Sony RDR-HXD562, RDR-HXD560 User Manual

Page 1

2-686-265-11(1)

DVD Recorder

Operating Instructions

To find out useful hints, tips and information about Sony products and services please visit: www.sony-europe.com/myproduct

RDR-HXD560/HXD562

Page 2

WARNING

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer serv icing to qualified personnel only. The mains lead must be changed only at a qualified service shop.

This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the laser protective housing inside the enclosure.

CAUTION

The use of optical instruments with this product will increase eye hazard. As the laser beam used in this DVD recorder is harmful to eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only.

This label is located on the laser protective housing inside the enclosure.

Notice for customers in the United Kingdom and Republic of Ireland

A molded plug complying with BS1363 is fitted to this equipment for your safety and convenience. Should the fuse in the plug supplied need to be replaced, a 5 AMP fuse approved by ASTA or BSI to BS1362, (i.e., marked with

or mark) must be used. If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.

Precautions

• This unit operates on 220 – 240 V AC, 50/60 Hz. Check that the unit’s operating voltage is identical with your local power supply.

• To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus.

• Install this system so that the mains lead can be unplugged from the wall socket immediately in the event of trouble.

Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Precautions

This equipment has been tested and found to comply with the limits set out in the EMC Directive using a connection cable shorter than 3 metres.

On safety

Should any solid object or liquid fall into the cabinet, unplug the recorder and have it checked by qualified personnel before operating it any further.

About the hard disk drive

The hard disk has a high storage density, which enables long recording durations and quick access to the written data. However, it can easily be damaged by shock, vibration or dust, and should be kept away from magnets. To avoid losing important data, observe the following precautions.

• Do not apply a strong shock to the recorder.

• Do not place the recorder in a location subject to mechanical vibrations or in an unstable location.

• Do not place the recorder on top of a hot surface, such as a VCR or amplifier (receiver).

• Do not use the recorder in a place subject to extreme changes in temperature (temperature gradient le ss than 10 °C/hour).

• Do not move the recorder with its mains lead connected.

• Do not disconnect the mains lead while the power is on.

• When disconnecting the mains lead, turn off the power and make sure that the hard disk drive is not operating (the clock is displayed in the front panel display for at least 30 seconds and all recording or dubbing has stopped).

Page 3

• Do not move the recorder for one minute after you have unplugged the mains lead.

• Do not attempt to replace or upgrade the hard disk by yourself, as this may result in malfunction.

If the hard disk drive should malfunction, you ca nnot recover lost data. The hard disk drive is only a temporary storage space.

About repairing the hard disk drive

• The contents of the hard disk drive may be checked in case of repair or inspectio n during a malfunction or modification. However, the contents wil l not be backed up or saved by Sony.

• If the hard disk needs to be formatted or replaced, it will be done at the discretion of Sony. All contents of the hard disk drive will be erased, including contents that violate copyright laws.

On power sources

• The recorder is not disconnected from the AC power source (mains) as long as it is connected to the wall outlet, even if the recorder itself has been turned off.

• If you are not going to use the recorder for a long time, be sure to dis connect the recorder from the wall outlet. To disconnect the AC power cord (mains lead), grasp the plug itself; never pull the cord.

On placement

• Place the recorder in a location with adequate ventilation to prevent heat build-up in the recorder.

• Do not place the recorder on a soft surface such as a rug that might block the ventilation holes.

• Do not place the recorder in a confined space such as a bookshelf or similar unit.

• Do not place the recorder in a location near heat sources, or in a place subject to direct sunlight, excessive dust, or mechanical shock.

• Do not place the recorder in an inclined position. It is designed to be operated in a horizontal position only.

• Keep the recorder and discs away from equipment with strong magnets, such as microwave ovens, or large loudspeakers.

• Do not place heavy objects on the recorder.

On recording

Make trial recordings before making the actual recording.

On compensation for lost recordings

Sony is not liable and will not compensate for any lost recordings or relevant losses, including when recordings are not made due to reasons including recorder failure, or when the contents of a recording are lost or damaged as a result of recorder failure or repair undertaken to the recorder. Sony will not restore, recover, or replicate the recorded contents under any circumstances.

Copyrights

• Television programmes, films, video tapes, discs, and other materials may be copyrighted. Unauthorized recording of such material may be contrary to the provisions of the copyright laws. Also, use of this recorder with cable television transmission may require authorization from the cable television transmitter and/or programme owner.

• This product incorporates copyright protection technology that is protecte d by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Copy guard function

Since the recorder has a copy guard function, programmes received through an external tuner (not supplied) may contain copy protection signals (copy guard function) and as such may not be recordable, depending on the type of signal.

IMPORTANT NOTICE

Caution: This recorder is capable of holding a still video image or on-screen display image on your television screen indefinitely. If you leave the still video image or onscreen display image displayed on your TV for an extended period of time you risk permanent damage to your television screen. Plasma display panels and projection televisions are especially susceptible to this.

If you have any questions or problems concerning your recorder, please consult your nearest Sony dealer.

,continued

Page 4

About this manual

Check your model name

The instructions in this manual are for 2 models: RDR-HXD560 and RDRHXD562. Check your model name by looking at the front panel of the recorder.

• In this manual, the internal hard disk drive is written as “HDD,” and “disc” is used as a general reference for the HDD, DVDs, or CDs unless otherwise specified by the text or illustrations.

• Icons, such as , listed at the top of each explanation indicate what kind of media can be used with the function being explained.

• Instructions in this manual describe the controls on the remote. You can also use the controls on the recorder if they have the same or similar names as those on the remote.

• The on-screen display illustrations used in this manual may not match the graphics displaye d on your TV screen.

• The explanations regarding DVDs in this manual refer to DVDs cre ated on this r ecorder. The explanations do not apply to DVDs that are created on other recorders and played back on this recorder.

DVD

Page 5

Table of Contents

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Quick Guide to Disc Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Recordable and playable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Playable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Hookups and Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Hooking Up the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Step 1: Connecting the Aerial Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Step 2: Connecting the Video Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

About the SMARTLINK features (for SCART connections only). . . . . . . 14

Step 3: Connecting the Audio Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Step 4: Connecting the Mains Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Step 5: Preparing the Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Controlling TVs with the remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

If you have a Sony DVD player or more than one Sony DVD recorder

Changing programme positions of the recorder using the remote . . . . . 19

Step 6: Easy Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Connecting a VCR or Similar Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Connecting to the LINE 3 jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Connecting to the LINE 2 IN jacks on the front panel . . . . . . . . . . . . . . . 22

Connecting to a Satellite or Digital Tuner . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Eight Basic Operations — Getting to Know Your DVD Recorder

1. Inserting a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

2. Recording a Programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Checking the disc status while recording . . . . . . . . . . . . . . . . . . . . . . . . 25

3. Playing the Recorded Programme (Title List) . . . . . . . . . . . . . . . . . . . . . . 26

4. Displaying the Playing/Remaining Time and Play Information . . . . . . . . . 28

Checking the playing/remaining time. . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Checking the remaining disc space. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5. Changing the Name of a Recorded Programme . . . . . . . . . . . . . . . . . . . 31

6. Labelling and Protecting a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Labelling a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Protecting a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

7. Playing the Disc on Other DVD Equipment (Finalise) . . . . . . . . . . . . . . .33

Finalising the disc using Z (open/close) button . . . . . . . . . . . . . . . . . . . 34

Finalising the disc using “Disc Information” display. . . . . . . . . . . . . . . . .34

Unfinalising a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

8. Reformatting a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

. . . . 18

Guide to Digital Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

EPG (Electronic Programme Guide) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Viewing a list of available channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Viewing programmes related to a specific category . . . . . . . . . . . . . . . .38

Programme information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Displaying the programme information . . . . . . . . . . . . . . . . . . . . . . . . . . 39

,continued

Page 6

Viewing a digital text service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Selecting digital text from dedicated digital teletext channels. . . . . . . . . 40

Selecting digital text from other channels . . . . . . . . . . . . . . . . . . . . . . . . 41

Favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Setting the Favourites List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Watching or listening to a favourite channel . . . . . . . . . . . . . . . . . . . . . . 42

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Timer Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Before Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Recording mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Unrecordable pictures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Timer Recording (Standard/EPG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Setting the timer manually (Standard). . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Recording TV programmes using the EPG. . . . . . . . . . . . . . . . . . . . . . . 48

Recording programmes using Series Recording . . . . . . . . . . . . . . . . . . 49

Using the Quick Timer function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Adjusting the recording picture quality and size . . . . . . . . . . . . . . . . . . . 51

Creating chapters in a title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Checking/Changing/Cancelling Timer Settings . . . . . . . . . . . . . . . . . . . . . . 52

Checking/Changing/Cancelling using the EPG. . . . . . . . . . . . . . . . . . . . 52

Checking/Changing/Cancelling using the Timer List. . . . . . . . . . . . . . . . 53

Recording From Connected Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Recording from connected equipment with a timer (Synchro Rec) . . . . . 55

Recording from connected equipment without a timer . . . . . . . . . . . . . . 57

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Playing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Playback options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Adjusting the picture quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Adjusting the delay between the picture and sound (AV SYNC) . . . . . . 62

Pausing a TV Broadcast (TV Pause) . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Playing from the beginning of the programme you are recording

(Chasing Playback). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Playing a previous recording while making another

(Simultaneous Rec and Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Searching for a Title/Chapter/Track, etc. . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Playing MP3 Audio Tracks or JPEG Image Files . . . . . . . . . . . . . . . . . . . . . 65

About MP3 audio tracks and JPEG image files . . . . . . . . . . . . . . . . . . . 66

MP3 audio tracks or JPEG image files that the recorder can play . . . . . 66

About playback order of albums, tracks, and files. . . . . . . . . . . . . . . . . . 67

Erasing and Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

Before Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Erasing and Editing a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Erasing multiple titles (Erase Titles) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Erasing a section of a title (A-B Erase) . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Dividing a title (Divide) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Creating chapters manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Page 7

Creating and Editing a Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

Moving a Playlist title (Change Order). . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Combining multiple Playlist titles (Combine) . . . . . . . . . . . . . . . . . . . . . . 74

Dividing a Playlist title (Divide) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Dubbing (HDD y DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Before Dubbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

About “Dub Mode” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Dubbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79

Dubbing a single title (Title Dubbing). . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Dubbing multiple titles (Dub Selected Titles). . . . . . . . . . . . . . . . . . . . . .80

DV Dubbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82

Before DV Dubbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82

Preparing for DV dubbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Recording an Entire DV Format Tape (One Touch Dubbing) . . . . . . . . . . . . 84

Program Edit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Settings and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Clock and Language Settings (Basic) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Language. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Digital TV settings (DTV Settings) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88

Favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88

Parental Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

Technical Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

Video Settings (Video) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Audio Settings (Audio) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Recording Settings (Recording) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

Disc Settings (DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98

Remote Control Settings/Factory Settings (Others) . . . . . . . . . . . . . . . . . .100

Easy Setup (Resetting the Recorder) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102

Self-diagnosis Function (When letters/numbers appear in the display) . . . 108

Notes About This Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110

About i.LINK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Guide to Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112

Language Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Area Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Page 8

Quick Guide to Disc Types

Recordable and playable discs

Type Disc Logo

Hard disk drive (internal)

DVD+RW

VR mode

DVDRW

Video mode

DVD+R

DVD+R DL

Icon used in this manual

HDD

RWVR

Video

Formatting (new discs)

Formatting unnecessary

Automatically formatted in +VR mode (DVD+RW VIDEO)

Format in VR mode (page 24)

Format in Video mode (page 24)

Automatically formatted in +VR mode (DVD+R VIDEO)

Compatibility with other DVD players (finalising)

Dub HDD contents to a DVD to play on other DVD players

Playable on DVD+RW compatible players (automatically finalised)

Playable only on VR mode compatible players (finalisation unnecessary)

Playable on most DVD players (finalisation necessary) (page 33)

Format in VR

DVD-R

VR mode

RVR

mode (page 24) Formatting is performed using the “Disc Information”

Playable only on DVD-R in VR mode compatible players (finalisation necessary) (page 33)

display.

Video mode

Automatically

Video

formatted in Video mode

Playable on most DVD players (finalisation necessary) (page 33)

Page 9

Usable disc versions (as of March 2006)

• 8x-speed or slower DVD+RWs

• 6x-speed or slower DVD-RWs (Ver.1.1, Ver.1.2 with CPRM

)

• 16x-speed or slower DVD+Rs

• 16x-speed or slower DVD-Rs (Ver.2.0, Ver.2.1 with CPRM

)

• 8x-speed or slower DVD+R DL (Double Layer) discs

“DVD+RW,” “DVD-RW,” “DVD+R,” “DVD+R DL,” and “DVD-R” are trademarks.

When an unformatted DVD-R is inserted into this recorder, it is automatically formatted in Video mode. To format a new DVD-R in VR mode, format using the “Disc Information” display (page 24).

CPRM (Content Protection for Recordable Media) is a coding technology that protects copyrights for images.

Discs that cannot be recorded on

• 8 cm discs

• DVD-R DL (Dual Layer) discs

• DVD-RAMs

,continued

Page 10

Playable discs

Type Disc Logo

DVD VIDEO

VIDEO CD

DATA DVD —

DATA CD —

8 cm DVD+RW/ DVD-RW/DVD-R

——

Icon used in this manual

DVD

VCD

DATA DVD

DATA CD

Characteristics

Discs such as movies that can be purchased or rented This recorder also recognizes DVDRAMs and DVD-R Dual Layer (Video mode) discs as DVD Video compatible discs. If the DVD-RAM has a removable cartridge, remove the cartridge before playback.

VIDEO CDs or CD-Rs/CD-RWs in VIDEO CD/Super VIDEO CD format

Music CDs or CD-Rs/CD-RWs in music CD format

DVD+RWs/DVD+Rs/DVD-RWs/ DVD-Rs/DVD-ROMs containing JPEG image files

CD-ROMs/CD-Rs/CD-RWs containing either MP3 audio tracks or JPEG image files

8 cm DVD+RW, DVD-RW, and DVD-R recorded with a DVD video camera (Still images recorded with a DVD video camera cannot be played.)

“DVD VIDEO” and “CD” are trademarks.

