4-113-865-52 (1)

FM/AM Compact Disc Player

Operating Instructions

Manual de instrucciones

To cancel the demonstration (DEMO) display, see page 6. Para cancelar la pantalla de demostración (DEMO), consulte la página 6.

CDX-GT680UI CDX-GT680UI

For installation and connections, see the supplied installation/connections manual.

This label is located on the bottom of the chassis.

Microsoft, Windows Media, and the Windows logo are trademarks or registered

trademarks of Microsoft Corporation in the United States and/or other countries.

iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

iPhone is a trademark of Apple Inc.

MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.

This product is protected by certain intellectual property rights of Microsoft Corporation. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft or an authorized Microsoft subsidiary.

Content providers are using the digital rights management technology for Windows Media contained in this device (“WM-DRM”) to protect the integrity of their content (“Secure Content”) so that their intellectual property, including copyright, in such content is not misappropriated. This device uses WM-DRM software to play Secure Content (“WM-DRM Software”). If the security of the WM-DRM Software in this device has been compromised, owners of Secure Content (“Secure Content Owners”) may request that Microsoft revoke the WM-DRM Software’s right to acquire new licenses to copy, display and/or play Secure Content. Revocation does not alter the WM-DRM Software’s ability to play unprotected content. A list of revoked WM-DRM Software is sent to your device whenever you download a license for Secure Content from the Internet or from a PC. Microsoft may, in conjunction with such license, also download revocation lists onto your device on behalf of Secure Content Owners.

Warning if your car’s ignition has no ACC position

Be sure to set the Auto Off function (page 16). The unit will shut off completely and automatically in the set time after the unit is turned off, which prevents battery drain. If you do not set the Auto Off function, press and hold (OFF) until the display disappears each time you turn the ignition off.

Table of Contents

Getting Started

Playable discs on this unit . . . . . . . . . . . . . . . . . 6

Resetting the unit. . . . . . . . . . . . . . . . . . . . . . . . 6

Canceling the DEMO mode . . . . . . . . . . . . . . . 6

Preparing the card remote commander . . . . . . . 6

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . 6

Detaching the front panel . . . . . . . . . . . . . . . . . 7

Attaching the front panel . . . . . . . . . . . . . . . 7

Location of controls and basic operations

Main unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Card remote commander RM-X151 . . . . . . . 8

Searching for a track . . . . . . . . . . . . . . . . . . . . 10

Searching a track by name

— Quick-BrowZer . . . . . . . . . . . . . . . . . . . 10

Searching a track by listening to track passages

— ZAPPIN . . . . . . . . . . . . . . . . . . . . . . . . . 10

Radio

Storing and receiving stations . . . . . . . . . . . . . 11

Storing automatically — BTM . . . . . . . . . . 11

Storing manually. . . . . . . . . . . . . . . . . . . . . 11

Receiving the stored stations . . . . . . . . . . . 11

Tuning automatically . . . . . . . . . . . . . . . . . 11

Playing a disc. . . . . . . . . . . . . . . . . . . . . . . . . . 12

Display items . . . . . . . . . . . . . . . . . . . . . . . 12

Repeat and shuffle play. . . . . . . . . . . . . . . . 12

USB devices

Playing back a USB device. . . . . . . . . . . . . . . 12

Display items . . . . . . . . . . . . . . . . . . . . . . . 13

Repeat and shuffle play . . . . . . . . . . . . . . . 13

iPod

Playing back iPod . . . . . . . . . . . . . . . . . . . . . . 14

Display items . . . . . . . . . . . . . . . . . . . . . . . 15

Setting the play mode . . . . . . . . . . . . . . . . . . . 15

Repeat and shuffle play . . . . . . . . . . . . . . . 15

Operating an iPod directly

— Passenger control . . . . . . . . . . . . . . . . . . . . 15

Other functions

Changing the sound settings . . . . . . . . . . . . . . 16

Adjusting the sound characteristics . . . . . . 16

Customizing the equalizer curve

— EQ3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Adjusting setup items — SET . . . . . . . . . . . . 16

Using optional equipment. . . . . . . . . . . . . . . . 17

Auxiliary audio equipment. . . . . . . . . . . . . 17

CD changer. . . . . . . . . . . . . . . . . . . . . . . . . 18

Rotary commander RM-X4S . . . . . . . . . . . 18

Additional Information

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Notes on discs . . . . . . . . . . . . . . . . . . . . . . 19

Playback order of MP3/WMA/AAC

files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

About iPod . . . . . . . . . . . . . . . . . . . . . . . . . 20

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Removing the unit. . . . . . . . . . . . . . . . . . . . . . 21

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 21

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 22

Error displays/Messages. . . . . . . . . . . . . . . 24

Support site

If you have any questions or for the latest support information on this product, please visit the web site below:

Customers in Latin America:

http://esupport.sony.com/ES/LA/

Customers in Pan Asia:

http://www.sony-asia.com/section/support http://www.sony-asia.com/caraudio/

Provides information on:

• Models and manufacturers of compatible digital audio players

• Supported MP3/WMA/AAC files

Getting Started

Playable discs on this unit

This unit can play CD-DA (also containing CD TEXT) and CD-R/CD-RW (MP3/WMA/AAC files (page 19)).

Type of discs Label on the disc

CD-DA

Preparing the card remote commander

Remove the insulation film.

Tip

For how to replace the battery, page 20.

MP3

WMA

AAC

Resetting the unit

Before operating the unit for the first time, or after replacing the car battery or changing the connections, you must reset the unit. Detach the front panel (page 7) and press the RESET button (page 8) with a pointed object, such as a ball-point pen.

Note

Pressing the RESET button will erase the clock setting and some stored contents.

Canceling the DEMO mode

You can cancel the demonstration display which appears during turning off.

1 Press and hold the select button.

The setup display appears.

2 Press the select button repeatedly

until “DEMO” appears.

3 Rotate the control dial to select

“DEMO-OFF.”

4 Press and hold the select button.

The setup is complete and the display returns to normal play/reception mode.

Setting the clock

The clock uses a 12-hour digital indication.

1 Press and hold the select button.

The setup display appears.

2 Press the select button repeatedly

until “CLOCK-ADJ” appears.

3 Press (SEEK) +.

The hour indication flashes.

4 Rotate the control dial to set the hour

and minute.

To move the digital indication, press (SEEK) +/–.

5 After setting the minute, press the

select button.

The setup is complete and the clock starts.

To display the clock, press (DSPL). Press (DSPL) again to return to the previous display.

Detaching the front panel

You can detach the front panel of this unit to prevent theft.

Caution alarm

If you turn the ignition switch to the OFF position without detaching the front panel, the caution alarm will sound for a few seconds. The alarm will only sound if the built-in amplifier is used.

1 Press (OFF).

The unit is turned off.

2 Press (OPEN).

The front panel is flipped down.

3 Slide the front panel to the right, then

gently pull out the left end of the front panel.

Notes

• Do not drop or put excessive pressure on the front panel and display window.

• Do not subject the front panel to heat/high temperature or moisture. Avoid leaving it in a parked car or on a dashboard/rear tray.

• Do not detach the front panel during playback of the USB device, otherwise USB data may be damaged.

Attaching the front panel

Place the hole A of the front panel onto the spindle B on the unit, then lightly push the left side in. Press (SOURCE) on the unit (or insert a disc) to operate the unit.

Note

Do not put anything on the inner surface of the front panel.
