Welcome
Congratulations on your purchase of this Sony VAIO® computer, and welcome to the VAIO User Guide.
This User Guide provides detailed information on all aspects of using your new VAIO computer, from keyboard functions to
preinstalled software applications.
In the left navigation window, click the topics you want to learn more about, and that information will be displayed in this
main window.
Click here to find the latest updates and supplemental information about your computer.
Click here to view your computer's hardware specifications and software information.
Page 1
Using Your VAIO Computer
This section describes the following aspects of your new computer:
Using the Keyboard
Using the Touchpad
Using the Center Jog Dial Control
Using the Optical Disc Drive
Using PC Cards
Using Memory Stick Media
Using the Multipurpose Bay
Using the Floppy Disk Drive
Using Power Saving Modes
Connecting a Telephone Cable
Connecting to a Local Area Network
Connecting to a Wireless LAN
Page 2
Using the Keyboard
Your computer's keyboard is very similar to that of a typewriter, but the keyboard has additional keys that perform specific
computer-related tasks.
Keyboard
Key Description
Numeric keypad Contains the keys found on a typical calculator. Use the numeric keypad area to type numbers or to
perform mathematical calculations such as addition and subtraction. Note that you must press the Num Lock key to activate
the numeric keypad. (When you do so, the Num Lock light will be on.) Press the Num Lock key again to deactivate it.
Navigation keys The Left/Right/Up/Down arrow keys are devoted to move the cursor on the screen, and also function
as the Home, End, Page Up, and Page Down keys, respectively.
Correction keys The Insert, Back Space, and Delete keys enable you to make corrections in your documents.
Function keys The 12 function keys along the top of the keyboard are used to perform designated tasks. For example, in
many applications, F1 is the Help key. The task associated with each function key may vary from one application to the
next.
Escape key The Esc (Escape) key is used to cancel commands.
Print Screen key The Print Screen key takes an electronic snapshot of the screen and places it in the Windows
®
Clipboard. You can then paste the screen shot into a document and print it.
Operator keys
(Shift, Ctrl, Alt keys) Several keys are always used with at least one other key: Ctrl, Alt, and Shift. When held down with
another key, the Ctrl (Control) and Alt (Alternate) keys offer another way to give commands. For example, in many
applications, instead of choosing the Save command from a menu, you can hold down Ctrl and press S (referred to as
Ctrl+S). The Shift key operates the same way as on a typewriter; it is used to produce capital letters or special symbols
such as @ and $.
Windows key
The key with the Windows logo displays the Windows Start menu; it is the equivalent of clicking the Start
button on the taskbar. See Combinations and functions with the Windows key for more information.
Fn key The Fn key is used in combination with other keys to issue commands. See Combinations and functions with
the Fn key for more information.
Applications key
The Applications key displays a shortcut menu of context-sensitive choices. Pressing this key is the equivalent
Page 3
of clicking the right mouse button.
Page 4
Combinations and functions with the Windows key
Combination Function
+ F1 Displays the VAIO Help and Support Center window.
+ Tab Switches the selected button on the taskbar.
+ D Displays the desktop.
+ E Displays the My Computer window.
+ F Displays the Search window to find a file or folder. This is the equivalent of selecting Search from the Start
menu.
+ Ctrl + F Displays the Search Results: Computers window where you can locate other computers. This is the
equivalent of selecting Search and then Computers from the Start menu.
+ M Minimizes all displayed windows.
Shift + + M Returns all minimized windows to their previous size.
+ R Displays the Run window. This is the equivalent of selecting Run from the Start menu.
Fn + + Insert Displays the Properties window. This is the equivalent of selecting Control Panel and then System
from the Start menu.
Page 5
Indicators
Indicator Function
Power
Light is green when the power to the computer is turned on, flashes amber in Standby mode, and turns off
when the computer is in Hibernate mode or powered off.
Battery
Indicates the status of the battery inserted in the battery bay.
Memory Stick
Indicates that the Memory Stick® slot is in use.
Hard disk
This indicator will light when data is being read from or written to the hard disk. Do not enter Standby mode or
turn off the computer when this indicator is on.
Page 6
Indicator lights
Light On Off
Num Lock
The number keys in the numeric keypad are active. The alphanumeric character keys in the keypad area are
active.
Caps Lock
The letters appear in uppercase as you type. The Shift key lowers the case of typed letters when Caps Lock is on.
Letters appear in lower case as you type (unless you hold down the Shift key).
Scroll Lock
The screen scrolls differently. (Exactly how it scrolls depends on the specific application. It has no effect in many
applications.) Information moves across the display normally.
Page 7
Combinations and functions with the Fn key
If you switch user identities during a computing session, the Fn+F7 and Fn+F8 key functionality (if available on your
computer) will be interrupted. To switch to an external display or monitor, see Selecting the Display Mode for more
information.
Combinations/
Feature Function
Fn+ (F3)
Mute On/Off Toggles the built-in speaker off and on.
Fn+ (F4)
Speaker volume Adjusts the built-in speaker volume.
To increase volume, press Fn+F4, then or .
To decrease volume, press Fn+F4, then or .
Fn+ (F5)
Brightness control Adjusts the brightness of the LCD.
To increase light intensity, press Fn+F5 and then or .
To decrease light intensity, press Fn+F5 and then or .
Fn+ / (F7)
Switch to the external monitor/LCD Toggles through the LCD, external display (connected to the Monitor port) and
both LCD and external display.
Select one display at a time to playback DVDs. Connect the cable before you turn on the computer, otherwise Fn + F7 will
not work.
Fn+ only/
(F8)
Control AV Out Toggles between LCD-only and dual LCD/TV display modes.
Select one display at a time to playback DVDs. Connect the cable before you turn on the computer, otherwise Fn + F8 will
not work. You cannot use the Fn + F8 function to switch between LCD and TV once a DVD is inserted into the optical disc
drive.
Fn+ (F12)
Hibernate Provides for the lowest level of power consumption. When you run this command, the state of the
system and state of the peripheral devices are written to the hard disk and the system power is turned off. To return the
system to its original state, use the power button to turn on power.
Fn+Esc
Page 8
Standby Puts the system into Standby mode, a power management state. To return the system to the active
state, press any key.
You can also carry out these functions using the center Jog Dial Control. Some functions are not available until
Windows® launches.
Page 9
Using the Touchpad
The keyboard contains a cursor-pointing device called a touchpad. You can point to, select, drag, and scroll objects on the
screen using the built-in touchpad.
Touchpad
Action Description
Point Slide one finger on the touchpad to place the pointer on an item or object.
Click Press the left button once.
Double-click Press the left button twice.
Right-click Press the right button once. In many applications, this action displays a shortcut menu of context-sensitive
choices.
Drag Slide one finger while pressing the left button.
Scroll Move your finger along the right edge of the touchpad to scroll vertically. Move your finger along the bottom to
scroll horizontally. (The scroll function is available only with applications that support a touchpad scroll feature.)
