4-433-081-11(1)

LCD TV

Operating Instructions

Introducing Your New
BRAVIA

Getting Started

Operating the TV

Using Features

Using the Menus

Other Information

®

KDL-42EX441 / 42EX440 / 32EX340

Sony Customer Support

U.S.A.: http://www.sony.com/tvsupport
Canada: http://www.sony.ca/support

United States

1.800.222.SONY

Please Do Not Return
the Product to the Store

Canada

1.877.899.SONY

Owner’s Record

The model and serial numbers are located at the side
and rear of the TV. Record these numbers in the spaces
provided below. Refer to them whenever you call upon
your Sony dealer regarding this TV.

Model Name

Serial No.

CAUTION

To prevent electric shock and blade exposure, do not use
this polarized AC plug with an extension cord, receptacle or
other outlet unless the blades can be fully inserted.

❑ Operate the TV only on 110-240 V AC

(USA/Canada/Mexico 120 V AC).

❑ Avoid operating the TV at temperatures

below 41°F (5°C).

Licensing Information

Macintosh is a trademark of Apple Inc., registered in the U.S.
and other countries.

HDMI, the HDMI logo, and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI
Licensing, LLC in the United States and other countries.

Fergason Patent Properties, LLC:

U.S. Patent No. 5,717,422

U.S. Patent No. 6,816,141

Manufactured under license from Dolby Laboratories. Dolby
and the double-D symbol are trademarks of Dolby
Laboratories.

Blu-ray Disc is a trademark.

“BRAVIA” and , BRAVIA Sync, and are
trademarks or registered marks of Sony Corporation.

“PlayStation” is a registered trademark and “PS3” is a
trademark of Sony Computer Entertainment Inc.

Cleaning

When cleaning, be sure to unplug the power
cord to avoid any chance of electric shock.

• Wipe the LCD screen gently with a soft cloth.

• Stubborn stains may be removed with a
cloth slightly moistened with a solution of
mild soap and warm water.

• If using a chemically pretreated cloth, please
follow the instruction provided on the
package.

• Never use strong solvents such as a thinner,
alcohol or benzine for cleaning.

• See the supplied Safety Booklet for
additional information.

Your BRAVIA TV is ENERGY STAR® qualified
in the “Home” mode. It meets strict energy
efficiency guidelines set by the U.S.
Environmental Protection Agency and
Department of Energy.

ENERGY STAR is a joint program of these
government agencies, designed to promote energy efficient
products and practices. Changes to certain features,
settings, and functionalities of this TV (i.e. Picture/Sound,
Light Sensor, Power Savings) can increase or change the
power consumption. Depending upon such changed
settings, the power consumption may exceed the limits
required for the ENERGY STAR qualification in the “Home”
mode.

The 32 class has a 31.5 inch viewable image size (measured diagonally).

2

Contents

Introducing Your New BRAVIA

Welcome to the World of BRAVIA® . . . . . . . .4

Experiencing Stunning HD with Your

BRAVIA . . . . . . . . . . . . . . . . . . . . . . . . . . .4

The Four Steps to a Stunning HD

Experience . . . . . . . . . . . . . . . . . . . . . . . . .5

TV Feature Highlights . . . . . . . . . . . . . . . . . . .5

®

Getting Started

Setting Up Your TV. . . . . . . . . . . . . . . . . . . . .7

Attaching the Table-Top Stand . . . . . . . . . . . .8

Locating Inputs and Outputs . . . . . . . . . . . . .10

Connecting the TV . . . . . . . . . . . . . . . . . . . .12

Connecting Other Equipment . . . . . . . . . . . .16

When Installing the TV Against a Wall or

Enclosed Area . . . . . . . . . . . . . . . . . . . . .17

Securing the TV . . . . . . . . . . . . . . . . . . . . . .18

Running Initial Setup. . . . . . . . . . . . . . . . . . .20

Operating the TV

Using the Remote Control. . . . . . . . . . . . . . . 22

Remote Control Button Description . . . . . . .23

TV Controls and Indicators . . . . . . . . . . . . . .26

Using Features

BRAVIA® SyncTM with Control for HDMI . . . 28

Using PIP Feature. . . . . . . . . . . . . . . . . . . . .29

Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Wide Mode . . . . . . . . . . . . . . . . . . . . . . . . . .30

Wide Mode with PC . . . . . . . . . . . . . . . . . . .31

Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Playing back Photo/Music/Video via USB. . .32

Photo Frame

(KDL-42EX440/32EX340 only). . . . . . . . .34

Using the Menus

Navigating through TV Menus . . . . . . . . . . .36

Using the Picture Settings. . . . . . . . . . . . . . .38

Using the Sound Settings . . . . . . . . . . . . . . .40

Using the Screen Settings . . . . . . . . . . . . . .42

Using the Channel Settings . . . . . . . . . . . . .44

Using the Parental Lock Settings . . . . . . . . .45

Using the Setup Settings . . . . . . . . . . . . . . .48

Using the Eco Settings . . . . . . . . . . . . . . . . .53

Other Information

PC Input Signal Reference Chart for

PC and HDMI IN. . . . . . . . . . . . . . . . . . . . 54

Using a Wall-Mount Bracket . . . . . . . . . . . . .55

Installing the Wall-Mount Bracket . . . . . . . . .56

Troubleshooting . . . . . . . . . . . . . . . . . . . . . .65

Important Notices . . . . . . . . . . . . . . . . . . . . .71

Specifications . . . . . . . . . . . . . . . . . . . . . . . . 72

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

Customer Support

United States
http://www.sony.com/tvsupport
Canada
http://www.sony.ca/support

On-line Registration

United States
http://productregistration.sony.com
Canada
http://www.sony.ca/registration

3

Introducing Your New BRAVIA

®

Welcome to the World of BRAVIA

®

Thank you for choosing this Sony
documentation listed below to get the most out of your TV.

Safety Booklet

Contains precautionary
measures to keep you and
your TV safe. Read this
information prior to setting up
your TV.

Operating Instructions

Provides the most detailed
information to operate your
TV.

BRAVIA® high-definition television. Use the

Quick Setup Guide

Provides TV setup information with sample
connection diagrams.

Experiencing Stunning HD with Your BRAVIA

The quality of the image you see on your BRAVIA
signal it receives. To experience the stunning detail of your new
access to HD programming. Your
from:

BRAVIA

TV can receive and display HD programming

TV is only as good as the quality of the

BRAVIA

TV, you need

• Over-the-air broadcasting via HD-quality antenna

• HD cable subscription

• HD satellite subscription

• Blu-ray Disc™ player or other HD compatible external equipment

Contact your cable, satellite or HD service provider for information on upgrading to HD
programming.

4

The Four Steps to a Stunning HD Experience

Set, Source, Sound, and Setup

Along with your BRAVIA TV set, a complete HD system requires a source of HD
programming, an HD sound system, and a proper connection setup. Refer to the Quick
Setup Guide, enclosed separately, for connecting optional equipment.

You can enjoy crisp, clear images, smooth
movement, and high-impact visuals from 1080 HD
signals as shown here.
When you compare a high-definition signal to a
standard analog signal, you will notice a big
difference in picture quality. If black bars appear as
shown here, press WIDE on the remote control to fill
the screen.

TV Feature Highlights

Introducing Your New BRAVIA

®

Your BRAVIA comes with many convenient features, such as:

®

➢ BRAVIA

equipment supporting the Control for HDMI function (page 28).

➢ Digital Media Accessibility: Use the Photo, Music, and Video icons to

access photo, music, and video files from Sony USB equipment (page 32).

➢ PIP (Picture in Picture): You can work on your PC and watch your favorite TV

program simultaneously (page 29).

➢ Favorites: Your favorite channels and inputs are at your finger tips for easy

access (page 30).

➢ Auto Wide Mode: Set your TV to automatically adjust the screen based on the

signal resolution (page 30).

➢ Input Selection: Allows you to easily switch between the connected equipment

(page 32).

➢ Scene Select: Allows you to easily adjust your TV to the most suitable picture

and sound settings based on the scenes for the best quality result for the
contents genre you are watching (page 24).

SyncTM: Allows your BRAVIA TV to communicate with other Sony

(Continued)

5

➢ Photo Frame (KDL-42EX440/32EX340 only): You can enjoy the large photo

frame display with music (page 34).

➢ On Timer: Set timer to wake up TV automatically with preferred setting of input

and volume. You can also wake up with your favorite photo and music through
photo frame feature (page 50).

6

Getting Started

Setting Up Your TV

Some TV models are packaged with a detached Table-Top Stand so you can mount
your TV to a wall right away. If you are not mounting the TV to a wall, you will need to
attach the Table-Top Stand. You will need a Phillips screwdriver and the supplied
screws to complete the task. Look for the attachment instructions provided with the TV.
Be sure to consider the following while setting up your TV:

• Disconnect all cables when carrying the TV.

• Carry the TV with the adequate number of people; larger size TVs require two or more people.

• Correct hand placement while carrying the TV is very important for safety and to avoid damage.

• Ensure your TV has adequate ventilation, see page 17.

• For best picture quality, do not expose the screen to direct illumination or sunlight.

• Avoid installing the TV in a room with reflective wall and floor materials.

• Avoid moving the TV from a cold area to a warm area. Sudden room temperature changes may
cause moisture condensation. This may cause the TV to show poor picture and/or poor color.
Should this occur, allow moisture to evaporate completely before powering the TV on.

Getting Started

7

Attaching the Table-Top Stand

• Refer to the supplied stand leaflet for proper attachment.

• For best picture quality, do not expose the screen to direct illumination or sunlight.

1 Place the TV with its screen facing down on a level and stable surface covered with

a thick and soft cloth.

2 Fix the TV to the stand according to the arrow marks that guide the screw holes

using the supplied screws.

Thick and soft cloth

* Be careful not to hit the Table-Top Stand against the edge of

the surface when attaching it.

• To detach the Table-Top Stand from the TV, remove the three screws guided by the arrow mark
on the Table-Top Stand. Do not remove any other screws.

• Hold the Table-Top Stand with one hand to avoid it dropping when attaching.

• This TV is very heavy, so two or more people should place the TV onto thick and soft cloth.

• If using an electric screwdriver, set the tightening torque at approximately 1.5 N·m (15 kgf·cm).

Screw (+PSW 5 x 16)
(Supplied)

8

• Be sure to securely tighten the three supplied screws, otherwise the TV may fall down.

• Use an appropriate screwdriver to attach the screws tightly without damaging the screw head.

• Please ensure the AC power cord is away from the stand installation location when you attach
the stand.

• Do not touch the inner side of the bottom of the TV stand to avoid being hurt.

Getting Started

9

Locating Inputs and Outputs

Side PanelRear Panel

Item Description

1 CABLE/

ANTENNA

2 AUDIO OUT Connects to the audio input jacks of your analog audio equipment. You can

3 DIGITAL AUDIO

OUT (OPTICAL)

4 PC IN (RGB) Connects to a personal computer’s video and audio output connector. Can

1

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are

*

trademarks of Dolby Laboratories.

