Sony ST17i User’s Guide
Xperia
Extended User guide
™
active
Contents
Important information..................................................................6
Water resistance guide................................................................7
Android™ – what and why?.........................................................8
Applications........................................................................................8
Getting started..............................................................................9
Assembly............................................................................................9
Turning on the phone........................................................................12
Screen lock.......................................................................................12
Setup guide......................................................................................12
Accounts and services......................................................................13
Getting to know your phone......................................................14
Phone overview.................................................................................14
Using the keys..................................................................................15
Charging the battery.........................................................................15
Using the touch screen.....................................................................16
Home screen....................................................................................19
Accessing and using applications......................................................21
Status and notifications.....................................................................23
Phone settings menu........................................................................24
Typing text........................................................................................24
Keyboard and Phonepad settings.....................................................27
Adjusting the volume.........................................................................27
Customizing your phone...................................................................28
Battery..............................................................................................30
Memory............................................................................................31
Stereo portable handsfree.................................................................32
Internet and messaging settings........................................................32
Turning off data traffic.......................................................................33
Data roaming....................................................................................34
Network settings...............................................................................34
Calling..........................................................................................35
Emergency calls................................................................................35
Call handling.....................................................................................35
Voicemail..........................................................................................36
Multiple calls.....................................................................................37
Conference calls...............................................................................37
Call settings......................................................................................38
Contacts .....................................................................................39
Opening the Contacts application for the first time............................39
2
This is an Internet version of this publication. © Print only for private use.
Getting contacts into your phone......................................................39
Contacts screen overview.................................................................40
Managing your contacts....................................................................40
Communicating with your contacts...................................................42
Sharing your contacts.......................................................................42
Backing up contacts.........................................................................43
Messaging...................................................................................44
Using text and multimedia messaging...............................................44
Text and multimedia message options..............................................45
Email............................................................................................46
Using e-mail......................................................................................46
Using email accounts........................................................................48
Gmail™ and other Google™ services ...............................................48
Google Talk™ ............................................................................50
Sony Ericsson Timescape™......................................................51
Timescape™ main view....................................................................51
Timescape™ widget.........................................................................51
Using Timescape™...........................................................................52
Timescape™ settings........................................................................54
Getting started with Android Market™....................................55
Payment options...............................................................................55
Downloading from Android Market™................................................55
Clearing your application data...........................................................56
Permissions......................................................................................56
Installing non-Android Market™ applications.....................................57
PlayNow™ service.....................................................................58
Before you download content...........................................................58
Downloading from the PlayNow™ service.........................................58
Qriocity™ Video..........................................................................59
Qriocity™ menu overview..................................................................59
Creating a Qriocity™ account...........................................................59
Exploring the Qriocity™ video selection.............................................59
Renting or buying a video..................................................................59
Watching a video from Qriocity™......................................................60
Getting organized.......................................................................61
Calendar...........................................................................................61
Alarm clock.......................................................................................61
NeoReader™ application...........................................................64
NeoReader™ application menu overview..........................................64
ANT+............................................................................................65
3
This is an Internet version of this publication. © Print only for private use.
Synchronizing.............................................................................66
Synchronizing with Google™............................................................66
Synchronizing your corporate email, calendar and contacts..............67
Synchronizing with Facebook™........................................................67
Synchronizing and storing your contacts and calendar......................68
Synchronizing using SyncML™.........................................................69
Connecting to wireless networks.............................................70
Wi-Fi®..............................................................................................70
Virtual private networks (VPNs)..........................................................74
Web browser...............................................................................75
Toolbar.............................................................................................75
Browsing the web.............................................................................75
Navigating web pages.......................................................................76
Managing bookmarks.......................................................................76
Managing text and images................................................................77
Multiple windows..............................................................................77
Downloading from the web...............................................................78
Browser settings...............................................................................78
Music...........................................................................................79
Copying media files to your memory card..........................................79
Using the music player .....................................................................79
TrackID™ technology................................................................84
Using TrackID™ technology results...................................................84
FM radio......................................................................................85
FM radio overview.............................................................................85
Moving between radio channels........................................................85
Using your favorite radio channels.....................................................85
Making a new search for radio channels............................................86
Switching between the speaker and the handsfree...........................86
Identifying radio tracks using TrackID™.............................................86
Taking photos and recording videos........................................87
Camera controls...............................................................................87
Using the still camera........................................................................88
Using the video camera.....................................................................93
Viewing your photos and videos in Gallery..............................97
Working with albums.........................................................................97
Working with photos.........................................................................99
Bluetooth™ wireless technology............................................102
Phone name...................................................................................102
Pairing with another Bluetooth™ device..........................................102
Sending and receiving items using Bluetooth™ technology.............103
4
This is an Internet version of this publication. © Print only for private use.
