Page 1
Monitor Family Pocket Guide
Page 2
MULTIFORMAT VIDEO MONITORS
■ 14-inch HR Trinitron, EBU Phosphors, 800 TV lines
■ Multiple format SD & HD inputs
■ Auto White Balance capabilities
■ Selectable aspect ratio 16:9/4:3
■ Separate control unit for BVM-D14H1E
■ Multiple monitor control
■ Optional SD & HD plug-in decoder boards
BVM-D14H1E
BVM-D Series
■ 32 & 24-inch Flat 16:9 HR Trinitron,
EBU Phosphors, 1000 TV lines
■ Multiple format SD & HD inputs
■ Auto White Balance capabilities
■ Selectable aspect ratio 16:9/4:3
■ Separate control unit & memory
card
■ Digital uniformity
■ Digital convergence
(BVM-D32E1WE)
■ Optional SD & HD plug-in decoder
boards
BVM-D32E1WE
BVM-D24E1WE
■ 9-inch HR Trinitron, EBU Phosphors, 450 TV lines
■ Multiple format SD & HD inputs
■ Auto White Balance capabilities
■ Selectable aspect ratio 16:9/4:3
■ Separate control unit for BVM-D9H1E
■ Multiple monitor control
■ Optional SD & HD plug-in decoder boards
■ 20-inch HR Trinitron, EBU
Phosphors, 900 TV lines
■ Multiple format SD & HD inputs
■ Auto White Balance capabilities
■ Selectable aspect ratio 16:9/4:3
■ Separate control unit & memory
card
■ Multiple monitor control
■ Optional SD & HD plug-in decoder
boards
■ 24-inch Flat 16:9 HR Trinitron,
EBU Phosphors, 1000 TV lines
■ Multiple format HD inputs
■ Flicker free progressive images
■ 4:4:4 Dual link HD SDI signal
processing
■ SXGA computer input signal
■ Auto White Balance capabilities
■ Separate control unit & memory
card
■ Digital uniformity & Digital
convergence
BVM-D14H5E
BVM-F24E BVM-D20F1E
BVM-D9H1E BVM-D9H5E
PROFESSIONAL VIDEO MONITORS
■ 20 & 14-inch Trinitron, 600 TV lines
■ Selectable aspect ratio 16:9/4:3
■ Composite PAL/NTSC and Y/C
video input
■ Basic monitoring function
■ Parallel remote function
■ Silver Support supplied as standard
■ 9-inch HR Trinitron
- PVM-9L3: 450 TV lines
■ 9-inch Trinitron
- PVM-9L2: 250 TV lines
■ Selectable aspect ratio 16:9/4:3
■ Versatile analogue video inputs
■ Optional plug-in decoder boards
■ Li-Ion battery operation
■ Rack mountable (two units)
■ Silver Support supplied as standard
PVM-20L1
PVM-14L1
PVM-L Series
■ 20 & 14-inch HR Trinitron
- PVM-20L4 /PVM-14L4:
800 TV lines, EBU phosphors
■ 14-inch Trinitron
- PVM-14L3: 600 TV lines
■ Auto White Balance capabilities
■ Selectable aspect ratio 16:9/4:3
■ Versatile analogue video inputs
■ Compact chassis
■ Multiple monitor control
■ Optional plug-in decoder boards
■ Silver Support supplied as standard
PVM-20L4
PVM-14L4
PVM-14L3
■ 9-inch Trinitron, 250 TV lines
■ Selectable aspect ratio 16:9/4:3
■ PAL/NTSC and Y/C inputs
■ Parallel remote function
■ Rack mountable (two units)
■ Silver Support supplied as standard
■ 14-inch,1000 TV lines
■ Selectable aspect ratio 16:9/4:3
(PVM-146E)
■ D65 colour temperature (PVM-146E)
■ Convenient operating functions
(PVM-146E)
■ Rack mountable
■ Silver Support supplied as standard
■ 20 & 14-inch Trinitron, 600 TV lines
■ Selectable aspect ratio 16:9/4:3
■ Versatile analogue video inputs
