Sony XBR-65A8H, XBR-65A8CH, XBR-55A8H, XBR-55A8CH Owner's Manual

Television

Téléviseur Televisor digital a color con pantalla de diodo orgánico de emisión de luz (OLED)

5-014-776-11(1)

Reference Guide	US
Manuel de référence	FR
Guía de referencia	ES

Read this manual before using this product

Sony Customer Support

U.S.A.:

http://www.sony.com/tvsupport

Canada:

http://www.sony.ca/support

United States	Canada
1.800.222.SONY	1.877.899.SONY

Call the telephone number that appears on your warranty card/policy.

Please do not return the product to the store.

Lisez ce manuel avant d’utiliser le produit

Service à la clientèle Sony

Canada : http://www.sony.ca/support États-Unis : http://www.sony.com/tvsupport

Canada États-Unis 1.877.899.SONY 1.800.222.SONY

Appelez le numéro de téléphone qui apparaît sur votre carte/police de garantie.

Ne retournez pas le produit au magasin.

Lea este manual antes de usar el producto

Centro de Asistencia de Sony

http://esupport.sony.com/ES/LA/

Llame al número de teléfono que aparece en su tarjeta/póliza de garantía.

Por favor no devuelva el producto a la tienda donde adquirió el producto.

XBR-65A8H / 65A8CH / 55A8H / 55A8CH

About Manuals

This TV comes with the following manuals. Please retain the manuals for future reference.

Setup Guide

• TV installation and setup.

Reference Guide (this manual) / Safety Documentation

•Safety information, remote control, troubleshooting, wall-mount installation, specification, etc.

Help Guide (On screen Manual)

• Settings, Android TV functions, Internet connection, troubleshooting, etc.

• To open it, press the HELP button on the remote control and select Help Guide.

IMPORTANT - Read the End User Software License Agreement before using your Sony product. Using your product indicates your acceptance of the End User Software License Agreement. The software license agreement between you and Sony is available online at Sony website (http://www.sony.net/ tv-software-licenses/) or on your product screen. Go to [Settings] t [Device Preferences] t [About] t [Legal information] t [End user license agreement].

Note

•Images and illustrations used in the Setup Guide and this manual are for reference only and may differ from the actual product.

The 65” class has a 64.5 inch (163.9 cm) viewable image size and the 55” class has a 54.6 inch (138.8 cm) viewable image size (measured diagonally).

•You can refer to the Help Guide with your smartphone.

https://rd1.sony.net/

help/tv/husltn1/ h_usltn/

IMPORTANT NOTICE TO MEXICO

This equipment operation is subject to the following two conditions: (1) It is possible that this equipment or device may not cause harmful interference, and (2) this equipment or device must accept any interference, including interference that may cause undesired operation.

For information related to certificate number, refer to the package label and/or product.

Note: This product uses the following module for wireless functionalities:

Model: DHUR-SY63

Brand: Wistron NeWeb Corporation

CAUTION

To prevent electric shock and blade exposure, do not use this AC plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted.

•Operate the TV only on 110 V – 240 V AC (U.S.A./Canada 120 V AC)

Location of the identification label

Labels for the TV Model No. and Power Supply rating are located on the rear of the TV.

IMPORTANT NOTICE

Owner’s Record

The model and serial numbers are located at the side and/or rear of the TV. Record these numbers in the spaces provided below. Refer to them whenever you call upon your Sony dealer regarding this TV.

Model Name

Serial No.

Note

This television includes a QAM demodulator which should allow you to receive unscrambled digital cable television programming via subscription service to a cable service provider. Availability of digital cable television programming in your area depends on the type of programming and signal provided by your cable service provider.

Safety Information

Notice for customers in the United States of America

Supplier’s Declaration of Conformity

Trade Name: SONY

Model: XBR-65A8H / XBR-65A8CH / XBR-55A8H /

XBR-55A8CH

Responsible Party: Sony Electronics Inc.

Address: 16535 Via Esprillo, San Diego, CA 92127 U.S.A.

