Sony PCV-RX790G VAIO User Guide (primary manual) Specification

Sony Electronics Inc.
Information Technology Product Division
16765 West Bernardo Drive, San Diego, CA 92127
For more information: 1.800.4SONYPC (476-6972)
Web address: http://www.sony.com/vaio

Computer Interface: The computer industry lacks standards, and therefore, there are a multitude of
varying software packages and add-on hardware options. This personal computer is not manufactured
to any specific software, and Sony does not and cannot make any warranty or representation with
respect to the performance of this product with any particular software packages and/or non-Sony add­on hardware option except those mentioned in this document. Sony hereby disclaims any
representations or warranty that this product is compatible with any combination of non-Sony products
you may choose to connect. While Sony representatives or Sony authorized dealers may be able to
assist you and may make recommendations, they are NOT authorized to vary or waive this disclaimer.
Purchasers must determine for themselves the suitability and compatibility of the hardware and
software in each and every particular instance. Some pre-installed software titles may not include full
documentation. Software titles pre-installed on the Sony Desktop Computer are subject to change
without notice. Simulated graphic shown on display.

©2002 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Sony, i.LINK, VAIO Digital Studio, VAIO Smart, Giga Pocket, Memory
Stick, SonicStage, DVgate, MovieShaker, and VAIO are trademarks of Sony. Intel and Pentium are
registered trademarks of Intel Corporation. Microsoft, Windows and Outlook are trademarks of
Microsoft Corporation. All other trademarks are trademarks of their respective owners. This product
meets the standards of the International Energy Star Program for energy efficiency. Features and
specifications are subject to change without notice. Weights and measurements are approximate.

Printed in U.S.A. 4/02
Rev. 1.00

SPECIFICATIONS

• Intel®Pentium®4 Processor 2.40B

†††

GHz

†

• 512MB PC800-40 RDRAM (Expandable to 1
GB)

• 533MHz Front Side Bus

• 120GB

††

7200rpm Ultra ATA/100 Hard Drive

• DVD-RW / CD-RW Drive

• DVD-ROM Drive

•

Giga Pocket

TM

Personal Video Recorder

• Watch Live TV

• Record Shows for Later Playback

•

Internet TV Programming Guide

• Analog Video Input for 8mm or VHS

Camcorders

• 4X AGP 3D Graphics Hardware Acceleration
(nVIDIA

®

GeForce4™ MX 440)

• 64MB Video Memory (128-bit DDR)

• Optical Out for Dolby Digital

®

• High-Speed Internet Ready with
10Base-T/100Base-TX Fast Ethernet

• Front and Rear Accessible i.LINK

®

(IEEE

1394) Interfaces and USB Connections

1

• Memory Stick®Media Slot

• Programmable VAIO Smart

™

Keyboard

¾

Giga PocketTMPersonal Video Recorder

¾

Watch and Record TV Programs

¾

DVD-RW / CD-RW - Create Your Own DVDs!

¾

Intel®Pentium®4 Processor 2.40B

†††

GHz

†

¾

512MB PC800-40 RDRAM / 120

GB

††

7200rpm Hard Drive

¾

64MB nVIDIA®GeForce4™MX 440 Graphics

Sony VAIO®Digital Studio™ PC

PCV

PCV

-RX790G

-RX790G

FEATURES

i.LINK

®

(IEEE 1394)

Video Audio Integrated Operation

With

Personal Video

Recorder & DVD

Recorder

MODEL

PCV-RX790G

P

ROCESSOR

Intel®Pentium® 4 Processor 2.40B

†††

GHz

†

CACHE MEMORY

512KB Integrated On-Die Level 2

F

RONT SIDE BUS SPEED

533MHz

S

TANDARD RAM

512MB PC800-40 RDRAM (expandable to 1 GB)

H

ARD DRIVE

120GB††7200rpm Ultra ATA/100 Hard Drive

DVD-RW / CD-RW D

RIVE

DVD-RW

(2X max. write / 1X max. rewrite / 4X

max. read)

