DIGITAL VIDEOCASSETTE RECORDER
MSW-A2000
MSW-A2000P
MSW-M2000
MSW-M2000P
OPERATION MANUAL
1st Edition (Revised 6)
[English]
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
To avoid electrical shock, do not open
the cabinet. Refer servicing to qualified
personnel only.
This apparatus must be earthed.
AVERTISSEMENT
For the customers in the USA
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful
interference in which case the user will be required to
correct the interference at his own expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority
to operate this equipment.
Afin d’éviter tout risque d’incendie ou
d’électrocution, ne pas exposer cet
appareil à la pluie ou à l’humidité.
Afin d’écarter tout risque d’électrocution,
garder le coffret fermé. Ne confier
l’entretien de l’appareil qu’à un
personnel qualifié.
CET APPAREIL DOIT ÊTRE RELIÉ À LA
TERRE.
VORSICHT
Um Feuergefahr und die Gefahr eines
elektrischen Schlages zu vermeiden, darf
das Gerät weder Regen noch
Feuchtigkeit ausgesetzt werden.
Um einen elektrischen Schlag zu
vermeiden, darf das Gehäuse nicht
geöffnet werden. Überlassen Sie
Wartungsarbeiten stets nur einem
Fachmann.
The shielded interface cable recommended in this manual
must be used with this equipment in order to comply with
the limits for a digital device pursuant to Subpart B of Part
15 of FCC Rules.
This symbol is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: THIS WARNING IS APPLICABLE FOR USA
ONLY.
If used in USA, use the UL LISTED power
cord specified below.
DO NOT USE ANY OTHER POWER CORD.
Plug Cap Parallel blade with ground pin
(NEMA 5-15P Configuration)
Cord Type SJT, three 16 or 18 AWG
wires
Length Less than 2.5 m (8 ft 3 in)
Rating Minimum 10 A, 125 V
Using this unit at a voltage other than 120V
may require the use of a different line cord or
attachment plug, or both. To reduce the risk
of fire or electric shock, refer servicing to
qualified service personnel.
DIESES GERÄT MUSS GEERDET
WERDEN.
For the customers in Europe
This product with the CE marking complies with both the
EMC Directive (89/336/EEC) and the Low Voltage Directive
(73/23/EEC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the
following European standards:
• EN60950: Product Safety
• EN55103-1: Electromagnetic Interference (Emission)
• EN55103-2: Electromagnetic Susceptibility (Immunity)
This product is intended for use in the following
Electromagnetic Environment (s):
E1 (Residential), E2 (Commercial and light industrial), E3
(Urban outdoors) and E4 (Controlled EMC environment
ex. TV studio)
Table of Contents
Chapter 1
Overview
Chapter 2
Location and Function
of Parts
Chapter 3
Preparations
1-1 Features ........................................................................................... 1-1
1-2 Example System Configuration .................................................... 1-4
2-1 Control Panels ................................................................................ 2-1
2-1-1 Upper Control Panel ............................................................... 2-2
2-1-2 Lower Control Panel ............................................................... 2-3
2-1-3 Switch Panel ......................................................................... 2-15
2-2 Connector Panel ............................................................................ 2-16
3-1 Connections to External Devices ................................................... 3-1
3-1-1 Connections to Digital Devices .............................................. 3-1
3-1-2 Connections to Analog Devices .............................................. 3-2
3-1-3 Connections Using the SDTI-CP Interface............................. 3-3
3-2 Reference Signals for Video Output and Servo System .............. 3-4
3-2-1 External Sync Signal for the Internal Reference Video
Signal Generator .................................................................... 3-4
3-2-2 Reference Signal for the Servo System ................................. 3-5
3-2-3 Connecting Reference Signals ............................................... 3-6
3-3 Setup ................................................................................................ 3-8
3-4 Superimposed Character Information ......................................... 3-9
3-5 Cassettes ........................................................................................ 3-11
3-5-1 Cassette Types...................................................................... 3-11
3-5-2 Inserting and Ejecting Cassettes .......................................... 3-11
3-5-3 Preventing Accidental Erasure of Recordings ..................... 3-12
Chapter 4
Recording and
Playback
Chapter 5
Editing
4-1 Recording ........................................................................................ 4-1
4-1-1 Preparations for Recording .................................................... 4-1
4-1-2 Recording Time Code and User Bit Values .......................... 4-2
4-1-3 Recording Procedure ............................................................. 4-5
4-2 Playback .......................................................................................... 4-6
4-2-1 Preparations for Playback ...................................................... 4-6
4-2-2 Playback Procedures .............................................................. 4-7
4-2-3 Dynamic Motion Control (DMC) Playback ........................ 4-12
5-1 Automatic Editing .......................................................................... 5-1
5-1-1 Overview ............................................................................... 5-1
5-1-2 Switch and Menu Settings ..................................................... 5-2
5-1-3 Selecting the Editing Mode ................................................... 5-3
5-1-4 Setting Edit Points ................................................................. 5-3
5-1-5 Modifying and Deleting Edit Points ...................................... 5-6
5-1-6 Cue-Up to Edit Points and Preroll ......................................... 5-7
5-1-7 Preview .................................................................................. 5-7
5-1-8 Carrying Out Automatic Editing ........................................... 5-8
5-2 DMC Editing ................................................................................. 5-11
5-2-1 Overview of DMC Editing .................................................. 5-11
5-2-2 Carrying Out DMC Editing ................................................. 5-12
(Continued)
Table of Contents 1
Table of Contents
Chapter 5
Editing (Continued)
Chapter 6
Shot Mark Function
Chapter 7
Tele-File
5-3 Special Automatic Editing Methods ........................................... 5-13
5-3-1 Quick Editing ....................................................................... 5-13
5-3-2 Continuous Editing .............................................................. 5-13
5-3-3 Standalone Editing ............................................................... 5-14
5-3-4 Manual Editing .................................................................... 5-14
5-3-5 Preread Editing .................................................................... 5-14
6-1 Overview ......................................................................................... 6-1
6-2 Shot Mark Operation Menu .......................................................... 6-2
6-3 Shot Mark Operations ................................................................... 6-3
6-3-1 Reading Shot Marks .............................................................. 6-3
6-3-2 Writing Shot Marks ............................................................... 6-3
6-3-3 Shot Mark List Operations .................................................... 6-4
6-3-4 Cueing Up to Shot Marks ...................................................... 6-6
6-3-5 Reading In Shot Data ............................................................. 6-7
6-3-6 Sorting Shot Marks ................................................................ 6-8
7-1 Overview of Tele-File Functions .................................................... 7-1
7-2 Opening the Tele-File Menu ........................................................... 7-2
7-3 Tele-File Menu ................................................................................. 7-3
7-3-1 Clip Data Display .................................................................. 7-3
7-3-2 Preroll and Cue Up Using Clip Data ..................................... 7-6
7-3-3 Modifying Clip Data .............................................................. 7-7
7-3-4 Undo/Resume Functions...................................................... 7-10
7-3-5 Displaying and Modifying Attribute Data ........................... 7-11
Chapter 8
Function Menu
Chapter 9
Setup Menus
Chapter 10
Maintenance and
Inspection
Appendix
8-1 Overview ......................................................................................... 8-1
8-1-1 Function Menu Configuration ............................................... 8-1
8-1-2 Using the Function Menu ....................................................... 8-1
8-2 Function Menu Item List ................................................................ 8-3
9-1 Setup Menu Configuration ............................................................ 9-1
9-2 Setup Menu Operations ................................................................. 9-2
9-3 Items in the Basic Setup Menu ...................................................... 9-5
9-4 Items in the Extended Setup Menu ............................................... 9-7
10-1 Removing a Cassette When Tape Slack Occurs ...................... 10-1
10-2 Head Cleaning ............................................................................ 10-1
10-3 Error Messages ........................................................................... 10-2
10-4 Moisture Condensation .............................................................. 10-4
10-5 Regular Checks ........................................................................... 10-5
10-5-1 Digital Hours Meter ............................................................ 10-5
10-5-2 Maintenance Timings ......................................................... 10-6
Specifications......................................................................................... A-1
Index ....................................................................................................... I-1
2 Table of Contents
1-1 Features
Chapter 1 Overview
The MSW-A2000/A2000P/M2000/M2000P is a digital
videocassette recorder based on the MPEG IMX
format.
This unit uses large scale integrated circuits for signal
processing, and has a simple internal construction,
allowing it to provide functionality at least equivalent
to a conventional VTR in a compact (4U size),
lightweight, and low power consumption design.
It not only offers recording and playback in MPEG
IMX format, but can also play back tapes recorded in
Betacam SX format or analog Betacam format.
Furthermore, the MSW-M2000/M2000P can also
playback tapes recorded in digital Betacam format.
MPEG IMX format
The MPEG IMX format uses the same 12.65-mm
width tape as the conventional Betacam series. This
economical format uses 50 Mbps high image quality
MPEG-2 compression, and offers up to three hours of
recording.
The video signal compression, as in the Betacam SX
format, uses MPEG-2, and compressed data can be
passed directly without loss of quality, not only to
VTRs, but also to other devices with MPEG support,
such as nonlinear editors or servers. There is thus high
compatibility with the next generation of digital
television formats supporting MPEG-2.
The audio tracks allow up to eight channels to be
recorded, and this also provides future extensibility for
multichannel, multilingual broadcasting, data
broadcasting, and so on.
Direction of tape travel
Direction of head
Video
Audio
Audio
motion
SAT
a)
High-performance heads and compatibility
playback function
Chapter 1 Overview
The newly developed high-performance heads and
dynamic tracking (DT) technology provide highdensity recording and playback in narrow tracks with
high reliability. In addition to the MPEG IMX
recording and playback heads, this unit is also
equipped with Betacam SX format playback heads,
and analog Betacam DT heads, to provide
compatibility playback functions, and allowing a wide
variety of recorded resources to be used effectively.
High-precision digital signal processing
and range of interfaces
The MPEG IMX VTR digital video signal processing
uses 4:2:2 component video signals complying with
ITU-R Rec 601/SMPTE 259M, which are compressed
with ISO/IEC 13818-2000 MPEG-2 compression.
While supporting a wide range of input and output
signals, all of the VTR internal processing is digital,
providing high stability and reliability.
The audio signals, similarly, are based on AES/EBU
format, and are subjected to digital signal processing
while still uncompressed.
The following interfaces are standard equipment, for
ease of connection to different external devices.
• Analog composite signal input/output
• Analog component signal input/output
• Analog audio signal input/output (4 channels)
• Serial Digital Interface SMPTE 259M input/output
(component digital video/audio, 8 channels)
• AES/EBU serial digital audio input/output (8
channels)
• SDTI-CP SMPTE 326M input/output (MPEG video/
audio data)
• Time code input/output
Video
Control (CTL) track
a) Supplemental Automatic Tracking signal
Time code track
Chapter 1 Overview 1-1
1-1 Features
Chapter 1 Overview
High image quality MPEG-2 intraframe
encoding at 50 Mbps.
The video signal compression uses MPEG-2
intraframe encoding conforming to 4:2:2 Profile @
Main Level, with a 1:3.3 compression ratio; the data is
then recorded with a bit rate of 50 Mbps. With the
highly efficient MPEG-2 compression, the image
quality is high enough to withstand a range of editing
and dubbing operations.
The recorded MPEG-2 data can be passed directly to
other nonlinear systems, allowing optimum editing
with no loss of image quality.
High quality eight-channel audio
High quality 16 bit/48 kHz digital audio is supported.
There are eight digital audio input/output channels,
and four analog audio input/output channels.
To support even higher quality recording and
playback, there is a four-channel mode using 24 bit/48
kHz encoding. Thus this unit is eminently suitable not
only for multichannel applications, but also for high
quality audio editing.
Recording and playback of SDTI
compressed data
Basic operation buttons and jog/shuttle
dial
The basic buttons and jog/shuttle dial for VTR and
editing operations are provided in the conventional
VTR layout, ensuring continuity with conventional
operating panels.
Time data display
This can be selected to display a CTL counter value,
time code value, or time code user bits. It can also
display edit points and edit durations.
Menu-based control interface
The time data/menu display shows not only various
values and settings, but also the pages of a menu
system for commonly used functions. You can use the
function keys and MULTI CONTROL knob to easily
change settings.
Other operation settings, including interfacing with
external devices, can be set from the control panel by
the same type of setup menu system as on a
conventional VTR.
Eight-channel audio level meters
This unit is fitted with SDTI-CP input/output
complying with SMPTE 326M, and can therefore be
used for transferring MPEG-2 data, audio data,
metadata, and so on to a VTR or nonlinear device.
Newly developed multifunction control
panel
While a compact 4U size, this unit has a front panel
which provides a wide range of functions while
maintaining existing operability.
The unit has independent audio level meters and
recording/playback level controls for all eight
channels. The level meters are on the control panel, so
that when the panel is used remotely from the main
unit it is still easy to check or adjust the audio levels.
1-2 Chapter 1 Overview
High quality variable speed playback and
digital jog sound function
In digital BETACAM or MPEG IMX format playback,
the dedicated playback DT heads allow smooth,
noiseless playback from –1 to +3 times normal speed.
In analog Betacam compatible playback also, similar
dedicated DT heads allow noiseless playback from –1
to +3 times normal speed, and in Betacam SX format
compatible playback, special multi-head playback
technology allows noiseless playback from –1 to +2
times normal speed.
In slow motion operation, the digital jog sound
function provides the same ease of operation as a
conventional analog VTR.
Wide range of editing functions
Tele-File functions
Tele-File enables data writing/reading between
cassettes with memory labels and VTRs. It increases
the efficiency of operations such as recording,
playback and editing, and source data management.
Remote control function
This unit can be controlled from an external remote
controller or editor through an interface complying
with RS-422A (serial 9-pin). Since two remote control
connectors are provided, you can also control a
number of VTRs simultaneously.
Additionally, a parallel (50-pin) interface is also fitted
as standard, supporting easy external control through
the parallel interface.
Chapter 1 Overview
By combining two units, you can carry out both
assemble editing and insert editing automatically. All
of the necessary editing functions are provided to set
and amend edit points, to preview and review results of
editing, and so on.
DMC editing
This allows automatic editing with a varying playback
speed memorized beforehand for an edit segment.
Split editing
In insert editing, this allows editing with the audio IN
and OUT points to be displaced from the video edit
points.
Preread editing
This allows you to play back prerecorded video and
audio material, edit it by applying effects with an
external device, and then rerecord in real time on the
same tape.
Rack mounting
Using the optional RMM-131 Rack Mount Adaptor,
you can mount the unit in a standard EIA 19-inch rack.
For details of rack mounting, refer to the Installation
Manual.
Cross-fade editing
In audio editing, to avoid unnatural effects at edit
points, you can fade the audio track. The setting allows
you to select fade-in, fade-out, or cut-in.
Chapter 1 Overview 1-3
Chapter 1 Overview
1-2 Example System Configuration
1-1 Features
The following conceptual diagram shows an example
of use.
Microphone
Digital/analog cassette
Video monitor
Analog composite
Audio monitor
MSW-A2000/A2000P/M2000/M2000P
Analog audio
BVE-series editor
Tape control
SDTI-CP
SDI
Analog composite/component
SDI
Audio/video
server
system
VTR with SDI connectors
or analog VTR
1-4 Chapter 1 Overview
2-1 Control Panels
There are three control panels, as follows:
• Upper control panel
• Lower control panel
• Switch panel
Z
Upper control panel
Chapter 2 Location and Function of Parts
Chapter 2 Location and Function of Parts
(see page 2-2)
PANEL SELECT CONTROL PANEL
KEY INHIBIT
FRONTREAR
OFF
ON
VID. INPB/EE CONFI CTL/TC
PB
Y-R,B
OFF TC
MENU
TCGSET
Switch panel (access by opening the lower control panel)
Lower control panel unlock buttons
Pushing in these buttons allows you to open the lower control panel.
Lower control panel
(see page 2-15)
(see page 2-3)
Chapter 2 Location and Function of Parts 2-1
2-1 Control Panels
2-1-1 Upper Control Panel
Chapter 2 Location and Function of Parts
1 POWER switch
2 REMOTE buttons and RS-232C indicator
3 EJECT button
POWER
PHONES
5 PHONES jack and control
REMOTE
1(9P) 2(50P) RS-232C
EJECT
Z
4 Format indicators
BETACAM/SP
BETACAM SX MPEG IMX
Cassette compartment
Digital BETACAM
1 POWER switch
Pressing the ‘ ) ’ side of the switch powers the unit on.
When the unit is powered on, the audio setting display
section (see page 2-5) and the time data/menu display
section (see page 2-7) light.
2 REMOTE buttons and RS-232C indicator
Press one of these buttons to select the device
controlling this unit.
1(9P): This unit is controlled by the device connected
to the REMOTE 1-IN(9P) or REMOTE 1OUT(9P) connector. The button lights.
2(50P): This unit is controlled by the device
connected to the REMOTE 2 PARALLEL I/
O(50P) connector. The button lights.
RS-232C indicator: This indicator lights when this
unit is controlled through the RS-232C connector.
3 EJECT button
To eject the cassette, press this button. While the
cassette is being ejected, this button lights.
When using the lower control panel as remote control
panel, press the DELETE button and STOP button at
the same time to eject the cassette.
4 Format indicators
The BETACAM/SP, BETACAM SX, MPEG IMX, or
a)
Digital BETACAM
indicator lights depending on the
current recording or playback format.
The BETACAM/SP indicator lights when the format is
Betacam or Betacam SP.
a) The MSW-A2000/A2000P does not have the Digital
BETACAM indicator.
5 PHONES jack and control
Connect stereo headphones with an impedance of
8 ohms, to monitor the sound during recording,
playback and editing.
The control knob adjusts the volume.
It is possible to set an internal board switch so that the
output volume from the MONITOR OUTPUT L and R
connectors is controlled simultaneously.
For details, refer to the Installation Manual.
Note
Ejecting with the EJECT button is a local operation. It
is not possible to eject a cassette in another unit by
remote control.
2-2 Chapter 2 Location and Function of Parts
2-1-2 Lower Control Panel
1 Audio control section
(see page 2-4)
2 CHANNEL CONDITION
indicator
(see page 2-6)
3 Menu control buttons
(see page 2-7)
VID. IN PB/EE CONFI CTL/TC
PB
Y-R,B
OFF TC
4 Time data/menu display section
5 MULTI CONTROL knob and SHIFT
indicator
(see page 2-8)
6 RESET button
TCGSET
MENU
7 Search control section
8 REC INHI indicator
9 Tape transport control section
(see page 2-7)
Chapter 2 Location and Function of Parts
(see page 2-9)
(see page 2-9)
(see page 2-10)
(see page 2-10)
VID. IN PB/EE CONFI CTL/TC
Y-R,B
qd Editing control section
qf Shot mark section
q; Editing mode setting
section
(see page 2-12)
MENU
PB
OFF TC
TCGSET
(see page 2-14)
qa ALARM indicator and KEY INHI
indicator
(see page 2-12)
qs PLAYER button and RECORDER
button
(see page 2-12)
(see page 2-13)
Chapter 2 Location and Function of Parts 2-3
2-1 Control Panels
1 Audio control section
1 Audio selection function selector buttons
2 DISPLAY FULL/FINE button
Chapter 2 Location and Function of Parts
5 REC controls
In the audio control section, you can select and display
input and output signals for audio channels 1 to 8.
Note
When 24-bit/4-channel mode is selected for audio
recording/playback, the audio setting display
section displays only audio signal settings for channels
1 to 4. You cannot make audio input/output signal
settings for channels 5 to 8.
Switching audio recording/playback modes between 16-bit/
8-channel and 24-bit/4-channel requires maintenance menu
operations. For details, refer to the Maintenance Manual
Volume 1.
When a digital Betacam tape is played back, the digital
audio levels are displayed on the level meters for
channels 1 to 4 in the audio setting display section 3.
The level meter for channel 7 displays the cue audio
level always in FULL mode (see the description of the
DISPLAY FULL/FINE button 2).
3 Audio setting display section
4 Audio signal
selection buttons
7 ALL CH
indicators
6 PB controls
1 Audio selection function selector buttons
INPUT (input signal selection mode) button:
Pressing this button puts the unit into input signal
selection mode. In the audio setting display
section, indicators flash to indicate the currently
selected signal for each channel (SDI, AES/EBU,
or ANA). In this state, you can use the audio
signal selection buttons to select the signal to
input to each channel.
Pressing this button again takes the unit out of
input signal selection mode and puts it into
monitor signal selection mode.
Note
When SDTI is selected for the input video signal,
you cannot use audio signal selection buttons to
make audio signal input selection for each
channel. Use the function menu to make SDTI
signal selection.
MIXING (mixing setting mode) button: Pressing
this button puts the unit into mixing setting mode.
In the audio setting display section, the MIX
indicator flashes. In this state, you can use the
audio signal selection buttons to specify which
input channel signal will be recorded on which
audio track on the tape.
Pressing this button again takes the unit out of
mixing setting mode and puts it into monitor
signal selection mode.
On how to operate in input signal selection mode, mixing
setting mode, and monitor signal selection mode, see the
descriptions of the audio signal selection buttons 4 on page
2-5.