■ Convenient operating functions
■ Optional plug-in decoder boards
■ Silver Support supplied as standard
PVM-9L3
PVM-9L2
PVM-20L2
PVM-14L2
PVM-145E
PVM-146E
PVM-9L1
PVM-95E
PVM-96E
Black & White
Monitors
■ 9-inch, 800 TV lines
■ Selectable aspect ratio 16:9/4:3
(PVM-96E)
■ D65 colour temperature (PVM-96E)
■ Convenient operating functions
(PVM-96E)
■ Rack mountable
■ Silver Support supplied as standard
PROFESSIONAL LCD VIDEO MONITORS
■ 15-inch LCD
■ XGA LCD panel
■ Separate LCD and video processor
■ Selectable aspect ratio 16:9/4:3
■ Versatile video and computer inputs
■ Multiformat SD/HD video inputs
■ Compact, slim and lightweight
LCD panel
■ Low power consumption
■ Parallel remote function
■ Rack mount capability
■ Silver Support supplied as standard
LMD Series
■ 32-inch LCD
■ WXGA LCD panel
■ Separate LCD and video processor
■ Selectable aspect ratio 16:9/4:3
■ Versatile video and computer inputs
■ Multiformat SD/HD video inputs
■ Compact, slim and lightweight
LCD panel
■ Low power consumption
■ Parallel remote function
■ Silver Support supplied as standard
LMD-320W
& MEU-WX1
LMD-150
& MEU-WX1
LMD-650
■ 6.5-inch high resolution LCD
■ VGA panel (640 x 480 pixels)
■ High brightness & contrast
■ Selectable aspect ratio 4:3/16:9
■ Composite PAL & Y/C inputs
■ Li-Ion battery operation
■ Rack mountable (two units)
■ Silver Support supplied as standard
■ 17-inch LCD
■ WXGA LCD panel
■ Separate LCD and video processor
■ Selectable aspect ratio 16:9/4:3
■ Versatile video and computer inputs
■ Multiformat SD/HD video inputs
■ Compact, slim and lightweight
LCD panel
■ Low power consumption
■ Parallel remote function
■ Rack mount capability
■ Silver Support supplied as standard
■ 23-inch LCD
■ WXGA LCD panel
■ Separate LCD and video processor
■ Selectable aspect ratio 16:9/4:3
■ Versatile video and computer inputs
■ Multiformat SD/HD video inputs
■ Compact, slim and lightweight
LCD panel
■ Low power consumption
■ Parallel remote function
■ Silver Support supplied as standard
LMD-230W
& MEU-WX1
LMD-171W
& MEU-WX1
■ 14-inch HR Trinitron, EBU
phosphors, 800 TV lines
■ Auto White Balance capabilities
■ Selectable aspect ratio 16:9/4:3
■ Integrated control unit & memory
card
■ Multiple monitor control
■ Optional plug-in decoder boards
■ 14-inch HR Trinitron, EBU
phosphors, 800 TV lines
■ Auto White Balance capabilities
■ Selectable aspect ratio 16:9/4:3
■ Separate control unit & memory
card
■ Multiple monitor control
■ Optional plug-in decoder boards
■ 20-inch HR Trinitron, EBU
phosphors, 900 TV lines
■ Auto White Balance capabilities
■ Selectable aspect ratio 16:9/4:3
■ Separate control unit & memory
card
■ Multiple monitor control
■ Optional plug-in decoder boards
BVM-20F1E BVM-14F1E
BVM-14F5E
BVM-F Series
ACCESSORIES
BVM Accessories
Optional Plug-in Decoder Boards
BKM-20D SDI input decoder – 3 x SDI inputs and 1 x analogue component
BKM-21D SDI/PAL/NTSC input decoder – 3 x SDI inputs and 3 x analogue composite
BKM-22X SDI and analogue input expansion board