The Mouse Properties dialog box lets you customize your mouse and touchpad features, such as touch sensitivity, motion,
and buttons.
To open the Mouse Properties dialog box
1.
Click Start on the Windows® taskbar, and then Control Panel.
2.
Click Printers and Other Hardware, and then Mouse. The Mouse Properties dialog box opens.
Page 10
VAIO Action Setup
VAIO Action Setup manages the settings for your computer's center Jog Dial Control, Memory Stick® media, and i.LINK
®1
interface. An overview of some of the functions controlled by VAIO Action Setup is provided in this section. For more
information on changing the settings using VAIO Action Setup, right-click the Jog Dial Utility icon or in the taskbar and
click Help Topics.
1
i.LINK is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnection. T he i.LINK c onnec tion may vary, depending on the
software applications, operating s ys tem, and c ompatible i.LI NK devices. A ll products with an i.LI N K c onnec tor may not c ommunic ate with eac h other. Refer
to the documentation that came with your compatible i.LIN K devic e for information on operating c onditions and proper c onnec tion. Before c onnecting
compatible i.LI N K P C peripherals to your system, s uch as a C D-RW or hard dis k drive, c onfirm their operating s ys tem c ompatibility and required operating
conditions.
Page 11
Using the Center Jog Dial Control
Your computer is equipped with a center Jog Dial Control located below the left and right buttons. The center Jog Dial
Control enables you to open an application, folder, or document from a predefined list by rotating and pressing the center
Jog Dial Control. In addition, when you press the center Jog Dial Control, you can turn on your computer automatically and
start the selected application or document.
Center Jog Dial Control
The center Jog Dial Control window always appears in the display. It is either in the launcher mode or in the guide mode.
Page 12
Using the center Jog Dial Control
This section explains how to use the center Jog Dial Control. For information on how to change the settings of the center
Jog Dial Control, right-click the Jog Dial Utility icon or in the taskbar and click Help Topics.
Page 13
Launcher mode
The center Jog Dial Control window is in launcher mode until a software application is launched or the Jog Dial Control
window becomes active. When you select an item in the Jog Dial Control window and it is displayed between orange bars,
you can press the center Jog Dial Control to view a submenu of that item.
Using Launcher mode
To use the center Jog Dial Control, click the Jog Dial Control window or the Jog Dial Utility icon in the taskbar. Alternatively,
you can press the center Jog Dial Control while the Jog Dial Control window is active to switch to launcher mode.
Jog Dial Launcher
To select a desired item, proceed as follows:
1.
Rotate the center Jog Dial Control to select the item you want, and then press the center Jog Dial Control. The
Jog Dial Launcher window switches to guide mode and shows the function of the center Jog Dial Control.
Jog Dial Guide
2.
Rotate or press the center Jog Dial Control to use the desired function.
3.
To select another item, repeat steps 1 through 3 above.
Page 14
Guide mode
The Jog Dial Control window is in the guide mode when software is in use and the software window is active. Depending on
the software you are using, you can select items from the displayed list using the center Jog Dial Control. You can switch
between guide mode and launcher mode by pressing the Ctrl key and the center Jog Dial Control.
Using Guide mode
The Jog Dial Control window displays the function of the center Jog Dial Control.
Page 15
Center Jog Dial back button
The center Jog Dial Control includes a back button located to the right of the control. Pressing this button brings you back to
the previous screen.
Page 16
Using the center Jog Dial Control with Sony software
If Sony software that supports the center Jog Dial Control is active, you can use the functions of the center Jog Dial Control
that are allocated to that software. For more information on functions allocated to software, see the software application's
Help.
Page 17
Using the center Jog Dial Control with other software
If the software you are using supports the center Jog Dial Control, you can still use the center Jog Dial Control to scroll the
window or adjust the window size.
Using a Dialog box
When a window such as Screen Properties is active, the Dialog box is displayed in the Jog Dial window. You can select an
item in the window by rotating the center Jog Dial Control. Pressing the center Jog Dial Control is the equivalent of pressing
Enter or Select.
Jog Dial Guide Dialog Box
Page 18
Using the Optical Disc Drive
Your computer comes with an optical disc drive, which is located on the right panel of the computer. See the Specifications
sheet for the particular drive installed on your computer.
Page 19
To insert a disc
1.
Turn on the computer.
When the computer is in Standby or Hibernate mode, you cannot insert a disc. See Controlling Power
Management for more information on Standby and Hibernate modes.
2.
Press the Eject button to open the optical disc drive. The tray slides out.
Ejecting the Tray
Avoid using adhesive labels to identify your discs. Adhesive labels may come off while the disc is in use in your
optical disc drive, and may cause damage to the unit.
3.
Place an optical disc on the tray with the label side facing up. For DVDs that can played on both sides, the side of
the disc facing up is the side that plays.
4.
Press the disc onto the hub until the disc clicks securely into place.
Inserting an Optical Disc
5.
Close the tray by pushing it gently.
Page 20
To eject a disc
When you finish using a disc, wait until the LED indicator turns off, and then press the Eject button to remove the disc.
When the computer is in a power saving mode, you cannot remove an optical disc. See Controlling Power Management for
more information about power saving modes.
If the optical disc does not slide out when you press the Eject button, turn off the computer and insert a thin, pointed
object (such as a paper clip) into the manual eject hole.
Make sure to seat the disc firmly over the hub fingers. If you do not seat the disc firmly, you could damage your
optical disc drive and you may not be able to open the tray.
Manual Eject Hole
Page 21
To play a DVD
To play a DVD, you may use the optical disc drive and the preinstalled WinDVD® application. For more information, see the
Help menu in the WinDVD application.
Before you use the optical disc drive to play a DVD, quit any open applications.
Your optical disc drive can read most DVD-R media. When you are ready to play a DVD, read the suggestions below to
maximize your video viewing experience.
When playing a DVD on battery power, set the power management profile to DVD. You can also set the power
management profile to Automatic Profile Selection if the display is not clear when using other profiles.
Automatic Profile Selection sets the power management profile to DVD whenever a DVD is inserted. See
"Controlling Power Management" for more information.
If you connect your computer to a TV display, you may need to adjust the display resolution. Read the suggestions
below to set the display resolution to the proper dimensions. Also see Selecting the Display Mode for more
information.
If the computer is set to the default display setting, part of the video screen will not appear. To view the entire
screen, adjust the display resolution to 1024 x 768.
Some discs recorded at 20 or 24 bits may produce noise while playing. If you have audio devices
connected, this may cause damage to your hearing and the speakers. Reduce the volume before playing a DVD.
You cannot use the Fn + F8 function to switch between LCD and TV once a DVD is inserted into the optical disc drive.
Do not switch between LCD and the external display while the DVD is playing. This may cause a malfunction, and you
may need to restart the DVD software.
Do not switch the power saving modes while you are playing the DVD.