Discs that cannot be played

• PHOTO CDs

• CD-ROMs/CD-Rs/CD-RWs that are

recorded in a format different from the formats mentioned in the table above.

• Data part of CD-Extras

• DVD-ROMs/DVD+RWs/DVD-RWs/

DVD+Rs/DVD-Rs that do not contain DVD Video or JPEG image files.

• DVD Audio discs

• Cartridge-only type DVD-RAMs and/or

DVD-RAMs that do not contain DVD Video.

• HD layer on Super Audio CDs

• DVD VIDEOs with a different region code (page 11).

• DVDs that were recorded on a different recorder and not correctly finalised.

Page 11

Maximum recordable number of titles

Disc Number of titles*

HDD 300

DVD-RW/DVD-R 99

DVD+RW/DVD+R 49

DVD+R DL 49

* The maximum length for one title is eight hours.

Note on playback operations of DVD VIDEOs/VIDEO CDs

Some playback operations of DVD VIDEOs/ VIDEO CDs may be intentionally set by software producers. Since this recorder plays DVD VIDEOs/VIDEO CDs according to the disc contents the software producers designed, some playback features may not be available. See the instructions supplied with the DVD VIDEOs/VIDEO CDs.

Region code (DVD VIDEO only)

Your recorder has a region code printed on the rear of the unit and will only play DVD VIDEOs (playback only) labelled with identical region codes. This system is used to protect copyrights. DVD VIDEOs labelled will also play

ALL

on this recorder. If you try to play any other DVD VIDEO, the message “Playback prohibited by region code.” will appear on the TV screen. Depending on the DVD VIDEO, no region code indication may be labelled even though playing the DVD VIDEO is prohibited by area restrictions.

Region code

Note on DualDiscs

A DualDisc is a two sided disc product which mates DVD recorded material on one side with digital audio material on the other side. However, since the audio material side does not conform to the Compact Disc (CD) standard, playback on this product is not guaranteed.

b Notes

• Some DVD+RWs/DVD+Rs, DVD-RWs/DVDRs, DVD-RAMs, or CD-RWs/CD-Rs cannot be played on this recorder due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software. The disc will not play if it has not been correctly finalised. For more information, see the operating instructions for the recording device.

• You cannot mix VR mode and Video m ode on the same DVD-RW. To change the disc’s format, reformat the disc (page 35). Note that the disc’s contents will be erased after reformatting.

• You cannot shorten the time required for recording even with high-speed discs.

• It is recommended that you use discs with “For Video” printed on their packaging.

• You cannot add new recordings to DVD+Rs, DVD-Rs, or DVD-RWs (Video mode) that contain recordings made on other DVD equipment.

• In some cases, you may not be able to add new recordings to DVD+RWs that contain recordings made on other DVD equipment. If you do add a new recording, note that this recorder will rewrite the DVD menu.

• You cannot edit recordings on DVD+RWs, DVD-RWs (Video mode), DVD+Rs, or DVD-Rs that are made on other DVD equipment.

• If the disc contains PC data unrecognizable by this recorder, the data may be erased.

• You may not be able to record on some recordable discs, depending on the disc.

Music discs encoded with copyright protection technologies

This product is designed to play back discs that conform to the Compact Disc (CD) standard. Recently, various music discs encoded with copyright protection technologies are being marketed by some record companies. Please be aware that among those discs, there are some that do not conform to the CD standard and may not be playable by this product.

Page 12

Hookups and Settings

Hooking Up the Recorder

Follow steps 1 through 6 to hook up and adjust the settings of the recorder. Do not connect the mains lead until you reach “Step 4: Connecting the Mains Lead” on page 16.

b Notes

• See “Specifications” (page 110) for a list of supplied accessories.

• Plug in cords securely to prevent unwanted noise.

• Refer to the instructions supplied with the components to be connected.

• You cannot connect this recorder to a TV that does not have a SCART or video input jack.

• Be sure to disconnect the mains lead of each component before connecting.

Step 1: Connecting the Aerial Cable

Connect the aerial cable by following the steps below.

to AERIAL IN

to AERIAL OUT

: Signal flow

Aerial cable (supplied)

DVD recorder

1 Disconnect the aerial cable from your TV, and connect it to AERIAL IN on the rear

panel of the recorder.

2 Connect AERIAL OUT of the recorder to the aerial input of your TV using the supplied

aerial cable.

Page 13

Step 2: Connecting the Video Cords

Select one of the following patterns, A through D, according to the input jack on your TV monitor, projector, or AV amplifier (receiver). This will enable you to view pictures.

INPUT

VIDEO

AUDI O

TV, projector, or AV amplifier (receiver)

to LINE 2 OUT (VIDEO)

to LINE 2 OUT (S VIDEO)

S-video cord (not supplied)

INPUT

S VIDEO

TV, projector, or AV amplifier (receiver)

Audio/video cord (not supplied)

SCART cord (not supplied)

(yellow)

(red) (blue)

Component video cord (not supplied)

to i LINE 1 – TV

DVD recorder

(green)

to COMPONENT VIDEO OUT

COMPONENT

VIDEO IN

TV, projector, or AV amplifier (receiver)

B/CB

R/CR

(green)

(blue)

(red)

Hookups and Settings

: Signal flow

A SCART input jack

When you set “Easy Setup - Line1 Output” to “S Video” or “RGB” (page 20), use a SCART cord that conforms to the selected signal.

B Video input jack

About the SMARTLINK features (for SCART connections only)

If the connected TV (or other connected equipment such as a set top box) complies with SMARTLINK, NexTView Link MEGALOGIC CINEMALINK*2, Q-Link*3, EURO VIEW

LINK

, EASYLINK*2,

, or T-V LINK*5, you can enjoy the

following SMARTLINK features.

• TV Direct Rec. You can easily record what you are watching on your TV (page 25).

• One Touch Play You can turn on the recorder and TV, set the TV’s input to the recorder, and start playback with one touch of the H (play) button (page 59).

• One Touch Menu You can turn on the recorder and TV, set the TV to the recorder’s programme position, and display the Title List menu with one touch of the TITLE LIST button (page 59).

• One Touch Timer You can turn on the recorder and TV, set the TV to the recorder’s programme position, and display the timer programming menu with one touch of the TIMER button (page 47).

• One Touch EPG You can turn on the recorder and TV, set the TV to the recorder’s channel, and display the Electronic Programme Guide screen with one touch of the (GUIDE) button (page 37).

• Automatic Power Off The recorder will turn off automatically if the recorder is not used after you turn off the TV.

“MEGALOGIC” is a registered trademark of Grundig Corporation.

“EASYLINK” and “CINEMALINK” are trademarks of Philips Corporation.

“Q-Link” and “NexTView Link” are trademarks of Panasonic Corporation.

“EURO VIEW LINK” is a trademark of Toshiba Corporation.

“T-V LINK” is a trademark of JVC Corporation.

z Hint

SMARTLINK also works with TVs or other equipment having EPG Timer Control, EPG Title Download, and Now Recording functions. For details, refer to the operating instructions supplied with your TV or other equipment.

b Notes

• The SMARTLINK features are available only when “Video” is selected in “Line1 Output.”

• The power must be turned on to use all SMARTLINK features except One Touch Play, One Touch Menu, One Touch Timer and One Touch EPG.

• Not all TVs respond to the functions above.

Page 15

Step 3: Connecting the Audio Cords

Select one of the following patterns, A or B, according to the input jack on your TV monitor, projector, or AV amplifier (receiver). This will enable you to listen to sound.

[Speakers]

Rear (L)

Front (L)

AV amplifier (receiver) with a decoder

[Speakers]

Rear (R)

Front (R)

Hookups and Settings

Centre

to DIGITAL OUT (COAXIAL)

to LINE 2 OUT (R-AUDIO-L)

Audio/video cord

(white)

(red)

(yellow)*

: Signal flow

* The yellow plug is used for video signals (page 13).

(not supplied)

Subwoofer

to coaxial digital input

Coaxial digital cord (not supplied)

DVD recorder

INPUT

(yellow)

(white)

(red)

TV, projector, or AV amplifier (receiver)

VIDEO

AUDIO

A Digital audio input jack

If your AV amplifier (receiver) has a Dolby*1 Digital, DTS

, or MPEG audio decoder and a digital input jack, use this connection. You can enjoy Dolby Digital (5.1ch), DTS (5.1ch), and MPEG audio (5.1ch) surround effects.

B Audio L/R (left/right) input jacks

This connection will use your TV’s or stereo amplifier’s (receiver’s) two speakers for sound.

,continued

Page 16

z Hint

For correct speaker location, see the operating instructions supplied with the connected components.

b Notes

• Do not connect your TV’s audio output jacks to the LINE IN (R-AUDIO-L) jacks at the same time. This will cause unwanted noise to come from your TV’s speakers.

• With connection B, do not connect the LINE IN (R-AUDIO-L) and LINE 2 OUT (R-AUDIO-L) jacks to your TV’s audio output jacks at the same time. This will cause unwanted noise to come from your TV’s speakers.

• With connection A, after you have comple ted the connection, make the appropriate settings under “Easy Setup - Audio Connection” (page 20). Otherwise, no sound or a loud noise will come from your speakers.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Step 4: Connecting the Mains Lead

Connect the supplied mains lead to the AC IN terminal of the recorder. Then plug the recorder and TV mains leads (power cords) into the mains. After you connect the mains lead, you must wait for a short while before operating the recorder. You can operate the recorder once the front panel display lights up and the recorder enters standby mode. If you connect additional equipment to this recorder (page 21), be sure to connect the mains lead after all connections are complete.

~ AC IN

to AC IN

to mains

Page 17

Step 5: Preparing the Remote

You can control the recorder using the supplied remote. Insert two R6 (size AA) batteries by matching the 3 and # ends on the batteries to the markings inside the battery compartment. When using the remote, point it at the remote sensor on the recorder.

b Notes

• If the supplied remote interferes your other Sony DVD recorder or player, change the command mode number for this recorder (page 18).

• Use the batteries correctly to avoid possible leakage and corrosion. Should leakage occur, do not touch the liquid with bare hands. Observe the following: – Do not use a new battery with an old battery, or

batteries of different manufacturers. – Do not attempt to recharge the batteries. – If you do not intend to use the remote for an

extended period of time, remove the batteries. – If battery leakage occurs, wipe out any liquid

inside the battery compartment, and insert new

batteries.

• Do not expose the remote sensor (marked on the front panel) to strong light, such as direct sunlight or a lighting apparatus . The recorder may not respond to the remote.

Controlling TVs with the remote

You can adjust the remote’s signal to control your TV.

b Notes

• Depending on the connected unit, you may not be able to control your TV with some or all of the buttons below.

• If you enter a new code number, the code number previously entered will be erased.

• When you replace the batteries of the remote, the code number may be reset to the default setting. Set the appropriate code number again.

Number buttons

TV 2 +/–

TV/DVD

TV PROG

+/–

TV [/1 TV t

1 Hold down the TV [/1 button located

at the bottom of the remote.

Do not press the [/1 button at the top of the remote.

Hookups and Settings

,continued

Page 18

2 With the TV [/1 button pressed down,

enter the TV’s manufacturer code using the number buttons.

For instance, to enter “09,” press “0” then “9.” After you enter the last number, release the TV [/1 button.

Code numbers of controllable TVs

If more than one code number is listed, try entering them one at a time until you find the one that works with your TV.

Manufacturer Code number

Sony 01 (default)

Grundig 11

Hitachi 24

ITT/Nokia 15, 16

JVC 33

Loewe 45

Nokia 69, 73

Panasonic 17, 49

Philips 06, 07, 08, 72

Saba 12, 13, 74

Samsung 22, 23, 71

Sanyo 25

Sharp 29

Telefunken 36

Thomson 43, 75

Toshiba 38

The remote performs the following:

Buttons Operations

TV [/1 Turns your TV on or

TV 2 (volume) +/–

TV PROG +/– Selects the

TV t Switches your TV’s

off

Adjusts the volume of your TV

programme position on your TV

input source

To operate the TV/DVD button (for SCART connections only)

The TV/DVD button switches between the recorder and the last input source selected on the TV. Point your remote at the recorder when using this button. When you connect the recorder to the TV via the SCART jacks, the input source for the TV is set to the recorder automatically when you start playback. To watch another source, press the TV/DVD button to switch the TV’s input source.

If you have a Sony DVD player or more than one Sony DVD recorder

If the supplied remote interferes with your other Sony DVD recorder or player, set the command mode number for this recorder and the supplied remote to one that differs from the other Sony DVD recorder or player after you have completed “Step 6: Easy Setup.” The default command mode setting for this recorder and the supplied remote is DVD3.

Number buttons

SYSTEM MENU

M/m, ENTER

1 Check that “Easy Setup” (page 20)

has been finished. If “Easy Setup” has not been finished, first perform “Easy Setup.”

2 Press SYSTEM MENU.

The System Menu appears.

Page 19

3 Select “SETUP,” and press ENTER.

4 Select “Others,” and press ENTER.

5 Select “Command Mode,” and press

ENTER.

To check the Command Mode for the recorder

Press x on the recorder when the recorder is turned off. The Command Mode for the recorder appears in the front panel display.

If the Command Mode for the recorder has not been changed, set the Command Mode for the remote to the default setting of DVD3. If the Command Mode for the remote is changed to DVD1 or DVD2, you will be unable to operate this recorder.

Changing programme positions of the recorder using the remote

You can change programme positions of the recorder using the number buttons.

Number buttons

Hookups and Settings

6 Select a Command Mode (DVD1,

DVD2, or DVD3), and press ENTER.

7 Set the Command Mode for the remote

so it matches the Command Mode for the recorder you set above.

Follow the steps below to set the Command Mode on the remote.

1 Hold down ENTER. 2 While holding down ENTER, enter

the Command Mode code number using the number buttons.

Command Mode Code number

DVD1 number button 1

DVD2 number button 2

DVD3 number button 3

3 Hold down both the number and

ENTER buttons at the same time for more than three seconds.

ENTER

Example: for channel 50 Press “5,” “0,” then press ENTER.

Page 20

Step 6: Easy Setup

Make the basic adjustments by following the on-screen instructions in “Easy Setup.”

[/1

</M/m/,,

RETURN

ENTER

TV [/1

1 Turn on the recorder and your TV.

Then switch the input selector on your TV so that the signal from the recorder appears on your TV screen.

