4-412-246-11(1)
|
|
Digital Still Camera / Instruction Manual |
GB |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
CT |
|
|
|
|
|
|
|
|
|
|
|
|
|
CS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DSC-HX10/HX10V
English
“Cyber-shot User Guide” is an on-line manual. Refer to it for in-depth instructions on the many functions of the camera. 1 Access the Sony support page.
http://www.sony.net/SonyInfo/Support/ 2 Select your country or region.
3Search for the model name of your camera within the support page.
• Check the model name on the bottom of your camera.
The number in parentheses indicates the number of pieces.
•Camera (1)
•Rechargeable battery pack NP-BG1 (1)/Battery case (1)
•Micro USB cable (1)
•AC Adaptor AC-UB10/UB10B (1)
•Power cord (mains lead) (not supplied in the USA and Canada) (1)
•Wrist strap (1)
•Instruction Manual (this manual) (1)
GB
2
Owner’s Record
The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call your Sony dealer regarding this product.
Model No. DSC-HX10/DSC-HX10V
Serial No. _____________________________
Model No. AC-UB10/AC-UB10B
Serial No. _____________________________
GB
WARNING
To reduce fire or shock hazard, do not expose the unit to rain or moisture.
IMPORTANT SAFETY INSTRUCTIONS -SAVE THESE INSTRUCTIONS DANGER
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS
If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the proper configuration for the power outlet.
CAUTION
[ Battery pack
If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical burns. Observe the following cautions.
•Do not disassemble.
•Do not crush and do not expose the battery pack to any shock or force such as hammering, dropping or stepping on it.
•Do not short circuit and do not allow metal objects to come into contact with the battery terminals.
•Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a car parked in the sun.
•Do not incinerate or dispose of in fire.
•Do not handle damaged or leaking lithium ion batteries.
GB
3
•Be sure to charge the battery pack using a genuine Sony battery charger or a device that can charge the battery pack.
•Keep the battery pack out of the reach of small children.
•Keep the battery pack dry.
•Replace only with the same or equivalent type recommended by Sony.
•Dispose of used battery packs promptly as described in the instructions.
[ AC Adaptor
Connect the AC Adaptor to the nearest wall outlet (wall socket).
If some trouble occurs while using the AC Adaptor, immediately shut off the power by disconnecting the plug from the wall outlet (wall socket).
The power cord (mains lead), if supplied, is designed specifically for use with this camera only, and should not be used with other electrical equipment.
For Customers in the U.S.A. and Canada
[ RECYCLING LITHIUM-ION BATTERIES
Lithium-Ion batteries are recyclable.
You can help preserve our environment by returning your used rechargeable batteries to the collection and recycling location nearest you.
For more information regarding recycling of rechargeable batteries, call toll free
1-800-822-8837, or visit http://www.rbrc.org/
Caution: Do not handle damaged or leaking Lithium-Ion batteries.
[ Battery pack
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
GB
4
For Customers in the U.S.A.
UL is an internationally recognized safety organization.
The UL Mark on the product means it has been UL Listed.
If you have any questions about this product, you may call: |
|
|
Sony Customer Information Center |
|
|
1-800-222-SONY (7669). |
|
|
The number below is for the FCC related matters only. |
GB |
|
[ Regulatory Information |
|
|
|
|
|
Declaration of Conformity |
|
|
Trade Name: SONY |
|
|
Model No.: DSC-HX10V |
|
|
Responsible Party: Sony Electronics Inc. |
|
|
Address: 16530 Via Esprillo, |
|
|
San Diego, CA 92127 U.S.A. |
|
|
Telephone No.: 858-942-2230 |
|
|
This device complies with Part15 of the FCC Rules. Operation is subject to the |
|
|
following two conditions: (1) This device may not cause harmful interference, and (2) |
|
|
this device must accept any interference received, including interference that may cause |
|
|
undesired operation. |
|
|
|
|
|
[ CAUTION
You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.
[ Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
The supplied interface cable must be used with the equipment in order to comply with the |
GB |
limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules. |
5 |
For Customers in Canada
This device complies with RSS-310 of Industry Canada. Operation is subject to the condition that this device does not cause harmful interference.