Change the settings to disable the screen saver and the virus checker.
Do not use memory-resident utility software to speed up disc access. This may cause the computer to malfunction.
Page 22
To play an audio CD
To play an audio CD, make sure the audio function is turned on. To do this, complete the following procedure.
1.
Click Start, and click Control Panel, and Performance and Maintenance, and System. The System Properties
window appears.
2.
Select the Hardware tab, and click Device Manager. The Device Manager window appears.
3.
Double-click DVD/CD-ROM drives to open a list of the optical disc drive devices installed on your computer.
4.
Right-click the particular optical disc drive device installed on your computer, and select Properties from the
drop-down list. A properties window appears.
5.
Select the Properties tab, and check the "Enable digital CD audio for this CD-ROM device" box, if it is not already
checked.
6.
Click OK.
Page 23
Notes on CD and DVD discs
Do not drop or bend the disc.
Do not touch the surface of the disc. Fingerprints and dust on the surface of a disc may cause reading errors. Proper
care of the disc is essential to maintain its reliability. Do not use solvents such as benzine, thinner, commercially
available cleaners or anti-static spray, as they may cause damage to the disc.
For normal cleaning, hold the disc by its edge and use a soft cloth to wipe the surface from the center out.
If the disc is badly soiled, moisten a soft cloth with water, wring it out well, and use it to wipe the surface of the disc
from the center out. Wipe off any remaining moisture with a dry, soft cloth.
Page 24
To write data to a CD-RW or CD-R disc1
You can use Sony SonicStage and Microsoft® Windows® XP to write data to a CD-R or CD-RW disc. To create a CD-R disc
that is readable in a CD-ROM drive, make sure that you finish the writing process before ejecting the disc. For more
information, see the instructions included with Windows® XP.
Do not strike or shake the computer while writing data to a disc.
Always use the AC adapter as the power source for your computer if you are writing data to a CD-RW or CD-R disc.
Using battery power may result in data transfer failure.
To avoid writing errors, remove the compact woofer or do not play music while writing data to a CD-RW or CD-R disc.
Notes on writing data to a CD-RW or CD-R disc
For optimal writing speed, deactivate the screen saver and exit anti-virus software before writing data to a disc.
For best results, use CD-Rs that are compatible with 16x speed.
Your computer does not support 1x or 2x writing speed.
Memory-resident disc utilities may cause unstable operation or data loss. Deactivate these utilities before writing
data to a disc.
If your computer has preinstalled Microsoft® Office applications, such as Excel, Word, and Outlook, turn off the
FindFast application.
1
For computer models equipped with a C D-RW/DV D C ombo Drive.
Page 25
Using PC Cards
Do not strike or shake the computer while writing data to a disc.
Always use the AC adapter as the power source for your computer if you are writing data to a CD-RW or CD-R disc.
Using battery power may result in data transfer failure.
Your computer includes two PC Card slots. PC Cards enable you to connect portable external devices such as another hard
disk drive, or a PC Network Interface Card (NIC) to connect to a network.
The PC Card slots can accommodate two Type I/II PC Cards, or one Type III PC Card. These slots are compatible with
CardBus. Use the lower slot for Type III PC Cards. You do not need to shut down your computer before inserting or
removing a PC Card.
Page 26
To insert a PC Card
1.
Insert the PC Card into the PC Card slot. Make sure the front label of the PC Card is facing up.
Inserting a PC Card
2.
Push the PC Card gently into the slot. The PC Card is automatically detected by your system. The Unplug or
Eject Hardware icon appears in the taskbar.
Do not force a PC Card into the slot as this may damage the connector pins.
Do not carry your computer while touching the head of a PC Card, as pressure or shock may damage the connector
pins.
Page 27
To remove a PC Card
If your computer is turned on, follow these instructions. If your computer is turned off, skip to step number 5.
1.
Close all applications that use the PC Card; otherwise, data may be lost.
2.
Double-click the green arrow icon in the taskbar.
3.
Select an option in the Hardware devices box, and click Stop. The Stop a Hardware device window opens.
4.
Click OK to confirm your selection, and then Close.
5.
Press the PC Card Release button. The Release button pops out.
6.
Press the PC Card Release button a second time (in some cases). Remove the card.
Notes on using PC Cards
For some PC Cards, if you alternate between normal power operation and the Standby or Hibernate power
management modes while the card is inserted, you may find that a device connected to your system is not
recognized. Restart your system to correct the problem.
Some PC Cards may require that you disable idle devices when using the PC Card. You can use Sony Notebook
Setup to disable devices. See Displaying the Sony Notebook Setup Screen for more information.
Be sure to use the most recent software driver provided by the PC Card manufacturer.
If an exclamation mark (!) appears on the Device Manager tab in the System Properties dialog box, remove the
software driver and then reinstall it.
You may not be able to use some PC Cards or some functions of the PC Card with this computer. If you have
difficulty inserting a card, check that you are orienting the card correctly. See the manual that came with your PC
Card for more information on its use.
Page 28
Using Memory Stick Media
This compact, portable, and versatile recording medium has a data capacity exceeding that of a floppy disk. The medium is
specially designed for exchanging and sharing digital data with compatible products. Because it is removable, the media can
be used for external data storage.
Page 29
Types of Memory Stick media
The following two types of Memory Stick media can be used with your computer:
MagicGate 1 Memory Stick media (hereafter called MG Memory Stick media), which is provided with copyright
protection
Memory Stick2 media, which does not have the same copyright protection as MagicGate Memory Stick media
Some music files with secure copyright protection may be stored on MG Memory Stick media but not on regular Memory Stick
media.You can also use MagicGate media-compatible devices to record and playback music when they are connected to
your computer.
You can store mixed data on the Memory Stick media. For example, you can copy an ordinary file onto a MG Memory Stick
media that already contains music files.
What is MagicGate Memory Stick media?
MagicGate Memory Stick media provides copyright protection that consists of authentication and encryption technology.
Authentication technology ensures that protected content is only transferred between compliant devices and media.
Protected content is recorded and transferred in an encrypted format to prevent unauthorized duplication or playback.
MG Memory Stick media has the MG mark .
To insert Memory Stick media
1.
Insert the Memory Stick media with the arrow facing up and toward the Memory Stick media slot.
Inserting the media in the wrong direction may damage the connector pins.
2.
Carefully slide the Memory Stick media into the slot until it clicks in place.
Inserting Memory Stick Media
To view the contents of Memory Stick media
1.
Click Start in the Windows taskbar and then click My Computer
2.
Double-click Sony Memory Stick under the Devices with Removable Storage box. The Sony Memory Stick window
opens.
To remove Memory Stick media
1.
Make sure the Memory Stick media indicator is off.
2.
Push the Memory Stick media in toward the computer.
3.
When the Memory Stick media ejects, pull it out.
Page 30
Be careful when removing the Memory Stick media, as it may eject completely from the slot.
