Sony FDR-AX1 Marketing Specifications
FDR-AX1
Sony’s First 4K/60p Consumer Camcorder
Tell your story in four times the resolution of Full HD with the 4K camera that’s
made for everyone. Shoot with the breathtaking quality of XAVC-S 4K/60p
and capture professional audio with XLR mic inputs. Even take direct,
manual control with zoom, focus and iris rings, plus 7 assignable buttons. The
groundbreaking power of 4K is ready to capture your imagination—experience
it with Sony. Let the revolution begin.
Key Features
Capture 4K/60p video that far exceeds HD resolution
Playback 4K content captured on the AX1 on a compatible1 4K TV by simply connecting the two devices with supplied
HDMI cable. Thanks to original Sony technology, Sony BRAVIA TVs especially bring out the full quality of 4K/60p recordings.
Full HD monitors can also be used to enjoy this content by simply changing the menu HDMI output settings to 1920 x 1080.
XAVC-S codec allows extended 4K/HD video recording
The FDR-AX1 records 4K/HD movies in the XAVC-S format, which was developed for consumer usage based on the
professional XAVC 4K/HD format. XAVC-S uses MPEG-4 AVC/H.264 Long GOP for video and linear PCM for audio
compression, while saving les in an MP4 wrapper. The XAVC-S codec allows longer recording times within a given media
capacity than XAVC, making 4K recording easier and more convenient.
1/2.3” 8.3MP Exmor R® CMOS image sensor
Sony’s unique Exmor R® CMOS sensor is essential to the stunning image quality that the FDR-AX1 achieves. Its backilluminated structure featuring wiring layers on the back of a photodiode (light receiving element) dramatically boosts
low-light sensitivity for shooting better, more lifelike images even in dim lighting. Sony’s cutting-edge technology also
makes the camera nimble at reading massive 4K data at 60 fps.
Professional image processor for real-time 4K / 60 fps recording
An extraordinary image processor, identical to those in 4K camcorders used by professionals, rapidly processes signals
transmitted from the CMOS sensor and nalizes images. In processing the vast 4K data in real time at 60p, the processor
achieves four times the resolution of the HD format. This processor not only features high-performance noise reduction
technology for better image quality, it is also specically tuned for the AX1 so it delivers image processing performance
that accelerates the evolution of camcorders.
Sony G-lens with 20X (31.5-630mm eq.) smooth servo zoom
The “G Lens” advances the Sony heritage of image processing innovation by redening what an aspheric lens and
special low-dispersion glass together can faithfully reproduce. Accordingly, the “G Lens” is specially tuned to capture
qualities of denition and color that put these groundbreaking Handycam® camcorders in a class of their own. In addition,
the high-quality lens oers a broad zooming range from wide-angle to 20x optical zoom (31.5-630mm 35mm equivalent),
enabling an amazing range of video expression.
3 ND lters and 5 paint functions for expressive cinematic looks
The AX1 features three ND lters for adjusting the amount of light entering the image sensor from the lens. There are
four lter settings: O (Clear), ¼ lter, 1/16 lter and 1/64 lter. These lter settings give users the ability to adjust to light
conditions, while maintaining desired shutter angle and aperture even on bright and sunny days. Six paint functions
(white, oset white, gamma, detail, skin detail and matrix) can be combined and adjusted in the paint menu to create
expressive movie styling and cinematic looks.
Built-in mic w/2x additional Pro XLR jacks for external inputs
In addition to a high-performance internal microphone, the AX1 features two external XLR jacks for connecting external
microphones that can also be used to record superior-quality balanced audio synchronized to the video. You can also
mix audio from recordings made using the internal microphone and externally connected microphones, respectively.
7x assignable buttons and 3x control rings (focus/iris/zoom)
The AX1 was designed with two start/stop buttons (one on the side of the camera grip and another on the handle) for
ease of use while shooting.
The handle also features a zoom lever that enables convenient access while shooting from low angles.
Seven assignable buttons can be programmed with functions that enable users to quickly access them without using
menus. Assign functions to adjust to shooting conditions on the y such as Marker, Zebra, Peaking, Focus Magnier, Auto
Exposure Level, Steadyshot, Color Bars, Rec Lamp [F], Rec Lamp [R].
Two XQD card slots for high-speed 4K recording and playback
The AX1 uses XQD media card for smooth, high-speed reading and writing of 4K video and features two XQD media slots.
A relay recording feature makes it possible to lengthen recording by automatically switching between two or more
media.
The AX1 is compatible with following types of XQD media cards:
XQD media card S-series
XQD media card H-series
XQD media card N-series
View 4K 60P video on compatible BRAVIA® TVs w/supplied HDMI® cable
Playback 4K content captured on the FDR-AX1 on a 4K TV by simply connecting the two devices with supplied HDMI
cable. Thanks to original Sony technology, Sony BRAVIA® TVs especially bring out the full quality of 4K/60p recordings. Full
HD monitors can also be used to enjoy this content by simply changing the menu HDMI output settings to 1920 x 1080.
®
Zebra, Peaking, Center marker and guide frame
Have condence in getting the setting right and not missing he shot. Tools such as Zebra, Peaking, Center Marker and
Guide Frame are professional features to enable precise manual control.
Zebra: While recording, this function highlights over exposed bright areas with stripes in the LCD and viewnder. This
feedback helps users adjust brightness and prevent whiteout.
Peaking highlights the area’s most sharply in focus, in the LCD and viewnder for accurate manual focusing. Users can
choose white, red, yellow or blue peaking to clearly contrast with the subject and adjust the peaking level to low, medium
or high.
Determine the center of your image at a glance using the Center Marker feature in the LCD or viewnder and use the
guide frame for aligning horizontal and vertical lines to ensure your captured image is within screen boundaries.
High-quality XAVC-S up to 150 Mbps 4K / 50Mbps HD recording
High quality XAVC-S can be recorded to 150mbps. Additionally, there is also an option to record very high quality Full HD
at 50mbps with the FDR-AX1.
Specications
Camera
Camera Type Digital 4K Video Camera Recorder
Imaging Sensor
Imaging Sensor 1/2.3” back-illuminated Exmor R® CMOS Sensor
Pixel Gross Approx.18900K pixels
Eective Picture Resolution Movie: Approx.8300K pixels
Color Filter System RGB primary color lters
Recording
Media Type XQD Memory Card x 2
Video Format
Video Resolution
Video Actual (Pixel) Approx.8300K pixels
Video Signal 4K (UHDTV), ITU standard
Microphone/Speaker Built-in Stereo Microphone, Monoral Speaker
XAVC- S format
MPEG4-AVC/H264
HD: 1920×1080 60P (50), 1920×1080 30P (50), 1920×1080 24P (50), 1920×1080 50P
(50), 1920×1080 25P (50);4K: 3840×2160 60P (150), 3840×2160 30P (100), 3840×2160
30P (60), 3840×2160 24P (100), 3840×2160 24P (60), 3840×2160 50P (150), 3840×2160
25P (100), 3840×2160 25P (60)