Telephone Number: 858-942-2230

2US

FCC Related Information

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Pursuant to FCC regulations, you are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

Safety and Regulatory

5 GHz bands are restricted to indoor operations only.

Notice for customers in Canada

This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

(1)This device may not cause interference.

(2)This device must accept any interference, including interference that may cause undesired operation of the device.

To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.

High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

Notice for customers in the United States of America and Canada

This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated keeping the radiator at least 20 cm or more away from person’s body (excluding extremities: hands, wrists, feet and ankles).

This device and its antenna(s) must not be co-located or operating with any other antenna or transmitter except Grant condition.

Compatible Wall-Mount Bracket

Information

Use the following Sony Wall-Mount Bracket with your TV model.

		Sony TV Model No.
		XBR-65A8H / XBR-65A8CH /
		XBR-55A8H / XBR-55A8CH
Sony Wall-Mount		SU-WL855*1
Bracket Model No.
Use with other Wall-Mount Brackets*2 may cause instability
				US
and could result in property damage or injury.
*1	Only on limited region/country/TV model.
*2	For instructions on using the Wall-Mount bracket with
	your TV please go to https://www.sony.com/am/
	support for your TV model and download “Wall-Mount
	Bracket”.

To Customers

Sufficient expertise is required for TV installations. Be sure to subcontract the installation to a Sony dealer or licensed contractor and pay adequate attention to safety during the installation.

Before setting up your TV

Some TV models are packaged with a detached Table-Top Stand so you can mount your TV to a wall right away. See “Installing the TV to the Wall” if you want to mount the TV to a wall. If you are not mounting the TV to a wall, you will need to attach the Table-Top Stand (refer to the Setup Guide).

Be sure to consider the following while setting up your TV:

•Disconnect all cables when carrying the TV.

•Carry the TV with the adequate number of people; larger size TVs require two or more people.

•Correct hand placement while carrying the TV is very important for safety and to avoid damage.

•When handling or mounting the TV set, do not lay down the TV.

•Ensure your TV has adequate ventilation, refer to the safety documentation.

•For best picture quality, do not expose the screen to direct illumination or sunlight.

•Avoid installing the TV in a room with reflective wall and floor materials.

•Avoid moving the TV from a cold area to a warm area. Sudden room temperature changes may cause moisture condensation. This may cause the TV to show poor picture and/or poor color. Should this occur, allow moisture to evaporate completely before powering the TV on.

3US

Securing the TV

Sony strongly recommends taking measures to prevent the TV from toppling over.

Unsecured TVs may topple and result in property damage, serious bodily injury or even death.

Preventing the TV from Toppling

•Secure the TV to a wall and/or Stand.

•Do not allow children to play or climb on furniture and TV sets.

•Avoid placing or hanging items on the TV.

•Never install the TV on:

slippery, unstable and/or uneven surfaces.

furniture that can easily be used as steps, such as a chest of drawers.

•Install the TV where it cannot be pulled, pushed, or knocked over.

•Install the TV so that the TV’s Table-Top Stand does not protrude out from the Stand (not supplied). If the Table-Top Stand protrudes out from the Stand, it may cause TV set to topple over, fall down, and cause personal injury or damage to the TV.

•Route all AC power cords and connecting cables so that they are not accessible to curious children.

Recommended Measures to Secure the TV

Consider the following measures when securing your TV to a Stand (not supplied).

1Secure the Stand for the TV.

Make sure the Stand can adequately support the weight of the TV. Use two angle braces (not supplied) to secure the Stand. For each angle brace use the appropriate hardware to:

•Attach one side of the angle brace to the wall stud.

•Attach the other side to the Stand.

Angle brace (not supplied)

Stand

2Secure the TV to the Stand.

Use the optional hardware listed as follows (not supplied):

•M6 machine screws (screwed into the TV’s rear cover).

•A screw or similar (attach it to the Stand).

•Rope or chain (strong enough to support the weight of the TV). Make sure that there is no excess slack in the rope or chain.

1Screw hole on the rear cover

M6 machine screw (not supplied)

Rope or chain (not supplied)

2

	1.5 N·m
3	{15 kgf·cm}
Screw (not supplied)

The length of the M6 machine screw differs depending on the rope or chain diameter. Please refer to below illustration.