Connecting your phone to a computer..................................105
Transferring and handling content using a USB cable......................105
USB connection modes..................................................................105
Transferring files using Media transfer mode via Wi-Fi®...................106
PC Companion...............................................................................107
Media Go™ ...................................................................................107
Location services.....................................................................108
Using GPS......................................................................................108
Google Maps™...............................................................................109
Getting directions............................................................................109
Locking and protecting your phone.......................................110
IMEI number...................................................................................110
SIM card protection........................................................................110
Setting a screen lock.......................................................................111
Updating your phone...............................................................113
Updating your phone wirelessly.......................................................113
Updating your phone using a USB cable connection.......................113
Phone settings overview.........................................................115
Icon overview............................................................................116
Status icons....................................................................................116
Notification icons.............................................................................116
Application overview................................................................118
User support.............................................................................120
Troubleshooting.......................................................................121
My phone is not working as expected.............................................121
Resetting the phone........................................................................121
I cannot charge the phone..............................................................121
No battery charging icon appears when phone starts charging.......121
The battery performance is low.......................................................121
I cannot transfer content between my phone and the computer,
when using a USB cable.................................................................121
I cannot use Internet-based services...............................................122
Error messages...............................................................................122
Recycle your phone.................................................................123
Legal information.....................................................................124
Index..........................................................................................125
5
This is an Internet version of this publication. © Print only for private use.
Important information
Please read the Important information leaflet before you use your mobile phone.
Some of the services and features described in this User guide are not supported in all countries/
regions or by all networks and/or service providers in all areas. Without limitation, this applies to
the GSM International Emergency Number 112. Please contact your network operator or service
provider to determine availability of any specific service or feature and whether additional access
or usage fees apply.
6
This is an Internet version of this publication. © Print only for private use.
Water resistance guide
>1m
In order for your Xperia™ active to be water-resistant, the covers of the micro USB port
and the headset connector must be firmly closed. Also, make sure that the back cover and
the battery cover are attached correctly. The Startup guide provides instructions on how
to correctly attach the battery cover and the back cover.
Avoid exposing your device to environments with excessive dust or moisture. Normal wear
and tear, along with damage to your device, can reduce its ability to resist dust or moisture.
Ocean water Swimming pool Diving
Hot water Sand/mud Other liquid
chemicals
Never submerge the mobile phone, the micro USB port or the headset connector in water,
expose the mobile phone to any liquid chemicals, or expose your mobile phone to moist
environments with extreme high or low temperatures. If water or liquid gets on the micro
USB port and the headset connector, wipe it off with a dry cloth. The water resistance of
the micro USB port and the headset connector are not guaranteed in all environments or
conditions.
All compatible accessories, including batteries, chargers, handsfree devices, micro USB
cables, microSD™ cards, lanyards, and so on are not dust and water-resistant on their
own.
Your warranty does not cover damage or defects caused by abuse or improper use of your
device. If you have any further questions about the use of your products, get help from our
Customer support service.
7
This is an Internet version of this publication. © Print only for private use.
Android™ – what and why?
An Android™ phone can perform many of the same functions as a computer. But you can
also adjust it to better suit your needs, receive the information you want, and have fun at
the same time. You can add and delete applications, or enhance them to improve
functionality. At Android Market™ you can download a range of applications and games
from a constantly growing collection. You can also integrate applications on your Android™
phone with your personal data and online accounts. For example, you can back up your
phone contacts, access your different email accounts and calendars from one place, keep
track of your appointments, and engage in as much social networking as you like.
Android™ phones are constantly evolving. When a new software version is available and
your phone supports this new software, you can update your phone to get new features
and the latest improvements.
Your Android™ phone is pre-loaded with Google™ services. To get the most out of any of the
provided Google™ services, you should have a Google™ account and sign in to it when you
first start your phone. You also need to have Internet access to use many of the features in
Android™.
Applications
An application is a phone program that helps you perform a task. For example, there are
applications to make calls, take photos and download more applications.
8
This is an Internet version of this publication. © Print only for private use.
Getting started
2
1
3
Assembly
To remove the back cover and the battery cover
1
Insert a thumbnail into the gap under the headset connector cover and the micro
USB port cover, then lift up the two covers.
2
Insert a thumbnail into the gap (as shown in step 2 of the illustration above), then lift
up the back cover slowly but firmly.
3
Place a thumbnail under the lip (indicated by the arrow on the battery cover), then
lift up and remove the battery cover.
Do not use sharp objects that may damage parts of the phone.