The initial settings message appears.

• If this message does not appear, select “Easy Setup” from “SETUP” in the System Menu (“Settings and Adjustments” on page 87).

2 Press ENTER.

Follow the on-screen instructions to make the following settings.

Easy Setup - Auto Tune

The recorder will automatically capture and store the available TV and Radio channels.

Easy Setup - Clock

The recorder will automatically search for a clock signal. If a clock signal cannot be found, set the clock manually using </M/m/,, and press ENTER.

Easy Setup - TV Type (page 92)

If you have a wide-screen TV, select “16:9.” If you have a standard TV, select either “4:3 Letter Box” (shrink to fit) or “4:3 Pan Scan” (stretch to fit). This will determine how “wide-screen” images are displayed on your TV.

Easy Setup - Component Out

If you are using the COMPONENT VIDEO OUT jack, select “On.”

Easy Setup - Line1 Output

To output video signals, select “Video.” To output S video signals, select “S Video.” To output RGB signals, select “RGB.” Select “Video” to enjoy the SMARTLINK features.

• If you set “Easy Setup - Component Out” to “On,” you cannot select “RGB.”

Easy Setup - Audio Connection

If you connected an AV amplifier (receiver) using a coaxial cord, select “Yes : DIGITAL OUT” and set the digital output signal (page 95).

3 Press ENTER when “Finish” appears.

“Easy Setup” is finished.

To return to the previous step

Press O RETURN.

z Hints

• If your AV amplifier (receiver) has an MPEG audio decoder, set “MPEG” to “MPEG” (page 95).

• If you want to run “Easy Setup” again, select “Easy Setup” from “SETUP” in the System Menu (page 101).

Page 21

Connecting a VCR or Similar Device

After disconnecting the recorder’s mains lead from the mains, connect a VCR or similar recording device to the LINE IN jacks of this recorder. Use the DV IN jack on the front panel if the equipment has a DV output jack (i.LINK jack) (page 82). For details, refer to the instruction manual supplied with the connected equipment. To record on this recorder, see “Recording from connected equipment without a timer” on page 57.

Connecting to the LINE 3 jack

Connect a VCR or similar recording device to the LINE 3 jack of this recorder.

VCR

SCART cord (not supplied)

to SCART input

Hookups and Settings

to i LINE 3

to i LINE 1 – TV

DVD recorder

b Notes

• Pictures containing copy protection signals that prohibit any copying cannot be recorded.

• If you pass the recorder signals through a VCR, you may not receive a clear image on your TV screen.

VCRDVD recorder TV

Be sure to connect your VCR to the DVD recorder and to your TV in the order shown below. To watch video tapes, watch the tapes through a second line input on your TV.

VCR TV

• The SMARTLINK features are not available for devices connected via the DVD recorder’s LINE 3 jack.

• When you record to a VCR from this DVD recorder, do not switch the input source to TV by pressing the TV/DVD button on the remote.

• If you disconnect the recorder’s mains lead, you will not be able to view the signals from the connected VCR.

DVD recorder

Line input 1

Line input 2

,continued

Page 22

Connecting to the LINE 2 IN jacks on the front panel

Connect a VCR or similar recording device to the LINE 2 IN jacks of this recorder. If the equipment has an S-video jack, you can use an S-video cord instead of an audio/video cord.

VCR, etc.

S VIDEO

OUTPUT

VIDEO

AUDI O

S-video cord

(not supplied)

to LINE 2 IN

: Signal flow

Audio/video cord (not supplied)

DVD recorder

z Hint

When the connected equipment outputs only monaural sound, connect to just the L(MONO) and VIDEO input jacks on the front of the recorder. Do not connect the R input jack.

b Notes

• Do not connect the yellow LINE IN (VIDEO) jack when using an S-video cord.

• Do not connect the output jack of this recorder to another equipment’s input jack with the other

equipment’s output jack connected to the input jack of this recorder. This may cause noise (feedback).

• Do not connect more than one type of video cord between the recorder and your TV at the same time.

Page 23

Connecting to a Satellite or Digital Tuner

Connect a satellite or digital tuner to this recorder using the LINE 3 jack. Disconnect the recorder’s mains lead from the mains when connecting the tuner. To use the Synchro-Rec function, see below.

Satellite tuner, CanalSat, etc.

SCART cord (not supplied)

to i LINE 1 – TVto i LINE 3

to SCART input

DVD recorder

Hookups and Settings

If the satellite tuner can output RGB signals

This recorder accepts RGB signals. If the satellite tuner can output RGB signals, connect the TV SCART connector on the satellite tuner to the LINE 3 jack, and set “Line3 Input” of “Scart Setting” to “Video/ RGB” in the “Video” setup (page 93). Note that this connection and setup disable the SMARTLINK function. If you want to use the SMARTLINK function with a compatible set top box, see the instructions supplied with the set top box.

If you want to use the Synchro Rec function

This connection is necessary to use the Synchro-Recording function. See “Recording from connected equipment with a timer (Synchro Rec)” on page 55. Set “Line3 Input” of “Scart Setting” in the “Video” setup (page 93) according to the specifications of your satellite tuner. See your satellite tuner’s instructions for more information. If you are using a B Sky B tuner, be sure to connect the tuner’s VCR SCART jack to the LINE 3 jack. Then set “Line3 Input” of “Scart Setting” according to the specifications of the VCR SCART jack on your satellite tuner.

b Notes

• Synchro-Recording does not work with some tuners. For details, see the tuner’s operating instructions.

• If you disconnect the recorder’s mains lead, you will not be able to view the signals from the connected tuner.

Page 24

Eight Basic Operations

— Getting to Know Your DVD Recorder

1. Inserting a Disc

Video

DATA CD

Z (open/ close)

RWVR-RW

DVD

VCD CD

Video

RVR

DATA DVD

DVD

1 Press DVD. 2 Press Z (open/close), and place a

disc on the disc tray.

2. Recording a Programme

HDD

RVR-R

Video

RWVR-RW

This section introduces the basic operation to record a current TV programme to the hard disk (HDD) or to a disc (DVD). For an explanation of how to make timer recordings, see page 44.

HDD DVD

Video

PROG +/–

DISPLAY

Recording/playing side facing down

3 Press Z (open/close) to close the disc

tray.

Wait until “LOAD” disappears from the front panel display. Unused DVDs are formatted automatically.

• For DVD-RW discs DVD-RWs are formatted in the recording format (VR mode or Video mode) set by “Format DVD-RW” in the “DVD” setup.

• For DVD-R discs DVD-Rs are automatically formatted in Video mode. To format an unused DVD-R in VR mode, format the disc using the “Disc Information” display (page 35)

If the disc is recordable on this recorder, you can manually re-format the disc to make a blank disc (page 35).

before

you make a recording.

z REC x REC

STOP

TV/DVD

REC MODE

TV t

1 Press HDD or DVD.

If you want to record to a DVD, insert a recordable DVD.

2 Press PROG +/– to select the

programme position or input source you want to record.

3 Press REC MODE repeatedly to select

the recording mode.

Each time you press the button, the display on the TV screen changes as follows:

For more details about the recording mode, see page 44.

Page 25

4 Press z REC.

Recording starts. Recording stops automatically after 8 hours of continuous recording or when the HDD or DVD is full.

Checking the disc status while recording

You can check the recording information such as recording time or disc type.

To stop recording

Press x REC STOP. Note that it may take a few seconds for recorder to stop recording.

To watch another TV programme while recording

If your TV is connected to the i LINE 1 – TV jack, set your TV to the TV input using the TV/DVD button and select the programme you want to watch. If your TV is connected to the LINE 2 OUT or COMPONENT VIDEO OUT jacks, set the TV to TV input using the TV t button (page 17).

TV Direct Rec.

If you are using the SMARTLINK connection and the “TV Direct Rec.” is set to “On” (page 98), you can easily record what you are watching on your TV. When the TV and the recorder are turned on, press z REC. The recorder starts recording what you are watching on your TV.

b Notes

• If “TV” appears in the front panel display, you cannot turn off the TV or change the programme position during TV Direct Rec. To turn off the function, set “TV Direct Rec.” to “Off” in the “Recording” setup (page 98).

• After pressing z REC, it may take a short while to start recording.

• You cannot change the recording mode while recording.

• If there is a power failure, the programme you are recording may be erased.

Press DISPLAY during recording.

The recording information appears.

A Disc type/format B Recording status C Recording mode D Recording time

Press DISPLAY to turn off the display.

Eight Basic Operations — Getting to Know Your DVD Recorder

Page 26

3. Playing the Recorded Programme (Title List)

RWVR-RW

Video

HDD

RVR

To play a recorded title, select the title from the Title List.

HDD DVD

TITLE LIST

Video

</M/m/,, ENTER

OPTIONS

CM x

1 Press HDD or DVD.

If you select DVD, insert a DVD (see “1. Inserting a Disc” on page 24). Playback starts automatically depending on the disc.

2 Press TITLE LIST.

To show the extended Title List, press OPTIONS to select “Display List,” and press ENTER. Title List with Thumbnail Images (Example: DVD+RW)

Extended Title List

A Disc type:

Displays the media type, HDD or DVD. Also displays the title type (Original or Playlist) for HDD or DVD-RW/DVD-R (VR mode) disc titles.

B Disc space (remainder/total) C Title information:

Displays the title number, title name, and recording date. Title size is shown in the Thumbnail title list. z (red): Indicates that the title is currently being recorded.

: Indicates that the title is currently

being dubbed.

: Indicates the protected title. “NEW”: Indicates that the title is newly recorded (not played back) (HDD only).

: Indicates titles containing “CopyOnce” copy protection signals (HDD only) (page 78).

Page 27

D Scroll bar:

Appears when all of the titles do not fit on the list. To view the hidden titles, press M/m.

E Title’s thumbnail picture:

The still images for each title are displayed.

3 Select a title, and press ENTER.

The sub-menu appears. The sub-menu displays options applicable only to the selected item. The displayed options differ depending upon the model, situation, and disc type.

Sub-menu

4 Select “Play,” and press ENTER.

Playback starts from the selected title.

To stop playback

Press x (stop).

To scroll the list display by page (Page mode)

Press / while the list display is turned on. Each time you press Title List changes to the next/previous page of titles.

About the Title List for HDD/DVD-RWs/ DVD-Rs (VR mode)

You can switch the Title List to show Original or Playlist titles. While the Title List menu is turned on, press </,.

/ , the entire

To change the title order (Sort)

While the Title List menu is turned on, press OPTIONS to select “Sort Titles.” Press M/m to select the item, and press ENTER.

Order Sorted

By Date In order of when the titles

By Title In alphabetical order.

By Number In order of recorded title

Unseen Title (HDD only)

were recorded. The title that is recorded most recently is listed at the top.

number.

In order of when the titles were recorded. The title that is recorded most recently and has not been played is listed at the top. Playlist titles are not displayed.

To change a title thumbnail picture (Thumbnail) (HDD/DVD-RW/DVD-R in VR mode only)

You can select a favourite scene for the thumbnail picture shown in the Title List menu.

1 Press TITLE LIST.

Press </, to switch the Title Lists, if necessary.

2 Select a title, and press ENTER.

The sub-menu appears.

3 Select “Set Thumbnail,” and press

ENTER. The display for setting the thumbnail point appears and the title starts to play.

4 While watching the playback picture,

press m/M to select the scene you want to set for a thumbnail picture, and press ENTER. Playback pauses.

5 Press ENTER if the scene is correct.

If the scene is incorrect, press c/C to select the scene you want to set for a thumbnail picture, and press ENTER. The display asks for confirmation.

• To change the thumbnail, press M.

6 Select “OK,” and press ENTER.

The scene is set for the title’s thumbnail picture.

Eight Basic Operations — Getting to Know Your DVD Recorder

,continued

Page 28

To turn off the Title List

Press TITLE LIST.

z Hints

• After recording, the first scene of the recording (the title) is automatically set as the thumbnail picture.

• You can select “TITLE LIST” from the System Menu.

b Notes

• The title names may not appear for DVDs created on other DVD recorders.

• It may take a few seconds for the thumbnail pictures to be displayed.

• After editing, the title thumbnail picture may change to the first scene of the recording (title).

• After dubbing, the title thumbnail picture set on the source recording is cancelled.

4. Displaying the Playing/Remaining Time and Play Information

Video

RWVR-RW

DVD

VCD

HDD

RVR

DATA DVD

DATA CD

You can check the playing time and remaining time of the current title, chapter, track, or disc. Also, you can check the disc name recorded on the DVD/CD.

Video

DISPLAY

TIME/TEXT

ENTER

OPTIONS

Press DISPLAY.

The displays differ depending on the disc type or playing status.

A Title number/name

(Shows either track number, track name, scene number, or file name for CDs, VIDEO CDs, DATA DVDs, or DATA CDs.)

Page 29

B Available functions for DVD VIDEOs

( angle/ audio/ subtitle, etc.), or playback data for DATA DVDs and DATA CDs

C The current selected function or audio

setting (appears only temporarily) Example: Dolby Digital 5.1 ch

Rear (L/R)

Front (L/R) + Centre

LFE (Low Frequency Effect)

D The current selected angle

E Disc type F Title type (

/format (page 8)

only appears for Playlists)

G Play mode H Recording mode (page 44) I Playing status bar

J Title number (chapter number*3)

(page 64) (Shows either track number, scene number, album number

, or file number for CDs, VIDEO CDs, DATA DVDs, or DATA CDs.)

K Album name appears for DATA DVDs

or DATA CDs. For CDs with CD text, press TIME/ TEXT.

L Playing time (remaining time

Displays Super VIDEO CDs as “SVCD,” DATA CDs as “CD” and DATA DVDs as “DVD.”

Does not appear with VIDEO CDs, DATA DVDs, and DATA CDs.

Displayed when you press TIME/TEXT repeatedly.

)

z Hints

• If “DTS” of “Audio Connection” i s set to “Off” in the “Audio” setup, the DTS track selection option will not appear on the screen even if the disc contains DTS tracks (page 95).

• When “Auto Display” is set to “On” (default) in the “Video” setup (page 94), information automatically appears on the screen when the recorder is operated.

b Note

Playing time of MP3 audio tracks may not be displayed correctly.