9 mm – 13 mm

Screw (M6)

Rope or chain

TV’s rear cover

4US

3Anchor the TV to the wall by using bolts, wall anchor and chain (or rope).

M6 eye bolts (not supplied)

Rope or chain (not supplied)

Wall-mount holes

Wall-anchor (not supplied)

Please refer to below illustration for M6 eye bolt length.

9 mm – 13 mm

M6 eye bolt

TV’s rear cover

Note

•Your TV is shipped with screws attached to the rear of the TV depending on the TV model. (They are fastened in the screw holes for wall mounting.) Be sure to remove the upper two screws prior to anchoring the TV to a wall.

•Securing the TV to the Stand without securing the TV and the Stand to the wall provides minimum protection against the TV toppling over. For further protection, be sure to follow the three measures recommended.

The BRAVIA® 4K TV Experience
Thank you for choosing Sony! Your new BRAVIA® TV
opens the door to the “4K TV Experience”. This
document will help you get the most out of your TV.
Please take a moment to register your TV at:
U.S.A.: http://productregistration.sony.com
Canada: http://www.sony.ca/registration
Four Steps to a 4K TV Experience
Set, Source, Sound, and Setup.
1 Set
Now that you have made the best selection in OLED	US
TV technology, be sure to remove all of the
accessories from the packaging before setting up
your TV.

2Source

To experience the stunning detail of your BRAVIA TV, you need access to HD programming.

•Upgrade your signal or content source to high-definition (4K) by contacting your HD service provider.

•Bring the astonishing resolution of your Sony 4K Ultra HD TV to life with Sony 4K Ultra HD Blu-ray Player. (The availability depends on region)

•Receive over-the-air HD broadcasts with an HD-quality antenna connected directly to the back of your TV.

Visit http://www.antennaweb.org for more information on antenna selection and setup.

•Discover the wealth of entertainment now available on super-high resolution Blu-ray Disc™ player and other Sony HD equipment.

3Sound

Complete the high-definition experience with a BRAVIA Sync™ surround sound system or A/V receiver from Sony.

4Setup

Install your TV and connect your sources. To help assure the highest quality for your HD experience, use Premium High Speed HDMI (High-Definition Multimedia Interface) cables.

To learn more about 4K TV, visit:

U.S.A.: http://www.sony.com/HDTV

Canada: http://www.sony.ca/hdtv

This TV displays all video input signals in a resolution of 3,840 dots × 2,160 lines.

Note

•For details of supported formats, refer to the “Specifications” in this manual.

•For supported PC formats, refer to the Help Guide.

5US

Protecting the TV Screen (OLED TV)

Precautions to Protect the Screen from Damage

Image retention

OLED TV’s are susceptible to image retention (burn-in) due to the characteristics of the materials used. Image retention may occur if images are displayed in the same location on the screen repeatedly or over extended periods of time.

This is not a malfunction of the TV. Avoid displaying images that may cause image retention.

The following are examples of images that may cause image retention:

•Content with black bars either on the top and bottom and/or the left and right sides of the screen. (for example, Letterboxed, 4:3 screen, Standard definition)

•Static images such as photos.

•Video games that might have static content in some part of the screen.

•On-screen menus, program guides, channel logos etc.

•Static content from applications.

•On-screen tickers, such as those used for news and headlines.

To reduce the risk of image retention:

•Sony recommends that you turn off the TV normally by pressing the power button on the remote control or the TV.

•Fill the screen by changing [Wide mode] to eliminate the black bars. Select [Wide mode] other than [Normal].

•Turn off the OSD (On Screen Display) by pressing the DISPLAY button, and turn off the menus from connected equipment. For details, refer to the instruction manuals for the connected equipment.

•Avoid displaying static images with bright colors (including white), clocks or logos on any portion of the screen.

•Set the picture settings based on the ambient conditions. The Standard Picture is recommended for home use and when viewing content that often displays the station logos, etc.

The TV has following features to help reduce/prevent image retention.