BKM-24N Precision NTSC input decoder
BKM-25P Precision PAL input decoder
BKM-26M Precision PAL-M input decoder
BKM-27T PAL/NTSC/SECAM input decoder
BKM-28X Analogue input expansion board
BKM-41HD HD SDI input adaptor – 1 x digital input for BVM-D20/24/32 models
BKM-42HD HD SDI input adaptor – 2 x digital inputs for BVM-D20/24/32 models
BKM-48X HD/SD Analogue input expansion board with floating inputs
BKM-120D SDI input adaptor – 2 x SDI inputs for BVM-D9/14 models
BKM-127W NTSC/PAL input adaptor for BVM-D9/14 models
BKM-129X Analogue component/GBR input board for BVM-D9/14 models
BKM-142HD
HD SDI input adaptor – 2 x digital inputs for BVM-D9/14 models
Accessories
BKM-10R Control panel for up to 32 monitors via RS485 serial remote
BKM-11R Hand-held control unit, operationally identical to the BKM-10R
BKM-12Y Memory card for BKM-10R/11R to save and download monitor settings
BKM-14L External auto set-up probe
BKM-32H Control unit attachment kit to attach BKM-10R to BVM-20F/G monitors
BKM-33H14 16:9 widescreen mask for 14-inch BVM F/G Series
BKM-33H20 16:9 widescreen mask for 20-inch BVM F/G Series
BKM-34H Control unit attachment kit to attach BKM-10R to BVM-D24/F24 monitors
VF-508 Hood & rear protector for 9-inch BVM-D series
Rack Mounting Kits
BKM-30E14 19-inch EIA standard rack mount kit for 14-inch stand alone monitors
BKM-31E14 19-inch EIA standard rack mount kit for 14-inch display monitors
BKM-30E20 19-inch EIA standard rack mount kit for 20-inch display monitors
MB-509 Blank panel for BVM-D9H5E
MB-510 Rack mount kit for BKM-10R
MB-519 Blank panel for BVM-D9H1E
MB-520 Rack mount kit for 9-inch BVM-D series
PVM Accessories
Optional plug-in decoder boards
BKM-120D SDI video plug-in decoder board for PVM-L series
BKM-129X Analogue component/GBR input board for PVM-L series
BKM-150CP SDTI-CP/SDI video/audio plug-in decoder board for PVM-L series
Accessories
BKM-140M 16:9 mask for 14-inch PVM-L4/L3 series
BKM-200M 16:9 mask for PVM-20L4
Rack Mounting Kits
MB-502C Rack mount bracket for 14-inch PVM-L2/N and black and white monitors
MB-506 Rack mount adapter for two LMD-650
MB-509 Blank panel for 9-inch monitors
MB-520 Rack mounting kit for 6 & 9-inch monitors
MB-521 Rack mount bracket for 14-inch PVM-L4/L3 series
SLR-102 Slide rail kit for 14-inch PVM-L2/N and black and white monitors
SLR-103C Slide rail kit for 20-inch PVM-L2 & N series
SLR-104 Slide rail kit for 20-inch PVM-20L4
LMD Accessories
Optional plug-in decoder
BKM-220D SDI video decoder - 2 x digital inputs
BKM-255DV DV signal decoder - 2 x digital inputs
BKM-243HS SD/HD SDI video decoder - 2 x digital inputs
Accessories
BKM-320D SDI video decoder for LMD-440/5320/720W
SMF-600 Extension cable for LMD-150/210/171W/230W
SU-558 Monitor stand for LMD-150/210/171W/230W
SU-559 Floor stand for LMD-320W
Rack Mounting Kits
MB-522A Rack mount kit for LMD-171W
MB-523 Rack mount kit for LMD-210
MB-524 Rack mount kit for LMD-150
BROADCAST VIDEO MONITORS
NEW
■ LMD-440: 4x4-inch LCD
