Hardware Guide

PCG-TR series PCG-Z1 series PCG-V505 series

Read this first

Hardware Guide

Read this first

Notice

This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval.

Sony Corporation provides no warranty with regard to this manual, the software, or other information contained herein and hereby expressly disclaims any implied warranties or merchantability or fitness for any particular purpose with regard to this manual, the software or such other information. In no event shall Sony Corporation be liable for any incidental, consequential, or special damages, whether based on tort, contract, or otherwise, arising out of or in connection with this manual, the software, or other information contained herein or the use thereof.

Macrovision: This product incorporates copyright protection technology that is protected by U.S.patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

In the manual, the ™ or ® marks are not specified.

Sony Corporation reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein is governed by the terms of a separate user licence agreement.

Please note that the illustrations in this manual may not necessarily apply to your model. Please see the Specifications sheet for the specific configuration of your VAIO.

Read this first

Hardware Guide

ENERGY STAR

As an ENERGY STAR Partner, Sony has determined that this product meets the ENERGY STAR guidelines for energy efficiency. The International E computers and their office equipment. The program backs the development and dissemination of products with functions that effectively reduce energy consumption. It is an open system in which business proprietors can participate voluntarily. The targeted products are office equipment such as computers, displays, printers, facsimiles and copiers. Their standards and logos are uniform among participating nations.

NERGY STAR is a U.S. registered mark.

NERGY STAR Office Equipment Program is an international program that promotes energy saving through the use of

Owner's record

The serial number and model number are located on the bottom of your Sony computer. Record the numbers and refer to them if you call VAIO-Link. See also the printed Specifications document.

Read this first

Safety Information

General

Hardware Guide

❑ Opening the unit, for whatever reason, could lead to damages that are not covered by the guarantee. ❑ To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. ❑ To prevent fire or shock hazard, do not expose your VAIO computer to rain or moisture. ❑ If reporting a gas leak, do not use the modem or a telephone in the vicinity of the leak. ❑ Avoid using the modem during a severe electrical storm. ❑ To change the backup battery, please contact your nearest Sony Service Centre. ❑ Before you connect peripherals, turn off the computer and all peripherals. ❑ Connect the power cord only after connecting all cables. ❑ Turn on the computer only after turning off all peripherals. ❑ Do not move your computer while the system is in Standby mode. ❑ The magnetic properties of some objects can have serious consequences for your hard disk drive. They

can erase the data on the hard disk drive and cause the computer to malfunction. Do not place your computer near or on any objects which emit magnetic fields, mainly:

❑ TV sets ❑ Speakers ❑ Magnets and magnetic bracelets.

Audio/video

❑ Audio and picture distortion may occur if this equipment is positioned in close proximity to any

equipment emitting electromagnetic radiation.

Read this first

Hardware Guide

Connectivity

❑ Never install modem or telephone wiring during a severe lightning storm. ❑ Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. ❑ Take care when installing or modifying telephone lines. ❑ Use your computer only with the supplied AC adapter. To disconnect your computer completely from

mains voltage, unplug the AC adapter.

❑ Make sure that the socket outlet is easily accessible. ❑ Never touch uninsulated telephone wire or terminals unless the telephone line has been disconnected

at the network interface.

Read this first

Regulatory information

Sony hereby declares that this product is in compliance with the essential requirements and other relevant provisions of European Directive 1999/5/EC (radio equipment and telecommunications terminal equipment Directive).

Hardware Guide

Declaration of Conformity

The European Union is targeting the free movement of goods for the internal market and to prevent technical barriers to trade. This effort has resulted in several EU Directives asking that manufacturers make their products comply with essential standards. Manufacturers are required to affix the "CE" mark on the products they sell and to draw up a "Declaration of Conformity" (DoC).

Primarily, the Declarations of Conformity are intended for the market surveillance authorities as proof that products satisfy the required standards. Additionally, Sony provides these EU DoC's on the website http://www.compliance.sony.de

You can search for all Declarations of Conformity available for a specific product by typing in the model name in the search box above. A list of matching documents will be displayed and can be downloaded. Please note that the availability of declarations depends on the scope of the EU Directives and the individual product specifications.

This product complies with EN 55022 Class B and EN 55024 for use in following areas: residential, commercial and light-industrial. This product has been tested and found compliant with the limits set out in the EMC Directive for using connection cables not longer than 3 metres (9.8 feet). Before activating the built-in modem, please read the Modem Regulations leaflet.

The optical disc drive is classified as a CLASS 1 LASER PRODUCT and complies with the Laser Product Safety Standard EN 60825-1. Repair and maintenance only by authorised Sony technicians. Improper repairs and use can create safety hazards.

as a service to our customers.

CLASS 1

LASER PRODUCT

TO EN 60825-1

Depending on the country, usage of the built-in Bluetooth™ functionality may be restricted. For country-specific details, please refer to the Bluetooth™ Safety Regulations leaflet.

Read this first

Hardware Guide

Depending on the country, usage of the Wireless LAN functionality may be restricted. For country-specific details, please refer to the Wireless LAN Regulations leaflet. The Wireless LAN PC functionality which is incorporated into this unit has passed Wi-Fi

certification, and complies with the interoperability specifications established by WECA (Wireless Ethernet Compatibility Alliance).

Read this first

Hardware Guide

Disposing of lithium ion batteries

❑ Do not handle damaged or leaking lithium ion batteries. Dispose of promptly and properly at end-of-life. ❑ Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type

recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

❑ The battery pack used in this device may present a fire or chemical burn hazard if mistreated. Do not

disassemble, heat above 60°C (140°F) or incinerate.

❑ Dispose of used batteries promptly and properly. ❑ Keep away from children. ❑ In some areas the disposal of lithium ion batteries in household or business waste may be prohibited. ❑ Use the public collection system.

Disposing of internal memory backup battery

❑ Your computer is equipped with an internal memory backup battery that should not have to be replaced

during the lifetime of the product. For changing this battery, please contact VAIO-Link.

❑ Danger of explosion if the battery is incorrectly replaced. ❑ Dispose of properly at end-of-life. ❑ In some areas the disposal of lithium ion and other non-hazardous batteries in household or business

waste may be prohibited.

❑ Please use the public collection system.

Welcome

Hardware Guide

Welcome

Congratulations on purchasing a Sony VAIO computer. Sony has combined leading-edge technology in audio, video, computing and communications to provide you with state-of-the-art personal computing.

Here are the main features you can enjoy:

❑ Exceptional performance. ❑ Portability - The rechargeable battery pack provides hours of use without AC power. ❑ Sony audio and video quality - A high-resolution LCD screen enables you to take advantage of today’s

advanced multimedia applications, games, and entertainment software.

❑ Multimedia features – Enjoy audio and video CDs/DVDs. ❑ Interconnectivity – Your computer has Ethernet, USB 2.0 (High-speed/Full-speed/Low-speed) and i.LINK

functionalities. i.LINK is a bidirectional digital interface for exchanging data. With the Memory Stick you can easily exchange and share digital data with compatible products.

❑ Wireless technology – Thanks to the Bluetooth

you can communicate freely, without cables or wires.

❑ Windows - Your system includes Microsoft’s Windows XP Professional or Home Edition* with Service

Pack 1a operating system.

❑ Photo, video, and webcam capabilities* – Use the built-in MOTION EYE camera to capture pictures

and videos.

❑ Communications - Access popular online services, send and receive e-mails, browse the Internet. ❑ Excellent customer support - If you are experiencing any problems with your computer, please check

the VAIO-Link website for a possible solution: http://www.vaio-link.com Before contacting VAIO-Link, please try to solve the problem by reading this guide, your printed Guide to Troubleshooting and Using the VAIO Recovery and Documentation Disc or the manuals and help files for the peripherals or software.

∗ Depending on your model. Read the printed Specifications document for more information.

* and the Wireless LAN (IEEE 802.11b/g)* technology,

Welcome

Documentation pack

Your Documentation Pack contains printed information and user guides to read on your computer.

Hardware Guide

Online documentation

You can read the online Hardware and Software Guides on your computer by double-clicking the My Documentation icon on your desktop.

Printed documentation

❑ A Getting Started brochure, where you will find a brief description of the items in your box, and how

to setup your computer;

❑ A Specifications sheet, containing a table of specifications , a list of bundled software and an overview

of all connectors;

❑ A Guide to Troubleshooting and Using the VAIO Recovery and Documentation Disc, where you

will find solutions to common problems, an explanation of the purpose and use of the VAIO Recovery and Documentation Disc delivered with your computer, and VAIO-Link information;

❑ You r Sony Guarantee conditions; ❑ A Safety Regulations leaflet; ❑ A Modem Regulations leaflet. ❑ A Wireless LAN Regulations leaflet; ❑ A Bluetooth™ Regulations leaflet applying to the Bluetooth function*.

∗ Depending on your model. Read the printed Specifications document for more information.

Welcome

Hardware Guide

Further sources

1 Consult the Online Help files of the software you are using for detailed information on features and

troubleshooting.

2 Go to http://www.club-vaio.com

to find online tutorials about your favourite VAIO software.

Welcome

Hardware Guide

Ergonomic considerations

You will be using your computer as a portable device in a variety of environments. Whenever possible, you should attempt to take account of the following ergonomic considerations to both stationary and portable environments:

❑ Position of your computer – Place the computer directly in front of you (1). Keep your forearms

horizontal (2), with your wrists in a neutral, comfortable position (3) while using the keyboard, touchpad, or external mouse. Let your upper arms hang naturally at your sides. Have breaks during sessions with your computer. Excessive use of the computer may strain muscles or tendons.

❑ Furniture and posture – Sit in a chair with good back support. Adjust the level of the chair so your feet

are flat on the floor. A footrest may make you more comfortable. Sit in a relaxed, upright posture and avoid slouching forward or leaning far backwards.

❑ Viewing angle of the computer’s display – Use the display’s tilting feature to find the best position.

You can reduce eye strain and muscle fatigue by adjusting the tilt of the display to the proper position. Adjust the brightness setting of the display as well.

Welcome

Hardware Guide

❑ Lighting – Choose a location where windows and lights do not create glare and reflection on the

display. Use indirect lighting to avoid bright spots on the display. You can also purchase accessories for your display that help reduce glare. Proper lighting adds to your comfort and work effectiveness.

❑ Positioning an external display – When using an external display, set the display at a comfortable

viewing distance. Make sure the display screen is at eye level or slightly lower when you are sitting in front of the monitor.

Using your VAIO computer

Once you have read and followed the information in the printed Getting Started guide and Specifications sheet, you can start using your computer safely and confidently.

Hardware Guide

Read on to get the most out of using your VAIO computer

❑ Connecting a power source (page 14) ❑ Setting up your computer with Sony Notebook Setup (page 20) ❑ Shutting down your computer safely (page 22) ❑ Using the keyboard (page 23) ❑ Using the touchpad (page 27) ❑ Using the volume buttons and the Magnify button (page 27) ❑ Using the disc drive (page 29) ❑ Using PC Cards (page 35) ❑ Using the Memory Stick (page 38) ❑ Using the modem (page 41) ❑ Using the Bluetooth functionality (page 44) ❑ Using Wireless LAN (WLAN) (page 50) ❑ Using the built-in MOTION EYE Camera* (page 60) ❑ Using power saving modes (page 63) ❑ Managing power with PowerPanel (page 67)

Using your VAIO computer

Connecting a power source

You can use either an AC adapter or a rechargeable battery pack as a power source.

