Sony MPK-DVF2 User Manual

Marine Pack
3-866-145-11 (1)
Operating Instructions Mode d’emploi Manual de instrucciones
US FR ES
MPK-DVF2
©1999 by Sony Corporation
WARNING
For the Customers in CANADA
DISPOSAL OF LITHIUM ION BATTERY.
LITHIUM ION BATTERY. DISPOSE OF PROPERLY.
You can return your unwanted lithium ion batteries to your nearest Sony Service Center or Factory Service Center. Note: In some areas the disposal of lithium ion
batteries in household or business trash may
be prohibited. For the Sony Factory Service Center nearest you call 416-499-SONY (Canada only) Caution:Do not handle damaged or leaking lithium
ion battery.
Owner’s Record
The model and serial number are located on the inside of the front shell. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product.
Model No MPK-DVF2 Serial No. _____________
2-US
Table of contents
MPK-DVF Table of contents 3
Features and Precautions ........................... 3
Checking supplied accessories .................. 6
Preparing ...................................................... 7
1 Preparing the camcorder ............... 7
2 Preparing the Marine Pack ........... 9
3 Attaching the camcorder to the
marine pack ................................... 10

Features and Precautions

• MPK-DVF2 can be used with the Sony Handycam Vision™ camcorder DCR-TRV7/ TRV8/TRV9/TRV10/TRV890/TRV900 .
• Recording at a depth of 75 meters (246 feet) is possible.
• The following operation can be performed underwater.
– Power on/off – Auto focusing on/off – Recording start/stop – Photo recording (DCR-TRV8/TRV9/TRV10/TRV890/TRV900 only) – Electric zoom function – Monitoring on the LCD screen
Recording .................................................... 13
When the LEAK lamp flashes ........... 14
Removing the camcorder ......................... 15
Note on the O-ring .................................... 16
Underwater recording .............................. 17
Labeling parts and controls...................... 18
Specifications.............................................. 19
US
This mark indicates that this product is a genuine accessory for Sony video products. When purchasing Sony video products, Sony recommends that you purchase accessories with this “GENUINE VIDEO ACCESSORIES” mark.
On the video camera recording
• Take care not to expose the equipment to salty air. Do not drop water on the equipment.
• Do not open the marine pack underwater or at the beach. Preparation such as installing and checking the equipment should be done in a place with low humidity and no salty air.
• When your camcorder is to be used near the sea for a long time, we recommend that it be checked periodically by Sony dealer.
• If the equipment becomes wet during use, take it immediately to the nearest Sony dealer for preventative maintenance.
• We recommend you use battery packs with a large capacity.
3-US
Features and Precautions
On the marine pack
• If you open and join the front and rear shells in a place with high temperature and high humidity, moisture condensation may occur when you put the marine pack in the water, causing the front glass to fog.
The waterproof integrity of the marine pack is maintained by the O-ring, and the groove and surface where it touches. Be especially careful not to damage or deform that area. For details, see “Note on the O-ring” (page 16).
• Do not leave the marine pack under direct sunlight for a long period of time, otherwise the temperature in the marine pack may rise and the equipment inside may be damaged. If you can not avoid leaving the marine pack under direct sunlight, be sure to cover the marine pack with a towel or other protection.
• Do not throw the marine pack into the water. Lower it gently into the water.
On recording underwater
• Checking that the equipment operates correctly and that there is no water leakage at a depth of about one meter (3 feet) before you dive deeper.
• Be sure to follow the safety rules for diving, such as diving period and depth.
• Remove the bubbles from the outside of the front glass before recording.
Sony dose not accept liability for damage to the video camera recorder, battery, etc. in the marine pack or for the loss of prerecorded material if a water leakage caused by incorrect operation occurs.
On maintenance
The metal parts will rust and the movement of the operation switches will be impaired if you leave salt water on the marine pack. If sea water enters through scratches in the coating, the salt can corrode the metal parts of the marine pack unit and cause the coating to peel off. After recording in the sea, submerge the marine pack in tap water or fresh water for about 30 minutes before undoing the buckles to completely remove any salt from the marine pack unit, filter and wide-conversion lens. After washing, wipe the water from the inside of the marine pack and the loaded video camcorder with a soft dry cloth. Always carry out the above when you use the marine pack. Do not use any type of solvent such as thinner, benzine or alcohol for cleaning, as this might damage the surface finish.
4-US
When you store the marine pack
• Coat the O-ring slightly with the supplied grease, and put it in the groove correctly. Join the front and rear shells then put in a cool and dry place without fastening the buckles.
• Prevent dust from collecting on the O-ring.
• Avoid storing the marine pack in a very hot, cold or humid place, or together with naphthalene or camphor, as these conditions might damage the unit.
After using the marine pack
• Insert the A/V connecting cable plug to the plug holder of the camera mounting shoe B.
• Insert the remote and microphone plugs to the plug holder inside of the front shell.
Features and Precautions
Using the supplied carrying bag
Attach the supplied carrying belt and adjust the length of the belt.
On transportation
• When transporting the marine pack, be sure to remove your camcorder from it.
• Avoid rough handling or a shock. We recommend to cover the marine pack with a towel or other protection.
US
5-US

