Sony DSXM55BT User Manual

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\010COV.fm masterpage: Cover

010COV.book Page 1 Wednesday, December 2, 2015 8:19 PM

4-588-324-11(1)

FM/AM Digital Media Player

The warranty for this product is included in this manual (page 38, 39).

La garantie de ce produit est inclus dans le présent manuel (page 37).

Owner’s Record

The model and serial numbers are located on the bottom of the unit. Record the serial number in the spaces provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product.

Model No. DSX-M55BT Serial No.

To cancel the demonstration (DEMO) display, see page 21.

To switch the FM/AM tuning step, see page 9. For the connection/installation, see page 33.

Pour annuler l’affichage de démonstration (DEMO), reportez-vous à la page 00.

Pour commuter l’intervalle de syntonisation FM/AM, reportezvous à la page 00.

Pour le raccordement/l’installation, reportez-vous à la page 00.

Para cancelar la pantalla de demostración (DEMO), consulte la página 00.

Para cambiar el paso de sintonización de FM/AM, consulte la página 00.

Para la conexión/instalación, consulte la página 00.

Operating Instructions

Mode d’emploi

Manual de instrucciones

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\020INT.fm masterpage: Left

010COV.book Page 2 Wednesday, December 2, 2015 8:19 PM

For safety, be sure to install this unit in the dashboard of the boat as the rear side of the unit becomes hot during use. For details, see “Connection/Installation” (page 33).

The nameplate indicating operating voltage, etc., is located on the bottom of the chassis.

Warning

FOR THE CUSTOMERS IN THE USA. NOT APPLICABLE IN CANADA, INCLUDING IN THE PROVINCE OF QUEBEC.

POUR LES CLIENTS AUX ÉTATS-UNIS. NON APPLICABLE AU CANADA, Y COMPRIS LA PROVINCE DE QUÉBEC.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.  Increase the separation between the

equipment and receiver.

 Connect the equipment into an outlet on a

circuit different from that to which the receiver is connected.

 Consult the dealer or an experienced radio/TV

technician for help.

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

2GB

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\020INT.fm masterpage: Right_

010COV.book Page 3 Wednesday, December 2, 2015 8:19 PM

This device complies with Part 15 of the FCC Rules and Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.

This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that is deemed to comply without maximum permissive exposure evaluation (MPE).

For the State of California, USA only

Perchlorate Material – special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate

Made in Thailand

Hereby, Sony Corporation, declares that this equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. For details, please access the following URL: http://www.compliance.sony.de/

Notice for customers: the following information is only applicable to equipment sold in countries applying EU Directives

Manufacturer: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan For EU product compliance: Sony Belgium, bijkantoor van Sony Europe Limited, Da Vincilaan 7-D1, 1935 Zaventem, Belgium

Disposal of waste batteries and electrical and electronic equipment (applicable in the European Union and other European countries with separate collection systems)

This symbol on the product, the battery or on the packaging indicates that the product and the battery shall not be treated as household waste. On certain batteries this symbol might be used in combination with a chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are added if the battery contains m ore than 0.0005% mercury or

0.004% lead. By ensuring these products and batteries are disposed of correctly, you will help prevent potentially negative consequences for the environment and human health which could otherwise be caused by inappropriate waste handling. The recycling of the materials will help to conserve natural resources. In case of products that for safety, performance or data integrity reasons require a permanent connection with an incorporated battery, this battery should be replaced by qualified service staff only. To ensure that the battery and the electrical and electronic equipment will be treated properly, hand over these products at end-of-life to the applicable collection point for the recycling of electrical and electronic equipment. For all other batteries, please view the section on how to remove the battery from the product safely. Hand the battery over to the applicable collection point for the recycling of waste batteries. For more detailed information about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product or battery.

3GB

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\020INT.fm masterpage: Left

010COV.book Page 4 Wednesday, December 2, 2015 8:19 PM

Note on the lithium battery

Do not expose the battery to excessive heat such as direct sunlight, fire or the like.