2 DISPLAY FULL/FINE button
Pressing this button toggles the display mode of the
level meters in the audio setting display section
between FULL and FINE.
FULL: The display covers the range –60 dB to 0 dB
or –40 dB to +20 dB as selected using setup menu
item 806. In this mode the segment of the display
corresponding to the current audio level and all
lower segments light.
FINE: The display is enlarged, with a step of
0.25 dB. A segment indicating the reference level
lights. In this mode only the segment of the
display corresponding to the current audio level
lights. If the audio level exceeds the maximum
display level, the top segment flashes, and if the
audio level goes below the minimum display
level, the bottom segment flashes.
2-4 Chapter 2 Location and Function of Parts
3 Audio setting display section
Input signal indicator
DATA indicator
MIX indicator
OVER indicator
Level meter
SDI SDTI
AES/EBU/ANA
DATA 5
6 7 8
MIX 1 2 3 4
OVER
dB dB
-10
-20
-30
-40
-60
L R
0
EMPH
2
1
0
-1
-10
-20
-2
-40
20
10
Input channel
indicator
Monitor channel L
and R indicators
Input channel indicator: Indicates the input channel
from which audio signals are recorded on the
audio track. Two numbers light to indicate that
signals from the corresponding input channels are
mixed for recording.
Monitor channel L and R indicators: Indicate
whether or not the signals of the track are output
to the MONITOR OUTPUT L and R connectors
or the PHONES jack. ‘L’ lights to indicate output
to the left monitor channel, and ‘R’ lights to
indicate output to the right monitor channel.
EMPH (emphasis) indicator: While the unit is in
recording or playback mode, this lights when the
emphasis setting is on for the audio signal on the
corresponding track.
Chapter 2 Location and Function of Parts
EMPH indicator
4 Audio signal selection buttons (CH1 to CH8)
The function of these buttons depends on the signal
selection mode set with the audio selection function
Input signal indicator: Indicates the currently
selected input signal (‘SDI’, ‘SDTI’, ‘AES/EBU’,
‘ANA’ for analog) for the corresponding audio
input channel.
DATA indicator: Lights when the corresponding
audio track (audio channel on the tape) is put into
data mode.
selector buttons (INPUT, MIXING) 1 as follows.
Input signal selection mode (the input signal
indicator flashes): The buttons in the upper row
select signals for each audio input channel.
When the CH1 to CH4 buttons are pressed, the
selected signal cycles between SDI t AES/EBU
t ANA(LOG) t SDI.
When ANA (analog) has been selected with the
For details of the data mode, refer to the Maintenance
Manual Volume 1.
MIX (mixing) indicator: Flashes when a mixing
setting operation is enabled for the corresponding
audio track. The indicator showing the number of
the selected input channel lights.
OVER indicator: While the unit is in recording or
playback mode, this lights when the level of the
audio signal on the corresponding channel exceeds
the maximum level that can be indicated on the
level meter.
Level meter: Displays the audio signal level when
1)
the unit is in recording, E-E
, or playback mode.
You can use the setup menu to switch the display
mode between PEAK.0 (0 dB is maximum level)
and REF.0 (0 dB is the reference level). You can
also use the DISPLAY FULL/FINE button 2 to
enlarge the display only near the reference level.
When a digital Betacam tape is played back, the
level meter for channel 7 displays the cue audio
CH5 to CH8 buttons, the analog audio signals
connected to the CH1 to CH4 input connectors are
selected, respectively.
Press the INPUT button to confirm the input signal
selections.
Mixing setting mode (the MIX indicator flashes):
The buttons in the lower row (REC row) select the
tracks (audio channels on the tape) to contain the
mixed signals. In the audio setting display section,
the MIX indicator for the corresponding track
flashes. The buttons in the upper row (EXT row)
select the input channel signals to record on the
corresponding track. By pressing two buttons at
the same time, you can specify that the signals of
two input channels be mixed for recording.
For example, if you want to record the mixed
signals of input channels 1 and 4 on track 3, press
the CH3 button in the lower row (REC row), and
then simultaneously press the CH1 and CH4
buttons in the upper row (EXT row).
level.
..........................................................................................................................................................................................................
1) E-E mode: Abbreviation of “Electric-to-Electric mode”.
In this mode, video and audio signals input to the VTR
are output after passing through internal electric circuits,
but not through magnetic conversion circuits such as
heads and tapes. This can be used to check input signals
and for adjusting input signal levels.
Chapter 2 Location and Function of Parts 2-5
2-1 Control Panels
Note
Before selecting signals from two input channels
for recording in one recorder channel, check to be
sure that the emphasis settings (ON or OFF) of the
two input channels are the same. Recording and
playback of mixed signals cannot be carried out
Chapter 2 Location and Function of Parts
correctly if the emphasis settings are different.
For audio tracks with emphasis on, the EMPH
indicator in the audio setting display section
lights.
When the input signal selection for the CH5
button is ANA, and MIX for track 2 is set to the
CH5 button, the analog signals connected to the
CH1 input connector are recorded on track 2.
Monitor signal selection mode (the input signal
indicator and the MIX indicator do not flash):
The buttons in the upper and lower rows select
tracks to be output to the MONITOR OUTPUT L
and R connectors on the connector panel or the
PHONES jack on the upper control panel. The
buttons in the upper row (L row) select tracks for
output to the MONITOR OUTPUT L connector,
and the buttons on the lower row (R row) select
tracks for output to the MONITOR OUTPUT R
connector. You can obtain the mixed output of
multiple tracks by simultaneously pressing
multiple buttons in the upper or lower rows. For
example, simultaneously press the CH1, CH2, and
CH3 buttons in the upper row to mix the signals of
audio tracks 1, 2, and 3 for output to the
MONITOR OUTPUT L connector.
5 REC (recording) controls
These individually adjust the recording levels on
channels 1 to 8.
To set the recording level, put the unit into E-E mode,
press to protrude the control knobs and adjust the level
while watching the level meters.
When the control knobs are pushed in, the recording
levels return to the preset levels and cannot be
adjusted.
For details about selecting the E-E mode, see the
description of the REC button in the tape transport control
section (see page 2-10) and function menu HOME page (see
page 8-3).
About the CH8/ALL CH (channels) control in the
REC control row
You can choose to use the rightmost CH8/ALL CH
control in the REC control row to adjust the recording
level of all channels. This setting is made in setup
menu item 131. When adjustment by the CH8/ALL
CH control is enabled, the CH1 to CH7 controls in the
REC row are disabled.
6 PB (playback) controls
These adjust individually the playback levels on
channels 1 to 8.
During playback, press to protrude the control knobs
and adjust the level while monitoring the audio level
indication on the level meters in the audio setting
display section.
When the control knobs are pushed in, the playback
levels return to the preset levels, and cannot be
adjusted.
When playing back a digital Betacam tape, you can
use the control knob for channel 7 to adjust the cue
audio playback level.
About the CH8/ALL CH (channels) control in the
PB control row
You can choose to use the rightmost CH8/ALL CH
control in the PB control row to adjust the playback
level of all channels. This setting is made in setup
menu item 132. When adjustment by the CH8/ALL
CH control is enabled, the CH1 to CH7 controls in the
PB row are disabled.
7 ALL CH (channels) indicators
These indicators light when adjustment of all audio
channels by the CH8/ALL CH controls in the REC and
PB control rows is selected.
2 CHANNEL CONDITION indicator
A three-color indicator shows the state of the playback
signal.
Green: The state of the playback signal is good.
Yellow: The playback signal is somewhat
deteriorated, but playback is possible.
Red: The playback signal is deteriorated.
When this indicator remains on, head cleaning or
an internal inspection is necessary.
2-6 Chapter 2 Location and Function of Parts
Note
During analog playback, indications are by green and
red only.
3 Menu control buttons
These buttons are used for function menu (see the
following section “Overview of the function menu”)
and setup menu (see Chapter 9) operations. The page
buttons (V, v, and HOME) select menu pages, and the
function buttons (F1 to F6) make function settings.
V: Selects the next page in the order HOME t 1 t
2 t 3 t 4 t 5 t HOME.
v: Selects the next page in the order HOME t 5 t
4 t 3 t 2 t 1 t HOME.
When there are setup menu definitions on page 6,
page 6 is displayed between page 5 and the HOME
page.
HOME: Selects the function menu HOME page.
When at least one user-defined function key is set
in the HOME2 page, pressing the HOME button
toggles the menu page display between HOME
and HOME2.
F1 to F6: Make settings for the items displayed in the
upper line of the menu display (the menu item
display line). Pressing one of these buttons
changes the setting for the corresponding item and
displays the setting in the lower line of the menu
display.
If there is no setting displayed in the lower line of
the menu display, even though a menu item is
displayed in the upper line, pressing the
corresponding function button moves to a lower
menu level.
Overview of the function menu
The function menu provides convenient access to
frequently used function settings, such as input video
signal selection and time code settings.
For details on the function menu, see Chapter 8.
4 Time data/menu display section
1 Time data display
This displays indicators relating to time data and other
indicators.
Time data display area 1
Time data type indicator
DF indicator
LTC indicator
VITC indicator
Capstan lock mode indicator
Playback format indicator
System frequency indicator
525/625 indicator
CONFI (ON)/PREREAD
indicators
VIUB VITC
DF LTC
01: : :23 45 06
Time data display area 2
2F
CONFI ON
DOLBY NR
DOLBY NR indicator
Speed indication area
Time data display area 1
Normally this displays a CTL count, time code value,
or user bit value according to the setting in function
menu HOME page for F4 (CTL/TC).
Time data type indicator
This indicates the type of data displayed in the time
data display area 1.
LTC (longitudinal time code): Time code recorded
on a longitudinal track on the tape
LUB: LTC user bit values
VITC (vertical interval time code): Time code
recorded in the vertical blanking interval
VIUB: VITC user bit value
Chapter 2 Location and Function of Parts
1 Time data display
VIUB VITC
DF LTC
2F
01: : :23 45 06
1
VID. IN PB/EE CONFI CTL/TC
Y-R,B
PB
2 Menu display
OFF TC
MENU
CONFI ON
DOLBY NR
TCGSET
59.94
IMX 525
REM: 01: 23 : 45 78. 9%
DF (drop-frame) indicator (525-line mode only)
This lights when values of drop-frame mode time code
are displayed.
LTC indicator
Regardless of the display in time data display
area 1, this indicator lights when LTC values are being
read or recorded.
Chapter 2 Location and Function of Parts 2-7
2-1 Control Panels
VITC indicator
Regardless of the display in time data display
area 1, this indicator lights when VITC values are
being read or recorded.
Capstan lock mode indicator
Chapter 2 Location and Function of Parts
This indicates the capstan lock mode (2F, 4F, or 8F)
set in function menu page 4 or in setup menu item 106.
Playback format indicator
This indicator shows the current playback format.
DB: Digital BETACAM format
IMX: MPEG IMX format, bit rate 50 Mbps, 8 audio
channels
IMX4: MPEG IMX format, bit rate 50 Mbps, 4 audio
channels
SX: Betacam SX format
SP: Betacam SP format
No display: Betacam format
System frequency indicator
Displays the current playback field frequency, and the
bit rate of recording or SDTI-CP output.
525/625 indicator
This indicator shows the number of scan lines for the
television standard (525 (NTSC) or 625 (PAL))
selected using setup menu item 013.
CONFI (ON)/PREREAD indicators
These indicate the state of the VTR CONFI playback
function. When the CONFI playback function is
enabled by the setting in function menu HOME page,
the CONFI indicator appears, and when CONFI
playback is actually being carried out the ON indicator
also appears.
When F6 (PREREAD) is set to ON in function menu
page 4, the CONFI playback function is disabled and
one of the following is displayed.
PREREAD: Preread of both audio and video
A-PREAD: Preread of both audio only
V-PREAD: Preread of video only
Time data display area 2
Displays data types and time data such as the time code
of edit points and the total time of that tape.
The following data types are shown.
TOTL: Time value representing the total tape length.
REM: Time value representing the remaining tape
length.
Either TOTL or REM appears depending on the
function menu page 3 setting for F5 (T INFO).
The values displayed are approximate values
calculated on the basis of the detected tape diameter.
They are not precise to units of seconds.
IN: video IN point
OUT: video OUT point
AIN: audio IN point
AOUT: audio OUT point
DUR: duration value
TCG (time code generator): time code generated by
the internal time code generator
DOLBY NR indicator
This lights when the Dolby noise-reduction
functioning.
Speed indication area
This indicates the speed of a DMC playback.
During a DMC playback, “DMC SPD” is displayed in
time data display area 2.
1)
2 Menu display
This displays the function menu and setup menu.
For details on the function menu, see Chapter 8 and for
details on the setup menu, see Chapter 9.
2)
circuit is
..........................................................................................................................................................................................................
1) CONFI playback: This refers to playback of the audio
and video signals immediately after recording, using the
confidence heads, the signal being output to all intents
and purposes simultaneously with recording. This is used
to check recording.
2) Dolby noise reduction: Dolby noise reduction
manufactured under license from Dolby Laboratories
Licensing Corporation. “DOLBY” and the double-D
symbol ; are trademarks of Dolby Laboratories
Licensing Corporation.
2-8 Chapter 2 Location and Function of Parts
5 MULTI CONTROL knob and SHIFT
indicator
For details of playback in jog mode, see the description of
the search dial 5.
In function menu operations, rotate the MULTI
CONTROL knob to change settings that flash in the
menu display section. In setup menu operations, rotate
this knob to select menu items.
The SHIFT indicator lights when you press this knob
in. In this state, the value of the setting changes by a
greater amount when you rotate the knob.
6 RESET button
To reset a CTL, time code (TC) or user bit (UB) value
displayed in time data display area 1, hold this button
down.
Resetting the CTL value erases all edit points.
7 Search control section
1 SHUTTLE button
2 JOG button
3 VAR button
JOG
SHUTTLE/VAR
VAR
FORWARD
JOG
4 SHUTTLE/VAR
and JOG
indicators
5 Search dial
RECORDER
T
U
H
S
REVERSE
E
L
T
3 VAR (variable) button
To use the search dial for playback in variable speed
mode, press this button, turning it on.
For details of playback in variable speed mode, see the
description of the search dial 5.
4 SHUTTLE/VAR and JOG indicators
Either of the indicators is lit to show the current search
mode or the mode used last. When the unit is turned
on, the SHUTTLE/VAR indicator lights.
When the SHUTTLE/VAR indicator is lit: Shuttle
or variable speed mode
When the JOG indicator is lit: Jog mode
5 Search dial
Turn this to carry out playback in the modes shown in
the following table. Turning the dial clockwise lights
the H indicator and plays back in the forward
direction. Turning the dial counterclockwise lights the
h indicator and plays back in the reverse direction.
When the tape is stopped or the unit is turned on, the
s indicator lights. Pressing the dial toggles between
shuttle and jog modes or between variable speed and
jog modes.
You can carry out noiseless playback in the following
speed ranges depending on the tape format.
Digital Betacam: –1 to +3 times normal speed
MPEG IMX: –1 to +3 times normal speed
Betacam SX: –1 to +2 times normal speed
Betacam/Betacam SP: –1 to +3 times normal speed
Chapter 2 Location and Function of Parts
1 SHUTTLE button
To use the search dial for playback in shuttle mode,
press this button, turning it on.
For details of playback in shuttle mode, see the description
of the search dial 5.
2 JOG button
To use the search dial for playback in jog mode, press
this button, turning it on.
Chapter 2 Location and Function of Parts 2-9
PREROLL
REW
PLAY
F FWD
STOP
REC
EDIT
STANDBY
2-1 Control Panels
Playback modes using the search dial
Playback mode
Shuttle
Chapter 2 Location and Function of Parts
Jog Press the JOG button or the search
Variable speed Press the VAR button, turning it on,
Capstan override
Setting setup menu item 101 (see page 9-7) to KEY enables
you to use only the SHUTTLE, JOG, and VAR buttons to
select shuttle/jog/variable speed modes.
Operations and functions
Press the SHUTTLE button or the
search dial so that the SHUTTLE
button lights, then turn the search dial.
Playback is carried out at a speed
determined by the position of the
search dial. The playback speed
range is as follows:
• Using a Digital Betacam tape: –50 to
+50 times normal speed
• Using an MPEG IMX tape: –60 to
+60 times normal speed
• Using a Betacam SX tape: –60 to
+60 times normal speed
• Using an analog Betacam tape: –35
to +35 times normal speed for 525/
60 mode or –42 to +42 times normal
speed for 625/50 mode
The search dial has detents at the still
position and at ±5 times normal
speed.
The maximum shuttle mode playback
speed can be changed by changing
the setting of setup menu item 102
(see page 9-7)
dial so that the JOG button lights, then
turn the search dial. Playback is
carried out at a speed determined by
the speed of rotation of the search
dial. The playback speed range is –1
to +1 time normal speed.
The search dial has no detents.
then turn the search dial. You can
control the playback speed finely (a
maximum of 51 steps) in the range in
which noiseless playback is possible.
The search dial has detents at the still
position and at the normal speed
position.
.
For details on operation, see page 4-
9.
8 REC INHI (recording inhibit) indicator
This indicator is on or off according to the
combination of the F5 (RECINH) setting on function
menu page 4 and the record inhibit plug on the
cassette, as shown in the following table. When this
indicator is on, recording on tape is prohibited.
REC INHI indicator indications
RECINH setting
ON
OFF Record inhibit Lit
State of the record
inhibit plug on the
cassette
Record inhibit/permit Lit
Record permit
a) It is possible to make a setting (setup menu item 107) so
that in this case the indicator flashes.
REC INHI
indicator state
a)
Off
9 Tape transport control section
1 PREROLL button
2 REC button
3 EDIT button
4 STANDBY button
5 STOP button
7 PLAY button
8 SERVO indicator
9 REW button
1 PREROLL button
Press this button to cue up to the preroll point (before
the IN point by the time set as the preroll time) on the
tape. You can change or select the preroll time and the
state of the unit at the end of preroll (“stop mode”
still playback mode) using setup menu item 001 or
401.
6 F FWD button
1)
or
Cuing up edit points
Hold down the IN, OUT, AUDIO IN, or AUDIO OUT
..........................................................................................................................................................................................................
1) Stop mode: The state in which the device currently the
subject of operation is stopped, and the STOP button is
lit.
button while pressing this button to cue up to the
corresponding edit point.
2-10 Chapter 2 Location and Function of Parts
2 REC (record) button
To start recording, press this button together with the
PLAY button, turning it on.
Monitoring in E-E mode
When the unit is in stop mode, pressing the REC
button causes it to light and allows you to monitor the
video and audio in E-E mode. To return to the original
state, press the STOP button.
During playback, search, fast forward, or rewind,
while the REC button is held down you can monitor
the video and audio in E-E mode. In this case the
button does not light.
3 EDIT button
To carry out manual editing, press this button
simultaneously with the PLAY button.
5 STOP button
To stop recording or playback, press this button,
turning it on.
When you stop playback, the unit switches either to
still playback or to E-E mode according to the setting
on function menu HOME page for F2 (PB/EE) and the
setting of setup menu item 108.
Fault display function
The STOP button flashes in the following cases related
to reference signals:
• When F2 (OUTREF) is set to INPUT on function
menu page 4, and there is no input video signal.
• When F2 (OUTREF) is set to REF in function menu
page 4, and there is no external reference signal input
or the input external reference signal is not
synchronized to the input video signal.
Chapter 2 Location and Function of Parts
Monitoring in E-E mode
When the unit is in stop mode, pressing the EDIT
button causes it to light and allows you to monitor the
input signal selected with the ASSEMBLE button or
INSERT buttons in E-E mode. To return to the original
state, press the STOP button.
During playback, search, fast forward, or rewind,
while the EDIT button is held down you can monitor
the video and audio input signals in E-E mode.
4 STANDBY button
When a cassette is inserted and this button is off, to put
the unit in standby mode, press the button, turning it
on.
In standby mode, the drum is rotating and the tape is in
contact with the drum. As a result, recording or
playback can start immediately.
To end standby mode, press the STANDBY button,
turning it off.
If 8 minutes (value can be varied using setup menu
item 501) elapse in standby mode, the unit
automatically switches out of standby mode to protect
the tape.
6 F FWD (fast forward) button
To fast forward the tape, press this button, turning it
on.
7 PLAY button
To start playback, press this button, turning it on.
To operate in capstan override mode
Hold down this button, and turn the search dial.
For details of capstan override mode, see page 4-9.
8 SERVO indicator
Lights when the drum servo and capstan servo are
locked.
9 REW (rewind) button
To rewind the tape, press this button, turning it on.
Chapter 2 Location and Function of Parts 2-11
2-1 Control Panels
q; Editing mode setting section
1 ASSEMBLE button
Chapter 2 Location and Function of Parts
1 ASSEMBLE button
Press this button, turning it on, to carry out assemble
editing
All signals (video signals, audio signals, time code
signals, and so on) are recorded together.
Press the button again, turning it off, to exit from
assemble editing mode.
Note
When even one of the INSERT buttons is lit, the
ASSEMBLE button does not work. To use the
ASSEMBLE button, turn off all the lit INSERT
buttons.
2 INSERT buttons
Press the corresponding button, turning it on, to select
a signal for insert editing
turning it off, to cancel the selection.