1
M agic Gate Memory Stick and are trademarks of Sony C orporation.
2
M emory Stic k and are trademarks of Sony C orporation.
Page 31
Write-protecting Memory Stick media
Memory Stick media is designed with a write-protect tab to protect valuable data from accidental erasure or overwriting.
Move the tab to the right or left to set or release write-protection.
Write-protect off Data can be saved on the Memory Stick media.
Write-protect on Data can be read from but not saved on the Memory Stick media.
Using the Write-protect Tab
Page 32
Formatting Memory Stick media
Memory Stick media is formatted for immediate use when you purchase it. If you need to reformat Memory Stick media,
follow the procedures below.
Reformatting erases all current data that is stored on Memory Stick media. Before you reformat, confirm that
the media does not contain files you want to keep.
1.
Insert the Memory Stick media into the computer. See To insert Memory Stick media for more information.
2.
Click Start in the Windows taskbar, and click My Computer.
3.
Under Devices with Removable Storage, right-click Sony Memory Stick - MG, and select Format. The Format Sony
Memory Stick - MG dialog box appears.
4.
Select the appropriate options, and click Start.
Page 33
Notes on using Memory Stick media
When the write-protect tab of the Memory Stick media is set to LOCK, data cannot be recorded or erased.
Before using Memory Stick media, back up important data.
Wait a minimum of 10 seconds after the Memory Stick media finishes reading or writing data before removing the
media.
If the media is removed prematurely, a blue screen with an error message appears, prompting you to continue or
exit. Reinsert the media into the slot and press Enter to continue. This enables the media to finish reading or writing
data.
You can view video clips that you have recorded with Memory Stick media- compatible video camera recorders.
The media slot can accommodate one Memory Stick media at a time.
You may copy images from a digital video camera using Memory Stick media.
Only MagicGate Memory Stick media can be used with copyright protected data such as music.
Copyright protected music cannot be checked-out to any Memory Stick media other than MG Memory Stick media.
Recorded music is limited to private use only. Using recorded music for any other purpose requires permission of the
copyright holders.
Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources.
Formatting Memory Stick media erases all data (including music data) previously saved to it. Before you format
Memory Stick media, confirm that the media does not contain files you want to keep.
Do not use the media in locations that are subject to static electricity or electrical noise.
Do not touch the media connector with your finger or metallic objects.
Do not attach labels other than the supplied label to a media.
Do not bend, drop, or apply strong shock to the media.
Do not disassemble or modify the media.
Do not allow the media to get wet.
Do not use or store the media in a location that is subject to:
Extremely high temperatures, such as in a car parked in the sun
Direct sunlight
High humidity or places with corrosive substances
To prolong the life of the media, use the supplied storage case. See the instructions that came with your media for
more information on its use.
Page 34
Using the Multipurpose Bay
You may install a variety of devices into the multipurpose bay to expand your computer's functionality. The multipurpose bay
supports the removable weight saver, floppy disk drive, compact woofer, or the internal numeric keypad (Ten-Key Bay unit).
You may install only one device at a time.
You may install a device into and remove a device from the multipurpose bay while the computer is powered
completely on or turned off. Installing and removing a device while the computer is in a power saving mode is not
supported.
Page 35
To install a device while the computer is on or off
Before you install a compact woofer, prop up the rear tilt stands on the bottom of the computer to maximize woofer
performance.
1.
Remove any device that is already installed in the bay. See To remove a device while the computer is off or To
remove a device while the computer is on for more information.
2.
Slide the device, such as the weight saver, into the multipurpose bay until it clicks into place. The computer
automatically detects the installed device.
Inserting a Device
Page 36
To remove a device while the computer is off
1.
Slide and hold the multipurpose bay Release switch in the release position while you gently pull the device from
the bay.
Multipurpose Bay Release Switch
If you do not plan to install another device into the multipurpose bay, insert the supplied weigh saver to protect
the bay.
Page 37
To remove a device while the computer is on
Before disconnecting the device, close any active applications to help prevent data loss.
1.
Double-click the Safely Remove Hardware icon on the taskbar. The Safely Remove Hardware window
appears.
2.
In the Hardware devices box, click the device you want to remove, and click Stop. The Stop a Hardware device
window appears.
3.
Verify that the correct device is selected, and click OK. A message appears stating it is now safe to remove the
device from the computer.
4.
Slide and hold the multipurpose bay Release switch in the release position while you gently pull the device from
the bay.
If you do not plan to install another device into the multipurpose bay, insert the supplied weigh saver to protect the
bay.
Page 38
Notes on using a device in the multipurpose bay
Do not place the compact woofer near any magnetic recording media, such as a hard disk, floppy disk, or mini
disk. The woofer's magnetic field may damage the data stored on this type of media.
Do not use the external speakers and the compact woofer at the same time. Using both devices at the same time
does not enhance sound quality.
Page 39
Using the Floppy Disk Drive
Whether you installed the supplied floppy disk drive into the multipurpose bay or connected an external floppy disk drive to
the computer, you will find that both floppy disk drives are similar and easy to use.
Page 40
To insert a floppy disk into the floppy disk drive
1.
Hold the floppy disk with the label facing up.
2.
Gently push the floppy disk into the drive until it clicks into place.
Inserting a Floppy Disk
Page 41
To remove a floppy disk from the floppy disk drive
1.
Close all applications that were opened from the disk and wait for the LED indicator to turn off.
Remov ing a Floppy Disk
2.
Push the Eject button, and remove the disk.
Do not push the Eject button when the LED indicator is turned on; otherwise, you may lose data.
Page 42
Notes on handling floppy disks
Do not open the shutter manually and touch the surface of the floppy disk.
Keep floppy disks away from magnets.
Keep floppy disk away from direct sunlight and other heat sources.
Page 43
Using Power Saving Modes
When you use a battery as the source of power for your computer, you can take advantage of power management settings
to conserve battery life. In addition to the normal operating mode, which allows you to turn off specific devices, your
computer has two distinct power saving modes: Standby and Hibernate. When using battery power, be aware that the
computer automatically enters Hibernate mode when the remaining battery charge drops below 5 percent, regardless of
the power management setting you select.
If the battery level falls below 10 percent, you should either attach the AC adapter to recharge the battery or shut
down your computer and insert a fully charged battery.
Page 44
Normal mode
Normal mode is the normal state of your computer when it is in use. The power indicator displays green when your
computer is in this mode. To save power, you can turn off a specific device such as the LCD or the hard disk drive.
Page 45
Standby mode
In Standby Mode the computer saves the current state of the system in RAM and switches off power to the CPU. The amber
power indicator flashes in this mode.
To activate Standby mode
Press the key combination Fn + Esc.
To return to Normal mode
Press any key to return to Normal mode.
Page 46
Hibernate mode
In the Hibernate mode, the state of the system is saved on the hard disk drive and power is turned off. The power indicator
is off in this mode.