Checking supplied accessories

Check that the following accessories are supplied with your sports pack.
123
B
456
789
0qaqs
qd qf qg
1 Camera mounting shoe A (1)
for DCR-TRV7
2 Camera mounting shoe B (1)
for DCR-TRV8/TRV9/TRV10/ TRV890/TRV900
3 Spacer for camera mounting shoe B
(1) for DCR-TRV8/TRV10
4 Screw plate for camera mounting
shoe B (1)
5 Screw driver part (1)
The screw driver part is installed in the camera mounting shoe B.
6 Battery cushion (1) 7 O-ring (1)
6-US
8 Grease (1) 9 NP-F330 battery pack for the LCD
monitor (1)
0 R6 (size AA) battery (2) qa Sunshade (1) qs Color filter (VF-MK2) (1) qd Reflex prevention ring (2)
Large: ø 37 mm (1) Small: ø 30 mm (1)
qf Underwater wide–conversion lens
(VCL-MK2) (1)
qg Carrying bag (1)
Carrying belt (1)
qh Strap (3)

Preparing

1 Preparing the camcorder

The DCR-TRV9 is the model used for illustration purposes. Otherwise, the model name is indicated in the illustrations. Any differences in operation are clearly indicated in the text, for example, “DCR-TRV9 only”. For details, please refer to the operating instructions supplied with your camcorder.
(1) Remove the lens cap, shoulder strap, conversion lens or filter from the
camcorder.
(2) Attach a charged battery pack. (3) Insert a cassette tape. (4) Attach the reflex prevention ring to the tip of the lens.
for DCR-TRV7/TRV9 : ø 37 mm (large) for DCR-TRV8/TRV10 : ø 30 mm (small) for DCR-TRV890/TRV900 : disuse
(5) Attach the camera mounting shoe A (for DCR-TRV7) or the camera mounting
shoe B* (for DCR-TRV8**/TRV9/TRV10**/TRV890/TRV900). Remove the metal part from the camera mounting shoe B and firmly attach the screw plate until the catch on the reverse side of the camera mounting shoe B clicks into place. For DCR-TRV8/TRV9/TRV10/TRV890/TRV900, connect the A/V connecting cable of the camera mounting shoe B to the camcorder’s AUDIO/VIDEO jack.
(6) Adjust the camcorder.
Cancel the following functions: BACK LIGHT,NightShot, PROGRAM AE and picture effect.
Camera mounting shoe A
Camera mounting shoe B
DCR-TRV7
1 DCR-TRV9 2 DCR-TRV890/TRV900 3 DCR-TRV8/TRV10
* To attach the camera mounting shoe B
Attach the screw plate to the camera mounting shoe B.
1
2
US F ES
Installing position of the screw plate
** Use the spacer supplied when you attach the camera mounting shoe B.
Spacer
B
Camera mounting shoe B
Installing position of the screw plate
Screw plate
3
7-US
Preparing
1
6
2 Select COMMANDER
to ON in the menu system.
4 Select V-OUT/LCD in the DISPLAY
menu, and press the DISPLAY button on your camcorder before attaching it to the marine pack.
DCR-TRV7
DCR-TRV8/TRV9/TRV10/TRV890/TRV900
5
Remove the metal part.
Fasten the screw.
3 Slide the AUTO LOCK
switch up.
1 Set the POWER switch
to CAMERA.
3 Slide FOCUS switch up
to AUTO.
8-US
2 Select COMMANDER
to ON in the menu system.
4 Select V-OUT/LCD in the DISPLAY
menu, and press the DISPLAY button on your camcorder before attaching it to the marine pack.
1 Set the POWER switch
to CAMERA.
Preparing

