Sony XA1 G3223, XA1 G3221 User Manual
User guide
™
Xperia
G3221/G3223
XA1 Ultra
Contents
Getting started............................................................................... 6
About this User guide........................................................................ 6
Overview............................................................................................ 6
Assembly........................................................................................... 7
Screen protection...............................................................................8
Starting your device for the first time.................................................8
Why do I need a Google™ account?.................................................9
Device security.............................................................................10
Making sure your device is protected..............................................10
Screen lock...................................................................................... 10
Unlocking your device automatically............................................... 12
SIM card protection......................................................................... 15
Finding the identification number of your device.............................15
Finding a lost device ....................................................................... 16
Learning the basics...................................................................... 18
Using the touchscreen.....................................................................18
Locking and unlocking the screen................................................... 20
Home screen....................................................................................20
Application screen........................................................................... 22
Navigating applications....................................................................23
Widgets............................................................................................25
Shortcuts and folders...................................................................... 25
Background and themes..................................................................26
Taking a screenshot......................................................................... 27
Notifications..................................................................................... 27
Icons in the status bar..................................................................... 29
Applications overview...................................................................... 31
Battery and maintenance............................................................. 33
Charging your device.......................................................................33
Battery and power management..................................................... 34
Updating your device.......................................................................36
Maintenance using a computer....................................................... 37
Storage and memory....................................................................... 38
Backing up and restoring content....................................................39
Downloading applications............................................................43
Downloading applications from Google Play™............................... 43
Downloading applications from other sources................................ 43
Internet and networks.................................................................. 44
Browsing the web............................................................................ 44
2
Internet and MMS settings ............................................................. 44
Wi-Fi.................................................................................................45
Sharing your mobile data connection.............................................. 47
Controlling data usage.....................................................................48
Selecting mobile networks...............................................................49
Virtual private networks (VPNs)........................................................50
Synchronising data on your device..............................................51
Synchronising with online accounts................................................ 51
Synchronising with Microsoft® Exchange ActiveSync®.................51
Basic settings...............................................................................53
Accessing settings...........................................................................53
Volume settings................................................................................53
Do not disturb mode........................................................................ 54
Screen settings................................................................................ 55
Application settings......................................................................... 56
Resetting your applications............................................................. 57
Screen saver.................................................................................... 58
Language settings............................................................................59
Date and time...................................................................................59
Super-vivid mode.............................................................................59
Enhancing the sound output............................................................59
Multiple user accounts.....................................................................60
Typing text....................................................................................62
On-screen keyboards...................................................................... 62
Editing text....................................................................................... 63
Calling.......................................................................................... 64
Making calls..................................................................................... 64
Receiving calls................................................................................. 65
Ongoing calls................................................................................... 66
Using the call log............................................................................. 67
Forwarding calls...............................................................................67
Restricting calls................................................................................67
Multiple calls.................................................................................... 68
Conference calls.............................................................................. 69
Voicemail..........................................................................................69
Emergency calls...............................................................................70
Contacts.......................................................................................71
Searching and viewing contacts......................................................71
Adding and editing contacts............................................................72
Transferring contacts....................................................................... 73
Backing up contacts........................................................................ 74
Adding medical and emergency contact information......................74
3
Favourites........................................................................................ 75
Sending contact information............................................................75
Avoiding duplicate entries in the Contacts application................... 76
Messaging and chat.....................................................................77
Reading and sending messages......................................................77
Organising your messages.............................................................. 78
Calling from Messaging................................................................... 78
Messaging settings.......................................................................... 79
Video chat........................................................................................ 79
Email.............................................................................................80
Setting up email............................................................................... 80
Sending and receiving email messages...........................................80
Organising your email messages.....................................................81
Email account settings.....................................................................82
Gmail™............................................................................................ 82
Music and FM radio..................................................................... 84
Transferring music to your device....................................................84
Listening to music............................................................................84
Music menu..................................................................................... 86
Playlists............................................................................................ 86
Sharing music.................................................................................. 87
Enhancing the sound....................................................................... 87
Listening to the radio....................................................................... 87
Favourite radio channels..................................................................89
Radio sound settings....................................................................... 89
Camera.........................................................................................90
Taking photos and recording videos................................................90
General camera settings.................................................................. 91
Still camera settings.........................................................................95
Video camera settings..................................................................... 97
Photos and videos in Album...................................................... 100
Viewing photos and videos............................................................100
Album home screen menu............................................................. 101
Sharing and managing photos and videos.................................... 102
Editing photos with the Photo editor application...........................103
Editing videos with the Video editor application............................103
Hiding photos and videos.............................................................. 104
Viewing your photos on a map...................................................... 104
Videos.........................................................................................106
The Video application.................................................................... 106
Transferring video content to your device..................................... 107
Managing video content................................................................ 107
4
Movie Creator................................................................................ 107
Connectivity............................................................................... 109
Mirroring the screen of your device wirelessly on a TV................. 109
Displaying files on another device using Cast............................... 109
Connecting your device to USB accessories................................ 110
NFC................................................................................................111
Bluetooth® wireless technology....................................................113
Smart apps and features that save you time............................. 116
Google Search & Now....................................................................116
Using the News Suite application..................................................116
Using your device as a wallet........................................................ 116
Travel and maps......................................................................... 117
Using location services.................................................................. 117
Google Maps™ and navigation..................................................... 117
Using data traffic when travelling.................................................. 118
Airplane mode................................................................................118
Clock and Calendar....................................................................119
Calendar.........................................................................................119
Clock..............................................................................................119
Accessibility............................................................................... 122
Magnification gesture.................................................................... 122
Font size.........................................................................................122
Display size.................................................................................... 122
Colour correction........................................................................... 122
TalkBack.........................................................................................122
Mono audio.................................................................................... 123
TTY (Teletypewriter) mode............................................................. 123
Switch Access............................................................................... 123
Support and legal.......................................................................125
Support application....................................................................... 125
Xperia™ Tips..................................................................................125
Help in menus and applications.....................................................125
Running diagnostic tests on your device.......................................125
Restarting, resetting and repairing.................................................125
Help us improve our software........................................................127
Warranty, SAR and usage guidelines.............................................127
Recycling your device....................................................................127
Legal information........................................................................... 127
5
Getting started
About this User guide
This is the Xperia™ XA1 Ultra User guide for the Android™ 7.0 software version. If
you're not sure which software version your device is running, you can check it in the
Settings menu.