Using the AC adapter

Hardware Guide

To use the AC adapter, proceed as follows:

1 Plug the cable attached to the AC adapter (1) into the DC In connector (2) on the computer. 2 Plug one end of the power cord (3) into the AC adapter. 3 Plug the other end of the power cord into an AC outlet (4).

The LED at the end of the power cord turns green when the AC adapter is plugged in.

✍ Use your computer only with the supplied AC adapter.

To disconnect your computer completely from mains voltage, unplug the AC adapter.

Make sure that the socket outlet is easily accessible.

Using your VAIO computer

Using the battery pack

You can use a battery pack as a source of power. The battery pack supplied with your computer is not fully charged at the time of purchase.

Hardware Guide

Inserting the battery pack (PCG-Z1, PCG-V505 series)

To insert the battery pack, proceed as follows:

1 Move the lock lever (1) on the bottom of the computer to the Unlock position.

2 Align the grooves (2) and tabs on the battery (3) with the tabs and notches on the back of the computer,

and then slide the battery towards the computer until it clicks into place.

3 Slide the lock lever into the Lock position to secure the battery on the computer.

✍ When the computer is directly connected to AC power and has a battery pack inserted in the battery bay, it uses power from the AC outlet.

Make sure the cover is closed before inserting the battery pack.

Using your VAIO computer

Inserting the battery pack (PCG-TR series)

To insert the battery, proceed as follows:

1 Insert the tabs (1) on the battery into the

Hardware Guide

notches (2) and push the battery down into the compartment until it clicks into place.

2 Slide the lock lever into the Lock position to

secure the battery on the computer.

✍ When the computer is directly connected to AC power and has

a battery pack inserted in the battery bay, it uses power from the AC outlet.

Make sure the cover is closed before inserting the battery pack.

Charging the battery pack

To charge the battery pack, proceed as follows:

1 Connect the AC adapter to the computer. 2 Insert the battery pack. The computer

automatically charges the battery (the battery indicator light flashes in a double blink pattern as the battery charges). Depending on your model, your computer has one or two battery indicator lights.

Battery indicator light status Meaning

On The computer is using battery power.

Single blink The battery is running out of power.

Double blink The battery is charging.

Off The computer is using AC power.

Using your VAIO computer

✍ When the battery is running out of power, both the battery and power indicators blink.

Keep the battery pack in the computer while it is directly connected to AC power. The battery pack continues to charge while you are using the computer.

Hardware Guide

If the battery level falls below 10%, you should either attach the AC adapter to recharge the battery or shut down your computer and insert a fully charged battery.

You can extend battery life by changing the power management modes in the PowerPanel utility.

The battery pack supplied with your computer is a lithium ion battery and can be recharged any time. Charging a partially discharged battery does not affect battery life.

The battery indicator light is on while you use the battery pack as a power source. When the battery life is nearly depleted, both the battery and power indicators start flashing.

For some software applications and some peripheral devices, your computer may not enter Hibernate mode even when battery life is low. To avoid loss of data when using battery power, you should save your data frequently and manually activate a power management mode, such as Standby or Hibernate.

When the computer is directly connected to AC power and has a battery pack inserted in the battery bay, it uses power from the AC outlet.

Using your VAIO computer

Removing the battery pack

To remove the battery pack, proceed as follows:

1 Turn off the computer and close the cover.

Hardware Guide

2 Slide the lock lever (1) to the Unlock position. 3 Slide and hold the release lever (2) as indicated and slide the battery away from the computer.

PCG-Z1, PCG-V505 series:

PCG-TR series:

Using your VAIO computer

✍ You can remove the battery pack without turning off the computer if it is connected to the mains voltage (AC adapter).

Close the cover before you remove the battery pack.

You may lose data if you remove the battery pack while the computer is on and not connected to the AC adapter or if you remove the battery while the computer is in Standby mode.

Hardware Guide

Using your VAIO computer

Setting up your computer with Sony Notebook Setup

The Sony Notebook Setup utility allows you to consult system information, specify preferences for system behaviour, and set up password protection for your VAIO computer.

Hardware Guide

To use Sony Notebook Setup, proceed as follows:

1 Click the Start button on the Windows taskbar. 2 In All Programs, select Sony Notebook Setup and then click Sony Notebook Setup.

The Sony Notebook Setup window appears.

Tab De scription

About This Computer Displays system information, including memory capacity, serial number, and BIOS version.

Initial Setting Selects the drive and device order you wish to use for loading the operating system. You can

Power On Password Sets the password to secure your computer.

Device Disables ports or devices to release resources to the system. To change the port settings, select a

Bass boost Turns the Bass Boost function on/off (only with headphones). You can also check the effect of

P1 P2 buttons Sets the functions from a drop-down list for the P1/P2 buttons located next to the keyboard. Select

specify the hard drive as well as other drives inserted into your computer. You can change the volume of the sounds played while the operating system is loading.

If you use this option, remember the password at all times. If you forget the password, you cannot change this setting anymore, and you will not be able to start your computer.

port and click Settings in the Device tab.

the Bass Boost function by selecting a sound file sample and playing it.

External Display and click Advanced to set up the display options*. ∗ Depending on your model. Read the printed Specifications document for more information.

3 Select the tab for the item you want to change.

Using your VAIO computer

4 Once finished, click OK.

The item has been changed.

✍ For more information about each option, click Help on the Sony Notebook Setup screen to display the help file.

Hardware Guide

If you open Sony Notebook Setup as a limited user, then only the About This Computer tab will be visible.

Using your VAIO computer

Shutting down your computer safely

It is important that you shut down your computer properly so you do not lose unsaved data.

To shut down your computer, proceed as follows:

Hardware Guide

1 Turn off any peripherals connected to your computer. 2 Click the Start button. 3 Click Turn Off Computer.

The Turn off computer window appears.

4 Click Tur n Off. 5 Respond to any prompts warning you to save documents or to consider other users and wait for your

computer to turn off automatically. The power indicator turns off.

✍ See the printed Troubleshooting guide if you have problems shutting down your computer.

Using your VAIO computer

Using the keyboard

Your keyboard is very similar to a desktop computer’s, but has additional keys that perform specific notebook-related tasks.

Hardware Guide

For more information on the standard keys, please go to the Windows Help and Support Center. The VAIO-Link website (www.vaio-link.com keyboard.

Combinations and functions with the <Fn> key

Combinations/ Feature Functions

<Fn> + <Esc> : Standby Puts the system into Standby mode, a power management state. To return the system to the

<Fn> + (F3): speaker switch Toggles the built-in speaker on and off.

<Fn> + (F4): speaker volume Adjusts the built-in speaker volume.

<Fn> + (F5): brightness control Adjusts the brightness of the LCD.

) also contains glossary information to help you use the

active state, press any key.

To increase volume, press <Fn>+<F4> and then or .

To decrease volume, press <Fn>+<F4> and then or . You can also adjust the volume by pressing the Volume up and Volume down keys below the

touchpad of your computer.

To increase lightness intensity, press <Fn>+<F5> and then or .

<Fn> + (F7)*: switch to the external display

To decrease light intensity, press <Fn>+<F5> and then or .

Toggles between the LCD, external device (monitor or TV depending on which device is connected) and both LCD and external device. This function can only be used by the first user to log in. It will not work under a second user account.

Using your VAIO computer

Combinations/ Feature Functions

<Fn> + (F12): Hibernate Provides for the lowest level of power consumption. When you execute this command, the

Hardware Guide

FN + B

* This function can only be used by the first user to log on. It will not work if you have switched to another user account. If another

user wants to display on an external monitor or TV, use the monitor properties to switch to an external monitor or TV.

✍ Some functions are not available until Windows is launched.

Troubleshooting sound

My speakers are not producing sound

❑ The built-in speakers may be turned off. Press <Fn>+<F3> to turn on the speakers. ❑ The speaker volume may be turned to the minimum. Press <Fn>+<F4> and then or to increase the

volume. You can also use the Volume up and Volume down keys.

❑ If your computer is powered by battery, check that the battery is inserted properly. ❑ If you are using an application that has its own volume control, check that the volume is turned up. ❑ Check the volume controls in Windows.

states of the system and of the peripheral devices are written to the hard disk and the system power is turned off. To return the system to its original state, use the power switch to turn on the power.

For details on power management, see the section Using power saving modes (page 63).

Activates BassBoost. This means that the bass sound level is enhanced at all levels without distorting other frequencies (only with headphones).

Using your VAIO computer

Indicators

Indicator Functions

Hardware Guide

Power

Battery

Wireless LAN Turns on when the Wireless LAN is activated. Turns off when the Wireless LAN is not

MagicGate Memory Stick Turns on when the Memory Stick is in use. Turns off when the Memory Stick is no

P1 P2 indicator* Set up functions for each button. For more details see the Sony Notebook Setup chapter

Bluetooth indicator* Turns blue when the Bluetooth functionality is available.

MOTION EYE camera indicator* Turns green when the MOTION EYE Camera is working.

∗ Depending on your model. Read the printed Specifications document for more information.

Power on: lights green. Standby mode: flashes umber.

Indicates the status of the battery.

activated.

longer in use.

in the Software Guide.

Using your VAIO computer

Light On Off

Hardware Guide

Hard disk

Num Lock

Caps Lock

Scroll Lock

Data is read from or written to the hard drive. The hard drive is not being accessed.

Turns on when the number keys in the numeric keypad are active.

Turns on when the letters appear in uppercase as you type. The <Shift> key lowers the case of typed characters when Caps Lock is on.

Turns on when the screen scrolls differently (Not all applications support this function).

Turns off when the alphanumeric character keys in the keypad area are active.

Turns off when the letters appear in lowercase as you type (unless you hold down the <Shift> key).

Turns off when the information moves across the display normally.

Using your VAIO computer

Using the touchpad

The keyboard contains a cursor-pointing device, your touchpad (1). You can point to, select, drag, and scroll objects on the screen using the built-in touchpad.

Hardware Guide

Using the volume buttons and the Magnify button

Action Description

Point Slide one finger on the touchpad to place the pointer (2) on an

item or object.

Click Press the left button (3) once.

Double-click Press the left button twice.

Right-click Press the right button (4) once. In many applications, this action

displays a shortcut menu.

Drag Slide one finger while pressing the left button.

Scroll Move your finger along the right edge of the touchpad to scroll

vertically. Move your finger along the bottom to scroll horizontally (the scroll function is available only with applications that support a touchpad scroll feature).

Your computer is provided with special buttons to help you using the computer*. They are located on the right side of the LCD screen.

❑ Volume buttons

You can increase and decrease the volume. It corresponds to the key combinations <Fn>+<F4>. See Combinations and functions with the <Fn> key (page 23).

∗ Depending on your model. Read the printed Specifications document for more information.

Using your VAIO computer

❑ Magnify button (Zoom)

You can change the image resolution in all applications, except in those that use the MOTION EYE Camera or the DVD player.

✍ When an external display is connected to your computer, the Magnify button is disabled.

Hardware Guide

The default resolution of your computer's LCD is 1280 x 768 pixels ,Highest (32 bit), and the resolution of 1024 x 600 pixels is applied after magnification.

