Page 1

VCLICK!

Table of contents

Basic Operations

Using functions for shooting

Digital Still Camera

Cyber-shot Handbook

DSC-W200

Before operating the unit, please read this Handbook thoroughly together with the

“Instruction Manual” and the “Cyber-shot Step-up Guide”, and retain them for future

reference.

Using functions for viewing

Customizing the settings

Viewing images on a TV

Using your computer

Printing still images

Troubleshooting

Others

Index

Page 2

Notes on using your camera

Types of “Memory Stick” that can be used (not supplied)

The IC recording medium used by this camera is a “Memory Stick Duo”. There are two types of “Memory Stick”.

“Memory Stick Duo”: you can use a “Memory Stick Duo” with your camera.

“Memory Stick”: you cannot use a “Memory Stick” with your camera.

Other memory cards cannot be used.

• For details on “Memory Stick Duo”, see page 118.

When using a “Memory Stick Duo” with “Memory Stick” compatible equipment

You can use the “Memory Stick Duo” by inserting it into the Memory Stick Duo Adaptor (not supplied).

Memory Stick Duo Adaptor

Notes on the battery pack

• Charge the battery pack (supplied) before using the camera for the first time.

• The battery pack can be charged even if it is not completely discharged. Also, even if the battery pack is not fully charged, you can use the partially charged capacity of the battery pack as is.

• If you do not intend to use the battery pack for a long time, use up the existing charge and remove it from your camera, then store it in a cool, dry place. This is to maintain the battery pack functions.

• For details on the usable battery pack, see page 120.

Carl Zeiss lens

This camera is equipped with a Carl Zeiss lens which is capable of reproducing sharp images with excellent contrast. The lens for this camera has been produced under a quality assurance system certified by Carl Zeiss in accordance with the quality standards of Carl Zeiss in Germany.

Notes on the LCD screen and lens

• The LCD screen is manufactured using extremely high-precision technology so over

99.99% of the pixels are operational for effective use. However, there may be some tiny black points and/or bright points (white, red, blue or green in color) that constantly appear on the LCD screen. These points are normal in the manufacturing process and do not affect the recording in any way.

Black, white, red, blue or green points

• Exposing the LCD screen or the lens to direct sunlight for long periods may cause malfunctions. Be careful when placing the camera near a window or outdoors.

• Do not press against the LCD screen. The screen may be discolored and that may cause a malfunction.

• Images may trail across on the LCD screen in a cold location. This is not a malfunction.

• Be careful not to bump the movable lens, and be careful not to apply force to it.

The pictures used in this Handbook

The photographs used as examples of pictures in this Handbook are reproduced images, and are not actual images shot using this camera.

Page 3

Notes on using your camera .....................................................................2

Basic techniques for better images ...........................................................7

Focus – Focusing on a subject successfully..................................................... 7

Exposure – Adjusting the light intensity ............................................................ 9

Color – On the effects of lighting ..................................................................... 10

Quality – On “image quality” and “image size” ............................................... 11

Flash – On using the flash ............................................................................... 13

Identifying parts.......................................................................................14

Indicators on the screen..........................................................................16

Changing the screen display...................................................................20

Using the internal memory ......................................................................22

Basic Operations

Using the mode dial.................................................................................23

Shooting images easily (Auto Adjustment mode)....................................24

Shooting still images (Scene Selection) ..................................................28

Shooting with the manual exposure........................................................31

Viewing images .......................................................................................32

Deleting images.......................................................................................34

Learning the various functions – HOME/Menu........................................36

Menu items..............................................................................................39

Using functions for shooting

Shooting menu ........................................................................................40

Scene Selection: Selecting the scene selection Image Size: Selecting the image size Face Detection: Detecting the face of subject REC Mode: Selecting the continuous shooting method Color Mode: Changing the vividness of the image or adding special effects ISO: Selecting a luminous sensitivity EV: Adjusting the light intensity Metering Mode: Selecting the metering mode Focus: Changing the focus method White Bal: Adjusting the color tones Flash Level: Adjusting the amount of flash light Red Eye Reduction: Reducing the red-eye phenomenon Contrast: Adjusting the contrast Sharpness: Adjusting the sharpness

Page 4

Table of contents

SteadyShot: Selecting the anti-blur mode SETUP: Selecting the shooting settings

Using functions for viewing

Playing back images from the HOME screen.............................52

(Single Image): Playing back a single image (Index Display): Playing back a list of images (Slide Show): Playing back a series of images

Viewing menu .....................................................................................55

(Delete): Deleting images (Slide Show): Playing back a series of images

(Retouch): Retouching still images after shooting

(Protect): Preventing accidental erasure

: Adding a Print order mark (Print): Printing images using a printer (Rotate): Rotating a still image (Select Folder): Selecting the folder for viewing images

Customizing the settings

Customizing the Manage Memory feature and the Settings

........ 60

Manage Memory..........................................................................62

Memory Tool — Memory Stick Tool................................................. 62

Format Create REC. Folder

Change REC. Folder Copy

Memory Tool — Internal Memory Tool .............................................65

Format

Settings ..........................................................................................66

Main settings — Main Settings 1...................................................... 66

Beep Function Guide

Initialize

Main settings — Main Settings 2...................................................... 67

USB Connect COMPONENT

Video Out

Shooting Settings — Shooting Settings 1.........................................69

AF Illuminator Grid Line AF Mode

Digital Zoom Conversion Lens

Page 5

Table of contents

Shooting Settings — Shooting Settings 2.........................................72

Auto Orientation Auto Review

Clock Settings...................................................................................73

Language Setting..............................................................................74

Viewing images on a TV

Viewing images on a TV..........................................................................75

Using your computer

Enjoying your Windows computer...........................................................78

Installing the software (supplied).............................................................80

Copying images to your computer...........................................................81

Viewing image files stored on a computer with your camera (using a

“Memory Stick Duo”) ...............................................................................87

Using the “Picture Motion Browser” (supplied)........................................88

Using the “Music Transfer” (supplied) .....................................................94

Using your Macintosh computer..............................................................95

Printing still images

How to print still images ..........................................................................97

Printing images directly using a PictBridge compliant printer..................98

Printing at a shop ..................................................................................101

Troubleshooting

Troubleshooting.....................................................................................103

Warning indicators and messages........................................................114

Others

To use your camera abroad — Power sources.....................................117

On the “Memory Stick” ..........................................................................118

On the battery pack...............................................................................120

On the battery charger ..........................................................................121

Page 6

Table of contents

Index

Index .....................................................................................................122

Page 7

Basic techniques for better images

Focus

Exposure

Color Quality

This section describes the basics so you can enjoy your camera. It tells you how to use various camera functions such as the mode dial (page 23), the HOME screen (page 36), the menus (page 38), and so on.

Focusing on a subject successfully

Flash

When you press the shutter button halfway down, the camera adjusts the focus automatically (Auto Focus). Remember to press the shutter button only halfway down.

Press the shutter button fully down suddenly.

To shoot a still image difficult to focus on If the image looks blurred even after focusing, it may be because of camera shake.

Press the shutter button halfway down.

t [Focus] (page 46)

AE/AF lock indicator flashing , lit/beeps

Then press the shutter button fully down.

t See

“Hints for preventing blur” (as follows).

Page 8

Basic techniques for better images

Hints for preventing blur

The camera moved accidentally when you took the picture. This is called “Camera shake.” On the other hand, if the subject moved when you took the picture, it is called “subject blur.”

Camera shake

Cause

Your hands or body shake while you hold the camera and press the shutter button, and the entire screen is blurred.

What you can do to reduce the blurring

• Use a tripod or place the camera on a flat, stable surface to hold the camera steady.

• Shoot with a 2-second delay self-timer and stabilize your camera by holding your shooting arm firmly at your side after pressing the shutter button.

Subject blur

Cause

Even though the camera is steady, the subject moves during the exposure so the subject looks blurred when the shutter button is pressed.

Notes

• The anti-blur function is enabled in the factory default settings so that the camera shake is reduced automatically. However, this is not effective for subject blur.

• Besides, camera shake and subject blur occur frequently under low-light or slow shutter speed conditions, such as those encountered in Twilight or Twilight Portrait mode. In that case, shoot with the above tips in mind.

What you can do to reduce the blurring

• Select (High Sensitivity mode) or (Extra High Sensitivity mode) in Scene Selection.

• Select a higher ISO sensitivity to make the shutter speed faster, and press the shutter button before the subject moves.

Page 9

Basic techniques for better images

Exposure

You can create various images by adjusting the exposure and the ISO sensitivity. Exposure is the amount of light that the camera will receive when you release the shutter.

Adjusting the light intensity

Shutter speed = Length of time the camera receives

Exposure:

Aperture = Size of the opening allowing light to pass

Overexposure

= too much light Whitish image

Correct exposure

Underexposure

= too little light Darker image

light

through

ISO sensitivity (Recommended Exposure Index)

Recording sensitivity

The exposure is automatically set to the proper value in the auto adjustment mode. However, you can adjust it manually using the functions below.

Manual exposure:

Allows you to adjust the shutter speed and aperture value manually (page 31).

Adjusting EV:

Allows you to adjust the exposure determined by the camera (pages 21, 44).

Metering Mode:

Allows you to change the part of the subject to be measured to determine the exposure (page 45).

Page 10

Basic techniques for better images

Adjusting ISO Sensitivity (Recommended Exposure Index)

ISO sensitivity is a speed rating for recording media that incorporates an image sensor that receives light. Even when the exposure is the same, images differ depending on the ISO sensitivity. To adjust the ISO sensitivity, see page 44.

High ISO sensitivity

Records a bright image even when shooting in a dark location. However, the image tends to become noisy.

Low ISO sensitivity

Records a smoother image. However, when the exposure is insufficient, the image may become darker.

Color

The apparent color of the subject is affected by the lighting conditions.

On the effects of lighting

Example: The color of an image affected by light sources

Weather/lighting

Characteristics of light

The color tones are adjusted automatically in the auto adjustment mode. However, you can adjust color tones manually with [White Bal] (page 48).

Daylight Cloudy Fluorescent Incandescent

White (standard) Bluish Green-tinged Reddish

Page 11

Basic techniques for better images

Quality

On “image quality” and “image size”

A digital image is made up of a collection of small dots called pixels. If it contains a large number of pixels, the picture becomes large, it takes up more memory, and the image is displayed in fine detail. “Image size” is shown by the number of pixels. Although you cannot see the differences on the screen of the camera, the fine detail and data processing time differ when the image is printed or displayed on a computer screen.

Description of the pixels and the image size

1 Image size: 12M

4000 pixels × 3000 pixels = 12,000,000 pixels

2 Image size: VGA

Pixels

640 pixels × 480 pixels = 307,200 pixels

Selecting the image size for use (page 12)

Pixel

Many pixels (Fine image quality and large file size)

Few pixels (Rough image quality but small file size)

Example: Printing in up to A3+ size

Example: An attached image to be sent by email

Page 12

Basic techniques for better images

The default settings are marked with .

Image size Guidelines No. of images Printing

12M

For prints up to A3+ (13×19") Less

(4000×3000)

3:2

Shoot in 3:2 aspect ratio

(4000×2672)

For prints up to A3 (11×17")

(3264×2448)

For prints up to A4 (8.5×11")

(2592×1944)

3M (2048×1536)

For prints up to 10×15 cm (4×6") or 13×18 cm (5×7")

Fine

VGA (640×480)

16:9

Shoot at a small image size for e-mail attachment

Shoot in HDTV aspect ratio

(1920×1080)

1) Images are recorded in 3:2 aspect ratio, same as photograph printing paper or postcards, etc.

2) Both edges of the image may be cut off when printing (page 111).

Movie image size Frame/Second Usage guidelines

640(Fine) (640×480) Approx. 30 Shoot high quality movie for display on TV

640(Standard) (640×480) Approx. 17 Shoot standard quality movie for display on

320 (320×240) Approx. 8 Shoot at a small size for email attachment

• The larger the image size, the higher the image quality.

