gMovie Version 1.4

Operating Instructions

• CLIÉ, PictureGear, Memory Stick and the Memory Stick logo are trademarks of Sony Corporation.

• generic media and gMovie are trademarks of generic media, inc.

• Microsoft and Windows are registered trademarks of Microsoft Corporation.

• Graffiti, HotSync and Palm OS are registered trademarks, and Palm Desktop and the HotSync logo are trademarks of Palm, Inc. or its subsidiaries.

• QuickTime and the QuickTime logo are trademarks used under license. QuickTime is registered in the U.S. and other countries.

All other trademarks are trademarks of their respective owners. Before using this software, please read the Software License Agreement that is supplied with the

product.

❒ Copying all or part of the contents of this software, sample images, and Operating Manual,

or renting the software are prohibited by copyright laws.

❒ The Company is not liable for damage or loss resulting from the use of this software, or for

any claim from a third party.

❒ The Company assumes no responsibility aside from the replacement of the media due to

manufacturing fault.

❒ This software must not be used in a system other than that specified. ❒ The software specifications may be subject to change without notice.

Table of Contents

Before Use

Features ............................................................................................................... 4

Basic Operations

Starting gMovie ................................................................................................. 5

Playing back a media file ................................................................................. 7

To return to the media list ......................................................................... 8

To playback the next media item .............................................................. 8

To playback the previous media item ...................................................... 8

To playback all media items consecutively (Sequence Play mode) ..... 8

To delete a media item ............................................................................... 9

You can also use the supplied remote controller to control the

functions ................................................................................................... 9

Miscellaneous

Menu Commands ............................................................................................ 10

Media menu ............................................................................................... 10

Creating a media file for gMovie using PictureGear 4.4 Lite ................... 12

Installing the PictureGear 4.4 Lite software to your computer .......... 12

Movie (media) file formats you can use with PictureGear 4.4 Lite ... 13 Sending media files to a CLIÉ handheld

using the HotSync function ................................................................. 13

Copying movie files to a Memory Stick media..................................... 15

Before Use

Features

gMovie is the application which enables the display and playback of motion picture data with sound, made for the CLIÉ handheld by using a Windows

When you send movie data made for the CLIÉ handheld by PictureGear Lite using HotSync operation, or copy the data to the CLIÉ handheld by using a Memory Stick media, they are automatically registered to the movie list of gMovie.

Even if your CLIÉ handheld does not have audio playback function, the playback of audio data is possible by connecting the Audio Adapter (PEGA-SA500) to your CLIÉ handheld. When you connect the Audio Adapter to your CLIÉ handheld, gMovie Ver. 1.4 supports playback of color movies with sound, Jog Dial control.

application such as PictureGear Lite.

Basic Operations

Continued on next page

Starting gMovie

Select gMovie from the Home screen of the CLIÉ handheld by rotating and pressing the Jog Dial navigator.

The gMovie application starts and the media (movie file) list appears. Motion pictures that you can playback with gMovie are called "media."

z If no media file is installed, no list is displayed. To create a media file,

see to "Creating a media file for gMovie using PictureGear 4.4 Lite" (page 12).

Movies stored in the Memory Stick media are indicated with the icon.

Media List

By rotating and pressing the Jog Dial navigator you can select and play back the media.

Details

Tapping this icon displays details of the media.

Switchable information

[video] indicates the movie without sound. [audio + video] indicates the movie with sound.

Tapping these buttons toggles the contents of switchable information in four ways.

Name of Media item

Switchable information : Tapping the following icon, displays of contents change.

: displays the type of media item.

: displays the dimensions of the media item (pixels).

: displays the duration of the media item (seconds).

If the media file has many frames per second, the actual time duration may be longer than that displayed.

: displays storage requirements (KB).