■ LMD-5320: 3x5.6-inch LCD
■ LMD-720W: 2x7-inch LCD
■ Selectable aspect ratio 16:9/4:3
(LMD-720W)
■ PAL/NTSC input
■ Optional SDI video decoder
■ Parallel remote function
■ Rack mount capability
■ Silver Support supplied as standard
■ 21-inch LCD
■ XGA LCD panel
■ Separate LCD and video processor
■ Selectable aspect ratio 16:9/4:3
■ Versatile video and computer inputs
■ Multiformat SD/HD video inputs
■ Compact, slim and lightweight
LCD panel
■ Low power consumption
■ Parallel remote function
■ Rack mount capability
■ Silver Support supplied as standard
LMD-210
& MEU-WX1
LMD-440
LMD-5320
LMD-720W
NEW
NEW
Page 3
CONFIGURATIONS
STAND ALONE CONFIGURATION
FOR THE BVM 20-INCH MONITOR
BVM-20F1E BVM 20-inch Display unit
BKM-10R Control unit
BKM-32H Control unit attachment kit
TYPICAL INPUT CONFIGURATIONS
SDI only BKM-20D 3 x SDI inputs,
1 x Component
SDI and composite BKM-21D 3 x SDI,
(PAL/NTSC) 3 x Composite inputs
High precision PAL BKM-25P 6 x Composite inputs
Multistandard BKM-27T 6 x Composite inputs
composite
PAL/SECAM/NTSC
All BVM Series monitors have 1x Component/RGB input as
standard
SLOT STRUCTURE FOR OPTIONAL INPUT DECODERS
4 Slots BVM-20F1E, BVM-14F5E
2 Slots BVM-14F1E
BVM Series
Stand alone and typical
input configurations
BKM-10R Control Unit
attached to 20-inch monitor
SPECIFICATIONS
MULTIFORMAT VIDEO MONITORS
BVM-D SERIES
PROFESSIONAL VIDEO MONITORS
PVM-L SERIES
PROFESSIONAL VIDEO MONITORS
BLACK & WHITE MONITORS
PROFESSIONAL LCD VIDEO MONITORS
LMD SERIES
BVM-D32E1WE BVM-D24E1WE BVM-F24E BVM-D20F1E BVM-D14H1E BVM-D14H5E BVM-D9H1E BVM-D9H5E BVM-20F1E BVM-14F1E BVM-14F5E PVM-20L4 PVM-20L2 PVM-20L1 PVM-14L4 PVM-14L3 PVM-14L2 PVM-14L1 PVM-9L3 PVM-9L2 PVM-9L1 PVM-145E PVM-146E PVM-95E PVM-96E LMD-440 LMD-5320 LMD-720W LMD-650 LMD-150 LMD-171W LMD-210 LMD-230W LMD-320W
MEU-WX1 MEU-WX1 MEU-WX1 MEU-WX1 MEU-WX1
BROADCAST VIDEO MONITORS
BVM-F SERIES
Picture size 32-inch 24-inch 24-inch 20-inch 14-inch 14-inch 9-inch 9-inch 20-inch 14-inch 14-inch 20-inch 20-inch 20-inch 14-inch 14-inch 14-inch 14-inch 9-inch 9-inch 9-inch 14-inch 14-inch 9-inch 9-inch 4x4-inch 3x5.6-inch 2x7-inch WS 6.5-inch 15-inch 17-inch WS 21-inch 23-inch WS 32-inch WS
Picture Resolution 1000 TV lines 1000 TV lines 1000 TV lines 900 TV lines 800 TV lines 800 TV lines 450 TV lines 450 TV lines 900 TV lines 800 TV lines 800 TV lines 800 TV lines 600 TV lines 600 TV lines 800 TV lines 600 TV lines 600 TV lines 600 TV lines 450 TV lines 250 TV lines 250 TV lines 1000 TV lines 1000 TV lines 900 TV lines 900 TV lines 480 x 234 dots 320 x 240 dots 480 x 234 dots 640 x 480 dots 1024 x 768 dots 1280 x 768 dots 1024 x 768 dots 1280 x 768 dots 1280 x 768 dots
Phosphors EBU EBU EBU EBU EBU EBU EBU EBU EBU EBU EBU EBU P22 P22 EBU P22 P22 P22 P22 P22 P22 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Pitch size 0.32 mm~0.36 mm 0.25 mm 0.25 mm 0.30 mm 0.25 mm 0.25 mm 0.25 mm 0.25 mm 0.30 mm 0.25 mm 0.25 mm 0.31 mm 0.4 mm 0.4 mm 0.25 mm 0.25 mm 0.25 mm 0.25 mm 0.25 mm 0.5 mm 0.5 mm N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