To insert the SIM card and the memory card
•
Remove the back cover and the battery cover, then insert the SIM card and the
memory card into the relevant slots.
Memory card may not be included with purchase in all markets.
9
This is an Internet version of this publication. © Print only for private use.
To remove the battery
1
2
1
Remove the back cover and the battery cover.
2
Place the tip of your finger into the opening on the bottom side of the battery and lift
up the battery.
To remove the memory card
You must unmount your memory card or turn off your phone before you can safely remove the
memory card. For more information, see Safely removing the memory card on page 31.
•
Remove the back cover and the battery cover, then draw the memory card outward
to remove it.
To remove the SIM card
1
Remove the back cover, the battery cover and the battery.
2
Place the tip of your finger on the SIM card and slide it out of its slot.
10
This is an Internet version of this publication. © Print only for private use.
To attach the battery cover and the back cover
1
3
2
1
2
1
Place the battery cover over the back of the phone so that the camera lens hole in
the cover fits over the camera lens.
2
Press down gently on all edges of the battery cover to attach it securely.
3
Place the back cover over the back of the phone so that the camera lens hole in the
cover fits over the camera lens. Then press down firmly on all edges of the back
cover to attach it tightly.
4
Press down the micro USB port cover and the headset connector cover to make
sure they are fully latched.
Correctly attaching the back cover and the battery cover can keep your phone resistant to water.
The phone is not resistant to water when the micro USB port cover or the headset connector
cover is open, for example, when the phone is charging or when it's connected to a wired headset.
11
This is an Internet version of this publication. © Print only for private use.
Turning on the phone
To turn on the phone
1
Press and hold down the power key on the left side of the phone until the phone
vibrates.
2
If your screen goes dark, briefly press the key to activate the screen.
3
To unlock the screen, drag to the right across the screen.
4
Enter your SIM card PIN when requested, and select OK.
Your SIM card PIN is initially supplied by your network operator, but you can change it later from
the Settings menu. To correct a mistake made while entering your SIM card PIN, press .
It might take a while for the phone to start up.
To turn off the phone
1
Press and hold down the power key until the options menu opens.
2
In the options menu, tap Power off.
3
Tap OK.
It may take a while for the phone to shut down.
Screen lock
When your phone is on and left idle for a set period of time, the screen darkens to save
battery power, and locks automatically. This lock prevents unwanted actions on the touch
screen when you are not using it.
To activate the screen
•
Briefly press the key.
To unlock the screen
•
Drag the
To lock the screen manually
•
When the screen is active, briefly press the key.
icon to the right across the screen.
Setup guide
The first time you start your phone, a setup guide opens to explain basic phone functions
and helps you enter essential settings. This is a good time to configure your phone to your
specific needs.
The setup guide covers the following:
•
Basic phone settings such as language and Internet. For example, you can adjust settings
for how you access the Internet.
•
Wi-Fi® settings – speed up your connection and decrease data transfer costs.
•
Online service settings – helps you with email setup, online service accounts, and contact
transfers from an old phone or other data source.
12
This is an Internet version of this publication. © Print only for private use.
You can also refer to the respective chapters in the in-phone User guide, available through
the Support application in the phone and at www.sonyericsson.com/support, for more help
with the following:
•
Wi-Fi®
•
Sony Ericsson Sync
If you prefer, you can skip some steps and access the setup guide later from the Application
screen or change the settings from the Settings menu.
To access the setup guide
1
From the Home screen, tap .
2
Find and tap Setup guide.
Accounts and services
Sign in to your online service accounts from your phone and benefit from a range of services.
Combine services and get even more out of them. For example, collect contacts from your
Google™ and Facebook™ accounts and integrate them into your phonebook, so you have
everything in one place.
You can sign up to online services from your phone as well as from a computer. When you
sign up for the first time, an account is created with your user name, password, settings
and personal information. The next time you sign in, you get a personalized view.
Google™ account
Having a Google account is key to using a range of applications and services with your
Android phone. You need a Google™ account, for example, to use the Gmail™ application
in your phone, to chat to friends using Google Talk™, to synchronize your phone calendar
with your Google Calendar™, and to download applications and games from Android
Market™.
Sony Ericsson account
Store your phone contacts on a secure Sony Ericsson server, and you'll always have a
backup online. You can also store your phone calendar and Internet bookmarks in your
Sony Ericsson account.
Exchange ActiveSync® account
Synchronize your phone with your corporate Exchange ActiveSync® account. This way,
you keep your work email, contacts, and calendar events with you at all times.
Facebook™ account
Facebook™ connects you with friends, family and colleagues all over the world. Log in now
to share your world with others.