RF input that connects to your Cable or VHF/UHF antenna.

use these outputs to listen to your TV’s audio through your stereo system.

Connects to the optical audio input of digital audio equipment that is PCM/

1

Dolby*

also be connected to other analog RGB equipment. See “PC Input Signal
Reference Chart” on page 54 for the signals that can be displayed.
For some Apple Macintosh computers, it may be necessary to use an
adapter (not supplied). If an adapter is used, connect the adapter to the
computer before connecting the HD15-HD15 cable.
You may need to adjust the TV settings or your PC’s resolution and timing.
See page 15 for information on how to setup your PC to this TV.

Digital compatible.

10

Item Description

5 VIDEO IN/

COMPONENT
IN/R-AUDIO-L
(MONO)

67HDMI IN 1/2 HDMI (High-Definition Multimedia Interface) provides an uncompressed,

8 USB Connects to USB equipment to access photo, music, and video files.

• An HDMI or Component video (YPBPR) connection is required to view 480i, 480p, 720p, 1080i
and 1080p video formats. 1080/24p is available only with HDMI connection.

This input port can be used as a composite video input (VIDEO) or as a
component video input (COMPONENT). For composite use, connect the
yellow jack to Y for video and use audio L (mono) and R for audio signal.
For component connection, use Y, P
connect the audio L (mono) and R for audio signal.
This TV can auto detect and switch between the VIDEO and COMPONENT
when VIDEO or COMPONENT is connected.
To set to auto detection, press HOME, select Settings, and then select the

Setup settings. Select the Video/Component Selection option in AV
Setup then set to Auto.

all-digital audio/video interface between this TV and any HDMI-equipped
audio/video equipment, such as a set-top box, DVD player, and A/V
receiver. HDMI supports enhanced, or high-definition video, plus digital
audio. Be sure to use only an HDMI cable that bears the HDMI logo.
Use the HDMI IN 1 port when connecting DVI equipment. Use a DVI-to­HDMI cable or adapter (not supplied). Equipment using a DVI connection
also requires an additional audio connection using an audio cable
connected to PC/HDMI 1 AUDIO IN of PC IN.

, PR for video signals and also

B

Getting Started

11

Connecting the TV

Cable System or VHF/UHF Antenna System

You can enjoy high-definition and standard-definition digital programming (if available in
your area) along with standard-definition analog programming.
This TV is capable of receiving unscrambled digital programming for both cable (QAM
and 8VSB) and external VHF/UHF antenna (ATSC).

x Cable or VHF/UHF (or VHF only)

75-ohm coaxial cable Rear of TV

CABLE/ANTENNA

• It is strongly recommended that you connect the CABLE/ANTENNA input using a 75-ohm
coaxial cable to receive optimum picture quality. A 300-ohm twin lead cable can easily be
affected by radio frequency interference, resulting in signal degradation.

Cable System and VHF/UHF Antenna System

Use an optional A-B RF switch (not supplied) to switch between the cable and over-the­air antenna programming, as indicated below.

A/B RF Switch

Cable

Antenna

• Be sure to set the Signal Type setting to Cable or Antenna found under the Channel settings
for your input signal (page 44).

A

B

Rear of TV

CABLE/ANTENNA

12

HD Cable Box/HD Satellite Box

You can enjoy high-definition programming by subscribing to a high-definition cable
service or a high-definition satellite service. For the best possible picture, make sure you
connect this equipment to your TV via the HDMI or component video (with audio) input
located on the back of your TV.

x Shown with HDMI Connection

CATV/Satellite

Rear of TV

HD cable box/
HD satellite box

HDMI cable

x Shown with DVI Connection

antenna cable

CATV/Satellite
antenna cable

Getting Started

Rear of TV

Audio cable
(stereo mini plugs)

DVI-to-HDMI cable

HD cable box/
HD satellite box

(Continued)

13

x Shown with Component Connection

CATV/Satellite

Rear of TV

HD cable box/
HD satellite box

AUDIO-R (red)

AUDIO-L (white)

P

(red)

R

P

(blue)

B

Y (green)

Component video cable

Audio cable

• If your equipment has a DVI output and not an HDMI output, connect the DVI output to the HDMI
IN 1 (with DVI-to-HDMI cable or adapter) and connect the audio output to the AUDIO IN of PC
IN. For details, see page 10.

antenna cable

14

PC

Use the TV as a monitor for your PC by connecting an HD15-HD15 cable connection as
shown below. This TV can also be connected to a PC with a DVI or HDMI output. (Refer
to the separate Quick Setup Guide.)

Rear of TV

Audio cable (stereo mini plugs)

HD15-HD15 cable
(analog RGB)

• Connect the PC IN jack to the PC using an HD15-HD15 cable with ferrite core (analog RGB) and
audio cable (page 10).

Getting Started

15

Connecting Other Equipment

Blu-ray Disc Player/
“PS3”

DVD
player

Digital satellite
receiver

Digital
cable box

CABLE/ANTENNA

Analog audio equipment
(A/V Receiver/HomeTheater)

Digital audio equipment
(A/V Receiver/Home
Theater)

Personal computer

Audio
system

USB

Digital recorder

• Refer to the Quick Setup Guide (supplied) when connecting other equipment to your TV.

16

When Installing the TV Against a Wall or Enclosed Area

Make sure that your TV has adequate ventilation. Allow enough space around the TV as
shown below. Avoid operating the TV at temperatures below 41 °F (5 °C).

Installed with stand

11

4 inches
(10 cm)

7

/

8

(30 cm)

inches

4 inches
(10 cm)

3

inches

/

2

8

(6 cm)

Installed on the wall

11

4 inches
(10 cm)

7

inches

/

8

(30 cm)

4 inches
(10 cm)

Leave at least
this much space

4 inches (10 cm)

around the set.

Leave at least this much space around the set.

Never install the TV set as follows:

Air circulation is blocked.

Wall Wall

Air circulation is blocked.

• Inadequate ventilation can lead to overheating of the TV and may cause damage to your TV or
cause a fire.

Getting Started

17

Securing the TV

Sony strongly recommends taking measures to prevent the TV from toppling
over. Unsecured TVs may topple and result in property damage, serious bodily
injury or even death.

Preventing the TV from Toppling

❑ Secure the TV to a wall and/or stand.
❑ Do not allow children to play or climb on furniture and TV sets.
❑ Avoid placing or hanging items on the TV.
❑ Never install the TV on:

• slippery, unstable and/or uneven surfaces.

• furniture that can easily be used as steps, such as a chest of drawers.

❑ Install the TV where it cannot be pulled, pushed, or knocked over.
❑ Route all AC power cords and connecting cables so that they are not accessible to curious

children.

Recommended Measures to Secure the TV

Consider the following measures when securing your TV to a TV stand (not supplied).

1 Secure the stand for the TV.

Make sure the TV stand can adequately support the weight of the TV. Use two angle
braces (not supplied) to secure the stand.
For each angle brace use the appropriate hardware to:

• attach one side of the angle brace to the wall stud.

• attach the other side to the TV stand.

18

Angle braces

Stand

2 Secure the TV to the stand.

Use the optional hardware listed below (not supplied):

• M4 machine screw (screwed into the TV’s Table-Top Stand).

• A screw or similar (attach it to the TV stand).

• Rope or chain (strong enough to support the weight of the TV). Make sure that there is
no excess slack in the rope or chain.

An alternative way to secure the TV is with an optional Sony Support Belt Kit.

M4 machine

screw (not supplied)
Screw hole on the
Table-Top Stand

Rope or chain
(not supplied)

Screw
(not supplied)

The length of the M4 machine screw differs depending on the rope or chain
diameter. Please refer to below illustration.

Screw M4
Rope or chain

6-8 mm

TV’s Table-Top Stand

3 Anchor the TV to the wall.

Anchor the TV to the wall by using bolts, wall anchor and chain (or rope).

Wall-anchor
(not supplied)

Wall-mount

Anchor bolts
(not supplied)

holes

Rope or chain
(not supplied)

Getting Started

• Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV
model name.
For United States call: 1-800-488-7669 or visit: http://www.sony.com/accessories
For Canada call: 1-877-899-7669

• Securing the TV to the stand without securing the TV and the stand to the wall provides minimum
protection against the TV toppling over. For further protection, be sure to follow the three
measures recommended.

19

Running Initial Setup

During initial setup, you will perform the following:

• Set the language for the On Screen Display (OSD) text

• Choose your viewing environment

• Scan for digital and analog channels

• Set the current date and time after Auto Program.

Complete your cable connections before beginning the Initial Setup. Refer to the Quick
Setup Guide (supplied) for sample connection diagrams.

1 Turn on the TV.

The Initial Setup screen will appear.

2 Use the remote control buttons described below to navigate through the Initial

Setup.

V/v/B/b buttons:

Allow you to navigate and highlight options where applicable.

button:

Allows you to select the highlighted option and advance to the next screen.

3 Auto Program will scan for available channels from the signal source directly

connected to the TV’s CABLE/ANTENNA input. Follow the help text provided on the
screen to run the Auto Program.

4 Set the current date and time.

20

• If you cancel the Auto Program, any channels you have selected are not registered. To rescan
for available channels, run Auto Program.

• Connect either your cable or antenna to the TV (you can connect both using an A-B RF switch
(not supplied)); for more details see page 12.

Getting Started

21

Operating the TV

Using the Remote Control

To Insert Batteries into the Remote Control

Insert two size AA batteries (supplied) by matching e and E on the batteries to the
diagram inside the battery compartment of the remote control.

Push to
open

Guidelines to follow

• Point your remote control directly at the IR sensor
located on your TV.

• Make sure that no objects are blocking the path
between the remote control and the IR sensor on your
TV.

• Fluorescent lamps can interfere with your remote
control; try turning off the fluorescent lamps.

• If you are having problems with the remote control,
reinsert or replace your batteries and make sure that
they are correctly inserted.

22

Remote Control Button Description

Button Description

1

2

3

1 INPUT Press to display the list of External Inputs and TV

mode. Press repeatedly to toggle through the
inputs. See page 32.

2 SYNC

MENU

3 Equipment

Control

Press to display the BRAVIA Sync Menu and then
select connected HDMI equipment from

Device Selection

These buttons are used to control the equipment
connected to the TV by using the Control for

HDMI function (not available on all Control for
HDMI equipment). Some other buttons on the

remote control may also operate BRAVIA
equipment.

(PREV): Press to replay the current program

.

from the previous chapter mark.

X (PAUSE): Press to pause playback.
x (STOP): Press to stop playback.

(NEXT): Press to advance forward to the

>

next chapter mark.
m (fast reverse): Press to play a program in
fast rewind mode.
N (PLAY): Press to play a program at a normal
speed.
M (fast forward): Press to play a program in
fast forward mode.

.

HDMI

®

SyncTM

Operating the TV

• The 5, N and CH + buttons have a tactile dot. Use them as a reference when operating the TV.

