Activate voice control by saying

a “magic word”.

• Answer and reject calls when using

a handsfree.

Before voice dialling

Activate the voice dialling function and record your voice commands. An icon appears next to a phone number that has a voice command.

To activate voice dialling and record names

1 } Settings } the General tab } Voice

control } Voice dialling } Activate

} Yes } New voice

If the contact has more than one number, use and to view the numbers. Select the number to add the voice command to. Record a voice command such as “John mobile”.

3 Instructions appear. Wait for the tone

and say the command that you want to record. The voice command is played back to you.

4 If the recording sounds ok } Yes.

If not } No and repeat step 3. To record another voice command for a contact } New voice } Add again and repeat steps 2-4 above.

Caller name

Hear your recorded contact name when you receive a call from that contact.

and select a contact.

28 Calling

This is the Internet version of the user's guide. © Print only for private use.

To turn the caller name on or off

} Settings } the General tab } Voice control } Play caller name.

Voice dialling

Start voice dialling from standby using the phone, a portable handsfree, a Bluetooth headset or by saying your magic word.

To make a call

1 From standby, press and hold one

of the volume buttons.

2 Wait for the tone and say a recorded

name, for example “John mobile”. The name is played back to you and the call is connected.

To make a call with a handsfree

From standby, press and hold the handsfree button, or press the Bluetooth headset button.

The magic word

Record and use a voice command as a magic word to activate voice control without pressing any keys. The magic word can only be used with a handsfree or a Bluetooth headset.

Choose a long, unusual word or phrase that can easily be distinguished from ordinary background speech.

To activate and record the magic word

1 } Settings } the General tab

} Voice control } Magic word } Activate.

2 Instructions appear. } Continue. Wait

for the tone and say the magic word.

3 }Yes to accept or } No for a new

recording.

4 Instructions appear. } Continue and

select the environments in which you want your magic word to be activated.

Voice answering

Answer or reject incoming calls by using your voice, when using a handsfree.

You can only use a MIDI, WAV (16 kHz), EMY or IMY file as a ringtone with voice answering.

To activate voice answering and record voice answer commands

1 } Settings } the General tab

} Voice control } Voice answer } Activate.

2 Instructions appear. } Continue.

Wait for the tone and say “Answer”, or another word.

3 } Yes to accept or } No for a new

recording.

This is the Internet version of the user's guide. © Print only for private use.

29Calling

4 Instructions appear } Continue.

Wait for the tone and say “Busy”, or another word.

5 } Yes to accept or } No for a new

recording.

6 Instructions appear. } Continue and

select the environments in which you want voice answering to be activated.

To answer or reject a call using voice commands

When the phone rings, say:

• “Answer” to connect the call or

• “Busy” to reject the call.

To edit your voice commands

} Contacts select the contact } More } Edit contact. Scroll to the relevant tab.

To re-record a voice command

1 } Settings } the General tab

} Voice control } Voice dialling } Edit names.

2 Select a command } More

} Replace voice.

3 Wait for the tone and say

the command.

Diverting calls

Divert calls, for example, to an answering service.

When the Restrict calls function is activated, some Divert calls options are not available.

Your phone has the following options:

• Divert always – all calls.

• When busy – if a call is ongoing.

• Not reachable – if turned off

or unreachable.

• No reply – if not answered

in a specified time.

To activate a call divert

1 } Settings } the Calls tab } Divert calls. 2 Select a call type and divert option

} Activate.

3 Enter the phone number to divert

your calls to, or press Look up to find a contact } OK.

To deactivate a call divert

Scroll to the divert option } Deactivate.

32 Restricted dialling.

More than one call

Handle more than one call simultaneously.

30 Calling

This is the Internet version of the user's guide. © Print only for private use.

Call waiting service

When activated, you hear a beep if you receive a second call.

To activate or deactivate the call waiting service

} Settings } the Calls tab by using

or and }

To make a second call

1 } More } Hold to hold the ongoing call. 2 Enter the number to call } More } Call.

Receiving a second voice call

When you receive a second call, you can:

} Answer and put the ongoing call

on hold.

} Busy to reject and continue the

ongoing call.

} Replace active call to answer and

end the ongoing call.

Handling two voice calls

If you have calls ongoing and on hold, you can:

} More } Switch to switch between

the two calls.

} More } Join calls to join the two calls. } More } Transfer call to connect the

two calls. You are disconnected from both calls.

Manage calls } Call waiting

} End call and } Yes to retrieve the

held call.

} End call twice to end both calls

(operator dependent).

You cannot answer a third call without ending one of the first two calls or joining them into a conference call.

Conference calls

Start a conference call by joining an ongoing call and a call on hold. You then put the conference on hold to call and add up to five participants or just to make another call.

There may be additional charges for calls involving multiple parties, contact your network operator for more information.

To join the two calls into a conference call

} More } Join calls.

To add a new participant

1 } More } Hold to put the joined calls

on hold.

2 } More } Add call and call the next

person you want to include in the

conference call.

3 } More } Join calls. 4 Repeat steps 1-3 to include more

participants.

This is the Internet version of the user's guide. © Print only for private use.

31Calling

To release a participant

} More } Release part and select

the participant that to release from the conference call.

To have a private conversation

1 } More } Talk to and select the

participant that you want to talk to.

2 } More } Join calls to resume the

conference call.

Two voice lines

Make separate calls with different phone numbers if your subscription supports alternate line service.

To select a line for outgoing calls

} Settings and use or

to the Calls tab and select line 1 or 2.

To change the name of a line

} Settings and use or to scroll

to the Display tab } Edit line names and select the line to edit.

to scroll

My numbers

View, add and edit your own phone numbers.

To check your phone numbers

} Contacts } Options } Special numbers } My numbers and select

one of the options.

Accept calls

Receive calls only from certain phone numbers. If the divert calls option

When busy is activated, calls are

diverted.

To add numbers to the accepted callers list

1 } Settings and use or

to the Calls tab } Manage calls

} Accept calls } Only from list } Edit } Add. Select a contact.

2 To add a group of contacts to the

accepted callers list } Groups

34 Groups

To accept all calls

} Settings } the Calls tab } Manage calls } Accept calls } All callers.

to scroll

Restricted dialling

Restrict outgoing and incoming calls. A password from your service provider is required.

If you divert incoming calls, you cannot activate some Restrict calls options.

32 Calling

This is the Internet version of the user's guide. © Print only for private use.

The following calls can be restricted:

• All outgoing – All outgoing calls.

• Outgoing intl. – All outgoing

international calls.

• Outgoing intl. roam – All outgoing

international calls except to your home country.

• All incoming – All incoming calls.

• Inc. when roaming – All incoming

calls when you are abroad

21 Networks

To activate or deactivate a call restriction

1 } Settings and use or

to the Calls tab } Manage calls

} Restrict calls and select an option.

2 Select Activate or Deactivate, enter

your password } OK.

to scroll

Fixed dialling

The fixed dialling function allows calls to be made only to certain numbers saved on the SIM card. The fixed numbers are protected by your PIN2.

You can still call the international emergency number, 112, even when the fixed dialling function is activated.

Partial numbers can be saved. For

example, saving 0123456 allows calls

to be made to all numbers starting

with 0123456.

When fixed dialling is activated, you

cannot view or manage any phone

numbers saved on the SIM card.

To activate or deactivate fixed dialling

1 } Contacts } Options

} Special numbers } Fixed dialling

and select Activate or Deactivate.

2 Enter your PIN2 } OK and then } OK

again to confirm.

To save a fixed number

} Contacts } Options

} Special numbers } Fixed dialling

} Fixed dialling } New number and

enter the information.

Call time and cost

During a call, the duration of the call

is shown on the screen. You can check

the duration of your last call, outgoing

calls and the total time.

To check the call time

} Settings and use or

to the Calls tab } Time & cost

} Call timers.

to scroll

This is the Internet version of the user's guide. © Print only for private use.

33Calling

Additional calling functions

Tone signals

Use telephone banking services or control an answering machine with tone signals during a call.

• To send the tones, press the keys

- , or .

• To clear the screen after a call, press

• To turn the tones on or off during

a call, } More } Disable tones or

Enable tones.

Notepad

Enter a phone number during a call. When you end the call, the number remains on the screen to call or save in the phonebook.

} Call to call the number. } More } Save number and select a contact

to save the number. To create a new contact and save the number to

} New contact.

Showing or hiding your number

If your subscription supports the Calling Line Identification Restriction (CLIR) service, you can hide your phone number when making a call.

To always show or hide your phone number

1 } Settings } the Calls tab

} Show/hide my no.

2 Select Show number, Hide number

or Network default.

Groups

Create a group of numbers and email addresses to send messages to several recipients at the same time

35 Messaging

groups (with numbers) when you create accepted callers lists

calls

To create a group of numbers and email addresses

1 } Contacts } Options } Groups

} New group } Add.

2 Enter a name for the group } Continue. 3 } New } Add to find and select

a contact number.

4 Repeat step 3 to add more numbers.

} Done.

. You can also use

32 Accept

34 Calling

This is the Internet version of the user's guide. © Print only for private use.

Business cards

Add your own business card as a contact.

To add your own business card

} Contacts } Options } My business card and add information for your

business card } Save.

To send your business card

} Contacts } Options } My business card } Send my card and select

a transfer method.

Messaging

Text messaging, picture messaging,

voice messaging, email, My friends.

Your phone supports various messaging

services. Please contact your service

provider about the services you can use,

or for more information, visit

www.SonyEricsson.com

Text messaging (SMS)

Text messages can contain simple

pictures, sound effects, animations,

and melodies. You can also create

and use templates for your messages.

If you send a text message to a group,

you will be charged for each member.

Before you start

Make sure that the number of your

service centre is set. The number

is supplied by your service provider

and is usually saved on the SIM card

or you can add the number yourself.

To set a service centre number

} Messaging } Settings } Text

message } Service centre. If the

service centre number is saved on

the SIM card it is shown in the list.

/support

This is the Internet version of the user's guide. © Print only for private use.

35Messaging

2 If there is no number in the list

} New ServiceCentre and enter the

number, including the international “+” sign and country/region code } Save.

Sending text messages

For information about entering letters

17 Entering letters

Some language-specific characters use more space. For some languages you can deactivate space.

National chars.

to save

To write and send a text message

1 } Messaging } Write new

} Text message.

2 Write your message } Continue.

(If you want to save the message for later, press . } Yes to save in Drafts.)

3 } Enter phone no. and enter a number,

or } Contacts look-up to retrieve a number or a group from Contacts, or } Enter email addr. or select from the last used recipients list } Send.

To send a message to an email address, you need to set an email gateway number,

} Text message }

The number is supplied by your service provider.

} Messaging } Settings

Email gateway

To copy and paste text in a message

1 While writing your message

} More

} Edit } Copy all to copy all of the text

in your message or } Copy text } Start and use the navigation key to scroll and mark text in your message } End.

2 }

More } Edit } Paste.

To insert an item in a text message

1 While writing your message } More

} Add item.

2 Select an item type and then an item.

You can convert your text message to a picture message. While writing your message

message

message, (MMS).

} More } To picture

and continue creating a picture

38 Picture messaging

Receiving text messages

When you receive a text message, it appears in the Activity menu if

New events is set to Activity menu. } View to read the message.

If New events is set to Popup, you are asked if you want to read the text message. } Yes to read the message or } No to read it later. When you have read the text message } More for options or press to close the message.

36 Messaging

This is the Internet version of the user's guide. © Print only for private use.

To call a number in a text message

Select the phone number displayed in the message, } Call.

Saving and deleting text messages

Received text messages are saved in the phone memory. When the phone memory is full, delete messages or move them to the SIM card to be able to receive new messages. Messages saved on the SIM card remain until they are deleted.

To save a message

1 } Messaging } Inbox and select the

message to save.

2 } More } Save message. 3 } Saved messages to save on the

SIM card or } Templates to save the

message as a template in the phone.

To save an item in a text message

1 While reading a message, select the

phone number, picture or Web address

to save } More.

2 } Use (the phone number you have

selected appears) to save the phone

number or } Save picture to save a

picture or } Save bookmark to save

a bookmark.

To delete a message

1 } Messaging and select a folder. 2 Select the message to delete and

press .