13
This is an Internet version of this publication. © Print only for private use.
Getting to know your phone
1 2 3 54
6
7
8
10
9
111213
16
15
14
19
20
17
18
21
22
Phone overview
14
This is an Internet version of this publication. © Print only for private use.
1. Light sensor
2. Notification LED
3. Ear speaker
4. Proximity sensor 1
5. Proximity sensor 2
6. Volume key/Zoom key
7. Touch screen
8. Camera key
9. Menu key
10. Strap hole
11. Home key
Using the keys
12. Main microphone
13. Back key
14. Second microphone
15. Camera LED light
16. Power key/Screen lock
17. Speaker
18. Camera lens
19. Micro USB port cover
20. Headset connector cover
21. Micro USB port
22. Headset connector
•
•
•
•
•
Close the on-screen keypad, a dialog box, an options menu, or the Notification panel
Press and hold to open a window showing your most recently used applications
Open a list of options available in the current screen or application
Go back to the previous screen
Back
Home
Go to the Home screen
Menu
Charging the battery
Your phone battery is partly charged when you buy the phone. It may take a few minutes
before the battery icon appears on the screen when you connect the phone charger
cable to a power source, such as a USB port or a phone charger. You can still use your
phone while it is charging.
The battery will start to discharge a little after it is fully charged and then it charges again after a
certain time when the phone charger is connected. This is to extend battery life and may result
in the charge status showing a level below 100 percent.
15
This is an Internet version of this publication. © Print only for private use.
1
3
2
To charge the phone
1
Plug the phone charger into a power outlet.
2
Plug one end of the USB cable into the charger (or into the USB port of a computer).
3
Plug the other end of the cable into the micro USB port on your phone, with the USB
symbol facing up.
4
When the phone is fully charged, disconnect the USB cable from your phone by
pulling it straight outward.
Be sure not to bend the connector when removing the cable from the phone.
Using the touch screen
A protective plastic sheet is attached to the screen of your phone when you buy it. You
need to peel off this sheet before using the touch screen. Otherwise, the touch screen might
not function properly.
When your phone is on and left idle for a set period of time, the screen darkens to save
battery power, and locks automatically. This lock prevents unwanted actions on the touch
screen when you are not using it. You can also set personal locks to protect your
subscription and make sure only you can access your phone.
Your phone screen is made from glass. Do not touch the screen if the glass is cracked or
shattered. Avoid trying to repair a damaged screen yourself. Glass screens are sensitive to
mechanical shocks. Cases of negligent care are not covered by the Sony Ericsson warranty
service.
To open or highlight an item
•
Tap the item.
To mark or unmark options
•
Tap the relevant checkbox, or in some cases the right side of the list option, to mark
or unmark an option.
16
This is an Internet version of this publication. © Print only for private use.
Marked checkbox
Unmarked checkbox
Marked list option
Unmarked list option
Zooming
There are two ways to zoom. The zoom options available depend on the application you
are using.
To zoom
•
When available, tap or to zoom in or out.
You may have to drag the screen (in any direction) to make the zoom icons appear.
To zoom with two fingers
•
Place two fingers on the screen at once and pinch them together (to zoom out) or
spread them apart (to zoom in).
Use the zoom function when viewing photos and maps, or when browsing the Web.
Scrolling
Scroll by moving your finger up or down on the screen. On some web pages you can also
scroll to the sides.
Dragging or flicking will not activate anything on the screen.
17
This is an Internet version of this publication. © Print only for private use.
To scroll
•
Drag or flick your finger in the direction you want to scroll on the screen.
To scroll more quickly, flick your finger in the direction you want to go on the screen.
To flick
•
To scroll more quickly, flick your finger in the direction you want to go on the screen.
You can wait for the scrolling movement to stop by itself, or you can stop it
immediately by tapping the screen.
Sensors
Your phone includes a light sensor and a proximity sensor. The light sensor detects the
ambient light level and adjusts the brightness of the screen accordingly. The proximity
sensor turns the touch screen off when your face touches the screen. This prevents you
from unintentionally activating phone functions when you are engaged in a call.
18
This is an Internet version of this publication. © Print only for private use.
Home screen
02:40
Jan 6, 1980
AM
02
0
Jan 6,
6,
19801980
Your phone's Home screen is the equivalent of the desktop on a computer. It's the gateway
to your phone's main features. You can customize your Home screen with widgets,
shortcuts, folders, themes, wallpaper, and other items.
The four corners on the Home screen help you access applications or web page shortcuts
quickly.
The Home screen extends beyond the regular screen display width, so you need to flick
left or right to view content in one of the screen's four extensions. shows which part
of the Home screen you are in.
