Sony KDL-50WF6, KDL-43WF6, KDL-43RF4 User Manual

Download

Television

Operating Instructions

4-729-423-11(1)

KDL-50WF6xx / 43WF6xx / 43RF4xx

Table of Contents

IMPORTANT NOTICE . . . . . . . . . . . . . . . . . . . . 3

Safety Information . . . . . . . . . . . . . . . . . . . . . 3

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Parts and Controls

TV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Remote Control . . . . . . . . . . . . . . . . . . . . 10

Connecting TV to the Internet

Setting up the Internet Connection . . . . 12

Type 1: Secured network with Wi-Fi

Protected Setup™ (WPS) . . . . . . . . . . . . . . . 12

Type 2: Secured network without Wi-Fi

Protected Setup™ (WPS) . . . . . . . . . . . . . . . 13

Type 3: Unsecured network with any type

of wireless LAN router . . . . . . . . . . . . . . . . . 13

Type 4: Wired network setup . . . . . . . . . . . 13

Preparing a Wired Network . . . . . . . . . . . . . 14

Viewing the Network Status . . . . . . . . . . . . 14

If You Cannot Connect to the

Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

USB Tethering . . . . . . . . . . . . . . . . . . . . . . 14

Watching TV

Changing the Viewing Style . . . . . . . . . . 16

Changing the Screen Format . . . . . . . . . . . . 16

Setting Scene Select. . . . . . . . . . . . . . . . . . . 16

Navigating through Home Menu

Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

All Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Photo Sharing Plus . . . . . . . . . . . . . . . . . . . . 17

Using the TV as a Photo Frame Mode. . . . . 18

Channels . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Programme List. . . . . . . . . . . . . . . . . . . . . . . 18

Digital EPG. . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Recordings. . . . . . . . . . . . . . . . . . . . . . . . . 19

Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Playback Photo/Music/Video via USB . . . . 19

Playback Photo/Music/Video via Home

Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

System Settings . . . . . . . . . . . . . . . . . . . . . . 21

Network Setup . . . . . . . . . . . . . . . . . . . . . . .30

Customer Support . . . . . . . . . . . . . . . . . . . . 30

Help Guide . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Home Screen . . . . . . . . . . . . . . . . . . . . . . . 31

Recommendations Row. . . . . . . . . . . . . . . . 31

Recent Apps . . . . . . . . . . . . . . . . . . . . . . . . . 31

Recent Channels . . . . . . . . . . . . . . . . . . . . . . 31

Viewing Pictures from Connected Equipment

Connection Diagram. . . . . . . . . . . . . . . . .32

Using Audio and Video Equipment . . . . .33

Using Screen mirroring. . . . . . . . . . . . . . .33

Installing the TV to the Wall . . . . . . . . . . 34

Additional Information

Troubleshooting . . . . . . . . . . . . . . . . . . . .35

Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Sound. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Specifications . . . . . . . . . . . . . . . . . . . . . 38

Internet Connection and Data Privacy

FUSE

This product connects to the i nternet during initial setup as soon as a network is conn ected in order to confirm internet connection, and later to configure the Home screen. Your IP address is use d in these an d all other in ternet connect ions. If you do not want your IP address be used at all, do not set-up the wireless internet functi on and do not connect an i nternet cable. Please refer to the privacy information presented in the set-up screens for further detai ls of internet connections.

Introduction

Thank you for choosing this Sony product. Before operating the TV, please read this manual tho roughly and retain it for fu ture ref erence.

Note

• Before operating the TV, please read the “Safety Information” (page 3).

• Images an d illustrations used in the Setu p Guide and this manual are for reference only and may differ from the actual product.

• The “xx” that a ppears in the model name corresponds to a numeric digit, related to design, colour or TV system.

Attaching the Table-Top Stand to the TV

Refer to the Setup Guide o n top of the cushion.

NOTICE FOR CUSTOMERS IN THE UNITED KINGDOM

A moulded plug complying with BS1363 is fitted to this equipment for your safety and conve nience. Should the fuse in the plug supplied need to be replaced with the same rating of fuse approved by ASTA or BSI to BS 1362 (i.e., marked with If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover a fter you change the fu se. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nea rest Sony service station.

How to replace the fuse

Open the fuse compa rtment with a blad e screwdriver, and replace the fuse. Please refer to the illustration that actually equipped with t he product.

or ) must be used.

IMPORTANT NOTICE

This product has been manufactured by or on behalf of Sony Visual Products Inc.

EU Importer: Sony Europe Limited.

Inquiries to the EU Im porter or related to product compl iance in Europe should be sent to the manufacturer's authorized representative, Sony Belgium, bijkan toor van Sony Europe Limited, Da Vincilaan 7-D1, 1935 Zaventem , Belgium.

Help Guide (Manual) (Only on limited region/country/TV model)

For more detailed information, press HOME o n the remote control, then select [Help Guide] under [Settings] menu. You can also check the Hel p Guide from your PC or sm artphone (information provided on the back cover).

Location of the identification label

Labels for the TV Model No., Product ion Date (year/mo nth) and Power Supply rating are located on the rear of th e TV or package.

For models with supplied mains adaptor: Labels for the mains a daptor Model No. and Serial No. are located on the bottom of the m ains adaptor.

WARNING

TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OTHER OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES.

Notice for Radio Equipment

Hereby, Sony Visual Products Inc. de clares that the radio equipment types KDL-50WF665, KDL-50WF663, KDL-50WF660, KDL-43WF665, KDL-43WF663, KDL-43WF660, KDL-43RF455, KDL-43RF453, KDL-43RF450 are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.compliance.sony.de/

This radio equipment can be operated in the EU without infringing applicable requirements on the use of radio spectrum.

Safety Information

WARNING

Caution

Risk of explosion if the batter y is replaced by an incorrect ty pe. Batteries must not be exposed to excessive heat such as sunshine, fire or the like or extremely l ow air pressure that can result in an ex plosion or le akage of fla mmable liqu id or gas.

Stability Hazard

The televis ion set may fall , causing serio us personal injury or death. Never place a television se t in an unstable location. A tele vision set may fall, causing serio us persona l injury or d eath. Many injuries, particularly to children, can be avoided by taking simple precautions such as:

• Using cabinets or stands recommended by the manufacturer of the television set.

• Only using furniture that can safely supp ort the television set.

• Ensuring the television set is not overhanging the edge of the

Screw (M6)

Wall-Mount Bracket

8 mm - 12 mm

TV’s rear cov er

8 mm - 12 mm

1.5 N·m/1,5 N·m {15 kgf·cm}

M6 screw (not supplied)

Screw (not supplied)

Cord

(not supplied)

30 cm

10 cm

Leave at least this space around the set.

30 cm

10 cm

Leave at least this space around the set.

6 cm

supporting furniture.

• Not plac ing the televi sion set on tall fu rniture (for exam ple, cupboards or bookcases) w ithout anchoring both the furniture and the television set to a suitable support.

• Not placing the television set on cloth o r other materials that may be located between the television set and supporting furniture.

• Educating children about the dangers of climbing on furniture to reach the television set or its controls.

If your existing television set i s being retained and relocated, the same considerations as above should be applied.

Installation/Set-up

Install and use the TV set in accordance with the instructions below in order to avoid any risk of fire, electric shock o r damage and/or injuries. Apparatus connected to the protective earthing of the building installation through the mai ns connection or through other apparatus with a connection to p rotective earthing – and to a television distribution system using coaxial cable, may in some circumstances create a fire hazard. Connect ion to a television distribution system therefore has to be provided through a device providing electrical isolation below a certain frequency range (galvanic isolator, see EN 60728-11).

Installation

• The TV set should be installed near an easily accessib le mains socket.

• Place the TV on a stable, level surface to prevent it from falling over and caus ing personal injury or prop erty damag e.

• Install the TV so that the TV's Table-Top Stand does not protrude out from the TV stand (not supplied). If the Table-Top Stand protrudes out from the TV stand, it may cause TV set to topple over, fall down, and cause personal injury or damage to the TV.

Tran spo rti ng

• Before transpor ting the TV set, disconnect all cables.

• Two or three people are needed to transport a large TV set.

• When transpo rting the TV set by han d, hold it as shown belo w. Do not put stress on the LCD pan el and the frame around the screen.

• When lifting or moving the TV set, hold it firmly from the bottom.

• When transpo rting the TV set, do not su bject it to jolts or excessive vibration.

• When transpo rting the TV set for repairs o r when moving, pack it using the original car ton and packing material.

Topple prevention

• Only qu alified serv ice personnel sh ould carry out wall-moun t installations.

• For safety reasons, it is strongly recommended that you use Sony accessories, including: Wall-Mount Bracket – SU-WL450

• Be su re to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mo unt Bracket to the TV set. The supplied screws are designed as indicated by illustration when measured from the attaching surface of the Wall-Mount Bracket. The diameter and length of the screws differ depending on the Wall-Mount Bracket model. Use of screws other than th ose supplied may resu lt in internal damage to the TV set or cause it to fall, etc.

Vent ilation

• Never cover the ventilation holes or insert anything in the cabinet.

• Leave space arou nd the TV set as shown be low.

• It is strongly recommende d that you use a Sony Wall-Mount Bracket in order to provide adequate air circul ation.

Installed on the wall

Installed with stand

• To ensure proper ventilation and prevent the collection of dirt or dust:  Do no t lay the TV set flat, install ups ide down, backwards, or

sideways.

 Do not place the TV set on a shelf, rug, be d or in a closet.

Air circulation is blocked.

Wall Wall

 Do not cover the T V set with a cloth, such as curtains, or items

such as newspapers, etc.

 Do not install the TV set as show n below.

Mains lead

Handle the mains lea d and socket as follows in order to avoid any risk of fire, electric shock or damage and/or injuries:

• Use only mains leads supplied by Sony, not other suppliers.

• Insert the p lug fully into the ma ins socket.

• Operate the TV set on a 220 V - 240 V AC supply only.

• When wiring cables, be sure to unplug the main s lead for your safety and take care not to catch your feet on th e cables.

• Disconnect the mains lead from the mains socket before working on or moving the TV set.

• Keep the mains le ad away from heat sources.

• Unplug the mains plug and clean it regularly. If the plug is covered with dust and it picks up moisture, its insulation may deteriorate, which could result in a fire.

Note

• Do not use th e supplied mains lead on an y other equipment.

• Do not p inch, bend, or twist the mains lea d excessively. The core conductors may be exposed or broken.

• Do not modif y the mains lead.

• Do not put any thing heavy on the main s lead.

• Do not pull on the mains lead itself when disconnecting the mains lead.

• Do not connect too many appliances to th e same mains so cket.

• Do not use a po or fitting mains socket.

NOTE ON MAINS ADAPTOR (models with supplied mains adaptor only)

Warni ng

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatu s. Do not install th is equipment in a confin ed space, such as a booksh elf or similar unit.

• Please ens ure that the mains socket is installe d near the equipment and shall be easily accessible.