• The more frames per second you played back, the smoother playback can be.

Rough

Page 13

Basic techniques for better images

Flash

On using the flash

The eyes of the subject may come out red, or fuzzy white circular spots may appear when using the flash. These phenomena can be reduced by taking the following steps.

The “Red-eye phenomenon”

This is caused by the reflection of flash light off the blood vessels of the retina of the subjects eyes because the pupils of the subjects eyes are wide open in a dark place.

Camera Eye

Retina

How can the “Red-eye phenomenon” be reduced?

• Set [Red Eye Reduction] to [On] (page 49).

• Select (High Sensitivity mode)* or (Extra High Sensitivity mode)* in Scene Selection (page 29).

(The flash is turned off automatically.)

• When the eyes of the subject turns out red, correct the image with [Retouch] on the viewing menu (page 55) or with the supplied software “Picture Motion Browser”.

The “White circular spots”

This is caused by particles (dust, pollen, etc.) in the air, which when they are close to the lens, can be accentuated by the camera’s flash.

Camera

Particles (dust,

pollen, etc.) in

the air

How can the “White circular spots” be reduced?

• Light the room and shoot the subject without a flash.

• Select (High Sensitivity mode)* or (Extra High Sensitivity mode)* in Scene Selection. (The flash is turned off automatically.)

Subject

* Even though you selected (High Sensitivity mode) or (Extra High Sensitivity mode) in Scene

Selection, the shutter speed might be slower under low-light conditions, or in a dark place. In that case, use a tripod or hold your shooting arm firmly at your side after pressing the shutter button.

Page 14

Identifying parts

See the pages in parentheses for details of operation.

A POWER button/POWER lamp B Shutter button (24) C Microphone D Flash (26) E AF illuminator (69)/Self-timer lamp

(27)

F Finder window G Lens

4 5 6

A AE/AF lock lamp/Self-timer lamp

(green) (27)

B Flash charging lamp/Record lamp

(orange)

C Finder D LCD screen (20) E (Playback) button (32) F MENU button (38) G For shooting: Zoom (W/T) button (25)

For viewing: / (Playback zoom) button/ (Index) button (32, 33)

H Hook for strap I Battery/“Memory Stick Duo” cover J Mode dial (23) K Control button

Menu on: v/V/b/B/z (38) Menu off: DISP/ / / (20, 26) When the mode dial is set to M: Shutter Speed/Aperture (31)

L HOME button (36)

Page 15

Identifying parts

M “Memory Stick Duo” slot N Battery insertion slot O Access lamp P Battery eject lever Q Multi connector (bottom)

Used in the following situations:

• Making a USB connection between the camera and the computer.

• Making a connection to audio/video input jacks on a TV.

• Making a connection to a PictBridge compliant printer.

R Speaker (bottom) S Tripod receptacle (bottom)

• Use a tripod with a screw length of less than

5.5 mm (7/32 inch). You will be unable to firmly secure the camera to tripods having screws longer than 5.5 mm (7/32 inch), and may damage the camera.

Page 16

Indicators on the screen

RETU RN

Each time you press v (DISP) button, the display changes (page 20). See the pages in parentheses for details of operation.

When shooting still images

RETURN

When shooting movies

Display Indication

Battery remaining

Mode dial (23)

Low battery warning (114)

Image size

Mode dial/Menu (Scene Selection)

White balance (48)

(40)

(28)

Display Indication

Recording mode (42)

BRK

±1.0

Metering mode (45)

Face Detection (41)

SteadyShot

Vibration warning

• Indicates vibration may prevent you from shooting clear images due to insufficient lighting. Even if the vibration warning appears, you can still shoot images. However, we recommend that you turn on the anti-blur function, using the flash for better lighting or using a tripod or other means to stabilize the camera (page 8).

Zoom scaling (

Contrast (50)

Sharpness (50)

Color mode

(51)

(43)

25, 70)

Page 17

Indicators on the screen

Display Indication

Manual exposure setting

z RETURN z SET

1.0m Focus preset distance

z AE/AF lock (24)

Standby REC

ISO400 ISO number (44)

125 Shutter speed

F3.5 Aperture value

+2.0EV Exposure Value 00:00:12 Recording time

AF range finder frame

mode (31)

Function guide for Manual exposure (31)

(46)

Standby a movie/Recording a movie

NR slow shutter

• When the shutter speed drops below a certain speed in low light conditions, the NR (Noise Reduction) slow shutter function activates automatically to reduce the picture noise.

(44)

(46)

indicator

Macro (26)

Display Indication

Recording Media

Recording folder

• This does not appear when using internal memory.

96 Remaining number of

00:00:00 Remaining recordable time

Flash mode (26)

Conversion lens (71)

recordable images

AF illuminator

Red-eye reduction (49)

Flash charging

(62)

(69)

Display Indication

C:32:00 Self-diagnosis display

(114)

Self-timer (27)

Spot metering cross hair

(45)

AF range finder frame (46)

Histogram (20)

Page 18

Indicators on the screen

When playing back still images

When playing back movies

Display Indication

Battery remaining

VOL. Volume (32)

Image size

Protect (57)

Print order (DPOF) mark

(40)

(101)

PictBridge connecting (99)

Zoom scaling (32)

PictBridge connecting

(100)

• Do not disconnect the cable for multi-use terminal while the icon is displayed.

Display Indication

N Playback (32)

Playback bar

00:00:12 Counter

101-0012 Folder-file number

2007 1 1 9:30 AM

z STOP z PLAY

BACK/

V VOLUME Adjust volume

Recorded date/time of the playback image

Function guide for playing image

Select images

Histogram

• appears when histogram

(20)

display is disabled.

(59)

Page 19

Indicators on the screen

Display Indication

Playback Media

Playback folder

• This does not appear when using internal memory.

8/8 12/12 Image number/Number of

Change folder

Metering mode (45)

Flash

images recorded in selected folder

• This does not appear when using internal memory.

White balance

(59)

(48)

C:32:00 Self-diagnosis display

(114)

ISO400 ISO number (44)

+2.0EV Exposure Value (44)

500 Shutter speed

F3.5 Aperture value

Page 20

Changing the screen display

• If you view images in bright outside light, adjust the brightness of the LCD backlight up. However, the battery power may decrease faster

v (DISP) (Screen display button) button

Each time you press the v (DISP) button, the display changes as follows.

Brightness of LCD backlight up

Histogram on

During playback, the image information is displayed.

Histogram display

Indicators off

(page 21)

under such condition.

• The display becomes Histogram on Indicators off to a TV (page 75).

• The histogram does not appear in the following situations: While shooting

– When the menu is displayed. – When recording movies During playback – When the menu is displayed. – In index mode – When you are using playback zoom. – When you are rotating still images. – During playback of movies

• During image playback, you cannot turn the LCD screen off.

• A large difference in the histogram displayed when shooting and during playback may occur when:

– The flash strobes. – The shutter speed is slow or fast.

• The histogram may not appear for images recorded using other cameras.

• When you set the LCD screen to off, the digital zoom does not function. When you select (flash mode)/ (self-timer)/ (macro), the image is displayed for about two seconds.

t Indicators on when connected

LCD screen off

Indicators on

Page 21

Changing the screen display

z Adjusting EV (Exposure Value) by

displaying a histogram

BrightDark

A histogram is a graph showing the brightness of an image. Press v (DISP) repeatedly to display the histogram inside the screen. The graph display indicates a bright image when skewed to the right side, and a dark image when skewed to the left side.

A Number of pixels B Brightness

• The histogram also appears when playing back a single image, but you cannot adjust the exposure.

Page 22

Using the internal memory

The camera has approximately 31 MB of internal memory. This memory is not removable. Even when there is no “Memory Stick Duo” inserted in the camera, you can record images using this internal memory.

• Movies with the image size set to [640(Fine)] cannot be recorded using the internal memory.

When a “Memory Stick Duo” is inserted

[Recording]: Images are recorded on the “Memory Stick Duo”.

[Playback]: Images on the “Memory Stick Duo” are

Internal

On image data stored in the internal memory

We recommend that you copy (back up) data without error using one of the following methods.

To copy (back up) data on a “Memory Stick Duo”

Prepare a “Memory Stick Duo” with a capacity of 64 MB or more, then perform the procedure explained in [Copy] (page 64).

To copy (back up) data on a hard disk of your computer

Perform the procedure on pages 81 to 83 without a “Memory Stick Duo” inserted in the camera.

memory

played back. [Menu, Settings, etc.]: Various functions can be

performed on images on the “Memory Stick Duo”.

When there is no “Memory Stick Duo” inserted

[Recording]: Images are recorded using the internal memory.

[Playback]: Images stored in the internal memory are played back.

[Menu, Settings, etc.]: Various functions can be performed on images in the internal memory.

• You cannot copy image data on a “Memory Stick Duo” to the internal memory.

• By connecting the camera and a computer with a cable for multi-use terminal, you can copy data stored in

the internal memory to a computer. However you cannot copy data on a computer to the internal memory.

Page 23

Basic Operations

Using the mode dial

Set the mode dial to the desired function.

: Auto Adjustment mode

Allows easy shooting with the settings adjusted automatically. t page 24

: Program Auto mode*

Allows you to shoot with the exposure adjusted automatically (both the shutter speed and the aperture value).

: Manual Exposure Shooting mode*

Allows you to shoot after adjusting the exposure manually (both the shutter speed and the aperture value).

Mode dial

Basic Operations

t page 31

: Movie recording mode

Allows you to record movies with audio. t page 24

/ / / / /SCN ( ): Scene Selection mode

Allows you to shoot with preset settings according to the scene. t page 28

* You can select various setting using the menu. (For details on the functions available t page 39)

Page 24

Shooting images easily (Auto Adjustment mode)

Mode dial

Shutter button

Finder

Macro button

DISP button

Zoom button

MENU button

HOME button

Self-timer button

z button

v/V/b/B button

Control button

1 Select the desired function from the mode dial.

When shooting still images (Auto Adjustment mode): Select . When shooting movies: Select .

2 Hold the camera steady, keeping your arm at your side.

Position the subject in the center of the focus frame.

3 Shoot with the shutter button.

When shooting still images:

1Press and hold the shutter button halfway down to focus.

The z (AE/AF lock) indicator (green) flashes, a beep sounds, the indicator stops flashing and remains lit.

Flash button

Page 25

Shooting images easily (Auto Adjustment mode)

2Press the shutter button fully down.

AE/AF lock

When shooting movies:

Press the shutter button fully down. To stop recording, press the shutter button fully down again.

If you shoot a still image of a subject that is difficult to focus on

• The shortest shooting distance is approx. 50 cm (19 3/4 inches). Shoot in the close-up (Macro) mode when you shoot a subject closer than the shooting distance (page 26).

• When the camera cannot focus on the subject automatically, the AE/AF lock indicator changes to flashing slowly and the beep does not sound. In addition, the AF range finder frame disappears. Recompose the shot and focus again.

Subjects difficult to focus on are:

– Distant from the camera and dark – The contrast between the subject and its background is poor. – Seen through glass – Moving fast – Reflective light or with a lustrous finish –Flashing – Backlit

W/T Using the zoom

Press T to zoom, press W to undo the zoom.

• When the zoom scale exceeds 3×, the camera uses the Digital Zoom function.

For details on the [Digital Zoom] settings and the image quality, see page 70.

• You cannot change the zoom scale while shooting a movie.

Basic Operations

Page 26

Shooting images easily (Auto Adjustment mode)

Flash (Selecting a flash mode for still images)

Press B ( ) on the control button repeatedly until the desired mode is selected.

(No indicator): Flash Auto

Strobes when there is insufficient light or backlight (default setting).

: Flash forced on

: Slow synchro (Flash forced on)

The shutter speed is slow in a dark place to clearly shoot the background that is out of flash light.

