Sony RD0090 User Guide

User guide

SmartWatch 3

SWR50

Getting started...............................................................................4

Introduction........................................................................................4

Overview............................................................................................4

Charging............................................................................................4

Turning on and off..............................................................................5

Setting up your SmartWatch 3...........................................................5

Learning the basics........................................................................7

Using the touchscreen.......................................................................7

Dimming and waking up the screen..................................................7

Home screen......................................................................................8

Cards.................................................................................................8

Viewing status icons..........................................................................9

Basic settings...............................................................................10

Accessing settings...........................................................................10

Screen settings................................................................................10

Airplane mode..................................................................................10

Restarting and resetting...................................................................11

Using your SmartWatch 3............................................................12

Staying organised with your SmartWatch 3....................................12

Messaging........................................................................................12

Email................................................................................................12

Handling incoming calls...................................................................13

Navigation........................................................................................13

Viewing your journeys on a map......................................................14

Music...............................................................................................14

Reminders........................................................................................14

Notes................................................................................................14

Agenda.............................................................................................15

Getting quick answers.....................................................................15

Counting steps.................................................................................16

Setting an alarm...............................................................................16

Setting a timer..................................................................................17

Using the stopwatch function..........................................................17

Checking flights or hotel reservations.............................................17

Getting traffic information................................................................17

Tracking packages...........................................................................17

Using your SmartWatch 3 as a standalone device..........................17

Android Wear application.............................................................19

Android Wear on your phone or tablet............................................19

This is an Internet version of this publication. © Print only for private use.

Selecting applications for voice actions..........................................19

Installing suggested applications.....................................................19

Connecting and reconnecting..........................................................19

Paring with another wearable device...............................................20

Adjusting settings for your SmartWatch 3.......................................20

Android Wear help...........................................................................20

Important information...................................................................21

Using your accessory in wet and dusty conditions.........................21

Legal information.............................................................................22

This is an Internet version of this publication. © Print only for private use.

Getting started

Introduction

Your SmartWatch 3 accessory, which is powered by Android Wear, organises your information, suggests what you need, and shows it to you before you even ask. Use it to receive and reply to messages, view appointment notifications, and glance at weather updates – all from the convenience of your wrist. There’s no need to reach

for a phone or tablet as long as a Bluetooth® connection has been established with your SmartWatch 3.

Using voice commands, you can ask questions like “When is my next meeting?” or “How do I get to the train station?” and get straight answers. You can also, for example, use the SmartWatch 3 to keep track of your fitness with daily summaries showing your step count. And you can regularly add new apps from Google Play™ to extend functionality. Useful new apps and features are being added all the time as well as updates to existing apps that you’ve installed. You get automatic notifications when such updates are available.

The SmartWatch 3 works with any Android™ phone or tablet running Android™ version 4.3 or higher. To see if your Android™ device is compatible for use with Android wear, go to

To achieve full functionality and performance, use the wristband together with the main unit of the SmartWatch 3.

http://g.co/WearCheck

Overview

1 Microphone

2 Light sensor

3 Touchscreen

4 Power key

5 Main unit

6 NFC™ detection area

7 Cover for Micro USB port

8 Wristband

Charging

Before using your SmartWatch 3 for the first time, you need to charge it for approximately 30 minutes. Sony chargers and USB cables are recommended.

This is an Internet version of this publication. © Print only for private use.

To charge your SmartWatch 3

Plug one end of the USB cable into the Micro USB port of your SmartWatch 3.

Plug the other end of the cable into the charger or into the USB port of a computer.

Make sure the charger or computer is connected to an active power source.

To view the battery level

•

From the home screen, which displays the time, swipe downwards from the top to the middle of the screen.

Turning on and off

To turn on your SmartWatch 3

•

Press and hold down the power key until the SmartWatch 3 vibrates.

To turn off your SmartWatch 3

Press and hold down the power key until the Settings menu appears.

Find and tap Power off, then tap

Setting up your SmartWatch 3

For your SmartWatch 3 accessory to work properly, you must first install the latest version of the Android Wear application on your Android™ phone or tablet and then pair and connect the phone or tablet with your accessory. There are two ways to perform this setup. You can use NFC, which launches much of the pairing, connection and setup procedure automatically. Alternatively, if your phone or tablet doesn’t support NFC, you can use the manual setup option. Remember that you can only pair the SmartWatch 3 with one phone or tablet at a time.

This is an Internet version of this publication. © Print only for private use.

To set up your SmartWatch 3 using NFC

Make sure that your Android™ phone or tablet is connected to a Wi-Fi

network and that it maintains a Wi-Fi® connection throughout the setup procedure.

Phone or tablet: Make sure that the NFC function is turned on and that the

screen is active and unlocked.

Place your phone or tablet over the SmartWatch 3 so that the NFC detection area of each device touches each other. A screen opens on the phone or tablet which displays a download page for Android Wear on Google Play™.

Phone or tablet: Tap the relevant text or icons on the screen to download and

install Android Wear.

Phone or tablet: Once Android Wear is installed, open the Android Wear

application, then follow the relevant on-screen instructions.

Phone or tablet: If Bluetooth® is not turned on, tap Turn on Bluetooth when

prompted.

Phone or tablet: From the list of available devices, select the SmartWatch 3. A

pairing code now appears on both the SmartWatch 3 and your phone or tablet.

Confirm the same code on both devices. The SmartWatch 3 now looks for updates and may restart automatically.

Phone or tablet: Follow the on-screen instructions to complete the setup.

After setup, the SmartWatch 3 prompts you to turn on some features, such as Google Now and Location services, to add more functionality and improve the user experience. If desired, follow the relevant instructions.

The first time you pair and connect SmartWatch 3 with a new phone or tablet, the procedure can take several minutes. The time can vary depending on the network.

To set up your SmartWatch 3 manually

Make sure that your Android™ phone or tablet is connected to a Wi-Fi network and that it maintains a Wi-Fi® connection throughout the setup

procedure.

Turn on your SmartWatch 3.

Phone or tablet: Search for the Android Wear application on Google Play™,

then download and install the application.

Phone or tablet: Once Android Wear is installed, open the Android Wear

application, then follow the relevant on-screen instructions.

Phone or tablet: If Bluetooth® is not turned on, tap Turn on Bluetooth when

prompted.

Phone or tablet: From the list of available devices, select the SmartWatch 3. A

pairing code now appears on both the SmartWatch 3 and your phone or tablet.

Confirm the same code on both devices. The SmartWatch 3 now looks for updates and may restart automatically.

Phone or tablet: Follow the on-screen instructions to complete the setup.

The first time you pair and connect the SmartWatch 3 with a new phone or tablet, the procedure can take several minutes. The time can vary depending on the network.

Learning the basics

Using the touchscreen

Swiping

Swipe up

Swipe down

Swipe left

Swipe right

Tapping

•

Open or select an item.

•

View more cards, if available.

•

Browse down through options in a menu.

•

View previous cards, if not dismissed.

•

Browse up through options in a menu.

•

See more details and actions, if available.

•

Dismiss a card or close a menu.

Dimming and waking up the screen

When your SmartWatch 3 is on and left idle for a period of time, the screen dims automatically. You can also dim the screen manually and wake it up at any time.

To wake up the screen

Perform one of the following actions:

•

When the SmartWatch 3 is on your wrist, turn it towards you.

•

Tap the screen or briefly press the power key.

To dim the screen manually

Perform one of the following actions:

•

Cover the screen with the palm of your hand.

•

Briefly press the power key.