• Be sure to use th e supplied mains ada ptor and mains lead.

• Do not use an y other mains adaptor. It may cause a malfunction.

• Connect the mains adaptor to an easily accessible mains socket.

• Do not coil the m ains lead around the mains adaptor. The core wire may be cu t and/or it may cause a malfunction of the media receiver.

• Do not touch the mains adaptor with wet hands .

• If you notice an abnormality in the mains adaptor, disconnect it from the mains so cket immediately.

• The set is not dis connected from the mains so urce as long as it is connected to the mains socket, even if the set itself has been turned off.

• As the ma ins adaptor will become warm when it is used for a long time, you may feel hot whe n touching it by hand.

Prohibited Usage

Do not install/use th e TV set in locations, environmen ts or situations such as th ose listed below, or the TV set may malfunction and cause a fire, electric shock, damage and/or injuries.

Locations:

• Outdoor s (in direct sunlight), at the se ashore, on a ship or other vessel, insid e a vehicle, in medical inst itutions, u nstable locations, near water, rain, moisture or smo ke.

Environments:

• Places that are hot, humid, or excessively dusty; where insects may enter; where it might be exposed to mechanical vibration, near flammable obje cts (candles, etc.). The TV set sh all not be exposed to dripping or splashing and no objects filled with liquids, such a s vases, shall be pla ced on the TV.

Situations:

• Use when y our hands are wet, with the cabinet removed, or with attachments not recom mended by the manufa cturer. Disconnect the TV set from ma ins socket and aerial during lightning storms.

• Install the T V so that it sticks out into an open space. Injury or damage from a person or ob ject bumping into the TV may result.

• Place the TV in a humid or dusty space, or in a room with oily smoke or steam (near cooking tables or humidifiers). Fire, electric sho ck, or warpin g may result.

• Install the TV in places subject to extreme temperature such as in direct sunlight, near a radiator or a heating vent. The TV may overhe at in such condition which can cause deformation of the enclosure and/or TV malfunction.

• If the TV is p laced in the changing room of a public bath or hot spring, the TV may be damaged by airborne sulfur, etc.

• For best picture quality, do not expose the screen to direct illumination or sunlight.

• Avoid moving the TV from a cold area to a warm area. Sudden room te mperat ure cha nges m ay cau se moi sture co ndens ation . This may cause the TV to show poor picture and/or poor colour. Should this occur, allow moistu re to evaporate compl etely before powering the TV on.

Broken pieces:

• D o not throw anything at the TV set. The screen glass may break by the impact and cause serious injury.

• If the surfa ce of the TV set cracks, do not touch it unt il you have unplugged the mains lead. Otherwise this may cause an electric shock.

When not in use

• If you will n ot be using the TV set for seve ral days, the TV set should be disconnected from the mains for environmental and safety reasons.

• As the TV set is not disconnected from the mains when the TV set is just turned off, pull the plug from th e mains to disconnect the TV set completely.

• Some TV se ts may have features that require the T V set to be left in standby to work correctly.

For children

1.5 mm max.

(Reference drawing of the F type plug)

7 mm max.

• Do not allow chi ldren to climb on the TV set.

• Keep small accessories out of the reach of children, so that they are not mistakenly swallowed.

If the following problems occur...

Turn off the T V set and unplug the mains lead im mediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service perso nnel.

When:

• Mains lead is d amaged.

• Poor fitting of mains socket.

• TV set is damaged by being dropped, hit or having something thrown at it.

• Any liquid or solid object falls through openings in the cabinet.

About LCD TV Temperature

When the LCD TV is used for an extended period, the panel surrounds become warm. You may feel hot whe n touching there by the hand.

Precautions

Viewing the TV

• View the TV in moderate li ght, as viewing th e TV in poor light or during long period of time, strains your eyes.

• When using he adphones, adjust th e volume so as to avoid excessive levels , as hea ring damage may result.

LCD Screen

• Although the LCD screen is made with high-precision technology and 99.99 % or more of the pixels are effective, black dots may app ear or bright points of light (red, blue, or green) may appear constantly on the LCD screen. This is a structural property of the LCD screen and is not a malfunction.

• Do not push or scratch the front filter, or place objects on top of this TV set. The image may be uneven or the LCD screen may be damaged.

• If this TV set is use d in a cold place, a smear may occur in th e picture or the picture may become dark. This does not indicate a failure. These phenomena disappear as the temperature rises.

• Ghosting may occur when still pictures are displayed continuously. It may disappear after a few moments.

• The screen and cabinet get warm whe n this TV set is in use. This is not a malfunction.

• The LCD screen contains a small amount of liquid crystal. Follow your local ordinances and regulations for disposal.

Handling and cleaning the screen surface/ cabinet of the TV set

Be sure to unplug the mai ns lead connected to the TV set from mains socket before c leaning. To avoid material degradation or screen coatin g degradation, observe the following precautions.

• To remove dust from the sc reen surface/cabinet, wipe gently with a soft cloth. If dus t is persistent, wipe wi th a soft cloth slightly moistened with a diluted mild detergent solution.

• Never spray water or de tergent directly on the TV set. It may drip to th e bottom of the screen or exterior parts and enter the TV set, and may cause dam age to the TV set.

• Never use any type of abrasive pad, alkaline/acid cl eaner, scouring powder, or volatile solvent, such as alcohol, benzene, thinner or insecticide. Using such materials or maintaining prolonged contact with rub ber or vinyl materials may result in damage to the screen sur face and cabinet material.

• Periodic vacuuming of the ventilation openings is recommended to ensure proper ventilation.

• When adjusting the angle of the TV s et, move it slowly so as to prevent the TV set from m oving or slipping off f rom its table stand.

Optional Equipment

• Keep optional components or any equipment emitting electromagnetic radiation a way from the TV set. Otherw ise picture distortion a nd/or noisy sound m ay occur.

• This equipm ent has been tested and found to comply with the limits set out in the EM C Directive using a connect ion signal cable shorter than 3 m eters.

• This equipm ent has been tested and found to comply with the limits set out in the EMC Directive using a RF cable shorte r than 30 meters for terrestrial/satellite/CATV terminal.

Recommendation of F type plug

Projection of the inner wire from the connection part must be less than 1.5 mm.

Caution about handling the remote control

• Observe the correct polarity when inserting batteries.

• Do not use di fferent types of batteries together or mix old and new batteries.

• Dispose o f batteries in an environmentall y friendly way. Certain regions may regulate the d isposal of batteries. Ple ase consult your local authority.

• Handle the remote control with care. Do not drop or step on it, or spill liquid of any kind onto it.

• Do not place the remote cont rol in a location near a heat source, a place subject to direct sunlight, or a damp room.

Wireless Function of the unit

• Do not operate this un it near medical equipmen t (pacemaker, etc.), as this may result in the malfunct ion of the medical equipment.

• Although th is unit transmits/receives scrambled signals, be careful of unauthorise d interception. We cannot be responsi ble for any trouble as a result.

• This equipment should be installed and operated keeping a separation distance of 20 cm or more between the an tenna of this device and a person's body.

Disposal of the TV set

Disposal of old electrical & electronic equipment (applicable in the European Union and other countries with separate collection systems)

This symbol on the product or on its packaging indicates that this product shal l not be treated

over to the appropriate collecti on point for the recycling of electrical and electronic equipment. By ensuring that this product is disposed of correctly, you will help to prevent potential negative consequences for the e nvironment and human health, which could be caused by inappropriate waste handling of this product. The recycling of m aterials will help to conserve n atural resources. For more detailed information ab out recycling of this product, please contact your loca l Civic Office, your household waste disposal service or the shop where you purchased the product.

product shall not be treated as ho usehold waste. On certain batteries this symbol migh t be used in combination with a chemical symbol. The chemical symbol for lead (Pb) is added if the battery contains more than 0.004 % lead. By ensuring that these batteries are disposed of correctly, you will help to prevent potentially negative conseque nces for the environment and human health which could be caused by inappropriate waste handling of the battery. The recycling of the materials will help to conserve natural resources. In case of products that for safety, performance or data integri ty reasons require a permanent connection with an incorpo rated battery, this battery should be replaced by qualified service staff only. To ensure that the battery will be treated properly, hand over the prod uct at end-of-life to the appropriate collection poi nt for the recycling of electrical and electronic equipment. For all oth er batteries, please view the section on how to remove the battery from the produc t safely. Hand the battery ove r to the appropriate collection point for the recycling of waste batteries. For m ore detailed information about recycling of this battery, please con tact your local Civic Office, your household waste disposal service or the shop where you purchased the product o r battery.

as household waste. Instead it shall be handed

Disposal of waste batteries (applicable in the European Union and other countries with separate collection systems)

This symbol on the battery or on the packaging indicates that the battery provi ded with this

Parts and Controls

 CAM (Conditional Access Module)

• Provides access to pay TV services. For details, refer to the instruction manual supplied with your CAM.

• Do not insert the smart card directly into the TV CAM slot. It must be fitted into the Conditional Access Module provided by your authorised dealer.

• CAM is not supported in some countries/ areas. Check with your authorised dealer.

• A CAM message may appear when you switch to a digital programme after using the Internet video.

  (Power) / + / –

Short press  to turn the TV on. Long press  until the TV turn off.

When the TV is on, Volume

Press + or – button to increase/decrease the volume. You can also press  until notification is displayed. Increases/decreases the volume by pressing the + or – button.

Input

Press  until notification is displayed. Moves the selected input source by pressing + (up) or – (down) button.

Programme

Press  until PROG notification is displayed. Select the programme by pressing + (up) or – (down) button.

 (Sensors/LED indicator)

• Receives signals from the remote control. Do not put anything over the sensor. Doing so may affect its function.

• Lights up in amber when the [Sleep Timer]* or [On Timer]* is set, or the TV is in Photo Frame Mode*.

• Lights up in white when [Power Saving]* is set to [Picture Off]*.

• Lights up in white when the TV is turned on.

• Does not light up when the TV is in standby mode.

• Flashes while the remote control is being operated.

• Lights up in red in recording mode.

(Only on limited region/country/TV model)

* For more detailed information, press HOME on the

remote control, then select [Help Guide] under [Settings] menu.

Note

• Make sure that the TV is completely turned off before unplugging the mains lead.

• To disconnect the TV from the mains completely, pull the plug from the mains socket.

• Please wait for a while when perform input selection to change to other input.

Remote Control

The remote control shape, locatio n, availability and function of remote control buttons may vary depending on your region/country/TV model.

 / (Input select / Text hold)

• Displays and selects the input source.

• In text mode, holds the current page.

 DIGITAL/ANALOG

Switches to digital or analogue input.

 Number buttons

• Select channels. For channel numbers 10 and above, enter the next digit quickly.

• In text mode, enter the three digit page number to select the page.

 EXIT

Return to the previous screen or exit from the menu. When an Interactive Application service is available, press to exit from the service.

 Colour buttons

Displays operation guide (when colour buttons are available).

