Sony SRS-XB3 Help Guide
Help Guide
Personal Audio System
SRS-XB3
The following explains how to use this speaker. Select a topic from the navigation pane.
Getting Started
What you can do with the speaker
Parts and controls
Included items
Checking the contents of the box
Power source
Connecting to an AC outlet
Turning the power on
Turning the power off
Using the BLUETOOTH standby function
Charging USB devices such as smartphones
Auto power off function
Switching the auto power off function
Making connections
BLUETOOTH
How to make a wireless connection with BLUETOOTH devices
Pairing and connecting with a BLUETOOTH device
Connecting with a paired BLUETOOTH device
Connecting with an NFC-compatible device by One-touch (NFC)
Disconnecting the NFC-compatible device by One-touch (NFC)
Switching devices by One-touch (NFC)
Pairing and connecting with a computer (Windows 8)
Pairing and connecting with a computer (Windows 7)
Connecting with a paired computer (Windows 8)
Connecting with a paired computer (Windows 7)
Connecting to a portable audio device, etc.
Listening to music
BLUETOOTH device
Listening to music of a device via BLUETOOTH connection
Selecting the wireless playback quality of the speaker
Terminating the BLUETOOTH connection (After use)
Speaker Add function
Listening to music wirelessly with two speakers (Speaker Add function)
Switching between double mode and stereo mode (Speaker Add function)
Terminating the BLUETOOTH connection (After use)
Listening to music of a portable audio device, etc.
Enjoying EXTRA BASS
Phone calls
Receiving a call
Making a call
Button functions for a phone call
Terminating the BLUETOOTH connection (After use)
Information
About the indicators
Notes on use
Precautions
Notes on charging
Notes on water resistant feature
How to care for the speaker when wet
What is BLUETOOTH wireless technology?
What is LDAC?
Trademarks
Customer support websites
Troubleshooting
What can I do to solve a problem?
Power supply
Unable to turn on the speaker or charge the built-in battery
The power suddenly turns off
Sound
No sound/Sound from only one speaker/Low sound level
Distorted sound/Humming or noise in the speaker output
BLUETOOTH
Unable to pair the speaker with a BLUETOOTH device
Unable to connect the speaker to a BLUETOOTH device with One-touch connection (NFC)
Unable to connect a BLUETOOTH device with the speaker in the Speaker Add function
No voice/Low voice from callers
Reset
Using the RESET button
Initializing the speaker
Table Of Contents
TOC-1
Help Guide SRS-XB3 i......................................................................................................................
What you can do with the speaker 1.................................................................................................
Parts and controls 2...........................................................................................................................
Checking the contents of the box 4...................................................................................................
Power source i...................................................................................................................................
Connecting to an AC outlet 5.......................................................................................................
Turning the power on 7................................................................................................................
Turning the power off 8................................................................................................................
Using the BLUETOOTH standby function 9................................................................................
Charging USB devices such as smartphones 11........................................................................
Auto power off function 13...........................................................................................................
Switching the auto power off function 14.....................................................................................
Making connections ii........................................................................................................................
BLUETOOTH ii..................................................................................................................................
How to make a wireless connection with BLUETOOTH devices 15............................................
Pairing and connecting with a BLUETOOTH device 17..............................................................
Connecting with a paired BLUETOOTH device 20......................................................................
Connecting with an NFC-compatible device by One-touch (NFC) 22.........................................
Disconnecting the NFC-compatible device by One-touch (NFC) 25...........................................
Switching devices by One-touch (NFC) 26..................................................................................
Pairing and connecting with a computer (Windows 8) 27............................................................
Pairing and connecting with a computer (Windows 7) 35............................................................
Connecting with a paired computer (Windows 8) 40...................................................................
Connecting with a paired computer (Windows 7) 45...................................................................
Connecting to a portable audio device, etc. 48.................................................................................
Listening to music ii...........................................................................................................................
BLUETOOTH device ii.......................................................................................................................
Listening to music of a device via BLUETOOTH connection 50.................................................
Selecting the wireless playback quality of the speaker 52..........................................................
Terminating the BLUETOOTH connection (After use) 54...........................................................
Speaker Add function ii......................................................................................................................
Listening to music wirelessly with two speakers (Speaker Add function) 55...............................
Switching between double mode and stereo mode (Speaker Add function) 59..........................
Terminating the BLUETOOTH connection (After use) 54...........................................................