Checking the playing/ remaining time

You can view the playing or time information displayed on the front panel display.

Press TIME/TEXT repeatedly.

The displays differ depending on the disc type or playing status.

Example: When playing a DVD

Playing time and number of the current title

Remaining time of the current title

Playing time and number of the current chapter

Remaining time of the current chapter

Example: When playing a VIDEO CD

Playing time and number of the current scene or track

Eight Basic Operations — Getting to Know Your DVD Recorder

,continued

Page 30

Example: When playing a CD

Track playing time and the current track/index number

Remaining time of the current track

Playing time of the disc

Remaining time of the disc

CD text (when available)

Example: When playing an MP3 audio track

Playing time and number of the current track

Current album number

Example: When viewing a JPEG image

Current file number and total number of files in the current album

Current album number and total number of albums

b Notes

• The recorder can only display the first level of a CD’s text, such as the disc name.

• Playing time of MP3 audio tracks may not be displayed correctly.

Checking the remaining disc space

You can check the remaining disc space using the “Disc Information” display.

1 Insert a disc.

See “1. Inserting a Disc” on page 24.

2 Press OPTIONS to select “Disc

Information,” and press ENTER.

The “Disc Information” display appears. Available settings differ depending on the disc type. Example: When a DVD+RW is inserted.

“Remainder” (approximate)

• The remaining recording time in each of the recording modes

• Disc space bar

• Remaining disc space/total disc space

z Hint

To increase disc space, see “To open up disc space” (page 69).

Page 31

5. Changing the Name of a Recorded Programme

HDD

RVR

Video

RWVR-RW

Video

5 Press </M/m/, to select the

character you want to enter, and press ENTER.

The selected character appears at the top of the display. Example: Input Title Name

You can label a DVD, title, or programme by entering characters. You can enter up to 64 characters for a title or disc name, but the actual number of characters displayed in the menus such as the Title List will vary. The steps below explain how to change the name of the recorded programme.

Number buttons

TITLE LIST

INPUT SELECT

</M/m/,, ENTER

1 Press TITLE LIST. 2 Select a title, and press ENTER.

The sub-menu appears.

3 Select “Title Name,” and press

ENTER.

The display for entering characters appears.

4 Press </M/m/, to move the cursor

to the right of the display and select “A” (upper-case), “a” (lower-case), or “Symbol,” and press ENTER.

The characters for the selected type are displayed.

Eight Basic Operations — Getting to Know Your DVD Recorder

The type of characters will change according to the language you select in “Easy Setup.” Some languages allow you to enter an accent mark. To enter a letter with an accent mark, select an accent followed by the letter. Example: Select “ ` ” and then “a” to enter “à.” To insert a space, select “Space.”

6 Repeat steps 4 and 5 to enter the

remaining characters.

Input row

To erase a character, move the cursor to the right of the character at the input row. Select “Back” and press ENTER. To insert a character, move the cursor to the right of the point where you want to insert the character. Select the character and press ENTER. To erase all of the characters, select “Clear All” and press ENTER.

7 Select “Finish,” and press ENTER.

To cancel the setting, select “Cancel.”

,continued

Page 32

To use the number buttons

You can also use the number buttons to enter characters. Refer to the number next to each row of letters on your TV screen.

1 In step 5 above, press a number button

repeatedly to select a character. Example: Press the number 3 button once to enter “D.” Press the number 3 button three times to enter “F.”

2 Press ENTER and select the next

character.

3 Select “Finish” and press ENTER.

z Hint

You can switch between “A” (upper-case), “a” (lower-case), or “Symbol” by pressing INPUT SELECT.

6. Labelling and Protecting a Disc

You can execute options effective for the entire disc using the “Disc Information” display.

</M/m/,, ENTER OPTIONS

Labelling a disc

Video

RWVR-RW

Video

RVR

1 Insert a disc.

See “1. Inserting a Disc” on page 24.

2 Press OPTIONS to select “Disc

Information,” and press ENTER.

The “Disc Information” display appears. Available settings differ depending on the disc type. Example: When the inserted disc is a DVD+RW.

Page 33

3 Select “Disc Name,” and press

ENTER.

Enter the disc name in the “Input Disc Name” display (page 31).

b Note

You can enter up to 64 characters for a DVD’s disc name. The disc name may not appear when the disc is played on other DVD equipment.

Protecting a disc

RWVR

RVR

1 Insert a disc.

See “1. Inserting a Disc” on page 24.

2 Press OPTIONS to select “Disc

Information,” and press ENTER.

The “Disc Information” display appears. Available settings differ depending on the disc type. Example: When the inserted disc is a DVD-RW (VR mode).

A “On”/“Off”: Indicates whether

protection is set (DVD-RW/DVDR in VR mode only)

B “Protect Disc”

3 Select “Protect Disc,” and press

ENTER.

4 Select “Protect,” and press ENTER.

To cancel the protection

Select “Unprotected” in step 4.

z Hint

You can set protection for individual titles (page 69).

7. Playing the Disc on Other DVD Equipment (Finalise)

RWVR-RW

Video

Finalising is necessary when you play discs recorded with this recorder on other DVD equipment. When you finalise a DVD+RW, DVD-RW (Video mode), DVD+R, or DVD-R (Video mode), a DVD menu will be automatically created, which can be displayed on other DVD equipment. Before finalising, check the differences between the disc types in the table below.

Differences between the disc types

Discs are automatically finalised

when removed from the recorder. However, you may need to finalise the disc for certain DVD equipment, or if the recording time is short. You can edit or record on the disc even after finalising.

Finalising is unnecessary when

RWVR

playing a disc on VR format compatible equipment. Even if your other DVD equipment is VR format compatible, you may need to finalise the disc, especially if the recording time is short. You can edit or record on the disc even after finalising.

Finalising is necessary when

Video

playing on any equipment other than this recorder. After finalising, you cannot edit or record on the disc. If you want to record on it again, unfinalise (page 35) or reformat the disc (page 35). However, if you reformat the disc, all recorded contents will be erased.

Finalising is necessary. The disc

RVR

can be played only on equipment that supports DVD-R in VR mode. After finalising you cannot edit or record on the disc using this recorder.

Video

RVR

Eight Basic Operations — Getting to Know Your DVD Recorder

,continued

Page 34

Video

Z (open/ close)

Finalising is necessary when playing on any equipment other than this recorder. After finalising, you cannot edit or record on the disc.

</M/m/,, ENTER

OPTIONS

Finalising the disc using “Disc Information” display

1 Insert a disc.

See “1. Inserting a Disc” on page 24.

2 Press OPTIONS to select “Disc

Information,” and press ENTER.

The “Disc Information” display appears.

3 Select “Finalise,” and press ENTER.

The display shows the approximate time required for finalising and asks for confirmation.

Finalising the disc using Z (open/close) button

1 Make a recording.

See “2. Recording a Programme” on page 24.

2 Press Z (open/close).

The display shows the approximate time required for finalising and asks for confirmation. For DVD+RWs, the recorder automatically starts finalising the disc. After finalising, the disc will be ejected automatically.

3 Select “OK,” and press ENTER.

The recorder starts finalising the disc. After finalising, the disc will be ejected automatically.

4 Select “OK,” and press ENTER.

The recorder starts finalising the disc.

z Hint

You can check whether the disc has been finalised or not. If you cannot select “Finalise” in step 3 above, the disc has already been finalised.

b Notes

• Depending on the condition of the disc, recording, or the DVD equipment, discs may not play even if the discs are finalised.

• The recorder may not be able to finalise the disc if it was recorded on another recorder.

Page 35

Unfinalising a disc

RWVR-RW

For DVD-RWs (Video mode)

DVD-RWs (Video mode) that have been finalised to prohibit additional recording or editing can be unfinalised to allow further recording or editing.

For DVD-RWs (VR mode)

If you cannot record or edit on a DVD-RW (VR mode) that has been finalised with other DVD equipment, unfinalise the disc.

b Note

The recorder is not able to unfinalise DVD-RWs (Video mode) that have been finalised on another recorder.

Video

1 Insert a disc.

See “1. Inserting a Disc” on page 24.

2 Press OPTIONS to select “Disc

Information,” and press ENTER.

The “Disc Information” display appears.

3 Select “Unfinalise,” and press

ENTER.

The recorder starts unfinalising the disc. Unfinalising may take several minutes.

8. Reformatting a disc

RWVR-RW

New discs are automatically formatted when inserted. If necessary, you can manually reformat a DVD+RW or DVD-RW disc to make a blank disc. For DVD-RWs, you can select a recording format (VR mode or Video mode) according to your needs (page 68).

Video

</M/m/,, ENTER

OPTIONS

1 Insert a disc.

See “1. Inserting a Disc” on page 24.

2 Press OPTIONS to select “Disc

Information,” and press ENTER.

Example: When a DVD+RW is inserted.

Eight Basic Operations — Getting to Know Your DVD Recorder

3 Select “Format,” and press ENTER. 4 Select “OK,” and press ENTER.

For DVD-RWs and unrecorded DVD-Rs (Video mode), select “VR” or “Video,” and press ENTER. All contents on the disc are erased.

,continued

Page 36

z Hint

By reformatting, you can change the recording format on DVD-RWs, or record again on DVDRWs that have been finalised.

b Note

On this model, 1 GB (read “gigabyte”) is equivalent to 1 billion bytes. The larger the number, the larger the disc space.

Page 37

Guide to Digital Services

EPG (Electronic Programme Guide)

1 Press .

This display consists of an information box and a ten channel programme list covering a two hour period.

Example of EPG Display:

The Electronic Programme Guide is a guide showing the television programme schedule for a day or more at a time on your television (via the Digital Terrestrial Television tuner included in this recorder).

The EPG provides a quick and easy way to:

• View a complete list of all available channels.

• View a channel list related to a chosen category.

• Set a programme to be recorded (page 48).

b Note

Digital Services availability and content depend on the broadcaster. Digital Ser vices are not inst antly available wh en the recorder is first turned on.

Viewing a list of available channels

Number buttons

Colour buttons

</M/m/,,

RETURN

PAGE

ENTER

Guide to Digital Services

A Indicates the TV or Radio mode.

The Radio mode is indicated by a Radio icon .

B Indicates the Local Channel.

Number and the Channel name of the programme that is currently selected in the list.

C Indicates the currently selected

programme and allows you to move around the list.

D Channel name E Indicates the currently viewed

programme.

F Indicates if a timer recording is

associated with the event (page 48).

G Colour buttons H Truncated programme title in case

the name is too long to be displayed in the cell.

I Event bar (e.g. Indicates a timer

recording has been set during this time)

J Time slot

TV/RADIO

,continued

Page 38

K Icon tray

Depending on the channel and programme settings, some icons may appear in the display:

: Either the channel or the

programme is locked (page 88).

: Timer event icons

(page 48)

: Series Recording icon

(page 49)

L Indicates the current time and date.

2 Press </M/m/, or enter a channel

number using the number buttons to move around the list.

If you press , after selecting the last programme on the right, the schedule for the next two hours is displayed (depending on availability from the broadcaster).

3 Select a programme, and press

ENTER.

The full screen dialog appears with the description of the programme displayed in the information box.

4 Select “View Programme,” and press

ENTER.

Available buttons in the EPG display

Buttons Operations

PAGE / Display the previous/next

./> View the next or previous

The green button Toggle the display as

The yellow button

The red button (Category)

TV/RADIO Switch between TV and

RETURN Close the EPG display.

ten channels.

24-hour programme schedule.

follows: 2-hour schedule (half hour time shots) y 30-minute schedule (15 minutes time shots).

Display the channel for the selected programme

Search for programmes by category

Radio channels.

Viewing programmes related to a specific category

This feature allows you to search for programmes related to a particular topic. For example, if you select “News” from the category pop-up list, then only programmes related to News will be shown in the EPG.

b Note

The category of each programme is determined by the broadcaster.

PAGE

Colour buttons

M/m, ENTER

Page 39

1 Press . 2 Press the red button.

The category pop-up list appears.

3 Press M/m to select a category, and

press ENTER.

The selected category is displayed in a title bar at the top of the EPG display and only programmes related to that category will be shown in the list.

Some examples of category types are

as follows:

All Programmes: This gives a complete channel list. Films: Displays movies available for viewing. News: Displays all news channels. Entertainment: Displays all entertainment channels. Sports: Displays all sports channels. Kids: Displays all children’s channels. Music: Displays all music channels.

4 Press M/m to select a programme,

and press ENTER.

The sub menu appears with the description of the programme displayed in the information box.

5 Select “View Programme,” and press

ENTER.

Programme information

The programme information display pro vides a quick and easy way to:

• View descriptions of the programmes being broadcast now and next on the current channel.

• View descriptions of the programmes being broadcast now and next on the other channels.

• Switch between TV and RADIO channels.

Number buttons

</M/m/,, ENTER

PAGE

Displaying the programme information

Press .

The Information display appears showing a description of the current programme on view.

Guide to Digital Services

To scroll the Category display by page (Page mode)

Press PAGE / while the Category display is turned on to change to the previous/ next Category page.

z Hint

In step 4 above, the EPG application also allows you to set a timer recording. For more details, see “Recording TV programmes using the EPG” on page 48.

,continued

Page 40

Available buttons in the Information display

Buttons Operations

PAGE / Scroll the information

</, Toggle the display

M/m or the

number buttons

ENTER View the selected channel

display by page

between discription of the current/next programme

Display programme information for other channels

Toggle the Favourites List

Viewing a digital text service

Many digital TV channels broadcast information via their text service. This digital service includes high quality digital text and graphics along with advanced navigation options. Additionally, this recorder has access to dedicated text channels transmitted by the broadcasters.

b Note

The appearance, content and navigation methods of all digital text services are decided by the broadcaster.

Number buttons

PROG +/–

Colour buttons

</M/m/,, ENTER

Selecting digital text from dedicated digital teletext channels

1 Select a dedicated channel that is

broadcasting digital text.

You can search for a dedicated digital text channel using the “Electronic Programme Guide” (page 37). The text page is displayed.

Page 41

2 Once the text page is displayed (this

may take some time), follow the onscreen instructions to obtain your required selection.

On some pages the TV programme may also be displayed on the text screen. Onscreen instructions will inform you how to change the displayed programme. If you are instructed to press “OK” or “Select” when viewing the text pages, press ENTER.