: Flash forced off

• The flash strobes twice. The first time is to adjust the light quantity.

• While charging the flash, is displayed.

Macro (Shooting close-up)

Press b ( ) on the control button repeatedly until the desired mode is selected.

(No indicator): Macro Off

: Macro On (W side: Approx. 5 cm or farther (2 inches or farther), T side: Approx. 34 cm or farther (1 feet

1 1/2 inches or farther))

Macro

• Setting the zoom all the way to the W side is recommended.

• The in-focus range becomes narrow, and the complete subject may not entirely be in focus.

• The Auto Focus speed drops when you shoot images in the Macro.

Page 27

Shooting images easily (Auto Adjustment mode)

Using the self-timer

Press V ( ) on the control button repeatedly until the desired mode is selected.

(No indicator): Not using the self-timer

: Setting the 10-second delay self-timer : Setting the 2-second delay self-timer

Press the shutter button, the self-timer lamp flashes, and a beep sounds until the shutter operates.

Self-timer lamp

Basic Operations

To cancel, press

• Use the 2-second delay self-timer to prevent blur of an image made by the shaking of the

V () again.

camera when pressing the shutter button.

Page 28

Shooting still images (Scene Selection)

MENU button

Shutter button

z button

v/V/b/B button

Control button

Mode dial

Selecting from the mode dial

1 Select the desired mode of Scene Selection ( / / / / ) with the mode

dial.

2 Shoot with the shutter button.

Selecting from the menu screen

1 Select SCN with the mode dial.

2 Press MENU button, and select from / / / by using b/B of the

control button (page 38).

3 Shoot with the shutter button.

• For details on mode, see next page.

To cancel the Scene selection

Set the mode dial to other than the mode of Scene Selection.

Page 29

Shooting still images (Scene Selection)

Scene Selection modes

The following modes are predetermined to match the scene conditions.

Modes selected from the mode dial

High Sensitivity

Allows you to shoot images without a flash under low light conditions, reducing blur.

Soft Snap

Allows you to shoot images with a softer atmosphere for portraits of people, flowers, etc.

Twilight Portrait*

Suitable for shooting portraits in dark places. Allows you to shoot sharp images of people in dark places without losing the dark atmosphere of the surroundings.

Twilight*

Allows you to shoot night scenes at far distance without losing the dark atmosphere of the surroundings.

Landscape

Focuses only on a distant subject to shoot landscapes, etc.

Modes selected from the menu screen

Extra High Sensitivity

Allows you to shoot smoother images without a flash under low light conditions. The image size is set to [3M].

Beach

When shooting seaside or lakesid scenes, the blue of the water is clearly recorded.

Snow

When shooting snowy scenes or other places where the whole screen appears white, use this mode to prevent sunken colors and record clear images.

Fireworks*

Allows you to record fireworks in all their splendor.

Basic Operations

* When you shoot images using (Twilight Portrait) or (Twilight) or (Fireworks) mode, the shutter

speed is slower. To prevent a blurring, use of a tripod is recommended.

Page 30

Shooting still images (Scene Selection)

Functions you can use in Scene Selection

For shooting an image appropriately according to the scene condition, a combination of functions is determined by the camera. Some functions are not available, depending on the Scene Selection mode.

( : you can select the desired setting)

Macro Flash

—————

— / — —

/ — —

—————

* [Flash] cannot be selected. **When [Conversion Lens] is not set to [Off], the flash is set to (Flash forced off).

Face

Detection

—— * —

** —— —

—— * —

Burst/

Bracket

EV White Bal

—

Red Eye

Reduction

SteadyShot

Page 31

Shooting with the manual exposure

Shutter button

z button

v/V/b/B button

Control button

Mode dial

1 Select M from the mode dial and press z on the control button.

• [SET] changes to [RETURN] on the lower left of the screen and the camera is set to manual exposure setting mode.

2 Adjust the exposure manually using the control button.

b/B: Aperture (F value) v/V: Shutter speed

Basic Operations

RETURN

Shutter speed

• Select an aperture value from below.

– When the zoom is set fully to the W side, you can select an aperture F2.8, F5.6 or F8.0.

– When the zoom is set fully to the T side, you can select an aperture F5.5, F11 or F16.

• You can select a shutter speed from 30 to 1/1000 seconds. The difference between the settings and proper exposure judged by the camera appears as an EV value (page 44) on the screen. 0EV indicates the value judged as the most suitable by the camera.

Aperture value

3 Shooting with the shutter button.

• The flash is set to (Flash On) or (Flash Off).

• Shutter speeds of one second or longer are indicated by[”], for example, [1”].

• When you set the shutter speed slower, using a tripod is recommended to prevent the effects of vibration.

• If you select below 1/3 seconds, the NR slow shutter function activates automatically to reduce the picture noise, and [NR] appears on the screen.

• If you select slow shutter speeds, it takes time to process the data.

Page 32

Viewing images

(Playback zoom)/

(Index) button

(Playback)

button

MENU button

HOME button

(Playback zoom) button

z button

v/V/b/B button

Control button

1 Press (Playback) button.

• If you press (Playback) when the camera is powered off, the camera is turned on automatically and set to playback mode. To switch to the shooting mode, press (Playback) again.

2 Select an image with b/B on the control button.

Movie:

Press

z to playback a movie. (Press z again to stop playback.)

Press

B to fast forward, b to rewind. (Press z to return to normal playback.)

Press V to display the volume control screen, then press

• Movies with the image size [320] are displayed a size smaller.

/ To view an enlarged image (playback zoom)

Press while displaying a still image. To undo the zoom, press . Adjust the position: v/V/b/B Cancel playback zoom: z

• To store enlarged images: [Trimming] (page 56)

b/B to adjust the volume.

Page 33

Viewing images

Viewing an index screen

Press (Index) to display the index screen while a still image is displayed. Select an image with v/V/b/B. To return to the single image screen, press z. When using the “Memory Stick Duo”, if there are number of folders, select the folder selection bar with b, then select the desired folder with v/V.

• You can also access the index screen by selecting [ Index Display] from (View

Images) on the HOME screen.

• Each time you press (Index), the number of pictures on the index screen changes.

Basic Operations

Page 34

Deleting images

(Index) button

(Playback) button

MENU button

z button

v/V/b/B button

Control button

1 Press (Playback) button.

2 Press MENU while display in single-image mode or in index mode.

3 Select [Delete] with v on the control button.

4 Select the desired deletion method with b/B from among [This Image],

[Multiple Images] and [All In This Folder], then press z.

Page 35

Deleting images

When you select [This Image]

Deletes the selected image. Select [OK] with v, then press z.

When you select [Multiple Images]

Selects and deletes multiple images at once.

1 Select the images you want to delete, then press z.

mark is checked in the checkbox of the image.

Single Image Index Display

2 Press MENU. 3 Select [OK] with

v, then press z.

When you select [All In This Folder]

Deletes all the images in the selected folder. Select [OK] with v, then press z.

• After you select [Multiple Images] on the index screen, you can delete all the images in a

folder by selecting the folder selection bar with b and attaching a mark on the folder.

Basic Operations

Page 36

Learning the various functions – HOME/Menu

Using the HOME screen

The HOME screen is the basic screen used for accessing the various functions you can access the HOME screen regardless of the shooting/viewing mode.

Control button

z button

HOME button

v/V/b/B button

1 Press HOME to display the HOME screen.

Menu items

The available menu items vary depending on the camera mode. The shooting menu is available only in the shooting mode, and the viewing menu is available only in the playback mode. Also, the menu items available vary depending on the mode dial position. Only the available items are displayed on the screen.

( : available)

Mode dial position: Scene

Menu for shooting (page 40)

Scene Selection — — — * —

Image Size *

Face Detection — — * —

REC Mode * —

Color Mode — —

ISO — — —

EV —

Metering Mode — —

Focus — —

White Bal — *

Flash Level — — —

Red Eye Reduction * —

Contrast — — —

Sharpness — — —

SteadyShot —

SETUP

* The operation is limited according to the selected Scene Selection mode (page 29).

Menu for viewing (page 55)

(Delete) (Slide Show)

(Retouch) (Protect)

(Rotate) (Select Folder)

Basic Operations

(Print)

Page 40

Using functions for shooting

Shooting menu

The functions in shooting mode using MENU button are described below. For details on how to operate the menu, see page 38.

You cannot select the mode displayed in grey.

AvailableUnavailable

Modes selected from the menu screen when the mode dial is set to SCN

The default settings are marked with .

Scene Selection: Selecting the scene selection

Selects the scene selection in the menu. You can shoot images with the settings pre-adjusted to match various scene conditions (page 28).

Image Size: Selecting the image size

For still images

Selects image size for shooting still images. For details, see pages 11, 12.

• Image size is fixed to [3M] when [Extra High Sensitivity] is selected.

For movie

(Fine)

(Standard)

Selects image size for recording movies. For details, see page 12.

Page 41

Shooting menu For details on the operation 1 page 38

Face Detection: Detecting the face of subject

Selects whether to use the Face Detect function or not.

(On)

Detecting the faces of your subject will also adjust focus, strobe, exposure, white balance, and pre-strobe for red-eye reduction.

Face Detection mark

Face Detection frame

(Off)

• When [Face Detection] is set to [On], Digital zoom does not function.

• Available only for [Soft Snap], the default setting is [On].

• Up to 8 faces of your subjects can be detected. However, only up to 2 faces of your subjects

Does not use Face Detection function.

can be detected when you shoot images with Soft Snap.

• When the camera detects more than subjects, the camera will judge which is the main

subject and set focus by priority.

• The frame which the focus is set will turn green by pressing the shutter button half way

down. Even when the frame does not turn green, if the distance of the subject which the focus is set on and other subjects are the same, the focus is set on all subjects.

• Face Detection may fail, depending on the conditions under which it is used.

Using functions for shooting

Page 42

Shooting menu For details on the operation 1 page 38

REC Mode: Selecting the continuous shooting method

Selects whether the camera performs continuous shooting or not when you press the shutter button.

(Normal)

(Burst)

Does not shoot continuously.

Records up to 100 images in succession when you press and hold down the shutter button.

• The flash is set to (Flash forced off).

BRK ±0.3EV

BRK ±0.7EV

BRK ±1.0EV

Records a series of three images with the exposure values automatically shifted (Exposure Bracket). The larger the bracket step value, the larger the shift of the exposure value.

• When you cannot decide the correct exposure, shoot in the Exposure Bracket mode, shifting the exposure value. You can select the image with the best exposure afterward.

• When the mode dial is set to , the Exposure Bracket mode is not available.

• The flash is set to (Flash forced off).

On the Burst

• When recording with the self timer, a series of a maximum of five images is recorded.

• When recording with the mode dial set to M, you cannot select a shutter speed of 1/3 seconds or slower.

• The recording interval is approximately 0.5 seconds. The recording interval becomes longer, depending on the setting for the image size.

• When the battery level is low, or when the internal memory or “Memory Stick Duo” is full, the Burst stops.

On the Exposure Bracket

• The focus and white balance are adjusted for the first image, and these settings are also used for the other images.

• When recording with the mode dial set to M, you cannot select a shutter speed of 1/3 seconds or slower.

• When the exposure is manually adjusted (page 44), the exposure is shifted based on the adjusted brightness.

• The recording interval is approximately 0.5 seconds.

• If the subject is too bright or too dark, you may be unable to shoot properly with the selected bracket step value.

Page 43

Shooting menu For details on the operation 1 page 38

Color Mode: Changing the vividness of the image or adding special effects

You can change the brightness of the image, accompanied by effects.

(Normal)

(Vivid)

(Natural)

(Sepia)

(B & W)

• You can select only [Normal], [Sepia] or [B & W] when shooting movies.

Sets the image to bright and deep color.

Sets the image to quiet color.

Sets the image to sepia color.

Sets the image to monochromatic color.