Panel refresh

A notification to perform a panel refresh will appear after the TV has been in use for long periods of time. It is recommended to perform a panel refresh when you receive this notification. A panel refresh will adjust the panel uniformity. Panel refresh can also be performed manually and should only be used when image retention is very noticeable.

Caution:

•The Panel refresh function may affect the panel. As a reference, perform the Panel refresh only once a year, do not perform it more than once a year as it may affect the usable life of the panel.

•Panel refresh takes about one hour to complete.

•A white line may be displayed on the screen during the Panel refresh, this is not a malfunction of the TV.

•Panel refresh will only work when the room temperature is between 50 ºF and 104 ºF (10 ºC and 40 ºC).

Pixel shift

Automatically moves the image on the screen to prevent image retention.

Other feature

The screen brightness is automatically reduced when displaying still images, clocks, bright colors or logos etc.

Remote Control and TV

The remote control shape, location, availability and function of remote control buttons may vary depending on your region/country/TV model.

MIC

Ȫ

ȫ ȩ

Ȭ

ȭ

Ȯ

(The Google Assistant) / (Microphone): Use the Google Assistant*1*2 or voice search*2. For hints

on how to control your TV press (the Google Assistant) / (Microphone) button and speak the phrase “voice hints”.*1

/ / / /: On screen menu navigation and selection.

TV: Display TV channel list or switch to input.

(TV standby)

Number buttons

(dot)

APPS: Display a list of installed apps.

Google Play / NETFLIX*1 / Color buttons

GUIDE: Display the digital program guide of TV or Cable/Satellite box*1*3. DVR: Display the Rec list of DVR*3.

6US

INPUT: Display and select the input source, etc.

(Quick settings): Display Quick Settings.

BACK

HOME

VOL +/– (Volume)

JUMP MUTE*4

CH +/– (Channel)

AUDIO: Select the sound of multilingual source or dual sound (depend on program source).

SUBTITLE/CC

HELP: Display the Help menu.

/ / /

REC: Record the currently viewed program on DVR*3.

DISPLAY: Display information.

Guidelines for IR Remote Control

•Point your remote control directly at the IR sensor located on your TV.

•Make sure that no objects are blocking the path between the remote control and the IR sensor on your TV.

•Fluorescent lamps can interfere with your remote control; try turning off the fluorescent lamps.

•If you are having problems with the remote control, reinsert or replace your batteries and make sure that they are correctly inserted.

̚

Ȱ

	(Power)
	Remote Control sensor / Light
		US
	sensor / LED

*1 Only on limited region/country/TV model/ language.

*2 The Google Assistant or voice search requires an Internet connection.

*3 [Cable/Satellite box setup] setting is required.

*4 Accessibility shortcut is available by pressing and holding MUTE.

For more information, refer to the Help Guide.

7US

Installing the TV to the Wall

Using the optional Wall-Mount Bracket (SU-WL855 only)* (not supplied)

To Customers:

For product protection and safety reasons, Sony strongly recommends that installation of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself.

To Sony Dealers and Contractors:

Provide full attention to safety during the installation, periodic maintenance and examination of this product.

Wall-Mount Bracket Installation Information

This TV’s instruction manual only provides the steps to prepare the TV for Wall-Mount installation before it is installed on the wall. For instructions on Wall-Mount Bracket installation, see the Installation Information (Wall-Mount Bracket) on the Sony Customer Support website for your TV model at the following address. https://www.sony.com/am/support

Preparing for Wall-Mount Installation

•Prepare the TV for the Wall-Mount Bracket before making cable connections.

•Follow the instruction guide provided with the Wall-Mount Bracket for your model. Sufficient expertise is required in installing this TV, especially to determine the strength of the wall for withstanding the TV’s weight.

•Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.

•The length of the screw for Wall-Mount Bracket differs depending on the Wall-Mount Bracket thickness. Please refer to below illustration.

9 mm – 13 mm

Screw (M6)

Wall-Mount Bracket

TV’s rear cover

•Be sure to store the unused screws and Table-Top Stand in a safe place until you are ready to attach the Table-Top Stand. Keep the screws away from small children.