16:9 capability Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes N/A N/A Yes N/A Yes N/A N/A Yes Yes Yes Yes Yes Yes Yes
Colour temperature D65/D93/User D65/D93/User D65/D61/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User D65/D93/User N/A D65 N/A D65 N/A N/A N/A N/A N/A N/A N/A N/A N/A
Colour system BKM-25P: Precise PAL BKM-25P: Precise PAL BKM-25P: Precise PAL BKM-25P: Precise PAL BKM-127W: PAL/NTSC BKM-127W: PAL/NTSC BKM-127W: PAL/NTSC BKM-127W: PAL/NTSC BKM-25P: Precise PAL BKM-25P: Precise PAL BKM-25P: Precise PAL PAL/NTSC/ PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC CCIR, EIA CCIR, EIA CCIR, EIA CCIR, EIA PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC PAL/NTSC
BKM-27T: PAL/SECAM/ BKM-27T: PAL/SECAM/ BKM-27T: PAL/SECAM/ BKM-27T: PAL/SECAM/ BKM-27T: PAL/SECAM/ BKM-27T: PAL/SECAM/ BKM-27T: PAL/SECAM/ SECAM/NTSC 4.43 SECAM/NTSC 4.43 SECAM/NTSC 4.43
NTSC/NTSC 4.43 NTSC/NTSC 4.43 NTSC/NTSC 4.43 NTSC/NTSC 4.43 NTSC/NTSC 4.43 NTSC/NTSC 4.43 NTSC/NTSC 4.43
Auto white balance BKM-14L BKM-14L BKM-14L BKM-14L BKM-14L BKM-14L BKM-14L BKM-14L BKM-14L BKM-14L BKM-14L BKM-14L N/A N/A BKM-14L BKM-14L N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Minolta/Philips/ Minolta/Philips/ Minolta/Philips/ Minolta/Philips/ Minolta/Philips/ Minolta/Philips/ Minolta/Philips/ Minolta/Philips/ Minolta/Philips/ Minolta/Philips/ Minolta/Philips/
Thoma/Graseby Thoma/Graseby Thoma/Graseby Thoma/Graseby Thoma/Graseby Thoma/Graseby Thoma/Graseby Thoma/Graseby Thoma/Graseby Thoma/Graseby Thoma/Graseby
Computer input N/A N/A SXGA N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A VGA ~ SXGA VGA ~ SXGA VGA ~ SXGA VGA ~ SXGA VGA ~ SXGA
Composite video input 6x(BKM-25P/BKM-27T) 6x(BKM-25P/BKM-27T) N/A 6x(BKM-25P/BKM-27T) 2x(BKM-127W) 2x(BKM-127W) 2x(BKM-127W) 2x(BKM-127W) 6x(BKM-25P/BKM-27T) 6x(BKM-25P/BKM-27T) 6x(BKM-25P/BKM-27T) 2x 2x 2x 2x 2x 2x 2x 2x 2x 1x 2x 2x 2x 2x 4x1 3x1 2x1 1x 1x 1x 1x 1x 1x
Component/RGB input 1x 1x 1xRGB 1x 1x 1x 1x 1x 1x 1x 1x 1x 1x N/A 1x 1x 1x N/A 1x(BKM-129X) 1x(BKM-129X) N/A N/A N/A N/A N/A N/A N/A N/A N/A 1x 1x 1x 1x 1x
Y/C video input 3x(BKM-25P/BKM-27T) 3x(BKM-25P/BKM-27T) N/A 3x(BKM-25P/BKM-27T) 1x(BKM-127W) 1x(BKM-127W) 1x(BKM-127W) 1x(BKM-127W) 3x(BKM-25P/BKM-27T) 3x(BKM-25P/BKM-27T) 3x(BKM-25P/BKM-27T) 1x 1x 1x 1x 1x 1x 1x 1x 1x 1x N/A N/A N/A N/A N/A N/A N/A 1x 1x 1x 1x 1x 1x
HD-SDI video input 1x(BKM-41HD) 1x(BKM-41HD) 2x 1x(BKM-41HD) 2x(BKM-142HD) 2x(BKM-142HD) 2x(BKM-142HD) 2x(BKM-142HD) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 2x(BKM-243HS) 2x(BKM-243HS) 2x(BKM-243HS) 2x(BKM-243HS) 2x(BKM-243HS)
2x(BKM-42HD) 2x(BKM-42HD) 2x(BKM-42HD)
SDI video input 3x(BKM-20D/BKM-21D) 3x(BKM-20D/BKM-21D) N/A 3x(BKM-20D/BKM-21D) 2x(BKM-120D) 2x(BKM-120D) 2x(BKM-120D) 2x(BKM-120D) 3x(BKM-20D/BKM-21D) 3x(BKM-20D/BKM-21D) 3x(BKM-20D/BKM-21D) 2x(BKM-120D) 2x(BKM-120D) N/A 2x(BKM-120D) 2x(BKM-120D) 2x(BKM-120D) N/A 2x(BKM-120D) 2x(BKM-120D) N/A N/A N/A N/A N/A 4x(4xBKM-320D) 3x(3xBKM-320D) 2x(2xBKM-320D) N/A 2x(BKM-220D) 2x(BKM-220D) 2x(BKM-220D) 2x(BKM-220D) 2x(BKM-220D)