Using functions for shooting

Page 44

Shooting menu For details on the operation 1 page 38

ISO: Selecting a luminous sensitivity

High ISO sensitivityLow ISO sensitivity

Selects a luminous sensitivity with units of ISO. The larger the number, the higher the sensitivity.

Select a large number when shooting in dark locations or shooting a subject moving at high speed, or select a small number to obtain high image quality.

• For details on the ISO sensitivity, see page 10.

• Note that the image tends to become noisier as the ISO sensitivity number increases.

• [ISO] is set to [Auto] in the Scene Selection mode. When set to [Extra High Sensitivity], sensitivity is increase up to a maximum of 6400.

• You can select only from [ISO AUTO], [ISO 100] to [ISO 400] when set to Burst or Exposure Bracket.

• When shooting under brighter conditions, the camera automatically increases its tone reproduction and helps prevent images to become whitish (excluding when [ISO] is set to [ISO 100]).

EV: Adjusting the light intensity

–2.0EV

0EV

+2.0EV

• For details on the Exposure, see page 9.

Manually adjusts the exposure.

Toward +Toward –

Toward –: Darkens an image.

The exposure is determined automatically by the camera.

Toward +: Brightens an image.

Page 45

Shooting menu For details on the operation 1 page 38

• The compensation value can be set in 1/3EV increments.

• If a subject is being shot in extremely bright or dark conditions, or the flash is used, the exposure adjustment may not be effective.

Metering Mode: Selecting the metering mode

Selects the metering mode that sets which part of the subject to measure to determine the exposure.

(Multi)

(Center)

(Spot)

(Only for still image)

• For details on the Exposure, see page 9.

• When using spot metering or center-weighted metering, setting [Focus] to [Center AF] is recommended to focus on the metering position (page 46).

Divides into multiple regions and measures each region. The camera determines a well-balanced exposure (Multi-pattern metering).

Measures the center of the image, and determines the exposure based on the brightness of the subject there (Centerweighted metering).

Measures only a part of the subject (Spot metering).

• This function is useful when the subject is backlit or when there is strong contrast between the subject and the background.

Spot metering cross hairs

Positions on the subject

Using functions for shooting

Page 46

Shooting menu For details on the operation 1 page 38

Focus: Changing the focus method

You can change the focus method. Use the menu when it is difficult to get the proper focus in auto focus mode.

(Multi AF)

Focuses on a subject in all ranges of the finder frame automatically.

• This mode is useful when the subject is not in the center of the

frame.

AF range finder frame (Only for still image)

AF range finder frame indicator

(Center AF)

(Only for still image)

(Spot AF)

(Only for still image)

Focuses on a subject in the center of the finder frame automatically.

• Using together with the AF lock function lets you shoot in the

desired image composition.

AF range finder frame

AF range finder frame indicator

Focuses on an extremely small subject or a narrow area automatically.

• Using together with the AF lock function lets you shoot in the

desired image composition. Hold the camera steady not to misalign the subject and the AF range finder frame.

AF range finder frame

AF range finder frame indicator

Page 47

Shooting menu For details on the operation 1 page 38

0.5 m

1.0 m

3.0 m

7.0 m

Focuses on the subject using a previously set distance to the subject. (Focus preset)

• When shooting a subject through a net or through window glass, it is difficult to get the proper focus in auto focus mode. In these cases, use of [Focus] is convenient.

(unlimited distance)

• AF stands for Auto Focus.

• Distance setting information in “Focus Preset” is approximate. If you point the lens up or down, the error increases.

• When you use Digital Zoom or AF illuminator, the normal AF range finder frame is disabled and a new AF range finder frame is displayed by a dotted line. In this case, the priority of AF movement is given to subjects around the center of the frame.

z If the subject is out of focus

When shooting with the subject at the edge of the frame (or the screen), or when using [Center AF] or [Spot AF], the camera may not focus on a subject at the edge of the frame.

96P

In such cases, do as follows.

1 Recompose the shot so that the subject is centered in the AF range finder, and press the shutter

button halfway down to focus on the subject (AF lock).

AF range finder frame

Using functions for shooting

AE/AF lock indicator

As long as you do not press the shutter button fully down, you can retry the procedure as many times as you want.

2 When the AE/AF lock indicator stops flashing and remains on, return to the fully composed shot,

and press the shutter button fully down.

Page 48

Shooting menu For details on the operation 1 page 38

White Bal: Adjusting the color tones

Adjusts the color tones according to the lighting condition in a situation, for example, when the colors of an image look strange.

(Auto)

(Daylight)

Adjusts the White Balance automatically.

Adjusts for conditions outside under a clear sky, at sundown, night scenes, the presence of neon signs or fireworks.

(Cloudy)

(Fluorescent Light 1)/ (Fluorescent Light 2)/ (Fluorescent Light 3)

n (Incandescent)

Adjusts for a cloudy sky or a shady location.

Fluorescent Light 1: Adjust for white fluorescent lighting. Fluorescent Light 2: Adjust for natural white fluorescent lighting. Fluorescent Light 3: Adjust for day white fluorescent lighting.

Adjusts for places under incandescent lamp, or under bright lighting, such as in a photo studio.

Page 49

Shooting menu For details on the operation 1 page 38

(Flash)

• For details on the white balance, see page 10.

• Under fluorescent lights that flicker, the white balance function may not work correctly even though you select [Fluorescent Light 1], [Fluorescent Light 2], [Fluorescent Light 3].

• Except in [Flash] modes, [White Bal] is set to [Auto] when the flash strobes.

Adjusts for the flash conditions.

• You cannot select this item when shooting movies.

Flash Level: Adjusting the amount of flash light

Adjusts the amount of flash light.

(–)

Toward –: Makes the flash level lower.

(Normal)

(+)

• To change flash mode, see page 26.

Toward +: Makes the flash level higher.

Red Eye Reduction: Reducing the red-eye phenomenon

The flash strobes two or more times before shooting to reduce the red-eye phenomenon when using the flash.

Using functions for shooting

(Auto)

(On)

(Off)

• Because it takes about a second until the shutter clicks, hold the camera firmly to prevent the effects of vibration. Also, do not let the subject move.

Reduces the red-eye phenomenon whenever necessary, only when using the Face Detection Function.

The flash always strobes to reduce the red-eye phenomenon.

Does not use Red Eye Reduction.

Page 50

Shooting menu For details on the operation 1 page 38

• Red-eye reduction may not produce the desired effects depending on individual differences, the distance to the subject, if the subject does not see the pre-strobe, or other conditions. In such a case, you can correct the red-eye phenomenon using [Retouch] in the viewing menu after shooting (page 57).

• When the Face Detection function is not used, the Red Eye Reduction will not function even when [Auto] is selected.

Contrast: Adjusting the contrast

Adjusts the contrast of the image.

(–)

Toward –: Reduces the contrast.

(Normal)

(+)

(DRO)

Toward +: Enhances the contrast.

Adjusts the contrast of the image automatically.

• When using flash, if [Metering Mode] is set to [Center] or [Spot], the contrast will not be adjusted automatically.

Sharpness: Adjusting the sharpness

Adjusts the sharpness of the image.

(–)

Toward –: Softens the image.

(Normal)

(+)

Toward +: Sharpens the image.

Page 51

Shooting menu For details on the operation 1 page 38

SteadyShot: Selecting the anti-blur mode

Selects the anti-blur mode.

(Shooting)

(Continuous)

(Off)

• In Auto Adjustment mode, [SteadyShot] will be set to [Shooting].

• For movies, the options are limited to [Continuous] and [Off]. The default setting is set to [Continuous].

• The anti-blur function may not work properly in the following cases. – When camera shake is too strong – When the shutter speed is slow, for example, shooting night scenes

Activates the anti-blur function when pressing the shutter button halfway down.

Always activates the anti-blur function. You can stabilize images even when zooming up a far subject.

• Battery consumption is faster than in [Shooting] mode.

Does not use anti-blur mode.

SETUP: Selecting the shooting settings

Selects the settings for the shooting function. These items appearing in this menu are same ones as those in [ Shooting Settings] on the HOME screen. See page 37.

Using functions for shooting

Page 52

Using functions for viewing

Playing back images from the HOME screen

You can select the ways to playback images.

HOME button

1 Press HOME. 2 Select (View Images) with b/B on the control button. 3 Select the desired viewing method with v/V.

(Single Image): Playing back a single image

Displays the image shot last. This is the same as pressing the (Playback) (page 32).

(Index Display): Playing back a list of images

Displays a list of images contained in the selected folder. This is the same as pressing the (Index) (page 33).

(Slide Show): Playing back a series of images

1 Select [ Slide Show] on the HOME screen.

2 Select [Start] with v

/V, then press z to start playback.

To pause the slide show

Press z on the control button. To restart, select [Continue] with

• The slide show resumes from the image which was paused, however, the music starts again from the beginning.

v/V, then press z.

Page 53

Playing back images from the HOME screen

To display the previous/next image

Press b/B while the slide show is paused.

To adjust the volume of the music

Press V to display the volume control screen, the press b/B to adjust the volume.

To end the slide show

Select [Exit] with v/V while the slide show is paused, then press z.

To change the setup

The default settings are marked with .


When you use a “Memory Stick Duo” (not supplied)

Folder

All

Effects

Simple

Nostalgic

Stylish

Active

Normal

Plays back all the images in the selected folder.

Plays back all the images in a “Memory Stick Duo” in order.

A simple slide show suitable for a wide range of scenes.

A moody slide show reproducing the atmosphere of a movie scene.

A stylish slide show proceeding at a middle tempo.

A high-tempo slide show suitable for active scenes.

A basic slide show switching images at a predetermined interval.

Using functions for viewing

• When set to [Simple], [Nostalgic], [Stylish] or [Active] only still images are displayed.

• Music is not played (set to [Off]) during a [Normal] slide show. The sound of movies will be heard.

Page 54

Playing back images from the HOME screen

Music

The preset-Music differs depending on the effect you select.

Music 1

Music 2

Music 3

Music 4

Off

Interval

3 sec

The default setting for a [Simple] slide show.

The default setting for a [Nostalgic] slide show.

The default setting for a [Stylish] slide show.

The default setting for a [Active] slide show.

Setting for a [Normal] slide show. No Music available.

Sets the display interval of images for a [Normal] slide show.

5 sec

10 sec

30 sec

1 min

Auto

Repeat

Off

The interval is set to suit the selected [Effects] item. The setting is fixed to [Auto] when [Normal] is not selected as the [Effects].

Plays back images in a continuous loop.

After all the images have been played back, the slide show ends.

z To add /change Music files

You can transfer a desired music file from your CDs or MP3 files to the camera to playback during Slide show. You can transfer music using [ Music Tool] in (Printing, Other) on the HOME screen and the “Music Transfer” software (supplied) installed on a computer. For details, see pages 94 and 96.

• You can record up to four pieces of music on the camera (The four preset pieces (Music 1-4) can be replaced with the ones you transferred).

• A maximum length of each music file for music playback of the camera is about 3 minutes.

• If you cannot playback a Music file due to damage or other malfunctions to the file, execute [Format Music] (page 94) and transfer the music again.

Page 55

Viewing menu

This section explains the menu items available when you press MENU button in playback mode. For details on how to use the menu, see page 38.

For details on the operation 1 page 38

(Delete): Deleting images

Selects and deletes images on the single-image screen or the index screen. see page 34

(This Image)

(Multiple Images)

(All In This Folder)

Deletes the image that is now selected.

Selects and deletes multiple images.

Deletes all the images in the selected folder.

(Slide Show): Playing back a series of images

This item has same function as [ Slide Show] on the HOME screen. See page 52.

(Retouch): Retouching still images after shooting

The trimmed image is recorded as the newest file in the selected recording folder, and the original image is retained.

