Sony HCDC-990 Service manual

HCD-C770/C990

AUDIO POWER SPECIFICATIONS (C770: US model)

POWER OUTPUT AND TOTAL HARMONIC DISTORTION:

With 3 ohm loads, both channels driven, from 150 – 10,000 Hz; rated
70 watts per channel minimum RMS power, with no more than 1 %
total harmonic distortion from 250 milliwatts to rated output.

Amplifier section

Stereo mode (C770) 90 W + 90 W (3 ohms at 1 kHz, THD 10 %)

Surround mode (C770) Front: 90 W + 90 W

Center*: 90 W
Rear*: 90 W + 90 W (3 ohms at 1 kHz, THD 10 %)
Subwoofer*: 100 W (3 ohms at 100 Hz, THD 10 %)

* Depending on the sound field settings and the source, there may be no sound output.

Inputs (Analog) VIDEO 1, 2:

Sensitivity: 150 mV
Impedance: 50 kilohms

Inputs (Digital) VIDEO 2 (optical):

Sensitivity: –

Outputs (Analog) VIDEO 1 (AUDIO OUT):

Voltage: 2 V
Impedance: 1 kilohms

PHONES:

Accepts low- and high-impedance headphones

AUDIO POWER SPECIFICATIONS (C990: US model)

POWER OUTPUT AND TOTAL HARMONIC DISTORTION:

With 3 ohm loads, both channels driven, from 150 – 10,000 Hz; rated
75 watts per channel minimum RMS power, with no more than 1 %
total harmonic distortion from 250 milliwatts to rated output.

Stereo mode (C990) 100 W + 100 W (3 ohms at 1 kHz, THD 10 %)

Surround mode (C990) Front: 100 W + 100 W

Center*: 100 W
Rear*: 100 W + 100 W (3 ohms at 1 kHz, THD 10 %)
Subwoofer*: 100 W (3 ohms at 100 Hz, THD 10 %)

SERVICE MANUAL

Ver 1.5 2003.07

HCD-C770/C990 is the amplifier, DVD/CD
player and tuner section in DAV-C770/C990.

Photo: HCD-C770

SPECIFICATIONS

US Model

Canadian Model

HCD-C770/C990

AEP Model

Australian Model

HCD-C770

Model Name Using Similar Mechanism NEW
Mechanism Type CDM69-DVBU16
Base Unit Name DVBU16
Optical Traverse Unit Name DBU-1

9-874-059-06 Sony Corporation

2003G05-1 Home Audio Company

C 2003.07 Published by Sony Engineering Corporation

– Continued on next page –

SACD/DVD RECEIVER

HCD-C770/C990

g

Super Audio CD/DVD system

Laser Semiconductor laser

Signal format system NTSC or NTSC/PAL
Frequency response (at 2 CH STEREO mode)

Signal-to-noise ratio More than 80 dB (VIDEO 1 (AUDIO) connectors only)
Harmonic distortion Less than 0.03 %

FM tuner section

System PLL quartz-locked digital synthesizer system
Tuning range
North American model: 87.5 – 108.0 MHz (100 kHz step)
Other models: 87.5 – 108.0 MHz (50 kHz step)
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz

AM tuner section

System PLL quartz-locked digital synthesizer system
Tuning range
North American model: 530 – 1,710 kHz (with the interval set at 10 kHz)

European model: 531 – 1,602 kHz (with the interval set at 9 kHz)
Other models: 531 – 1,602 kHz (with the interval set at 9 kHz)

Antenna Loop antenna
Intermediate frequency 450 kHz

Video section

Inputs Video: 1 Vp-p 75 ohms
Outputs Video: 1 Vp-p 75 ohms

General

Power requirements
North American model: 120 V AC, 60 Hz
European model: 230 V AC, 50/60 Hz
Australian model: 220 – 240 V AC, 50/60 Hz
Power consumption (C770) 135 W (120 V AC) 135 W (230 V AC)

Power consumption (C990) 140 W (120 V AC)

Dimensions (approx.) × 70 × 335 mm (14 × 2

Mass (approx.) 4.4 kg (9 lb 12 oz)
Operating temperature 5˚C to 35˚C (41˚F to 95˚F)
Operating humidity 5 % to 90 %

n and specifications are subject to change without notice.