The magnified view is implemented by applying the resolution of 1024 x 600 pixels to the LCD with the resolution of 1280 x 768 pixels, thus not as clear as the original view.

Pressing the (Magnify) button changes the resolution, thus may cause a defect to any running software that does not support change in resolution. Make sure to quit such software before pressing the (Magnify) button.

The (Magnify) button may not work with graphic images as it magnifies the screen view by changing the resolution.

The location and size of software windows may change when the screen view is magnified or the original view is restored because pressing the (Magnify) button changes the resolution.

When the LCD screen view is magnified, switching the view to the external display disables the function and restores the original view.

Using your VAIO computer

Using the disc drive

Your computer is equipped with a disc drive. See the Specifications sheet for details on your model.

To insert a disc, proceed as follows:

Hardware Guide

1 Turn on the computer. 2 Press the eject button (1) to open the drive.

The tray slides out.

3 Place a disc in the middle of the tray with the

label side facing up until the disc clicks into place.

4 Close the tray by pushing it gently.

✍ See the Troubleshooting Guide if you have problems using discs.

Reading and writing CDs and DVDs*

To achieve optimum performance when writing data on to disc (also called ’burning’), follow these recommendations :

❑ To make the data on a disc readable on an optical drive, you need to close the session when you eject it.

To complete this process, follow the instructions included with your software.

❑ Only use circular discs. Do not use discs with any other shape (star, heart, card, etc.), as this may damage

the disk drive.

❑ Do not strike or shake the computer while writing data to a disc. ❑ For optimal writing speed, deactivate the screensaver before writing data to a disc. ❑ Memory-resident disc utilities may cause unstable operation or data loss. Deactivate these utilities before

writing data to a disc.

❑ When using your software application to burn discs, make sure you exit and close all other applications.

Using your VAIO computer

❑ Never touch the surface of the disc. Fingerprints and dust on the surface of a disc may cause writing

errors.

❑ Do not put your VAIO computer into a power saving mode while using the pre-installed software and

while using the CD burning software.

Hardware Guide

❑ Never put stickers on discs. This will affect the use of the disc irreparably.

* Depending on your model. Ultra Speed CD-RW is not supported.

Playing DVDs

To achieve optimum performance when playing DVDs, you should follow these recommendations.

❑ You can play DVDs using the optical drive and the WinDVD for VAIO software. See the help file on the

WinDVD for VAIO software for details.

❑ Close all open applications before playing a DVD movie. ❑ Do not use resident disc utilities or resident utilities to speed up the access of discs, because they may

cause the system to become unstable.

❑ Make sure that the screensaver is deactivated. ❑ Region codes indicators are labelled on the DVDs to indicate in which region and on what type of player

you can play the disc. Unless a '2' (Europe belongs to region '2') or 'all' (this means that you can play this DVD everywhere in the world) is labelled on your DVD disc or on the packaging, you cannot play the disc on this player.

❑ Do not try to change the region code settings of the DVD drive. Any difficulties caused by changing the

region code settings of the DVD drive are out of warranty.

Using your VAIO computer

Troubleshooting optical disc drives

I cannot switch from LCD display to TV and vice versa

Hardware Guide

If a DVD disc is inserted in the optical drive, remove the disc.

My disc drive tray does not open

❑ Make sure the computer is turned on and press the eject button on the drive. ❑ Click Start, and select My Computer. Right-click the optical disc drive and select Eject. ❑ Make sure the computer is not in Standby or Hibernate mode. ❑ If this does not work, try the following:

When the computer is OFF, open the tray by inserting a sharp, pointed object (for example a paperclip) into the hole next to the eject button.

I cannot play a disc

❑ After inserting the disc, wait for a few seconds for the system to detect it before you try to access it. ❑ Make sure the label of the disc is facing up. ❑ If the disc requires software, make sure the software is installed according to the instructions of the

program.

❑ Check the volume of your speakers. ❑ Clean the disc with an appropriate cleaner. ❑ Make sure your computer is running on AC power supply only and try the disc again. ❑ There may be condensation in the drive. Remove the disc and leave the drive open for approximately

one hour. Remove the battery while you wait for the condensation to disappear.

❑ Make sure that the power profile you are using is not Ultimate Battery Life. Please use AC Power

(when using AC power) or Maximum Battery Life (when running on batteries).

Using your VAIO computer

I cannot play a DVD

❑ If a region code warning appears when you are using the DVD player, it could be that the DVD you are

trying to play is incompatible with the DVD drive on your computer. The region code is listed on the packaging of the disc.

Hardware Guide

❑ Change the resolution under Control Panel - Display to a lower resolution. ❑ If you see video but cannot hear sound, check all of the following:

❑ Make sure the mute setting is off on your DVD player. ❑ Check the Master Volume settings of the Sounds and Audio Device Properties. ❑ If you have connected speakers externally, check the volume settings of your computer speakers and

check the connections between your speakers and the computer.

❑ In the Device Manager, check that the correct drivers are installed properly. To display the Device

Manager, click Start, then Control Panel. Double-click the System icon. On the Hardware tab, click the Device Manager button.

❑ A dirty or damaged disc may cause the computer to 'hang' while it tries to read the disc. If necessary,

reboot the computer, remove the disc and then check that it is not dirty or damaged.

❑ Check your PG settings (Parental Guidance) in the DVD software as they might be preventing you from

playing certain DVDs when they are activated.

✍ On your computer, the default DVD region code is 2. Do not change this setting using the Region Code Change function in Windows, or using any

other software applications. System malfunctions originating from the user changing the DVD region code are beyond the scope of your warranty and will result in service charges for repair.

If you do not immediately see the Display icon after clicking Control Panel, click Switch to Classic View on the left.

Using your VAIO computer

I cannot play a DVD when using two screens

❑ When you use two screens at the same time (LCD and TV / LCD and CRT), the following errors will occur:

❑ You will see a Hardware Overlay error message if you attempt to launch Click to DVD.

Hardware Guide

❑ You cannot play a DVD with Windows Media Player version 9*. ❑ You cannot play a DVD with Real One Player. This is because your computer uses the "video overlay"

when two screens are in use. The software applications above do not support this feature, which is why the problems occur*.

❑ You will not have a problem in the following situations:

❑ When you use a CRT or an LCD display on its own. ❑ When you play MPEG files which are recorded on the hard drive with Windows Media Player 9 or

RealOne Player*.

Depending on your model. Read the Specifications document for more information.

The reading speed of CD/DVD-RWs is very slow

Generally, the reading speed of a CD/DVD-RW is slower than that of a -ROM or -R. The reading speed can also vary depending on the type of format.

The disc tray does not eject even when the eject button is pressed

❑ Check that the computer is turned on. ❑ The CD-writing application software may be stopping the disk from being ejected. ❑ Make sure the computer is not in Standby or Hibernate mode. ❑ Make sure that the power profile you are using is not Ultimate Battery Life. Please use AC Power

(when using AC power) or Maximum Battery Life (when running on batteries).

Using your VAIO computer

The disc tray ejects even when it has been locked into place

❑ Ensure that the disc is placed with the label side facing up. ❑ Clean the disc and the disc drive lens with an appropriate cleaner.

Hardware Guide

❑ The disc may be scratched. Place another disc to see if that is the reason. ❑ There may be condensation in the drive. Remove the disc and leave the drive open for approximately

one hour. Remove the battery while you wait for the condensation to disappear.

Using your VAIO computer

Using PC Cards

Your computer includes one or two PC Card slots (depending on your model). PC Cards allow you to connect portable external devices. Please see your printed Specifications sheet to see if your computer has one or

Hardware Guide

two PC Card slots. You do not need to shut down your computer when inserting a PC Card.

Inserting a PC Card

To insert a PC Card, proceed as follows:

1 Insert the PC Card into one of the PC Card slots with the front label facing upwards.

2 Gently push the PC Card slot into the connector.

The PC Card is automatically detected by your system. The Safely Remove Hardware icon appears in the system tray.

✍ Some devices may not function properly if you repeat returning to Normal mode from Standby mode or Hibernate mode.

The computer will return to its original state if you restart it.

Some PC Cards may require you to disable idle devices when using the PC Card. You can use Sony computer Setup to disable devices.

Make sure you use the most recent software driver provided by the PC Card manufacturer.

Using your VAIO computer

If an “!” mark appears on the Device Manager tab in the System Properties dialog box, remove the software driver and then reinstall it.

You do not need to shut down the computer before inserting or removing a PC Card.

Do not force a PC Card into the slot. It may damage the connector pins. If you have difficulty inserting a PC Card, check that you are inserting the PC Card in the correct direction. See the manual supplied with your PC Card for more information on use.

Hardware Guide

For some PC Cards, if you alternate between Normal power operation and Standby or Hibernate power management modes while the card is inserted, you may find that a device connected to your system is not recognised. Restart your system to correct the problem.

Do not carry your computer while touching the head of a PC Card, as pressure or shock may damage the connector pins.

If you computer has two PC Card slots, it is recommended that you always use the same slot for a PC Card as switching slots can cause problems with some PC Cards.

If your computer has two PC Card slots, the PC Card slots can accommodate (at the same time) two Type I, two Type II or one Type III PC Card. These slots are compatible with Card Bus ports.

If your computer has two PC Card slots, use the lower slot for PC Type III cards.

Removing a PC Card

Follow the steps below to remove the PC Card while your computer is on. If it is not removed properly, your system may not work properly. If you want to remove a PC Card when your computer is off, skip steps 1 to 7.

To remove a PC Card, proceed as follows:

1 Double-click the Safely Remove Hardware icon in the system tray.

The Safely Remove Hardware dialog box appears.

2 Select the hardware you want to unplug. 3 Click Stop. 4 In the Stop a Hardware Device dialog box, confirm that the device can be safely removed from the

system.

5 Click OK.

A dialog box appears, explaining that it is safe to remove the device.

Using your VAIO computer

6 Click OK. 7 Click Close. 8 Push the PC Card release button so that the release button pops out.

Hardware Guide

9 Push the PC Card release button a second time so that the PC Card pops out. 10 Gently take hold of the Card and pull it out of the slot. 11 If the PC Card release button is still out, push it back in to close the front panel cover.

✍ If you unplug the PC Card from the computer when it is still turned on, your system might crash and you might lose data that you did not save before.

Before you remove the PC Card, click the PC Card icon in the taskbar and close the card. Close any applications that use the PC Card before removing the card. Otherwise, data may be lost.

While the card is inserted, your computer may not enter the Hibernate power management mode. It may enter Standby mode. It is recommended that you remove the card before your computer enters Hibernate mode by pressing the <Fn>+<F12> keys or by using the PowerPanel Utility, and when it is set to enter Hibernate automatically while using a battery as the source of power.

Some PC Cards or their functions may not be compatible with this computer.

Troubleshooting PC Cards

My PC Card is not working

❑ Make sure the PC Card is compatible with your version of Windows. ❑ Use the Sony Notebook Setup utility to disable devices you are not currently using.

Using your VAIO computer

Using the Memory Stick

Your VAIO computer is designed to support the Memory Stick. The Memory Stick is a compact, portable, and versatile device especially designed for exchanging and sharing digital data with compatible products, such

Hardware Guide

as digital cameras, mobile phones and CLIE handheld devices. Because it is removable, it can be used for external data storage. Use the flash memory technology to download anything that can be converted into digital data, such as pictures, music, words, sounds, movies and photographs. The Memory Stick family ranges in capacity and compatibility.