2 Preparing the Marine Pack

(1)Remove the grip. (2)Insert the dry batteries into the grip. (3)Unfasten the 3 buckles and open the marine pack.
If you lift the metal fitting in the direction of the finder when the buckles are open, the buckles will stop.
(4)Attach the supplied battery pack NP-F330 for the LCD monitor to the rear
shell. Be sure to charge the battery pack fully before attaching.
1
2
US F ES
1 Remove the screw
with something like a coin.
3
2 Insert the dry batteries with
the polarity positioned correctly as indicated on the grip.
4
3 Fasten the screw tightly.
The battery pack may come loose if dropped or subjected to impacts so insert the supplied battery cushion.
9-US
Preparing

3 Attaching the camcorder to the marine pack

The cords are placed in the plug holders of the marine pack at the factory. Pull the plugs out of the holders when in use.
(1) For DCR-TRV7 only, connect the monitor plug to AUDIO VIDEO jack. (2) Connect the remote plug to LANC
plug to MIC jack (plug in power) (1).
(3) Attach the camcorder.
Insert the camera mounting shoe until it clicks.
(4) For DCR-TRV8/TRV9/TRV10/TRV890/TRV900, connect the monitor cord to the
jack of camera mounting shoe B.
(5) Attach the front shell to the rear shell. Hold the both shells firmly and fasten 3
buckles securely.
Take care not to pinch the remote, microphone, and monitor cords. If this happens water may leak in.
(6) Attach the grip.
control (2) jack, and the microphone
Note
To prevent the cords from twisting or slacking, make sure that these plugs are inserted as the correct direction as the illusration.
10-US
Preparing
1
2
3
DCR-TRV7 only
to AUDIO VIDEO jack.
DCR-TRV7
DCR-TRV7 DCR-TRV8/TRV9/TRV10/TRV890/
2
1
Remove the monitor cord hook.
Once slide up, then pull.
DCR-TRV8/TRV9/TRV10/TRV890/ TRV900
US F ES
TRV900
11-US
12-US
Preparing
DCR-TRV8/TRV9/TRV10/
45
TRV890/TRV900
Now you ready for underwater recording. Be sure to check that there is no water leakage before you dive.
Tips for the LCD monitor
• The image does not appear on the LCD screen with only attaching the battery pack to the rear shell. The LCD screen is linked with the power of your camcorder.
• Remaining battery time displayed on the LCD screen refers to the time how many minutes the battery of camcorder lasts. It is not the remaining battery time of the LCD monitor.
Tips for the battery pack for the LCD monitor
The recording time is approximately 6 hours when you record continuously using the fully charged NP-F330. The actual recording time might be less than 6 hours since the potential recording time depends on the conditions of use.
Tips for the supplied battery pack NP-F330
• Use a separately purchased AC adapter/charger that can charge the NP-F330 battery pack supplied (the same AC adapter/charger that can be used to charge the NP­F550).
• The LCD monitor of the marine pack does not correspond with the “InfoLITHIUM” battery.
What is the “InfoLITHIUM” battery pack. The “InfoLITHIUM” battery pack is a lithium battery pack which can exchange data
with compatible video equipment about its battery consumption. When you use this battery pack with video equipment having the mark,
the video equipment will indicate the remaining battery time in minutes.* However, if you use it with video equipment not having this mark, the remaining battery capacity will not indicated in minutes.
* The indication may not be accurate depending on the condition and environment
which the equipment is used under.
Note on dry batteries
• With normal operation, dry batteries will last for about 6 months.
• If the marine pack is not used for long period of time, remove the batteries to avoid possible damage from the battery leakage.
• Do not try to recharge dry batteries.
• If a battery leak should develop, carefully and thoroughly wipe away battery fluid from the battery compartment before inserting new ones.
6