To retouch the still images

1 Select the images you want to retouch from the single -image screen or the index screen. 2 Press MENU button. 3 Select the [Retouch] with v/V, then press z after select the desired mode with b/B. 4 Retouch the images according to below instructions.

• Images cannot be retouched while the camera is connected to a High Definition TV.

(Soft Focus)

Blurs the periphery around a chosen point to signalize a subject.

1 Set the center point of the desired image to retouch with v/V/

b/B, then press MENU button.

2 Select [Level] with v/V and press z.

Select level of retouch with v/V, then press z again.

3 Adjust the desired range to retouch with W/T button. 4 Select [OK] with v/V, then press z.

Using functions for viewing

Page 56

Viewing menu For details on the operation 1 page 38

(Partial Color)

(Fisheye Lens)

(Cross Filter)

(Trimming)

Surrounds a chosen point in monochrome to signalize a subject.

1 Set the center point of the desired image to retouch with v/V/

b/B, then press MENU button.

2 Adjust the desired range to retouch with W/T button. 3 Select [OK] with v/V, then press z.

Applies a fisheye effect around a chosen point.

1 Set the center point of the desired image to retouch with v/V/

b/B, then press MENU button.

2 Select [Level] with v/V and press z.

Select level of retouch with v/V, then press z again.

3 Select [OK] with v/V, then press z.

Adds starburst effects to light sources.

1 Select [Level] with v/V and press z.

Select level of retouch with v/V, then press z again.

2 Adjust the desired length to retouch with W/T button. 3 Select [OK] with v/V, then press z.

Records the zoomed playback image.

1 Press W/T button to zoom in on the trimming range. 2 Set the point with v/V/b/B, then press MENU button. 3 Selects [Image Size] with v/V and press z.

Selects Image Size to record with v/V, then press z again.

4 Select [OK] with v/V, then press z.

Page 57

Viewing menu For details on the operation 1 page 38

(Red Eye Correction)

When you select [Trimming]

• The image size that you can trim may vary depending on the image.

• The quality of trimmed images may deteriorate.

Corrects the red-eye phenomenon caused by flash.

Select [OK] with v/V, then press z.

• You may not be able to correct the red-eye phenomenon depending on the image.

(Protect): Preventing accidental erasure

Protects images against accidental erasure.

(This Image)

(Multiple Images)

Protects/unlocks the currently selected image.

Selects and protects/unlocks multiple images.

To protect an image

1 Select the images you want to protect while displaying images in single-image mode or in index

mode.

2 Press MENU. 3 Select [Protect] with v/V, and select [This Image] with b/B, then press z.

The image is protected and the (Protect) indicator appears on the image.

Using functions for viewing

To select and protect images

1 Press MENU in single-image mode or in index mode. 2 Select [Protect] with v/V, and select [Multiple Images] with b/B, then press z.

In single-image mode:

3 Select the image you want to protect with b/B on the control button, then press z.

is attached to the selected image.

4 Press b/B to display other images you want to protect, then press z.

Page 58

Viewing menu For details on the operation 1 page 38

5 Press MENU. 6 Select [OK] with v, then press z.

In index mode:

3 Select the image you want to protect with v/V/b/B on the control button, then press z.

is attached to the selected image.

4 To protect other images, repeat step 3. 5 To select all the images in a folder, select the folder selection bar with b, then press z.

is attached to the selected folder.

6 Press MENU. 7 Select [OK] with v, then press z.

(Protect) indicator appears on the selected images.

To cancel the protection

Select the image for which you want to cancel protection, and unlock it by performing the same procedure to protect it.

(Protect) indicator disappears.

• Note that the formatting erases all the data stored on the recording media, even if the images

are protected, and these images cannot be restored.

• It may take some time to protect an image.

: Adding a Print order mark

Adds (Print order) mark to images you want to print. See page 101.

(This Image)

(Multiple Images)

Attaches/clears the DPOF-based print marks to (from) the image that is now selected.

Selects images and attaches/clears the DPOF-based print marks to (from) the images.

(Print): Printing images using a printer

See page 98. This item has same function as [ Print] on the HOME screen.

Page 59

Viewing menu For details on the operation 1 page 38

(Rotate): Rotating a still image

Rotates a still image.

1 Display the image to be rotated. 2 Press MENU to display the menu. 3 Select [Rotate] with v/V on the control button, then press z. 4 Select [ 5 Select [OK] with v/V, then press z.

• You cannot rotate protected images or movies.

• You may not be able to rotate images shot with other cameras.

• When viewing images on a computer, the image rotation information may not be reflected depending on the software.

], then rotate the image with b/B.

(Select Folder): Selecting the folder for viewing images

Selects the folder containing the image you want to playback when using the camera with “Memory Stick Duo”.

1 Select the desired folder with b/B on the control button.

Using functions for viewing

2 Select [OK] with v, then press z.

To cancel selecting the folder selection

Select [Exit] in step 2, then press z.

z On the folder

The camera stores images in a specified folder of a “Memory Stick Duo”. You can change the folder or create a new one.

• To create a new folder t [Create REC. Folder] (page 62)

• To change the folder for recording images t [Change REC. Folder] (page 63)

• When multiple folders are created in the “Memory Stick Duo” and the first or last image in the folder is displayed, the following indicators appear.

: Moves to the previous folder : Moves to the next folder : Moves to either the previous or next folders

Page 60

Customizing the settings

Customizing the Manage Memory feature and the Settings

You can change the default settings using (Manage Memory) or (Settings) on the HOME screen.

Control button

z button

HOME button

v/V/b/B button

1 Press HOME to display the HOME screen.

2 Select (Manage Memory) or (Settings) with b/B on the control button.

3 Select the desired item with v/V, then press z.

4 Press B and select the desired setting with v/V, then press z.

Page 61

Customizing the Manage Memory feature and the Settings

5 Select the desired setting with v/V, then press z.

To cancel the setting change

Select [Cancel] if it is one of the setting item, then press z. If not, press b on the control button.

• This setting is maintained even when the power is turned off.

• The camera is set to the shooting mode by pressing the shutter button halfway down.

Customizing the settings

Page 62

Manage Memory

For details on the operation 1 page 60

Memory Tool — Memory Stick Tool

This item appears only when a “Memory Stick Duo” is inserted in the camera.

Format

Formats the “Memory Stick Duo”. A commercially available “Memory Stick Duo” is already formatted, and can be used immediately.

• Note that formatting irrevocably erases all data on a “Memory Stick Duo”, including even protected images.

1 Select [Format] with v/V/b/B on the control button, then press z.

The message “All data on Memory Stick will be erased” appears.

2 Select [OK] with v, then press z.

The format is completed.

To cancel the formatting

Select [Cancel] in step 2, then press z.

Create REC. Folder

Creates a folder in a “Memory Stick Duo” for recording images.

1 Select [Create REC. Folder] with v/V/b/B on the control button, then press z.

The folder creation screen appears.

2 Select [OK] with v, then press z.

A new folder is created with a number incremented one higher than the largest number, and the folder becomes the current recording folder.

To cancel the folder creation

Select [Cancel] in step 2, then press z.

• When not creating a new folder, the “101MSDCF” folder is selected as the recording folder.

• You can create folders designated up to “999MSDCF”.

• Images are recorded in the newly created folder until a different folder is created or selected.

• You cannot delete a folder with the camera. To delete a folder, use your computer, etc.

• Up to 4,000 images can be stored in one folder. When the folder capacity is exceeded, a new folder is automatically created.

• For details, see “Image file storage destinations and file names” (page 86).

Page 63

Manage Memory For details on the operation 1 page 60

Change REC. Folder

Changes the folder currently used for recording images.

1 Select [Change REC. Folder] with v/V/b/B on the control button, then press z.

The folder selection screen appears.

2 Select the desired folder with b/B, and [OK] with v, then press z.

To cancel changing the recording folder

Select [Cancel] in step 2, then press z.

• You cannot select the “100MSDCF” folder as a recording folder.

• You cannot move recorded images to a different folder.

Customizing the settings

Page 64

Manage Memory For details on the operation 1 page 60

Copy

Copies all images in the internal memory to a “Memory Stick Duo”.

1 Insert a “Memory Stick Duo” having 64 MB or larger capacity. 2 Select [Copy] with v/V/b/B on the control button, then press z.

The message “All data in internal memory will be copied” appears.

3 Select [OK] with v, then press z.

Copying starts.

To cancel the copying

Select [Cancel] in step 3, then press z.

• Use a fully charged battery pack. If you attempt to copy image files using a battery pack with little remaining charge, the battery pack may run out, causing copying to fail or possibly corrupting the data.

• You cannot copy individual images.

• The original images in the internal memory are retained even after copying. To delete the contents of the internal memory, remove the “Memory Stick Duo” after copying, then execute the [Format] command in [Internal Memory Tool] (page 65).

• When you copy the data in the internal memory to the “Memory Stick Duo”, all the data will be copied. You cannot choose a specific folder on the “Memory Stick Duo” as the destination for the data to be copied.

• Even if you copy data, a (Print order) mark is not copied.

Page 65

Manage Memory For details on the operation 1 page 60

Memory Tool — Internal Memory Tool

This item does not appear when a “Memory Stick Duo” is inserted in the camera.

Format

Formats the internal memory.

• Note that formatting irrevocably erases all data in the internal memory, including even protected images.

1 Select [Format] with v/V/b/B on the control button, then press z.

The message “All data in internal memory will be erased” appears.

2 Select [OK] with v, then press z.

The format is completed.

To cancel the formatting

Select [Cancel] in step 2, then press z.

Customizing the settings

Page 66

Settings

For details on the operation 1 page 60

Main settings — Main Settings 1

The default settings are marked with .

Beep

Selects the sound produced when you operate the camera.

Shutter

Off

Function Guide

When you operate the camera, the description of functions is displayed.

Off

Initialize

Initializes the setting to the default setting. Even if you execute this function, the images stored in the internal memory are retained.

1 Select [Initialize] with v/V/b/B, then press z.

The message “Initialize all settings” appears.

2 Select [OK] with v, then press z.

The settings are reset to the default setting.

To cancel the resetting

Select [Cancel] in step 2, then press z.

• Make sure that the power is not disconnected during resetting.

Turns on the shutter sound when you press the shutter button.

Turns on the beep/shutter sound when you press the control button/press the shutter button.

Turns off the beep/shutter sound.

Displays the function guide.

Does not display the function guide.

Page 67

Settings For details on the operation 1 page 60

Main settings — Main Settings 2

The default settings are marked with .

USB Connect

Selects the USB mode to be used when connecting the camera to a computer or a PictBridge compliant printer using the cable for multi-use terminal.

PictBridge

Mass Storage

Auto

Connects the camera to a PictBridge compliant printer (page 98). When you connect the camera to a computer, the copy wizard starts automatically, and the images in the recording folder on the camera are copied to the computer. (with Windows XP, Mac OS X)

Establishes a Mass Storage connection between the camera and a computer or other USB device (page 82).

The camera recognizes automatically and sets up communication with a computer or PictBridge compliant printer (pages 82 and 98).

• If the camera and a PictBridge compliant printer cannot be connected when set to [Auto], change the setting to [PictBridge].

• If the camera and a computer or other USB device cannot be connected when set to [Auto], change the setting to [Mass Storage].

Customizing the settings

COMPONENT

Selects the video signal output type from SD and HD(1080i), according to the TV connected see page 75.

HD(1080i)

Selects this item to connect the camera to a 1080i-capable High Definition TV.

Selects this item to connect the camera to a TV that is not compatible with an HD(1080i) signal.

Page 68

Settings For details on the operation 1 page 60

Video Out

Sets the video signal output according to the TV color system of the connected video equipment. Different countries and regions use different TV color systems. If you want to view images on a TV screen, check page 77 for the TV color system of the country or region where the camera is used.

NTSC

PAL

Sets the video output signal to NTSC mode (e.g., for the USA, Japan).

Sets the video output signal to PAL mode (e.g., for Europe).