For Customers in Europe
GB
6
Hereby, Sony Corporation, declares that this DSC-HX10V Digital Still Camera is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. For details, please access the following URL: http://www.compliance.sony.de/
[ Notice for the customers in the countries applying EU Directives
The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or guarantee matters please refer to the addresses given in separate service or guarantee documents.
This product has been tested and found compliant with the limits set out in the EMC regulation for using connection cables shorter than 3 meters (9.8 feet).
[ Attention
The electromagnetic fields at the specific frequencies may influence the picture and sound of this unit.
[ Notice
If static electricity or electromagnetism causes data transfer to discontinue midway (fail), restart the application or disconnect and connect the communication cable (USB, etc.) again.
[Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)
This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural
resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.
[Disposal of waste batteries (applicable in the European Union and other European countries with separate collection systems)
This symbol on the battery or on the packaging indicates that the battery provided with this product shall not be treated as household waste.
On certain batteries this symbol might be used in combination with a
chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are added if the battery contains more than 0.0005% mercury or 0.004% lead. By ensuring these batteries are disposed of correctly, you will help prevent
potentially negative consequences for the environment and human health which could otherwise be caused by inappropriate waste handling of the battery. The recycling of the GB materials will help to conserve natural resources.
In case of products that for safety, performance or data integrity reasons require a permanent connection with an incorporated battery, this battery should be replaced by qualified service staff only. To ensure that the battery will be treated properly, hand over the product at end-of-life to the applicable collection point for the recycling of electrical and electronic equipment.
For all other batteries, please view the section on how to remove the battery from the product safely.
Hand the battery over to the applicable collection point for the recycling of waste batteries. For more detailed information about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.
Notice for customers in the United Kingdom
A moulded plug complying with BS 1363 is fitted to this equipment for your safety and convenience.
Should the fuse in the plug supplied need to be replaced, a fuse of the same rating as the supplied one and approved by ASTA or BSI to BS 1362, (i.e., marked with an or
mark) must be used.
If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.
GB
7
GB
8
A Shutter button B Mode dial
(Intelligent Auto)/
(Superior Auto)/
(Background Defocus)/
(Program Auto)/
(Scene
Selection)/ (Manual Exposure
Shooting)/ (iSweep
Panorama)/ (Movie Mode)/
(3D Shooting)
CFor shooting: W/T (Zoom) lever
For viewing: (Index) lever/
(Playback zoom) lever
DSelf-timer lamp/Smile Shutter lamp/AF illuminator
E ON/OFF (Power) button F Power/Charge lamp
G Speaker
HFlash
•Do not hold your fingers near the flash.
•When using the flash, the flash pops up automatically.
•The flash goes down automatically when the power is turned off, the camera is switched to playback mode or the shooting mode is changed.
I Microphone
J Lens
K LCD screen
LGPS sensor (built-in, DSCHX10V only)
M (Playback) button N MOVIE (Movie) button O HDMI mini jack
P Hook for wrist strap Q Control wheel
R/
(In-Camera Guide/Delete) button
S MENU button
TTripod receptacle
•Use a tripod with a screw less than 5.5 mm (7/32 inches) long. Otherwise, you cannot firmly secure the camera, and damage to the camera may occur.
U Micro USB connector V (TransferJet™) mark W Memory card slot
X Battery/memory card cover Y Battery eject lever
Z Battery insertion slot wj Access lamp
GB
Battery eject lever
1 Open the cover.
2 Insert the battery pack.
•While pressing the battery eject lever, insert the battery pack as illustrated. Make sure that the battery eject lever locks after insertion.
•Closing the cover with the battery inserted incorrectly may damage the camera.
GB
9
For customers in the USA and Canada
Power cord |
|
|
(Mains lead) |
Power/Charge lamp |
|
|
Lit: Charging |
|
For customers in countries/regions |
Off: Charging finished |
|
Flashing: |
||
other than the USA and Canada |
||
Charging error |
||
|
||
|
Charging paused due to |
|
|
overheating |
1 Connect the camera to the AC Adaptor (supplied), using the micro USB cable (supplied).
2 Connect the AC Adaptor to the wall outlet (wall socket).
The Power/Charge lamp lights orange, and charging starts.