System and application updates can present the features in your device in another way than
described in this User guide. The Android™ version might not be affected in an update. For
more information about software updates, see
To check the current software version of your device
1
From your Home screen, tap
2
Find Settings > About phone > Android™ version.
To find the model number and name of your device
1
From your Home screen, tap
2
Find and tap
The device model number and name are displayed.
.
.
.
Limitations to services and features
Some of the services and features described in this User guide may not be supported
in all countries or regions, or by all networks or service providers. The GSM
International Emergency Number can always be used in all countries, regions,
networks and by all service providers, provided that the device is connected to the
mobile network. Please contact your network operator or service provider to
determine the availability of any specific service or feature and whether additional
access or usage fees apply.
The use of certain features and applications described in this guide may require
access to the internet. You may incur data connection charges when you connect to
the internet with your device. Contact your wireless service provider for more
information.
Updating your device
on page 36.
Overview
6
This is an internet version of this publication. © Print only for private use.
1. Charging/Notification light
2. Headset jack
3. Front camera lens
4. Second microphone
5. Ear speaker
6. Proximity/Light sensor
7. Front flash
8. Volume button
9. Power key
11. Main microphone
12. Loudspeaker
13. Charger/USB Type-C™ cable port
14. Wi-Fi/GPS/Bluetooth antenna area
15. Main camera lens
16. Main flash
17. NFC™ detection area
18. Nano SIM/Memory card slot cover
19. Main antenna area
10. Camera key
Assembly
Your device only supports nano SIM cards. The nano SIM card and the memory card
have separate slots in the same holder. Make sure you don’t confuse the two.
To prevent data loss, make sure you turn off your device or unmount the memory card before
you drag out the holder to remove the nano SIM card or memory card from the device.
To insert nano SIM card and memory card
Do not cut your SIM card, for example using a blade or scissors, as this may damage your
device.
7
This is an internet version of this publication. © Print only for private use.
1
Using your fingernail, drag out the nano SIM card tray.
2
Firmly place the SIM card in the correct orientation as shown in the illustration.
3
Insert the memory card in the correct orientation into the memory card slot as
shown in the illustration.
4
Gently push the tray back into the slot until it fits into place.
To remove the nano SIM card
1
With the screen facing down, open and drag out the nano SIM card tray using
your fingernail.
2
Remove the nano SIM card, then gently push the tray back into the slot until it
fits into place.
To remove a memory card
1
Turn off your device.
2
With the device facing down, drag out the cover for the nano SIM card tray.
3
Gently push and remove the memory card, then gently push the tray back into
the slot until it fits into place.
Screen protection
Before using your device, remove the protection
It is recommended to protect your device with a Sony branded screen cover or a
protector intended for your Xperia™ model. The use of third party screen protection
accessories may prevent your device from working correctly by covering sensors,
lenses, speakers, or microphones and can invalidate the warranty.
film by pulling up on the protruding tab.
Starting your device for the first time
It is recommended that you charge the battery for at least 30 minutes before starting
up your device for the first time. You can still use your device while it is charging, see
Charging your device
The first time you start your device, a setup guide helps you to configure basic
settings, personalise your device and sign in to your accounts, for example a
Google™ account.
To turn on the device
on page 33.
It is important to use the USB Type-C™ cable (provided) when charging your device, as other
types of USB cables can damage your device. It is recommended to charge the battery for at
least 30 minutes before you turn on the device for the first time.
8
This is an internet version of this publication. © Print only for private use.
1
Press and hold down the power key until the device vibrates.
2
Enter your SIM card PIN when requested, then tap .
3
Wait a moment for the device to start.
Your SIM card PIN is initially supplied by your network operator, but you can change it later
from the Settings menu. To correct a mistake made while entering your SIM card PIN, tap .
To turn off the device
1
Press and hold down the power key
2
In the options menu, tap Power off.
It may take a while for the device to shut down.
until the options menu opens.
Why do I need a Google™ account?
Your Xperia™ device from Sony runs on the Android™ platform developed by
Google™. A range of Google™ applications and services is available on your device
when you purchase it, for example, Gmail™, Google Maps™, YouTube™ and the
Play Store™ application, which gives you access to the Google Play™ online store
for downloading Android™ applications. To get the most out of these services, you
need a Google™ account. For example, a Google™ account enables you to do all of
the following:
•
Download and install applications from Google Play™.
•
Synchronise your email, contacts and calendar using Gmail™.
•
Chat with friends using the Hangouts™ application.
•
Synchronise your browsing history and bookmarks using the Google Chrome™ web
browser.
•
Identify yourself as the authorised user after a software repair using Xperia™
Companion.
•
Remotely find, lock or clear a lost or stolen device using the my Xperia™ or
Android™ Device Manager services.
For more information about Android™ and Google™, go to
http://support.google.com
.
It is crucial that you remember your Google™ account username and password. In some
situations, you may need to identify yourself for security reasons using your Google™ account.