Note
When the ASSEMBLE button is lit, none of the
INSERT buttons work. To use INSERT buttons, press
the ASSEMBLE button, turning it off.
VIDEO TC CH1 CH5 CH6 CH7 CH8CH2 CH3 CH4
2 INSERT buttons
1)
.
VIDEO button: Selects the video signal.
TC (time code) button: Selects time code.
CH1 to CH8 (audio channels 1 to 8) buttons:
Select the signals on audio channels 1 to 8.
INSERTASSEMBLE
2)
. Press the button again,
qa ALARM indicator and KEY INHI
indicator
ALARM indicator
This lights when a hardware error is detected on the
unit, and goes off when the error is resolved.
When this indicator is lit, an error message appears in
the time data/menu display section. If you are using
the SDI OUTPUT 3 (SUPER) or COMPOSITE
VIDEO OUTPUT 3 (SUPER) connector, then when
the setting of F4 (CHARA) in function menu page 4 is
ON, the error message also appears on the monitor
screen.
For details on error messages, refer to Section 1-24 in the
Maintenance Manual Volume 1.
KEY INHI (inhibit) indicator
This indicator lights when the KEY INHIBIT switch
on the switch panel (see page 2-15) is set to ON.
qs PLAYER button and RECORDER
button
When you carry out editing using a VTR connected to
the REMOTE 1-IN(9P) or REMOTE 1-OUT(9P)
connector (see page 2-19) as the player and this unit as
the recorder, these buttons select which VTR the
editing control buttons and tape transport buttons on
this unit control.
PLAYER: The editing control buttons and tape
transport buttons on this unit control the external
player VTR.
RECORDER: The editing control buttons and tape
transport buttons on this unit control the recorder,
that is to say, this unit.
When this unit is being used in standalone mode,
neither button functions.
..........................................................................................................................................................................................................
1) Assemble editing: Editing in which new video/audio is
added in sequence to the end of existing recorded video/
audio.
2) Insert editing: Editing in which new video/audio is added
to an intermediate position of existing recorded video/
audio.
2-12 Chapter 2 Location and Function of Parts
qd Editing control section
1 DMC EDIT button
2 MEMORY indicator
3 DELETE button
4 TRIM buttons
5 Edit point setting buttons
TRIM
AUDIO
IN OUT
DMC EDIT
PREVIEW REVIEWAUTO EDIT
8 PREVIEW button
1 DMC EDIT button
To carry out recording of playback at any speed
between –1 and +3 times normal (between –1 and +2
times normal for Betacam SX), automatic playback,
and automatic editing.
For playback in feed mode, hold down this button and
press the PLAY button.
Playback in feed mode requires a setting of extended
menu item 111.
2 MEMORY indicator
When memorizing the playback speed using the DMC
EDIT button, this indicator flashes as the playback
speed is captured to memory, and lights continuously
once the speed is captured.
3 DELETE button
This deletes an existing edit point.
Hold down this button and press the IN, OUT, AUDIO
IN, or AUDIO OUT button which is lit, indicating an
existing edit point, to delete the corresponding edit
point. The button either goes off or flashes. When the
button flashes, it is necessary to set the deleted edit
point again.
To cancel the DMC mode, hold down the DMC button
and press the DELETE button.
DELETE
MEMORY
7 AUTO EDIT button
ENTRY
IN OUT
6 REVIEW button
4 TRIM buttons
Use these buttons to trim an edit point to single-frame
precision.
Hold down the IN, OUT, AUDIO IN, or AUDIO OUT
button, and press one of these buttons. The ‘+’ button
advances the corresponding edit point by one frame,
and the ‘–’ button sets it back by one frame.
Pressing one of these buttons while holding down the
PLAY button adjusts the tape speed by +8% or –8%
correspondingly. (Capstan override function)
5 Edit point setting buttons
IN button and OUT button
To set a video IN point or OUT point, hold down the
IN button or OUT button, and press the ENTRY
button.
After you have made the setting, pressing the IN
button or OUT button displays the video IN point or
video OUT point set in time data display area 2.
AUDIO IN button and AUDIO OUT button
In insert editing, to set an audio IN point or audio OUT
point separate from the corresponding video edit point,
hold down the AUDIO IN button or AUDIO OUT
button, and press the ENTRY button.
After you have made the setting, pressing the AUDIO
IN button or AUDIO OUT button displays the audio
IN point or audio OUT point set in time data display
area 2.
ENTRY button
Use this for setting edit points and so on.
• To set a video IN point or OUT point: Hold down the
IN button or OUT button, and press this button.
• To set an audio IN point or OUT point: Hold down
the AUDIO IN button or AUDIO OUT button, and
press this button.
6 REVIEW button
Use this button to review the editing results after
carrying out automatic editing.
Chapter 2 Location and Function of Parts
Chapter 2 Location and Function of Parts 2-13
2-1 Control Panels
7 AUTO (automatic) EDIT button
After edit point setting, to carry out automatic editing
(recording), press this button, turning it on.
If the IN point is not set, the automatic editing is
carried out with the point where you pressed this
button as the IN point.
Chapter 2 Location and Function of Parts
If you pressed the PREVIEW button to carry out a
preview, when the preview ends this button flashes.
8 PREVIEW button
After edit point setting, to preview the editing results
on the monitor before recording, press this button,
turning it on.
If the IN point is not set, the preview is carried out
with the point where you pressed this button as the IN
point.
During the preview it is lit, and when the preview ends
it flashes.
qf Shot mark section
1 LIST button
LIST GOOD SHOT MARK
REC/
ERASE
1 LIST button
Use this button to read in and list shot marks.
2 REC/ERASE indicator
This lights in the state in which writing, amending, and
deleting of shot marks is enabled and flashes while a
shot mark is actually being written, amended or
deleted.
3 MARK button
Hold this button down for 2 seconds or more, to enable
writing, amending, and deleting of shot marks.
2 REC/ERASE indicator
3 MARK button
2-14 Chapter 2 Location and Function of Parts
2-1-3 Switch Panel
To access the switch panel, open the lower control
panel.
1 KEY INHIBIT switch
2 PANEL SELECT switch
KEY INHIBIT
ON
PANEL SELECT CONTROL PANEL
OFF
FRONTREAR
5 Memory card slot
1 KEY INHIBIT switch
Moving this switch to the ON position disables the
controls on the upper and lower control panels.
You can specify which buttons and knobs are disabled
in setup menu item 118.
2 PANEL SELECT switch
In addition to the lower control panel, you can connect
a similar control panel to this unit. When two control
panels are connected to the unit, the PANEL SELECT
switch is used to specify which panel be enabled to
control the unit.
FRONT: Enables the control panel connected to the
CONTROL PANEL connector on the switch
panel.
REAR: Enables the control panel connected to the
CONTROL PANEL connector on the connector
panel. When setup menu item 117 is set to PARA,
this switch position also enables the control panel
connected to the CONTROL PANEL connector
on the switch panel.
On how to open the lower control panel, see the figure on
page 2-1.
Chapter 2 Location and Function of Parts
3 CONTROL PANEL connector
4 Memory card ejection button
4 Memory card ejection button
Press to eject a memory card from the memory card
slot.
5 Memory card slot
Insert a memory card to update this unit’s firmware.
You can save or load setup menu settings onto the
memory card. (This function is not supported in this
version.)
For details on firmware update, refer to the Maintenance
Manual Volume 1.
3 CONTROL PANEL connector (10-pin, round
type)
Plug in the lower control panel connection cable.
Chapter 2 Location and Function of Parts 2-15
2-2 Connector Panel
Cooling fan
Chapter 2 Location and Function of Parts
1 Analog audio input/output section
1 AUDIO INPUT CH1 to CH4 connectors
2 AUDIO INPUT CH1 to CH4 LEVEL switches
2 Analog video input/output section
1 Analog audio input/output
section
75Ω 75Ω
7 Time code input/output
section
(see page 2-19)
8 Audio monitor signal output section
page 2-19)
3 Digital audio input/output section
6 External device connectors
(see
2 AUDIO INPUT CH1 to CH4 (channels 1 to 4)
LEVEL switches
Set these for each channel as shown in the following
table, according to the audio input levels to the
AUDIO INPUT CH1 to CH4 connectors and the
impedance.
(see page 2-17)
(see page 2-17)
(see page 2-18)
4 Digital signal input/
output section
(see
page 2-18)
Cooling fan
5 Power supply section
(see page 2-18)
CH1
CH1
LOW
OFF
LEVEL
HIGH
ON
600Ω
AUDIO INPUT
CH2
LOW
OFF
CH3
LEVEL
HIGH
LOW
ON
OFF
600Ω
AUDIO OUTPUT CUE
LEVEL
HIGH
ON
600Ω
CH4
LOW
OFF
LEVEL
HIGH
ON
600Ω
OUTCH2 CH3 CH4
4 CUE OUT connector
3 AUDIO OUTPUT CH1 to CH4 connectors
1 AUDIO INPUT CH1 to CH4 (channels 1 to 4)
connectors (XLR 3-pin, female)
Input analog audio signals to channels 1 to 4.
You can record analog audio signals input to these
connectors to any audio track on the tape.
2-16 Chapter 2 Location and Function of Parts
AUDIO INPUT CH1 to CH4 LEVEL switch settings
Audio input level and impedance Switch setting
Level
–60 dBu
(microphone input)
+4 dBu
(line audio input)
+4 dBm
(line audio input)
Impedance
High impedance
(approx. 20 kΩ)
High impedance
(approx. 20 kΩ)
LOW-OFF
(left position)
HIGH-OFF
(center position)
600Ω HIGH-ON 600Ω
(right position)
3 AUDIO OUTPUT CH1 to CH4 (channels 1 to 4)
connectors (XLR 3-pin, male)
These connectors output analog audio signals for
channels 1 to 4.
4 CUE OUT(cue audio output) connector (XLR 3pin, male) (MSW-M2000/M2000P only)
When playing back a digital Betacam tape, this
connector outputs the cue audio signal.
2 Analog video input/output section
1 REF.VIDEO INPUT connectors and 75 Ω termination switch
2 COMPOSITE VIDEO INPUT connectors
and 75 Ω termination switch
VIDEO INPUT
REF.VIDEO COMPOSITE COMPONENT
OFF ON OFF ON
75Ω 75Ω
VIDEO OUTPUT
COMPOSITE COMPONENT
1
2
3
(SUPER)
R-Y
B-Y
Y
R-Y
3 COMPONENT VIDEO
B-Y
Y
INPUT connectors
4 COMPONENT VIDEO
OUTPUT connectors
5 COMPOSITE VIDEO OUTPUT connectors
(BNC type)
These connectors output analog composite video
signals.
When the setting of F4 (CHARA) in function menu
page 4 is ON, connector 3 (SUPER) outputs a signal
with superimposed time code, menu settings, alarm
messages, and other text information.
3 Digital audio input/output section
1 AUDIO INPUT (AES/EBU) connectors
AUDIO INPUT(AES/EBU)
CH1/2 CH3/4 CH5/6 CH7/8
AUDIO OUTPUT(AES/EBU)
CH1/2 CH3/4 CH5/6 CH7/8
2 AUDIO OUTPUT (AES/EBU) connectors
Chapter 2 Location and Function of Parts
5 COMPOSITE VIDEO
OUTPUT connectors
1 REF. (reference) VIDEO INPUT connectors
(BNC type) and 75 Ω termination switch
Input a reference video signal. Input a video signal
with chroma burst (VBS) or a monochrome video
signal (VS). When using the loop-through connection
set the switch to the OFF position, and otherwise to the
ON position.
2 COMPOSITE VIDEO INPUT connectors (BNC
type) and 75 Ω termination switch
Input analog composite video signals.
When using the loop-through connection set the switch
to the OFF position, and otherwise to the ON position.
3 COMPONENT VIDEO INPUT connectors
(BNC type)
Input analog component video signals (Y/R–Y/B–Y).
4 COMPONENT VIDEO OUTPUT connectors
(BNC type)
These connectors output analog component video
signals (Y/R–Y/B–Y).
1 AUDIO INPUT (AES/EBU) connectors (BNC
type)
Input up to four sets (8 channels: channels 1/2, 3/4, 5/6
and 7/8) of AES/EBU format digital audio signals.
2 AUDIO OUTPUT (AES/EBU) connectors (BNC
type)
These connectors output up to four sets (8 channels:
channels 1/2, 3/4, 5/6 and 7/8) of AES/EBU format
digital audio signals.
Chapter 2 Location and Function of Parts 2-17
2-2 Connector Panel
4 Digital signal input/output section
SDI
INPUT
Chapter 2 Location and Function of Parts
SDI
OUTPUT
1
2
3(
SUPER
)
4 SDI OUTPUT connectors
SDTI-CP
INPUT
OUTPUT
1
2
1 SDI INPUT connectors
2 SDTI-CP INPUT connector
3 SDTI-CP OUTPUT connectors
5 Power supply section
1 AC IN connector
2 Ground terminal
1 AC IN connector
Use the optional power cord to connect this to an AC
outlet.
2 Ground terminal
Connect this to ground.
6 External device connectors
1 SDI (Serial Digital Interface) INPUT connectors
(BNC type)
Input D1 format digital video/audio signals. Of the two
connectors, the upper one is for input, and the lower
one is for an active-through connection.
2 SDTI-CP (Serial Data Transport Interface)
INPUT connector (BNC type)
Inputs SDTI-CP format video and audio signals.
3 SDTI-CP (Serial Data Transport Interface)
OUTPUT connectors (BNC type)
Output SDTI-CP format video and audio signals.
4 SDI (Serial Digital Interface) OUTPUT
connectors (BNC type)
These connectors output D1 format digital video/audio
signals.
When the setting of F4 (CHARA) in function menu
page 4 is ON, connector 3 (SUPER) outputs a signal
with superimposed time code, menu settings, alarm
messages, and other text information.
REMOTE 2 PARALLEL I/O(50P)
1 REMOTE 2 PARALLEL
REMOTE 1-IN(9P)
REMOTE 1-OUT(9P)
RS232C
CONTROL PANEL
VIDEO CONTROL
(OPTION)
I/O(50P) connector
2 CONTROL PANEL
connector
3 VIDEO CONTROL
connector
4 OPTION connector
5 REMOTE 1-IN(9P)
connector
6 REMOTE 1-OUT(9P)
connector
7 RS-232C connector
1 REMOTE 2 PARALLEL I/O(50P) connector
(D-sub 50-pin)
Connect remote control signals from an external
device.
For details, refer to the Installation Manual.
2-18 Chapter 2 Location and Function of Parts
2 CONTROL PANEL connector (round type, 10pin)
In addition to the lower control panel, a similar control
panel can be connected to this unit. To connect such a
second control panel, use this connector. When two
control panels are connected, use the PANEL SELECT
switch on the switch panel (see page 2-15) to specify
which control panel will control this unit.
3 VIDEO CONTROL connector (D-sub 15-pin)
For remote control of the internal digital video
processor, connect an optional BVR-50/50P Remote
Control Unit.
Always power off this unit before connecting the
remote control unit.
4 OPTION connector (D-sub 9-pin)
Not used.
5 REMOTE 1-IN(9P) connector (D-sub 9-pin)
When using this unit together with another MSWA2000/A2000P/M2000/M2000P or a D-1, D-2, or
Betacam VTR, and a BVE-series BVE-900/910/2000/
9000/9000P/9100/9100P or other editor, connect the
optional 9-pin remote control cable from the other unit
to this connector.
Depending on the setting of setup menu item 211, you
can use this connector alone, or in a loop-through
configuration with the REMOTE 1-OUT(9P)
connector.
7 Time code input/output section
1 TIME CODE IN connector
TIME CODE
IN OUT
2 TIME CODE OUT connector
1 TIME CODE IN connector (XLR 3-pin, female)
To record time code from an external device, input a
time code signal from the time code output connector
of the other device.
2 TIME CODE OUT connector (XLR 3-pin, male)
This outputs a time code according to the operating
state of the unit, as follows:
• During playback: the playback time code
By setting setup menu item 606, you can also output
the time code from the internal time code generator
locked to the playback time code.
• During recording: the time code generated by the
internal time code generator or the time code input to
the TIME CODE IN connector.
8 Audio monitor signal output section
Chapter 2 Location and Function of Parts
6 REMOTE 1-OUT(9P) connector (D-sub 9-pin)
This provides the loop-through output for remote
control signals from the REMOTE 1-IN(9P)
connector.
Depending on the setting of setup menu item 211, you
can use this connector alone, or in a loop-through
configuration with the REMOTE 1-IN(9P) connector.
7 RS-232C connector (D-sub 9-pin)
Use this for monitoring and diagnosis of the state of
this unit from an external computer, using ISR
(Interactive Status Reporting).
1 MONITOR OUTPUT R
MONITOR OUTPUT
RL
connector
2 MONITOR OUTPUT L
connector
1 MONITOR OUTPUT R connector (XLR 3-pin,
male)
This outputs the audio signals whose output
destination was set to ‘R’ with the audio signal
selection buttons in the audio control section. If
multiple tracks have been set to ‘R’, the signals of
those tracks are mixed for output.
Chapter 2 Location and Function of Parts 2-19
2-2 Connector Panel
2 MONITOR OUTPUT L connector (XLR 3-pin,
male)
This outputs the audio signals whose output
destination was set to ‘L’ with the audio signal
selection buttons in the audio control section. If
multiple tracks have been set to ‘L’, the signals of
Chapter 2 Location and Function of Parts
those tracks are mixed for output.
2-20 Chapter 2 Location and Function of Parts
3-1 Connections to External Devices
3-1-1 Connections to Digital Devices
Chapter 3 Preparations
This unit can input serial digital signals (video and
audio) from another digital VTR such as the DNW-75/
75P/65/65P, DNW-A75/A75P/A65/A65P and DVW-
Reference signal
75 Ω termination
switch: OFF
REF. VIDEO INPUT
DNW-A75/A75P (player)
A500/A500P/500/500P. The following example shows
the connections with a DNW-A75/A75P unit as a
player, with this unit used as recorder.
SDI OUTPUT
REMOTE-IN(9P)
Chapter 3 Preparations
75Ω termination
REF. VIDEO INPUT
MSW-A2000/A2000P/M2000/M2000P
switch: ON
REMOTE 1-OUT(9P)
SDI OUTPUT 3
(SUPER)
SDI INPUT
(recorder)
BVM-1454 series video
monitor
Chapter 3 Preparations 3-1
3-1 Connections to External Devices
The following example shows the connections with an
analog VTR (a Betacam SP VTR, D2 VTR, 1-inch
VTR, etc.) for recording analog audio and video
signals.
Chapter 3 Preparations
3-1-2 Connections to Analog Devices
COMPONENT/
COMPOSITE
VIDEO OUTPUT
AUDIO INPUT CH1 to CH4 LEVEL switches:
Set according to the analog input level and
the impedance.
(see page 2-16)
Video monitor
75 Ω termination switch:
Set to OFF when using an analog
composite video signal bridge
connection, and otherwise to ON.
MSW-A2000/A2000P/M2000/M2000P
AUDIO OUTPUT
CH1 to CH4
DVR-28/28P/20/20P D2
VTR, BVH-3000/3000PS
1-inch VTR, etc. (player)
BVW-75/70/65/60 series
Betacam SP VTR (player)
REMOTE (9P)
VIDEO OUTPUT
COMPOSITE
AUDIO OUTPUT
CH1 to CH4
REMOTE (9P)
VIDEO OUTPUT
COMPONENT
AUDIO INPUT
CH1 to CH4
REMOTE 1-IN
(9P)
COMPOSITE
VIDEO INPUT
COMPONENT
VIDEO INPUT
3-2 Chapter 3 Preparations
3-1-3 Connections Using the SDTI-CP Interface
The following examples show the connections with
devices that support the SDTI-CP interface for
• When this unit is used as player
Reference signal
75Ω termination switch: ON
REF. VIDEO INPUT
SDI OUTPUT 3
MSW-A2000/A2000P/M2000/M2000P (player)
dubbing video and audio signals.
SDTI-CP
OUTPUT
SDTI-CP
INPUT
Data storage unit for
nonlinear editing system
(MAV-555, etc.)
VIdeo monitor
Chapter 3 Preparations
• When this unit is used as recorder
MSW-A2000/A2000P/M2000/M2000P (recorder)
VIdeo monitor
SDI OUTPUT 3
SDTI-CP
INPUT
SDTI-CP
OUTPUT
VIdeo monitor
Data storage unit for
nonlinear editing system
(MAV-555, etc.)
VIdeo monitor
Chapter 3 Preparations 3-3
3-2 Reference Signals for Video Output and Servo System
This section describes how reference signals for the
video output signals and servo system are selected.
Chapter 3 Preparations
The internal reference video signal generator is
synchronized either to a reference video signal or to an
input video signal. Depending on the settings of the
function menu item OUTREF and setup menu item
309, and the input signal selection, the external
The output from the internal reference video signal
generator is supplied to the output video signal and
servo circuits as a reference signal.
3-2-1 External Sync Signal for the Internal Reference Video Signal Generator
synchronization status is as shown in the following
flowchart.
The video signals are output always synchronized to
the internal reference video signal.
Start
Yes
SDTI-CP input?
No
Is a signal input to
the connector selected
with the VID.IN setting?
EXT AUTO1
INPUT
Yes
No
Setting of setup
menu item 309?