To activate Hibernate mode
1.
Press the key combination Fn + F12, or press the power button and release it immediately. The computer enters
Hibernate mode.
Do not move the computer until its power indicator turns off.
2.
Press the power button to return to normal mode.
Page 47
Notes on power saving modes
When returning from Hibernate mode, the system status stored on the hard disk is erased and the computer starts
normally if you press the power button and hold it for more than four (4) seconds.
Standby uses more power than Hibernate.
Standby requires less time than Hibernate to return to normal mode.
Page 48
Connecting a Telephone Cable
You need to connect a telephone cable to take advantage of online services and the Internet.
In order to register your Sony VAIO computer, register your software online, and use Sony Customer Support, you
must connect to a telephone cable.
1.
Plug one end of the telephone cable into the Modem jack on the computer.
Connecting a Telephone Cable
2.
Plug the other end of the telephone cable into the wall jack.
Your computer does not work with party lines, cannot be connected to a coin-operated telephone, and may not
work with multiple telephone lines or a private branch exchange (PBX). Some of these connections may result in excess
electrical current and could cause a malfunction in the internal modem.
If you connect a telephone cable coming through a splitter, the modem or connected device may not work properly.
Page 49
Connecting to a Local Area Network
You can connect your computer to 10BASE-T and 100BASE-TX-type Local Area Networks (LANs). For the detailed settings
and devices needed to connect to the network, ask your network administrator.
Connecting to LAN
Warning: Only connect 10BASE-T and 100BASE-TX cables to the Ethernet port. Do not connect any other
type of network cable or phone cable. Connecting cables other than those listed above may result in an electric current
overload and could cause a malfunction, excessive heat, or fire in the port. To connect the unit to the network, contact
your network administrator.
Page 50
Setting up your Ethernet connection
To connect to the network
1.
Click Start on the Windows® taskbar, and select My Computer.
2.
In the Other Places box on the left, click My Network Places.
3.
In the Network Tasks box, click Add a network place or click Set up a home or small office network, depending on
your configuration. Depending on your choice, either the Add Network Place Wizard or Network Setup Wizard
window appears.
4.
Follow the on-screen instructions.
Page 51
Connecting to a Wireless LAN1
Your computer may come with a built-in mini PCI card that allows for wireless connections. With Sony's Wireless Local Area
Network (LAN) functionality, all compatible digital devices can communicate freely without cable connections. A Wireless LAN
is a network in which a mobile user can connect to a LAN through a wireless (radio) connection. You can opt to purchase a
Wireless LAN Access Point to set up a LAN.
Comm unicating v ia Wireless LAN
1
Wireless LA N func tionality is available on selected models only.
Page 52
Turning On Wireless LAN
To enable Wireless LAN functionality, first locate the Wireless LAN switch on the top right corner of the computer. Move the
switch to the ON position. The Wireless LAN indicator lights up.
Connecting to a Wireless LAN
Page 53
The Wireless LAN Access Point
The Wireless LAN Access Point is designed for building a Wireless LAN environment. You can easily build a wireless LAN
environment by plugging the access point into an AC power outlet and using a card that allows for wireless connections
with the provided software. Because a wireless LAN configuration requires no wiring, you can operate multiple computers
more freely than ever before.
You can also connect an access point to a telephone line, Integrated Services Digital Network (ISDN) router, cable modem,
or Digital Subscriber Line (xDSL) modem to share access to the Internet among multiple computers.
Comm unicating v ia Wireless LAN Access Point
For information on available Sony products, go to: http://www.sonystyle.com/vaio.
Page 54
Communicating with an Access Point (infrastructure)
An extended network infrastructure is one that extends an existing wired local network to wireless devices by providing an
access point. The access point bridges the wireless and wired LAN and acts as a central controller for the Wireless LAN. The
access point coordinates transmission and reception from multiple wireless devices within a specific range.
If you create a network using a network (or encryption) key, you will need that key to access the network.
To set up and connect with an access point
1.
Locate the Wireless LAN switch and move the switch to the ON position.
2.
Click the Wireless Network Connection icon on the Windows® taskbar. The Connect to a Wireless Network
window appears.
Connecting to a Wireless LAN
3.
Select a network from the Available Networks list box.
4.
Type a key in the Network key box. This is necessary if the network was created with an encryption key;
otherwise, you cannot connect to the network.
5.
Click Connect.
The network key is data used to protect signals passing through a wireless LAN that conforms with IEEE 802.11b
standard. It is also called an "encryption key." Wireless LAN communication can only occur between an access point and
computer that are using the same key information.
When you enter the network key and the connection is made, the access point is registered, and you do not have to enter
the network key when you connect thereafter.
Page 55
Communicating without an access point (ad-hoc)
An ad-hoc network is one in which a local network is created only by the wireless devices themselves, with no other central
controller or access point. Each device communicates directly with other devices in the network. You can set up an ad-hoc
network easily at home, either with a network key for added security or without a key.
If you create a network using a network (or encryption) key, you will need that key to access the network.
To set up and connect without a network key
1.
Locate the Wireless LAN switch and move the switch to the ON position.
2.
Click the Wireless Network Connection icon on the Windows® taskbar. The Connect to a Wireless Network
window appears.
3.
Click Advanced. The Wireless Network Connection Properties window appears.
Setting Wireless Network Connection Properties
4.
Make sure the Wireless Networks tab is selected, and click Add. The Wireless Network Properties window
appears.
5.
Type in a Network name (SSID), and check the "This is a computer-to-computer (ad hoc) network; wireless
access points are not used." box.
6.
Click OK.
7.
Select a network from the Preferred networks list, and click OK.
To set up and connect with a network key
1.
Follow steps 1 to 4 of To set up and connect without a network key.
2.
Type in a Network name (SSID), and check the "Data encryption (WEP enabled)" box, and the Network
Authentication (Shared mode)" box.
3.
Deselect the "This key is provided for me automatically" box.
4.
Type in a Network key name. You will need this key to access the network.
Page 56
5.
Click OK.
6.
Click Advanced. The Advanced dialog box appears.
7.
Select "Computer-to-computer (ad hoc) networks only.", and click Close.
8.
Select a network from the Preferred networks list, and click OK.
To connect to an existing network
1.
Locate the Wireless LAN switch, and move the switch to the ON position.
2.
Click the Wireless Network Connection icon on the Windows® taskbar. The Connect to a Wireless Network
window appears.
3.
Click Advanced. The Wireless Network Connection Properties window appears.
4.
Select the Wireless Networks tab, if it is not already selected, and select a network from the Preferred networks
list.
5.
Click OK.
Page 57
Checking your connection status
To confirm your connection status with an access point
1.
Right-click the Wireless Network Connection icon on the Windows taskbar.
2.
Click Status in the pop-up menu. The Wireless Network Connection Status window appears.