Page 69

Settings For details on the operation 1 page 60

Shooting Settings — Shooting Settings 1

The default settings are marked with .

AF Illuminator

The AF illuminator supplies fill light to focus more easily on a subject in dark surroundings. The AF illuminator emits red light allowing the camera to focus easily when the shutter button is pressed halfway, until the focus is locked. The indicator appears at this time.

Auto

Off

• If the AF illuminator light does not reach the subject sufficiently or the subject has no contrast, focus will not be achieved. (A distance of up to approximately 2.8 m (9 feet 2 1/4 inches) (zoom: W)/2.2 m (7 feet 2 5/8 inches) (zoom: T) is recommended.)

• Focus is achieved as long as the AF illuminator light reaches the subject, even if the light is slightly off the center of the subject.

• You cannot use the AF illuminator when: – When Focus preset is set (page 46). – When (Twilight mode) or (Landscape mode) or (Fireworks mode) is selected in the Scene

mode. – When [Face Detection] is set to [On]. – When [Conversion Lens] is not set to [Off].

• When you use AF illuminator, the normal AF range finder frame is disabled and new AF range finder frame is displayed by a dotted line. AF operates with priority on subjects located near the center of the frame.

• The AF illuminator emits very bright light. Although there are no problems with safety, do not look directly into the AF illuminator emitter at close range.

Uses the AF illuminator.

Does not use AF illuminator.

Customizing the settings

Grid Line

With reference to the grid lines, you can easily set a subject in a horizontal/vertical position.

Off

• The grid lines are not recorded.

Displays the grid lines.

Does not display the grid line.

Page 70

Settings For details on the operation 1 page 60

AF Mode

Selects the auto focus operation mode.

Single

Monitor

• When [Face Detection] is set to [On], the AF mode is disabled.

Automatically adjusts the focus when the shutter button is pressed and held halfway down. This mode is useful for shooting stationary subjects.

Automatically adjusts the focus before the shutter button is pressed and held halfway down. This mode shortens the time needed for focusing.

• Battery consumption is faster than in [Single] mode.

Digital Zoom

Selects the digital zoom mode. The camera enlarges the image using optical zoom (up to 3×). When the zoom scale exceeds 3×, the camera uses either smart or precision digital zoom.

Smart (Smart zoom) ()

Precision (Precision digital zoom)

Enlarges the image digitally within the range where the image will not be distorted, according to the image size. This is not available when the image size is set to [12M] or [3:2].

• The maximum zoom scale of Smart zoom is shown in the following table.

Enlarges all image sizes up to a maximum of 6×, but the image quality deteriorates.

()

Off

Does not use the digital zoom.

Image size and maximum zoom scale using Smart zoom

Size Maximum zoom scale

8M Approx. 3.7×

5M Approx. 4.6×

3M Approx. 5.9×

VGA Approx. 18×

16:9 Approx. 6.2×

• When (Extra High Sensitivity mode) is selected in the Scene mode, the Smart zoom does not function.

• When [Face Detection] is set to [On], you cannot use the Digital Zoom.

• When you set the LCD screen to off, you cannot use the digital zoom.

Page 71

Settings For details on the operation 1 page 60

Conversion Lens

Sets for achieving appropriate focus when attaching a conversion lens (not supplied). Attach the adaptor ring (not supplied), then attach a conversion lens.

Tele ( )

Wide ( )

Off

• When not set to [Off], the flash is set to (Flash forced off).

• Check the shooting image on the LCD screen due to covering in the finder window.

• The available zoom area is limited.

• The available focusing area is limited.

• For details, see the operating instructions supplied with your conversion lens.

Attaches a tele conversion lens.

Attaches a wide conversion lens.

Does not attach a lens.

Customizing the settings

Page 72

Settings For details on the operation 1 page 60

Shooting Settings — Shooting Settings 2

The default settings are marked with .

Auto Orientation

When the camera is rotated to shoot a portrait image, the camera records its position change and displays the image in the portrait position.

Off

• Depending on the shooting angle of the camera, the orientation of the image may not be recorded correctly. When the orientation of the image is not correct, you can rotate the image using the procedure on page 59.

Auto Review

Displays the recorded image on the screen for approximately two seconds immediately after shooting a still image.

Off

• If you press the shutter button halfway down during this period, the recorded image display disappears and you can immediately shoot the next image.

Records the image with the correct orientation.

Auto Orientation deactivated.

Use the Auto Review.

Does not use Auto Review.

Page 73

Settings For details on the operation 1 page 60

Clock Settings

Sets the date and time.

1 Select [ Clock Settings] from (Settings) on the HOME screen.

2 Select the date display format with v/V, then press z. 3 Select each item with b/B and set the numeric value with v/V, then press z. 4 Select [OK], then press z.

To cancel the clock setting

Select [Cancel] in step 4, then press z.

Customizing the settings

Page 74

Settings For details on the operation 1 page 60

Language Setting

Selects the language to be used to display the menu items, warnings, and messages.

Page 75

Viewing images on a TV

You can view images on a TV screen by connecting the camera to a TV. The connection varies according to the type of TV the camera is connected to.

Viewing images by connecting your camera to a TV with the supplied cable for multi-use terminal

Turn off both your camera and the TV before connecting the camera and the TV.

1 Connect the camera to the TV.

1 To audio/video

input jacks

VIDEO

AUDIO

Yellow/White/Red

Yellow Black

(Playback) button

Control button

Cable for multi-use terminal (supplied)

• Place the camera with the screen facing upwards.

• If your TV has stereo input jacks, connect the audio plug (black) of the cable for multi-use terminal to the left audio jack.

2 To the multi

connector

2 Turn on the TV and set the TV/video input switch to “video”.

• For details, see the operating instructions supplied with the TV.

3 Press (Playback) to turn on the camera.

Images shot with the camera appear on the TV screen.

Press b/B on the control button to select the desired image.

• When using your camera abroad, it may be necessary to switch the video signal output to match that of your TV system (page 68).

Viewing images on a TV

Page 76

Viewing images on a TV

Viewing an image by connecting your camera to a HD TV

You can view an image recorded on the camera by connecting the camera to an HD (High Definition) TV with the component cable (not supplied).

Turn off both your camera and the TV before connecting the camera and the TV.

1 Connect the camera to the TV.

1 To audio/video

input jacks

COMPONENT

VIDEO IN

Green/Blue/Red White/Red

Component video cable (not supplied)

• Place the camera with the screen facing upwards.

• The video plugs (Green/Blue/Red) of the component video cable (not supplied) are color-coded to match the jacks on the TV.

AUDIO

(Playback) button

Control button

HOME button

2 To the multi

connector

2 Turn on the TV and set the TV/video input switch to “video”.

• For details, see the operating instructions supplied with the TV.

3 Press (Playback) to turn on the camera.

Images shot with the camera appear on the TV screen.

Press b/B on the control button to select the desired image.

Page 77

Viewing images on a TV

• Set [COMPONENT] to [HD(1080i)] in [Main Settings 2] by selecting (Settings) on the HOME

screen (page 67).

• When using your camera abroad, it may be necessary to switch the video signal output to match that

of your TV system (page 68).

• You cannot view movies output in HD signal format.

On TV color systems

If you want to view images on a TV screen, you need a TV with a video input jack and the cable for multi-use terminal. The color system of the TV must match that of your digital still camera. Check the following lists for the TV color system of the country or region where the camera is used.

NTSC system

Bahama Islands, Bolivia, Canada, Central America, Chile, Colombia, Ecuador, Jamaica, Japan, Korea, Mexico, Peru, Surinam, Taiwan, the Philippines, the U.S.A., Venezuela, etc.

PAL system

Australia, Austria, Belgium, China, Czech Republic, Denmark, Finland, Germany, Holland, Hong Kong, Hungary, Italy, Kuwait, Malaysia, New Zealand, Norway, Poland, Portugal, Singapore, Slovak Republic, Spain, Sweden, Switzerland, Thailand, United Kingdom, etc.

PAL-M system

Brazil

PAL-N system

Argentina, Paraguay, Uruguay

SECAM system

Bulgaria, France, Guiana, Iran, Iraq, Monaco, Russia, Ukraine, etc.

Viewing images on a TV

Page 78

Using your computer

Enjoying your Windows computer

For details on using a Macintosh computer, refer to “Using your Macintosh computer” (page 95). This section describes the English version of screen contents.

• Under Windows Vista, some names and operations may differ from those described below.

Install the software (supplied) first (page 80)

Copying images to your computer (page 81)

•

Viewing images on your computer

Enjoying images using the “Picture Motion Browser” and “Music Transfer” (pages 88 and 94)

• Viewing images saved on your computer

• Viewing photos organized by date

• Editing images

• Displaying the shooting locations of still images on maps

online (To do this, your computer needs to be connected to the Internet.)

• Creates a disc with the images shot (requires CD or DVD

disc writing drive)

• Printing or saving still images with the date

• Adding/changing Music using “Music Transfer”

Page 79

Enjoying your Windows computer

Recommended computer environment

The following environment is recommended for a computer connected to the camera.

Recommended environment for copying images

OS (pre-installed): Microsoft Windows

2000 Professional, Windows XP* or Windows Vista*

• Operation is not assured in an environment

based on an upgrade of the operating systems described above or in a multi-boot environment.

USB jack: Provided as standard

Recommended environment for using “Picture Motion Browser” and “Music Transfer”

OS (pre-installed): Microsoft Windows

2000 Professional, Windows XP* or Windows Vista*

Sound card: 16-bit stereo sound card with

speakers

CPU/Memory: Pentium III 500 MHz or

faster, 128 MB of RAM or more (Recommended: Pentium III 800 MHz or faster and 256 MB of RAM or more)

Software: DirectX 9.0c or later

Hard Disk: Disk space required for

installation—200 MB or more

Display: Screen resolution: 1024 × 768 dots

or more Colors: High Color (16-bit color) or more

* 64-bit editions and Starter (Edition) are not

supported.

• The software is compatible with DirectX technology. Installation of “DirectX” may be required.

Notes on connecting your camera to a computer

• Operations are not guaranteed for all the recommended computer environments mentioned above.

• If you connect two or more USB devices to a single computer at the same time, some devices, including your camera, may not operate, depending on the types of USB devices you are using.

• Operations are not guaranteed when using a USB hub.

• Connecting your camera using a USB interface that is compatible with Hi-Speed USB (USB 2.0 compliant) allows advanced tr ansfer (high speed transfer) as this camera is compatible with HiSpeed USB (USB 2.0 compliant).

• There are three modes for a USB connection when connecting a computer, [Auto] (default setting), [Mass Storage] and [PictBridge] modes. This section describes the [Auto] and [Mass Storage] as examples. For details on [PictBridge], see page 67.

• When your computer resumes from a suspend or sleep mode, communication between your camera and your computer may not recover at the same time.

Technical Support

Additional information on this product and answers to frequently asked questions can be found at the Sony Customer Support Website. http://www.sony.net/

Using your computer

Page 80

Installing the software (supplied)

You can install the software (supplied) using the following procedure.

• When using Windows 2000, do not connect the camera to the computer before installation.

• Log on as Administrator.

• When the software (supplied) is installed, the USB driver is installed automatically.

1 Turn on your computer, and

insert the CD-ROM (supplied) into the CD-ROM drive.

The installation menu screen appears.

4 Select the [Region] and [Country/

Area], then click [Next].

When the [Welcome to the InstallShield Wizard for SonyPicture Utility] appears, click [Next].

The “License Agreement” screen appears. Read the agreement carefully. If you accept the terms of the agreement, click the radio button next to [I accept the terms of the license agreement] and then click [Next].

5 Follow the instructions on the

screen to complete the installation.

• When the restarting confirmation message appears, restart the computer following the

• If it does not appear, double-click (My Computer)

• Under Windows Vista, the AutoPlay screen may appear. Select “Run Install.exe” and follow the instructions that appear on the screen to proceed with the installation.

t (SONYPICTUTIL).

instructions on the screen.