•Turn off the camera while charging the battery.
•You can charge the battery pack even when it is partially charged.
•When the Power/Charge lamp flashes and charging is not finished, remove and re-insert the battery pack.
GB
10
Notes
• If the Power/Charge lamp on the camera flashes when the AC Adaptor is connected to the wall outlet (wall socket), this indicates that charging is temporarily stopped because the temperature is outside the recommended range. When the temperature gets back within the appropriate range, the charging resumes. We recommend charging the battery pack in an ambient temperature of between 10°C to 30°C (50ºF to 86ºF).
• The battery pack may not be effectively charged if the terminal section of the
battery is dirty. In this case, wipe any dust off lightly using a soft cloth or a cotton GB swab to clean the terminal section of the battery.
•Connect the AC Adaptor (supplied) to the nearest wall outlet (wall socket). If malfunctions occur while using the AC Adaptor, disconnect the plug from the wall outlet (wall socket) immediately to disconnect from the power source.
•When charging is finished, disconnect the AC Adaptor from the wall outlet (wall socket).
•Be sure to use only genuine Sony brand battery packs, micro USB cable (supplied) and AC Adaptor (supplied).
x Charging time (Full charge)
The charging time is approximately 175 min. using the AC Adaptor (supplied).
Note
•The above charging time applies when charging a fully depleted battery pack at a temperature of 25°C (77°F). Charging may take longer depending on conditions of use and circumstances.
GB
11
x Charging by connecting to a computer
The battery pack can be charged by connecting the camera to a computer using a micro USB cable.
Note
•Note the following points when charging via a computer:
–If the camera is connected to a laptop computer that is not connected to a power source, the laptop battery level decreases. Do not charge for an extended period of time.
–Do not turn on/off or restart the computer, or wake the computer to resume from sleep mode when a USB connection has been established between the computer and the camera. The camera may cause a malfunction. Before turning on/off, or restarting the computer or waking the computer from sleep mode, disconnect the camera and the computer.
–No guarantees are made for charging using a custom-built computer or a modified computer.
GB
12
xBattery life and number of images that can be recorded and played back
|
Battery life |
Number of images |
Shooting (still images) |
Approx. 170 min. |
Approx. 340 images |
|
|
|
Viewing (still images) |
Approx. 260 min. |
Approx. 5200 images |
|
|
|
Shooting (movies) |
Approx. 85 min. |
— |
|
|
|
GB
Notes
•The above number of images applies when the battery pack is fully charged. The number of images may decrease depending on the conditions of use.
•The number of images that can be recorded is for shooting under the following conditions:
–Using Sony “Memory Stick PRO Duo” (Mark2) media (sold separately)
–The battery pack is used at an ambient temperature of 25°C (77°F).
–[GPS setting] is set to [Off] (DSC-HX10V only).
–[Disp. Resolution] is set to [Standard].
•The number for “Shooting (still images)” is based on the CIPA standard, and is for shooting under the following conditions:
(CIPA: Camera & Imaging Products Association)
–DISP (Display Setting) is set to [ON].
–Shooting once every 30 seconds.
–The zoom is switched alternately between the W and T ends.
–The flash strobes once every two times.
–The power turns on and off once every ten times.
•The battery life for movies applies shooting under the following conditions:
–Movie quality: AVC HD HQ
–When continuous shooting ends because of set limits (page 25), press the MOVIE (Movie) button again and continue shooting. Shooting functions such as the zoom do not operate.
GB
13
x Supplying power
The camera can be supplied with power from the wall outlet (wall socket) by connecting to the AC Adaptor, using the micro USB cable (supplied).
You can import images to a computer without worrying about draining the battery pack by connecting the camera to a computer using the micro USB cable.
In addition, you can use the AC Adaptor AC-UD10 (sold separately) for shooting to supply power when shooting.
Notes
•Power cannot be supplied when the battery pack is not inserted in the camera.
•When the camera is connected directly to a computer or to a power outlet using the supplied AC Adaptor AC-UB10/UB10B, power supply is available only in playback mode. If the camera is in shooting mode or while you are changing the settings of the camera, power is not supplied even if you make a USB connection using the micro USB cable.