To save or delete several messages

1 } Messaging and select a folder. 2 Select a message } More } Delete all

to delete all messages in the folder or } Mark several scroll and select messages by pressing Mark or

Unmark

3 } More } Save message to save

messages in the phone memory or on the SIM card or } Delete messages.

Long messages

The number of characters allowed in a text message depends on the language used for writing. You can send a longer message by linking two or more messages. You are charged for each of the messages linked in a long message. You may not receive all parts of a long message at the same time.

Check with your service provider for the maximum number of messages that can be linked.

This is the Internet version of the user's guide. © Print only for private use.

37Messaging

To turn long messages on

} Messaging } Settings } Text message } Max msg. length } Max available.

Templates for text messages

Add a new template or save a message as a template in your phone

37 To save a message

To add a template

1 } Messaging } Templates

} New template } Text.

2 Insert text } OK. 3 Enter a title } OK.

To use a template

1 } Messaging } Templates select

a template from the list } Use

} Text message.

2 Add text or } Continue and select

a recipient to send the message to.

Message options

Set a default value for several message options or choose the settings each time you send a message.

To set default text message options

} Messaging } Settings } Text message and select the options

to change.

To set message options for a specific message

1 When the message is written and

a recipient is selected } More

} Advanced.

2 Select an option to change } Edit and

select a new setting } Done.

To check the delivery status of a sent message

} Messaging } Sent messages and

select a text message } View } More

} View status.

Picture messaging (MMS)

Picture messages can contain text, pictures, video clips, camera pictures, sound recordings, and signatures. You can send picture messages to a mobile phone or an email address.

Before you start

Both you and the recipient must have subscriptions that support picture messaging.

38 Messaging

This is the Internet version of the user's guide. © Print only for private use.

Before sending a picture message,

make sure that:

1 The address of your message server

is set } Messaging } Settings

} Picture message } Message server.

2 You have entered the correct settings

} Messaging } Settings } Picture

message } Internet profiles.

If no Internet profile exists, you can

automatically receive all the settings

for MMS in a message from your

network operator or from

www.SonyEricsson.com/support

Creating and sending picture

messages

Select to write text, Add picture,

Add sound, Add video, Add page,

Add signature and Attachments.

You can add an already existing file

or use camera pictures and videos,

or the sound recorder to record sounds.

To create and send a picture

message

} Messaging } Write new } Picture

msg

} More to view a list of items to add to your message. Select an item.

2 } More to add more items to the

message. For specific item options, select items in the message and press the left selection key.

3 When ready to send } Continue. 4 } Enter email addr. or } Enter phone

no. or } Contacts look-up to retreive

a number or group in Contacts or select from the last used recipients list } Send.

When writing and editing picture messages you can use the copy and paste functionality paste text in a message

To set default picture message options

} Messaging } Settings } Picture message and select the options

to change.

Additional send options

Request a read report, a delivery report and set a priority for a specific message. You can also add more recipients to the message.

To select additional send options

1 When the message is created and

a recipient is selected } More.

2 } Add recipient to add recipients or

} Edit recipients to edit and add

recipients. } Edit subject to change the message subject or } Advanced to select additional send options.

36 To copy and

This is the Internet version of the user's guide. © Print only for private use.

39Messaging

Receiving picture messages

Select how to download your picture messages and how to save items that you receive in the picture messages.

To set Automatic download

} Messaging } Settings } Picture message } Auto download to view

and select one of the following options:

• Always ask – automatically

download.

• Ask in roaming – ask to download.

• Not in roaming – do not download.

• Always ask – always ask to

download.

• Off – new messages appear in the Inbox. Select the message and } View to download.

To receive picture messages

When you receive an automatically downloaded picture message, the picture message appears in the Activity menu if New events is set to Activity menu. } View to read the message.

If New events is set to Popup, you are asked if you want to read the picture message. } Yes to read or play the message, } Stop to stop playing or reading the message, } Reply to immediately reply or } More to view a list of options. Press to close the message.

40 Messaging

This is the Internet version of the user's guide. © Print only for private use.

To save an item in a picture message

When viewing a picture message

} More } Save items and select an

item to save from the list that appears.

Delete picture messages

Picture messages are saved in the phone memory. When the phone memory is full, you must delete messages to be able to receive new messages

text messages

Templates for picture messages

Add a new template or use a predefined template.

To add a template

1 } Messaging } Templates

} New template } Picture msg.

2 } More to add new items. 3 } Save, enter a title } OK to save the

template.

4 Select a template from the list } Use

} Continue and select a recipient to

send the message to.

To use a predefined template

1 } Messaging } Templates and select

a template from the list } Use to use the template as it is or } More } Edit

template to edit the template, } Save,

enter a title } OK to save the changes.

37 Saving and deleting

2 } Continue and select a recipient

to send the message to or select a template from the list } Use } Continue if you have edited the template.

Voice messages

Send and receive a sound recording as a voice message.

The sender and receiver must have a subscription supporting picture messaging.

To record and send a voice message

1 } Messaging } Write new

} Voice message.

2 Record your message. } Stop to end. 3 } Send to send the message. 4

} Enter email addr.

recipient

or } Enter phone no. for a

recipient phone number or } Contacts

look-up for a number or group in

Contacts or select from the last used recipients list below the send options.

} Send.

Receiving voice messages

When you receive an automatically downloaded voice message, the voice message appears in the Activity menu if New events is set to Activity menu.

} Play to listen to the message.

for an email

If New events is set to Popup, you are asked if you want to listen to the voice message. } Yes to play the message or } No if you want to play the message later. When you have listened to the voice message } More to view a list of options. Press to close the message.

Email

Connect to a POP3 or IMAP mail server to send and receive email messages with your phone. You can use the same email settings in your phone as in your computer email program.

Before you start

Make sure that your phone subscription supports Internet, email and data transfer (GPRS) and that you have registered as an email user and have email account settings in your phone.

60 Settings

For more information on how to enter your email settings contact your network operator or visit www.SonyEricsson.com/support.

This is the Internet version of the user's guide. © Print only for private use.

41Messaging

Create an email account

If necessary you can manually create an email account. Make sure that you have the email account settings from your email provider available.

Some of the settings are required and some are optional.

To enter required email account settings

1 } Messaging } Email } Settings

} Account settings } New account } Add.

2 Enter a name for the account } OK. 3 Press to select Email address,

enter the email address } OK.

4 Press to select Connect using and

select a data account (provided by your network operator or service provider).

5 Press to select Connection type

(POP3 or IMAP).

6 Press to select Incoming server,

enter the server name or IP address

} OK.

7 Press to select Username, enter

the username for the email account

} OK.

8 Press to select Password, enter the

password for the email account } OK.

9 Press and scroll to select Outgoing

server, enter the server name or IP

address } OK.

To enter optional email account settings

} Messaging }

Email } Settings

} Account settings } New account } Add to enter settings for a new

account or select an already existing account from the list } More } Edit

account and press or to scroll

and select optional settings for your email account, for example Check

interval.

Default email account

If you have several email accounts you can set one as default.

To set a default email account

} Messaging } Email } Settings } Account settings and select

an account.

To write and send an email message

1 } Messaging } Email } Write new. 2 } Add to enter the recipient field

} Enter email addr. to enter an email

address } OK or } Contacts look-up to select a recipient from Contacts

} Select or select an email address

from the last used recipients list below the send options } Select.

42 Messaging

This is the Internet version of the user's guide. © Print only for private use.

3 To add more recipients select To, Cc

or Bcc and select recipients to add. When finished selecting recipients

} Done.

4 Press to select the subject field,

type an email subject } OK. To edit the subject } Edit.

5 Press to select the text field, write

your message } OK. To edit the message

} Edit.

6 Press to select the attachment field.

} Add and choose the attachment type

to add } Select to select the attachment to add } Done or New attachment to add more attachments.

7 } Continue } Send.

When writing and editing email messages you can use the copy and paste functionality text in a message

To receive and read email messages

1 } Messaging } Email } Inbox

} Send & rec when the inbox is empty

or } Messaging } Email } Inbox

} More } Send & rec to download

new messages.

2 Select a message in the inbox

} View to read it.

36 To copy and paste

To reply to an email message

1 Select the message to reply in the inbox

} More } Reply or open the message } Reply.

2 } Include message to include the

original message in your reply or

}

Write new to exclude the original

message from your reply.

3 Write your message in the text field

} OK. To edit the message } Edit.

4 } Continue } Send.

To save in an email address

1 Open the message and select an email

address, a phone number or a Web address.

} More } Save address

address or } More } Save

bookmark to save a Web address or

} More } Use } Save number to save a phone

number.

To view or save an item in an email message

Select a message } More } Save

attachm. and select an item. } Save

to save the item or } More } View to view the item.

to save an

This is the Internet version of the user's guide. © Print only for private use.

43Messaging

To save an email message

Select a message } More

} Save message } Saved email.

The number of email messages that can be saved in the phone depends on available memory. When the phone memory is full, you must delete messages to be able to receive new messages

37 Saving and deleting text

messages

To save several email messages

1 } Messaging } Email } Inbox. 2 } More } Mark several and scroll

to select messages by pressing Mark or Unmark.

3 } More } Save message.

To delete an email message (POP3)

1 } Messaging } Email } Inbox } More. 2 } Mark for deletion or } Mark several

and scroll to select messages by pressing } Mark or Unmark. Marked messages are deleted the next time you connect to your server.

To delete an email message (IMAP4)

1 } Messaging } Email } Inbox 2 } Mark for deletion or

} More.

} Mark several

} Mark or Unmark.

My friends

Connect and log in to the My friends server to communicate online with your favourite friends. If your subscription supports instant messaging and presence services, you can send and receive messages and see contact status when they are online.

Contact your network operator for more information.

To log in to your My friends server

} Messaging } My friends } Log in.

To log out

} More } Log out.

To add a contact to the list

} Messaging } My friends } the Contacts tab, More } Add contact.

To send a chat message from My friends

1 } Messaging } My friends } the

Contacts tab and select a contact

from the list.

2 } Chat and type your message } Send.

You can also continue a chat conversation from the

Conversations

tab.

3 } More } Clear inbox. } With send &

rec.

No send and rec.

to delete

messages.

44 Messaging

This is the Internet version of the user's guide. © Print only for private use.

Status

Show your status to your contacts only or show it to all users on the My friends server.

To set status

} Messaging } My friends } More } Settings and select Show my status.

Choose To all or Only to contacts

} Select.

To change your own status

} Messaging } My friends } the My status tab and update your status

information. Use or to scroll between the status fields.

Chat group

A chat group can be started by your service provider, by an individual My friends user or by yourself. You can save chat groups by saving a chat invitation or by searching for a specific chat group.

To start a chat group

1 } Messaging } My friends } the Chat

groups tab } More } Add chat group } New chat group.

2 Select contacts to invite to the chat

group from your list of contacts

} Continue.

3 Enter a short invitation text } Continue

} Send.

To add a chat group

1 }

Messaging } My friends } the Chat

groups tab } More } Add chat group.

2 } By group ID to enter chat group ID

directly or } Search to search for a chat group.

The conversation history is preserved between log in and log out to let you return to chat messages from old conversations.

Area and cell information

Information messages may be sent to network subscribers within a certain area or cell.

To turn information on or off

} Messaging } Settings } Area info } Reception or Cell information.

This is the Internet version of the user's guide. © Print only for private use.

45Messaging

Imaging

Camera, video recorder, pictures.

Camera and video recorder

To take a picture or record a video clip

1 Close the phone. From

standby, press and hold to activate the camera. Use the navigation key to switch between camera and video recorder.

2 Press to take a picture or start

recording. To use Auto focus, press

half way down. To end recording,

press again.

• To take another picture or record

another clip, press to return to the viewfinder.

• To deactivate the camera or the video

recorder, press and hold .

Camera settings

When you are in the viewfinder

} Settings to view a number of options

to adjust and enhance your pictures and video clips before taking or recording them.

You can take pictures, record video clips, save, view and send them as email attachments or in picture messages.

If you try to record with a strong light source such as direct sunlight or a lamp, the screen may black out or the picture may be distorted.

Do not look directly at the camera light diodes of the phone using a magnification device. Failure to comply with this warning may damage your eyes.