To go to the Home screen
•
Press .
To browse the Home screen
•
Flick right or left.
To share an item from your Home screen
1
Press
2
Touch and hold an item until it magnifies and the phone vibrates, then drag the item
to open your Home screen.
to .
3
Select an option and confirm, if necessary. You can now share the applications and
widgets you like with your friends so they can download and use them.
Widgets
Widgets are small applications that you can use directly on your Home screen. For example,
the Music player widget allows you to start playing music directly and the Sony Ericsson
Timescape™ widget displays incoming messages.
To add a widget to the Home screen
1
From your Home screen, press .
2
Tap Add > Widgets.
3
Tap a widget.
To get an overview of all widgets on your Home screen
•
Pinch on any area of your Home screen. All widgets from different parts of your Home
screen are now displayed in one view.
When all Home screen widgets are combined in one view, tap on any widget to go to the part
of the Home screen containing that widget.
19
This is an Internet version of this publication. © Print only for private use.
Rearranging your Home screen
Customize the appearance of your Home screen and change the features you can access
from it. Change the screen background, move items around, create folders, and add
shortcuts to contacts.
To open the options menu of your Home screen
You can open the Home screen options menu in two ways:
•
From your Home screen, press .
•
Touch and hold on any part of your Home screen.
Rearranging your Home screen corners
Rearrange the items in your Home screen corners with the applications or web page
shortcuts (bookmarks) you access most frequently. You can add a maximum of four
shortcuts to each of the corners.
To add an application to a corner
1
From your Home screen, tap .
2
Touch and hold an application until the Home screen appears and the phone
vibrates, then drag the application to one of the corners.
To add a webpage shortcut to a corner
1
From your Home screen, press .
2
Tap Add > Shortcuts > Bookmark.
3
Select a bookmark to add the bookmark to your Home screen.
4
Drag the bookmark to one of the corners.
See To add a webpage shortcut to your Home screen on page 76.
To delete an item from a corner
1
From your Home screen, tap one of the corners to magnify the corner.
2
Touch and hold an item in the corner until the phone vibrates, then drag the item to
.
To move an item away from a corner
1
From your Home screen, tap one of the corners to magnify the corner.
2
Touch and hold an item in the corner until the phone vibrates, then drag the item
away from the corner and drop the item on an area of your Home screen.
To add a shortcut to the Home screen
1
From your Home screen, press
2
Tap Add > Shortcuts.
3
Find and select a shortcut.
Add an application shortcut directly from the Application screen by touching and holding the
application.
.
To add a folder to the Home screen
1
From your Home screen, press .
2
Tap Add > Folder.
3
Enter a name for the folder, select an icon, and tap Done.
Drop an item on top of another item on your Home screen to create a folder automatically.
To add items to a folder
•
Touch and hold an item until it magnifies and the phone vibrates, then drag the item
to the folder.
20
This is an Internet version of this publication. © Print only for private use.
To rename a folder
1
Tap the folder to open it.
2
Touch the folder's title bar to show the Folder name field.
3
Enter the new folder name and tap Done.
To move an item on the Home screen
1
Press to open your Home screen.
2
Touch and hold an item until it magnifies and the phone vibrates, then drag the item
to the new location.
To delete an item from the Home screen
•
Touch and hold an item until it magnifies and the phone vibrates, then drag the item
to .
Changing the background of your Home screen
Adapt the Home screen to your own style using wallpapers and different themes.
To change your Home screen wallpaper
1
From your Home screen, press .
2
Tap Wallpaper, then select a wallpaper.
You can use a photo you have taken, or an animation. Go to Android Market™ and other sources
to download, for example, live wallpapers that change with the changing hours of the day.
To set a theme
1
From your Home screen, press .
2
Tap Theme, then select a theme.
When you change a theme, the background also changes in some applications.
Accessing and using applications
Open applications from shortcuts on your Home screen or from the Application screen.
Application screen
The Application screen, which you open from your Home screen, contains the applications
that come installed with your phone as well as the applications you download.
The Application screen extends beyond the regular screen width, so you need to flick left
and right to view all content.
To open the Application screen
•
From your Home screen, tap .
To browse the Application screen
•
Open the Application screen, then flick right or left.
This is an Internet version of this publication. © Print only for private use.
21
To create a shortcut to an application on the Home screen
1
From your Home screen, tap .
2
Touch and hold an application until it appears on your Home screen, then drag it to
the desired location.
To share an application from your Application screen
1
From your Home screen, tap .
2
Touch and hold an application until it appears on your Home screen, then drag the
item to .