To exit the text service

Follow the on screen instructions, or press PROG +/–.

Selecting digital text from other channels

Digital text services may also be available on other digital channels. This is sometimes indicated by a small symbol on your TV screen, superimposed on the programme you are watching.

1 Select a channel. 2 Press (Text) or the button

indicated on screen by the broadcaster.

The text information appears.

3 Access required information using

</M/m/,, the colour buttons and/ or the number buttons.

If you are instructed to press “OK” or “Select” when viewing the text pages, press ENTER.

To exit the text service

Follow the on screen instructions, or press PROG +/–.

Favourites

The Favourite application gives you the option to:

• Store your favourite channels into one of four TV or four Radio lists.

• Add or delete channels to the Favourites List.

• Quickly display a favourite channel.

• All receivable channels are automatically stored in the Favourites List.

Colour

SYSTEM MENU

PAGE

TV/RADIO

buttons

</M/m/,, ENTER

Setting the Favourites List

1 Press SYSTEM MENU.

The System Menu Display appears.

2 Select “SETUP,” and press ENTER.

The Setup Display appears.

3 Select “DTV Settings,” and press

ENTER.

Guide to Digital Services

,continued

Page 42

4 Select “Favourites,” and press

ENTER.

“Favourites List 1” display appears. Press repeatedly to switch to a different Favourites List.

This display shows all the TV or Radio channels available to you.

5 Press TV/RADIO to display either your

favourite TV or favourite Radio channels at any time.

The Radio mode is indicated by the presence of a Radio icon in the Favourites List panel.

6 Press M/m or enter a channel number

to select a channel you want to delete as a favourite, and press ENTER.

Press ENTER again to add the channel back to the Favourites List.

Watching or listening to a favourite channel

1 While in normal operation mode,

press repeatedly to select a list. Then press ENTER.

The selected Favourites List display appears.

Indicates the currently viewed channel

2 Press TV/RADIO to display either your

favourite TV or favourite Radio channels at any time.

The Radio mode is indicated by the presence of a Radio icon in the Favourites List panel.

3 Press to switch to a different

Favourites List.

4 Press M/m to select the channel you

want to view or listen to, and press ENTER.

If you do not want to choose from one of the channels in the display, press the red or green button to view the previous or next available channels.

z Hints

• Press the blue button to vie w the list showing only your favourite channels.

• Press the blue button once again when you wish to return to the previous favourite channel setting display.

To scroll the Favourites List display by page (Page mode)

Press PAGE / while the Favourites List display is turned on to change to the previous/next page.

Page 43

Index

The Index application is an easy way to display a scrollable list of all the tuned channels, including your favourites channel lists, and allows one of these to be selected.

M/m, ENTER

PAGE

TV/RADIO

Press TV/RADIO to display either the TV or the Radio channels at any time.

The Radio mode is indicated by the presence of a Radio icon in the Index panel.

4 Press M/m to select the desired

channel, then press ENTER to exit the index menu and view the selected channel.

To scroll the Index display by page (Page mode)

Press PAGE / while the Index display is turned on to change to the previous/next page.

Guide to Digital Services

1 While in normal operation mode,

press ENTER.

The Index display for the last display you viewed appears. For instance, if the last display you viewed was the Favourites List, then the Favourites List appears.

2 Press to switch between the

Programme List.

Page 44

Timer Recording

Before Recording

Before you start recording…

• Check that the disc has enough available space for the recording (page 30). For the HDD, DVD+RWs, and DVD-RWs, you can free up disc space by erasing titles (page 69).

• Adjust the recording picture quality and picture size if necessary (page 51).

z Hint

Timer recordings will be made regardless whether or not the recorder is turned on. You can turn off the recorder without affecting the recording even after recording starts.

b Notes

• To play a recorded disc o n other DVD equipment, finalise the disc (page 33).

• If digital teletext is operated while recording, it’s contents will be recorded on the disc.

• If the subtitles are disp layed while recording, they will be recorded on the disc.

Recording mode

Like the standard ×3 recording modes of video tapes, you can select the desired recording mode using the REC MODE button. Recording modes with higher quality provide a more beautiful recording, but the large data volume also results in a shorter recording time. Conversely, a longer duration provides a longer recording time, but the lower data volume results in a coarser picture quality.

Press REC MODE repeatedly to switch the recording modes.

To select the HQ+ mode, set “HQ Setting” of the “HDD Rec. Settings” to “HQ+” in the “Recording” setup (page 97). “HQ+” records pictures in higher quality than HQ on the HDD. Note that HQ+ plus appears as HQ in the front panel display and the on-screen displays.

Approx. recording

Recording mode

HQ+ (High quality) 8 – HQ R 13 1 HSP R 19 1 hr.

SP (Standard mode) 26 2 LSP r 33 2 hr.

ESP r 39 3 LP r 53 4 EP r 79 6

SLP (Long duration) 106 8

* The recording time for DVD+R DL (Double

Layer) discs is as follows: HQ: 1 hour 48 minutes HSP: 2 hours 42 minutes SP: 3 hours 37 minutes LSP: 4 hours 31 minutes ESP: 5 hours 25 minutes LP: 7 hours 14 minutes EP: 10 hours 51 minutes

: 14 hours 28 minutes

SLP

time (hours)

HDD DVD*

30 min.

b Notes

• The maximum continuous recording time for a single title is eight hours.

• Situations below may cause slight inaccuracies with the recording time. – Rec ording a programme with poor reception, or

a programme or video source of low picture

quality – Recording on a disc that has already been edited – Recording only a still picture or just sound

Page 45

Unrecordable pictures

Pictures with copy protection cannot be recorded on this recorder. When the recorder receives a copy guard signal, the recorder continues to record but only a blank, grey coloured screen will be recorded.

Copy control signals

Copy-Free

Copy-Once

Copy-Never None (a blank screen is

* The recorded disc can be played only on CPRM

compatible equipment (page 8).

Recordable discs

RWVR

Video

RWVR

RVR

(CPRM*)

HDD

recorded)

RVR

Timer Recording (Standard/EPG)

RWVR-RW

Video

HDD

RVR

You can set the timer for a total of 40 programmes, up to 30 days in advance. There are three methods to set the timer: the standard method, EPG method and Series Recording method.

• Standard: Set the date, time, and programme position of the programme manually.

• EPG: Set a programme to be recorded based on the information provided by the EPG (Electronic Programme Guide) (page 48).

• Series Recording: Automatically sets the recorder to record programmes in a series (page 49).

Setting the timer manually (Standard)

Video

Timer Recording

[TIMER]

x REC

STOP

</M/m/,, ENTER

OPTIONS

,continued

Page 46

1 Press [TIMER].

4 Select “OK,” and press ENTER.

The “TIMER LIST” display (page 53) appears. The TIMER REC indicator lights up on the front panel and the recorder is ready to start recording. Unlike a VCR, there is no need to turn off the recorder before the timer recording starts.

2 Press M/m to select the “Day and

Time” or “Mode” row. Then press ENTER.

3 Select an item using </, and

adjust using M/m. Then press ENTER.

To make additional changes to items in different rows, return to step 2. The adjustable items are listed below. “Day and Time”: Sets the date, start time, and stop time, and selects the programme position or input source. The date item changes as follows: Today y …… y Sat 28.10 (30 days later) y Sun (every Sunday) y …… y Sat (every Saturday) y Mon - Fri (Monday to Friday) y Mon - Sat (Monday to Saturday) y Daily y Today “Mode”: Selects the recording mode (page 44). “Media”: Selects the media, HDD or DVD. “Update” (HDD only): Automatically records over a previously recorded programme that is set to be recorded daily or weekly. “Extend Time”: Sets the duration in increments of 10 minutes, for a maximum of 60 minutes when a timer recording is in progress. If the programme set to be recorded daily or weekly is extended, the manually extended time set here will be added to the subsequent timer recording times.

• If you make a mistake, select the item and change the setting.

To stop recording during timer recording

Press x REC STOP. Note that it may take a few seconds for the recorder to stop recording.

Rec. Mode Adjust

If there is not enough available disc space for the recording, the recorder automatically adjusts the recording mode to enable the entire programme to be recorded. Set “Rec. Mode Adjust” of the “Timer Settings” to “On” in the “Recording” setup (page 97).

Auto Title Erase (HDD only)

If there is not enough space for a timer recording, the recorder automatically erases old titles recorded on the HDD. The oldest, played title is erased. Set “Auto Title Erase” of the “Timer Settings” to “On” in the “Recording” setup (page 97). Protected titles are not erased.

If the timer settings overlap

Overlapped timer settings are shown as follows.

To store the setting as shown, select “OK.” The programme that has a mark next to it has lower priority and will not be entirely recorded. To cancel the overlapped setting, select “Cancel.”

Page 47

To confirm, change, or cancel a timer recording

See “Checking/Changing/Cancelling Timer Settings” on page 52.

To extend the recording duration time while recording

1 Press OPTIONS during recording to

select “Extend Rec.,” and press ENTER.

2 Press M/m to select the duration time.

You can set the duration in increments of 10 minutes, for a maximum of 60 minutes.

3 Select “OK” and press ENTER.

One Touch Timer

If you use the SMARTLINK connection, you can easily display the timer programming menu. When the TV is turned on or in standby mode, press automatically turns on and the TV’s input is switched to the recorder. The Timer programming menu appears.

[TIMER]. The recorder

b Notes

• If a message indicating that the disc is full appears on the screen, change the disc, or make available space for the recording (HDD/DVD+RW/DVDRW only) (page 70).

• C heck that the clock is cor rectly set before setting the timer recording. If not, the timer recording cannot be made.

• To record a satellite programme, turn on the satellite tuner and select the satellite programme you want to record. Leave the satellite tuner turned on until the recorder finishes recording. If you connect equipment wit h a timer function, you can use the Synchro Rec function (page 55).

• Even if the timer is set for the same daily or weekly programme, the timer recording cannot be made if it overlaps with a programme that has priority. “ ” will appear next to the overlapped setting in the Timer List. Check the priority order of the settings.

• Eve n if the timer is set, timer recordings cannot be made while recording a programme that has priority.

• The Rec Mode Adjust function only works with a timer recording. It does not function with Quick Timer or Synchro Rec. In addition, the Rec Mode Adjust function does not work when recording to the HDD while “Auto Title Erase” of the “Timer Settings” is set to “On” in the “Recording” setup.

Timer Recording

z Hint

If you are recording to the HDD or a DVD-RW (VR mode) at a recording mode that is SP or lower and is a 2x speed or hig her disc, you can play the title as it is being recorded by selecting the programme title on the Title List (page 63).

,continued

Page 48

Recording TV programmes using the EPG

The EPG function is a feature that simplifies setting the timer. Just select the programme you want to record in the EPG display. The date, time, and channel of that programme are set automatically.

DVDHDD

Number buttons

</M/m/,, ENTER

PAGE

x REC

STOP

4 Press ENTER.

The sub menu appears with the description of the programme displayed in the information box.

indicates that the programme is age

limited (page 88).

5 Select “Timer,” and press ENTER.

• In case of a current TV/radio broadcast timer setting, your recorder will immediately start recording.

• In case of a future programme timer setting, an event bar and a new icon appear in the EPG display indicating that a timer event is associated with that programme.

1 Press HDD or DVD.

When you record to a DVD, insert a recordable DVD (see “1. Inserting a Disc” on page 24).

2 Press .

3 Select a programme using </M/m/

, or the number buttons.

To know more about the navigation options in the EPG application, see page 37.

Your recorder will automatically begin recording when the programme starts. To modify the timer setting, see page 52.

Some examples of timer event icon

types are:

(red): Indicates that the whole

programme is set to be recorded.

(grey): Indicates that the programme is set to be recorded, but only a part or none of the programme can be recorded (e.g. because of timer setting overlap).

(red): Indicates the programme is now recording.

Page 49

To scroll the EPG display by page (Page mode)

Press PAGE / while the EPG display is turned on to display the previous/next ten channels.

To stop recording during timer recording

Press x REC STOP. Note that it may take a few seconds for the recorder to stop recording.

If the timer settings overlap

See page 46.

To extend the recording duration time while recording (Guide Timer Extend)

See page 47.

To confirm, change, or cancel timer recording

See “Checking/Changing/Cancelling Timer Settings” (page 52).

z Hint

The Rec Mode Adjust function also works with this timer method (page 46).

b Notes

• This function cannot be used when the broadcaster does not include series information with the programme data.

• Whether or not a programme is in a series is determined by the broadcaster.

Number buttons

Colour buttons

</M/m/,,

RETURN

z REC

ENTER

Timer Recording

b Notes

• This recorder is featured with an EPG timer auto extend functionality that allows EPG timer recordings to be made in case of an early start (before the scheduled start time) or late finish (after the scheduled end time).

• The EPG programme start and end time are determined by the broadcaster.

Recording programmes using Series Recording

Series Recording is a feature which uses information from the Electronic Programme Guide to provide the following features:

• Automatically record programmes in a series.

• Record the subsequent parts of events which are split.

• Provide links to recommended programmes.

1 Press .

2 Select a programme containing series

information using </M/m/, or the number buttons.

“Series Info” appears under the blue bar at the bottom of the EPG screen when the programme contains series information.

,continued

Page 50

3 Press the blue button (“Series Info”).

The Series Information display appears. Press the red button to display the Programme Guide and see more information about the selected programme. Press O RETURN to return.

Confirming Series Recording settings

After you have set a programme for Series Recording, the following icons appear in the Series Information display.

(Series):

Indicates that the programme is a candidate for Series Recording.

(Link):

Indicates that the series has been set for Series Recording.

b Notes

• If a program is not completely recorded then the repeat will be recorded.

• Series Recordings may overlap with EPG or manual timer settings. Check timer settings using the Timer List (page 52).

(repeat):

Indicates a repeat programme.

(Recommended):

The event is recommended by broadcaster as a link for current series. Note that recommended programmes will not be automatically set for recording with Series Recording.

4 Press ENTER.

5 Select “Series Timer.”

The selected programme is set for recording and appears in the Timer List (page 53). The other programmes in the series will be set for recording (appear in the Timer List) as each previous recording is completed. For example, if there are three programmes in a series, the second programme will be set for recording only after the first recording is finished. The third programme will be set for recording only after the second recording is finished.