Warning if your boat’s ignition has no ACC position

Be sure to set the AUTO OFF function (page 21). The unit will shut off completely and automatically in the set time after the unit is turned off, which prevents battery drain. If you do not set the AUTO OFF function, press and hold OFF until the display disappears each time you turn the ignition off.

Disclaimer regarding services offered by third parties

Services offered by third parties may be changed, suspended, or terminated without prior notice. Sony does not bear any responsibility in these sorts of situations.

Important notice

Caution

IN NO EVENT SHALL SONY BE LIABLE FOR ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR OTHER DAMAGES INCLUDING, WITHOUT LIMITATION, LOSS OF PROFITS, LOSS OF REVENUE, LOSS OF DATA, LOSS OF USE OF THE PRODUCT OR ANY ASSOCIATED EQUIPMENT, DOWNTIME, AND PURCHASER’S TIME RELATED TO OR ARISING OUT OF THE USE OF THIS PRODUCT, ITS HARDWARE AND/OR ITS SOFTWARE.

Dear customer, this product includes a radio transmitter. According to UNECE Regulation no. 10, vessel manufacturers may impose specific conditions for installation of radio transmitters into boats. Please check your boat’s operation manual or contact the manufacturer or your boat dealer, before you install this product.

Emergency calls

This BLUETOOTH boat handsfree and the electronic device connected to the handsfree operate using radio signals, cellular, and landline networks as well as user-programmed function, which cannot guarantee connection under all conditions. Therefore do not rely solely upon any electronic device for essential communications (such as medical emergencies).

On BLUETOOTH communication

 Microwaves emitting from a BLUETOOTH device

may affect the operation of electronic medical devices. Turn off this unit and other BLUETOOTH devices in the following locations, as it may cause an accident.  where inflammable gas is present, in a hospital,

train, airplane, or petrol station

 near automatic doors or a fire alarm

 This unit supports security capabilities that

comply with the BLUETOOTH standard to provide a secure connection when the BLUETOOTH wireless technology is used, but security may not be enough depending on the setting. Be careful when communicating using BLUETOOTH wireless technology.

 We do not take any responsibility for the leakage

of information during BLUETOOTH communication.

If you have any questions or problems concerning your unit that are not covered in this manual, consult your nearest Sony dealer.

4GB

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\010COVTOC.fm masterpage: Right

010COV.book Page 5 Wednesday, December 2, 2015 8:19 PM

Table of Contents

Warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Guide to Parts and Controls . . . . . . . . . . . . . . . . . . 6

Getting Started

Detaching the Front Panel. . . . . . . . . . . . . . . . . . . . 8

Switching the FM/AM Tuning Step . . . . . . . . . . . . . 9

Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Preparing a BLUETOOTH Device . . . . . . . . . . . . . . . 9

Connecting a USB Device . . . . . . . . . . . . . . . . . . . . 11

Connecting Other Portable Audio Device . . . . . . . 12

Listening to the Radio

Listening to the Radio . . . . . . . . . . . . . . . . . . . . . . . 12

Using Radio Data System (RDS) . . . . . . . . . . . . . . . 13

Listening to the SiriusXM Radio

(US/Canada only) . . . . . . . . . . . . . . . . . . . . . . . . 13

Playback

Playing a USB Device . . . . . . . . . . . . . . . . . . . . . . . . 15

Playing a BLUETOOTH Device . . . . . . . . . . . . . . . . . 15

Searching and Playing Tracks . . . . . . . . . . . . . . . . 16

Listening to Pandora®

Setting up Pandora® . . . . . . . . . . . . . . . . . . . . . . . . 17

Streaming Pandora®. . . . . . . . . . . . . . . . . . . . . . . . . 17

Available Operations in Pandora®. . . . . . . . . . . . . . 17

Settings

Canceling the DEMO Mode. . . . . . . . . . . . . . . . . . . 21

Basic Setting Operation . . . . . . . . . . . . . . . . . . . . . 21

General Setup (GENERAL) . . . . . . . . . . . . . . . . . . . . 21

Sound Setup (SOUND) . . . . . . . . . . . . . . . . . . . . . . . 22

Display Setup (DISPLAY) . . . . . . . . . . . . . . . . . . . . . 22

BLUETOOTH Setup (BT) . . . . . . . . . . . . . . . . . . . . . . 22

Additional Information

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Connection/Installation

Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Parts List for Installation . . . . . . . . . . . . . . . . . . . . . 33

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Important notice

The warranty for this product is included in this manual (page 38, 39). Keep this manual for future use.