To use the zoom

Use the volume buttons to zoom in and out.

To adjust brightness

Use the navigation key to increase or decrease brightness.

To turn on the photo light

Slide

the lock switch to shift between

on, off and auto.

Camera and video options

When the camera or video is activated

}Settings for the following options:

• Switch to video camera – record a

video clip or Switch to still camera – take a picture.

• Shoot mode (camera):

} Normal – no frame. } Panorama – join several pictures

into one.

} Frames – add a frame to your picture.

46 Imaging

This is the Internet version of the user's guide. © Print only for private use.

} Burst – take a rapid sequence

of pictures.

} Self-portrait – take a picture of

yourself with the camera on the front of the phone.

• Shoot mode (video): For picture message, Normal

or Self-portrait.

• Picture size (camera) – Large 1632x1224, Medium 640x480

or Small 160x120.

• Video size (video) – only available when Self-portrait is selected in Shoot mode.

• Auto focus – select On, Macro or Off.

To use Auto focus, press half way down. You will hear a beep when auto focus is set within the frame that appears.

• Turn on night mode – adapt to poor

lighting conditions.

• Light – select Auto, On or Off.

• Turn on self-timer (camera) – take

a picture a few seconds after pressing the camera button.

• Effects:

} Off – no effect. } Black & white – no colour. } Negative – reversed colours. } Sepia – brown tint. } Solarize – overexposure.

• White balance – adjust the colours

to lighting conditions.

• Turn on spot photometry – adjust

exposure to the centre of the picture or video.

• Picture quality (camera): Normal or Fine picture quality.

• Shutter sound (camera) – select

different shutter sounds.

• Turn on time and date (camera)

– add time and date.

• Reset file no. (camera) – reset the

file number counter.

• Save to – select Memory Stick or Phone memory to save the picture

or video.

• Turn on mirroring – shows a mirrored

image in self-portrait mode.

Transferring pictures to your computer

Using the USB cable, you can drag-and drop camera pictures to a computer running Windows® 2000, Windows XP and Mac OS X

using the USB cable

To further enhance and organize the camera pictures on a computer, Windows users can install Adobe® Photoshop® Album Starter Edition, included on the CD that comes with phone.

67 Transferring files

This is the Internet version of the user's guide. © Print only for private use.

47Imaging

Pictures

Your phone comes with a number of pictures and animations. You can:

• Use a picture as wallpaper and as

a screen saver.

• Assign a picture to a contact.

• Exchange pictures using one of the

available transfer methods.

Handling pictures

View, add, edit or delete pictures in

File manager. The number of pictures

that you can save depends on the size of the pictures. File types supported are, for example, GIF, JPEG, WBMP, BMP, PNG and SVG-Tiny.

To view your pictures

1 } File manager } Pictures. 2 The pictures are shown in thumbnail

view. To get a full view } View.

To display pictures in a slide show

1 } File manager } Pictures and select

a picture.

2 } View } More } Slide show.

To view information about a file

1 } File manager } Pictures or Videos,

select file.

2 } More } Information.

48 Imaging

This is the Internet version of the user's guide. © Print only for private use.

Using pictures

Add a picture to a contact, use it at start-up, as a wallpaper in standby or as a screen saver.

Screen saver

The screen saver activates automatically when the phone is idle for a few seconds. After a few more seconds, the screen saver changes to sleep mode, to save power. Press a button to activate the screen again.

To use a picture

1 } File manager } Pictures and select

a picture.

2 }

More } Use as and select an option.

To edit pictures

58 PhotoDJ™

Exchanging pictures

You can exchange pictures using one of the available transfer methods. Please note that you are not allowed to exchange some copyright protected material. For more information on sending and receiving pictures in messages

To send a picture

1 } File manager } Pictures and scroll

to a picture. } More } Send a transfer method.

2 For more options } More.

35 Messaging

and select

To receive a picture via a transfer method

Select a transfer method and follow the instructions that appear.

Some phones that support pictures cannot

receive picture sizes of more than 160x120.

The best picture size to view on a computer is 1632x1224.

To save a picture in a message

37 To save an item in a text message picture message save an item in an email message

Take a self-portrait

Set the shoot mode setting to selfportrait mode and hold the phone as shown in the illustration. Press to take a picture or record a video clip.

or %

40 To save an item in a

or %

43 To view or

Saving pictures and video clips

When you have taken a picture or recorded a video clip, the phone saves it in the phone memory or on the Memory Stick PRO™ Duo, if inserted.

If the phone memory or Memory Stick is full, you cannot save any more pictures or video clips unless you delete or move files

Sending pictures and video clips

When you have taken a picture or recorded a video clip, you can send it as a picture message if the file size has not exceeded the limit. To exchange pictures and video clips using other transfer methods

pictures

To manage a video clip or a picture

Record a video clip or take a picture

} More and select an option.

Transferring pictures to your computer

Using the USB cable, you can dragand-drop camera pictures to a computer

67 Transferring files using the USB

cable

19 File manager

48 Exchanging

This is the Internet version of the user's guide. © Print only for private use.

49Imaging

Remote screen

Use a compatible Bluetooth accessory to view pictures on a remote screen such as a TV. The accessory is not included with your phone. For a complete list of compatible accessories, please visit

support

To connect to a remote screen

} File manager } Pictures } View } More } Remote screen.

65 To add a device to your phone

www.SonyEricsson.com/

Entertainment

WALKMAN

ringtones, MusicDJ™, VideoDJ™, games and more.

WALKMAN™ player

The WALKMAN™ player is an all in one music and video player. The following file types are supported: MP3, MP4, 3GP, AAC, AAC+, AMR, MIDI, IMY, EMY and WAV (16 kHz

maximum sample rate) and Real®8. You can also use streamed files that are 3GPP compatible.

AMR and MIDI files are only visible and possible to play with the WALKMAN player if they are DRM-protected. You can, however, listen to other AMR and MIDI files, using the file manager.

Your computer needs to have one of the following operating systems to be able to use Disc2Phone: Windows® 2000 SP4, XP Home, or XP Professional.

To transfer files with the provided USB cable

cable

™, radio, PlayNow™,

67 Transferring files using the USB

50 Entertainment

This is the Internet version of the user's guide. © Print only for private use.

Transferring music

Disc2Phone computer software and USB drivers are included on the CD that comes with the phone. Use Disc2Phone to transfer music from CDs or your computer to the phone memory or Memory Stick PRO Duo™ in your phone.

To install Disc2Phone

1 Turn on your computer and insert

the CD that came with your phone. The CD starts automatically and the installation window opens.

2 Select a language and click

Install Disc2Phone

3 Click

the instructions. When the installation is complete, a Disc2Phone icon appears on the desktop.

To use Disc2Phone

1 Connect the phone to a computer

with the USB cable that came with your phone

67 Transferring files

using the USB cable

2 } Settings } the Connectivity tab

} USB connection } File transfer.

The phone will turn off and prepare for transferral of files.

and follow

3 Start Disc2Phone by double-clicking

the icon on the computer desktop.

4 For details on transferring music,

please refer to Disc2Phone Help. Click in the top right corner of the Disc2Phone window.

Do not remove the USB cable from the phone or computer during transfer, as this may corrupt the Memory Stick and the phone memory. You cannot view the transferred files in your phone until you have removed the USB cable from the phone.

5 You can obtain CD information (artist,

track, etc.) via Disc2Phone if you are connected to the Internet while extracting music from a CD.

For safe disconnection of the USB cable in

File transfer

Removable Disk icon in Windows Explorer and select Eject.

mode, right-click on the

www.SonyEricsson.com/ support

More information about moving files to your WALKMAN™ phone is available at

www.SonyEricsson.com/support

This is the Internet version of the user's guide. © Print only for private use.

51Entertainment

To play music and videos

1 } WALKMAN. The WALKMAN™

player browser opens.

2 Browse for songs by artist or track,

or in playlists. You can also browse for video clips. Select a list } Open.

3 Highlight a title } Play.

WALKMAN™ player controls

• Press and hold to open or

minimize the WALKMAN™ player during playback.

• Press to pause the playback.

Press again to resume playing.

• Press to go to the next music file

or video clip.

• Press to go to the previous music

file or video clip.

• Press and hold or to fast forward

or rewind when playing music files or video clips.

• Press or to view and scroll files

in the current playlist during playback.

• Press Play to select a highlighted file

in a list.

• When a video clip is playing, press

to play the video in slow motion.

} Play to resume normal playback.

• When a video clip is paused, press

to play the video one frame at a time.

• When in Now playing, press to

go to the WALKMAN™ player browser.

• Press and hold to exit.

Radio

To be able to listen to the radio you must turn on your phone and connect the HPM-80. The latest used broadcasting frequency will automatically start when the radio is turned on.

Do not use the phone in areas where mobile phones are prohibited,

84 Efficient use.

To listen to the radio

1 Turn on your phone and connect the

HPM-80.

2 Press and hold the MP/FM - ON/OFF

button to turn on the HPM-80.

3 Press the MP/FM - ON/OFF button

to switch to the radio.

HPM-80 radio control

• Slide or to manually find

a broadcasting frequency.

• Slide and hold or to manually

fast search for a broadcasting frequency.

• Press to automatically search

for a broadcasting frequency.

• Press and hold to mute and

unmute the ear speakers.

• Press the volume buttons to increase

or decrease the volume.

52 Entertainment

This is the Internet version of the user's guide. © Print only for private use.

Control the WALKMAN™ player with the HPM-80

To control the WALKMAN™ player with the HPM-80

1 Turn on your phone and connect

the HPM-80.

2 Press and hold the MP/FM - ON/OFF

button to turn on the HPM-80.

3 Press the MP/FM - ON/OFF button

to switch to the WALKMAN™ player.

4 Press to start or pause music.

HPM-80 WALKMAN™ player control

• Slide or for previous or next

track.

• Slide and hold or to rewind

or fast forward between tracks.

• Press and hold to mute and

unmute the ear speakers.

• Press the volume buttons to increase

or decrease the volume.

Browsing files

Browse music files and video clips in lists:

• Artists – lists music files you have

transferred using Disc2Phone.

• Tracks – lists all music files

(not ringtones) in your phone and on the Memory Stick.

• Playlists – create or play your own

lists of music files.

• Videos – lists all video clips in your

phone and on the Memory Stick.

Playlists

To organize the media files that are stored in the File manager, you can create playlists. Files in a playlist can be sorted by artist, title or by the order in which the files were added to the playlist. You can add a file to more than one playlist.

When you delete a playlist or a file from the playlist, the actual music or video file is not deleted from the memory, just the playlist reference to it. You can still add the file to another playlist.

To create a playlist

1 } WALKMAN } Playlists } New

playlist } Add. Enter a name } OK.

2 Select from the files that are available

in the File manager. You can add several files at a time and you can also add folders. All files in the selected folders will be added to the playlist.

To add files to a playlist

1 } WALKMAN } Playlists select a

playlist } Open } More

2 Select from the files that are available

in the File manager.

} Add media.

This is the Internet version of the user's guide. © Print only for private use.

53Entertainment

To remove files from a playlist

1 } WALKMAN } Playlists select

a playlist } Open.

2 Select the file and press .

To delete a playlist

} WALKMAN } Playlists select

a playlist and press .

WALKMAN™ player options

} More for options:

• Now playing – go to the Now playing view.

• Add media – add files or folders

to the playlist.

• Sort – sort by artist, title or by the

order in which files were added to the playlist.

• Delete – remove a file from the

playlist. In user-created playlists only the reference to the file is removed. In the Tracks list, the file is permanently deleted from the memory.

• Minimize – minimize the

WALKMAN™ player and return to standby with the music still playing.

• Rename – rename user-created

playlists.

• Delete playlist – delete user-created

playlists. Files are not deleted from

File manager.

• Information – view information

about the current file or video.

• Play mode – change the playback

order of songs and videos. Select

Shuffle to play the playlist files in

random order, or Loop to restart the playlist when the last file has been played.

• Equalizer – change treble and bass

settings.

• Send – send a music file or video

clip.

• Fullscreen – play in fullscreen.

• Capture frame – when a video clip

is paused, capture a picture from it.