AUTO2
Setting of OUTREF ?
REF
Currently recording
or editing?
No
Is a signal input to
the REF. VIDEO
INPUT connector?
No
INPUT
Yes
Setting of OUTREF ?
REF
Currently recording?
No
Yes
Synchronize to the input video
signal selected with the VID.IN
setting.
3-4 Chapter 3 Preparations
Yes
Synchronize to the reference
video signal input to the REF.
VIDEO INPUT connector.
No external synchronization
3-2-2 Reference Signal for the Servo System
The VTR automatically selects either the input video
signal or the output from the internal reference video
signal generator as the reference signal for the servo
Yes
EXT
INPUT
SDTI-CP input?
Setting of setup
menu item 309?
Setting of OUTREF ?
system. Which of the two signals is selected depends
on the operational status of the VTR, as shown in the
following flowchart.
Start
Chapter 3 Preparations
No
AUTO1
AUTO2
Is a signal input to the
connector selected with
the VID.IN setting?
Yes
Lock the servo to the input
video signal selected with
VID.IN setting.
No
Yes
Synchronize to the reference
video signal input to the REF.
VIDEO INPUT connector.
Currently
recording or
editing?
Is a signal input to
the REF. VIDEO
INPUT connector?
REF
No
No
Yes
No external synchronization
Chapter 3 Preparations 3-5
3-2 Reference Signals for Video Output and Servo System
Connect reference signals as shown below, according
to the way in which the unit is to be used.
• Connections for recording from a switcher or signal generator
Chapter 3 Preparations
3-2-3 Connecting Reference Signals
Reference signal
Switcher or signal generator
75 Ω termination switch: ON
MSW-A2000/A2000P/M2000/M2000P
REF. VIDEO
INPUT
• Connections for recording from an external VTR (player)
Reference signal
75 Ω termination switch: OFF
SDI INPUT
75 Ω termination switch: ON
REF. VIDEO
INPUT
MSW-A2000/A2000P/M2000/M2000P (recorder)
3-6 Chapter 3 Preparations
SDI INPUT
REF. VIDEO
INPUT
SDI OUTPUT
DNW-A65/A65P (player)
• Connections for playback
75 Ω termination switch: ON
MSW-A2000/A2000P/M2000/M2000P
REF. VIDEO
INPUT
Reference signal
Video monitor
• SDI OUTPUT
• COMPOSITE
• COMPONENT
Chapter 3 Preparations
Chapter 3 Preparations 3-7
3-3 Setup
The principal setup operations before operating this
unit can be carried out using setup menus.
The setup menus of this unit comprise a basic setup
menu and an extended setup menu. The contents of
these menus are as follows.
Chapter 3 Preparations
• Items relating to the hours meter
• Items relating to operation
• Items relating to menu banks
Extended setup menu:
• Items relating to control panels
• Items relating to the remote control interface
• Items relating to editing operations
• Items relating to preroll
• Items relating to tape protection
• Items relating to the time code generator
• Items relating to video control
• Items relating to audio control
• Items relating to digital processing
For detailed information about the items, except for the
basic setup menu items relating to the hours meter, of these
menus and how to use them, see Chapter 9 “Setup Menus”.
For detailed information about menu operations relating to
the hours meter, see Section 10-5-1 “Digital Hours
Meter”(page 10-5).
Basic setup menu:
This unit allows menu settings to be saved in what are
termed “menu banks.” Saved sets of menu settings can
be recalled for use as required.
For more information about the menu banks, see the section
“Menu bank operations (menu items B01 to B13)” (page
8-4) .
3-8 Chapter 3 Preparations
3-4 Superimposed Character Information
When the function menu item CHARA is set to ON,
the video signal output from the COMPOSITE VIDEO
OUTPUT 3 (SUPER) connector or the SDI OUTPUT
3 (SUPER) connector contains superimposed character
information, including time code, menu settings, and
alarm messages.
Information displayed
1 Type of time data
Time data
TCR . 2 3 : 5 9 . 4 0 . 1 8 *
PSHUTTLESTILL
Adjusting the character display
You can adjust the position, size and type of the
superimposed characters using setup menu items 002,
003, 005, 009, and 011.
For details, see Section 8-3 “Items in the Basic Setup
Menu” (page 8-5).
Chapter 3 Preparations
2 Time code reader drop frame mark
(for 525-line mode only)
3 Time code generator drop frame mark (for
525-line mode only)
4 VITC field mark
5 Recorder/player selection
Note
The display shown above corresponds to the factory
default settings of the unit.
Changing the setting of setup menu item 005 allows
different time data to be displayed in the lower line of
the display.
For details, see Section 9-3 “Items in the Basic Setup
Menu” (page 9-5).
6 Operation mode
1 Type of time data
Display
CTL CTL counter data
TCR LTC reader time code
UBR LTC reader user’s bits
TCR. VITC reader time code
UBR. VITC reader user’s bits
TCG Time code generator time code
UBG Time code generator user’s bits
IN IN point
OUT OUT point
AI Audio IN point
AO Audio OUT point
DUR Duration between any two of the four edit
Meaning
points (IN, OUT, audio IN, audio OUT)
Note
If the time data or user’s bits cannot be read correctly,
they will be displayed with an asterisk. For example,
“T*R”, “U*R”, “T*R.” or “U*R.”.
Chapter 3 Preparations 3-9
3-4 Superimposed Character Information
2 Time code reader drop frame mark (for 525-line
mode only)
3 Time code generator drop frame mark (for 525line mode only)
Chapter 3 Preparations
4 VITC field mark
5 Recorder/player selection
The indication changes as follows, according to the
state of the RECORDER/PLAYER buttons on the
control panel.
6 Operation mode
The field is divided into three blocks, A, B and C.
• Block A displays the operation mode.
• Block B displays the servo lock status or tape speed.
• Block C displays a x mark to indicate an edit section
“.”: Indicates drop frame mode
“:”: Indicates non-drop-frame mode
“.”: Indicates drop frame mode (factory preset)
“:”: Indicates non-drop-frame mode
“ ” (blank): Fields 1 and 3 (for 525/60 mode) or
fields 1, 3, 5 and 7 (for 625/50 mode)
“ * ”: Fields 2 and 4 (for 525/60 mode) or fields 2, 4,
6 and 8 (for 625/50 mode)
No display: Neither the RECORDER or PLAYER
button is lit.
P: The PLAYER button is lit.
R: The RECORDER button is lit.
during automatic editing, or the section between the
IN and OUT points in auto feed playback.
A
B
C
Display
Block A Block B
SPD (speed) Feed playback speed setting
FEED (speed) During feed playback (speed
A-FEED During auto feed playback, or
A-FEED (speed) During auto feed playback, or
TAPE UNTHREAD Cassette is not loaded.
STANDBY OFF Standby off mode
T.RELEASE Tape tension released
STOP Stop mode
F.FWD Fast forward mode
REW Rewind mode
PREROLL Preroll mode
PLAY Playback mode (servo
PLAY Playback mode (servo locked)LOCK
PLAY Variation
from normal
speed (%)
REC Record mode (servo unocked)
REC LOCK Record mode (servo locked)
EDIT Edit mode (servo unlocked)
EDIT LOCK Edit mode (servo locked)
JOG STILL A still picture in jog mode
JOG FWD Jog mode in forward direction
JOG REV Jog mode in reverse direction
SHUTTLE (Speed) Shuttle mode
VAR (Speed) Variable speed mode
AUTO EDIT Automatic editing mode
PREVIEW Preview mode
REVIEW Review mode
DMC (Speed)
D-PREV (Speed)
D-EDIT (Speed)
DMC-SPD (Speed) DMC initial speed setting
PLY-SPD Variation
from normal
speed
Operation mode
(+1.00 or +2.00 (BKMW-105
installed))
display same as during setting)
cue up
feed playback (speed display
same as during setting)
unlocked)
Capstan override mode
page 4-9)
a)
DMC playback mode
a)
DMC editing preview mode
a)
DMC editing mode
Tape speed override mode
(when “TSO” is selected in
setup menu item 111)
(see
3-10 Chapter 3 Preparations
a) Initial speed settings or stored speed settings
3-5 Cassettes
1
2
F FWDREW
PLAY
STOP
STANDBY
3-5-1 Cassette Types
This unit uses the following MPEG IMX cassettes for
both recording and playback.
MPEG IMX cassettes
Small cassettes BCT-6MX/12MX/22MX/32MX/60MX
Large cassettes BCT-64MXL/94MXL/124MXL/184MXL
The following tapes can be used for playback only.
• Digital Betacam cassettes
• Betacam SX cassettes
• Betacam SP cassettes (metal tape)
• Betacam cassettes (oxide tape)
3-5-2 Inserting and Ejecting Cassettes
It is not possible to insert or eject a cassette unless the
unit is powered on.
Inserting a cassette
EJECT button
Small cassette
Large cassette
STANDBY button
STOP button
Chapter 3 Preparations
1 Turn the POWER switch on.
2 Check the following points, then insert the cassette
in the orientation shown in the figure.
• Check that message “ERR-10” is not shown in
the time data/menu display section.
• Check that there is no slack in the tape.
The cassette is drawn into the unit, and the
STANDBY and STOP buttons light.
If message “ERR-10” appears in the time data/menu display
section, there is moisture condensation in the unit.
Chapter 3 Preparations 3-11
3-5 Cassettes
Removing slack from the tape
Press in one of the reels with a finger, and turn gently
in the direction shown by the arrows until there is no
slack in the tape.
Chapter 3 Preparations
Ejecting a cassette
Press the EJECT button.
Ejecting is a local operation. It is not possible to eject a
cassette in another unit by remote control.
Note
If the tape slacks inside the unit, pressing the EJECT button
may not eject the cassette. For information about how to
remove the cassette in such a case, refer to Section 1-17 in
the Installation Manual.
3-5-3 Preventing Accidental Erasure of Recordings
To prevent a tape from being inadvertently erased,
press in the red record inhibit plug on the cassette.
Large cassette
Small cassette
Press in the red record inhibit plug. (“ON”)
Return this plug to its original position to enable recording on the
tape again. (“OFF”)
3-12 Chapter 3 Preparations
4-1 Recording
This section describes video and audio recording on
the unit.
4-1-1 Preparations for Recording
Chapter 4 Recording and Playback
Switch and menu settings
Before beginning recording, make necessary switch
and menu settings.
POWER switch: ‘ & ’ side (ON)
REMOTE buttons
(see page 2-2)
Audio signal selection buttons
Select the audio channel to be monitored.
Z
: off
VID. INPB/EE CONFI CTL/TC
PB
Y-R,B
OFF TC
For details on each setting, see the pages indicated in
parenthesis.
(see page 2-5)
CONFI (ON)/PREREAD indicators
MENU
TCGSET
:
(see page 2-8)
VID.IN setting
Select the input video signal.
PREREAD setting
(see page 8-8)
CONFI setting
ENABLE
PB/EE setting
CTL/TC setting
Select the time data to be displayed.
RECINH setting
OFF
: lit
(see page 8-3)
: OFF
(see page 8-3)
(see page 8-3)
(see page 8-3)
(see page 8-8)
Chapter 4 Recording and Playback
±
:
:
: PB
:
:
Audio selection function selector buttons
(see page 2-4)
: Select the input audio signal.
REC controls
Adjust the audio recording levels.
(see page 2-6)
:
Chapter 4 Recording and Playback 4-1
4-1 Recording
Adjusting the audio recording levels
When carrying out audio recording at a
reference level
Leave the REC controls pressed in. The audio signals
will be recorded at a preset reference level (a reference
0 dB indication for an input of +4 dBm).
Manually adjusting the recording levels
For each channel, press to protrude the REC control in
the upper control panel, and adjust so that the audio
level indication is 0 dB for an average volume. Carry
out the adjustment in E-E mode.
For details of selecting the E-E mode, see the description of
Chapter 4 Recording and Playback
the REC button in the tape transport control section (page
2-11) and the PB/EE setting in function menu HOME page
(page 8-3).
To change the display range of the audio
level indications
Press the DISPLAY FULL/FINE button (see page 2-
4).
To use the emphasis function
To add emphasis to the analog input audio signal or
analog playback audio signal, set the EMPHSS to ON
(see page 8-6).
When the signal to which emphasis has been applied is
played back, it is automatically subjected to
deemphasis processing.
Using the emphasis-deemphasis processing enables the
dynamic range to be improved by reducing highfrequency noise.
4-1-2 Recording Time Code and User Bit Values
There are three ways of recording time code, as
follows:
• Setting an initial value, then recording the output of
the internal time code generator
• Recording the output of the internal time code
generator synchronized to an external time code
generator
• Recording the output of an external time code
without modification
To monitor the simultaneous playback of
the recorded video and audio signals
Set the CONFI to ENABLE (see page 8-3) to light the
CONFI indicator. It is now possible to simultaneously
monitor the video and audio signals being recorded.
To set an initial value then record the time
code
If necessary, change the settings in function menu page
1 (see page 8-4).
Set the TCG (F1) to INT, and the TCG (F2) to
PRESET.
4-2 Chapter 4 Recording and Playback
Setting an initial time code value
Use the following procedure.
RESET button
Z
1,2,3,4,5,6
Setting the time code value to the real time
With the settings in function menu page 1 set as
follows, carry out the procedure under the heading
above, “Setting an initial time code value”. In steps 3
and 4, set the value slightly after the current time, then
carry out step 6 at the instant the real time catches up
with the setting.
TCG (F1): INT
TCG (F2): PRESET
RUN: FREE
DF: DF (525/60 mode only)
Setting a user bit value
The user bit values recorded on the time code track
provide for eight hexadecimal digits, which can be
used to hold the date, time, or other information.
Use the following procedure.
Chapter 4 Recording and Playback
1 Set the CTL/TC to TC.
2 Press the F6 (TCGSET) button.
The function menu display changes as follows.
00 : 00 : 00 : 00
TCG
SET
The first digit of the time code value (8 digits:
hours, minutes, seconds, and frames) flashes.
To set all digits to zero
Press the RESET button.
SET EXIT
3 Press the F1 (T) or F2 (t) button to select the
digit to be changed.
Pressing the F2 (t) button moves the flashing
digit position to the right, and pressing the F1 (T)
button moves the flashing digit position to the left.
4 Turn the MULTI CONTROL knob or press the F3
(+)/F4 (–) button to change the value in the
flashing digit position.
1 Set the CTL/TC to UB.
2 Carry out the procedure in steps 2 to 6 under the
heading above, “Setting an initial time code
value”.
You can set each digit to any hexadecimal value,
represented by 0 to 9, and A to F.
Note
If any of the settings (to write a recording start mark)
in item G03 of the shot mark operation menu are set to
ON, then for 20 frames from each recording, assemble
editing, or insert editing start, the user bits are
overwritten with the shot mark data.
5 Until all the digits are set as required, repeat steps
3 and 4.
6 Press the F5 (SET) button.
When the RUN is set to FREE in function menu
page 1, the time code value immediately starts
advancing.
Chapter 4 Recording and Playback 4-3
4-1 Recording
To synchronize the internal time code
generator to an external signal
Use this method to synchronize the time code
generators of a number of VTRs, or to record the
playback time code signal from an external VTR
without deterioration of the signal waveform.
In this case the RUN and DF settings are ignored.
You can synchronize the internal time code generator
to either of the following external time codes.
• The time code output (LTC) of an external time code
generator or external VTR connected to the TIME
CODE IN connector of the unit
• The time code (VITC) present in a video signal input
to the unit
Chapter 4 Recording and Playback
• The time code (SMPTE RP188) present in an SDI
signal input to the unit
• The time code present in an SDTI-CP signal input to
the unit
To synchronize the internal time code generator to an
external signal, use the following procedure.
• When synchronizing to the time code (SMPTE
RP188) in an SDI signal:
With the VID.IN in function menu HOME page,
select SDI.
• When synchronizing to the time code in an SDTICP signal:
With the VID.IN in function menu HOME page,
select SDTI.
2 Perform the following settings in function menu
page 1.
• When synchronizing to an external time code
output (LTC) or the time code (VITC) in an input
video signal:
TCG (F1): EXT
TCG (F2): REGEN
VITC: ON (when recording VITC)
TCR: LTC or VITC according as you are
synchronizing to LTC or VITC (If set to
AUTO, LTC is used.)
• When synchronizing to the time code (SMPTE
RP188) in an SDI signal:
TCG (F1): RP188
TCG (F2), VITC, TCR: Any setting
Z
• When synchronizing to the time code in an SDTICP signal:
TCG (F1): CP-LTC
TCG (F2), VITC, TCR: Any setting
TIME CODE
IN OUT
1,2
1
TIME CODE IN connector
1 • When synchronizing to an external time code
output (LTC):
Connect the time code output of the external time
code generator or external VTR to the TIME
CODE IN connector.
• When synchronizing to the time code (VITC) in
an input video signal:
With the VID.IN in function menu HOME page,
select an input video signal containing VITC.
Note
When the TCG (F1) is set to RP188 or CP-LTC,
when settings of the TCG (F1) and VID.IN
conflict with each other, or when the input signal
selected with the VID.IN is not present, the
TCG (F1) setting display flashes.
This starts the internal time code generator running
in synchronization with the external time code
generator.
Once the internal time code generator is
synchronized with the external time code
generator, even if the external time code generator
connection is removed, the internal time code
generator continues to run.
4-4 Chapter 4 Recording and Playback
To record an external time code without
modification
Using this method has no effect on the running of the
internal time code generator.
To record the playback time code from an external
VTR, the method under the heading above, “To
synchronize the internal time code generator to an
external signal”, is recommended.
Z
4-1-3 Recording Procedure
To record, use the following procedure.
Z
21 3
Chapter 4 Recording and Playback
1 Insert a cassette.
TIME CODE
IN OUT
2
1
1 Connect the time code output of the external time
code generator to the TIME CODE IN connector.
2 Perform the following settings in function menu
page 1:
TCG (F1): EXT
TCG (F2): PRESET
For details, see the section “Inserting a cassette” (page
3-11).
2 Hold down the REC button, and press the PLAY
button.
Recording starts, the servo locks, and the SERVO
indicator lights.
3 To stop recording, press the STOP button.
If you record to the end of the tape
The tape is automatically rewound, and stops.
Chapter 4 Recording and Playback 4-5
4-2 Playback
This section describes playback of video and audio.
4-2-1 Preparations for Playback
Switch and menu settings
Before beginning playback, make necessary switch
and menu settings.
Chapter 4 Recording and Playback
POWER switch: ‘ & ’ side (ON)
REMOTE buttons
(see page 2-2)
Audio signal selection buttons
Select the audio channel(s) to be monitored.
Z
: off
VID. INPB/EE CONFI CTL/TC
PB
Y-R,B
OFF TC
For details on each setting, see the pages indicated in
parenthesis.
(see page 2-5)
MENU
TCGSET
:
PB controls
Adjust the audio playback levels.
(see page 2-6)
4-6 Chapter 4 Recording and Playback
:
TCR setting
PB/EE setting
TCG (F2) setting
TCG (F1) setting
CTL/TC setting
(see page 8-4)
(see page 8-3)
: Select the time code to be displayed.
(see page 8-4)
(see page 8-4)
(see page 8-3)
: PB
: Select the output time code.
: INT
: Select the time data to be displayed.
Time data selection
Displayed time data
Use the CTL/TC setting in function menu HOME page
to select one of CTL (control), time code, and user bit
values. When you select time code, the data displayed
is determined by the TCR setting (LTC/AUTO/VITC)
in function menu page 1 as follows.
TCR setting Displayed data
LTC LTC recorded on tape
AUTO
VITC
LTC or VITC (automatically switched)
VITC recorded on tape
• Playback using the capstan override function
The playback speed is adjusted temporarily according
to the angular position of the search dial, to align the
playback phase with that of another VTR.
• DMC Playback
Playback carried out at memorized varying speed.
Normal playback
First insert a cassette.
For details of how to insert a cassette, see Section 3-5-2
“Inserting and Ejecting Cassettes” (page 3-11).
Output time code
The TCG (F2) setting and setup menu item 606
determine whether the time code output from the
TIME CODE OUT connector is the time code
generated by the internal time code generator
(REGEN), or the playback time code (PRESET).
For details of the TCG (F2) settings, see page 8-4.
Playback with SDTI-CP output
When the tape format is other than Betacam SX,
Digital Betacam or Analog Betacam, video and audio
signals are output even in E-E mode.
Note
When you are using cassettes other than digital
Betacam, Betacam SX and analog Betacam cassettes,
video and audio signals can be output in E-E mode.
4-2-2 Playback Procedures
Cassette compartment
Z
STOP button
PLAY button
To start playback
Press the PLAY button.
Playback starts, the servo locks, and the SERVO
indicator lights.
To stop playback
Press the STOP button.
Chapter 4 Recording and Playback
This section describes the following types of playback
which the unit can carry out:
• Normal playback
Playback at normal (×1) speed
• Playback in jog mode
Variable speed playback, with the speed determined
by the speed of turning the search dial
• Playback in shuttle mode
Variable speed playback, with the speed determined
by the angular position of the search dial
• Playback in variable speed mode
Variable speed playback, with the speed finely
determined by the angular position of the search dial
If you play back to the end of the tape
The tape is automatically rewound, and stops.