Handsfree Calling (via BLUETOOTH only)

Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Available Operations during Call . . . . . . . . . . . . . 19

Useful Functions

Using Siri Eyes Free . . . . . . . . . . . . . . . . . . . . . . . . 20

5GB

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\030CD.fm masterpage: Left

010COV.book Page 6 Wednesday, December 2, 2015 8:19 PM

Guide to Parts and Controls

Main unit

 Front panel release button  SRC (source)

Turn o n th e po wer. Change the source.

OFF

Press and hold for 1 second to turn the source off and display the clock. Press and hold for more than 2 seconds to turn off the power and the display. If the unit is turned off and the display disappears, operation by the remote commander is not available.

 Control dial

Rotate to adjust the volume.

PUSH ENTER

Enter the selected item.

MENU*

Open the setup menu.

VOICE (page 19, 20)

Press and hold for more than 2 seconds to activate voice dial or the Siri function (iPhone only).

6GB

N-Mark

Touch the control dial with Android™ smartphone to make Bluetooth® connection.

* Not available when the BT phone is selected.

 Display window  SEEK +/–

Tune in radio stations automatically. Press and hold to tune manually.

/ (prev/next) / (fast-reverse/fast-forward)

 PTY (program type)

Select PTY in RDS.

(browse) (page 14, 16, 17)

Enter the browse mode during playback.

 CALL

Enter the call menu. Receive/end a call. Press and hold for more than 2 seconds to switch the BLUETOOTH signal.

 MODE (page 12, 14, 15, 17, 19)

(back)

Return to the previous display.

 Receptor for the remote commander

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\030CD.fm masterpage: Right

010COV.book Page 7 Wednesday, December 2, 2015 8:19 PM

 Number buttons (1 to 6)

Receive stored radio stations. Press and hold to store stations. Call a stored phone number. Press and hold to store a phone number.

ALBUM /

Skip an album for audio device. Press and hold to skip albums continuously. Press  to thumbs up, or  to thumbs down in Pandora® (page 17).

(repeat)

(shuffle) MIC (page 19) PAU SE

 MEGA BASS

Reinforces bass sound in synchronization with the volume level. Press to change the MEGA BASS setting: [1], [2], [OFF].

 AUX input jack  DSPL (display)

Press to change display items.

SCRL (scroll)

Press and hold to scroll a display item.

 USB port  Microphone (inner panel)

In order for the handsfree function to work properly, do not cover the microphone with tape, etc.

RM-X231 Remote commander

The VOL (volume) + button has a tactile dot.

 CALL

Enter the call menu. Receive/end a call.

 SOUND*

Open the SOUND menu directly.

MENU*

Press and hold to open the setup menu.

* Not available when the BT phone is selected.

///

Select a setup item, etc.

ENTER

Enter the selected item.

/ (prev/next) +/– (album +/–)

 VOL (volume) +/–

7GB

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\030CD.fm masterpage: Left

010COV.book Page 8 Wednesday, December 2, 2015 8:19 PM

Remove the insulation film before use.

Getting Started

Detaching the Front Panel

You can detach the front panel of this unit to prevent theft.

1 Press and hold OFF  until the unit turns

RM-X11M Marine remote commander (not supplied)

 VOL (volume) +/–  GP (group)/ALBM (album) +/–

Receive stored stations.

off, press the front panel release button , then pull the panel towards you to remove.

Caution alarm

If you turn the ignition switch to the OFF position without detaching the front panel, the caution alarm will sound for a few seconds. The alarm will only sound if the built-in amplifier is used.

