Sony KD-85ZH8 Users guide [nl, uk]

Dismantling information for use

by professional recyclers

ORIGINAL MANUAL ISSUE DATE:

Model

：

2021.02

KD-75ZH8
KD-85ZH8

Conditions of Use:
(1) Please use this information only for the purpose of repair and recycling of Sony products. Using this information for any

purpose other than the purpose described foregoing is forbidden.

(2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part

without the prior written permission of the author.

Revision of Information:
This information may be changed or updated at any time without any prior notice. Please confirm that this information is up­to-date before using it.

9-888-783-41

LCD TV

Sony Home Entertainment & Sound Products Inc.

© 2021.02

MODEL LISTS

MODEL REMOTE DESTINATION

KD-75ZH8 RMF-TX611E CEI, UKA

KD-85ZH8 RMF-TX611E CEI, UKA

REMOTE

1 LIST OF ITEMS TO BRING

1. Screwdriver (e.g. #2 Phillips Screwdriver)

2. Multimeter

3. ESD Wrist Straps

4. Metal Washer (Flat) or Coin (for remove Rear Cover)

5. Ruler (for remove Rear Cover)

2 OPTIONAL EQUIPMENT

TOOLS & EQUIPMENTS

1. Screwdriver (e.g. #0 Phillips Screwdriver)

2. Parts Tray for loose screws and small items

3. Flashlight

For Surface Mounted Parts/Connectors;

Hot-Air Type soldering Iron is needed.

Thickness: approx. 1.5mm
Diameter: 20~25mm

(wrap in tape (L=50mm))

Plastic or Metal Ruler
(In case of Metal ruler, wrap
in tape (L=50mm) for prevent
scratches)

3

DISSASSEMBLY AND REMOVAL CAUTION 75”

4

EXPLODED VIEW AND PART LIST 75”

•Place the TV set facing downwards on a stable, level surface before disassemblyand assembly of parts.

!

• and shaded parts are critical for safety. Replace only with part number specified.

• Parts contain confidential information. Strictly follow the instruction whenever the components are
repaired and/or replaced.

1-4. EXPLODED VIEW AND
PART LIST

1

7

12

 (*) Parts are not stocked since they are seldom required for routine service.

Some delays should be anticipated when ordering these components.

 Picture provided in this section might have slight difference from the actual sets.
 The reference numberbeside the part indicates the disassembly sequence.
 Remove screws before disassembly. Unplug connectors before disassembly

11

2

4

3

8

5

12

10

9

6

5

Only on limited region / country /

EXPLODED VIEW AND PART LIST 75”

•Place the TV set facing downwards on a stable, level surface before disassemblyand assembly of parts.

!

• and shaded parts are critical for safety. Replace only with part number specified.

• Parts contain confidential information. Strictly follow the instruction whenever the components are
repaired and/or replaced.

1-4. EXPLODED VIEW AND

14

PART LIST

22

20

21

19

11

1

16

25

26

23

15

17

 (*) Parts are not stocked since they are seldom required for routine service.

Some delays should be anticipated when ordering these components.

 Picture provided in this section might have slight difference from the actual sets.
 The reference numberbeside the part indicates the disassembly sequence.
 Remove screws before disassembly. Unplug connectors before disassembly

*

24

27

14

18

7

5

10

8

13

9

12

6

TV model

Stand

28

29

2

3

4

6

CN9002(B)(1)

CN6503(PSU)(1)

TSA(1)

J101(TCON)(1)

CN5601(ONT)(1)

CN1001(LD)(1)

CN5400(ONT)(1)

BT(1)

CN1002(LD)(1)

CN2401(ONT)(1)

CN2400(ONT)(1)

J102(TCON)(1)

J103(TCON)(1)

J104(TCON)(1)

J105(TCON)(1)

HARNESS/CABLES 75”

