Page 1
CMT-
CPX22
Micro System
200 Watts Total: 100 Watts Per Channel x 2 (RMS 10% THD)
5 Disc Tray Loading CD Player Mechanism
S
-Master™ Digital Amplifier Design
2-Way Main Speakers with 5" Glass Fiber Woofers and a Soft Dome
Tweeter
CD-R/CD-RW with MP3 Playback Capability
1
Dual Cassette Deck-
Dual Auto Reverse
20 FM and 10 AM Station Presets
Analog Audio Input x 1 (Video/MD)
Optical Digital Output
CD Play Modes (Program/Shuffle/Repeat)
Page 2
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com
Last Updated: 10/12/2007
CMT-
CPX22
Micro System
Please visit the Dealer Network for current information at
www.sony.com/dn
Features
S-
Master® Digital Amplifier More efficient than traditional
analog amplifiers by using less energy to produce the same
signal. The audio benefits are higher resolution sound quality,
monitored noise reduction and accurate sound reproduction.
CD-R/CD-RW with MP3 Playback Capability Plays back MP3
files recorded onto CD-R/RW discs.
1
Tuner with 20 FM and 10 AM Station Presets Provides easy
access to the most listened to radio stations.
2 Way Main Speakers with Hybrid Dual 5" Woofer A two driver
design helps ensure audio accuracy by providing a greater
frequency range. The speaker's crossover splits the frequency
band into two ranges: bass frequencies to the woofer, treble
frequencies go to the tweeter.
CD Play Modes (Program/Shuffle/Repeat) lets you hear
tracks in sequence as recorded, in program RMS order or a
single track over and over, or all tracks in random (Shuffle)
order.
5 Disc CD Changer Provides a unique way to keep the music
going all day, or all night long.
Specifications
General
Type of Use: Desktop Micro System
Tray Type: 5 Disc Tray Loading
Disc Capacity: 5
Audio
Digital-to-Analog Converter: 1 Bit
Frequency Response:
2Hz-20kHz
Format(s) Supported: CD-R/RW
Antenna System: AM: Loop Antenna, FM: Lead Antenna
Tape System: Synchronized CD Recording
Frequency Range: AM: 530-1710kHz
Impedance: 4 Ohms
CD Play Mode(s):
Program, Shuffle, Repeat
Station Preset(s): 10 AM, 20 FM
Sound Enhancer: DSG - Dynamic Sound Generator
Tape Operation: Full Logic Dual Cassette Deck
Audio Features
Digital Amplifier: Yes (S-Master® Digital Amplifier)
Convenience Features
Timer Events:
Daily/Record/Play/Sleep
Power Save Mode: Yes
Hardware
Remote Control: Yes (Remote Commander® Remote Control)
Power
Power Requirements: AC 120V, 60Hz
Output Power: 200W Total (100 Watts Per Channel x 2 (RMS 10%
THD))
Speaker
Speaker System: 2 Way Bass Reflex Type
Inputs and Outputs
Analog Audio Input(s): 1 (Rear)
Optical Audio Output(s): 1 (Rear)
Headphone Output(s): 1 (Mini-pin)
Dimensions
Weight: 30 lbs, 10 oz (13.9 Kg)
Measurements: 9.1 x 11.5 x 14.0" (230 x 292 x 355mm)
Supplied Accessories
Instruction Manual
Remote Commander® Remote Control (RM-SC3)
Batteries x 2
FM Lead Antenna
UPC Code:
027242644793
1. CD-R/RW playback may not be compatible with all discs, depending on recording conditions.
©2005 Sony Electronics Inc.
Sony, Remote Commander, and S-Master are trademarks of Sony. All other trademarks are property of their
respective owners.
Features and specifications are subject to change without notice. Non-metric weights and measures are
approximate.