If you fail to give your Google™ username and password in such situations, your device is
locked. Also, if you have more than one Google™ account, make sure to enter the details for
the relevant account.
To set up a Google™ account on your device
1
From your Home screen, tap .
2
Find and tap Settings > Accounts & sync > Add account > Google.
3
Follow the registration wizard to create a Google™ account, or sign in if you
already have an account.
You can also sign in to or create a Google™ account from the setup guide the
start your device. Alternatively, you can go online and create an account at
www.google.com/accounts
.
first time you
To remove a Google™ account
1
From your Home screen, tap .
2
Tap Settings > Accounts & sync > Google.
3
Select the Google™ account that you want to remove.
4
Tap > Remove account.
5
Tap Remove account again to confirm.
If you remove your Google™ account, any security features that are linked to your Google™
account will no longer be available.
9
This is an internet version of this publication. © Print only for private use.
Device security
Making sure your device is protected
Your device includes several security options, strongly recommended in case of loss
or theft.
These options are as follows:
•
Set a secure screen lock on your device using a PIN, password or pattern to prevent
anyone from accessing or resetting your device.
•
Add a Google™ account to prevent others from using your device if it gets stolen or
wiped.
•
Activate either the “Protection by my Xperia” or the Android™ Device Manager web
service. Using one of these services, you can remotely locate, lock or clear a lost
device.
Verifying the ownership of your device
Certain protection features require you to either unlock your screen with your PIN,
password, pattern, or enter your Google™ account information. Below are examples
of protection features and some of the required credentials:
Factory Data
Reset
protection
Protection by
my Xperia
You must unlock your screen before you are allowed to perform a
Factory Data Reset.
If you remotely reset your device using this service, you must enter
the username and password for a Google™ account associated with
the service. The device must be connected to the internet before the
setup process can be completed. Otherwise, you will not be able to
use your device after the reset.
Android™
Device
Manager
If you remotely reset your device using this service, you must enter
the username and password for a Google™ account. The device must
be connected to the internet before the setup process can be
completed. Otherwise, you will not be able to use your device after
the reset.
Software repair
If you use the Xperia™ Companion software to perform a software
repair, you’re asked to enter your Google™ account username and
password when you start the device after the repair is complete.
For Android™ Device Manager, it is necessary to enter information from a Google™ account.
This can be any Google™ account which you have set up on the device as an owner. If you
cannot provide the relevant account information during a setup process, you won't be able to
use the device at all.
Screen lock
There are several screen lock options available. The security level of each lock type is
listed below in order of weakest to strongest:
•
Swipe: no protection, but you have quick access to the Home screen.
•
Pattern: draw a simple pattern with your finger to unlock your device.
•
PIN: enter a numeric PIN of at least four digits to unlock your device.
•
Password: enter an alpha-numeric password to unlock your device.
It is very important that you remember your screen lock pattern, PIN or password. If
you forget this information, it may not be possible to restore important data such as
contacts and messages. If you have set up a Microsoft® Exchange ActiveSync®
(EAS) account on your Xperia™ device, the EAS security settings may limit the lock
screen type to only a PIN or password. This occurs when your network administrator
specifies a lock screen type for all EAS accounts for enterprise security reasons.
10
This is an internet version of this publication. © Print only for private use.
Contact the network administrator of your company or organisation to check what
network security policies are implemented for mobile devices.
For more settings for each screen lock type tap beside Screen lock.
To create a screen lock pattern
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Screen lock > Pattern.
3
Choose an option and follow the instructions on your device.
If you enter an incorrect lock pattern five times in a row, you must wait 30 seconds before
trying again.
To change your screen lock type
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Screen lock.
3
Choose an option and follow the instructions on your device.
To change the screen lock pattern
1
From your Home screen, tap
2
Find and tap Settings> Lock screen & security > Screen lock.
3
Draw your screen unlock pattern.
4
Tap Pattern, choose an option and follow the instructions on your device.
.
To create a screen lock PIN
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Screen lock > PIN.
3
Choose an option. Enter a numeric PIN, then tap CONTINUE.
4
Re-enter and confirm your PIN, then tap OK.
To create a screen lock password
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Screen lock > Password.
3
Choose an option and follow the instructions on your device.
To activate the Swipe unlock function
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Screen lock.
3
Draw your screen unlock pattern, or enter your PIN or password depending on
which of these screen lock types is enabled.
4
Tap Swipe, then tap YES, REMOVE.
Resetting a forgotten screen lock
If you’ve forgotten your screen lock PIN, password or pattern, you may be able to
reset it using the Protection by my Xperia service. No content on your device is lost
after you have performed a screen lock reset using this service.
To reset the screen lock using Protection by my Xperia
1
Make sure you know your Google™ account username and password and that
you have enabled the Protection by my Xperia service on your device.
2
Go to
myxperia.sonymobile.com
3
Sign in using the same Google™ account that you have set up on your device.
4
Click the picture of your device under Your devices.
5
Select Lock to replace the current screen lock with a new PIN code.
6
Follow the on-screen instructions provided by Protection by my Xperia.
using any internet-connected device.
Depending on your security settings, your device may lock after a screen lock reset. You then
need to enter your Google™ account username and password in order to use the device.
11
This is an internet version of this publication. © Print only for private use.
Unlocking your device automatically
The Smart Lock feature makes unlocking your device easier by letting you set it to
unlock automatically in certain situations. You can keep your device unlocked, for
example, when it’s connected to a Bluetooth® device or when you’re carrying it with
you. With Smart Lock enabled you still need to unlock your device manually after
restarting, and after leaving the device inactive for 4 hours.
You can set Smart Lock to keep your device unlocked using the following settings:
•
On-body detection: Keep your device unlocked when you're carrying it with you.