Serial numbers

Make sure the serial numbers on the bottom of the unit and the back of the front panel are matched correctly. Otherwise you cannot make BLUETOOTH pairing, connection and disconnection by NFC.

8GB

Attaching the front panel

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\030CD.fm masterpage: Right

010COV.book Page 9 Wednesday, December 2, 2015 8:19 PM

Switching the FM/AM Tuning Step

Set the FM/AM tuning step of your country. This setting appears only while the source is off and

the clock is displayed.

1 Press MENU, rotate the control dial to

select [SET GENERAL], then press it.

2 Rotate the control dial to select [SET

TUNER-STP], then press it.

3 Rotate the control dial to select from [SET

50K/9K], [SET 100K/10K] or [SET 200K/ 10K], then press it.

Setting the Clock

1 Press MENU, rotate the control dial to

select [SET GENERAL], then press it.

2 Rotate the control dial to select [SET

CLOCK-ADJ], then press it.

The hour indication flashes.

3 Rotate the control dial to set the hour

and minute.

To move the digital indication, press SEEK +/–.

4 After setting the minute, press MENU.

The setup is complete and the clock starts.

To display the clock

Press DSPL.

Preparing a BLUETOOTH Device

You can enjoy music, or perform handsfree calling depending on the BLUETOOTH compatible device such as a smartphone, cellular phone and audio device (hereafter “BLUETOOTH device” if not otherwise specified). For details on connecting, refer to the operating instructions supplied with the device. Before connecting the device, turn down the volume of this unit; otherwise, loud sound may result.

Connecting with a Smartphone by One touch (NFC)

By touching the control dial on the unit with an NFC* compatible smartphone, the unit is paired and connected with the smartphone automatically.

* NFC (Near Field Communication) is a technology

enabling short-range wireless communication between various devices, such as mobile phones and IC tags. Thanks to the NFC function, data communication can be achieved easily just by touching the relevant symbol or designated location on NFC compatible devices.

For a smartphone with Android OS 4.0 or lower installed, downloading the app “NFC Easy Connect” available at Google Play™ is required. The app may not be downloadable in some countries/regions.

1 Activate the NFC function on the

smartphone.

For details, refer to the operating instructions supplied with the smartphone.

2 Touch the N-Mark part of the unit with

the N-Mark part of the smartphone.

Make sure that lights up on the disp lay of the unit.

9GB

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\030CD.fm masterpage: Left

[0000]

Input passkey

010COV.book Page 10 Wednesday, December 2, 2015 8:19 PM

To disconnect by One touch

Touch the N-Mark part of the unit with the N-Mark part of the smartphone again.

Notes

 When making the connection, handle the

smartphone carefully to prevent scratches.

 One touch connection is not possible when t he unit is

already connected to another NFC compatible device. In this case, disconnect the other device, and make connection with the smartphone again.

Pairing and connecting with a BLUETOOTH device

When connecting a BLUETOOTH device for the first time, mutual registration (called “pairing”) is required. Pairing enables this unit and other devices to recognize each other.

1 Place the BLUETOOTH device within 1 m

(3 ft) of this unit.

2 Press CALL, rotate the control dial to

select [SET PAIRING], then press it.

flashes while the unit is in pairing standby

mode.

3 Perform pairing on the BLUETOOTH

device so it detects this unit.

4 Select [DSX-M55BT] shown in the display

of the BLUETOOTH device.

If your model name does not appear, repeat from step 2.

5 If passkey* input is required on the

BLUETOOTH device, input [0000].

* Passkey may be called “Passcode,” “PIN code,”

“PIN number” or “Password,” etc., depending on the device.

When pairing is made, stays lit.

6 Select this unit on the BLUETOOTH device

to establish the BLUETOOTH connection.

or lights up when the connection is made.

Note

While connecting to a BLUETOOTH device, this unit cannot be detected from another device. To enable detection, enter the pairing mode and search for this unit from another device.

To start playback

For details, see “Playing a BLUETOOTH Device” (page 15).

To cancel pairing

Perform step 2 to cancel the pairing mode after this unit and the BLUETOOTH device are paired.