3
Select an option and confirm, if necessary. You can now share the applications you
like with your friends so they can download and use them.
Opening and closing applications
To open an application
•
From your Home screen or the Application screen, tap the application.
To close an application
•
Press .
Some applications are paused when you press
to run in the background. In the first case, the next time you open the application, you can
continue where you left off.
to exit, while other applications may continue
Recently used applications window
You can view and access recently used applications from this window.
To open the recently used applications window
•
Press and hold down .
Application menu
You can open a menu at any time when you are using an application by pressing the
key on your phone. The menu will look different depending on which application you
are using.
To open a menu in an application
•
While using the application, press
A menu is not available in all applications.
.
Rearranging your Application screen
Move the applications around on the Application screen according to your preferences.
To arrange applications on the Application screen
1
From your Home screen, tap to go to the Application screen.
2
Tap and select an option.
22
This is an Internet version of this publication. © Print only for private use.
To move an application on the Application screen
1
Open the Application screen, then tap .
2
Touch and hold an item until it magnifies and the phone vibrates, then drag the item
to the new location.
3
Tap to exit edit mode.
You can only move your applications when is selected.
To uninstall an application from the Application screen
1
From your Home screen, tap .
2
Tap . All uninstallable applications are marked with a icon.
3
Tap the application you want to uninstall, then tap OK.
Status and notifications
The status bar at the top of your screen shows what's going on in your phone. To the left
you get notifications when there is something new or ongoing. For example, new message
and calendar notifications appear here. The right side shows the signal strength, battery
status, and other information.
Checking notifications and ongoing activities
You can drag down the status bar to open the Notification panel and get more information.
For example, open a new message or view a calendar event from the Notification panel.
You can also open running applications, such as the music player.
To open the Notification panel
•
Drag the status bar downwards.
This is an Internet version of this publication. © Print only for private use.
23
To close the Notification panel
•
Drag the tab at the bottom of the Notification panel upward.
To open a running application from the Notification panel
•
From the Notification panel, tap the icon for the running application to open it.
To clear the Notification panel
•
From the Notification panel, tap Clear.
Phone settings menu
View and change your phone settings from the Settings menu.
To access the phone settings
1
From the Home screen, tap .
2
Tap Settings.
Typing text
Use either the Phonepad or the on-screen keyboard to enter letters, numbers and other
characters. The Phonepad is similar to a standard 12-key telephone keypad while the onscreen keyboard has a QWERTY layout.
Phonepad
The Phonepad is similar to a standard 12-key telephone keypad. It gives you predictive text
and multi-tap input options. You can activate the Phonepad text input method via the
keyboard settings. The Phonepad is only available in portrait orientation.
24
This is an Internet version of this publication. © Print only for private use.
Using the Phonepad
1
7
8
’’’.
-
ABC
DEF ?
JKL MNOGHI
!
TUV WXYZPQRS
5
123
3
4 6
2
1 Choose a text input option
2 Change the character case and turn on the caps lock
3 Display numbers
4 Display symbols and smileys
5 Enter a space
6 Open the input settings menu to change, for example, the Writing languages. This key also changes the
7 Enter a carriage return or confirm text input
8 Delete a character before the cursor
writing language when more than one input language is selected.
All illustrations are for illustration purposes only and may not accurately depict the actual phone.
To display the Phonepad to enter text
•
While holding the phone in portrait orientation, tap a text entry field.
To enter text using the Phonepad
When using the Phonepad, you can choose from two input options:
•
When
want is not the first letter on the key. Tap the word that appears or tap to view more
word suggestions and select a word from the list.
•
When appears in the Phonepad, tap the on-screen key for the character you want to
enter. Keep pressing this key until the desired character is selected. Then do the same for
the next character you want to enter, and so on.
To hide the Phonepad
•
When the Phonepad is open, press .
To shift between upper-case and lower-case letters
•
Before you enter a letter, tap
To turn on the caps lock
•
Before you type a word, tap or until appears.
To enter numbers using the Phonepad
•
When the Phonepad is open, tap
appears in the Phonepad, tap each character key only once, even if the letter you
to switch to upper-case , or vice versa.
. A Phonepad with numbers appears.
To insert symbols and smileys using the Phonepad
1
When the Phonepad is open, tap . A grid with symbols and smileys appears.
2
Scroll up or down to view more options. Tap a symbol or smiley to select it.
This is an Internet version of this publication. © Print only for private use.
25
To delete characters
12:45
3G
.,
516
7
432
•
Tap to place the cursor after the character you want to delete, then tap .
To enter a carriage return
•
When you enter text, tap to enter a carriage return.
To edit text
1
When you enter text, touch and hold the text field until the Edit text menu appears.