•
Trusted places: Keep your device unlocked when you're in a familiar, secure location
such as your home.
•
Trusted devices: Keep your device unlocked when a trusted Bluetooth® or NFC
device is connected.
•
Trusted face: Unlock your device by looking at it.
•
Trusted voice: Set up voice recognition to search in any screen.
The Smart Lock feature is developed by Google™ and its exact functionality may change over
time due to updates from Google™. Furthermore the feature may not be available in every
market, country or region.
To enable Smart Lock
1
Set a pattern, PIN or password as a screen lock if you have not already done
so.
2
From your Home screen, tap
3
Find and tap Settings > Lock screen & security > Trust agents.
4
Tap the Smart Lock (Google) slider to enable the function.
5
Tap the back arrow next to Trust agents.
6
Find and tap Smart Lock.
7
Enter your pattern, PIN or password. You need to enter these credentials
whenever you want to change your Smart Lock settings.
8
Select a Smart Lock type.
.
To set up or remove trusted face
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Smart Lock > Trusted face.
3
Tap SET UP > NEXT. Follow the instructions on your device, then tap
FINISHED.
4
To remove a trusted face, tap Remove trusted face > REMOVE.
For enhanced accuracy, tap
Trusted face > Improve face-matching.
To set up trusted voice
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Smart Lock > Trusted voice.
3
Follow the instructions on your device.
Keeping your device unlocked while you’re carrying it
Using the On-body detection feature, you can keep your device unlocked while
you're carrying it in your hand or in a pocket or bag. The accelerometer in your device
keeps your device unlocked while it senses that it's being carried. The device locks
when the accelerometer detects that the device has been put down.
When you use the On-body detection feature, you need to be aware of the following
behaviours:
•
Any time you put your device down and it senses that it's no longer being carried, it
locks automatically.
•
The device can take up to one minute to lock.
•
After you get into a car, bus, train or other land vehicle, your device can take between
5 and 10 minutes to lock.
•
Note that when you get on an airplane or a boat (or another non-land based vehicle),
your device may not lock automatically, so make sure to lock it manually if needed.
12
This is an internet version of this publication. © Print only for private use.
•
When you pick up your device again or get out of the vehicle, just unlock it once and
your device then stays unlocked for as long as you have it on you.
The On-body detection feature can't distinguish whose body is connected. If you give your
device to someone else while it's unlocked using On-body detection, your device may stay
unlocked for the other user. Keep in mind that On-body detection as a security feature is less
secure than a pattern, PIN, or password.
To enable or disable On-body detection
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Smart Lock > On-body
detection.
3
Tap the slider to enable the function, then tap CONTINUE. To disable the
function tap the slider beside On.
Connecting to trusted devices
You can designate a connected device as trusted and keep your Xperia™ device
unlocked while connected. If you have a device that you connect to regularly using
Bluetooth® or NFC, for example, a home entertainment system or a fitness tracker,
you can add it as a trusted device and bypass the added security of the lock screen
to save time. This feature is suitable if you’re normally in a relatively secure place
when you use these devices. In some cases, you may still need to manually unlock
your device before a trusted device can be connected.
It is not recommended to add devices that are constantly connected to your device as trusted
devices, for example, Bluetooth® keyboards or cases.
As soon as a trusted device is switched off or moves out of range, your screen locks and you
need your PIN, pattern or password to unlock it.
To add or remove a trusted Bluetooth® device
1
Make sure your device is paired and connected to the Bluetooth® device that
you want to add as a trusted device.
2
From your Home screen, tap
3
Find and tap Settings > Lock screen & security > Smart Lock.
4
In the Smart lock menu tap Trusted devices > ADD TRUSTED DEVICE >
.
Bluetooth.
5
Tap a device name to select it from the list of connected and paired devices,
then tap YES, ADD.
6
To remove a paired device, select it from the list and tap REMOVE TRUSTED
DEVICE.
To add or remove a trusted NFC device
1
Make sure your device is paired and connected to the Bluetooth® device that
you want to add as a trusted device.
2
Find and tap Settings > Lock screen & security > Smart Lock.
3
Tap Trusted devices > ADD TRUSTED DEVICE > NFC.
4
Follow the on-screen instructions.
5
To remove a paired device, select it from the list and tap REMOVE TRUSTED
DEVICE
Making sure you're secure when using trusted devices
Different Bluetooth® devices support different Bluetooth® standards and security
capabilities. There's a possibility that someone could keep your Xperia™ device
unlocked by imitating your Bluetooth® connection, even if your trusted device is no
longer nearby. Your device is not always able to determine whether your connection
is secure from someone trying to imitate it.
13
This is an internet version of this publication. © Print only for private use.
When your device can't determine whether you're using a secure connection, you'll
get a notification on your Xperia™ device and may need to manually unlock it before
the trusted device can keep it unlocked.
Bluetooth® connectivity range can vary depending on factors like the model of your device,
the connected Bluetooth® device, and your environment. Depending on these factors,
Bluetooth® connections can work over distances up to 100 metres.
Connecting to trusted places
When the Trusted places feature is set up, the lock screen security on your Xperia™
device gets disabled when you are in a designated trusted location. For this feature to
work, you must have an internet connection (preferably over Wi-Fi) and allow your
device to use your current location.
To set up trusted places, first make sure that high accuracy location mode or batterysaving location mode is enabled on your device before you add home or custom
locations.
The exact dimensions of a trusted location are an estimate and may extend beyond the
physical walls of your home or other areas that you have added as a trusted locations. This
feature can keep your device unlocked within a radius of up to 80 metres. Also be aware that
location signals can be replicated or manipulated. Someone with access to specialised
equipment could unlock your device.