(Continued)

23

Button Description

4 Colored

buttons

5 RETURN Press to go back to the previous screen or exit

6 HOME/

MENU

7 SCENE Optimizes picture and sound quality by selecting

When the colored buttons are available, an
operation guide appears on the screen.

from the screen when displaying menu items and
settings.

Press to display the menu with TV functions and
settings. See “Using the Menus” on page 36.

the following items.
Auto: Automatically optimizes picture and sound
quality according to the input source.
General: No optimized picture and sound quality
for any scene.
Photo: Reproduces the texture and color of a
printed photo.
Music: Lets you experience dynamic and clear
sound just like at a concert.
Cinema: Delivers picture and sound just like in a
theater.
Game: Broadens your game-playing experience
with superb picture and sound quality.
Graphics: Eases prolonged monitor viewing with
clearer detailed pictures.
Sports: Presents realistic pictures and sound just
like in a stadium.

• When you set Scene Select to Photo, Music, Cinema, Game or Sports, Sound Mode is
automatically set to Standard.

24

qs

qd

qf

qg

qh

8

9

0

qa ql

qj

qk

Button Description

8 0-9 Press 0-9 to select a channel.
9 Use with 0-9 to select digital channels.

For example, to enter 2.1, press , , and

.

0 VOL (2)

+/–

qa MUTING Press to mute the sound. Press again or press

qs POWER

"/1

qd DISPLAY Press once to display the banner with channel/

qf V/v/B/b Press V/v/B/b to move focus/highlight. Press

qg OPTIONS Press to display a list of convenient functions and

qh WIDE Press repeatedly to cycle through the available

qj CC Press to cycle through the available settings for

qk CH +/– Press to scan through channels. To scan quickly

ql JUMP Press to jump back and forth between two

Press to adjust the volume.

VOL + to restore the sound.

Press to turn on and off the TV.

program information you are watching. The
banner will time out in a few seconds or press
again to exit.

to select/confirm an item.

menu shortcuts. The options menu items vary
based on current input and content.

Wide Mode settings. See page 30.

Closed Captions (CC) : On, Off, and On when
Muting.

through channels, press and hold down either CH
+/–.

channels and external inputs. The TV alternates
between the current/last channel or external input
selected.

2 1

Operating the TV

25

TV Controls and Indicators

Item Description

1 (IR) Infrared

Receiver/
Light sensor

2 (Picture

Off)/
(Timer) LED

3 1 (Standby)

LED

4 " (Power) LED Lights up in green when the TV is turned on.
5 "/1 (Power) Touch to turn on and off the TV.
6 – CH + Touch to scan through channels. To scan quickly through channels, touch and

7 – 2 +Touch to adjust the volume. In the menu screen, these buttons serve as left/

8

t (Input)

Receives IR signal from the remote control.
Senses room light level and adjusts the screen brightness accordingly. Do not
put anything over the sensor, doing so may affect its function.

Lights up in orange when the timer is set or the TV is in Photo Frame Mode.
Lights up in green when the Power Saving is set to Picture Off.

Lights up in red when the TV is in standby mode.

hold down either CH –/+. In the menu screen, these buttons serve as up/down
buttons.

right buttons.
Touch to display the list of external inputs. Touch repeatedly to toggle through

the inputs.
In the menu screen, this button serves as confirming the selection or setting.

26

Item Description

9 HOME Touch to display menu with TV functions and settings (see “Using the Menus”

on page 36).

0 Speaker Outputs audio signal.

• For more information about setting up the external inputs labels, see page 50.

• Make sure that the TV is completely switched off before unplugging the power cord.

Operating the TV

27

Using Features

BRAVIA® SyncTM with Control for HDMI

With the Control for HDMI function,
BRAVIA Sync helps to communicate with
BRAVIA Sync-compatible equipment

using HDMI CEC (Consumer Electronics
Control). Use the following settings and
tips to help unify control of your
connected equipment.

1 Press HOME and select Settings,

then select the Setup settings.

2 Select the HDMI Settings, then

highlight Control for HDMI, and set to
On.

x Controlling BRAVIA Sync-

Compatible Equipment

To control the equipment by using the
remote control, press SYNC MENU and
select the desired equipment from HDMI
Device Selection.

Sync Menu

HDMI 1

HDMI Device Selection

Device Control

Speakers

TV Control

Return to TV

x AV Amplifier

• Automatically turns the connected AV
amplifier on and switches the sound output
from the TV speaker to the audio system
when you turn the TV on.

• Automatically switches the sound output to
the AV amplifier by turning the AV amplifier
on when the TV is turned on.

• Automatically turns the connected AV
amplifier off when you switch the TV to
standby mode.

• Adjusts the volume (VOL +/-) and mutes the
sound (MUTING) of the connected AV
amplifier through the TV’s remote control.

x Video Camera

• Automatically turns the TV on and switches
the input to the connected video camera
when the connected video camera is turned
on.

• Automatically turns the connected video
camera off when you switch the TV to
standby mode.

• Control for HDMI (BRAVIA Sync) is only
available for the connected Sony equipment
that has the BRAVIA Sync or is compatible
with Control for HDMI.

• The Control for HDMI settings must be set
on both the TV and connected equipment.
For settings on the connected equipment,
refer to their instruction manuals.

• When specific Sony equipment compatible
with Control for HDMI (BRAVIA Sync) is
connected, BRAVIA sync is automatically
activated on the equipment.

x BD/DVD Player

• Automatically turns the BRAVIA Sync-

compatible equipment on and switches the
input to that equipment when you select it
from the Sync Menu.

• Automatically turns the TV on and switches
the input to the connected equipment when
the equipment starts to play.

• Automatically turns the connected
equipment off when you switch the TV to
standby mode.

28

Using PIP Feature

PIP (picture in picture) displays a picture

from a connected PC in full screen, and a
TV program or other external input (see
below “To Enter PIP” table) in an inset
window. (Closed Captions (CC) is not
available with PIP mode.)

Sub Window
(Location of the

Main
Window
(PC)

To Enter PIP

PIP Supported Inputs

In main window In sub window

PC TV channel (CABLE/

ANTENNA), VIDEO
IN, HDMI IN 1/2
(video timing)

HDMI IN (PC timing) TV channel (CABLE/

ANTENNA), VIDEO
IN, COMPONENT IN

Sub Window
can be moved
by pressing
V/v/B/b.)

x To Swap Audio

You can swap audio between the main
and sub window.

1 Press OPTIONS.
2 Press V/v to highlight Audio Swap

and press .

3 Press V/v to highlight the window to

be audible, then press .

Using Features

1 Press OPTIONS while in the PC

mode.

2 Select PIP from the OPTIONS menu.
3 The sub window will appear.

x To Change Channels

You can change the channel of the sub
window by pressing CH +/– or entering
the channel number using the 0-9 numeric
and buttons.

x To Exit from PIP

You can exit from PIP, using any of the
following methods:

1 Press OPTIONS, press V/v to highlight

Exit PIP, then press to exit to the full PC

screen.

2 Press RETURN.

29

Favorites

Wide Mode

Your favorite channels and external inputs
can be accessed by pressing the HOME
button once they are added to the list.

1 Press HOME.
2 Press V/v to select Favorites, then

press .

The favorites list appears.

3 Press V/v to select a channel or input,

then press .

x To add to Favorites

While tuned to the channel you want to
watch or viewing connected equipment,
press HOME and select Favorites to
display the list. Highlight Add to
Favorites, then press . Your newly
added item will be listed at the top of the
list. When you continue to add items
beyond the 10th item, the item listed at the
bottom of the list will be automatically
removed from the list.

The Wide Mode feature allows you to
select the screen display of your
preference. Based on the original signal
source, you may see black bars around
the picture or just on the both sides of the
screen. Sometimes you will see the
picture filled the full screen. This is due to
the signals your TV receives.

You can manually select available Wide
Mode settings as you watch your TV by
pressing the WIDE button on your remote
control or you can set your TV to Auto
Wide.

x To set Auto Wide

Press HOME and select Settings, then
select the Screen settings.
Select Auto Wide and set to On.

x To change the Wide Screen Mode

Press WIDE repeatedly to cycle through
the available modes.

4:3 Original source 16:9 Original source

Standard­definition source

mm

Wide Zoom Wide Zoom

High-definition source

• Favorite channels and external inputs can
also be added using the OPTIONS button
on the remote control.

•Your Favorites list will be cleared each time
you run the Auto Program.

30

Normal Normal

This mode is not
available.

Full Full

4:3 Original source 16:9 Original source

Zoom Zoom

Normal is available with 480i or 480p

sources only.

Wide Mode with PC

Wide Mode is also available for the PC

settings. When a PC is connected to the
TV and PC input is selected, you can
change the PC Screen settings.

PC Settings


Sound

Screen

Channel

Parental Lock

Setup

Eco

ConfirmConfirm

Wide Mode

Reset

Auto Adjustment

Phase

Pitch

Horizontal Center

Vertical Center

x To change the Wide Screen Mode for

PC Timing

Press WIDE repeatedly to cycle through
the available modes while in the PC input
mode.

Incoming PC signal

Normal

RETURN

PC

0

0

0

0

Back

Using Features

800 × 600

m

Normal

Full 1

Full 2

• Use the Auto Adjustment to adjust the

display position and phase of the picture
when the TV receives an input signal from
the connected PC.

31

Inputs

Press INPUT to display the Input menu
and toggle through the external inputs to
select your video signal for viewing
including the TV mode. The inputs list
consists of TV mode and other equipment
connected to the TV.
You can label your external inputs to
identify them easily.

x To Manage on Input

Press HOME and select Settings, then
select the Setup settings. Select the
Manage Inputs option in AV Setup. Press

V/v to highlight the video input (HDMI 1-2,
Video, Component, PC) to which you

want to assign a label; press to select
the input of your choice.

x To Manage Label

Press B/b to highlight one of the
displayed labels that corresponds to your
connected equipment, then press .

x To Manage Enable

1 Press B/b to select enable column.
2 Press V/v to select Auto, Always or

Off. The selected input will be listed

always.

Playing back Photo/ Music/Video via USB

You can enjoy photo/music/video files
stored in a Sony digital still camera or
camcorder through a USB cable or USB
storage device on your TV.

1 Connect a supported USB device to

the TV.

2 Press HOME.
3 Press V/v to select Photo, Music, or

Video, then press .

The file or folder list appears.

4 Press V/v/B/b to select a file or folder,

then press .
When you select a folder, select a file,
then press .
Playback starts.

• If you connect the USB device when USB
Auto Start is set to On (page 48), the
thumbnail view of the last played Photo/
Music/Video appears automatically.

32

x Notes when playing back files

• While the TV is accessing the data on
the USB device, observe the following:

– Do not turn off the TV or connect USB

device.
– Do not disconnect the USB cable.
– Do not remove the USB device.

The data on the USB device may be
damaged.

• Sony will not be held liable for any
damage to, or loss of, data on the
recording media due to a malfunction of
any connected devices or the TV.