•If you connect the camera and a computer using the micro USB cable while the camera is in playback mode, the display on the camera will change from the
playback screen to the USB connection screen. Press (Playback) button to switch to the playback screen.
Ensure the notched corner faces correctly.
1
2
Open the cover.
Insert the memory card (sold separately).
•With the notched corner facing as illustrated, insert the memory card until it clicks into place.
GB 3 Close the cover.
14
x Memory cards that can be used
|
Memory card |
For still images |
For movies |
|
|
|
Memory Stick PRO Duo |
a |
a (Mark2 only) |
|
|
|
|
|
|
|
|
A |
Memory Stick PRO-HG Duo |
a |
a |
|
|
|
|
|
|
|
|
|
Memory Stick Duo |
a |
— |
|
|
|
|
|
|
|
|
B |
Memory Stick Micro (M2) |
a |
— |
|
|
|
|
|
|
|
|
|
Memory Stick Micro (Mark2) |
a |
a |
GB |
|
|
SD memory card |
a |
a (Class 4 or faster) |
|
|
|
|
|
|
|
|
C |
SDHC memory card |
a |
a (Class 4 or faster) |
|
|
|
|
|
|
|
|
|
SDXC memory card |
a |
a (Class 4 or faster) |
|
|
|
|
|
|
|
|
D |
microSD memory card |
a |
a (Class 4 or faster) |
|
|
|
|
|
|
|
|
microSDHC memory card |
a |
a (Class 4 or faster) |
|
|
|
|
|
|
|||
|
|
|
|
|
|
•In this manual, the products in the table are collectively referred to as follows: A: “Memory Stick Duo” media
B: “Memory Stick Micro” media C: SD card
D: microSD memory card
Note
•When using “Memory Stick Micro” media or microSD memory cards with this camera, make sure to use with the appropriate adaptor.
x To remove the memory card/battery pack
Memory card: Push the memory card in once to eject the memory card. Battery pack: Slide the battery eject lever. Be sure not to drop the battery pack.
Note
•Never remove the memory card/battery pack when the access lamp (page 8) is lit. This may cause damage to data in the memory card/internal memory.
GB
15
ON/OFF (Power)
Power/Charge lamp (green)
Control wheel
Select items: v/V/b/B
Set the numeric value of date and time: /
Set: z
1 Press the ON/OFF (Power) button.
Date & Time setting is displayed when you turn on the camera for the first time.
• It may take time for the power to turn on and allow operation.
2 Select a desired language.
3 Select a desired geographic location by following the on-screen instructions, then press z on the control wheel.
4 Set [Date & Time Format], [Daylight Savings] or [Summer Time] and [Date & Time], then select [OK] t [OK].
• Midnight is indicated as 12:00 AM, and noon as 12:00 PM.
5
GB
Follow the instructions on the screen.
•The battery pack will run out quickly when:
–[GPS setting] is set to [On] (DSC-HX10V only).
–[Disp. Resolution] is set to [High].
16
Mode dial
: Intelligent Auto
: Movie Mode
Shooting still images
Shutter button
MOVIE
GB
W/T (Zoom)
lever
W: zoom out T: zoom in
Do not cover the flash (A).
1 Press the shutter button halfway down to focus.
When the image is in focus, a beep sounds and the z indicator lights.
2 Press the shutter button fully down to shoot an image.
Shooting movies
1 Press the MOVIE (Movie) button to start recording.
•Use the W/T (zoom) lever to change the zoom scale.
•Press the shutter button to shoot still images while continuing to record the movie.
2 Press the MOVIE button again to stop recording.
Notes
•Do not push down or pull up the flash manually. This may cause a malfunction.
•The sound of the lens and lever operating will be recorded when the zoom function operates while shooting a movie. The sound of the MOVIE button operating may also be recorded when movie recording is finished.
•Continuous shooting is possible for approximately 29 minutes at one time at the camera’s default settings and when the temperature is approximately 25°C (77°F).