Listening to music of a portable audio device, etc. 61.......................................................................
Enjoying EXTRA BASS 63................................................................................................................
Phone calls ii.....................................................................................................................................
Receiving a call 64............................................................................................................................
Making a call 67.................................................................................................................................
TOC-2
Button functions for a phone call 70..................................................................................................
Terminating the BLUETOOTH connection (After use) 54.................................................................
Information iii.....................................................................................................................................
About the indicators 71......................................................................................................................
Notes on use iii..................................................................................................................................
Precautions 73.............................................................................................................................
Notes on charging 75..................................................................................................................
Notes on water resistant feature 76.............................................................................................
How to care for the speaker when wet 78...................................................................................
What is BLUETOOTH wireless technology? 79..........................................................................
What is LDAC? 81.......................................................................................................................
Trademarks 82..................................................................................................................................
Customer support websites 83..........................................................................................................
Troubleshooting iii.............................................................................................................................
What can I do to solve a problem? 84...............................................................................................
Power supply iii..................................................................................................................................
Unable to turn on the speaker or charge the built-in battery 85..................................................
The power suddenly turns off 86.................................................................................................
Sound iii.............................................................................................................................................
No sound/Sound from only one speaker/Low sound level 87.....................................................
Distorted sound/Humming or noise in the speaker output 88......................................................
BLUETOOTH iii.................................................................................................................................
Unable to pair the speaker with a BLUETOOTH device 89.........................................................
Unable to connect the speaker to a BLUETOOTH device with One-touch
connection (NFC) 90...................................................................................................................
Unable to connect a BLUETOOTH device with the speaker in the Speaker
Add function 91............................................................................................................................
No voice/Low voice from callers 92.............................................................................................
Reset iii..............................................................................................................................................
Using the RESET button 93........................................................................................................
Initializing the speaker 94............................................................................................................
Help Guide
1
Personal Audio System
SRS-XB3
What you can do with the speaker
One-touch connection (NFC)
BLUETOOTH Ver. 3.0
Compatible BLUETOOTH profiles
By connecting the speaker with a smartphone via BLUETOOTH, you can talk hands-free using the built-in microphone and
speaker.
“Noise suppression” and “Echo cancellation” enable phone calls with high-quality sound.
Noise suppression: Noise picked up by the speaker is suppressed, so the caller will hear your voice with less noise.
Echo cancellation: By reducing sound from the speaker picked up by the speaker microphone, echoes generated by the
caller’s phone will be suppressed.
You can enjoy up to about 24 hours
battery.
BLUETOOTH standby function
External input jack: AUDIO IN
Charging the speaker by connecting the AC adaptor supplied
By connecting two SRS-XB3 speakers via BLUETOOTH, you can play audio in either stereo mode (stereo sound) or double
mode.
You can charge a USB device such as smartphone by connecting it to the DC OUT ONLY port (USB) of the speaker via USB
cable.
You can orient the speaker into a vertical position.
The speaker has a water resistant specification
the IEC60529 “Ingress Protection Rating (IP Code).”
*1
: A2DP, AVRCP, HFP, HSP
*2*3
of continuous wireless music playback with the built-in lithium ion rechargeable
*4*5
of IPX5*6 as specified in “Degrees of protection against ingress of water” of
*1
BLUETOOTH standard profiles indicate the purpose of BLUETOOTH communication between devices.
*2
The battery life may vary depending on the ambient temperature or conditions of use. The method of estimating the battery life has been changed since
2015.
*3
When the specified music source is used and the volume level of the speaker is set to 10. If the volume level of the speaker is set to maximum, the
usage life will be approx. 4 hours. Time may vary, depending on the temperature or conditions of use.
*4
Requires that the cap is fastened securely.
*5
The supplied accessories are not water resistant.
*6
IPX5 (Degree of protection against jets of water): The system has been tested and found to remain functional after exposure to direct jet streams of
water using a nozzle of 6.3 mm (about 1/4 in) internal diameter from any direction where approximately 12.5 L/ min of water is applied for a period of
more than 3 minutes from a distance of about 3 meters (about 10 ft).
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
2
Personal Audio System
SRS-XB3
Parts and controls
(power) button/indicator
1.
CHARGE indicator
2.
–/+ (volume) buttons
3.
4.
5.
6.
(call) button
EXTRA BASS button/indicator
(BLUETOOTH) PAIRING button/indicator
ADD button
7.