Online music and videos

View videos and listen to music by streaming them to your phone from the Internet. If settings are not already in your phone information, contact your network operator or visit

www.SonyEricsson.com/support

To select a data account for streaming

} Settings } the Connectivity tab } Streaming settings and select

the data account to use.

60 Settings

. For more

54 Entertainment

This is the Internet version of the user's guide. © Print only for private use.

To stream video and audio

1 } Internet services } More

} Enter address.

2 Enter or choose the address to a Web

page and select a link to stream from. The WALKMAN player opens automatically when a link is selected.

To stream saved music and videos

1 } Internet services } More

} Bookmarks.

2 Select a link to stream. The WALKMAN

player opens and plays the music or video.

PlayNow™

Listen to music before you purchase and download it to your phone.

This function is network- or operatordependent. Contact your network operator for information about your subscription and PlayNow™. In some countries you may be able to purchase music tones from some of the world’s top musical artists.

This service is not available in all countries.

Before you start

If settings are not in your phone

60 Settings

To listen to PlayNow™ music

} PlayNow™ and select music from

a list.

Downloading from PlayNow™

The total price appears when you select to download and save a music file. Your phone bill or prepay card is debited when a purchase is accepted. Terms and conditions are also provided in the phone kit.

To download a music file

1 When you have listened to a music file

and agreed to accept the conditions

} Yes to download.

2 A text message is sent to confirm

payment and the file is made available to download. Music is saved in

File manager } Sounds.

Ringtones and melodies

You can exchange music, sounds and tracks, for example, using one of the available transfer methods.

You are not allowed to exchange some copyright-protected material. A DRMprotected file has a key symbol.

To select a ringtone

} Settings } and scroll to the Sounds & alerts tab } Ringtone.

This is the Internet version of the user's guide. © Print only for private use.

55Entertainment

To turn the ringtone on or off

Press and hold from standby. All signals except the alarm signal are affected.

To set the ringtone volume

1 } Settings } and scroll to the Sounds

& alerts tab } Ring volume and press

or to decrease or increase the

volume.

2 } Save.

Caller-specific ringtones

If your subscription supports Calling Line Identification (CLI) service, you can assign personal ringtones to contacts

ringtone to a phone contact

To set the vibrating alert

} Settings } the Sounds & alerts tab } Vibrating alert and select a setting.

Sounds and alerts options

From Settings } the Sounds & alerts tab, you can set:

• Message alert – select how to be

• Key sound – select what sound

26 To add a picture or a

notified of an incoming message.

to hear when you press the keys

MusicDJ™

Compose and edit your own melodies to use as ringtones. A melody consists of four types of tracks – Drums,

Basses, Chords, and Accents. A track

contains a number of music blocks. The blocks consist of pre-arranged sounds with different characteristics. The blocks are grouped into Intro,

Verse, Chorus, and Break. You

compose a melody by adding music blocks to the tracks.

To compose a melody

1 } Entertainment } MusicDJ™. 2 } Insert, Copy or Paste blocks. Use

, , or to move between the

blocks. Press to delete a block.

} More to view more options.

To edit a MusicDJ™ melody

} File manager } Sounds and select

the melody } More } Edit.

Exchanging MusicDJ™ melodies

Send and receive melodies using one of the available transfer methods. You are not allowed to exchange copyright-protected material.

You cannot send a polyphonic melody or an MP3 file in a text message.

56 Entertainment

This is the Internet version of the user's guide. © Print only for private use.

To send a melody

1 } File manager } Sounds and select

a melody.

2 } More } Send and select a transfer

method.

To receive a melody via a transfer method

Select a transfer method and follow the instructions that appear.

VideoDJ™

Compose and edit your own video clips by using video clips, pictures and text. You can also use trim to delete unwanted parts to shorten a video clip.

To create a video clip

1 } Entertainment } VideoDJ™. 2 } Add } Video clip, Picture, Text

or Camera } Select.

3 To add more items press } Add.

To edit a selected video clip

} Edit for options:

• Trim – to shorten the video clip.

• Add text – to add text to the video

clip.

• Replace – to select a new video clip.

• Delete – to remove the video clip.

• Move – to move the video clip to

another position.

To edit a selected picture

} Edit for options:

• Replace – to select a new picture.

• Duration – to select the display time

for the picture.

• Delete – to remove the picture.

• Move – to move the picture

to another position.

To edit a selected text

} Edit for options:

• Edit – to change the text.

• Background – to set background.

• Text colour – to set font colour.

• Duration – to select the display time

for the text.

• Delete – to remove the text.

• Move

– to move the text to another

position.

VideoDJ™ options

} More for options:

• Play – to view the video clip.

• Send – to send the video clip.

• Soundtrack – to add a soundtrack

to the video clip.

• Transitions – to set transitions

between video clips, pictures and text.

This is the Internet version of the user's guide. © Print only for private use.

57Entertainment

• Save – to save the video clip.

• Insert – to insert a new video clip,

picture or text.

• New video – to create a new

video clip.

To edit video clips in File manager

1 } File manager } Videos } Open

and select file.

2 } More } VideoDJ™ } Edit.

Sending video clips

You can send a video clip using one of the available transfer methods. Short video clips can be sent using picture messaging. If a video clip is too long, you can use the Trim function to make a video clip shorter.

To trim a video clip

1 Select a video clip from the storyboard

} Edit } Trim.

2 } Set to set the start point and } Start. 3 } Set to set the end point and } End. 4 Repeat steps 2 and 3 or } Done.

PhotoDJ™

Edit files using PhotoDJ™ or when viewing files.

To edit and save a file

1 } Entertainment } PhotoDJ™ or

} File manager } Pictures and select

a file } View } More } Edit.

2 } Tool and select an option. 3 After you have edited the selected

picture } More } Save picture.

Sound recorder

With the sound recorder, you can

record either your own memos or calls.

Recorded sounds can also be set as

ringtones. Recording of a conversation

is stopped if a participant ends the

call. Recording of all sounds stops

automatically if you receive a call.

In some countries or states it is required

by law that you inform the other person

before recording the call.

To record a sound

1 } Entertainment } Record sound. 2 Wait until you hear a tone. When

the recording starts, Recording and

a timer appears.

3 } Save to end, } Play to listen or

} More for options: Record new,

Send, Rename, Delete, Recorded

sounds.

58 Entertainment

This is the Internet version of the user's guide. © Print only for private use.

To listen to a recording

} File manager } Sounds and select

a recording } Play or } Stop.

Themes

Change the appearance of the screen, for example, colours and wallpaper, by using themes. Your phone has some predefined themes that cannot be deleted if they are protected. You can create new themes and download them to your phone. For more information, visit

www.SonyEricsson.com/support

To select or change a theme

} File manager } Themes and select

a theme.

Exchanging themes

Exchange themes using a transfer method.

To send a theme

1 } File manager } Themes and select

a theme.

2 } More } Send and select a transfer

method.

To receive and save a theme

1 Use a transfer method and open the

message you received the theme in.

2 Follow the instructions that appear

on the screen.

This is the Internet version of the user's guide. © Print only for private use.

Games

Your phone has several entertaining games. You can also download games and applications directly to the folders in your phone. Help texts are available for most games.

To start and end a game

1 } Entertainment } Games, select

game } Select.

2 Press and hold to end the game.

Applications

Download and run Java™ applications. You can view information or set different permission levels.

To view info for Java™ applications

1 } File manager } Applications or

} Games.

2 Select an application or a game

} More } Information.

To set permissions for Java™ applications

1 } File manager } Applications or

} Games.

2 Select an application or a game } More

} Permissions and set options.

59Entertainment

Java application screen size

Some Java applications are designed for a specific screen size and may not be able to adapt the application to the screen. For more information, contact the application vendor.

To set the screen size for a Java™ application

1 } File manager } Applications or

} Games.

2 Select an application or a game

} More } Screen size.

3 Select an option, for example,

User defined } Width and Height

to edit values.

Connectivity

Internet and email settings,

synchronizing, Bluetooth, infrared,

USB cable, update service.

Settings

Settings may already be entered when

you buy your phone. If not, make sure

you have a phone subscription that

supports data transfer (GPRS).

Download settings for Internet/WAP

browsing, email and MMS (picture

messaging) at

www.SonyEricsson.com/support

To download settings

1 On your computer, browse to

www.SonyEricsson.com/support

2 Select a region and a country

or Global support area.

3 Select the

a phone model.

4 Select which setting to download

to your phone.

Using Internet

Browse the Internet using HTTP

(Hyper Text Transfer Protocol).

Phone setup

tab, and select

60 Connectivity

This is the Internet version of the user's guide. © Print only for private use.

To select an Internet profile

} Settings and use or to scroll to

the Connectivity tab } Internet settings

} Internet profiles and select a profile

to use.

To start browsing

} Internet services and select a service

or } Internet services } More to view options.

To stop browsing

} More } Exit browser.

For more information contact your network operator or visit www.SonyEricsson.com/support.

Options when browsing

} More to view options. The menu

contains the following options but may depend on the Web page you are visiting:

If you select an email address when browsing a Web page, you can send a message to that address.

} Go to for options:

• Sony Ericsson – go to the pre-

defined homepage set for the current profile.

• Bookmarks – create, use or edit

bookmarks.

• Enter address – enter the address

to a Web page.

• History – list of previously visited

Web pages.

} Tools for options:

• Add bookmark – add a new

bookmark.

• Save picture – save a picture.

• Save page – save the current

Web page.

• Refresh page – refresh the current

Web page.

• Send link – send a link to the current

Web page.

• Make a call – make a call while

browsing the Internet. } More

}

End call to end the call and

continue browsing.

} View for options:

• Full screen – select normal

or full screen.

• Text only – select full content

or text only.

• Zoom – zoom in or out on the

Web page.

• Zoom to normal – set zoom

to default.

} Advanced to enter settings

for the browser.

} Exit browser to disconnect

and go to standby.

This is the Internet version of the user's guide. © Print only for private use.

61Connectivity

Using bookmarks

Use, create and edit bookmarks for the browser.

To work with bookmarks

1 } Internet services } More } Go to

} Bookmarks and select a bookmark } More.

2 Select an option.

Downloading

Download files, for example, pictures, themes, games and ringtones from Web pages.

To download from the Sony Ericsson Web page

1 } Internet services } Sony Ericsson. 2 Browse the Web page, select a file

to download and follow the instructions that appear.

Internet profile for Java™ applications

Some Java applications need to connect to the Internet to receive information, for example, games that downloads new levels from a game server.

Before you start

If settings are not in your phone

60 Settings

To select a profile for Java

} Settings } the Connectivity tab

} Settings for Java™ and select

an Internet profile.

Stored information

When browsing, you can save

information.

It is advisable to clear all sensitive

information from previously visited

Internet services. This is to avoid misuse

of personal information if your phone is

misplaced, lost or stolen.

The following information can

be saved:

• Cookies – improve Web page

access efficiency.

• Passwords – improve server access

efficiency.

To allow cookies

} Internet services } More } Advanced

} the Browsing tab } Allow cookies

} On.

To clear cookies

} Internet services } More } Advanced

} the Other tab } Clear cookies } Yes.

62 Connectivity

This is the Internet version of the user's guide. © Print only for private use.

To clear the password list

} Internet services } More } Advanced } the Other tab } Clear passwords } Yes.

Internet security

Secure browsing is supported. When using an Internet profile you can turn on security in the phone.

Trusted certificates

Certain Internet services, such as banking, require certificates in your phone. Your phone may already contain certificates when you buy it or you can download new certificates.

To check certificates in your phone

} Settings } the Connectivity tab } Internet settings } Security } Trusted cert.

Synchronizing

Synchronize phone contacts, appointments, tasks and notes via Bluetooth, the infrared port, Internet services or the USB cable included with the phone.

Synchronization software for your computer is available on the CD included with the phone. You can also visit

www.SonyEricsson.com/support

to download the software or Getting started guides for synchronization.

To select sync order for contacts

} Contacts } Options } Advanced } Sync. order to select sorting by first

or last name.

Synchronization with nearby devices

Install computer synchronization software from the CD that came with your phone or download it from

www.SonyEricsson.com/support

The software includes help information.

Remote synchronization via Internet

Synchronize online via an Internet service.

Before you start

• If settings are not in your phone

60 Settings

• Register a synchronization account

online.