• USB playback is supported for the
following photo file formats:

– JPEG (JPEG format files with the extension

“.jpg” and conforming to DCF 2.0 or Exif

2.21)

• USB playback is supported for the
following music file format:

– MP3 (files with the extension “.mp3” that

have not been copyrighted)

• USB playback is supported for the
following video file format:

– MPEG1, MPEG2 (files with the extension

“.mpg”)

• USB Auto Start shows photo files in the
newest digital still camera folder (DCF­compliant, highest-numbered “DCIM”
folder).

• USB Auto Start may not work
automatically when some digital still
cameras are connected.

• The file name and folder name are only
supported in English.

• When you connect a Sony digital still
camera, set the camera’s USB
connection mode to “Auto” or “Mass
Storage.” For more information about
USB connection mode, refer to the
instructions supplied with your digital
camera.

• Use a USB storage device that is
compliant with USB Mass Storage Class
standards.

• The file system on the USB device
supports FAT16, FAT32 and NTFS.

Using Features

33

Photo Frame (KDL­42EX440/32EX340
only)

You can enjoy looking at photos, listening
to music, or seeing the clock and
calendar, at the same time.

Photo Frame Mode

Toda y NextPrevious

You can enter photo frame mode using
any of the following methods:

1 Press HOME, and then select Photo

Frame Mode.

2 Press OPTIONS, when you are playing

back the photo/music files.

x To select music

You can select music from USB memory,
using any of the following methods:

1 Press HOME and select Settings, then

Setup > Photo Frame Settings > Music
Selection.

Press to select the file from thumbnail
view.

2 In photo frame mode, press OPTIONS >

Music Selection.

Press to select the file from thumbnail
view.

3 Press HOME, and select Music. When

playing back music, press OPTIONS >

Photo Frame Mode to launch Photo
Frame with the selected music.

x To select Display mode

You can change the photo frame display
by selecting Display Mode (page 48).

• Image and Clock

You can switch the frame, e.g. image and
clock, full screen image or full screen
clock.
For more details, see page 48.

x To select photo

You can select photos from USB memory,
using any of the following methods:

1 Press HOME and select Settings, then

Setup > Photo Frame Settings > Image
Selection.

Press to select the file from thumbnail
view.

2 In photo frame mode, press OPTIONS >

Image Selection. Press to select the file

from thumbnail view.

3 Press HOME, and select Photo. When

playing back a photo, press OPTIONS >

Photo Frame Mode to launch Photo
Frame with the selected photo.

34

• Full Screen Image

• Full Screen Clock

x To select Clock Display mode

There are five calendar display modes.
When the Display Mode setting is set to

Image and Clock, you can set to
Calendar, Analog Clock or Digital
Clock. When the Display Mode setting is
set to Full Screen Clock, you can set to
Calendar, Calendar and Clock or Clock.

For more details, see page 48:

•Calendar

• Analog Clock

• Digital Clock

• Calendar and Clock

•Clock

x Duration

To save power, photo frame mode will
shut down after 24 hours of TV with power
off automatically. After running photo
frame mode for 24 hours, not use this
mode for at least one hour, to avoid panel
burn-in.
Duration time can be set to Duration in
Photo Frame Settings. For more details,
see page 48.

Using Features

To avoid panel burn-in, the position of the
photo, clock and calendar are switched
automatically every hour.

35

Using the Menus

Navigating through TV Menus

The HOME button allows you to access a variety of TV settings and USB media files.

1 Press on the remote control to display the menu

options.

2 Press V/v/B/b to navigate on the menu or adjust the

settings.

3 Press to select or confirm.
4 Press to exit.

You can select Photo Frame Mode which enables you to enjoy photo, music

Photo Frame

Mode

(KDL­42EX440/
32EX340
only)

Favorites

and clock. For details, see page 34.

The Favorites feature provides quick access to your frequently used items,
such as preferred TV channels or external inputs (e.g. game console, DVD
player). For details, see page 30.

36


Music

Video

The Photo, Music, and Video icons organize your photo, music, and video
files from USB connected equipment. Be sure to select the correct icon when
accessing files. Refer to the feature section for more information on these
icons (page 32).

Settings

The Settings icon contains all of the necessary configurations to customize
your TV settings. The options you can select may vary. Unavailable options
are grayed out or not displayed.

Picture: adjust the picture on your TV to fit your viewing preference.
Sound: customize your sound settings to suit your audio preference. You can

also change the settings to output the sound to your connected audio
equipment.

Screen: adjust the size and shape of the images you see on the screen.
Channel: navigate your favorite channels and inputs and select the signal type,

as well as autoprogram channels. You can also customize the channels you see
and the labels assigned to them.
Parental Lock: set the password and limit access to programming based on
rating levels. You can also block channels and inputs.

Setup: modify and customize a variety of general setting options.
Eco: changes the settings related to power consumption.

Using the Menus

37

Using the Picture Settings

Option Description

Picture Mode

Customized
picture viewing

Reset Resets the current Picture settings to their defaults, except Picture Mode.
Backlight Adjust to brighten or darken the backlight.
Picture Adjust to increase or decrease picture contrast.
Brightness Adjust to brighten or darken the picture.
Color Adjust to increase or decrease color intensity.
Hue Adjust to increase or decrease the green tones.
Sharpness Adjust to sharpen or soften the picture.
Color

Temperature

White adjustment

Noise Reduction Select to reduce the picture noise level. Select from Auto, High, Medium,

MPEG Noise
Reduction

CineMotion Provides improved picture movement and reduces picture blur and graininess

Displays the options selected in the Scene Select settings (page 24). When
Scene Select is set to General, the first three options below can be selected.

Vivid Select for enhanced picture contrast and sharpness.
Standard Select for standard picture settings. Recommended for home

entertainment.

Custom Select to store your preferred settings.
Cinema For film-based content. Suitable in a theater-like environment.
Photo For standard viewing of photographs.
Sports Optimizes picture quality for viewing sports.
Game For standard picture suitable for games.
Graphics Optimizes picture quality for viewing graphics.

Cool Select to give the white colors a bluish tint.
Neutral Select to give the white colors a neutral tint.
Warm 1/Warm 2Select to give the white colors a reddish tint. Warm 2 gives a

redder tint than Warm 1.

Low and Off.

Select to reduce the picture noise in MPEG-compressed videos. This is
effective when viewing a DVD or digital broadcast. Select from High, Medium,
Low and Off.

for film-based content. Select Auto to represent original film-based content as
is.

38

Option Description

Advanced
Settings

Reset Resets the advanced settings to the default values.
Adv. Contrast

Enhancer

Black
Corrector

Gamma Adjusts the balance between bright and dark areas of the

Clear White Emphasizes white colors. Select from High, Low and Off.
Live Color Makes colors more vivid. Select from High, Medium, Low

LED Motion
Mode

White Balance Adjusts the color temperature in detail.

Automatically adjusts backlight and contrast to the most
suitable settings judging from the brightness of the screen.
This setting is especially effective for dark scenes, and will
increase the contrast distinction of the darker picture scenes.
Select from High, Medium, Low and Off.

Enhances black areas of the picture for stronger contrast.
Select from High, Medium, Low and Off.

picture.

and Off.
Lights up the backlight adequately, reducing blur in movies,

but the brightness decreases.

•Available Picture options, including options in Advanced Settings depend on Scene Select
and Picture Mode.

Using the Menus

39

Using the Sound Settings

Option Description

Sound Mode

Customized
sound listening

Reset Resets the current Sound settings to their defaults, except MTS Audio,

Equalizer Adjust allows you to select your frequency response curve. Select Reset to

Balance Adjust to emphasize left or right speaker balance.
Steady Sound Select On to stabilize the volume across all programs and commercials.

Volume Offset Adjust the volume level of the current input relative to other inputs.
Surround Allows you to select the suitable surround effects depending on the genre of

Bass Booster Select On to produce a fuller sound for more impact, by emphasizing the bass

Sets a sound mode. Sound Mode includes options best suited for video and
photographs, respectively. The available options depend on the scene select
settings.

Dynamic Enhances treble and bass.
Standard Standard sound optimized for home use.
Clear Voice Suitable for spoken dialog.
Custom Select to store your preferred settings.

Alternate Audio and Speakers.

reset the Equalizer settings to the default values.

Select Off to disable this function.

TV program (movie, sport, music, etc.) or video game. The available options
depend on the scene select setting.

On/Off Select On to optimize the sound quality to enjoy the effects of

the Surround option and to create a virtual surround sound
using the 2ch speaker.

Cinema/Off Provides surround effects just like the high-grade audio

systems found in movie theaters.
This option is available when you select Cinema in the Scene

Select setting.

Music/Off Provides surround effects that make you feel like you are

surrounded by sound as in a music hall.
This option is available when you select Photo or Music in
the Scene Select setting.

Sports/Off Provides surround effects that make you feel like you are

watching a live sports contest.
This option is available when you select Sports in the Scene

Select setting.

Game/Off Provides surround effects that enhance game sound.

This option is available when you select Game in the Scene
Select setting.

sounds.
Select Off to disable this function.

40

Option Description

MTS Audio

Enjoy stereo,
bilingual and
mono programs

Alternate Audio

Digital channels
only

Speakers TV Speakers Select to use the TV speakers.

Audio Out Variable Adjusts the volume with the TV’s remote control, when using

HDMI/DVI Audio
Source

HDMI 1 input only

Stereo Select for stereo reception when viewing a program

broadcast in stereo.

Auto SAP Select to automatically switch the TV to second audio

programs when a signal is received. If no SAP signal is
present, the TV remains in Stereo mode.

Mono Select for mono reception. Use to reduce noise during weak

stereo broadcasts.

Select among the available options to switch among the alternate audio
streams. The program you are tuned to may be broadcasted in a different
language in the alternate audio streams.

Audio System Select to use an external audio system for the TV sound. By

selecting this option you are disabling the TV speakers.

an external audio system.

Fixed Adjusts the volume using the connected audio system’s

remote control.

Sets the audio signal source for HDMI/DVI input.
Auto Automatically sets the audio signal source based on the

video signal.

HDMI Audio Sets the HDMI input as the audio signal source.
PC Audio Sets the PC/HDMI audio input as the audio signal source.

Using the Menus

• MTS Audio is only available for analog programs.

• Alternate Audio is only available if the program is broadcast with alternate audio streams.

• You can also access Sound Mode, MTS Audio and Alternate Audio by using the OPTIONS
button on the remote control.

41

Using the Screen Settings

Option Description

Wide Mode Wide Zoom Fills the screen with minimum distortion.

Normal Select to display 4:3 picture in original size when the original

source is 4:3.

Full Select to enlarge the picture horizontally to fill the screen when

the original source is 4:3 (Standard definition source). When the
original source is 16:9 (High-definition source), select this mode
to display the 16:9 picture in its original size.

Zoom Select to enlarge the original picture without distorting the aspect

ratio.

Auto Wide On Select On to automatically change Wide Mode setting based on

the content.

Off If frequent screen changes are disturbing to you, select Off.

Choose one of the Wide Mode options when this function is set
to Off.