It is possible to disable the automatic rewind function by
changing the setting of setup menu item 125.
When using the Dolby noise reduction system
When using an analog Betacam cassette, you can use
Dolby C noise reduction for audio playback.
To activate the Dolby noise reduction system, set the
DOLBY of function menu page 4 to NR ON (see page
8-7).
Chapter 4 Recording and Playback 4-7
4-2 Playback
Playback in jog mode
In jog mode, you can control the speed of playback by
the speed of turning the search dial. The playback
speed range is ±1 times normal speed.
The playback speed range can be ±3 times normal speed by
changing the setting of setup menu item 116.
To carry out playback in jog mode, use the following
procedure.
Chapter 4 Recording and Playback
Playback in shuttle mode
In shuttle mode, you can control the speed of playback
by the angular position of the search dial. The range of
playback speed is as follows:
• Using a Digital Betacam tape: ±50 times
• Using an MPEG IMX tape: ±60 times
• Using a Betacam SX tape: ±60 times
• Using an analog Betacam tape: ±35 times (for 525/60
mode) or ±42 times (for 625/50 mode)
There are detents on the search dial at the still position
and at ±5 times normal speed.
To carry out playback in shuttle mode, use the
Z
following procedure.
Z
1 1,2,3
1 Press the JOG button or search dial so that the JOG
button is lit.
Pressing the search dial toggles between jog mode
and shuttle mode.
2 Turn the search dial in the desired direction, at the
speed corresponding to the desired playback speed.
Playback in jog mode starts.
3 To stop playback in jog mode, stop turning the
search dial.
The function to toggle between jog mode and shuttle
mode each time the search dial is pressed can be
disabled by changing the setting of setup menu item
101.
1 1,2,33
1 Press the SHUTTLE button or search dial so that
the SHUTTLE button is lit.
Pressing the search dial toggles between jog mode
and shuttle mode.
2 Turn the search dial to the desired angle
corresponding to the desired playback speed.
Playback in shuttle mode starts.
3 To stop playback in shuttle mode, return the search
dial to the center position, or press the STOP
button.
The function to toggle between jog mode and shuttle
mode each time the search dial is pressed can be
disabled by changing the setting of setup menu item
101.
4-8 Chapter 4 Recording and Playback
To return to normal-speed playback
Press the PLAY button.
To alternate between normal-speed playback
and shuttle mode playback
Set the search dial to the position corresponding to the
desired shuttle playback speed, then switch between
normal-speed playback and shuttle playback by
pressing the PLAY and SHUTTLE buttons alternately.
For intermittent shuttle mode playback, press the
STOP and SHUTTLE buttons alternately.
To alternate between normal-speed playback
and variable speed mode playback
Set the search dial to the position corresponding to the
desired variable playback speed, then switch between
normal-speed playback and variable speed playback by
pressing the PLAY and VAR buttons alternately.
For intermittent variable speed mode playback, press
the STOP and VAR buttons alternately.
Playback in variable speed mode
In variable speed mode, you can finely control (51
steps) the playback speed in the following speed
ranges depending on the tape format.
Digital Betacam: –1 to +3 times normal speed
MPEG IMX: –1 to +3 times normal speed
Betacam SX: –1 to +2 times normal speed
Betacam/Betacam SP: –1 to +3 times normal speed
There are detents on the search dial at the still position
and at ±1 times normal speed.
To carry out playback in variable speed mode, use the
following procedure.
Z
Playback using the capstan override
function
You can use the capstan override function to adjust the
playback speed temporarily. This function is
convenient for playback phase synchronization with
another VTR playing back the same program.
Two types of playback operation are available using
the capstan override function (capstan
override playback).
To perform temporal capstan override
playback
Z
Chapter 4 Recording and Playback
1 2,33
1 Press the VAR button, turning it on.
2 Turn the search dial to the desired angle
corresponding to the desired playback speed.
Playback in variable speed mode starts.
3 To stop playback in variable speed mode, return
the search dial to the center position, or press the
STOP button.
To return to normal-speed playback
Press the PLAY button.
1(A)1(B) 2
1 (A) Hold down the PLAY button, and turn the
search dial in the desired direction to adjust the
playback speed.
The range of speed adjustment is ± 15% in
steps of 1%.
(B) Hold down the PLAY button, and press the
TRIM buttons to adjust the playback speed.
The playback speed can be adjusted to ± 8%
only.
The SERVO indicator goes off.
(Continued)
Chapter 4 Recording and Playback 4-9
4-2 Playback
2 When the adjustment is completed, release the
PLAY button.
The tape transport returns to normal speed, and the
SERVO indicator comes on again.
To perform continuous capstan override
playback
Chapter 4 Recording and Playback
1 Set setup menu item 111 (TSO PLAY) to TSO.
2 Hold down the DMC EDIT button and turn the
MULTI CONTROL knob to select the playback
speed.
The selected playback speed is displayed in time
data display area 2 on the lower control
panel of this unit as well as in the character
information display on the monitor screen.
Carrying out playback in feed mode
Use the following procedure to carry out feed mode
playback.
Speed display area
Z
Z
2 31
1 Hold down the DMC EDIT button, and turn the
search dial to set the playback speed.
32
When BKMW-105 option is installed
In MPEG IMX playback, you can set the feed
mode playback speed to 1 or 2 times normal speed
by rotating the MULTI CONTROL knob with the
DMC EDIT button held down. If the option is not
installed, feed mode playback speed is 1 times
normal speed.
2 Hold down the DMC EDIT button, and press the
PLAY button.
Both buttons light, and playback in feed mode
starts.
3 Press the PLAY button while holding down the
DMC EDIT button.
4 Press the PLAY button or perform any other
operation to exit the tape speed override mode.
See Section 9-2 “Setup Menu Operations” (page 9-2) for
details of setup menu operations.
For details of character information displayed on the video
monitor screen, see the descriptions of F4 (CHARA) in
function menu page 4 (page 8-7) and setup menu item 005
(page 9-5).
4-10 Chapter 4 Recording and Playback
3 Where you wish to stop playback, press the STOP
button.
Playback stops.
Auto feed playback
Auto feed playback is a function for feed mode
playback of the segment between a specified IN point
and OUT point.
By connecting this unit to a recorder VTR with a
RECEIVE STANDBY function (MAV-555/2000 etc.)
via the SDTI-CONTROL PANEL interface and
executing auto feed playback on this unit, you can
record the interval between the IN and OUT points on
the recorder.
1 On the HOME page of the function menu, set F4
(CTL/TC) to TC.
2 Start playback and, with the ENTRY button held
down, press the IN button at the point where you
want to set the IN point. To set the OUT point,
press the OUT button with the ENTRY button held
down.
3 With the DMC EDIT/FEED button held down,
press PREVIEW button. (Before starting, refer to
step 1 of the previous section “Carrying out
playback in feed mode” and set the feed mode
playback speed.)
Chapter 4 Recording and Playback
The VTR prerolls to a point 5 seconds before the
IN point (this can be changed with item 001 of the
basic menu) and starts auto feed playback.
Playback stops after postroll for 2 seconds beyond
the OUT point.
The segment between the IN and OUT points is
recorded on the recorder.
Chapter 4 Recording and Playback 4-11
4-2 Playback
4-2-3 Dynamic Motion Control (DMC) Playback
Overview
DMC playback allows you to vary the playback speed
for a certain section of a tape, in variable speed mode
(from –1 to +3 times normal speed for digital Betacam
playback, from –1 to +3 times normal speed for MPEG
IMX playback, from –1 to +2 times normal speed for
Betacam SX playback, or from –1 to +3 times normal
speed for analog Betacam playback), and store the
varying speed in memory for later playback at the
same varying speed.
Chapter 4 Recording and Playback
Waiting for the on-air cue
before starting DMC
playback
Press the REVIEW button again
at the on-air cue.
Starting DMC playback
immediately after preroll
For example, during a live broadcast of a sporting
event you can set the start and end points of highlights
while recording, and then provide immediate DMC
playback of those highlights.
During DMC playback the tape moves as shown in the
following figure.
On-air start point Preroll point Speed variation start point Speed variation end point On-air end point
Stop
Press the REVIEW button.
Normal speed
playback
Press the PREVIEW button.
DMC playback
Normal speed playback
Stop
Normal speed
playback
Storing a varying playback speed in
memory
To store the playback speed for DMC playback, use
the following procedure.
Note
Make sure that the TSO PLAY of setup menu item 111
is set to DIS beforehand.
Z
251,4 733,4,6
DMC playback Normal speed playback
1 Press the DMC EDIT button, turning it on.
2 Either while playing back the recorded tape, or
during recording, press the ENTRY button and one
of the following buttons simultaneously, to set the
start and end points.
• On-air start point: AUDIO IN button
• Speed variation start point: IN button
• Speed variation end point: OUT button
• On-air end point: AUDIO OUT button
Each press turns the corresponding button on.
3 Press the search dial or the SHUTTLE button or
VAR button to enter shuttle/variable speed mode.
The SHUTTLE/VAR indicator lights.
(Continued)
4-12 Chapter 4 Recording and Playback
4 Holding down the DMC EDIT button, turn the
search dial, to set the initial speed at the playback
start point.
The speed you set appears in the speed indication
area. During this period the tape does not move.
When the initial speed setting is complete, release
the DMC EDIT button.
5 Press the PREVIEW button.
The tape is prerolled and played back at normal
speed from the on-air start point to the speed
variation start point. On passing the speed variation
start point, the MEMORY indicator begins to
flash, and playback begins at the speed set in step
4.
6 Turn the search dial to vary the playback speed.
Executing DMC Playback
There are two methods of starting DMC playback.
• Starting playback at the on-air cue from the on-air
start point
• Starting playback immediately after preroll
Notes
• To avoid operating mistakes we recommend that you
use the VTR in standalone mode when carrying out
DMC playback.
• When using two VTRs connected for editing, you can
only use the recorder VTR for DMC playback, and
only when neither the RECORDER nor PLAYER
button is lit.
To start playback at the on-air cue from the
on-air start point
Use the following procedure.
Chapter 4 Recording and Playback
While the MEMORY indicator is flashing, the
speed variations are stored in memory. On passing
the speed variation end point, the MEMORY
indicator changes from flashing to continuously lit,
and the variable speed storing ends.
7 Press the STOP button to stop the tape.
If the MEMORY indicator lights continuously
before the speed variation end point
This indicates that the memory became full at that
point. It is therefore not possible to record more speed
variation. The maximum capacity is a duration of 120
seconds.
To amend the stored speed variation
Press the PREVIEW button.
The interval between the speed variation start and end
points is automatically played back at the stored speed.
Operate the search dial as required, to adjust the
playback speed.
Setting the initial speed to normal speed
In step 4, press the PLAY button.
Z
1,2
1 Press the REVIEW button.
The REVIEW button lights, and the tape is cued up
to the on-air start point. After the tape is cued up,
the REVIEW button flashes.
2 At the moment the on-air cue is given, press the
REVIEW button once more.
The REVIEW button lights, and playback starts at
standard speed.
Between the speed variation start and end points,
DMC playback is carried out at the stored speed,
and then playback continues at normal speed and
the tape stops at the on-air end point.
Chapter 4 Recording and Playback 4-13
4-2 Playback
To start playback immediately after preroll
Press the PREVIEW button.
The PREVIEW button lights, and after preroll, DMC
playback is carried out for the section from the speed
variation start point, then playback continues at normal
speed from the speed variation end point.
To stop the tape during DMC playback
Press the STOP button.
To exit DMC playback mode
Press the DMC EDIT button and the DELETE button
simultaneously.
Chapter 4 Recording and Playback
4-14 Chapter 4 Recording and Playback
5-1 Automatic Editing
Chapter 5 Editing
This section describes how to carry out automatic
editing with this unit and another VTR connected to
the REMOTE1-IN(9P) connector.
5-1-1 Overview
Editing mode
• Assemble editing
This is the editing mode in which successive portions
of the edited result are recorded on the end of the
already completed section.
The CTL signal, video signal, audio signal, and time
code are all newly recorded on the tape.
• Insert editing
In this mode, new material is recorded at an
intermediate point of an existing recording.
The CTL signal is not recorded. The video signal,
audio signal, and time code signal can all be
independently recorded.
You can carry out DMC editing in both editing modes.
In insert editing, split editing is also possible.
Using CTL to interpolate time code values
When you are using time code values as edit point
addresses, the time code must be recorded on the tape
in correct time sequence (i.e. the sections must be in
strictly ascending time order).
If the time code values are all in correct time sequence,
then if there are any discontinuities in the time code,
the unit allows them to be interpolated using the CTL
counter.
Recording time code
For automatic editing, regardless of the TCG (F1) and
TCG (F2) settings, time code is recorded continuously
from the previous time code recorded on the tape.
Sequence of editing operations
The following flowchart outlines the sequence of
operations in automatic editing with two VTRs.
Selecting the editing mode
Setting the recorder and player edit points
Previewing the edit segments
Amending edit points as necessary
Carrying out automatic editing
Checking the editing results as necessary
(page 5-3)
(page 5-3)
(page 5-7)
(page 5-6)
(page 5-8)
(page 5-9)
Using an editing control unit
When controlling this unit with an editing control unit,
set an edit delay on the editing control unit so that cut
in and cut out instructions are output 5 frames before
the actual edit point.
Notes on video output to the monitor
In E-E mode, the video output of the unit is delayed by
the time for video circuit processing with respect to the
input video signal (8H).
Unlike the playback operations described in Chapter 4,
for playback to be carried out in editing mode with
both the player and recorder specified, you can use
setup menu item 701 to delay the SYNC phase,
delaying it by 8H.
Chapter 5 Editing
Using setup menu item 610, it is also possible to record time
code according to the settings in the function menu.
Chapter 5 Editing 5-1
5-1 Automatic Editing
5-1-2 Switch and Menu Settings
Before beginning editing, make necessary switch and menu settings.
Recorder settings
POWER switch: ‘ & ’ side (ON)
Chapter 5 Editing
REMOTE buttons
REC controls
(see page 2-6)
audio recording levels.
Player settings
(see page 2-2)
Editing mode setting section
Z
VID. INPB/EE CONFI CTL/TC
Y-R,B
: Adjust the
: 1(9P)
(see page 5-3)
TCGSET
PB
OFF TC
MENU
: Select assemble editing or insert editing.
Audio selection function selector buttons
Select the input audio signal.
VID.IN setting
Select the input video signal.
RECINH setting
OFF
CTL/TC setting
TC or CTL
(see page 2-4)
(see page 8-3)
(see page 8-8)
(see page 8-3)
:
:
:
:
PB controls
Adjust the audio playback levels.
5-2 Chapter 5 Editing
POWER switch: ‘ & ’ side (ON)
REMOTE buttons
(see page 2-6)
:
(see page 2-2)
: 1(9P)
VID. INPB/EE CONFI CTL/TC
PB
Y-R,B
OFF TC
CTL/TC setting
MENU
TCGSET
(see page 8-3)
: TC or CTL
5-1-3 Selecting the Editing Mode
To select the editing mode
Select assemble editing or insert editing.
1 Press the RECORDER button or PLAYER button
to select the VTR on which you will set the edit
point.
The button which you have pressed lights.
ASSEMBLE button
INSERT buttons
Z
IN/OUT buttons
Depending on the editing mode, press the following
button or buttons.
• For assemble editing: ASSEMBLE button
• For insert editing: the desired INSERT buttons
(VIDEO, CH1 to CH8, TC)
When you select the editing mode, the IN/OUT
buttons begin to flash, indicating that the edit points
require setting.
5-1-4 Setting Edit Points
Set the edit points (IN and OUT points). To use split
editing in insert mode, you can set the audio and video
edit points separately.
2 Turn the search dial in jog or shuttle mode, and
position the tape at the required edit point.
For details of playback in jog or shuttle mode, see the
sections “Playback in jog mode” and “Playback in
shuttle mode” (page 4-8).
3 At the point at which you wish to set the IN point
or OUT point, hold down the ENTRY button and
press the IN button or OUT button as the case may
be.
When the IN point or OUT point is set, the IN
button or OUT button respectively lights.
Chapter 5 Editing
4 Repeat steps 1 to 3 until all the necessary edit
points are set.
When the IN points on both the recorder and
player are set, the PREVIEW button and AUTO
EDIT button flash, and it becomes possible to
carry out a preview or editing operation.
Automatic setting of edit points
Editing requires four edit points: the IN and OUT
points on both the recorder and player. However, once
any three of these points are defined, the last point is
set automatically. For example, if you set the recorder
IN and OUT points, and the player IN point, the player
OUT point is set automatically.
To set an edit point
Z
Note
In the following cases, the DELETE button begins to
flash and you cannot carry out automatic editing.
• The OUT point is before the IN point.
• All four of the recorder IN and OUT points and the
player IN and OUT points have been set.
Use the DELETE button to delete a redundant edit
point, or set the edit points correctly.
For details of deleting edit points, see the section “Deleting
an edit point” (page 5-6).
312
Chapter 5 Editing 5-3
5-1 Automatic Editing
Chapter 5 Editing
Setting split edit points
In split editing, you can set the edit points for audio
and video independently. Set the audio edit points with
the AUDIO IN/OUT buttons, and the video edit points
with the IN/OUT buttons.
Note that split editing is only possible when the
recording mode is insert editing.
Z
421 3
1 Press the appropriate INSERT button (VIDEO,
CH1 to CH8, or TC).
The IN/OUT and AUDIO IN/OUT buttons flash.
2 Press the RECORDER or PLAYER button to
select the VTR for which edit points are to be set.
Note
During split editing, if you set six or more edit points
for the recorder and player, the DELETE button starts
to flash, to indicate that such a setup is impossible.
Delete all unnecessary edit points, using the DELETE
button.
For details of how to delete edit points, see the section
“Deleting an edit point” (page 5-6).
Automatic setting of edit points in split editing
Split editing requires a total of eight edit points: four
video edit points (player IN and OUT and recorder IN
and OUT) and four audio edit points (player audio IN
and OUT and recorder audio IN and OUT). However,
as soon as you set five points, the system automatically
calculates and sets the remaining three points.
Specifically, once you have set three of the four video
edit points and two audio edit points, the remaining
three edit points are set automatically, regardless of
whether these points are for the recorder or player.
In the figure below, the edit points shown within boxes
are already set. The other edit points (recorder audio
OUT point, and player audio IN and video OUT
points) are set automatically.
Note that, regardless of whether it was set manually or
automatically, any edit point can be deleted or
corrected later.
The button you have pressed lights.
3 To find the edit point, rotate the search dial in jog
or shuttle mode.
For details of jog/shuttle mode playback, see the
sections “Playback in jog mode” and “Playback in
shuttle mode” (page 4-8).
4 Press the ENTRY button together with one of the
IN, OUT, AUDIO IN, and AUDIO OUT buttons,
to set the edit point.
Once an edit point is set, the corresponding button
changes from flashing to continuously lit.
5 Repeat steps 2 through 4 to set the required edit
points.
As each edit point is set, the corresponding button
changes from flashing to continuously lit.
Audio IN point Audio OUT point
Recorder
Player
Audio IN point
You can set audio cut in, crossfade, fade in, and fade out
effects, including their durations, by menu selection.
For details, refer to the Installation Manual.
IN point
IN point
Audio OUT point
OUT point
OUT point
5-4 Chapter 5 Editing
When the audio IN point is not set for insert
editing of audio only
As long as the audio OUT point is set, the VTR is
ready for preview or editing. If the audio IN point has
not been set, the current tape position is automatically
used as the audio IN point.
Using a VTR without a split editing function as
the player
If it is not possible to set separate audio and video edit
points on the VTR you are using as the player, by
setting the audio IN and OUT points on the recorder
(this unit), then setting three video edit points, split
editing is possible.
To display the time value for an edit point
To display the duration of an edit segment
You can display the duration between two edit points
in the following three cases, in the time data/menu
display section (see page 2-7).
• When two edit points are set: the duration of the
segment between the two points
• When only one edit point is set: the duration of the
segment between the point which is set and the
current tape position
• When no edit point is set: the duration of the
previous edit segment
The duration is displayed in time data display area 2,
thus: “DURATION 0:01:10:00”.
To display a duration, use the following procedure.
You can display the time value for an edit point in the
time data/menu display section (see page 2-7).
The edit point appears in time data display area 2.
Time data display area 1
Time data display area 2
Z
12
1 Press the RECORDER button or PLAYER button
to select the VTR on which you wish to check the
edit point.
1 Press the RECORDER button or PLAYER button
to select the VTR on which you wish to check the
duration.
Chapter 5 Editing
The button you have pressed lights.
2 Hold down any two of the IN, OUT, AUDIO IN
and AUDIO OUT buttons.
While you hold down the buttons, the duration is
displayed in time data display area 2.
The button you have pressed lights.
2 Hold down the IN, OUT, AUDIO IN or AUDIO
OUT button according to the edit point you wish to
check.
While you hold down the button, the
corresponding indicator lights in the upper line of
time data display area 2, and the time value of the
edit point is displayed.
Chapter 5 Editing 5-5
5-1 Automatic Editing
Chapter 5 Editing
5-1-5 Modifying and Deleting Edit Points
If the edit points are not set correctly, for example if an
OUT point is before a corresponding IN point, the
DELETE button flashes, and it is not possible to carry
out a preview or editing operation. In this case, either
modify the erroneous edit point, or first delete it and
then enter it correctly.