Connecting with a paired BLUETOOTH device

To use a paired device, connection with this unit is required. Some paired devices will connect automatically.

10GB

1 Press CALL, rotate the control dial to

select [SET BT SIGNL], then press it.

Make sure that lights up.

2 Activate the BLUETOOTH function on the

BLUETOOTH device.

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\030CD.fm masterpage: Right

010COV.book Page 11 Wednesday, December 2, 2015 8:19 PM

3 Operate the BLUETOOTH device to

connect to this unit.

or lights up.

Icons in the display:

Lights up when handsfree calling is available by enabling the HFP (Handsfree Profile).

Lights up when the audio device is playable by enabling the A2DP (Advanced Audio Distribution Profile).

To connect the last-connected device from this unit

Activate the BLUETOOTH function on the BLUETOOTH device. Press SRC to select [BT PHONE] or [BT AUDIO]. Press ENTER to connect with the cellular phone, or PAUSE to connect with the audio device.

Note

While streaming BLUETOOTH audio, you cannot connect from this unit to the cellular phone. Connect from the cellular phone to this unit instead.

Tip

With BLUETOOTH signal on: when the ignition is turned to on, this unit reconnects automatically to the lastconnected ce llul ar phone.

Connecting with an iPhone/iPod (BLUETOOTH Auto Pairing)

When an iPhone/iPod with iOS5 or later installed is connected to the USB port, the unit is paired and connected with the iPhone/iPod automatically. To enable BLUETOOTH Auto Pairing, make sure [AUTOPAIR] in [BT] is set to [ON] (page 23).

1 Activate the BLUETOOTH function on the

iPhone/iPod.

2 Connect an iPhone/iPod to the USB port.

Make sure that lights up on the disp lay of the unit.

Notes

 BLUETOOTH Auto Pairing is not possible if the unit is

already connected to another BLUETOOTH device. In this case, disconnect the other device, then connect the iPhone/iPod again.

 If BLUETOOTH Auto Pairing is not established, see

“Preparing a BLUETOOTH Device” for details (page 9).

Connecting a USB Device

1 Turn down the volume on the unit. 2 Connect the USB device to the unit.

To connect an iPod/iPhone, use the USB connection cable for iPod (not supplied).

11GB

DSX-M55BT

4-588-324-11(1)

G:\DATA\4588324111\4588324111DSXM55BTUC\01GB-DSXM55BTUC\030CD.fm masterpage: Left

010COV.book Page 12 Wednesday, December 2, 2015 8:19 PM

Connecting Other Portable Audio Device

1 Turn off the portable audio device. 2 Turn down the volume on the unit. 3 Connect the portable audio device to the

AUX input jack (stereo mini jack) on the unit with a connecting cord (not supplied)*.

* Be sure to use a straight type plug.

4 Press SRC to select [AUX].

To match the volume level of the connected device to other sources

Start playback of the portable audio device at a moderate volume, and set your usual listening volume on the unit. Press MENU, then select [SET SOUND]  [SET AUX VOL] (page 22).

Listening to the Radio

Tuning step setting is required (page 9). To listen to the radio, press SRC to select [TUNER].

Storing automatically (BTM)

1 Press MODE to change the band (FM1,

FM2, FM3, AM1 or AM2).

2 Press MENU, rotate the control dial to

select [SET GENERAL], then press it.

3 Rotate the control dial to select [SET

BTM], then press it.

The unit stores stations in order of frequency on the number buttons.

Tuning

1 Press MODE to change the band (FM1,

FM2, FM3, AM1 or AM2).

2 Perform tuning.

To tune manually

Press and hold SEEK +/– to locate the approximate frequency, then press SEEK +/– repeatedly to fine adjust to the desired frequency.

To tune automatically

Press SEEK +/–. Scanning stops when the unit receives a station.

12GB

Storing manually

1 While receiving the station that you want

to store, press and hold a number button (1 to 6) until [MEM] appears.

DSX-M55BT

4-588-324-11(1)

+ 28 hidden pages