4:3 Default

Select the default
Screen Mode to
use for 4:3
sources

Auto Display
Area

Display Area Full Pixel Displays pictures in their original size when parts of the picture

Horizontal
Center

Wide Zoom Enlarges the 4:3 picture to fill the 16:9 screen, displaying as

much of the original image as possible.

Normal Select to display the 4:3 picture in its original size.
Off Select to continue using the current Wide Mode setting when the

channel or input is changed.

Select On to automatically adjust the picture to the most appropriate display
area.
Select Off to disable this function.

are cut off (available depending on the TV model).

+1 Displays pictures in their original size.

This option is only available for Digital TV and HDMI input signals
(non 1080i and 1080p video formats).

Normal Displays pictures in their recommended size.

-1 Enlarges the picture so that the edges are outside the visible

display area.

Allows you to move the position of the picture left and right. (Available in Wide
Zoom and Zoom.)

• Normal in the Wide Mode setting is not available when you are watching a 720p, 1080i or 1080p

source.

• If 4:3 Default is set to anything but Off, the Wide Mode setting changes only for the current
channel. When you change channels (or inputs), Wide Mode is automatically replaced with the
4:3 Default setting for 4:3 sources. To retain the current Wide Mode setting as channels and
inputs are changed, set 4:3 Default to Off.

• 4:3 Default is not available if Auto Wide is set to Off.

42

Option Description

Vertical Center Allows you to move the position of the picture up and down. (Available in Wide

Zoom and Zoom.)

PC Settings When a PC is connected to the TV and the PC input is selected, the PC

settings screen appears instead of the Screen settings.
You can also select the PIP feature which allows you to view two pictures
simultaneously from OPTIONS button (page 29).

Wide Mode Normal Select to display in the original image size.

Full 1 Select to enlarge the picture to fill the display area,

keeping its original aspect ratio.

Full 2 Select to enlarge the picture to fill the display area.
Reset Resets all PC settings to the default values.
Auto

Adjustment

Phase Adjust after Pitch to fine tune overall sharpness.
Pitch Adjust uneven sharpness on screen.
Horizontal

Center
Vertical

Center

Select to automatically adjust the display position and phase of

the picture when the TV receives an input signal from the

connected PC. Note that Auto Adjustment may not work well

with certain input signals. In such cases, manually adjust the

options below.

Allows you to move the position of the picture left and right.

Allows you to move the position of the picture up and down.

Using the Menus

• For the PC Input Signal Reference Chart, see page 54.

• Auto Adjustment, Phase and Pitch are not available with PC signal connected to HDMI input.

43

Using the Channel Settings

Option Description

Signal Type Cable Select if you are receiving cable channels via Cable TV

provider.

Antenna Select if you are using an antenna.

Auto Program Automatically sets up the channel list on the TV for all receivable channels.

1 Select Auto Program.
2 Select OK to start Auto Program.

Add Digital
Channels

Show/Hide
Channels

Edit Channel
Labels

Analog Fine
Tune

1 Select Add Digital Channels.
2 Select OK to add digital channels.

Allows you to show or hide channels that appear when you use the CH +/–
buttons.

1 Press V/v to scroll through the channels until you find the channel you

want to show or hide. Then press to select it.

2 Press V/v to determine if the channel will be shown or hidden. Then press

to select it.

Allows you to assign labels (such as station call letters) to channel numbers.

1 Press V/v to scroll through the channel numbers. Then press to

select the channel number that you want to assign a label.

2 Press V/v to scroll through the label characters (A-Z, 0-9, etc.). Press b to

move to the next character. Repeat the previous steps to add up to seven
characters to the label. When finished, press .

Allows you to fine-tune the selected analog channel manually if you feel that a
slight tuning adjustment may improve picture quality. Select Auto to adjust to
the most appropriate analog channel.

• You should run Auto Program after changing the Signal Type setting.

• Running Auto Program will clear the Favorites list.

• Channels that you set to be hidden can be accessed by the 0-9 and buttons.

• You can set channels to be hidden that are automatically set in Auto Program.

44

Using the Parental Lock Settings

Option Description

Password The Parental Lock settings allow you to set up the TV to block programs

according to their content and rating levels. Use 0-9 on the remote control to
enter a four-digit password. The first time you create a password, confirm the
password by entering it again.

Change
Password
Country U.S.A. Select to use U.S.A. ratings (page 46).

Rating Off Turn Parental Lock off. No programs are blocked from

Downloadable
U.S. Rating

(Available only
in U.S.A.
where advanced
ratings exist)

Unrated

(Available only
when Country is
set to U.S.A.)

Channel Block Allows you to block channels regardless of program ratings.

External Input
Block

Select to change your password.

Canada Select to use Canadian ratings (page 47).

viewing.

Child Maximum ratings permitted are:

U.S.: TV-Y, TV-G, G
Canada: C, G, TV-Y

Youth Maximum ratings permitted are:

U.S.: TV-PG, PG
Canada: C8+, PG, 8 ans+, TV-PG

Young Adult Maximum ratings permitted are:

U.S.: TV-14, PG-13
Canada: 14+, 13 ans+, TV-14

Custom Select to set ratings manually.

U.S.: See page 46 for details.
Canada: See page 47 for details.

Off Turn Downloadable U.S. Rating off. No programs that contain

downloadable ratings are blocked from viewing.

Custom Select to block programs based on downloadable ratings.
Clear All Select to clear the entire downloadable rating system.

Allow Allows programs and movies that are broadcasted without a

rating.

Block Blocks all programs and movies that are broadcasted without

a rating.

To View a Blocked Channel

Press when tuned to the blocked channel then enter the password.
Allows you to block external inputs regardless of program ratings.

To View a Blocked External Input

Press when tuned to the blocked input then enter the password.

Using the Menus

(Continued)

45

• You need your password for any future access into the Parental Lock settings. If you lose your

password, see “Lost password” on page 70.

• Selecting Clear All will delete the current Downloadable U.S. Rating menu and the menu will

no longer be available until the TV is tuned to a channel that contains downloadable ratings.

• If you block unrated TV programs, be aware that the following types of programs may be
blocked: programs broadcasted from another country, emergency broadcasts, political
programs, sports, news, public service announcements, religious programs and weather.

US Models: Selecting Custom Parental Lock Rating Options

To select custom rating options for the U.S., select U.S.A. in the Country setting (page

45).

Option Description

Movie Rating G All children and general audience.

PG Parental guidance suggested.
PG-13 Parental guidance for children under 13.
R Restricted viewing, parental guidance is suggested for

children under 17.

NC-17 and X No one 17 or under allowed.

TV Rating

Block programs
by their rating,
content or both

Age-Based Ratings

TV-Y All children.
TV-Y7 Directed to children age 7 and older.
TV-G General audience.
TV-PG Parental guidance suggested.
TV-14 Parents strongly cautioned.
TV-MA Mature audience only.

Content-Based Ratings

FV Fantasy violence.
D Suggestive dialog.
L Strong language.
S Sexual situations.
V Violence.

• To ensure maximum blocking capability, set the Age-Based Ratings.

46

Canadian Models: Selecting Custom Parental Lock Rating
Options

To select custom rating options for Canada, select Canada in the Country setting (page

45).

Option Description

English Rating C All children.

C8+ Children 8 years and older.
G General programming.
PG Parental guidance.
14+ Viewers 14 and older.
18+ Adult programming.

French Rating G General programming.

8 ans+ Not recommended for young children.
13 ans+ Not recommended for ages under 13.
16 ans+ Not recommended for ages under 16.
18 ans+ Programming restricted to adults.

U.S.A. Rating See “US Models” on page 46 for details.

Viewing Blocked Programs

You can view blocked programs by entering your password. Press when tuned to a
blocked program, then enter the password. This temporarily deactivates the parental
control feature. To reactivate the Parental Lock settings, turn off the TV. When the TV is
turned on again, your Parental Lock settings are reactivated.

Using the Menus

47

Using the Setup Settings

Option Description

Photo Frame
Settings

(KDL­42EX440/
32EX340 only)

USB Auto
Start

Display Mode Allows you to select the display mode. Select from Image and

Clock Display Allows you to select the clock display. Select from Calendar,

Audio
Application

Selection

Music
Selection

Slideshow
Setting

Music
Playback
Setting

Duration Selects the time period (1 h, 2 h, 4 h or 24 h) after which the TV

First day of the
week

Select On to show the thumbnail view automatically when the TV is turned on and
a digital still camera or other device containing photo files is connected to the
USB port then turned on.

Clock, Full Screen Image or Full Screen Clock. See page 34.

Analog Clock, Digital Clock, Calendar and Clock or Clock.
Calendar and Clock and Clock can be displayed only when
Display Mode is Full Screen Clock. This setting will be
changed automatically according to the Display Mode setting.

Music You can enjoy music with this function.
Off Turns off the music.

Select image.

Select music.

Slideshow You can play a slideshow of photos.
Single View Displays one photo only.
All Tracks Listen to all music tracks.
Single Track Set to listen to a single music track.

automatically switches to standby mode.
Set Sunday or Monday as the first day of the week on the

calendar.

48

Option Description

Closed
Captions
(CC)

Allows you to select from several closed caption modes (for programs that are
broadcast with closed captioning).

CC Display On Closed Captions (CC) is turned on.

Analog CC Allows you to select basic analog (EIA-608) closed caption

Digital CC When the digital closed caption service is available, select from

Digital CC
Options

Off Closed Captions (CC) is turned off.
On when

Muting

options.

CC1, CC2,
CC3, CC4

Text1, Text2,
Text3, Text4

the Service 1-6 or CC1-4.
Allows you to make additional settings for digital closed caption

options. Select As Broadcast or Custom. The Custom option is
available on the Digital CC setting.

Custom Allows you to customize the following settings:

Closed Captions (CC) is turned on when the TV

is muted.

Displays a printed version of the dialog or sound
effects of a program. (Should be set to CC1 for
most programs.)

Displays network/station information presented
using either half or the whole screen (if available).

Character
Size

Character
Style

Character
Color

Character
Opacity

Edge Type None, Raised, Depressed,

Edge Color Color 1-8
Background

Color
Background

Opacity

Small, Standard, Large

Style 1-7

Color 1-8

Solid, Translucent

Outline, Left Shadow,
Right Shadow

Color 1-8

Solid, Translucent

Using the Menus

• You can turn on Closed Captions (CC) options (On, Off or On when Muting) by pressing the
CC button on the remote control.

(Continued)

49

Option Description

Info
Banner

Clock/Timers Sleep Timer Set the time in minutes (Off, 15, 30, 45, 60, 90, or 120) that you

Initial Setup If you miss the Initial Setup when you first connect the TV or if you want to scan

Language Select to display all on-screen settings in your language of choice: English,

Startup Logo Select On to display the logo when the TV is turned on. Select Off to disable it.
AV Setup Manage Inputs Assigns a name to external equipment.

Displays the information related to the input signal you are watching. Select Small
to display minimal channel and program title or select Large to display detailed
channel and program information along with the TV icon if you are viewing the TV.
This information will appear if it is available from the broadcaster.
Info Banner appears on the screen each time the channel and external inputs
are changed or when DISPLAY on the remote control is pressed.

would like the TV to remain on before shutting off automatically.