 YouTube (Only on limited region/

country/TV model)

Accesses the “YouTube” online service.

 / (Info / Text reveal)

• Displays information. Press once to display information about the programme/input you are viewing. Press again to remove the display from the screen.

• In text mode, reveals hidden information (e.g. answers to a quiz).

 SLEEP

Press repeatedly until the TV displays the time in minutes ([Off]/[15 min]/[30 min]/ [45 min]/[60 min]/[90 min]/[120 min]) that you want the TV to remain on before shutting off. To cancel the sleep timer, press SLEEP repeatedly until [Off] appears.

 //// (Item select / Enter)

• Select or adjust items.

• Confirm selected items.

 RETURN

• Returns to the previous screen of any displayed menu.

• Stops playback when playing photo/ music/video file.

 HOME

Displays or cancels the menu.

 +/– (Volume)

Adjusts the volume.

 AUDIO

Select the sound of multilingual source or dual sound for the programme currently being viewed (Depend on programme source).

 (Subtitle)

Changes the subtitle setting.

//////

• Operate media contents on the TV and connected BRAVIA Sync-compatible device.

• This key also can be used to operate VOD (Video on Demand) service playback. Availability is depend on VOD service. (Except KDL-43RF4xx)

 REC (Not available for Italy)

Record the current programme with the USB HDD recording function.

 (TV standby)

Turns the TV on or switches to standby mode.

 SYNC MENU

Press to display the BRAVIA Sync Menu and then select connected HDMI equipment from [Device Selection]. The following options can be selected from BRAVIA Sync Menu.

Device Control:

Use the [Device Control] to operate equipment that is compatible with BRAVIA Sync Control. Select options from [Home (Menu)], [Options], [Content List] and [Power Off] to operate the equipment.

Speakers:

Select [TV Speakers] or [Audio System] to output the TV’s sound from the TV speakers or connected audio equipment.

TV Control:

Use the [TV Control] menu to operate the TV from the [Home (Menu)] or [Options] menu.

Return to TV:

Select this option to return to the TV programme.

 (Text)

In text mode, displays Text broadcast. Each time you press , the display changes cyclically as follows: Tex t  Text over the TV picture (mix mode)  No Text (exit the Text service)

 NETFLIX (Only on limited region/

country/TV model)

Accesses the “NETFLIX” online service.

 GUIDE (EPG)

Displays the Digital EPG (Electronic Programme Guide).

 OPTIONS

Displays a list that contains shortcuts to some setting menus. The listed options vary depending on the current input and content.

 (Jump)

Returns to the previous channel or input viewed more than 15 seconds.

 PROG +/–/ /

• Selects the next (+) or previous (–) channel.

• In text mode, selects the next ( ) or previous ( ) page.

 (Mute)

Mutes the sound. Press again to restore the sound.

 TITLE LIST (Not available for Italy)

Display the Title list.

 (Wide Mode)

Adjusts the screen display. Press repeatedly to select the desired wide mode.

Hint

• The number 5, , PROG + and AUDIO buttons have

tactile dots. Use the tactile dots as references when operating the TV.

Note

• If subtitles are selected and the user launches a digital text application via ‘text’ key, subtitles may, under certain circumstance stop being displayed. When the user exits the digital text application, subtitle decoding will resume automatically.

Connecting TV to the Internet

(Except KDL-43RF4xx)

Setting up the Internet Connection

To use the network features of your TV it needs to be connected to the Internet. The setup procedure differs depending on the type of network and LAN router. Before setting up the Internet connection, be sure to set up a LAN router. Check your wireless LAN environment using the following chart.

Wireless LAN

Secure Wireless LAN? NO

YES m

Do you use a wireless LAN router compatible with Wi-Fi Protected Setup™ (WPS)?

YES m

Typ e 1*

Wired LAN , Typ e 4

* Type 1 is easier to set up if your router has an

automatic setting button, e.g. Air Station One-Touch Secure System (AOSS). Most of the latest routers have this function. Check your router.

Typ e 1: Follow the configuration for Secured

network with Wi-Fi Protected Setup™ (WPS).

Typ e 2: Follow the configuration for Secured

network without Wi-Fi Protected Setup™ (WPS).

Typ e 3: Follow the configuration for Unsecured

network with any type of wireless LAN router.

Typ e 4: Follow the configuration for Wired

network setup.

k Typ e 3

NO k Typ e 2

Type 1: Secured network with Wi-Fi Protected Setup™ (WPS)

The WPS standard makes security of a wireless home network as straightforward as pressing the WPS button on the wireless LAN router. Before setting up a wireless LAN, check the location of the WPS button on the router and verify how to use it. For security purpose, [WPS (PIN)] provides a PIN code for your router. PIN code is renewed every time you select [WPS (PIN)].

1 Press HOME, then select [Settings]* 

[System Settings]  [Setup]  [Network]  [Network Setup].

2 IP Address setting/Proxy server:

– automatic setting: [Set up network connection]  [Easy] – manual setting: [Set up network connection]  [Expert]  [Wired Setup] or [Wireless Setup]

3 Select [WPS (Push Button)] for Push

Button method or [WPS (PIN)] for PIN method.

Note

Button name of the WPS may differ depending on the router (e.g. AOSS button).

4 Follow the instructions on the setup

screen.

Note

• If you use WPS for network setup, the security settings of the wireless LAN router activate, and any equipment previously connected to the wireless LAN in a non-secure status will be disconnected from the network. In this case, activate the security settings of the disconnected equipment and then reconnect. Or, you can deactivate the security settings of the wireless LAN router, and then connect the equipment to a TV in a non-secure status.

• To use the network with IPv6, select [Settings]*  [System Settings]  [Setup]  [Network]  [IPv6/ IPv4 Priority]  [IPv6], then select [Easy] in [Set up network connection].

• When IPv6 is selected, HTTP Proxy cannot be set.

Type 2: Secured network without Wi-Fi Protected Setup™ (WPS)

To set up a wireless LAN, SSID (wireless network name) and security key (WEP or WPA key) will be required. If you do not know them, consult the instruction manual of your router.

1 Press HOME, then select [Settings]* 

[System Settings]  [Setup]  [Network]  [Network Setup].

2 IP Address setting/Proxy server:

– automatic setting: [Set up network connection]  [Easy] – manual setting: [Set up network connection]  [Expert]  [Wired Setup] or [Wireless Setup]

3 Select [Scan], then select a network from

the list of scanned wireless networks.

4 Follow the instructions on the setup

screen.

Note

• To use the network with IPv6, select [Settings]*  [System Settings]  [Setup]  [Network]  [IPv6/ IPv4 Priority]  [IPv6], then select [Easy] in [Set up network connection].

• When IPv6 is selected, HTTP Proxy cannot be set.

• Please make sure your surrounding is secure when you key in your password.

Type 3: Unsecured network with any type of wireless LAN router

To set up a wireless LAN, SSID (wireless network name) will be required.

1 Press HOME, then select [Settings]* 

[System Settings]  [Setup]  [Network]  [Network Setup].

2 IP Address setting/Proxy server:

– automatic setting: [Set up network connection]  [Easy] – manual setting: [Set up network connection]  [Expert]  [Wired Setup] or [Wireless Setup]

3 Select [Scan], then select a network from

the list of scanned wireless networks.

4 Follow the instructions on the setup

screen.

Note

• Security key (WEP or WPA key) will not be required because you do not need to select any security method in this procedure.

• To use the network with IPv6, select [Settings]*  [System Settings]  [Setup]  [Network]  [IPv6/ IPv4 Priority]  [IPv6], then select [Easy] in [Set up network connection].

• When IPv6 is selected, HTTP Proxy cannot be set.

Type 4: Wired network setup

Enter the respective alphanumeric values for your router if necessary. The items that need to be set (e.g. IP Address, Subnet Mask, DHCP) may differ depending on the Internet service provider or router. For details, refer to the instruction manuals provided by your Internet service provider, or those supplied with the router.

1 Press HOME, then select [Settings]* 

[System Settings]  [Setup]  [Network]  [Network Setup].

2 IP Address setting/Proxy server:

– automatic setting: [Set up network connection]  [Easy] – manual setting: [Set up network connection]  [Expert]  [Wired Setup] or [Wireless Setup]

3 Follow the instructions on the setup

screen.

[Network Setup] can also be set from [Auto Startup] menu.

Note

• Allows automatic configuration of your wired/ wireless network.

When connecting with LAN cable: Wired When connecting with built-in Wireless LAN:

Wireless

When connecting with both of the cables: Wired

• Set to [Easy], sets the IP address automatically. For proxy server is not use.

• To use the network with IPv6, select [Settings]*  [System Settings]  [Setup]  [Network]  [IPv6/ IPv4 Priority]  [IPv6], then select [Easy] in [Set up network connection].

• When IPv6 is selected, HTTP Proxy cannot be set.

Preparing a Wired Network

Internet

Modem with router functions

Router

Modem

Internet

If You Cannot Connect to the Internet

Use the diagnosis to check possible causes for network connection failures, and settings.

1 Press HOME, then select [Settings]* 

[System Settings]  [Setup]  [Network]  [Network Setup].

2 Select [View Network setting and

status].

3 Select [Check Connection].

This may take several minutes. You cannot cancel the diagnosis after selecting [Check Connection].

* Only on limited region/country/TV model

Note

• For LAN connections, use a Category 7 cable (not supplied).

Viewing the Network Status

You can confirm your network status.

1 Press HOME, then select [Settings]* 

[System Settings]  [Setup]  [Network]  [Network Setup].

2 Select [View Network setting and

status].

* Only on limited region/country/TV model

USB Tethering

(Except KDL-43RF4xx)

Your smartphone (depending on models/ compatible OS version) can be used as a wireless modem to share its mobile data connection with the TV via USB cable. Your TV will automatically detect USB Tethering connection if a compatible mobile with USB Tethering turned ON is connected.

To confirm your USB Tethering status

Press HOME, then select [Settings]*  [System Settings]  [Setup]  [Network]  [USB Tethering Status].

* Only on limited region/country/TV model

Privacy Policy

When you use the following functions to connect to the Internet, certain information which is considered to be personal information, will be sent to Sony Visual Products Inc. global servers.

Your agreement is required in order for it to be collected and used.

• System software updates by connecting to

Sony Visual Products Inc. global servers via the Internet.

• Internet content or other Internet services

from service providers like YouTube.

This TV has the setting screens in auto startup sequence or [Setup] menu to confirm your agreement to this after you read the detail of the Privacy Policy. If you want to use these functions, please check [Agree] in each setting screen. If [Disagree] is checked, the above two functions are not available. You can change this setting by pressing HOME, then select [Settings]*  [System Settings]  [Setup]  [Privacy Policy].

* Only on limited region/country/TV model

Watching TV

Changing the Viewing Style

1 Press  on the TV or the remote control

to turn on the TV.

2 Press DIGITAL/ANALOG to switch

between digital and analogue inputs.

3 Press the number buttons or PROG +/–

to select a TV channel.