L (left)/R (right) indicators
3
8.
N-mark
9.
Microphone
10
Cap
11
.
AUDIO IN jack
12
.
RESET button
13
.
DC IN 15V jack
14
.
DC OUT ONLY port (USB)
15
.
.
Related Topic
About the indicators
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
4
Personal Audio System
SRS-XB3
Checking the contents of the box
After opening the package, check that all items in the list below are included in the package.
If any items are missing, contact your dealer.
Personal audio system (SRS-XB3)
AC adaptor
Plug (depending on your region/country)
Operating Instructions
Provides you with instructions on how to connect the speaker with BLUETOOTH devices and basic operations.
Reference Guide
Provides you with precautions and product specifications.
Warranty card (depending on your region/country)
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
5
Personal Audio System
SRS-XB3
Connecting to an AC outlet
The speaker can be operated by connecting it to an AC outlet via AC adaptor (supplied) or built-in battery (rechargeable).
Before using the speaker for the first time, be sure to charge the battery by connecting the speaker to an AC outlet via the
supplied AC adaptor.
You can operate the speaker by battery instead of the AC adaptor by charging the speaker before use.
Connect the supplied AC adaptor to the DC IN 15V jack.
1
Plug the AC adaptor to an AC outlet.
2
Charging starts and the CHARGE indicator lights up in orange. Charging is completed in about four hours*1 and the indicator
turns off. Once the battery is fully charged, it will not be charged furthermore even if the speaker is kept connected to an AC
outlet.
*1
Time that is required to charge the empty battery to its full capacity.
Battery life (when using the BLUETOOTH connection)
About 24 hours
The time stated above may vary depending on ambient temperature or conditions of use.
*2
The method of estimating the battery life has been changed since 2015.
*3
When the specified music source is used and the volume level of the speaker is set to 10. If the volume level of the speaker is set to maximum, the
usage life will be approx. 4 hours. Time may vary, depending on the temperature or conditions of use.
*2*3
.
When the battery is running low
When the CHARGE indicator flashes slowly in orange, the battery is running low and needs to be charged. In this state, the
speaker cannot supply power to other devices.
6
If the CHARGE indicator flashes three times in orange and turns off when you turn on the speaker, the battery is empty and
needs to be charged.
Note
When you switch the power source between an AC outlet and battery by connecting/disconnecting the AC adaptor, the speaker may stop sound
output for a short while. This is not a malfunction.
In an extremely cold or hot environment, charging stops for safety. If charging takes a long time, it also makes charging of the speaker stop. In
these conditions, the CHARGE indicator keeps flashing in orange quickly, but this is not a malfunction. To resolve these issues, unplug the AC
adaptor and plug it in again within the operating temperature of between 5 °C and 35 °C (41 °F and 95 °F).
Even if you do not intend to use the speaker for a long time, charge the battery to its full capacity once every six months to maintain its
performance.
Related Topic
Turning the power on
Notes on charging
Enjoying EXTRA BASS
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
7
Personal Audio System
SRS-XB3
Turning the power on
Press the (power) button.
1
(power) indicator lights up in green.
The
Hint
When you turn on the speaker for the first time after purchase, the EXTRA BASS function is on, and the indicator on the EXTRA BASS button
lights up in white.
Note
If the CHARGE indicator flashes three times in orange and turns off when you turn on the speaker, the battery is empty and needs to be charged.
When the CHARGE indicator flashes slowly in orange, the battery is running low and needs to be charged. In this state, the speaker cannot supply
power to other devices.
Related Topic
Turning the power off
Connecting to an AC outlet
Enjoying EXTRA BASS
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
8
Personal Audio System
SRS-XB3
Turning the power off
Press the (power) button.
1
(power) indicator turns off.
The
Hint
When you turn off the speaker while the BLUETOOTH standby function is on, the (power) indicator lights up in orange and the speaker enters
the BLUETOOTH standby mode.
Related Topic
Auto power off function
Using the BLUETOOTH standby function
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
9
Personal Audio System
SRS-XB3
Using the BLUETOOTH standby function
When the BLUETOOTH standby function is turned on, the speaker turns on automatically by operating a BLUETOOTH device,
and starts the BLUETOOTH connection.
Before operating the speaker, note the following:
The BLUETOOTH standby function can be set only when the speaker is connected to an AC outlet via the AC adaptor. When
the speaker is being powered by the built-in battery only, the BLUETOOTH standby function is not available.
