Page 1

3-861-742-11 (2)

80-68385-1 Rev A

Portable Dual Band PCS Telephone

Operating Instructions

CM-B1200 CM-B2200 CM-B3200

Page 2

Before operating your portable dual band telephone, please read this manual thoroughly and retain it for future reference.

If your usage includes in-vehicle operation, it is recommended that you refer to the Installation/Connections/Operation manual for the optional accessory kits.

DISPOSAL OF LITHIUM ION BATTERY

LITHIUM ION BATTERY. DISPOSE OF PROPERLY.

You can return your unwanted lithium ion batteries to your nearest Sony Service Center or Factory Service Center.

Note: In some areas the disposal of lithium ion batteries in household or business

trash may be prohibited.

For the Sony Service Center nearest you call 1-800-222-SONY (United States only). For the Sony Factory Service Center nearest you call 416-499-SONY (Canada only).

WARNING

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

FCC CAUTION STATEMENT

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

Owner’s record

The model number, regulatory number, and serial number are located on a nameplate inside the battery compartment. Record the serial number in the space provided below. Refer to these numbers whenever you call your dealer regarding this product.

Model No.: __________________ Serial No.: _________________

©1997 Sony Electronics Inc. All rights reserved. Reproduction without written consent expressly prohibited. Sony and Jog Dial are trademarks of Sony. All other trademarks are the property of their respective owners. Design and specifications are subject to change without notice. Talk and standby times are subject to change.

Page 3

Rules and regulations

The U.S. Federal Communications Commission and the Industry Canada regulate cellular/PCS telephone service in their respective countries. It is important for you, the cellular/PCS telephone user, to observe the applicable regulations when operating your cellular/PCS telephone in either country. In addition to these U.S. and Canadian federal regulations, you may be bound also by certain state, provincial, territorial, and local rules and regulations, as well as by your cellular/ PCS carrier’s tariff (the rates, terms, and conditions of its service). If you wish to use your cellular/PCS telephone in both the U.S. and Canada, please consult with your System Operator.

Furthermore, you should remember that your cellular/PCS radiotelephone, — i.e., it combines both wireline technology, as used in your home or office telephone system, and radio technology — and that the scope of regulations and precautions is therefore broader than the scope of regulations and precautions relating to wireline-only telephone usage.

Some of the major points of consideration are set out below. Please note, however, that these “Rules and Regulations" and "Safety Precautions” sections do not constitute legal advice, and are intended merely for general information purposes. If you have specific questions, please contact your cellular/PCS carrier (System Operator).

License — If your home system is in the U.S., you do not require a separate license to operate your cellular/PCS telephone; obtaining a cellular/PCS telephone access number is sufficient to register you as a user. If your home system is in Canada, a separate license is

telephone

is a

required; your carrier will assist you in the licensing process. If you wish to use your cellular/PCS telephone on both sides of the border, please contact your cellular/PCS carrier (System Operator).

Equipment modifications — The U.S. Federal Communications Commission has type-approved the model of cellular/PCS telephone which you have purchased, and has allocated a specific frequency range for cellular/PCS service. No changes or adjustments are to be made to your cellular/PCS telephone.

The radio equipment shall be made available for inspection upon request by representatives of the FCC or licensees.

Denial of service — A cellular/PCS carrier may deny service temporarily or terminate service for violation of any government regulations or violation of its tariff.

Privacy — As a telephone user, you have come to assume a certain standard of privacy when you place or receive a telephone call via the traditional wireline systems. However, because cellular/PCS telephones effect calls, the same standard cannot always be assured. While it is unlawful for any unauthorized person to divulge or use any information obtained from intercepting or “listening in on” conversations intended for others, you should not assume that your conversation is completely secure. Commercially available scanning equipment can permit a third party to monitor the radio channels used for cellular/PCS telephone calls.

Interference — No person shall interfere with, or cause interference to, any radio communication or signal.

utilize radio transmissions to

Page 4

Safety precautions

IMPORTANT

For safe and efficient operation of your phone, observe these guidelines.

Your dual mode (analog/digital CDMA) hand-held portable cellular/PCS telephone uses both analog frequency modulation (FM) technology and digital Code Division Multiple Access (CDMA) technology. CDMA is a newer radio frequency (RF) technology than the FM technology that has been used for radio communications for decades.

Your dual mode portable cellular/PCS telephone is a radio transmitter and receiver. When the phone is ON, it receives and sends out radio frequency (RF) energy. The phone operates in the frequency range of 824 MHz to 894 MHz in analog mode, and 1851 MHz to 1989 MHz in digital CDMA mode. When you use your phone, the cellular/PCS system handling your call controls the mode of operation (analog or digital CDMA) and the power level at which your phone transmits. power is continuously transmitted at a level that can range from about 6 mW to about 600 mW. In the digital CDMA mode, the power is transmitted as a digitally coded waveform at a rate varying from 100 Hz to 800 Hz. The average power can range from about

0.01 µW to about 300 mW.

Exposure to radio frequency energy

Research on health effects from RF energy has focused for many years on FM radio technology. That research and studies regarding newer radio technologies, such as CDMA, have found no credible scientific evidence that adverse health effects result from the use of cellular/PCS telephones.

In the analog mode, the

The Institute of Electrical and Electronics Engineers (IEEE) in 1991, and The American National Standards Institute (ANSI) in 1992, updated the 1982 ANSI Standard for safety levels with respect to human exposure to RF energy. Over 120 scientists, engineers, and physicians from universities, government health agencies, and industry, reviewed the available research and developed this updated Standard. In March 1993, the U.S. Federal Communications Commission (FCC) proposed the adoption of this updated Standard.

The design of your phone complies with this updated Standard. Of course, if you want to limit RF exposure even further than the updated ANSI Standard, you may choose to control the duration of your calls and operate your phone in the most power efficient manner.

Efficient phone operation

For your phone to operate at the lowest power level consistent with satisfactory call quality, please observe the following guidelines:

Your phone has an extendable antenna; extend it fully whenever possible for maximum efficiency.

Hold the phone as you would any other telephone. While speaking directly into the mouthpiece, position the antenna up and over your shoulder.

Do not hold the antenna when the phone is in use. Holding the antenna affects call quality and may cause the phone to operate at a higher power level than needed.

Page 5

Antenna care and replacement

Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Replace a damaged antenna immediately. Take your phone to an authorized service center for repair.

Use only the supplied or approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, and violate FCC regulations.

Driving

Check the laws and regulations on the use of cellular/PCS telephones in the areas where you drive. Always obey them. Also, when using your phone while driving, please:

• pay full attention to driving;

• use hands-free operation, if available;

• pull off the road and park before making or answering a call, if driving conditions so require.

Electronic devices

Most modern electronic equipment is shielded from RF energy. However, RF energy from cellular/PCS telephones may affect some electronic equipment.

RF energy may affect improperly installed or inadequately shielded electronic operating and entertainment systems in motor vehicles. Check with the manufacturer or its representative to determine if these systems are adequately shielded from external RF energy. You should also check with the manufacturer of any equipment that has been added to your vehicle.

Medical devices

Consult the manufacturer of any personal medical devices (such as

pacemakers, hearing aids, etc.) to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn your phone OFF in health care facilities when regulations posted in the areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

Aircraft

Turn your phone OFF before boarding any aircraft.

• Use it on the ground only with crew permission.

• Do not use in the air.

To prevent possible interference with aircraft systems, U.S. Federal Aviation Administration (FAA) regulations require you to have permission from a crew member to use your phone while the plane is on the ground. To prevent interference with systems, FCC regulations prohibit using your phone while the plane is in the air.

aircraft communication

Children

Do not allow children to play with your phone. It is not a toy. Children could hurt themselves or others (by poking themselves or others in the eye with the antenna, for example). Children also could damage the phone or make calls that increase your telephone bills.

Blasting areas

To avoid interfering with blasting operations, turn your unit OFF when in a “blasting area” or in areas posted: “Turn off two-way radio.” Construction crews often use remote control RF devices to set off explosives.

Page 6

Potentially explosive atmospheres

Turn your phone OFF when in any area with a potentially explosive atmosphere. It is rare, but your phone or its accessories could generate sparks. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations; below deck on boats; fuel or chemical transfer or storage facilities; areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn off your vehicle’s engine.

Do not transport or store flammable gas, liquid, or explosives in the compartment of your vehicle which contains your phone or accessories.

In the United States, vehicles using liquefied petroleum gas (such as propane or butane) must comply with the National Fire Protection Standard (NFPA-58). For a copy of this standard, contact the National Fire Protection Association, One Batterymarch Park, Quincy, MA 02269, Attn: Publication Sales Division.

In Canada, vehicles using liquefied petroleum gas (such as propane or butane) must comply with the Canadian Gas Association (CAN/CGS-B149.2). For a copy of this standard, contact the Canadian Standards Association, 178 Rexdale Blvd., Etobicoke, ON M9W 1R3, Attn.: Standard Sales Department.

Page 7

Table of contents

Rules and regulations ................................................................ 3

Safety precautions ...................................................................... 4

Getting Started

Basic Operations

Quick Ways to Make Calls

Advanced Features

Additional Information

Unpacking your phone .............................................................. 8

Looking at your phone ............................................................ 10

Charging the battery pack ....................................................... 13

Turning the phone on ............................................................... 16

Using the Jog Dial™ navigator ............................................... 17

Making calls .............................................................................. 18

Receiving calls ........................................................................... 20

Storing phone numbers in the Phone Book .......................... 22

Calling from the Phone Book.................................................. 28

Searching the Phone Book ....................................................... 30

Calling from the Calls List....................................................... 33

Sending DTMF signals from the Phone Book ...................... 35

About the Features menu ........................................................ 36

Adjusting the volume .............................................................. 38

Checking and setting the timers ............................................. 42

Using the Directory .................................................................. 44

Miscellaneous extra features ................................................... 50

Setting security options ........................................................... 53

Setting display options ............................................................ 58

Adjusting network settings ..................................................... 62

Using the Short Messaging Service........................................ 67

Troubleshooting ........................................................................ 74

List of menu items .................................................................... 75

Specifications............................................................................. 77

Glossary ..................................................................................... 78

Index ........................................................................................... 81

Getting StartedQuick Ways

Basic

Operations

to Make Calls

Features

Advanced

Additional

Information

Page 8

Unpacking your phone

Carefully unpack your phone and check the contents using this list. If there is something missing, please contact your nearest Sony dealer.

Portable Dual Band QN-003BPLH Hi-Cap Li-Ion PCS Telephone (1) Battery Pack (1)

Hand Strap (1) QN-001AC AC Adapter (1)

Page 9

Attaching the hand strap

Getting Started

Page 10

Looking at your phone

!¡

SEND



1 4



GHI



ABC

JKL

TUV

OPER

END

PWRCLR

3 6 9

DEF

MNO

!™

!£

!¢

Page 11

For further information, refer to the page numbers indicated in parentheses ( ).

END

PWR

Telephone

1 Antenna (16)

2 Earpiece

3 Display (12)

SEND

button (18 to 20)

Press to make outgoing calls and to receive incoming calls.

5 Jog Dial™ navigator (17)

Push and turn for menu navigation and for changing settings on menus. In this manual, the indicates that you should push the Jog Dial™ navigator in towards the center of the phone.

6 (message) button (68)

Press to access messages.

CLR

(clear) button (17, 18, 36)

Press to clear the last or all entered digits on the display, or to exit the current mode of operation.

icon

9 Microphone

0 Battery pack release tab (13)

Slide up to remove the battery pack.

!¡ Battery pack (13)

!™

!£

button (17, 18, 20)

Press to end calls. Also cancels operations and returns the phone to standby mode.

(power) button (16)

Press to turn the phone on or off.

