Sony PS4 CUH-1116A Quick Start Manual

Quick Start Guide

English

CUH-1116A 7026139

Getting started

Connect to your TV.

Follow the steps to below to connect your PlayStation®4 system to
yourTV.

Rear view

To an electricity supply

2

AC IN connector HDMI OUT port

AC power cord

• When using the system in a vertical position,
use the supplied vertical stand. Place the
PS4™ system on a soft cloth and align the
front of the stand with the front of the PS4™
system.

• Do not lift the system only by the stand when
the stand is attached.

HDMI input port

HDMI cable

Connect the PlayStation®Camera.

Remove the protective film, and then place the camera in front of your TV, at
the centre.

Rear view

AUX port

PlayStation®Camera

To fix the camera in place

Remove the white film from the supplied double-sided tape (for

PlayStation®Camera), and then attach the tape to the bottom of
the camera.

Remove the yellow film, and then secure the camera on a

horizontal surface in front of your TV.

NOTE: The double-sided tape should not be used to attach the
camera to the TV itself. Use of the tape to secure the camera to a
painted surface may result in the marking or removal of paintwork.

35° 35°

• If the camera’s dual lenses ever become dirty,
wipe them with a soft cloth.

• If you need to adjust the angle of the camera,
rotate it up or down.

EN

3

Connect to a LAN cable (sold separately).

No Wi-Fi connection? You can use a LAN cable to connect your PS4™ system
to the Internet instead.
To connect your PS4™ system to the Internet via Wi-Fi, do not connect a
LANcable.

Rear view

LAN port

Type of connection:

Router Internet connected device

LAN cable

(sold separately)

We recommend connecting your PS4™ system to the Internet to get the most
out of it.

such as a modem

To the Internet

4

Turn on your TV, and then change the TV channel to

HDMI™.

Turn on your PS4™ system by touching the (power)

button.

The power indicator will blink blue, before turning white.

Front view

If you can't get a picture when the PS4™ system is turned on (the power
indicator will turn
7seconds (until the system beeps twice) to turn off the power, and then turn
on the power again.

white), simply touch the (power) button for at least

Power indicator

Power button

EN

5