Recording Split Programmes

Movies and other programmes that are split into 2 or more parts are called Split Programmes. If you set the timer for one part of a Split Programme, the other parts are automatically recorded. For example, if the first half is set to be recorded, the last half will be recorded automatically.

b Note

Only the earliest part of the Split Programme is displayed on the Timer List.

Using the Quick Timer function

You can set the recorder to record in 30 minute increments.

Press z REC repeatedly to set the duration.

Each press advances the time in 30 minute increments. The maximum duration is six hours.

(normal recording)

The time counter decreases minute by minute to 0:00, then the recorder stops recording (the power does not turn off). Even if you turn off the recorder during recording, the recorder continues to record until the time counter runs out.

Page 51

Note that the Quick Timer function does not work if “TV Direct Rec.” is set to “On” in the “Recording” setup (page 98).

2 Select the item you want to adjust,

and press ENTER.

The adjustment display appears.

To cancel the Quick Timer

Press z REC repeatedly until the counter appears in the front panel display. The recorder returns to normal recording mode.

Adjusting the recording picture quality and size

You can adjust the recording picture quality and picture size.

</M/m/,, ENTER

OPTIONS

1 Before recording starts, press

OPTIONS to select “Rec. Settings,” and press ENTER.

Example: Rec. NR

“Rec. Mode”: Selects the recording mode for the desired recording time and picture quality. For more information, see “Recording mode” on page 44.

“HDD Rec. Picture Size”/“DVD Rec. Picture Size”: Sets the picture size of the programme to be recorded.

• Auto (HDD only) (default): Automatically selects the actual picture size.

• 4:3: Sets the picture size to 4:3.

• 16:9: Sets the picture size to 16:9 (wide mode).

“DVD Rec. Picture Size” works with DVD-RWs/DVD-Rs (Video mode) when the recording mode is set to HQ, HSP, SP, LSP, or ESP. For all other recording modes, the screen size is fixed at “4:3.” For DVD-Rs/DVD-RWs (VR mode), the actual picture size is recorded regardless of the setting. For example, if a 16:9 size picture is received, the disc records the picture as 16:9 even if “DVD Rec. Picture Size” is set to “4:3.” For DVD+RWs/DVD+Rs, the screen size is fixed at “4:3.”

Timer Recording

“Rec. NR” (noise reduction): Reduces noise contained in the video signal.

“Rec. Video Equalizer”: Adjusts the picture in greater detail. Press M/m to select the item you want to adjust, then press ENTER.

• Contrast: Changes the contrast.

• Brightness: Changes the overall brightness.

• Colour: Makes the colours deeper or lighter.

,continued

Page 52

3 Adjust the setting using </M/m/,,

and press ENTER.

The default setting is underlined. “Rec. NR”: (weak) Off 1 ~ 2 (strong) “Rec. Video Equalizer”:

• Contrast: (weak) –3 ~ 0

• Brightness: (dark) –3 ~ 0 ~ 3 (bright)

• Colour: (light) –3 ~ 0 Repeat steps 2 and 3 to adjust any other

items.

b Notes

• If one programme contains two picture sizes, the selected size is recorded. However, if the 16:9 signal cannot be recorded as 16:9, it is recorded as 4:3.

• When playing a 16:9 size picture recorded as 4:3, the image is fixed to 4:3 Letter Box regardless of the setting in “TV Type” of “Video” setup (page 92).

• Remnants of images may appear on your screen when using “Rec. NR.”

• “Rec. Video Equalizer” does not affect the input of the DV IN jack or digital TV pictures and does not work with RGB signals.

~ 3

~ 3 (strong)

~ 3 (deep)

Checking/Changing/ Cancelling Timer Settings

RWVR-RW

Video

HDD

RVR

There are two ways to check, change or cancel the timer settings.

• Using the EPG

• Using the Timer List

SYSTEM

RETURN

Video

</M/m/,, ENTER

Creating chapters in a title

The recorder can automatically divide a recording (a title) into chapters by inserting chapter marks at approximately 6 minute intervals during recording. To disable this function, set “Auto Chapter” in the “Recording” setup to “Off” (page 98). When recording to the HDD, a DVD-R (VR mode) or a DVD-RW (VR mode), you can insert and erase chapter marks manually (page 72).

b Note

When dubbing (page 76), the chapter marks in the dubbing source are not retained in the dubbed title.

Checking/Changing/Cancelling using the EPG

1 Press .

A timer setting can be identified using the event bar and the timer event icon displayed in the EPG display. For details, see page 48.

Page 53

2 Press </M/m/, to select a future

timer event you want to check/change/ cancel. Then press ENTER.

The Event Action menu appears.

b Note

If you set “Repeat rec.” to any option other than “Off” in step 3, your EPG timer recording will be converted into a standard timer recording. The timer event icon disappears from the EPG display.

Checking/Changing/Cancelling using the Timer List

3 Press M/m to select an option. Then

press ENTER.

The sub menu appears:

“Modify”: Changes the timer setting. Select an item using </, and adjust using M/m. Select “OK” and press ENTER.

“Erase”: Erases the timer setting.

“Check Overlap”: Checks for overlapped settings.

Select “Close” to return to the EPG display. To change or cancel the setting, repeat steps 2 and 3 above.

1 Press SYSTEM MENU.

The System Menu appears.

2 Select “TIMER LIST,” and press

ENTER.

The Timer List appears.

Timer information displays the recording date, time, recording mode, etc.

: Indicates that the setting is overlapped by another setting.

(red):

Indicates the setting currently being recorded.

: Indicates that the timer recording cannot be recorded as set, such as for a timer recording that cannot be recorded in the selected recording mode.

: Indicates the setting is being recorded to the HDD.

: Indicates the setting is being recorded to a DVD.

: Indicates the setting that the Update function is set for.

When all of the timer settings do not fit on the list, the scroll bar appears. To view the hidden timer settings, press M/m.

Timer Recording

,continued

Page 54

3 Select the timer setting you want to

check/change/cancel, and press ENTER.

The sub-menu appears.

4 Select one of the options, and press

ENTER.

“Modify”: Changes the timer setting. Select an item using </, and adjust using M/m. Select “OK” and press ENTER.

“Erase”: Erases the timer setting. Select “OK” and press ENTER.

“Info”: Displays the timer setting information box along with the disc space required to record the whole programme (according to the selected recording mode).

Press O RETURN to return to the Timer List. To change or cancel the setting, repeat steps 3 and 4 above.

When the timer settings overlap

The programme set last has priority.

Example: You set the timer in order of A, B, and C (setting C has first priority)

will be cut off

“Check Overlap”: Checks for overlapped settings.

Select “Close” to return to the Timer List.

Actual recording

If the end time of one recording and the start time of another are the same

The end of programme A will be cut off.

Page 55

To scroll the list display by page (Page mode)

Press / while the list display is turned on. Each time you press

/ , the entire

Timer List changes to the next/previous page of timer settings.

To turn off the Timer List

Press O RETURN.

Recording From Connected Equipment

HDD

RVR

Video

RWVR-RW

Video

z Hint

For manual timer settings, you cannot modify the timer setting for the current recording, but you can extend the duration of the recording time while recording (page 47). For timer settings using the EPG, you can modify the timer setting for the current recording while recording, but you cannot extend the duration of the recording (even when recording is stopped).

b Notes

• Even if the timer is set, timer recordings cannot be made while recording a programme that has priority.

Auto Title Erase (HDD only)

DVDHDD

INPUT SELECT

</M/m/,, ENTER

OPTIONS

z REC x REC

STOP

REC MODE c z SYNCHRO REC

Recording from connected equipment with a timer (Synchro Rec)

You can set the recorder to automatically record programmes from connected equipment that has a timer function (such as a satellite tuner). Connect the equipment to the LINE 3 jack of the recorder (page 23). When the connected equipment turns on, the recorder starts recording a programme from the LINE 3 jack.

Timer Recording

1 Before recording, select HDD or DVD.

If you select DVD, insert a recordable DVD (see “1. Inserting a Disc” on page 24).

2 Set “Synchro Rec.” to “Record to

HDD” or “Record to DVD” in the “Recording” setup (page 98).

,continued

Page 56

3 Press INPUT SELECT repeatedly to

select “L3.”

4 Select the desired audio signal when

recording a bilingual programme to the HDD or DVD-RWs/DVD-Rs (VR mode).

Press OPTIONS to select “Line Audio Input,” and press ENTER. Then select “Bilingual,” and press ENTER.

5 Press REC MODE repeatedly to select

the recording mode.

For details about the recording mode, see page 44.

6 Set the timer on the connected

equipment to the time of the programme you want to record, and turn it off.

7 Press c z SYNCHRO REC.

The SYNCHRO REC indicator lights up on the front panel. The recorder is ready to start Synchro-Recording. The recorder automatically starts recording when it receives an input signal from the connected equipment. The recorder stops recording when the connected equipment turns off.

To stop recording

Press x REC STOP or c z SYNCHRO REC.

b Notes

• The recorder starts recording only after detecting a video signal from the connec ted equipment. The beginning of the programme may not be recorded regardless of whether or not the recorder’s power is on or off.

• During Synchro-Recording, other operations, such as normal recording, cannot be performed.

• To use the connected equipment while the recorder is standing by for Synchro-Recording, cancel Synchro-Recording by pressing c z SYNCHRO REC. Be sure to turn off the connected equipment and press c z SYNCHRO REC to reset Synchro-Recording before the timer recording starts.

• The Synchro Rec function does not work with some tuners. For details, see the tuner’s operating instructions.

If the timer settings of a SynchroRecording and another timer recording overlap

Regardless of whether or not the programme is a Synchro Rec programme, the programme that starts first has priority and the second programme starts recording only after the first programme has finished.

First programme

Second programme

will be cut off

To cancel Synchro Rec

Press c z SYNCHRO REC. The SYNCHRO REC indicator on the recorder turns off.

Page 57

Recording from connected equipment without a timer

You can record from a connected VCR or similar device. To connect a VCR or similar device, see “Connecting a VCR or Similar Device” on page 21. Use the DV IN jack on the front panel if the equipment has a DV output jack (i.LINK jack).

1 Press HDD or DVD.

If you select DVD, insert a recordable DVD (see “1. Inserting a Disc” on page 24).

2 Press INPUT SELECT to select an input

source according to the connection you made.

The front panel display changes as follows:

programme position

3 Select the desired audio signal when

recording a bilingual programme to the HDD or DVD-RWs/DVD-Rs (VR mode).

Press OPTIONS to select “Line Audio Input,” and press ENTER. Then select “Bilingual,” and press ENTER.

4 Press REC MODE repeatedly to select

the recording mode.

For details about the recording mode, see page 44.

5 Insert the source tape into the

connected equipment and set to playback pause.

6 Press z REC.

This recorder starts recording.

7 Press the pause (or play) button on the

connected equipment to cancel the playback pause status.

The connected eq uipment starts playback and the playback image is recorded by this recorder. To stop recording, press x REC STOP on this recorder.

If you connect a digital video camera with a DV IN jack

See “DV Dubbing” on page 82 for an explanation of how to record from the DV IN jack.

z Hint

You can adjust the settings for the recording picture before recording. See “Adjusting the recording picture quality and size” on page 51.

b Notes

• When recording a video game image, the screen may not be clear.

• Any programme that contains a Copy-Never c opy guard signal cannot be recorded. The recorder continues to record, but a blank screen will be recorded.

Timer Recording

Page 58

Playback

Playing

3 Select the title, and press ENTER.

The sub-menu appears.

4 Select “Play,” and press ENTER.

Playback starts from the selected title.

Video

RWVR-RW

DVD

HDD

RVR

DATA CD

DATA DVD

HDD DVD

Number buttons

AUDIO

TOP MENU

TITLE LIST

VCD

Video

SUBTITLE

</M/m/,, ENTER OPTIONS

1 Press HDD or DVD.

• If you select DVD, insert a disc (see “1. Inserting a Disc” on page 24).

• If you insert a DVD VIDEO, VIDEO CD, CD, DATA DVD, or DATA CD, press H. Playback starts.

2 Press TITLE LIST.

For details about the Title List, see “3. Playing the Recorded Programme (Title List)” on page 26. Example: DVD+RW

To use the DVD’s Menu

When you play a DVD VIDEO, or a finalised DVD+RW, DVD-RW (Video mode), DVD+R, or DVD-R (Video mode), you can display the disc’s menu by pressing TOP MENU or MENU.

To play VIDEO CDs with PBC functions

PBC (Playback Control) allows you to play VIDEO CDs interactively using the menu on your TV screen. When you start playing a VIDEO CD with PBC functions, the menu appears. Select an item using the number buttons and press ENTER. Then, follow the instructions in the menu (press H when “Press SELECT” appears). The PBC function of Super VIDEO CDs does not work with this recorder. Super VIDEO CDs are played in continuous play mode only.

To change the angles

If various angles (multi-angles) for a scene are recorded on the disc, “ ” appears in the front panel display. Press OPTIONS during playback to select “Change Angle,” and press ENTER.

To stop playback

Press x.

To playback quickly with sound (Scan Audio)

When you press M during playback of a title recorded in the HDD, you can play quickly with dialogue or sound (“x1.3” appears). No sound is output when you press M two or more times to change search speed.

Page 59

To resume playback from the point where you stopped (Resume Play)

When you press H again after you stop playback, the recorder resumes playback from the point where you pressed x. To start from the beginning, press OPTIONS to select “Play Beginning,” and press ENTER. Playback starts from the beginning of the title/track/scene.

The point where you stopped playing is cleared when: – you open the disc tray (except for HDD). – you play another title (except for HDD). – you switch the Title List menu to Original

or Playlist (HDD/DVD-RWs/DVD-Rs in

VR mode only). – you edit the title after stopping playback. – you change the settings on the recorder. – you turn off the recorder (VIDEO CD/CD/

DATA DVD/DATA CD only). – you make a recording (except for HDD/

DVD-RWs/DVD-Rs in VR mode). – you disconnect the mains lead.

b Note

You cannot resume playback during TV Pause.

To lock the disc tray (Child Lock)

You can lock the disc tray to prevent children from ejecting the disc. When the recorder is turned on, hold down x until “LOCKED” appears in the front panel display. The Z (open/close) button does not work while the Child Lock is set.