4 Press  +/– to adjust the volume.

In digital mode

An information banner appears briefly. The following icons may be indicated on the banner.

Data service (Broadcast application)

Radio service

Scrambled/Subscription service

Multiple audio languages available

Subtitles available

Subtitles and/or audio available for the

hearing impaired Recommended minimum age for

current programme (from 3 to 18 years)

Parental Lock

Digital Programme Lock

Audio available for the visually

impaired

Spoken subtitle audio available

Multi-channel audio available

Changing the Screen Format

1 Press repeatedly to select the screen

format.

[Wide Zoom]* [Normal]

[Full] [Zoom]*

[14:9]*

* Parts of the top and bottom of the picture may

be cut off.

Note

• You cannot select [14:9] for HD source pictures.

For HDMI PC Input (PC timing)

[Normal] [Full 1]

[Full 2]

Setting Scene Select

1 Press OPTIONS. 2 Press / then to select [Scene

Select].

When you select the desired scene option, the optimum picture and sound quality for selected scene are automatically set. The options you can select may vary. Unavailable options are greyed out.

Navigating through Home Menu

The HOME button allows you to access a variety of TV settings and features.

Apps

(Only on limited region/country/TV model)

All Apps

Internet Content delivers a variety of ondemand entertainment straight to your TV. You can enjoy your favourite internet content (Except KDL-43RF4xx), Photo Sharing Plus (Except KDL-43RF4xx) and Photo Frame Mode.

Note

• Be sure to connect your TV to the Internet and

complete [Network Setup] (page 26).

To use Internet Content

1 Press HOME. 2 Press /// then to select [All

Apps].

3 Press /// to select the desired

internet service in service list.

4 Press to launch the desired internet

content.

5 Press the red/green/yellow/blue button

to filter the app category by Photo/ Music/Video/All.

To exit Internet Content

Press HOME.

Note

• If you experience difficulties with this feature, check

that the Internet connection is set up properly.

• The interface to Internet content depends on the

Internet content providers.

• To update Internet Content services, press HOME,

then select [Settings]*  [System Settings]  [Setup]  [Network]  [Refresh Internet Content].

To use NETFL IX

Press NETFLIX button on the remote control to launch menu.

Note

• It is possible that Netflix cannot be used via a Proxy server.

Photo Sharing Plus

(Except KDL-43RF4xx)

Connect, copy and view favourite photos on TV using your devices (e.g. smartphones or tablets).

HOME  [All Apps]  [Photo Sharing Plus]

Note

• Follow the instructions on the screen to connect your device to the TV.

• Open web browser on device after all connections are established, then follow the instructions on the screen to access the URL.

To display photo on TV

1 Tap on your device to start. 2 Select a photo.

The selected photo will be displayed automatically on TV.

To save a photo displayed on TV

1 Tap thumbnail on your device, then hold

the photo to open the context menu.

2 Select [OK].

Note

• Connect a USB flash drive to store up to 50 photos.

• Up to 10 smartphones or tablets can be connected to the TV at the same time.

• Maximum file size of each photo is 20 MB.

• You can also throw a background music with a maximum file size of 30 MB.

• The default browser for Android 2.3 or later is supported.

• The default browser for iOS is supported; however, some functions cannot be used depending on the version of your iOS.

Using the TV as a Photo Frame Mode

Photo Frame Mode displays the clock and calendar at the same time as displaying a photo, and listening to music.

HOME  [All Apps]  [Photo Frame Mode]

To launch Photo Frame Mode while playback USB media

1 Press OPTIONS, while playback a photo

or music file.

2 Press / then to select [Photo

Frame Mode] to launch Photo Frame.

Channels

(Only on limited region/country/TV model)

Programme List

1 Press HOME in digital mode. 2 Press / then to select [Programme

List].

To select Display mode

You can change the Photo Frame Mode display by selecting [Display Mode] in the [Photo Frame Settings] (page 27).

To select Clock Display mode

You can select among three clock display modes by selecting [Clock Display] in the [Photo Frame Settings] (page 27).

Note

• This TV does not have a battery powered backup for the clock. If there is a power failure or if you disconnect the power cord, the current date and time will reset automatically.

Duration

To save power, the TV continually plays back in Photo Frame Mode for up to 24 hours before powering off automatically. After automatic power off, do not use Photo Frame Mode for at least one hour to avoid panel burn-in. You can change the setting of the [Duration] in the [Photo Frame Settings] (page 27).

To avoid panel burn-in, the position of the photo, clock and calendar are switched automatically every hour.

3 Press /// then to select a

programme.

To use the Favourite list

The Favourite feature allows you to specify up to four lists of your favourite programmes. While watching TV, press Favourite list.

Hint

• Press the blue button to edit the Favourite list. Follow the guides at the bottom of the screen.

to create or display a

Digital EPG

1 Press GUIDE in digital mode.

2 Press /// then to select a

programme.

Recordings

(Function not available in Italy)

1 Press HOME in digital mode. 2 Press /// then to select [Title

List], [Timer List], [Error List] or [Manual timer REC] under [Recordings] menu.

Note

•Press  REC button to record currently viewed

programme in digital mode with USB HDD recording function.

• Be sure to connect the HDD to the TV before recording.

Media

Playback Photo/Music/Video via USB

You can enjoy photo/music/video files stored in a Sony digital still camera/camcorder/ smartphone (depending on models)* through a USB cable or USB storage device on your TV.

1 Connect a supported USB device to the

TV.

* Device needs to be in Media transfer mode (MTP).

2 Press HOME. 3 Press /// then to select

[Photo], [Music] or [Video] under [Media] menu.

4 [Device Selection] appears. Press /

then to select a device (Except KDL-43RF4xx).

5 Press /// then to select a file

or folder.

6 If more than one USB device is

connected, press the red button to select [Playback Options] then [Device Selection] to select the appropriate USB device (KDL-43RF4xx only).

Playback Options

Press the red button in thumbnail view to display the list of USB playback settings.

Display Settings

Press OPTIONS in thumbnail view to display the option to change the thumbnail view to list view.

To adjust the picture and sound quality of USB media

Press OPTIONS during media playback then select [Picture] or [Sound].

Note

• Press /// then to select and adjust an item.

To play a photo as a slideshow (Photo)

1 Press the green button in thumbnail/list

view to start slideshow. To set [Slideshow Effect] and [Slideshow Speed], press OPTIONS Options]. To stop a slideshow, press RETURN.

Note

• While the TV is accessing the data on a USB device, observe the following:

 Do not turn off the TV.  Do not disconnect the USB cable.  Do not remove the USB device.

The data on the USB device may be damaged.

• Sony will not be held liable for any damage to, or loss of, data on the recording media due to a malfunction of any connected devices or the TV.

• The file system on the USB device supports FAT16, FAT32 a nd NTFS.

• The file name and folder name may not display correctly in some cases.

• When you connect a Sony digital still camera, set the camera’s USB connection mode to Auto or Mass Storage. For more information about USB connection mode, refer to the instructions supplied with your digital camera.

• Use a USB storage device that is compliant with USB mass storage device class standards.

• If a selected file has incorrect container information, or is incomplete, it cannot be played back.



[Playback

USB Video format

• AVI (.avi)

Video Codec: MPEG1, MPEG2, Xvid, MPEG4,

H.264, Motion JPEG

Audio Codec: PCM, MPEG1 Layer1/2, MPEG2

AAC, MPEG4 AAC, MPEG4 HE-AAC, Dolby Digital, Dolby Digital Plus, WMA v8, MP3

•ASF (.wmv, .asf)

Video Codec: WMV v9, Xvid, VC-1 Audio Codec: MP3, WMA v8

• MP4 (.mp4, .mov, .3gp)

Video Codec: MPEG4, H.264, H.263, Motion

JPEG, H.265

Audio Codec: MPEG1 Layer1/2, MP3, MPEG2

AAC, MPEG4 AAC, MPEG4 HE-AAC, AC4

•MKV (.mkv)

Video Codec: WMV v9, MPEG4, H.264, VC-1,

VP8, VP9, H.265

Audio Codec: PCM, MPEG1 Layer1/2, MP3,

MPEG2 AAC, MPEG4 AAC, MPEG4 HE-AAC, Dolby Digital, WMA v8, Dolby Digital Plus, DTS, FLAC, VORBIS

•WebM (.webm)

Video Codec: VP8, VP9 Audio Codec: VORBIS

• PS (.mpg, .mpeg, .vro, .vob)

Video Codec: MPEG1, MPEG2 Audio Codec: MPEG1 Layer1/2, MP3, Dolby

Digital, Dolby Digital Plus, DTS

• TS (.ts, .m2ts)

Video Codec: MPEG2, H.264, VC-1, H.265 Audio Codec: MPEG1 Layer1/2, MP3, MPEG2

AAC, MPEG4 AAC, MPEG4 HE-AAC, Dolby Digital, Dolby Digital Plus, DTS, AC4

USB Music format

• LPCM, DTS-CD (.wav)

• MPEG1 audio layer3 (.mp3)

•WMA v8 (.wma)

• FLAC (.flac)

USB Photo format

• JPEG (.jpg, .jpeg)

Note

• Playback of the above file formats is not guaranteed.

Playback Photo/Music/Video via Home Network

(Except KDL-43RF4xx)

You can enjoy various content (e.g. photo/ music/video files) stored on DLNA Certified™ media servers. The home network feature allows you to enjoy network content in other rooms.

Playing photo/music/video

1 Press HOME, then select [Media] 

[Photo], [Music] or [Video]  the desired media server.

2 Select files or folders to play from the

list.

Note

• The server is required to be DLNA Certified™.

• Files from a network device need to be in the following formats:

Still images: JPEG Music: MP3, linear PCM, WMA Video: AVCHD, MPEG2, MPEG1, MP4 (AVC), MP4

(MPEG4), WMV

• Depending on the file, playback may not be possible even when using the supported formats.

Renderer

You can play back photo, music and video files stored in network devices (e.g. digital still cameras, mobile phones, PC) on the TV screen by directly operating the target device. The network should also be renderer-compatible devices.

Renderer settings

Press HOME, then select [Settings]*  [System Settings] Network Setup]



[Setup]  [Network]  [Home



[Renderer].

Display Settings for Media Servers

Select home network servers to be displayed in the Home Menu. Up to 10 servers can be displayed.

1 Press HOME, then select [Settings]* 

[System Settings]  [Setup]  [Network]  [Home Network Setup]  [Server Display Settings].

2 Select the server to display in the Device

Selection.

* Only on limited region/country/TV model

Settings

Noise Reduction

Reduces the picture noise (snowy picture) in a weak signal.

System Settings

Note

• The options you can adjust vary depending on the situation. Unavailable options are greyed out or not displayed.

• Satellite features are only available for satellite models.


Picture Mode

Sets a picture mode.

Reset

Resets all the [Picture] settings except [Picture Mode] to the default settings.

Backlight

Adjusts the brightness of the backlight.