• DirectX may be installed depending on system environment of your computer.

6 Remove the CD-ROM after the

installation is complete.

2 Click [Install].

The “Choose Setup Language” screen appears.

3 Select the desired language, then

click [Next].

The [Location Settings] screen appears.

After you install the software, a shortcut icon for the customers registration website is created on the desktop.

Once you register on the website, you can get secure and useful customer support. http://www.sony.net/registration/di

Page 81

Copying images to your computer

This section describes the process using a Windows computer as an example. You can copy images from the camera to your computer as follows.

For a computer with a Memory Stick slot

Remove the “Memory Stick Duo” from the camera and insert it in the Memory Stick Duo Adaptor. Insert the Memory Stick Duo Adaptor in the computer and copy the images.

• Even when you are using Windows 95/98/98 SecondEdition/NT/Me, you can copy images by inserting the “Memory Stick Duo” into the Memory Stick slot on your computer.

• If the “Memory Stick PRO Duo” is not recognized, see page 108.

For a computer without a Memory Stick slot

Make a USB connection and follow Stages 1 through 4 on pages 81 to 85 to copy images.

• When you are using Windows 2000, install the software (supplied) before proceeding. With Windows XP, installation is unnecessary.

• The screen displays shown in this section are the examples for copying images from “Memory Stick Duo”.

• This camera is not compatible with Windows 95/98/98 SecondEdition/NT/Me of the Windows operating system. When you use a computer without a Memory Stick slot, use a commercially available Memory Stick Reader/Writer to copy images from a “Memory Stick Duo” to your computer.

• To copy images in the internal memory to your computer, copy the images to a “Memory Stick Duo” first, then copy them to your computer.

Stage 1: Preparing the camera and the computer

1 Insert a “Memory Stick Duo” with

recorded images into the camera.

• When copying images in the internal memory, this step is unnecessary.

2 Insert the sufficiently charged

battery pack in the camera, or connect the camera to a wall outlet (wall socket) with the AC Adaptor (not supplied) and the USB, A/V, DC IN cable for multiuse terminal (not supplied).

• When you copy images to your computer using a battery pack with little remaining charge, copying may fail or image data may become corrupted if the battery pack shuts down too soon.

3 Press (Playback), then turn on

the computer.

(Playback)

button

Using your computer

Page 82

Copying images to your computer

Stage 2: Connecting the camera and your computer

2 To the multi

connector

1 To a USB

jack

Cable for multi-use terminal

• With Windows XP/Vista, the AutoPlay wizard appears on the desktop.

“Connecting to Mass Storage...” appears on the screen of the camera.

Access indicators*

• If “Connecting to Mass Storage...” does not appear, set [USB Connect] to [Mass Storage] (page 67).

• When the software (supplied) has been installed, the [Import Images] screen (page 89) may be displayed. In this case, you can import images directly using “Picture Motion Browser”.

Stage 3-A: Copying images to a computer

• For Windows 2000, follow the procedure explained in “Stage 3-B: Copying images to a Computer” on page 83.

• For Windows XP/Vista, when the wizard screen does not appear automatically, follow the procedure explained in “Stage 3-B: Copying images to a Computer” on page 83.

This section describes an example of copying images to a “My Documents” folder.

1 After making a USB connection in

Stage 2, click [Copy pictures to a folder on my computer using Microsoft Scanner and Camera Wizard] screen appears automatically on the desktop.

t [OK] as the wizard

When a USB connection is established for the first time, your computer automatically runs a program to recognize the camera. Wait for a while.

* is displayed on the screen during the

communication session. Do not operate the computer while the indicator is displayed. When the indicator changes to

, you can start using the computer

again.

The “Scanner and Camera Wizard” screen appears.

Page 83

Copying images to your computer

2 Click [Next].

The images saved on the “Memory Stick Duo” of the camera appear.

• If no “Memory Stick Duo” is inserted, images in the internal memory appear.

3 Click the check box of unwanted

images to remove the checkmark so they are not copied, then click [Next].

The “Picture Name and Destination” screen appears.

4 Select a name and destination for

the images, then click [Next].

Image copying starts. When the copying is completed, the “Other Options” screen appears.

• This section describes an example of copying images to the “My Documents” folder.

5 Click the radio button next to

[Nothing. I’m finished working with these pictures] to select it, then click [Next].

The “Completing the Scanner and Camera Wizard” screen appears.

6 Click [Finish].

The wizard screen closes.

• To continue copying other images, disconnect the cable for multi-use terminal (page 85). Then follow the procedure explained in “Stage 2: Connecting the camera and your computer” on page 82.

Stage 3-B: Copying images to a Computer

• For Windows XP, follow the procedure explained in “Stage 3-A: Copying images to a computer” on page 82.

This section describes an example of copying images to the “My Documents” folder.

Using your computer

Page 84

Copying images to your computer

1 Double-click [My Computer] t

[Removable Disk]

• If the “Removable Disk” icon is not displayed, see page 109.

t [DCIM].

2 Double-click the folder where the

image files you want to copy are stored.

Then, right-click an image file to display the menu and click [Copy].

3 Double-click the [My Documents]

folder. Then, right-click on the “My Documents” window to display the menu and click [Paste].

The image files are copied to the “My Documents” folder.

• When an image with the same file name exists in the copy destination folder, the overwrite confirmation message appears. When you overwrite an existing image with a new one, the original file data is deleted. To copy an image file to the computer without overwriting, change the file name to a different name and then copy the image file. However, note that if you change the file name (page 87), you may not be able to playback that image with your camera.

• On the storage destination of the image files, see page 86.

Page 85

Copying images to your computer

Stage 4: Viewing images on your computer

This section describes the procedure for viewing copied images in the “My Documents” folder.

1 Click [Start] t [My Documents].

The contents of the “My Documents” folder are displayed.

• If you are not using Windows XP, double-click [My Documents] on the desktop.

2 Double-click the desired image

file.

To delete the USB connection

Perform the procedures listed below beforehand when:

• Disconnecting the cable for multi-use terminal

• Removing a “Memory Stick Duo”

• Inserting a “Memory Stick Duo” into the camera after copying images from the internal memory

• Turning off the camera

1 Double-click on the tasktray.

Double-click here

2 Click (USB Mass Storage Device)

[Stop].

3 Confirm the device on the confirmation

window, then click [OK].

4 Click [OK].

The device is disconnected.

•Step 4 is unnecessary for Windows XP.

Using your computer

The image is displayed.

Page 86

Copying images to your computer

Image file storage destinations and file names

The image files recorded with your camera are grouped as folders on the “Memory Stick Duo”.

Example: viewing folders on Windows XP

A Folder containing image data recorded

using a camera not equipped with the folder creating function

B Folder containing image data recorded

using this camera When no new folders are created, there are folders as follows:

– “Memory Stick Duo”; “101MSDCF” only – Internal memory; “101_SONY” only

• You cannot record any images to the “100MSDCF” folder. The images in these folders are available only for viewing.

• You cannot record/playback any images to the “MISC” folder.

• Image files are named as follows. ssss

stands for any number within the range from 0001 to 9999. The numerical portions of the name of a movie file recorded in movie mode and its corresponding index image file are the same.

– Still image files: DSC0ssss.JPG – Movie files: MOV0ssss.MPG – Index image files that are recorded when you

record movies: MOV0ssss.THM

• For more information about folders, see pages 59 and 62.

Page 87

Viewing image files stored on a computer with your camera (using a “Memory Stick Duo”)

This section describes the process using a Windows computer as an example. When an image file copied to a computer no longer remains on a “Memory Stick Duo”, you can view that image again on the camera by copying the image file on the computer to a “Memory Stick Duo”.

• Step 1 is not necessary if the file name set with your camera has not been changed.

• You may be unable to playback some images depending on the image size.

• When an image file has been processed by a computer or when the image file was recorded using a model other than that of your camera, playback on your camera is not guaranteed.

• When there is no folder, create a folder with your camera (page 62) first, and then copy the image file.

2 Copy the image file to the

“Memory Stick Duo” folder in the following order.

1Right-click the image file, then click

[Copy].

2Double-click [Removable Disk] or

[Sony MemoryStick] in [My Computer].

3Right-click the [sssMSDCF] folder

in the [DCIM] folder, then click [Paste].

• sss stands for any number within the

range from 100 to 999.

1 Right-click the image file, then

click [Rename]. Change the file name to “DSC0ssss”.

Enter a number from 0001 to 9999 for ssss.

1 2

• If the overwrite confirmation message appears, enter a different number.

• An extension may be displayed depending on the computer settings. The extension for still images is JPG, and the extension for movies is MPG. Do not change the extension.

Using your computer

Page 88

Using the “Picture Motion Browser” (supplied)

You can use still images and movies from the camera more than ever by taking advantage of the software. This section summarizes the “Picture Motion Browser” and gives the basic instructions.

“Picture Motion Browser” overview

With the “Picture Motion Browser” you can:

• Import images shot with the camera and display them on the computer.

• Organize images on the computer on a calendar by shooting date to view them.

• Retouch (Red Eye Correction, etc.), print, and send still images as e-mail attachments, change the shooting date and more.

• Still images can be printed or saved with the date.

• You can create a data disc using a CD burner drive or DVD burner drive.

• For details on the “Picture Motion Browser”, refer to the Help.

To access the Help, click [Start] t [All Programs] (in Windows 2000, [Programs]) t [Sony Picture Utility] t [Help] t [Picture Motion Browser].

Starting and exiting the “Picture Motion Browser”

Starting the “Picture Motion Browser”

Double-click the (Picture Motion Browser) icon on the desktop. Or, from the Start menu: Click [Start] t [All Programs] (in Windows 2000, [Programs]) t [Sony Picture Utility] t [Picture Motion Browser].

• The confirmation message of the Information tool appears on the screen when starting the “Picture Motion Browser” for the first time. Select [Start]. This function informs you of news, such as software updates. You can change the setting later.

Exiting the “Picture Motion Browser”

Click button in the top right corner of the screen.

Basic instructions

Follow these steps to import and view images from the camera.

Importing images

1 Make sure “Media Check Tool”* is

running.

Look for a the taskbar.

* “Media Check Tool” is a program that

automatically detects and imports images when a “Memory Stick” is inserted or when the camera is connected.

• If there is no icon: Click [Start] t [All

Programs] (in Windows t [Sony Picture Utility] t [Tools] t [Media Check Tool].

(Media Check Tool) icon in

2000, [Programs])

Page 89

Using the “Picture Motion Browser” (supplied)

2 Connect the camera to your

computer with the cable for multiuse terminal.

After the camera is automatically detected, the [Import Images] screen is displayed.

• If you use the Memory Stick slot, refer to page 81.

• In Windows XP, if the AutoPlay Wizard appears, close it.

3 Import the images.

To start importing images, click the [Import] button.

By default, images are imported into a folder created in “My Pictures” that is named with the date of importing.

• For instructions on changing the “Folder to be imported”, refer to page 92.

Viewing images

1 Checking imported images

When importing is complete, the “Picture Motion Browser” starts. Thumbnails of the imported images are displayed.

• The “My Pictures” folder is set as the default folder in “Viewed folders”.

• You can double-click a thumbnail to display the image by itself.

2 Viewing images in “Viewed

folders” arranged by shooting date on a calendar

1Click the [Calendar] tab.

Years when images were shot are listed.

2Click the year.

Images shot that year are displayed, arranged on the calendar by shooting date.

3To display images by month, click the

desired month. Thumbnails of images shot that month are displayed.

4To display images by time, click the

desired date. Thumbnails of images shot that day are displayed, arranged by hour.

Using your computer

Page 90

Using the “Picture Motion Browser” (supplied)

Year display screen

Month display screen

Hour display screen

3 Displaying individual images

On the hour display screen, double-click a thumbnail to display the image by itself in a separate window.