Recording

POWER switch
AUTO FOCUS ON/OFF button
REC lamp (red) LEAK lamp (yellow)
(1) Set POWER switch to ON. (2) Press START/STOP button to start recording.
REC lamp (red) lights up during recording.
To stop recording
Press START/STOP button.
To zoom
Press ZOOM button. Press T for telephoto (subject appears closer) and W for wide-angle (subject appears farther away). You cannot change the zooming speed of the camcorder.
PHOTO button
ZOOM button
START/STOP button
US F ES
Note on Photo recording (DCR-TRV8/TRV9/TRV10/TRV890/TRV900 only)
If you press PHOTO button when a still picture appears on the LCD screen or in the viewfinder, the camcorder will record that still picture. You cannot check the recorded picture by pressing PHOTO button lightly. For details, please refer to the operating instructions supplied with your camcorder. When you use DCR-TRV8/TRV10/TRV890/TRV900, the memory photo function does not work when your camcorder is placed in MPK-DVF2.
To keep a subject in focus
After you focus on a subject, press AUTO FOCUS ON/OFF button to set the camcorder to manual focus mode. Even if fish swim between the camcorder and the subject, you can still keep the subject in focus. Press AUTO FOCUS ON/OFF button again to set the camcorder to auto focus mode.
Note on before recording
Check that the equipment operates correctly and that there is no water leakage at a depth of about one meter (3 feet) before you dive deeper.
Note on recording
Do not cover the control emitter or detector with your finger because the remote control signal for operations is transmitted from the grip to the marine pack.
13-US
Recording
To attach the supplied wide-conversion lens
Attach the wide-conversion lens until it fits firmly. You can attach the wide-conversion lens both on land and underwater.
Note
This wide-conversion lens is to be used only underwater.
When using the supplied color filter, attach it on top of the wide-conversion lens.
Using the supplied sunshade
The supplied sunshade for the LCD monitor reduces glare from the LCD monitor. Attach the sunshade as shown in the illustration.
You can attach the wide-conversion lens, sunshade, and color filter underwater
If the image on the LCD screen is not clear because of the air remains between these accessories and the marine pack, reattach them underwater.
Note
Attach the supplied straps not to lose these accessories when removing them underwater.
Attach the sunshade until it fits firmly.
14-US
To attach the strap
After attaching the straps to these accessories, hook the loops of the straps to the grip of your marine pack.

When the LEAK lamp flashes

If water happen to leak in , the LEAK lamp (yellow) flashes.
LEAK lamp (yellow)
In such a case, remove the marine pack from the water as soon as possible, keeping it horizontal. Be sure to surface following the safety rules for diving. Dry the marine pack with a soft cloth and then open it. To switch off the lamp, disconnect the remote control cable. Check the cause of the leak. If the camcorder is wet, take it to the nearest Sony dealer immediately.
Color filter
Wide­conversion lens
Sunshade