Contrast

Increases or decreases picture contrast.

Brightness

Brightens or darkens the picture.

Colour

Increases or decreases colour intensity.

Hue

Increases or decreases the green tones and red tones.

Colour Temperature

Adjusts the whiteness of the picture.

MPEG Noise Reduction

Reduces the picture noise in MPEGcompressed video.

Film Mode

Provides improved picture movement when playing BD (Blu-ray Disc), DVD or VCR images taken on film. Select [Auto] to represent original film-based content as it is.

Note

• If the image contains irregular signals or too much noise, [Film Mode] is automatically turned off even if [Auto] is selected.

Advanced Settings

Sets [Picture] settings in more detail.

Reset: Resets all the advanced settings

to the default settings.

Adv. Contrast Enhancer: Automatically

adjusts [Backlight] and [Contrast] to the most suitable settings for dark images scenes.

Black Corrector: Enhances black areas

of the picture for stronger contrast.

Gamma: Adjusts the balance between

bright and dark areas of the picture.

Clear White: Emphasises white colours. Live Colour: Makes colours more vivid. LED Motion Mode: Reduces blur in

movies by controlling the LED backlight source, but the brightness decreases.

Sharpness

Sharpens or softens the picture.

Reality Creation

Adjusts fineness and noise for realistic picture.

Resolution: Adjusts fineness and

clarity. Select [Manual] from [Reality Creation] to adjust the [Resolution].

Sound

ClearAudio+

Let you enjoy the best sound quality by the combination of a well-balanced digital signal processing technology.

Sound Mode

Select according to content you want to enjoy.

Reset

Reset [Surround], [Surround Effect], [Sound Restoration (DSEE)], [Equaliser], [Voice Zoom], [Advanced Auto Volume], [Balance], and [Volume Offset] settings.

Surround

Virtually reproduce realistic surround sound.

Surround Effect

Adjust the surround sound effect.

Sound Restoration (DSEE)

Reproduce the spatial natural sound quality by decoding high frequencies and small sound often lost by digital compression.

Equaliser

Adjusts sound frequency settings.

Voice Zoom

Emphasize voice or ambient audio.

Advanced Auto Volume

Automatically compensates for the volume level that may vary by programme or input.

Balance

Emphasises left or right speaker balance.

Dual Sound

Sets the sound from the speaker to [Mono], [Stereo], [A] or [B].

Note

• If the signal is very weak, the sound becomes monaural automatically.

• If the stereo sound is noisy when receiving a NICAM programme, select [Mono]. The sound becomes monaural, but the noise is reduced.

• The [Dual Sound] setting is memorized for each programme position.

• You cannot listen to stereo broadcast sound when [Mono] is selected.

Hint

• If you select other equipment connected to the TV, set [Dual Sound] to [Stereo], [A] or [B].

Advanced Settings

Dynamic Range: Compensates for

differences in the audio level between different channels.

Note

• The effect may not function or may vary depending on the programme regardless of the [Dynamic Range] setting.

Dolby Digital Plus Out: Select [Auto] to

pass through Dolby Digital Plus stream to ARC when Dolby Digital Plus is available through connected Audio System. During Dolby Digital Plus stream is output, Digital Audio Out (optical)* is muted. Select [Off] to convert Dolby Digital Plus stream to Dolby Digital for both ARC (Audio system) and Digital Audio Out (optical)*.

* Only on limited region/country/TV model.

HE-AAC Audio Level: Adjust the HE-

AAC audio sound level.

MPEG Audio Level: Adjusts the MPEG

audio sound level.

Dolby AC-4 Dialog Enhancer: Adjust

the dialog level for AC-4 source.

Volume Offset

Adjusts the volume level of the current input relative to other inputs.

Screen

Screen Format

For details about Screen Format, see page 16.

Auto Format

Automatically changes [Screen Format] to match the input signal.

4:3 Default

Sets the default [Screen Format] for a 4:3 input signal.

Auto Display Area

Automatically adjusts the picture to the most appropriate display area.

Display Area

Adjusts the picture display area.

Horizontal Shift

Adjusts the horizontal position of the picture.

Vertical Shift

Adjusts the vertical position of the picture.

Vertical Size

Adjusts the vertical size of the picture when [Screen Format] is set to [Wide Zoom].

PC Settings

Select [Screen Format], see page 16.

Channel Setup

Analogue Setup

Analogue Auto Tuning: Tunes in all the

available analogue channels. Usually you do not need to do this operation because the channels are already tuned when the TV was first installed. However, this option allows you to repeat the process (e.g., to retune the TV after moving house, or to search for new channels that have been launched by broadcasters).

Manual Programme Preset: Before

selecting [TV System]/[Channel]/ [AFT]/[Audio Filter]/[Skip]/[Colour System], press PROG +/– to select the programme number with the channel. You cannot select a programme number that is set to [Skip].

Programme

Presets programme channels manually.

Signal Level

Displays the signal level for programme currently being watched.

Programme Sorting: Changes the

order in which the channels are stored on the TV.

Digital Setup

Digital Tuning:

Digital Auto Tuning

Tunes in the available digital channels. This option allows you to retune the TV after moving house, or to search for new channels that have been launched by broadcasters.

Auto Tuning Range Normal: Searches for available

channels within your region/country. Full: Searches for available channels regardless of region/country.

Note

• You can run [Digital Auto Tuning] after moving to a new residence, changing service providers, or to search for newly launched channels.

Programme List Edit

Removes any unwanted digital channels stored on the TV, and changes the order of the digital channels stored on the TV.

Digital Manual Tuning

Tunes the digital channels manually.

Subtitle Setup:

Subtitle Setting

When [For Hard Of Hearing] is selected, some visual aids may also be displayed with the subtitles (if TV channels broadcast such information).

Primary Preferred Language

Select preferred language which subtitles are displayed in.

Secondary Preferred Language

Select secondary preferred language which subtitles are displayed in.

Audio Setup:

Audio type (Audio description)

Normal

Provides normal audio type.

Audio Description

Provides audio description (narration) of visual information if TV channels broadcast such information.

For Hard Of Hearing

Switches to broadcast for the hearing impaired when [For Hard Of Hearing] is selected.

Spoken subtitle

Switches to broadcast for the spoken subtitle audio if TV channels broadcast such information.

Primary Preferred Language

Select the preferred language used for a programme. Some digital channels may broadcast several audio languages for a programme.

Secondary Preferred Language

Select the secondary preferred language used for a programme. Some digital channels may broadcast several audio languages for a programme.

Mixing Level

Adjusts the TV main audio and Audio Description output levels.

Hint

• This option is only available when [Audio Description] in [Audio type (Audio description)] is set.

Guide Setup:

Update Guide in standby

TV obtains EPG data during standby mode.

Technical Setup:

Auto Service Update

Enables the TV to detect and store new digital services as they become available.

Service Replacement

Select [On] to automatically change the channel when broadcaster changes transmission of the viewing programme to a different channel.

Programme List Transfer

Import or export tuned programmes using USB device.

Satellite Setup:

Allows you to automatically tune satellite channels.

Digital Satellite Tuning

Tunes in the available satellite service. This option allows you to retune the TV after moving house, or to search for new channels that have been launched by broadcasters.

Note

• You can decide the installation type and set up the tuning options according to setting mentioned below:

Antenna Configuration

Allows you to select the Single Cable Distribution, Fixed Antenna or DiSEqC. Your satellite installation type may be Single Cable Distribution, Fixed Antenna or DiSEqC. Single Cable installations enable delivery of satellite programmes for multiple receivers over a single coaxial cable. Each receiver or tuner is allocated one user ‘band’. DiSEqC installations allow you connect to multiple satellite dishes or LNBs if you have them, and to select between them using the TV control. Fixed Antenna is usually the simplest installation type, where there is one satellite dish and LNB.

Band

The number of the user band allocated to the TV or tuner.

Band Frequency

The frequency of the user band allocated to the TV or tuner.

Other (General Satellite)

The TV will search for satellite services based on group of general settings.

DiSEqC Control

Settings for controlling additional satellite equipment such as satellite selector switches.

Scan Type

Full Scan performs a scan of all available satellite frequencies. Network Scan performs a scan based on predefined network parameters. Manual Scan allows you to set the scan frequency and other transponder parameters.

Hint

• If services are missing after this Network Scan, please perform the full scan.

Satellite Programme List Edit

Removes any unwanted satellite service stored on the TV, and changes the order of the satellite service stored on the TV.

Satellite Auto Service Update

Enables the TV to detect and store new satellite services as they become available.

Manual Service Update (preserves

favourites and timers):

Searches for available service update manually.

CA Module Setup:

Allows you to access a pay TV service once you obtain a Conditional Access Module (CAM) and a view card.

CA Module PIN:

Allows you to enter the 8 digits Conditional Access Module (CAM) PIN to be stored in TV.

Delete Service List:

Deletes a service list. Select [Yes] to delete.

Interactive Application Setup

(Except KDL-43RF4xx):

The interactive application service offers high-quality digital text and graphics, along with advanced options. The service is supported by broadcasters.

Interactive Application

Enables the viewing of programmes featuring interactive services.

Auto Start Application

Launches broadcast-related applications automatically.

Application for (Prog. [current program])

Enables the interactive application service for the current programme.

Note

• The interactive service is only available if provided by the broadcaster.

• Available functions and screen content vary depending on the broadcaster.

Parental Lock

PIN Code

Sets a PIN code to block channels, external inputs, Internet services and all channel tuning related settings. Use 0-9 on the remote control to enter a four-digit PIN code.

Change PIN Code

Select to change your PIN code.

Parental Rating

Sets an age restriction for viewing. To view any programme rated for ages above the age you specify, enter the correct PIN code.

Setup Protection

Enable or disable protection on programme related operations.

Digital Programme Lock

Locks a digital channel from being watched. To view a blocked channel, select [Unlocked].

Satellite Programme Lock

Locks satellite programme from being watched. To view locked programme, select [Unlocked].

Note

• To view locked programme, key in the PIN code or select [Programme locked.] in [Parental Lock] to unlock.

External Input Lock

Locks external input from being watched. To view an external input, select [Unlocked].

Note

• Entering the correct PIN code for blocked channel or external input will temporarily deactivate the [Parental Lock] feature. To reactivate the [Parental Lock] settings, turn off and on the TV.

Hint

• If you lost your PIN code, see page 38.

Internet Lock (Except KDL-43RF4xx)

Locks internet content from being watched. To view an internet content, select [Unlocked].

Setup

Network (Except KDL-43RF4xx)

Network Setup: Sets the network

status settings.

USB Tethering Status: Displays the USB

Tet heri n g sta tus.

IPv6/IPv4 Priority: Switch between

[IPv6] and [IPv4 (Recommended)].

Note

• To use the network with [IPv6], select [IPv6], then select [Easy] in [Set up network connection].

• When IPv6 is selected, HTTP Proxy cannot be set.

• When IPv6 is selected, some Internet browser sites, applications or contents cannot be watched.

