To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To avoid electrical shock, do not
open the cabinet. Refer s ervicing to
qualified personnel only.
The mains lead must be changed
only at a qualified service shop.
This appliance is classified as a
CLASS 1 LASER product. The
CLASS 1 LASER PRODUCT
MARKING is located on the laser
protective housing inside the
enclosure.
CAUTION
The use of optical instruments with
this product will increase eye
hazard. As the laser beam used in
this DVD recorder is harmful to
eyes, do not attempt to disassemble
the cabinet.
Refer servicing to qualified
personnel only.
This label is located on the laser
protective housing inside the
enclosure.
Notice for customers in the
United Kingdom and
Republic of Ireland
A molded plug complying with
BS1363 is fitted to this equipment
for your safety and convenience.
Should the fuse in the plug
supplied need to be replaced, a 5
AMP fuse approved by ASTA or
BSI to BS1362, (i.e., marked with
or mark) must be used.
If the plug supplied with this
equipment has a detachable fuse
cover, be sure to attach the fuse
cover after you change the fuse.
Never use the plug without the fuse
cover. If you should lose the fuse
cover, please contact your nearest
Sony service station.
Precautions
• This unit operates on 220 –
240 V AC, 50/60 Hz. Check that
the unit’s operating voltage is
identical with your local power
supply.
• To prevent fire or shock hazard,
do not place objects filled with
liquids, such as vases, on the
apparatus.
• Install this system so that the
mains lead can be unplugged
from the wall socket
immediately in the event of
trouble.
GUIDE Plus+, VIDEO Plus+, GLINK are (1) registered trademarks
or trademarks of, (2) manufactured
under license from and (3) subject
of various international patents and
patent applications owned by, or
licensed to, Gemstar-TV Guide
International, Inc. and/or its relate d
affiliates.
GEMSTAR-TV GUIDE
INTERNATIONAL, INC. AND/
OR ITS RELATED AFFILIATES
ARE NOT IN ANY WAY
LIABLE FOR THE ACCURACY
OF THE PROGRAM
SCHEDULE INFORMATION
PROVIDED BY THE GUIDE
PLUS+ SYSTEM. IN NO EVENT
SHALL GEMSTAR-TV GUIDE
INTERNATIONAL, INC. AND /
OR ITS RELATED AFFILIATES
BE LIABLE FOR ANY
AMOUNTS REPRESENTING
LOSS OF PROFITS, LOSS OF
BUSINESS, OR INDIRECT,
SPECIAL, OR
CONSEQUENTIAL DAMAGES
IN CONNECTION WITH THE
PROVISION OR USE OF ANY
INFORMATION, EQUIPMENT,
OR SERVICES RELATING TO
THE GUIDE PLUS+ SYSTEM.
Disposal of Old Electrical
& Electronic Equipment
(Applicable in the
European Union and
other European countries
with separate collection
systems)
This symbol on the product or on
its packaging indicates that this
product shall not be treated as
household waste. Instead it shall be
handed over to the applicable
collection point for the recycling of
electrical and electronic
equipment. By ensuring this
product is disposed of correctly,
you will help prevent potential
negative consequences for the
environment and human health,
which could otherwise be caused
by inappropriate waste handling of
this product. The recycling of
materials will help to conserve
natural resources. For more
detailed information about
recycling of this product, please
contact your local Civic Office,
your household waste disposal
service or the shop where you
purchased the product.
2
Precautions
This equipment has been tested
and found to comply with the
limits set out in the EMC
Directive using a connection
cable shorter than 3 metres.
On safety
Should any solid object or liquid
fall into the cabinet, unplug the
recorder and have it checked by
qualified personnel before
operating it any further.
About the hard disk drive
The hard disk has a high storage
density, which enables long
recording durations and quick
access to the written data.
However, it can easily be
damaged by shock, vibration or
dust, and should be kept away
from magnets. To avoid losing
important data, observe the
following precautions.
• Do not apply a strong shock to
the recorder.
• Do not place the recorder in a
location subject to mechanical
vibrations or in an unstable
location.
• Do not place the recorder on
top of a hot surface, such as a
VCR or amplifier (receiver).
• Do not use the recorder in a
place subject to extreme
changes in temperature
(temperature gradient less than
10 °C/hour).
• Do not move the recorder with
its mains lead connected.
• Do not disconnect the mains
lead while the power is on.
• When disconnecting the mains
lead, turn off the power and
make sure that the hard disk
drive is not operating (the
clock is displayed in the front
panel display and a ll recording
or dubbing has stopped).
• Do not move the recorder for
one minute after you have
unplugged the mains lead.
• Do not attempt to replace or
upgrade the hard disk by
yourself, as this may result in
malfunction.
If the hard disk drive should
malfunction, you ca nnot recover
lost data. The hard disk drive is
only a temporary storage space.
About repairing the hard
disk drive
• The contents of the hard disk
drive may be checked in case
of repair or inspection du ring a
malfunction or modification.
However, the contents will not
be backed up or saved by
Sony.
• If the hard disk needs to be
formatted or replaced, it will
be done at the discretion of
Sony. All contents of the hard
disk drive will be erased,
including contents that violate
copyright laws.
On power sources
• The recorder is not
disconnected from the AC
power source (mains) as long
as it is connected to the wall
outlet, even if the recorder
itself has been turned off.