CD-RW

(8X max. write / 4X max. rewrite / 24X

max. read)

DVD-ROM

16X max. DVD-ROM Read / 40X max. CD-ROM

Read

F

LOPPY DISK DRIVE

3.5" 1.44MB Floppy Disk Drive

V

IDEO & GRAPHICS

4X AGP 3D Graphics Hardware Acceleration

(nVIDIA

®

GeForce4

™

MX 440)
64MB Video Memory (128-bit DDR)
MPEG2 Realtime Encoder/Decoder board

with TV Tuner

E

THERNET

10Base-T/100Base-TX Fast Ethernet

M

ODEM

V.90 compatible data/fax modem

E

XPANSION SLOTS

One AGP (occupied by Graphics Card)
Three PCI (two occupied)
Memory Stick

®

Media Slot

E

XPANSION BAY S

Two 5.25" Half-Height (occupied)
One External 3.5" (occupied)
Two Internal 3.5" (one occupied)

P

ORT CONNECTORS

Four USB (two front/two rear)
Two PS/2

®

(Mouse/Keyboard)
One VGA monitor port
One Serial / One Parallel
One 6pin i.LINK port (rear)
One 4pin i.LINK port (front)
One Headphone / One Microphone
One Line In
S-Video: Two Inputs/ One Output
Composite Video / Audio Input
Stereo Line Input/Output
Coaxial Input (VHF/UHF)

S

UPPLIED ACCESSORIES

Speakers (Stereo)
VAIO Smart

™

Keyboard

PS/2

®

Wheel Mouse
4pin-4pin i.LINK cable
TV Coaxial cable
Two Composite to S-Video Adapters

P

OWER REQUIREMENTS

100-120V -3A (50/60Hz)

P

OWER MANAGEMENT

ACPI 1.0 Compliant

D

IMENSIONS (CPU)

8.0"(W) x 14.2"(H) x 14.6"(D)

W

EIGHT (CPU)

28.5 lbs.

S

ERVICE

One Year Limited Express Repair Service
(upon registration; 90 days without

registration)*

L

IMITED WARRANTY

One Year Parts and Labor (upon registration;
90 days without
registration)*

T

ELEPHONE SUPPORT

Hardware: One Year
Software and Operating System: 90 Days

P

RE-INSTALLED SOFTWARE

OPERATING SYSTEM

Microsoft®Windows®XP Home Edition

Sony PCs use Genuine Microsoft

®

Windows®Operating Systems
www.microsoft.com/piracy/howtotell

SONY ORIGINAL SOFTWARE

Giga Pocket™Personal Video Recorder
DVgate

™

Simple DVD Maker
SonicStage

™

for VAIO

®

MovieShaker

™

Smart Capture
DigitalPrint
PowerDVD

O

THER SOFTWARE APPLICATIONS

Corel WordPerfect® Office 2002
Sonic Solutions DVDit!

®

for VAIO

®

Adobe®Photoshop®Elements
Adobe

®

Premiere®LE

Veritas

®

RecordNowTMDX

Adobe

®

Acrobat®Reader

®

Apple QuickTime

®

Intuit Quicken®2002

2

Microsoft®Outlook®Express

A

NTI-VIRUS & RECOVERY SOFTWARE

Trend Micro PC-Cillin

®

Sony Application Recovery CD(s)
Sony System Recovery CD(s)

O

NLINE CENTER

VAIO Support Agent
America Online

®

**

EarthLink TotalAccess

™

**

* Display sold separately.

† GHz denotes microprocessor internal clock speed; other factors

may affect application performance.

†† GB means one billion bytes when referring to Hard Drive

capacity. Accessible capacity may vary.
†††Naming of 2.40GHz based on 533MHz Front Side Bus.
* Certain restrictions apply.
** Requires payment of additional fees or subscription for use.
1 i.LINK is a trademark of Sony used only to designate that a

product contains an IEEE 1394 connector. All products with an

i.LINK connector may not communicate with each other.
2 Previous Quicken users may require additional upgrade.