Please see your printed Specifications sheet to see which Memory Stick types are compatible with your VAIO and if there are any limitations.

❑ You can purchase Memory Sticks from the Sony Style website (www.sonystyle-europe.com), or from your

local Sony dealer.

❑ Detailed information about which CLIÉ handhelds are compatible with which Memory Sticks can be

found here: www.clie-link.com

❑ Detailed information about which VAIO computers are compatible with which Memory Sticks can be

found here: www.vaio-link.com

Using your VAIO computer

LOCK

LOCK LOCK

Write-protecting a Memory Stick

Memory Sticks are designed with an erasure prevention switch to protect valuable data from accidental erasure or overwriting.

Hardware Guide

Move the tab to the right or left* to set or release write-protection. When the erasure prevention switch is off, data can be saved on the Memory Stick. When the erasure prevention switch is on, data can be read from but not saved on the Memory Stick.

* The 128 MB Memory Stick has a vertical lock.

Inserting a Memory Stick

There are 2 ways you can insert a Memory Stick in your computer:

❑ Using the Memory Stick slot; ❑ Using a PC Card slot. To do this, you need an optional PC Card adapter.

You can only insert one Memory Stick at a time.

To insert a Memory Stick using the Memory Stick slot, proceed as follows:

1 Once you have stored your data from your digital device, insert the Memory Stick with the arrow facing

up and toward the Memory Stick slot.

Using your VAIO computer

2 Carefully slide the Memory Stick into the slot until it clicks in place.

The Memory Stick is automatically detected by your system and appears in your My Computer window as a local drive, under the appropriate letter (depending on the configuration of your computer).

Hardware Guide

! Hold the Memory Stick with the arrow pointing in the correct direction when you insert it into the slot. To avoid damaging the computer or the Memory

Stick, do not force the Memory Stick into the slot if it does not insert smoothly.

Removing a Memory Stick

To remove a Memory Stick using the Memory Stick slot, proceed as follows:

1 Check that the access light is off. 2 Push the Memory Stick in towards the computer.

The Memory Stick ejects.

3 Pull the Memory Stick out of the slot.

✍ Always remove the Memory Stick gently, or it may pop out unexpectedly.

It is recommended that you remove the Memory Stick before shutting down the computer.

Using your VAIO computer

Using the modem

Your computer is equipped with an internal modem. You need to connect to a phone line to take advantage of online services and the Internet, as well as to

Hardware Guide

To connect a phone line, proceed as follows:

1 Plug one end of the phone cable (1) into the phone line jack on the computer. 2 Plug the other end into the wall jack (2).

Troubleshooting the modem

My modem does not work or cannot establish a connection

❑ Check that the phone line is plugged into your computer. ❑ Make sure that the modem is the only device connected to your phone line. ❑ Check that the phone line is working. You can check the line by plugging in an ordinary phone and

listening for a dial tone.

❑ Check that the phone number the program is dialling is correct. The modem dialling mode may be

incompatible with your telephone line.

❑ The modem may not work properly if you are with a Private Automatic Branch eXchange (PABX).

Using your VAIO computer

❑ In the Phone and Modem Options dialog box (Control Panel / Phone and Modem Options), check

that your modem is listed in the Modems tab, and that the location information is correct on the Dialing Rules tab. If you do not see the Phone and Modem Options icon, click Switch to Classic View on the left side.

Hardware Guide

❑ A country-specific phone plug is supplied with your VAIO computer, allowing you to plug the phone line

into the wall jack. We recommend you to use the supplied plug, because the usage of any other phone plug can decrease the connection quality.

❑ Your computer cannot be connected to a coin-operated telephone, and may not work with multiple

phone lines or a private branch exchange (PBX). If you connect the modem to a parallel connected phone line, the modem or the other connected device may not function properly. Some of these connections may result in excess electrical current and could cause a malfunction in the internal modem.

❑ Only DTMF (Dual Tone Multi Frequency) signalling (tone dialling) is supported. ❑ Before using the modem, it will be necessary to select the country where you are actually using it. The

detailed procedure for selecting your present location is explained in Configuring your modem in the Software Guide.

❑ Do not pull the flexible cover too forcefully.

My modem connection is slow

Many factors influence modem connection speed, including telephone line noise or compatibility with telephone equipment (such as fax machines or other modems). If you think your modem is not connecting properly to other PC-based modems, fax machines, or your Internet Service Provider, check the following:

❑ Have your phone company check that your phone line is free from any line noise. ❑ If your problem is fax-related, check that there are no problems with the fax machine you are calling and

that it is compatible with fax modems.

Using your VAIO computer

❑ If you are having a problem connecting with your Internet Service Provider, check that the ISP is not

experiencing technical problems.

❑ If you have a second phone line available, try connecting the modem to that line.

Hardware Guide

Using your VAIO computer

Using the Bluetooth functionality

Your notebook is equipped with Bluetooth*. The Bluetooth wireless technology enables you to establish wireless communication between your notebook and other Bluetooth devices such as a notebook, a mobile

Hardware Guide

phone or a modem station without any cable within a 10 metres range in open space. All Bluetooth communications are made in conjunction with the BlueSpace NE software.

To connect to a Bluetooth device, proceed as follows:

1 Turn on the Wireless switch.

The Switch wireless devices dialog box appears.

2 Select the Bluetooth option button. 3 Click OK.

The Bluetooth icon appears in the taskbar.

∗

Depending on your model. Read the printed Specifications document for more information.

✍ Read the Bluetooth Regulations Lea flet before using the Bluetooth functionality.

The 2.4 GHz band with which Bluetooth devices or wireless LAN devices work, is used by various devices. Bluetooth devices use the technology to minimize the interference from other devices that use the same wave length. Communication speed and distances can be inferior to the standard values. Interference from other devices may also stop communications.

! The Bluetooth functions may not work depending on the devices or the software version used. ! When you purchase Bluetooth devices, check their operating conditions.

Bluetooth security

The Bluetooth wireless technology has an authentication function, which allows you to make sure with whom you communicate. With the authentication function, you can avoid any anonymous Bluetooth device to access your notebook. The first time two Bluetooth devices communicate, a common Passkey (a password required for

Using your VAIO computer

authentication) should be determined for both devices to be registered. Once a device is registered, there is no need to reenter the Passkey. You can change your settings in order not to be discovered by other Bluetooth devices or you can set a limit. For more information, see the BlueSpace NE online help.

Hardware Guide

Setting up Wireless Connections with BlueSpace NE

Your notebook is equipped with the Bluetooth wireless technology*. This new technology allows wireless communication over short distances and completely eliminates the need of using cables. All Bluetooth communications are made in conjunction with the BlueSpace NE software.

∗ Depending on your model. Read the printed Specifications document for more information.

Communicating with another Bluetooth device

With the BlueSpace NE software, you can connect your notebook to a Bluetooth device such as another notebook, a mobile phone or a modem station without any cables. For more details, see the BlueSpace NE online help.

To communicate with another Bluetooth device, proceed as follows:

1 Turn on the Bluetooth switch. 2 When the Switch wireless devices dialog box appears, select Bluetooth, and the application will start

automatically. The Bluetooth light indicator turns blue.

3 Click the Device Discovery button in your notebook’s panel on the left of the window to see the

available remote devices.

4 Select the remote device you want to connect to. If necessary, scroll up and down in the Bluetooth

Device List to make your selection.

Using your VAIO computer

5 Click the Service Discovery button to find the services available for the selected device.

Sometimes when using a remote device, the confirmation for the authentication dialog box is displayed.

6 Click Yes and the Bluetooth Connection Wizard appears.

Hardware Guide

7 Click Next to continue. 8 Enter the same passkey in both your local and your remote device, and then click Next. Once the remote

device has been successfully authenticated, click Finish and the Service Discovery will be carried out.

9 Click the service icon you want to use and proceed as applicable in each profile. When the connection

has been completed and the information has been sent, the service icon turns blue.

✍ Do not simultaneously use the Bluetooth function and wireless

communication devices which use the 2.4 GHz band such as a wireless LAN PC Card.

The passkey can be different each time, but must be the same at both ends.

For certain devices, such as a mouse, no passkey can be entered.

!If you changed the name of your computer during Windows

go to USB Bluetooth Device under Device Manager (Start - Control Panel System - Hardware - Device Manager - Bluetooth Radios) and right-click Properties. Under Advanced click Default to restore the default name since the name of your computer and the computer name defined in BlueSpace NE must be the same. For further information, please go to www.vaio-link.com

setup, please

Using your VAIO computer

Communicating with another Bluetooth device using the connection navigation

With the BlueSpace NE connection navigation, you can easily establish a Bluetooth connection and transfer data, such as files or pictures, to another Bluetooth device*.

Hardware Guide

To use the BlueSpace NE connection navigation, proceed as follows:

1 Turn on the Bluetooth switch. 2 When the Switch wireless devices dialog box appears, select Bluetooth, and the application will start

automatically. The Bluetooth light indicator turns blue.

3 Click the Connection navigation button in your notebook’s panel on the left of the window and follow

the steps in the BlueSpace NE connection navigation dialog box.

∗ For more details, see the BlueSpace NE online help.

✍ Do not simultaneously use the Bluetooth function and wireless communication devices which use the 2.4 GHz band such as a wireless LAN PC Card.

The passkey can be different each time, but must be the same at both ends.

For certain devices, such as a mouse, no passkey can be entered.

! If you changed the name of your computer during Windows

Control Panel - System - Hardware - Device Manager - Bluetooth Radios) and right-click Properties. Under Advanced click Default to restore the default name since the name of your computer and the computer name defined in BlueSpace NE must be the same. For further information, please go to www.vaio-link.com

Stopping the Bluetooth connection

To stop the Bluetooth individual connection, proceed as follows:

1 Click the service button of the service from which you wish to disconnect. 2 Click Yes in the Confirm Service Disconnection dialog box. 3 Turn off the Bluetooth switch located on the left front side of your notebook.

The Bluetooth LED turns off.

setup, please go to USB Bluetooth Device under Device Manager (Start -

Using your VAIO computer

Troubleshooting Bluetooth

I cannot use the Bluetooth function

Hardware Guide

❑ If the Bluetooth LED is off, turn on the Bluetooth switch. ❑ You cannot use the Bluetooth function when the computer is in a power saving mode. Return to normal

mode, then turn on the Bluetooth switch located on the front of your notebook.

❑ You may not be able to use the Bluetooth function if you choose the Minimum CPU performance

feature in PowerPanel. Select another mode. See the PowerPanel online help for more details.

❑ You may not be able to use the Bluetooth function if you choose Ultimate Battery Life in PowerPanel.

Select another mode. See the PowerPanel online help for more details.

The connected device does not appear in the Remote Bluetooth Device List

If the connected device is also connected to other devices, it may not appear in your Remote Bluetooth Device Panel or you may not be able to communicate with the device.

I cannot find the Bluetooth device with which I want to communicate

❑ Check that the Bluetooth function of the device with which you want to communicate is on. See the

other device’s manual for more details.

❑ If the device with which you want to communicate is already communicating with another Bluetooth™

device, it may not be found or it may not be able to communicate with your notebook.