Note

•Read the supplied Safety Booklet for additional safety information.

* Only on limited region/country/TV model.

Installing the TV to the Wall from Carton

1 Remove the center cushion.

8US

2Remove the screws from the rear of the TV.

Note

•Be sure to store the removed screws and reuse when attaching the Wall-Mount Bracket to the TV set. Keep the screws away from small children.

Installing the TV to the Wall from Table-Top Stand

Remove the screws from the rear of the TV.

Note

•Be sure to store the removed screws and reuse when attaching the Wall-Mount Bracket to the TV set. Keep the screws away from small children.

Using the optional Wall-Mount Bracket (Except SU-WL855) (not supplied)

This TV’s instruction manual only provides the steps to prepare the TV for Wall-Mount installation before it is installed on the wall.

Your TV can be mounted to a wall using a suitable Wall-Mount Bracket (not supplied). If the Table-Top Stand is attached to the TV, the TV may require detaching the Table-Top Stand; see “Detaching the Table-Top Stand from the TV”.

Prepare the TV for the Wall-Mount Bracket before making cable connections.

For product protection and safety reasons, Sony strongly recommends that installation of your TV on the wall be performed by qualified professionals. Do not attempt to install it yourself.

•Follow the instruction guide provided with the Wall-Mount Bracket for your model. Sufficient expertise is required in installing this TV, especially to determine

the strength of the wall for withstanding
the TV’s weight.	US

•The screws for Wall-Mount Bracket are not supplied.

•The length of the screw for Wall-Mount Bracket differs depending on the Wall-Mount Bracket thickness. Please refer to below illustration.

9 mm – 13 mm

Screw (M6)

Wall-Mount Bracket

TV’s rear cover

•Refer to the following table for wall-mount hole pattern.

Wall-mount hole

Model Name

pattern

×

XBR-65A8H

XBR-65A8CH

300 × 300 mm

XBR-55A8H

XBR-55A8CH

•Be sure to store the unused screws and Table-Top Stand in a safe place until you are ready to attach the Table-Top Stand. Keep the screws away from small children.

Note

•Read the supplied Safety Booklet for additional safety information.

•For more detailed information, visit Sony Customer Support website.*

* Only on limited region/country/TV model.

9US

1Remove the screws from the rear of the TV.

2Attach the Wall-Mount Bracket (not supplied) using the screws (not supplied).

Wall-Mount Bracket (not supplied)

Screw (not supplied)

Note

•If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}.

Detaching the Table-Top Stand from the TV

1Remove one side of the Table-Top Stand at a time. Firmly hold the Table-Top Stand securely with both hands while the other people lift up the TV.

2Repeat the previous step and remove the other side of the Table-Top Stand.

Note

•Three or more people are required to detach the Table-Top Stand.

•Be careful not to use excessive force while detaching the Table-Top Stand from the TV as it may cause the TV set to fall resulting in personal injury or physical damage to the TV.

•Take care when handling the Table-Top Stand to prevent damage to the TV.

•Be careful when lifting the TV as the Table-Top Stand is detached, the Table-Top Stand may topple over and cause personal injury.

•Take care when removing the Table-Top Stand from the TV to prevent it from falling over and damaging the surface that the TV is sitting on.

•Do not remove the Table-Top Stand for any reason other than to install corresponding accessories on the TV.

10US

•Be sure the TV is vertical before turning on. To avoid uneven picture uniformity do not power on the TV with the panel facing down.

Troubleshooting

General troubleshooting for issues like: black screen, no sound, frozen picture, TV does not respond, or network is lost, do the following steps.

1Restart your TV by pressing the power button on the remote control for about five seconds. The TV will restart. If the TV does not recover, try unplugging the AC power cord. Then press the power button on the TV, and release it. Wait for two minutes, and plug in the AC power cord.

2Refer to the Help menu by pressing HELP on the remote control.

3Connect your TV to the Internet and perform a software update. Sony recommends you to keep your TV software updated. Software updates provide new features and performance improvements.

4Visit Sony support website (information provided at the end of this manual).