Modifying an edit point
To modify an edit point, use the following procedure.
Time data display area 1
Time data display area 2
Z
Deleting an edit point
To delete an edit point, use the following procedure.
You can use the same procedure whether or not the
DELETE button is flashing.
Z
12
1 Press the RECORDER button or PLAYER button
to select the VTR on which you wish to delete the
edit point.
12
1 Press the RECORDER button or PLAYER button
to select the VTR on which you wish to modify the
edit point.
The button you have pressed lights.
2 Hold down the IN, OUT, AUDIO IN, or AUDIO
OUT button corresponding to the edit point you
wish to modify, and press the TRIM buttons
(+ or –).
While you hold down the button, the time value for
the edit point appears in the display; pressing the +
button increases the value by one frame, and
pressing the – button decreases it by one frame.
The button you have pressed lights.
2 Hold down the DELETE button and press the IN,
OUT, AUDIO IN or AUDIO OUT button
according to the edit point you wish to delete.
The edit point is deleted according to which button
you pressed, and the DELETE button goes off.
5-6 Chapter 5 Editing
5-1-6 Cue-Up to Edit Points and Preroll
To preroll to a position before an edit IN point or cue
up to any edit point, use the following procedure.
5-1-7 Preview
When you have set the edit points, the PREVIEW
button flashes, indicating that you can carry out a
preview.
To carry out a preview, use the following procedure.
Z
12
1 Press the RECORDER button or PLAYER button
to select the VTR on which you wish to operate.
The button you have pressed lights.
2 • To cue up to an edit point
Hold down the IN/OUT button or AUDIO IN/
OUT button according to the edit point to which
you wish to cue up, and press the PREROLL
button.
This cues up to the edit point you have selected.
• To preroll
Press the PREROLL button.
The tape is wound back to a position 5 seconds
before the edit IN point, and stops.
To change the preroll time
The factory default setting for the preroll time is 5
seconds, but you can use menu item 001 to change this
to any value from 0 to 30 seconds. If you change the
preroll time, make sure that the setting is not longer
than the recording length before the edit IN point.
Note that for automatic editing, the preroll time setting
on the recorder takes precedence.
For details of menu item 001, see Section 9-3 “Items in the
Basic Setup Menu” (page 9-5).
Z
12
Chapter 5 Editing
1 Press the RECORDER button, turning it on.
2 Press the PREVIEW button.
The PREVIEW button changes from flashing to
continuously lit, and the preview is carried out.
At the end of the preview, the PREVIEW button
flashes again.
To stop the preview
Press the STOP button.
The tape stops at the position where you pressed
the button.
To return the tape to the preroll point
Press the PREROLL button.
To return the tape to the IN point or OUT point
Press the PREROLL button and the IN button or OUT
button simultaneously.
After the preview, make any necessary adjustments to
the edit points, then repeat the preview.
For details of how to modify or delete edit points, see
Section 5-1-5 “Modifying and Deleting Edit Points” (page
5-6).
Chapter 5 Editing 5-7
5-1 Automatic Editing
Chapter 5 Editing
Monitor output
During a preview, on a monitor connected to the
recorder you can monitor the following video and
audio.
• From the preroll point to the IN point, you can
monitor the playback from the recorder.
• From the IN point to the OUT point, you can monitor
the playback from the player through the recorder in
E-E mode.
5-1-8 Carrying Out Automatic Editing
Preroll point
Recorder
Preroll
IN point
Edit segment
• From the OUT point to the postroll point, you can
monitor the playback from the recorder.
The following figure illustrates this.
Playback
(recorder)
Tape transport
OUT point
IN point
E-E mode
(player)
Postroll point
OUT point
Playback
(recorder)
Postroll
Player
Time flow
Playback
Overview
When you carry out automatic editing, the recorder
and player operate as shown in the figure above, to
copy the video and audio signals between the IN and
OUT points on the player to the segment between the
IN and OUT points on the recorder.
Recording overlap
(in case of assemble
editing)
Stop
Stop
Monitor output
During execution of an automatic edit, as during a
preview, on a monitor connected to the recorder you
can monitor the following video and audio.
• From the preroll point to the IN point, you can
monitor the playback from the recorder.
• From the IN point to the OUT point, you can monitor
the playback from the player through the recorder in
E-E mode.
• From the OUT point to the postroll point, you can
monitor the playback from the recorder.
5-8 Chapter 5 Editing
The following figure illustrates this.
IN point OUT point
Z
Playback
(recorder)
E-E mode
(player)
Playback
(recorder)
Using a single monitor for video and audio
on both player and recorder
For efficient editing if only one monitor is available,
use the following method.
1 Connect the monitor to the recorder.
2 In the basic setup menu, set item 008 to AUTO.
3 Press the PLAYER button on the recorder.
This forces the recorder to E-E mode, in which the
player video and audio signals are output to the
monitor.
Note
In insert editing to tape, it is necessary for audio,
video, and CTL signals to be recorded in advance
throughout the insert editing section on the tape. If you
execute an insert edit over a section where these
signals are not present, noise or breakup can occur in
the audio and video when that section is played back.
Starting automatic editing
When you have set the edit points, press the flashing
AUTO EDIT button.
The AUTO EDIT button changes from flashing to
continuously lit, and the automatic editing operation
begins.
At the end of the editing operation, the AUTO EDIT
button goes off.
OUT button
ENTRY button
REVIEW button
AUTO EDIT button
PREVIEW button
To change the OUT point after starting
automatic editing operation
After starting the automatic editing operation, to end
the operation before the preset OUT point, hold down
the ENTRY button and press the OUT button.
The position where you pressed the button becomes
the OUT point, and editing ends.
To abandon automatic editing
Press the STOP button.
The automatic editing operation is abandoned. At the
same time, the PREVIEW button and AUTO EDIT
button start flashing, and the state before the editing
was started is restored.
In this case, the IN and OUT points already set are
preserved so that you can carry out a preview or
automatic editing operation again by pressing the
PREVIEW button or AUTO EDIT button.
Reviewing the editing results
After carrying out an editing operation, you can carry
out a review, to check the editing results on the
monitor.
To carry out a review, after carrying out the edit, and
before you set any new edit points or make other
settings, press the REVIEW button.
The REVIEW button lights, and the review is carried
out.
At the end of the review the REVIEW button goes off,
and the tape returns to the OUT point.
Chapter 5 Editing
Chapter 5 Editing 5-9
5-1 Automatic Editing
After automatic editing, to adjust the edit
points and reexecute the edit
Hold down the DELETE button and press the ENTRY
button to recall the edit points. After adjusting the edit
points, press the AUTO EDIT button to carry out the
edit again.
For details of how to adjust edit points, see Section 5-1-5
“Modifying and Deleting Edit Points” (page 5-6).
Note
It may not be possible to make an accurate setting of
edit points when SDTI-CP input signal
is selected for editing.
Chapter 5 Editing
5-10 Chapter 5 Editing
5-2 DMC Editing
By controlling the player playback speed from the
recorder you can achieve variable speed editing.
5-2-1 Overview of DMC Editing
Conditions for DMC editing
DMC editing can be used for insert or assemble
editing, but not for audio split editing.
Preroll
Recorder
Playback
Preroll time x
initial speed
IN point OUT point
IN point
Tape movement during DMC editing
The following figure illustrates how the tapes move on
the player and recorder during DMC editing.
Tape transport
Postroll
DMC editing Playback
Chapter 5 Editing
Stop
Postroll time x
final speed
Time flow
Player
Tape moves at
initial speed
Playback at stored
varying speed
Stop
Tape moves at
final speed
Chapter 5 Editing 5-11
5-2 DMC Editing
Chapter 5 Editing
5-2-2 Carrying Out DMC Editing
Setting the edit points and player speed
Use the following procedure.
Z
482,6,7 31 6,95
1 Press the ASSEMBLE button or the desired
INSERT button to select the editing mode.
2 Press the DMC EDIT button.
This unit switches to the DMC editing mode, and
the DMC EDIT button lights.
3 Press the RECORDER button.
4 Holding down the ENTRY button, press the IN or
OUT button to set an edit point.
7 When the initial speed setting is complete, release
the DMC EDIT button.
8 Press the PREVIEW button.
The tape is prerolled and then the recorder starts
operating at normal speed and the player at the set
initial speed.
9 On passing the IN point, the MEMORY indicator
begins to flash: turn the search dial to vary the
playback speed.
While the MEMORY indicator is flashing, the
speed variations are stored in memory. On passing
the OUT point, the MEMORY indicator changes
from flashing to continuously lit, and the variable
speed storing ends.
If the MEMORY indicator lights continuously
before the OUT point
This indicates that the memory became full at that
point. Thus even before the OUT point is reached, it is
not possible to record more speed variation.
The maximum capacity is a duration of 120 seconds.
Quitting the DMC edit mode
Press the DELETE button and DMC EDIT button
simultaneously.
5 Press the PLAYER button, to set the player IN
point.
Note
It is not possible to set the player OUT point.
6 Holding down the DMC EDIT button, turn the
search dial, to set the initial speed.
To select normal speed as the initial speed, press
the PLAY button.
The speed you set appears in the speed indication
area.
5-12 Chapter 5 Editing
Executing the DMC edit
Press the AUTO EDIT button.
DMC editing is carried out at the stored varying speed.
Once the editing is carried out, the stored speed
variation is lost from memory.
To check the editing results
Press the REVIEW button.
Note
It is not possible to carry out DMC editing when
SDTI-CP input signal is selected.
5-3 Special Automatic Editing Methods
This section describes the following automatic editing
methods:
• Quick editing
• Continuous editing
• Standalone editing
• Manual editing
• Preread editing
5-3-1 Quick Editing
After selecting the edit mode, you can save on editing
time by setting the edit points and executing the edit at
the same time.
For quick editing, use the following procedure.
Z
5-3-2 Continuous Editing
After an automatic editing operation, the recorder
automatically returns to the OUT point. For the
second and subsequent editing operations, you can
continue editing by simply specifying the IN and OUT
points on the player. In this case the current OUT
point on the recorder becomes the new IN point.
OUT point of preceding edit =
Recorder
Preceding edit segment
Player
IN point
After automatic editing of one edit segment, to carry
out continuous editing use the following procedure.
IN point of current edit
Current edit segment
OUT point
Chapter 5 Editing
123
1 When operating the player, press the PLAYER
button, turning it on, and when operating the
recorder, press the RECORDER button, turning it
on, then stop the tapes on both the player and the
recorder at the positions you wish to make the
respective IN points.
2 Press the AUTO EDIT button.
Editing starts.
3 Watching the editing on the monitor, at the
position you wish to make the OUT point, hold
down the ENTRY button and press the OUT
button.
Editing ends.
The point at which you started the editing becomes
the IN point, and the point at which you ended the
editing becomes the OUT point.
1 Set the player IN and OUT points.
On the recorder the OUT point for the previous
edit becomes the new IN point.
2 Press the PREVIEW button to carry out a preview.
3 Press the AUTO EDIT button.
This executes the edit.
When the editing operation is completed, the
recorder stops at the OUT point, and the player
stops 2 seconds after the OUT point.
By repeating this process, you can carry out
continuous editing.
By setting setup menu item 326, you can make the preceding
OUT point automatically become the new IN point.
If you want to preview
In step 1, after setting the recorder or player IN point,
press the PREVIEW button.
Chapter 5 Editing 5-13
5-3 Special Automatic Editing Methods
Chapter 5 Editing
5-3-3 Standalone Editing
This refers to editing using as the player an external
device which cannot be controlled remotely through
the REMOTE1-IN(9P) connector. For example, you
can record a color bar signal from a signal generator in
the joints between the scenes of an already completed
tape.
Carrying out standalone editing
Set the IN point with neither the PLAYER button or
RECORDER button lit.
The AUTO EDIT button flashes, and it is now possible
to carry out automatic editing.
If necessary, you can also first set the OUT point.
5-3-4 Manual Editing
Use the following procedure to carry out manual
editing.
6 At the editing end point (the recorder OUT point),
press the PLAY button.
Editing ends, and the recorder continues with
playback.
7 Press the STOP button to stop the recorder
playback.
5-3-5 Preread Editing
Video and digital audio signals already recorded on the
tape can be used as an edit source for insert editing.
This type of editing is called “preread editing”, as this
unit uses the preread heads to read the signals in
advance from the tape.
The signals read out can be send to a mixer for mixing,
and can be recorded either on the original channels or
on other digital audio channels.
For preread editing, set the PREREAD to ON (see
page 8-8).
1 Press the RECORDER button, turning it on.
2 Use the search dial in jog or shuttle mode to find
the editing start point (the recorder IN point), and
stop the tape just before this point.
Note
If the recorder is in stop mode, then when editing
starts this section of the video will break up.
3 Select the editing mode.
4 Press the PLAY button.
The recorder begins playback.
Note
It takes about two seconds until the playback video
stabilizes. For this reason, start the playback from
before the segment of video you wish to use.
5 At the editing start point (the recorder IN point),
press the EDIT button and PLAY button
simultaneously.
Digital or analog
audio input
Digital or analog
video output
Audio source
Digital or analog
audio output
Audio mixer
Digital or analog
video input
Video switcher
Video source
Editing starts.
5-14 Chapter 5 Editing
Notes
• In preread editing, if an input video signal is used as
the reference signal for the output video signal, this
forms a feedback loop. To prevent the occurrence of
feedback, set the OUTREF in function menu page 4
to REF, and set item 309 in the extended setup menu
to AUTO 1 so as to use an external reference signal.
• When the preread mode is selected, to prevent
feedback due to the loop connection, whatever the
editing mode of this unit, no E-E video output is
available.
When the PREREAD is set to OFF after preread
editing, however, if the loop connection remains and
an E-E signal is output, feedback will occur.
To prevent this, select PB mode for the video and
digital audio channels in all the modes before the
preread editing, as follows.
1 Set PB/EE in function menu HOME page to PB.
2 Set the PREREAD in function menu page 4 to ON.
3 Make the necessary connections for the preread
editing.
4 After selecting the desired insert editing mode,
carry out the preread editing.
5 When the preread editing is completed, remove the
connections.
6 Set the PREREAD to OFF.
7 Check that no loop connection remains.
Note
It is not possible to carry out a preread editing when
SDTI-CP input/output signal is selected.
Chapter 5 Editing
Chapter 5 Editing 5-15
6-1 Overview
Chapter 6 Shot Mark Function
This unit can record shot marks or use shot marks
recorded in MPEG IMX or Betacam SX format.
Types of shot mark
This unit supports the following three types of shot
mark. This chapter describes recording start marks and
Shot mark type
Recording start mark Automatically written at the
Shot mark 1 and
shot mark 2
Post mark Not written
Writing on a camcorder,
etc.
start of recording.
Written by a manual shot
mark operation during
recording or editing.
(Written only on this unit)
Writing on this unit
Written or not according to a separate menu
setting for each recording mode (crash recording,
assemble editing, insert editing).
For each mode for which the setting is “ON”, the
mark is written automatically at the start of
recording.
Written by a button operation during crash
recording or assemble editing. A menu setting
determines which of three types of mark is
written: shot mark 1, shot mark 2, or post mark.
Written by a button operation during playback,
while stopped, during a search, or during
recording (crash recording or assemble editing).
First, the shot mark functions of this unit are described
in simple terms.
Reading shot marks
This unit reads in shot marks written on a tape and
stores them in memory. (To a maximum of 200)
Once this data is stored in this unit, it is preserved even
when the power is turned off.
Shot marks are indications at desired points on a tape
which enable faster cueing.
post marks, treating them as varieties of shot marks.
Modifying and
erasing on this unit
Possible
Cueing up to shot marks
By selecting a desired shot mark from the shot mark
list, you can cue up immediately to that position. By
means of a button operation, you can also cue up to the
shot marks adjacent to the current tape position (index
function).
Shot data display
Chapter 6
Shot Mark Function
Writing and erasing shot marks
For recording start marks, a menu setting determines
whether or not they are written each time recording
starts. Shot mark 1, shot mark 2, and post mark types
can be written at any point on a tape, and also erased
or rewritten.
Shot mark list operations
On the monitor, you can display a list of the shot
marks read in by this unit, select required shot marks,
delete shot marks, and so on. You can also add a
memo mark (#) to a shot mark in the list.
During tape playback, you can add virtual shot marks
to the list. This is not written on the tape itself.
When the tape includes shot data (camera, time, and
other information captured at the time of shooting),
you can read this in, and display the details on a
monitor. It is also possible to display the shot mark list
and shot data simultaneously.
Sorting shot marks by cassette
When the tape includes shot data, this unit recognizes
which cassette each shot mark comes from. You can
therefore sort the read-in shot marks by cassette in
time code order.
Chapter 6 Shot Mark Function 6-1
6-2 Shot Mark Operation Menu
This section describes the settings in the shot mark
operation menu.
Displaying the shot mark operation menu
With the function menu HOME page showing in the
menu display, hold down the MARK button, and press
the F5 (MENU) button.
The following menu appears on the monitor.
Chapter 6
Shot Mark Function
SHOT MARKER
GO1:SEARCH TYPE - all
GO2:LISTING TYPE
GO3:RS.MARK MODE
GO4:MARK IN REC shot1
Z
F5 (MENU) button
MARK button
Details of the shot mark operation menu
The shot mark operation menu comprises four items,
G01 to G04. The detailed contents appear in the
following table.
Item
number
G01 Select which shot mark type the
G02 LISTING
G03 RS.MARK
G04
Item name Settings
SEARCH
TYPE
TYPE
MODE
MARK IN REC Select the type of shot mark to
index function searches for, from
the following possibilities:
all
rec start mark
shot mark 1
shot mark 2
post mark
For each type of shot mark,
select whether to read into the
list (ON) or not read (OFF):
rec start mark
shot mark 1
shot mark 2
post mark
For each type of recording,
select whether to write recording
start marks (ON) or not write
them (OFF):
crash rec: crash recording
assemble: assemble editing
insert: insert editing
write during recording and
assemble editing.
shot mark 1
shot mark 2
post mark
6-2 Chapter 6 Shot Mark Function
Changing the menu settings
The basic procedure for accessing menu items and
changing settings is the same as for the setup menus.
Note, however, the operations in “To change the
settings of menu items with sub-items” (page 9-3) for
items G02 and G03.
Similarly to the setup menu, the shot mark operation menu is
configured so that its current settings as well as menu banks
are saved separately for 525-line and 625-line modes. For
the menu bank operation of the shot mark operation menu,
the same procedure is used as that of the setup menu.
For details of the setup menu configuration and operations,
see Section 9-1 “Setup Menu Configuration” (page 9-1) and
Section 9-2 “Setup Menu Operations”(page 9-2),
respectively.
6-3 Shot Mark Operations
This section describes the operations concerning
reading and writing shot marks. Note that the
following operations cannot be carried out by remote
control.
6-3-1 Reading Shot Marks
To read in shot marks
With a cassette loaded, hold down the LIST button and
press the F FWD or REW button.
Z
F FWD button
REW button
LIST button
While the shot marks are being read in, the F FWD or
REW button flashes.
The unit searches to the end of the tape, then rewinds
automatically.
For the procedure for listing the shot marks read in, see
page 6-4.
Reading shot marks from more than one
cassette
After changing the cassettes, carry out the reading
operation again.
Data written in the new cassette will be added as long
as the total does not exceed 200 shot marks. For
example, if 190 shot marks have already read in, only
10 shot marks will be read from the new tape.
In the shot mark list (see page 6-5) the data from
different cassettes is separated by a row of dashes.
6-3-2 Writing Shot Marks
Writing recording start marks during
recording
In item G03 of the shot mark operation menu (page 6-
2), for each of the three recording modes (crash
recording, assemble editing, and insert editing), select
whether or not to write recording start mark.
When you set a particular mode to “ON”, a recording
start mark is written on the tape each time you start
recording in that mode.
Note
For insert mode, press the TC button to turn the
indicator on.
Writing shot mark 1, shot mark 2, or post
marks
Chapter 6
Shot Mark Function
Note
It is only possible to read in a maximum of 200 shot
marks.
When 200 shot marks have been read in, the control
panel display shows the message “S-LIST FULL”, and
the reading stops.
To cancel the message, press one of the tape transport
buttons.
To stop reading
Press the STOP button.
Selecting the type of shot mark written
In item G04 of the shot mark operation menu (page 6-
2), select one of shot mark 1, shot mark 2, and post
mark.
Note
If any of the settings (to write a recording start mark)
in item G03 of the shot mark operation menu are set to
“ON,” then for 20 frames from each recording,
assemble editing, or insert editing start, the user bits
are overwritten with the shot mark data.
Chapter 6 Shot Mark Function 6-3
6-3 Shot Mark Operations
To write in crash recording or assemble
editing
1 Hold the MARK button down for at least 2
seconds.
2 At the position you wish to write the mark, hold
down the ENTRY button, and press the MARK
button.
A mark of the type selected in item G04 of the shot
mark operation menu is written.
Z
ENTRY button
Erasing a shot mark
Select the shot mark from the shot mark list, and then
carry out the deletion operation.
For details of the procedure, see page 6-6.