SDI/SDTI-CP video/ N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 2x(BKM-150CP) 2x(BKM-150CP) N/A 2x(BKM-150CP) 2x(BKM-150CP) 2x(BKM-150CP) N/A 2x(BKM-150CP) 2x(BKM-150CP) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
audio input
i.LINK video input N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 2x(BKM-255DV) 2x(BKM-255DV) 2x(BKM-255DV) 2x(BKM-255DV) 2x(BKM-255DV)
External Sync Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes N/A Yes Yes Yes N/A Yes Yes N/A Yes Yes Yes Yes N/A N/A N/A N/A Yes Yes Yes Yes Yes
Built-in speaker N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes N/A N/A N/A Yes Yes Yes Yes Yes Yes
Underscan Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes N/A Yes Yes Yes N/A Yes Yes N/A N/A Yes N/A Yes N/A N/A N/A N/A Yes Yes Yes Yes Yes
Blue only Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes N/A Yes Yes Yes N/A Yes Yes N/A N/A Yes N/A Yes N/A N/A N/A N/A Yes Yes Yes Yes Yes
H/V delay Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes N/A N/A Yes Yes N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A Yes Yes Yes Yes Yes
Tally lamp Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes N/A Yes Yes Yes N/A Yes Yes N/A N/A Yes N/A Yes Yes Yes Yes Yes (MB-506) Yes Yes Yes Yes Yes
Remote control Serial/parallel Serial/parallel Serial/parallel Serial/parallel Serial/parallel Serial/parallel Serial/parallel Serial/parallel Serial/parallel Serial/parallel Serial/parallel Serial/parallel Parallel Parallel Serial/parallel Serial/parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel Parallel
Rack mount N/A N/A N/A BKM-30E20 BKM-31E14 BKM-30E14 MB-520 MB-520 BKM-30E20 BKM-31E14 BKM-30E14 SLR-104 SLR-103C SLR-103C MB-521 MB-521 MB-502C/SLR-102 MB-502C/SLR-102 MB-520 MB-520 MB-520 MB-502C/SLR-102 MB-502C/SLR-102 MB-520 MB-520 Yes Yes Yes MB-506 MB-524 MB-522A MB-523 N/A N/A
Power requirements AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V AC 100 to 240V DC 12V, AC 100 to 240V DC 12V, AC 100 DC 16.5V, AC 100 DC 12V, AC 100 AC 100 to 240V
(50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) (50/60Hz) AC Power adaptor (50/60Hz) to 240V (50/60Hz) to 240 V (50/60Hz) to 240V (50/60Hz) (50/60Hz)
Power consumption 180W (235W max) 155W (205W max) 220W 150W (210W max) 100W (115W max) 100W (115W max) 60W (85W max) 60W (85W max) 200W max 145W max 175W 115W (125W max) 98W (108W max) 75W 90W (100W max) 90W (100W max) 75W (85W max) 68W AC: 47W (58W max) AC: 47W (58W max) 40W 25W 25W 23W 23W 18W (26W max) 22W (28W max) 22W (26W max) 12W 35W (LMD) 42W (LMD) 70 W (LMD) 62W (LMD) 150 W (LMD)
DC: 38W (48W Max) DC: 38W (48W Max) 23W (MEU) 23W (MEU) 23W (MEU) 23W (MEU) 23W (MEU)
Li-Ion battery operation N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A Yes Yes N/A N/A N/A N/A N/A N/A N/A N/A Yes N/A N/A N/A N/A N/A