Desi

(Super Audio CD/DVD: λ = 650 nm)
(CD: λ = 780 nm)
Emission duration: continuous

DVD (PCM): 2 Hz to 22 kHz (±1.0 dB)
CD: 2 Hz to 20 kHz (±1.0 dB)

531 – 1,710 kHz (with the interval set at 9 kHz)

530 – 1,710 kHz (with the interval set at 10 kHz)

S video:

Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms

COMPONENT:

Y: 1 Vp-p 75 ohms

B/CB

, PR/CR: 0.7 Vp-p 75 ohms

P

1 W (120 V AC) 2 W (230 V AC)
(at the Power Saving Mode)

1 W (120 V AC) (at the Power Saving Mode)
355
incl. projecting parts

7

/8 × 13 1/4 inches) (w/h/d)

SELF DIAGNOSIS FUNCTION

Self-diagnosis Function

(When letters/numbers appear in the
display)

When the self-diagnosis function is
activated to prevent the system from
malfunctioning. In this case a five-character
service number (e.g., C 13 00) with a
combination of a letter and digits appears on
the screen and the front panel display. Refer
to the following table.

C:13:00

First three
characters of
the service
number

C 13

C 31

E XX

(xx is a number)

Note: Refer to the “5. TEST MODE” (page 22) for another self-diagnosis

function.

Cause and/or Corrective
Action

The disc is dirty.
, Clean the disc with a soft

cloth.

The disc is not inserted
correctly.
, Re-insert the disc

correctly.

To prevent a malfunction, the
system has performed the self­diagnosis function.
, Contact your nearest Sony

dealer or local authorized
Sony service facility and
give the 5-character
service number.
Example: E 61 10

2

HCD-C770/C990

1.5 k

Ω

0.15 µF

AC
voltmeter
(0.75 V)

To Exposed Metal
Parts on Set

Earth Ground

Notes on chip component replacement

•Never reuse a disconnected chip component.

• Notice that the minus side of a tantalum capacitor may be dam­aged by heat.

Flexible Circuit Board Repairing

•Keep the temperature of the soldering iron around 270 ˚C dur­ing repairing.

• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).

• Be careful not to apply force on the conductor when soldering
or unsoldering.

CAUTION

Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous ra­diation exposure.

SAFETY CHECK-OUT

After correcting the original service problem, perform the follow­ing safety check before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts for AC leakage.
Check leakage as described below.

LEAKAGE TEST

The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes.).
Leakage current can be measured by any one of three methods.

1. A commercial leakage tester, such as the Simpson 229 or RCA
WT -540A. Follow the man ufacturers’ instructions to use these
instruments.

2. A battery-operated A C milliammeter. The Data Precision 245
digital multimeter is suitable for this job.

3. Measuring the voltage drop across a resistor by means of a V OM
or battery-operated A C voltmeter . The “limit” indication is 0.75
V, so analog meters must have an accurate low-voltage scale.
The Simpson 250 and Sanwa SH-63Trd are examples of a pas­sive VOM that is suitable. Nearly all battery operated digital
multimeters that have a 2 V A C range are suitable. (See Fig. A)

This appliance is classified as a
CLASS 1 LASER product. The label
is located on the bottom exterior.

This label is located on the bottom
exterior.

Fig. A. Using an AC voltmeter to check AC leakage.

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED
LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB­LISHED BY SONY.

ATTENTION AU COMPOSANT AYANT RAPPORT

À LA SÉCURITÉ!

LES COMPOSANTS IDENTIFIÉS P AR UNE MARQUE 0
SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE
DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ
DE FONCTIONNEMENT. NE REMPLACER CES COM­POSANTS QUE PAR DES PIÈCES SONY DONT LES
NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.

3

HCD-C770/C990

Ver 1.5