6-3-3 Shot Mark List Operations
Displaying the shot mark list
Hold down the ENTRY button and press the LIST
button.
Z
Chapter 6
Shot Mark Function
Writing during playback, while stopped, or
during a search
When this unit is in any of the playback, stop, or
search modes, you can write a post mark only.
1 Hold the MARK button down for at least 2
seconds.
The REC/ERASE indicator lights.
2 At the position you wish to write the mark, hold
down the ENTRY button and press the MARK
button.
A post mark is written the instant you pressed the
MARK button.
While the mark is being written, the message
“RECORD SHOT MARK” appears on the
monitor, and the REC/ERASE indicator flashes.
MARK button
REC/ERASE indicator
ENTRY button
LIST button
All of the shot mark types for which item G02 in the
shot mark operation menu is set to “ON” appear in the
list. If you do the same operation again, the list display
disappears.
While the shot mark list is displayed, the function
menu display changes as follows.
SHT
MRK
SETING EXITMEMO SELECT DELETE
6-4 Chapter 6 Shot Mark Function
Example of list display
The following figure shows how the list is organized.
Shot mark number of current cursor
position / total number of stored shot
marks
Separator
between read-in
groups of shot
marks
Cursor (current
shot mark position)
Position in list
SHOT MARKER
(011/180)
NO. TIME CODE
---------------------------*011 S1 10:04:05:11
012 R 10:05:35:24
013 V 10:07:05:02
--------------------------- 014 R 10:08:35:04
015 S2 10:09:05:11
016 R 10:10:35:24
017 #R 10:10:36:00
Time code
Shot mark type
R: recording start mark
S1: shot mark 1
S2: shot mark 2
V: virtual shot mark
P: post mark
#: memo mark
A virtual shot mark appears on the monitor as “V-
MARK xxx” (xxx is the number). This is not written to
the tape.
After entering a virtual shot mark, if you change the
cassette or power the unit off, it appears in the list as
the first shot mark of the next group read in.
Adding a memo mark (#)
Select the shot mark to which you wish to add the
memo mark, then press the F1 (MEMO) button.
Repeat this operation to remove a memo mark.
Selecting the types of shot mark to be
read in the list
For each of the types of shot mark (recording start
mark, shot mark 1, shot mark 2, and post mark) you
can specify whether it is read in.
In item G02 of the shot mark operation menu, set the
required types to “ON”.
Selecting a shot mark
Turn the MULTI CONTROL knob to align the asterisk
cursor with the desired shot mark.
Entering virtual shot marks
When the REC/ERASE indicator is off, hold down the
ENTRY button and press the MARK button.
Z
ENTRY button
MARK button
For details of the menu, see page 6-2.
You can also use the following procedure.
1 With the shot mark list displayed, press the F5
(SETING) button.
You can now select the shot mark types.
The function menu display changes as follows.
SHT
MRK
EXITPREV NEXT OFF ON
2 Press the F1 (PREV) or F2 (NEXT) button to
select a shot mark type.
3 Press the F4 (ON) or F3 (OFF) button to switch
between ON (displayed) and OFF (not displayed).
4 To return to the shot mark list, press the F6 (EXIT)
button.
Deleting a shot mark from the list
To delete a shot mark or the shot mark list, you can use
the F2 (SELECT) button instead of the MARK button,
and the F3 (DELETE) button instead of the DELETE
button.
Chapter 6
Shot Mark Function
Chapter 6 Shot Mark Function 6-5
6-3 Shot Mark Operations
To delete an individual shot mark
Use the following procedure.
1 With the shot mark list displayed, select the shot
mark to be deleted using the MULTI CONTROL
knob.
2 Hold the MARK button down.
While you hold down the button, an “X” appears
after the selected shot mark number, indicating that
Chapter 6
Shot Mark Function
it will be deleted.
To delete more than one shot mark, while holding
down the MARK button turn the MULTI
CONTROL knob to select all of the shot marks.
Z
312
1 With no shot mark list displayed, hold the MARK
button down for at least 2 seconds.
The REC/ERASE indicator lights, indicating that
you can rewrite or erase shot marks.
2 Display the shot mark list.
3 Turn the MULTI CONTROL knob to select on the
list the shot mark you wish to erase.
4 Press the DELETE button and MARK button
simultaneously.
During the erasure process the message “ERASE
SHOT MARK” appears, and the REC/ERASE
indicator flashes.
5 When the shot mark has been erased, close the shot
mark list.
6 Hold down the MARK button for at least 2
seconds, to turn off the REC/ERASE indicator.
6-3-4 Cueing Up to Shot Marks
3 With the MARK button held down, press the
DELETE button.
This deletes the shot marks which were marked by
an “X”.
To delete the entire list
Hold down the DELETE button and press the LIST
button.
This deletes all shot marks from the list. This does not
erase marks from the tape.
Erasing shot marks from the tape
To erase a shot mark, use the following procedure.
Note
Once you erase a shot mark from the tape, it cannot be
read back in.
Cueing up to a selected shot mark
Use the following procedure.
Z
MARK button
12
F FWD button
REW button
1 Select the desired shot mark from the shot mark
list.
6-6 Chapter 6 Shot Mark Function
2 Press the PREROLL button.
Cueing up to shot marks adjacent to the
current tape position (index function)
1 In item G01 of the shot mark operation menu
(page 6-2), select one of recording start mark, shot
mark 1, shot mark 2, and post mark, or select all.
The tape is played back, and the shot data displayed.
To delete the shot data
Once again hold down the ENTRY button, and press
the PLAY button.
2 Holding down the MARK button, press the F FWD
button or REW button.
While the tape is moving the F FWD button or
REW button flashes.
When the shot mark is detected, its type is
displayed in time data display area 2 on the
lower control panel and in the character
information display on the monitor screen.
For details of character information display on the
monitor screen, see F4 (CHARA) in function menu page
4 (page 8-7) and setup menu item 005 (page 9-5).
Note
You cannot use the above procedure to cue up to a
virtual shot mark.
6-3-5 Reading In Shot Data
Example of shot data display
The shot data display appears as shown below.
MODEL NAME DNW 0090
SERIAL NUMBER 010001
DATE 1998.05.11
TIME 12.55.10
CASSETTE NUMBER 0095
SHOT NUMBER 0052
ID1 AAAAAAAAAAAA
Camera IDs
Recording
time code
ID2 BBBBBBBBBBBB
ID3 CCCCCCCCCCCC
ID4 DDDDDDDDDDDD
TCR 23:59:59:29
The details in the shot data depend on the shooting
conditions. If because of the devices used there is no
shot data on a part of the tape, it appears as blank.
Displaying the shot data on the shot mark
list
Chapter 6
Shot Mark Function
When there is shot data (time, device, and other
information about the shooting) written on the tape,
you can read it in and display it on the monitor.
Displaying the shot data
Holding down the ENTRY button, press the PLAY
button.
Z
PLAY button
ENTRY button
Turn the MULTI CONTROL knob to position the
cursor on a separator in the shot mark list.
If there is shot data recorded when the immediately
following shot mark was written, it appears in the
display as shown below.
Model name (4 characters)
Model number (4 digits)
Serial number (6 digits)
SHOT MARK
Shot data
First shot
mark in the
group
(---/180)
NO. TIME CODE
*012345-DNW_-0123-4567011 S1 10:04:05:11
012 R 10:05:35:24
013 V 10:07:05:02
---------------------------014 R 10:08:35:04
015 S2 10:09:05:11
016 R 10:10:35:24
017 R 10:10:36:00
You can sort the shot marks in the list, based on the shot
data. For details, see the next section.
Cassette number (4 digits)
Chapter 6 Shot Mark Function 6-7
6-3 Shot Mark Operations
6-3-6 Sorting Shot Marks
Based on shot data recorded on the tape, you can
separate the shot marks by cassette, and sort them in
time code sequence.
To sort the shot marks
Use the following procedure.
Chapter 6
Shot Mark Function
Cassette 2 (first time)
Cassette 2 (second time)
Z
Cassette 1
Cassette 3
321
Before sorting
SHOT MARKER
(---/180)
NO. TIME CODE
*012345-DNW_-0123-4567011 S1 10:04:05:11
---------------------------012 V 10:07:05:02
013 R 10:08:35:04
---------------------------014 S2 10:09:05:11
015 R 10:10:35:24
016 R 10:10:36:00
---------------------------017 R 10:05:35:24
1 With the shot mark list displayed, press the F5
(SETING) button.
2 Press the F2 (NEXT) button, and select SORTING
LIST.
3 Press the F4 (ON) button to change the setting to
ON.
Sorting starts. When it ends, the setting indication
returns to OFF.
For example, if shot marks have been read in twice
from the same cassette, these can be collated as shown
in the following figure.
After sorting
SHOT MARKER
(---/180)
NO. TIME CODE
*012345-DNW_-0123-4567011 S1 10:04:05:11
---------------------------012 S2 10:09:05:11
013 R 10:10:35:24
014 R 10:10:36:00
---------------------------015 R 10:05:35:24
016 V 10:07:05:02
017 R 10:08:35:04
Cassette 1
Cassette 3
Cassette 2 (first and second
times)
6-8 Chapter 6 Shot Mark Function
Shot marks from the cassette 2 read in twice are
collated, and arranged in time code sequence.
7-1 Overview of Tele-File Functions
Chapter 7 Tele-File
Tele-File is a non-contact data carrier system.
Tele-File increases the efficiency of data management
and operations such as recording, playback, and
editing by enabling information to be exchanged
between VTRs with data reading and writing functions
and cassettes with Tele-File labels.
Memory label
Newly developed IC
The Tele-File system employs a newly developed
memory IC with the following features.
• Thin design: With a thickness of 0.5 mm, the IC can
be attached to cassettes as a memory label.
• Memory capacity: 1 KB/8 KB (user area,
rewritable)
• Data transfer speed: 100 kbps
• Security functions: Reading and writing
authorization can be controlled through multiple
passwords and permission settings.
Data management in clip units
In Tele-File, data is managed in units called “clips.” A
clip consists of the following data items, whose
settings can be displayed and changed.
• Cue point
• Write protect
• Mark
• Recording start point
• IN point
• OUT point
• Take number
• Cut number
• Scene number
• Comment
Data library management with handy
reader/writer
An optional handy reader/writer (supporting Memory
Stick) is available to facilitate data library
management.
Chapter 7 Tele-File
Chapter 7 Tele-File 7-1
7-2 Opening the Tele-File Menu
Opening from the function menu
Display page 5 of the function menu in the menu
display section, and then press the F1 (TELE-F)
button.
The Tele-File menu opens.
For details about the function menu, see Chapter 8
“Function Menu” (page 8-1).
Opening automatically
When setup menu item 134 is set to ON, and when the
current function menu page is HOME, HOME2, or
page 1 to page 5, the Tele-File menu opens
automatically whenever a Tele-File label is detected on
a cassette loaded into the VTR.
For details about setup menu item 134, see Section 9-4
“Items in the Extended Setup Menu” (page 9-4).
Configuration of the Tele-File menu
The Tele-File menu has a tree structure, as illustrated
below.
When the menu first opens, the menu operation mode
is clip data display mode.
[Tele-File menu]
Clip data display mode
Attribute data display/
modify mode
Clip data modify mode
Undo check mode
Chapter 7 Tele-File
7-2 Chapter 7 Tele-File
7-3 Tele-File Menu
7-3-1 Clip Data Display
How to read the display
Shown below are examples of the default menu
displays in the menu display section and the monitor
display.
Menu display section
Tele-File menu indicator
Data type indicator
Setting display area
TEL
Cue
SELECT
ATTRIB
E-F
HOME
Monitor display
F1 F2 F3 F4 F5 F6
Menu items (functions)
For more information about how to display menus on the
monitor, see the section “To display menus on the monitor”
(page 9-2).
UNDO WR/EXT
Title
Final data recording date
Data type
Clip No. 0001
Clip No. 0002
Clip No. 0003
·
·
·
TELE-FILE : TEST 01
2001/07/21 No. 0001 48%
Cue Point WP Mark R
*00:00:02:10 ON KEEP @
00:00:31:10
00:00:57:10
Number of selected clip
Remaining memory percentage
a) The Tele-File memory always contains the attribute data so that this indication never shows “100%.”
Tele-File menu indicator
Indicates that the menu display section is currently
displaying the Tele-File menu.
display mode. There are the following types.
Cue: Cue point
Protct: Write protected
Mark: Mark
Data type indicator
Indicates the type of data selected with the clip data
R-Strt: Recording start point
IN: IN point
OUT: OUT point
Take: Take number
Cut: Cut number
Scene: Scene number
Comnt: Comment
a)
Chapter 7 Tele-File
Chapter 7 Tele-File 7-3
7-3 Tele-File Menu
Chapter 7 Tele-File
Setting display area
Displays the setting of the currently selected data type,
and a cursor (“*” or “>”).
The meaning of the cursor symbols is as follows:
*: Indicates that the mode is clip data display mode or
Menu items (functions)
Display menu items (functions).
These are common for all of the data items in clip data
display mode. The function assignments for each item
are as follows.
attribute data display/modify mode, and that data is
selected.
>: Indicates that the mode is clip data modify mode or
attribute data display/modify mode, and prompts for
data entry or modification.
Clip data display mode menu items
Item name Function
F1 (ATTRIB)
F2 (SELECT) Selects a data modification mode for the data selected in the clip. The cursor changes from “*” to “>”.
F3 (T) Selects data in a clip.
F4 (t) Selects data in a clip.
F5 (UNDO) Selects undo check mode. This button appears and is enabled when data has been modified after being
F6 (WR/EXT) Writes data and exits from the Tele-File menu (return to function menu page 5).
Selects attribute data display/modify mode.
For details about attribute data display/modify mode, see Section 7-3-5 “Displaying and Modifying
Attribute Data” (page 7-11).
Note
In the following cases, the SELECT item does not appear, and it is not possible to select a data
modification mode.
• When setup menu item 133 is set to REMOTE
• When the memory label itself is write protected
For more information about clip data modifications, see Section 7-3-3 “Modifying Clip Data” (page 7-7).
With each press, the “*” cursor moves to select the previous data item. The display scrolls to the left
when the cursor moves to data that is not currently displayed.
With each press, the “*” cursor moves to select the next data item. The display scrolls to the right when
the cursor moves to data that is not currently displayed.
read from the Tele-File label.
For more information about undo check mode, see Section 7-3-4 “Undo/Resume Functions” (page 7-10).
7-4 Chapter 7 Tele-File
Title
2001/07/21 No. 0001 48%
Cue Point WP Mark R
TELE-FILE : TEST 01
00:00:02:10 *ON KEEP @
00:00:31:10
00:00:57:10
The title (maximum 14 characters) set in attribute data
display/modify mode.
Selected clip number
A 4-digit number representing the number of the
selected clip (with the “*” cursor).
Remaining memory percentage
The percentage of remaining memory (user area)
available for use.
If there is not sufficient free memory, the message <<
MEMORY FULL!!>> appears (stays lit for three
seconds) in time data display area 2 when you attempt
to add data.
Final data recording date
The data (year/month/day) on which data was most
recently recorded.
Data type
The data type. The displayed data is the same as the
data displayed in the menu display section, but some of
the captions are different. There are the following
types.
Cue Point: Cue point
WP: Write protected
Mark: Mark
R: Recording start point
IN Point: IN point
OUT Point: OUT point
Tk: Take number
Cut: Cut number
Scn: Scene number
Comment: Comment
Clip data No. 0001...
Data is displayed for 1 clip per line.
Clips are assigned continuous numbers, beginning with
No. 0001 for the clip on the top line.
To select clips
Rotate the MULTI CONTROL knob in clip data
display mode.
The data for the selected clip appears in the menu
display section, where it is selected.
In the monitor display, the “*” cursor moves up and
down as clips are selected.
Data which is not visible is selected and displayed
after scrolling.
TELE-FILE : TEST 01
2001/07/21 No. 0001 48%
Cue Point WP Mark R
Cursor
00:00:02:10 ON KEEP @
*00:00:31:10
00:00:57:10
To select data in a clip
In clip data display mode, press the F3 (T) or F4 (t)
button.
The “*” cursor moves and data is selected. Data which
is not visible is selected and displayed after scrolling.
(Scrolling)
Cursor
Chapter 7 Tele-File
Chapter 7 Tele-File 7-5
7-3 Tele-File Menu
Moving the cursor directly
Regardless of the cursor’s current position, pressing
one of the following buttons moves the cursor directly
to the specified position in the same clip and displays
the data.
IN (video IN point) button: IN point data
OUT (video OUT point) button: OUT point data
MARK button: Cue point data
To display the duration
Press the IN (video IN point) and OUT (video OUT
point) buttons simultaneously. The cursor moves to the
IN point data of the same clip, and the duration
appears while the buttons are held down. If there is no
IN point or OUT point data, the duration is displayed
as 0:00:00:00.
7-3-2 Preroll and Cue Up Using Clip Data
To cue up the cue point, IN point, or OUT
point
1 Select a clip.
2 Press the PREROLL button while holding down
the IN (video IN point), OUT (video OUT point),
or MARK button.
The unit exits from the Tele-File menu and cues up
the position of the data selected in step 2 (the cue
point position if the MARK button was pressed).
Note
The unit does not preroll if there is no data for the
selected point.
Chapter 7 Tele-File
In clip data display mode, you can use clip data to
preroll and cue up.
To preroll to the cue point, IN point, or
OUT point
1 Select a clip.
2 Select the cue point, the IN point, or the OUT
point.
3 Press the PREROLL button.
The unit exits from the Tele-File menu and prerolls
to the position of the selected data.
The preroll time is according to the setting of setup
menu item 001.
Note
The unit does not preroll if there is no data for the
selected point.
7-6 Chapter 7 Tele-File
7-3-3 Modifying Clip Data
To modify clip data, put the unit into clip data display
mode and then press the F2 (SELECT) button to put it
The function assignments for menu items in clip data
modification mode are as follows.
into clip data modification mode (the cursor changes to
“>”).
Clip data modification mode menu items
Item name Function
F1 (RETURN)
F2 (MODIFY) Changes the setting of the selected data, or makes a new setting.
F3 (DELETE) Deletes the data setting value. Enabled when cue point, IN point, OUT point, take number, cut number,
F4 (DEL LN) Deletes the selected clip.
F5 (INS LN) Inserts a clip at the cursor position.
HOME + F4
(DELETE ALL)
Returns to clip data display mode.
The function button changes according to the data type.
See the following for more information about how to set the various data types.
• Cue point, IN point, OUT point: “To set time code data” (page 7-8)
• Write protect, mark, recording start point: “To make write protect, mark, and recording start point
settings” (page 7-9)
• Take number, cut number, scene number: “To make take number, cut number, and scene number
settings” (page 7-9)
• Comment: “To make comment settings” (7-10)
scene number, or comment data is selected.
A confirmation message appears. Press one of the following buttons to confirm or cancel the operation.
• F1 (CANCEL): Cancels the deletion and returns to clip data display mode.
• F2 (OK): Executes the deletion and returns to clip data display mode.
A confirmation message appears. Press one of the following buttons to confirm or cancel the operation.
• F1 (CANCEL): Cancels the deletion and returns to clip data display mode.
• F2 (OK): Executes the deletion and returns to clip data display mode.
A confirmation message appears. Press one of the following buttons to confirm or cancel the operation.
• F1 (CANCEL): Cancels the insertion and returns to clip data display mode.
• F2 (OK): Executes the insertion and returns to clip data display mode.
Deletes all clips.
A confirmation message appears. Press one of the following buttons to confirm or cancel the operation.
• F1 (CANCEL): Cancels the deletion and returns to clip data display mode.
• F2 (OK): Executes the deletion and returns to clip data display mode.
Chapter 7 Tele-File
Chapter 7 Tele-File 7-7
7-3 Tele-File Menu
To add and delete clips
To add clips
1 Rotate the MULTI CONTROL knob to move the
“*” cursor to the position where you want to insert
the clip.
2 Press the F2 (SELECT) button.
The unit enters clip data modification mode.
3 Press the F5 (INS LN) button.
A confirmation message “INSERT CLIP OK?”
appears.
4 Press the F2 (OK) button.
The clip is added at the position to which you
moved the cursor in step 1.
To delete clips
To set time code data
Proceed as follows to make or change settings for cue
point, IN point, and OUT point data.
1 Select a clip.
2 Select cue point, IN point, or OUT point.
3 Press the F2 (SELECT) button.
The unit enters clip data modification mode.
4 Press the F2 (MODIFY) button.
The two most significant digits begin to flash, and
the data can be set or modified.
5 Press the F3 (T) or F4 (t) button until the digit
that you want to set starts flashing.
6 Rotate the MULTI CONTROL knob to make the
setting.
Chapter 7 Tele-File
1 Select the clip to delete.
2 Press the F2 (SELECT) button.
The unit enters clip data modification mode.
3 Press the F4 (DEL LN) button.
A confirmation message “DELETE THIS CLIP
OK?” appears.
4 Press the F2 (OK) button.
The clip selected in step 1 is deleted.
To display the offset from the previous setting
value
The offset is displayed as long as you hold down
the F2 (OFFSET) button.
7 Repeat steps 5 and 6 until you have set all the
required digits.
8 Press the F5 (SET) button.
The setting is confirmed and the unit returns to clip
data display mode.