• Enter remote synchronization

settings.

This is the Internet version of the user's guide. © Print only for private use.

63Connectivity

To enter remote synchronization settings

1 } Organizer } Synchronization

} New account } Yes to create

a new account.

2 Enter a name for the new account

} Continue.

3 Enter the following:

• Server address – server URL.

• Username – account username.

• Password – account password.

• Connection – select an Internet

profile.

• Applications – mark applications

to synchronize.

• App. settings – select an application

and enter a database name, and if required, username and password.

• Sync. interval – set how often

to synchronize.

• Remote initiation – select to always

accept, never accept or always ask when starting from a service.

• Remote security – insert a server ID

and a server password.

4 } Save to save your new account.

To start remote synchronization

} Organizer } Synchronization and

select an account } Start.

Bluetooth™ wireless

technology

Bluetooth makes it possible to connect

wirelessly to other Bluetooth devices.

You can:

• connect to several devices at the

same time.

• synchronize information with other

devices.

• use the remote control functionality.

• use a remote screen.

• exchange items and play

multiplayer games.

We recommend a range within 10 metres,

with no solid objects in between, for

Bluetooth communication.

Before you start

• Turn on Bluetooth to communicate

with other devices.

• Pair the Bluetooth devices with your

phone that you want to communicate with.

Please check if local laws or regulations

restrict the use of Bluetooth. If Bluetooth

is not allowed, you must ensure that the

Bluetooth function is turned off. The

maximum allowed Bluetooth radio output

power in the phone is automatically

adjusted according to possible local

restrictions. This means that the range

may vary.

64 Connectivity

This is the Internet version of the user's guide. © Print only for private use.

To turn Bluetooth on

} Settings } the Connectivity tab } Bluetooth } Turn on.

Adding devices to your phone

Enter a passcode to set up a secure link between your phone and the device. Enter the same passcode on the device when prompted. Devices with no user interface, such as a handsfree, will have a pre-defined passcode. Consult the device user guide for more information.

Make sure that the device you want to add has Bluetooth activated and visible.

To add a device to your phone

1 } Settings } the Connectivity tab

} Bluetooth } My devices } New

device

to search for available devices.

2 Select a device from the list. 3 Enter a passcode, if required.

To organize your list of devices

1 } Settings } the Connectivity tab

} Bluetooth } My devices and select

a device from the list.

2 } More to view a list of options.

Power save

Turn on to reduce power consumption by optimizing your phone for use with a single Bluetooth device. Turn off to connect with several Bluetooth devices at the same time.

To save power

} Settings } the Connectivity tab } Bluetooth } Powersave } On.

Phone name

Enter a name for your phone to be shown to other devices when found.

To enter a phone name

} Settings } the Connectivity tab } Bluetooth } Phone name.

Visibility

Choose to make your phone visible to other Bluetooth devices or not. If set to hide, other devices will not be able to discover your phone via Bluetooth.

To show or hide your phone

} Settings } the Connectivity tab } Bluetooth } Visibility } Show phone

or Hide phone.

Exchanging items

Send or receive items using Bluetooth as the transfer method. Choose a device from the list of found devices.

This is the Internet version of the user's guide. © Print only for private use.

65Connectivity

To send an item

1 Select an item, for example } Contacts

and select a contact.

} More } Send contact

} Via Bluetooth

3 Select the device to send the item to

} Select.

To receive an item

} Settings } the Connectivity tab } Bluetooth } Turn on. Make sure the

phone is visible,

your phone

65 To show or hide

. When you receive an item,

follow the instructions that appear.

To add a Bluetooth handsfree

1 } Settings } the Connectivity tab

} Bluetooth } Handsfree.

2 } Yes if you are adding a Bluetooth

handsfree for the first time or

} My handsfree } New handsfree } Add if you are adding another

Bluetooth handsfree. Ensure that your handsfree is in pairing mode. Consult the device user guide for more information.

Transferring sound

Transfer the sound for calls when using a Bluetooth handsfree. You can also transfer the sound for calls using the keypad.

To transfer sound when using a handsfree

During a call, } More } Transfer sound and select a device.

Directing sound

Direct sound when answering a call with the phone keypad or the handsfree button.

To direct sound when answering a call with a handsfree

1 } Settings } the Connectivity tab

} Bluetooth } Handsfree } Incoming call.

2 } In phone to direct to the phone or

} In handsfree to direct to the

handsfree.

Remote control

Use your phone as a remote control device to control computer applications such as a media player or Microsoft PowerPoint

presentations. Your computer must support Bluetooth HID Profile.

To select remote control

1 } Entertainment } Remote control. 2 Select an application to use and the

computer to connect to.

66 Connectivity

This is the Internet version of the user's guide. © Print only for private use.

File transfer

Use a computer equipped with Bluetooth to view and transfer files in the file manager. Use drag-and-drop functionality to:

• Transfer files between phone and

computer.

• Move and organize files.

• Delete files from the phone.

Infrared port

Use the infrared port as a transfer method with compatible devices. You can, for example, synchronize calendar items

When connecting to a computer, refer to its user documentation. Make sure that computer infrared speed is set to 115200 bps.

To turn the infrared port on

} Settings } the Connectivity tab } Infrared port } On or } 10 minutes

to turn on for 10 minutes.

To connect two devices

1 Turn on infrared in both devices. 2 Make sure the infrared port on your

phone is facing the infrared port on the other device with a maximum distance of 20 cm.

63 Synchronizing

To send an item using the infrared port (for example a contact)

1 Turn on infrared in both devices.

} Contacts and select a contact.

2 } More } Send contact } Via infrared.

Transferring files using the USB cable

When you connect your phone to a computer using the USB cable, the Memory Stick and the phone memory appear as drives or devices on the computer. If you are a Windows user, you can install the USB cable drivers

using the CD that comes with your phone,

drivers

Only use the USB cable that comes with the phone, and connect the USB cable directly to your computer. Do not remove

the USB cable from the phone or computer

during file transfer as this may corrupt the Memory Stick and the phone memory.

You can use the drag-and-drop functionality in your computer to:

• Transfer files between your phone

• Move, delete and organize files in

68 To install the USB

and the computer.

the phone memory or on the Memory.

67Connectivity

Your computer needs to have one of the following operating systems to be able to use this feature: Windows® 2000, Windows XP and Mac OS X.

To install and use the USB cable

1 Computer: Install the Sony Ericsson

PC Suite from the CD that comes with the phone.

2 Connect the USB cable to the phone

and the computer.

3 Phone: } Settings } the Connectivity

tab } USB connection } Phone mode to synchronize with the computer or use the phone as a modem. The phone will remain on in this mode.

4 Phone: } Settings } the Connectivity

tab } USB connection } File transfer to transfer music, pictures and other files to your phone. The phone will turn off in this mode.

5 For safe disconnection of the USB cable

in File transfer mode, right-click on the Removable Disk icon in Windows Explorer and select Eject.

6 Remove the USB cable from your

phone.

To install the USB drivers

1 Turn on your computer and insert the

CD that came with your phone. If the PC Suite installation window opens, simply close it as it is not needed here.

2 Turn on your phone and connect the

USB cable to a computer and to the phone. The "Found New Hardware Wizards" starts on the computer.

3 Computer: Click

automatically

4 The wizard should find the USB

software drivers automatically.

Finish

Click

5 Repeat steps 3 and 4 until all five

drivers are installed.

Install the software

and click

68 Connectivity

Update service

Keep your phone updated with the latest software. When a new software version is available, you can download and install it without affecting the user data in your phone.

Choose one of the following methods to update your phone:

• over the air via your phone or

• online via the provided USB cable

and an Internet-connected computer.

The Update service requires data access (GPRS). Your operator will provide you with a subscription with data access and with price information.

Before you start

If settings are not in your phone

60 Settings

To use Update service over the air

1 } Settings } the General tab

} Update service.

2 } Search for update to search for

the latest available software. Start the update process by following the installation instructions, or

} Software version to display the

current software installed in your mobile phone, or

} Reminder to set when to search

for new software.

To use Update service online

1 Connect the USB cable to the

computer and the phone.

2 Visit

www.SonyEricsson.com/support

3 Select a region and country. 4 Enter the product name. 5 Select Sony Ericsson Update Service

and follow the instructions.

69Connectivity

More features

Alarm clock, calendar, tasks, profiles, time and date, SIM card lock, etc.

Alarm clock

Set an alarm for a specific time. You can also set an alarm to recur on specific days. The alarm signal is on even if the phone is set to silent or turned off.

To use alarms

} Organizer } Alarms and select

an option:

• } Alarm set a time } Save.

• } Recurrent alarm. Set the time and

select days } Mark } Done.

• } Alarm signal and select a sound.

To snooze or turn an alarm off

To turn the alarm signal off when it rings, press any key or } Snooze. If you do not want the alarm to be repeated } Turn off.

To cancel an alarm

} Organizer } Alarms } Alarm } Turn off.

Calendar

You can use the calendar to keep track of important meetings. The calendar can be synchronized with a computer calendar or with a calendar on the Web

63 Synchronizing

Appointments

Add new appointments or use existing appointments as templates. You can also set reminders for appointments.

To add a new appointment

1 } Organizer } Calendar and select

a date } Select } New appointment

} Add.

2 Enter details and confirm each entry.

To view an appointment

1 } Organizer } Calendar and select

a day (appointment days marked in bold).

2 Select an appointment } View.

To view a calendar week

} Organizer } Calendar } More } View week.

70 More features

To set when reminders should sound

1 } Organizer } Calendar } More

} Advanced } Reminders.

2 } Always for a reminder to sound even

when the phone is turned off or set to silent. When the reminder sounds

} Yes to read the appointment or } No

to turn off the reminder. A reminders option set in the calendar affects a reminders option set in tasks.

Navigating in your calendar

Use the navigation key to move between days or weeks. In the monthly and weekly views, you can also use the keypad as follows

Today´s date

Back a week Next week

Back a month Next month

Back a year Next year

Calendar settings

} Organizer } Calendar } More

to select an option:

• View week – view appointments

of the week.

• New appointment – add a new

appointment.

• Change date – go to another date

in the calendar.

• Advanced – find, set reminders or

select a start day for the week.

• Delete – delete appointments.

Exchanging appointments

Exchange appointments using a transfer method. You can also synchronize appointments with acomputer

To send an appointment

Select an appointment in the list for a certain day } More } Send and select a transfer method.

63 Synchronizing

Tasks

Add new tasks or use existing tasks as templates. You can also set reminders for tasks.

To add a new task

1 } Organizer } Tasks } New task } Add. 2 } Task or Phone call. 3 Enter details and confirm each entry.

To view a task

} Organizer } Tasks and select a task } View.

71More features

To set when reminders should sound

1 } Organizer } Tasks and select a task

} More } Reminders.

2 } Always for a reminder to sound even

when the phone is turned off or set to silent. When the reminder sounds } Yes to read the task, or to call the phone number in a phone task. } No to turn off the reminder. A reminders option set in tasks affects a reminders option set in the calendar.

Exchanging tasks

Exchange tasks using a transfer method. You can also synchronize tasks with acomputer

To send a task

Select a task in the list of tasks for a certain day } More } Send and select a transfer method.

63 Synchronizing

Notes

Make notes and save them in a list. You can also show a note in standby.

To add a note

} Organizer } Notes } New note } Add and enter the note } Save.

To edit notes

1 } Organizer } Notes and a list appears. 2 Select a note } More and select an

option.

Exchanging notes

Exchange notes using a transfer method. You can also synchronize notes with a computer

63 Synchronizing

To send a note

Select a note } More } Send and select a transfer method.

Timer

Your phone has a timer. When the signal rings, press any key to turn it off.

To set the timer

} Organizer } Timer and set the hours,

minutes and seconds for countdown.

Stopwatch

Your phone has a stopwatch that can save several laps. The stopwatch continues to run when you answer an incoming call.

72 More features

To use the stopwatch

1 } Organizer } Stopwatch } Start. 2 } Stop or } New lap if you want

a lap time.

3 To reset the stopwatch } Reset.

Light

Use the light as a flash light in dimly lit environments. The light can also be used as an SOS signal.

