Page 1
Digital Voice Recorder
ICD-UX560BLK
Normal, Focus, and Wide-stereo recording provide you with the
opportunity to record the audio that you need to capture in any
environment.
Bullets
• Built-in stereo microphone and voice operated recording
• Three recording options: wide/stereo, narrow/focus and normal
• Quick charge; up to 1-hour recording time, with 3-minute charge
• Easy to use user-interface and recording level indicator
• MicroSD memory card slot, headphone jack & mic input
• Linear PCM & MP3 recording and playback
• Playback recordings at various speeds with Digital Pitch Control
• Charging is a snap, with the built-in USB Direct Connection
• 4GB built-in memory for up to 159-hours of recording time
• Built-in rechargeable Lithium battery; up to 27-hours
Features
Built-in stereo microphone and voice operated recording
The built-in stereo mic allows you to capture stereo voice recordings, while voice operated recording makes it
simple to start and stop recording at any time.
Three different audio recording functions
Normal, focus recording, and Wide stereo recording allows you to record sound naturally, with a narrow recording
range, or directionally with emphasis on the left or right channel.
Quick charge; up to 1-hour recording time, with 3-minute charge
With just one 3-minute charge the voice recorder can provide 1 hour of recording time.
Easy to use user-interface and recording level indicator
The new easy to use UI makes it easy to navigate through and search for different recordings by date and time. It
also provides a new recording level meter, which makes it easy to know the exact level of volume the left and right
channel are recording.
MicroSD memory card slot, headphone jack & mic input
The inclusion of a MicroSD card slot allows for expandable storage in addition to the 4 GB of included memory,
while the inclusion of a headphone jack enables you to easily listen to your recording, and the mic input provides an
easy connection for an external microphone.
Page 2
Linear PCM & MP3 recording and playback
General Features
Built-in Memory
4GB
PC Connectivity
Yes
Built-in Microphone
Stereo (5-Mic)
Recording Format
Linear PCM/MP3
LPCM
MP3
AAC
WMA
Maximum Number of File
5000 files (including number of folder)
Maximum Number of Files in one
Folder
199
Calendar Search
Yes
LCD Backlight
Yes
USB Connection Charging
Yes
Battery Type (provided)
Built-in Lithium Battery
Maximum recording time (Built-in memory):
* Default settings for the recording scenes
Other Product Relationships
Playback & Edit
Digital Pitch Control (Speed Control)
Yes
Noise Cut
Yes (Clear Voice)
Graphic Equalizer
Yes
A-B Repeat
Yes
Easy Search
Yes
Track Mark
Yes
Erase / Protect
Yes / Yes
Divide
Yes
Move File
Yes
File Copy
Yes
Folder Name Change (without using
Yes
Enjoy 5 hours and 20 minutes of the highest quality Linear PCM recording1 or 159 hours of MP3 recording2.
Playback recordings at various speeds with Digital Pitch Control
Playback speed control allows you to control the rate of speed during file playback to give ultimate control of how
you listen to your recordings.
Charging is a snap, with the built-in USB Direct Connection
Built in USB allows for direct connection charging to your laptop or other devices with USB ports.
4GB built-in memory for up to 159-hours of recording time
Record for up to 159 hours with 4GB of built-in memory.
Built-in rechargeable Lithium battery; up to 27-hours
The built in rechargeable battery can last up to 27 hours.
Specification
Playback Format
Recording and Playback Times
Supplied Accessories
LPCM 44.1 kHz/16 bit: 5 hours 20 minutes
MP3 192 kbps*: 39 hours 45 minutes
MP3 128 kbps: 59 hours 35 minutes
MP3 48 kbps (MONO): 159 hours
Carrying Case / Pouch
Page 3
PC)
Weights and Measurements
Dimensions (approx.)
1 1/2 x 4 x 7/16 in (36.6 mm x 101.5 x 10.5 mm) not including projecting
parts and controls
Weight (approx.)
1.9 oz (52 g)
1. Recording time is given for recording in Linear PCM format at 44.1 kHz/16 bit.
2. Recording time is given for recording in MP3 format at 192 kbps.
©2016 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is
prohibited. Sony and the Sony logo are registered trademarks of Sony Corporation. All other trademarks are
trademarks of their respective owners. Features and specifications are subject to change without notice. /Updated:
May 30, 2016