Built-in Wi-Fi: Turn s th e bu ilt-in

wireless LAN [On] or [Off]. Set to [Off], if you do not use the built-in wireless LAN. When you switch from [Off] to [On], establish the network connection via [Network Setup].

Wi-Fi Direct: Turns On/Off to connect

your TV with Wi-Fi Direct device such as PC, Mobile Phone or Digital Camera.

Wi-Fi Direct Settings: Set to connect a

Wi-Fi direct device to the TV using the Wi-Fi Direct function. If you cannot connect, press OPTIONS key and select [Manual].

Device Name: Change the name of the

TV shown on the connected device.

Refresh Internet Content: Connect to

the internet to receive available Internet content services.

Guidance Block for Recorded Titles (for United Kingdom only)

You can block recorded content by displaying a guidance that requires password input to access.

Home Network Setup:

Server Display Settings

Displays the connected server list. You can select the server to display in the Device Selection.

Server Diagnostics

Diagnoses whether the TV can connect to each server on the home network.

Remote Start

This feature allow connected device in the home network to turn on the TV.

Note

• The standby power consumption will increase if [On] is set.

Renderer

Renderer Function

Enables the TV to play media files on a device (e.g. digital still camera).

Renderer Access Control

Allows access from a specified control device.

Renderer Setup

Adjusts the [Renderer Setup] detailed settings.

Home Screen (Only on limited region/ country/TV model)

Allows you to change between [Basic] or [Advanced] Home Menu feature. Select [Advanced] to enable the enhanced feature.

Photo Frame Settings

Display Mode: Allows you to select the

display mode. See page 18.

Clock Display: Allows you to select the

clock display.

Note

• This option is available when [Display Mode] is set to [Image and Clock] or [Full Screen Clock].

Image Selection: Select image. Music Selection: Select music. Slideshow Setting: Select from

showing slideshow mode or single view photo.

Music Playback Setting: Select from

listening to all tracks or a single music track.

Duration: Select the time period after

which the TV automatically switches to standby mode.

First day of the week: Sets [Sunday] or

[Monday] as the first day of the week on the calendar.

USB Auto Start

When USB device is connected to the USB port, select [On] to automatically view the thumbnail of the last played Photo/ Music/Video.

Select [Agree] or [Disagree] for Privacy Policy confirmation. (page 15)

Privacy Setup*

Manages your personal information.

* Only on limited region/country/TV model.

Clock/Timers

Sets the timer and clock.

Sleep Timer: Sets the time in minutes

that you would like the TV to remain on before shutting off automatically.

On Timer: Turns on the TV from

standby mode at a time you set, and tuned to a channel or input of your preference. Before setting this function, make sure you set the correct current time.

Clock Set: Sets the current time and

date.

Auto/Manual

Select [Manual] to set current time manually.

Automatic time zone

Sets whether or not to automatically select the time zone you are in. On: Automatically switches between

summer time and winter time according to the calendar.

Off: The time is displayed according to

the time difference set by [Time Zone ].

Automatic daylight saving time

Sets whether or not to automatically switch between summer time and winter time.

Date

Set current date.

Time

Set Current Time.

Time Zone

Allows you to manually select the time zone you are in, if it is not the same as the default time zone setting for your country/region.

Recording Setup (Function not available in Italy)

To register and deregister HDD for recording fun ction.

Recording time auto update:

Recording time will be updated automatically based on changes in the broadcast signal.

Off

Recording time will be based on time of the booking/reservation.

It is recommended not to change this menu setting when you have existing booked timers.

Auto Startup

Starts the initial setup procedure. This option allows you to retune the TV after moving houses, or to search for new channels that have been launched by broadcasters.

Language

Select the language in which the menus are displayed.

Physical keyboard (for web browser* only) (Except KDL-43RF4xx)

Select the physical keyboard language when physical keyboard is connected to the TV.

* Only on limited region/country/TV model.

Start-up Logo

Select [On] to display the logo when the TV is turned on. Select [Off] to disable it.

LED Indicator

Select [On] to light up the LED indicator. Select [Off] to disable it.

AV Setup

AV Preset: Assigns name to external

equipment input.

Enable

Select [Auto] to display names only when the equipment is connected, or [Always] to display regardless of connection status.

Colour System: Selects the colour

system according to the composite video signal from the input source.

Speakers: Select sound output from

the TV speakers or external audio equipment.

Headphone/Audio Out: Sets the sound

output to headphone, external audio systems or Active Subwoofer connected to the TV. Disconnect headphone from the TV when you select [Audio out (Fixed)], [Audio out (Variable)] or [Subwoofer].

Audio out (Fixed)

The audio output of the TV is fixed. Use your audio receiver’s volume control to adjust the volume (and other audio settings) through your audio system.

Audio out (Variable)

When using an external audio system, volume output from audio out can be controlled using the TV’s remote control.

Headphone Speaker Link: Switches the

TV’s internal speakers on/off when you connect headphone to the TV.

Headphone Volume: Adjusts the

volume of the headphone.

Note

• This option is not available, when [Headphone/Audio Out] is set to [Audio out (Fixed)], [Audio out (Variable)] or [Subwoofer].

Subwoofer: To enable, set

[Headphone/Audio Out] to [Subwoofer].

Subwoofer Level

Adjust subwoofer volume level.

Phase

Select the phase polarity.

Subwoofer Sync

Adjusts the time lag of Subwoofer sound.

Digital Audio Out: Sets the audio signal

that is output by connecting using digital audio output (optical)* cable or HDMI cable.

* Only on limited region/country/TV model

Auto 1

Output compressed audio without change.

Auto 2

Output only compressed audio for multichannel content without change.

PCM

Always output in PCM.

TV Position: Improves the speaker

settings when set as [Table-Top Stand] or [Wall Mount] according to your TV’s position.

HDMI Signal Format (Only on limited

region/country/TV model):

Standard

Standard HDMI format for normal use.

Enhanced

Set only when using devices supporting HDMI 2K HDR (High Dynamic Range) format.

Note

• HDMI IN 1 and HDMI IN 2 signal format changes at the same time.

• Change to [Standard] if the picture and sound do not output correctly in [Enhanced].

• Some contents may not be displayed as 2K HDR when 4K HDR contents playback from a source device.

BRAVIA Sync Settings

Allows the TV to communicate with equipment that is compatible with the BRAVIA Sync Control function, and connected to the HDMI ports of the TV. Note that communication settings must also be made on the connected equipment.

BRAVIA Sync Control: Sets whether or

not to link the operations of the TV and the connected equipment that is compatible with BRAVIA Sync Control. When set to [On], the following functions are available. If the specific Sony equipment that is compatible with BRAVIA Sync Control is connected, this setting is applied to the connected equipment automatically.

Auto Devices Off: When set to [On], the

connected equipment that is compatible with BRAVIA Sync Control turns off when your TV goes to standby mode.

Auto TV On: When set to [On], the TV

turns on when you turn on the connected equipment that is compatible with BRAVIA Sync Control.

BRAVIA Sync Device List: Displays a list

of connected equipment that is compatible with BRAVIA Sync Control. Select [Enable] to update the [BRAVIA Sync Device List].

Device Control Keys: Select button

functions of the TV’s remote control to operate the connected equipment.

None

Deactivates the control by the TV’s remote control.

Normal

For basic operations, such as navigation buttons (up, down, left or right, etc.).

Tuning Keys

For basic operations and operation of channel-related buttons, such as PROG +/– or (0-9), etc. Useful when you control a tuner or set-top box, etc.; via the remote control.

Menu Keys

For basic operations and operation of the HOME/OPTIONS buttons. Useful when you select menus of a BD player, etc.; via the remote control.

Tuning and Menu Keys

For basic operations and operation of channel-related buttons and HOME/ OPTIONS buttons.

Note

• Some equipment with [BRAVIA Sync Control] does not support the [Device Control Keys ] feature.

Network Setup (United Kingdom model KDL-43RF4xx only)

Allows you to set up the IP settings of the TV's Ethernet port and establish a network connection.

Note

• For LAN connections, use a Category 5 cable (not supplied).

• This TV supports additional content/services provided by the MHEG Internet Connected Services feature. General Internet (IPTV/Web service/e-mail, etc.) is not supported by this TV.

Customer Support

Provides information of your TV’s model, software, and others. For details, see page 30.

Network Setup

(Except KDL-43RF4xx)

View Network setting and status

Displays network setting and status.

Set up network connection

Allows you to set up the network connection.

Customer Support

Model Name

Displays model name of your TV.

Software Version

Displays current software version of your TV.

Digital

Select [System Information] to display digital channel information of your TV.

External Inputs

Select [View AV Preset] to view or manage the TV input.

Picture Check

View Test Picture: Allows you to check the

picture condition on the display.

Eco

Reset

Resets the current Eco settings to the default values.

Power Saving

Reduces power consumption of the TV by adjusting the backlight. When you select [Picture Off], the picture is switched off. The sound remains unchanged.

Idle TV standby

Turns the TV off after it has been kept idle for the preset length of time.

USB System Update (KDL-43RF4xx only)

Select to perform system update.

Software Update (Except KDL-43RF4xx)

Updates the TV system using USB memory or via Network.

Note

• Software update via the internet may vary depending on your region/country/TV model.

• To update the software, please visit Sony support website.

Automatic Software Download

Select [On] to download the software automatically. Select [Off] to disable it.

Factory Settings

Resets all settings to factory settings. After completing this process, the initial setup screen is displayed.

Note

• Be sure not to turn the TV off during this period (it takes about 30 seconds) or press any buttons.

Initialize Personal Information (Except KDL-43RF4xx)

You can erase your personal information stored in the TV.

Product Support

Displays your TV’s product information.

Help Guide (Except KDL-43RF4xx)

Help feature offers a lot of information about your TV.

Legal information (Except KDL-43RF4xx)

Display the notices and licenses for software used in this television.

Help Guide

(Except KDL-43RF4xx)

Help Guide

Help feature offers a lot of information about your TV.

Home Screen

(Only on limited region/country/TV model)

Recommendations Row

Select [On] or [Off] to display recommended contents.

Recent Apps

Select [On] or [Off] to display recently used apps.

Recent Channels

Select [On] or [Off] to display recently viewed channels.

Viewing Pictures from Connected Equipment

Audio System with Optical Audio Input

HDMI Device

Digital still camera/ Camcorder/USB storage media

Headphone/ Audio System/ Subwoofer

Router

VCR/Video game equipment/ DVD player/Camcorder/External Box

Conditional Access Module

Cable/ Antenna (aerial)/ External Box

Satellite

Audio System with ARC/HDMI Device

< 12 mm

< 21 mm

< 14 mm

Connection Diagram

You can connect a wide range of optional equipment to your TV.

Note

• Depending on TV model, connecting a large USB device may interfere with other connected devices beside it.

• When connecting a large USB device, connect only 1 USB jack.

Note

Terminals, labels and functions may vary depending on region/country/TV model.