!¢ Connector (14)

Use to connect the phone to either the AC adapter, a cigarette lighter adapter, a desktop charger, or a hands-free car kit.

Getting Started

8 Number buttons, 0 to 9, and

/ buttons (18, 22, 29)

Use the number buttons to enter letters and numbers. Press and hold a number button, 0 to 9, for touch dialing. Use the to move the cursor to the right or left when you are entering letters.

/ buttons

Page 12

Display

The top row of the display contains icons that inform you of the current status of your phone. The bottom four rows of the display are for text such as phone numbers, names, and operational prompts. Each row displays a maximum of 12 characters.

1 2 3 4 5 6 7

888

1 Short character display

Shows settings such as the number of the currently displayed Features menu, as well as Phone Book and Calls List memory locations.

2 (in-use) / (out-of-service)

icon (16, 18, 20)

The in-use icon appears during a call. A slash through the in-use icon appears when no signal is received. You cannot make or receive calls when the out-of-service icon is visible.

3 (digital) icon

Appears when your phone is operating in digital (CDMA) mode.

4 (signal strength) icon (16)

Tells you the approximate strength of the signal being received.

5 (roam) icon (62)

Appears when you are roaming outside your home service area.

6 (message) icon (67)

Appears when you have new text or voice mail messages pending. The icon flashes if the new message is urgent.

7 (battery) icon (14, 15)

Shows the approximate amount of charge power remaining in the battery pack. Recharge the battery pack before it is fully discharged.

8 Character display

Prompts various actions, and then displays the results. It also shows phone numbers and names.

Page 13

Charging the battery pack

Charge the battery before using the phone. A new battery is not fully charged. To charge the battery, attach the battery pack to the handset, then connect the supplied AC adapter.

Attaching the battery pack

1 Hook the battery pack onto

the bottom of the phone 1, and ease the battery pack down 2.

2 Attach the battery pack by

pressing down firmly on the thumb indent.

To remove the battery pack

1 Push the battery pack release

tab upwards.

Getting Started

2 Lift up the top of the battery

pack 1, and pull it out 2.

Page 14

Charging the battery

Connect the AC adapter to the phone and the other end to a standard 120V AC outlet as illustrated below. The charging time is about 5 hours. You can charge the battery pack with the phone turned on, but charging will take longer.

to an AC outlet

display

to the connector on the phone (the thumb indent should face upwards)

When the power is turned on

The letters “CH” are shown in the upper left corner of the standby display, and pack is being charged.

When the battery pack is fully charged, the letters “FCH” appear instead, and

stops flashing.

flashes. This indicates that the battery

----SONY---12:34P 12/25 :Saved #s :Features

FCH

----SONY---12:34P 12/25 :Saved #s :Features

When the power is turned off

The message “Battery is Charging” is displayed, and flashes.

Battery is Charging

Power is OFF

When the battery pack is fully charged, the message “Charging is Complete” is displayed, and

Notes

• If you make or receive a call when the battery pack is not charged sufficiently, the call will be cut off. In that case, you will hear an alarm, indicating that the battery is low.

• You can turn on the phone without the battery pack, but you cannot make or receive a call, even if you connect the AC adapter to an AC outlet.

stops flashing.

Charging is Complete

Power is OFF

Page 15

Notes on charging

• When you charge the battery pack, avoid: – charging for long periods of time, since this reduces battery life. – charging in temperatures below 32°F (0°C) or over 104°F (40°C). – charging the battery in direct sunlight or in places with high humidity

(such as a bathroom).

• Do not use any battery pack other than the one specified in these instructions.

• It is normal for the battery pack to become warm during charging or after use.

• The supplied AC adapter is not intended to be serviced. In the event of a

malfunction, it should be replaced.

Notes on the battery pack

• Do not dispose of the battery pack in a fire or short-circuit it. Doing so may cause

the battery pack to leak or get hot, which could cause personal injury.

• Do not try to disassemble the battery pack.

Checking the battery

Battery duration

The battery lasts approximately as long as indicated in the following table.

CDMA mode Analog mode

In standby mode 60 hours 14 hours In use continuously 4 hours 2 hours

Getting Started

Battery condition

The battery icon indicates the battery level as follows (when the power is on):

Full

Note that the battery icon displays the approximate charge level and that the consumption may vary depending on conditions of use, such as ambient temperature, network coverage, and usage patterns.

n n n

n n

Empty

When the battery is empty

The battery icon flashes and a warning message is displayed. A beep sounds, indicating that the battery is low. Shortly thereafter, the phone turns off. Recharge the battery as soon as possible.

Page 16

Turning the phone on



PWRCLR

SEND

END

PWR

To use your phone, the power must be turned on. It is preferable to extend the antenna, since this maximizes signal strength and

Pull up

minimizes interference.

Extending the antenna

Hold the end of the antenna and pull up until fully extended.

To retract the antenna

Push the antenna down until it is fully retracted.

Turning the power on

Hold down

PWR

for about one second. A beep sounds and the

phone starts searching for a signal.

When the phone has found a service signal, the standby display appears. Now the phone is ready to use.

To check the signal strength

The signal strength icon indicates various levels of signal strength. It is best to make calls when the signal is strong, although calls can be made when the signal strength is weak.

Looking for

service.....

:Saved #s :Features

My Phone 12:34P 12/25 :Saved #s :Features

Strong Weak

If you are out of the service area

The out-of-service icon ( ) appears, and the phone searches for a service signal.

If a signal cannot be found, the phone enters power save mode. It will “wake up” automatically at intervals (based on carrier network settings) to search for a service signal.

Turning the power off

Hold down appears briefly, then the phone turns off.

PWR

for about one second. The following display

Looking for

service.....

:Saved #s :Features

No Service available. Now in power saving mode.

POWERING OFF

Page 17

Using the Jog Dial™ navigator

END

The Jog Dial™ navigator makes it easy to navigate from one menu to another.

Choosing a menu item

To choose a menu item, push the Jog Dial™ navigator. The flashing arrow ( ) on the display indicates the item you can select by pushing push again, you will go to the Sounds menu.

on the standby display, you will go to the Features menu. If you push

Display

SEND

(Jog Dial™

END

navigator)

CLR



PWRCLR

ABC3DEF

. As illustrated below, if you

Getting Started

My Phone 12:34P 12/25 :Saved #s :Features

F-1

FEATURES Sounds

/ /

Timers Directory

F11

SOUNDS Ringer Vol Mute/UnMute Keybeep Vol

As shown below, if you enter digits on the standby display, the word “Options” appears at the bottom of the display, preceded by

123-456-7890 :Options

OPTIONS Find Number Send Save

. Push to access the Options menu.

To go back

If you want to go back to the previous display, press the standby display, either press

END

or hold down

CLR

. If you want to return to

CLR

Scrolling through menu items

To scroll through menu items, turn the Jog Dial™ navigator when the icon appears. The up ( scrollable direction. For example, if you turn scroll through the submenu items, as follows:

F11

SOUNDS Ringer Vol Mute/UnMute Keybeep Vol

) and down ( ) arrows on the display indicate the available

within the Sounds menu, you will

F12

SOUNDS Ringer Vol

Mute/UnMute Keybeep Vol

F13

SOUNDS Mute/UnMute Keybeep Vol EarpieceVol

On the leftmost display,

is not shown. This indicates that you cannot scroll up.

Page 18

Making calls

SEND

END

You can call any number up to 32 digits from within a service area. The out-of-service icon ( indicates that you are outside the service area.

)

SEND

END

CLR

Number buttons

and /

In the following example, the phone number to be called is 123-456-7890.

1 Use the number buttons to enter the

number.

The following display appears. If you enter the wrong digit, press press display.

2 Press

The phone dials the number you have entered. The icon appears.

When the call is connected, the call timer appears and displays the elapsed call time.

CLR

to back up. To clear all entered digits,

END

or hold down

SEND

to dial.

CLR

to return to the standby

123-456-7890 :Options

Calling...

123-456-7890

Time: 0:01

PWRCLR



ABC3DEF



JKL6MNO

GHI



TUV

OPER

3 Press

END

to end the call when you are

finished.

The icon disappears, and the final elapsed call time flashes for 10 seconds.

The standby display automatically reappears.

123-456-7890

Time: 1:21

My Phone 12:34P 12/25 :Saved #s :Features

Page 19

Tips

• When dialing, you can insert a pause to attach a DTMF (Dual Tone Multiple Frequency) number to the number you are calling (see page 35 for a description of DTMF).

• If Auto-Hyphen is turned on, the phone number is hyphenated automatically as you enter the digits (see page 59).

• If Minute Alert is turned on, a beep sounds 10 seconds before every full minute throughout the call (see page 43).

• Enhanced voice privacy is indicated by the message “–P–” displayed in the upper left corner of the LCD (see page 64). This feature is carrier-dependent.

To adjust the earpiece volume during a call

Turn up to increase the volume. Turn

down to decrease the volume.

Tip

In addition, you can adjust the volume using the Sounds menu (see page 40).

To mute/unmute the microphone during a call

Push and hold .

Tip

In addition, you can mute the microphone using the Sounds menu (see page 38).

To redial the last number

On the standby display, press automatically.

SEND

. The number you dialed last is redialed

Basic

Operations

Page 20

Receiving calls

SEND

END

CLR

You can receive calls as long as the out-of-service icon ( that you are outside the service area.

When you receive a call, the ringer sounds and “Incoming Call” flashes.

If you turn off the ringer volume (see page 38), you will not hear the ringer sound. The message “–Ringer Off–” is displayed on the standby display.

) is not displayed. The icon indicates

Note

SEND



ABC3DEF



JKL6MNO

GHI



TUV



OPER

Incoming Call

END

PWRCLR

1 Press

When the call is connected, the call timer appears and

SEND

to answer the call.

Time: 0:01

displays the elapsed call time.

2 Press

END

to end the call when you are

finished.

The icon disappears and the final elapsed call time flashes for 10 seconds.

Time: 1:21

The standby display automatically reappears.

My Phone 12:34P 12/25 :Saved #s :Features

Tips

• Using the Jog Dial™ navigator, you can adjust the earpiece volume or mute the microphone during a call (see page 19).

• Enhanced voice privacy is indicated by the message “–P–” displayed in the upper left corner of the LCD (see page 64). This feature is carrier-dependent.

• If Any Key Answ is turned on, you can answer the call by pressing any button except (see page 52).

PWR

Page 21

If the caller has caller ID

The caller’s phone number appears on the display when you receive a call, if both the caller and the carrier support this feature.

If the caller has caller ID and the number matches a Phone Book entry, the name that you stored with the number (if any) is displayed also.

If you miss a call

If you miss an incoming call, a message appears similar to the one in the following display. To return to the standby display, either press caller’s number is stored in the Calls List (see page 33).

CLR

END

, or . If the caller had caller ID, the

Incoming Call From

123-456-7890

Incoming Call From SONY 123-456-7890

You have missed 15 calls. :OK

Basic

Operations

Page 22

Storing phone numbers in the Phone Book



ABC3DEF

JKL6MNO

TUV

OPER

GHI

PQ RS

PWRCLR

SEND

END

CLR

Your phone features a built-in Phone Book memory, in which you can store up to 99 (01–99) phone numbers with names. You can dial stored numbers quickly by recalling them from the Phone Book (see page 28)

Each phone number can contain up to 32 digits, and each name up to 12 characters. This section shows how to store, edit, and erase Phone Book

Number

buttons,

numbers quickly.

In the following example, the phone number to be stored is 123-456-7890, and the name is SONY.

On the standby display, use the number buttons to enter the number.

The number appears on the display. In addition, you can store hyphens, pauses, and links

123-456-7890 :Options

with your Phone Book entries (see page 24).

2 Push .

The Options menu appears.

OPTIONS Find Number Send Save

3 Turn to select “Save,” then push .

The following display appears, prompting you for a name to accompany the number.