• If you are not going to use the
recorder for a long time, be
sure to disconnect the recorder
from the wall outlet. To
disconnect the AC power cord
(mains lead), grasp the plug
itself; never pull the cord.
• Before disconnecting the AC
power cord (mains lead),
check that the recorder’s hard
disk is not operating
(recording or dubbing) on the
front panel display.
On placement
• Place the recorder in a location
with adequate ventilation to
prevent heat build-up in the
recorder.
• Do not place the recorder on a
soft surface such as a rug that
might block the ventilation
holes.
• Do not place the recorder in a
confined space such as a
bookshelf or similar unit.
• Do not place the recorder in a
location near heat sources, or
in a place subject to direct
sunlight, excessive dust, or
mechanical shock.
• Do not place the recorder in an
inclined position. It is
designed to be operated in a
horizontal position only.
• Keep the recorder and discs
away from equipment with
strong magnets, such as
microwave ovens, or large
loudspeakers.
• Do not place heavy objects on
the recorder.
On recording
Make trial recordings before
making the actual recording.
On compensation for lost
recordings
Sony is not liable and will not
compensate for any lost
recordings or relevant losses,
including when recordings are
not made due to reasons
including recorder failure, or
when the contents of a recording
are lost or damaged as a result of
recorder failure or repair
undertaken to the recorder. Sony
will not restore, recover, or
replicate the recorded contents
under any circumstances.
,continued
3
Copyrights
• Television programmes, films,
video tapes, discs, and other
materials may be copyrighted.
Unauthorized recording of
such material may be contrary
to the provisions of the
copyright laws. Also, use of
this recorder with cable
television transmission may
require authorization from the
cable television transmitter
and/or programme owner.
• This product incorporates
copyright protection
technology that is pr otected by
U.S. patents and other
intellectual property rights.
Use of this copyright
protection technology must be
authorized by Macrovision,
and is intended for home and
other limited viewing uses
only unless otherwise
authorized by Macrovision.
Reverse engineering or
disassembly is prohibited.
Copy guard function
Since the recorder has a copy
guard function, programmes
received through an external
tuner (not supplied) may contain
copy protection signals (copy
guard function) and as such may
not be recordable, depending on
the type of signal.
IMPORTANT NOTICE
Caution: This recorder is
capable of holding a still
video image or on-screen
display image on your
television screen
indefinitely. If you leave the
still video image or onscreen display image
displayed on your TV for an
extended period of time you
risk permanent damage to
your television screen.
Plasma display panels and
projection televisions are
especially susceptible to this.
If you have any questions or
problems concerning your
recorder, please consult your
nearest Sony dealer.
About this manual
Check your model name
The instructions in this
manual are for 2 models:
RDR-HX525 and RDRHX725. Check your model
name by looking at the front
panel of the recorder.
• In this manual, the internal
hard disk drive is written as
“HDD,” and “disc” is used as a
general reference for the HDD,
DVDs, or CDs unless
otherwise specified by the text
or illustrations.
• Icons, such as , listed
at the top of each explanation
indicate what kind of media
can be used with the function
being explained.
• Instructions in this manual
describe the controls on the
remote. You can also use the
controls on the recorder if they
have the same or similar
names as those on the remote.
• The on-screen display
illustrations used in this
manual may not match the
graphics displayed on your TV
screen.
• The explanations regarding
DVDs in this manual refer to
DVDs created on this recorder.
The explanations do not apply
to DVDs that are created on
other recorders and played
back on this recorder.
Automatically
formatted in
+VR mode
(DVD+RW
VIDEO)
Format in VR
mode (page 32)
Format in
Video mode
(page 32)
Automatically
formatted in
+VR mode
(DVD+R
VIDEO)
Compatibility with other DVD
players (finalising)
Dub HDD contents to a DVD
to play on other DVD players
Playable on DVD+RW
compatible players
(automatically finalised)
Playable only on VR mode
compatible players
(finalisation unnecessary)
Playable on most DVD
players (finalisation
necessary) (page 40)
Playable on most DVD
players (finalisation
necessary) (page 40)
Format in VR
DVD-R
VR
mode
-
RVR
mode
(page 32)
Formatting is
performed
using the “Disc
Information”
*1
Playable only on DVD-R in
VR mode compatible players
(finalisation necessary)
(page 40)
display.
Video
mode
Automatically
Video
formatted in
Video mode
-
R
Playable on most DVD
players (finalisation
necessary) (page 40)
8
Usable disc versions (as of March 2006)
• 8x-speed or slower DVD+RWs
• 6x-speed or slower DVD-RWs (Ver.1.1,
Ver.1.2 with CPRM
*2
)
• 16x-speed or slower DVD+Rs
• 16x-speed or slower DVD-Rs (Ver.2.0,
Ver.2.1 with CPRM
*2
)
• 8x-speed or slower DVD+R DL (Double
Layer) discs
“DVD+RW,” “DVD-RW,” “DVD+R,” “DVD+R
DL,” and “DVD-R” are trademarks.
*1
When an unformatted DVD-R is inserted into
this recorder, it is automatically formatted in
Video mode. To format a new DVD-R in VR
mode, format using the “Disc Information”
display (page 32).