9

1

2

6

5

15

7

10
11

4

13

12

14

REF. NO PART NO. DESCRIPTION REMARKS

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

1-007-210-11 HARNESS ASSY (SP) CN9005(B)-SP-PZSP-

1-912-989-11 CONNECTOR ASSY 2P CN6504(PSU)-CN6502(PSU)-CN6501(PSU)-

1-007-207-11 CONNECTOR ASSY 6P (KEY) CN1203(B)-KEY-

1-007-211-11 CONNECTOR ASSY 16P CN6403(PSU)-

1-007-208-11 CONNECTOR ASSY 28P (PWR1) CN6401(PSU)-CN800(B)-

1-007-209-11 CONNECTOR ASSY 28P (PWR2) CN6402(PSU)-CN6601(PSU)-CN1000(LD)-

1-007-504-11 FLEXIBLE FLAT CABLE 14P CN9409(B)-

1-007-169-11 FLEXIBLE FLAT CABLE 20P/25P CN4801(B)-CN1201(B)-H-

1-007-171-11 FLEXIBLE FLAT CABLE 30P CN8200(B)-

1-007-172-11 FLEXIBLE FLAT CABLE 41P(B-ONT) CN9200(B)-

1-007-173-11 FLEXIBLE FLAT CABLE 51P(BONT) CN9201(B)-

1-007-174-11 FLEXIBLE FLAT CABLE 51P (OT1) CN2600(ONT)-

1-007-175-11 FLEXIBLE FLAT CABLE 51P (OT2) CN2601(ONT)-

1-007-176-11 FLEXIBLE FLAT CABLE 51P (OT3) CN4600(ONT)-

1-007-177-11 FLEXIBLE FLAT CABLE 51P (OT4) CN4601(ONT)-

8

3

7

SET PART LIST

PARTS LIST 75”

REF. NO PART NO.

15

17

19

21

25

26

27

A-5014-378-A COMPL SVC ONTJ_NE

A-5014-136-A COMPL SVC BM3J20_EUUK_NE

1-006-773-11 G07(CH) - STATIC CONVERTER(TV)

!

1-006-772-11 G06(CH) - STATIC CONVERTER(TV)

!

A-5012-964-A 20LD320A1 COMPL

1-007-507-11 MOUNTED PWB E-T-CON(75)

A-5017-286-A P-MOD (HDAS075DTU02)(SERVICE)

DESCRIPTION

OTHER PARTS

PART NO.

1-002-007-11 C17 AC CORD SET(SWISS)

1-912-832-11 POWER-SUPPLY CORD SET(EU)

1-001-115-11 POWER-SUPPLY CORD SET(UK)

DESCRIPTION

REMARKS

REMARKS

CEI

CEI

UKA

Printed Circuit Board, incl. capacitors

Printed Circuit Board, incl. capacitors

Internal Power Supply

Internal Power Supply

Printed Circuit Board, incl. capacitors

Printed Circuit Board, incl. capacitors

Liquid Crystal Display

Cable

8

DISSASSEMBLY AND REMOVAL CAUTION 85”

9

Only on limited region / country /

EXPLODED VIEWS 85”

•Place the TV set facing downwards on a stable, level surface before disassemblyand assembly of parts.

!

• and shaded parts are critical for safety. Replace only with part number specified.

• Parts contain confidential information. Strictly follow the instruction whenever the components are
repaired and/or replaced.

2-4. EXPLODED VIEW AND
PART LIST

1

7

 (*) Parts are not stocked since they are seldom required for routine service.

Some delays should be anticipated when ordering these components.

 Picture provided in this section might have slight difference from the actual sets.
 The reference numberbeside the part indicates the disassembly sequence.
 Remove screws before disassembly. Unplug connectors before disassembly

*

TV model

12

2

6

10

9

4

3

5

*

8

10

9

12

11

*

10

Only on limited region / country /

EXPLODED VIEWS 85”

•Place the TV set facing downwards on a stable, level surface before disassemblyand assembly of parts.

!

• and shaded parts are critical for safety. Replace only with part number specified.

• Parts contain confidential information. Strictly follow the instruction whenever the components are
repaired and/or replaced.

2-4. EXPLODED VIEW AND
PART LIST

24

23

22

21

20

1

28

25

15

11

13

6

27

16

 (*) Parts are not stocked since they are seldom required for routine service.

Some delays should be anticipated when ordering these components.