To cancel the setting or modification and return
to clip data display mode
Press the F1 (CANCEL) button.
7-8 Chapter 7 Tele-File
To set the set or modified data as other time
data
Press the F6 (SET TO) button and select the time
data (cue point, IN point, or OUT point), and then
press the F5 (SET) or F6 (SET NL) button. The
position where the data is set differs as follows,
depending on the button pressed.
• F5 (SET): The data is set in the selected time
data position.
• F6 (SET NL): A new clip is added at the lowest
line and the time data is set at the selected data
position in the new clip.
To make take number, cut number, and
scene number settings
Proceed as follows to make take number, cut number,
and scene number settings.
1 Select a clip.
2 Select take number, cut number, or scene number.
3 Press the F2 (SELECT) button.
The unit enters clip data modification mode.
To make write protect, mark, and
recording start point settings
Proceed as follows to make write protect, mark, and
recording start point settings.
1 Select a clip.
2 Select write protect, mark, or recording start point.
3 Press the F2 (SELECT) button.
The unit enters clip data modification mode.
4 Press the F2 (MODIFY) button.
The data entry area begins to flash, and the data
can be set.
5 Select the data by pressing the F3 (+) or F4 (−)
button or rotating the MULTI CONTROL knob.
6 Press the F2 (SET) button.
4 Press the F2 (MODIFY) button.
The most significant digit begins to flash, and the
data can be set.
5 Press the F3 (T) or F4 (t) button until the digit
that you want to set starts flashing.
6 Rotate the MULTI CONTROL knob to make the
setting.
7 Repeat steps 5 and 6 until you have set all the
required digits.
8 Press the F2 (SET) button.
The setting is confirmed and the unit returns to clip
data display mode.
Chapter 7 Tele-File
The data setting is confirmed and the unit returns
to clip data display mode.
Chapter 7 Tele-File 7-9
7-3 Tele-File Menu
To make comment settings
Proceed as follows to make comment settings.
1 Select a clip.
2 Select comment.
3 Press the F2 (SELECT) button.
The unit enters clip data modification mode.
4 Press the F2 (MODIFY) button.
The data entry area begins to flash, and the data
can be set.
5 Enter a character by rotating the MULTI
CONTROL knob.
6 Press F4 (t) button to move to the next character
place.
7-3-4 Undo/Resume Functions
Undo function
The undo function cancels all modifications and
returns the data to the state it was in when first read.
Press the F5 (UNDO) button in clip data display mode.
A confirmation message appears. Press the F2 (OK)
button to execute the undo and cancel all modifications
to the data.
Resume function
If you have not modified any data since the last
execution of the undo function, you can press the F5
(UNDO) button again. The button functions as a
resume button, which cancels the immediately
preceding undo.
Press the F5 (UNDO) button in clip data display mode.
A confirmation message appears. Press the F2 (OK)
button to execute the resume and cancel the
immediately preceding undo.
Chapter 7 Tele-File
7 Repeat steps 5 and 6 until you have entered the
entire comment.
To delete characters
Press the F3 (T) or F4 (t) button until the
character that you want to delete starts flashing,
and then press the F5 (DELETE) button.
To insert characters
Press the F3 (T) or F4 (t) button until the
character place after the place where you want to
insert starts flashing, and then press the F6
(INSERT) button.
8 Press the F2 (OK) button.
The comment is confirmed and the unit returns to
clip data display mode.
7-10 Chapter 7 Tele-File
7-3-5 Displaying and Modifying Attribute Data
You can display and modify attribute data. The
example below shows attribute data displayed on the
monitor.
Video final recording date
Administrator data
Number of cue points
Memory size
Amount of memory used
TELE-FILE INFORMATION
*REC DATE 2001/07/21
TITLE TEST 01
ID
ADMIN
MODEL
SERIAL 00000
WRITE INHIBIT OFF
THREAD COUNT 00012
CUE POINT No. 0003
CONTROL MODE panel
SIZE 01024 USED 0270
Video final recording date
The most recent date (year/month/day) on which video
was recorded on the tape.
Title
The title (name assigned to Tele-File, etc., maximum
24 characters).
The title can be modified.
ID
The ID (unique number assigned to Tele-File,
maximum 24 characters).
The ID can be modified.
Administrator data
Data about the administrator of the cassette or tape
material (maximum 16 characters).
The administrator data can be modified.
Model name
The model name of the VTR that recorded most
recently to the tape.
Serial number
The serial number of the VTR that recorded most
recently to the tape.
Write inhibit setting
Whether the entire Tele-File is write inhibited.
The write inhibit setting can be modified.
Chapter 7 Tele-File
Thread count
The thread count value recorded on the tape.
Number of cue points
The number of cue points recorded in the Tele-File.
You can check the cue point values in clip data display
mode.
Control mode
The setting of menu item 133.
For more information about menu item 133, see page 9-10.
Memory size
The size of the memory in the Tele-File (unit: bytes).
Amount of memory used
The amount of memory currently being used (unit:
bytes).
Chapter 7 Tele-File 7-11
7-3 Tele-File Menu
To modify attribute data
You can modify the title, ID, administrator data, and
write inhibit setting attributes.
However, the attributes cannot be modified when the
write inhibit setting is ON. Proceed as follows after
setting the write inhibit setting to OFF.
1 Rotate the MULTI CONTROL knob to select the
item.
The F2 (SELECT) button is enabled when you
select an item that can be modified (title, ID,
administrator data, and write inhibit setting).
2 Press the F2 (SELECT) button.
The data can be set or modified.
3 Rotate the MULTI CONTROL knob to set or
modify the data..
2 Press the F2 (OK) button.
All modifiable data is erased.
Note
In the following cases, the FORMAT item does not
appear, and it is not possible to select a data
modification mode.
• When setup menu item 133 is set to REMOTE
• When the memory label itself is write protected
Chapter 7 Tele-File
4 Press the F2 (SET) button.
The change to the setting is confirmed.
Note
In the following cases, the SELECT item does not
appear, and it is not possible to select a data
modification mode.
• When setup menu item 133 is set to REMOTE
• When the memory label itself is write protected
To format the Tele-File memory
You can format the Tele-File memory (erase all
modifiable data). However, the memory cannot be
formatted in the following cases.
• When the write inhibit setting is ON
• When the control protocol is “remote”
To format Tele-File memory, proceed as follows.
1 Press the F4 (FORMAT) button.
A confirmation message appears.
7-12 Chapter 7 Tele-File
8-1 Overview
Chapter 8 Function Menu
The function menu allows you to make frequently
made settings, such as selection of input video signals
and time code settings.
8-1-1 Function Menu Configuration
The function menu consists of six pages by factory
default: the HOME page and five pages numbered 1 to
5. You can also display the HOME2 page by setting
user-defined function keys. The following icons appear
at the left edge of the menu display section to denote
the current page.
: HOME page
1
: Page 1
1
: Page 2
2
: Page 3
3
: Page 4
4
: Page 5
5
: Page 6
6
: HOME 2 page
2
Each page has a menu display section made up of an
upper and lower part. The upper part displays the
menu items (functions) in the page, and the lower part
displays the menu item settings. The figure below
shows the menu display section in the HOME page.
HOME2 page (user-defined function keys)
Up to six function keys can be defined (i.e. six
functions can be assigned to the F1 to F6 buttons in the
HOME2 page).
You can select and define the following function keys:
• Functions selected from the function menu items in
the HOME page and menu pages 1 to 4
• Function key to display the setting for setup menu
item 211 (REMOTE1 PORT) and to carry out the
operation when the menu item setting is “panel”.
Note
By factory default, no function keys are defined in the
HOME2 page.
It is not possible to display the HOME2 page unless
you have defined at least one function key in that page.
For details on defining user-defined function keys in the
HOME2 page, refer to the Maintenance Manual Volume 1.
Page 6
You can define up to six setup menu items (assign six
setup menu items to the F1 to F6 buttons) and register
them on page 6.
Note
There is nothing defined on page 6 when the unit is
shipped from the factory.
Menu items (functions)
VID. IN PB/EE CONFI CTL/TC
HOME F1 F2 F3 F4 F5 F6
PB
Y-R,B
Settings (values)
OFF TC
MENU
TCGSET
In the figure above, Y-R,B (analog component signals)
is selected as the setting for VID.IN, the menu item for
button F1. This manual refers to this as “F1 (VID.IN)
in function menu HOME page is set to Y-R,B.”
For more information about defining setup menu items for
page 6, refer to Volume 1 of the Maintenance Manual.
Chapter 8 Function Menu 8-1
Chapter 8 Function Menu
8-1 Overview
8-1-2 Using the Function Menu
To change a menu item setting
To change a menu item setting, press the
corresponding function button (F1 to F6) to display the
desired setting in the lower part of the menu display.
Each press of the button displays the next setting.
When a menu item setting flashes
Menu item settings flash to inform you that you can
change the setting value by rotating the MULTI
CONTROL knob.
To change the function menu page
Press either of the page buttons (V, v).
• The V button selects the next page in the order
HOMEt1t2t3t4t5tHOME...
• The v button selects the next page in the order
HOMEt5t4t3t2t1tHOME...
When there are setup menu definitions on page 6, page
6 is displayed between page 5 and the HOME page.
With one of menu pages 1 to 5 displayed, pressing the
HOME button changes the page to the HOME page.
Pressing the HOME button when the HOME or
HOME2 page is displayed changes the page to
HOME2 or HOME, respectively.
Chapter 8 Function Menu
Settings which do not appear in the menu
display section
In the HOME page (see the figure in “8-1-1 Function
Menu Configuration”), the settings for F5 (MENU)
and F6 (TCGSET) do not appear in the menu
display.When you press the F5 or F6 button, the whole
menu page changes to allow you to set these items.
8-2 Chapter 8 Function Menu
8-2 Function Menu Item List
The function menu has the following items.
HOME page
Item
F1 (VID.IN) Selects the input video signal.
Setting
COMPST: Analog composite signal
Y-R,B: Analog component signal
SDI: SDI signal
SDTI: SDTI-CP signal
SG (normally not displayed): Test signal from the internal test signal generator
(For details, see setup
menu item 710 on page 8-19.)
F2 (PB/EE) Selects the video and audio signals output during fast forward, rewind, stop, and standby.
PB: Playback signals
EE: E-E mode signals
F3 (CONFI) Selects whether or not to use the CONFI playback function when recording.
ENABLE: Use the CONFI playback function.
DISABL: Do not use the CONFI playback function.
F4 (CTL/TC) Selects the time data to display in time data display area 1
TC: Playback time code read by the internal time code reader, or recording time code. The LTC or VITC
time data type indicator
UB: User bits data of playback time code or recording time code. The LUB or VIUB time data type indicator
lights, depending on whether the time code is LTC or VITC.
CTL: The running time of the tape being played back or recorded, as calculated from a count of CTL
signals recorded on the tape. The time is displayed in Hours:Minutes:Seconds:Frames format.
F5 (MENU) Puts the system into setup menu mode
F6 (TCGSET)
When the current setup menu settings are the same as the contents of any of menu banks 1 to 3, or the
factory defaults, the corresponding indication (1), (2), (3), or (dflt) appears.
(1): Same as menu bank 1.
(2): Same as menu bank 2.
(3): Same as menu bank 3.
(dflt): Same as factory defaults.
• When F4 (CTL/TC) is set to TC, a screen appears that allows you to set the initial value of the time code
generated by the internal time code generator
• When F4 (CTL/TC) is set to UB, a screen appears that allows you to set the time code user bits
page 4-3)
.
(see page 2-7)
(see Chapter 8)
b)
lights.
(see page 4-3)
(see page 2-7)
b)
.
.
a)
.
Chapter 8 Function Menu
(see
a) When an editing operation is carried out, CONFI playback is disabled.
b) The selection of LTC or VITC depends on the setting of F6 (TCR) in function menu page 1 .
Chapter 8 Function Menu 8-3
8-2 Function Menu Item List
Page 1
Item Setting
F1 (TCG) Selects the time code to use.
F2 (TCG) For the internal time code generator, selects one of the following.
F3 (RUN) Selects one of the following running modes for the internal time code generator.
F4 (DF)
Chapter 8 Function Menu
F5 (VITC) Specifies whether or not to record the VITC generated by the internal time code generator.
F6 (TCR) Selects the type of time code to display in the time data display.
INT: Time code generated by the internal time code generator
EXT: One of the following time codes
• When F6 (TCR) is set to LTC or AUTO, the external time code input from the TIME CODE IN connector
• When F6 (TCR) is set to VITC, the VITC time code of the input video signal
RP188: Synchronize the internal time code generator with the SMPTE RP188 time code contained in the
SDI input signal.
CP-LTC: Synchronize the internal time code generator with the time code contained in the SDTI-CP input
signal.
.
Note
When the setting made with this menu item does not agree with the input video setting, the menu setting
flashes as a warning, as follows.
• When this menu item is set to RP-188 with F1(VID.IN) set to other than SDI in the HOME page, the
indication “RP188” flashes.
• When this menu item is set to CP-LTC with F1(VID.IN) set to other than SDTI in the HOME page, the
indication “CP-LTC” flashes.
Nevertheless, the unit operates in compliance with the setting of this menu item.
PRESET: Preset the initial value of time code generated by the internal time code generator by a control
panel operation, or by remote control from the device connected to the REMOTE1-IN(9P) connector.
REGEN: Synchronize the internal time code generator with the playback time code read by the internal
time code reader.
FREE: The time code continues to increase as long as the unit is powered on, regardless of the unit’s
operating mode.
REC: Time code increases during recording only. If you select this mode, you should also set F1 (TCG) to
INT, and set F2 (TCG) to PRESET.
In 525-line mode, selects either drop-frame mode or non-drop frame mode for the time code generator and
the CTL counter.
DF: Drop-frame mode
NDF: Non-drop frame mode
ON: Record internally generated VITC.
OFF: Do not record internally generated VITC.
LTC: Display LTC.
AUTO: Display VITC when tape speed is 1/2 or less of normal speed, and LTC otherwise.
VITC: Display VITC.
8-4 Chapter 8 Function Menu
Page 2
Item Setting
F1 (V.PROC) Selects the control method for the internal digital video processor.
LOCAL: Change the settings of the internal digital video processor by using this function menu.
REMOTE: Use the optional BVR-50/50P Remote Control Unit to control the internal digital video
processor.
MENU: Change the settings of the internal digital video processor by using the MENU of the HOME page.
F2 (VIDEO) Sets the video signal output level (–∞ to +3 dB).
PRESET: Regardless of manually values, the video signal is set to the standard level.
Manual setting: With the displayed setting flashing, you can rotate the MULTI CONTROL knob to adjust
the value for the video signal output level.
F3 (CHROMA) Sets the chroma signal output level (–∞ to +3 dB).
PRESET: Regardless of manually set values, the chroma signal is set to the standard level.
Manual setting: With the displayed setting flashing, you can rotate the MULTI CONTROL knob to adjust
the value for the chroma signal output level.
F4 (HUE) (525line mode)/
(C PHAS) (625line mode)
F5 (SETUP)
(525-line mode)/
(BLACK) (625line mode)
F6 (YC DLY) Sets amount of Y/C delay.
Sets the color phase (phase relative to burst)
PRESET: Regardless of manually set values, the color phase is set to the standard value.
Manual setting: With the displayed setting flashing, you can rotate the MULTI CONTROL knob to adjust
the value across the range ±30°.
Sets the setup level (525/60 mode) or black level (625/50 mode)
PRESET: Regardless of manually set values, the level is set to the standard value.
Manual setting: With the displayed setting flashing, you can rotate the MULTI CONTROL knob to adjust
the setup level across the range ±30 IRE (525/60 mode) or to adjust the black level across the range
±210 mV (625/50 mode).
PRESET: Regardless of manually set values, the Y/C delay is to the standard value.
Manual setting: With the displayed setting flashing, you can rotate the MULTI CONTROL knob to adjust
the Y/C delay across the range ±100 ns.
Chapter 8 Function Menu 8-5
Chapter 8 Function Menu
8-2 Function Menu Item List
Page 3
Item
F1 (SYNC) Sets the output signal sync phase.
F2 (SC) Sets the output signal subcarrier phase.
F3 (VIN LV) Sets the level of composite video signals input to the COMPOSITE VIDEO INPUT connectors.
F4 (EMPHSS) Specifies whether to add audio emphasis to analog audio input signals and Betacam/Betacam SP format
F5 (T INFO) Selects the type of time data to display in time data display area 2.
Setting
Setting method
With the displayed setting flashing, you can rotate the MULTI CONTROL knob to adjust the output signal
sync phase across the range ±15 µs relative to this unit’s input reference signal.
Adjust this item when you want to adjust the output signal sync phase precisely to match a reference
signal, or when connecting this unit and other VTRs to a device such as a switcher to perform operations
such as special effects editing.
Setting method
With the displayed setting flashing, you can rotate the MULTI CONTROL knob to adjust the output signal
subcarrier phase across the range ±200 ns relative to this unit’s input reference signal.
Adjust this item when you are using composite signals in editing and want to adjust the output signal
subcarrier phase precisely to match a reference signal. Even when this value is adjusted, the output SCH
(subcarrier to sync) phase is maintained.
AGC: Adjusts the level automatically.
Manual setting: With the displayed setting flashing, you can rotate the MULTI CONTROL knob to adjust
the level of composite video signals input to the COMPOSITE VIDEO INPUT connectors.
playback audio signals.
ON: Add audio emphasis.
OFF: Do not add audio emphasis.
TOTAL: Display total time.
REMAIN: Display remaining time.
Chapter 8 Function Menu
8-6 Chapter 8 Function Menu
Page 4
Item Setting
F1 (CAPSTN) Selects the number of fields for capstan lock in playback and editing.
In 525/60 mode
2F: The capstan servo locks in units of 2 fields.
• For tape output, color framing may not match the reference signal selected with the F2 (OUTREF).
• In assemble editing, color framing may be non-continuous at edit points.
When playing back a tape that was recorded with composite source signals, a vertical shift in the video
(H shift) occurs. (When setup menu item 712 is set to ON.)
4F: The capstan servo locks in units of 4 fields.
• For tape output, color framing matches the reference signal selected with the F2 (OUTREF).
• In assemble editing, color framing is continuous at edit points.
Even when playing back a tape that was recorded with composite source signals, no vertical shift in
the video (H shift) occurs. You should set this menu item to this setting when you are editing
composite signals, when continuity in video phase across edit points is required, and when you
perform A/B-roll editing.
In 625/50 mode
2F: The capstan servo locks in units of 2 fields.
• For tape output, color framing may not match the reference signal selected with the F2 (OUTREF).
• In assemble editing, color framing may be non-continuous at edit points.
When playing back a tape that was recorded with composite source signals, a vertical shift in the
video (H shift) occurs. (When setup menu item 712 is set to ON.)
4F: The capstan servo locks in units of 4 fields.
• For tape output, color framing may not match the reference signal selected with the F2 (OUTREF).
• In assemble editing, color framing may be non-continuous at edit points.
When playing back a tape that was recorded with composite source signals, a vertical shift in the
video (H shift) occurs. (When setup menu item 712 is set to ON.)
8F: The capstan servo locks in units of 8 fields.
• For tape output, color framing matches the reference signal selected with the F2 (OUTREF).
• In assemble editing, color framing is continuous at edit points.
Even when playing back a tape that was recorded with composite source signals, no vertical shift in
the video (H shift) occurs. You should set this menu item to this setting when you are editing
composite signals, when continuity in video phase across edit points is required, and when you
perform A/B-roll editing.
F2 (OUTREF) Selects the reference signal of this unit, according to the setting of setup menu item 309 and this unit’s
operating state.
REF: Use the signal input to the REF.VIDEO INPUT connector as the reference signal. During recording,
input digital audio signals and video signals must be synchronized with this signal.
INPUT: Use the input video signal selected in the F1 (VID.IN) of the HOME page as the reference signal.
F3 (DOLBY) When using oxide tapes, specifies whether or not to use the Dolby type C low-frequency noise reduction
(NR) system.
NR ON: Use the Dolby NR system when playing back analog Betacam oxide tapes.
NR OFF: Do not use the Dolby NR system when playing back analog Betacam oxide tapes.
F4 (CHARA) Specifies whether or not to superimpose time code, menu settings, error messages, and so on over the
video signals output to the 3 (SUPER) connector in the SDI OUTPUT connectors, and the 3 (SUPER)
connector in the COMPOSITE VIDEO OUTPUT connectors.
ON: Superimpose.
OFF: Do not superimpose.
(Continued)
Chapter 8 Function Menu
Chapter 8 Function Menu 8-7
8-2 Function Menu Item List
Item Setting
F5 (RECINH) Specifies whether or not to inhibit recording to tape.
ON: Inhibit recording to tape depending on the setting of setup menu item 310.
OFF: Do not inhibit recording to tape.
F6 (PREREAD) Specifies whether or not to preread (read before write) in insert editing.
ON: Preread depending on the setting of setup menu item 319.
OFF: Do not preread.
Page 5
Page 5 is assigned to the Tele-File menu.
For more information about the Tele-File menu, see Section
7-3 “Tele-File Menu” (page 7-3).
Chapter 8 Function Menu
8-8 Chapter 8 Function Menu
Loading...