*2
CPRM (Content Protection for Recordable
Media) is a coding technology that protects
copyrights for images.
Discs that cannot be recorded on
• 8 cm discs
• DVD-R DL (Dual Layer) discs
,continued
9
Playable discs
TypeDisc Logo
DVD VIDEO
VIDEO CD
CD
DATA DVD—
DATA CD—
8 cm DVD+RW/
DVD-RW/DVD-R
——
Icon used in
this manual
DVD
VCD
CD
DATA DVD
DATA CD
Characteristics
Discs such as movies that can be
purchased or rented
This recorder also recognizes DVD-R
Dual Layer (Video mode) discs as DVD
Video compatible discs.
VIDEO CDs or CD-Rs/CD-RWs in
VIDEO CD/Super VIDEO CD format
CD-ROMs/CD-Rs/CD-RWs
containing either MP3 audio tracks or
JPEG image files
8 cm DVD+RW, DVD-RW, and
DVD-R recorded with a DVD video
camera
(Still images recorded with a DVD
video camera cannot be played.)
“DVD VIDEO” and “CD” are trademarks.
Discs that cannot be played
• PHOTO CDs
• CD-ROMs/CD-Rs/CD-RWs that are
recorded in a format different from the
formats mentioned in the table above.
• Data part of CD-Extras
• DVD-ROMs/DVD+RWs/DVD-RWs/
DVD+Rs/DVD-Rs that do not contain
DVD Video or JPEG image files.
• DVD Audio discs
• DVD-RAMs
• HD layer on Super Audio CDs
• DVD VIDEOs with a different region code
(page 11).
• DVDs that were recorded on a different
recorder and not correctly finalised.
10
Maximum recordable number of titles
DiscNumber of titles*
HDD300
DVD-RW/DVD-R99
DVD+RW/DVD+R49
DVD+R DL49
* The maximum length for one title is eight hours.
Note on playback operations of DVD
VIDEOs/VIDEO CDs
Some playback operations of DVD VIDEOs/
VIDEO CDs may be intentionally set by
software producers. Since this recorder plays
DVD VIDEOs/VIDEO CDs according to the
disc contents the software producers
designed, some playback features may not be
available. See the instructions supplied with
the DVD VIDEOs/VIDEO CDs.
Region code (DVD VIDEO only)
Your recorder has a region code printed on
the rear of the unit and will only play DVD
VIDEOs (playback only) labelled with
identical region codes. This system is used to
protect copyrights.
DVD VIDEOs labelled will also play
ALL
on this recorder.
If you try to play any other DVD VIDEO, the
message “Playback prohibited by region
code.” will appear on the TV screen.
Depending on the DVD VIDEO, no region
code indication may be labelled even though
playing the DVD VIDEO is prohibited by
area restrictions.
Region code
Note on DualDiscs
A DualDisc is a two sided disc product which
mates DVD recorded material on one side
with digital audio material on the other side.
However, since the audio material side does
not conform to the Compact Disc (CD)
standard, playback on this product is not
guaranteed.
b Notes
• Some DVD+RWs/DVD+Rs, DVD-RWs/DVDRs, or CD-RWs/CD-Rs cannot be played on this
recorder due to the recording quality or physical
condition of the disc, or the characteristics of the
recording device and authoring software. The
disc will not play if it has not been correctly
finalised. For more information, see the operating
instructions for the recording device.
• You cannot mix VR mode and Video mode on the
same DVD-RW. To change the disc’s format,
reformat the disc (page 42). Note that the disc’s
contents will be erased after reformatting.
• You cannot shorten the time required for
recording even with high-speed discs.
• It is recommended that you use discs with “For
Video” printed on their packaging.
• You cannot add new recordings to DVD+Rs,
DVD-Rs, or DVD-RWs (Video mode) that
contain recordings made on other DVD
equipment.
• In some cases, you may not be able to add new
recordings to DVD+RWs that contain recordings
made on other DVD equipment. If you do add a
new recording, note that this recorder will rewrite
the DVD menu.
• You cannot edit recordings on DVD+RWs,
DVD-RWs (Video mode), DVD+Rs, or DVD-Rs
that are made on other DVD equipment.
• If the disc contains PC data unrecognizable by
this recorder, the data may be erased.
• You may not be able to record on some
recordable discs, depending on the disc.
Music discs encoded with copyright
protection technologies
This product is designed to play back discs
that conform to the Compact Disc (CD)
standard.
Recently, various music discs encoded with
copyright protection technologies are being
marketed by some record companies. Please
be aware that among those discs, there are
some that do not conform to the CD standard
and may not be playable by this product.
11
Hookups and Settings
Hooking Up the Recorder
Follow steps 1 through 6 to hook up and adjust the settings of the recorder. Do not connect the
mains lead until you reach “Step 4: Connecting the Mains Lead” on page 20.
b Notes
• See “Specifications” (page 115) for a list of supplied accessories.
• Plug in cords securely to prevent unwanted noise.
• Refer to the instructions supplied with the components to be connected.
• You cannot connect this recorder to a TV that does not have a SCART or video input jack.
• Be sure to disconnect the mains lead of each component before connecting.