The data transfer speed is slow

The data transfer speed depends on the obstacles and/or the distance between the two devices, but also on the radio wave quality, the operating system or the software used. Try to move your notebook or try to place the two devices closer.

Using your VAIO computer

I cannot communicate with the other device although the distance between both devices is within 10 metres

❑ The data transfer distance can be shorter than 10 metres depending on existing obstacles between the

two devices, on radio wave quality, on the operating system or the software used. Try to move your notebook or to place both devices closer.

Hardware Guide

❑ If the device with which you want to communicate is already communicating with another Bluetooth

device, it may not be found or it may not be able to communicate with your notebook.

❑ Check that the Bluetooth function of the device with which you want to communicate is on. See the

other device’s manual for more details.

Using your VAIO computer

Using Wireless LAN (WLAN)

Thanks to Sony’s Wireless LAN (WLAN), all your digital devices with built-in WLAN functionality communicate freely with each other through a powerful network. A WLAN is a network in which a mobile

Hardware Guide

user can connect to a local area network (LAN) through a wireless (radio) connection. So there is no need anymore to pull cables or wires through walls and ceilings. The Sony WLAN supports all normal Ethernet activities, but with the added benefits of mobility and roaming. You can still access information, internet/intranet and network resources, even in the middle of a meeting, or as you move from one place to another. You can communicate without an Access Point, this means that you can communicate between a limited number of computers (ad-hoc), or you can communicate through an Access Point, which allows you to create a full infrastructure network (infrastructure).

✍ In some countries, using WLAN products may be restricted by the local regulations (e.g. limited number of channels). Therefore, before activating the

WLAN functionality, read the Wireless LAN Regulation carefully. For more information on channel selection, see Wireless LAN channel selection (page 57).

WLAN uses the IEEE 802.11b/g standard, which specifies the used technology. The standard includes the encryption method: Wired Equivalent Privacy (WEP), which is a security protocol and WiFi Protected Access (WPA - Proposed jointly by the IEEE and Wi-Fi Alliance, WiFi Protected

Access is a specification of standards based, interoperable security enhancements that increase the level of data protection and access control for existing WiFi networks. WPA has been designed to be forward compatible with the IEEE 802.11i specification. It utilizes the enhanced data encryption TKIP (Temporal Key Integrity Protocol) in addition to user authentication using 802.1X and EAP (Extensible Authentication Protocol)). Data encryption protects the vulnerable wireless link between clients and Access Points. Besides that, there are other typical LAN security mechanisms to ensure privacy, such as: password protection, end-to-end encryption, virtual private networks, and authentication.

Wireless LAN devices using the IEEE 802.11a standard and the ones using the IEEE 802.11b or g standard cannot communicate because the frequencies are different. Wireless LAN devices using the IEEE 802.11g standard can only communicate with a device using the IEEE 802.11b standard, not with the a standard.

IEEE 802.11b: The standard speed is 11 Mbps, or about 30 to 100 times faster than a standard dial up. IEEE 802.11g: The standard speed is 54 Mbps, or about 5 times faster than a Wireless LAN device using the IEEE 802.11b standard.

Using your VAIO computer

Communicating without Access Point (ad-hoc)*

An ad-hoc network is a network in which a local network is created only by the wireless devices themselves, with no other central controller or Access Point. Each device communicates directly with other devices in the

Hardware Guide

network. You can set up an ad-hoc network easily at home.

* For more information on your model, please read your Specifications document.

If your computer is equipped with wireless LAN 802.11 b/g, proceed as follows:

1 Turn on the Wireless LAN switch.

If your notebook supports Bluetooth, the Switch wireless devices dialog box appears. Select Wireless LAN and click OK. The Wireless Switcher button changes into Wireless LAN.

2 Double-click the network icon in the taskbar displaying Wireless Network Connection.

The Connect to Wireless Network dialog box appears.

3 Click the Advanced button.

The Wireless Network Connection Properties dialog box appears.

4 Select the Wireless Networks tab.

Using your VAIO computer

5 Click the Add… button.

The Wireless Network Properties dialog box appears.

6 Enter a Network name (SSID)*.

You can choose a 6-digit name.

Hardware Guide

7 Select Open from the Network Authentication drop-down box. 8 Select WEP from the Data Encryption drop-down box. 9 Deselect the The key is provided for me automatically option button.

Some information becomes visible.

10 Fill in the Network key*.

The network key should be 5 or 13 ascii characters or 10 or 26 hexadecimal characters long. You can choose whatever you want**.

11 Fill in exactly the same Network key again, for confirmation. 12 Select the checkbox This is a computer to computer (ad hoc) network; wireless access points are

not used at the bottom of the screen.

13 Click OK.

You r Network name appears in the Preferred networks.

14 Click Advanced.

The Advanced dialog box appears.

15 Select the Computer-to-computer (ad hoc) networks only option button. 16 Click Close. 17 Click OK.

Your computer is ready to communicate with another computer.

* If you want to communicate between two or more computers, you need to configure all these computers the exact same way. This means that you need to enter the same Network name and the same Network key on all computers as on the first computer you configure.

Using your VAIO computer

** ASCII: The basis of character sets used in almost all present-day computers. ASCII is a code for representing English characters as numbers, with each letter assigned a number from 0 to 127. Hexadecimal: A number representation using the digits 0-9, with their usual meaning, plus the letters A-F (or a-f) to represent hexadecimal digits with values of (decimal) 10 to 15.

Hardware Guide

✍ In France, only certain channels are legally allowed when using WLAN outdoors.

For more information, see the Wireless LAN Regulations leaflet.

An ad-hoc network does not support WPA.

If your computer is equipped with wireless LAN 802.11 b, proceed as follows:

1 Turn on the Wireless LAN switch.

The Switch wireless devices dialog box appears.

2 Select Wireless LAN and click OK.

The Wireless Switcher button changes into Wireless LAN.

3 Double-click the network icon in the taskbar displaying Wireless Network Connection.

The Wireless Network Connection dialog box appears.

4 Click the Advanced button.

The Wireless Network Connection Properties dialog box appears.

5 Select the Wireless Networks tab. 6 Click the Add… button.

The Wireless Network Properties dialog box appears.

7 Enter a Network name (SSID)*.

The Data encryption (WEP enabled) option button must be selected.

8 Select the Network Authentication (Shared mode) option button. 9 Deselect the The key is provided for me automatically option button.

Some information becomes visible.

Using your VAIO computer

10 Fill in the Network key**.

The network key should be 5 or 13 ascii characters or 10 or 26 hexadecimal characters long. You can choose whatever you want***.

11 Click OK.

Hardware Guide

You r Network name appears in the Preferred networks.

12 Click Advanced.

The Advanced dialog box appears.

13 Select the Computer-to-computer (ad hoc) networks only option button. 14 Click Close. 15 Click OK.

Your computer is ready to communicate with another computer.

* For more information on your model, please read your Specifications document.

** If you want to communicate between two or more computers, you need to configure all these computers the exact same way. This means that you need to enter the same Network name and the same Network key on all computers as on the first computer you configure.

*** ASCII: The basis of character sets used in almost all present-day computers. ASCII is a code for representing English characters as numbers, with each letter assigned a number from 0 to 127. Hexadecimal: A number representation using the digits 0-9, with their usual meaning, plus the letters A-F (or a-f) to represent hexadecimal digits with values of (decimal) 10 to 15.

✍ In France, only certain channels are legally allowed when using WLAN outdoors.

For more information, see the Wireless LAN Regulations leaflet.

Using your VAIO computer

Communicating with an Access Point (infrastructure)

An infrastructure network is a network that extends an existing wired local network to wireless devices by providing an Access Point, for example the Sony PCWA-A320 Access Point. The Access Point bridges the

Hardware Guide

wireless and wired LAN and acts as a central controller for the Wireless LAN. The Access Point coordinates transmission and reception from multiple wireless devices within a specific range.

To communicate with an Access Point (infrastructure), proceed as follows:

1 Turn on the Wireless switch.

If your notebook supports Bluetooth, the Switch wireless devices dialog box appears. Select Wireless LAN and click OK. The Wireless Switcher button changes into Wireless LAN.

2 Right-click the network icon in the taskbar displaying the Wireless Network Connection message. 3 Click View Available Wireless Networks.

The Wireless Network Connection dialog box appears.

4 Select the network you want to use.

Using your VAIO computer

5 Type the Network Key.

If you are using the Sony Access Point PCWA-A320, by default, you do not need to enter any encryption key (WEP/WPA). To be able to communicate, you must select the box Allow me to connect

to the selected wireless network, even though it is not secure.

Hardware Guide

6 Click Connect.

After 30 seconds, the connection is established.

✍ For more information about setting up an access point, see the documentation supplied with your Access Point.

The length of the network key can be set up as in the case of ad-hoc network; meaning, 5 or 13 ascii characters or 10 or 26 hexadecimal characters long.

The WPA key needs to contain at least 8 characters.

Using the WiFi protected access (WPA)

WPA is a wireless security enhancement that allows you to transfer data in a highly secure way*.

To use WPA on your notebook, proceed as follows:

1 Turn on the Wireless LAN switch.

If your notebook supports Bluetooth, the Switch wireless devices dialog box appears. Select Wireless LAN and click OK. The Wireless Switcher button changes into Wireless LAN.

2 Right-click the network icon in the taskbar displaying Wireless Network Connection. 3 Select View available network connections.

The Wireless Network Properties dialog box appears.

4 Select the wireless network to which you want to connect. 5 Fill in the Network key.

The network key should be at least 8 characters long. You can choose whatever you want.

6 Fill in exactly the same Network key again, for confirmation.

Using your VAIO computer

7 Click Connect.

The connection is established.

∗ For more information on the access point, please refer to its manual.

Hardware Guide

✍ In France, only certain channels are legally allowed when using WLAN outdoors.

For more information, see the Wireless LAN Regulations leaflet.

Wireless LAN channel selection

In a 802.11b configuration, channel 1 to 11 can be used. In a 802.11g configuration, channel 1 to 13 can be used*.

∗ Depending on your model. Read the printed Specifications document for more information.

(a) With an access point ("Infrastructure")

❑ The channel used will be the channel selected by the Access Point. ❑ ATT: For details on how to select the channel that will be used by the Access Point, please refer to the

corresponding Instruction Manual.

(b) Without an access point ("Ad-hoc")

❑ If the Wireless connection is initiated by the VAIO computer, channel 11 will be selected. ❑ ATT: In France, outdoors, Wireless LAN connections are only allowed on certain channels. For details,

please refer to the Wireless LAN Regulations leaflet.

❑ If the Wireless connection is initiated by a peer Wireless LAN equipment, the Wireless LAN

communication will make use of the channel selected by the peer Wireless LAN equipment.

Using your VAIO computer

Troubleshooting Wireless LAN

I cannot use the Wireless LAN function

Hardware Guide

❑ Check if the Wireless switch is turned on.

The Wireless LAN Access Point and your computer cannot communicate

❑ Check if the Wireless LAN switch is turned on. ❑ Check if the power of the Access Point is turned on. ❑ Check if the Access Point is displayed in the Available networks window.

