Sony KV-14LM1U User Manual

4-205-569-32(1)
R
FD Trinitron Colour Television
Instruction Manual
KV-14LM1U
© 2000 by Sony Corporation
GB
NOTICE FOR CUSTOMERS IN THE UNITED KINGDOM
A moulded plug complying with BS1363 is fitted to this equipment for your safety and convenience. Should the fuse in the plug supplied need to be replaced, a 5 AMP fuse approved by ASTA or BSI to BS 1362 (i.e. marked with 2 or @) must be used. When an alternative type of plug is used it should be fitted with a 5 AMP FUSE, otherwise the circuit should be protected by a 5 AMP FUSE at the distribution board. If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.
How to replace the fuse
Open the fuse compartment with a blade screwdriver, and replace the fuse.
IMPORTANT
If the plug supplied is not suitable for the socket outlets in your home, it should be cut off and an appropriate plug fitted in accordance with the following instructions: The wires in this mains lead are coloured in accordance with the following code: Blue Neutral Brown Live As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. Do not connect either wire to the earth terminal in the plug which is marked by the letter E or by the safety earth symbol or coloured green or green and yellow.
WARNING
• To prevent shock hazard, do not insert the plug cut off from the mains lead into a socket outlet. This plug cannot be used and should be destroyed.
• To prevent fire or shock hazard, do not expose the unit to rain or moisture.
• Dangerously high voltages are present inside the set. Do not open the cabinet. Refer servicing to qualified personnel only.
2
Introduction
Thank you for choosing this Sony FD Trinitron Colour Television.
Before operating the TV, please read this manual thoroughly and retain it for future reference.
• Symbols used in the manual:
Informs you of possible hazards.
Important information
Information on a feature.
1,2... Sequence of instructions.
MENU
Shaded buttons on the remote control show you the buttons you have to press to follow
K
the sequence of the instructions.
Informs you of the result of instructions.
Table of Contents
Notice for Customers in the United Kingdom....................................................................................2
Introduction.............................................................................................................................................. 3
Safety Information................................................................................................................................... 4
Overview
Overview of Remote Control Buttons .................................................................................................. 5
Overview of TV Buttons ........................................................................................................................6
Installation
Inserting Batteries into the Remote Control ........................................................................................ 6
Connecting an Indoor Aerial ................................................................................................................7
Connecting an Outdoor Aerial and VCR ............................................................................................7
GB
First Time Operation
Switching On the TV and Automatically Tuning ..............................................................................8
Menu system
Introducing and Using the Menu System..........................................................................................10
Menu Guide ........................................................................................................................................... 10
Additional Information
Connecting Optional Equipment ........................................................................................................ 16
Using Optional Equipment .................................................................................................................. 16
Specifications.......................................................................................................................................... 17
Troubleshooting..................................................................................................................................... 18
Television Channel Number Guide for United Kingdom............................................................... 19
Table of Contents
3
Safety Information
This set is to operate on a 220­240V AC supply only. Take care not to connect too many appliances to the same power socket as this could result in fire or electric shock.
Do not open the cabinet and the rear cover of the TV. Refer to qualified service personnel only.
Do not cover the ventilation openings of the TV For ventilation, leave a space of at least 10cm all around the set.
For environmental and safety reasons, it is recommended that the TV set is not left in standby mode when not in use. Disconnect from the mains.
For your own safety, do not touch any part of the TV, power lead or aerial lead during lightning storms.
Never place the TV in hot, humid or excessively dusty places. Do not install the TV where it may be exposed to mechanical vibrations.
Never push objects of any kind into the set as this could result in a fire or electric shock. Never spill liquid of any kind on the set. If any liquid or solid object does fall through, do not operate the TV. Have it checked immediately by qualified personnel.
To prevent fire or shock hazard, do not expose the TV to rain or moisture.
To prevent fire, keep inflammable objects or naked lights (eg candles) away from the TV.
Clean the TV with a soft, lightly dampened cloth. Do not use benzine, thinner or any other chemicals to clean the TV. Do not scratch the TV screen. As a safety precaution, unplug the TV before cleaning it.
Place the TV on a secure stable stand. Do not allow children to climb on to it. Do not place the TV on its side or face up.
4
Safety Information
Pull out the power lead by the plug. Do not pull on the power lead itself.
Unplug the power lead before moving the TV. Avoid uneven surfaces, quick steps or excessive force. If the set has been dropped or damaged, have it checked immediately by qualified service personnel.
Take care not to place heavy objects on the power lead as this could result in damage. We recommend you wind any excess lead around the holders provided on the rear of the TV.
Do not cover the ventilation openings of the TV with items such as curtains or newspapers etc.
Overview of Remote Control Buttons
Muting the Sound
Press to mute TV sound. press again to restore the sound.
Displaying on Screen information
Press to display all on-screen indications. Press again to cancel.
Selecting channels
Press to select channels.
For double-digit programme numbers, e.g. 23, press -/-- first, then the buttons 2 and 3.
If you enter an incorrect first digit, this should be corrected by entering another digit (0-9) and then selecting
-/-- button again to enter the
programme number of your choice.
Selecting TV mode
Press to switch off video input.
This button does not work on this set.
This button does not work on this set.
Selecting Picture mode
Press repeatedly to change the picture mode.
Adjusting TV volume
Press to adjust the volume of the TV.
This button does not work on this set.
Selecting channels
Press to select the next or previous channel.
To Temporarily Switch Off TV
Press to temporarily switch off TV (the standby indicator on TV lights up). Press again to switch on TV from standby mode.
To save energy we recommend switching off completely when TV is not in use.
After 15 minutes without a signal and without any button
being pressed, the TV switches
1
2
4
5
7
8
0
automatically into standby
3
mode.
6
Selecting input source
Press repeatedly until the desired
9
input symbol of the source appears on the TV screen.
MENU
Back to the channel last watched
K
Press to watch the last channel selected (watched for at least 5 seconds).
Displaying the menu system
PROGR
Press to display the menu on the TV screen. Press again to remove the menu display from the TV screen.
Menu selection
Scroll Up
RM
889
S
Scroll Down Previous menu or selection Next menu or selection
OK confirms your selection
Selecting Screen format
Press to view programmes in 16:9 mode. Press again to return to 4:3 mode.
GB
Overview
5
Overview of TV Buttons
Programme Up or Down Buttons (Select TV channels)
Standby indicator
On/Off
switch
Video Input jack
Audio Input jack
Headphone
jack
Auto Start Up Button
Selecting Input source
Volume control buttons
Inserting Batteries into the Remote Control
Make sure to insert the supplied batteries using the correct polarities. Always remember you dispose of used batteries in an environmental friendly way.
6
Overview-Installation