12
Step 1: Connecting the Aerial Cable and Set Top Box
Controller
Select one of the following aerial hookups. Do NOT set “Line3 Input” of the “Scart Setting” to
“Decoder” in the “Video” setup (page 99) when making connection A or B.
If you haveHookup
Set top box receiver with an aerial output (or aerial and SCART
output)
Set top box receiver with a SCART output onlyB (page 15)
No set top box receiverC (page 16)
A (page 14)
If the set top box receiver can output RGB signals
This recorder accepts RGB signals. If the set top box receiver can output RGB signals, connect
the TV SCART connector on the set top box receiver to the LINE 3/DECODER jack, and set
“Line3 Input” of “Scart Setting” to “Video/RGB” in the “Video” setup (page 98). Note that this
connection and setup disable the SMARTLINK function. If you want to use the SMARTLINK
function with a compatible set top box receiver, see the instructions supplied with the set top
box receiver.
If you want to use the Synchro Rec function
A SCART connection between the set top box receiver and the recorder is necessary to use the
Synchro-Recording function. See “Recording from connected equipment with a timer (Synchro
Rec)” on page 61.
Set “Line3 Input” of “Scart Setting” in the “Video” setup (page 98) according to the
specifications of your set top box receiver. See your set top box receiver’s instructions for more
information.
If you are using a B Sky B tuner, be sure to connect the tuner’s VCR SCART jack to the LINE
3/DECODER jack. Then set “Line3 Input” of “Scart Setting” according to the specifications of
the VCR SCART jack on your set top box receiver.
Hookups and Settings
Using the set top box receiver control function
The set top box receiver control function can be used with hookup A or B. It allows the recorder
to control a set top box receiver via the supplied set top box controller. The recorder controls
programme positions on the set top box receiver for timer recording. You can also use the
recorder’s remote control to change programme positions on the set top box receiver whenever
the set top box receiver and recorder are turned on.
To use the set top box receiver control function, you need to connect the set top box controller
(page 24). After setting up the set top box receiver control, check that the recorder can correctly
control the set top box receiver (page 25).
b Notes
• If your aerial is a flat cable (300-ohm twin lead cable), use an external aerial connector (not supplied) to
connect the aerial to the recorder.
• If you have separate cables for AERIAL antennas, use an AERIAL UHF/VHF band mixer (not supplied)
to connect the aerial to the recorder.
• Synchro-Recording does not work with some tuners. For details, see the tuner’s operating instructions.
• If you disconnect the recorder’s mains lead, you will not be able to view the signals from the connected
set top box receiver.
,continued
13
A: Set top box receiver with an aerial output (or aerial and SCART
output)
With this hookup, you can record any programme position on the set top box receiver.
To watch cable programmes, you need to match the programme position on the recorder to the
aerial output programme position on the cable box.
Place the set
Wall
Aerial cable
(supplied)
to AERIAL IN
Set top box
receiver
to AERIAL OUT
ANT IN
TO TV
Set top box
controller
(page 13)
SCART cord*
(not supplied)
to G-LINK
top box
controller
near the
remote
sensor on the
set top box
receiver.
DVD recorder
to aerial input
: Signal flow
* Connect only if your set top box receiver has a SCART connection.
14
TV
.
B: Set top box receiver with a SCART output only
With this hookup, you can record any programme position on the set top box receiver. Be sure
that the set top box receiver is turned on.
To watch cable or satellite programmes, you need to match the programme position on the
recorder to the input jack connected to the set top box receiver (i LINE 3/DECODER).
Place the set top box controller
near the remote sensor on the set
top box receiver.
Set top box
controller
(page 13)
Set top box receiver
to SCART output
SCART cord
(not supplied)
ANT IN
TO TV
Aerial cable
(supplied)
to aerial input
Wall
TV
Hookups and Settings
to G-LINK
: Signal flow
to i LINE 3/DECODER
DVD recorder
,continued
15
C: No set top box receiver
Use this hookup if you watch cable programme position without a cable box. Also use this
hookup if you are connecting just an aerial antenna.
With this hookup, you can record any programme position by selecting the programme position
on the recorder.
Wall
to AERIAL IN
to AERIAL OUT
Aerial cable (supplied)
: Signal flow
DVD recorder
TV
to aerial input
16
Step 2: Connecting the Video Cords
Select one of the following patterns, A through D, according to the input jack on your TV
monitor, projector, or AV amplifier (receiver). This will enable you to view pictures.
INPUT
B
TV, projector, or AV
amplifier (receiver)
VIDEO
L
AUDIO
R
Audio/video cord
(not supplied)
to LINE 2 OUT (VIDEO)
(yellow)
SCART cord
(not supplied)
to i LINE 1 – TV
A
TV
DVD recorder
Hookups and Settings
to LINE 2 OUT (S VIDEO)
C
TV, projector, or AV
amplifier (receiver)
INPUT
S VIDEO
: Signal flow
to COMPONENT
VIDEO OUT
S-video cord
(not supplied)
A SCART input jack
When you set “Easy Setup - Line1 Output” to
“S Video” or “RGB” (page 24), use a
SCART cord that conforms to the selected
signal.
B Video input jack
You will enjoy standard quality images.
C S VIDEO input jack
You will enjoy high quality images.