Do not look directly at the camera light diodes of the phone using a magnification device. Failure to comply with this warning may damage your eyes.

To use the light

1 } Organizer } Light. 2 Choose between On for 1 minute, On,

Off or SOS.

Calculator

The calculator can add, subtract, divide and multiply.

To use the calculator

} Organizer } Calculator.

• Press or to select ÷ x - + . % =.

• Press to delete the figure.

• Press to enter a decimal point.

Code memo

Save security codes, such as for credit cards, in the code memo. Set a passcode to open the code memo.

Checkword and security

To confirm that you have entered the correct passcode you must enter a checkword.

When you enter your passcode to open the code memo, the checkword is shown for a short time. If the passcode is correct, the correct codes are shown. If you enter the incorrect passcode, the checkword and the codes that are shown are also incorrect.

To open code memo for the first time

1 } Organizer } Code memo. A message

with instructions appears } Continue.

2 Enter a four-digit passcode } Continue. 3 Re-enter the new passcode to confirm. 4 Enter a checkword (maximum 15

characters) } Done. The checkword

can consist of both letters and

numbers.

To add a new code

1 } Organizer } Code memo and enter

your passcode } New code } Add.

2 Enter a name associated with the

code } Continue.

3 Enter the code } Done.

73More features

To change the passcode

1 } Organizer } Code memo and enter

your passcode } More } Change

passcode.

2 Enter your new passcode } Continue. 3 Re-enter the new passcode }

Continue.

4 Enter a checkword } Done.

Forgot your passcode?

If you forget your passcode, you must reset the code memo.

To reset code memo

1 } Organizer } Code memo and enter

any passcode to access the code memo. The checkword and codes that

are then shown are incorrect.

2 } More } Reset. 3 Reset code memo? appears } Yes.

The code memo is reset and all entries

are cleared. The next time you enter

the code memo, you must start at

73 To open code memo for the first

time

Profiles

Your phone has predefined profiles that

are set to suit a certain environment.

You can reset all profile settings to the

way they were set when you bought

your phone.

To select a profile

} Settings } the General tab } Profiles

and select a profile.

To view and edit a profile

} Settings } the General tab } Profiles } More } View and edit.

You cannot rename the normal profile.

To reset profiles

} Settings } the General tab } Profiles } More } Reset profiles.

Time and date

The time is always displayed in standby.

• To set the time } Settings } the General tab } Time & date } Time.

Enter the time } Save.

• To set the time format } Format and

select an option.

• To set the date and date format

} Settings } the General tab } Time & date } Date.

SIM card lock

The SIM card lock protects your subscription, but not the phone itself, from unauthorized use. If you change SIM cards, your phone still works with the new SIM card.

74 More features

Most SIM cards are locked at the time of purchase. If the SIM card lock is on, you have to enter a PIN (Personal Identity Number) every time you turn on your phone.

If you enter your PIN incorrectly three times in a row, the SIM card is blocked. This is indicated by the message PIN

blocked. To unblock it, you need to

enter your PUK (Personal Unblocking Key). Your PIN and PUK are supplied by your network operator. You can edit your PIN and select a new fourto eight-digit PIN.

If the message Codes do not match appears when you edit your PIN, you entered the new PIN incorrectly.

If the message followed by old PIN incorrectly.

Wrong PIN

Old PIN:

, you entered your

appears,

To unblock your SIM card

1 When PIN blocked appears, enter

your PUK } OK.

2 Enter a new four- to eight-digit PIN

} OK.

3 Re-enter the new PIN to confirm } OK.

To edit your PIN

1 } Settings } the General tab } Locks

} SIM lock } Change PIN.

2 Enter your PIN } OK. 3 Enter a new four- to eight-digit PIN

} OK.

4 Re-enter the new PIN to confirm } OK.

To turn the SIM card lock on or off

1 } Settings } the General tab } Locks

} SIM lock } Protection and select On

or Off.

2 Enter your PIN

} OK.

Phone lock

Protect your phone against unauthorized use if it is stolen and the SIM card is exchanged. You can change the phone lock code (0000) to any four- to eightdigit personal code.

Automatic phone lock

If the phone lock is set to automatic, you do not need to enter your phone lock code until a different SIM card is inserted in the phone.

It is important that you remember your new code. If you should forget it, you have to hand in your phone to your local Sony Ericsson retailer.

75More features

To set the phone lock

1 } Settings } the General tab } Locks

} Phone lock } Protection and select

an alternative.

2 Enter the phone lock code } OK.

To unlock the phone

If the phone lock is on, enter your code

} OK.

To edit your phone lock code

} Settings } the General tab } Locks } Phone lock } Change code.

Keypad lock

Lock the keypad to avoid dialling a number by accident.

Calls to the international emergency number 112 can still be made, even when the keypad is locked.

Automatic keylock

In standby, automatic keylock means the keypad is locked a short while after you last pressed a key.

To set the automatic keylock

} Settings } the General tab } Locks } Automatic keylock.

To lock the keypad manually

Slide the lock switch or open the phone and press } Lock keys. You can still answer an incoming call and the keypad locks again after the call. The keypad remains locked until you unlock it manually.

To unlock the keypad manually

When the phone is open, press

} Unlock or slide the lock switch.

When the phone is closed, open the phone or slide the lock switch.

Start-up screen

You can select a start-up screen that will appear when you turn your phone on.

To select a start-up screen

} Settings } the Display tab } Start-up screen and select

an option.

Brightness

Adjust the brightness of the screen.

To set the brightness

} Settings } the Display tab } Brightness.

76 More features

Troubleshooting

Why doesn’t the phone work the way I want?

This chapter lists some problems that you might encounter while using your phone. Some problems require you to call your network operator, but you can easily correct most of the problems yourself.

However, if you need to hand in your phone for repair, please note that you may lose information and content that you have saved in your phone. You are advised to make a copy of such information before handing your phone in for repair.

For more support go to

www.SonyEricsson.com/support

I have problems with memory capacity or the phone working slowly

Possible cause

is full or the memory contents are not properly organized.

Solution

day to free memory and increase the capacity of your phone.

: The phone memory

: Restart your phone every

You also have the option to do a

Master reset. Some of your personal

data and settings you have made will be lost when doing this

reset

No battery icon appears when I start charging the phone

Possible cause:

or has not been used for a long time.

Solution:

before the battery icon appears on the screen.

Some menu options appear in grey

It may take up to 30 minutes

Possible cause:

activated or your subscription does not support the function.

Solution:

operator.

Possible cause:

themes, pictures and sounds that are copyright-protected, the Send menu is sometimes unavailable.

I do not understand the language in menus

Contact your network

Since you cannot send

Possible cause:

is set in the phone.

Solution:

Change the language

17 Phone language

79 Master

The battery is empty

A service is not

The wrong language

77Troubleshooting

I cannot turn on the phone

Possible cause:

is discharged.

Solution:

5 To charge the battery

Solution:

charger attached. If the phone starts, restart the phone with no charger attached.

I cannot charge the phone or battery capacity is low

Possible cause:

properly connected to the phone.

Solution:

connector clicks properly into place when connected

battery

Possible cause:

connection is bad.

Solution:

clean the connectors. You can use a soft brush, cloth or q-tip, soaked with alcohol. Make sure that the battery is completely dry before you put it back. Check that the battery connectors in the phone are undamaged.

Possible cause:

out and needs to be replaced.

The battery

Recharge the battery

Turn the phone on with the

The charger is not

Make sure that the charger

The battery

Remove the battery and

The battery is worn

5 To charge the

Solution:

charger for the same phone model, or visit your retailer and ask them to verify if the battery and charger are working properly.

The phone turns itself off

Possible cause:

been pushed unintentionally.

Solution:

lock, or lock the keypad manually

Possible cause:

connection is bad.

Solution:

inserted correctly

card and battery

I cannot use SMS/text messages on my phone

Possible cause:

or incorrect.

Solution:

to find out the correct SMS service centre setting

(SMS)

I cannot use MMS/picture messages on my phone

Possible cause:

does not include data capability.

Try another battery and

The button has

Turn on the automatic key

76 Keypad lock

Make sure the battery is

Contact your network operator

The battery

5 To insert SIM

Settings are missing

35 Text messaging

Your subscription

78 Troubleshooting

Solution:

operator.

Possible cause:

or incorrect.

Solution:

Please contact your network

Settings are missing

Go to

www.SonyEricsson.com/support

choose your phone model, then choose “Phone setup – MMS” and follow the instructions

I cannot use the Internet

Possible cause:

does not include data capability.

Solution:

operator.

Please contact your network

Possible cause:

missing or incorrect.

Solution:

Go to

60 Settings

Your subscription

Internet settings are

www.SonyEricsson.com/support

choose your phone model, then choose “Phone setup – WAP” and follow the instructions

The phone cannot be detected by other users via Bluetooth

Possible cause:

Bluetooth on.

60 Settings

You have not turned

Solution:

is turned on and that your phone is visible to other users

hide your phone

I cannot synchronize or transfer data

between my phone and my computer, when using the included USB cable

Possible cause:

been properly detected and installed

on your computer. The software that came with your phone has not been properly installed on the computer.

Solution: www.SonyEricsson.com/support

choose your phone model, then choose “Product information” - “Getting started”. The guide “Synchronizing the phone with a computer” contains installation

instructions and a troubleshooting guide, that may assist you in solving the problem.

Master reset

The changes that you have made to settings and the content that you have added or edited, will be deleted.

If you select Reset settings, the changes that you have made to settings will be deleted.

Make sure that Bluetooth

65 To show or

The cable has not

Go to

79Troubleshooting

If you select Reset all, in addition to your changes to settings, all contacts, messages, personal data, and content that you have downloaded, received or edited will also be deleted.

To reset the phone

1 } Settings } the General tab

} Master reset.

2 } Reset settings or } Reset all. 3 When instructions appear } Continue.

If you select melodies and pictures that you have downloaded, received or edited is also deleted.

Error messages

Insert SIM

Possible cause:

in the phone or you may have inserted it incorrectly.

Solution:

5 To insert SIM card and battery

Possible cause:

connectors need cleaning.

Solution:

clean it. Also check that the card is not damaged in a way that may prevent connection to the phone connectors. In that case, contact your network operator for a new SIM card.

Reset all

, content such as

There is no SIM card

Insert a SIM card

The SIM card

Remove the SIM card and

Insert correct SIM card

Possible cause:

work only with certain SIM cards.

Solution:

correct operator SIM card for your phone.

Wrong PIN/Wrong PIN2

Possible cause:

PIN or PIN2 incorrectly.

Solution:

} Yes

PIN blocked/PIN2 blocked

Possible cause:

PIN or PIN2 code incorrectly three times in a row.

Solution:

lock

Codes do not match

Possible cause:

you have entered do not match.

Solution:

a security code (for example your PIN) you have to confirm the new code by entering exactly the same code again.

74 SIM card lock.

The phone is set to

Check if you are using the

You have entered your

Enter the correct PIN or PIN2

74 SIM card lock

You have entered your

To unblock %

The two codes that

When you want to change

74 SIM card

80 Troubleshooting

No netw. coverage

Possible cause:

receiving any radio signal, or the received signal is too weak.

Solution:

and make sure that the network has coverage where you are. If so, try to do a new search.

Possible cause:

working properly.

Solution:

phone. If you still get the same or a similar message, please contact your network operator.

Possible cause:

working properly.

Solution:

phone. If this works, it is probably the phone that is causing the problem. Please contact the nearest Sony Ericsson service location.

Emerg. calls only

Possible cause:

of a network, but you are not allowed to use it. However, in an emergency, some network operators allow you to call the international emergency number 112.

Your phone is not

Contact your network operator

The SIM card is not

Insert your SIM card in another

The phone is not

Insert your SIM card in another

You are within range

Solution:

signal that is strong enough. Contact your network operator and make sure your subscription is ok

Phone lock

Possible cause:

Solution

Phone lock code:

Possible cause:

is required.

Solution:

Your phone comes with the default phone lock code 0000

You have to move to get a

22 Emergency calls.

The phone is locked.

: To unlock the phone

75 Phone lock.

The phone lock code

Enter the phone lock code.

75 Phone

lock.

PUK blocked

Possible cause:

personal unblocking key code (PUK) incorrectly 10 times in a row.