❑ To check this, click Start and then Control Panel. ❑ Double-click the Network Connections icon. ❑ Right-click the Wireless Network Connection icon and select Properties. ❑ Select the Wireless Networks tab. ❑ Check if the Access Point is displayed in Available networks. ❑ Connection availability is affected by distance and obstructions. You may need to move your

computer away from obstructions or neared to any Access Point you may be using.

The data transfer speed is slow

❑ The maximum communication speed can vary depending on the obstacles or the distance between the

communication devices, the radio waves, the operating system or the software you use. Remove the obstacle or make the distance between the Access Point and your machine smaller.

❑ It is possible that your Access Point communicates at the same time with another Access Point. Read the

manual of the Access Point.

❑ If several computers communicate with the same Access Point, the concentration may be too high. Wait

a few minutes and try to access again.

Using your VAIO computer

❑ If a Wireless LAN device using the IEEE 802.11g standard communicates with a device using the IEEE

802.11b standard, then it is normal that the speed reduces. Devices using the IEEE 802.11g standard are 5 times faster then the ones using the IEEE 802.11b standard.

Hardware Guide

I cannot access the Internet

❑ Check the settings of the Access Point. See the manual of the Access Point. ❑ Check if your computer and the Access Point are communicating. ❑ Make the distance between the Access Point and your machine smaller.

Using your VAIO computer

Using the built-in MOTION EYE Camera*

Your computer includes a built-in MOTION EYE camera. You can use the camera software to shoot still images, record video clips or make on line video conferences.

Hardware Guide

You can focus the image turning the adjustment dial (2) in the camera. You can also rotate the MOTION EYE camera backwards and forwards to choose the view point shown in the camera.

∗ Depending on your model. Read the printed Specifications document for more information.

On the right side of the LCD screen, you find the CAPTURE button (3) for using with the MOTION EYE camera. Clicking this button you can:

❑ Shoot still images ❑ Start and stop recording video clips

Using your VAIO computer

❑ Start the Network Smart Capture application

✍ To start Network Smart Capture with the Capture button, the application must be installed.

To start the MOTION EYE camera with the Windows® application, proceed as follows:

Hardware Guide

Under Start- My Computer- Scanners and Cameras click Sony Visual Communication Camera VCCU01.

The camera starts automatically. The MOTION EYE camera indicator (1) turns green when the camera is working.

✍ You can only shoot still images.

To start the MOTION EYE camera with the Network Smart Capture application, proceed as follows:

❑ Click Start - All Programs - Network Smart Capture,

❑ Press the Capture button.

For more information about Network Smart Capture, please refer to the Software Guide supplied with your computer.

Troubleshooting MOTION EYE Camera

There is a vertical line when shooting a bright subject with a dark background using MOTION EYE

This is a phenomenon called “smear”. It is not a malfunction.

The image in the view finder of Network Smart Capture is rough

If you are shooting a subject in rapid movement, there may be a gap. This is not a malfunction.

Using your VAIO computer

The images captured with MOTION EYE are not clear

❑ Shooting under fluorescent light may result in reflections. ❑ Red or green noises may occur if the captured images include dark parts.

Hardware Guide

❑ Check that the lens of the MOTION EYE is clean. ❑ Use the focus ring to adjust.

There are picture gaps and sound gaps when importing video images

Gaps may occur based on the effect settings in Network Smart Capture.

The MOTION EYE does not show any images

❑ Check that other software such as Network Smart Capture does not use the MOTION EYE. ❑ Depending on monitor mode, colour palette and other causes, the video memory is running out and the

camera image is not displayed. Reduce the colour palette or monitor resolution.

❑ If the above countermeasures do not work, restart the computer.

Using your VAIO computer

Using power saving modes

When you use a battery as the source of power for your computer, you can take advantage of power management settings to conserve battery life. In addition to the normal operating mode, which allows you

Hardware Guide

to turn off specific devices, your computer has two distinct power saving modes: Standby and Hibernate. When using battery power, you should be aware that the computer automatically enters Hibernate mode when the remaining battery charge drops below 7 percent, regardless of the power management setting you select.

✍ If the battery level falls below 10 percent, you should either attach the AC adapter to recharge the battery or shut down your computer and insert a

fully charged battery.

Using Normal mode

This is the normal state of your computer when it is in use. The green power indicator light is on in this mode. To save power while not working, you can turn off a specific device such as the LCD or the hard disk.

Using Standby mode

Standby mode turns off the LCD screen and sets the hard disk and the CPU to a low power consumption mode. The umber power light flashes in this mode.

To activate Standby mode, proceed as follows:

Go to Start/Turn Off Computer and press Stand By. Or press the <Fn>+<Esc> keys simultaneously. To return to Normal mode, press any key.

Using your VAIO computer

✍ If you press the power button for more than four seconds, the computer will switch off automatically.

When the computer is in Standby mode, you cannot insert a disc.

The computer comes out of Standby mode quicker than out of Hibernate mode.

Hardware Guide

Standby uses more power than Hibernate.

If the computer is not used for 25 minutes, it will enter System Standby mode when running on AC power. When running on batteries, the computer will enter System Standby mode after 5 minutes if unused. To avoid this, you can change the settings either in PowerPanel (right-click on the PowerPanel icon and select Edit/Create Profile) or in the Control Panel. Please note that your Control Panel settings are valid only until the next reboot.

Using Hibernate mode

The state of the system is saved on the hard disk and power is turned off. The power indicator light is off in this mode.

To activate Hibernate mode, proceed as follows:

Press <Fn>+<F12>. The Hibernating screen appears and the computer enters Hibernate mode.

Alternatively, Click Start, and then Turn Off Computer.

In the Turn off computer screen, hold down the <Shift>-key and press Hibernate.

To return to Normal mode, proceed as follows:

Turn on the computer by pressing the power button. The computer returns to its previous state.

Using your VAIO computer

✍ If you press the power button for more than four seconds, the computer will switch off automatically.

When the computer is in Hibernate mode, you cannot insert a disc.

Hibernate mode requires more time than Standby mode to be activated.

Hardware Guide

It takes more time to return to normal mode from Hibernate mode than from Standby mode.

Hibernate mode uses less power than Standby mode.

Do not move the computer until its power indicator turns off.

Using your VAIO computer

Troubleshooting power management

The power management setting is not responding

Your computer’s operating system may become unstable if a lower power state, such as Hibernate is

Hardware Guide

initiated, and then changed before the computer completely enters the lower power state.

To restore the computer to its normal operating stability, proceed as follows:

1 Close all open applications. 2 Press <Ctrl>+<Alt>+<Delete> simultaneously and select Restart from the drop-down list.

The computer restarts.

3 If the procedure does not work, press and hold the power button for four seconds or longer to shut

down the computer.

Using your VAIO computer

Managing power with PowerPanel

The PowerPanel utility controls the power management of your computer and provides key information about system activity and battery life. The automatic power management selects the most advantageous

Hardware Guide

profiles, or lets you customise the profiles you choose, according to your own needs, with the goal of extended battery life.

Moreover, performance of your computer can be improved with Performance Balancer, both for battery and AC mode, adjusting LCD brightness and CPU fan noise.

PowerPanel has the following features:

❑ Automatic Profile Selection (APS) based on the currently active application; ❑ Ability to select specific Power Profiles manually from the menu; ❑ Ability to edit and create new profiles; ❑ Ability to display detailed battery information; ❑ It works in harmony with your Windows settings; ❑ Support for Windows XP Theme; ❑ ToolTips to signal Power Profile changes; ❑ Ability to select limited Power Profiles directly from the Power Profile page; ❑ Ability to prevent specific users from modifying profiles.

Using your VAIO computer

Activating PowerPanel

When you start the computer, the PowerPanel icon appears in the system tray by default. To see the current power profile, simply point to the icon. The current power profile will be displayed in a tooltip.

Hardware Guide

To change profiles, proceed as follows:

1 Right-click the PowerPanel icon in the taskbar and select Profiles. 2 In the Profiles menu, select a profile.

The appropriate power settings are activated.

✍ When you use the battery pack as power source, your system selects the Maximum Battery Life power management profile by default. If you select

a different power management profile while using battery power, the same profile will automatically be selected the next time you use the battery pack to power your computer.

Activating power management profiles

PowerPanel provides several predefined power management profiles. Each profile consists of a group of power management settings that are designed to meet specific power management goals, ranging from maximum power management to no power management.

Running on AC

Icon Description

AC Power – The power management state when AC power is in use. PowerPanel automatically loads the AC profile unless you disable this feature.

Power Management Off (Plugged in) – Turns off all power management features such as Standby and Hibernate modes.

Using your VAIO computer

Running on batteries

Icon Description

Hardware Guide

Automatic Profile Selection - Analyses the performance of each application you choose and matches the profiles to its needs.

Maximum Battery Life – Provides power saving features to give you maximum battery life and good performance. It reduces the brightness of the display and puts the system into Standby mode after a specified time period.

Ultimate Battery Life – Extends the Maximum Battery Life by completely disabling the optical drive.

! When you select this profile, it completely shuts off the power of the Memory Stick port to save some extra power for longer

battery life. The Memory Stick port is accessible again as soon as a Memory Stick is inserted in the slot.

! When you select this profile, it completely shuts off the power of the optical drive to save extra power for longer battery life.

The system can neither read nor write from or to the optical drive, moreover the drive does not start spinning at all.

Maximum Performance – Provides the best system performance while still conserving power.

Word Processing – Optimises power management with longer timeouts on the hard disk and display screen. You

can also establish settings for LCD (Video) Standby, Hard Disk Standby, and Standby to optimise power management for your system.

Spreadsheet – Reduces the LCD brightness to 'medium', as your software does not require higher performance.

Presentation – Keeps the display on at all times while it conserves power. This option is ideal for slideshow

presentations. You can establish settings for LCD (Video) Standby, Hard Disk Standby, and Standby to optimise power management for your system.

Communications – Extends battery life by initiating a quick display time-out. You can also establish settings for LCD (Video) Standby, Hard Disk Standby, and Standby to optimise power management for your system.

Using your VAIO computer

Icon Description

Hardware Guide

Power Management Off (Running on batteries) – Turns off all power management features such as Standby

Selecting automatic profiles when running on batteries

A power profile is a set of timer values for a variety of system devices. PowerPanel automatically selects the profile associated with the application you are using and changes profiles as you switch between applications. Power management lets your system enter energy saving modes by levelling some energy-consuming parameters, such as LCD brightness, or hard disk activity.

To select automatic profiles, proceed as follows:

Games – Disables the display and the Hard Disk timer.

DVD – Optimises performance and power requirements for DVD usage.

Camera – Optimises performance and power requirements for camera usage.

and Hibernate modes.

1 Right-click the PowerPanel icon in the taskbar and select Profiles. 2 Select Automatic Profile Selection.

✍ The Automatic Profile Selection feature deactivates when you manually select another power profile from the menu.

Using your VAIO computer

Displaying detailed battery information

You can display detailed information of your computer's battery.

There are 3 ways in which you can display battery information:

Hardware Guide

❑ Right-click the PowerPanel icon in the taskbar and select Battery Information from the menu. ❑ Double-click the PowerPanel icon in the taskbar and select the Battery tab.

The Battery tab in the PowerPanel window contains information such as the estimated battery life remaining and charging time.