(red)
Component
video cord
(not supplied)
(green)(blue)
COMPONENT
VIDEO IN
PB/CB
PR/CR
TV, projector, or AV
amplifier (receiver)
Y
(green)
(blue)
(red)
D Component video input jacks (Y, PB/CB,
R/CR)
P
You will enjoy accurate colour reproduction
and high quality images.
If your TV accepts progressive 525p/625p
format signals, you must use this connection
and set “Component Out” in the “Video”
setup to “On” (page 98). Then set
“Progressive Output” of the “Video Output”
to “On” in the “Video” setup to send
progressive video signals. For details, see
“Progressive Output” on page 98.
D
,continued
17
When playing “wide screen” images
Some recorded images may not fit your TV
screen. To change the picture size, see
page 97.
If you are connecting to a VCR
Connect your VCR to the LINE 3/
DECODER jack on the recorder (page 27).
b Notes
• Do not connect more than one type of video cord
between the recorder and your TV at the same
time.
• W hen you connect the recorder to your TV via the
SCART jacks, the TV’s input source is set to the
recorder automatically when you start playback.
If necessary, press TV t to return the input to
the TV.
• For correct SMARTLINK connection, you will
need a SCART cord that has the full 21 pins.
Refer to your TV’s instruction manual as well for
this connection.
• If you connect this recorder to a TV with
SMARTLINK, set “Easy Setup - Line1 Output”
to “Video.”
About the SMARTLINK
features (for SCART
connections only)
If the connected TV (or other connected
equipment such as a set top box) complies
with SMARTLINK, NexTView Link
MEGALOGIC
CINEMALINK
*4
LINK
*1
, EASYLINK*2,
*2
, Q-Link*3, EURO VIEW
, or T-V LINK*5, you can enjoy the
following SMARTLINK features.
• Preset Download
You can download the tuner preset data
from your TV to this recorder, and tune the
recorder according to that data in “Easy
Setup.” This greatly simplifies the “Easy
Setup” procedure. Be careful not to
disconnect the cables or exit the “Easy
Setup” function during this procedure
(page 24).
• TV Direct Rec
You can easily record what you are
watching on your TV (page 33).
• One Touch Play
You can turn on the recorder an d TV, set the
TV’s input to the recorder, and start
playback with one touch of the H (play)
button (page 65).
*3
,
• One Touch Menu
You can turn on the recorder and TV, set the
TV to the recorder’s programme position,
and display the Title List menu with one
touch of the TITLE LIST button (page 65).
• One Touch EPG
You can turn on the recorder and TV, set the
TV to the recorder’s programme position,
and display the GUIDE Plus+ system
“Home Screen” with one touch of the TV
GUIDE button on the remote.
• Automatic Power Off
The recorder will turn off automatically if
the recorder is not used after you turn off
the TV.
• NexTView Download
You can easily set the timer by using the
NexTView Download function on your TV.
See your TV’s instruction manual.
*1
“MEGALOGIC” is a registered trademark of
Grundig Corporation.
*2
“EASYLINK” and “CINEMALINK” are
trademarks of Philips Corporation.
*3
“Q-Link” and “NexTView Link” are trademarks
of Panasonic Corporation.
*4
“EURO VIEW LINK” is a trademark of Toshiba
Corporation.
*5
“T-V LINK” is a trademark of JVC Corporation.
z Hint
SMARTLINK also works with TVs or other
equipment having EPG Timer Control, EPG Title
Download, and Now Recording functions. For
details, refer to the operating instructions supplied
with your TV or other equipment.
b Notes
• The SMARTLINK features are available only
when “Video” is selected in “Line1 Output.”
• The power must be turned on to use all
SMARTLINK features except One Touch Play,
One Touch Menu and One Touch EPG.
• Not all TVs respond to the functions above.
18
Step 3: Connecting the Audio Cords
Select one of the following patterns, A or B, according to the input jack on your TV monitor,
projector, or AV amplifier (receiver). This will enable you to listen to sound.
[Speakers]
Rear (L)
Front (L)
AV amplifier (receiver)
with a decoder
[Speakers]
Rear (R)
Front (R)
A
Hookups and Settings
Centre
: Signal flow
to DIGITAL OUT (COAXIAL)
to LINE 2 OUT (R-AUDIO-L)
Audio/video cord
(white)
(red)
(yellow)*
(not supplied)
Subwoofer
to coaxial digital input
Coaxial digital cord (not supplied)
DVD recorder
INPUT
(yellow)
(white)
(red)
VIDEO
L
AUDIO
R
TV, projector, or AV
amplifier (receiver)
B
* The yellow plug is used for video signals (page 17).
A Digital audio input jack
If your AV amplifier (receiver) has a Dolby
Digital, DTS
*2
, or MPEG audio decoder and
*1
a digital input jack, use this connection. You
can enjoy Dolby Digital (5.1ch), DTS
(5.1ch), and MPEG audio (5.1ch) surround
effects.
B Audio L/R (left/right) input jacks
This connection will use your TV’s or stereo
amplifier’s (receiver’s) two speakers for
sound.
z Hint
For correct speaker location, see the operating
instructions supplied with the connected
components.
,continued
19
b Notes
• Do not connect your TV’s audio output jacks to
the LINE IN (R-AUDIO-L) jacks at the same
time. This will cause unwanted noise to come
from your TV’s speakers.