Enter a Name

:Save

4 Use the number buttons to enter the name.

If you press the same button in quick succession, the letter you just entered changes. (See the “Alphanumeric table” on page 23.) For the next entry, wait until the cursor moves one step to the right or use / or

to move the cursor and insert spaces between characters. If you enter the wrong character, press to clear the character highlighted by the cursor.

CLR

Enter a Name S

:Save

Page 23

To enter “SONY”

Press Press

four times to enter an “S.”



MNO

three times to enter an “O.” Wait until the cursor

moves one step to the right for the next entry.

MNO

Press Press

twice to enter an “N.”

three times to enter a “Y.”

5 When you are finished, push to store

the phone number and name.

A display appears similar to the following. It indicates the first available memory location.

Enter a Name SONY

:Save

Save in location 15? :Save :Other Loc

6 Push to store the new number in the

first available memory location.

If you want to store it in another location, turn to select the desired location or enter the location number, then push . A confirmation message appears,

L15

SONY has been stored in location 15.

followed by the status of the Phone Book.

PHONE BOOK LOCATIONS: 21 used 78 empty

Tip

In addition, you can use the Directory menu to store Phone Book numbers (see page 44).

Alphanumeric table

Each time you press a number button, the letters/numbers are cycled as follows:

Button Sequence

8 9

OPER

ABC

DEF

GHI

JKL

MNO

TUV



PQ RS



–“.‘,&():1 ABCabc2 DEFdef3 GHIghi4 JKLjkl5 MNOmno6 PQRSpqrs7 TUVtuv8 WXYZwxyz9 0

Quick Ways

to Make Calls

Page 24

To enter a hyphen, pause, or link

In addition to digits, you can insert hyphens, pauses, and links into the phone number of a Phone Book entry. Hyphens: Turn off the phone’s autohyphenation feature (see page 59) when you want to enter a hyphen manually, e.g., when you store a foreign number. Pauses: When you want to send DTMF signals (see page 35) for electronic banking, etc., inserting a pause after the first string of digits makes the phone pause before dialing the second string. This ensures your counterpart is ready to accept that string. Links: You can join two or more Phone Book entries (e.g., a doctor’s phone number and your medical record number). Once you have specified the first entry, you insert a link. Then you specify the second number by entering its memory location number.

1 While entering digits, push .

The Options menu appears.

123 :Options

2 Turn to select the information you

want to enter and push

After inserting a hyphen, pause, or link, the display returns to number entry mode.

To enter Select The display shows

a hyphen Enter Hyphen – a pause Enter Pause P a link Enter Link L

OPTIONS Find Number Send Save

If the Phone Book is full

If no memory locations are available, the following display appears.

Memory Full! No more Phone Book entries open

After entering a name, the following display appears, prompting you to specify a memory slot to overwrite. To cancel, hold down

CLR

Save in location _? Memory Full, Enter loc. #

Editing stored information

You can edit the name, phone number, and memory location of specific entries stored in the Phone Book.

1 On the standby display, turn once.

The Saved #s display appears.

SAVED #S :Calls List :Phone Book :Find Name

Page 25

2 Turn down to select “Phone Book.”

The first entry in the Phone Book appears.

L01

Office

123-456-7890 :Options

3 Turn to select the entry that contains

the information you want to edit.

The contents of the selected memory location are displayed.

4 Push .

The Options menu appears.

5 Turn to select “Edit,” then push .

The Edit menu appears.

6 Turn to select the item you want to

edit, then push

The stored information that corresponds to the selected item appears.

To change Select

the name Name the phone number Phone # the memory location Location #

L15

SONY

123-456-7890 :Options

L15

OPTIONS Erase Send Edit

L15

EDIT THE Name Phone # Location #

L15

Edit Number

123-456-7890 :Options

Quick Ways

to Make Calls

7 Enter the new information.

Enter new information the same way you stored original information (see page 22). The old information is overwritten.

8 When you are finished, push .

The Options menu reappears when you edit the phone number. New information is saved immediately when you edit the name or memory location.

L15

Edit Number

123-456-7890 :Options

L15

OPTIONS Enter Pause Save Enter Link

Page 26

9 Turn to select “Save,” then push .

A message appears, similar to the one in the following display, confirming that your changes have been saved.

L15

SONY has been saved in location 15.

Tip

In addition, you can use the Directory menu to edit Phone Book numbers (see page 46).

Erasing a phone number

You can erase stored Phone Book entries. If the selected entry is restricted, you must enter the four-digit lock code before you can erase it (see page 54).

1 On the standby display, turn down

twice to select “Phone Book.”

The first Phone Book entry is displayed.

2 Turn to find the Phone Book entry you

want to erase.

The contents of the selected memory location are displayed.

L01

Office

123-456-7890 :Options

L15

SONY

123-456-7890 :Options

3 Push .

The Options menu appears.

4 Turn to select “Erase,” then push .

A message appears, similar to the one in the following display, confirming the erasure.

5 Push again.

The selected entry is erased. After a few seconds, the standby display reappears.

Tips

• In addition, you can use the Directory menu to erase one Phone Book entry at a time (see page 45).

• Use the Security menu to erase all Phone Book entries at once (see page 56).

OPTIONS Erase Send Edit

L15

Erase Phone Book Location 15? :Erase

L15

-erased-

Page 27

Restricting Phone Book entries

You can restrict individual Phone Book entries or the entire Phone Book, so that access can be gained only by entering a lock code (see page 54). The phone numbers of restricted entries will not be displayed.

1 Select the Phone Book entry that you want

to restrict, then push

The Options menu appears.

2 Turn to select “Restrict,” then push .

The following display appears.

3 Push to restrict the selected entry.

Now the selected entry is restricted. After a few seconds, the standby display reappears.

To unrestrict an entry

1 Select the Phone Book entry that you want

to unrestrict.

The following display indicates a restricted entry.

2 Push .

The Options menu appears.

3 Turn to select “Restrict,” then push .

The following display appears, prompting you to enter the lock code.

Use the number buttons to enter the lock code.

Now the selected entry is unrestricted. After a few seconds, the standby display reappears.

L15

OPTIONS Erase Send Edit

L15

My Phone

123-456-7890 :Restrict

L15

Entry is now Restricted

L15

SONY <number is restricted> :Options

L15

OPTIONS Erase Send Edit

L15

Restricted phone book entry. CODE: ----

L15

Entry is now UnRestricted

Quick Ways

to Make Calls

Tip

Also, you can use the Security menu to restrict/unrestrict Phone Book entries (see page 54).

Page 28

Calling from the Phone Book



ABC3DEF

JKL6MNO

TUV

OPER

GHI

PQ RS

PWRCLR

SEND

END

SEND

You can dial frequently used numbers quickly from the Phone Book using the Jog Dial™ navigator. Alternatively, by using speed/touch dialing, you only need to press a few buttons to dial these numbers.

Number buttons

and /

1 On the standby display, turn once.

The Saved #s display appears.

SAVED #S :Calls List :Phone Book :Find Name

2 Turn down to select “Phone Book.”

The first entry in the Phone Book appears.

3 Turn to select the desired Phone Book

entry.

The contents of the selected entry are displayed.

4 Push .

The Options menu appears.

L01

Office

123-456-7890 :Options

L15

SONY

123-456-7890 :Options

L15

OPTIONS Erase Send Edit

5 Push again to make a call.

The phone dials the number stored in the selected Phone Book entry. The icon appears.

Tips

• You can search for a phone number by name or memory location (see pages 30 and 31).

• Whenever the phone number is displayed, you can call it by pushing or

• If the phone number of a selected Phone Book entry is too long to fit on the screen, you can still view the overflow digits by selecting “View Number” on the Options menu.

Calling... SONY

123-456-7890

SEND

Page 29

To release a pause or link during a call

If a Phone Book entry contains pauses or links, only the digits up to the first pause or link are displayed. To dial the rest of the selected entry (and release the pause or link), push

Time: 0:01 SONY 123L :Release

Speed dialing

To dial quickly, you can enter the Phone Book memory location numbers. The phone calls the number stored in the corresponding location.

1 Use the number buttons to enter the

memory location number.

15 :Options

2 Press

The name and phone number of the memory location appear. The phone dials the number stored in the entered memory location.

SEND

to dial the number.

Calling... SONY

123-456-7890

Touch dialing

You can dial a phone number stored in the Phone Book without pressing Before using this feature, make sure that Touch Dial on the Extras menu is set to “on” (see page 50).

SEND

1 Use the number buttons to enter the

memory location number, and hold down the last digit of the memory location number for about two seconds.

The name and phone number of the memory location appear. The phone dials the number stored in the entered memory location.

Calling... SONY

123-456-7890

Quick Ways

to Make Calls

Page 30

Searching the Phone Book

To locate a desired Phone Book entry, you can search by name, phone number, or memory location. You can search the Phone Book either alphabetically or for a string of characters.

Searching alphabetically

When you enter only one character, the phone lists all entries that begin with the entered character.

1 From the standby display, turn once.

The Saved #s display appears.

SEND



ABC3DEF



JKL6MNO

GHI



TUV



OPER

SAVED #S :Calls List :Phone Book :Find Name

END

PWRCLR

2 Push .

The Search display appears.

SEARCH FOR

(Enter Name) :Find

3 Enter only the first letter of the name you

want to find.

4 Push .

All Phone Book entries that begin with the entered character are displayed alphabetically.

SEARCH FOR S (Enter Name) :Find

L15

SONY

123-456-7890 :Options

5 Turn to view the next entry.

Tip

In addition, you can use the Directory menu to search the Phone Book by name (see page 47).

Page 31

Searching for a string of characters

When you enter two or more characters, the phone searches for entries that contain those characters. The results are displayed starting from the lowest memory location number.

1 From the standby display, turn once.

The Saved #s display appears.

SAVED #S :Calls List :Phone Book :Find Name

2 Push .

The Search display appears.

SEARCH FOR

(Enter Name) :Find

3 Enter at least two characters.

SEARCH FOR NY (Enter Name) :Find

Quick Ways

to Make Calls

4 Push .

The entries containing the selected string are displayed starting from the lowest memory location number.

L15

SONY

123-456-7890 :Options

5 Turn to view the next entry in the

search string.

Searching by memory location

The phone searches for a memory location that matches the entered digit(s), and displays a list of options.

On the standby display, enter location (a maximum of two digits).

ush .

The Options menu appears.

the memory

15 :Options

OPTIONS Recall Loc# Send Save

Page 32

3 Turn up to select “Recall Loc#,” then

push

The Phone Book entry stored in the selected memory location is displayed.

L15

SONY

123-456-7890 :Options

If the entered location is empty, a message appears similar to the one in the following display. After a few seconds, the standby display reappears.

Tip

In addition, you can use the Directory menu to search the Phone Book by memory location (see page 48).

L15

Phone Book storage location 15 is empty.

Searching for a phone number

The phone lists all entries that contain the entered digit(s).

On the standby display, enter at least the first three digits of the phone number you want to find.

Push .

The Options menu appears.

Turn up to select “Find Number,” then push

The Phone Book lists and displays all entries matching the entered digits. Depending on the Sort Book setting (see page 60), the entries are listed either alphabetically or by memory location.

456 :Options

OPTIONS Find Number Send Save

L15

SONY

123-456-7890 :Options

Turn up to view the next entry that contains the search string.

If a matching Phone Book entry is not found, a message similar to the following is displayed. After a few seconds, the standby display reappears.

L01

"645" wasn't found in any Phone Book entries

Page 33

Calling from the Calls List



ABC3DEF

JKL6MNO

TUV

OPER

GHI

PQ RS

PWRCLR

SEND

END

Information on the ten most recent outgoing calls, incoming calls, scratch pad entries, and missed calls are stored in the phone’s Calls List. If you call the same number twice in a row, only the most recent call is stored in the Calls List.