❑ Display the Battery Information toolbar on the screen, which shows the battery status icon, the

percentage of remaining capacity and the amount of running time left in the battery. To display the Battery Information toolbar, right-click the taskbar and select Toolbars then Battery Information from the menu.

Battery icon Battery status

Discharging: the icon is blue

Fully charged: the icon is completely blue with an AC power plug

Charging: the icon is blue with a red clip attached to the terminal

No battery: the icon is blue with a yellow cross over it

Using your VAIO computer

Displaying CPU information

You can also view the level of performance of your notebook with the CPU Controls. To do so, you just have to hover your cursor over the CPU icon in the taskbar.

Hardware Guide

There are three possible icons:

Icon Action

Adaptive

Battery Life

Performance

Editing a power profile

This control automatically selects the CPU optimal clock speed and power voltage according to the state in which the computer is used. This will be the default icon when the computer is connected to the mains supply.

This control helps to reduce the notebook’s power consumption by decreasing the CPU clock speed and the power voltage. This icon appears when you right-click the CPU icon in the taskbar and select Profiles and then Ultimate Battery Life. This will be the default icon when the computer running on batteries.

This control helps to maximize the CPU clock speed. The computer can then be used at its maximum performance. This will be the default icon when playing games or watching a DVD.

To edit the power management settings of a power profile, proceed as follows:

1 Right-click the PowerPanel icon in the taskbar and select Edit/Create Profiles from the menu.

The Profile Editor window appears.

2 Click the profile you want to edit on the left of the screen. 3 Double-click the power profile property (Hibernate, Standby…) you want to modify on the right of the

screen. An option list or a dialog box appears.

Using your VAIO computer

4 Make your settings. 5 Click the File menu and then click Save

✍ You must have Administrator’s rights on your computer to be able to edit existing profiles. Users whose account type is Limited can only open the

Hardware Guide

Power Profile tab in the Power Panel window in view mode. To check your user account information, select the User Accounts category in the Control Panel. Your account type must be Computer administrator to be able to edit power profile.

Creating a power profile

To create a power profile, proceed as follows:

1 Right-click the PowerPanel icon in the taskbar and select Edit/Create Profiles from the menu.

The Profile Editor window appears.

2 Select New from the File menu. 3 In the Create New Profile dialog box, check the appropriate option button to specify the type of power

management profile that you want to create and click OK.

4 Select the new power management settings you would like for the device. 5 Click the File menu and then click Save.

Managing performance with Performance Balancer

The Performance Balancer is installed by default together with PowerPanel to set up the performance of your computer depending on the LCD brightness and the quietness of the CPU fan.

To use Performance Balancer, proceed as follows:

1 Click the Start button on the Windows® taskbar. 2 In All Programs, select Performance Balancer and then click Performance Balancer.

The Performance Balancer window appears.

Using your VAIO computer

To set up the performance of your computer, proceed as follows:

1 When operating on battery mode:

❑ Click Power-saving to enjoy a long battery life and a CPU fan with minimum noise. Performance

Hardware Guide

and LCD brightness will be reduced to lower battery consumption.

❑ Click Customize if you want to adjust the brightness and the CPU fan quietness to determine the

CPU performance and the battery life.

❑ Click Full-power to maximise system performance what allows you to run many applications at the

same time with a high LCD brightness. With this setting, the battery life and the quietness of CPU fan are reduced.

2 When plugged in:

❑ Click Customize if you want to adjust the brightness and CPU fan quietness manually to determine

the CPU performance and the power consumption.

❑ Click Full power to maximise system performance, which allows you to run many software at the

same time, renouncing to CPU fan quietness.

An additional option is the Timer Settings where you can set up the LCD display to turn off automatically and go into Standby mode after a period of inactivity, when operating either on battery or AC mode.

Connecting peripheral devices

You can add functionality to your computer by using the various ports on your unit.

❑ Connecting a port replicator (page 76)

Hardware Guide

❑ Connecting an external display (page 81) ❑ Selecting display modes (PCG-Z1, PCG-V505 series) (page 85) ❑ Selecting display modes (PCG-TR series) (page 86) ❑ Using the Dual Display function (page 88) ❑ Connecting external speakers (page 91) ❑ Connecting an external microphone (page 92) ❑ Connecting a Universal Serial Bus (USB) device (page 93) ❑ Connecting a printer (page 98) ❑ Connecting an i.LINK device (page 100) ❑ Connecting to a network (LAN) (page 103)

✍ To identify and locate the ports on your computer, please see the printed Specifications sheet.

Sony computer supplies, accessories and peripherals can be purchased from your local retailer or from the Sony website: www.sonystyle-europe.com

For more information about connection compatibility, go to the VAIO-Link website: www.vaio-link.com

Connecting peripheral devices

Connecting a port replicator

Your computer supports the use of an optional port replicator. Attaching a port replicator enables you to connect additional peripherals to your computer, such as a printer or an external display*.

Hardware Guide

PCG-Z1 series:

1 DC In port (page 14) 4 Monitor/VGA port (page 81)

2 3 USB ports (page 93) 5DVI-D connector(page 82)

3 Parallel printer port (page 98) 6 Ethernet port

(10BASE-T/ 100BASE-TX)

(page 103)

Connecting peripheral devices

PCG-V505 series:

Hardware Guide

1DVI-D connector(page 82) 4 Parallel printer

port

2 Monitor/VGA port (page 81) 5 Ethernet port

(10BASE-T/ 100BASE-TX)

3 3 USB ports (page 93) 6 DC In port (page 14)

∗ Depending on your model. Read the printed Specifications document for more information.

(page 98)

(page 103)

✍ The port replicator can be powered only with the AC adapter supplied with your notebook. Do not remove the AC adapter from the port replicator or

the AC outlet when using the port replicator; this may cause data damage or hardware malfunctions.

Attaching your computer to the port replicator

If your computer is equipped with a port replicator, proceed as follows:

1 Disconnect all peripherals from the computer. 2 Plug the cable attached to the AC adapter (1) into the DC In port (2) on the port replicator (3).

Connecting peripheral devices

3 Plug the power cord (4) into the AC adapter and an AC outlet.

Hardware Guide

4 Open the port replicator cover.

5 Align the bottom connector of the notebook with the connector on the port replicator and push down

until it clicks into place.

Connecting peripheral devices

Hardware Guide

6 Turn on the notebook.

✍ When attaching your computer to the port replicator, do not attempt to insert or remove the battery pack. Lifting and turning the computer with the

attached port replicator may cause a temporary loss of power.

Use the AC adapter that comes with your notebook or the optional Sony adapter.

Connecting peripheral devices

Disconnecting your computer from the port replicator

To disconnect your computer from the port replicator, proceed as follows:

1 Stop the connected peripherals.

Hardware Guide

2 Close the cover and pull the levers on each side of the port replicator to disconnect the computer from

the port replicator.

3 Lift the computer away from the port replicator. 4 Close the port replicator connector cover on the bottom of your computer.

✍ It is extremely important to close the port replicator connector cover after removing your computer from the port replicator. If the cover is left open,

dust may get inside and damage the computer. To disconnect your port replicator completely from the mains voltage, unplug the AC adapter.

Connecting peripheral devices

Connecting an external display

You can connect an external display to your computer. For example, you can use your computer with a computer display or a projector.

Hardware Guide

✍ Turn off your computer and the peripherals, unplug the AC adapter and the power cord before connecting the external display.

Connect the power cord after connecting all other cables.

Turn on the peripherals, then turn on your computer.

Connected external displays are used as second screens.

On Windows systems only, you can also use an external display to set up a virtual desktop.

Connecting peripheral devices

Connecting a computer display

You can connect a computer display (monitor) either directly to your computer or via the (optional) port replicator.

Hardware Guide

To connect a computer display, proceed as follows:

1 If you want to connect a VGA monitor, plug the display

cable (1) (not supplied) on the notebook or on the port replicator.

2 If you want to connect a TFT/DVI monitor, plug the

display cable (not supplied) into the DVI-D connector on the port replicator.

3 If necessary, plug one end of the display’s power cord

(3) into the display, and the other end into an AC outlet.

✍ DVI-D stands for Digital Visual Interface - Digital. It is a kind of DVI connector that only supports digital video signals, so no analogue video

signals. It has 24 pins.

A DVI-I connector (Digital Visual Interface - Integrated) supports digital video and analogue video signals. It has 29 pins.

! You can not connect a DVI-I to VGA cable to a DVI-D connector!

Connecting peripheral devices

Connecting a multimedia computer display

You can connect the computer to a multimedia computer display that includes built-in speakers and a microphone.

Hardware Guide

To connect a multimedia computer display, proceed as follows:

1 Plug the display cable (1) into the monitor/VGA

connector (2) on the computer.

2 Plug the speaker cable (3) into the headphone

connector (4) on the computer.

3 Plug the microphone cable (5) into the microphone

connector (6) on the computer.

Connecting peripheral devices

Connecting a projector

To connect a projector, proceed as follows:

1 Plug the RGB signal cable (1) into the

Hardware Guide

monitor/VGA connector (2) identified by the symbol.

2 Plug the audio cable (3) (not supplied)

into the earphone connector (4) identified by the symbol.

3 Plug the RGB signal cable and the audio

cable into the connectors of the projector (5).

4 Connect the power cord (6) of the

projector into an AC outlet.

✍ Under certain circumstances, you may not be able to

display the computer LCD screen and an external display or a projector at the same time.

You can toggle the output between the computer LCDscreen and the external monitor by pressing the key combination <Fn>+<F7>.

Connecting peripheral devices

Selecting display modes (PCG-Z1, PCG-V505 series)

Both models use the MOBILITY RADEON video controller. You can select which display is used when the computer is connected to an external display. When you connect an external display, you can switch the

Hardware Guide

display between your computer's LCD and the external monitor. Before you can select a display, you need to shut down your computer, connect the external display (FDP (Flat Display Panel), panel or monitor to your computer, and restart.

To select a display, proceed as follows:

1 Click the Start, then Control Panel.

The Control Panel appears.

2 Double-click Appearance and Themes, and then select Display.

The Display Properties dialog box appears.

3 Click the Settings tab. 4 Click the Advanced button.

The Sony Notebook LCD and MOBILITY RADEON Properties dialog box appears.

5 Click the Displays tab.

Select the Monitor, Panel or FPD icon.

6 Click Apply and then OK.

✍ You may not be able to display the computer LCD screen and an external display or a projector at the same time, depending on the types of computer

displays and projectors you are using.

Before turning on the computer, turn on the peripheral devices.

Connecting peripheral devices

Selecting display modes (PCG-TR series)

This model uses the Intel® 855 GM Integrated Graphics video controller. You can select which display is used when the notebook is connected to an external device.

Hardware Guide

To connect an external display, proceed as follows:

1 Connect the external device to the Monitor/VGA connector on the left side of the computer. 2 Press and hold the <Fn> key and press the <F7> key to change the destination.

The output destination changes every time you press the <F7> key while holding the <Fn> key. The output destination options are listed below:

• LCD only: Displays contents on your computer's LCD only.

• LCD only + MONITOR (VGA): Displays contents simultaneously on your computer's LCD and the external display*.

• MONITOR (VGA): Displays contents on the external display only*.

• Setup: Displays the resolution setting window for the external display. The image appears on the external display.

To set up the video controller options, proceed as follows:

1 Click Start, then Control Panel.

The Control Panel appears.