• With connection B, do not connect the LINE IN
(R-AUDIO-L) and LINE 2 OUT (R-AUDIO-L)
jacks to your TV’s audio output jacks at the same
time. This will cause unwanted noise to come
from your TV’s speakers.
• W ith connection A, after you have completed the
connection, make the appropriate settings under
“Easy Setup - Audio Connection” (page 24).
Otherwise, no sound or a loud noise will come
from your speakers.
*1
Manufactured under license from Dolby
Laboratories.
“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
*2
“DTS” and “DTS Digital Out” are trademarks of
Digital Theater Systems, Inc.
Step 4: Connecting the
Mains Lead
Connect the supplied mains lead to the AC IN
terminal of the recorder. Then plug the
recorder and TV mains leads (power cords)
into the mains. After you connect the mains
lead, you must wait for a short while before operating the recorder. You can
operate the recorder once the front panel
display lights up and the recorder enters
standby mode.
If you connect additional equipment to this
recorder (page 27), be sure to connect the
mains lead after all connections are complete.
~ AC IN
1
to AC IN
2
to mains
20
Step 5: Preparing the
Remote
You can control the recorder using the
supplied remote. Insert two R6 (size AA)
batteries by matching the 3 and # ends on
the batteries to the markings inside the
battery compartment. When using the
remote, point it at the remote sensor on the
recorder.
b Notes
• If the supplied remote interferes your other Sony
DVD recorder or player, change the command
mode number for this recorder (page 22).
• Use the batteries correctly to avoid possible
leakage and corrosion. Should leakage occur, do
not touch the liquid with bare hands. Observe the
following:
– Do not use a new battery with an old battery, or
batteries of different manufacturers.
– Do not attempt to recharge the batteries.
– If you do not intend to use the remote for an
extended period of time, remove the batteries.
– If battery leakage occurs, wipe out any liquid
inside the battery compartment, and insert new
batteries.
• Do not expose the remote sensor (marked on
the front panel) to strong light, such as direct
sunlight or a lighting apparatus . The recorder may
not respond to the remote.
Controlling TVs with the
remote
You can adjust the remote’s signal to control
your TV.
b Notes
• Depending on the connected unit, you may not be
able to control your TV with some or all of the
buttons below.
• If you enter a new code number, the code number
previously entered will be erased.
• When you replace the batteries of the remote, the
code number may be reset to the default setting.
Set the appropriate code number again.
Number
buttons
TV/DVD
TV 2 +/–
TV PROG
+/–
TV [/1
TV t
1 Hold down the TV [/1 button located
at the bottom of the remote.
Do not press the [/1 button at the top of
the remote.
Hookups and Settings
,continued
21
2 With the TV [/1 button pressed down,
enter the TV’s manufacturer code
using the number buttons.
For instance, to enter “09,” press “0” then
“9.” After you enter the last number,
release the TV [/1 button.
Code numbers of controllable TVs
If more than one code number is listed,
try entering them one at a time until you
find the one that works with your TV.
ManufacturerCode number
Sony01 (default)
Hitachi24
JVC33
Panasonic17, 49
Philips06, 08
Samsung71
Sanyo25
Thomson43
Toshiba38
The remote performs the following:
ButtonsOperations
TV [/1Turns your TV on or
TV 2 (volume)
+/–
TV PROG +/–Selects the
TV tSwitches your TV’s
off
Adjusts the volume
of your TV
programme position
on your TV
input source
If you have a Sony DVD player
or more than one Sony DVD
recorder
If the supplied remote interferes with your
other Sony DVD recorder or player, set the
command mode number for this recorder and
the supplied remote to one that differs from
the other Sony DVD recorder or player after
you have completed “Step 6: Easy Setup.”
The default command mode setting for this
recorder and the supplied remote is DVD3.
Number
buttons
SYSTEM
MENU
M/m,
ENTER
1 Check that “Easy Setup” (page 24)
has been finished. If “Easy Setup” has
not been finished, first perform “Easy
Setup.”
2 Press SYSTEM MENU.
The System Menu appears.
3 Select “SETUP,” and press ENTER.
To operate the TV/DVD button
(for SCART connections only)
The TV/DVD button switches between the
recorder and the last input source selected on
the TV. Point your remote at the recorder
when using this button.
When you connect the recorder to the TV via
the SCART jacks, the input source for the TV
is set to the recorder automatically when you
start playback. To watch another source,
press the TV/DVD button to switch the TV’s
input source.
22
4 Select “Others,” and press ENTER.
5 Select “Command Mode,” and press
ENTER.
6 Select a Command Mode (DVD1,
DVD2, or DVD3), and press ENTER.
7 Set the Command Mode for the remote
so it matches the Command Mode for
the recorder you set above.
Follow the steps below to set the
Command Mode on the remote.
1 Hold down ENTER.
2 While holding down ENTER, enter
the Command Mode code number
using the number buttons.
Command Mode Code number
DVD1number button 1
DVD2number button 2
DVD3number button 3
3 Hold down both the number and
ENTER buttons at the same time for
more than three seconds.
If the Command Mode for the recorder has
not been changed, set the Command Mode
for the remote to the default setting of
DVD3. If the Command Mode for the
remote is changed to DVD1 or DVD2, you
will be unable to operate this recorder.