Number buttons

and /

1 On the standby display, turn once.

The Saved #s display appears.

2 Turn up to select “Calls List.”

Information on the most recent call appears. “Calls List is empty” is displayed if there are no entries.

3 Turn to select the entry you want.

The contents of the selected entry are displayed.

SEND

SAVED #S :Calls List :Phone Book :Find Name

C01

CALL FROM Office 123-456-7890 :Options

C06

CALL TO SONY 123-456-7890 :Options

Quick Ways

to Make Calls

4 Push .

The Options menu appears.

5 Push again to call the selected entry.

The phone dials the selected Calls List entry. The icon appears.

C06

OPTIONS Save Send Duration

C06

Calling... SONY

123-456-7890

Page 34

Tips

• In addition, you can dial by pressing

• If the selected entry contains a pause or a link, only the digits up to the pause or link are dialed. To release pauses and links, see page 29.

• In addition, you can use the Directory menu to view the Calls List (see page 49).

SEND

after selecting the entry in step 3 on page 33.

To view detailed information of Calls List entries

In addition, you can view the digits of a phone number that do not fit on the screen, the duration of the call, or the time and date of the call by using the Options menu (see step 4 on page 33).

To view Select

digits that do not fit on the screen View Number the duration of the call Duration the time and date of the call Time/Date

To save the number to the Phone Book

Select “Save” from the Options menu (step 4 on page 33) by pushing the Jog Dial™ navigator.

Page 35

Sending DTMF signals from the Phone Book



ABC3DEF

JKL6MNO

TUV

OPER

GHI

PQ RS

PWRCLR

SEND

END

You can send DTMF (Dual Tone Multiple Frequency) signals to access electronic services (such as telephone banking) when dialing numbers from the Phone Book. Dual Tone Multiple Frequency is also known as “touchtone.” A tone is generated when you press a telephone button (number, to access answering machines, pagers, telephone banking services, data services, and other electronic services.

, or #). It can be used

Number buttons

and /

1 During a call, search for the Phone Book

entry that contains the numbers you want to send.

The selected entry is displayed. Use the Directory

L15

SONY

123-456-7890 :Options

menu to search for the Phone Book entry (see pages 47 and 48).

2 Push .

The Options menu appears.

L15

OPTIONS Erase Send Edit

3 Turn to select “Number Tone,” then

L01

Tones can be played only during a call.

push

A DTMF signal, containing the entered digits, is sent in a burst.

If you try to send a DTMF signal in standby mode

The following message is displayed. You can send a DTMF signal only during a call.

Notes

• To enter and send numbers one by one during a call, use the number buttons to send the DTMF number.

• To change the length of the DTMF transmission, see “Setting the keybeep length” on page 41.

Quick Ways

to Make Calls

Page 36

END

About the Features menu



ABC3DEF

JKL6MNO

TUV

OPER

GHI

PQ RS

PWRCLR

SEND

END

CLR

You can use the Features menu to activate the special features of your phone.

Number buttons

and /

Menu structure

The phone uses a hierarchical on-screen menu structure for setting and editing parameters. For a comprehensive list of submenus and corresponding settings, see “List of menu items” on pages 75 and 76.

My Phone 12:34P 12/25 :Saved #s :Features

F-1

FEATURES Sounds

/ /

Timers Directory

F11

SOUNDS Ringer Vol Mute/UnMute Keybeep Vol

Standby display Main (Features) menu Submenu

Viewing and selecting menu options

The Jog Dial™ navigator makes it easy to navigate the phone’s menus. The procedure to view and select menu options is common to most of the Features menus (see page 75). These menus are accessible during a call also. The following example shows how to set the backlight.

1 On the standby display, push to select

“Features.”

If the standby display is not shown, press down

CLR

, then push to display the Features menu. The arrow and the menu number flash, indicating which menu will be selected by pushing (in this case the Sounds menu [F–1]).

or hold

F-1

FEATURES Sounds Timers Directory

Page 37

2 Turn to select “Display,” then push .

The Display menu appears. The arrow and the last digit of the submenu number flash, indicating which submenu will be selected by pushing (in this case the Banner menu [F61]).

Turn to select “Backlight,” then push .

The Backlight menu appears. The current setting is indicated by a check mark (✓) and is displayed in capital letters. (See page 59 for an additional description on setting the backlight.)

F61

DISPLAY Banner Backlight Auto-Hyphen

F62

BACKLIGHT FOR 7 SECS :Choices :To Set

4 Turn to select the setting.

The available options appear in a cyclic manner as you turn .

F62

BACKLIGHT off :Choices :To Set

5 Push to enter the new setting.

The standby display reappears.

To exit from the Features menu

Press

END

or hold down

CLR

to return to the standby display.

To return to the previous display

CLR

Press

. To go back further, press

Notes

• If you reach the last menu item and try to turn further, a beep indicates that you have reached the end of the menu. To view other menu items, turn in the opposite direction.

• The standby display automatically reappears after 30 seconds of inactivity.

Tip

Each menu item can be accessed quickly from the standby display by pushing , and then pushing the number of the menu item. The item number then appears in the upper left corner of the display in step 3. For example, you can access the backlight setting by pushing followed by

MNO

and

ABC

CLR

again.

My Phone 12:34P 12/25 :Saved #s :Features

Features

Advanced

Page 38

Adjusting the volume

You can adjust the volume of the ringer, keybeep, and earpiece on the Sounds menu. In addition, you can select the type of sounds heard when the phone rings and when you press buttons. (See page 36 for instructions on how to reach the Sounds menu.)

F11

SOUNDS Ringer Vol Mute/UnMute Keybeep Vol

Sounds menu

Adjusting the ringer volume [F11]

1 Push to select “Ringer Vol.” from the

Sounds menu.

The Ringer Vol. menu appears.

2 Turn up to raise the ringer volume,

and down to lower it.

You can select from five ringer volume settings: “off,” “low,” “med.” (medium), “high,” and “escalate.”

F11

RINGER VOL. HIGH :Choices :To Set

F11

RINGER VOL. med. :Choices :To Set

3 Push to enter the new setting.

The standby display reappears.

If you turn off the ringer volume

The message “–Ringer Off–” is displayed at the top of the screen when the standby display appears.

Tip

If you set the ringer volume to “escalate,” the telephone rings twice at a low volume, then once at medium volume, and thereafter at a high volume.

-Ringer Off12:34P 12/25 :Saved #s :Features

Muting/unmuting the microphone [F12]

You can mute/unmute the phone during a call directly, without using the Sounds menu, by pushing and holding

In addition, you can mute/unmute the microphone during a call using the Sounds menu. This feature is disabled in standby mode.

1 During a call, push to select “Sounds”

from the Features menu.

The Sounds menu appears.

F12

SOUNDS Ringer Vol Mute/UnMute Keybeep Vol

Page 39

2 Push to select “Mute/UnMute.”

The following display appears. Now the microphone is muted.

MUTED: 1:21

Hold down to (un)mute

3 To unmute the microphone, push and hold

for one second.

The Features menu appears for a moment and the microphone is now unmuted.

F-1

FEATURES Sounds Timers Directory

Adjusting the keybeep volume [F13]

You can adjust the volume of the beep that sounds when you press a button.

1 Turn to select “Keybeep Vol” from the

Sounds menu, then push

The Keybeep Vol menu appears.

2 Turn up to raise the keybeep volume,

and down to lower it.

You can select from four keybeep volume settings: “off,” “low,” “med.” (medium), and “high.”

F13

KEYBEEP VOL HIGH :Choices :To Set

F13

KEYBEEP VOL low :Choices :To Set

3 Push to enter the new setting.

The standby display reappears.

Features

Advanced

Page 40

Adjusting the earpiece volume [F14]

You can adjust the earpiece volume during a call by turning . In addition, you can adjust the speaker volume as follows:

1 Turn to select “Earpiece Vol” from the

Sounds menu, then push

The Earpiece Vol menu appears.

2 Turn up to raise the earpiece volume,

and down to lower it.

You can select from seven earpiece volume settings, from “1” to “7.” A higher number indicates higher volume.

3 Push to enter the new setting.

The standby display reappears.

Setting the ringer type [F15]

You can set the type of beep that sounds for an incoming call.

1 Turn to select “Ringer Type” from the

Sounds menu, then push

The Ringer Type menu appears.

2 Turn to select the ringer type.

You can select from five different ringer settings. The ringer sounds every time you turn .

F14

EARPIECE VOL 7 :Choices To Set

F14

EARPIECE VOL 4 :Choices :To Set

F15

RINGER TYPE STANDARD :Choices :To Set

F15

RINGER TYPE option 2 :Choices :To Set

3 Push to enter the new setting.

The standby display reappears.

Page 41

Setting the keybeep type [F16]

You can set the beep that sounds when you press a button to either a tone or a click. Tones sound similar to DTMF tones, and clicks are indicated by single beeps.

1 Turn to select “Key Sound” from the

Sounds menu, then push

The Key Sound menu appears.

2 Turn to select the keybeep type.

You can select “tones” or “clicks.”

F16

KEY SOUND TONES :Choices :To Set

F16

KEY SOUND clicks :Choices :To Set

3 Push to enter the new setting.

The standby display reappears.

Note

DTMF tones are sent to the other party during a call even if you set the keybeep type to “clicks.”

Setting the keybeep length [F17]

You can set the length of the beep that sounds when you press a button. This setting affects both the keybeep feedback and DTMF transmission tones. The phone sends a short DTMF burst (default) or plays every tone of the DTMF signal as long as the key is held down.

1 Turn to select “Beep Length” from the

Sounds menu, then push

The Beep Length menu appears.

F17

BEEP LENGTH STANDARD :Choices :To Set

Features

Advanced

2 Turn to select the keybeep length.

You can select “standard” or “long.”

3 Push to enter the new setting.

The standby display reappears.

F17

BEEP LENGTH long :Choices :To Set

Page 42

Checking and setting the timers

You can check call durations on the Timers menu. In addition, you can set the phone to alert you every minute of a call, and make the phone turn itself off automatically.

F21

TIMERS All Calls RecentCalls MinuteAlert

Timers menu

Checking the duration of all calls [F21]

You can view the total duration of all calls. This information cannot be reset.

1 Turn to select “All Calls” from the

Timers menu, then push

The All Calls display appears.

F21

ALL CALLS 150m58s 90 calls :Done

2 Push to go back to the standby display.

Checking and resetting the duration of recent calls [F22]

You can view the total duration of the most recent calls.

1 Turn to select “Recent Calls” from the

Timers menu, then push

The Recent Calls display appears.

F22

RECENT CALLS 45m30s 20 calls 1:To Reset

2 Press



to reset, or hold down

CLR

back to the standby display.

If you choose to reset, the counter of recent calls and the corresponding durations are reset.

to go

F22

-reset-

Page 43

Setting the minute alert [F23]

You can set the phone to alert you ten seconds before every full minute.

1 Turn to select “Minute Alert” from the

Timers menu, then push

The Minute Alert menu appears.

2 Turn to select “on” or “off.”

F23F

MINUTE ALERT OFF :Choices :To Set

F23F

MINUTE ALERT on :Choices :To Set

3 Push to enter the new setting.

The standby display reappears.

Setting the phone to automatically turn off [F24]

You can set the phone to automatically turn itself off after a specified duration.

1 Turn to select “Auto-Off” from the

Timers menu, then push

The Auto-Off menu appears.

2 Turn to select the duration before the

phone powers off automatically.

You can select from five settings: “never,” “in 3 hours,” “in 2 hours,” “in 1 hour,” and “in 30 mins.” If you select “never,” the phone does not turn itself off automatically.