2 Double-click Appearance and Themes, and then select Display.

The Display Properties dialog box appears.

3 Click the Settings tab. 4 Click the Advanced button and choose the Intel® Extreme Graphics tab.

Then choose the Graphics Properties icon.

5 Click the Devices tab.

Select the Monitor, Notebook, Intel® Dual Display Clone or Extended Desktop icon.

6 Click Apply and then OK.

Connecting peripheral devices

* The external destination is displayed only when an external display is connected to your computer.

✍ You cannot switch the display during video playback or while using the built-in MOTION EYE camera.

Selecting the external display may automatically change the resolution of your computer's LCD.

Hardware Guide

Connecting peripheral devices

Using the Dual Display function

The dual display function allows you to distribute portions of your desktop across separate displays. For example, if you have an external monitor attached to the monitor connector, your LCD display and the

Hardware Guide

monitor can function as a single desktop. You can move the cursor from one display to the other. This allows you to drag objects, such as an open

application window or a toolbar, from one display to the other. This configuration of a single desktop distributed across separate displays, is referred to as a virtual desktop.

✍ Your monitor or TV hardware may not support the Dual Display function.

Certain software applications may not be compatible with Dual Display settings.

Make sure that your computer does not enter Standby or Hibernate mode while you are using Dual Display mode, otherwise your computer may not return to Normal mode.

If you set different colours on each display, do not divide one single window on two displays, otherwise your software may not work properly.

Set fewer colours or a lower resolution for each display.

Connecting peripheral devices

Selecting the Dual Display mode

To select the Dual Display mode, proceed as follows:

1 Click the Start button on the Windows taskbar.

Hardware Guide

2 Click Control Panel. 3 Click Appearance and Themes. 4 Click the Display icon. 5 Select the Settings tab. 6 Click the display marked 2. 7 Select the Extend my Windows desktop onto this monitor check box. 8 Click Apply and then OK.

✍ Your monitor or TV hardware may not support the Dual Display function.

Setting the colours and resolution for each display

You can set the display colours and resolution for each display that is part of a virtual desktop.

To set the display colours and resolution for each display, proceed as follows:

1 Click the Start button on the Windows taskbar. 2 Click Control Panel. 3 Click Appearance and Themes. 4 Click the Display icon. 5 Select the Settings tab. 6 Click the display you want to change (1 or 2): display colours or resolution. 7 Select an option from the Color quality list to change colours. 8 Use the slider in the Screen resolution to adjust the resolution. 9 Click Apply and then OK.

Connecting peripheral devices

Customizing the virtual desktop

You can customize the Dual Display mode by changing the position of the two monitors comprising the virtual desktop.

Hardware Guide

To customize Dual Display mode, proceed as follows:

1 Click the Start button on the Windows taskbar. 2 Click Control Panel. 3 Click Appearance and Themes. 4 Click the Display icon. 5 Click the Settings tab. 6 Drag the monitor icons to match the physical arrangement of your monitors. The two monitor icons must

be connected to create a virtual desktop.

7 Click Apply and then OK.

Deactivating the Dual Display function

To deactivate the Dual Display function, proceed as follows:

1 Click the Start button on the Windows taskbar. 2 Click Control Panel. 3 Click Appearance and Themes. 4 Click the Display icon. 5 Click the Settings tab. 6 Click the display 2. 7 Deselect the Extend my Windows desktop onto this monitor option.

This will disable the Dual Display.

✍ For switching from Primary to Secondary display, see the section Selecting display modes (PCG-Z1, PCG-V505 series) (page 85).

Connecting peripheral devices

Connecting external speakers

You can enhance the sound quality of your computer by connecting external speakers.

To connect external speakers, proceed as follows:

Hardware Guide

1 Plug the speaker cable (1) into the headphone connector (2). 2 Plug the other end of the speaker cable into the external speaker (3). 3 Turn down the volume of the speakers before you turn them on.

✍ Make sure your speakers are designed for computer use.

Do not place floppy disks on the speakers; their magnetic field may damage the data on the disks.

Troubleshooting sound

My speakers are not producing sound

❑ If you use external speakers, check that the speakers are properly connected and the volume is turned

up. If the speakers have a mute button, make sure it is off. If batteries power the speakers, check that the batteries are inserted properly and that they are charged.

❑ If you have connected an audio cable to the headphone connector, disconnect the cable.

Connecting peripheral devices

Connecting an external microphone

If you need to use a sound input device, for example to chat on the Internet, you need to plug in an external microphone.

Hardware Guide

To connect an external microphone, proceed as follows:

Plug the microphone cable (1) into the microphone connector (2) identified by the symbol.

✍ Make sure your microphone is designed for computer use.

Troubleshooting sound

My microphone does not work

❑ If you are using an external microphone, check that the microphone is plugged into the microphone

connector correctly.

Connecting peripheral devices

Connecting a Universal Serial Bus (USB) device

You can connect a USB device (for example, a mouse, floppy disk drive, keyboard, printer) to your computer. USB devices are hot plug and play devices. You do not need to shut down your computer prior to connecting

Hardware Guide

these devices unless the manual supplied with the device states otherwise. For some USB devices you need to install the software before you connect the device. Not following this

procedure might cause the device not to work properly. For more information, check the manual provided with the USB device.

❑ Connecting a USB mouse (page 94) ❑ Connecting a USB floppy disk drive (page 95)

Connecting peripheral devices

Connecting a USB mouse

To connect a USB mouse, proceed as follows:

1 Choose the USB connector (1) you prefer to use.

Hardware Guide

2 Plug the USB mouse cable (2) into the USB connector.

You can use your USB mouse (3).

✍ The VAIO USB mouse software driver is preinstalled on your computer, therefore, you only need to plug the USB mouse into the USB connector and

you can start working.

Connecting peripheral devices

Connecting a USB floppy disk drive

As an optional extra, you can purchase a USB floppy disk drive and connect it to your computer.

To connect a USB floppy disk drive, proceed as follows:

Hardware Guide

1 Choose the USB connector you prefer to use. 2 Plug the USB floppy disk drive cable into the USB connector. The VAIO logo on the disk drive should be

facing up. Your USB floppy disk drive is now ready for use.

To remove a USB floppy disk drive, proceed as follows:

❑ If your computer is on, wait until the floppy drive LED indicator turns off and then unplug the USB cable.

If the floppy disk drive is not removed properly, your system may crash and you may lose any unsaved data.

❑ If your computer is off, you can unplug the USB cable directly from the computer.

Connecting peripheral devices

Inserting a floppy disk

To insert a floppy disk, proceed as follows:

1 Hold the disk (1) with the label side facing up.

Hardware Guide

2 Gently push the disk into the drive (2) until it clicks into place.

Removing a floppy disk

To remove a floppy disk, proceed as follows:

When you have finished using the floppy disk, wait until the LED indicator (1) turns off and then press the eject button (2) to remove the disk.

✍ Before pressing the eject button, make sure that the LED indicator is turned off.

If the disk does not come out by pressing the eject button, disconnect the floppy disk drive from the computer.

! Do not press the eject button while the LED indicator is on. It may damage the floppy disk.

Connecting peripheral devices

Troubleshooting floppy disks

My USB floppy disk drive cannot write to a floppy disk

❑ The floppy disk is write-protected. Disable the write-protect feature or use a floppy disk that is not

Hardware Guide

write-protected.

❑ Check that the disk is properly inserted into the floppy disk drive. ❑ Your disk may be corrupt. Try to insert another floppy disk.

The optional PCGA-UFD5/A (USB) floppy disk drive is not recognised as drive A

To set the UFD5/A to A, proceed as follows :

Turn the system power on.

2 Connect the UFD5/A. 3 Select Control Panel from the Start menu. 4 Double-click System. 5 Select the Hardware tab, then click Device Manager. 6 Select Universal Serial Bus controllers, then Y-E Data USB Floppy. 7 From the Action menu, click Uninstall. 8 Keep clicking OK until the Confirmation of deletion of device message appears. 9 Select Scan for hardware changes from the Action menu.

The UFD5/A is recognised as drive A.

Connecting peripheral devices

Connecting a printer

You can connect a Windows-compatible printer to your computer to print documents.

Hardware Guide

You can connect a USB printer compatible with your version of Windows to your computer.

To connect a printer using the USB connector, proceed as follows:

1 Plug a USB printer cable (1) into one of the USB connectors (2) on your computer.

A USB connector is identified by the symbol on your computer and printer.

2 Plug the printer power cord into an AC outlet (3).

Connecting a printer using the USB connector

Connecting peripheral devices

Connecting a printer using the printer connector

To connect a printer using the printer connector, proceed as follows:

1 Plug the printer cable (1) supplied with the printer into the printer connector (2) identified by the

Hardware Guide

symbol.

2 Plug the printer power cord (3) into an AC outlet.

✍ Turn off your computer and the printer, unplug the AC adapter and the power cord before connecting the printer.

Sony PCG-Z1XEP, PCG-Z1XMP, PCG-V505DP, PCG-Z1XSP, PCG-TR2MP Hardware Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Read this first

Notice

ENERGY STAR

Owner's record

Safety Information

General

Audio/video

Connectivity

Regulatory information

Disposing of lithium ion batteries

Disposing of internal memory backup battery

Welcome

Documentation pack

Online documentation

Printed documentation

Further sources

Ergonomic considerations

Using your VAIO computer

Connecting a power source

Using the AC adapter

Using the battery pack

Inserting the battery pack (PCG-Z1, PCG-V505 series)

Inserting the battery pack (PCG-TR series)

Charging the battery pack

Removing the battery pack

Setting up your computer with Sony Notebook Setup

Shutting down your computer safely

Using the keyboard

Combinations and functions with the <Fn> key

Troubleshooting sound

My speakers are not producing sound

Indicators

Using the touchpad

Using the volume buttons and the Magnify button

Using the disc drive

Reading and writing CDs and DVDs*

Playing DVDs

Troubleshooting optical disc drives

I cannot switch from LCD display to TV and vice versa

My disc drive tray does not open

I cannot play a disc

I cannot play a DVD

I cannot play a DVD when using two screens

The reading speed of CD/DVD-RWs is very slow

The disc tray does not eject even when the eject button is pressed

The disc tray ejects even when it has been locked into place

Using PC Cards

Inserting a PC Card

Removing a PC Card

Troubleshooting PC Cards

My PC Card is not working

Using the Memory Stick

Write-protecting a Memory Stick

Inserting a Memory Stick

Removing a Memory Stick

Using the modem

Troubleshooting the modem

My modem does not work or cannot establish a connection

My modem connection is slow

Using the Bluetooth functionality

Bluetooth security

Setting up Wireless Connections with BlueSpace NE

Communicating with another Bluetooth device

Communicating with another Bluetooth device using the connection navigation

Stopping the Bluetooth connection

Troubleshooting Bluetooth

I cannot use the Bluetooth function

The connected device does not appear in the Remote Bluetooth Device List

I cannot find the Bluetooth device with which I want to communicate

The data transfer speed is slow

Using Wireless LAN (WLAN)

Communicating without Access Point (ad-hoc)*

Communicating with an Access Point (infrastructure)

Using the WiFi protected access (WPA)

Wireless LAN channel selection

(a) With an access point ("Infrastructure")