Removing the camcorder

Before opening the marine pack, rinse it with fresh water and dry with a soft cloth.
Note
• When you open the marine pack, make sure you are dry. And take care that no water drips from your wet suit.
• When you open the marine pack, do not pull the monitor plug cord by force.
(1) Remove the grip. (2) Unfasten 3 buckles and open the marine pack.
For DCR-TRV8/TRV9/TRV10/TRV890/TRV900 , disconnect the monitor cord from the camera mounting shoe B.
(3) Take the camcorder out of the front shell.
Holding the camera mounting shoe by the knobs and extract the camcorder.
(4) Disconnect the remote plug and the microphone plug. (5) Disconnect the monitor plug (for DCR-TRV7 ), the A/V connecting cable of
camera mounting shoe B (for DCR-TRV8/TRV9/TRV10/TRV890/TRV900 ) from AUDIO/VIDEO jack. When you take the camcorder out of the shell, be careful not to pull the remote cord, microphone cord or A/V connecting cable.
(6) Remove the camera mounting shoe. (7) Remove the battery pack for the LCD monitor.
43
US F ES
5
6
DCR-TRV7 DCR-TRV8/TRV9/TRV10/TRV890/
TRV900
After using
B
15-US
Removing the camcorder
After using
• Insert the A/V connecting cable plug to the plug holder of the camera mounting shoe B.
• Insert the remote and microphone plugs to the plug holder inside of the front shell.

Note on the O-ring

The O-ring assures the waterproof function of the marine pack. To maintain waterproof integrity, use it correctly. Incorrect handling may cause water to leak in.
O-ring
Check the O-ring
Check that there are no scratches or cracks on the O-ring as they may allow water to leak in. If there are scratches or cracks, replace the damaged O-ring with a new one. Do not remove the O-ring from the groove with a metal tool or a tool with a sharp point.
16-US
Remove any dust, sand or hair from the O-ring.
Make sure there is no dust, sand or hair on the O-ring, in the groove, or on the surface of the marine pack where the O-ring touches. If there is, clean them completely, or the O-ring and the surface of the marine pack may be damaged and water may leak in.
Grease the O-ring
Check that there are no cracks or dust on the O-ring, then coat it slightly with the supplied grease using your finger. They will prevent wear. While applying the grease, recheck for cracks or dust. Never use cloth or paper to apply grease because the fibers may cling. Do not use any type of grease other than the supplied one, or it may damage the O-ring. If you run out of silicone grease (2-115-921-01) you can purchase it from your nearest Sony Service Center.
Do not twist the O-ring
Put the O-ring in the groove evenly. Never twist it.
Do not pinch the O-ring with the marine pack
When jointing the front and rear shells, take care not to pinch the O-ring between the front and rear shells. If this happens, not only will the O-ring be damaged, but water may leak in.
Useful life of the O-ring
Depending upon the maintenance and the length of use, we recommend changing the O-ring every one or two years.
The O-ring (3-977-362-01) can be replaced at your nearest Sony Service Center.

Underwater recording

Recording underwater is different from recording on land because it is affected by the clarity, depth of the water and the light condition. The following are hints for good recording underwater.
Color characteristic underwater
Water absorbs light, especially red light, so that objects in deep water are seen bluish. The color of objects is affected by the clarity of the water.
To record in natural color, use the supplied color filter.
Wide-conversion lens
Color filter
Best time for recording
The best recording time is from 10:00 a.m. to 2:00 p.m. When the sun its highest, optimum results can be obtained.
Subject size underwater
Since the refractive index underwater is higher than that in air, an object appears 1/4 more closer, and therefore larger. This phenomenon affects the lens on the camcorder as well as human eye. Using the supplied wide-conversion lens is recommended.
Camera work on slow and stable motion
When recording, keep your body stable. An unstable shot will be magnified on the TV screen. Move the camcorder as slow as
possible. As most of the object underwater move, you can record a good program without moving the camcorder.
Underwater video light
In deep water or under locks where direct sunlight does not reach, recording with an underwater video lights is recommended.
To record at night, use a powerful underwater video light.
Attachable to the both sides of video light shoe.
Underwater video light such as Sony HVL-ML20 (not supplied)
US F ES
Note on recording underwater
• Be sure to follow the safety rules for diving, such as diving period and depth.
• Remove the bubbles from the outside of the front glass before recording.
17-US
Loading...
+ 39 hidden pages