If pairing information is not stored in the speaker, such is the case when the speaker is used for the first time after purchase,
the speaker will not enter the BLUETOOTH standby mode.
Connect the speaker to the AC outlet.
1
Turn on the speaker.
2
The
(power) indicator lights up in green.
Press and hold the
3
orange.
The speaker turns off and enters the BLUETOOTH standby mode.
When the speaker is accessed by a BLUETOOTH device, the speaker turns on automatically and starts the BLUETOOTH
connection.
(power) button for at least four seconds until the (power) indicator lights up in
To turn off the BLUETOOTH standby function
Perform step 1 to 2 above again and press and hold the (power) button over four seconds until the (power) indicator turns
off. The BLUETOOTH standby function is turned off and the speaker will turn off.
Hint
10
The (power) indicator lights up in orange while the speaker is turned off when the BLUETOOTH standby function is activated.
Related Topic
Connecting to an AC outlet
Turning the power on
How to make a wireless connection with BLUETOOTH devices
About the indicators
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
11
Personal Audio System
SRS-XB3
Charging USB devices such as smartphones
You can charge a USB device, such as a smartphone, by connecting it to the speaker with a USB cable (not supplied). Even if
the speaker is not connected to an AC outlet, its built-in battery can supply power to a USB device.
Connect a USB device such as a smartphone to the DC OUT ONLY port (USB) using a USB cable (not
1
supplied).
When you connect the speaker to an AC outlet via the AC adaptor (supplied), the connected USB device starts to be
charged automatically.
If the speaker is being powered by the built-in battery only, proceed to step 2.
Turn on the speaker.
2
The
(power) indicator lights up in green and the USB device starts to be charged.
Note
If the speaker is being powered by the built-in battery only, charging of the connected USB device will stop when the speaker turns off.
When the CHARGE indicator flashes slowly in orange, the battery is running low and needs to be charged. In this state, the speaker cannot supply
power to other devices.
Music playback is not available with a USB cable.
12
Related Topic
Connecting to an AC outlet
Turning the power on
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
13
Personal Audio System
SRS-XB3
Auto power off function
If the speaker satisfies the following conditions for 15 minutes, it turns off automatically.
When the speaker is in BLUETOOTH mode
No operation on the speaker.
No BLUETOOTH connection has been established between the speaker and a smartphone or mobile phone via HFP/HSP.
HFP and HSP are types of BLUETOOTH profiles.
HSP (Headset Profile): Allows calling/cellular phone operation.
HFP (Hands-Free Profile): Allows hands-free calling/cellular phone operation.
No music (sound) is played when the speaker is connected to a BLUETOOTH device.
When the speaker is in AUDIO IN mode
No operation on the speaker.
No music (sound) is played on an audio device connected to the AUDIO IN jack or the music (sound) of an audio device
connected to the AUDIO IN jack is too small.
No BLUETOOTH device is connected to the speaker via HFP/HSP.
Note
The speaker turns off automatically if it satisfies the conditions above for 15 minutes, even if the speaker is charging a USB device that is
connected to the DC OUT ONLY port (USB). If the speaker is being powered by the built-in battery only, charging will stop when the speaker turns
off.
Related Topic
Switching the auto power off function
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
14
Personal Audio System
SRS-XB3
Switching the auto power off function
You can switch the auto power off function on/off. At the time of purchase, the setting is on.
Connect the speaker to the AC adaptor, and turn off the power.
1
Press and hold the + button and the – button at the same time for at least five seconds.
2
When the auto power off function switches to off, the
When the function switches to on, the
Related Topic
Auto power off function
(BLUETOOTH) indicator flashes twice in white.
(BLUETOOTH) indicator flashes three times in white.
Help Guide
15
Personal Audio System
SRS-XB3
How to make a wireless connection with BLUETOOTH devices
You can enjoy music and hands-free calling with the speaker wirelessly by using your device’s BLUETOOTH function.
Before operating the speaker, be sure to do the following:
Place the BLUETOOTH device within 1 m (3 ft) of the speaker.
Connect the speaker to an AC outlet or charge the battery sufficiently.
Stop playback on a BLUETOOTH device to avoid sudden loud sound output from the speaker.
Prepare the operating instructions supplied with the BLUETOOTH device for reference.