Page 58
Turning Off Wireless LAN
To turn off Wireless LAN functionality
Turning off Wireless LAN functionality while accessing remote documents, files, or resources may result in data
loss.
1.
Close all files that you are accessing through the network connection.
2.
Locate the Wireless LAN switch, and move the switch to the OFF position. The Wireless LAN indicator switches
off. It may take a few moments for the computer to disconnect.
Page 59
Notes on using Wireless LAN
Sony Wireless LAN devices support the IEEE 802.11b standard. Devices connecting to a Wireless LAN using the IEEE
802.11a standard cannot connect to devices using the IEEE 802.11b standard.
Wireless LAN communication occurs on divided frequency bands known as channels. Third-party Wireless LAN Access
Point channels may be preset to different channels from Sony devices.
If using a Wireless LAN Access Point, refer to connectivity information contained in those instructions.
Page 60
Connecting Peripheral Devices
You can add functionality to your notebook by connecting a variety of peripherals, as discussed in the following sections:
Connecting a USB Device
Connecting a USB Printer
Connecting a Parallel Port Printer
Connecting an Audio Device
Connecting an Audio-Video Device
Connecting an i.LINK Audio-Video Device
Connecting an External Display
Connecting with another VAIO computer
Connecting External Speakers
Connecting an External Microphone
Expanding Your Computer Capabilities
Page 61
Connecting a USB Device
You can connect a universal serial bus (USB) device, such as a external mouse, keyboard, speaker, and microphone to your
computer. However, make sure the USB device you want to connect is compatible with the Windows® operating system
installed on your computer.
Page 62
To connect a USB device
1.
Locate a USB port on the rear panel of your computer.
2.
Plug one end of the USB cable (not supplied) into one of these ports, and plug the opposite end of the cable into
the USB device, if it is not already connected.
You can use a Sony USB mouse (not supplied) with this computer. The USB mouse software driver is preinstalled,
however, the first time you connect a mouse, on-screen installation instructions may appear. Press Enter to complete the
on-screen instructions.
Connecting a USB Device to a USB Port
See the manual that came with your USB device for more information on its installation and use.
Page 63
Connecting a USB Printer
You can connect a universal serial bus (USB) printer to your computer. However, make sure the USB device you want to
connect is compatible with the Windows® operating system installed on your computer.
Page 64
To connect a USB printer
1.
Locate a USB port on the rear panel of the computer.
2.
Plug one end of the USB printer cable (not supplied) into one of these ports, and plug the opposite end of the
cable into the USB port on your printer.
3.
Make sure your computer's printer settings are properly set. See Displaying the Sony Notebook Setup Screen for
more information.
To use a printer, you may need to install the driver software that came with your printer.
Connecting a USB Printer
See the manual that came with your printer for more information on its installation and use.
Page 65
Connecting a Parallel Port Printer
You can connect a parallel port printer to your computer. However, make sure the parallel port printer you want to connect
is compatible with the Windows® operating system installed on your computer.
Page 66
To connect to a parallel port printer
1.
Locate the Printer port on the rear panel of the computer.
2.
Plug one end of the printer cable (not supplied) into this port, and plug the opposite end of the cable into the
parallel port on your printer.
3.
Make sure your computer's printer settings are properly set. See Displaying the Sony Notebook Setup Screen for
more information.
To use a printer, you may need to install the driver software that came with your printer.
Connecting a Parallel Port Printer
See the manual that came with your printer for more information on its installation and use.
If your printer stops functioning after resuming from a power saving mode, see Troubleshooting the Printer for more
information.
Page 67
Connecting an Audio Device
You can connect an audio device to your computer using mini-plug cables shorter than 2 meters with no resistance.
Page 68
To connect an audio device
1.
Plug one end of an audio cable (not supplied) into the Headphone jack on the computer.
2.
Plug the opposite end of the audio cable into an audio output device, such as a CD player, active speaker, or
amplifier.
Connecting an Audio Device
Page 69
Connecting an Audio-Video Device
You can connect an audio-video (AV) device, such as a TV or a VCR, to your computer.
Page 70
To connect an AV device
1.
Locate the AV Out jack on the left panel of the computer.
2.
Plug one end of an audio-video cable (not supplied) into this jack, and plug the opposite end of the cable into
the audio-video device.
3.
Make sure you switch the TV input channel to external input and set up the TV configuration system. See To
change the display for more information.
Connecting a TV to the Computer
See the manual that came with your peripheral device for more information on its installation and use.
Page 71
To change the display
If you insert a DVD in your optical disc drive to watch on your TV, the Fn+F8 key combination might not activate the function
to toggle between your LCD and TV. Follow these steps.
1.
Connect the TV to the computer.
2.
Restart the computer and wait until it finishes rebooting.
3.
Press the Fn+F8 key combination to toggle between the LCD and TV display. The DVD will play on only one
display at a time, so select either LCD or TV as the primary display. See Selecting the Display Mode for more
information.
4.
Re-insert your DVD to launch your DVD software.
A part of the image cannot be displayed on your TV display if the resolution of your notebook is more than 1024 x 768
dots.
Page 72
Connecting an i.LINK Audio-Video Device
You can connect an i.LINK®1 enabled digital video camera recorder to the i.LINK® S400 (IEEE 1394) port on your computer.
1
i.LINK is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnector. T he i.LINK c onnec tion may vary, depending on the
software application, operating system, and c ompatible i.LI N K devices. A ll products with an i.LI N K c onnec tion may not c ommunic ate with eac h other. Refer
to the documentation that came with your compatible i.LIN K devic e for more information on operating c onditions and proper c onnec tion. Before c onnecting
compatible i.LI N K P C peripherals to your system, s uch as a C D-RW or hard dis k drive, c onfirm their operating s ys tem c ompatibility and required operating
conditions.
Page 73
To connect a digital video camera recorder
1.
Plug one end of the i.LINK® cable (not supplied) into the i.LINK port on the left panel of the computer.
2.
Plug the opposite end of the i.LINK cable into the DV IN/OUT port on the digital video camera recorder.
Connecting Digital Video Camera Recorder to i.LINK Port1
Page 74
Notes on connecting an i.LINK device
Only the Sony digital video camera port labeled DV IN/OUT or i.LINK are i.LINK-compatible.
Do not connect more than one digital video camera at a time. The software supplied with your computer will not
recognize multiple cameras.
The i.LINK port does not supply power to external devices. If the external device requires power from the i.LINK
port, you cannot use the device with the computer.
The computer supports transfer rates up to 400 Mbps; however, the actual transfer rate is the lowest transfer rate
of the external device.
The i.LINK features available may vary depending on the software applications you use. See the documentation that
accompanied your software for more information.
See the manual that came with your digital video camera recorder for more information on its installation and use.
Page 75
Connecting an External Display
You can connect any of the following external displays to your computer.
Computer display (monitor)
Multimedia computer display
Projector
Page 76
To connect a computer display
1.