Changing programme positions
of the recorder using the
remote
You can change programme positions of the
recorder using the number buttons.
Number
buttons
ENTER
Example: for channel 50
Press “5,” “0,” then press ENTER.
Hookups and Settings
To check the Command Mode for the
recorder
Press x on the recorder when the recorder is
turned off. The Command Mode for the
recorder appears in the front panel display.
23
Step 6: Easy Setup
Make the basic adjustments by following the
on-screen instructions in “Easy Setup.”
[/1
TV GUIDE
</M/m/,,
O
RETURN
ENTER
TV [/1
1 Turn on the recorder and your TV.
Then switch the input selector on your
TV so that the signal from the recorder
appears on your TV screen.
The initial settings message appears.
• If this message does not appear, select
“Easy Setup” from “SETUP” in the
System Menu (“Settings and
Adjustments” on page 93).
2 Press ENTER.
Follow the on-screen instructions to
make the following settings.
Easy Setup - OSD
Select a language for the on-screen
displays.
Easy Setup - Tuner System
Select your country/region or language.
The programme position order will be set
according to the country/region you set.
To set the programme positions
manually, see page 93.
• If you live in a French speaking country
that is not listed on the display, select
“ELSE - English.”
Easy Setup - Postal Code
Enter your postal code using the number
buttons or </M/m/,, and press
ENTER.
To erase a number, move the cursor to
the number, and press O RETURN.
Note that the option for entering your
Postal Code only appears if you select
one of the following tuner systems in the
step above:
UK, B, NL, D, E, I, CH, A.
Easy Setup - Clock
The recorder will automatically search
for a clock signal. If a clock signal cannot
be found, set the clock manually using
</M/m/,, and press ENTER.
Easy Setup - TV Type (page 97)
If you have a wide-screen TV, select
“16:9.” If you have a standard TV, select
either “4:3 Letter Box” (shrink to fit) or
“4:3 Pan Scan” (stretch to fit). This will
determine how “wide-screen” images are
displayed on your TV.
Easy Setup - Component Out
If you are using the COMPONENT
VIDEO OUT jack, select “On.”
Easy Setup - Line3 Input
If you plan to connect a decoder such as
a PAY-TV/Canal Plus analogue decoder
to the LINE 3/DECODER jack, select
“Yes.”
Easy Setup - Line1 Output
To output video signals, select “Video.”
To output S video signals, select “S
Video.”
To output RGB signals, select “RGB.”
Select “Video” to enjoy the
SMARTLINK features.
• If you set “Easy Setup - Component
Out” to “On,” you cannot select
“RGB.”
• If you set “Easy Setup - Line3 Input” to
“Yes,” you cannot select “S Video.”
Easy Setup - Audio Connection
If you connected an AV amplifier
(receiver) using a coaxial cord, select
“Yes : DIGITAL OUT” and set the
digital output signal (page 100).
24
3 Press ENTER when “Finish” appears.
“Easy Setup” is finished.
To receive Guide Plus+ system data
your recorder must be turned off
when not in use. If your recorder is
connected to a set top box receiver, be
sure to leave the set top box receiver
turned on. After initial setup, it may
take up to 24 hours to begin receiving
TV programme listings.
To return to the previous step
Press O RETURN.
z Hints
• If your AV amplifier (receiver) has an MPEG
audio decoder, set “MPEG” to “MPEG”
(page 100).
• If you want to run “Easy Setup” again, select
“Easy Setup” from “SETUP” in the System Menu
(page 106).
Setting up your set top box
receiver for the GUIDE Plus+
®
system
Follow the steps below to set up your set top
box receiver for the GUIDE Plus+ system.
Note that the OSD language, Clock, Country
and Postal Code are all set for the GUIDE
Plus+ system when Easy Setup is completed.
1 Press TV GUIDE.
The GUIDE Plus+ system “Home
Screen” appears.
2 Select “Setup” in the Menu Bar using
M/,, and press ENTER.
The GUIDE Plus+ setup menu appears.
3 Select “Basic Setup” using M/m, and
press ENTER.
4 Select “External Receiver 1,” and
press ENTER.
You can also select “External Receiver
2” or “External Receiver 3” if you have
connected additional set top box
receivers.
5 Press ENTER to select “Continue.”
6 Select the set top box receiver type
using M/m, and press ENTER.
7 Select the provider using M/m, and
press ENTER.
If you select “None,” you can select a
receiver brand from a list of all available
brands.
8 Select the receiver brand using M/m,
and press ENTER.
If your receiver brand is not on the list,
select “???.”
The receiver brand list is automatically
updated, so your receiver may be
available at a later date. Select your brand
when it becomes available. Until then,
use “???.”
9 Select the connection you used for
your set top box receiver using M/m,
and press ENTER.
When the set top box receiver is
connected to the recorder using hookup
A or C, select “Antenna.” When the set
top box receiver is connected to the
recorder using hookup B, select “Line3.”
The display asks for confirmation.
10
Press ENTER to select “Continue.”
The Video Window switches to the
specified programme position.
11
Select “YES” using M/m, and press
ENTER.
The display asks for confirmation.
If the Video Window does not switch to
the specified programme position, select
“NO” and press ENTER until the Video
Window switches to the specified
programme position.