2
Select an option.
On-screen keyboard
Tap the keys of the on-screen QWERTY keyboard to enter text conveniently. Some
applications open the on-screen keyboard automatically. You can also open this keyboard
by touching a text field.
Using the on-screen keyboard
1
Change the character case and turn on the caps lock. For some languages, this key is used to access extra
2 Close the on-screen keyboard view
3 Display numbers and symbols. Touch and hold to display smileys.
4 Enter a space
5 Open the input settings menu to change, for example, the Writing languages. This key also changes the
writing language when more than one input language is selected.
6 Enter a carriage return or confirm text input
7 Delete a character before the cursor
All illustrations are for illustration purposes only and may not accurately depict the actual phone.
characters in the language.
To open the on-screen keyboard for the first time
•
Hold your phone horizontally and tap a text entry field.
•
To use the on-screen keyboard in portrait orientation, tap a text entry field, then tap
or touch and hold if you have already selected more than one input language.
Tap Portrait keyboard and select an option.
Once you’ve made the setting, you can simply activate the on-screen keyboard by tapping a
text entry field.
To switch between the on-screen keyboard and the Phonepad
1
When you enter text, tap , or touch and hold if you have already selected more
than one input language.
2
Tap Portrait keyboard and select an option.
Remember the Phonepad is only available in portrait orientation.
26
This is an Internet version of this publication. © Print only for private use.
To enter text using the on-screen keyboard
•
To enter a character visible on the keyboard, tap the character.
•
To enter a character variant, touch and hold a regular keyboard character to get a
list of available options, then select from the list. For example, to enter "é", touch and
hold "e" until other options appear, then, while keeping your finger pressed on the
keyboard, drag to and select "é".
To enter numbers or symbols
•
When you enter text, tap . A keyboard with numbers and symbols appears. Tap
to view more options.
To insert a smiley
1
When you enter text, touch and hold .
2
Select a smiley.
Keyboard and Phonepad settings
You can select settings for the on-screen keyboard and the Phonepad, such as writing
language and automatic correction.
To access the on-screen keyboard and the Phonepad settings
•
When you enter text using the on-screen keyboard or Phonepad, tap . If you have
selected more than one writing language, touch and hold instead.
To change the writing language using the on-screen keyboard or the Phonepad
1
When you enter text, tap , or touch and hold if you have already selected more
than one input language.
2
Tap Writing languages and select the languages you want to use for writing.
3
If you have selected more than one input language, tap to switch between the
selected writing languages.
Text input settings
When entering text, you can access a text input settings menu that helps you set options
for text prediction. For example, you can decide how you want the phone to present word
alternatives and correct words as you type, or enable the text input application to remember
new words you write.
To change the text input settings
1
When you enter text using the on-screen keyboard or the Phonepad, tap , or
touch and hold .
2
Tap Text input settings.
3
Select the desired settings.
Adjusting the volume
You can adjust the ringtone volume for phone calls and notifications as well as for music
and video playback.
To adjust the ring volume with the volume key
•
Press the volume key up or down.
To adjust the media playing volume with the volume key
•
When playing music or watching video, press the volume key up or down.
27
This is an Internet version of this publication. © Print only for private use.
To set the phone to silent and vibrate mode
1
From the Home screen, tap .
2
Find and tap Settings > Sound.
3
Mark the Silent mode checkbox.
4
Select Vibrate and choose an option.
To enhance the speaker loudness
1
From the Home screen, tap .
2
Find and tap Settings > Sound.
3
Mark the xLOUD™ checkbox.
Customizing your phone
Adapt the phone to your needs by adjusting, for example, your personal ringtone, phone
language and your Privacy settings.
Time and date
You can change the time and date in your phone.
To set the date manually
1
From the Home screen, tap
2
Find and tap Settings > Date & time.
3
Unmark the Automatic checkbox, if it is marked.
4
Tap Set date.
5
Adjust the date by scrolling up and down.
6
Tap Set.
.
To set the time manually
1
From the Home screen, tap
2
Find and tap Settings > Date & time.
3
Unmark the Automatic checkbox, if it is marked.
4
Tap Set time.
5
Adjust the hour and minute by scrolling up and down.
6
Tap AM to change to PM or vice versa.
7
Tap Set.
If you want to use
To set the time zone
1
From the Home screen, tap
2
Find and tap Settings > Date & time.
3
Unmark the Automatic checkbox, if it is marked.
4
Tap Select time zone.
5
Select an option.
To set the date format
1
From your Home screen, tap
2
Find and tap Settings > Date & time > Select date format.
3
Select an option.