Pairing the speaker with a BLUETOOTH device
Pairing is the process required to mutually register the information on BLUETOOTH devices to be connected wirelessly.
It is necessary to pair a device with the speaker to be able to make a BLUETOOTH connection for the first time.
Select your situation from the following two connecting patterns. The method is the same, even when pairing a second device or
more.
Pairing and connecting with a BLUETOOTH device
Connecting with an NFC-compatible device by One-touch (NFC)
Connecting the speaker with the paired device
Once the BLUETOOTH devices are paired, there is no need to pair them again. To connect a device already paired, refer to the
following topic.
Connecting with a paired BLUETOOTH device
Connecting the speaker with an NFC-compatible device by One-touch (NFC)
By touching the speaker with an NFC-compatible device such as a smartphone or Walkman,etc., the speaker is turned on
automatically and then proceeds to pairing and making a BLUETOOTH connection. For details, refer to the following topics.
Connecting with an NFC-compatible device by One-touch (NFC)
Disconnecting the NFC-compatible device by One-touch (NFC)
Switching devices by One-touch (NFC)
Compatible smartphones
NFC-compatible smartphones with Android 2.3.3 or later installed
Compatible Walkman models
NFC-compatible Walkman models*
*
Even if your Walkman is compatible with the NFC function, it may not be able to make a BLUETOOTH connection with the speaker by one touch. For
details on the compatible models, refer to the operating instructions supplied with your Walkman.
16
NFC
NFC (Near Field Communication) is a technology enabling short-range wireless communication between various devices,
such as smartphones and IC tags.
Thanks to the NFC function, data communication - for example, BLUETOOTH pairing - can be achieved easily by simply
touching NFC-compatible devices together (i.e., at the N-mark symbol or location designated on each device).
Note
Once the BLUETOOTH devices are paired, there is no need to pair them again, except in the following cases:
Pairing information has been deleted after repair, etc.
The speaker is already paired with eight devices and another device is to be paired.
The speaker can be paired with up to eight devices. If a new device is paired after eight devices have already been paired, the paired device
with the oldest connection time is replaced by the new one.
When the pairing information of the speaker has been deleted from the BLUETOOTH device.
When the speaker is initialized, all pairing information is deleted.
The speaker can be paired with multiple devices, but can only play music from one paired device at a time.
When an audio cable is connected to the speaker’s AUDIO IN jack while the speaker and the BLUETOOTH device have been connected via
BLUETOOTH connection, sound from the BLUETOOTH-connected device is not output from the speaker (the hands-free function is available). To
listen to music from the BLUETOOTH device, disconnect the audio cable from the speaker's AUDIO IN jack.
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
17
Personal Audio System
SRS-XB3
Pairing and connecting with a BLUETOOTH device
The speaker can be paired with up to eight BLUETOOTH devices.
When pairing with two or more BLUETOOTH devices, perform the following pairing procedure for each device.
Before operating the speaker, be sure to do the following:
Place the BLUETOOTH device within 1 m (3 ft) of the speaker.
Connect the speaker to the AC outlet or charge the battery sufficiently.
Stop playback on a BLUETOOTH device to avoid sudden loud sound output from the speaker.
Prepare the operating instructions supplied with the BLUETOOTH device for reference.
Turn on the speaker.
1
(power) indicator lights up in green.
The
The
(BLUETOOTH) indicator begins to flash in white.
When you turn on the speaker for the first time after purchase, the (BLUETOOTH) indicator will begin to flash quickly
in white and the speaker enters pairing mode automatically by just turning on the speaker. Proceed to step 3.
When you turn on the speaker, the speaker tries to make a BLUETOOTH connection with the last connected
BLUETOOTH device. If the device is nearby and its BLUETOOTH function is on, the BLUETOOTH connection is
established automatically and the
device, terminate the current BLUETOOTH connection by operating the currently connected BLUETOOTH device.
Press and hold the
2
(BLUETOOTH) indicator begins to flash quickly in white.
The speaker enters pairing mode.
(BLUETOOTH) PAIRING button until you hear beeps and the
(BLUETOOTH) indicator stays lit. When you want to connect another BLUETOOTH
Perform the pairing procedure on the BLUETOOTH device to detect the speaker.
18
3
When a list of detected devices appears on the display of the BLUETOOTH device, select “SRS-XB3.”
If a passkey* is required on the display of the BLUETOOTH device, enter “0000.”
*
A passkey may be called “Passcode”, “PIN code”, “PIN number” or “Password.”