On Timer Turns on the TV from standby mode at a time you set, and tuned

to a TV channel or input of your preference. Before setting this
function, make sure you set the correct current Time.

Current Time You can set the current time manually. Select Date (Month/Day/

Year) to set the date, then select Time to set the time.

• This TV does not have a battery powered backup for the
clock. Therefore, if there is a power failure or if you disconnect
the power cord, be sure to reset the current date and time.

all receivable channels, select Initial Setup. Follow the instructions on the screen.
Some settings such as Picture, Sound, and Parental Lock will not be affected
by this Initial Setup. If you wish to return your TV to factory settings, please see
the Troubleshooting section on page 65.

Español, Français.

Select Auto to display names when the equipment is connected
and/or the signal of the equipment is ready to be shown, or
Always to display regardless of connection status or Off to
disable input (only for TV and PC inputs).

Video/
Component
Selection

Select Auto to have the TV detect and switch between the
Video or Component when Video or Component is connected.

• You can assign following labels for each input (except TV):

–, Cable, Satellite, VCR, DVD/BD, Home Theater, Game, Camcorder, Digital Camera, PC,
Edit (except PC IN)
–, Edit (for PC IN)

•“–” indicates that no labels are assigned.

• If you select Edit, you can edit video labels. Follow the same steps for Edit Channel Labels on

page 44.

50

Option Description

HDMI
Settings

Adjustments
Lock

Communicates with equipment compatible with the Control for HDMI function.
Control for

HDMI

Device Auto
Power Off

TV Auto Power OnSelect On to control your TV’s power on from your connected

Device List Displays a list of equipment with Control for HDMI function

Device Control
Keys

•Press OPTIONS while the equipment supporting Control for HDMI is
connected to display the Device Control options. The Device Control option
provides access to the Home (Menu), Options and Content List of your
connected equipment with your TV remote control.

• Some equipment with Control for HDMI
feature.

• HDMI Settings must be setup on the connected equipment.

Select Lock so no adjustment can be made to items grayed out, except Picture
Mode and CineMotion.
Select Unlock to allow adjustment to any of the Picture settings.

Links the operations of the TV and the equipment.
For specific Sony equipment compatible with Control for HDMI,
this setting is applied automatically to the connected equipment
when set to On.

Select On to have your connected equipment with Control for
HDMI function power off automatically when the TV is turned off.
Select Off to disable this function. This feature is available when
Control for HDMI is On.

equipment with Control for HDMI function. Select Off to disable
this function. This feature is available when Control for HDMI is
On.

connected to the TV.
Select button functions of the TV’s remote control to operate the

connected equipment.
None Deactivates the control by the TV’s remote

control.

Normal Enables basic operations, such as navigation

buttons (up, down, left or right, etc.).

Tuning Keys For basic operations and operation of channel-

related buttons, such as CH +/– or 0-9, etc. Useful
when you control a tuner or set-top box, etc; via
the remote control.

Menu Keys For basic operations and operation of the HOME/

OPTIONS buttons. Useful when you select menus

of a BD player, etc; via the remote control.

Tuning and
Menu Keys

For basic operations and operation of channel­related buttons and HOME/OPTIONS buttons.

does not support the Device Control

Using the Menus

(Continued)

51

Option Description

Product
Support

Contact Sony Sony contact information is available on this screen for your

Signal
Diagnostics

convenience. TV specific information such as Model Name,
Serial Number, Software Version and downloadable ratings (if
available from the TV) are displayed here.

Press to display the diagnostics information for the current
signal.

52

Using the Eco Settings

Option Description

Reset Resets the current Eco settings to the default values.
Power Saving Select from Off, Low, High, Picture Off to adjust your TV’s power consumption.

By selecting the High option, you will reduce the power consumption more than
the other available settings.
While Picture Off is set, pressing VOL +/– or MUTING buttons will not disable this
function. Press other buttons to disable it.

Idle TV
Standby

Light Sensor Optimizes the picture settings according to the ambient lighting.
Auto Shut Off Select On to automatically power off the TV when no input signal is detected for a

Select to automatically power off the TV after 1 h, 2 h, or 4 h when no buttons are
pressed or touched on the remote control or the TV. Select Off to disable this
function.

certain period of time. Select Off to disable this function.

Using the Menus

53

Other Information

PC Input Signal Reference Chart for PC and HDMI IN

After connecting the PC to the TV, set the output signal from the PC according to the
chart below.

x KDL-32EX340

Resolution

Signals Horizontal

(Pixel)

VGA 640 × 480 31.5 60 VGA

SVGA 800 × 600 37.9 60 VESA Guidelines

XGA 1,024 × 768 48.4 60 VESA Guidelines

WXGA 1,280 × 768 47.4 60 VESA

1,280 × 768 47.8 60 VESA

1,360 × 768 47.7 60 VESA

× Vertical

(Line)

x KDL-42EX441/KDL-42EX440

Resolution

Signals Horizontal

(Pixel)

VGA 640 × 480 31.5 60 VGA

SVGA 800 × 600 37.9 60 VESA Guidelines

XGA 1,024 × 768 48.4 60 VESA Guidelines

WXGA 1,280 × 768 47.4 60 VESA

1,280 × 768 47.8 60 VESA

1,360 × 768 47.7 60 VESA

SXGA 1,280 × 1,024 64.0 60 VESA

HDTV* 1,920 × 1,080 67.5 60 CEA-861*

× Vertical

(Line)

Horizontal
frequency (kHz)

Horizontal
frequency (kHz)

Vertical
frequency (Hz)

Vertical
frequency (Hz)

Standard

Standard

* The 1080p timing when applied to the HDMI input will be treated as a video timing and not PC

timing. This affects Picture settings and Wide Mode settings. To view PC content set Scene
Select to Graphics, Wide Mode to Full, and Display Area to Full Pixel.

• This TV’s PC input does not support Sync on Green or Composite Sync.

• This TV’s PC VGA input does not support interlaced signals.

• Your PC must support one of the above PC input signals to display on the television.

• In plug and play, signals with a 60 Hz vertical frequency will be detected automatically. (PC
reboot may be necessary.)

54

Using a Wall-Mount Bracket

Your TV can be mounted on a wall using a Wall-Mount Bracket (not supplied) out of the
box as packaged. Some larger size TV may require removing the Table-Top Stand; refer
to the instructions provided with the TV.
Prepare the TV for the Wall-Mount Bracket before making cable connections.

For product protection and safety reasons, Sony strongly recommends that you
use the Wall-Mount Bracket designed for your TV and the installation should be
performed by a Sony dealer or licensed contractor.

• Follow the instruction guide provided with the Wall-Mount Bracket for your model.
Sufficient expertise is required in installing this TV, especially to determine the strength
of the wall for withstanding the TV’s weight.

• Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the
mounting hooks to the TV set.
The supplied screws are designed as indicated by illustration when measured from
the attaching surface of the mounting hook.
The diameter and length of the screws differ depending on the Wall-mount bracket
model. Use of screws other than those supplied may result in internal damage to the
TV set or cause it to fall, etc.

32EX340: 6.5~10 mm
42EX440/EX441: 8~12 mm

Screw (supplied with the Wall-Mount Bracket)
32EX340: M4
42EX440/EX441: M6

Mounting Hook

Hook attachment on rear of TV set

• Be sure to store the unused screws and Table-Top Stand in a safe place until you are
ready to attach the Table-Top Stand. Keep the screws away from small children.

• Read the supplied Safety Booklet for additional safety information.

Other Information

55

Installing the Wall-Mount Bracket

x To Customers

Your TV can be wall-mounted using SU-WL500 or SU-WL100 Wall-Mount Bracket (sold
separately).

Please provide this installation information as well as the instruction supplied with SU­WL500 or SU-WL100 Wall-Mount Bracket to your installer.

x To Sony Dealers and Licensed Contractors

To avoid injury and property damage, read these instructions carefully. Periodic
inspection and maintenance is highly recommended to ensure that TV is securely
mounted.

x Note when installing

When using the SU-WL500 or SU-WL100 Wall-Mount Bracket, the space between the
wall and the TV will be 6 cm (2

3

/8 inches). Use this space to route cables to the TV.

6 cm (23/8 inches)

56

For SU-WL500 (KDL-42EX441/42EX440 only)

Step 1: Check the parts required for the installation

Open the Wall-Mount Bracket package and check the contents for all required parts
along with the Instructions.

Step 2: Decide on the installation location

Decide where you want to install your TV. Refer to the TV installation dimensions table.
Refer to the Instructions for SU-WL500.

x Dimension Table

Screen center point

Unit: mm
(inches)

TV Model

KDL-42EX441
KDL-42EX440

TV Dimensions Screen

center
dimensions

Length for each mounting angle Weight

Angle (0°) Angle (20°)

AB C DEFGH

(38

983

603

3

/4)

(23 3/4)

143

(5 3/4)

457
(18)

111

(4 3/8)

287

(11 3/8)

556
(22)

466

(18 3/8)

TV ×4

13.2 kg

(29.1 lb.)

52.8 kg

(116.3 lb.)

Figures in the above table may differ slightly depending on the installation.

CAUTION

The wall that the TV will be installed on should be capable of supporting a weight of at
least four times that of the TV. Refer to your TV’s operating instructions for its weight.

Step 3: Install the Base Bracket on the wall

Refer to the Instructions for SU-WL500.

(Continued)

57

Other Information

Step 4: Prepare the TV for wall mount installation

Follow the steps below to prepare for installing the TV.

1 Disconnect all the cables from the TV.
2 Detach the Table-Top Stand from the TV.

1 Place the TV with its screen facing down on a level and stable surface covered with a thick

and soft cloth.

• Be careful not to hit the Table-Top Stand against the edge of the surface when placing
the TV with its screen facing down.

2 Remove the screws guided by the arrow marks and of the TV.

Do not remove any other screws from the TV.

Thick and
soft cloth

• Hold the Table-Top Stand with one hand to avoid it dropping when detaching.

• Before attaching the Wall-Mount Bracket, hang the AC power cord down behind the TV.

58

3 Secure the Mounting Hook to the rear of the TV.

Determine the screw locations and secure the Mounting Hooks to the rear of the TV.
Refer to the “Screw and Hook Locations Diagram/Table” shown below.

1 Secure the Mounting Hooks to the rear of the TV using only the supplied screws

(M6 × 16).

2 Be sure to tighten the screws with equal torque strength.

Align the tab on the rear of the

Screw
(M6 × 16)

Mounting
Hook

Square
hole

Square hole

Mounting Hook with the square hole
on the rear of the TV as illustrated.

Tab

Other Information

(Continued)

59

x Screw and Hook Locations Diagram/Table

TV Model Screw location Hook location

KDL-42EX441
KDL-42EX440

e, j b

Screw location

When installing the Mounting Hooks on
the TV.

4 Adjust the angle of the Mounting Hook.

Refer to the Instructions for SU-WL500.