 Picture provided in this section might have slight difference from the actual sets.
 The reference numberbeside the part indicates the disassembly sequence.
 Remove screws before disassembly. Unplug connectors before disassembly

*

26

29

15

7

17

2

5

18

3

19

10

12

8

4

14

9

TV model

Stand

30

31

11

CN9002(B)(1)

CN6503(PSU)(1)

TSA(1)

CN5601(ONT)(1)

CN1005(LD)(1)

CN6603(PSU)(1)

CN5400(ONT)(1)

BT(1)

CN1003(LD)(1)

CN2401(ONT)(1)

CN2400(ONT)(1)

J102(TCON)(1)

J103(TCON)(1)

J104(TCON)(1)

J105(TCON)(1)

SECTION 2

KD-85ZH8

5

1

6

2

14

16

12

15

13

8

REF. NO PART NO. DESCRIPTION REMARKS

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

1-007-215-11 HARNESS ASSY (SP) CN9005(B)-SP-PZSP-

1-912-989-11 CONNECTOR ASSY 2P CN6504(PSU)-CN6502(PSU)-CN6501(PSU)-

1-007-207-11 CONNECTOR ASSY 6P (KEY) CN1203(B)-KEY-

1-007-212-11 CONNECTOR ASSY 30P (PWR1) CN6401(PSU)-CN800(B)-

1-007-213-11 CONNECTOR ASSY 30P (PWR2) CN6602(PSU)-CN1004(LD)-

1-007-214-11 CONNECTOR ASSY 6P (PWR3) CN6403(PSU)-

1-007-504-11 FLEXIBLE FLAT CABLE 14P CN9409(B)-

1-007-170-11 FLEXIBLE FLAT CABLE 20P/25P CN4801(B)-CN1201(B)-H-

1-007-180-11 FLEXIBLE FLAT CABLE 30P CN8200(B)-

1-007-172-11 FLEXIBLE FLAT CABLE 41P(B-ONT) CN9200(B)-

1-007-173-11 FLEXIBLE FLAT CABLE 51P(BONT) CN9201(B)-

1-007-181-11 FLEXIBLE FLAT CABLE 51P (OT1) CN2600(ONT)-

1-007-182-11 FLEXIBLE FLAT CABLE 51P (OT2) CN2601(ONT)-

1-007-183-11 FLEXIBLE FLAT CABLE 51P (OT3) CN4600(ONT)-

1-007-184-11 FLEXIBLE FLAT CABLE 51P (OT4) CN4601(ONT)-

1-007-216-11 CONNECTOR ASSY 20P CN6402(PSU)-J101(TCON)(1)

9

4

7

10
11

3

12

SET PART LIST

PARTS LIST 85”

REF. NO PART NO.

16

18

20

22

27

28

29

A-5014-378-A COMPL SVC ONTJ_NE

A-5014-136-A COMPL SVC BM3J20_EUUK_NE

1-006-774-11 G97C(CH) - STATIC CONVERTER(TV

!

!

1-006-775-11 G98C(CH) - STATIC CONVERTER(TV

A-5012-963-A 20LD288A1 COMPL

1-007-509-11 MOUNTED PWB E-T-CON(85)

!

A-5017-288-A P-MOD (HDAS085DTU02)(SERVICE)

DESCRIPTION

OTHER PARTS

PART NO.

1-002-007-11 C17 AC CORD SET(SWISS)

!

!

1-912-832-11 POWER-SUPPLY CORD SET(EU)

!

1-001-115-11 POWER-SUPPLY CORD SET(UK)

DESCRIPTION

REMARKS

REMARKS

CEI

CEI

UKA

Printed Circuit Board, incl. capacitors

Printed Circuit Board, incl. capacitors

Internal Power Supply

Internal Power Supply

Printed Circuit Board, incl. capacitors

Printed Circuit Board, incl. capacitors

Liquid Crystal Display

Cable

13

PART LIST

SMART CORE

1

2

3

4

5

6

7

8

REF. NO PART NO. DESCRIPTION

1
2
3
4
5
6
7
8
9

5-009-848-01
1-003-571-21
1-003-571-11
5-009-849-01
A-5011-916-B
5-009-264-11
5-009-265-11
5-009-266-11
5-009-847-01

COVER, TOP(LMN)
FPC-MIC(R)
FPC-MIC(L)
OP, INNER (LMN)
HT1_8K_MIC_CT MOUNT
LIGHT, GUIDE ILM(BNN)
LIGHT, GUIDE OPT(BNN)
LIGHT, GUIDE LED(PCH)
COVER, BTM (LMN)

9

14

9-888-783-41

Sony Home Entertainment & Sound Products Inc.

English

© 2021.0