Make the BLUETOOTH connection from the BLUETOOTH device.
4
When the BLUETOOTH connection is established, the
(BLUETOOTH) indicator stays lit.
If the BLUETOOTH connection is not established, repeat from step 2.
Hint
For details on operating a BLUETOOTH device, refer to the operating instructions supplied with the BLUETOOTH device.
Note
The pairing mode of the speaker is released after about 5 minutes and the (BLUETOOTH) indicator flashes slowly. However, when pairing
information is not stored in the speaker, such as at the factory settings, the pairing mode is not released. If the pairing mode is released before
finishing the process, repeat from step 2.
When pairing with a BLUETOOTH device that cannot display a list of detected devices or that has no display, you may be able to pair the device
by setting both the speaker and the BLUETOOTH device to pairing mode. At this time, if a passkey besides “0000” is set on the BLUETOOTH
device, pairing cannot be done with the speaker.
Once the BLUETOOTH devices are paired, there is no need to pair them again, except in the following cases:
Pairing information has been deleted after repair, etc.
19
The speaker is already paired with eight devices and another device is to be paired.
The speaker can be paired with up to eight devices. If a new device is paired after eight devices have already been paired, the paired device
with the oldest connection time is replaced by the new one.
When the pairing information of the speaker has been deleted from the BLUETOOTH device.
When the speaker is initialized, all the pairing information is deleted.
The speaker can be paired with multiple devices, but can only play music from one paired device at a time.
When an audio cable is connected to the speaker’s AUDIO IN jack while the speaker and the BLUETOOTH device have been connected via
BLUETOOTH connection, sound from the BLUETOOTH-connected device is not output from the speaker (the hands-free function is available). To
listen to music from the BLUETOOTH device, disconnect the audio cable from the speaker's AUDIO IN jack.
Related Topic
Connecting with a paired BLUETOOTH device
Listening to music of a device via BLUETOOTH connection
Terminating the BLUETOOTH connection (After use)
Listening to music wirelessly with two speakers (Speaker Add function)
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
20
Personal Audio System
SRS-XB3
Connecting with a paired BLUETOOTH device
Check the following before you operate the speaker.
If the speaker was previously paired with a different device, turn off the BLUETOOTH function for the other device.
Turn on the speaker.
1
(power) indicator lights up in green.
The
The
(BLUETOOTH) indicator begins to flash in white.
When you turn on the speaker, the speaker tries to make a BLUETOOTH connection with the last connected BLUETOOTH
device. If the device is nearby and its BLUETOOTH function is on, the BLUETOOTH connection is established automatically
and the
BLUETOOTH connection by operating the currently connected BLUETOOTH device.
Make the BLUETOOTH connection from the BLUETOOTH device.
2
When the BLUETOOTH connection is established, the
(BLUETOOTH) indicator stays lit. When you want to connect another BLUETOOTH device, terminate the current
(BLUETOOTH) indicator stays lit.
Hint
21
If the devices cannot connect, enter pairing mode to connect.
(The speaker can be paired with up to eight devices. If the speaker is paired with multiple devices, it is necessary to enter pairing mode to
connect.)
When the BLUETOOTH standby function is turned on, the speaker turns on automatically by operating a BLUETOOTH device, and starts the
BLUETOOTH connection.
Note
When the speaker made a connection automatically with the last connected BLUETOOTH device, the BLUETOOTH function may not work
properly. In this case, terminate the BLUETOOTH connection by operating the connected BLUETOOTH device and reestablish a connection.
When an audio cable is connected to the speaker’s AUDIO IN jack while the speaker and the BLUETOOTH device have been connected via a
BLUETOOTH connection, sound from the BLUETOOTH-connected device is not output from the speaker (the hands-free function is available). To
listen to music from the BLUETOOTH device, disconnect the audio cable from the speaker's AUDIO IN jack.
Related Topic
Pairing and connecting with a BLUETOOTH device
Listening to music of a device via BLUETOOTH connection
Terminating the BLUETOOTH connection (After use)
4-587-623-11(2) Copyright 2016 Sony Corporation
Help Guide
22
Personal Audio System
SRS-XB3
Connecting with an NFC-compatible device by One - touch ( NFC)
By touching the speaker with an NFC-compatible device such as a smartphone, the speaker turns on automatically, then
proceeds to pairing and BLUETOOTH connection.