Solution:

operator.

Charging, alien battery

Possible cause

are using is not a Sony Ericsson approved battery.

Solution:

You entered your

Contact your network

: The battery that you

86 Battery use and care

81Troubleshooting

Important information

Sony Ericsson Consumer Web site, safe and efficient use, warranty, declaration of conformity.

Sony Ericsson Consumer Web site

www.SonyEricsson.com

support section where help and tips are only a few clicks away. Here you will find the latest computer software updates and tips on how to use your product more efficiently.

Service and support

From now on you will have access to a portfolio of exclusive service advantages such as:

• Global and local websites providing support.

• A global network of Call Centers.

• An extensive network of Sony Ericsson service

partners.

is a

• A warranty period. Learn more about the warranty

conditions in this user guide. On

www.SonyEricsson.com

section in the language of your choice, you will find the latest support tools and information, such as software updates, Knowledgebase, Phone setup and additional help when you require it.

For operator-specific services and features, please contact your network operator for more information.

You can also contact our Call Centers. See the phone number for the nearest Call Center in the list below. If your country/region is not represented in the list, please contact you local dealer. (The phone numbers below were correct at the time of going to print. On

www.SonyEricsson.com

find the latest updates.) In the unlikely event that your product needs service, please contact the dealer from whom it was purchased or one of our service partners. Save your original proof of purchase, you will need it if you need to claim warranty.

For a call to one of our Call Centers you will be charged according to national rates, including local taxes, unless the phone number is a toll-free number.

, under the support

country phone number email adress

Australia 1-300 650 050 questions.AU@support.sonyericsson.com Argentina 800-333-7427 questions.AR@support.sonyericsson.com Austria 0810 200245 questions.AT@support.sonyericsson.com Bangalore 080-57505555 question.IN@support.sonyericsson.com Belgium 02-7451611 questions.BE@support.sonyericsson.com Brazil 4001-0444 questions.BR@support.sonyericsson.com Canada 1-866-766-9374 questions.CA@support.sonyericsson.com Central Africa +27 112589023 questions.CF@support.sonyericsson.com Chile 123-0020-0656 questions.CL@support.sonyericsson.com China 4008100000 questions.CN@support.sonyericsson.com Colombia 18009122135 questions.CO@support.sonyericsson.com Croatia 062 000 000 questions.HR@support.sonyericsson.com Czech Republic 844 550 055 questions.CZ@support.sonyericsson.com

you can always

82 Important information

Denmark 33 31 28 28 questions.DK@support.sonyericsson.com Finland 09-299 2000 questions.FI@support.sonyericsson.com France 0 825 383 383 questions.FR@support.sonyericsson.com Germany 0180 534 2020 questions.DE@support.sonyericsson.com Greece 801-11-810-810

Hong Kong 8203 8863 questions.HK@support.sonyericsson.com Hungary 01 437 7300 questions.HU@support.sonyericsson.com India 39011111 (Add STD code when dialling from a GSM connection)

Indonesia 021-2701388 questions.ID@support.sonyericsson.com Ireland 1850 545 888 questions.IE@support.sonyericsson.com Italy 06 48895206 questions.IT@support.sonyericsson.com Malaysia 03-78809800 questions.MY@support.sonyericsson.com Mexico 001-95-888-821-8408 questions.MX@support.sonyericsson.com Mumbai 022-56995555 questions.IN@support.sonyericsson.com Netherlands 0900 899 8318 questions.NL@support.sonyericsson.com New Zealand 0800-100150 questions.NZ@support.sonyericsson.com Norway 815 00 840 questions.NO@support.sonyericsson.com Philippines 02-6351860 questions.PH@support.sonyericsson.com Poland 0 (prefix) 22 6916200 questions.PL@support.sonyericsson.com Portugal 808 204 466 questions.PT@support.sonyericsson.com Romania (+4021) 401 0401 questions.RO@support.sonyericsson.com Russia 095 7870986 questions.RU@support.sonyericsson.com Singapore 67440733 questions.SG@support.sonyericsson.com Slovakia 02-5443 6443 questions.SK@support.sonyericsson.com South Africa 0861 632222 questions.ZA@support.sonyericsson.com Spain 902 180 576 questions.ES@support.sonyericsson.com Sweden 013-24 45 00 questions.SE@support.sonyericsson.com Switzerland 0848 824 040 questions.CH@support.sonyericsson.com Taiwan 02-25625511 questions.TW@support.sonyericsson.com Thailand 02-2483030 questions.TH@support.sonyericsson.com Turkey 0212 47 37 777 questions.TR@support.sonyericsson.com United Arab Emirates 43 919880 questions.AE@support.sonyericsson.com United Kingdom 08705 23 7237 questions.GB@support.sonyericsson.com United States 1-866-766-9374 questions.US@support.sonyericsson.com Venezuela 0-800-100-2250 questions.VE@support.sonyericsson.com

210-89 91 919 (from mobile) questions.GR@support.sonyericsson.com

questions.IN@support.sonyericsson.com

83Important information

Guidelines for Safe and Efficient Use

Please read this information before using your mobile phone.

Recommendations

• Always treat your product with care and

keep it in a clean and dust-free place.

• Do not expose your product to liquid or moisture

or humidity.

• Do not expose your product to

extreme high or low temperatures.

• Do not expose your product to open

flames or lit tobacco products.

• Do not drop, throw or try to bend your

product.

• Do not close your product with an object inserted

between keypad and display; this may damage your product.

• Do not paint your product.

• Do not use your product near medical equipment

without requesting permission.

• Do not use your product when in, or around

aircraft, or areas posted “turn off two-way radio”.

• Do not use your product in an area

where a potentially explosive atmosphere exists.

• Do not place your product or install

wireless equipment in the area above your car's air bag.

• Do not attempt to disassemble your

product. Only Sony Ericsson authorised personnel should perform service.

Antenna

Only use an antenna that has been specifically design ed by Sony Ericsson for your mobile phone. Use of unauthorised or modified antennas could damage your mobile phone and may violate regulations, causing loss of performance and SAR levels above the recommended limits (see below).

Efficient use

Hold your mobile phone as you would any other phone. Do not cover the top of the phone when in use, as this affects call quality and may cause the phone to operate at a higher power level than needed, thus shortening talk and standby times.

Radio frequency (RF) exposure and SAR

Your mobile phone is a low-power radio transmitter and receiver. When it is turned on, it emits low levels of radio frequency energy (also known as radio waves or radio frequency fields). Governments around the world have adopted comprehensive international safety guidelines, developed by scientific organizations, e.g. ICNIRP (International Commission on Non-Ionizing Radiation Protection) and IEEE (The Institute of Electrical and Electronics Engineers Inc.) through periodic and thorough evaluation of scientific studies. These guidelines establish permitted levels of radio wave exposure for the general population. The levels include a safety margin designed to assure the safety of all persons, regardless of age and health, and to account for any variations in measurements.

Specific Absorption Rate (SAR) is the unit of measurement for the amount of radio frequency energy absorbed by the body when using a mobile phone. The SAR value is determined at the highest certified power level in laboratory conditions, but the actual SAR level of the mobile phone while operating can be well below this value.

This is because the mobile phone is designed to use the minimum power required to reach the network.

Variations in SAR below the radio frequency exposure guidelines do not mean that there are variations in safety. While there may be differences in SAR levels among mobile phones, all Sony Ericsson mobile phone models are designed to meet radio frequency exposure guidelines.

84 Important information

A separate leaflet with SAR information for this mobile phone model is included with the material that comes with this mobile phone. This information can also be found, together with more information on radio frequency exposure and SAR, on

www.SonyEricsson.com

Driving

Please check if local laws and regulations restrict the use of mobile phones while driving or require drivers to use handsfree solutions. We recommend that you use only Sony Ericsson handsfree solutions intended for use with your product. Please note that because of possible interference to electronic equipment, some vehicle manufacturers forbid the use of mobile phones in their vehicles unless a handsfree kit with an external antenna supports the installation.

Always give full attention to driving and pull off the road and park before making or answering a call if driving conditions so require.

Personal medical devices

Mobile phones may affect the operation of cardiac pacemakers and other implanted equipment. Please avoid placing the mobile phone over the pacemaker, e.g. in your breast pocket. When using the mobile phone, place it at the ear opposite the pacemaker. If a minimum distance of 15 cm (6 inches) is kept between the mobile phone and the pacemaker, the risk of interference is limited. If you have any reason to suspect that interference is taking place, immediately turn off your mobile phone. Contact your cardiologist for more information. For other medical devices, please consult the manufacturer of the device.

CHILDREN

DO NOT ALLOW CHILDREN TO PLAY WITH YOUR MOBILE PHONE OR ITS ACCESSORIES. THEY COULD HURT

THEMSELVES OR OTHERS, OR COULD ACCIDENTALLY DAMAGE THE MOBILE PHONE OR ACCESSORY. YOUR MOBILE PHONE OR ITS ACCESSORY MAY CONTAIN SMALL PARTS THAT COULD BE DETACHED AND CREATE A CHOKING HAZARD.

Disposal of old electrical & electronic equipment

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local city office or your household waste disposal service or the shop where you purchased the product.

Power supply

Connect the AC power adapter only to designated power sources as marked on the product. Make sure the cord is positioned so that it will not be subjected to damage or stress. To reduce risk of electric shock, unplug the unit from any power source before attempting to clean it. The AC power adapter must not be used outdoors or in damp areas. Never alter the cord or plug. If the plug will not fit into the outlet, have a proper outlet installed by a qualified electrician.

Emergency calls

Mobile phones operate using radio signals, which cannot guarantee connection under all conditions.

85Important information

Therefore you should never rely solely upon any mobile phone for essential communications (e.g. medical emergencies).

Emergency calls may not be possible on all cellular networks or when certain network services and/or mobile phone features are in use. Check with your local service provider.

Battery use and care

We recommend that you fully charge the battery before you use your mobile phone for the first time. The battery can only be charged in temperatures between +5°C (+41°F) and +45°C (+113°F). A new battery or one that has not been used for a long time could have reduced capacity the first few times it is used.

The talk and standby times depend on the actual transmission conditions when using the mobile phone. If the mobile phone is used near a base station, less power is required and talk and standby times are prolonged.

• War ning! May explode if disposed of

in fire.

• Use only Sony Ericsson branded

original batteries and chargers intended for use with your mobile phone. Other chargers may not charge sufficiently or may produce excessive heat. Using other batteries and chargers could be dangerous.

• Do not expose the battery to liquid.

• Do not let the metal contacts on the battery touch

another metal object. This could short-circuit and damage the battery.

• Do not disassemble or modify the battery.

• Do not expose the battery to extreme

temperatures, never above +60°C (+140°F). For maximum battery capacity, use the battery in room temperature.

• Turn off your mobile phone before removing

the battery.

• Keep out of children's reach.

• Use the battery for the intended

purpose only.

• Do not allow the battery to be put into

the mouth. Battery electrolytes may be toxic if swallowed.

Disposing of the battery

Please check local regulations for disposal of batteries or call your local Sony Ericsson Call Center for information.

The battery should never be placed in municipal waste. Use a battery disposal facility if available.

End User Licence Agreement

This wireless device (“Device”) contains software owned by Sony Ericsson Mobile Communications AB (“Sony Ericsson”) and its third party suppliers and licensors (“Software”).

As user of this Device, Sony Ericsson grants you a non-exclusive, non-transferable, non-assignable license to use the Software solely in conjunction with the Device on which it is installed. Nothing herein shall be construed as a sale of the Software to a user of this Device.

You shall not reproduce, modify, distribute, reverse engineer, decompile, otherwise alter or use any other means to discover the source code of the Software or any component of the Software. For avoidance of doubt, you are at all times entitled to transfer all rights and obligations to the Software to a third party, solely together with the Device with which you received the Software, provided always that such third party agrees in writing to be bound by these rules.

You are granted this license for a term of the useful life of this Device. You can terminate this license by transferring all your rights to the Device on which you have received the Software to a third party in

86 Important information

writing. If you fail to comply with any of the terms and conditions set out in this license, it will terminate with immediate effect.

Sony Ericsson and its third party suppliers and licensors are the sole and exclusive owner of and retain all rights, title and interest in and to the Software. Sony Ericsson, and, to the extent that the Software contains material or code of a third party, such third party, shall be entitled third party beneficiaries of these terms.