Dimensions (W/H/D) mm 794 x 556.5 x 694 565.5 x 436.8 x 587.3 565.5 x 436.8 x 609.3 444 x 414 x 570 346 x 280 x 519 482 x 280 x 562 217 x 174 x 364.5 218 x 217 x 379.5 444 x 414 x 570 346 x 280 x 530 482 x 280 x 530 452 x 414 x 500 453 x 463 x 529 449 x 441 x 502 346 x 280 x 424 346 x 280 x 424 346 x 340 x 430 346 x 340 x 414 217 x 218 x 373 217 x 218 x 373 217 x 218 x 350 346 x 340 x 330 346 x 340 x 330 217 x 218 x 250 217 x 218 x 250 483 x 88.1 x 47 483 x 131 x 47 483 x 131 x 47 217 x 135 x 55 379 x 297 x 71 434 x 294 x 67 (LMD) 515 x 409 x 77 563 x 372 x 78 (LMD) 790 x 512 x 94 (LMD)
434 x 44 x 305 (MEU) 434 x 44 x 305 (MEU) 434 x 44 x 305 (MEU) 434 x 44 x 305 (MEU)
Mass approx 94 kg approx 51 kg approx 54 kg approx 38 kg approx 21 kg approx 23 kg approx 8.5 kg approx 9.5 kg approx 37 kg approx 23 kg approx 26 kg approx 31 kg approx 33 kg approx 28 kg approx 17 kg approx 17 kg approx 18 kg approx 15 kg approx 8 kg approx 8 kg approx 6.3 kg approx 11 kg approx 11 kg approx 5.5 kg approx 5.5 kg 1.9 kg 2.3kg 2.3kg approx 1 kg 5kg approx 4.9 kg (LMD) approx. 7 Kg approx 6.6 kg (LMD) approx 25 kg (LMD)
approx 4.5 kg (MEU) approx 4.5 kg (MEU) approx 4.5 kg (MEU) approx 4.5 kg (MEU)
Height N/A N/A N/A 9U 6U 6U 4U 5U 9U 6U 6U 9U 10U 10U 6U 6U 8U 8U 5U 5U 5U 8U 8U 5U 5U 2U 3U 3U 4U with MB-506 7U with MB-524 7U with MB-522A 10U with MB-523 N/A N/A
Page 4
2 Years Support
The Silver Support Pack extends the support period from
the standard 1-year warranty to two years. Not only that,
but extra features and services are also included.
Operational Phone Call Centre
Operational phone support is provided to give advice
and help so that the user can get the most out of their
equipment and maximise its performance. Our telephone
support is available from Monday to Friday and in 5 languages: English, French, German, Italian and Spanish.
Collection Anywhere
In the event of equipment failure, Sony will arrange
collection of the faulty unit directly from, and delivery
of the repaired unit directly to the customer’s location anywhere in mainland EU, Norway or Switzerland. That
makes it simpler, quicker and even more convenient for
the customer.
Repair within 7 days
Sony will collect, repair and return the unit to the
customer’s preferred location within 7 working days. So,
minimum downtime, increased confidence and the ability
to plan your business are guaranteed.
Loan
If the faulty equipment cannot be repaired in time, the
hotline will contact the customer and arrange to have a
loan unit delivered. Arrangements will be made to collect
the loan unit as soon as confirmation is received that the
repair has been carried out satisfactorily.
5 additional reasons to choose PVM Series and LMD Series
Page 5
© 2004 Sony Corporation. Sony is a registered trademark of the Sony
Corporation, Japan. Sony Trinitron and HR Trinitron are trademarks of
Sony Corporation. Features and specifications are subject to change
without notice.
CA Monitor Pocket Guide/GB- / /2004
SONY EUROPE
www.sonybiz.net
Loading...
