Sony ICF-C11IP/WHT Specifications
ICF-C11IP/BLK
Powerful alarm clock dock functionality for Apple® devices with LightningTM
connector.1 Automatic time set with backup battery ensures easy alarm
setup and reliable functionality even during a power interruption, while
dual 2-5-7 day alarms start your day o right, waking you with either: iPod®/
iPhone®, AM/FM radio, or even the buzzer.
Music your way
Gently fall asleep or wake up to your iPod®, iPhone®, buzzer, or radio.
Dock for Apple® devices with LightningTM connector
1
Dock, listen and charge your Lightning™ connector compatible iPod® and iPhone® via the durable
and easy to use Flexi-dock1. Compatible with the iPhone® 5, it also accommodates many cases so
you can plug and play. When not using the Flexi-dock, snap the spring-loaded cover shut for a clean
look.
Alarm Flexibility
Dual alarms can be activated independently of one another, and can also be set as a 2-5-7 day
alarm to dierentiate weekend and weekday settings.
LCD Brightness Control
Easily adjust LCD brightness to one of four settings to suit your preference.
No Power, No Problem
An optional backup battery keeps the clock and alarm functional, even during a power interruption.
Easy, Automatic Time Set
Pre-set at the factory to current EST (Eastern Standard Time), all you need to do when setting up the
unit is to plug it in and set the correct time zone. Even better, the built-in calendar even recognizes
the date, automatically adjusting for Daylight Savings or Standard Time.
Enjoy AM/FM radio programming
A built-in digital AM/FM tuner with 30 station presets lets you choose from a wide variety of radio, talk
and music programming.
Control your tunes with remote control
Control your iPod® or iPhone
®1
from across the room with the included full-function remote control.
Plays well with others...
An auxiliary audio input lets you connect digital music players to the speaker dock for easy access to
your music (cable not included).
Free Sony® D-Sappli™ App available
A free Sony® App (D-Sappli™), available at iTunes®, enables expanded speaker functionality when
using an Apple® device with the following features: an enlarged clock display, a music play timer,
and a sleep timer.
2
1
Specications
Audio
Frequency Range
Full Range
Speaker Size
Speaker Output 0.8 W mono output (at 10% harmonic distortion)
Tuner Type Digital AM/FM
Tuning
Convenience
Alarm Dual, Choose from: iPod®, Radio, or Buzzer
FM 87.5 MHz - 108 MHz, 0.1 MHz Step
AM 530 kHz - 1070 kHz, 1- kHz Step
Approx. 1 5/8 inches (4.0 cm) diameter
FM: 87.5 - 108 MHz
AM: 530 -1710 kHz
AM/FM Memory
Presets
Snooze w/
Extendable
Snooze
Timer Clock Sleep timer: 15 min.|30 min.|60 min.|90 min.
30 Station Presets Total: 20 FM, 10 AM
Extendable Snooze System-set from 10 to 60 minutes in
ten minute increments
Convenience Features
Remote Control Remote Commander®
General
Day/Night
Function
4 Step brightness control (Hi, Mid, Lo, O)
Hardware
Display
Remote Control Remote Control with Lithium battery
Large, Easy to Read Blue Backlit LCD Display with
Brightness Control
Inputs and Outputs
Antenna
Terminal(s)
Audio In Audio IN jack (3.5 mm steroe mini jack)
DC-In Barrel connector (3.5 mm)
Digital Audio
Input(s)
Input(s) iPod LightningTM Connector, Auxiliary Audio input
Output(s) Mono 0.8 W (at 10% harmonic distortioon)
Dual conductor plug for AM loop antenna
Works with:
iPhone 5
iPod touch (5th generation)
iPod nano (7th generation)
Power
Power Back-up 3 V DC, CR2032 Lithium Battery (1)
Power
Requirements
DC in 6 V
Speaker
Speaker
Dimensions
Approx. 1.6 in. (40 mm) diameter, cone type, 16 Ohms
Weights and Measurements
Dimensions
(Approx.)
Weight (Approx.) 1 lb. 1 oz. (482 g.)
5 in. x 3.6 in. x 4 in. (126 mm x 92 mm x 100 mm
(w/h/d))
Accessories
Startup Guide (1)
Owner's Manual (1)
Supplied
Accessories
Warranty Card (Included in Manual)
AC Power Adaptor (1)
AM Loop Antenna (1)
Remote Control (1)
1. Compatible with iPhone® 5, iPod® touch 5th generation, and iPod Nano 7th generation.
2. Subject to app terms and conditions
© 2013 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. iPod, iPhone, and Lightning Connector are trademarks
of Apple Inc., registered in the U.S. and other countries. All other trademarks are
trademarks of their respective owners. Features and specications are subject to change
without notice. Non-metric weights and measures are approximate and may vary.
/Updated: July 3, 2013