To add your home location
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Smart Lock > Trusted places
> Home.
3
To enter the desired location type the address in the search bar. Your device
searches for the entered location.
To edit your home location
1
From your Home screen, tap
2
Find and tap Settings > Lock screen & security > Smart Lock > Trusted places.
3
Select your home location.
4
Tap Edit.
5
In the search bar, enter the location that you want to use as your home
.
location.
If other residences share your street address, you can add the actual location of your home
within the building complex as a custom place.
To remove your home location
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Smart Lock > Trusted places
> Home.
3
Tap Edit > .
Using custom locations
You can add any location as a trusted, custom place where your device can remain
unlocked.
To add a custom place
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Smart Lock > Trusted places.
3
Tap Add trusted place.
4
To use your current location as a custom place, tap Select this location.
5
Alternatively, to enter another location, tap and type the address. Your
device searches for the entered location. Tap the suggested address, to use it.
6
To fine-tune the location, tap the back arrow next to the address, drag the
location pin to the desired location, then tap Select this location.
14
This is an internet version of this publication. © Print only for private use.
To edit a custom place
1
From your Home screen, tap .
2
Find and tap Settings > Lock screen & security > Smart Lock > Trusted places.
3
Select the place that you want to edit.
4
Tap Edit Address.
5
To enter another location, tap and then type the address. Your device
searches for the entered location. To use the suggested address, tap the
address.
6
To fine-tune the location, tap the back arrow next to the address, drag the
location pin to the desired location, then tap Select this location.
To remove a custom place
1
From your Home screen, tap
2
Find and tap Settings > Lock screen & security > Smart Lock > Trusted places.
3
Select the place that you want to remove.
4
Tap Delete.
.
SIM card protection
You can lock and unlock each SIM card that you use in your device with a PIN
(Personal Identification Number). When a SIM card is locked, the subscription linked
to the card is protected against misuse, meaning that you have to enter a PIN every
time you start your device.
If you enter the PIN incorrectly too many times, your SIM card will get blocked. You
then need to enter your PUK (Personal Unblocking Key) and a new PIN. Your PIN and
PUK are supplied by your network operator.
To set up or remove a SIM card lock
1
From the Home screen, tap
2
Find and tap Settings > Lock screen & security > Set up SIM card lock.
3
Tap the Lock SIM card slider to enable or disable the SIM card lock.
4
Enter the SIM card PIN and tap OK. The SIM card lock is now active and you
will be prompted to enter the PIN every time you restart the device.
To change the SIM card PIN
1
From the Home screen, tap
2
Find and tap Settings > Lock screen & security > Set up SIM card lock.
3
Tap Change SIM PIN.
4
Enter the old SIM card PIN and tap OK.
5
Enter the new SIM card PIN and tap OK.
6
Re-type the new SIM card PIN and tap OK.
To unlock a blocked SIM card using the PUK code
1
Enter the PUK code and tap
2
Enter a new PIN code and tap
3
Re-enter the new PIN code and tap .
If you enter an incorrect PUK code too many times, you need to contact your network operator
to get a new SIM card.
.
.
.
.
Finding the identification number of your device
Your device has a unique identification number. This number is referred to as the IMEI
(International Mobile Equipment Identity). You should keep a copy of this number.
You may require it, for example, when you access the Xperia™ Care support service
to register your device. Also, if your device is stolen, some network providers can use
this number to stop the device from accessing the network in your country or region.
15
This is an internet version of this publication. © Print only for private use.
To view your IMEI number on the label strip
1
Open the cover for the nano SIM and memory card slot.
2
Remove the SIM Card tray.
3
Drag the strip outwards using your fingernail. The IMEI number is displayed on
the strip.
You can also view the IMEI number by opening the phone dialer and entering *#06#.
To view your IMEI number via the device settings
1
From your Home screen, tap .
2
Find and tap Settings > About phone > Status > IMEI information.
Finding a lost device
If you have a Google™ account, the “Protection by my Xperia” web service can help
you locate and secure your device if you ever lose it. If you have activated this service
on your device, you can:
•
Locate your device on a map.
•
Sound an alert even if the device is in Do not disturb mode.
•
Remotely lock the device and make the device display your contact details to anyone
who finds it.
•
Remotely clear the internal and external memory of the device as a last resort.
If you’ve cleared the internal memory of the device using the “Protection by my Xperia” web
service, you must sign in to a Google™ account that was previously synced on this device the
next time you turn on the device.
The “Protection by my Xperia” service may not be available in all countries or regions.
16
This is an internet version of this publication. © Print only for private use.
To activate Protection by my Xperia
1
Make sure you have an active data connection, and enable location services
on your device.
2
From your Home screen, tap .
3
Find and tap Settings > Lock screen & security > Protection by my Xperia >
ACTIVATE.
4
Mark the checkbox to agree to the terms and conditions of the service, then
tap ACCEPT.
5
If prompted, sign in to your Google™ account, or create a new account if you
don’t already have one.
6
To verify that Protection by my Xperia can locate your device, go to
myxperia.sonymobile.com
If you are sharing a device with multiple users, note that the Protection by my Xperia service is
only available to the user who is logged in as the owner.
and sign in to your Google™ account.
Finding a lost device using Android™ Device Manager
Google™ offers a location and security web service called Android™ Device
Manager. You can use it in parallel with, or as an alternative to, the Protection by my
Xperia service. If you lose your device, you can use Android™ Device Manager to:
•
Find and show where your device is located.
•
Ring or lock your device, erase everything on it, or add a phone number to the lock
screen.
For additional information about Android™ Device Manager, go to
www.support.google.com
.
Android™ Device Manager does not work if your device is turned off or if it does not have a
connection to the internet. The Android™ Device Manager service may not be available in all
countries or regions.