When movie recording is finished, you can restart recording by pressing the |
|
MOVIE button again. Recording may stop to protect the camera depending on the |
GB |
ambient temperature. |
17 |
W: zoom out
T: zoom in
Control wheel
(Playback)
/ (Delete) |
Select images: B (next)/b (previous) or turn |
|
|
|
the control wheel |
|
Set: z |
1 Press the (Playback) button.
•When images on a memory card recorded with other cameras are played back on this camera, the registration screen for the data file appears.
x Selecting next/previous image
Select an image by pressing B (next)/b (previous) on the control wheel or by turning the control wheel. Press z in the center of the control wheel to view movies.
x Deleting an image
1 Press /
(Delete) button.
2 Select [This Image] with v on the control wheel, then press z.
x Returning to shooting images
Press the shutter button halfway down.
GB
18
This camera is equipped with a built-in instruction guide. This allows you to search the camera’s functions according to your needs.
GB
/
(In-Camera Guide)
MENU
1 Press the MENU button.
2 Select the desired MENU item, then press the/
(InCamera Guide) button.
The operation guide for the selected item is displayed.
•If you press the/
(In-Camera Guide) button when the MENU screen is not displayed, you can search the guide using keywords or icons.
Other functions used when shooting or playing back can be operated using the control wheel or MENU button on the camera. This camera is equipped with a Function Guide that allows you to easily select from the functions. While displaying the guide, you can use various functions.
Control wheel
MENU
Function Guide |
GB |
|
19
x Control wheel
DISP (Display Setting): Allows you to change the screen display.
/
(Cont. Shooting/Self-Timer): Allows you to use the self-timer and burst shooting mode.
(Photo Creativity): Allows you to change [Brightness], [Color], [Vividness] and [Picture Effect] when shooting mode is set to [Intelligent Auto] or [Superior Auto].
(Flash): Allows you to select a flash mode for still images.
Center button (Tracking focus): The camera tracks the subject and adjusts focus automatically even when the subject is moving.
x Menu Items
Shooting
Movie shooting |
Select movie recording mode. |
|
scene |
|
|
|
|
|
3D Shooting |
Select the 3D image shooting mode. |
|
|
|
|
Picture Effect |
Shoot a still image with an original texture according to |
|
the desired effect. |
||
|
||
|
|
|
Scene Selection |
Select pre-set settings to match various scene conditions. |
|
|
|
|
Easy Mode |
Shoot still images using minimal functions. |
|
|
|
|
Defocus Effect |
Set the level of background defocus effect when |
|
shooting in Background Defocus mode. |
||
|
||
|
|
|
Still Image |
Set the still image size shot while recording a movie. |
|
Size(Dual Rec) |
|
|
|
|
|
Still Image Size/ |
Select the image size and the quality for still images, |
|
Panorama Image |
panoramic images or movie files. |
|
Size/Movie Size/ |
|
|
Movie Quality |
|
|
|
|
|
HDR Painting |
When [HDR Painting] is selected in Picture Effect, sets |
|
effect |
the effect level. |
|
|
|
|
Area of emphasis |
When [Miniature] is selected in Picture Effect, sets the |
|
part to focus on. |
||
|
||
|
|
|
Color hue |
When [Toy camera] is selected in Picture Effect, sets the |
|
color hue. |
||
|
||
|
|
GB
20
Extracted Color |
When [Partial Color] is selected in Picture Effect, selects |
|
|
the color to extract. |
|
|
|
|
|
|
|
|
|
|
|
Watercolor Effect |
When [Watercolor] is selected in Picture Effect, sets the |
|
|
effect level. |
|
|
|
|
|
|
|
|
|
|
|
Illustration Effect |
When [Illustration] is selected in Picture Effect, sets the |
|
|
effect level. |
|
|
|
|
|
|
|
|
|
|
|
EV |
Adjust the exposure manually. |
GB |
|
|
|||
|
|
|
|
ISO |
Adjust the luminous sensitivity. |