F24F

AUTO-OFF NEVER :Choices :To Set

F24F

AUTO-OFF in 30 mins :Choices :To Set

Features

Advanced

3 Push to enter the new setting.

If you set the phone to power off in 30 minutes, for example, the following display appears.

Notes

• If you press any button or operate the Jog Dial™ navigator, the timer is reset and the countdown starts over.

• The phone does not turn itself off automatically during a call.

• If the Auto-Off timer is set, the phone turns off after a user-specified duration and the countdown “Off:xx:xx:xx” is displayed.

• Once the phone turns off, the setting will revert to “never.”

F24F

Phone will turn off in 30 minutes.

Page 44

Using the Directory

You can use the Directory menu to check your phone number, as well as store, erase, and edit phone numbers and names in the Phone Book. Also, you can use this menu to view the Calls List.

F31

DIRECTORY My Number Save Erase

Directory menu

Checking your phone number [F31]

1 Push to select “My Number” from the

Directory menu.

The My Phone # display appears, showing your phone’s number.

F31

MY PHONE #

123-456-7890 :Done

2 Push to exit this feature.

The standby display reappears.

Storing phone numbers [F32]

For quick and easy dialing, the Phone Book allows you to store up to 99 phone numbers.

1 Turn to select “Save” from the Directory

menu, then push

The following display appears.

F32

Enter number to save and then for next step.

2 Use the number buttons to enter the

phone number, then push

The Options menu appears. (See the “Alphanumeric table” on page 23.)

3 Turn to select “Save,” then push .

The following display appears, prompting you for a name to accompany the number.

4 Use the number buttons to enter the name.

Use / to move the cursor or to insert spaces between characters. If you enter the wrong character,

CLR

press cursor. (See the “Alphanumeric table” on page 23.)

to clear the character highlighted by the

OPTIONS Enter Pause Save Enter Link

Enter a Name

:Save

Enter a Name SONY

:Save

Page 45

5 When you are finished, push to store

the phone number and name.

A display similar to the following appears.

Save in location 15? :Save :Other Loc

6 Push to store the new number in the

first available memory location.

If you want to store it in another location, turn to select the desired location, then push . A confirmation message appears, followed by the

L15

SONY has been saved in location 15.

status of the Phone Book.

PHONE BOOK LOCATIONS: 21 used 78 empty

Tip

In addition, you can use the Options menu to store Phone Book numbers (see page 22).

Erasing a phone number [F33]

You can erase stored Phone Book entries. If the selected entry is restricted, you must enter the four-digit lock code to erase it (see page 54).

1 Turn to select “Erase” from the

Directory menu, then push

The following display appears, prompting you for the Phone Book entry to be erased.

2 Turn to select the entry you want to

erase, then push

A display similar to the following appears, prompting you to confirm that the selected Phone Book entry should be erased. In addition, you can use the number buttons to select the entry to be erased.

F33

to find entry to erase then to select.

L15

Erase Phone Book Location 15? :Erase

Features

Advanced

3 Push again.

The selected entry is erased. After a few seconds, the standby display reappears.

Tips

• Also, you can use the Options menu to erase one Phone Book entry at a time (see page 26).

• Use the Security menu to erase all Phone Book entries at once (see page 56).

L15

-erased-

Page 46

Editing stored information [F34]

You can edit the name, phone number, and memory location of specific entries stored in the Phone Book. If the selected entry is restricted, you must enter the fourdigit lock code to edit it (see page 54).

1 Turn to select “Edit” from the Directory

menu, then push

The following display appears, prompting you for the Phone Book entry to be edited.

2 Turn to select the entry that contains

the information you want to edit.

In addition, you can use the number buttons to select the entry to be edited.

A display similar to the following appears, prompting you to confirm that the selected Phone Book entry should be edited.

3 Push again.

The Edit menu appears.

4 Turn to select the item you want to

change, then push

You can change the name, phone number, or memory location by selecting “Name,” “Phone #,” or “Location #,” respectively. The stored information that corresponds to the selected item appears.

F34

to find entry to edit then to select

L15

My Phone

123-456-7890 :Edit

L15

Edit PhBook Location 15? SONY :Edit

L15

EDIT THE Name Phone # Location #

5 Enter the new information.

The old information is overwritten.

6 When you are finished, push .

A display similar to the following appears, confirming that your changes have been saved.

Tip

In addition, you can use the Options menu to edit Phone Book entries (see page 25).

L15

Edit Number

123-456-7890 :Options

L15

SONY has been saved in location 15.

Page 47

Searching the Phone Book by name [F35]

You can find name entries in the Phone Book by searching alphabetically or for a string of characters.

Tip

In addition, you can use the Options menu to search the Phone Book by names (see pages 30 and 31).

To search alphabetically

When you enter only one character, the phone lists all entries starting from the ones that begin with the entered character.

1 Turn to select “Find Name” from the

Directory menu, then push

The Search display appears, prompting you for a search string.

Enter only the first letter of the name you want to find.

3 Push .

All Phone Book entries are displayed alphabetically, starting from the ones that begin with the entered character.

4 Turn to view the next entry.

F35

SEARCH FOR

(Enter Name) :Find

F35

SEARCH FOR S (Enter Name) :Find

L15

SONY

123-456-7890 :Options

Features

Advanced

Page 48

To search for a string of characters

When you enter two or more characters, the phone searches for entries that contain the entered string. The results are displayed starting from the lowest memory location number.

1 Turn to select “Find Name” from the

Directory menu, then push

The Search display appears, prompting you for a search string.

2 Enter at least two characters.

3 Push .

The entries containing the selected string are displayed starting from the lowest memory location number.

F35

SEARCH FOR

(Enter Name) :Find

F35

SEARCH FOR NY (Enter Name) :Find

L15

SONY

123-456-7890 :Options

4 Turn to view the next entry.

Searching the Phone Book by memory location [F36]

You can find memory locations easily.

1 Turn to select “Phone Book” from the

Directory menu, then push

The following display appears, prompting you for a search string.

F36

for all book entries or enter the location #.

2 Use the number buttons to enter the

memory location number.

The Phone Book entry that matches the search string is displayed.

If the selected entry is empty, the display shows the message “Phone Book storage location XX is empty.” After a few seconds, the standby display reappears.

L15

SONY

123-456-7890 :Options

L15

Phone Book storage location 15 is empty.

Page 49

Tips

• In addition, you can use the Options menu to find Phone Book memory locations (see page 31).

• In addition, you can turn to scroll through the entire Phone Book instead of entering the memory location number in step 2.

Viewing the Calls List [F37]

You can view Calls List entries easily.

1 Turn to select “Calls List” from the

Directory menu, then push

The following display appears, allowing you to view the Calls List. If the Calls List is empty, the display shows the message “Calls List is empty.”

2 Turn to view the Calls List entries.

The most recent entry is displayed first. To view the rest of the ten most recent entries, turn .

Tip

In addition, you can view the Calls List from the standby display (see page 33).

To place a call

SEND

Press Options menu, then select “Send” and push

in step 2. In addition, you can push to go to the

F37

for calls list. Then to get each call's time

C06

CALL TO SONY 123-456-7890 :Options

C06

Calling... SONY

123-456-7890

Features

Advanced

Page 50

Miscellaneous extra features

On the Extras menu, you can set the phone to enable touch dialing, redial automatically, and answer incoming calls automatically or at the press of any button. Also, you can use this menu to lock the keypad and to jot down phone numbers.

Preventing accidental operation [F41]

F41

EXTRAS Key Guard Touch Dial Auto-Retry

Extras menu

You can lock the keypad by pushing and holding from the standby display. Locking the keypad offers low-level security. For example, it disables accidental dialing when you keep the phone in your pocket.

1 Turn to select “Key Guard” from the

Extras menu, then push

The following message appears.

After a few seconds, the standby display reappears. The keypad lock icon ( ) and the text “Keyguard On” indicates that the keypad is locked.

F41

Keypad is now guarded. Press "123" to unlock

My Phone 12:34P 12/25

Keyguard On

To unlock the keypad

Press

ABC



and

DEF

in quick succession.

To answer an incoming call when the keypad is locked

Just press

SEND

. You do not need to unlock the keypad.

Tips

• You can lock the keypad even when the phone itself is locked (see page 53).

• The backlight and keybeeps are turned off when the keypad is locked.

Activating touch dialing [F42]

If you want to use the touch dialing feature (see page 29), set to “on.”

1 Turn to select “Touch Dial” from the

Extras menu, then push

The Touch Dial menu appears.

2 Turn to select “on” or “off.”

3 Push to enter the new setting.

The standby display reappears.

F42

TOUCH DIAL ON :Choices :To Set

F42

TOUCH DIAL off Choices :To Set

Page 51

Setting the phone to redial automatically [F43]

You can set the interval for redialing. If the attempt to dial is not successful, the phone tries to redial it up to five times.

1 Turn to select “Auto-Retry” from the

Extras menu, then push

The Auto-Retry menu appears.

2 Turn to select the interval.

You can select “off,” “on 60 secs,” “on 30 secs,” or “on 10 secs.” If you select “off,” the phone does not try to redial automatically.

F43

AUTO-RETRY OFF :Choices :To Set

F43

AUTO-RETRY on 30 secs :Choices :To Set

3 Push to enter the new setting.

The standby display reappears.

Setting the phone to answer automatically [F44]

You can set the phone to answer calls automatically. If you turn auto-answering on, the phone answers incoming calls on the second ring when the phone is used in conjunction with a Sony Hands-Free Car Kit.

1 Turn to select “Auto-Answer” from the

Extras menu, then push

The Auto-Answer menu appears.

F44

AUTO-ANSWER OFF :Choices :To Set

Features

Advanced

2 Turn to select “on” or “off.”

3 Push to enter the new setting.

The standby display reappears.

The message “–AutoAnswer–” is displayed on the standby display when you select “on” and the phone is in the hands-free car kit.

F44

AUTO-ANSWER on :Choices :To Set

My Phone

-AutoAnswer :Saved #s :Features

Page 52

Setting all buttons to answer incoming calls [F45]

You can have all buttons (except on.

PWR

) answer incoming calls by turning this feature

1 Turn to select “Any Key Answ” from

the Extras menu, then push

The Any Key Answ menu appears.

2 Turn to select “on” or “off.”

F45

ANY KEY ANSW

:Choices :To Set

F45

ANY KEY ANSW

:Choices :To Set

off

3 Push to enter the new setting.

The standby display reappears.

Using the scratch pad [F46]

Your phone has a scratch pad feature, which is useful for writing down phone numbers temporarily. The phone does not send DTMF tones when you enter digits to the scratch pad.

1 Turn to select “Scratch Pad” from the

Extras menu, then push

The Scratch Pad display appears, prompting you to enter a phone number.

2 Use the number buttons to enter the digits.

F46

SCRATCH PAD (enter number) :Options

F46

SCRATCH PAD

123-456-7890 :Options

3 Push .

The Options menu appears. Besides storing digits, you can enter hyphens, pauses, and links (see page 24).

Turn to select “Store&Exit,” then push .

The information is stored as a scratch pad entry in the Calls List. When the Calls List reaches more than 10 list items, the oldest entries will be deleted as needed to make room for new entries.

OPTIONS Enter Pause Store&Exit Enter Link

Page 53

Setting security options

You can restrict unauthorized access to your phone and the information it holds. Additionally, on the Security menu, you can reset menu settings to default and store emergency numbers. Unlike other items on the Features menu, accessing the Security menu requires a lock code when you select it from the Features menu.

A typical default lock code is either the last four digits of your phone number or 0000.

F-5

SECURITY Enter code for access. CODE: ----

F51

SECURITY Lock Phone New Code Restrict #

Security menu

Preventing others from using your phone [F51]

This option lets you set when the phone will be locked. When the phone is locked, carrying out most operations requires entering the lock code; you can still answer incoming calls and dial 911 or other stored emergency numbers.