Turn off the computer before you connect the computer display.
2.
Locate the VGA (Monitor) port.
3.
Plug the display cable (not supplied) into the VGA (Monitor) port.
4.
Verify that the power cord is plugged into the computer display and an AC outlet.
5.
Turn on all external devices before turning on the computer.
Connecting an External Computer Display
Page 77
To connect a multimedia computer display
1.
Turn off the computer before you connect the multimedia computer display.
2.
Locate the AV Out jack on the left panel of the computer.
3.
Plug one end of the display cable (not supplied) into the AV Out jack, and plug the opposite end of the display
cable into the multimedia computer display.
4.
Verify that the power cord is plugged into the multimedia computer display and an AC outlet.
5.
Turn on all external devices before you turn on the computer.
Connecting a Multimedia Com puter Display
See the manual that came with your multimedia computer display for more information on its installation and use.
Page 78
To connect a projector
1.
Turn off the computer before you connect the projector.
2.
Locate the VGA (Monitor) port and the Headphone jack on the computer.
3.
Plug one end of the display cable (not supplied) into the VGA port, and plug the opposite end into the
appropriate port on the projector.
4.
Plug one end of the audio cable (not supplied) into the Headphone jack, and plug the opposite end into the
appropriate port on the projector.
5.
Verify that the power cord is plugged into the projector and an AC outlet.
6.
Turn on all external devices before you turn on the computer.
Connecting a Projector
See the manual that came with your projector for more information on its installation and use.
Page 79
Changing the display when connecting an external computer display or projector
When you connect an external display to the VGA (Monitor) port, you can toggle the output between the Liquid Crystal
Display (LCD), the external monitor, or both devices. Press the Fn+F7 key combination to select a display. See Selecting the
Display Mode for more information.
Connect the external display to the computer before you turn it on, otherwise the Fn+F7 key combination will not
work.
Page 80
Connecting with another VAIO computer
The preinstalled Microsoft® Windows® XP operating system enables you to use a compatible i.LINK®1 cable (not supplied) to
connect your VAIO computer to another compatible computer. You can use one computer to edit, copy, or delete files on the
other computer. You can also print from a printer attached to either computer.
Connecting with an i.LINK Cable
1
i.LINK is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnection. T he i.LINK c onnec tion may vary, depending on the
software applications, operating s ys tem, and c ompatible i.LI NK devices. A ll products with an i.LI N K c onnec tor may not c ommunic ate with eac h other. Refer
to the documentation that came with your compatible i.LIN K devic e for information on operating c onditions and proper c onnec tion. Before c onnecting
compatible i.LI N K P C peripherals to your system, s uch as a C D-RW or hard dis k drive, c onfirm their operating s ys tem c ompatibility and required operating
conditions.
Page 81
To connect two VAIO computers
1.
Right-click My Computer, and select Properties.
2.
Select the Computer Name tab, and type in a unique name for the computer. You will use this unique name to
differentiate the two computers once they are networked together.
3.
Click Apply, and then click OK.
4.
Repeat steps 1 to 3 on the second computer.
5.
Reboot both computers to install these settings.
6.
Connect one end of the i.LINK cable to the i.LINK port on each computer.
To connect VAIO computers that do not have the latest Windows® operating system, Smart Connect software may be
necessary. Consult the Sony Web site for support options (http://www.sony.com/pcsupport).
Page 82
Connecting External Speakers
You can enhance the sound quality of your computer by connecting external speakers (not supplied).
Do not place floppy disks on the speakers. The speakers' magnetic field may damage the data on the floppy
disks.
Page 83
To connect external speakers
1.
Make sure that your speakers are designed for computer use.
2.
Turn down the volume of the speakers.
3.
Locate the Headphone jack on the left panel of the computer.
4.
Plug one end of the speaker cable (not supplied) into the Headphone jack.
Connecting External Speakers to the Headphone Jack
See the manual that came with your speakers for more information on its installation and use.
Page 84
Notes on connecting external speakers
Do not connect external speakers to the AV Out jack. Connecting speakers to this jack will not damage the
speakers, but only one speaker will function.
Do not use the external speakers and the compact woofer at the same time. Using both devices at the same time
does not enhance sound quality.
Page 85
Connecting an External Microphone
You can enhance the quality of sound input by using an external microphone (not supplied).
Page 86
To connect an external microphone
1.
Make sure that your microphone is designed for computer use.
2.
Locate the Microphone jack on the left panel of the computer. A protruding dot above the Microphone jack
distinguishes this jack from the Headphone jack.
3.
Plug one end of the microphone cable (not supplied) into the Microphone jack.
Connecting External Microphone to the Microphone Jack
See the manual that came with your microphone for more information on its installation and use.
Page 87
To record from a microphone or audio device
You can record messages, memos, or other recordings in analog by connecting a microphone or other audio device to the
Microphone jack of your computer and switching the jack's functionality. The Microphone jack is for MIC IN (monaural).
1.
Double-click the Volume icon on the taskbar. The Volume Control window appears.
2.
From the Options menu, click Properties. The Properties window appears.
3.
In the Adjust volume for box, click the Recording option button to select it, and then click OK. The Recording
Control window appears.
4.
If it is not already turned on, click the Select check box at the bottom of the Microphone column. Close the
Recording Control window.
5.
Click Start on the taskbar, and select All Programs, Accessories, Entertainment, and then Sound Recorder. The
Sound - Sound Recorder window appears.
You are ready to begin recording. For help using Sound Recorder, click Help in the Sound Recorder window.
Page 88
Adjusting the volume
You can adjust the volume for playing or recording, but you can only adjust the recording volume in the Recording Control
window. If you adjust the volume, the adjustment is only effective for playing sound. It does not adjust the volume for
recording sound.
To adjust the volume when playing
1.
Double-click Volume icon in the taskbar. The Volume Control window appears.
2.
In the Volume Control column, move the slider up for increased volume and down for decreased volume.
Sound device Function
Volume Control Adjusts the sound level from the speakers or headphones.
Wave Adjusts the wavfile sound or the system sound of Windows.
SW Synth Adjusts the internal or external synthesizer volume.
CD Audio Adjusts the volume of the CD in the optical disc drive.
Microphone Adjusts the internal or external microphone volume.
Telephony Adjusts the modem or telephone line volume.
PC Beep Adjusts the beep sound when inserting or removing the PC Card and other devices.
Line Adjusts the sensitivity of volume input.
Page 89
Expanding Your Computer Capabilities
You can connect the following peripheral devices to your computer to expand its capabilities and enhance its versatility to
meet your needs:
A Personal Digital Assistant (PDA)
A Wireless LAN Access Point
A Wireless LAN PC Card
Page 90
Personal Digital Assistant
A handheld PDA is the quintessential personal planner and entertainment center that fits in your pocket. With a PDA, you
can easily perform the following functions:
Enter your schedule details in the calendar and view them by the day, week, or month, and even set an alarm to
remind you of important events.