5 Perform the factory data reset.

When you plug in the TV, the TV may not be able to turn on for a while even if you press the power button on the remote control or the TV.

It takes time to initialize the system. Wait for about one minute, then operate it again.

How to reset the TV to factory settings

WARNING: The reset will clear all of your customized settings including the parental lock setting.

•You can reset the TV to factory settings by selecting [Factory data reset]. How to select [Factory data reset], refer to the Help Guide.

•To force factory data reset, unplug the AC power cord. Press and hold button on the TV, then plug in the AC power cord.

•For security purposes, be sure to remove all personal and account information before discarding, selling or passing your TV to someone else by: unlinking/ unregistering, signing out of and deactivating all network services as well as factory reset the TV.

The remote control does not function.

• Replace the batteries.

The parental lock password has been	US
forgotten.

•Enter 4357 for the PIN and enter the new PIN.

The restricted profile password has been forgotten.

• Perform the force factory data reset.

The screen becomes darker while watching TV.

•If the whole image or part of the image remains still, the screen brightness will be gradually reduced to prevent image retention. This is not a malfunction of the TV.

You are concerned about image retention.

If the same image is displayed repeatedly or for long periods of time, image retention may occur. To reduce image retention, we recommend that you turn off the TV normally by pressing the power button on the remote control or the TV.

Note

•Perform Panel refresh manually only when image retention is particularly noticeable. As a reference, perform it only once a year. Avoid performing it more than once a year because it may affect the usable life of the panel.

•Images that include clocks, logos and bright colors (including white) easily cause image retention. Avoid displaying these types of images for long periods of time, otherwise image retention may occur.

A white line appears on the screen.

•Panel refresh automatically runs after the TV has been used for long periods of time to reduce image retention. Panel refresh starts after the TV is turned off and takes about one hour to complete. A white line may be displayed on the screen during the Panel refresh. This is not a malfunction of the TV.

11US

The message [Panel refresh did not finish…] is displayed.

When i) the TV is turned on, ii) the AC power cord is unplugged, or iii) the room temperature falls outside of the range between 50 ºF and 104 ºF (10 ºC and 40 ºC) during the Panel refresh, the Panel refresh is not completed. Please avoid the above three conditions during the Panel refresh.

For more information on troubleshooting, refer to the Help Guide.

Specifications

System

Television system

NTSC: American TV Standard

ATSC (8VSB Terrestrial): ATSC compliant 8VSB

QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality)

Channel coverage

Analog terrestrial: 2 – 69 / Digital terrestrial: 2 – 69

Analog Cable: 1 – 135 / Digital Cable: 1 – 135

Panel system: OLED (Organic Light Emitting Diode) Panel

Speaker output: 10 W + 10 W + 5 W + 5 W Wireless technology

Protocol IEEE 802.11a/b/g/n/ac Bluetooth® Version 4.2

Input/Output jacks

CABLE/ANTENNA

75 ohm external terminal for RF inputs/ VIDEO IN

Video/Audio input (mini jack)

HDMI IN 1/2/3/4 (support 4K resolution, HDCP 2.3-compatible)

Video:

4096 × 2160p (60 Hz)*1*2, 4096 × 2160p (24 Hz)*1, 3840 × 2160p (60 Hz)*2, 3840 × 2160p (24, 30 Hz), 1080p (30, 60,

120 Hz), 1080/24p, 1080i (60 Hz), 720p (30, 60 Hz), 720/24p, 480p, PC Formats*3

Audio:

In eARC (Enhanced Audio Return Channel) mode

Refer to the Help Guide for details. Except eARC mode

5.1 channel linear PCM: 32/44.1/48/ 88.2/96/176.4/192 kHz 16/20/24 bits, Dolby Audio, Dolby Atmos, DTS

eARC/ARC (Enhanced Audio Return Channel/Audio Return Channel) (HDMI IN 3 only)*4

In eARC mode

Refer to the Help Guide for details. In ARC mode

Two channel linear PCM: 48 kHz 16 bits, Dolby Audio, Dolby Atmos, DTS

DIGITAL AUDIO OUT (OPTICAL) Digital optical jack (Two channel linear PCM: 48 kHz 16 bits, Dolby Audio, DTS)

(Stereo mini jack) Headphone

1, 2, 3

USB port 1 and 2 support High Speed USB (USB 2.0)

USB port 3 supports Super Speed USB (USB 3.1 Gen 1)

LAN

10BASE-T/100BASE-TX connector (Depending on the operating environment of the network, connection speed may differ. The communication rate and quality are not guaranteed.)