Compatible smartphones
NFC-compatible smartphones with Android 2.3.3 or later installed
Compatible Walkman models
NFC-compatible Walkman models
*1
Even if your Walkman is compatible with the NFC function, it may not be able to make a BLUETOOTH connection with the speaker by One-touch. For
details on the compatible models, refer to the operating instructions supplied with your Walkman.
NFC
NFC (Near Field Communication) is a technology enabling short-range wireless communication between various devices,
such as smartphones and IC tags.
Thanks to the NFC function, data communication - for example, BLUETOOTH pairing - can be achieved easily by simply
touching NFC-compatible devices together (i.e., at the N-mark symbol or location designated on each device).
*1
Set the NFC function of the device to on.
1
For details, refer to the operating instructions supplied with the device.
If your smartphone OS is Android 2.3.3 or later, and less than Android 4.1:
proceed to step 2.
If your smartphone OS is Android 4.1 or later: proceed to step 4.
NFC-compatible Walkman models
*2
The procedures for the NFC settings may vary depending on Walkman models. For details, refer to the operating instructions supplied with your
Walkman.
Download and install the app “NFC Easy Connect” on the smartphone.
2
*2
: proceed to step 4.
“NFC Easy Connect” is a free Android app you can download from Google Play.
Download the app by searching for “NFC Easy Connect” or access it by using the following two-dimensional code. A fee
may be charged to download the app.
To download via the two-dimensional code, a two-dimensional code reader app is required.
Access the following Web site to search for the app:
https://play.google.com/store/apps/details?id=com.sony.easyconnect
Download via the two-dimensional code:
The app may not be downloadable in some countries/regions.
23
Start “NFC Easy Connect” on the smartphone.
3
Make sure that the app screen is displayed.
Touch the speaker with the device.
4
Unlock the screen of the device beforehand.
Keep touching the device on the N marked part of the speaker until the device responds.
If the speaker is off, it will turn on when the device touches it.
Follow the on-screen instructions to establish the connection.
When the BLUETOOTH connection is established,
(BLUETOOTH) indicator stays lit.
To disconnect, touch the speaker with the device again.
Hint
24
If you cannot connect the speaker, try the following.
Start the app on the device and move the device slowly over the N marked part of the speaker.
If the device is in a case, remove the case.
Make sure that the app screen is displayed on the device.
If you touch a device on the speaker, the device terminates the BLUETOOTH connection with the current device (NFC-compatible headset, etc.),
and connects with the speaker (One-touch connection switching).
When using the Speaker Add function, touch the speaker where the
connection with the speaker where the
(BLUETOOTH) indicator is turned off.
Note
When an audio cable is connected to the speaker’s AUDIO IN jack while the speaker and the BLUETOOTH device have been connected via
BLUETOOTH connection, sound from the BLUETOOTH-connected device is not output from the speaker (the hands-free function is available). To
listen to music from the BLUETOOTH device, disconnect the audio cable from the speaker’s AUDIO IN jack.
If your smartphone is a type that goes into standby mode in response to magnetic force, it may not be able to connected by NFC.
Related Topic
Disconnecting the NFC-compatible device by One-touch (NFC)
Switching devices by One-touch (NFC)
Listening to music of a device via BLUETOOTH connection
Listening to music wirelessly with two speakers (Speaker Add function)
4-587-623-11(2) Copyright 2016 Sony Corporation
(BLUETOOTH) indicator is lit. The device cannot make a BLUETOOTH
Help Guide
25
Personal Audio System
SRS-XB3
Disconnecting the NFC-compatible device by One-touch ( NFC)
You can disconnect the speaker from the connected NFC-compatible device such as a smartphone or Walkman, etc. by touching
the speaker with it.
Touch the device on the N marked part of the speaker.
1
Hint
After the speaker is disconnected from the device by One-touch, if no operation is performed and no sound is input for 15 minutes, the speaker
turns off automatically by the auto power off function.
If you cannot disconnect the speaker, try the following.
Start the app on the device, and move the device slowly over the N marked part of the speaker.
If the device is in a case, remove the case.
Make sure that the app screen is displayed on the device.
When using the Speaker Add function, touch the speaker where the
touching the speaker where the
4-587-623-11(2) Copyright 2016 Sony Corporation
(BLUETOOTH) indicator is lit. The device cannot be disconnected if
(BLUETOOTH) indicator is turned off.
Loading...