The validity, construction and performance of this license shall be governed by the laws of Sweden. The foregoing shall apply to the full extent permitted by, when applicable, statutory consumer rights.

Limited Warranty

Sony Ericsson Mobile Communications AB, S-221 88 Lund, Sweden, (Sony Ericsson), provides this Limited Warranty for your mobile phone and original accessory delivered with your mobile phone (hereinafter referred to as “Product”).

Should your Product need warranty service, please return it to the dealer from whom it was purchased, or contact your local Sony Ericsson Call Center (national rates may apply) or visit

www.SonyEricsson.com

Our warranty

Subject to the conditions of this Limited Warranty, Sony Ericsson warrants this Product to be free from defects in design, material and workmanship at the time of its original purchase by a consumer, and for a subsequent period of one (1) year.

What we will do

If, during the warranty period, this Product fails to operate under normal use and service, due to defects in design, materials or workmanship, Sony Ericsson authorised distributors or service partners, in the country/region* where you purchased the Product,

to get further information.

will, at their option, either repair or replace the Product in accordance with the terms and conditions stipulated herein.

Sony Ericsson and its service partners reserve the right to charge a handling fee if a returned Product is found not to be under warranty according to the conditions below.

Please note that some of your personal settings, downloads or other information may be lost when your Sony Ericsson Product is repaired or replaced. At present Sony Ericsson may be prevented by applicable law, other regulation or technical restrictions from making a backup copy of certain downloads. Sony Ericsson does not take any responsibility for any lost information of any kind and will not reimburse you for any such loss. You should always make backup copies of all the information stored on your Sony Ericsson Product such as downloads, calendar and contacts before handing in your Sony Ericsson Product for repair or replacement.

Conditions

1 The warranty is valid only if the original proof

of purchase issued to the original purchaser by a Sony Ericsson authorised dealer, specifying the date of purchase and serial number**, for this product, is presented with the Product to be repaired or replaced. Sony Ericsson reserves the right to refuse warranty service if this information has been removed or changed after the original purchase of the Product from the dealer.

2 If Sony Ericsson repairs or replaces the Product,

the repaired or replaced Product shall be warranted for the remaining time of the original warranty period or for ninety (90) days from the date of repair, whichever is longer. Repair or replacement may involve the use of functionally equivalent reconditioned units. Replaced parts or components will become the property of Sony Ericsson.

87Important information

3 This warranty does not cover any failure of the

Product due to normal wear and tear, or due to misuse, including but not limited to use in other than the normal and customary manner, in accordance with the Sony Ericsson instructions for use and maintenance of the Product. Nor does this warranty cover any failure of the Product due to accident, software or hardware modification or adjustment, acts of God or damage resulting from liquid. A rechargeable battery can be charged and discharged hundreds of times. However, it will eventually wear out – this is not a defect. When the talk-time or standby time is noticeably shorter, it is time to replace your battery. Sony Ericsson recommends that you use only batteries and chargers approved by Sony Ericsson. Minor variations in display brightness and color may occur between phones. There may be tiny, bright or dark dots on the display. These are called defective pixels and occur when individual dots have malfunctioned and can not be adjusted. Two defective pixels are deemed acceptable. Minor variations in camera image appearance may occur between phones. This is nothing uncommon and is not regarded as a defective camera module.

4 Since the cellular system on which the Product is to

operate is provided by a carrier independent from Sony Ericsson, Sony Ericsson will not be responsible for the operation, availability, coverage, services or range of that system.

5 This warranty does not cover Product failures

caused by installations, modifications, or repair or opening of the Product performed by a non-Sony Ericsson authorised person.

6 The warranty does not cover Product failures which

have been caused by use of accessories or other peripheral devices which are not Sony Ericsson branded original accessories intended for use with the Product.

7 Tampering with any of the seals on the Product will

void the warranty.

8 THERE ARE NO EXPRESS WARRANTIES,

WHETHER WRITTEN OR ORAL, OTHER THAN THIS PRINTED LIMITED WARRANTY. ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL SONY ERICSSON OR ITS LICENSORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOST PROFITS OR COMMERCIAL LOSS; TO THE FULL EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.

Some countries/states do not allow the exclusion or limitation of incidental or consequential damages, or limitation of the duration of implied warranties, so the preceding limitations or exclusions may not apply to you.

The warranty provided does not affect the consumer's statutory rights under applicable legislation in force, nor the consumer’s rights against the dealer arising from their sales/purchase contract. *EUROPEAN UNION (EU)

If you have purchased your Product in an EU country you can have your Product serviced, under the conditions set out above, within the warranty period in any EU country where an identical Product is sold by an authorised Sony Ericsson distributor. To find out if your Product is sold in the EU country you are in, please call the local Sony Ericsson Call Center. Please observe that certain services may not be possible elsewhere than in the country of original purchase, for example due to the fact that your Product may have an interior or exterior which is different from equivalent models sold in other EU countries. It may not be possible to repair SIMlocked Products. ** In some countries/regions additional information is requested. If so, this is clearly shown on the valid proof of purchase.

88 Important information

FCC Statement

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Declaration of Conformity

We, Sony Ericsson Mobile Communications AB of Nya Vattentornet

S-221 88 Lund, Sweden declare under our sole responsibility that our product

Sony Ericsson type AAD-3022011-BV

and in combination with our accessories, to which this declaration relates is in conformity with the appropriate standards 3GPP TS 51.010-1,EN 301908-1, EN 301489-7, EN 301489-24 EN 300328, EN 301489-17 and EN 60950, following the provisions of, Radio Equipment and Telecommunication Terminal Equipment directive

99/5/EC with requirements covering EMC directive 89/336/EEC, and Low Voltage directive 73/23/EEC.

Lund, September 2005

Hiroshi Yoshioka, Head of Product Business Unit GSM/UMTS

We fulfil the requirements of the R&TTE Directive (99/5/EC).

89Important information

Index

alarm clock ......................................... 70

answering service ............................... 28

applications ........................................ 59

appointments ...................................... 70

automatic redialling ............................ 21

battery

inserting and charging .................. 5

use and care ............................... 86

Bluetooth™ wireless technology ........ 64

business cards .................................... 35

buttons

See

keys and buttons ............ 14

calculator ............................................ 73

calendar .........................................70–71

call divert ............................................ 30

call list ................................................. 27

call numbers in message .................... 37

call time .............................................. 33

call waiting .......................................... 31

caller-specific ringtones ..................... 56

calls

accepting .................................... 32

answering and rejecting ............. 21

emergency ...................................22

handling two calls ........................31

international .................................21

making and receiving ..............8, 21

making notes during ....................34

missed .........................................22

putting on hold ............................30

recording .....................................58

restricting .....................................32

code memo ..........................................73

conference calls ...................................31

contacts

adding phone contacts ................25

default contacts ...........................24

groups of .....................................34

synchronizing ...............................63

date ......................................................74

declaration of conformity .....................89

delivery status ......................................38

Disc2Phone .........................................51

installing .......................................51

display, brightness ...............................76

downloading files .................................62

Index

effects, camera ................................... 47

email ..............................................41–44

end user licence agreement ............... 86

entering letters

multitap input .............................. 17

T9™ Text Input ........................... 17

file manager ........................................ 19

fixed dialling ........................................ 33

games ................................................. 59

groups ................................................. 34

handsfree ............................................ 66

help texts, in phone ............................ 14

hiding number ..................................... 34

HPM-80 ................................................ 9

icons ................................................... 16

infrared port ........................................ 67

instant messaging Internet

bookmarks .................................. 62

cookies and passwords .............. 62

See

My friends ...... 44

security and certificates ..............63

settings ........................................60

key

keys and buttons .........................14

keypad lock .........................................76

keys and buttons .................................14

language ..............................................77

light ......................................................73

locks

SIM card ......................................74

long messages .....................................37

magic word ..........................................29

memory status

phone contacts ............................25

SIM contacts ...............................25

Memory Stick Duo™

formatting ....................................20

menu overview .....................................10

messages

area and cell information .............45

delivery status ..............................38

email ............................................41

picture ..........................................38

Index

text .............................................. 35

voice ........................................... 41

microphone ......................................... 22

See

MMS multitap input

music

MusicDJ™ .......................................... 56

My friends ........................................... 44

my numbers ........................................ 32

picture messages ............... 38

entering letters ............................ 17

transferring ................................. 51

navigating menus ................................ 14

networks ............................................. 21

notepad ............................................... 34

notes ................................................... 72

open/close, phone ................................ 8

phone

assembly ...................................... 4

language ..................................... 17

Phone overview .......................... 10

photo light ........................................... 46

PhotoDJ™ .......................................... 58

picture messages ..........................38–40

picture sizes .........................................46

pictures ................................................48

edit ...............................................58

screen saver ................................48

PIN code

changing ......................................75

unblocking .....................................6

playlists ..........................................53–54

PlayNow™ ...........................................55

profiles .................................................74

PUK ...........................................6, 74, 75

remote control .....................................66

ringtones ........................................55–56

safety guidelines ..................................84

screen saver ........................................48

self-portrait ..........................................49

sending

appointments and tasks ..............71

business cards ............................35

melodies and ringtones ...............57

notes ............................................72

pictures ........................................48

themes .........................................59

Index

settings

display brightness ....................... 76

email ........................................... 41

Internet ....................................... 60

Java™ ......................................... 62

setup wizard ......................................... 7

shortcuts ............................................. 16

SIM card

contact numbers ........................ 24

copying to/from .......................... 26

lock and unblock ........................ 74

See

SMS SOS

sound recorder ................................... 58

sound, transferring and directing ....... 66

speed dialling ...................................... 27

start-up screen ............................. 48, 76

stopwatch ........................................... 72

streaming media ................................. 55

synchronizing .................................63–64

text messages .................... 35

See

emergency numbers ........... 22

T9™ Text Input

add words ................................... 18

entering letters ............................ 17

tasks ..............................................71–72

templates ...................................... 38, 40

text messages ...............................35–38

themes .................................................59

time ......................................................74

timer .....................................................72

transferring

camera pictures ...........................47

files ..............................................67

music ...........................................51

turning on/off

Bluetooth .....................................65

infrared port .................................67

phone lock ...................................76

ringtone ........................................56

SIM lock protection .....................75

unblock SIM card ................................75

Update service .....................................69

USB drivers

installing .......................................68

video recorder .....................................49

VideoDJ™ ............................................57

voice answering ...................................29

voice control ..................................28–30

voice dialling ........................................29

voice messages ...................................41

voicemail ..............................................28

Index

volume

setting ringtone ........................... 56

volume, ear speaker ........................... 22

WALKMAN™ player ......................50–55

wallpaper ............................................ 48

WAP

See

Internet ............................... 60

warranty .............................................. 86

writing languages ................................ 17

zoom

camera ........................................ 46

Web page ................................... 61

Sony Ericsson W900, UMTS-GSM 1900 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Sony Ericsson

Getting started

Instruction symbols

Assembly

Turning on the phone and making calls

HPM-80

Phone and menu overview

Navigation

Shortcuts

Phone language

Entering letters

Activity menu

File manager

Calling

Making and receiving calls

Emergency calls

Video call

Contacts

Using contacts

Synchronizing contacts

Call list

Speed dialling

Voicemail

Voice control

Voice dialling

The magic word

Diverting calls

More than one call

Conference calls

Two voice lines

My numbers

Accept calls

Restricted dialling

Fixed dialling

Call time and cost

Additional calling functions

Groups

Business cards

Messaging

Text messaging (SMS)

Picture messaging (MMS)

Voice messages

Email

My friends

Area and cell information

Imaging

Camera and video recorder

Transferring pictures to your computer

Pictures

Entertainment

WALKMAN™ player

www.SonyEricsson.com/ support

Radio

Control the WALKMAN™ player with the HPM-80

PlayNow™

Ringtones and melodies

MusicDJ™

VideoDJ™

PhotoDJ™

Sound recorder

Themes

Games

Applications

Connectivity

Settings

Synchronizing

Infrared port

Transferring files using the USB cable

Update service

More features

Alarm clock

Calendar

Tasks

Notes

Timer