Refer to the Help Guide for supported files and formats in Home Network.

REMOTE

RS-232C mini jack, IR IN mini jack

These jacks are for receiving the external control signal.

Power and others

Power requirements

110 V – 240 V AC, 50/60 Hz (U.S.A./ Canada 120 V AC, 60 Hz)

Power consumption In use

XBR-65A8H / XBR-65A8CH: 457 W XBR-55A8H / XBR-55A8CH: 341 W

In standby*5*6

Less than 0.5 W with 120 V AC and less than 0.5 W with 240 V AC

Screen size (measured diagonally) (Approx.) XBR-65A8H / XBR-65A8CH: 163.9 cm / 64.5 inches (65” class)

XBR-55A8H / XBR-55A8CH: 138.8 cm / 54.6 inches (55” class)

12US

Display resolution

3,840 dots (horizontal) × 2,160 lines (vertical)

Output Rating USB 1/2

5 V , 500 mA MAX USB 3

5 V , 900 mA MAX

Dimensions (Approx.) (w × h × d) (mm) / (inches)

with stand Standard position:

XBR-65A8H / XBR-65A8CH: 1,448 × 857 × 326 / 57 1/8 × 33 3/4 × 12 7/8

XBR-55A8H / XBR-55A8CH: 1,227 × 733 × 326 / 48 3/8 × 28 7/8 × 12 7/8

Sound bar position:

XBR-65A8H / XBR-65A8CH: 1,448 × 908 × 323 / 57 1/8 × 35 3/4 × 12 3/4

XBR-55A8H / XBR-55A8CH: 1,227 × 784 × 323 / 48 3/8 × 30 7/8 × 12 3/4

without stand

XBR-65A8H / XBR-65A8CH: 1,448 × 836 × 52 / 57 1/8 × 33 × 2 1/8

XBR-55A8H / XBR-55A8CH: 1,227 × 712 × 52 / 48 3/8 × 28 1/8 × 2 1/8

wall-mount hole pattern 300 × 300 mm

wall-mount screw size (mm)

M6 (length: see “Installing the TV to the Wall”.)

Mass (Approx.) (kg) / (lb.)

with stand (without stand) XBR-65A8H / XBR-65A8CH: 23.6 / 52 (21.8 / 48.1)

XBR-55A8H / XBR-55A8CH: 18.6 / 41 (16.8 / 37.1)

Others

Optional accessories Wall-Mount Bracket: SU-WL855

Operating temperature: 0 ºC – 40 ºC / 32 ºF

– 104 ºF

*1 When 4096 × 2160p is input and [Wide mode] is set to [Normal], the resolution is displayed as 3840 × 2160p. To display 4096 × 2160p, set [Wide mode] setting to [Full 1] or [Full 2].

*2 To support 18 Gbps, set [HDMI signal format] to [Enhanced format].

*3 Refer to the online Help Guide for details.

*4 Connect your audio system to the HDMI IN 3 to route TV audio to your audio system.

*5 Specified standby power is reached after the TV finishes necessary internal processes.

*6 Standby power consumption will increase when your TV is connected to the network.

Note

•Optional accessories availability depends on countries/region/TV model/stock.

•Design and specifications are subject to change without notice.

•Subscriptions for services and applications may be required and additional terms, conditions and/or charges may apply when using the Google Assistant.

Licensing Information

• The terms HDMI, HDMI High-Definition	US
Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks
of HDMI Licensing Administrator, Inc.

•Dolby, Dolby Vision, Dolby Atmos, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license from Dolby Laboratories. Confidential unpublished works. Copyright © 2012-2018 Dolby Laboratories. All rights reserved.