1 Push to select “Lock Phone” from the

Security menu.

The Lock Phone menu appears.

2 Turn to select when the phone will be

locked.

You can select “never,” “on power-up,” or “right now.” If you select “never,” the phone is available for use at any time without a lock code. If you select “on powerup,” the phone is locked every time you turn it on.

F51

LOCK PHONE NEVER :Choices :To Set

F51

LOCK PHONE on power-up :Choices :To Set

Features

Advanced

3 Push to enter the new setting.

The standby display reappears. The message “ :Unlock” indicates that the phone is locked.

To unlock the phone

On the standby display, push . When prompted, enter the lock code.

My Phone 12:34P 12/25

:Unlock

Page 54

Setting a new lock code [F52]

The lock code must be entered every time you want to unlock the phone, and also when you want to access restricted numbers.

1 Turn to select “New Code” from the

Security menu, then push

The Enter New Code display appears, prompting you to enter a new lock code.

Use the number buttons to enter a lock code.

The lock code must be exactly four digits long.

3 Push to store the new lock code in

memory.

A confirmation display appears.

Note

Keep a record of your lock code. If you forget it, contact your service provider.

Restricting a Phone Book entry [F53]

You can restrict access to individual Phone Book entries.

1 Turn to select “Restrict #” from the

Security menu, then push

The following display appears, prompting you to specify the Phone Book entry to be restricted.

F52

ENTER NEW CODE:

--- :Save Code

F52

ENTER NEW CODE: 2345 :Save Code

F52

New lock code is 2345

F53

for all book entries or enter the location #.

2 Turn to select the Phone Book entry

that you want to restrict.

Push to restrict the selected entry.

Now the selected entry is restricted.

L15

My Phone

123-456-7890 :Restrict

L15

Entry is now Restricted

Page 55

To unrestrict an entry

Follow the procedure for restricting an entry on the previous page to select the entry you want to unrestrict.

L15

Entry is now UnRestricted

Notes

• The phone number of a restricted entry is not displayed when you view the Phone Book and make a call.

• Restricted entries are not listed or displayed after a digit string search (see pages 31 and 48).

• Calling, editing, and erasing a restricted entry requires the four-digit lock code.

Tip

In addition, you can use the Options menu to restrict/unrestrict Phone Book entries (see page 27).

Restricting all Phone Book entries [F54]

You can restrict access to all Phone Book entries. All operations that involve Phone Book entries require the four-digit lock code (see page 54).

1 Turn to select “Restrict All” from the

Security menu, then push

The Restrict All menu appears.

2 Turn to set restriction of all Phone Book

entries on or off.

F54

RESTRICT ALL OFF :Choices :To Set

F54

RESTRICT ALL on :Choices :To Set

3 Push to enter the new setting.

The standby display reappears.

Note

If you restricted some entries by using “Restrict #,” they are still restricted when you turn off “Restrict All.”

Features

Advanced

Page 56

Reverting to default settings [F55]

You can reset all menu settings to the defaults. This does not affect Phone Book or Calls List entries.

1 Turn to select “Master Reset” from the

Security menu, then push

The Master Reset display appears.

2 Press

or push

to revert to the factory defaults,



to keep the current settings.

If you revert to the factory defaults, all your custom menu settings are erased.

Erasing all Phone Book entries [F56]

You can erase all Phone Book entries at once.

1 Turn to select “Erase Book” from the

Security menu, then push

The Erase Book display appears.

2 Press

or push

If you erase all entries, the following display appears.

to erase all Phone Book entries,



to quit without erasing.

F55

MASTER RESET 1:To Reset All Settings :Quit

F55

-reset-

F56

ERASE BOOK 1:To Erase Phone Book :Quit

F56

-erased-

Erasing all Calls List entries [F57]

You can erase all Calls List entries at once.

1 Turn to select “Erase Calls” from the

Security menu, then push

The Erase Calls display appears.

2 Press

push



to erase all Calls List entries, or

to quit without erasing.

If you erase all entries, the following display appears.

F57

ERASE CALLS 1:To Erase Calls List :Quit

F57

-erased-

Page 57

Storing emergency numbers [F58]

You can use the Security menu to store up to three emergency numbers other than 911 (which you cannot erase). You can call these numbers even when the phone is locked.

1 Turn to select “Emergency #” from the

Security menu, then push

The first Emergency # display appears.

2 Turn to select the emergency memory

location, then push

The following display appears, prompting you to enter the phone number for the emergency entry.

3 Use the number buttons to enter the

number.

4 Push to store the emergency number.

The entered emergency number is stored in memory. To store other emergency numbers, repeat the above procedure. To go back to the standby display, hold down

CLR

F58

EMERGENCY #1 (empty) :Other #'s :Edit #

F58

Enter phone number for emergency entry #1

F58

123-456-7890 :Store #

Features

Advanced

Page 58

Setting display options

You can use the features on the Display menu to change the appearance of the on-screen display.

Setting the banner [F61]

You can change what the banner reads.

1 Push to select “Banner” from the

Display menu.

The Banner display appears. The current banner text is displayed.

2 Push again to start editing.

The following message appears, prompting you to enter a new banner.

3 Use the number buttons or to enter the

new banner text.

The banner can be up to 12 characters long. For details on character entry, see the “Alphanumeric table” on page 23.

F61

DISPLAY Banner Backlight Auto-Hyphen

Display menu

F61

BANNER

----SONY----

:Edit

F61

BANNER

---SONY---(Enter Text) :Done

F61

BANNER My Phone (Enter Text) :Done

4 Push to save the new banner.

The standby display reappears. Your new banner is displayed.

My Phone 12:34P 12/25 :Saved #s :Features

Page 59

Setting the backlight [F62]

You can adjust the duration of the backlight on the display and keypad.

1 Turn to select “Backlight” from the

Display menu, then push

The Backlight menu appears.

2 Turn to select how long the backlight is

on after the last press of a button.

You can select “for 15 secs,” “for 7 secs,” or “off.” If the phone is used in conjunction with a hands-free car kit, a

F62

BACKLIGHT FOR 7 SECS :Choices :To Set

F62

BACKLIGHT for 15 secs :Choices :To Set

cigarette lighter adapter, or a single- or dual-slot battery charger, the added option of “always on” leaves the backlight on.

3 Push to enter the new setting.

The standby display reappears.

Setting autohyphenation [F63]

You can turn the autohyphenation feature on and off. If you turn it on, entered numbers are hyphenated according to the North American Numbering Plan (eleven digits which include a long distance identifier, a three-digit area code, a three-digit community code, and a four-digit location code, e.g., 9-999-999-9999).

1 Turn to select “Auto-Hyphen” from the

Display menu, then push

The Auto-Hyphen menu appears.

F63

AUTO-HYPHEN ON :Choices :To Set

Features

Advanced

2 Turn to select “on” or “off.”

3 Push to enter the new setting.

The standby display reappears.

F63

AUTO-HYPHEN off :Choices :To Set

Page 60

Sorting the Phone Book [F64]

You can determine how the Phone Book will be displayed, and also set the phone to sort the entries either alphabetically or by memory location.

1 Turn to select “Sort Book” from the

Display menu, then push

The Sort Book menu appears.

2 Turn to set the sorting preferences.

You can choose to sort the Phone Book “by Loc. #” (by location) or “alphabetic” (alphabetically).

3 Push to enter the new setting.

The standby display reappears.

F64

SORT BOOK BY LOC. # :Choices :To Set

F64

SORT BOOK alphabetic :Choices :To Set

Page 61

Setting the menu length [F65]

You can set the menu length (long or short). The short menu displays only the most common items on the Features menu; the long menu displays all items.

1 Turn to select “Menu Length” from the

Display menu, then push

The Menu Length menu appears.

2 Turn to set the menu length.

You can select “short” or “long.”

F65

MENU LENGTH LONG :Choices :To Set

F65

MENU LENGTH short :Choices :To Set

3 Push to enter the new setting.

The standby display reappears.

Items on the short menu

The short menu contains the following items:

• Ringer Vol. (see page 38)

• My Number (see page 44)

• Saved #s (see pages 28, 30, 33)

• Lock Phone (see page 53)

• Long Menu (see page 75)

Note

The item “Saved #s” contains the items “Find Name” (see page 30), “Phone Book” (see page 28), and “Calls List” (see page 33).

Features

Advanced

To return to the long menu

On the short menu, turn to select “Long Menu,” then push .

Page 62

Adjusting network settings

On the Network menu, you can set the phone to alert you when the roaming status changes, when a call is dropped, or when enhanced voice privacy is lost. You can set how NAM’s (Number Assignment Modules) are switched, and also activate new services. NAM’s are phone identifier numbers associated specifically with your phone. For example, you may have both a

F71

NETWORK Roam Alert Drop Alert Priv. Alert

Network menu

business phone number and also a personal phone number associated with your phone.

Setting the roaming alert [F71]

Your phone is roaming when you use it outside of the home area. Roaming access to a different carrier and the types of calls you can make varies with the agreement between your “home” carrier and the currently serving carrier. Check with your service provider for details about roaming in a specific area.

1 Push to select “Roam Alert” from the

Network menu.

The Roam Alert menu appears.

Turn to select “on” or “off.”

3 Push to enter the new setting.

The standby display reappears.

F71

ROAM ALERT OFF :Choices :To Set

F71

ROAM ALERT on :Choices :To Set

When you enter another service area

The roaming icon (R) appears on the display. A beep accompanies the icon if you have turned the roam alert on.

If you leave any valid service area

The following display appears, indicating that you are outside the area serviced by your “home” carrier or other valid service areas. The out-of-service icon (

) also appears.

If you are in an analog roaming area

The message “Analog Roam” is displayed on the standby display. This message indicates that you are outside your home area, and that you are in an analog service area.

Entering Roam Service Area

Leaving Service Area

My Phone Analog Roam :Saved #s :Features

Page 63

Setting the drop alert [F72]

If the signal fades, your phone may drop the ongoing call. You can choose to be alerted by an audible alarm when a call is dropped.

1 Turn to select “Drop Alert” from the

Network menu, then push

The Drop Alert menu appears.

2 Turn to select “on” or “off.”

3 Push to enter the new setting.

The standby display reappears.

When a call is dropped

The following display appears. A beep will sound if you have turned the drop alert on.

F72

DROP ALERT OFF :Choices :To Set

F72

DROP ALERT on :Choices :To Set

Time: 1:30 SIGNAL FADED Your call was lost.

Features

Advanced

Page 64

Setting the voice privacy alert [F73]

A display appears to indicate if enhanced voice privacy is lost during a call. You can choose to have an audible alarm accompany this display.

1 Turn to select “Priv. Alert” from the

Network menu, then push

The Priv. Alert menu appears.

2 Turn to select “on” or “off.”

3 Push to enter the new setting.

The standby display reappears.

If enhanced voice privacy is lost

The following display appears. A beep accompanies the display if you have turned the voice privacy alert on.

When enhanced voice privacy is regained

The following display appears. A beep accompanies the display when enhanced voice privacy is regained and you have turned the voice privacy alert on.

F73

PRIV. ALERT OFF :Choices :To Set

F73

PRIV. ALERT on :Choices :To Set

Time: 1:30 Enhanced Privacy was just lost.

-P-

Time: 1:30 Enhanced Privacy is regained

Note

The network automatically turns on enhanced voice privacy if it is available. You do not have to change your phone settings. For details, contact your service provider.

Page 65

Switching NAM’s automatically [F74]

Your phone allows you to store up to two NAM’s (Number Assignment Modules). To add or remove NAM’s, contact your service provider who will change the NAM’s for you. You can set the phone to switch between them automatically. The phone switches from one NAM to the other if it enters a service provider’s coverage area that matches one of your NAM settings. To switch manually, see “Switching NAM’s manually” below.