Step 5: Install the TV on the wall

Refer to the Instructions for SU-WL500.

Hook location

When installing the TV onto Base Bracket.

Wall

TV

~

• When you put the TV back on the Table-Top Stand, reverse the above steps.

• When moving the TV, do not squeeze the bottom of the front panel too tight.

• Remove the screws or install the Mounting Hook on a stable and level surface.

60

For SU-WL100 (KDL-32EX340 only)

Step 1: Check the parts required for the installation

Open the Wall-Mount Bracket package and check the contents for all required parts
along with the Instructions.

Step 2: Adjust the position of the holders of the Base Plate

Refer to the Instructions for SU-WL100.

Step 3: Decide on the installation location

Decide where you want to install your TV. Refer to the TV installation dimensions table.
Refer to the Instructions for SU-WL100.

x Dimension Table

Other Information

Screen center point

Unit: mm
(inches)

TV Model AB C DEFGH

KDL-32EX340

TV
Dimensions

753

(29

471

3

/4)

(18 5/8)39(1 9/16)

Screen
center
dimensions

Length for each mounting angle Weight

Angle (0°) Angle (20°)

TV

208

(8 1/4)

108

(4 3/8)

269

(10 5/8)

432

(17 1/8)

(7 5/8)

192

7.1 kg

15.7

(

lb.

)

×4

28.4 kg

62.6

(

lb.

Figures in the above table may differ slightly depending on the installation.

CAUTION

The wall that the TV will be installed on should be capable of supporting a weight of at
least four times that of the TV.

Step 4: Install the Base Plate on the wall

Refer to the Instructions for SU-WL100.

(Continued)

61

)

Step 5: Prepare the TV for wall mount installation

Follow the steps below to prepare for installing the TV.

1 Disconnect all the cables from the TV.
2 Detach the Table-Top Stand from the TV. For details, see page 58.
3 Align the holes on the left Mounting Hook with the corresponding holes on the rear of

the TV.

Secure them to the TV using two screws (supplied with SU-WL100).

Screw
(M4 × 12)

Mounting Hook

4 Adjust the angle of the Mounting Hook.

Mounting Hook

Arm

62

5 Align the holes on the right Mounting Hook with the corresponding holes on the rear

of the TV.

Secure them to the TV using two screws (supplied with SU-WL100).

Screw
(M4 × 12)

Mounting Hook

Step 6: Install the TV on the Base Plate

Refer to the Instructions for SU-WL100.

1 Connect the cables to the corresponding inputs on the rear of the TV.

For details on the cable connection, see “Connecting Other Equipment” on page 16.

2 Install the TV onto the Base Plate.

Other Information

(Continued)

63

x Hook locations diagram

Install the TV onto the location “a” of the Base Plate.

• When using an electric screwdriver to tighten the screws, the torque must be approximately

1.5 N·m {15 kgf·cm}. Do not lift the Mounting Hook before the screws (two screws each for left /
right) are secured.

64

Troubleshooting

Many of the poor pictures and poor sound conditions are related to improper connection
of the cables; refer to the Quick Setup Guide provided for connections.
If you have questions, service needs, or require technical assistance related to the use
of your Sony TV even after you read this operating instructions manual, contact the
following:

For US Support:

http://www.sony.com/tvsupport

For Canadian Support:

http://www.sony.ca/support

x Things to consider

• Check the input selection by pressing the INPUT button. You may be watching the

wrong input.

• If you cannot hear sound from the TV, you may have accidentally pressed the MUTING
button on your remote control; press the MUTING button again or press VOL + to
deactivate muting, or set Speakers to Audio System.

• If the remote control is not functioning properly, the batteries may be installed
incorrectly or may be low or an object or light may be interfering with the remote
control.

• To reset the TV to factory default settings:

1 Turn on the TV.
2 Press and hold down the V button on the remote, touch the "/1 button on the TV set.

(The TV will turn itself off, then back on again.)

3 Release the V button when the TV is turn on.

IMPORTANT: The factory reset will clear all of your customized settings including the
Parental Lock setting.
When the Password is lost or cannot be remembered, enter the master password: 4357.
This password clears your previous password and allows you to enter a new password.

or call 1-800-222-SONY (7669)

or call 1-877-899-SONY (7669)

Other Information

Condition Explanation/Solution

No picture

No picture • Check the Power Saving settings (see page 53).

Cannot receive any
channels

• Make sure the power cord is connected securely.

• Turn on the power of the TV.

• Check cable/antenna connections.

• Make sure the Signal Type setting is correct for your TV signal

source.

(Continued)

65

Condition Explanation/Solution

TV is locked to one
channel

Cannot receive or select
channels

The TV turns off
automatically

No picture from some
video sources

Poor picture

Picture quality not as
good as viewed at the
store

Broadcast HD formats
have poor quality

Double images or ghosts • Check cable/antenna connections.

Only snow and noise
appear on the screen

Dotted lines or stripes • Keep the TV away from noise sources such as cars, motorcycles,

No color / Dark picture /
Color is not correct / The
picture is too bright

Noisy picture • Make sure that the antenna is connected using a 75-ohm coaxial

•Perform Auto Program to add receivable channels that are not

present in the TV’s memory (see pages 20 and 44).

•Perform Auto Program to add receivable channels that are not

present in the TV’s memory (see pages 20 and 44).

• To receive or select cable channels, make sure that Signal Type
in the Channel settings is set to Cable (see page 44). To receive
or select UHF channels over an antenna, make sure Signal Type
is set to Antenna.

• Check if Sleep Timer is activated (see page 50).

• Check Idle TV Standby in the Eco settings.

• Check Duration of Photo Frame Settings.

• Check Duration if TV is turned on by On Timer.

• Check the connection between the optional video equipment
and the TV.

•Press INPUT on the remote control (see page 32).

• Picture quality depends on the signal content. See Quick Setup
Guide (supplied) to display the best possible picture for that
signal.

• Content and signal quality are controlled by the signal provider.
Many HD channels and content are actually upscaled versions of
standard-definition broadcasts. The picture is affected by the
quality of the signal received, which varies between channel and
program.

• Check the antenna location and direction.

• Check if the antenna is broken or bent.

• Check if the antenna has reached the end of its serviceable life.
(3-5 years in normal use, 1-2 years at the seaside.)

or hair-dryers.

• If using 300 ohm twin lead, move the excess lead away from the
TV or try using 75-ohm coaxial cable instead.

• Adjust the Picture Mode options in the Picture settings (see
page 38).

• If you set the Power Saving mode to Low or High, it will
enhance the black level.

cable (not supplied).

• Keep the antenna cable away from other connecting cords.

• To avoid TV interference, make sure to use an undamaged
antenna cable.

66

Condition Explanation/Solution

Blurry picture / Poor color • Transporting the TV from a cold to a warm location or a sudden

No sound / Noisy sound

No sound but good

Audio noise • Make sure that the antenna is connected using a 75-ohm coaxial

No audio or low audio
with Home Theater
System

No color / Irregular

BRAVIA Sync

Cannot find connected
BRAVIA Sync HDMI
device

Second A/V receiver is
not listed on the Device

List

change in room temperature may cause moisture condensation,
resulting in a blurry picture or poor color. Turn off your TV and
wait a few hours before powering on again.

• Check the volume control.

•Press MUTING or VOL + so that “Muting” disappears from the

screen (see page 25).

•Set Speakers to TV Speakers in the Sound settings (see page

41). If it is set to Audio System, sound is not output from the TV’s
speakers regardless of the TV’s volume control.

• When using HDMI input with Super Audio CD or DVD-Audio,
DIGITAL AUDIO OUT (OPTICAL) may not provide an audio
signal.

• When tuned to a digital channel with Alternate Audio, the
broadcaster may not be broadcasting your preferred Alternate

Audio language. Press OPTIONS, highlight and select Alternate
Audio, and change the Alternate Audio language (see page

41).

cable (not supplied).

• Keep the antenna cable away from other connecting cords.

• To avoid TV interference, make sure to use an undamaged
antenna cable.

•Set Speakers to Audio System in the Sound settings (see page

41).

•Set Audio Out to Fixed in the Sound settings (see page 41).

• Verify that the Video/Component Selection (see page 50) is set
to the current input type in use. We suggest leaving this setting to
Auto.

• Make sure that the Control for HDMI is set up on both the TV
and the optional device compatible with BRAVIA Sync (see
page 28).

• Only one A/V receiver may be used with the BRAVIA Sync and

Control for HDMI functions at one time (see page 51).

Other Information

(Continued)

67

Condition Explanation/Solution

PC Input

No picture / No signal • Confirm the PC is correctly connected to the TV with either the

Poor Picture • Adjust the resolution (see page 54).

General

TV screen feels warm • Due to the thin profile of this television, the heat generated by the

Wide Mode changes
automatically

Suddenly the picture
gets smaller

“Black box” on screen • You have selected a text option and no text is available (see

PC IN (with an HD15 cable) or with the HDMI IN.

• Ensure the output signal from the PC is one of the formats listed
on page 54.

• Turn the PC off. Confirm the PC connection and restart the PC.
Plug-and-play will auto-detect the TV and correctly set up PC
timing.

• Verify the PC is not in standby or hibernation mode.

•Adjust Pitch and Phase.

LCD panel backlight and supporting electronics will be more
noticeable. This is normal operation and not a cause for concern.

• The current Wide Mode setting is automatically replaced with the
4:3 Default setting when you change the channel or video input,
if 4:3 Default in the Screen settings is set to other than Off. If you
want to lock in Wide Mode selected with WIDE on the remote
control, set 4:3 Default to Off in the Screen settings (see page

42).

• Check the Auto Wide option in the Screen settings (see page

42).

• The picture gets smaller during the commercials due to the
method in which the provider broadcasts their content. When HD
content channels switch to SD content (commercials), the picture
may be small with a black border.

• Auto Wide will not expand the picture during these content
changes since the content information is regulated by the
channel signal provider. You can manually change the Wide
Mode if you prefer (see page 30). This setting will remain in
effect until you change the channel or input or manually change
the Wide Mode again.

page 49). To turn off this feature, set the CC Display option to
Off. If you were trying to select closed captioning, select CC1
instead of Text1-4.

68

Condition Explanation/Solution

Black bands appear at
the edges of the screen

Certain programs on
DVD or other digital
sources display a loss of
detail, especially during
fast-motion or dark
scenes

Remote control does not
operate

Some digital cable
channels are not being
displayed

Some photo, music, or
video files are not
displaying from my USB
equipment

Photo images appear
small in the screen

Photo images or folders
take time to display

• Some wide screen programs are filmed in aspect ratios that are
greater than 16:9 (this is especially common with theatrical
releases). Your TV will show these programs with black bands at
the top and bottom of the screen. For more details, check the
documentation that came with your DVD/Blu-ray (or contact your
program provider).

• Programs in 4:3 aspect ratio will have bands on left and right
sides of the screen.

• Programs broadcast in HD formats (720p and 1080i) with 4:3
content will commonly have black bands on the left and right
sides of the screen which are added by the broadcaster (see
image on left).