To activate Android™ Device Manager
1
If you are sharing a device with multiple users, make sure that you are logged
in as the owner.
2
Make sure that you have an active data connection and that location services
are enabled.
3
From your Home screen, tap
4
Find and tap Settings > Google > Security.
5
Tap the sliders beside Remotely locate this device and Allow remote lock and
.
erase to enable both functions.
6
If prompted, agree to the terms and conditions by tapping Activate this device
administrator.
7
To verify that Android™ Device Manager can locate your device after you
activate the service, go to
www.android.com/devicemanager
and sign in using
your Google™ account.
You can also activate Android™ Device Manager from
administrators.
Lock screen & security under Device
17
This is an internet version of this publication. © Print only for private use.
Learning the basics
Using the touchscreen
Tapping
•
Open or select an item.
•
Mark or unmark a checkbox or option.
•
Enter text using the on-screen keyboard.
Touching and holding
•
Move an item.
•
Activate an item-specific menu.
•
Activate selection mode, for example, to select several items from a list.
18
This is an internet version of this publication. © Print only for private use.
Pinching and spreading
•
Zoom in or out on web pages, photos and maps, and when you’re taking photos or
shooting videos.
Swiping and scrolling
•
Scroll up or down a list.
•
Swipe left or right, for example, between Home screen panes.
•
Swipe left or right to reveal more options.
Flicking
•
Scroll quickly, for example, in a list or on a web page. You can stop the scrolling
movement by tapping the screen.
19
This is an internet version of this publication. © Print only for private use.
Locking and unlocking the screen
When your device is on and left idle for a set period of time, the screen darkens to
save battery power and locks automatically. This lock prevents unwanted actions on
the touchscreen when you are not using it. When you buy your device, a basic screen
swipe lock is already set. This means that you have to swipe left or upwards on the
screen to unlock it. You can change the security settings later and add other kinds of
locks. See
To activate the screen
•
Briefly press the power key .
To lock the screen
1
When the screen is active, briefly press the power key
2
Alternatively, double tap any empty area on the Home screen. To enable this
function, touch and hold any area on your Home screen until the device
vibrates, then tap
Screen lock
and tap the slider beside Double-tap to sleep.
on page 10.
.
Home screen
The Home screen is the starting point for using your device. It's similar to the desktop
on a computer screen. Your Home screen can have up to twenty panes, which
extend beyond the regular screen display width. The number of Home screen panes
is represented by a series of dots at the lower part of the Home screen. The
highlighted dot shows the pane that is currently displayed.
1 Welcome to Xperia™ widget — Tap to open the widget and select a task such as copying content
from your old device or setting up Xperia™ services
2 Dots — Represents the number of Home screen panes
To go to the Home screen
•
Press
.
20
This is an internet version of this publication. © Print only for private use.
To browse the Home screen
Home screen panes
You can add new panes to your Home screen (up to a maximum of twenty panes)
and delete panes. You can also set the pane that you want to use as the main Home
screen pane.
To set a pane as the main Home screen pane
1
Touch and hold any area on your Home screen until the device vibrates.
2
Flick left or right to browse to the pane that you want to set as your main Home
screen pane, then tap
When Google Search & Now is enabled, the left-most pane is reserved for this service and the
main Home screen pane cannot be changed. For more information, see
on page 116.
.
Google Search & Now
To add a pane to your Home screen
1
Touch and hold any area on your Home screen until the device vibrates.
2
To browse the panes, flick all the way to the right or left, then tap .
When Google Search & Now is enabled, the left-most pane is reserved for this service and
additional panes cannot be added to the left. For more information, see
on page 116.
Google Search & Now
To delete a pane from your Home screen
1
Touch and hold any area on your Home screen until the device vibrates.
2
Flick left or right to browse to the pane that you want to delete, then tap
on
the top right corner of the pane.
21
This is an internet version of this publication. © Print only for private use.
Home screen settings
To disable or uninstall an application from the Home screen
Disabling a pre-installed app deletes all data, but the app can be enabled again from Settings
> Apps. Only downloaded apps can be fully uninstalled.
1
Touch and hold any area on your Home screen until the device vibrates.
2
Flick left or right to browse the panes. All applications that can be disabled or
uninstalled are indicated by .
3
Tap the relevant application, then tap DISABLE if the app came pre-installed
on your device or OK if the app was downloaded and you would like to
uninstall it.
To adjust the size of icons on your Home screen
1
Touch and hold any area on your Home screen until the device vibrates, then
tap .
2
Tap Icon size, then select an option.
Application screen
The Application screen, which you open from the Home screen, contains the
applications that come pre-installed on your device as well as applications that you
download.
To view all applications on the Application screen
1
From your Home screen, tap .
2
Flick left or right on the Application screen.
To enable or disable the recommended apps listings
The first time you access the application screen you get the option to enable or
disable recommended apps listings. You can also enable or disable this feature later
by following the steps below:
1
Touch and hold any area on your Home screen until the device vibrates, then
tap .
2
Tap the App recommendations slider.
To open an application from the Application screen
•
When the Application screen is open, flick left or right to find the application,
and then tap the application.
To search for an application from the Application screen
1
When the Application screen is open, tap Search applications or simply swipe
down on the Application screen or Home screen.
2
Enter the name of the application that you want to search for.
22
This is an internet version of this publication. © Print only for private use.
To arrange applications on the Application screen
1
When the Application screen is open, tap .
2
Tap Sort apps, then select an option.
To add an application shortcut to the Home screen
1
On the Application screen, touch and hold an application icon until the device
vibrates, then drag the icon to the top of the screen. The Home screen opens.
2
Drag the icon to the desired location on the Home screen, then release it.