Supports 3-pole stereo mini jack only.

For an external device which has only SCART AV OUT, use a SCART-RCA adapter.

Using Audio and Video Equipment

1 Turn on the connected equipment. 2 Press to display the input source. 3 Press / then to select the desired

input source.

The highlighted item is selected if 5 seconds pass without any operation.

Note

• When connecting a digital audio system not compatible with Audio Return Channel (ARC) technology using a n HDMI cable, you need to connect an optical audio cable to the DIGITAL AUDIO OUT (OPTICAL)* to output digital sound.

• When connecting with an HDMI cable, be sure to use HighSpeed HDMI Cable with Cable Type Logo (Recommended SONY Cable).

• When connecting mono equipment, connect the audio cable to the L (mono) jack.

* Only on limited region/country/TV model.

To use BRAVIA Sy nc devi ces

When connecting the TV to BRAVIA Sync compatible equipment, you can control them together. Be sure to perform the necessary settings in advance. The BRAVIA Sync Control settings must be set on both the TV and the connected equipment. See [BRAVIA Sync Settings] (page 29) for the settings on the TV side. Refer to the connected equipment operating instructions for the settings on the connected equipment side.

Using Screen mirroring

(Except KDL-43RF4xx)

Screen mirroring displays the screen of a compatible device (e.g. smartphones) on your large TV screen by Miracast technology. No wireless router (or access point) is required to use this feature.

1 Press the / button, then select

[Screen mirroring] using

/ buttons.

2 Operate the Screen mirroring

compatible device to connect with the TV. Once connected, the device screen will be displayed on the TV.

To list connected devices/deregister device

When the waiting screen for the Screen mirroring is displayed, press OPTIONS, then select [Show Device List / Delete]. To deregister a device, select the device in the list to delete, press . Then, select [Yes] in the confirmation display.

To display registration notification when attempting to connect a device with the TV

Activating this function can avoid an unintended device from being connected. When the standby screen for Screen mirroring is displayed, press OPTIONS, then select [Registration Notification] Note that once you decline registration request from a device, you will not be able to connect the device unless you delete it from the device list.

To change the band setting (for experts)

When the standby screen for Screen mirroring is displayed, press OPTIONS, then select [Band Setting].

Note

• Connecting devices must conform to the following:

Screen mirroring compatible devices:

2.4 GHz connection (5 GHz not supported).

• For information about the supported wireless band of your device, refer to the instruction manual of your device.



[On].

Installing the TV to the Wall

This TV’s instruction manual only provides the steps to prepare the TV for Wall-Mount installation before it is installed on the wall.

To Customers:

For product protection and safety reasons, Sony strongly recommends that installation of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself.

To Sony Dealers and Contractors:

Provide full attention to safety during the installation, periodic maintenance and examination of this product.

Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.

Use the Wall-Mount Bracket SU-WL450 (not supplied) to install the TV to the wall. When installing the Wall-Mount Bracket, also refer to the Operating Instructions and Installation Guide supplied with the Wall-Mount Bracket.

For instructions on Wall-Mount Bracket installation, see the Installation Information (Wall-Mount Bracket) on the product page for your TV model. www.sony.eu/support/

Additional Information

Troubleshooting

When the LED indicator is flashing red, count how many times it flashes (interval time is three seconds).

If the LED indicator flashes red, reset the TV by disconnecting the mains lead from the TV for two minutes, then turn on the TV. If the problem persists, contact your dealer or Sony service centre with the number of times the LED indicator flashes red (interval time is three seconds). Press  on the TV to turn it off, disconnect the mains lead, and inform your dealer or Sony service centre.

When the LED indicator is not flashing, check the items as follows.

If the p roblem persists , hav e you r TV serv iced by qualified service personnel.


No picture (screen is dark) and no sound

 Check the antenna (aerial)/cable connection.  Connect the TV to the mains socket, and press 

on the TV or the remote control.

No picture or no menu information from equipment connected to the video input jack appears on the screen

 Press to display the connected equipment

list, then select the desired input.

 Check the connection between the optional

equipment and the TV.

Double images or ghosting

 Check the antenna (aerial)/cable connection,

location or direction.

Only snow and noise appear on the screen

 Check if the antenna is broken or bent.  Check if the antenna has reached the end of its

serviceable life (three to five years in normal use, one to two years at the seaside).

Distorted picture (dotted lines or stripes)

 Keep the TV away from electrical noise sources

such as cars, motorcycles, hair-dryers or optional equipment.

 When installing optional equipment, leave some

space between the optional equipment and the TV.

 Check the antenna (aerial)/cable connection.  Keep the antenna cable away from other

connecting cables.

Picture or sound noise when viewing a TV channel

 Adjust [AFT] (Automatic Fine Tuning) to obtain

better picture reception. This function is for analogue TV channels only.

Tiny black points and/or bright points appear on the screen

 The picture of a display unit is composed of

pixels. Tiny black points and/or bright points (pixels) on the screen do not indicate a malfunction.

Picture contours are distorted

 Change the current setting of [Film Mode] to

other settings (page 21).

No colour on programmes

 Select [Reset] (page 21).

No picture from the connected equipment appears on the screen

 Turn the connected equipment on.  Check the cable connection.  Press to display the connected equipment

list, then select the desired input.

 Correctly insert the memory card or other storage

device in the digital still camera.

 Use a digital still camera memory card or other

storage device that has been formatted according to the instruction manual supplied with the digital still camera.

 Operations are not guaranteed for all USB

devices. Also, operations differ depending on the features of the USB device and the video being played.

Cannot select the connected equipment on the menu or cannot switch the input

 Check the cable connection.

Sound

No sound, but good picture

 Press  +/– or  (Mute).  Check if [Speakers] in [AV Setup] is set to [TV

Speakers] (page 28).

 Check if the headphone plug is connected to the

TV.

No sound or noisy sound

 Check if the TV system setting is appropriate

(page 22).

Channels

The desired channel cannot be selected

 Switch between digital and analogue mode and

select the desired digital/analogue channel.

Some channels are blank

 The channel is for scrambled/subscription service

only. Subscribe to a pay TV service.

 Channel is used only for data (no picture or

sound).

 Contact the broadcaster for transmission details.

Digital channels are not displayed

 Contact a local installer to find out if digital

transmissions are provided in your area.

 Upgrade to a higher gain antenna.

To change the tuning range (available depending on your region/country)

 Press the HOME button, then select [Settings]* t

[System Settings] Setup]

t [Digital Tuning] t [Auto Tuning

Range]. [Normal] Searches for available channels within your region/country. [Full] Searches for available channels regardless of region/country.

Note

• [Auto Service Update] is available depending on your region/country.

Hint

• You can run [Digital Auto Tuning] after moving to a new residence, changing service providers, or to search for newly launched channels.

• It is recommended that you set [Digital Setup] t [Technical Setup] t [Auto Service Update] to [On] to allow new digital services to be added automatically as they become available. If it is set to [Off], you will be notified of new digital services by an on-screen message and the ser vices will not be automatically added. The availability of this function depends on your region/country. If unavailable, perform [Digital Auto Tuning] to add new services.

t [Channel Setup] t [Digital

Network

* Cannot use VOD service during

recording.

What kind of devices can be connected to use the Screen mirroring function?

 Sony Screen mirroring compatible devices

(Xperia) can be connected.

Video or sound sometimes cuts out

 Devices emitting radio waves, such as other

wireless LAN devices or microwave ovens, may interfere with the Screen mirroring function using wireless LAN. Keep the TV or Sony Screen mirroring compatible devices (Xperia) away from such devices, or turn them off if possible.

 Communication speed may change according to

the distance or obstacles between devices, device configuration, radio wave condition, line congestion or what device you use. Communication may cut out due to the radio wave condition.

Some pay contents cannot be played

 The source device needs to be compatible with

HDCP (High-bandwidth Digital Content Protection) 2.2 system. Some pay contents may not be displayed via a non-compatible source device.

Apps are inaccessible

 Check that the LAN cable or mains lead of the

router/modem* has been connected properly.

* Your router/modem must be set in advance to

connect to the Internet. Contact your Internet service provider for router/modem settings.

 Try using apps later. The app content provider’s

server may be out of service.

Sometimes video streaming quality is poor when using the wireless LAN

 The wireless network connection quality varies

depending on the distance or obstacles (e.g. wall) between the TV and the wireless router (access point), environment interference, and quality of the wireless router (access point).

Wireless LAN connection fails or radio reception conditions are poor

 Check the installation location of the TV and

wireless router (access point). Signal condition may be affected for the following reasons.  Other wireless devices, microwaves,

fluorescent lights, etc., are placed nearby.

 There are floors or walls between the wireless

router (access point) and TV. If the problem persists even after checking the above, try making a wired LAN connection.

Poor picture on Internet Video

 Quality depends on the original video provided by

the internet content provider and your connection bandwidth.

Certain internet content displays a loss of detail, especially during fast-motion or dark scenes

 Video quality and picture size depend on

broadband speed and delivery by content providers.

Good picture quality but no sound on the internet content

 Quality depends on the original content provided

by the internet content provider and your connection bandwidth.

 Due to the nature of Internet video, not all videos

will contain sound.

Your TV cannot connect to the server

 Check the LAN cable or connection to your server

and your TV.

 Check if your network is properly configured on

your TV.

A message appears stating that the TV cannot connect to your network

 Check the current network settings. Press HOME,

then select [Settings]* [Setup]

t [Network] t [Network Setup] t

t [System Settings] t

[View Network setting and status]. If all of your network settings are “-”, your server may not be connected properly. Check your network connections and/or server’s instruction manual for connection information.

 Reconfigure your network settings.  If the LAN cable is connected to an active server

and the TV has acquired an IP address, check your DLNA Certified™ media server’s connections and configurations.

Note

 Your IP address configuration can be viewed by

selecting the [View Network setting and status] option.

DLNA Certified™ media server is inaccessible although it is listed under [Media] in the Home Menu

 Check your LAN cable/connection or your server

connections. The TV may have lost connection with the server.

 Perform [Server Diagnostics] to check if your

media server is properly communicating with the TV. Press HOME, then select [Settings]* [System Settings] [Home Network Setup]

t [Setup] t [Network] t

t [Server Diagnostics].

When using the renderer function, music files cannot be played back

 Some applications display a photo file pre-

installed in the PC simultaneously with music playback when using the renderer function. Depending on the pre-installed photo file, music playback may not be possible, but may become possible by changing the photo file.

You could not connect Internet

 Check that the LAN cable or mains lead of the

router/modem* has been connected properly.

* Your router/modem must be set in advance to

connect to the Internet. Contact your Internet service provider for router/modem settings.

You do not have YouTube ID

 If you do not have a YouTube ID and password,

register them through the address below. http://www.google.com/device (You can also register a YouTube ID and password from your PC.) After registering your ID, you can use it immediately.

General

The TV turns off automatically (the TV enters standby mode)

 Check if the [Sleep Timer] is activated (page 27).  Check if the [Duration] is activated by [On Timer]

(page 27) or [Photo Frame Settings] (page 27).