• Auto Wide will not expand the picture when the black bands on
the sides of the screen are added by the broadcaster. You can
manually change the Wide Mode to Wide Zoom, or Zoom to fill
the screen, which will remain in affect until you change the
channel or input or manually change the Wide Mode again.

• This is due to the digital compression of the source content used
by certain digital broadcasts and DVDs which may cause your
TV’s screen to display less detail than usual, or cause artifacts
(small blocks or dots, pixelations) to appear on your screen.
These signal compressions are more visible and are dependent
on the clarity and resolution of the TV.

• To determine if the problem is with the remote control or not,
touch a button on the TV.

• Check the polarity of the batteries or replace the batteries.

• Point the remote control at the remote control sensor located at
the front of the TV.

• Keep the remote control sensor area clear from obstacles.

• Fluorescent lamps can interfere with your remote control
operation; try turning off the fluorescent lamps.

• Certain cable companies have limitations on the broadcast of
digital cable channels. Check with your cable company for more
information.

• The digital cable channel may be set to Hidden in the Show/
Hide Channels setting (see page 44).

• The accessible file or folder limit in a directory is 1,000 for USB
connected equipment. This limit includes non-supported files or
just folders. Files or folders are populated based on their time
stamps. Photo, music files or folders exceeding the limit will not
be displayed.

• Set display size to expanded.

• Whether or not photo images can or cannot be displayed in full­screen depends on the resolution or aspect ratio of the file.

• Depending on the image dimension, file size, and number of files
in a folder, some photo images or folders take time to display.

• The first time a camera is connected to the TV via USB cable, it
may take up to a couple of minutes for the photos to display.

Other Information

(Continued)

69

Condition Explanation/Solution

Lost password • Select the Password settings on the Parental Lock settings,

How to reset the TV to
factory settings

The TV surrounds
become warm

then enter the following master password: 4357. This password
clears your previous password and allows you to enter a new
password (see page 45).

• Turn on the TV. While holding down V on the remote control,

touch "/1 on the TV. (The TV will turn itself off, then back on
again.) Release V.
IMPORTANT: The reset will clear all of your customized settings
including the Parental Lock setting.

• When the TV is used for an extended period, the TV surrounds
become warm. You may feel hot when touching there by the
hand.

70

Important Notices

Declaration of Conformity

Trade Name: SONY
Model: KDL-42EX441/KDL-42EX440/KDL-32EX340
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo,
San Diego, CA 92127 U.S.A.
Telephone Number: 858-942-2230

This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.

For Customers in Canada

This Class B digital apparatus complies with Canadian
ICES-003.

FCC Related Information

This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:

❑ Reorient or relocate the receiving antenna.
❑ Increase the separation between the equipment and

receiver.

❑ Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

❑ Consult the dealer or an experienced radio/TV

technician for help.

Pursuant to FCC regulations, you are cautioned that any
changes or modifications not expressly approved in this
manual could void your authority to operate this
equipment.

Compatible Wall-Mount Bracket
Information

Use the following Sony Wall-Mount Bracket with your TV
model.

Sony TV Model No.

KDL-42EX441
KDL-42EX440

Sony Wall-Mount
Bracket Model

SU-WL500 SU-WL100

No.

Use with other Wall-Mount Brackets may cause instability
and could result in property damages or injury.

Note

This television includes a QAM demodulator which should
allow you to receive unscrambled digital cable television
programming via subscription service to a cable service
provider. Availability of digital cable television programming
in your area depends on the type of programming and signal
provided by your cable service provider.

To Customers

Sufficient expertise is required for TV installations. Be sure to
subcontract the installation to a Sony dealer or licensed
contractor and pay adequate attention to safety during the
installation.

Pour les clients résidant au Canada

Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.

Information sur le support de fixation murale
compatible

Utilisez le support de fixation murale Sony ci-dessous
correspondant au modèle de votre téléviseur.

Numéro de modèle de
téléviseur Sony

KDL-42EX441
KDL-42EX440

Numéro de
modèle du
support de
fixation murale
Sony

L’utilisation d’un autre support de fixation murale peut
provoquer l’instabilité de l’appareil et causer des blessures
ou des dommages matériels.

SU-WL500 SU-WL100

KDL-32EX340

KDL-32EX340

Other Information

71

Specifications

System

Television system NTSC: American TV standard

Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69

Panel system LCD (Liquid Crystal Display) Panel

Speaker output KDL-42EX440/KDL-32EX340: 6 W + 6 W

Input/Output jacks

CABLE/ANTENNA 75-ohm external terminal for RF inputs

VIDEO IN VIDEO: 1 Vp-p, 75 ohms unbalanced, sync negative

COMPONENT IN YP

HDMI IN 1/2 HDMI: Video: 480i, 480p, 720p, 1080i, 1080p, 1080/24p

AUDIO OUT 500 mVrms (typical)

DIGITAL AUDIO OUT
(OPTICAL)

PC IN D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive

PC/HDMI IN 1 AUDIO IN Stereo mini jack, 500 mVrms, (Typical) / Impedance: 47 kilohms

USB Photo, Music and Video

ATSC (8VSB terrestrial): ATSC compliant 8VSB
QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality)

Analog Cable: 1 - 135 / Digital Cable: 1 - 135

KDL-42EX441: 8 W + 8 W

AUDIO: 500 mVrms (Typical) / Impedance: 47 kilohms

BPR (Component Video): Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative / PB: 0.7 Vp-p,

75 ohms

R: 0.7 Vp-p, 75 ohms / Signal format: 480i, 480p, 720p, 1080i, 1080p

P
AUDIO: 500 mVrms (Typical) / Impedance: 47 kilohms

Audio: Two channel linear PCM 32, 44.1 and 48 kHz, 16, 20 and 24bits, Dolby Digital

PC Input (see page 54)

PCM/Dolby Digital optical signal

See the PC Input Signal Reference Chart for PC and HDMI IN on page 54.

Model name KDL-42EX441

KDL-32EX340

KDL-42EX440

Power and others

Power requirement 110-240 V AC, 50/60 Hz (U.S.A./Canada/Mexico 120 V AC, 60 Hz)

Power consumption

in use

in standby Less than 0.15 W with 120 V AC and with 240 V AC less than 0.3 W

Screen size*

(measured diagonally)

Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical) 1,366 dots (horizontal) × 768 lines (vertical)

Speaker/Full range (2) (mm)

Dimensions* with stand (mm)

without stand (mm)

wall-mount hole pattern
(mm)

wall-mount screw size
(mm)

(inches)

(cm) 106.7 80.0

(inches)

(inches)

(inches)

M6 (length: refer to diagram on page 55) M4 (length: refer to diagram on page 55)

95 W 55 W

42

40 × 100

5

/8 × 4)

(1

983 × 643 × 233

3

/4 × 25 3/8 × 9 1/

38

983 × 603 × 75

3

/4 × 23 3/4 × 3

38

300 × 300 200 × 100

4

753 × 510 × 213

29

29 3/4 × 18 5/8 × 2 7/

31.5

(32 class)

3

/4 × 20 1/8 × 8 1/

753 × 471 × 71

2

8

72

Model name KDL-42EX441

KDL-32EX340

KDL-42EX440

Mass* with stand (kg)

without stand (kg)

Supplied accessories Remote control RM-YD080 (1)/Size AA batteries (2)/Operating Instructions (1)/Quick Setup

common to all models

Optional accessories Connecting cables / Support Belt Kit / Wall-Mount Bracket: SU-WL500 (KDL-42EX441/

(lb.)

(lb.)

Guide (1)/Warranty Card (1)/Safety and Regulatory Booklet (1)/Software License (1)/Stand
installation guide (1)/Table-Top Stand (1 set)/Screw (3)

42EX440), SU-WL100 (KDL-32EX340)

14.1

31.1

13.2

29.1

7.7

17.0

7.1

15.7

• Optional accessories availability depends on its stock.

• Design and specifications are subject to change without notice.
* Dimensions and mass are approximate values.

Other Information

73

Index

0-9 buttons 25
4:3 Default 42

A

Add Digital Channels 44
Advanced Settings 39
Alternate Audio 41
Analog Fine Tune 44
AUDIO OUT 10
Audio Out 41
Auto Display Area 42
Auto Program 20, 44
Auto Shut Off 53
Auto Wide 42
AV Setup 50

B

Backlight 38
Balance 40
Bass Booster 40
Brightness 38

C

CABLE/ANTENNA 10
CC button 25
CH +/– button 25, 26
Change Password 45
Channel Block 45
CineMotion 38
Clock/Timers 50
Closed Captions (CC) 49
Color 38
Color Temperature 38
Colored buttons 24
COMPONENT IN 11
Country 45

D

DIGITAL AUDIO OUT (OPTICAL)

10

Display Area 42
DISPLAY button 25
Downloadable U.S. Rating 45

E

Edit Channel Labels 44
English Rating 47
Equalizer 40
Equipment Control button 23
External Input Block 45

F

French Rating 47

H

HDMI IN 11
HDMI Settings 51
HDMI/DVI Audio Source 41
HOME/MENU button 24, 27
Horizontal Center 42, 43
Hue 38

I

Idle TV Standby 53
Info Banner 50
Infrared Receiver (IR) 26
Initial Setup 50
INPUT button 23, 26
Installing the TV on a wall 55, 56

J

JUMP button 25

L

Language 50
Light sensor 26, 53

M

Movie Rating 46
MPEG Noise Reduction 38
MTS Audio 41
Music 32
MUTING button 25

N

Noise Reduction 38

O

OPTIONS button 25

P

Password 45
PC IN 10
PC Settings 43
Photo 32
Photo Frame 34
Photo Frame Settings 48
Picture 38
Picture Adjustments Lock 51
Picture Mode 38
Picture Off ( ) LED 26
PIP 29
Power ("/1) button 26
POWER ("/1) button 25
POWER (") LED 26
Power Saving 53
Product Support 52

R

Rating 45
Reset 38, 40, 53, 70
RETURN button 24

S

SCENE button 24
Settings

Sharpness 38
Show/Hide Channels 44
Signal Type 44
Sound Mode 40
Speaker 27
Speakers 41
Standby (1) LED 26
Startup Logo 50
Steady Sound 40
Surround 40
SYNC MENU button 23

44

Channel
Eco 53
Parental Lock 45
Picture 38
Screen 42
Setup 48
Sound 40

T

Timer ( ) LED 26
Troubleshooting 65–70
TV Rating 46

U

U.S.A. Rating 47
Unrated 45
USB 11
USB Auto Start 48

V

Vertical Center 43
Video 32
VIDEO IN 11
Viewing Blocked Programs 47
VOL (2) +/– button 25, 26
Volume Offset 40

W

WIDE button 25
Wide Mode 42, 43

74

Online
Registration:

For Your Convenience

Be sure to register your TV.

United States
Canada

http://productregistration.sony.com
http://www.sony.ca/registration

© 2012 Sony Corporation Printed in U.S.A.

4-433-081-11(1)