To unlock the disc tray, hold down x until “UNLOCKED” appears in the front panel display when the recorder is turned on.

One Touch Play

If you use the SMARTLINK connection, you can easily start playing. Press H. The recorder and your TV automatically turn on and the TV’s input is switched to the recorder. Playback starts automatically.

One Touch Menu

If you use the SMARTLINK connection, you can easily display the Title List. Press TITLE LIST. The recorder and your TV automatically turn on and the TV’s input is switched to the recorder. The Title List appears.

Playback

To play restricted DVDs (Parental Control)

If you play a restricted DVD, the message “Do you want to temporarily change the Parental Control level to *?” appears on your TV screen.

1 Select “OK” and press ENTER.

The display for entering your password appears.

2 Enter your four-digit password using the

number buttons.

3 Press ENTER to select “OK.”

The recorder starts playback.

To register or change the password, see “Parental Control (DVD VIDEO only)” on page 98.

z Hints

• You can also use the H button in step 3

(page 58) to start playback.

• Even if you select “Factory Setup” in the “Others” setup (page 101), the Child Lock remains set.

,continued

Page 60

Playback options

To check the position of the buttons below, see the illustration on page 58. For MP3 or JPEG operations, see “Playing MP3 Audio Tracks or JPEG Image Files” on page 65.

Buttons

Operations

AUDIO Selects one of the audio tracks recorded on the disc when pressed

HDD

DVD

RWVR

VCD

RVR

repeatedly in normal playback mode.

: Selects the language.

DVD

HDD

VCD

RWVR

: Selects the main or sub sound.

RVR

: Selects stereo or monaural audio tracks.

SUBTITLE Selects a subtitle language when pressed repeatedly.

DVD

/ (instant replay/

Replays the scene/briefly fast forwards the scene.

instant advance)

RWVR

HDD

Video

DVD

RVR

. (previous)/> (next) Goes to the beginning of the previous/next title/chapter/scene/

track. For the HDD, you cannot go to the beginning of the previous/ next title.

(fast reverse/fast forward)

Fast reverses/fast forwards the disc when pressed during playback. Search speed changes as follows:

fast reverse fast forward

m1 T t 1M

m2 T T t t 2M

T T T t t t 3M

When you press and hold the button, fast forward/fast reverse continues at the selected speed until you release the button.

When you press M once during playback of a title recorded in the HDD, you can play quickly with sound (“x1.3” appears).

m3 and 3M are only available for the HDD and DVDs.

(slow, freeze frame)

HDD

Video

DVD

RWVR

RVR

VCD

Plays in slow motion when pressed for more than one second in pause mode. Plays one frame at a time when pressed briefly in pause mode.

* Playback direction only

X (pause) Pauses playback.

To resume normal playback, press H.

Page 61

b Notes

• An gles and subtitles cannot be changed with titles recorded on this recorder.

• Slideshows made with a DVD camcorder can only be played. Other play functions, such as fast forward, cannot be used.

Notes on playing DTS sound tracks on a CD

• When playing DTS-encoded CDs, excessive noise will be heard from the LINE1-TV/LINE 3/ LINE 2 OUT (R-AUDIO-L) jacks. To avoid possible damage to the audio system, the consumer should take proper precautions when the LINE1-TV/LINE 3/LINE 2 OUT (R-AUDIOL) jacks of the recorder are connected to an amplification system. To enjoy DTS Digital Surround™ playback, an external DTS decoder must be connected to the DIGITAL OUT jack of the recorder.

• Set the sound to “Stereo” using the AUDIO button when you play DTS sound tracks on a CD (page 60).

Notes on playing DVDs with a DTS sound track

DTS audio signals are output only through the DIGITAL OUT (COAXIAL) jack. When you play a DVD with DTS sound tracks, set “DTS” to “On” in the “Audio” setup (page 95).

Adjusting the picture quality

HDD

RVR

Video

RWVR-RW

DVD

VCD

Video

1 Press OPTIONS during playback to

select “Video Settings,” and press ENTER.

2 Select an item, and press ENTER.

The adjustment display appears. “FNR” (frame noise reduction): Reduces noise contained in the luminance element of the video signal. “BNR” (block noise reduction): Reduces “block noise” or mosaic like patterns in the picture. “MNR” (mosquito noise reduction): Reduces the faint noise appearing around the outlines of the images. The noise reduction effects are automatically adjusted within each setting range according to the video bit rate and other factors. “Sharpness”: Sharpens the outlines of the images. “PB Video Equalizer” (Playback video equalizer): Adjusts the picture in greater detail. Select an item and press ENTER.

• Contrast: changes the contrast.

• Brightness: changes the overall brightness.

• Colour: makes the colours deeper or lighter.

• Hue: changes the colour balance.

3 Press </, to adjust the setting, and

press ENTER.

The default settings are underlined. “FNR”: (weak) Off 1 2 “BNR”: (weak) Off 1 2 3 (strong) “MNR”: (weak) Off 1 2 “Sharpness”*: (weak) Off (strong) “PB Video Equalizer”:

• Contrast: (weak) –3 ~ 0

• Brightness: (dark) –3 ~ 0 ~ 3 (bright)

• Colour: (light) –3 ~ 0

• Hue: (red) –3 ~ 0

Repeat steps 2 and 3 to adjust any other items.

* “1” softens the outlines of the images. “2”

enhances the outlines a nd “3” enhances them more than “2.”

3 (strong)

1 2 3

~ 3 (strong)

~ 3 (deep)

~ 3 (green)

Playback

,continued

Page 62

b Notes

• If the outlines of the images on your screen become blurred, set “BNR” and/or “MNR” to “Off.”

• Depending on the disc or the scene being played, the above BNR, MNR, or FNR effects may be hard to discern. And, these functions may not work with some screen sizes.

• When using the “Sharpness” function, noise found in the title may become more apparent. In this case, it is recommended that you use the BNR function with the “Sharpness” function. If the condition still does not improve, set the “Sharpness” level to “Off.”

Adjusting the delay between the picture and sound (AV SYNC)

Pausing a TV Broadcast (TV Pause)

You can pause a current TV broadcast, and then continue watching the programme at a later time. This is useful when you receive an unexpected phone call or visitor while watching TV.

1 While viewing a TV broadcast with

this recorder, press X.

The picture pauses. You can pause the picture for up to three hours.

HDD

RVR-R

Video

RWVR-RW

DVD

VCD

Video

1 Press OPTIONS during playback to

select “Audio Settings,” and press ENTER.

2 Select “AV SYNC,” and press ENTER.

“AV SYNC”: When the video is delayed, this function delays the audio for synchronization with the video (0 to 120 milliseconds). Larger numbers indicate a longer audio delay for synchronization with the video. When dubbing to a VCR or other video recording equipment, be sure to return this setting to 0 ms (default).

3 Press </, to adjust the setting, and

press ENTER.

TV pause

2 Press X or H again to resume

watching the programme.

b Notes

• Paused titles are not saved to the HDD.

• This function is cancelled when:

– x (stop) is pressed. – PROG +/– is pressed. – DVD is pressed. – Z (open/close) is pressed. – TITLE LIST is pressed. – INPUT SELECT is pressed. – the recorder is turned off. – a timer recording or Synchro-Recording is

started.

– DV dubbing or regular dubbing is started.

• It may take one minute or more to resume playback of the paused programme.

• Ev en if you fast forward the recorded pr ogramme, there will always be a time difference of about one minute or more between the recorded programme and the current TV broadcast.

Page 63

Playing from the beginning of the programme you are recording (Chasing Playback)

HDD

“Chasing Playback” allows you to view the recorded part of a programme while the recording is being made. You do not need to wait until the recording finishes.

Press OPTIONS while recording to select “Chasing Playback,” and press ENTER.

Playback starts from the beginning of the programme you are recording. When you fast forward to the point that you are recording, Chasing Playback returns to normal playback.

b Notes

• For DVD-RWs (VR mode), this function does not

• The DVD’s picture on your TV screen freezes for

• Chasing Playback is possible from one minute or

• Ev en if you fast forward the recorded pr ogramme,

RWVR

work when recording: – on a 1x-speed DVD-RW. – in the HQ or HSP recording mode.

a few seconds when you fast forward/fast reverse or instant replay/advance the recording.

more after recording starts.

there will always be a time difference of about one minute or more between the recorded programme and the current TV broadcast.

• While recording to the HDD: Play another title on the HDD. Play a previously recorded programme on a DVD by pressing DVD.

• While recording to a DVD: Play a previously recorded programme on the HDD by pressing HDD.

• While recording to a DVD-RW (VR mode)*1: Play another title on the same DVD-RW (VR mode) disc.

Simultaneous Rec and Play function does not work when you record: – on a 1x-speed DVD-RW. – in the HQ or HSP recording mode.

Picture noise may appear depending upon the condition of the recording, or when playing a title recorded in the HQ or HSP recording mode. The picture freezes for a few seconds when you use fast forward/fast reverse or instant replay/ advance.

You can also play a DVD VIDEO, VIDEO CD, Super VIDEO CD, CD, DATA DVD, or DATA CD while recording on the HDD.

Example: Play another title on the HDD while recording to the HDD.

1 While recording, press TITLE LIST to

display the HDD Title List.

2 Select the title you want to play, and

press ENTER.

3 Select “Play” from the sub-menu, and

press ENTER. Playback starts from the selected title.

Playback

Playing a previous recording while making another (Simultaneous Rec and Play)

HDD

RVR-R

DATA DVD

DATA CD

Video

RWVR-RW

DVD

VCD

“Simultaneous Rec and Play” allows you to view a previously recorded programme while recording programmes. Playback continues even if a timer recording starts. Use this function as follows:

Video

Example: Play a DVD while recording to the HDD.

1 While recording, press DVD and insert

the DVD into the recorder.

2 Press TITLE LIST to display the DVD

Title List.

3 Select the title you want to play, and

press ENTER.

4 Select “Play” from the sub-menu, and

press ENTER. Playback starts from the selected title.

b Note

You cannot play a DVD or VIDEO CD recorded in the NTSC colour system while recording on the HDD. When playing a VIDEO CD, be sure to set “Colour System” to “PAL” in the “Video” setup (page 94).

Page 64

Searching for a Title/ Chapter/Track, etc.

The display for entering the number appears. Example: Title Search

Video

RWVR-RW

DVD

VCD

HDD

RVR

DATA CD

DATA DVD

You can search a disc by title, chapter, scene or track. As titles and tracks are assigned individual numbers, select the title or track by entering its number. You can also search for a scene using the time code.

Number buttons

Video

ENTER

OPTIONS

1 Press OPTIONS during playback to

select a search method, and press ENTER.

“Title Search” (for DVDs) “Chapter Search” (for HDD/DVDs) “Track Search” (for CDs/DATA CDs) “Search” (for VIDEO CDs) “Album Search” (for DATA DVDs/ DATA CDs) “Time Search” (for HDD/DVDs): Searches for a starting point by entering the time code. “File Search” (for DATA DVDs/DATA CDs)

The number in parentheses indicates the total number of titles, tracks, etc.

2 Press the number buttons to select the

number of the title, chapter, track, time code, etc., you want.

For example: Time Search To find a scene at 2 hours, 10 minutes, and 20 seconds, enter “21020.” If you make a mistake, select another number.

3 Press ENTER.

The recorder starts playback from the selected number.

b Note

“Title Search” is not applicable to the HDD.

Page 65

Playing MP3 Audio Tracks or JPEG Image Files

DATA DVD

DATA CD

You can play MP3 audio tracks and JPEG image files on DATA CDs (CD-ROMs/CDRs/CD-RWs) or JPEG image files on DATA DVDs (DVD-ROMs/DVD+RWs/DVD+Rs/ DVD-RWs/DVD-Rs).

AUDIO

DISPLAY TIME/TEXT

</M/m/,, ENTER

OPTIONS

1 Insert a disc.

See “1. Inserting a Disc” on page 24.

2 Press H.

For MP3 discs, playback starts from the first MP3 audio track on the disc. For JPEG files, a slideshow of the pictures on the disc begins. If the disc contains MP3 audio tracks and JPEG image files, only the JPEG image files are played back when H is pressed.

To stop playback or slideshow

Press x.

To pause playback or slideshow

Press X.

To play the beginning of the track

Press OPTIONS to select “Play Beginning,” and press ENTER.

To fast forward or review a track

Press m/M during playback.

To go to the next or previous MP3 audio track or JPEG image file

Press . or > during playback. If you repeatedly press . or >, you will go to the next or previous album. (MP3 audio track only)

To go to the next or previous album

Press / during playback or slideshow.

To rotate a picture

Press OPTIONS while the JPEG image is displayed to select “Rotate Right” or “Rotate Left,” and press ENTER.

z Hints

• Press the AUDIO button

stereo or monaural audio tracks.

• You can rotate a JPEG image by using the </, buttons when the image is displayed.

• Press DISPLAY repeatedly to show information about the JPEG album or image on your TV screen. Then press TIME/TEXT to toggle between the current selected image number and album number.

to switch between

b Notes

• Some JPEG files, especially files of three million pixels or more, may lengthen the slideshow interval.

• Rotated JPEG images will not be saved when you switch to another folder.

• Images larger than 720 × 480 will be reduced to 720 × 480 when displayed.

• The following images are not displayed: – progressive JPEG image files – greyscale JPEG image files – 4:1:1 JPEG image files

• When you attempt to play a broken file or a file that does not satisfy the play conditions, appears but the recorder cannot play the file.

Playback

,continued

Page 66

About MP3 audio tracks and JPEG image files

MP3 is an aud io compression technology that satisfies certain ISO/MPEG regulations. JPEG is an image compression technology. You can play MP3 (MPEG1 Audio Layer 3) format audio tracks and JPEG image files on DATA CDs (CD-ROMs/CD-Rs/CD-RWs) or JPEG image files on DATA DVDs (DVDROMs/DVD+RWs/DVD+Rs/DVD-RWs/ DVD-Rs). DATA CDs must be recorded according to ISO9660 Level 1, Level 2 or Joliet format for the recorder to recognize the MP3 tracks. You can also play discs recorded in MultiSession/Border. See the instructions supplied with the disc drives and the recording software (not supplied) for details on the recording format.