To move an application on the Application screen
1
When the Application screen is open, tap
2
Make sure that Own order is selected under Sort apps.
3
Touch and hold the application until the device vibrates, then drag it to the new
.
location.
To disable or uninstall an application from the Application screen
Disabling a pre-installed app deletes all data, but the app can be enabled again from Settings
> Apps. Only downloaded apps can be fully uninstalled.
1
Touch and hold any area on the Application screen until the device vibrates. All
applications that can be disabled or uninstalled are then indicated by .
2
Tap the relevant application, then tap DISABLE if the app came pre-installed
on your device or OK if the app was downloaded and you would like to
uninstall it.
Navigating applications
You can navigate between applications using the navigation keys and the recently
used applications window, which lets you switch easily between all recently used
applications. The navigation keys are the Back key, the Home key, and the Recent
apps key. You can also pop open two applications on the screen at once using the
split screen mode, if the application supports multi-window function. Some
applications get closed when you press the Home key
paused or continue to run in the background. If an application is paused or running in
the background, you can continue where you left off the next time you open the
application.
to exit while others are
1 Clear all – Close all the recently used applications
2 Recently used applications window – Open a recently used application
3 Recent apps key – Open the recently used applications window and the favourites bar
4 Home key – Exit an application and go back to the Home screen
5 Back key – Go back to the previous screen within an application or close the application
23
This is an internet version of this publication. © Print only for private use.
To open the recently used applications window
•
Press .
To quickly switch between recently used applications
•
Quickly press twice.
To close all the recently used applications
•
Tap and then tap CLEAR ALL.
To open a menu in an application
•
While using the application, tap .
A menu is not available in all applications.
Split screen mode
Split screen mode enables you to view two applications at once, for example, if you
want to view your email inbox and a web browser at the same time.
1 Application 1 in upper window
2 Split screen border – Drag to resize windows
3 Application 2 in lower window
4 Split screen key – Select a recently used application
5 Home key – Go back to the Home screen
6 Back key – Go back to the previous screen within an application or close the application
Not all applications support split screen mode.
To use split screen mode
1
Make sure that the two applications that you want to use in split screen mode
are open and running in the background.
2
Tap , and then drag and drop the desired application to the top part of the
screen.
3
In the lower part of the screen, tap the second desired application.
4
In portrait orientation drag the black bar in the centre up or down to resize the
windows.
5
To exit split screen mode, tap and hold
.
One-handed operations
You can activate the one-handed operation mode to use your device with one hand.
24
This is an internet version of this publication. © Print only for private use.
To enable one-handed operations
1
From your Home screen, tap > Settings > One-handed operations.
2
Tap Resize screen.
3
Tap , then drag your thumb from the right corner to the center of the screen.
To adjust the position of the screen
1
To move the screen to the left side or to the right side, tap
2
To move the screen upwards or downwards, drag the horizontal stripes.
3
To resize the screen, drag the three diagonal stripes.
To return to using the full screen, tap .
or accordingly.
Widgets
Widgets are small applications that you can use directly on your Home screen. They
also function as shortcuts. For example, the Weather widget allows you to see basic
weather information directly on your Home screen. When you tap the widget, the full
Weather application opens. You can download additional widgets from Google
Play™.
To add a widget to the Home screen
1
Touch and hold any empty area on your Home screen until the device vibrates,
then tap Widgets.
2
Find and tap the widget that you want to add.
To resize a widget
1
Touch and hold a widget until the device vibrates, then release it. If the widget
can be resized, for example, the Calendar widget, then a highlighted frame and
resizing dots appear.
2
Drag the dots inward or outward to shrink or expand the widget.
3
To confirm the new size of the widget, tap anywhere on the Home screen.
To move a widget
•
Touch and hold the widget until the device vibrates, then drag it to the new
location.
To remove a widget
•
Touch and hold the widget until the device vibrates, then drag it to Remove
from home screen.
Shortcuts and folders
Use shortcuts and folders to manage your applications and keep your Home screen
tidy.
25
This is an internet version of this publication. © Print only for private use.
1 Access an application using a shortcut
2 Access a folder containing applications
To add an application shortcut to your Home screen
1
Touch and hold an empty area on your Home screen.
2
In the customisation menu, tap Widgets > Shortcuts.
3
Scroll through the list and select an application. The selected application gets
added to the Home screen.
To move an item on the Home screen
•
Touch and hold the item until the device vibrates, then drag the item to the new
location.
To remove an item from the Home screen
•
Touch and hold the item until the device vibrates, then drag the item to
Remove from home screen on the top of the screen.
To create a folder on the Home screen
•
Touch and hold an application icon or a shortcut until the device vibrates, then
drag and drop it on top of another application icon or shortcut.
To add items to a folder on the Home screen
•
Touch and hold an item until the device vibrates, then drag the item to the
folder.
To rename a folder on the Home screen
1
Tap the folder to open it.
2
Tap the folder's title bar to show the Folder name field.
3
Enter the new folder name and tap DONE .
Background and themes
Your device comes with a default background, but you can adapt the Home screen
and Lock screen to your own style using wallpapers and themes featuring different
colours and patterns.
A wallpaper may be used without changing any of the other elements of your Home
screen and Lock screen. Live wallpapers add visual effects to your interactions with
the touch screen, letting the display change dynamically.
Themes can include a wallpaper, a screensaver, title bars, and a sound scheme that
all fit together to create a unique look and feel for your device.
To change your wallpaper
1
Touch and hold any empty area on your Home screen until the device vibrates.
2
Tap Wallpapers and select an option.
You can also change your Lock screen wallpaper or set the same image for both your Home
screen and Lock screen. Follow the steps above, then tap Album. Tap the desired image and
choose an option.