|
|
|
|
||
|
|
|
|
White Balance |
Adjust color tones of an image. |
|
|
|
|
|
|
Focus |
Select the focus method. |
|
|
|
|
|
|
Metering Mode |
Select the metering mode that sets which part of the |
|
|
subject to measure to determine the exposure. |
|
|
|
|
|
|
|
|
|
|
|
Cont. Shooting |
Select the number of images taken per second for Burst |
|
|
Interval |
shooting. |
|
|
|
|
|
|
Bracket Setting |
Set the type of the bracket shooting. |
|
|
|
|
|
|
Scene Recognition |
Set to automatically detect shooting conditions. |
|
|
|
|
|
|
Soft Skin Effect |
Set the Soft Skin Effect and the effect level. |
|
|
|
|
|
|
Smile Shutter |
Set to automatically release the shutter when a smile is |
|
|
detected. |
|
|
|
|
|
|
|
|
|
|
|
Smile Detection |
Set the Smile Shutter function sensitivity for detecting |
|
|
Sensitivity |
smiles. |
|
|
|
|
|
|
Face Detection |
Select to detect faces and adjust various settings |
|
|
automatically. |
|
|
|
|
|
|
|
|
|
|
|
Anti Blink |
Set to automatically shoot two images and select image |
|
|
in which the eyes are not blinking. |
|
|
|
|
|
|
|
|
|
|
|
|
Set the strength of SteadyShot in movie mode. If you |
|
|
Movie SteadyShot |
change the setting for [Movie SteadyShot], the angle of |
|
|
|
view will change. |
|
|
|
|
|
|
Position |
Check the GPS triangulating status and update the |
|
|
Information* |
position information. |
|
|
|
|
|
|
GPS Log REC* |
Record the route taken while carrying the camera. |
|
|
|
|
|
|
In-Camera Guide |
Search the camera’s functions according to your needs. |
|
|
|
|
|
|
* DSC-HX10V only |
GB |
|
21 |
||
|
Viewing
Slideshow |
Select a method of continuous playback. |
|
|
Send by |
Transfer data by closely aligning two products equipped |
TransferJet |
with TransferJet. |
|
|
Delete |
Delete an image. |
|
|
Retouch |
Retouch an image using various effects. |
|
|
Picture Effect |
Add various texture on images. |
|
|
3D Viewing |
Set to play back images shot in 3D mode on a 3D TV. |
|
|
View Mode |
Select the display format for images. |
|
|
Display Cont. |
Select to display burst images in groups or display all |
Shooting Group |
images during playback. |
|
|
Protect |
Protect the images. |
|
|
Print (DPOF) |
Add a print order mark to a still image. |
|
|
Rotate |
Rotate a still image to the left. |
|
|
In-Camera Guide |
Search the camera’s functions according to your needs. |
|
|
GB
22
x Setting items
If you press the MENU button while shooting or during playback, (Settings) is provided as a final selection. You can change the default
settings on the (Settings) screen.
|
Movie format/AF Illuminator/Grid Line/Clear Image |
|
|
|
Zoom/Digital Zoom/Wind Noise Reduct./Micref Level/ |
|
|
Shooting Settings |
Red Eye Reduction/Blink Alert/Write Date/Disp. |
|
|
|
Resolution |
GB |
|
|
Beep/Panel Brightness/Language Setting/Display color/ |
|
|
|
Demo Mode/Initialize/Function Guide/CTRL FOR |
|
|
|
HDMI/Eco Mode/USB Connect Setting/USB Power |
|
|
Main Settings |
Supply/LUN Setting/Download Music/Empty Music/ |
|
|
|
Airplane Mode*1/GPS setting*1/GPS assist data*1/Dlt. |
|
|
|
GPS Log Data*1/TransferJet/Eye-Fi/Version |
|
|
|
Format/Create REC.Folder/Change REC.Folder/Delete |
|
|
Memory Card |
REC.Folder/Copy/File Number |
|
|
Tool*2 |
|
|
|
|
Area Setting/Date & Time Setting/Auto Clock ADJ*1/ |
|
|
Clock Settings |
Auto Area ADJ*1 |
|
|
*1 DSC-HX10V only
*2 If a memory card is not inserted, (Internal Memory Tool) will be displayed and only [Format] can be selected.
GB
23
The built-in software “PlayMemories Home” allows you to import still images and movies to your computer and use them.
You can shoot or play back images on this camera even if you do not install “PlayMemories Home”, however, “PlayMemories Home” is required to import AVCHD movies to your computer.