Note on MultiSession/Border discs

If audio tracks and images in Music CD format or Video CD format are recorded in the first session/border, only the first session/ border will be played back.

b Note

The recorder may not be able to play some DATA CDs created in the Packet Write format.

MP3 audio tracks or JPEG image files that the recorder can play

The recorder can play the following tracks and files: – MP3 audio tracks with the extension

“.mp3.”

– JPEG image files with the extension “.jpeg”

or “.jpg.”

– JPEG image files that conform to the DCF*

image file format.

* “Design rule for Camera File system”: Image

standards for digital cameras regulated by JEITA (Japan Electronics and Information Technology Industries Association).

b Notes

• The recorder will play any data with the extension

“.mp3,” “.jpeg,” or “.jpg,” even if they are not in MP3 or JPEG format. Playing these data may generate a loud noise which could damage your speaker system.

• The recorder does not conform to audio tracks in

mp3PRO format.

• Some files cannot be played.

Page 67

About playback order of albums, tracks, and files

Albums play in the following order:

Structure of disc contents

Tree 1 Tree 2 Tree 3 Tree 4 Tree 5

ROOT

b Notes

• Depending on the software you use to create the DATA DVD/DATA CD, the playback order may differ from the above illustration.

• No more than a total of 999 individu al folders can be played. (Folders that do not contain JPEG/ MP3 files are counted as well.)

• No more than a total of 999 folders and 99 99 files can be played. (Files other than JPEG/MP3 files, and folders that do not contain JPEG/MP3 files are counted as well.)

• No more than 999 folders and files can be recognized in a single folder. (Folders that do not contain JPEG/MP3 files are counted as well.)

• Proceeding to the next or ano ther album may take some time.

• This recorder supports MP3 audio bit rates up to 320 kbps.

Playback

Album

MP3 audio track/ JPEG image file

When you insert a DATA CD/DATA DVD and press H, the numbered tracks (or files) are played sequentially, from 1 through 7. For JPEG image files, press to go to the next album. (For instance, when you want to go from 1 to 2.) Any sub-albums/tracks (or files) contained within a currently selected album take priority over the next album in the same tree. (Example: C contains D so 4 is played before 5.)

z Hints

• If you add numbers (01, 02, 03, etc.) to the front of the track/file names when you store the tracks (or files) in a disc, the tracks and files will be played in that order.

• Since a disc with many trees takes longer to start playback, it is recommended that you create albums with no more than two trees.

Page 68

Erasing and Editing

Before Editing

This recorder offers various edit options for various disc types.

b Notes

• You may lose the edited contents if you remove

the disc or a timer recording starts while editing.

• DVD discs created by DVD video cameras

cannot be edited on this recorder.

• If a message appears and indicates that the disc’s

control information is full, erase or edit unnecessary titles.

• When editing a DVD+R or DVD-R, finish all

editing before finalising the disc. You cannot edit a finalised disc.

RWVR

RVR

Original title

Playlist title

Edit features

HDD

Original title

Playlist title

Erase (page 69) Yes Yes Yes Yes Yes

Protect (page 69) Yes Yes Yes No Yes

Title Name (page 69) Yes Yes Yes Yes Yes

A-B Erase (page 70) Yes Yes Yes Yes Yes*

Erase Titles (page 70) Yes Yes Yes Yes Yes

Divide (page 71) Yes Yes No Yes No

Set Thumbnail (page 69) Yes Yes Yes Yes No

Chapter mark (page 72) Yes Yes Yes Yes No

Creating and Editing a

YesYesYesYesNo

Playlist (page 72)

Change Order (page 74) No No No Yes No

Combine (page 74) No Yes No Yes No

* DVD+RW only

Video

Page 69

To open up disc space

To open up disc space on a DVD+RW or DVD-RW (Video mode), erase the title with the largest number in the title list.

Largest title number

For the HDD and DVD-RWs (VR mode), you can erase any title. For DVD-Rs and DVD+Rs, the available disc space does not increase even if you erase titles. See “Erasing and Editing a Title” on page 69 or “Erasing multiple titles (Erase Titles)” on page 70.

To switch between the Playlist and Original Title List

You can display the Playlist titles in the Title List (Playlist), or the Original titles in the Title List (Original). To switch the two Title Lists, press

</, while a Title List is

displayed. To create and edit a Playlist, see page 72.

Erasing and Editing a Title

HDD

RVR-R

Video

RWVR-RW

This section explains the basic edit functions. Note that editing is irreversible. To edit the HDD or DVD-RWs/DVD-Rs (VR mode) without changing the original recordings, create a Playlist title (page 72).

CHAPTER MARK

RETURN

Video

CHAPTER MARK ERASE

TITLE LIST

</M/m/,, ENTER

OPTIONS

Erasing and Editing

1 Press TITLE LIST.

For HDD titles or DVD-RWs/DVD-Rs in VR mode, press

</, to switch the

Title Lists, if necessary.

2 Select a title, and press ENTER.

The sub-menu appears.

3 Select an option, and press ENTER.

You can make the following edits to the title. “Erase”: Erases the selected title. Select “OK” when asked for confirmation. “Protect”: Protects the title. “ ” appears next to the protected title. “Title Name”: Allows you to enter or reenter a title name (page 31). “A-B Erase”: Erases a section of the title (page 70).

,continued

Page 70

“Divide”: Divides a title into two titles (page 71). “Set Thumbnail”: Changes the title’s thumbnail picture that appears in the Title List (page 27). “Make a Playlist”: Adds the entire title to the Playlist title as one scene (page 74).

z Hints

• You can erase multiple titles at one time

(page 70).

• You can automatically erase titles that have

already played (page 97).

• You can label or re-label DVDs (page 32).

b Note

DVD-RW/DVD-R (VR mode) playlist titles cannot be protected.

Erasing multiple titles (Erase Titles)

RWVR-RW

Video

HDD

RVR

You can select and erase more than one title at one time using the OPTIONS menu.

Video

1 Press TITLE LIST.

For HDD titles or DVD-RWs/DVD-Rs in VR mode, press Title Lists, if necessary.

</, to switch the

2 Press OPTIONS to select “Erase

Titles,” and press ENTER.

The display for selecting titles to be erased appears.

4 Repeat step 3 to select all of the titles

you want to erase.

5 When you finish selecting titles,

select “OK,” and press ENTER.

The list of the titles to be erased appears for confirmation.

• To change the selection, select “Change,” and repeat from step 3.

6 Select “OK” and press ENTER.

The titles are erased.

To erase all titles on the disc

You can reformat the HDD, DVD+RW, or DVD-RW to make the disc or drive blank. To format the HDD, see “Format” on page 101. To format a DVD+RW or DVD-RW disc, see “8. Reformatting a disc” on page 35.

Erasing a section of a title (A-B Erase)

HDD

You can select a section (scene) in a title and erase it. Note that erasing scenes in a title cannot be undone.

RWVR

RVR

1 After step 2 of “Erasing and Editing a

Title,” select “A-B Erase” and press ENTER.

The display for setting point A appears. The title starts to play.

• To return to the beginning of the title, press X and then press ..

3 Select a title, and press ENTER.

A check mark appears in the check box next to the selected title.

• To clear the check mark, press ENTER again.

• To clear all of check marks, select “Reset.”

Playback point

2 Select point A using m/M, and

press ENTER.

Playback pauses.

Page 71

3 Press ENTER if point A is correct.

If point A is incorrect, select point A using c/C, and press ENTER. The display for setting point B appears.

4 Select point B using m/M, and

press ENTER.

Playback pauses.

5 Press ENTER if point B is correct.

If point B is incorrect, select point B using c/C, and press ENTER. The display asks for confirmation.

• To reset point A, press M and

O RETURN, and go to step 2.

• To reset point B, press M and repeat

step 4.

• To preview the title without scenes to be erased, select “Preview” (except for DVD+RWs).

6 Select “OK,” and press ENTER.

The scene is erased. The display for setting point A appears.

• To continue, go to step 2.

• To finish, select “Quit.”

z Hint

A chapter mark is inserted after the scene was erased. The chapter mark divides the title into separate chapters on either side of the mark.

Dividing a title (Divide)

HDD

If you want to dub a long title to a disc but do not want to reduce the picture quality, divide the title into two shorter titles. Note that dividing a title cannot be undone.

* Only playlist titles can be divided for DVD-RWs/

RWVR

DVD-Rs (VR mode).

RVR

1 Press TITLE LIST.

Press </, to switch the Title Lists, if necessary.

2 Select a title, and press ENTER.

The sub-menu appears.

3 Select “Divide,” and press ENTER.

The display for setting the dividing point appears, and the title starts to play.

• To return to the beginning of the title,

press X and then press ..

Erasing and Editing

b Notes

• Images or sound may be momentarily interrupted at the point where you erase a section of a title.

• Sections shorter than five seconds may not be erased.

• For DVD+RWs, the erased section may be slightly different from the points you selected.

4 Select the dividing point by pressing

m/M, and press ENTER.

Playback pauses.

5 Press ENTER if the dividing point is

correct.

If the dividing point is incorrect, select the dividing point using c/C, and press ENTER. The display asks for confirmation.

• To change the dividing point, press

6 Select “OK,” and press ENTER.

The title is divided in two.

z Hint

After a title is divided, the title name prior to division is assigned to both the first and second parts.

,continued

Page 72

Creating chapters manually

HDD

You can manually insert a chapter mark at any point you like during playback.

Press CHAPTER MARK at the point where you want to divide the title into chapters.

Each time you press the button, “Marking ...” appears on the screen and the scenes to the left and right of the mark become separate chapters.

To erase chapter marks

You can combine two chapters by erasing the chapter mark during playback. Press ./> to search for a chapter number, and while displaying the chapter containing the chapter mark you want to erase, press CHAPTER MARK ERASE. The current chapter combines with the previous chapter.

b Note

When dubbing, any chapter marks you enter will be erased.

RWVR

RVR

Creating and Editing a Playlist

HDD

Playlist edit allows you to edit or re-edit without changing the actual recordings. You can create up to 97 Playlist titles.

Example: You have recorded the final few matches of a football tournament on a DVDRW/DVD-R (VR mode). You want to create a digest with the goal scenes and other highlights, but you also want to keep the original recording.

Original

Playlist

In this case, you can compile highlight scenes as a Playlist title. You can even rearrange the scene order within the Playlist title. The Playlist title calls up data from the original titles for playback. When an original title is used for a Playlist title, the original title cannot be edited and erased.

RWVR

RVR

b Note

Playlist titles containing titles recorded with the “Copy-Once” copy protection signal cannot be dubbed or moved (page 78).

1 Press TITLE LIST.

If the Title List (Original) appears, press <.

2 Press OPTIONS to select “Create a

Playlist,” and press ENTER.

Page 73

3 Select “Select,” and press ENTER.

4 Select the title you want to include in

the Playlist title, and press ENTER.

The display for setting the start point (IN) appears. The title starts to play.

• To return to the beginning of the title,

press X and then press ..

5 Select the IN point using m/M,

and press ENTER.

Playback pauses.

6 Press ENTER if the IN point is correct.

If the IN point is incorrect, select the IN point using c/C, and press ENTER. The display for setting the end point (OUT) appears.

7 Select the OUT point using m/M,

and press ENTER.

Playback pauses.

8 Press ENTER if the OUT point is

correct.

If the OUT point is incorrect, select the OUT point using c/C, and press ENTER. The selected scene is added to the scene list.

• To add more scenes, go to step 5.

9 When you finish adding scenes, press

A Total duration of the selected

scene

B Total number of scenes C Selected scene

Select the scene you want to re-edit, and press ENTER.

The sub-menu appears. “Move”: Changes the scene order using </, and press ENTER. “Erase”: Erases the scene. When asked for confirmation, select “OK.”

• To add more scenes, press M and go to

step 5.

• To add more scenes from another title, select “Select” and go to step 4.

• To preview all of the captured scenes in the listed order, select “Preview.”

When you finish editing the scene list, select “OK,” and press ENTER.

The title of the created Playlist is added to the Title List (Playlist). The title name is the title name of the first scene.

z Hint

When a Playlist title is created, the IN and OUT points will become chapter marks, and each scene will become a chapter.

b Note

The picture may pause when the edited scene is played.

Erasing and Editing

,continued

Page 74

To add the entire title to the Playlist title as one scene (Make a Playlist)

1 Press TITLE LIST. If the Title List

(Playlist) appears, press ,.

2 Select the title and press ENTER.

The sub-menu appears.

3 Select “Make a Playlist,” and press

ENTER. The selected title is added to the Title List (Playlist). The title name is the same as the Original title name.

To play the Playlist title

1 Press TITLE LIST. If the Title List

(Original) appears, press <.

2 Select a title, and press ENTER.

The sub-menu appears.

3 Select “Play,” and press ENTER.

Moving a Playlist title (Change Order)

RWVR-RVR

You can change the Playlist title order within the Title List (Playlist).

1 Press TITLE LIST.

If the Title List (Original) appears, press

2 Press OPTIONS to select “Change

Order,” and press ENTER.

Combining multiple Playlist titles (Combine)

HDD

RWVR

RVR

1 Press TITLE LIST.

If the Title List (Original) menu appears, press <.

2 Press OPTIONS to select “Combine,”

and press ENTER.

The display for selecting titles appears.

3 Select a title, and press ENTER.

A number indicating the order in which you selected the title appears. To cancel the selection, press ENTER again.

4 Repeat step 3 to select all of the titles

you want to combine.

To cancel all of the selections, select “Reset.”

5 Select “OK,” and press ENTER.

The list of titles to be combined appears. To change the selection, select “Change” and go to step 3.

3 Select the title you want to move, and

press ENTER.

4 Select a new location for the title

using M/m, and press ENTER.

The title moves to the new location.

• To move more titles, go to step 3.

• To finish, select “Quit,” and press ENTER.

6 Select “OK,” and press ENTER.

The titles are combined.

z Hint

After titles are combined, the title name is the title name of the first title prior to combination.

Page 75

b Note

When the number of chapters in the title to be combined exceeds the limit, the chapters at the end are combined into a single chapter.

Dividing a Playlist title (Divide)

HDD

You can divide a Playlist title. For operations, see page 71.

RWVR

RVR

Erasing and Editing

Page 76