To set a theme
1
Touch and hold an empty area on your Home screen until the device vibrates.
2
Tap Themes.
3
Choose an option:
•
To use an existing theme, select the theme, then tap APPLY THEME.
•
To download a new theme, tap GET MORE THEMES.
When you change a theme, the background also changes in some applications.
26
This is an internet version of this publication. © Print only for private use.
Taking a screenshot
You can capture still images of any screen on your device as a screenshot.
Screenshots you take are automatically saved in Album.
To take a screenshot
1
Press and hold down the power key until a prompt window appears.
2
Tap .
You can also take a screenshot by pressing and holding the power key and volume down key
at the same time.
To view your screenshot
1
Double-tap the status bar to display the Notification panel.
2
Tap the screenshot.
You can also view your screenshots in the Album application.
Notifications
Notifications inform you of events such as new messages and calendar notifications
as well as activities in progress such as file downloads. Notifications appear in the
following places:
•
The status bar
•
The Notification panel
•
The lock screen
To open or close the Notification panel
1
To open the Notification panel, drag the status bar downwards, or simply
double-tap it.
2
To close the Notification panel, drag or flick the panel upwards.
After opening the
status bar down again.
Notification panel, you can access the Quick settings panel by dragging the
To take action on a notification in the Notification panel
•
Tap the notification.
You can directly reply to chat or email messages in the
27
This is an internet version of this publication. © Print only for private use.
Notification panel.
To dismiss a notification from the Notification panel
•
Swipe the notification left or right.
Not all notifications can be dismissed.
To change settings for notifications, simply drag the notification slowly to the left or right, then
tap .
To expand a notification on the Notification panel
•
Drag the notification downwards to expand and view more information about
the notification without opening the app.
Not all notifications are expandable.
To clear all notifications from the Notification panel
•
Tap CLEAR ALL.
To take action on a notification from the lock screen
•
Double-tap the notification.
To dismiss a notification from the lock screen
•
Swipe the notification left or right.
To expand a notification on the lock screen
•
Drag the notification downwards.
Not all
notifications are expandable.
Managing notifications on the lock screen
Show all
notification content
Hide sensitive
notification content
Don't show
notifications at all
To select the notifications to display on the lock screen
1
From your Home screen, tap .
2
Find and tap Settings > Notifications.
3
Tap , and then tap On the lock screen.
4
Select an option.
You can keep
feature, tap the Keep notifications on lock screen slider.
Get all notifications on the lock screen. When you have this setting turned on, keep
in mind that all content (including the content of incoming emails and chat
messages) will be visible on your lock screen unless you designate the relevant
apps as Hide sensitive content in the App notifications settings menu.
You must have a PIN, password, or pattern set up as your screen lock in order for
this setting to be available. Contents hidden is displayed on the lock screen when
sensitive notifications arrive. For example, you'll get a notification for an incoming
email or chat, but the content won't be visible on your lock screen.
You won't get any notifications on the lock screen.
notifications on the lock screen until you swipe to dismiss them. To enable this
Setting the notification level for an app
Block all
Sounds and vibrations off
This is an internet version of this publication. © Print only for private use.
Never receive notifications from the selected app.
Receive notifications but without sound, vibration or peeking into view.
28
Interrupts in Priority only
Receive notifications from this app even when Do not disturb is set to Priority
only.
To set the notification level for an app
1
From your Home screen, tap .
2
Find and tap Settings > Notifications.
3
Select the desired app.
4
Tap the sliders to adjust notification settings as desired.
Notification light
The notification light informs you about battery status and some other events. For
example, a flashing white light means there is a new message or a missed call. The
notification light is enabled by default but can be disabled manually.
When the notification light is disabled, it only lights up when there is a battery status warning,
for example, when the battery level goes below 15 percent.
To enable or disable the notification light
1
From your Home screen, tap .
2
Find and tap Settings > Notifications > .
3
Tap the slider beside Notification light to enable or disable the function.
Icons in the status bar
Status icons
No SIM card
Signal strength
No signal
Roaming
Sending and downloading LTE data
Sending and downloading GPRS data
Sending and downloading EDGE data
Sending and downloading 3G data
Sending and downloading HSPA+ data
A Wi-Fi connection is enabled and data is being transmitted
A Wi-Fi connection is enabled but there is no internet connection.
This icon also appears when you are trying to connect to a secured Wi-Fi
network. After a successful login, the exclamation mark disappears.
If Google™ is blocked in your area, the exclamation mark may appear even
when the device is connected to a Wi-Fi network and there is a working
internet connection.
Battery status
The battery is charging
Airplane mode is activated
29
This is an internet version of this publication. © Print only for private use.
The Bluetooth® function is activated
The microphone is muted
The speakerphone is on
Do not disturb mode is activated
Vibrate mode
An alarm is set
GPS is activated
Synchronisation is ongoing
Problem with sign-in or synchronisation
Depending on your service provider, network or region, the functions or services represented
by some icons in this list may not be available.
To manage status bar icons
1
From your Home screen, tap .
2
Find and tap Settings > Display> System icons.
3
Mark the checkboxes for the system icons that you want to appear in the
status bar.
Notification icons
New text message or multimedia message
Ongoing call
Missed call
Call on hold
Call forwarding is turned on
New voicemail message
New email message
Downloading data
Uploading data
Mobile data is disabled
Perform a basic setup of your device
A software update is available
System updates are available
Downloading system updates
Tap to install the downloaded system updates
STAMINA mode is activated
Ultra STAMINA mode is activated
Screenshot captured
Video chat with friends using the Duo™ application
A song is playing
30
This is an internet version of this publication. © Print only for private use.
Loading...