1 Connect the camera to a computer.
2 Windows 7: [Computer] t camera icon t media icon t Double-click [PMHOME.EXE]
Windows XP/Vista: [Computer] (in Windows XP, [My Computer]) t [PMHOME] t Double-click [PMHOME.EXE]
3 Follow the instructions on the screen to complete the installation.
Note
•“PlayMemories Home” is not compatible to Mac OS. If you play back images on a Mac, use the applications that are installed on your Mac.
For details, see http://www.sony.co.jp/imsoft/Mac/
x Features of “PlayMemories Home”
Below are examples of the functions available when you use “PlayMemories Home”. To take advantage of the various “PlayMemories Home” functions, connect to the Internet and install the “Expanded Feature”.
•You can import images shot with the camera to a computer and display them.
•You can display images stored on a computer by shooting date in a calendar display.
•You can correct (Red Eye Correction, etc.) still images, print the images, send images by e-mail, and change the shooting date and time.
•You can save and print images with the date.
•You can create a disc from AVCHD movies imported to a computer. (Expanded Feature)
GB
24
The number of still images and recordable time may vary depending on the shooting conditions and the memory card.
x Still images
|
|
(Units: Images) GB |
|
|
|
Internal memory |
Memory card |
|
|
|
Approx. 19 MB |
2 GB |
|
|
|
|
|
|
|
18M |
3 |
295 |
|
|
|
|
|
|
|
VGA |
65 |
6400 |
|
|
|
|
|
|
|
16:9(13M) |
3 |
330 |
|
|
|
|
|
|
|
x Movies
The table below shows the approximate maximum recording times. These are the total times for all movie files. Continuous shooting is possible for approximately 29 minutes. The maximum size of an MP4-format movie file is up to approximately 2 GB.
|
|
(h (hour), m (minute)) |
|
Internal memory |
Memory card |
|
Approx. 19 MB |
2 GB |
|
|
|
AVC HD 24M (FX) |
— |
10 m |
|
|
(10 m) |
|
|
|
AVC HD 9M (HQ) |
— |
20 m |
|
|
(15 m) |
|
|
|
MP4 12M |
— |
15 m |
|
|
|
MP4 3M |
— |
1 h 5 m |
|
|
|
The number in ( ) is the minimum recordable time. |
|
•The recordable time of movies varies because the camera is equipped with VBR (Variable Bit Rate), which automatically adjusts image quality depending on the shooting scene. When you record a fast-moving subject, the image is clearer but the recordable time is shorter because more memory is required for recording.
The recordable time also varies depending on the shooting conditions, the subject or the image quality/size settings.
GB
25
Functions built into this camera
•This manual describes each of the functions of TransferJet compatible/ incompatible devices, 1080 60i-compatible devices and 1080 50i-compatible devices.
–To determine whether your camera supports the GPS function, check the model name of your camera.
GPS-compatible: DSC-HX10V GPS-incompatible: DSC-HX10
–To check if your camera supports the TransferJet function, and whether it is a 1080 60i-compatible device or 1080 50i-compatible device, check for the
following marks on the bottom of the camera.
TransferJet-compatible device: (TransferJet) 1080 60i-compatible device: 60i
1080 50i-compatible device: 50i
•While aboard an airplane, set [Airplane Mode] to [On] (DSC-HX10V only).
•Do not watch 3D images shot with this camera for extended periods of time on 3D-compatible monitors.
•When you view 3D images shot with this camera on a 3D-compatible monitor, you may experience discomfort in the form of eye strain, fatigue, or nausea. To prevent these symptoms, we recommend that you take regular breaks. However, you need to determine for yourself the length and frequency of breaks you require, as they vary according to the individual. If you experience any type of discomfort, stop viewing the 3D images until you feel better, and consult a physician as necessary. Also refer to the operating instructions supplied with the device or software you have connected or are using with this camera. Note that a child’s eyesight is still at the development stage (particularly children below the age of 6). Consult a pediatrician or ophthalmologist before letting your child view 3D images, and make sure he/she observes the above precautions when viewing such images.
On GPS-compatible devices (DSC-HX10V only)
•Use GPS in accordance with regulations of countries and regions where you use it.
•If you do not record the direction or location information, set [GPS setting] to [Off].
On use and care
Avoid rough handling, disassembling, modifying, physical shock, or impact such as hammering, dropping, or stepping on the product. Be particularly careful of the lens.
GB
26