1 Turn to select “Auto-N.A.M.” from the

Network menu, then push

The Auto-N.A.M. menu appears.

2 Turn to set automatic switching on or

off.

3 Push to enter the new setting.

F74

AUTO-N.A.M. OFF :Choices :To Set

F74

AUTO-N.A.M. on :Choices :To Set

The standby display reappears.

Switching NAM’s manually [F75]

If automatic switching is turned off, you can configure the phone for manual switching between the two NAM’s. You must switch from one NAM to the other if the phone enters a service provider’s coverage area that matches the other NAM setting. To set the phone to switch automatically, see “Switching NAM’s automatically” above.

1 Turn to select “Set-N.A.M.” from the

Network menu, then push

The Set-N.A.M. menu appears.

Turn to switch between the two NAM’s.

The display alternately shows the name and the number of the selected NAM.

F75

SET-N.A.M. 1 NAM #1 :Choices :To Set

F75

SET-N.A.M. 2 <empty> :Choices :To Set

Features

Advanced

3 Push to enter the new setting.

The standby display reappears.

Page 66

Activating phone services (OTASP) [F76]

You can use the OTASP (Over-The-Air Service Provisioning) activation feature to self-activate your phone with a new service. Contact your service provider to see if this service is available in your area.

1 Turn to select “Activation” from the

Network menu, then push

The Activation menu appears.

2 Turn to select which system block to

CLR

. To cancel

activate the service on, then push

The following display appears, prompting you for confirmation. To go back one step, press activation and return to the standby display, press

3 Press

The phone calls up a service provider.

When a service provider is contacted, the following display appears, and you are connected to an operator.

When activation is complete, the following display appears followed by the standby display.

to confirm.



END

F76

ACTIVATION on Block A :Choices :To Set

F76

Attempt to activate Block A? 1:Yes

F76

Searching... Activation

Time: 0:01 Activation

Time: 4:20 Activation is complete! :OK

If activation fails

The following display appears. Push to retry, or press return to the standby display.

END

Time: 4:20 Activation has failed :Retry

Page 67

Using the Short Messaging Service



ABC3DEF

JKL6MNO

TUV

OPER

GHI

PQ RS

PWRCLR

SEND

END

This section contains information on the Short

SEND

Messaging Service (SMS). This feature lets you receive “text” messages, which are stored in your phone as long as there are enough memory locations available.

END

CLR

Contact your service provider to see if this service is available in your area.

Receiving messages

To receive messages, the phone must be turned on. The phone supports three types of messages: “MESSAGE” indicates a text message; “PAGE” typically contains only digits; “VOICE MAIL” is a voice mail notification, and indicates the number of new voice mail messages stored in your voice mailbox.

When you receive a message

The message icon ( ) appears on the display, accompanied by audible alerts. The following display appears. The first line indicates message type and priority. If the message is urgent, the message type is flanked by asterisks (*) and followed by an exclamation mark (!). If you press any key, this display disappears. The message icon (

) remains displayed as long as

there are unread messages.

** PAGE! ** at 11:15AM 12/25 from 123-456-7890

Features

Advanced

Tip

If you receive duplicate messages, the phone deletes the older one and stores the new one with the indication “DUPLICATE.”

WARNING

When you receive a new message and your phone does not have enough memory to store it, the phone automatically erases old messages that are not locked.

If the memory becomes full

The phone issues a warning when the memory is 75% full. At this point, you should erase expendable messages (see page 72).

If the memory becomes completely full or your phone does not have enough memory to receive an incoming message, new messages are rejected and the following display appears.

Msg Memory is 75% full. Please read new messages

Msg Memory is full. Last Msg(s) rejected.

Page 68

Accessing messages

1 Press from the standby display.

The Messages display appears, indicating the number of the following types of messages, respectively:

• Voice mail messages (see page 73).

• Unread text messages and pagings (see the section below).

• Text messages and pagings that you have already read but are still stored in memory (see page 69).

Reading text messages

You can read both new and old messages stored in memory. After reading messages, you can protect or erase them.

To read new messages

MESSAGES 15 Voice 5 New Text 5 Old Text

1 From the Messages display, turn to

select “New Text,” then push

The first message is displayed.

If there are no new messages, the following display appears. Push to return to the Messages display.

* URGENT * MESSAGE from SONY 123-456-7890

There are no new text messages. :OK

2 Turn to scroll through the message.

If you do not scroll, the display automatically scrolls down. A hollow box ( ) indicates the end of the message.

3 To proceed to the next message, push

when you reach the end of the message.

The Options menu appears. To return to the standby display, press

Turn to select “Next Msg,” then push .

The next message is displayed. If there are no more messages, the Messages display reappears.

END

12:25P 12/25 ============ :Options

OPTIONS Erase Msg Send Next Msg

MESSAGE from

123-456-7890

Page 69

To read old messages

1 From the Messages display, turn to

select “Old Text,” then push

A list of old messages is displayed. An asterisk (*) indicates an urgent message. A lock icon ( ) indicates that the message is locked (see page 70). If a number is too long to fit, an ellipsis (...) is used.

2 Turn to scroll through the list of old

messages.

3 To read the selected message, push .

The selected message is displayed.

OLD TEXT *Bob, flig 123-555-55 *555-1234

OLD TEXT 123-555-55 *555-1234 Great Job!!

Bob, flight comes in at 1:30. Please pick me up!

4 Turn to scroll through the message.

If you do not scroll, the display automatically scrolls down to the end of the message, which is indicated with a hollow box ( ).

5 When you have read the message, press

CLR

to return to the list of old messages.

To return to the Messages display, press . To read the next message, push to go to the Options menu, then select “Next Msg.”

12:25P 12/25 ============ :Options

OLD TEXT *Bob, flig 123-555-55 *555-1234

Features

Advanced

Page 70

To protect a text message

You can lock a message to protect it from being erased.

1 After reading a message, push .

The Options menu appears.

Turn to select “Lock Msg,” then

push

The following display appears, and the message is now locked.

Note

The phone does not erase locked messages automatically. When there is not enough memory for incoming messages, you must erase the locked messages manually.

To respond to a text message

OPTIONS Erase Msg Send Next Msg

Message now locked until "Erase Msg" is selected.

1 After reading a text message, push

The Options menu appears.

2 Turn to select “Send,” then push .

The phone dials the callback phone number which is attached to the message.

If the callback number is not attached to the message, no call is made and the following message is displayed.

Tip

In addition, you can dial the callback phone number by pressing message or the list of old messages.

SEND

OPTIONS Erase Msg Send Next Msg

Calling... SONY

123-456-7890

No callback phone number available. :OK

when viewing a text

Page 71

To save the callback number

1 After reading a message,

push .

The Options menu appears.

2 Turn to select “Save Number,” then

push

The following display appears, prompting you for a name to accompany the number.

3 Use the number buttons to enter the name.

If you press the same button in quick succession, the letter you just entered changes. (See the “Alphanumeric table” on page 23.) Use / or to move the cursor and insert spaces between characters. If you enter the wrong character, press

CLR

to clear the

character highlighted by the cursor.

4 When you are finished,

push

to store

the phone number and name.

A display similar to the following appears.

5 Push to store the new number in the

first available memory location.

If you want to store it in another location, turn to select the desired location, then

push

OPTIONS Erase Msg Send Next Msg

Enter a Name

:Save

Enter a Name SONY

:Save

Save in location 15? :Save :Other Loc

L15

SONY has been saved in location 15.

Features

Advanced

A confirmation message appears, followed by the status of the Phone Book.

PHONE BOOK LOCATIONS: 21 used 78 empty

Page 72

To erase a text message

1 After reading a text message,

push .

The Options menu appears.

2 Turn to select “Erase Msg,” then

push

The message is erased.

To erase all old text messages

1 Turn down to select “Erase Old” from

the Messages display, then

If the Messages display is not shown, press , then select “Erase Old.”

2 Press

To go back to the Messages display without erasing the messages,

to erase all old messages.



push

OPTIONS Erase Msg Send Next Msg

-erased-

Erase old text msgs? 1:Erase :Quit

MESSAGES 15 Voice 3 New Text 0 Old Text

Page 73

Reading voice mail notification messages

1 From the Messages display, turn to

select “Voice,” then push

The following display appears, indicating the number of voice messages stored in your voice mailbox. Press

CLR

to go back to the Messages display.

2 Turn to scroll through the message.

A hollow box ( ) indicates the end of the message.

To dial a callback number

1 After reading a voice mail notification

message, push

The Options menu appears.

2 Turn to select “Send,” then push .

The phone dials the callback phone number which is attached to the message.

Tip

In addition, you can dial the callback phone number by pressing display or when reading a voice mail notification message.

SEND

You have 15 new messages at 123-456-7890

12:25P 12/25 ============ :Options

OPTIONS Erase Msg Send Save Number

Calling... SONY

123-456-7890

from the Messages

Features

Advanced

To erase a voice message

1 After reading a voice mail notification

message, push

The Options menu appears.

Turn to select “Erase Msg,” then push .

The voice mail notification message is erased. The Messages display reappears, indicating that there are currently no voice mail notification messages stored in memory.

OPTIONS Erase Msg Send Save Number

MESSAGES 0 Voice 8 New Text 3 Old Text

Page 74

Troubleshooting

Problem

Nothing appears on the display.

The out-of-service icon

) appears.

(

Nothing happens when you press the buttons.

The call does not go through.

You can hear the other party, but the other party cannot hear you.

You hear the other party only faintly.

The call is cut off (“dropped”).

You hear an alternate high/low tone.

You forgot the lock code.

You hear a fast busy tone.

You cannot place or receive calls.

Cause/Remedy Page

• The phone is off. Turn the phone on.

• Battery is fully discharged. Recharge the battery.

• Battery may not be completely attached. Securely attach the battery.

• The phone is outside the service area, or the signal is too weak. Extend the antenna fully. Check NAM settings on the Network menu. If you set

• “Auto-NAM” to “off” and you are using two NAM’s, the phone may be ignoring an available service.

• The buttons may be locked.

• The phone may be locked. Enter the lock code to unlock the phone.

• Check the signal strength.

• If the out-of-service icon ( service. See above.

• Check the number.

• Press

• Listen for a busy signal.

• The microphone may be muted. Unmute the

• Adjust the earpiece volume. If possible, also reduce

•

• You are attempting to use the phone in an area

• Extend the antenna fully.

• Wait for the out-of-service icon (

• Try 0000, 1234 (commonly used as defaults), or the

• See your authorized dealer or service provider.

• The fast busy tone can result from any one of the

• Make sure that the phone is turned on, and that the

•

SEND

microphone.

the noise around you. You are possibly out of the coverage area. Redial the

number. If the problem continues, contact your carrier. Also see “The out-of-service icon (

without service.

then try to dial.

last four digits of your own number.

following problems: – The phone is improperly programmed. – The phone is out of range. – All channels are busy. – The antenna is broken or damaged.

out-of-service icon ( Check the system settings. If you are roaming, consult your service provider concerning roaming agreements.

) is displayed, there is no

19, 38

19, 40

) appears” above.

) to disappear,

) is not displayed.

16 14 13

50 54

16 16

18 18 —

16 16

—

— 16 — 16

Page 75

List of menu items

This section lists the Features menu and its submenus. Use these to set the various parameters that pertain to the operation of the phone. For details on how to navigate from one menu to another, see “About the Features menus” on page 36.