AM and PM, you have to unmark Use 24-hour format.
.
.
.
Ringtone settings
To set a phone ringtone
1
From your Home screen, tap
2
Find and tap Settings > Sound > Phone ringtone.
3
Select a ringtone.
4
Tap Done.
This is an Internet version of this publication. © Print only for private use.
.
28
To enable touch tones
1
From your Home screen, tap .
2
Find and tap Settings > Sound.
3
Mark the Audible touch tones and Audible selection checkboxes.
To select a notification ringtone
1
From your Home screen, tap
2
Find and tap Settings > Sound > Notification ringtone.
3
Select a ringtone.
4
Tap Done.
.
To set a vibrating alert
1
From your Home screen, tap .
2
Find and tap Settings > Sound.
3
Select Vibrate and choose an option.
Screen settings
To adjust the screen brightness
1
From your Home screen, tap
2
Find and tap Settings > Display > Brightness.
3
To decrease the screen brightness, drag the slider to the left. To increase it, drag
the slider to the right.
4
Tap OK.
.
The brightness level affects your battery performance. For tips on how to improve battery
performance, see Battery performance on page 30.
To set the screen to vibrate
1
From your Home screen, tap .
2
Find and tap Settings > Sound.
3
Mark the Haptic feedback checkbox. The screen now vibrates when you tap soft
keys and certain applications.
To adjust the idle time before the screen turns off
1
From your Home screen, tap
2
Find and tap Settings > Display > Screen timeout.
3
Select an option.
To turn off the screen quickly, briefly press the power key
.
.
To keep the screen on while charging the phone
1
From the Home screen, tap .
2
Find and tap Settings > Applications > Development.
3
Mark the Stay awake check box.
Phone language
You can select a language to use in your phone.
To change the phone language
1
From your Home screen, tap
2
Find and tap Settings > Language & keyboard > Select language.
3
Select an option.
4
Tap Done.
.
If you choose the wrong language and cannot read the menu texts, find and tap the
icon . Then select the entry beside , and select the first entry in the following menu. You can
then select the language you want.
Settings
29
This is an Internet version of this publication. © Print only for private use.
Airplane mode
In Airplane mode, your phone's network and radio transceivers are turned off to prevent
disturbance to sensitive equipment. However, you can still play games, listen to music,
watch videos and other content, as long as all this content is saved on your memory card.
You can also be notified by alarms, if alarms are activated.
Turning on Airplane mode reduces battery consumption.
To turn on Airplane mode
1
From your Home screen, tap .
2
Find and tap Settings > Wireless & networks.
3
Mark the Airplane mode checkbox.
You can also select Airplane mode from the Phone options menu. To access the Phone
options menu, press and hold the power key .
Battery
Your Android™ phone keeps you connected and updated wherever you are. This affects
the battery life of your phone. Below are some tips on how to prolong battery life while still
staying connected and up to date.
Battery performance
Standby time, a common term when it comes to battery performance, refers to the time during
which the phone is connected to the network and is not being used. The more time your phone
is in standby and not otherwise in operation, the longer the battery lasts.
The following tips can help you improve battery performance:
•
Charge your phone often. This will not affect the lifetime of the battery.
•
Downloading data from the Internet is power consuming. When you're not using the
Internet, you can save power by disabling all data connections over mobile networks. You
can do this from Settings > Wireless & networks > Mobile networks. This setting does
not prevent your phone from transmitting data over other wireless networks.
•
Turn off GPS, Bluetooth™ and Wi-Fi® when you don't need these features. You can turn
them on and off more easily by adding the Status switch widget to your Home screen. You
do not need to turn off 3G.
•
Set your synchronization applications (used to synchronize your email, calendar, and
contacts), to synchronize manually. You can also synchronize automatically, but increase
the intervals.
•
Check the battery usage menu on the phone to see which applications consume the most
power. Your battery consumes more power when you use video and music streaming
applications such as YouTube™. Some Android Market™ applications also consume more
power.
•
Close and exit applications that you are not using since multitasking affects the battery
performance.
•
Lower the brightness of the screen display.
•
Turn off your phone or use Airplane mode if you are in an area with no network coverage.
Otherwise, your phone repeatedly scans for available networks, and this consumes power.
•
Use a Sony Ericsson original handsfree device to listen to music. This consumes less battery
power than when you listen to music through the phone's loudspeakers.
For more information on how to maximize your battery performance, visit
www.sonyericsson.com/support.
To access the battery usage menu
1
From the Home screen, tap .
2
Find and tap Settings > About phone > Battery use to see which installed
applications consume the most battery power.
30
This is an Internet version of this publication. © Print only for private use.
Loading...