 Check if the [Idle TV standby] is activated

(page 30).

Some input sources cannot be selected

 Select [AV Preset] and select [Always] of the input

source (page 28).

The remote control does not function

 Replace the batteries.

HDMI equipment does not appear on [BRAVIA Sync Device List]

 Check that your equipment is compatible with

BRAVIA Sync Control.

Cannot select [Off] in [BRAVIA Sync Control]

 If you have connected any audio system that is

compatible with BRAVIA Sync Control, you cannot select [Off] in this menu. To change the audio output to the TV speaker, select [TV Speakers] in the [Speakers] menu (page 28).

The [Parental Lock] password has been forgotten

 Enter 9999 for the PIN code.  Update PIN code by pressing HOME and select

[Settings]* Lock]

t [System Settings] t [Parental

t [Change PIN Code].

Store Display Mode or Promoting Feature Logo appears on the screen

 On the remote control, press RETURN then

press HOME and select [Settings]* Settings] select [Home] in [Location].

* Only on limited region/country/TV model

t [Setup] t [Auto Startup]. Be sure to

t [System

Specifications

System

Panel system

LCD (Liquid Crystal Display) Panel, LED Backlight

TV system

Depending on your country/area selection/TV model Analogue: B/G, D/K, I Digital:DVB-T/DVB-C

Satellite*1: DVB-S/DVB-S2

Colour/video system

Analogue: PAL/SECAM/NTSC3.58 (video only)/ NTSC4.43 (video only) Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC MP/HP@L4.0, H.265/HEVC MP/Main10@L4.1 (Full HD 60fps)

Channel coverage

Depending on your country/area selection/TV model Analogue: UHF/VHF/Cable Digital: UHF/VHF/Cable Satellite*

Sound output (Only for 19.5 V supply)

5 W + 5 W

Wireless technology (Except KDL-43RF4xx)

Frequency band(s)

Frequency range Output Power

2400 - 2483.5 MHz < 20.0 dBm

Software version

TV: v8.___-____-_.___-____ / v8.___-____* Refer to [Customer Support] under [Setup] menu. Any updates of software/firmware for this equipment/accessories/components will never affect its conformity to Directive 2014/53/EU in future.

* Only on limited countr y/region/TV model.

DVB-T2*

: IF Frequency 950-2,150 MHz

Wireless LAN (IEEE802.11b/g/n)

Input/Output jacks

Antenna (aerial)/cable

75 ohm external terminal for VHF/UHF

Satellite antenna*

Female F Type Connector, 75 ohm. DiSEqC 1.0, LNB 13 V/18 V & 22 kHz tone, Single Cable Distribution EN50494.

/ AV IN

Video/Audio input (phono jacks)

HDMI IN 1/2 (HDCP 1.4-compatible)

Video:

1080p(30, 50, 60 Hz), 1080/24p, 1080i(50, 60 Hz), 720p(30, 50, 60 Hz), 720/24p, 576p, 576i, 480p, 480i

PC input:

(Resolution, Horizontal frequency, Vertical frequency)

640 × 480, 31.5 kHz, 60 Hz 800 × 600, 37.9 kHz, 60 Hz 1,024 × 768, 48.4 kHz, 60 Hz *1,280 × 720, 44.8 kHz, 60 Hz 1,280 × 1,024, 64.0 kHz, 60 Hz 1,152 × 864, 67.5 kHz, 75 Hz 1,600 × 900, 55.9 kHz, 60 Hz 1,680 × 1,050, 65.3 kHz, 60 Hz *1,920 × 1,080, 67.5 kHz, 60 Hz

* The 1080p and 720p timing when applied to the

HDMI input will be treated as a video timing and not PC timing for Screen Format.

Audio:

Two channel linear PCM: 32/44.1/48 kHz 16/20/ 24 bits, Dolby Digital, Dolby Digital Plus, DTS

ARC (Audio Return Channel) (HDMI IN 1 only)

Two channel linear PCM: 48 kHz 16 bits, Dolby Digital, Dolby Digital Plus, DTS

DIGITAL AUDIO OUT (OPTICAL)

Digital optical jack (Two channel linear PCM: 48 kHz 16 bits, Dolby Digital, DTS)

AUDIO OUT / (Stereo mini jack)

Headphone, Audio output, Subwoofer

1, 2 (HDD REC) (Function not available

in Italy)

USB port

CAM (Conditional Access Module) slot

DC IN 19.5 V

Mains adaptor input

(Except KDL-43RF4xx)

LAN (Depending on your country/area)

10BASE-T/100BASE-TX connector (Depending on the operating environment of the network, connection speed may differ. 10BASE-T/ 100BASE-TX communication rate and communication quality are not guaranteed for this TV.)

Others

Optional accessories

Wall-Mount Bracket: SU-WL450

Operating temperature

0 ºC – 40 ºC

Operating humidity

10 % – 80 % RH (non-condensing)

Power, Product Fiche and others

Power requirements

19.5 V DC with mains adaptor Rating: Input 220 V - 240 V AC, 50 Hz

Energy Efficiency Class

KDL-50WF6xx: A KDL-43WF6xx: A+ KDL-43RF4xx: A+

Screen size (measured diagonally) (approx.)

KDL-50WF6xx: 125.7 cm / 50 inches KDL-43WF6xx / 43RF4xx: 108.0 cm / 43 inches

Power consumption In [Standard] mode

KDL-50WF6xx: 80 W KDL-43WF6xx / 43RF4xx: 51 W

In [Vivid] mode

KDL-50WF665: 128 W KDL-50WF663: 117 W KDL-50WF660: 117 W KDL-43WF665: 81 W KDL-43WF663: 60 W KDL-43WF660: 60 W KDL-43RF455: 81 W KDL-43RF453: 60 W KDL-43RF450: 60 W

Average annual energy consumption*

KDL-50WF6xx: 117 kWh KDL-43WF6xx/ 43RF4xx: 74 kWh

Standby power consumption*3*

0.50 W

Display resolution

1,920 dots (horizontal) × 1,080 lines (vertical)

Dimensions (Approx.) (w × h × d)

wi th Tab le-Top Sta n d

KDL-50WF6xx: 113.0 x 71.7 x 26.8 cm KDL-43WF6xx / 43RF4xx: 97.4 × 62.8 × 26.8 cm

without Table-Top Stand

KDL-50WF6xx: 113.0 x 66.0 x 6.8 cm KDL-43WF6xx / 43RF4xx: 97.4 × 57.2 × 6.8 cm

Mass (Approx.)

wi th Tab le-Top Sta n d

KDL-50WF6xx: 11.4 kg KDL-43WF6xx / 43RF4xx: 8.2 kg

without Table-Top Stand

KDL-50WF6xx: 11 kg KDL-43WF6xx / 43RF4xx: 7.8 kg

Not all the TV sets have DVB-T2 or DVB-S/S2 technology or satellite antenna terminal.

Energy consumption per year, based on the power consumption of the television operating 4 hours per day for 365 days. The actual energy consumption will depend on how the television is used.

Specified standby power is reached after the TV finishes necessary internal processes.

(Except KDL-43RF4xx) Standby power consumption will increase when your TV is connected to the network.

Note

• Optional accessories availability depends on countries/region/TV model/stock.

• Do not remove the dummy card from TV CAM (Conditional Access Module) slot other than to insert a smart card fitted in CAM.

• Design and specifications are subject to change without notice.

Notes on Digital TV function

• Digital TV (DVB terrestrial, satellite and

cable), interactive services and network functions may not be available in all countries or areas. Some functions might not be enabled or might not operate correctly with some providers and network environments. Some TV service providers may charge a fee for their services.

• This TV supports digital broadcasting using

MPEG-2, H.264/MPEG-4 AVC and H.265/ HEVC codecs, but compatibility with all operator/service signals, which may change over time, cannot be guaranteed.

Notes on HDR (High Dynamic Range) (Only on limited region/country/TV model)

• Compatible with all HDR PS4 Game titles via HDMI and HDR videos of built-in Netflix and YouTube App only. (See Sony support website for more information).

• HDR image signal specifically means HDR10 Media Profile format (commonly referred to as HDR10).

• Compatibility with all HDR content is not guaranteed.

Trademark information

• The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

• Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories.

• “BRAVIA”, and BRAVIA Sync are trademarks or registered marks of Sony Corporation.

• “Blu-ray Disc”, “Blu-ray” and “Blu-ray Disc” logo are trademarks of Blu-ray Disc Association.

• “PlayStation” is a registered trademark and “PS4” is a trademark of Sony Interactive Entertainment Inc.

• For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS Digital Surround is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.

• TUXERA is a registered trademark of Tuxera Inc. in the US and other countries.

(Except KDL-43RF4xx)

• Wi-Fi®, Wi-Fi Alliance®, Wi-Fi Direct® and Miracast® are registered trademarks of Wi-Fi Alliance.

• Wi-Fi Protected Setup™ is a trademark of Wi-Fi Alliance.

• The Wi-Fi CERTIFIED™ Logo is a certification mark of Wi-Fi Alliance.

• Netflix is a registered trademark of Netflix, Inc.

• “YouTube” and the “YouTube logo” are registered trademarks of Google Inc.

For satellite models only:

• DiSEqC™ is a trademark of EUTELSAT. This TV supports DiSEqC 1.0. This TV is not intended for controlling motorized antennas.

• All other trademarks are the property of their respective owners.

(Except KDL-43RF4xx)

http://rd1.sony.net/help/tv/fceil1/h_cei/

Help Guide

(KDL-50WF6xx / 43WF6xx)

For useful information about Sony products

Sony KDL-50WF6, KDL-43WF6, KDL-43RF4 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

IMPORTANT NOTICE

Safety Information

Precautions

Parts and Controls

Remote Control

Connecting TV to the Internet

Setting up the Internet Connection

Type 1: Secured network with Wi-Fi Protected Setup™ (WPS)

Type 2: Secured network without Wi-Fi Protected Setup™ (WPS)

Type 3: Unsecured network with any type of wireless LAN router

Type 4: Wired network setup

Preparing a Wired Network

If You Cannot Connect to the Internet

Viewing the Network Status

USB Tethering

Privacy Policy

Watching TV

Changing the Viewing Style

Changing the Screen Format

Setting Scene Select

Navigating through Home Menu

Apps

All Apps

Photo Sharing Plus

Using the TV as a Photo Frame Mode

Channels

Programme List

Digital EPG

Recordings

Media

Playback Photo/Music/Video via USB

Playback Photo/Music/Video via Home Network

Settings

System Settings

Customer Support

Network Setup

Help Guide

Home Screen

Recommendations Row

Recent Apps

Recent Channels

Viewing Pictures from Connected Equipment

Connection Diagram

Using Audio and Video Equipment

Using Screen mirroring

Installing the TV to the Wall

Additional Information

Troubleshooting


Sound

Channels

Network

General

Specifications