Keep your contact names, addresses, phone numbers, and other details in the address book and find them when
you need them.
Add tasks to the To Do List, prioritize them, and assign them due dates.
Synchronize your data with the software on your computer to back up your data.
Track expenses when you are out of the office and transfer the data to your notebook.
Exchange data with your computer.
Page 91
Wireless LAN Access Point
The Wireless LAN Access Point is designed for building a wireless Local Area Network (LAN) environment. You can easily
build a wireless LAN environment by plugging the access point into an AC power outlet and using a card that allows for
wireless connections with the provided software. Because a wireless LAN configuration requires no wiring, you can operate
multiple computers more freely than ever before.
You can also connect your access point to a telephone line, Integrated Services Digital Network (ISDN) router, cable
modem, or Digital Subscriber Line (xDSL) modem to share access to the Internet among multiple computers.
Page 92
Wireless LAN PC Card
You can purchase an external Wireless LAN PC Card separately, but your computer (depending on the model you
purchased) may already come with a built-in mini PCI card that allows for wireless connections. The Wireless LAN PC Card is
designed for a wireless LAN environment. You can use the Wireless LAN PC Card with or without the access point. With the
access point, you can build a wireless LAN between computers that are equipped with the Wireless LAN PC Card and gain
access to the Internet. Without the access point, you can achieve direct communication (Peer-to-Peer mode) between
computers.
For more information on Sony Wireless LAN, go to http://www.sonystyle.com/vaio.
Page 93
Customizing Your VAIO Computer
The following sections briefly describe how to change your notebook's default settings.
Displaying the Sony Notebook Setup Screen
Controlling Power Management
Displaying Battery Information
Selecting the Display Mode
Using the Multilingual User Interface Language Option
Page 94
Displaying the Sony Notebook Setup Screen
To display the Sony Notebook Setup screen:
1.
Click Start on the Windows® taskbar, and then Control Panel.
2.
Click Performance and Maintenance, and then Sony Notebook Setup.
Sony Notebook Setup Screen
3.
Select the tab for the item you want to change. See Sony Notebook Setup tabs for more information.
4.
After you finish making your changes, click OK.
Page 95
Displaying the Sony Notebook Setup Screen
To display the Sony Notebook Setup screen:
1.
Click Start on the Windows® taskbar, and then Control Panel.
2.
Click Performance and Maintenance, and then Sony Notebook Setup.
Sony Notebook Setup Screen
3.
Select the tab for the item you want to change. See Sony Notebook Setup tabs for more information.
4.
After you finish making your changes, click OK.
Page 96
Sony Notebook Setup tabs
Tab Description
About This Computer Display system information, including memory capacity, serial number, and BIOS version.
Printer Select printer port mode settings.
Initial Setting Change the volume of the sounds that play while the operating system is loading. Select the order of
drives and devices from which you want to load the operating system. You can specify the hard drive as well as other drives
inserted into your computer.
Touchpad When you connect an optional mouse to your notebook, you can make your touchpad inactive. You can
also customize the settings of your mouse using the mouse utility.
Power On Password Set the password to secure your computer.
Enable Ports Enable or disable ports. Disabling ports releases resources to the system. To change the serial settings,
click Advanced on the Basic/Advanced tab.
Basic/Advanced Switch between Advanced mode (additional screens with advanced settings) and Basic mode of display.
For more information about each option, click Help on the Sony Notebook Setup screen to display the Help file.
Page 97
Controlling Power Management
The PowerPanel utility allows you to control the power management of your notebook and provides key information about
system activity and battery life. The following sections briefly describe how to conserve your computer's battery power. You
can also refer to PowerPanel Help for more detailed information. To activate a profile or command, see Displaying Battery
Information for more information.
Page 98
Viewing the Power Management status icons
The Power Management status icons are displayed in the taskbar at the lower-right corner of your screen. Move the pointer
over the Battery icon to see the tool tip that displays information about the active profile. Double-click the icon for additional
information.
To change the Power Management profile
1.
Right-click the CPU: Performance Profile: AC Power icon on the Windows taskbar.
2.
Select Profiles from the menu.
3.
Select a new profile from the pop-up list. See Power Management profiles for a description of available options.
When you use the battery pack to power your notebook, your system selects the Maximum Battery Life power
management profile by default. If you select a different power management profile while using battery power, that profile is
selected automatically the next time you use the battery pack to power your notebook.
Refer to the PowerPanel Help for information on customizing the Power Management toolbars.
To customize Power Management settings
You can customize the power management settings, such as the system timer and the brightness of the screen.
1.
Right-click the CPU: Performance Profile: AC Power icon on the Windows taskbar.
2.
Select Edit/Create Profiles from the menu.
3.
In the left panel, click a profile in which you want to change the settings.
4.
In the right panel, double-click an item in which you want to change the settings.
5.
Select an option from the drop-down list.
6.
Click the File menu, then click Save.
7.
Click the File menu, then click Exit.
Page 99
Power Management profiles
The PowerPanel utility provides several predefined power management profiles. Each profile consists of a group of power
management settings that are designed to meet specific power management goals — ranging from maximum power
management to no power management. You can change the settings for any of the predefined profiles (except for the
Disable Power Management profile), or you can create your own profile to suit your portable computing needs. The
predefined profiles are:
Icon Description
Maximum Performance
Provides the best system performance while still conserving power.
Maximum Battery Life
Provides power saving features to give you maximum battery life and good performance. It slows the notebook and puts it
into Standby mode after a specified time period.
Ultimate Battery Life1
Extends the Maximum Battery Life by disabling the i.LINK port.
Power Management Off
Disables all power management settings, such as Standby and Hibernate modes. You can not change the settings of this
profile.
AC Power
The power management state when AC power is in use. Similar to the Power Management Off setting. Power Management
automatically loads the AC profile unless you disable this feature.
Games
Disables the display and the Hard Disk Standby timer.
Presentation
Keeps the display on at all times while it conserves power. This option is ideal for slide show presentations. You can
establish settings for LCD (Video) Standby, Hard Disk Standby, and Standby mode to optimize power management for your
system.
Camera
Optimizes performance and power requirements for camera usage.
DVD
Optimizes performance and power requirements for DVD usage.
Word Processing
Optimizes power management with longer timeouts on the hard disk and display screen. You can also establish settings for
LCD (Video) Standby, Hard Disk Standby, and Standby mode to optimize power management for your system.
Spreadsheet
Optimizes performance and power requirements for spreadsheet applications.
Communications
Extends battery life by initiating a quick display timeout. The Internal modem remains powered. You can also establish
settings for LCD (Video) Standby, Hard Disk Standby, and Standby mode to optimize power management for your system.
Automatic Profile Selection
Automatically switches to a profile suitable for active applications.
1
O n s elected models only.
Do not choose the Automatic Profile Selection when connected to AC power.
Page 100
Loading...