Hookups and Settings
,continued
25
If you cannot get the recorder to control
your set top box receiver
Check the connection and position of the set
top box controller (page 14).
If your set top box receiver still does not
operate with this recorder, refer to the
instructions supplied with your set top box
receiver and contact your cable or satellite
company to see if they can provide you with
a compatible set top box receiver.
b Notes
• The list of external receivers controllable by the
GUIDE Plus+ system is updated constantly and is
distributed through GUIDE Plus+ system data
signals. Since the time your recorder has been
produced and the time you installed your recorder
for the first time, new external receiver codes
might have been added.
• If the external receiver is still not on the list or is
not controlled properly by the recorder, please
call Customer Support to report the brand and
model of your external receiver.
To fix the set top box controller to your set
top box receiver
Once you have confirmed that the set top box
controller controls your set top box receiver,
fix it in place.
1 Remove the backing on the double-sided
tape.
2 Attach it so that the set top box controller
is directly above the remote control
sensor on your set top box receiver.
26
Connecting a VCR or Similar Device
After disconnecting the recorder’s mains lead from the mains, connect a VCR or similar
recording device to the LINE IN jacks of this recorder.
Use the DV IN jack on the front panel if the equipment has a DV output jack (i.LINK jack)
(page 88).
For details, refer to the instruction manual supplied with the connected equipment.
To record on this recorder, see “Recording from connected equipment without a timer” on
page 63.
Connecting to the LINE 3/DECODER jack
Connect a VCR or similar recording device to the LINE 3/DECODER jack of this recorder.
VCR
SCART cord (not supplied)
TV
to SCART input
Hookups and Settings
to i LINE 3/DECODER
to i LINE 1 – TV
DVD recorder
b Notes
• Pictures containing copy protection signals that prohibit any copying cannot be recorded.
• If you pass the recorder signals through a VCR, you may not receive a clear image on your TV screen.
VCRDVD recorderTV
Be sure to connect your VCR to the DVD recorder and to your TV in the order shown below. To watch
video tapes, watch the tapes through a second line input on your TV.
Line input 1
VCRTV
• The SMARTLINK features are not available for devices connected via the DVD recorder’s LINE 3/
DECODER jack.
• When you record to a VCR from this DVD recorder, do not switch the input source to TV by pressing the
TV/DVD button on the remote.
• If you disconnect the recorder’s mains lead, you will not be able to view the signals from the connected
VCR.
DVD recorder
Line input 2
,continued
27
Connecting to the LINE 2 IN jacks on the front panel
Connect a VCR or similar recording device to the LINE 2 IN jacks of this recorder. If the
equipment has an S-video jack, you can use an S-video cord instead of an audio/video cord.
VCR, etc.
S VIDEO
OUTPUT
VIDEO
AUDIO
LR
S-video cord
(not supplied)
to LINE 2 IN
: Signal flow
Audio/video cord
(not supplied)
DVD recorder
z Hint
When the connected equipment outputs only monaural sound, connect to just the L(MONO) and VIDEO
input jacks on the front of the recorder. Do not connect the R input jack.
b Notes
• Do not connect the yellow LINE IN (VIDEO) jack when using an S-video cord.
• Do not connect the output jack of this recorder to another equipment’s input jack with the other
equipment’s output jack connected to the input jack of this recorder. This may cause noise (feedback).
• Do not connect more than one type of video cord between the recorder and your TV at the same time.
28
Connecting a PAY-TV/Canal Plus Analogue Decoder
You can watch or record PAY-TV/Canal Plus analogue decoder programmes if you connect a
decoder (not supplied) to the recorder. Disconnect the recorder’s mains lead from the mains
when connecting the decoder. Note that when you set “Line3 Input” to “Decoder” in step 5 of
“Setting PAY-TV/Canal Plus analogue programme positions” (page 30), you will not be able
to select “L3” because Line 3 will become a dedicated line for the decoder.
Connecting a decoder
Hookups and Settings
Aerial cable (supplied)
to AERIAL IN
to AERIAL OUT
to i LINE 1 – TV
SCART cord
(not supplied)
TV
to SCART input
PAY-TV/Canal Plus
analogue decoder
SCART cord
(not supplied)
to i LINE 3/DECODER
DVD recorder
,continued
29
Setting PAY-TV/Canal Plus
analogue programme positions
To watch or record PAY-TV/Canal Plus
analogue programmes, set your recorder to
receive the programme positions using the
on-screen display.
In order to set the programme positions
correctly, be sure to follow all of the steps
below.
Number
buttons
SYSTEM
MENU
</M/m/,,
O
RETURN
ENTER
1 Press SYSTEM MENU.
The System Menu appears.
2 Select “SETUP,” and press ENTER.
4 Select “Scart Setting,” and press
ENTER.
5 Press M/m to select “Video” or “RGB”
for “Line1 Output,” “Decoder” for
“Line3 Input,” and “Video” for “Line3
Output,” and press ENTER.
The “Video” setup display appears again.
6 Press O RETURN to return the cursor
to the left column.
7 Select “Basic,” and press ENTER.
8 Select “Channel Setting,” and press
ENTER.
3 Select “Video,” and press ENTER.
30
9 Press M/m to select the desired
programme position, and press
ENTER.