• You can edit displayed images by clicking the button in the toolbar.

Displaying images in full-screen mode

To display a slide show of current images in full-screen mode, click the

button.

• To list images from a particular year or month, click that period on the left of the screen.

• To play or pause the slide show, click the button on the lower left of the screen.

• To stop the slide show, click the button

on the lower left of the screen.

Page 91

Using the “Picture Motion Browser” (supplied)

Creating a data disc Using Map View to display still

images on a map

Images can be saved in CD or DVD as a data disc.

• CD burner drive or DVD burner drive

required.

• The following disc can be used for

creating a data disc.

– CD–R/RW (12 cm) – DVD±R/RW (12 cm) – DVD±R DL (12 cm)

If your still images have position information, you can see the images on maps online with Map View.

• To use the Map View function, your

computer needs to be connected to the Internet.

1 Select a thumbnail marked with

1 Select images to save on the disc.

• To select consecutive images, click the first image, then press and hold down “Shift” key while you click the last image.

• To select two or more non-consecutive images, press and hold down “Ctrl” key while clicking images.

2 Click .

The Map View main window appears.

2 Click the button on the tool

bar.

The [Create Data Disc] display appears.

3 Click [Start].

4 Follow the display instructions to

proceed with creating the data disc.

• To add desired images, drag and drop on the [Create Data Disc] display.

Selecting all images in a folder

Click the [folders] tab, then right-click on the desired folder icon and select [Create Data Disc]. All images in a folder can be selected.

• Maps and satellite images powered by Google Maps mapping service.

• You can later add position information on

the still images, using the Map View. For details, see the Help of Map View.

Using your computer

Page 92

Using the “Picture Motion Browser” (supplied)

Other functions

Preparing images stored on the computer for viewing

To view them, register the folder that contains the images as one of the “Viewed folders”.

1 Click on the main screen, or

choose [Register Folders to View] from the [File] menu.

The settings screen for “Viewed folders” registration is displayed.

2 Specify the folder with images for

importing to register the folder as one of the “Viewed folders”.

3 Click [OK].

The image information is registered in the database.

• Images in any subfolders of “Viewed

folders” are also registered.

Changing the “Folder to be imported”

To change the “Folder to be imported”, access the “Import Settings” screen.

1 Choose [Import Settings] t

[Location for Imported Images] from the [File] menu.

The “Location for Imported Images” screen is displayed.

2 Choose the “Folder to be

imported”.

• You can specify the “Folder to be

imported” from folders registered as “Viewed folders”.

Updating image registration information

To update image information, choose [Update Database] from the [Tools] menu.

• Updating the database may take a while.

• If you rename image files or folders in

“Viewed folders”, they cannot be displayed with this software. In this case, update the database.

Saving images with the date

1 Double-click an image to display it. 2 Click and select [Insert Date] from the

drop-down list.

3 Select your desired color and position, and

then click [OK].

4 Click to save.

Printing images with the date

1 Select the still image you want to print. 2 Click on the toolbar. 3 Click the check box of [Print date taken] in

Print Options.

4 Click [Print].

Page 93

Using the “Picture Motion Browser” (supplied)

To uninstall the “Picture Motion Browser”

1 Click [Start] t [Control Panel] (in

Windows 2000, [Start] t [Settings] t [Control Panel]), then double-click [Add/ Remove Programs].

2 Select [Sony Picture Utility], then click

[Remove] (in Windows 2000, [Change/ Remove]) to execute the uninstallation.

Using your computer

Page 94

Using the “Music Transfer” (supplied)

You can change the Music files that are preset at the factory with desired Music files using “Music Transfer” in the CDROM (supplied). Also, you can delete or add these files whenever you want.

Adding/Changing Music using “Music Transfer”

The music formats you can transfer with “Music Transfer” are listed below:

• MP3 files stored on the hard drive of your computer

• Music on CDs

• Preset-music saved on this camera

1 Press HOME to display the HOME

screen.

2 Select (Printing, Other) with

b/B on the control button, select [ Music Tool] with v/V, then press z.

3 Select [Download Music] with

v/V/b/B, then press z.

The message “Connect to PC” appears.

• To restore the music preset at the factory

to the camera:

1 Perform [Format Music] in step 3. 2 Execute [Restore defaults] on “Music

Transfer.”

All Music files return to the preset-music, and [Music] in the [Slide Show] menu is set to [Off].

• You can reset the Music files to the preset ones using [Initialize] (page 66), however, other settings will also be reset.

• For details on using “Music Transfer”, see the on-line help in “Music Transfer”.

4 Make a USB connection between

the camera and your computer.

5 Start “Music Transfer”.

6 Follow the instructions on the

screen to add/change Music files.

Page 95

Using your Macintosh computer

You can copy images to your Macintosh computer.

• “Picture Motion Browser” is not compatible with Macintosh computers.

Recommended computer environment

The following environment is recommended for a computer connected to the camera.

Recommended environment for copying images

OS (pre-installed): Mac OS 9.1/9.2/ Mac

OS X(v10.1 to v10.4)

USB jack: Provided as standard

Recommended environment for using “Music Transfer”

OS (pre-installed): Mac OS X (v10.3 to

v10.4)

CPU: iMac, eMac, iBook, PowerBook, Power

Mac G3/G4/G5 series, Mac mini

Memory: 64 MB or more (128 MB or more is

recommended)

Hard Disk: Disk space required for

installation—approximately 250 MB

Notes on connecting your camera to a computer

• Operations are not guaranteed for all the recommended computer environments mentioned above.

• If you connect two or more USB devices to a single computer at the same time, some devices, including your camera, may not operate depending on the types of USB devices you are using.

• Operations are not guaranteed when using a USB hub.

• Connecting your camera using a USB interface that is compatible with Hi-Speed USB (USB 2.0 compliant) allows advanced transfer (high speed transfer) as this camera is compatible with HiSpeed USB (USB 2.0 compliant).

• When your computer resumes from the suspend or sleep mode, communication between your camera and your computer may not recover at the same time.

Copying and viewing images on a computer

1 Prepare the camera and a

Macintosh computer.

Perform the same procedure as described in “Stage 1: Preparing the camera and the computer” on page 81.

2 Connect the cable for multi-use

terminal.

Perform the same procedure as described in “Stage 2: Connecting the camera and your computer” on page 82.

3 Copy image files to the Macintosh

computer.

1Double-click the newly recognized icon

t [DCIM] t the folder where the

images you want to copy are stored.

2Drag and drop the image files to the

hard disk icon. The image files are copied to the hard disk.

• For details on the storage location of the images and file names, see page 86.

Using your computer

Page 96

Using your Macintosh computer

4 View images on the computer.

Double-click the hard disk icon desired image file in the folder containing the copied files to open that image file.

To delete the USB connection

t the

1 Turn on your Macintosh computer, and

insert the CD-ROM (supplied) into the CD-ROM drive.

2 Double-click (SONYPICTUTIL). 3 Double-click the [MusicTransfer.pkg] file

in [MAC] folder. The installation of the software starts.

To add/change Music files

See “Adding/Changing Music using “Music Transfer”” on page 94.

Perform the procedures listed below beforehand when:

• Disconnecting the cable for multi-use terminal

• Removing a “Memory Stick Duo”

• Inserting a “Memory Stick Duo” into the camera after copying images from the internal memory

• Turning off the camera

Drag and drop the drive icon or the icon of the “Memory Stick Duo” to the “Trash” icon.

The camera is disconnected from the computer.

Adding/Changing Music using “Music Transfer”

You can change the Music files that are preset at the factory with desired Music files. Also, you can delete or add these files whenever you want. The music formats you can transfer with “Music Transfer” are listed below:

• MP3 files stored on the hard drive of your computer

• Music on CDs

• Preset-music saved on this camera

To install “Music Transfer”

• Shut down all other application software before you install “Music Transfer”.

• For installation, you need to log on as Administrator.

Technical Support

Additional information on this product and answers to frequently asked questions can be found at the Sony Customer Support Website. http://www.sony.net/

Page 97

Printing still images

How to print still images

When you print images shot in [16:9] mode, both edges may be cut off, so be sure to check before printing (page 111).

Printing directly using a PictBridge compliant printer (page 98)

You can print images by connecting the camera directly to a PictBridge compliant printer.

Printing directly using a “Memory Stick” compliant printer

You can print images with a “Memory Stick” compliant printer. For details, see the operating instructions supplied with the printer.

Printing using a computer

You can copy images to a computer using the supplied “Picture Motion Browser” software and print the images. You can insert the date on the image and print it (page 92).

Printing at a shop (page 101)

You can take a “Memory Stick Duo” containing images shot with your camera to a photo printing service shop. You can make a

(Print order) mark on images which you want to print out in

advance.

Printing still images

Page 98

Printing images directly using a PictBridge compliant printer

Even if you do not have a computer, you can print images shot using your camera by connecting the camera directly to a PictBridge compliant printer.

• “PictBridge” is based on the CIPA standard. (CIPA: Camera & Imaging Products Association)

• You cannot print movies.

• If the indicator flashes on the screen of the camera (error notification), check the connected printer.

Stage 1: Preparing the camera

Prepare the camera to connect it to the printer with the cable for multi-use terminal. When connecting the camera to a printer that is recognized when [USB Connect] is set to [Auto], Stage 1 is unnecessary.

MENU button

Control button

HOME button

• It is recommended to use a fully charged battery pack to prevent the power from turning off partway through printing.

1 Press HOME to display the HOME

screen.

2 Select (Settings) with b/B, and

select [ Main settings] with v/ V, then press z.

3 Select [Main Settings 2] with v/V/

b/B, and select [USB Connect], then press z.

4 Select [PictBridge] with v/V, then

press z.

The USB mode is set.

Page 99

Printing images directly using a PictBridge compliant printer

Stage 2: Connecting the camera to the printer

1 Connect the camera to the

printer.

2 To the multi

connector

1 To the

USB jack

Cable for multi-use terminal

2 Press (Playback) and turn on

your camera and the printer.

After the connection is made, the indicator appears.

Stage 3: Selecting images you want to print

Select [This Image] or [Multiple Images] with v/V, then press z.

When you select [This Image]

You can print the selected image. Move on to Stage 4.

When you select [Multiple Images]

You can print multiple selected images.

1Select the image you want to print with

b/B, then press z.

mark appears on the selected image.

2Press MENU to display the menu. 3Select [OK] with the control button,

then press z.

• After you select [Multiple Images] on the

index screen, you can print all the images in a folder by selecting the folder selection bar with b and attaching a mark on the folder.

Stage 4: Printing

1 Select print settings with the

control button.

Printing still images

The camera is set to playback mode, then an image and the print menu appear on the screen.

[Quantity]

When the [Layout] is set to [1-up/ Borderless] or [1-up/Border]:

Select the number of sheets of an image that you want to print. The image will be printed as a single image.

Page 100

Printing images directly using a PictBridge compliant printer

When the [Layout] is not set to [1up/Borderless] or [1-up/Border]:

Select the number of sets of images that you want to print as an index image. If you selected [This Image] in step 1, select the number of the same image you want to print side by side on a sheet as an index image.

• The designated number of images may not all fit onto a single sheet depending on the quantity of images.

[Layout]

Selects the number of image you want to print side by side on a sheet.

[Size]

Select the size of the printing sheet.

[Date]

Select [Day & Time] or [Date] to insert the date and time on images.

• When you choose [Date], the date will be inserted in the order you select (page 73). This function may not be provided depending on the printer.

2 Select [OK] with v, then press z.

The image is printed.

• Do not disconnect the cable for multi-use terminal while the (PictBridge Connecting) indicator appears on the screen.

Stage 5: Completing the printing

Make sure the screen has returned to Stage 2, and disconnect the cable for multi-use terminal from the camera.

To print other images

Select [Multiple Images], then perform the process again from stage 3.

100

indicator