Submenu Menu Item Settings Page

F-1 Sounds F11 Ringer Vol. off / low / medium / high / escalate 38

F12 Mute/UnMute mutes or unmutes the microphone 38 F13 Keybeep Vol off / low / medium / high 39 F14 Earpiece Vol 1 / 2 / 3 / 4 / 5 / 6 / 7 40 F15 Ringer Type standard / option 1 to 4 40 F16 Key Sound tones / clicks 41 F17 Beep Length standard / long 41

F-2 Timers F21 All Calls total call time, number of calls 42

F22 Recent Calls total call time, number of calls 42 F23 Minute Alert on / off 43 F24 Auto-Off never / in 3 hours / in 2 hours /

in 1 hour / in 30 mins 43

F-3 Directory F31 My Number —44

F32 Save —44 F33 Erase —45 F34 Edit —46 F35 Find Name —47 F36 Phone Book No default entries 48 F37 Calls List No default entries 49

F-4 Extras F41 Key Guard —50

F42 Touch Dial on / off 50 F43 Auto-Retry off / on 60 sec / on 30 sec / on 10 sec 51 F44 Auto-Answer on / off 51 F45 Any Key Answ on / off 52 F46 Scratch Pad —52

Additional

Information

Page 76

Submenu Menu Item Settings Page

F-5 Security F51 Lock Phone never / on power-up / right now 53

F52 New Code 0000 54 F53 Restrict # No default restricted numbers 54 F54 Restrict All on / off 55 F55 Master Reset —56 F56 Erase Book —56 F57 Erase Calls —56 F58 Emergency # No default numbers for #1 to #3 57

F-6 Display F61 Banner No default banner 58

F62 Backlight off / for 7 secs / for 15 secs / always on 59 F63 Auto-hyphen on / off 59 F64 Sort Book by loc. # / alphabetic 60 F65 Menu Length long / short 61

F-7 Network F71 Roam Alert on / off 62

F72 Drop Alert on / off 63 F73 Priv. Alert on / off 64 F74 Auto-N.A.M. on / off 65 F75 Set-N.A.M. N.A.M. 1 / N.A.M. 2 65 F76 Activation —66

Page 77

Specifications

Frequency range CDMA

Transmit: 1851.25 to 1908.75 MHz Receive: 1931.25 to 1988.75 MHz

Transmit: 824.04 to 848.97 MHz Receive: 869.04 to 893.97 MHz

Dimensions 5.7 × 2.0 × 1.5 inches (h/w/d)

(not including antenna) (146 × 50 × 37 mm)

Mass (weight) Approx. 7.2 oz (203 g)

(including battery)

RF power output CDMA: 0.01 µW to 300 mW

FM: 6 mW to 600 mW

Operational temperature –22°F to +140°F

(–30°C to +60°C) (excluding battery pack)

Supplied accessories QN-003BPLH Hi-Cap Li-Ion Battery Pack (1)

QN-001AC AC Adapter (1) Hand strap (1)

Optional accessories QN-002BCD Dual Slot Battery Charger

QN-003BPLH Hi-Cap Li-Ion Battery Pack QN-004BPLS Slim Li-Ion Battery Pack QN-005BPNM Ni-MH Battery Pack QN-006BPNC Ni-Cd Battery Pack QN-007HFK Hands-Free Car Kit QN-008CLA Rapid Charging Cigarette Lighter Adapter QN-009TA Travel Adapter QN-010LC Carrying Case (for CM-M1300, B1200, S1100

series telephones) QN-011PH Hands-Free Privacy Handset QN-012DA Data Cable QN-013HC Auto Travel Holder QN-016SKT Starter Kit

Charging Stand, Rapid Charging Cigarette Lighter Adapter) QN-017SKT Starter Kit

Charging Stand, Rapid Charging Cigarette Lighter Adapter) QN-018SKT Starter Kit

Charging Stand, Rapid Charging Cigarette Lighter Adapter) QN-018LC Carrying Case

telephones) QN-019LC Carrying Case

telephones) QN-020TCL Combination Travel Adapter/Cigarette

Lighter Adapter QN-025PHK Portable Hands-Free Car Kit

(QN-010LC Carrying Case, Single Slot

(QN-019LC Carrying Case, Single Slot

(QN-018LC Carrying Case, Single Slot

(for CM-M2300, B2200, S2100 series

(for CM-M3300, B3200, S3100 series

Additional

Information

Call 1-800-488-SONY (7669) to order additional accessories (USA only).

Design and specifications are subject to change without notice.

Page 78

Glossary

Automatic answer

Feature that automatically answers calls.

Automatic NAM

Feature that automatically selects an available NAM that matches the current serving system (carrier).

Automatic retry

Feature that automatically redials a call when a “System Busy” indication is received.

Banner

Message at the top of the standby display.

Calls List

See “Phone Book.”

Carrier

A company that provides cellular and PCS telephone service.

CDMA

Code Division Multiple Access. A spread-spectrum approach to digital transmission. With CDMA, each conversation is digitized, and then tagged with a code. The mobile phone receives only the signal with the appropriate code.

Dropped call

A call terminated because of a deep, long fade or because the user left the coverage area.

DTMF

Dual Tone Multiple Frequency, also known as “touch-tone.” Tone generated when you press a telephone button (number, answering machines, pagers, telephone banking services, data services, and other electronic services.

, or #). Can be used to access

ESN

Electronic Serial Number. The unique identification number of your telephone. The telephone transmits this number to the base station every time a call is placed.

Emergency number

In addition to the general emergency number (911 for the U.S.A. and Canada), three phone numbers can be stored as emergency numbers in your telephone. You can dial these numbers and 911 even when the phone is locked.

Home area

The area of the home system to which you subscribe.

Coverage area

The geographic area covered by one carrier. If you travel outside a carrier’s area, you cannot receive service from that carrier. Also see “Roam.”

Incoming call

A call received by your telephone.

Page 79

Lock

Prevents unauthorized calls by requiring the user to enter a code to use the phone. Even if the phone is locked, you can call any of the emergency numbers or answer incoming calls.

Memory

A storage area for names and phone numbers. Also see “Phone Book.”

The menu allows you to change or see the settings of your phone. You can access it from the standby display or during a call. See “List of menu items” on page 75 for an overview of this feature.

NAM

Number Assignment Module. Portion of your telephone’s memory programmed to contain information about your subscription to the carrier. Your telephone can have up to two NAM’s.

Pause

You can enter pause codes in the phone number memory data. Use this feature when accessing an answering machine, voice mail system, electronic banking system, etc. When a pause is inserted between two groups of digits, the phone will pause before dialing the next set of digits, allowing you to wait until your counterpart is ready to accept the string.

Minute alert

This alert beeps periodically during a call to help you keep track of the length of the call.

Multiple NAM registration

Registering your phone in more than one carrier. A cheaper alternative to roaming. If you travel frequently to a specific area, registering the local carrier in your phone’s NAM’s may be an economical alternative to roaming and long distance charges.

Phone Book

You can store up to 99 numbers in Phone Book memory, location number 01 to number 99. An additional recent number memory (Calls List) stores the last ten used phone numbers.

Roam

Your phone is roaming when you use it outside of the home area. Availability of roaming access to a different carrier and types of calls you can make varies with the agreement between your home carrier and serving carrier. Check with your carrier for details about roaming in a specific area.

Additional

Information

Page 80

Scratch pad

Allows you to enter a number and store it in the Calls List.

Service area

Region covered by a cellular/PCS service. Also see “Coverage area.”

SMS

Short Messaging Service. An extended service offered by carriers that allows you to receive text messages on your phone. Check with your carrier for details.

Speed dialing

Making a call using Phone Book memory locations. Also see “Phone Book.”

Touch dialing

A quick way of making a call using a number stored in a Phone Book memory location. Also see “Speed dialing.”

Touch-tone

See “DTMF.”

Voice mail

An extended service, offered by carriers, that allows you to retrieve voice mail messages stored in your voice mailbox. Check with your carrier for details.

Volume

You can adjust the volume of keybeep, ringer, and earpiece.

Page 81

Index

AC adapter 8, 14 Antenna 16 Automatic

Answer 51 Hyphenation 59 Retry 51 Redial 51

Backlight 59 Banner 58 Battery pack

Charging 14 Checking 15

Attaching/removing 13 Battery charge contacts 14 Battery pack release tab 13 Battery icon 14, 15

Calling

Calls List 33, 49

Dropped call 63

Ending calls 18, 20

Making calls 18

Receiving calls 20

Recent number 33

Redialing 19, 51

Restrictions 27, 54

Roaming 62

Speed dialing 29

Touch dialing 29, 50 Carrier 62, 66 CDMA (Code Division Multiple Access) 4 Character display 12 Clearing. See Deleting Coverage area 65 Cursor 22, 44

Dialing. See Calling Deleting

Calls List entries 56 Characters 22, 44 Message 72 Phone Book entries 26, 45 Phone numbers 26, 45

Voice mail 73 Digital icon 12 Display 12 Display settings

Accessing 36

Autohyphenation 59

Backlight 59

Banner 58

Time 42 Displays

Calling 18

Features menu 36

Hyphens/pauses/links 24

Menu setting 61

Security 53

Standby 16 Dropped call 63 DTMF (Dual Tone Multiple Frequency) 35

Earpiece 19, 40 Editing

Emergency numbers 57

Phone numbers 25, 46 Emergency numbers 57 Enabling

Lock 50

Touch dialing 50 Ending a call 18, 20 Entering

Hyphens 24

Links 24

Pauses 24 Erasing. See Deleting ESN (Electronic Serial Number) 78

Additional

Information

Page 82

Finding. See Searching

Hand strap

Attaching 9

Hyphens

Autohyphenation 59 Entering manually 24

Incoming call 20 In-use icon 18, 20

Keybeep 39

Menus

Accessing 36 Message button 68 Message icon 67 Messages

Calling back 70

Displaying 68

Erasing 72

Locking 70

Message list 68

Receiving 67 Microphone 19, 38 Minute alert 43 Multiple city registration 79 Muting the microphone 19, 38

NAM (Number Assignment Module) 62, 65 Number buttons 18, 22

Laws

Rules and regulations 3 Link 24 Lock code 54

Making calls 18 Manual

Answer 20

Call 18

Hyphenation 24

Redial 19 Memory

Deleting 26, 45

Editing 25, 46

Number searching 31, 32, 48

Storing 22, 44

Out-of-service icon 16, 62 Over-the-Air Service Provisioning (OTASP) 66 Overflow digits

Viewing 34

Pause 24 Phone Book 22, 28, 30, 44 Power

Turning off 16 Turning on 16

Quitting. See Power

Page 83

Receiving

Calls 20 Messages 67 Voice mail 73

Recent number memory

Calling recent numbers 33 Clearing call memory 56

Redialing

Auto-retry 51

Last dialed number 19 Restriction 27, 54 Ringer

Volume 38 Roam 62 Roam icon 62 Roaming agreement 62 Rules and regulations 3

Safety precautions 4 Scratch pad 52 Scrolling

Menus 17

Message 68

Message list 69 Searching

For a name 47

For a number 31, 32

For a message 69 Security code. See Security functions Security functions

Accessing 53

Clearing call memory 56

Emergency numbers 57

Lock mode 53

New lock code 54

Restriction 54

Sending. See Calling Service area 62 Signal strength icon 16 Special characters 23 Special features

Accessing 50 Changing DTMF transmission 41 Enabling touch dialing 50 Muting the microphone 38 Using the scratch pad 52 Setting auto-answer 51

Setting auto-retry 51 Standby display 16 System settings

Accessing 62

Over-the-Air Service Provisioning

(OTASP) 66

Selecting NAM’s

Auto-NAM 65 Manual NAM 65

Text Message. See Messages Touch dialing

Enabling 50 Troubleshooting 74 Turning phone on 16

Voice mail notification

Accessing 73

Receiving 73 Voice Privacy 64 Volume

Adjusting 38

Additional

Information

Page 84

SONY Wireless Hotline Number (USA only)

If you have any questions or comments, please call:

SONY WIRELESS HOTLINE

1-800-578-SONY (7669)

Printed in USA

Sony CM-B1200 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