•Gracenote, the Gracenote logo and logotype, “Powered by Gracenote” logo are either registered trademarks or trademarks of Gracenote, Inc. in the United States and/or other countries.

•Google, Google Play, Chromecast, YouTube, Android TV and other related marks and logos are trademarks of Google LLC.

•For DTS patents, see http:// patents.dts.com. Manufactured under license from DTS, Inc. DTS, the Symbol, DTS and the Symbol together, and Digital Surround are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved.

•Netflix is a registered trademark of Netflix, Inc.

•TUXERA is a registered trademark of Tuxera Inc. in the US and other countries.

•All other trademarks are the property of their respective owners.

13US

À propos des manuels

Ce téléviseur est fourni avec les manuels suivants. Veuillez conserver ces manuels à titre de référence.

Manuel de configuration

• Installation et configuration du téléviseur.

Manuel de référence (ce manuel) / Documentation de sécurité

•Consignes de sécurité, télécommande, dépannage, fixation murale, spécifications, etc.

Manuel d’aide (manuel à l’écran)

• Réglages, fonction Android TV, connexion Internet, dépannage, etc.

• Pour l’ouvrir, appuyez sur la touche HELP sur la télécommande et sélectionnez Manuel d’aide.

IMPORTANT - Lisez le contrat de licence logicielle de l’utilisateur final avant d’utiliser votre produit Sony.

Utiliser votre produit signifie que vous acceptez les termes du contrat de licence logicielle de l’utilisateur final. Le contrat de licence logicielle entre vous et Sony est disponible en ligne sur le site Web Sony (http:// www.sony.net/tv-software-licenses/) ou sur l’écran de votre produit. Accédez à [Paramètres] t [Préférences de l'appareil] t [À propos] t [Renseignements juridiques] t [Contrat de licence d'utilisateur final].

Remarque

•Les images et illustrations utilisées dans le Manuel de configuration et ce manuel sont fournies uniquement à titre de référence et peuvent différer de l’aspect réel du produit.

La taille d’image visualisable de la classe 65 po est de 64,5 pouces (163,9 cm) et la taille d’image visualisable de la classe 55 po est de 54,6 pouces (138,8 cm) (mesurée en diagonale).

Emplacement de l’étiquette d’identification

Les étiquettes indiquant le numéro de modèle et les caractéristiques nominales de l’alimentation du téléviseur se trouvent à l’arrière du téléviseur.

AVIS IMPORTANT

Fiche d’identification

Les numéros de modèle et de série sont indiqués à l’arrière et/ou sur le côté du téléviseur. Inscrivez ces numéros dans les espaces ci-dessous. Faites-y référence chaque fois que vous appelez votre détaillant Sony au sujet de ce téléviseur.

N° de modèle

•Vous pouvez consulter le Manuel d’aide avec votre téléphone intelligent.

https://rd1.sony.net/

help/tv/husltn1/ h_usltn/

ATTENTION

Pour prévenir les décharges électriques et l’exposition des broches, n’utilisez pas cette fiche CA avec une rallonge, une prise de courant ou une autre sortie de courant, sauf si les broches peuvent être insérées jusqu’au fond.

•Faites uniquement fonctionner le téléviseur sur un courant de 110 V – 240 V CA (États-Unis/Canada 120 V CA)

Remarque

Ce téléviseur comporte un démodulateur QAM qui devrait vous permettre de recevoir une programmation numérique décodée de câblodistribution par le biais d’un service d’abonnement auprès d’un câblodistributeur. La disponibilité d’une programmation télévisée numérique par câblodistribution dans votre région dépend du type de programmation et de signal fournis par votre câblodistributeur.

Consignes de sécurité

Avis pour les clients aux États-Unis d’Amérique

Déclaration de conformité du fournisseur

Appellation commerciale : SONY

Modèle : XBR-65A8H / XBR-65A8CH / XBR-55A8H / XBR-55A8CH

Partie responsable : Sony Electronics Inc.

Adresse : 16535 Via Esprillo, San Diego, CA 92127 U.S.A. Numéro de téléphone : 858-942-2230

N° de série

2FR
